Toshiba MD20Q42, MD13Q42 User Manual

DIGITAL VIDEO

Introduction

2

COMBINATION COLOR
TELEVISION AND DVD
VIDEO PLAYER

MD13Q42
MD20Q42

OWNER’S MANUAL

Connections

Basic setup

TV operation

Basic playback

Advanced playback

Function setup

Others

13

18

20

27

30

38

43

Illustration of MD20Q42

©2006 Toshiba Corporation
Before operating the unit, please read this manual thoroughly.

5X30401A [E] (Cover) 12/3/05, 3:29 PM1

Introduction

IMPORTANT SAFEGUARDS IM

Dear Customer,

Thank you for purchasing this Toshiba TV. This manual will
help you use the many exciting features of your new TV.

Before operating the TV, please read this manual
completely, and keep it nearby for future reference.

Safety Precautions

WARNING

TO REDUCE THE R ISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS APPLIANCE TO
RAIN OR MOISTURE.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION:

The lightning symbol in the triangle tells you that the
voltage inside this product may be strong enough to
cause an electric shock. DO NOT TRY TO SERVICE
THIS PRODUCT YOURSELF.

The exclamation mark in the triangle tells you that
important operating and maintenance instructions
follow this symbol.

CAUTION: To reduce the risk of electric shock, do
not use the polarized plug with an extension
cord, receptacle, or other outlet unless the
blades can be inserted completely to prevent
blade exposure.

TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER
(OR BACK). NO USER-SERVICEABLE
PAR TS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.

NOTE TO CATV INSTALLERS

This is a reminder to call the CATV system installer’s
attention to Article 820-40 of the NEC, which provides
guidelines for proper grounding and, in particular,
specifies that the cable ground shall be connected to the
grounding system of the building, as close to the point of
cable entry as practical. For additional antenna
grounding information, see items 25 and 26 on page 4.

NOTICE OF POSSIBLE ADVERSE

EFFECTS ON TV PICTURE DISPLAY

If a fixed (non-moving) pattern or image remains on
the TV screen for extended periods of time, the
image can become permanently ingrained in the
cathode ray tube(s) of the TV and cause subtle but
permanent ghost images. This type of damage is
NOT COVERED BY YOUR WARRANTY. (See item
33 on page 4 for details.)

2

Child Safety

It Makes A Difference
Where Your TV Stands

Congratulations on your purchase! As you enjoy
your new TV, keep these safety tips in mind:

The Issue

 If you are like most consumers, you have a TV in your

home. Many homes, in fact, have more than one TV.

 The home theater entertainment experience is a growing

trend, and larger TVs are popular purchases; however,
they are not always supported on the proper TV stands.

 Sometimes TVs are improperly secured or

inappropriately situated on dressers, bookcases, shelves,
desks, audio speakers, chests, or carts. As a result, TVs

may fall over, causing unnecessary injury.

Toshiba Cares!

 The consumer electronics industry

is committed to making home

entertainment enjoyable and safe.

 The Consumer Electronics

Association formed the Home

Entertainment Support Safety
Committee, comprised of TV and
consumer electronics furniture
manufacturers, to advocate

children’s safety and educate

consumers and their families about

television safety.

Tune Into Safety

 One size does NOT fit all! Use appropriate
furniture large enough to support the weight of your
TV (and other electronic components).

 Use appropriate angle braces, straps, and anchors to

secure your furniture to the wall (but never screw
anything directly into the TV).

 Carefully read and understand the other enclosed

instructions for proper use of this product.

 Do not allow children to climb on or play with

furniture and TVs.

 Avoid placing any item on top of your TV (such as a

VCR, remote control, or toy) that a curious child may
reach for.

 Remember that children can become excited while

watching a program and can potentially push or pull
a TV over.

 Share our safety message about this hidden hazard

of the home with your family and friends. Thank you!

2500 Wilson Blvd.
Arlington, VA 22201 U.S.A.
Tel. [phone] Fax [phone]
www.CE.org

CEA is the Sponsor, Producer and

Manager of the International CES

0303

®

5X30401A [E] (P02-05) 12/3/05, 3:29 PM2

IMPORTANT SAFEGUARDS

QUALIFIED

SERVICE

TECHNICIAN

Important Safety Instructions

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near

water.

6) Clean only with a dry cloth.

7) Do not block any ventilation
openings. Install in accordance with
the manufacturer’s instructions.

8) Do not install near any heat
sources such as radiators, heat
registers, stoves, or other apparatus
(including amplifiers) that produce heat.

9) Do not defeat the safety purpose of the polarized
or grounding type plug. A polarized plug has two
blades with one wider than the other. A grounding
type plug has two blades and a third grounding
prong. The wide blade or the third
prong are provided for your safety.
If the provided plug does not fit into
your outlet, consult an electrician
for replacement of the obsolete outlet.

10) Protect the power cord from being

walked on or pinched, particularly at
plugs, convenience receptacles, and
the point where it exits the apparatus.

Wide plug

Installation, Care and Service

Installation

Follow these recommendations and precautions and heed
all warnings when installing your TV:

16) Never modify this equipment. Changes or
modifications may void: a) the warranty, and b) the
user’s authority to operate this equipment under the
rules of the Federal Communications Commission.

17) DAN GER: R ISK OF S ERIO US PERSONAL

an unstable cart, stand, or table. The TV
may fall, causing serious personal injury,
death, or serious damage to the TV.

18) Never place or store the TV in direct
sunlight; hot, humid areas; areas
subject to excessive dust or vibration;
or locations with temperatures at or
below 41°F (5°C).

19) Always place the TV on the floor
or a sturdy, level, stable surface that
can support the weight of the unit.

20)

Never place items such as vases,
aquariums, or candles on top of the TV.

INJURY, DEATH, OR EQU IPM ENT
DAMAGE! Never place the TV on

Introduction

11) Only use attachments/accessories specified by
the manufacturer.

12) Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the
apparatus. When a cart is used, use

caution when moving the cart/apparatus
combination to avoid injury from tip-over.

13) Unplug this apparatus during

lightning storms or when unused
for long periods of time.

14) Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has
been damaged in any way, such as
power supply cord or plug is damaged,
liquid has been spilled or objects have
fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does
not operate normally, or has been dropped.

15) CAUTION: To reduce the risk of electric

shock, do not use the polarized plug
with an extension cord, receptacle, or other
outlet unless the blades can be inserted

completely to prevent blade exposure.

21) Never block or cover the slots or
openings in the TV cabinet back,
bottom and sides. Never place
the TV:

• on a bed, sofa, rug, or similar

surface;

• too close to drapes, curtains,

or walls; or

• in a confined space such as a

bookcase, built-in cabinet, or any
other place with poor ventilation.

The slots and openings are provided
to protect the TV from overheating
and to help maintain reliable
operation of the TV.

22) Never allow anything to rest on or roll over the power
cord, and never place the TV where the power cord is
subject to wear or abuse.

23) Never overload wall outlets and
extension cords.

0303

3

5X30401A [E] (P02-05) 12/3/05, 3:29 PM3

Introduction

Ground clamp

Antenna discharge unit
(NEC Section 810-20)

Grounding conductors
(NEC Section 810-21)

Power service grounding
electrode system (NEC Art 250 Part H)

Ground clamps

Antenna lead-in wire

Electric service equipment

QUALIFIED

SERVICE

TECHNICIAN

IMPORTANT SAFEGUARDS S

30) [This item applies to projection TVs only.] If the air

24) Always operate this equipment from
a 120V AC, 60 Hz power source only.

temperature rises suddenly (for example, when the TV
is first delivered), condensation may form on the
lenses. This can make the picture appear distorted or
the color appear faded. If this happens, turn off the TV
for 6 to 7 hours to allow the condensation to evaporate.

25) Always make sure the antenna system is properly
grounded to provide adequate protection against
voltage surges and built-up static charges (see Section
810 of the National Electric Code).

26) DANGER: RISK OF SERIOUS

PERSONAL I NJURY OR DEATH!

• Use extreme care to make sure you are

never in a position where your body (or any item you
are in contact with, such as a ladder or screwdriver)
can accidentally touch overhead power lines. Never
locate the antenna near overhead power lines or other
electrical circuits.

• Never attempt to install any of the following during
lightning activity:
a) an antenna system; or b) cables, wires, or any home
theater component connected to an antenna or phone
system.

Care

For better performance and safer operation of your
TOSHIBA TV, follow these recommendations and
precautions:

27) Always sit approximately 10–25 feet away from the TV
and as directly in front of it as possible. The picture can
appear dull if you sit too far to the left or right of the
TV, or if sunlight or room lights reflect on the screen.
Turn the T V off to check for reflections on the screen,
and then remove the source of reflections while
viewing the TV.

31)For added protection of your TV from lightning and
power surges, always unplug the power cord and
disconnect the antenna from the TV if you leave the TV
unattended or unused for long periods of time.

32) During normal use, the TV may make
occasional snapping or popping
sounds. This is normal, especially
when the unit is being turned on or
off. If these sounds become frequent
or continuous, unplug the power cord
and contact a Toshiba Authorized Service Center.

33) Possible Adverse Effects on TV Picture Display: If
a fixed (non-moving) pattern or image remains on the
TV screen for extended periods of time, the image can
become permanently ingrained in the cathode ray
tube(s) of the TV and cause subtle but permanent
ghost images. This type of damage is NOT
COVERED BY YOUR WARRANTY. Never leave the
TV on for extended periods of time while it
is displaying the following images or formats:

• Fixed Images, including but not limited to PIP/POP

windows, closed captions, video game patterns, TV
station logos, stock tickers, and websites.

• Special Formats that do not use the entire screen,

including but not limited to widescreen or letterbox
format media viewed on a 4:3 aspect ratio display
(with gray or black bars at the top and bottom of the
screen); or 4:3 aspect ratio format media viewed on a
widescreen/16:9 aspect ratio display (with gray or
black bars on the left and right sides of the screen).

Service

34) WAR NI NG: RISK O F ELECTRIC

SHOCK! Never attempt to service the

TV yourself. Opening and
removing the covers may expose
you to dangerous voltage or other
hazards. Refer all servicing to a
Toshiba Authorized Service Center.

28) Always unplug the TV before
cleaning. Never use liquid or
aerosol cleaners.

29) WARNING: RISK OF ELE CTRIC SHOC K!

Never spill liquids or push objects of any
kind into the TV cabinet slots.

4

5X30401A [E] (P02-05) 12/3/05, 3:29 PM4

35) If you have the TV serviced:

• Ask the service technician to use only replacement

parts specified by the manufacturer.

•

Upon completion of service, ask
the service technician to perform
routine safety checks to determine
that the TV is in safe operating
condition.

36)When the TV reaches the end of its useful life, ask a
qualified service technician to properly dispose of the
TV. Improper disposal may result in a picture tube

0303

implosion and possible personal injury.

SAFETY PRECAUTION/ Power source

WARNING: This equipment has been tested and found to comply with the limits for a Class B digital device,

CAUTION: Changes or modifications not expressly approved by the party responsible for compliance with the

CAUTION:

THIS DIGITAL VIDEO PLAYER EMPLOYS A LASER SYSTEM.

TO ENSURE PROPER USE OF THIS PRODUCT, PLEASE READ
THIS OWNER'S MANUAL CAREFULLY AND RETAIN FOR FU­TURE REFERENCE. SHOULD THE UNIT REQUIRE MAINTE­NANCE, CONTACT AN AUTHORIZED SERVICE LOCATION.

USE OF CONTROLS, ADJUSTMENTS OR THE PERFORMANCE
OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN
MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the distance between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.

- Consult the dealer or an experienced radio/TV technician for help.

FCC (Federal Communications Commission) Rules could void the user's authority to operate this
equipment.

Location of the required Marking

The rating sheet and the safety caution
are on the rear of the unit.

Introduction

TO PREVENT DIRECT EXPOSURE TO LASER BEAM, DO NOT
TRY TO OPEN THE ENCLOSURE. VISIBLE LASER RADIATION
MAY BE PRESENT WHEN THE ENCLOSURE IS OPENED. DO
NOT STARE INTO BEAM.

WARNING: This product contains a laser beam. Do not attempt to stare at the beam through the DVD disc tray

or the ventilation openings. Staring directly at the beam may cause permanent damage to your
eyesight.

CERTIFICATION: COMPLIES WITH
FDA RADIATION PERFORMANCE
STANDARDS, 21 CFR SUBCHAPTER J.

IMPORTANT RECYCLING INFORMATION

This product uses both Cathode Ray Tube (CRT) and other components that contain lead. In your
community there might be regulations that require you to dispose these materials properly under
environmental considerations. Please contact your local authorities, or the Electronic Industries
Alliance (http://www.eiae.org) for disposal or recycling information.

Power source

AC Outlet

Wider Hole
and Blade

Polarized AC Cord Plug
(One blade is wider than the other.)

TO USE AC POWER SOURCE

Use the AC polarized line cord provided for operation on AC. Insert the AC
cord plug into a standard 120V 60Hz polarized AC outlet.

Notes:

•Nev er connect the AC line cord plug to other than the specified voltage (120V
60Hz). Use the attached power cord only.

• If the polarized AC cord does not fit into a non-polarized AC outlet, do not
attempt to file or cut the blade. It is the user’s responsibility to have an
electrician replace the obsolete outlet.

• If you cause a static discharge when touching the unit and the unit fails to
function, simply unplug the unit from the AC outlet and plug it back in. The
unit should return to normal operation.

• If the AC cord plug is plugged in for the first time, wait for approx. 5 seconds
before pressing the POWER button.

5X30401A [E] (P02-05) 12/3/05, 3:29 PM5

5

Introduction

Precautions

Notes on handling

3 When shipping the unit, the original shipping carton

and packing materials come in handy. For fully
protection, repack the unit as it was originally packed
at the factory.

3 Do not use volatile liquids, such as insect spray, near

the unit. Do not leave rubber or plastic products to
contact the unit for prolonged period. They will leave
marks on the finish.

3 The top and rear panels of the unit may become

warm after a long period of use. This is not a
malfunction.

3 When the unit is not in use, be sure to remove the

disc and turn off the power.

3 If you do not use the unit for a long period, the unit

may not function properly in the future. Turn on and
use the unit occasionally.

Notes on locating

3 Place the unit on a level surface. Do not use it on a

shaky or unstable surface such as a wobbling table or
inclined stand. The loaded disc may become
disaligned and damage the unit.

3 When you place this unit near a TV, radio, or VCR,

the playback picture may become poor and the sound
may be distorted. In this case, place the unit away
from the TV, radio, or VCR.

Notes on moisture condensation

Moisture condensation damages the unit. Please
read the following carefully.

Moisture condensation occurs, for example, when you
pour a cold drink into a glass on a warm day. Drops of
water form on the outside of the glass. In the same way,
moisture may condense on the optical pick-up lens
inside this unit, one of the most crucial internal parts of
the unit.



3 Moisture condensation occurs during the

following cases.

When you bring the unit directly from a cold place to
a warm place.

When you use the unit in a room where you just
turned on the heater, or a place where the cold wind

from the air conditioner directly hits the unit.
In summer, when you use the unit in a hot and humid

place just after you move the unit from an air
conditioned room.
When you use the unit in a humid place.



























































 



Notes on cleaning

Use a soft, dry cloth for cleaning.

Use a dry cloth to wipe it dry.
Do not use any type of solvent, such as thinner and

benzine, as they may damage the surface of the unit.
If you use a chemical saturated cloth to clean the unit,
follow that product’s instructions.

6

3 Do not use the unit when moisture condensation

may occur.

If you use the unit in such a situation, it may damage
discs and internal parts. Remove the disc, connect
the power cord of the unit to the wall outlet, turn on
the unit, and leave it for two or three hours. After two
or three hours, the unit will have warmed up and
evaporated any moisture. Keep the unit connected to
the wall outlet and moisture condensation will seldom
occur.

Wait!

Wall outlet

5X30401A [E] (P06-07) 12/3/05, 3:29 PM6

Notes on discs

On handling discs

Do not touch the playback side of the disc.

Playback side

Do not attach paper or tape to discs.

On cleaning discs

Fingerprints and dust on the disc cause picture and
sound deterioration. Wipe the disc from the center
outwards with a soft cloth. Always keep the disc
clean.

Structure of disc contents

Normally, DVD video discs are divided into titles, and
the titles are sub-divided into chapters. Video CDs and
Audio CDs are divided into tracks.

DVD video disc

DVD video disc

Title 1 Title 2

Chapter 1 Chapter 2 Chapter 1 Chapter 2 Chapter 3

Video CD/Audio CD

Video CD/Audio CD

Tr a c k 1 Track 2 Track 3 Track 4 Track 5

Each title, chapter or track is assigned a number, which
is called “title number”, “chapter number” or “track
number” respectively.
There may be discs that do not have these numbers.

Introduction

Do not use any type of solvent such as thinner,
benzine, commercially available cleaners or antistatic
spray for vinyl LPs. It may damage the disc.

On storing discs

Do not store discs in a place subject to direct sunlight
or near heat sources.
Do not store discs in places subject to moisture and
dust such as a bathroom or near a humidifier.
Store discs vertically in a case. Stacking or placing
objects on discs outside of their case may cause
warping.

Notes on copyright

The unauthorized recording, use, distribution, or
revision of copyrighted materials including, without
limitation, television programs, videotapes, and DVDs,
is prohibited under the Copyright Laws of the United
States and other countries, and may subject you to civil
and criminal liability.

This product incorporates copyright protection
technology that is protected by U.S. patents and other
intellectual property rights. Use of this copyright
protection technology must be authorized by
Macrovision, and is intended for home and other limited
viewing uses only unless otherwise authorized by
Macrovision. Reverse engineering or disassembly is
prohibited.

5X30401A [E] (P06-07) 12/3/05, 3:29 PM7

7

Introduction

Notes on discs (Continued)

About this owner’s manual

This owner’s manual explains the basic instructions of
this unit. Some DVD video discs are produced in a
manner that allows specific or limited operation during
playback. As such, the unit may not respond to all
operating command. This is not a defect in the unit.
Refer to instruction notes of discs.

” may appear on the TV screen during operation.

“

” means that the operation is not permitted by the

A “
unit or the disc.
For example, sometimes it is unable to stop the playback
of copyright message of the disc when the STOP (3)
button is pressed. Alternatively, the “

” may also

indicate that the feature is not available for the disc.

Notes on region numbers

The region number of this unit is 1. If region numbers,
which stand for their playable area, are printed on your

ALL

1

or

DVD video disc and you do not find

, disc
playback will not be allowed by the player. (In this case,
the unit will display a message on-screen.)

On Video CDs

This DVD supports Video CDs equipped with the PBC
(Version 2.0) function. (PBC is the abbreviation of
Playback Control.) You can enjoy two playback
variations depending on types of discs.

• Video CD not equipped with PBC function

(Version 1.1)

Sound and movie can be played on this DVD in the
same way as an audio CD.

• Video CD equipped with PBC function

(Version 2.0)

In addition to operation of a Video CD not equipped
with the PBC function, you can enjoy playback of
interactive software with search function by using the
menu displayed on the TV screen (Menu Playback).
Some of the functions described in this owner’s
manual may not work with some discs.

8

Playable discs

This unit can play the following discs.

Disc Mark

DVD
video
discs

Video
CDs

Audio
CDs

The following discs are also available.

Some of these discs may be incompatible.

DIGITAL VIDEO

DVD-R/RW discs of DVD video format
CD-R/CD-RW discs of CD-DA, Video CD or JPEG

format
FUJICOLOR CD format

Contents

Audio

Video

(moving

pictures)

Audio

Video

(moving

pictures)

Audio

Disc
Size

12 cm

+

8 cm

12 cm

+

8 cm

12 cm

8 cm

•You cannot play discs other than those listed above.

•You cannot play discs of DVD-RAM, DVD-ROM,
Photo CD, etc., or non standardized discs even if they
may be labeled as above.

• Some CD-R/RWs cannot be played back depending
on the recording conditions.

• This unit uses the NTSC color system, and cannot
play DVD video discs recorded in any other color
system (PAL, SECAM, etc.).

Because of problems and errors that can occur during the
creation of DVD and CD software and/or the manufacture
of DVD and CD discs, Toshiba cannot guarantee that the
DVD player contained in this TV will play every feature of
every DVD bearing the DVD logo and/or every CD bearing
the CD logo. As one of the creators of DVD technology,
Toshiba DVD players are manufactured using the highest
standards of quality, and as a result, such incompatibilities
are rare. If you happen to experience any difficulty playing
a DVD or a CD on the DVD player contained in this TV,
please feel free to contact us via the method listed in the

“How to Obtain Warranty Services” section on page

is a trademark of DVD Format/Logo Licensing Corporation.

Maximum

playback time

Approx. 4 hours

(single sided disc)

Approx. 8 hours

(double sided disc)

Approx. 80 minutes

(single sided disc)

Approx. 160 minutes

(double sided disc)

Approx. 74 minutes

(single sided disc)

Approx. 20 minutes

(single sided disc)

Approx. 74 minutes

(single sided disc)

Approx. 20 minutes

(single sided disc)

49

.

5X30401A [E] (P08-12) 12/3/05, 3:29 PM8

Contents

Introduction

IMPORTANT SAFEGUARDS ............................ 2

SAFETY PRECAUTION.................................... 5

Precautions ....................................................... 6

Notes on discs................................................... 7

Contents ............................................................ 9

Identification of controls .................................. 10

Connections

Antenna connections....................................... 13

Cable TV connections .....................................14

Connecting to optional equipment................... 15

Basic setup

Starting setup ..................................................18

Setting the language .......................................19

TV operation

TV operation.................................................... 20

Closed captions............................................... 22

To memorize channels .................................... 23

Setting the V-Chip ........................................... 24

Picture control adjustment............................... 26

Adjusting the picture preference ..................... 26

Basic playback

Playing a disc ..................................................27

Advanced playback

Zooming ......................................................... 30

Locating desired scene .................................. 30

Marking desired scenes ................................. 31

Repeat playback............................................. 32

A-B Repeat playback ...................................... 32

Program playback .......................................... 33

Random playback........................................... 33

Changing angles ............................................ 34

Title selection ................................................. 34

DVD menu...................................................... 34

Changing soundtrack language ..................... 35

Subtitles ......................................................... 35

Disc status...................................................... 36

To turn off the PBC ........................................ 36

JPEG playback............................................... 37

Function setup

Customizing the function settings .................. 38

Temporary cancel the rating level

by DVD disc ................................................... 42

Others

Language code list ......................................... 43

Troubleshooting ............................................. 44

Reception disturbances.................................. 46

Specifications ................................................. 47

Limited warranty ............................................. 48

Introduction

5X30401A [E] (P08-12) 12/3/05, 3:29 PM9

9

Introduction

Identification of controls

See the page in for details.

Front

Illustration of MD20Q42

POWER indicator

POWER button

18

20

Disc tray

AUDIO (L/R)/VIDEO IN jacks (LINE)

STOP ( ) button

27

27

15

Rear

Illustration of MD20Q42

AC power cord

Remote sensor

OPEN/CLOSE ( ) button

12

VOLUME ( / ) buttons

COAXIAL DIGITAL AUDIO OUT jack

27

SKIP ( / ) buttons

PLAY ( ) button

CHANNEL ( / ) buttons

20

27

21

16

29

PHONES jack

21

10

5X30401A [E] (P08-12) 12/3/05, 3:29 PM10

RF IN jack

13

Remote control

The instructions in this manual describe the function on the remote control. See the page in for details.

Introduction

OPEN/CLOSE button

TV/DVD button

Direct channel
selection buttons (0-9)

Number buttons (0-9)

DISPLAY button

CH / buttons

SUBTITLE button

PLAY MODE button

Direction buttons

CH RTN button

SKIP button

TOP MENU button

27

27

20
30

21

21

35

INPUT button
ZOOM button

()

///

MENU button

SETUP button

PLAY button

PAUSE button

REV button

ANGLE button

15
30

32

19
19

38

27
28
21

29
29
34

34

POWER button

SLEEP button

JUMP button

-

VOL +/

AUDIO SELECT button

MUTE button

DVD MENU button

ENTER button

CANCEL button

STOP button

CLOSED CAPTION button
SKIP
FF button

SLOW button

MARKER button

30

buttons

21

27

button

29

18

21

20

34

18

18

29

29

31

35

22

*DVD MENU button

Use the DVD MENU button to
display the menu included on
many DVD video discs.
To operate a menu, follow the

instructions in “DVD menu.”

5X30401A [E] (P08-12) 12/3/05, 3:29 PM11

GAME button

REPEAT A
RETURN button

34

15

-

B button

32

38

11

Introduction

Identification of controls (Continued)

Inserting batteries

Open the battery compart-

12 3

ment cover in the direction of
the arrow.

Install two “R03/AAA” batter­ies (supplied), paying attention
to the polarity diagram in the
battery compartment.

Replace the compartment
cover.

Operation

• Aim the remote control at the remote sensor and press control buttons to operate.

• Operate the remote control within 30° angle on either side of the remote sensor, up to a distance of approx. 5
meters.

Illustration of MD20Q42

Approx. 5 meters

Caution:

Never throw batteries into a fire.

Notes:

• Be sure to use AAA size batteries.

• Dispose of batteries in a designated disposal area.

• Batteries should always be disposed of with the environment in mind. Always dispose of batteries in accord-

ance with applicable laws and regulations.

• If the remote control does not operate correctly, or if the operating range becomes reduced, replace batteries

with new ones.

• When necessary to replace batteries in the remote control, always replace both batteries with new ones.

• Never mix battery types or use new and used batteries in combination.

• Always remove batteries from remote control if they are dead or if the remote control is not to be used for an

extended period of time. This will prevent battery acid from leaking into the battery compartment.

12

5X30401A [E] (P08-12) 12/3/05, 3:29 PM12

Connections

Antenna connections

If you are using an indoor or outdoor antenna, follow the instructions below that correspond to your antenna system. If
you are using a cable TV service (CABLE), see page 14 for Cable TV connections.

Combination VHF/UHF antenna (Single 75 ohm cable or 300 ohm twin-lead wire)

Antenna

jack

Antenna

jack

Connect the 75 ohm cable from the combination
VHF/UHF antenna to the antenna jack.

If your combination VHF/UHF antenna has a 300
ohm twin-lead wire, the use of the 300-75 ohm

75 ohm coaxial cable
(not supplied)

300-75 ohm matching
transformer (supplied)

matching transformer may be necessary.

Combination VHF/UHF antenna (Separate VHF and UHF 300 ohm twin-lead wires)

Antenna

jack

Combiner
(not supplied)

300-75 ohm matching
transformer (supplied)

Connect the UHF 300 ohm twin-lead wire to the
combiner (not supplied). Connect the VHF 300
ohm twin-lead wire to the 300-75 ohm matching
transformer. Attach the transformer to the combiner,
then attach the combiner to the antenna jack.

Connections

UHF 300 ohm
twin-lead wire
(not supplied)

VHF 300 ohm
twin-lead wire
(not supplied)

Separate VHF/UHF antennas (75 ohm VHF cable and 300 ohm UHF twin-lead wires)

Antenna

jack

VHF 75 ohm
(not supplied)

Combiner
(not supplied)

UHF 300 ohm
twin-lead wire
(not supplied)

5X30401A [E] (P13-23) 12/3/05, 3:29 PM13

Connect the VHF 75 ohm cable and UHF 300 ohm
twin-lead wire to the combiner (not supplied).
Attach the combiner to the antenna jack.

13

Connections

Cable TV connections

This TV/DVD has an extended tuning range and can tune most cable channels without using a Cable TV converter box.
Some cable companies offer “premium pay channels” in which the signal is scrambled. Descrambling these signals for
normal viewing requires the use of a descrambler device which is generally provided by the cable company.

For subscribers to basic cable TV service

Antenna

jack

75 ohm
coaxial cable

For basic cable service not requiring a converter/descrambler
box, connect the Cable TV 75 ohm coaxial cable directly to the
Antenna jack on the back of the TV/DVD.

For subscribers to scrambled cable TV service

If you subscribe to a cable TV service which requires the use of a converter/descrambler box, connect the
incoming 75 ohm coaxial cable to the converter/descrambler box. Using another 75 ohm coaxial cable, connect
the output jack of the converter/descrambler box to the antenna jack on the TV/DVD. Follow the connections
shown below. Set the TV/DVD to the output channel of the converter/descrambler box (usually channel 3 or 4)
and use the converter/descrambler box to select channels.

Incoming
75 ohm
Cable TV

Converter/

descrambler

75 ohm cable
to TV/DVD

Antenna

jack

For subscribers to unscrambled basic cable TV service with scrambled
premium channels

If you subscribe to a cable TV service in which basic channels are unscrambled and premium channels require the
use of a converter/descrambler box, you may wish to use a signal splitter and an A/B Switch box (available from the
cable company or an electronics supply store). Follow the connections shown below. With the switch in the “B”
position, you can directly tune any nonscrambled channels on your TV/DVD. With the switch in the “A” position, tune
your TV/DVD to the output of the converter/descrambler box (usually channel 3 or 4) and use the converter/
descrambler box to tune scrambled channels.

Incoming
75 ohm
Cable TV

Splitter

Converter/

descrambler

A/B switch

75 ohm cable

A

to TV/DVD

B

Antenna

jack

14

5X30401A [E] (P13-23) 12/3/05, 3:29 PM14

Connecting to optional equipment

You can enjoy VCR, camcorder or TV game with connection to external
input. To select the external input, press INPUT and select “LINE” mode.

INPUT

To connect the TV/DVD to a VCR

Press the INPUT to select the “LINE” (external input) to use the TV as a monitor.
Operate your VCR as usual.

: Signal flow

VCR

VIDEO IN

To Audio/Video OUT

Audio/Video cable (not supplied)

Front of TV/DVD

To connect the TV/DVD to a camcorder

To playback from the camcorder, connect the camcorder to the TV/DVD as shown.

: Signal flow

Camcorder

VIDEO IN

To Audio/Video OUT

Front of TV/DVD

GAME

AUDIO IN (R)

AUDIO IN (L)

AUDIO IN (R)

AUDIO IN (L)

Connections

Audio/Video cable (not supplied)

To connect the TV/DVD to a TV Game

You can enjoy playing a TV game on the screen by adjusting to suitable brightness for your eyes.

1. Connect a TV Game to the TV/DVD.

2. Press GAME. The GAME mode screen appears.

• This TV/DVD has the GAME mode function (see page 21).

: Signal flow

To Audio/Video OUT

Audio/Video cable (not supplied)

Notes:

• You can also change the TV screen to LINE by pressing the CH

• The TV/DVD can also be used as a display device for many video games. However, due to the wide variety of different
types of signal generated by these devices and subsequent hook-up variations required, they have not all been included
in the suggested connection diagrams. You'll need to consult each component's Owner's Manual for additional
information.

• The unauthorized recording, use, distribution, or revision of television programs, videotapes, DVDs and other materials,
is prohibited under the Copyright Laws of the United States and other countries, and may subject you to civil and/or
criminal liability.

VIDEO IN

Front of TV/DVD

AUDIO IN (R)

AUDIO IN (L)

/ buttons.

15

5X30401A [E] (P13-23) 12/3/05, 3:29 PM15

Connections

Connecting to optional equipment (Continued)

You can enjoy high quality dynamic sounds by connecting the
TV/DVD to optional audio equipment.

Connecting to an amplifier equipped with a Dolby Digital decoder

Dolby Digital

Dolby Digital is the surround sound technology used in theaters showing the latest movies, and is now available to
reproduce this realistic effect in the home. You can enjoy motion picture and live concert DVD video discs encoded via the
Dolby Digital recording system with this dynamic realistic sound by connecting the TV/DVD to a 6 channel amplifier
equipped with a Dolby Digital decoder or Dolby Digital processor. If you have a Dolby Surround Pro Logic decoder, you will
obtain the full benefit of Pro Logic from the same DVD movies that provide full 5.1-channel Dolby Digital soundtracks, as
well as from titles with the Dolby Surround mark.

This section uses the following reference mark.

*

: Front speaker
: Rear speaker

: Center speaker
: Signal flow

: Sub woofer

Amplifier equipped with a

Dolby Digital decoder

To COAXIAL
type digital
audio input

75 Ω coaxial cable (not supplied)

• Use DVD video discs
encoded via the Dolby
Digital recording system.

Manufactured under license from
Dolby Laboratories. “Dolby”, “Pro
Logic”, and the double-D symbol
are trademarks of Dolby Labora­tories.

Connecting to an amplifier equipped with Dolby Surround Pro Logic

Dolby Surround Pro Logic

You can enjoy the dynamic realistic sound of Dolby Surround Pro Logic by connecting an amplifier and speaker system (right
and left front speakers, a center speaker, and one or two rear speakers).

3 With an amplifier equipped with Dolby Digital

Connect the equipment the same way as described in “Connecting to an amplifier equipped with a Dolby Digital decoder.”
Refer to that amplifier’s owner’s manual and set the amplifier so you can enjoy Dolby Surround Pro Logic sound.

3 With an amplifier not equipped with Dolby Digital

Connect the equipment as follows.

• This connection is only suitable for Video CDs and Audio CDs.

*

Amplifier equipped with

Dolby Surround Pro Logic

To COAXIAL
type digital
audio input

75 Ω coaxial cable (not supplied)

Connect one or two rear speak-

*
ers. The output sound from the

rear speakers will be monaural
even if you connect two rear
speakers.

Connecting to an amplifier equipped with a DTS decoder

Digital Theater Systems (DTS)

DTS is a high quality surround technology used in theaters and now available for home use, on DVD video discs or audio CDs.
If you have a DTS decoder or processor, you can obtain the full benefit of 5.1 channel DTS encoded sound tracks on DVD
video discs or audio CDs.

Amplifier equipped with

a DTS decoder

To COAXIAL
type digital
audio input

75 Ω coaxial cable (not supplied)

• Use DVD video discs
encoded via the Dolby
Digital recording system.

“DTS” and “DTS Digital Out”
are trademarks of Digital
Theater Systems, Inc.

16

5X30401A [E] (P13-23) 12/3/05, 3:29 PM16

Connecting to an amplifier equipped with an MPEG2 audio decoder

MPEG2 sound

You can enjoy motion picture and live concert DVD video discs encoded via the MPEG2 recording system with dynamic
realistic sound by connecting an amplifier equipped with an MPEG2 audio decoder or MPEG2 audio processor.

Amplifier equipped with an

MPEG2 audio decoder

To COAXIAL
type digital
audio input

75 Ω coaxial cable (not supplied)

• Use DVD video discs
encoded via the Dolby
Digital recording system.

Connecting to an amplifier equipped with a digital audio input

2 channel digital stereo

You can enjoy the dynamic sound of 2 channel digital stereo by connecting an amplifier equipped with a digital audio input
and speaker system (right and left front speakers).

Amplifier equipped with a

Digital audio input

To COAXIAL
type digital
audio input

75 Ω coaxial cable (not supplied)

Connections

Notes:

• DO NOT connect the COAXIAL DIGITAL AUDIO OUT jack of the TV/DVD to the AC-3 RF input of a Dolby Digital Receiver.
This input on your A/V Receiver is reserved for Laserdisc use only and is incompatible with the COAXIAL DIGITAL AUDIO
OUT jack of the TV/DVD.

• Connect the COAXIAL DIGITAL AUDIO OUT jack of the TV/DVD to the “COAXIAL” input of a Receiver or Processor.

• Refer to the owner’s manual of the connected equipment as well.

• When you connect the TV/DVD to other equipment, be sure to turn off the power and unplug all of the equipment from the
wall outlet before making any connections.

• The output sound of the TV/DVD has a wide dynamic range. Be sure to adjust the receiver’s volume to a moderate
listening level. Otherwise, the speakers and your hearing may be damaged by a sudden high volume sound.

•Turn off the amplifier before you connect or disconnect the TV/DVD’s power cord. If you leave the amplifier power on, the
speakers may be damaged.

5X30401A [E] (P13-23) 12/3/05, 3:29 PM17

17

AUTO CH MEMORY

STOP : CANCEL

Basic setup

Starting setup

The STARTING SETUP function makes installing your TV/DVD easily. It leads
you the Language selection, TV/CABLE selection and auto channel memory
automatically.

IMPORTANT: Make sure that the antenna or cable TV system connection
is made!

Starting setup

POWER

/

ENTER
CANCEL

Press POWER.
The starting setup function begins and the

1

Language setup menu appears on the screen.
Press
language, then press ENTER.

Press or to select “TV” or “CABLE”, then
press ENTER.

2

Press
ENTER.

3

If you select “CANCEL” and press ENTER, the
STARTING SETUP stops and changes to the TV
screen.

or to select your desired

LANGUAGE/IDIOMA/LANGUE

ENGLISH

ESPAÑOL
FRANCAIS

ENTER

><

//

CHANNEL PLAN

TV

CABLE

><

ENTER

//

or to select “START”, then press

Now the “AUTO CH MEMORY” starts.

After the starting setup is completed, the TV

4

channel appears on the screen.

Note:

If you press CANCEL in the process of “AUTO CH
MEMORY”, you can do starting set up function again.

Note:

The starting setup function will work only when you press

POWER for the first time.

18

5X30401A [E] (P13-23) 12/3/05, 3:30 PM18

AUTO SETUP

START

CANCEL

ENTER

//

><

Setting the language

This TV/DVD can display the on screen language in English, Spanish or French.
Select the language you prefer first, then proceed with the other menu
options.

Setting the language

ENTER

/ / /

MENU

Press MENU, then press or to select
option.

1

LANGUAGE/IDIOMA/LANGUE

ENGLISH
ESPAÑOL
FRANCAIS

/MENU

Press or to select the desired language:
English (ENGLISH), Spanish (ESPAÑOL) or

2

French (FRANCAIS), then press ENTER.

LANGUAGE/IDIOMA/LANGUE

ENGLISH

ESPAÑOL
FRANCAIS

ENTER/MENU

//

Press MENU repeatedly until the menu screen
is cleared.

3

Basic setup

Notes:

• If the unit does not operate properly, or No key operation

(by the unit and/or the remote control): Static electricity,

etc., may affect the player's operation. Disconnect the AC
power cord once, then connect it again.

• The TV section has its own menu and also DVD section has

its own menu 38.

5X30401A [E] (P13-23) 12/3/05, 3:30 PM19

19

TV operation

CH 012

TV operation

TV operation

POWER
0–9

VOL +/–

To turn on the TV/DVD, press POWER.

The Power indicator will light.

1

Adjust the volume level by pressing VOL + or –.
The volume level will be indicated on the

2

screen by green bars. As the volume level
increases, so do the number of bars. If the
volume decreases, the number of green bars
also decreases.

Set the TV/CABLE selection to the appropriate
position 23.

3

TV - VHF/UHF channels
CABLE

20

5X30401A [E] (P13-23) 12/3/05, 3:30 PM20

VOLUME 32

- Cable TV channels

Press Direct channel selection buttons (0–9)
to select the channel.

4

TV mode direct channel selection

When the TV/CABLE selection is in the TV position, all
channels can be instantly selected by using two
buttons. (for example, to
select channel 2, press “0”,
then “2”. If you press only “2”,
channel selection will be
delayed for a few seconds.)
For channels 10 and above,
press the 2 digits in order.

CABLE mode direct channel selection

When the TV/CABLE selection is in the CABLE
position, channels can be selected as follows:

TO SELECT CABLE TV CHANNELS:
1-9: Press “0” twice, then 1-9 as needed.

10-12: Press “0”, then the remaining 2 digits.

13-99: Press the 2 digits in order. Example, to

100-125: Press the 3 digits in order. Example, to

NOTE FOR CHANNELS 1-12:
If only 1 or 2 buttons are pressed, the corresponding
channel will be selected in 2 seconds.

Notes:

• If a channel with no broadcast is selected, the sound will auto­matically be muted.

• If a station being viewed stops broadcasting, the TV will auto­matically shut itself off after 15 minutes.

Example, to select channel 2, press
“002”.

Example, to select channel 12, press
“012”.

select channel 36, press “36”.

select channel 120, press “120”.

TV

VHF
2-13
UHF

14-69

CABLE

VHF
2-13

STD/HRC/IRC

14-36

(A) (W)

37-59

(AA) (WW)

60-85

(AAA) (ZZZ)

86-94

(86) (94)

95-99

(A-5) (A-1)

100-125

(100) (125)

01

(5A)

SLEEP

120

SLEEP

DISPLAY
VOL +/–

MUTE

/

CH

CH RTN

GAME

■ CHANNEL UP/DOWN

Press and release CH

or . The channel automati­cally stops at the next channel set into memory.
For proper operation, before selecting channels, they

should be set into the memory. See page

23

“To

memorize channels”.

■ DISPLAY

Press DISPLAY to display the current informations on
the screen. Press DISPLAY again to clear the display.

• Channel number or external input mode

CH 012

■ CH RETURN

This button allows you to go back to the last channel
selected by pressing CH RTN. Press CH RTN again to
return to the last channel you were watching.

■ SLEEP

To set the TV/DVD to turn off after a preset amount of
time, press SLEEP on the remote control. The clock
will count down 10 minutes for each press of SLEEP
(120, 110, ...10, 0). After the sleep time is programmed,
the display will appear briefly every ten minutes to
remind you that the sleep timer is operating. To confirm
the sleep timer setting, press SLEEP and the remain­ing time will be displayed for a few seconds. To cancel
the sleep timer, press SLEEP repeatedly until the
display turns to 0.

■ GAME MODE

After connecting a TV Game to the unit, press GAME.
The TV screen changes to the Game mode.

• The Game mode screen is adjusted to the suitable
brightness for your eyes.

• Game timer function: After one hour, the Game timer
display will appear every 30 minutes for approx. 5
seconds showing how long the time has passed up
to 4 hours.

• If GAME is pressed during standby mode, the unit
turns on automatically and the Game mode screen
appears on the screen.

TV operation

■ MUTE

Press MUTE to switch off the sound. The TV/DVD’s
sound will be silenced and “MUTE” will briefly appear on
the screen. The sound can be switched back on by
pressing this button again or one of VOL + /–.

5X30401A [E] (P13-23) 12/3/05, 3:30 PM21

GAME

■ HEADPHONES

Insert a stereo headphones (not supplied) with a 1/8”
mini plug into the PHONES jack on the front panel. If
you connect headphones, the sound from TV speakers
is muted.

MUTE

Illustration of MD20Q42

21

TV operation

Closed captions

WHAT IS CLOSED CAPTIONING?

This television has the capability to decode and display closed captioned
television programs. Closed captioning will display text on the screen for
hearing impaired viewers or it will translate and display text in another
language.

CLOSED
CAPTION

Closed captions

Captions: This closed caption mode will display text on the screen in English or another language (depending on the

setting of the closed captions CH 1/2).
Generally, closed captions in English are transmitted on captions channel 1 and closed captions in other languages
are transmitted on captions channel 2.

Text: The text closed caption mode will usually fill the screen with a programming schedule or other information.
After selecting a closed caption mode, it will stay in effect until it is changed, even if the channel is changed.
If the captions signal is lost due to a commercial or a break in the signal, the captions will reappear when the signal is
received again. If the channels are changed, the captions will be delayed approximately 10 seconds. The captions will
appear in places on the screen where they will least interfere with the picture, usually on the bottom of the screen.
News programs will usually show three-line closed captions which scroll onto the screen.
Most other shows provide two or three lined captions placed near the character who is speaking so the viewer can
follow the dialogue. Words in italics or underlined describe titles, words in foreign languages or words requiring empha­sis. Words that are sung usually appear enclosed by musical notes.
For television programs broadcasting with closed captions, look in your TV guide for the closed captions symbol (CC).

TO VIEW CLOSED CAPTIONS

Press CLOSED CAPTION to switch between normal TV and the two closed caption
modes (captions and full screen text). Closed captioning will display text on the screen
for hearing impaired viewers.

Notes:

• When selecting closed captions, the captioning will be delayed approximately 10 seconds.

• If no caption signal is received, no captions will appear, but the television will remain in the caption mode.

• Misspellings or unusual characters may occasionally appear during closed captioning. This is normal with closed captioning,
especially with live programs. This is because during live programs, captions are also entered live. These transmissions do not
allow time for editing.

• When captions are being displayed, on-screen displays, such as volume and mute may not be seen or may interfere with closed
captions.

• Some cable systems and copy protection systems may interfere with the closed captioned signal.

• If using an indoor antenna or if TV reception is very poor, the closed caption decoder may not appear or may appear with
strange characters or misspelled words. In this case, adjust the antenna for better reception or use an outdoor antenna.

NOTICE OF POSSIBLE ADVERSE EFFECTS ON TV PICTURE DISPLAY

Avoid displaying stationary images on your TV screen for extended periods of time. Fixed (non-moving) patterns or images
(including but not limited to PIP/POP windows, closed captions, video game patterns, TV station logos, stock tickers,
websites and special formats that do not use the entire screen) can become permanently ingrained in the cathode ray
tube(s) of the TV and cause subtle but permanent ghost images. This type of damage is NOT COVERED BY YOUR

WARRANTY.

22

5X30401A [E] (P13-23) 12/3/05, 3:30 PM22

To memorize channels


  

 







ADD

0-9

CH 001

/////

MENU



  

 







This TV/DVD is equipped with a channel memory feature which allows
channels to skip up or down to the next channel set into memory, skipping over
unwanted channels. Before selecting channels, they must be programmed into
the TV/DVD’s memory. In addition to normal VHF and UHF channels, this TV/
DVD can receive up to 113 Cable TV channels. To use this TV/DVD with an
antenna, set the TV/CABLE selection to the TV position. When shipped from
the factory, this selection is in the CABLE position.

0–9

/ / /

MENU

TV/CABLE selection

Press MENU in the TV mode, then press or

1

to select option.

TV/CABLE
AUTO CH MEMORY
ADD/ DELETE

MENU

////

Press or to select “TV/CABLE”.

2

TV/CABLE

AUTO CH MEMORY
ADD/ DELETE

MENU

////

Press or to select “TV” or “CABLE”.

3

TV - VHF/UHF channels
CABLE - Cable TV channels

CABLE

CABLE

Automatic memory tuning

Press or to select the “AUTO CH MEMORY”,
then press

The TV will begin memorizing all the channels
available in your area.

.

To ADD/DELETE channels

Press or to select “ADD/DELETE”, then

1

press

.

TV operation

5X30401A [E] (P13-23) 12/3/05, 3:30 PM23

TV/CABLE

AUTO CH MEMORY
ADD/ DELETE

MENU

////

Press MENU repeatedly until the menu screen is
cleared.

4

Cable TV chart

The chart below is typical of many cable system channel
allocations.

TV

Select the desired channel to be added or
deleted using Direct

2

(0–9) or

Press or to select “ADD” or “DELETE”,
whichever function you want to perform.

3

/ .

channel selection buttons

23

TV operation

Setting the V-Chip

An age limitation can be set to forbid children to watch programs according to
“TV RATING” and “MOVIE RATING” level set. To use the V-Chip function,
you must register a password.

Notes:

• If you forget the password, you cannot set the V-Chip.

•To avoid forgetting the password, write it down and keep in
the safe place.

To register password

Press MENU, then press or to select
option.

1

V-CHIP SET

NEW
PASSWORD : – – – –

////

Press or to select “PASSWORD”.

2

MENU

To change password

1

2

0–9

ENTER

/ / /

CANCEL
MENU

In the V-CHIP menu, press or to select
“CHANGE PASSWORD”, then press

V-CHIP
V-CHIP SET

CHANGE PASSWORD

MENU

///

Enter the new password using Number buttons
(0–9), then press ENTER.

.

OFF

V-CHIP SET

NEW
PASSWORD : – – – –

0–9/ENTER/CANCEL/MENU

Enter the password (4 digits) using Number
buttons (0–9), then press ENTER.

3

• If you input a wrong number, press CANCEL.

V-CHIP SET

NEW
PASSWORD :

0–9/ENTER/CANCEL/MENU

“ ” appears instead of the number.

Enter the same password again using Number
buttons (0–9) for safety, then press ENTER.

4

Now the password was registered and V-Chip
setting menu will appear on the display.

V-CHIP SET

CONFIRM
PASSWORD :

CHANGE PASSWORD

NEW
PASSWORD : – – – –

0-9/ENTER/CANCEL/MENU

Enter the same password again using Number
buttons (0–9) for safety, then press ENTER.

3

CHANGE PASSWORD

CONFIRM
PASSWORD :

0-9/ENTER/CANCEL/MENU

Press MENU repeatedly until the menu screen
is cleared.

4

24

5X30401A [E] (P24-26) 12/3/05, 3:30 PM24

0–9/ENTER/CANCEL/MENU

To set the V-Chip

DISPLAY

ENTER

/ / /

MENU

In the V-CHIP menu, press or to select
“V-CHIP SET”, then press

1

Press
press

2

After setting, press ENTER.

OFF : TV RATING is not set
TV-Y : All children
TV-Y7 : 7 years old and above
TV-G : General audience
TV-PG: Parental guidance
TV-14 : 14 years old and above
TV-MA: 17 years old and above

When you select TV- Y7, TV-PG, TV-14 or TV-MA,
press DISPLAY to show the contained rating.
Press
want.

Press or to select “MOVIE RATING”.

or to select “TV RATING”, then

or to display the desired setting.

/ or / to select the desired item you

.

V-CHIP

V-CHIP SET

CHANGE PASSWORD

MENU

///

V-CHIP SET

TV RATING

MOVIE RATING

ENTER/MENU

////

3

TV-Y

OFF

OFF

Press
After setting, press ENTER.

4

OFF : MOVIE RATING is not set
G:All ages
PG : Parental guidance
PG-13 : Parental guidance less than 13 years old
R:Under 17 years old Parental guidance

NC-17 : 17 years old and above
X:Adult only

Press or to select “V-CHIP”.

or to select

suggested

desired rating.

V-CHIP SET

TV RATING

MOVIE RATING

ENTER/MENU

////

5

V-CHIP

V-CHIP SET
CHANGE PASSWORD

MENU

////

Press or to display “ON”.

Now your settings were set into the memory.

6

V-CHIP

V-CHIP SET
CHANGE PASSWORD

MENU

////

TV-Y

PG-13

TV operation

OFF

ON

5X30401A [E] (P24-26) 12/3/05, 3:30 PM25

V-CHIP SET

TV RATING

MOVIE RATING

////

ENTER/MENU

TV-Y

OFF

Press MENU repeatedly until the menu screen is
cleared.

7

To use after the TV is protected

When the program applied to the V-Chip setting is received,
enter the
canceled.

Note:

The V-Chip function is activated only on programs that have
the rating signal.

password, then press ENTER. Protection can be

25

TV operation

Picture control adjustment/
Adjusting the picture preference

Picture controls are factory preset but you can adjust them individually as follows:
And also you can select four picture modes—Standard, Sports, Movie, and
Memory—as described in the following table:

Picture control adjustment Adjusting the picture preference

ENTER

/ / /

CANCEL
MENU

Press MENU and then press or to select

1

option.

PICTURE PREFERENCE

Press or to select “PICTURE”, then press

.

2


PICTURE PREFERENCE

MENU

///

Press or to select the item you want to
adjust, then press

3

Selection Pressing

BRIGHTNESS darker lighter
CONTRAST lower higher
COLOR paler deeper
TINT reddish greenish
SHARPNESS softer sharper

Note:

The CONTRAST default setting is set to maximum
(+32) at the factory.

or to adjust the setting.

BRIGHTNESS

CONTRAST
COLOR
TINT
SHARPNESS

CANCEL / MENU

////

+32

Press MENU and then press or to select

1

2

0

0
0
0

3

option.

PICTURE PREFERENCE

MENU

////

Press or to select “PICTURE
PREFERENCE”, then press

Press or to select the desired picture
mode, then press ENTER.

Mode Picture quality

STANDARD Standard picture quality (factory-set)
SPORTS Bright and dynamic picture (factory-set)
MOVIE Movie-like picture setting (factory-set)
MEMORY Your personal preferences (set by you;

see “Picture control adjustment” on left)

.


PICTURE PREFERENCE

MENU

///

PICTURE PREFERENCE

STANDARD
SPORTS
MOVIE

MEMORY

ENTER / MENU

//

After your desired setting, press MENU
repeatedly until the menu screen is cleared.

4

33

3 To return all adjustments to the factory preset levels

33

Press CANCEL while making picture adjustments.

26

5X30401A [E] (P24-26) 12/3/05, 3:30 PM26

After your desired setting, press MENU
repeatedly until the menu screen is cleared.

4

Note:

You cannot select “PICTURE PREFERENCE” in the Game
mode.

Basic playback

Playing a disc

This section shows you the basics on how to play a disc.

Illustration of MD20Q42

TV/DVD
POWER

OPEN/CLOSE

CAUTION

Keep your fingers well clear of the disc tray as it is closing.
Neglecting to do so may cause serious personal injury.

DVD
VCD

Basic playback

CD

Preparations:

• Insert the AC cord plug into a standard 120V 60Hz polarized AC outlet. If the AC cord plug is plugged in for the first time,
you need to set “Starting setup” 18.

• When connecting to other equipment, turn power off.

Press POWER on the unit or on the remote control
to turn on the unit.

1

The Power indicator will light.

•Every time you press POWER, the TV/DVD starts from

TV mode.

• When using an amplifier, switch on the amplifier.

Press TV/DVD to select DVD mode.

The DVD startup screen will appear on the screen.

2

“Reading” display will change to “No Disc”. (If DVD
disc has already loaded, playback will start automati­cally.)

Reading

1 3,5 5 6 4

Press OPEN/CLOSE or PLAY.

5

OR

•A menu screen will appear on the TV screen, if
the disc has a menu feature.
Press C/D or B/A to select title, then press ENTER.
Title is selected and play commences.

The disc tray closes automatically.
On the TV-screen, “ ” changes to
“Reading” and then playback
commences.

Reading

STOP
PLAY

Basic playback

Press OPEN/CLOSE.

3

Place a disc on the disc tray.

The disc tray opens.

4

With the playback
side facing down.

• There are two different disc sizes. Place the disc in
the correct guide on the disc tray. If the disc is out of
the guide, it may damage the disc and cause the unit
to malfunction.

• Do not place a disc which is unplayable on the disc tray.

Press STOP to end playback.

6

3 To start playback in the stop mode

Press PLAY.

Note:
If the unit does not operate properly:

Static electricity, etc., may affect the player's operation. Discon­nect the AC power cord, then connect it again.

3Resuming facility

• The unit records the stopped
point, depending on the disc.
“ ” appears on the screen.
Press PLAY to resume playback
(from the scene point).

• If you press STOP again (“3”
appears on the screen.), the unit
will clear the stopped point.

27

5X30401A [E] (P27-29) 12/3/05, 3:30 PM27

Basic playback

Playing a disc (Continued)

OPEN/CLOSE

About

The

DVD VCD CD

DVD VCD CD

icons on the heading bar show the playable discs for the

function described under that heading.

: You can use this function with DVD video discs.

VCD

: You can use this function with Video CDs.

CD

: You can use this function with Audio CDs and CD-R/RW CDs.

DVD
VCD

Basic playback

CD

To pause playback (still mode)

Press PAUSE during playback.

To resume normal playback, press

PLAY.

To remove the disc

Press OPEN/CLOSE.

Remove the disc after the disc tray
opens completely.

PA USE

STOP
PLAY

• The sound is muted during still
mode.

To stop playback

Press STOP.

Be sure to press OPEN/CLOSE to close the disc tray
after you remove the disc.

Notes:

• If a non-compatible disc is loaded, “Incorrect Disc”, “Region Code Error” or “Parental Error” will appear on the TV screen
according to the type of loaded disc. In this case, check your disc again 8 41.

• Some discs may take a minute or so to start playback.

• When you set a single-faced disc label downwards (i.e. the wrong way up) and press OPEN/CLOSE or PLAY on the unit,
“Reading” will appear on the display for a few minutes and then “Incorrect Disc” will continue to be displayed.

• Some discs may not work the resuming facility.

• Resuming cannot function when you play a PBC-featured Video CD while the PBC is on. To turn off the PBC, see page 36.

• Some playback operations of DVDs may be intentionally fixed by software producers. Since this unit plays DVDs according
to the disc contents the software producers designed, some playback features may not be available. Also refer to the
instructions supplied with the DVDs.

• Do not move the unit during playback. Doing so may damage the disc.

• Use OPEN/CLOSE to open and close the disc tray. Do not push the disc tray while it is moving. Doing so may cause the unit
to malfunction.

• Do not push up on the disc tray or put any objects other than discs on the disc tray. Doing so may cause the unit to
malfunction.

• In many instances, a menu screen will appear after playback of a movie is completed. Prolonged display of an on-screen
menu may damage your television set, permanently etching that image onto its screen. To avoid this, be sure to press
POWER on your remote control once the movie is completed.

• There may be a slight delay between you pressing the button and the function activating.

To obtain a higher quality picture

Occasionally, some picture noise not usually visible during a normal broadcast may appear on the TV screen while playing a
DVD video disc because the high resolution pictures on these discs include a lot of infor mation. While the amount of noise
depends on the TV you use with this unit, you should generally reduce the sharpness adjustment on your TV when viewing
DVD video discs.

28

5X30401A [E] (P27-29) 12/3/05, 3:30 PM28

Playing in fast reverse or fast forward directions

VCD

VCD

DVD
VCD

CD

DVD
VCD

CD

PAUSE

PLAY
FF
SKIP /
SLOW
REV

Press REV or FF during playback.

REV:Fast reverse playback
FF:Fast forward playback

Each time you press REV or FF, the
playback speed changes.

DVD

Playing frame by frame

Press PAUSE during still playback.

Each time you press PAUSE, the
picture advances one frame.

DVD

Playing in slow-motion

Press SLOW during playback.

Each time you press SLOW
slow-motion speed changes.

, the

To resume normal playback

Press PLAY.

Notes:

• The TV/DVD mutes sound during reverse and forward scan
of DVD/VCD video discs. However, the TV/DVD plays sound
during fast forward or fast reverse play of audio CDs.

• The playback speed may differ depending on the disc.

To resume normal playback
Press PLAY.

Note:

The sound is muted during frame by frame playback.

To resume normal playback

Press PLAY.

Note:

The sound is muted during slow-motion playback.

Basic playback

Locating a chapter or track

Press SKIP or repeatedly to display the chapter or track number you want.

Playback starts from the selected chapter or track.

To locate succeeding chapters or
tracks.

Note:

Press and hold SKIP on the unit during playback to play fast forward or fast reverse.
Each time you press and hold SKIP, the playback speed will change.

Notes:

•A prohibition symbol “ ” may appear at the upper left of the screen. This symbol means either the feature you tried is not

available on the disc, or the TV/DVD cannot access the feature at this time. This does not indicate a problem with the TV/DVD.

• The unit is capable of holding a still video image or On screen display image on your television screen indefinitely. If you leave
the still video image or On screen display image displayed on your TV for an extended period of time, you risk permanent
damage to your television screen. Projection televisions are very susceptible.

5X30401A [E] (P27-29) 12/3/05, 3:30 PM29

Playback starts from the beginning of
the current chapter or track.
When you press twice in quick successions,
playback starts from the beginning of
the preceding chapter or track.

29

Advanced playback

DISPLAY

Zooming/Locating desired scene

DVD
VCD

Zooming

CD

This unit will allow you to zoom in on the frame image. You
can then make selections by switching the position of the
frame.

Press ZOOM during playback.

1

The center part of the image will be
zoomed in.
Each press of ZOOM will change the
ZOOM
(x 2.0).

1 (x 1.3), 2 (x 1.5) and 3

1

0–9

JUMP

ZOOM

/ / /

CANCEL

ENTER

DVD
VCD

Locating desired scene

CD

Use the title, chapter and time recorded on the DVD disc to
locate the desired point to playback. In the case of VCD/CD
discs, time and track are used to locate the desired point to
playback.
To check the title, chapter and time, press DISPLAY.

Press JUMP during playback or stop mode.

1

T C

• “Time” works only in DVD playback
or DVD resume mode.

T

Press or to select the “ Time”, “
Title/Track” or “

2

T

Chapter”.

C

T

Press / / / to view a different part of the
frame.

2

You may move the frame from the
center position to UP, DOWN, LEFT
or RIGHT direction.

In the zoom mode, press ZOOM repeatedly to
return to a 1:1 view (

3

Notes:

•You can select the Pause, Slow or Search playback in the zoom
mode.

• Some discs may not respond to zoom feature.

Off).

T C

Press Number buttons (0–9) to input the number.

3

T C

• If you input a wrong number, press

CANCEL.

• Refer to the package supplied with
the disc to check the numbers.

Press ENTER. Playback starts.

4

Note:

In case of the Video-CD playback with PBC, the JUMP does not
work. To turn off PBC, see page 36.

• When you change the title,
playback starts from Chapter 1
of the selected title.

• Some discs may not work in the
above operation.

12

30

5X30401A [E] (P30-32) 12/3/05, 3:30 PM30

Marking desired scenes

VCD

The unit stores the points that you want to watch again up to 3 points.
You can resume playback from each scene.

/
ENTER
CANCEL

MARKER

DVD

Marking the scenes

Press MARKER during playback.

1

 !

Select the blank Marker using or , then
press ENTER at the desired scene.

2

• Up to 3 scenes can be selected.

• Repeat this procedure to set the
other 2 scenes.

1

Press MARKER to clear this display.

00:27:54

2 3

3

Notes:

• Some discs may not work with the marking operation.

• The marking is cancelled when you open the disc tray or turn
the power off.

• Some subtitles recorded around the marker may fail to
appear.

• In case of Video CD with PBC, the MARKER is prohibited.

DVD

Returning to the scenes

VCD

Press MARKER during playback or stop mode.

1

01:16:25

2 3

Press

1

00:27:54

or to select the Marker 1-3.

2

1

00:27:54

Press ENTER.

3

To cancel the Marker

Follow the above steps 1~2, then press CANCEL.

Playback starts from the marked
scene.

01:16:25

2 3

02:08:31

02:08:31

Advanced playback

31

5X30401A [E] (P30-32) 12/3/05, 3:30 PM31

Advanced playback

AB

Repeat playback/A-B Repeat playback

PLAY MODE

/

ENTER

PLAY

REPEAT A-B

DVD
VCD

Repeat playback A-B Repeat playback

CD

Press PLAY MODE during playback or stop mode.

DVD
VCD

CD

A-B repeat playback allows you to repeat a section between
two selected points.

1

Press REPEAT A-B during playback.

[DVD]
Press

2

[Video CD, Audio CD]
Press

ENTER to select “Track” or “All”.

/ to select “Chapter” or “Title”.

The unit automatically starts repeat
playback after finishing the current title
or chapter.

to select “Repeat” and then press

The unit automatically starts repeat
playback after finishing the current
track.

Repeat

1

:

Off

Press REPEAT A-B again.

2

The start point is selected.

The end point is selected. Playback
starts at the point that you selected.
Playback stops at the end point and
returns to Point A automatically, then
starts again.

A

:

Play Mode

• If you set the repeat mode during stop mode,

press PLAY to star t Repeat playback.

Press PLAY MODE again to clear the screen.

Off

/Enter/Play Mode

3

To resume normal playback

Select Repeat : “Off” in step 2.

Notes:

• Some discs may not work with the repeat operation.

• In case of Video CD with PBC, Repeat functions are prohib­ited during playback.

32

5X30401A [E] (P30-32) 12/3/05, 3:30 PM32

Repeat

:

Off

To resume normal playback

Press REPEAT A-B again.

“

Notes:

• In A-B Repeat mode, subtitles near the A or B locations may
not be displayed.

•You cannot set the A-B Repeat for the scenes that include
multiple angles.

• A-B Repeat playback does not work when Repeat playback is
activated.

•You may not be able to set A-B Repeat, during certain scenes
of the DVD.

• A-B Repeat does not work with an interactive DVD.

• A-B Repeat is prohibited when PBC is on.

” appears on the screen.

Off

Program playback/Random playback

   



T

You can arrange the playback order of tracks or files on the disc. And also
the unit can playback tracks or files in random order. These feature works for
Audio CD, Video CD and JPEG CD.

VCD

Program playback

CD

0–9

PLAY MODE
▲ / ▼ / /

CANCEL
PLAY

SKIP7
ENTER

Press PLAY MODE in the stop mode.

1



 

Press or to select Play Mode, then press
ENTER to select “Program”.

2

Play Mode

Press / / / to select the programming po­sition. Use Number buttons (0–9) to input the

3

Track or file numbers.

• To program others, repeat Step 3.

• If you input a wrong number, press

CANCEL.

 



 

:

Program Repeat

1

4

2

5

3

6

Clear Program Playback

/Enter/0 9/Cancel/Play Mode



 

















  

!"#! !#! 



7
8
9





Press / / / to select “Program Playback”
and press ENTER.

4





The programs you selected will start to playback in
order.

• In case of JPEG file, press SKIP

to continue

the program playback.

• To resume normal playback, select Play Mode:

:

Off

10
11
12

“Off” in step 2.

Advanced playback

■ To change the program

1. In the program mode, press / / / to select the track

number.

2. Press Number buttons (0–9) to select the track number to

be replaced.

■ To clear the program one by one

In the program mode, press / / / to select the track









number. Then press CANCEL.

■ To clear all the programs

In the program mode, press / / / to select “Clear”.
Then press ENTER.

Note:

The program is cancelled when you open the disc tray or turn
the power off.

VCD

CD

1

2

5X30401A [E] (P33-37) 12/3/05, 3:30 PM33

Random playback

Press PLAY MODE during playback or stop
mode.

Press / to select Play Mode, then press
ENTER to select “Random”.



 

 





Press PLAY

3

.

The Random Playback will start.

• If you set “Random” during
playback mode, Random playback
will begin after the track that is
currently being played has ended.

• To resume normal playback, select





Note:

In case of Video CD with PBC, you cannot set Random
function during playback.

Play Mode: “Off” in step 2.

33

Advanced playback

Changing angles/Title selection/DVD menu

ENTER

DVD MENU
▲ / ▼ /

PLAY
ANGLE

TOP MENU

Changing angles

When playing back a disc recorded with multi-angle facility, you can change the angle that you are viewing the scene from.

/

Press ANGLE during playback.

1

The current angle will appear.

1/9

Press ANGLE repeatedly until the desired angle
is selected.

2

Note:

Depending on the DVD, you may not be able to change the
angles even if multi-angles are recorded on the DVD.

Title selection

Two or more titles are recorded on some discs. If the title menu is recorded on the disc, you can select the desired title.

Press TOP MENU during playback.

1

Press / / / to select the desired title.

Title menu appears on the screen.

Press ENTER or PLAY.

3

The playback of the selected title will
start.

2

Note:

Depending on the DVD, you may not be able to select the title.
Depending on the DVD, a “title menu” may simply be called a
“menu” or “title” in the instructions supplied with the disc.

DVD menu

Some DVDs allow you to select the disc contents using the menu.
When you playback these DVDs, you can select the subtitle language and sound-track language, etc. using the menu.

Press DVD MENU during playback.

1

Press / / / to select the desired item.

The DVD menu appears on the screen.

• Press DVD MENU again to resume

playback at the scene when you
pressed DVD MENU.

2

Press ENTER.

3

Note:

Depending on the DVD, you may not be able to resume
playback from the scene point when you pressed DVD MENU.

The menu continues to another
screen. Repeat steps 2 and 3 to set
the item completely.

34

5X30401A [E] (P33-37) 12/3/05, 3:30 PM34

Changing soundtrack language/
Subtitles

DVD

Changing soundtrack language

VCD

You can select the language when you play a multilin­gual disc.

Press AUDIO SELECT during playback.

1

Press AUDIO SELECT repeatedly until the desired
language is selected.

2

The current soundtrack language will
appear.

1/8 Eng D

2/8 Fra D

SUBTITLE
AUDIO SELECT

Subtitles

When playing back a disc recorded with subtitles, you can
select the subtitle language or turn the subtitle off.

Press SUBTITLE repeatedly during playback until
the desired language is selected.

1

1/8 Eng

To turn off the subtitle, press SUBTITLE until
“Off” appears.

2

Off

Advanced playback

• The on screen display will disappear after a few
seconds.

In case of Video CD playback

Audio type changes as follows each time you press
AUDIO SELECT.

LR

Notes:

• If the desired language is not heard after pressing the button
several times, the language is not recorded on the disc.

• The selected soundtrack language is cancelled when you open
the disc tray. The initial default language or available language
will be heard if the disc is played back again.

• If you select DTS in playing DTS-encoded disc, no sound will
be heard from the TV/DVD’s speakers.

L

R

• The on screen display will disappear after a
few seconds.

Notes:

• Depending on the DVD, you may not be able to change
subtitles, or to turn subtitles on or off.

• While playing a DVD, the subtitle may change when you
open or close the disc tray.

• In some cases, a selected subtitle language may not be
changed immediately.

5X30401A [E] (P33-37) 12/3/05, 3:30 PM35

35

Advanced playback









 



 

Disc status/To turn off the PBC

DVD
VCD

Disc status

CD

VCD

To turn off the PBC

1

DISPLAY
PLAY MODE

/

ENTER

Press DISPLAY during playback. The status display
of the disc will appear on the screen in order like
the figure below.

DVD

Title elapsed playing time

Play status

Title number

Chapter No

1/2

Subtitle language

1/1 Eng 1/2 Fra D

00:03:13 01:30:32

CT

1/2

00:03:13 01:30:32

Type of audio

Display Off

Title total time

1/1

Camera angle

Audio language

VCD (with PBC)

Title elapsed playing time

Play status

05:28PBC 45:03

Title total time

Press PLAY MODE in the stop mode.

1

Press
ENTER to select “Off”.

2

Press PLAY MODE again to clear the screen.

/ to select Play Mode, then press

3

To turn on the PBC

Select Play Mode : “PBC” in step 2.

Note:

You can also turn off the PBC by pressing number button 1
and ENTER in the stop mode.

Title number

Audio CD

Play status

Tr ack number

• When you play a CD disc, the status display will
appear and remain on the screen.

36

5X30401A [E] (P33-37) 12/3/05, 3:30 PM36

T

T

1/1

11/99

05:28 45:03

Display Off

Tr ack elapsed playing time

34:56 71:33

Track total time

JPEG playback

You can select your desired JPEG file on the file menu and picture menu.
The selected JPEG file is automatically adjusted to the TV screen. (When the
aspect ratio of the JPEG file is different to your TV screen, the black bar will
appear at the top and bottom, or the both sides of the TV screen).

CAUTION:

Some JPEG CDs cannot be played back depending on the recording conditions.

CD CD

JPEG CD playback Slide show playback

0–9

PAU S E

ENTER

▲ / ▼ /

STOP
PLAY

SKIP

ANGLE

/

/

Place a JPEG disc on the disc tray.

1

A file menu screen will appear on the screen.
Press

2

Press / / / or Number buttons (0–9) to se­lect the desired file.

3

• To display next list, press SKIP or .

Press ENTER. The selected picture appears on
the screen.

4

Rotating an image

You can rotate an image by 90 degrees. Press
ANGLE during playback of the image.
“
on the screen.

Press STOP to end playback.

The file menu appears on the screen.

5

If you want to watch the other file, repeat steps
3 ~ 4.

Notes:

• During JPEG playback, you cannot use SEARCH and A-B
Repeat functions.

• You can use Repeat (Track or All), Random and Program
functions for JPEG CD playback 32 33.

/ to select folder.

-

CD

Collection

1

Pic-1

2

Pic-2

3

Pic-3

4

Pic-4

”, “ ”, “ ” or “ ” appears briefly

/36

8

Pic-8

9

Pic-9

10

Pic-10

11

Pic-11

The slide show enables you to view pictures (files) one after
another automatically.

Preparation:

Set “JPEG Interval” setting to “5 Seconds”, “10 Seconds” or
“15 Seconds” 40.

Select your desired starting file for the slide
show in the step 3 on left.

1

Press ENTER to start slide show from the se­lected file.

2

• If you press PA USE during the slide show, the slide

show stops temporary. “ 4 ” appears briefly on the
screen.
If the picture appears upside down or sideways, press
ANGLE repeatedly until it’s right side up.

”, “ ”, “ ” or “ ” appears briefly

“
on the screen.
Press PLAY or SKIP

• When the slide show playback finished, the file list ap­pears.

•To stop the slide show, press STOP. The file list ap­pears.

JPEG CD Information

Limitations on JPEG CD playback

• JPEG CD is the disc that is standardized by ISO9660, its
file name must include 3-digits extension letters, “jpg”.

• The directory and file names of the JPEG CD must be
correspond to the ISO standardized files.

• This unit can read 600 files per disc. If a disc has more than
600 files, it reads up to 600 files, the remaining files will be
omitted.

• The unit is able to recognize up to a maximum of 50
directories per disc.

• It may take more than one minute for this unit to read JPEG
files depending on its structure.

Limitations on display

• The maximum number for display is 16 letters. Available
letters for display are the following: capital or small
alphabets of A through Z, numbers of 0 through 9, and _
(under score).

• Other letters than those above are replaced in hyphen.

Notes on JPEG files

To play back JPEG CD in the recorded order,

1. Use JPEG software that records data alphabetically or
numerically.

2. Name each file including two-digit or three-digit number
(ex. “01” “02” or “001” “002”).

3. Refrain from making too many sub-folders.

again to resume the slide show.

Advanced playback

37

5X30401A [E] (P33-37) 12/3/05, 3:31 PM37

Function setup

Function setup

Customizing the function settings

You can change the default settings to customize performance
to your preference.

DVD
VCD

Setting procedure

CD

ENTER
▲ / ▼ / /

SETUP

RETURN

Press SETUP during stop mode.

1

2

Press
press

Press

The following on-screen display
appears.

or to select the desired section, then
or ENTER.

or to select the desired option.

3

Setting details

Section

/Enter/Setup/Return

Option

Menu
Subtitle
Audio

Change the selection using or , by referring
to the corresponding pages

4

• Repeat steps 3 and 4 to change
other settings.

• To select another operation, go
back to step 2 by pressing
repeatedly.

To clear SETUP screen, press SETUP or
RETURN.

5

Details

To select the language of “Menu”, “Subtitle” and
“Audio” if more than one language are recorded on
the disc.

39

~ 41.

Page

38

5X30401A [E] (P38-42) 12/3/05, 3:31 PM38

TV Screen

Display

Picture Mode

JPEG Interval

DRC

Password

Parental

To select a picture size according to the aspect
ratio of your TV.

To turn On or Off the operational status display on the
screen.

To select a preferred picture mode from “Video”,
“Film” or “Auto”.

To select a preferred setting for the slide show play­back.

To select On or Off for DRC (Dynamic Range Con­trol).

Input 4-digit password to set the parental level.

To select a preferred parental level for the parental
setting.

39

40

41

TV Screen
Display
Picture Mode

4:3

On

Auto

JPEG Interval Off

/Setup/Return

Setting details

Menu
Subtitle
Audio

/Setup/Return

English
English
English

Menu, Subtitle, Audio

You can select the language of “Menu”, “Subtitle” and
“Audio” if more than one languages are recorded onto
the disc.

English, Francais, Espanol:

The selected language will be heard or seen.

Other:

Other language can be selected (see “Language

43

code list”

).

Original (Audio):

The unit will select the first-priority language of
each disc.

Off (Subtitle):

Subtitles do not appear.

Notes:

• If the selected language is not recorded on the disc, the
first-priority language is selected.

• If you want to change the OSD language, you can per­form it by TV MENU 19.

TV Screen

You have the following screen sizes to choose from:

4:3

: (Letter box)

Select this mode when connecting to a conventional
TV. When playing back a wide screen-DVD disc, it
displays the wide picture with black bands at the
top and bottom of screen.

4:3

: (Pan & scan)

It displays the wide picture on the whole screen
with left and right edges automatically cut off.

Press OPEN/CLOSE to view in the selected screen size.

Note:

If the DVD disc is not formatted in the Pan & scan style,
it will display 4:3 style.

Display

On screen display can be switched on or off when you
press any buttons.

Function setup

5X30401A [E] (P38-42) 12/3/05, 3:31 PM39

On: On screen displays appear when you press

any buttons (factory setting).

Off: On screen displays do not appear when you

press any buttons.

39

Function setup

Customizing the function settings (Continued)

Setting details

Picture Mode

There are two types of source content in pictures re­corded in DVD video discs: film content (pictures re­corded from films at 24 frames per second) and video
content (video signals recorded at 30 frames per sec­ond). Make this selection according to the type of content
being viewed.

DRC

/Setup/Return

On

Auto: Select this position normally.

The DVD player automatically detects source
content, film or video of playback source,
and converts that signal in the progressive
output format in an appropriate method.

Film: The DVD player converts film content pictures

in the progressive output format appropri­ately. Suitable for playback of film content
pictures. The progressive output feature will
be most effective under this selection.

Video: The DVD player filters video signal and

converts it in the progressive output format
appropriately.
Suitable for playback of video content
pictures.

Note:

Depending on the disc, pictures may be cut off or doubled.
In this case, select “Video”.

JPEG Interval

You can continuously playback all JPEG files automati­cally.
After the selection below, the disc will start playback on
which JPEG files have been recorded.

Off:

Plays back one file at a time.

DRC

DRC (Dynamic Range Control) enables you to control
the dynamic range so as to achieve a suitable sound for
your equipment.

On: Loud sound such as explosion is toned

down slightly when played back. This is
suitable when it is connected to a stereo.

Off: It plays back at the recording level on the

disc.

Notes:

• This function works only during playback of Dolby Digital
recorded discs.

• The level of Dynamic Range Reduction may differ
depending on DVD video disc.

5 Seconds:

Plays back images in the form of a slide show at
5 second intervals.

10 Seconds:

Plays back images in the form of a slide show at
10 second intervals.

15 Seconds:

Plays back images in the form of a slide show in
15 second intervals.

40

5X30401A [E] (P38-42) 12/3/05, 3:31 PM40

To change the parental level

Password
Parental Off

/0Ð9/Enter/Cancel/Setup/Return

----

Parental control setting

Some discs are specified as not suitable for children.
Such discs can be limited not to playback with the unit.

1) Press C or D to select “Parental”, then press B
or A until the parental level you require to appear.

• Level Off: The parental control setting does not

function.

• Level 8: All DVD software can be played back.

• Level 1: DVD software for adults cannot be

played back.
Select from the level 1 to level 8. The limitation will
be more severe as the level number is lower.

2) Press C or D to select “Password”.

Press Number buttons (0–9) to input a 4-digit
password. Be sure to remember this number!

• If you input a wrong number, press CANCEL.

3) Press ENTER to store the password.

Note: Now the rating is locked and the setting can
not be changed unless you enter the correct
password.

4) Press OPEN/CLOSE to activate Parental control

setting. (See “Temporary cancel the rating level
by DVD disc”

.)

42

1) Press C or D to select “Password”.

2) Press Number buttons (0–9) to enter the password

you have stored.

3) Press ENTER.

• The rating is now unlocked.

4) Press C or D to select “Parental”, then press B
or A to change the parental level.

5) Press C or D to select “Password”, then press
Number buttons (0–9) to enter the password.
Note: You can change the password if you want.

6) Press ENTER.
Now the parental level is changed and locked.

If you forget the password.

1. Press OPEN/CLOSE to open the disc tray.

2. Remove the disc.

3. Press OPEN/CLOSE again to close the disc tray.
“No Disc” appears on the screen.

4. Press and hold STOP on the front panel, and at the
same time press 7 on the remote control until
“PASSWORD CLEAR” appears on the screen.

5. Enter a new password again.

Note:

39

If each setup
work under the same condition (especially with DVD discs).
Each setup will be retained in the memory even if you turn
the power off.

41

~

has completed, the unit can always

Function setup

Notes:

• Depending on the discs, the unit cannot limit playback.

• Some discs may not be encoded with specific rating
level information though its disc jacket says “adult.” For
those discs, the age restriction will not work.

5X30401A [E] (P38-42) 12/3/05, 3:31 PM41

41

Function setup

OPEN/CLOSE

Temporary cancel the rating level by DVD disc

Depending on the DVD disc, the disc may try to temporarily cancel the rating
level that you have set.
It is up to you to decide whether to cancel the rating level or not.

Load a DVD disc and press PLAY or OPEN/
CLOSE on the unit

1

If the DVD disc has been designed to temporarily
cancel the Rating level, the screen which follows

2

the “Reading” screen will change, depending on
which disc is played. If you select “YES” with the
ENTER key, “Your disc exceeds the parental
control level#.” screen will then appear.

Reading

If you wish to cancel the set rating level tempo­rarily, select “Parental Control Level” with

3

, then press ENTER. If the 4-digit password at

step 2 on page
entering screen will appear as shown in step 4.
Alternatively, if the password has not been set,
playback will commence. If you don’t know (or
have forgotten) the password, select “Cancel
Picture”.
The setting screen will disappear. Press OPEN/
CLOSE to remove the disc.

27

.

Your disc exceeds
the parental control level#.

Parental Control Level
Cancel Picture

/Enter/Return

41

has been set, the password

or

Enter the password with Number buttons (0–9).
Then press ENTER.

4

Playback will commence if the entered
password is correct.

5

Note:

This temporary cancellation of rating level will be kept until the
disc is ejected.
When the disc is ejected, the original rating level will be set again
automatically.

0–9

▲ / ▼
ENTER

PLAY

RETURN

To e xit from the entry, press RETURN.

  



  







42

5X30401A [E] (P38-42) 12/3/05, 3:31 PM42

Others

Language code list

Enter the appropriate code number for the initial settings “Menu”, “Subtitle” and/or “Audio” 39.

Language Name Code Language Name Code Language Name Code Language Name Code

Abkhazian 1112 Fiji 1620 Lingala 2224 Singhalese 2919

Afar 1111 Finnish 1619 Lithuanian 2230 Slovak 2921

Afrikaans 1116 French 1628 Macedonian 2321 Slovenian 2922

Albanian 2927 Frisian 1635 Malagasy 2317 Somali 2925

Amharic 1123 Galician 1722 Malay 2329 Spanish 1529

Arabic 1128 Georgian 2111 Malayalam 2322 Sundanese 2931

Armenian 1835 German 1415 Maltese 2330 Swahili 2933

Assamese 1129 Greek 1522 Maori 2319 Swedish 2932

Aymara 1135 Greenlandic 2122 Marathi 2328 Tagalog 3022

Azerbaijani 1136 Guarani 1724 Moldavian 2325 Tajik 3017

Bashkir 1211 Gujarati 1731 Mongolian 2324 Tamil 3011

Basque 1531 Hausa 1811 Nauru 2411 Tatar 3030

Bengali; Bangla 1224 Hebrew 1933 Nepali 2415 Telugu 3015

Bhutani 1436 Hindi 1819 Norwegian 2425 Thai 3018

Bihari 1218 Hungarian 1831 Oriya 2528 Tibetan 1225

Breton 1228 Icelandic 1929 Panjabi 2611 Tigrinya 3019

Bulgarian 1217 Indonesian 1924 Pashto, Pushto 2629 Tonga 3025

Burmese 2335 Interlingua 1911 Persian 1611 Turkish 3028

Byelorussian 1215 Irish 1711 Polish 2622 Turkmen 3021

Cambodian 2123 Italian 1930 Portuguese 2630 Twi 3033

Catalan 1311 Japanese 2011 Quechua 2731 Ukrainian 3121

Chinese 3618 Javanese 2033 Rhaeto-Romance2823 Urdu 3128

Corsican 1325 Kannada 2124 Romanian 2825 Uzbek 3136

Croatian 1828 Kashmiri 2129 Russian 2831 Vietnamese 3219

Czech 1329 Kazakh 2121 Samoan 2923 Volapük 3225

Danish 1411 Kirghiz 2135 Sanskrit 2911 Welsh 1335

Dutch 2422 Korean 2125 Scots Gaelic 1714 Wolof 3325

English 1524 Kurdish 2131 Serbian 2928 Xhosa 3418

Esperanto 1525 Laothian 2225 Serbo-Croatian 2918 Yiddish 2019

Others

Estonian 1530 Latin 2211 Shona 2924 Yoruba 3525

Faroese 1625 Latvian, Lettish 2232 Sindhi 2914 Zulu 3631

5X30401A [E] (P43-47) 12/3/05, 3:31 PM43

43

Others

Troubleshooting

Use the following check list for troubleshooting when you have problems with your unit. Consult your local dealer
or service outlet if problems persist.
Be sure all connections are properly made when using with other units.

SYMPTOMS POSSIBLE SOLUTIONS

POWER

TV/DVD does not operate.

TV BROADCAST RECEPTION

Poor sound or no sound.

Poor picture or no picture.

Poor reception on some channels.

Poor color or no color.

Picture wobbles or drifts.

No CATV reception.

Horizontal or diagonal bars on
screen.

No reception above channel 13.

TV shuts off.

Closed - Caption is not activated.

Display is not shown in your
language.

• Make sure the power cord is plugged in.

• Try another AC outlet.

• Power is off, check fuse or circuit breaker.

• Unplug unit, then plug it back in.

• Station or Cable TV experiencing problems, tune to another station.

• Check Volume adjustments.

• Check for sources of possible interference.

• Station or Cable TV experiencing problems, tune to another station.

• Check antenna or Cable TV connections, reorient antenna.

• Check for sources of possible interference.

• Check picture control adjustments.

Station or Cable TV experiencing problems, tune to another station.

•

• Station signal is weak, reorient antenna to receive weaker station.

• Check for sources of possible interference.

• Station or Cable TV experiencing problems, tune to another station.

• Make sure channels are set into memory.

• Check picture control adjustments.

• Check antenna or Cable TV connections, reorient antenna.

• Check for sources of possible interference.

• Station or Cable TV experiencing problems, tune to another station.

• Make sure channels are set into memory.

• Cable TV company is scrambling signal.

• Check antenna or Cable TV connections, reorient antenna.

• Check all Cable TV connections.

• Set TV/CABLE selection to the CABLE position.

• Station or Cable TV system problems, try another station.

• Check antenna or Cable TV connections, reorient antenna.

• Check for sources of possible interference.

• Make sure TV/CABLE selection is in the appropriate position.

• If using antenna, check UHF antenna connections.

• No broadcast on station tuned.

• Sleep Timer is set.

• Power interrupted.

• TV station experiencing problems or program tuned is not closed
captioned. Try another channel.

• Check Cable TV connection or VHF/UHF antenna, reposition or
rotate antenna.

• Press CLOSED CAPTION button to turn on the closed caption
decoder.

• Select proper language in the menu options.

PAGE

5

20
20
46

20

13, 14

46
26

20
13
46

20
23
26
13
46

20
23

–

13, 14

14
23
20

13,14

46

23
13

20
21

–

20

13,14

22

19

44

5X30401A [E] (P43-47) 12/3/05, 3:31 PM44

SYMPTOMS POSSIBLE SOLUTIONS PAGE

DVD

• No disc is inserted.

Playback doesn’t start.

No picture. • TV/DVD selector is not set correctly.

No sound.

Picture is distorted during fast
reverse/forward playback.

Stopping playback, search, slow­motion play, repeat play, or
program play, etc. cannot be
performed.

No on-screen display. • Select Display On.

No surround sound. • The setup does not match your stereo system.

The unit or remote operation key
is not functioning.

Playback does not start when the
title is selected.

Audio soundtrack and/or subtitle
language is not changed when
you playback a DVD.

No subtitle.

Angle cannot be changed. • Multi-angles are not recorded on the DVD disc.

“

” appears on the screen.

• The disc may be dirty. Clean up the disc.

• The unit cannot play CD-ROMs, etc.

• Check the input selector of the amplifier is set properly.

• The unit is in the special playback mode.

• Select the correct Audio Output position on AV amplifier.

• The picture will be distorted occasionally.

• Some discs may not do some of the functions.

• Turn off the unit and unplug the AC power cord for several
minutes, then replug it.

• Check the Parental setup.

• Multilingual language is not recorded on the DVD disc.

• Some discs have no subtitles.

• Subtitles are cleared. Press SUBTITLE.

• The function is prohibited with the unit or the disc.

27

27

29

39

16

41

35

35

34

29

7
8

–

–

–

–

–

Others

REMOTE CONTROL

The remote control does not
function.

5X30401A [E] (P43-47) 12/3/05, 3:31 PM45

• Aim at the remote control at the remote sensor.

• Operate within approx. 5 meters or reduce the light in the room.

• Clear the path of the beam.

• The batteries are weak. Replace the batteries.

• Check the batteries are inserted correctly.

12

45

Others

Reception disturbances

Most types of television interference can be remedied by adjusting the height and position of the VHF/UHF
antenna. Outdoor antennas are recommended for best results. The most common types of television
interference are shown below. If one of these symptoms appear when the TV/DVD is connected to a Cable
TV system, the disturbance may be caused by the local Cable TV company broadcast.

IGNITION

Black spots or horizontal streaks may appear, the picture may flutter or
drift. Usually caused by interference from automobile ignition systems,
neon lamps or AC powered tools and appliances such as drills or hair
dryers.

GHOSTS

Ghosts are caused by the television signal following two paths. One is
the direct path and the other is reflected by tall buildings, hills or other
large objects. Changing the direction or position of the antenna may
improve the reception.

SNOW

If the TV/DVD is located far from the TV station, in a fringe reception
area where the signal is weak, small dots may appear in the picture.
If the signal is extremely weak, the installation of a larger external
antenna may be necessary.

RADIO FREQUENCY INTERFERENCE (RFI)

Caused by two-way radios, this type of interference produces moving
ripples or diagonal streaks in the picture. Some cases may cause a
loss of contrast in the picture. Changing the direction and position of
the antenna or installing an RFI filter may improve the picture.

PICTURE SIZE VARIATION

A slight picture size variation is normal when you adjust the CONTRAST
or BRIGHTNESS settings.

CARE AND MAINTENANCE

To prevent fire or shock hazard, disconnect the TV/DVD from the power source before cleaning.
The finish on the cabinet may be cleaned with mild soap and a soft, damp cloth and cared for as other furniture.
Use caution when cleaning or wiping the plastic parts.

46

5X30401A [E] (P43-47) 12/3/05, 3:31 PM46

Specifications

MD13Q42

General

Power supply
Power consumption
Picture tube
Speaker
Audio output power
Weight
Dimensions

Tuner

Antenna input
Applicable disc
Frequency range
Operating conditions

AC 120 V 60 Hz
Operation: 75 W, Stand by: 3 W
13 Inch* (335.4 mm diagonal)

1.5 x 2.7 inches (38.1 x 68.6 mm), 8 ohm x 2

1.0 W + 1.0 W

24.3 lbs (11.0 kg)
Width: 14-1/4 inches (362 mm)
Height: 15-1/16 inches (382 mm)
Depth: 14-3/8 inches (365 mm)
181 channel freq. synthesized
VHF 2-13
UHF 14-69
CATV 125 Channels
UHF/VHF: 75 Ω coaxial
DVD (12 cm, 8 cm), CD (12 cm, 8 cm)
DVD: 4 Hz-22 kHz, CD: 4 Hz-20 kHz
Temperature: 5˚C-40˚C (41˚F-104˚F), Operating status: Horizontal

Operation: 90 W, Stand by: 5 W
20 Inch* (508.0 mm diagonal)
3 inches (76.2 mm), 8 ohm x 2

48.5 lbs (22.0 kg)
Width: 19-3/4 inches (502 mm)
Height: 20-3/16 inches (513 mm)
Depth: 19-1/4 inches (488.7 mm)

Input/Output

Video input 1.0 V (p-p), 75 Ω, negative sync., pin jack x 1
Audio input –8 dBm, 50 kΩ, negative sync., pin jack (L/R) x 1
Audio output (DIGITAL COAXIAL) 0.5 V (p-p), 75 Ω, pin jack x 1

Supplied accessories

Remote control (DC-SB2) ..................................... 1

Batteries (R03/AAA) ............................................. 2

300-75 Ω matching transformer ............................ 1

MD20Q42

Others

* Screen size is approximate.

• This model complies with the above specifications.

• Designs and specifications are subject to change without notice.

• This model may not be compatible with features and/or specifications that may be added in the future.

5X30401A [E] (P43-47) 6/12/05, 16:4747

47

Others

Limited warranty

Limited United States Warranty

for CRT-based TV/DVD Combinations, TV/VCR Combinations, and TV/DVD/VCR

Combinations, 25" and Smaller ("TV Combination(s)")

Toshiba America Consumer Products, L.L.C. ("TACP") makes the following limited warranties to original consumers in
the United States. THESE LIMITED WARRANTIES EXTEND TO THE ORIGINAL CONSUMER PURCHASER OR

ANY PERSON RECEIVING THIS TV COMBINATION AS A GIFT FROM THE ORIGINAL CONSUMER PURCHASER
AND TO NO OTHER PURCHASER OR TRANSFEREE.

TV COMBINATIONS PURCHASED IN THE U.S.A. AND USED ANYWHERE OUTSIDE OF THE U.S.A.,
INCLUDING, WITHOUT LIMITATION, CANADA AND MEXICO, ARE NOT COVERED BY THESE WARRANTIES.

TV COMBINATIONS PURCHASED ANYWHERE OUTSIDE OF THE U.S.A., INCLUDING, WITHOUT LIMITATION,
CANADA AND MEXICO, AND USED IN THE U.S.A., ARE NOT COVERED BY THESE WARRANTIES.

Limited Ninety (90) Day Warranty on Labor

TA CP warrants this TV Combination and its par ts against defects in materials or workmanship for a period of ninety
(90) days after the date of original retail purchase. DURING THIS PERIOD, TACP WILL, AT TACP'S OPTION,

REPAIR OR REPLACE A DEFECTIVE PART WITH A NEW OR REFURBISHED PART WITHOUT CHARGE TO
YOU FOR PARTS OR LABOR.

Limited One (1) Year Warranty on Parts

TA CP further warrants the parts in this TV Combination against defects in materials or workmanship for a period of
one (1) year after the date of original retail purchase. DURING THIS PERIOD, TACP WILL, AT TACP'S OPTION,

REPAIR OR REPLACE A DEFECTIVE PART WITH A NEW OR REFURBISHED PART WITHOUT CHARGE TO
YOU FOR THE PART, PROVIDED THAT IF A DEFECTIVE PART IS REPAIRED OR REPLACED AFTER NINETY
(90) DAYS AFTER THE DATE OF ORIGINAL RETAIL PURCHASE, YOU MUST PAY ALL LABOR CHARGES IN
CONNECTION WITH THE REPAIR OR REPLACEMENT THEREOF.

Limited Two (2) Year Warranty on Picture Tube

TA CP further warrants the picture tube in this TV Combination against defects in materials or workmanship for a
period of two (2) years after the date of original retail purchase. DURING THIS PERIOD, TACP WILL, AT TACP'S

OPTION, REPAIR OR REPLACE A DEFECTIVE PICTURE TUBE WITH A NEW OR REFURBISHED PICTURE
TUBE WITHOUT CHARGE TO YOU, PROVIDED THAT IF A DEFECTIVE PICTURE TUBE IS REPAIRED OR
REPLACED AFTER NINETY (90) DAYS AFTER THE DATE OF ORIGINAL RETAIL PURCHASE, YOU MUST PAY
ALL LABOR CHARGES IN CONNECTION WITH THE REPAIR OR REPLACEMENT THEREOF.

Rental Units

The warranty for TV Combination rental units begins on the date of the first rental or thirty (30) days after the date of
shipment to the rental firm, whichever comes first.

Limited Warranty for Commercial Units

TA CP warrants TV Combinations that are sold and used for commercial purposes as follows: all parts are warranted
against defects in materials or workmanship for a period of ninety (90) after the date of original retail purchase.

DURING THIS PERIOD, TACP WILL, AT TACP'S OPTION, REPAIR OR REPLACE A DEFECTIVE PART WITH A
NEW OR REFURBISHED PART WITHOUT CHARGE TO YOU.

Owner's Manual and Product Registration Card

Read this owner’s manual thoroughly before operating this TV Combination.

Complete and mail the enclosed product registration card or register your TV Combination online at
service as soon as possible. By registering your TV Combination you will enable TACP to bring you new products
specifically designed to meet your needs and help us to contact you in the unlikely event a safety notification is required
under the U.S. Consumer Product Safety Act. Failure to complete and retur n the product registration card does not
diminish your warranty rights.

www.tacp.toshiba.com/

48

5X30401A [E] (P50-Back) 12/3/05, 3:31 PM48

Your Responsibility

THE ABOVE WARRANTIES ARE SUBJECT TO THE FOLLOWING CONDITIONS:

(1) You must retain your original bill of sale or provide other proof of purchase.

(2) All warranty servicing of this TV Combination must be performed by an Authorized TACP Service Station.

(3) The warranties from TACP are effective only if this TV Combination is purchased and operated in the Continental

U.S.A. or Puerto Rico.

(4) Labor service charges for set installation, setup, adjustment of customer controls, and installation or repair of

antenna systems are not covered by this warranty. Reception problems caused by inadequate antenna systems,
misaligned satellite dishes, cable television distribution, VCRs, DVD players/recorders, personal computer level
IEEE-1394 devices, and any other connected signal source device are your responsibility.

(5) Warranties extend only to defects in materials or workmanship as limited above, and do not extend to any TV

Combination or parts that have been lost or discarded by you or to damage to the TV Combination or parts
caused by fires, misuse, accident, Acts of God (such as lightning or fluctuations in electric power), improper
installation, improper maintenance, or use in violation of instructions furnished by TACP; use or malfunction
through simultaneous use of this TV Combination and connected equipment; or to units that have been modified
or had the serial number removed, altered, defaced, or rendered illegible.

How to Obtain Warranty Service

If, after following all of the operating instructions in this manual and reviewing the section entitled "Troubleshooting,"
you find that service is needed:

(1) To find the nearest TACP Authorized Service Station, visit TACP's website at www.tacp.toshiba.com/service or

contact TACP's Consumer Solution Center toll free at 1-800-631-3811.

(2) You must present your original bill of sale or other proof of purchase to the TACP Authorized Service Station. You

must deliver the entire TV Combination to a TACP Authorized Service Station. You must pay for all transportation
and insurance charges for the TV Combination to and from the TACP Authorized Service Station.

For additional information, visit TACP's website:

www.tacp.toshiba.com

ALL WARRANTIES IMPLIED BY THE LAW OF ANY STATE OF THE U.S.A., INCLUDING THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE EXPRESSLY
LIMITED TO THE DURATION OF THE LIMITED WARRANTIES SET FORTH ABOVE. WITH THE EXCEPTION OF
ANY WARRANTIES IMPLIED BY THE LAW OF ANY STATE OF THE U.S.A. AS HEREBY LIMITED, THE
FOREGOING WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES, GUARANTEES,
AGREEMENTS, AND SIMILAR OBLIGATIONS OF TACP WITH RESPECT TO THE REPAIR OR REPLACEMENT
OF ANY PARTS. IN NO EVENT SHALL TACP BE LIABLE FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES
(INCLUDING, BUT NOT LIMITED TO, LOST PROFITS, BUSINESS INTERRUPTION, OR MODIFICATION OR
ERASURE OF RECORDED DATA CAUSED BY USE, MISUSE OR INABILITY TO USE THIS TV COMBINATION).

No person, agent, distributor, dealer, or company is authorized to change, modify, or extend the terms of these warranties
in any manner whatsoever. The time within which an action must be commenced to enforce any obligation of TACP
arising under the warranty or under any statute or law of the United States or any state thereof is hereby limited to
ninety (90) days from the date you discover, or should have discovered, the defect. This limitation does not apply to
implied warranties arising under the law of any state of the U.S.A.

THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS AND YOU MAY ALSO HAVE OTHER RIGHTS
WHICH MAY VARY FROM STATE TO STATE IN THE U.S.A. SOME STATES OF THE U.S.A. DO NOT ALLOW
LIMITATIONS ON THE DURATION OF AN IMPLIED WARRANTY, WHEN AN ACTION MAY BE BROUGHT, OR
THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES. THEREFORE, THE
ABOVE PROVISIONS MAY NOT APPLY TO YOU UNDER SUCH CIRCUMSTANCES.

Others

5X30401A [E] (P50-Back) 12/3/05, 3:31 PM49

49

Memo

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

5X30401A [E] (P50-Back) 12/3/05, 3:31 PM50

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

...................................................................................................................................

5X30401A [E] (P50-Back) 12/3/05, 3:31 PM51

J5X30401A SH 05/12

5X30401A [E] (P50-Back) 12/3/05, 3:31 PM52

N

Printed in Thailand
