CAMILEO® X400 Series User’s Guide

English/Español

GMAA00341011 08/11

Regulatory Information

FCC Information

Product Name: Camcorder

Model number: CAMILEO

FCC notice “Declaration of Conformity Information”

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

❖ Reorient or relocate the receiving antenna.

❖ Increase the separation between the equipment and receiver.

❖ Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

❖ Consult the dealer or an experienced radio/TV technician for help.

X400 Series

Changes or modifications made to this equipment, not expressly approved by TOSHIBA or parties authorized by TOSHIBA could void the user’s authority to operate the equipment.

FCC Conditions

This equipment has been tested and found to comply with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference.

(2) This device must accept any interference received. Including interference that may cause undesired operation.

Contact

Address: TOSHIBA America Information Systems, Inc.

9740 Irvine Boulevard Irvine, California 92618-1697

Telephone: (949) 583-3000

Safety Instructions

1 Do not drop, puncture or disassemble the camcorder; otherwise the

warranty will be voided.

2 Avoid all contact with water, and dry hands before using.

3 Do not expose the camcorder to high temperature or leave it in direct

sunlight. Doing so may damage the camcorder.

4 Use the camcorder with care. Avoid pressing hard on the camcorder body.

5 For your own safety, avoid using the camcorder when there is a storm or

lightning.

6 Do not use batteries of different specifications. Doing so may lead to the

potential for serious damage.

7 Remove the battery during long periods between usage, as a deteriorated

battery may affect the functionality of the camcorder.

8 Remove the battery if it shows signs of leaking or distortion.

9 Use only the accessories supplied by the manufacturer.

10 Keep the camcorder out of the reach of infants.

11 Risk of explosion if battery is replaced by an incorrect type.

12 Dispose of used batteries according to the instructions.

About the battery

❖ Use only batteries recommended by TOSHIBA as replacements. The

battery is a lithium ion battery, which can explode if not replaced, used, handled or disposed of properly. Dispose of the battery as required by local ordinances or regulations.

❖ Charge the battery only in an ambient temperature between 41 and 95

degrees Fahrenheit (5 and 35 degrees Celsius). Otherwise, the electrolyte solution might leak, battery performance might deteriorate and the battery life might be shortened.

❖ Never install or remove the battery without first turning off the power and

disconnecting the AC adaptor.

❖ Only use the supplied AC adaptor or USB cable, or an optional Toshiba

battery charger to charge the battery. Never attempt to charge the battery with any other charger.

About the remote control battery

Chemical burns and choking hazard due to battery ingestion

The remote control supplied with this camcorder contains a button cell battery. Keep the button cell battery out of reach of children. If swallowed, the button cell battery can cause serious injury or death. Severe burns can occur within hours of ingestion. If you suspect that a button cell battery has been swallowed, seek immediate medical attention.

Use care when changing the button cell battery. Keep all new and used button cell batteries out of reach of children and ensure that the battery compartment is completely secure after replacing the battery. If the battery compartment cannot be completely secured, discontinue use of the remote control and contact the manufacturer.

Use only button cell batteries recommended by the manufacturer as replacements. The button cell battery can explode if not replaced, used, handled, or disposed of properly. Dispose of the button cell battery as required by local ordinances or regulations.

California Perchlorate Information:

Products containing CR (manganese dioxide) lithium coin cell batteries may contain perchlorate. Perchlorate Material – special handling may apply. See http://www.dtsc.ca.gov/hazardouswaste/perchlorate.

Safety icons

NOTE

This manual contains safety instructions that must be observed to avoid potential hazards that could result in personal injuries, damage to your equipment, or loss of data. These safety cautions have been classified according to the seriousness of the risk, and icons highlight these instructions as follows:

Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.

Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.

Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.

Indicates a potentially hazardous situation which, if not avoided, may result in property damage.

Provides important information.

Additional Information

© Copyright 2011 TOSHIBA CORPORATION. All rights reserved. TOSHIBA reserves the right to make technical changes. TOSHIBA assumes no liability for damages incurred directly or indirectly from errors, omissions or discrepancies between this product and the documentation.

Trademarks

CAMILEO is a registered trademark of Toshiba America Information Systems, Inc. and/or Toshiba Corporation.

Adobe and Adobe Reader are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries.

ArcSoft, MediaImpression, and MediaConverter are registered trademarks of ArcSoft, Inc.

Facebook is a registered trademark of Facebook Inc.

HDMI, the HDMI Logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing, LLC.

Intel, Intel Core, Celeron, Centrino and Pentium are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries.

Mac is a trademark of Apple Inc., registered in the U.S. and other countries.

Microsoft, Windows, and Windows Vista are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.

Picasa is a trademark of Google Inc.

Secure Digital and SD are trademarks of SD Card Association.

YouTube and the YouTube logo are registered trademarks of Google, Inc.

All other brand and product names are trademarks or registered trademarks of their respective companies.

Chapter 1: Getting to Know Your Camcorder.......................... 10

Overview ................................................................10

Check the components .....................................11

System requirements........................................11

Front view .........................................................12

Rear view..........................................................12

Side view ..........................................................13

Underside view .................................................13

Chapter 2: Getting Started......................................................... 14

Loading the battery.................................................14

Charge your battery ..........................................16

Inserting and removing an SD™ Card (optional).....20

Protecting data on an SD™ Card.......................21

Turning the camcorder on and getting started .......22

Turning off the camcorder ......................................22

Chapter 3: Record Mode........................................................... 23

Button functions .....................................................23

LCD touch screen information ................................24

Notification icons..............................................24

Contents

Touch function icons ........................................26

Video recording ......................................................27

Photo recording......................................................28

Using Digital Light or Light function .......................28

Using the Zoom function ........................................28

Menu options/operations........................................29

Video Setting options........................................30

Photo Setting options .......................................36

Effects...............................................................40

Deleting files .....................................................43

Chapter 4: Playback Mode........................................................46

Button functions .....................................................46

LCD touch screen information ................................47

Notification icons..............................................47

Touch function icons ........................................48

Playback mode operations......................................49

Video Playback..................................................50

Photo Playback .................................................50

Delete a file in Playback mode...........................50

Video Trim ..............................................................51

Chapter 5: Camcorder Settings ................................................ 52

Setup Menu ............................................................52

Menu Sound .....................................................52

TV .....................................................................53

Language ..........................................................53

Time Settings....................................................54

Format ..............................................................54

Default Setting ..................................................55

Chapter 6: Viewing Photos and

Videos on TV.....................................................57

Connecting to a high-definition 16:9

(wide) TV ..........................................................57

Contents

Chapter 7: Viewing Photos and

Videos on a Computer...................................... 59

Installing bundled software.....................................59

Transferring photos or videos to a computer..........60

Chapter 8: Uploading Video and Photo Files to the

Internet............................................................... 61

CAMILEO® Uploader ...............................................62

Setting up your account information

for a Web site..............................................64

Chapter 9: Webcam Mode........................................................ 66

Chapter 10: Specifications ........................................................ 67

Operating Environment Conditions .........................68

Chapter 11: Troubleshooting.................................................... 69

Chapter 12: Other Information.................................................. 71

Toshiba Support .....................................................71

Before you call ..................................................71

Contacting Toshiba .................................................72

Toshiba’s technical support Web site................72

Toshiba voice contact .......................................72

Warranty.................................................................73

Online Warranty Information.............................73

Warranty Service ..............................................73

Chapter 1

Getting to Know Your Camcorder

Overview

Your Toshiba camcorder comes equipped with a 5MP sensor that can record H.264 format movies. This format allows for extended video recording with less memory.

Other features of your CAMILEO

❖ 23x optical zoom ❖ 120x digital zoom ❖ High quality images up to 16 megapixels ❖ 3” color LCD touch screen for easy viewing of video, pictures

and onscreen menus

❖ On-screen video trimming

❖ Video recording at full HD resolution of 1920 x 1080p ❖ Pause button to record multiple moments in a single file

❖ Electronic Image Stabilization to record smoother videos ❖ HDTV connectivity via a mini HDMI™ cable ❖ Built-in CAMILEO

videos captured by the camcorder to the Internet (for Windows

❖ Various effect options, such as Time Lapse and Slow Motion ❖ Built-in memory allowing you to take pictures and to record

movies without a memory card.

based systems only)

Uploader, allowing you to easily upload

X400 Series camcorder are:

A portion of the built-in memory is used for Firmware to operate the

NOTE

camcorder.

❖ Memory card slot allowing you to increase storage capacity.

Check the components

Unpack the box and make sure all items listed below are included:

Getting to Know Your Camcorder

Overview

Camcorder Mini USB cable Mini HDMI™ cable AC adaptor

Quick Start CD-ROM

Guide Software, User’s

Guide (this document),

and Warranty information

Cleaning cloth

Deluxe soft case Remote control AV to mini USB

(Sample Illustration) Components

*Preinstalled in the camcorder

Be sure to remove the protective film on the lens before using.

System requirements

❖ Microsoft® Windows® XP/Windows Vista®/Windows® 7 ❖ Intel ❖ 512 MB RAM ❖ 1 GB free HDD space ❖ 4x CD-ROM Drive ❖ Available USB 2.0 port

Mac compatibility

❖ Mac OS 10.6 or above ❖ CPU Intel ❖ 1 GB system memory ❖ 1 GB free HDD space ❖ DVD-ROM ❖ Available USB 2.0 port

Pentium® 4, 2.4 GHz or above

Core™ 2 Duo 2.4 GHz or above

Lithium-ion

rechargeable

battery*

Lens cover set

(lens cover

and strap)

cable

NOTE

Front view

Light

Getting to Know Your Camcorder

Overview

The LCD touch screen is manufactured using extremely high-precision technology. However, some tiny black and/or bright dots (white, red, blue or green) may appear on the LCD touch screen. These dots are a normal result of the manufacturing process, and do not affect the recording.

Photo button

Tele/Wide button

Speaker

Lens

IR receiver

Microphone

(Sample Illustration) Front view

Rear view

Mini USB/Mini HDMI™ port cover

(Sample Illustration) Rear view

LCD touch screen

Indicator light

Pause button

Video button

Side view

Getting to Know Your Camcorder

Overview

LCD touch screen

(Sample Illustration) Side views

Underside view

(Sample Illustration) Underside view

Microphone jack cover

Battery/SD™ Card coverTripod socket

Power button

Playback button

Light button

Chapter 2

Getting Started

Loading the battery

Before using the camcorder, you will need to remove the protective film from the battery. To do so, remove the battery, then remove the film, and replace the battery as shown below.

The battery comes pre-installed in the camcorder, however, you must remove the protective film on the battery before use.

To properly connect the battery:

1 Slide the safety latch and open the battery cover.

(Sample Illustration) Opening the battery cover

Getting Started

NOTE

Loading the battery

2 Remove the battery.

3 Pull the protective film off.

Protective film

Li-ion battery

(Sample Illustration) Removing the protective film

4 Reinsert the battery, making sure it is lined-up with the correct

polarity marks.

Li-ion battery

(Sample Illustration) Reinserting the battery

Be sure the orange latch is engaged after inserting the battery.

5 Close the battery cover.

Getting Started

Loading the battery

Charge your battery

You must use the supplied AC adaptor or the USB cable to charge your camcorder before use. Turn off the camcorder. A blinking light indicates active charging, and a solid light indicates that charging is complete. In AC charging mode, the light will turn off automatically after the battery is fully charged. The full charge time is approximately 4 hours.

(Sample Illustration) Charging the battery

Handling of the battery

❖ Never attempt to dispose of a battery by burning or by throwing

❖ Never attempt to disassemble, tamper with or repair a battery.

❖ Never short-circuit the battery by either accidentally or

it into a fire, and never allow exposure to a heating apparatus (e.g., microwave oven). Heat can cause a battery to explode and/or release caustic liquid, both which may possibly cause serious injury.

The battery could overheat and ignite. Leakage of the caustic alkaline solution or other electrolytic substances could cause fire, possibly resulting in death or serious injury.

intentionally bringing the battery terminals in contact with another conductive object. This could cause serious injury or a fire, and could also damage the battery and product. Always wrap the battery in plastic (or place it in a plastic bag) whenever transporting it, to avoid exposing the terminals to another conductive object which could result in serious injury. Always cover the metal terminals with insulating tape when disposing of the battery, to prevent accidental short-circuiting which could result in serious injury.

Getting Started

Loading the battery

❖ Never drive a nail or any other sharp object into the battery, hit

battery with a hammer or other object or step on it. Doing so could cause a fire or explosion possibly resulting in serious injury.

❖ Never charge the battery by a method other than as instructed.

Doing so could cause a fire or explosion possibly resulting in serious injury.

❖ Never connect the battery to a plug socket or a car cigarette plug

socket. The battery could rupture or ignite causing a fire or explosion possibly resulting in serious injury.

❖ Never allow a battery to become wet. A wet battery will overheat

or ignite causing rupture or fire, possibly resulting in death or serious injury.

❖ Never store a battery in an area of high humidity. This could

cause a fire or explosion possibly resulting in serious injury.

❖ Never expose a battery to abnormal shock, vibration or pressure.

Never use a battery which has been exposed to abnormal shock even if the appearance is normal. The battery’s internal protective device could fail, causing it to overheat or ignite resulting in caustic liquid leakage, or explosion or fire, possibly resulting in death or serious injury.

❖ Never subject a battery to heat, and never store it or use it near a

heat source. The battery could ignite or explode when heated or burned, possibly resulting in death or serious injury. Subjecting a battery to heat could also cause caustic liquid to leak. It can also cause failure, malfunction, or loss of stored data.

Use of correct battery

❖ Always use the battery supplied. Other batteries have different

voltage and terminal polarities. Use of non-conforming batteries could generate smoke or cause fire or rupture, possibly resulting in serious injury.

Getting Started

Loading the battery

Battery safety

❖ Never allow caustic electrolyte fluid leaked from the battery to

contact your eyes, body or clothing. Use appropriate protective gloves when handling a damaged

battery. If caustic electrolyte fluid from the battery should contact your

eyes, immediately wash your eyes with large amounts of running water and obtain prompt medical attention, to help prevent permanent eye damage.

If electrolyte fluid should contact any part of your body, immediately wash it off under running water to help prevent skin rashes.

If electrolyte fluid should contact your clothes, promptly remove them to help prevent the electrolyte fluid from contacting your body, possibly resulting in serious injury.

Battery warning indicators

❖ Always immediately turn the power off and disconnect the power

cable/cord plug from the plug socket and stop using the battery if you observe any of the following conditions:

❖ Offensive or unusual odor ❖ Excessive heat ❖ Discoloration ❖ Deformation, cracks or leaks ❖ Smoke ❖ Other unusual event during use, such as abnormal sound

In such an event, carefully and immediately remove the battery from the product. In some instances, you might have to wait for the product to cool down before removing the battery, in order to avoid any possible minor injury due to heat exposure. Do not turn on the product’s power again until an authorized Toshiba service provider has checked it for safety. Continued use could cause a fire or rupture possibly resulting in serious injury or product failure including but not limited to the loss of data.

Getting Started

NOTE

Loading the battery

Disposal of used batteries

❖ Always dispose of used batteries in compliance with all

applicable laws and regulations. Put insulating tape, such as cellophane tape, on the electrode during transportation to avoid a possible short circuit, fire or electric shock. Failure to do so could possibly result in serious injury.

Inserting the battery

❖ When installing a battery or before moving the product, always

make sure the battery is inserted correctly and securely. If the battery falls out, while you are carrying the product, you could be injured or the battery could be damaged.

Do not use an impaired or exhausted battery

❖ Never continue to use a battery after its recharging capability has

become impaired, or after the warning message indicating that the battery power is exhausted has been displayed.

Continued use of an exhausted or impaired battery could result in the loss of data or damage to the product.

Handling of the battery

❖ Never attempt to install batteries in reverse polarity.

❖ Make sure the battery is securely installed in the product before

attempting to charge the battery.

❖ Improper installation could generate smoke or fire, or cause the

battery to rupture.

NOTE

Getting Started

Inserting and removing an SD™ Card (optional)

❖ The battery is a lithium ion battery, which can explode if not

replaced, used, handled or disposed of properly. Dispose of the battery as required by local ordinances or regulations. Use only batteries recommended by TOSHIBA as replacements.

❖ Charge the battery only in an ambient temperature between 41

and 95 degrees Fahrenheit (5 and 35 degrees Celsius). Otherwise, the electrolyte solution might leak, battery performance might deteriorate and the battery life might be shortened.

❖ Never install or remove the battery without first turning off the

power and disconnecting the AC adaptor.

Inserting and removing an SD™ Card (optional)

An SD™ Card may need to be purchased separately.

Your camcorder comes with internal memory that allows you to store pictures and movies. You can expand the memory capacity by using an optional SD/SDHC/SDXC memory card.

1 Slide the safety latch and open the SD™ Card cover.

(Sample Illustration) Opening the SD™ Card cover

Getting Started

NOTE

Inserting and removing an SD™ Card (optional)

2 Insert the memory card into the slot until it locks in place as

shown below.

To remove the SD™ Card, press inward to release it. When the card pops out, grasp it and pull it

straight out.

(Sample Illustration) Inserting and removing an SD™ Card

To prevent data corruption, it is recommended that you format the SD™ Card in the camcorder before using.

All data will be erased if the SD™ Card is formatted. Make sure all data is copied to your computer or other media before formatting the SD™ Card.

When a memory card is inserted, photos and videos are saved onto the card rather than the built-in memory.

Protecting data on an SD™ Card

Photos or videos cannot be recorded on an SD™ Card when the card is locked (read only); however, photos and videos can be viewed.

Make sure the lock is in the writable position before recording photos and videos as shown below.

Write-protectedWritable

position position

(Sample Illustration) Protecting data on an SD™ Card

Getting Started

Turning the camcorder on and getting started

To turn on the camcorder, either:

❖ Flip the LCD touch screen outward to turn on the camcorder

automatically.

❖ Or press the Power ( ) button for approximately one second

to turn it on.

To record videos: Press the Video ( ) button to begin recording. Press it again to stop recording.

To take a still photo while recording a video: Press the Photo ( ) button.

To take a photo: Press the Photo ( ) button halfway down to focus until the focusing frame turns green. Then press it fully to take the photo.

Focusing frame: White Focusing frame: Green

(Sample Image) Focusing frames (green and white)

To view stored movies and pictures: Press the Playback ( ) button or touch the onscreen icon to switch to Playback mode.

Turning off the camcorder

To turn off the camcorder, either press the Power ( ) button for one second, or place the LCD touch screen back to its original position.

Chapter 3

Record Mode

Button functions

Video button:

1 Press to begin recording a video. 2 Press it again to stop recording.

Pause button:

1 Press to pause recording. 2 Press it again to resume recording on the same file.

Photo button:

1 Press halfway down to focus, then press it fully to take the

photo.

2 To take a photo during video recording press the photo button to

capture the image.

Note: The photo resolution will be the same as the video resolution. Tele (T) button:

Zoom in.

Wide (W) button:

Zoom out.

Power button:

Press for one second to turn the camcorder ON/OFF.

NOTE

Record Mode

LCD touch screen information

Playback button:

Switch between Record/Playback mode.

Light button:

Press to toggle the Light settings (Light ON, Light OFF, Digital light).

Touch the LCD touch screen to show the status of the setting.

LCD touch screen information

The indicators shown on the images below may appear on the LCD touch screen when photos and videos are recorded:

Onscreen notification icons Onscreen touch function icons

(Sample Image) LCD touch screen indicators

Notification icons

123

Battery: Full power

Battery: Medium power

Battery: Low power

Battery: No power

DC power mode

Macro mode for close ups

91011

151413 1612

Record Mode

LCD touch screen information

00:03:12

250

321

Scene

White balance

Recording time

Pause recording

The remaining amount of photos that can be taken at the current resolution settings

Current number of photos taken

Motion Detection (Video Record mode only)

Skin

Night

Backlight

Auto

Daylight

Fluorescent

Tungsten

Zoom meter: 1x~2700x (23x Optical Zoom, 120x Digital Zoom)

Slow Motion (Video Record mode only) Note: Slow motion videos will be recorded in WQVGA

resolution (432 x 240 [WQVGA]).

Time Lapse (Video Record mode only)

Pre-Record mode (Video Record mode only)

Record Mode

LCD touch screen information

Touch function icons

Digital light ON

Video Resolution

Photo resolution

Video Record mode

Photo Record mode

Light ON

Light OFF

Full HD (1080p 30)

60p

HD60 (720p 60)

HD30 (720p 30)

VGA (480p 30)

WQVGA (while the Slow Motion function is active, the video resolution is 432 x 240 [QVGA])

High-16MP

Standard-5MP

Low-3MP

Backlight ON/OFF

Self-timer ON/OFF

Playback mode

Photo mode

Video mode

Delete mode

❖ Tap on the screen to close the touchable function bars. Tap

NOTE

❖ Filter: Black & White/Classic/Negative can be previewed

❖ Stabilization, Time Lapse, and Slow Motion functions can not be

❖ Stabilization and Night mode functions can not be used

❖ Pre-Record, Motion Detection, Time Lapse, and Slow Motion

❖ The camcorder does not power off automatically in DC power

Video recording

Press the Video ( ) button to start recording. A time indicator displays on the LCD touch screen while recording a video. Press the Video button again to stop recording.

To pause recording, press the Pause ( ) button. To continue recording, press it again.

To take a still photo while recording a video, press the Photo ( ) button.

Touch the onscreen Playback ( ) icon to view a recorded video.

The resolution settings available are:

Record Mode

Video recording

again to show the bars.

immediately without the indicator on the LCD screen.

used simultaneously.

simultaneously.

functions can not be used simultaneously.

mode.

Video Quality

Full HD 1080/30: 1920 x 1080p 30fps

60p

HD60 720/60: 1280 x 720p 60fps HD30 720/30: 1280 x 720p 30fps VGA 480/30: 640 x 480p 30fps

The image resolution captured during video recording is the same as the video resolution.

NOTE

Record Mode

Photo recording

Press the Photo ( ) button halfway down until the focusing frame turns from white to green. Then press it fully down to take a photo.

Press the Playback button or touch the onscreen ( ) icon to view the photo.

The Resolution settings available are:

Image Quality High-16MP: 4608 x 3456 Standard-5MP: 2592 x 1944 Low-3MP: 2048 x 1536

Using Digital Light or Light function

This setting allows you to brighten the subject or extend the dynamic range of high contrast and backlight, so objects appear brighter and clearer.

1 Press the Light button.

The Digital Light ( ) icon appears on the screen.

2 Press the Light button again.

The Light ( ) icon appears on the screen. The light turns ON, providing illumination while recording.

3 Press the Video/Photo button to start recording or to take a

photo.

4 Press the Light button again to turn it OFF.

The light is disabled automatically when battery power is low.

Using the Zoom function

The Zoom function magnifies images when recording Videos or taking Photos.

❖ Press the Tele/Wide (T/W) buttons to zoom IN/OUT.

The camcorder zooms in by Optical Zoom first. When the Optical Zoom factor is at maximum, zooming stops temporarily. Press and hold the Tele (T) button when you want to zoom in beyond the Optical Zoom range. The Digital Zoom is activated and zooming continues.

Record Mode

Menu options/operations

❖ The Zoom function can be set from 1x~2700x (23x Optical

Zoom and 120x Digital Zoom).

Menu options/operations

Video Setting Photo Setting Effects Setup* Delete

Light Resolution Stabilization Motion Detection Face Tracking Slow Motion Pre-Record Time Lapse Date Printing Continuous Play

Light Resolution Self-Timer Smile Detection Date Printing ISO Slideshow

Macro mode Exposure Measure Scene Filter White Balance

Menu Sound TV Language Time Setting Format Default Setting

Delete Video Delete Photo Select & Delete Delete All

*Please see “Camcorder Settings” on page 52 for more information about Setup.

Operation Screen

1 Touch the onscreen ( ) icon.

The Menu screen appears. The available options are Video Setting,

Photo Setting, Effects, Setup, and Delete.

2 Touch the desired onscreen icon twice.

The options menu appears.

3 Touch to select the specific option you

want to change, and touch it again to enter its settings menu.

4 Touch twice to validate the new

setting.

5 Touch the Return/Exit ( ) icon twice,

or hold it down to exit.

NOTE

Record Mode

Menu options/operations

Video Setting options

Operation Screen

1 Touch the onscreen ( ) icon.

The Menu screen appears.

2 Touch the Video Setting icon twice.

The Video Setting menu appears.

3 The Video Setting menu options are:

Light, Resolution, Stabilization, Motion Detection, Face Tracking, Slow Motion, Pre-Record, Time Lapse, Date Printing, and Continuous Play.

Touch the icon once to view the description, touch twice to activate.

Light

In this option, select a mode to brighten the shooting area or to extend the brightness of objects. The Light settings available are:

ON Turns the light ON, providing illumination when recording.

OFF Turns the light OFF.

Digital Light

Operation Screen

1 In the Video Setting menu, touch the

Light icon twice.

2 Touch to select the desired option. 3 Touch again to validate the new

setting.

4 Touch the Return/Exit ( ) icon twice,

or hold it down to exit.

Extends the dynamic range of high contrast and backlight, so objects appear brighter and clearer.

Resolution

The Resolution settings available are:

Full HD 1080/30 Records videos at 1920 x 1080p 30fps resolution.

HD 720/60 Records videos at 1280 x 720p 60fps resolution.

HD 720/30 Records videos at 1280 x 720p 30fps resolution.

VGA 480/30 Records videos at 640 x 480p 30fps resolution.

Operation Screen

1 In the Video Setting menu, touch the

Resolution icon twice.

2 Touch to select the desired option. 3 Touch again to validate the new

setting.

4 Touch the Return/Exit ( ) icon twice,

or hold it down to exit.

Record Mode

Menu options/operations

Stabilization

Your camcorder provides a feature that steadies the image to help create clearer videos.

Operation Screen

1 In the Video Setting menu, touch the

Stabilization icon twice.

2 Touch to select the desired option. 3 Touch again to validate the new

setting.

4 Touch the Return/Exit ( ) icon twice,

or hold it down to exit.

Record Mode

Menu options/operations

Motion detection

This option allows the camcorder to automatically record videos when the camcorder detects movement.

Operation Screen

1 In the Video Setting menu, touch the

Motion Detect icon twice.

2 Touch to select the desired option. 3 Touch again to validate the new

setting.

4 Touch the Return/Exit ( ) icon twice,

or hold it down to exit. The camcorder will begin recording

automatically if movement is detected. It stops recording when movement stops.

Face Tracking

The camcorder detects and focuses on face(s) automatically. This function helps to capture subjects in backlit conditions.

Operation Screen

1 In the Video Setting menu, touch the

Face Tracking icon twice.

2 Touch to select the desired option. 3 Touch again to validate the new

setting.

4 Touch the Return/Exit ( ) icon twice,

or hold it down to exit.

In Record mode, when the camcorder is aimed at face(s), the face frame(s) appear.

Slow motion

NOTE

This option allows recording of videos with a slow motion effect. When the video is played, the playback time will be longer than the actual recording time.

Operation Screen

1 In the Video Setting menu, touch the

Slow Motion icon twice.

2 Touch to select the desired option. 3 Touch again to validate the new

setting.

4 Touch the Return/Exit ( ) icon twice,

or hold it down to exit.

❖ While using the Slow Motion setting, audio is not recorded and

zoom is disabled.

❖ The view angle may become smaller when the Slow Motion

function is activated.

❖ When the Slow Motion function is activated, the video resolution

is WQVGA.

Record Mode

Menu options/operations

Pre-Record

The Pre-Record function allows the camcorder to begin recording a few seconds before the Record button is pressed.

Touch the icon once to view the description, touch twice to activate.

Operation Screen

1 In the Video Setting menu, touch the

Pre-Record icon twice.

2 Touch to select the desired option. 3 Touch again to validate the new

setting.

4 Touch the Return/Exit ( ) icon twice,

or hold it down to exit.

NOTE

Record Mode

Menu options/operations

❖ Be sure to aim the camcorder at the subject and position it

securely before the Video button is pressed

❖ The Pre-Record function is disabled when another video setting

is activated.

Time Lapse

This option allows the camcorder to record still images at specific time intervals that can then be played back as one video file. The Time Lapse settings available are:

OFF Disables Time Lapse.

1 second Records one frame per second.

3 seconds Records one frame every three seconds.

5 seconds Records one frame every five seconds.

Operation Screen

1 In the Video Setting menu, touch the

Time Lapse icon twice.

2 Touch to select the desired option. 3 Touch again to validate the new

setting.

4 Touch the Return/Exit ( ) icon twice,

or hold it down to exit.

Date Printing

This option imprints the date and time on each video.

Operation Screen

1 In the Video Setting menu, touch the

Date Printing icon twice.

2 Touch to select the desired option. 3 Touch again to validate the new

setting.

4 Touch the Return/Exit ( ) icon twice,

or hold it down to exit.

When this function is activated, the date appears on the corner of the video.

Continuous Play

This option allows you to playback files continuously.

Record Mode

Menu options/operations

Operation Screen

1 In the Video Setting menu, touch the

Continuous Play icon twice.

2 Touch to select the desired option. 3 Touch again to validate the new

setting.

4 Touch the Return/Exit ( ) icon twice,

or hold it down to exit.

Record Mode

Menu options/operations

Photo Setting options

Operation Screen

1 Touch the onscreen ( ) icon.

The Menu screen appears.

2 Touch the Photo Settings icon twice.

The Photo Setting Menu appears.

3 The Photo Setting menu options are:

Light, Resolution, Self-Timer, Smile Detection, Date Printing, ISO, and Slideshow.

Light

In this option, select a mode to brighten the shooting area or to extend the brightness of objects. The Light settings available are:

ON Turns the light ON, providing illumination when recording.

OFF Turns the light OFF.

Digital Light

Operation Screen

1 In the Photo Setting menu, touch the

Light icon twice.

2 Touch to select the desired option. 3 Touch again to validate the new

setting.

4 Touch the Return/Exit ( ) icon twice,

or hold it down to exit.

Extends the dynamic range of high contrast and backlight, so objects appear brighter and clearer.

Resolution

The Resolution settings available are:

High-16MP Takes photos at 4608 x 3456, 16MP quality.

Standard-5MP Takes photos at 2592 x 1944, 5MP quality.

Low-3MP Takes photos at 2048 x 1536, 3MP quality.

Operation Screen

1 In the Photo Setting menu, touch the

Resolution icon twice.

2 Touch to select the desired option. 3 Touch again to validate the new

setting.

4 Touch the Return/Exit ( ) icon twice,

or hold it down to exit.

Self-Timer

The Self-Timer allows you to take photos with a ten-second time delay.

Record Mode

Menu options/operations

Operation Screen

1 In the Photo Setting menu, touch the

Self-Timer icon twice.

2 Touch to select the desired option. 3 Touch again to validate the new

setting.

4 Touch the Return/Exit ( ) icon twice,

or hold it down to exit.

Record Mode

Menu options/operations

Smile Detection

The camcorder automatically takes the photo when it detects a smile.

Operation Screen

1 In the Photo Setting menu, touch the

Smile Tracking icon twice.

2 Touch to select the desired option. 3 Touch again to validate the new

setting.

4 Touch the Return/Exit ( ) icon twice,

or hold it down to exit.

In Photo mode, when the camcorder is aimed at face(s), the face frame(s) appear around a smiling face and automatically take the photo.

Date Printing

This option imprints the date and time on each photo.

Operation Screen

1 In the Photo Setting menu, touch the

Date Printing icon twice.

2 Touch to select the desired option. 3 Touch again to validate the new

setting.

4 Touch the Return/Exit ( ) icon twice,

or hold it down to exit.

When this function is activated, the date appears on the corner of each photo.

ISO

NOTE

The camcorder automatically adjusts the ISO setting of images. Four manual ISO sensitivity settings are also available (800/1600/3200/6400). Use the higher setting to take a photo in the dark or in a poorly lit location, or for a subject moving at a high rate of speed.

Auto

800 ISO 800

1600 ISO 1600

3200 ISO 3200

6400 ISO 6400

Operation Screen

1 In the Photo Setting menu, touch the

ISO icon twice.

2 Touch to select the desired option. 3 Touch again to validate the new

setting.

4 Touch the Return/Exit ( ) icon twice,

or hold it down to exit.

Sets the ISO setting automatically according to conditions.

Record Mode

Menu options/operations

The image may become grainy with a higher ISO setting.

Slideshow

Photos can be viewed one after another in a slideshow in a chosen interval of time. The Slideshow settings available are:

2 seconds Displays one photo every two seconds.

5 seconds Displays one photo every five seconds.

10 seconds Displays one photo every ten seconds.

OFF Disables Slideshow.

1 In the Photo Setting menu, touch the

Slideshow icon twice.

2 Touch to select the desired option. 3 Touch again to validate the new

setting.

4 Touch the Return/Exit ( ) icon twice,

or hold it down to exit.

Record Mode

Menu options/operations

Operation Screen

Effects

Operation Screen

1 Touch the onscreen ( ) icon.

The Menu screen appears.

2 Touch the Effects icon twice.

The Effects menu screen appears.

3 The Effects menu options are: Macro

mode, Exposure Measure, Scene, Filter, and White Balance.

Macro mode

The camcorder adjusts the focus automatically. When this function is activated, the camcorder adjusts the focus with priority on close-up objects that are at a distance of approximately

0.39 - 47.24 ins. (1 - 120cm).

Operation Screen

1 In the Effects menu, touch the Macro

mode icon twice.

2 Touch to select the desired option. 3 Touch again to validate the new

setting.

4 Touch the Return/Exit ( ) icon twice,

or hold it down to exit.

Exposure Measure

The camcorder adjusts the exposure (amount of light the camcorder receives from the scene) automatically. The Exposure settings available are:

The camcorder meters the light in an average value for the overall scene and

Auto

adjusts the exposure automatically. This setting is suitable for normal conditions.

The camcorder still meters the light in an average value for the entire scene, but gives greater weight to the center. This

Center

way, the center of the image appears more clear, while the surrounding may appear darker.

The camcorder only meters the light in the middle spot of the scene. This setting is

Spot

typically used, for example, in capturing the light of a candle.

Operation Screen

1 In the Effects menu, touch the

Exposure Measure icon twice.

2 Touch to select the desired option. 3 Touch again to validate the new

setting.

4 Touch the Return/Exit ( ) icon twice,

or hold it down to exit.

Record Mode

Menu options/operations

Scene

You can select a mode according to the scene and conditions. The Scene settings available are:

Auto Automatically adjusts to current conditions.

Skin Adjusts skin tones to appear more natural.

Night Use in low light conditions or at night.

Backlight Use when the subject is brightly lit from behind.

NOTE

1 In the Effects menu, touch the Scene

icon twice.

2 Touch to select the desired option. 3 Touch again to validate the new

setting.

4 Touch the Return/Exit ( ) icon twice,

or hold it down to exit.

Record Mode

Menu options/operations

Operation Screen

To avoid blurry photos when taking photos in Night mode, place the camcorder on a flat, steady surface, or use a tripod.

Filter

You can select a special filter effect for photos and videos. The Filter settings available are:

Auto No filter effects.

Black & White The image is converted to black and white.

Classic The image is converted to sepia.

Negative The image is converted to a negative of the original.

Operation Screen

1 In the Effects menu, touch the Filter

icon twice.

2 Touch to select the desired option. 3 Touch again to validate the new

setting.

4 Touch the Return/Exit ( ) icon twice,

or hold it down to exit.

Scene/Filter: B/W / Classic / Negative effect can be previewed immediately without icons appearing on the LCD touch screen.

White Balance

The camcorder adjusts the white balance of images automatically. The White Balance settings available are:

Auto Automatically adjusts white balance.

Daylight Use in outdoor conditions.

Fluorescent Use in fluorescent lighting.

Tungsten Use in tungsten lighting.

Operation Screen

1 In the Effects menu, touch the White

Balance icon twice.

2 Touch to select the desired option. 3 Touch again to validate the new

setting.

4 Touch the Return/Exit ( ) icon twice,

or hold it down to exit.

Record Mode

Menu options/operations

Deleting files

Operation Screen

1 Touch the onscreen ( ) icon.

The Menu screen appears.

2 Touch the Delete icon twice. 3 The Delete menu appears. 4 The Delete menu options are: Delete

Video, Delete Photo, Select & Delete, and Delete All.

Record Mode

Menu options/operations

Deleting Video(s)

Operation Screen

1 In the Delete menu, touch the Delete

Video icon twice.

2 Touch to select the desired thumbnail

video(s). Check mark(s) will indicate the selected file(s).

3 Touch the Delete icon to delete the

selected video(s).

4 Touch the Return/Exit ( ) icon twice,

or hold it down to exit.

Deleting Photo(s)

Operation Screen

1 In the Delete menu, touch the Delete

Photo icon twice.

2 Touch to select the desired thumbnail

photo(s). Check mark(s) will indicate the selected file(s).

3 Touch the Delete icon to delete the

selected photo(s).

4 Touch the Return/Exit ( ) icon twice,

or hold it down to exit.

Select & Delete

Operation Screen

1 In the Delete menu, touch the Select

& Delete icon twice.

2 Touch to select the desired thumbnail

photo(s) and video(s). Check mark(s) will indicate the selected file(s).

3 Touch the Delete icon to delete the

selected photo(s) and video(s).

4 Touch the Return/Exit ( ) icon twice,

or hold it down to exit.

Delete All

NOTE

Use this option to delete all photos and videos.

Yes

Operation Screen

1 In the Delete menu, touch the Delete

All icon twice.

2 Touch to select the desired option. 3 Touch again to validate the new

setting.

4 Touch the Return/Exit ( ) icon twice,

or hold it down to exit.

❖ When an SD™ Card has been installed, only the photos and

videos stored on the card are deleted.

❖ Videos or photos cannot be deleted if the card is write-protected.

Deletes all photos and videos in the built-in memory (when no SD™ Card is installed), or delete all photos and videos on the installed SD™ Card.

Does not delete all photos and videos in the built-in memory (when no SD™ Card is installed), or do not delete all photos and videos on the installed SD™ Card.

Record Mode

Menu options/operations

Chapter 4

NOTE

Playback Mode

Button functions

The buttons have the following functions in Playback mode.

Video button:

1 Press to enter Video Record mode.

Photo button:

1 Press to enter Photo Record mode

In Video Playback Mode Tele (T) button:

Increase volume.

Wide (W) button:

Decrease volume.

Double tap the LCD touch screen to reset the zoom.

Power button:

Press for one second to turn the camcorder ON/OFF.

In Photo Playback Mode Tele (T) button:

Zoom in.

Wide (W) button:

Zoom out.

LCD touch screen information

Playback button:

Switch between Record/Playback mode.

Pause button:

1 Press to pause video playback. 2 Press it again to resume video playback.

LCD touch screen information

The indicators shown below may appear on the LCD touch screen while in Playback mode:

Onscreen notification icons Onscreen touch function icons

Playback Mode

(Sample Image) LCD touch screen indicators

Notification icons

00:03:12

321

250

Battery: Full power

Battery: Medium power

Battery: Low power

Battery: No power

DC power mode.

Playback time counter.

Current number of photos taken.

The remaining amount of photos that can be taken at the current resolution settings.

568

121110 139

NOTE

Playback Mode

LCD touch screen information

Touch function icons

Video Playback mode

Photo Playback mode

Volume control.

Video Playback mode.

Photo Playback mode.

Video Trim mode

Continuous play ON/OFF.

Slideshow ON/OFF.

Select & Play thumbnail screen ON.

Menu ON.

Return to Record mode.

Go to the previous file. Fast rewind Videos.

Play the file.

Pause.

Advance to the next file. Video fast forward.

Delete the current file.

Stop video play.

Tap the screen to display the Menu icons. Tap again to hide the icons.

Playback mode operations

To view and manage photos and videos in the built-in memory or on an SD™ Card, use the Playback mode.

Operation Screen

1 In Record mode, press the Playback

button or touch the onscreen ( ) icon to switch to Playback mode.

2 Touch the onscreen ( ) icon to

view the previous video/photo, or touch the onscreen ( ) icon to view the next video/photo.

3 Touch the onscreen ( ) icon.

The Menu screen appears.

4 Touch the onscreen ( ) icon to

open the thumbnail screen for photos and videos.

The Select & Play screen appears.

5 In the Select & Play screen, select the

file(s) you want to play, and then touch ( ) to confirm. Check marks appear on the selected file(s).

6 Touch the onscreen ( ) icon to

play the selected files. (Video: full length. Photo: displays for 2 seconds.)

Playback Mode

Playback mode operations

Playback Mode

Playback mode operations

Video Playback

Operation Screen

1 In the Video Playback mode, touch

the ( ) or ( ) icon to play or pause the video.

2 Touch the ( ) icon to view the

previous video, or touch the ( ) icon to view the next video.

3 While playing a video, touch the

() or () icon to fast rewind/forward the video.

4 In the Continuous Play On mode the

( ) icon is highlighted. Touch the ( ) icon to play all video files continuously. Touch the ( ) icon to stop the video.

5 Use the Tele/Wide buttons to adjust

the volume.

Photo Playback

Operation Screen

1 In the Photo Playback mode, touch

the ( ) icon to view the previous photo, or touch the ( ) icon to view the next photo.

2 In the Slideshow On mode the ( )

icon is highlighted. Touch the ( ) or ( ) icon to play or pause the slideshow. Touch the ( ) icon to stop the slideshow.

Delete a file in Playback mode

Operation Screen

1 In the Playback mode, touch the

( ) icon.

2 Touch the ( ) icon to delete the

current photo.

3 Touch the Return/Exit ( ) icon twice,

or hold it down to exit.

Playback Mode

NOTE

Video Tr im

❖ When an SD™ Card has been installed, only the photos and

videos stored on the card are deleted.

❖ Videos or photos cannot be deleted if the card is write-protected.

Video Trim

Use this option to trim the beginning and/or end of the recorded video and save it as a new video clip.

Operation Screen

1 In Video Playback mode, touch the

onscreen ( ) icon.

2 Touch the Dividing ( / ) icon (the

icon turns yellow) to indicate the beginning/end.

3 Touch the Rewind/Forward

( / ) icon to fine-tune the dividing point.

4 To preview the video, touch the

onscreen( ) or ( ) icon to play or pause the video. Touch the ( ) icon to stop the video.

5 Touch the Save As New ( ) icon to

trim the video at the black portion of the bar, leaving the green portion as a new video file.

6 Touch the Return/Exit ( ) icon twice,

or hold it down to exit.

Video Flow: Specify the Dividing ( / ) where the video clip is to be cut. Portions A and C will be cut, and portion B will be saved as the new video clip.

Chapter 5

Camcorder Settings

Setup Menu

Operation Screen

1 Touch the onscreen ( ) icon.

The Menu screen appears.

2 Touch the Setup ( ) icon twice to

enter its settings menu.

3 The Setup Menu options are: Menu

Sound (operation sound), TV, Language, Time Setting, Format, and Default Setting.

Menu Sound

You can enable or disable tone and operation sounds.

Operation Screen

1 In the Setup menu, touch the Menu

Sound icon twice. The Menu screen appears.

2 Touch to select the desired option. 3 Touch again to validate the setting. 4 Touch the Return/Exit ( ) icon twice,

or hold it down to exit.

Use this function to select the appropriate TV standard for your area, either NTSC or PAL.

An incorrect TV system setting may cause the image to flicker.

NTSC (60Hz) USA, Canada, Japan, South Korea, Taiwan, etc.

PAL (50Hz) UK, Europe, China, Australia, Singapore, Hong Kong, etc.

Operation Screen

1 In the Setup menu, touch the TV icon

twice.

2 Touch to select the desired option. 3 Touch again to validate the setting. 4 Touch the Return/Exit ( ) icon twice,

or hold it down to exit.

Language

Use this option to select the language of the user interface.

Camcorder Settings

Setup Menu

Operation Screen

1 In the Setup menu, touch the

Language icon twice.

2 Touch to select the desired option. 3 Touch again to validate the setting. 4 Touch the Return/Exit ( ) icon twice,

or hold it down to exit.

Camcorder Settings

Setup Menu

Time Settings

Operation Screen

1 In the Setup menu, touch the Time

Setting icon twice.

2 Touch the Month, Day, Year, Hour, or

Minute to set.

3 Touch the up/down arrows to adjust

the numeric value.

4 Touch the ( ) icon to validate the

setting.

5 Touch the Return/Exit ( ) icon twice,

or hold it down to exit.

Format

Use this option to delete all data in the built-in memory or on the SD™ Card.

YES

Deletes all photos and videos in the built-in memory (when no SD™ Card is installed), or delete all photos and videos on the installed SD™ Card.

Does not delete all photos and videos in the built-in memory (when no SD™ Card is installed), or do not delete all photos and videos on the installed SD™ Card.

Operation Screen

1 In the Setup menu, touch the Format

icon twice.

2 Touch to select the desired option. 3 Touch again to validate the setting. 4 Touch the Return/Exit ( ) icon twice,

or hold it down to exit.

All data will be erased if the SD™ Card is formatted. Make sure all data is copied to your computer or other media before formatting the SD™ Card.

Default Setting

To restore the default factory setting, select this option.

YES Restores to default factory setting.

NO Does not restore to default factory setting.

Operation Screen

1 In the Setup menu, touch the Default

Setting icon twice.

2 Choosing YES performs the

operation, and NO cancels the operation.

3 Touch the Return/Exit ( ) icon twice,

or hold it down to exit.

The following table lists the camcorder’s default settings:

Setting Default Factory Setting

Resolution

Light OFF Stabilization ON Motion Detection OFF Face Tracking OFF Slow Motion OFF Pre-Record OFF Time Lapse OFF Continuous Play OFF Self-Timer OFF Smile Detection OFF Date Printing OFF ISO Auto Slideshow OFF Macro Mode OFF Exposure Measure Auto

Video: Full HD 1080p/30 Photo: Standard-5M

Camcorder Settings

Setup Menu

Scene Auto Filter Auto White Balance Auto Menu Sound ON TV NTSC Language English Volume Level 4

Camcorder Settings

Setup Menu

Setting Default Factory Setting

Chapter 6

Viewing Photos and Videos on TV

Connecting to a high-definition 16:9 (wide) TV

To view images or videos from your camcorder on a TV:

1 Connect the mini HDMI™ cable to your camcorder’s mini

HDMI™ Out port.

2 Connect the other end of the cable to a television.

3 Set the video input source of your TV to HDMI™.

(16:9)

(Sample Image) Connecting a high-definition TV

NOTE

Viewing Photos and Videos on TV

Connecting to a high-definition 16:9 (wide) TV

4 The steps for viewing stored photos and videos on a TV are the

same steps used for viewing them on the LCD screen.

The LCD touch screen does not display when the camcorder is connected to an HDTV.

Some functions may not be accessible while the camcorder is connected to a TV or an HDTV.

Chapter 7

NOTE

Viewing Photos and Videos on a Computer

It may be necessary to install the bundled software application, ArcSoft MediaImpression computer.

Installing bundled software

The CD-ROM supplied with your camcorder contains two software applications.

❖ ArcSoft MediaImpression

helps manage your media, and upload videos to the Internet easily.

❖ Adobe

To install the bundled software:

1 Insert the CD-ROM into your computer’s optical disc drive.

2 Click “Install Application Software”. Follow the onscreen

Reader® is a popular program that is needed to view

the User’s Manual. Many users will find they already have this software installed on their computer.

The autorun screen appears.

instructions to complete the installation.

to view videos properly on your

is a user-friendly application that

NOTE

Viewing Photos and Videos on a Computer

Transferring photos or videos to a computer

Detailed information can be found in the online help of all the bundled software.

Transferring photos or videos to a computer

You can transfer photos or videos stored on your camcorder to a computer and send them via email to friends or post them on the Internet.

To do this:

1 Connect the computer and camcorder with the supplied mini

USB 2.0 cable.

The multi-indicator light blinks.

2 To access photos and videos on your SD™ Card: Videos and

photos can be found on your computer at “My Computer\Removable Disk\DCIM\100MEDIA.”

3 To access photos and videos in the camcorder’s internal

memory: Videos and photos can be found on your computer at “My Computer\DV\DCIM\100MEDIA"

4 In this folder, you can view, delete, move, or copy any

video/photo you want.

Chapter 8

NOTE

Uploading Video and Photo Files to the Internet

The built-in CAMILEO® Uploader application offers an easy way to upload video clips and photos to social media Web sites instantly, allowing you to share them with your family and friends on these Web sites. The bundled software, ArcSoft MediaImpression be used to upload video clips to these Web sites.

You must have Internet access to upload videos to a Web site.

, can also

CAMILEO Uploader for Windows® based systems only.

NOTE

Uploading Video and Photo Files to the Internet

CAMILEO® Uploader

To upload files to the Internet:

1 Connect the camcorder to the computer by using the supplied

USB cable.

(Sample Illustration) Connecting the camcorder to a computer

2 When the USB connection has been made, the CAMILEO

Uploader application AutoPlay window appears on your computer screen. (If the AutoPlay window does not appear, click My Computer > DVAP > DVAP.exe to execute the application.)

It may be necessary to first install ArcSoft MediaImpression® onto your computer to view videos/photos in the CAMILEO Uploader. If ArcSoft MediaImpression is not installed, you may be asked to install the H.264 Codec (ffdshow-a free software under GPL license) to view videos on CAMILEO Uploader correctly.

Uploading Video and Photo Files to the Internet

NOTE

CAMILEO® Uploader

3 Choose the Web site you wish to upload to.

(Sample Image) CAMILEO® Uploader main screen

Some social media Web sites may not be accessible in certain regions.

4 Click the Videos or Photos tab to go to the videos/photos

thumbnail page.

Use the scroll bar to view the next/previous page.

5 Click the files you wish to upload. Click Select All/Deselect

All to select/deselect all video or photo files shown on the

current page.

(Sample Image) CAMILEO® Uploader screen - Upload videos/photos

6 Click Upload to begin uploading your files.

NOTE

Uploading Video and Photo Files to the Internet

CAMILEO® Uploader

❖ Click CANCEL to stop the uploading process.

(Sample Image) CAMILEO® Uploader screen - Cancel

Setting up your account information for a Web site

You need to activate your Facebook account by email after registering it.

If the privacy setting of your Facebook account is set to the highest security level, you may have limited access to the CAMILEO Uploader.

1 Choose the Web site.

2 Click the Settings tab to view the setup screen.

3 Fill in your account information, and then click Save.

4 To save your account information and avoid re-entering your

Uploading Video and Photo Files to the Internet

NOTE

CAMILEO® Uploader

5 If you have not previously set up an account with the Web site,

one will first need to be created.

(Sample Image) CAMILEO® Uploader screen - Sign up for new account

Some social media Web sites may not be accessible in certain regions. You must have Internet access to upload files to a Web site.

Chapter 9

Webcam Mode

Connect the camcorder to your computer, using the supplied USB

2.0 cable. Press the Video button to switch to the Webcam mode. The Multi-indicator light glows blue. In this mode, you can implement live video conference meetings and multimedia communications.

(Sample Illustration) Connecting the camcorder to a computer

Chapter 10

Specifications

Image sensor 5 Megapixel BSI CMOS sensor Operations modes Video record, Photo record, Webcam Lens types 23x Optical zoom Lens Auto focus lens (F3.5 - 4.1)

Focus range

Zoom 1x ~ 120x (120x Digital zoom) Shutter Electronic LCD touch screen 3” (7.6 cm) LCD touch screen (16:9)

Storage media

Image resolution

Video resolution

Macro mode: wide: 0.39” (1cm) ~ 47.24” (120cm) Normal mode: 0.39” (1cm) ~ infinity

CAMILEO

used for firmware code).

CAMILEO

for firmware code). SD/SDHC/SDXC Card slot support (up to 128GB)

16MP: 4608 x 3456 (Interpolated) 5MP: 2592 x 1944 3MP: 2048 x 1536

Full HD (1080/30): 1920 x 1080 (30fps) HD (720/60): 1280 x 720 (60fps) HD (720/30): 1280 x 720 (30fps) VGA (480/30): 640 x 480p (30fps)

X400: Built-in 128MB memory (partial memory is

X416: Built-in 16GB memory (partial memory is used

Specifications

Operating Environment Conditions

Approximate recording length (1GB)

1920 x 1080

Resolution:

Recording length: ~00:11:30 ~00:11:30 ~00:17:15 ~00:34:30

(FHD1080p/ 30fps)

1280 x 720 (HD720p/

60fps)

1280 x 720 (HD720p/

30fps)

640 x 480 (VGA/30fps)

Approximate photo capacity (1GB)

Resolution: 16MP 5MP 3MP Photo capacity: ~426 photos ~817 photos ~1090 photos

White balance Auto, Daylight, Fluorescent, Tungsten ISO Auto/800/1600/3200/6400 Exposure Measure Auto/Center/Spot Self-timer 10 second delay Light Light ON/Light OFF/Digital Light

File format

Image play Single image/slideshow PC interface Mini USB 2.0 port TV out Mini HDMI™ port/AV via mini USB port

Battery

Dimensions

Weight

Photo: JPG Video: MP4 (H.264)

Lithium-ion rechargeable battery Battery weight: 1.1 oz. (31g) Battery charging time: 4 hours with AC adaptor Battery life: 1 hour 40 minutes with LCD on

4.7” (L) x 2.1” (W) x 2.4” (H) 120 (L) x 54 (W) x 62 (H) mm

CAMILEO X400: 10.4 oz. (295g) (without battery) CAMILEO X416: 10.5 oz. (297g) (without battery)

Operating Environment Conditions

Operating temperature: 14° to 104° F (-10° to 40° C)

Operating humidity: 20 to 85% (no condensation allowed)

Chapter 11

Troubleshooting

1 If the LCD screen preview is not clear while shooting, how

can the focus be adjusted?

Try switching between Macro and Normal modes.

2 The files on the memory card do not display properly when

the LCD touch screen shows the “!” marking.

The “!” symbol indicates that the SD™ Card is too low of a speed or contains corrupted files. To solve this problem, format the SD™ Card using the camcorder instead of a computer (Refer to “Format” on page 54).

Change the SD/SDHC/SDXC card to a high speed card.

3 Why do some of my indoor pictures look blurry and dark?

The camcorder extends picture exposure time under low-light/ indoor conditions. Keep the camcorder (and the target subject) steady for several seconds when taking pictures. The shutter sounds when a picture is taken.

4 How do I charge the battery?

You must use the supplied AC adaptor or the USB cable.

The camcorder must be turned OFF. A blinking light confirms the camcorder is currently charging. A steady light indicates that charging has been completed. The light turns off automatically after battery is fully charged (In AC charging Mode).

Troubleshooting

5 After connecting the USB cable to the computer:

❖ “DV” indicates the internal memory of the camcorder.

❖ “Removable Disk” indicates the external memory

(SD/SDHC/SDXC card installed in the camcorder) (path will vary depending on name of SD™ Card).

❖ “DVAP” indicates the built-in CAMILEO

Windows

Do not format the disk or delete the application. The CAMILEO® Uploader application may not function.

based systems only).

Uploader (for

Chapter 12

Other Information

Toshiba Support

If you require help or are having problems operating your product, you may need to contact Toshiba for additional technical assistance.

Before you call

Since some problems may be related to software, it is important that you investigate other sources of assistance first. Try the following before contacting Toshiba:

❖ Review the documentation supplied with your product.

❖ If a problem occurs when you are running software

applications, consult the software documentation for troubleshooting suggestions. Contact the software company’s technical support department for assistance.

❖ Consult the reseller or dealer from whom you purchased your

product. They are your best resource for current information and support.

Other Information

Contacting Toshiba

Toshiba’s technical support Web site

For technical support, or to stay current on the most recent software and hardware options for your CAMILEO product information, be sure to regularly check the Toshiba Web site at www.support.toshiba.com.

Toshiba voice contact

For technical support, call the Toshiba Customer Support Center:

Within the United States at (888) 592-0944

Outside the United States at (949) 583-3305

Toshiba Phone Service Center for Latin America Specialized technical service in Spanish.

Hours:

Monday through Friday from 8:00 a.m. to 9:00 p.m. EST:

Argentina: 0-800-666-3701

Bolivia: 800-10-0684

Chile: 800-646526

Colombia: 01-800-912-0539

Costa Rica: 0-800-011-1123

Ecuador: 00-1-949-587-6834*

El Salvador: 800-6601

Guatemala: 1-800-624-0114

Honduras: 00-1-949-587-6836*

Nicaragua: 00-1-949-587-6843*

Panamá: 008-000447813

Paraguay: 009-800-4410059

Perú: 0-800-5-3817

República Dominicana: 1-888-862-3225

Uruguay: 000-411-002-2297

Venezuela: 0800-1008819

product and for other

*Phone charges apply.

Warranty

Online Warranty Information

This product comes with a One (1) Year Standard Limited Warranty. The One (1) Year Standard Limited Warranty for Toshiba Computer Accessories and Electronics can be found online at

http://pcsupport.toshiba.com/accessories1yr.

Warranty Service

Customers located in the fifty (50) United States and District of Columbia may obtain warranty service by visiting the Toshiba Acclaim Web site at www.acclaim.toshiba.com or by contacting the telephone support center at 1-888-592-0944.

Customers located outside the fifty (50) United States and District of Columbia may obtain warranty service by contacting the telephone support center at 1-949-583-3305.

Other Information

Warranty

CAMILEO® serie X400 Manual del usuario

Información reglamentaria

Información de la Comisión Federal de Comunicaciones de Estados Unidos (FCC)

Nombre del producto: Videocámara

Número de modelo: CAMILEO® serie X400

Aviso de la FCC “Información sobre la declaración de conformidad”

Este equipo se probó y se comprobó que cumple con los límites para dispositivos digitales de Clase B, en virtud de la Parte 15 de las normas de la Comisión Federal de Comunicaciones de Estados Unidos (Federal Communications Commission o FCC). Estos límites están diseñados para proporcionar una protección razonable contra interferencias perjudiciales en una instalación residencial. Este equipo genera, utiliza y puede irradiar energía de radiofrecuencia y, si no se instala y utiliza conforme a las instrucciones, puede provocar interferencias perjudiciales a las comunicaciones por radio. Sin embargo, no se garantiza que no habrá interferencias en una instalación en particular. Si este equipo provoca interferencias perjudiciales en la recepción de radio o televisión, lo que se puede determinar apagando y encendiendo el equipo, recomendamos al usuario que intente corregir la interferencia adoptando una o varias de las medidas siguientes:

❖ Cambiar la orientación o la ubicación de la antena receptora.

❖ Aumentar la distancia entre el equipo y el receptor.

❖ Conectar el equipo a un tomacorriente en un circuito diferente al que está

conectado el receptor.

❖ Consultar al distribuidor o a un técnico especializado en radio y televisión

para obtener ayuda.

A D V E R T E N C I A

Los cambios o las modificaciones realizados a este equipo, que no estén aprobados expresamente por TOSHIBA o por terceros autorizados por TOSHIBA, pueden invalidar el derecho del usuario a utilizar el equipo.

Requisitos de la FCC

Este equipo se probó y se comprobó que cumple con la Parte 15 de las normativas de la FCC. Su funcionamiento está sujeto a las siguientes dos condiciones:

(1) Este dispositivo no debe causar interferencias perjudiciales.

(2) Este dispositivo debe aceptar cualquier interferencia, incluidas aquellas que puedan comprometer su funcionamiento.

Contacto

Dirección: TOSHIBA America Information Systems, Inc.

9740 Irvine Boulevard Irvine, California 92618-1697

Teléfono: (949) 583-3000

Instrucciones de seguridad

1 No deje caer la videocámara ni la perfore o desarme, de lo contrario se

anula la garantía.

2 Evite el contacto con el agua y séquese las manos antes de usar la

videocámara.

3 No exponga la videocámara a temperaturas elevadas ni la deje en contacto

directo con la luz del sol ya que la videocámara podría averiarse.

4 Use la videocámara con cuidado. No presione el cuerpo de la videocámara

con fuerza.

5 Para su seguridad personal, no utilice la videocámara durante una tormenta

ni cuando relampaguea.

6 No utilice baterías de especificaciones diferentes, ya que se podrían causar

daños graves.

7 Extraiga la batería cuando no esté utilizando la videocámara durante un

período prolongado, ya que una batería deteriorada puede afectar el funcionamiento de la videocámara.

8 Extraiga la batería si da muestras de que tiene una fuga o una deformación.

9 Utilice solamente los accesorios suministrados por el fabricante.

10 Mantenga la videocámara fuera del alcance de los niños.

11 Se corre el riesgo de una explosión cuando se reemplaza la batería con una

de tipo incorrecto.

12 Elimine las baterías usadas de acuerdo con las instrucciones.

Información sobre la batería

❖ Utilice solamente las baterías recomendadas por TOSHIBA como

repuestos. La batería es de iones de litio y puede explotar si no se reemplaza, utiliza, manipula o elimina en forma correcta. Deseche la batería según lo requieran la legislación y los reglamentos locales.

❖ Cargue la batería solamente a temperatura ambiente entre 5 y 35 grados

centígrados (41 y 95 grados Fahrenheit). De lo contrario, es posible que se fugue la solución electrolítica, que se deteriore el rendimiento de la batería y que se acorte su duración.

❖ Nunca instale o extraiga la batería sin antes apagar la alimentación y

desconectar el adaptador de CA.

❖ Para cargar la batería utilice solamente el adaptador de CA o el cable USB

suministrado, o un cargador de baterías Toshiba opcional. Nunca trate de cargar la batería con cualquier otro tipo de cargador.

Acerca de la batería del control remoto

A D V E R T E N C I A

Peligro de quemaduras químicas o de asfixia debido a la ingestión de la batería.

El control remoto que se suministra con esta videocámara contiene una batería de botón. Mantenga la batería de botón fuera del alcance de los niños. La ingestión de una batería de botón puede causar lesiones graves o la muerte. Pocas horas después de la ingestión se podrían producir quemaduras graves. Si sospecha que alguien ha ingerido una batería de botón busque atención médica inmediatamente.

Cargue la batería de botón con cuidado. Mantenga todas las baterías de botón, nuevas y usadas, fuera del alcance de los niños y asegúrese de que el compartimento de la batería cerrado completamente después de reemplazar la batería. Si el compartimento de la batería no se puede cerrar bien, deje de utilizar el control remoto y póngase en contacto con el fabricante.

Utilice como repuestos solamente las baterías de botón recomendadas por el fabricante. Si no se reemplaza, usa, maneja o desecha adecuadamente la batería de botón podría explotar. Deseche la batería de botón según lo requieran la legislación y los reglamentos locales.

Información sobre el perclorato para el estado de California:

Los productos que incluyen baterías de litio CR (dióxido de manganeso) de tipo botón podrían contener perclorato. Perclorato—puede requerir manejo especial. Consulte http://www.dtsc.ca.gov/hazardouswaste/perchlorate.

esté

Íconos de seguridad

Este manual contiene instrucciones de seguridad que deben seguirse a fin de evitar posibles peligros que podrían tener como consecuencia lesiones personales, daños al equipo o pérdida de datos. Son advertencias de seguridad que están clasificadas de acuerdo con la gravedad del peligro y están representadas por íconos que distinguen cada instrucción como se muestra abajo:

P E L I G R O

A D V E R T E N C I A

N O T

Este ícono indica la presencia de una situación inminentemente peligrosa que, de no evitarse, ocasionaría muerte o lesiones graves.

Este ícono indica la presencia de una situación potencialmente peligrosa que, de no evitarse, podría ocasionar muerte o lesiones graves.

Este ícono indica la presencia de una situación potencialmente peligrosa que, de no evitarse, podría ocasionar lesiones menores o moderadas.

Este ícono indica la presencia de una situación potencialmente peligrosa que, de no evitarse, podría ocasionar daños a la propiedad.

Este ícono brinda información importante.

Información adicional

© Copyright 2011 TOSHIBA CORPORATION. Todos los derechos reservados. TOSHIBA se reserva el derecho de efectuar cambios técnicos. TOSHIBA no asume ninguna responsabilidad por daños directos o indirectos incurridos por errores, omisiones o discrepancias entre este producto y la documentación.

Marcas comerciales

CAMILEO es una marca registrada de Toshiba America Information Systems, Inc. y/o Toshiba Corporation.

Adobe y Adobe Reader son marcas registradas o marcas comerciales de Adobe Systems Incorporated en Estados Unidos y/u otros países.

ArcSoft, MediaImpression y MediaConverter son marcas registradas de ArcSoft, Inc.

Facebook es una marca registrada de Facebook Inc.

HDMI, el logotipo de HDMI y High-Definition Multimedia Interface son marcas comerciales o marcas registradas de HDMI Licensing, LLC.

Intel, Intel Core, Celeron, Centrino y Pentium son marcas comerciales o marcas registradas de Intel Corporation o de sus subsidiarias en Estados Unidos y otros países.

Mac es una marca comercial de Apple Inc., registrada en Estados Unidos y otros países.

Microsoft, Windows y Windows Vista son marcas registradas o marcas comerciales de Microsoft Corporation en Estados Unidos y/u otros países.

Picasa es una marca comercial de Google Inc.

Secure Digital y SD son marcas comerciales de la SD Card Association.

YouTube y el logotipo de YouTube son marcas registradas de Google, Inc.

Todos los demás nombres de marcas y productos son marcas comerciales o marcas registradas de sus respectivas compañías.

Contenido

Capítulo 1: Familiarícese con la videocámara.......................... 10

Vista general ..........................................................10

Revise los componentes...................................11

Requisitos del sistema......................................12

Vista frontal ......................................................12

Vista posterior ..................................................13

Vista lateral .......................................................13

Vista inferior .....................................................13

Capítulo 2: Para comenzar........................................................ 14

Inserción de la batería.............................................14

Carga de la batería ............................................15

Inserción y extracción de una tarjeta SD™

(opcional) .........................................................20

Protección de datos en una tarjeta SD™ ...........21

Encender la videocámara y empezar a usarla..........22

Cómo apagar la videocámara..................................22

Contenido

Capítulo 3: Modo Grabar........................................................... 23

Funciones de los botones .......................................23

Información de la pantalla LCD táctil ......................24

Íconos de notificación.......................................24

Íconos táctiles de funciones..............................26

Grabación de video .................................................27

Grabación de fotografías.........................................28

Uso de la función Luz digital o Luz .........................28

Uso de la función del Zoom ....................................28

Opciones/operaciones del Menú.............................29

Opciones de configuración de Video.................30

Opciones de configuración de Fotografía..........36

Efectos..............................................................40

Eliminación de archivos ....................................44

Capítulo 4: Modo Reproducir....................................................47

Funciones de los botones .......................................47

Información de la pantalla LCD táctil ......................48

Íconos de notificación.......................................48

Íconos táctiles de funciones..............................49

Operaciones del modo Reproducir..........................50

Reproducción de video .....................................51

Reproducción de fotografía...............................51

Eliminar un archivo en el modo Reproducir......51

Recorte de video.....................................................52

Capítulo 5: Configuraciones de la videocámara...................... 53

Menú Configuración................................................53

Menú Sonido ....................................................54

TV .....................................................................54

Idioma...............................................................55

Ajuste de la hora ...............................................55

Formatear .........................................................55

Configuración predeterminada..........................56

Contenido

Capítulo 6: Ver fotografías o videos en un televisor................ 58

Conexión a un televisor de alta definición

de 16:9 (ancho) ................................................58

Capítulo 7: Ver fotografías o videos en una computadora..... 60

Instalación del paquete de software incluido...........60

Cómo transferir fotografías o videos a

la computadora.................................................61

Capítulo 8: Cómo cargar archivos de video y fotografías

en Internet.......................................................... 62

CAMILEO® Uploader ...............................................63

Configuración de la información

de cuenta de un sitio web ...........................65

Capítulo 9: Modo Cámara web................................................. 67

Capítulo 10: Especificaciones................................................... 68

Condiciones ambientales de funcionamiento..........69

Capítulo 11: Solución de problemas........................................ 70

Capítulo 12: Información adicional........................................... 72

Asistencia técnica de Toshiba .................................72

Antes de contactar a Toshiba............................72

Contacto con Toshiba .............................................73

Sitio web de asistencia técnica de Toshiba .......73

Contacto telefónico con Toshiba.......................73

Garantía ..................................................................74

Información en línea sobre la garantía..............74

Servicio de garantía ..........................................74

Capítulo 1

Familiarícese con la videocámara

Vista general

La videocámara Toshiba viene equipada con un sensor de 5 megapíxeles que puede grabar videos en formato H.264. Este formato permite grabar más video con menos memoria.

La videocámara CAMILEO funciones:

❖ Zoom óptico 23x ❖ Zoom digital 120x ❖ Imágenes de alta calidad hasta de 16 megapíxeles ❖ Pantalla LCD táctil a color de 3 pulgadas para visualizar con

facilidad videos, fotografías o los menús en pantalla.

❖ Recorte de videos en pantalla ❖ Grabación de video con resolución de alta definición completa

(HD) de 1920 x 1080p

❖ Botón Pausar para grabar en un solo archivo múltiples

momentos

❖ Estabilización de la imagen electrónica para grabar videos sin

dificultades

❖ Conectividad HDTV a través de un cable mini HDMI™ ❖ CAMILEO

fácilmente a Internet los videos registrados en la videocámara (solamente para sistemas basados en Windows

Uploader integrado, que permite transferir

X400 también incluye las siguientes

)

Familiarícese con la videocámara

Vista general

❖ Varias opciones de efectos tales como Tiempo de espera y

Cámara lenta

❖ Memoria integrada que permite tomar fotografías o grabar

videos sin utilizar una tarjeta de memoria

N O T

El firmware utiliza una porción de la memoria integrada para el funcionamiento de la videocámara.

❖ Ranura de tarjeta de memoria que permite aumentar la

capacidad de almacenamiento

Revise los componentes

Desempaque la caja y asegúrese de que estén incluidos los artículos enumerados a continuación:

Videocámara Cable mini USB Cable mini HDMI™ Adaptador de CA

Guía de CD-ROM

inicio rápido de software, Manual

del usuario (este documento),

e información de la garantía

(Ilustración de muestra) Componentes

*Preinstalada en la videocámara

Paño de limpieza de lujo

Estuche suave Control remoto Cable AV a

Batería de

iones de litio

recargable*

Juego de cubierta

para el lente

(cubierta para

el lente y correa)

mini USB

N O T

Asegúrese de retirar la película protectora del lente antes de usar la videocámara.

Familiarícese con la videocámara

Vista gen e ra l

Requisitos del sistema

❖ Microsoft® Windows® XP/Windows Vista®/Windows® 7

❖ Intel

❖ 512 MB de RAM

❖ 1 GB de espacio libre en el disco duro

❖ Unidad de CD-ROM de 4x

❖ Un puerto USB 2.0 disponible

Compatibilidad con Mac

❖ Mac OS 10.6 o superior

❖ CPU Intel

❖ 1 GB de memoria del sistema

❖ 1 GB de espacio libre en el disco duro

❖ DVD-ROM

❖ Un puerto USB 2.0 disponible

Pentium® 4, 2.4 GHz o superior

Core™ 2 Duo 2.4 GHz o superior

N O T

Vista frontal

Luz

Lente

Receptor de infrarrojos

Micrófono

(Ilustración de muestra) Vista frontal

La pantalla de cristales líquidos (LCD) táctil se fabrica utilizando una tecnología de altísima precisión. Sin embargo, podrían aparecer en la pantalla algunos puntos pequeños negros y/o brillantes (blancos, rojos, azules o verdes). Estos puntos son el resultado normal del proceso de fabricación y no afectan la grabación.

Botón Fotografía

Botón Tele/Gran angular

Parlante

Pantalla LCD táctil

Vista posterior

Luz indicadora

Familiarícese con la videocámara

Vista general

Botón Pausar

Cubierta del puerto Mini USB/Mini HDMI™

(Ilustración de muestra) Vista posterior

Vista lateral

Pantalla LCD táctil

Cubierta del conector del micrófono

(Ilustración de muestra) Vista lateral

Vista inferior

Botón Video

Botón de encendido

Botón Reproducir

Botón de la luz

Cubierta de la batería/tarjeta SD™ Ranura para el trípode

(Ilustración de muestra) Vista inferior

Capítulo 2

Para comenzar

Inserción de la batería

Antes de utilizar la videocámara debe retirar la película protectora de la batería. Para hacerlo, saque la batería, retire la película y vuelva a insertar la batería como se muestra a continuación.

La batería ya viene instalada en la videocámara, sin embargo, debe retirar la película protectora de la batería antes de usarla.

Para conectar correctamente la batería:

1 Deslice el pestillo de seguridad y abra la cubierta de la batería.

(Ilustración de muestra) Cómo abrir la cubierta de la batería

2 Saque la batería.

Para comenzar

Inserción de la batería

3 Quite la película protectora.

Película Protectora

Batería de iones de litio

(Ilustración de muestra) Cómo quitar la película protectora

4 Inserte de nuevo la batería asegurándose de que quede alineada

con las marcas de polaridad correctas.

N O T

Carga de la batería

Batería de iones de litio

(Ilustración de muestra) Cómo reinsertar la batería

5 Cierre la cubierta de la batería.

Antes de utilizar la videocámara debe cargar la batería usando el adaptador de CA o el cable USB que se suministran. Apague la videocámara. Una luz intermitente indica que se está cargando la batería y una luz sólida indica que se completó la carga. Cuando se utiliza el modo de carga con CA la luz se apaga automáticamente

Asegúrese de que el pestillo anaranjado esté enganchado después de insertar la batería.

Para comenzar

Inserción de la batería

cuando la batería está completamente cargada. El tiempo para la carga completa es de aproximadamente 4 horas.

(Ilustración de muestra) Cómo cargar la batería

A D V E R T E N C I A

Manejo de la batería

❖ Nunca trate de desechar una batería quemándola o exponiéndola

al fuego y nunca la ponga en contacto con un aparato que genere calor (ej.: un horno de microondas). El calor puede provocar la explosión de la batería y/o provocar la fuga de líquido cáustico, que podrían ambos causar lesiones graves.

❖ Nunca intente desarmar, alterar o reparar la batería, ya que ésta

podría sobrecalentarse e incendiarse. La fuga de la solución alcalino-cáustica o de otras sustancias electrolíticas podría provocar un incendio, que podría ocasionar la muerte o lesiones graves.

❖ Nunca ponga en contacto, accidental o intencionalmente, las

dos terminales de la batería con otro objeto conductor causando un cortocircuito. Esto podría ocasionar lesiones graves o provocar un incendio, así como dañar la batería y el producto. Cuando transporte la batería envuélvala siempre en un material plástico (o colóquela en una bolsa plástica) para evitar exponer sus terminales a otro objeto conductor, lo cual podría ocasionar lesiones graves. Al desechar la batería siempre cubra las terminales metálicas con cinta de aislar para evitar un cortocircuito accidental que podría ocasionar lesiones graves.

❖ Nunca inserte clavos ni objetos punzocortantes, golpee con un

martillo ni con algún otro objeto, ni pise la batería, ya que podría provocar un incendio o explosión que podría ocasionar lesiones graves.

❖ Nunca cargue la batería mediante un método que no esté

indicado en las instrucciones, ya que si lo hace podría provocar un incendio o explosión, que podría ocasionar lesiones graves.

Para comenzar

Inserción de la batería

A D V E R T E N C I A

❖ Nunca conecte la batería a un tomacorriente o al enchufe del

encendedor de un auto, ya que la batería podría romperse o encenderse provocando un incendio o explosión, que podría ocasionar lesiones graves.

❖ Nunca permita que se moje la batería, ya que una batería mojada

podría sobrecalentarse o encenderse provocando una ruptura o incendio, que podría ocasionar la muerte o lesiones graves.

❖ Nunca guarde una batería en un área con un alto nivel de

humedad, ya que esto podría provocar un incendio o explosión, que podría ocasionar lesiones graves.

❖ Nunca exponga la batería a condiciones anormales de impacto,

vibración o presión. Nunca use una batería que haya sido expuesta a condiciones anormales de impacto aunque la apariencia de ésta sea normal. El dispositivo de protección interno de la batería puede fallar, ocasionando que ésta se sobrecaliente o encienda provocando una fuga de líquido cáustico, una explosión o un incendio, que podría causar la muerte o lesiones graves.

❖ Nunca someta una batería al calor y nunca la guarde o use cerca

de una fuente de calor. Si la batería se calienta o se quema se podría encender o explotar, lo que podría ocasionar la muerte o lesiones graves. Someter una batería al calor también podría ocasionar una fuga del líquido cáustico, así como fallas, mal funcionamiento o pérdida de datos almacenados.

Uso de la batería correcta

❖ Siempre utilice la batería suministrada con la videocámara. Hay

otras baterías que tienen distintos voltajes y polaridades en las terminales. El uso de baterías no compatibles podría generar humo o provocar un incendio o ruptura, que podría ocasionar lesiones graves.

Para comenzar

Inserción de la batería

A D V E R T E N C I A

Seguridad de la batería

❖ Si la batería tiene una fuga, nunca permita que el fluido

electrolítico cáustico entre en contacto con sus ojos, cuerpo o ropa.

Use guantes protectores cuando manipule una batería dañada. En caso de que el fluido electrolítico cáustico de la batería

entrara en contacto con sus ojos, lávelos inmediatamente con cantidades abundantes de agua corriente y busque atención médica cuanto antes para evitar que sus ojos sufran daños irreversibles.

En caso de que el fluido electrolítico entrara en contacto con alguna parte de su cuerpo, lave esa parte inmediatamente bajo agua corriente para evitar irritaciones cutáneas.

En caso de que el fluido electrolítico entrara en contacto con su ropa, quítesela de inmediato para evitar que el fluido entre en contacto con su cuerpo, lo que podría ocasionar lesiones graves.

Indicadores de advertencia de la batería

❖ Si observa cualquiera de las siguientes condiciones apague

inmediatamente la alimentación, desconecte la clavija del cable de alimentación del tomacorriente y deje de usar la batería:

❖ Mal olor u olor inusual ❖ Calor excesivo ❖ Decoloración ❖ Deformación, grietas o fugas ❖ Humo ❖ Otras situaciones poco usuales durante el uso, tales como

un sonido anormal

En tales situaciones, extraiga de inmediato con cuidado la batería del producto. En algunos casos, tal vez tenga que esperar hasta que el producto se enfríe antes de retirar la batería, para evitar la posibilidad de sufrir una lesión menor debido a la exposición al calor. No vuelva a encender la alimentación del producto hasta que un representante de servicio autorizado de Toshiba haya comprobado que no acarrea ningún riesgo. Si continúa usando la batería podría provocar un incendio o una ruptura, que podría ocasionar lesiones graves o fallas al producto, incluyendo entre otras la pérdida de datos.

Para comenzar

Inserción de la batería

A D V E R T E N C I A

Desecho de baterías usadas

❖ Siempre deseche las baterías usadas de conformidad con todas

las leyes y normas pertinentes. Al transportarlas, coloque una cinta aislante, tal como una cinta de celofán, sobre el electrodo para evitar un posible cortocircuito, incendio o choque eléctrico. No cumplir con estas instrucciones podría resultar en lesiones graves.

Inserción de la batería

❖ Al instalar una batería o antes de mover el producto, siempre

asegúrese de que la batería esté insertada correctamente y de modo seguro. Si la batería llega a caerse mientras traslada el producto, usted podría sufrir lesiones o la batería podría dañarse.

No use una batería dañada o agotada

❖ Nunca continúe usando una batería después de que se haya

afectado su capacidad de recargarse o después de que aparezca un mensaje de advertencia que indique que se le ha agotado la energía.

Si continúa usando una batería agotada o dañada podría ocasionar la pérdida de datos o daños al producto.

N O T

A D V E R T E N C I A

Manejo de la batería

❖ Nunca trate de instalar baterías con la polaridad invertida.

❖ Asegúrese de que la batería esté bien instalada en el producto

antes de tratar de cargarla.

❖ Una instalación inadecuada puede causar humo o fuego, o hacer

que se rompa la batería.

Para comenzar

Inserción y extracción de una tarjeta SD™ (opcional)

❖ La batería es de iones de litio y puede explotar si no se

reemplaza, utiliza, manipula o elimina en forma correcta. Deseche la batería según lo requieran la legislación y los reglamentos locales. Utilice solamente las baterías recomendadas por TOSHIBA como repuestos.

❖ Cargue la batería solamente a temperatura ambiente entre 5 y 35

grados centígrados (41 y 95 grados Fahrenheit). De lo contrario, es posible que se fugue la solución electrolítica, que disminuya el rendimiento de la batería y que se acorte su duración.

❖ Nunca instale o extraiga la batería sin antes apagar la

alimentación y desconectar el adaptador de CA.

Inserción y extracción de una tarjeta SD™ (opcional)

N O T

Su videocámara viene con una memoria interna que le permite almacenar fotografías y videos. Usted puede aumentar la capacidad de la memoria utilizando una tarjeta de memoria SD/SDHC/SDXC opcional.

1 Deslice el pestillo de seguridad y abra la cubierta de la tarjeta SD™.

(Ilustración de muestra) Cómo abrir la cubierta de la tarjeta SD™

Podría ser necesario comprar la tarjeta SD™ por separado.

Para comenzar

Inserción y extracción de una tarjeta SD™ (opcional)

2 Inserte la tarjeta de memoria en la ranura hasta que encaje en

su lugar, como se muestra a continuación.

Para extraer la tarjeta SD™, presiónela hacia adentro para liberarla. Cuando se asome la tarjeta sujétela y sáquela en línea recta.

(Ilustración de muestra) Inserción y extracción de una tarjeta SD™

Para evitar la corrupción de datos se recomienda formatear la tarjeta SD™ en la videocámara antes de utilizarla.

Si se formatea la tarjeta SD™ se borran todos los datos. Por lo tanto, asegúrese de copiar todos los datos en una computadora o en otro medio antes de formatear la tarjeta SD™.

N O T

Cuando se inserta una tarjeta de memoria, los videos y las fotografías se guardan en la tarjeta en lugar de la memoria integrada.

Protección de datos en una tarjeta SD™

En una tarjeta SD™ que esté bloqueada (de lectura solamente) no se pueden grabar fotografías o videos pero sí se pueden ver.

Asegúrese de que el bloqueo esté en la posición de grabable antes de grabar fotos o videos como se muestra a continuación.

Posición dePosición de

grabable protección

contra escritura

(Ilustración de muestra) Protección de datos en una tarjeta SD™

Para comenzar

Encender la videocámara y empezar a usarla

Para encender la videocámara puede utilizar uno de los siguientes métodos:

❖ Abrir la pantalla LCD táctil para encender la videocámara

automáticamente.

❖ Presionar el botón de encendido ( ) durante

aproximadamente un segundo.

Para grabar videos: Presione el botón Video ( ) para iniciar la grabación. Presiónelo de nuevo para detener la grabación.

Para tomar una fotografía mientras se graba un video: Presione el botón Fotografía ( ).

Para tomar una fotografía: Presione a medias el botón Fotografía ( ) para enfocar hasta que el marco de enfoque se vuelva verde. Luego presione el botón del todo para tomar la fotografía.

Marco de enfoque: Blanco Marco de enfoque: Verde

(Imagen de muestra) Marcos de enfoque (verde y blanco)

Para ver las fotografías y los videos almacenados: Presione el botón Reproducir ( ) o toque el ícono en la pantalla para pasar al modo Reproducir.

Cómo apagar la videocámara

Para apagar la videocámara presione el botón de encendido ( ) durante un segundo o coloque de nuevo la pantalla LCD táctil en su posición original.

Capítulo 3

Modo Grabar

Funciones de los botones

Botón Video:

1 Presionar para iniciar la grabación de un video. 2 Presionar de nuevo para detener la grabación.

Botón Pausar:

1 Presionar para pausar la grabación. 2 Presionar de nuevo para reanudar la grabación del mismo archivo.

Botón Fotografía:

1 Presionar a medias para enfocar y luego presionar del todo para

tomar la fotografía.

2 Para tomar una fotografía durante la grabación de un video

presione el botón fotografía para capturar la imagen.

Nota: La resolución de la fotografía será igual a la resolución del video. Botón Tele (T):

Efectuar acercamientos.

Botón Gran angular (W):

Efectuar alejamientos.

Botón de encendido:

Presionar durante aproximadamente un segundo para encender o apagar la videocámara.

Modo Grabar

Información de la pantalla LCD táctil

Botón Reproducir:

Para alternar entre el modo Grabar y el modo Reproducir.

Botón de la luz:

Presionar para alternar entre las configuraciones de la luz (Luz encendida, Luz apagada, Luz digital).

N O T

Toque la pantalla LCD táctil para mostrar el estado de la configuración.

Información de la pantalla LCD táctil

Los indicadores que aparecen en las siguientes imágenes podrían aparecer en la pantalla LCD táctil cuando se registren fotografías o videos:

Íconos de notificación en pantalla Íconos táctiles de funciones en pantalla

(Imagen de muestra) Indicadores de la pantalla LCD táctil

Íconos de notificación

123

Batería: Alimentación plena

91011

151413 1612

Batería: Alimentación media

Batería: Alimentación baja

Batería: Sin alimentación

Modo de alimentación con corriente continua

Modo Macro para primeros planos

Modo Grabar

Información de la pantalla LCD táctil

Escena

Balance de blancos

00:03:12

250

321

Tiempo de grabación

Pausar grabación

Cantidad de fotografías restantes que se pueden tomar con la configuración de resolución actual

Cantidad actual de fotografías tomadas

Detección de movimiento (en el modo Grabar video solamente)

Piel

Noche

Luz de fondo

Auto

Luz de día

Fluorescente

Tungsteno

Contador del zoom: 1x~2700x (zoom óptico 23x, zoom digital 120x)

Cámara lenta (modo Grabar video solamente) Nota: Los videos en cámara lenta se grabarán en una

resolución WQVGA (432 x 240 [WQVGA]).

Tiempo de espera (modo Grabar video solamente)

Modo Pregrabar (modo Grabar video solamente)

Modo Grabar

Información de la pantalla LCD táctil

Íconos táctiles de funciones

Luz digital ENCENDIDA

Resolución de video

Resolución de fotografía

Modo Grabar video

Modo Grabar fotografía

Luz ENCENDIDA

Luz APAGADA

Full HD (1080p 30)

60p

HD60 (720p 60)

HD30 (720p 30)

VGA (480p 30)

WQVGA (cuando la función de Cámara lenta está activada, la resolución del video es de 432 x 240 [QVGA])

Alta - 16MP

Estándar - 5MP

Baja - 3MP

Luz de fondo ENCENDIDA/APAGADA

Autotemporizador ACTIVADO/DESACTIVADO

Menú

Modo Reproducir

Modo Fotografía

Modo Video

Modo Eliminar

Toshiba Camileo X400, Camileo X410, Camileo X416 User's Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

CAMILEO® X400 Series User’s Guide

Contents

Overview

Check the components

System requirements

Front view

Rear view

Side view

Underside view

Loading the battery

Charge your battery

Inserting and removing an SD™ Card (optional)

Protecting data on an SD™ Card

Turning the camcorder on and getting started

Turning off the camcorder

Button functions

LCD touch screen information

Notification icons

Touch function icons

Video recording

Photo recording

Using Digital Light or Light function

Using the Zoom function

Menu options/operations

Video Setting options

Photo Setting options

Effects

Deleting files

Button functions

LCD touch screen information

Notification icons

Touch function icons

Playback mode operations

Video Playback

Photo Playback

Delete a file in Playback mode

Video Tr im

Setup Menu

Menu Sound

Language

Time Settings

Format

Default Setting

Connecting to a high-definition 16:9 (wide) TV

Installing bundled software

Transferring photos or videos to a computer

CAMILEO® Uploader

Setting up your account information for a Web site

Operating Environment Conditions

Toshiba Support

Before you call

Contacting Toshiba

Toshiba’s technical support Web site

Toshiba voice contact

Warranty

Online Warranty Information

Warranty Service

CAMILEO® serie X400 Manual del usuario

Contenido

Vista general

Revise los componentes

Requisitos del sistema

Vista frontal

Vista posterior

Vista lateral

Vista inferior

Inserción de la batería

Carga de la batería

Inserción y extracción de una tarjeta SD™ (opcional)

Protección de datos en una tarjeta SD™

Encender la videocámara y empezar a usarla

Cómo apagar la videocámara

Funciones de los botones

Información de la pantalla LCD táctil

Íconos de notificación

Íconos táctiles de funciones
