CAMILEO® X400 Series User’s Guide

English/Español

GMAA00341011 08/11

Regulatory Information

FCC Information

Product Name: Camcorder

Model number: CAMILEO

FCC notice “Declaration of Conformity Information”

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

❖ Reorient or relocate the receiving antenna.

❖ Increase the separation between the equipment and receiver.

❖ Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

❖ Consult the dealer or an experienced radio/TV technician for help.

X400 Series

Changes or modifications made to this equipment, not expressly approved by TOSHIBA or parties authorized by TOSHIBA could void the user’s authority to operate the equipment.

FCC Conditions

This equipment has been tested and found to comply with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference.

(2) This device must accept any interference received. Including interference that may cause undesired operation.

Contact

Address: TOSHIBA America Information Systems, Inc.

9740 Irvine Boulevard Irvine, California 92618-1697

Telephone: (949) 583-3000

Safety Instructions

1 Do not drop, puncture or disassemble the camcorder; otherwise the

warranty will be voided.

2 Avoid all contact with water, and dry hands before using.

3 Do not expose the camcorder to high temperature or leave it in direct

sunlight. Doing so may damage the camcorder.

4 Use the camcorder with care. Avoid pressing hard on the camcorder body.

5 For your own safety, avoid using the camcorder when there is a storm or

lightning.

6 Do not use batteries of different specifications. Doing so may lead to the

potential for serious damage.

7 Remove the battery during long periods between usage, as a deteriorated

battery may affect the functionality of the camcorder.

8 Remove the battery if it shows signs of leaking or distortion.

9 Use only the accessories supplied by the manufacturer.

10 Keep the camcorder out of the reach of infants.

11 Risk of explosion if battery is replaced by an incorrect type.

12 Dispose of used batteries according to the instructions.

About the battery

❖ Use only batteries recommended by TOSHIBA as replacements. The

battery is a lithium ion battery, which can explode if not replaced, used, handled or disposed of properly. Dispose of the battery as required by local ordinances or regulations.

❖ Charge the battery only in an ambient temperature between 41 and 95

degrees Fahrenheit (5 and 35 degrees Celsius). Otherwise, the electrolyte solution might leak, battery performance might deteriorate and the battery life might be shortened.

❖ Never install or remove the battery without first turning off the power and

disconnecting the AC adaptor.

❖ Only use the supplied AC adaptor or USB cable, or an optional Toshiba

battery charger to charge the battery. Never attempt to charge the battery with any other charger.

About the remote control battery

Chemical burns and choking hazard due to battery ingestion

The remote control supplied with this camcorder contains a button cell battery. Keep the button cell battery out of reach of children. If swallowed, the button cell battery can cause serious injury or death. Severe burns can occur within hours of ingestion. If you suspect that a button cell battery has been swallowed, seek immediate medical attention.

Use care when changing the button cell battery. Keep all new and used button cell batteries out of reach of children and ensure that the battery compartment is completely secure after replacing the battery. If the battery compartment cannot be completely secured, discontinue use of the remote control and contact the manufacturer.

Use only button cell batteries recommended by the manufacturer as replacements. The button cell battery can explode if not replaced, used, handled, or disposed of properly. Dispose of the button cell battery as required by local ordinances or regulations.

California Perchlorate Information:

Products containing CR (manganese dioxide) lithium coin cell batteries may contain perchlorate. Perchlorate Material – special handling may apply. See http://www.dtsc.ca.gov/hazardouswaste/perchlorate.

Safety icons

NOTE

This manual contains safety instructions that must be observed to avoid potential hazards that could result in personal injuries, damage to your equipment, or loss of data. These safety cautions have been classified according to the seriousness of the risk, and icons highlight these instructions as follows:

Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.

Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.

Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.

Indicates a potentially hazardous situation which, if not avoided, may result in property damage.

Provides important information.

Additional Information

© Copyright 2011 TOSHIBA CORPORATION. All rights reserved. TOSHIBA reserves the right to make technical changes. TOSHIBA assumes no liability for damages incurred directly or indirectly from errors, omissions or discrepancies between this product and the documentation.

Trademarks

CAMILEO is a registered trademark of Toshiba America Information Systems, Inc. and/or Toshiba Corporation.

Adobe and Adobe Reader are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries.

ArcSoft, MediaImpression, and MediaConverter are registered trademarks of ArcSoft, Inc.

Facebook is a registered trademark of Facebook Inc.

HDMI, the HDMI Logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing, LLC.

Intel, Intel Core, Celeron, Centrino and Pentium are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries.

Mac is a trademark of Apple Inc., registered in the U.S. and other countries.

Microsoft, Windows, and Windows Vista are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.

Picasa is a trademark of Google Inc.

Secure Digital and SD are trademarks of SD Card Association.

YouTube and the YouTube logo are registered trademarks of Google, Inc.

All other brand and product names are trademarks or registered trademarks of their respective companies.

Chapter 1: Getting to Know Your Camcorder.......................... 10

Overview ................................................................10

Check the components .....................................11

System requirements........................................11

Front view .........................................................12

Rear view..........................................................12

Side view ..........................................................13

Underside view .................................................13

Chapter 2: Getting Started......................................................... 14

Loading the battery.................................................14

Charge your battery ..........................................16

Inserting and removing an SD™ Card (optional).....20

Protecting data on an SD™ Card.......................21

Turning the camcorder on and getting started .......22

Turning off the camcorder ......................................22

Chapter 3: Record Mode........................................................... 23

Button functions .....................................................23

LCD touch screen information ................................24

Notification icons..............................................24

Contents

Touch function icons ........................................26

Video recording ......................................................27

Photo recording......................................................28

Using Digital Light or Light function .......................28

Using the Zoom function ........................................28

Menu options/operations........................................29

Video Setting options........................................30

Photo Setting options .......................................36

Effects...............................................................40

Deleting files .....................................................43

Chapter 4: Playback Mode........................................................46

Button functions .....................................................46

LCD touch screen information ................................47

Notification icons..............................................47

Touch function icons ........................................48

Playback mode operations......................................49

Video Playback..................................................50

Photo Playback .................................................50

Delete a file in Playback mode...........................50

Video Trim ..............................................................51

Chapter 5: Camcorder Settings ................................................ 52

Setup Menu ............................................................52

Menu Sound .....................................................52

TV .....................................................................53

Language ..........................................................53

Time Settings....................................................54

Format ..............................................................54

Default Setting ..................................................55

Chapter 6: Viewing Photos and

Videos on TV.....................................................57

Connecting to a high-definition 16:9

(wide) TV ..........................................................57

Contents

Chapter 7: Viewing Photos and

Videos on a Computer...................................... 59

Installing bundled software.....................................59

Transferring photos or videos to a computer..........60

Chapter 8: Uploading Video and Photo Files to the

Internet............................................................... 61

CAMILEO® Uploader ...............................................62

Setting up your account information

for a Web site..............................................64

Chapter 9: Webcam Mode........................................................ 66

Chapter 10: Specifications ........................................................ 67

Operating Environment Conditions .........................68

Chapter 11: Troubleshooting.................................................... 69

Chapter 12: Other Information.................................................. 71

Toshiba Support .....................................................71

Before you call ..................................................71

Contacting Toshiba .................................................72

Toshiba’s technical support Web site................72

Toshiba voice contact .......................................72

Warranty.................................................................73

Online Warranty Information.............................73

Warranty Service ..............................................73

Chapter 1

Getting to Know Your Camcorder

Overview

Your Toshiba camcorder comes equipped with a 5MP sensor that can record H.264 format movies. This format allows for extended video recording with less memory.

Other features of your CAMILEO

❖ 23x optical zoom ❖ 120x digital zoom ❖ High quality images up to 16 megapixels ❖ 3” color LCD touch screen for easy viewing of video, pictures

and onscreen menus

❖ On-screen video trimming

❖ Video recording at full HD resolution of 1920 x 1080p ❖ Pause button to record multiple moments in a single file

❖ Electronic Image Stabilization to record smoother videos ❖ HDTV connectivity via a mini HDMI™ cable ❖ Built-in CAMILEO

videos captured by the camcorder to the Internet (for Windows

❖ Various effect options, such as Time Lapse and Slow Motion ❖ Built-in memory allowing you to take pictures and to record

movies without a memory card.

based systems only)

Uploader, allowing you to easily upload

X400 Series camcorder are:

A portion of the built-in memory is used for Firmware to operate the

NOTE

camcorder.

❖ Memory card slot allowing you to increase storage capacity.

Check the components

Unpack the box and make sure all items listed below are included:

Getting to Know Your Camcorder

Overview

Camcorder Mini USB cable Mini HDMI™ cable AC adaptor

Quick Start CD-ROM

Guide Software, User’s

Guide (this document),

and Warranty information

Cleaning cloth

Deluxe soft case Remote control AV to mini USB

(Sample Illustration) Components

*Preinstalled in the camcorder

Be sure to remove the protective film on the lens before using.

System requirements

❖ Microsoft® Windows® XP/Windows Vista®/Windows® 7 ❖ Intel ❖ 512 MB RAM ❖ 1 GB free HDD space ❖ 4x CD-ROM Drive ❖ Available USB 2.0 port

Mac compatibility

❖ Mac OS 10.6 or above ❖ CPU Intel ❖ 1 GB system memory ❖ 1 GB free HDD space ❖ DVD-ROM ❖ Available USB 2.0 port

Pentium® 4, 2.4 GHz or above

Core™ 2 Duo 2.4 GHz or above

Lithium-ion

rechargeable

battery*

Lens cover set

(lens cover

and strap)

cable

NOTE

Front view

Light

Getting to Know Your Camcorder

Overview

The LCD touch screen is manufactured using extremely high-precision technology. However, some tiny black and/or bright dots (white, red, blue or green) may appear on the LCD touch screen. These dots are a normal result of the manufacturing process, and do not affect the recording.

Photo button

Tele/Wide button

Speaker

Lens

IR receiver

Microphone

(Sample Illustration) Front view

Rear view

Mini USB/Mini HDMI™ port cover

(Sample Illustration) Rear view

LCD touch screen

Indicator light

Pause button

Video button

Side view

Getting to Know Your Camcorder

Overview

LCD touch screen

(Sample Illustration) Side views

Underside view

(Sample Illustration) Underside view

Microphone jack cover

Battery/SD™ Card coverTripod socket

Power button

Playback button

Light button

Chapter 2

Getting Started

Loading the battery

Before using the camcorder, you will need to remove the protective film from the battery. To do so, remove the battery, then remove the film, and replace the battery as shown below.

The battery comes pre-installed in the camcorder, however, you must remove the protective film on the battery before use.

To properly connect the battery:

1 Slide the safety latch and open the battery cover.

(Sample Illustration) Opening the battery cover

Getting Started

NOTE

Loading the battery

2 Remove the battery.

3 Pull the protective film off.

Protective film

Li-ion battery

(Sample Illustration) Removing the protective film

4 Reinsert the battery, making sure it is lined-up with the correct

polarity marks.

Li-ion battery

(Sample Illustration) Reinserting the battery

Be sure the orange latch is engaged after inserting the battery.

5 Close the battery cover.

Getting Started

Loading the battery

Charge your battery

You must use the supplied AC adaptor or the USB cable to charge your camcorder before use. Turn off the camcorder. A blinking light indicates active charging, and a solid light indicates that charging is complete. In AC charging mode, the light will turn off automatically after the battery is fully charged. The full charge time is approximately 4 hours.

(Sample Illustration) Charging the battery

Handling of the battery

❖ Never attempt to dispose of a battery by burning or by throwing

❖ Never attempt to disassemble, tamper with or repair a battery.

❖ Never short-circuit the battery by either accidentally or

it into a fire, and never allow exposure to a heating apparatus (e.g., microwave oven). Heat can cause a battery to explode and/or release caustic liquid, both which may possibly cause serious injury.

The battery could overheat and ignite. Leakage of the caustic alkaline solution or other electrolytic substances could cause fire, possibly resulting in death or serious injury.

intentionally bringing the battery terminals in contact with another conductive object. This could cause serious injury or a fire, and could also damage the battery and product. Always wrap the battery in plastic (or place it in a plastic bag) whenever transporting it, to avoid exposing the terminals to another conductive object which could result in serious injury. Always cover the metal terminals with insulating tape when disposing of the battery, to prevent accidental short-circuiting which could result in serious injury.

Getting Started

Loading the battery

❖ Never drive a nail or any other sharp object into the battery, hit

battery with a hammer or other object or step on it. Doing so could cause a fire or explosion possibly resulting in serious injury.

❖ Never charge the battery by a method other than as instructed.

Doing so could cause a fire or explosion possibly resulting in serious injury.

❖ Never connect the battery to a plug socket or a car cigarette plug

socket. The battery could rupture or ignite causing a fire or explosion possibly resulting in serious injury.

❖ Never allow a battery to become wet. A wet battery will overheat

or ignite causing rupture or fire, possibly resulting in death or serious injury.

❖ Never store a battery in an area of high humidity. This could

cause a fire or explosion possibly resulting in serious injury.

❖ Never expose a battery to abnormal shock, vibration or pressure.

Never use a battery which has been exposed to abnormal shock even if the appearance is normal. The battery’s internal protective device could fail, causing it to overheat or ignite resulting in caustic liquid leakage, or explosion or fire, possibly resulting in death or serious injury.

❖ Never subject a battery to heat, and never store it or use it near a

heat source. The battery could ignite or explode when heated or burned, possibly resulting in death or serious injury. Subjecting a battery to heat could also cause caustic liquid to leak. It can also cause failure, malfunction, or loss of stored data.

Use of correct battery

❖ Always use the battery supplied. Other batteries have different

voltage and terminal polarities. Use of non-conforming batteries could generate smoke or cause fire or rupture, possibly resulting in serious injury.

Getting Started

Loading the battery

Battery safety

❖ Never allow caustic electrolyte fluid leaked from the battery to

contact your eyes, body or clothing. Use appropriate protective gloves when handling a damaged

battery. If caustic electrolyte fluid from the battery should contact your

eyes, immediately wash your eyes with large amounts of running water and obtain prompt medical attention, to help prevent permanent eye damage.

If electrolyte fluid should contact any part of your body, immediately wash it off under running water to help prevent skin rashes.

If electrolyte fluid should contact your clothes, promptly remove them to help prevent the electrolyte fluid from contacting your body, possibly resulting in serious injury.

Battery warning indicators

❖ Always immediately turn the power off and disconnect the power

cable/cord plug from the plug socket and stop using the battery if you observe any of the following conditions:

❖ Offensive or unusual odor ❖ Excessive heat ❖ Discoloration ❖ Deformation, cracks or leaks ❖ Smoke ❖ Other unusual event during use, such as abnormal sound

In such an event, carefully and immediately remove the battery from the product. In some instances, you might have to wait for the product to cool down before removing the battery, in order to avoid any possible minor injury due to heat exposure. Do not turn on the product’s power again until an authorized Toshiba service provider has checked it for safety. Continued use could cause a fire or rupture possibly resulting in serious injury or product failure including but not limited to the loss of data.

Getting Started

NOTE

Loading the battery

Disposal of used batteries

❖ Always dispose of used batteries in compliance with all

applicable laws and regulations. Put insulating tape, such as cellophane tape, on the electrode during transportation to avoid a possible short circuit, fire or electric shock. Failure to do so could possibly result in serious injury.

Inserting the battery

❖ When installing a battery or before moving the product, always

make sure the battery is inserted correctly and securely. If the battery falls out, while you are carrying the product, you could be injured or the battery could be damaged.

Do not use an impaired or exhausted battery

❖ Never continue to use a battery after its recharging capability has

become impaired, or after the warning message indicating that the battery power is exhausted has been displayed.

Continued use of an exhausted or impaired battery could result in the loss of data or damage to the product.

Handling of the battery

❖ Never attempt to install batteries in reverse polarity.

❖ Make sure the battery is securely installed in the product before

attempting to charge the battery.

❖ Improper installation could generate smoke or fire, or cause the

battery to rupture.

NOTE

Getting Started

Inserting and removing an SD™ Card (optional)

❖ The battery is a lithium ion battery, which can explode if not

replaced, used, handled or disposed of properly. Dispose of the battery as required by local ordinances or regulations. Use only batteries recommended by TOSHIBA as replacements.

❖ Charge the battery only in an ambient temperature between 41

and 95 degrees Fahrenheit (5 and 35 degrees Celsius). Otherwise, the electrolyte solution might leak, battery performance might deteriorate and the battery life might be shortened.

❖ Never install or remove the battery without first turning off the

power and disconnecting the AC adaptor.

Inserting and removing an SD™ Card (optional)

An SD™ Card may need to be purchased separately.

Your camcorder comes with internal memory that allows you to store pictures and movies. You can expand the memory capacity by using an optional SD/SDHC/SDXC memory card.

1 Slide the safety latch and open the SD™ Card cover.

(Sample Illustration) Opening the SD™ Card cover

Getting Started

NOTE

Inserting and removing an SD™ Card (optional)

2 Insert the memory card into the slot until it locks in place as

shown below.

To remove the SD™ Card, press inward to release it. When the card pops out, grasp it and pull it

straight out.

(Sample Illustration) Inserting and removing an SD™ Card

To prevent data corruption, it is recommended that you format the SD™ Card in the camcorder before using.

All data will be erased if the SD™ Card is formatted. Make sure all data is copied to your computer or other media before formatting the SD™ Card.

When a memory card is inserted, photos and videos are saved onto the card rather than the built-in memory.

Protecting data on an SD™ Card

Photos or videos cannot be recorded on an SD™ Card when the card is locked (read only); however, photos and videos can be viewed.

Make sure the lock is in the writable position before recording photos and videos as shown below.

Write-protectedWritable

position position

(Sample Illustration) Protecting data on an SD™ Card

Getting Started

Turning the camcorder on and getting started

To turn on the camcorder, either:

❖ Flip the LCD touch screen outward to turn on the camcorder

automatically.

❖ Or press the Power ( ) button for approximately one second

to turn it on.

To record videos: Press the Video ( ) button to begin recording. Press it again to stop recording.

To take a still photo while recording a video: Press the Photo ( ) button.

To take a photo: Press the Photo ( ) button halfway down to focus until the focusing frame turns green. Then press it fully to take the photo.

Focusing frame: White Focusing frame: Green

(Sample Image) Focusing frames (green and white)

To view stored movies and pictures: Press the Playback ( ) button or touch the onscreen icon to switch to Playback mode.

Turning off the camcorder

To turn off the camcorder, either press the Power ( ) button for one second, or place the LCD touch screen back to its original position.

Chapter 3

Record Mode

Button functions

Video button:

1 Press to begin recording a video. 2 Press it again to stop recording.

Pause button:

1 Press to pause recording. 2 Press it again to resume recording on the same file.

Photo button:

1 Press halfway down to focus, then press it fully to take the

photo.

2 To take a photo during video recording press the photo button to

capture the image.

Note: The photo resolution will be the same as the video resolution. Tele (T) button:

Zoom in.

Wide (W) button:

Zoom out.

Power button:

Press for one second to turn the camcorder ON/OFF.

NOTE

Record Mode

LCD touch screen information

Playback button:

Switch between Record/Playback mode.

Light button:

Press to toggle the Light settings (Light ON, Light OFF, Digital light).

Touch the LCD touch screen to show the status of the setting.

LCD touch screen information

The indicators shown on the images below may appear on the LCD touch screen when photos and videos are recorded:

Onscreen notification icons Onscreen touch function icons

(Sample Image) LCD touch screen indicators

Notification icons

123

Battery: Full power

Battery: Medium power

Battery: Low power

Battery: No power

DC power mode

Macro mode for close ups

91011

151413 1612

Record Mode

LCD touch screen information

00:03:12

250

321

Scene

White balance

Recording time

Pause recording

The remaining amount of photos that can be taken at the current resolution settings

Current number of photos taken

Motion Detection (Video Record mode only)

Skin

Night

Backlight

Auto

Daylight

Fluorescent

Tungsten

Zoom meter: 1x~2700x (23x Optical Zoom, 120x Digital Zoom)

Slow Motion (Video Record mode only) Note: Slow motion videos will be recorded in WQVGA

resolution (432 x 240 [WQVGA]).

Time Lapse (Video Record mode only)

Pre-Record mode (Video Record mode only)

Record Mode

LCD touch screen information

Touch function icons

Digital light ON

Video Resolution

Photo resolution

Video Record mode

Photo Record mode

Light ON

Light OFF

Full HD (1080p 30)

60p

HD60 (720p 60)

HD30 (720p 30)

VGA (480p 30)

WQVGA (while the Slow Motion function is active, the video resolution is 432 x 240 [QVGA])

High-16MP

Standard-5MP

Low-3MP

Backlight ON/OFF

Self-timer ON/OFF

Playback mode

Photo mode

Video mode

Delete mode

❖ Tap on the screen to close the touchable function bars. Tap

NOTE

❖ Filter: Black & White/Classic/Negative can be previewed

❖ Stabilization, Time Lapse, and Slow Motion functions can not be

❖ Stabilization and Night mode functions can not be used

❖ Pre-Record, Motion Detection, Time Lapse, and Slow Motion

❖ The camcorder does not power off automatically in DC power

Video recording

Press the Video ( ) button to start recording. A time indicator displays on the LCD touch screen while recording a video. Press the Video button again to stop recording.

To pause recording, press the Pause ( ) button. To continue recording, press it again.

To take a still photo while recording a video, press the Photo ( ) button.

Touch the onscreen Playback ( ) icon to view a recorded video.

The resolution settings available are:

Record Mode

Video recording

again to show the bars.

immediately without the indicator on the LCD screen.

used simultaneously.

simultaneously.

functions can not be used simultaneously.

mode.

Video Quality

Full HD 1080/30: 1920 x 1080p 30fps

60p

HD60 720/60: 1280 x 720p 60fps HD30 720/30: 1280 x 720p 30fps VGA 480/30: 640 x 480p 30fps

The image resolution captured during video recording is the same as the video resolution.

NOTE

Record Mode

Photo recording

Press the Photo ( ) button halfway down until the focusing frame turns from white to green. Then press it fully down to take a photo.

Press the Playback button or touch the onscreen ( ) icon to view the photo.

The Resolution settings available are:

Image Quality High-16MP: 4608 x 3456 Standard-5MP: 2592 x 1944 Low-3MP: 2048 x 1536

Using Digital Light or Light function

This setting allows you to brighten the subject or extend the dynamic range of high contrast and backlight, so objects appear brighter and clearer.

1 Press the Light button.

The Digital Light ( ) icon appears on the screen.

2 Press the Light button again.

The Light ( ) icon appears on the screen. The light turns ON, providing illumination while recording.

3 Press the Video/Photo button to start recording or to take a

photo.

4 Press the Light button again to turn it OFF.

The light is disabled automatically when battery power is low.

Using the Zoom function

The Zoom function magnifies images when recording Videos or taking Photos.

❖ Press the Tele/Wide (T/W) buttons to zoom IN/OUT.

The camcorder zooms in by Optical Zoom first. When the Optical Zoom factor is at maximum, zooming stops temporarily. Press and hold the Tele (T) button when you want to zoom in beyond the Optical Zoom range. The Digital Zoom is activated and zooming continues.

Record Mode

Menu options/operations

❖ The Zoom function can be set from 1x~2700x (23x Optical

Zoom and 120x Digital Zoom).

Menu options/operations

Video Setting Photo Setting Effects Setup* Delete

Light Resolution Stabilization Motion Detection Face Tracking Slow Motion Pre-Record Time Lapse Date Printing Continuous Play

Light Resolution Self-Timer Smile Detection Date Printing ISO Slideshow

Macro mode Exposure Measure Scene Filter White Balance

Menu Sound TV Language Time Setting Format Default Setting

Delete Video Delete Photo Select & Delete Delete All

*Please see “Camcorder Settings” on page 52 for more information about Setup.

Operation Screen

1 Touch the onscreen ( ) icon.

The Menu screen appears. The available options are Video Setting,

Photo Setting, Effects, Setup, and Delete.

2 Touch the desired onscreen icon twice.

The options menu appears.

3 Touch to select the specific option you

want to change, and touch it again to enter its settings menu.

4 Touch twice to validate the new

setting.

5 Touch the Return/Exit ( ) icon twice,

or hold it down to exit.

NOTE

Record Mode

Menu options/operations

Video Setting options

Operation Screen

1 Touch the onscreen ( ) icon.

The Menu screen appears.

2 Touch the Video Setting icon twice.

The Video Setting menu appears.

3 The Video Setting menu options are:

Light, Resolution, Stabilization, Motion Detection, Face Tracking, Slow Motion, Pre-Record, Time Lapse, Date Printing, and Continuous Play.

Touch the icon once to view the description, touch twice to activate.

Light

In this option, select a mode to brighten the shooting area or to extend the brightness of objects. The Light settings available are:

ON Turns the light ON, providing illumination when recording.

OFF Turns the light OFF.

Digital Light

Operation Screen

1 In the Video Setting menu, touch the

Light icon twice.

2 Touch to select the desired option. 3 Touch again to validate the new

setting.

4 Touch the Return/Exit ( ) icon twice,

or hold it down to exit.

Extends the dynamic range of high contrast and backlight, so objects appear brighter and clearer.

+ 118 hidden pages
