Toshiba 19SL410U, 24SL410U, 32SL410U User Manual

Owner’s Manual

Integrated High Definition LCD Television

19SL410U 24SL410U 32SL410U

For an overview of steps for setting up your new TV, see page 10.

Note: To display a High Definition picture, the TV must be receiving a High Definition signal (such as an over-the-air High Definition TV broadcast, a High Definition digital cable program, or a High Definition digital satellite program). For details, please contact your TV antenna installer, cable provider, or satellite provider.

Owner’s Record

The model number and serial number are on the back of your TV. Record these numbers in the spaces below. Refer to these numbers whenever you communicate with your Toshiba dealer about this TV. Model number:

Serial number:

49.18S01.001

Dear Customer,

Thank you for purchasing this Toshiba LCD TV. This manual will help you use the many exciting features of your new LCD TV. Before operating your LCD TV, please read this manual completely, and keep it nearby for future reference.

Safety Precautions

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

WARNING

RISK OF ELECTRIC SHOCK

DO NOT OPEN.

WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

WARNING

To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation instructions. See item 25 on page 4.

WARNING: If you decide to wall mount this television, always use a UL Listed wall bracket appropriate for the size and weight of this television. The use of any wall bracket other than a UL Listed wall bracket appropriate for the size and weight of this television for wall mounting this television could result in serious bodily injury and/or property damage. See “"Removing the Pedestal Stand"” ( page 5).

NOTE TO CATV INSTALLERS

This is a reminder to call the CATV system installer’s attention to Article 820-40 of the U.S. NEC, which provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical. For additional antenna grounding information, see items 32 and 33 on page 4.

CHILD SAFETY:

It Makes A Difference How and Where You Use Your Flat Panel Display

Congratulations on your purchase! As you enjoy your new product, please keep these safety tips in mind:

The Issue

• The home theater entertainment experience is a growing trend and larger flat panel displays are popular purchases. However, flat panel displays are not always supported on the proper stands or installed according to the manufacturer’s recommendations.

Tune Into Safety

• One size does NOT fit all. Follow the manufacture’s recommendations for the safe installation and use of your flat panel display.

• Carefully read and understand all enclosed instructions for proper use of this product.

• Don’t allow children to climb on or play with furniture and television sets.

• Don’t place flat panel displays on furniture that can easily be used as steps, such as a chest of drawers.

• Remember that children can become excited while watching a program, especially on a “larger than life” flat panel display. Care should be taken to place or install the display where it cannot be pushed, pulled over, or knocked down.

• Care should be taken to route all cords and cables connected to the flat panel display so that they cannot be pulled or grabbed by curious children.

Wall Mounting: If you decide to wall mount your flat panel display, always:

• Use a mount that has been recommended by the display manufacturer and/or listed by an independent laboratory (such as UL, CSA, ETL).

• Follow all instructions supplied by the display and wall mount manufacturers.

• If you have any doubts about your ability to safely install your flat panel display, contact your retailer about professional installation.

• Make sure that the wall where you are mounting the display is appropriate. Some wall mounts are not designed to be mounted to walls with steel studs or old cinder block construction. If you are unsure, contact a professional installer.

• A minimum of two people are required for installation. Flat panel displays can be heavy.

• Flat panel displays that are inappropriately situated on dressers,

bookcases, shelves, desks,

speakers, chests or carts may fall over and cause injury.

TOSHIBA Cares!

• The consumer electronics industry is committed to making home

entertainment enjoyable and safe.

Important Safety Instructions

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

9) Do not defeat the safety purpose of the polarized or grounding type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10) Protect the power cord from being

walked on or pinched, particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11) Only use attachments/accessories specified by the

manufacturer.

12) Use only with the cart, stand, tripod,

bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

13) Unplug this apparatus during lightning storms or

when unused for long periods of time.

14) Refer all servicing to qualified service personnel. Ser-

vicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

Wide blade

Additional Safety Precautions

14a) CAUTION: If the TV is dropped and the cabinet or

enclosure surface has been damaged or the TV does not operate normally, take the following precautions:

• ALWAYS turn off the TV and unplug the power cord to avoid possible electric shock or fire.

• NEVER allow your body to come in contact with any broken glass or liquid from the damaged television. The LCD panel inside the TV contains glass and a toxic liquid. If the liquid comes in contact with your mouth or eyes, or your skin is cut by broken glass,

rinse the affected area thoroughly with water and consult your doctor.

• ALWAYS contact a service technician to inspect the TV any time it has been damaged or dropped.

15) CAUTION:

• To reduce the risk of electric shock, do not use the polarized plug with an extension cord, receptacle, or other outlet unless the blades can be inserted completely to prevent blade exposure.

• To prevent electric shock, match wide blade of plug to wide slot; fully insert.

16) CAUTION: Do not let children swallow the product or play with

the plastic bag. Keep the product and the plastic bag out of the reach of children.

17) CAUTION: Do not let water or other liquids come into contact

with the product, as it may result in damage.

18) WARNING:

• To prevent the spread of fire, keep candles or other

open flames away from this product at all times.

• Keep the product away from direct sunlight, fire or a

heat source such as a heater. This may reduce the product lifetime or result in fire.

Installation, Care, and Service

Installation

Follow these recommendations and precautions and heed all warnings when installing your TV:

19)

20) ALWAYS plug the product into an outlet that is located

in such a manner that it can be easily unplugged in case the product requires service.

21) NEVER route the product’s power cord inside a wall or

similar enclosed area.

22) Never modify this equipment. Changes or modifica-

tions may void: a) the warranty, and b) the user’s authority to operate this equipment under the rules of the Federal Communications Commission.

23)

Never place the TV on an unstable cart, stand, or table. The TV may fall, causing serious personal injury, death, or serious damage to the TV.

24) To avoid damage to this product, never place or store

the TV in direct sunlight; hot, humid areas; or areas subject to excessive dust or vibration.

WARNING: NEVER expose batteries to excessive heat such as sunshine, fire or the like.

DANGER: RISK OF SERIOUS PERSONAL INJURY, DEATH, OR EQUIPMENT DAMAGE!

(continued)

25) Always place the TV on the floor or a sturdy, level, stable surface that can support the weight of the unit. To secure the TV, use a sturdy strap from the hook(s) on the rear of the TV to a wall stud, pillar, or other immovable structure. Make sure the strap is tight, secure, and parallel to the floor.

Sturdy strap (as short as possible)

TV side

4” min.

Hook

TV top

26) The apparatus should not be exposed to dripping or splashing. Objects filled with liquids should not be placed on the apparatus.

27) Never block or cover the slots or openings in the TV cabinet back, bottom, and sides. Never place the TV:

• On a bed, sofa, rug, or similar

surface;

• Too close to drapes, curtains, or

walls; or

• In a confined space such as a

bookcase, built-in cabinet, or any other place with poor ventilation.

The slots and openings are provided to protect the TV from overheating and to help maintain reliable operation of the TV. Leave a space of at least 4 (four) inches around the TV.

28) Always place the back of the television at least four (4) inches away from any vertical surface (such as a wall) to allow proper ventilation.

29) Never allow anything to rest on or roll over the power cord, and never place the TV where the power cord is subject to wear or abuse.

30) Never overload wall outlets and extension cords.

31) Always operate this equipment from a 120 VAC, 60 Hz power source only.

32) Always make sure the antenna system is properly grounded to provide adequate protection against voltage surges and built-up static charges (see Section 810 of the National Electric Code).

33)

• Use extreme care to make sure you are never in a position where your body (or any item you are in contact with, such as a ladder or screwdriver) can accidentally touch overhead power lines. Never locate the antenna near overhead power lines or other electrical circuits.

• Never attempt to install any of the following during lightning activity: a) an antenna system; or b) cables, wires, or any home theater component connected to an antenna or phone system.

DANGER: RISK OF SERIOUS PERSONAL

INJURY OR DEATH!

Care

For better performance and safer operation of your TOSHIBA TV, follow these recommendations and precautions:

34) If you use the TV in a room whose temperature is 32 F (0 C) or below, the picture brightness may vary until the LCD warms up. This is not a sign of malfunction.

35) Always unplug the TV before cleaning. Gently wipe the display panel surface (the TV screen) using a dry, soft cloth (cotton, flannel, etc.). A hard cloth may damage the surface of the panel. Avoid contact with alcohol, thinner, benzene, acidic or alkaline solvent cleaners, abrasive cleaners, or chemical cloths, which may damage the surface. Never spray volatile compounds such as insecticide on the cabinet. Such products may damage or discolor the cabinet.

36) Never hit, press, or place anything on the back cover. These actions will damage internal parts.

37)

Never spill liquids or push objects of any kind into the TV cabinet slots.

38) While it is thundering, do not touch the connecting cables or apparatus.

39) To further protect your TV from lightning and power surges, always unplug the power cord and disconnect the antenna if you leave the TV unattended or unused for long periods of time.

WARNING:

RISK OF ELECTRIC SHOCK!

(continued)

40) ALWAYS unplug the TV to completely disconnect from mains power. When the TV is turned off using the on/ off switch, it is not completely disconnected from power and a minute amount of current is still consumed.

41) During normal use, the TV may make occasional snapping or popping sounds. This is normal, especially when the unit is being turned on or off. If these sounds become frequent or continuous, unplug the power cord and contact a Toshiba Authorized Service Provider.

42)

Never strike the screen with a sharp or heavy object.

43)

• The LCD screen of this product can be damaged by ultraviolet radiation from the sun. When selecting a location for the television, avoid locations where the screen may be exposed to direct sunlight, such as in front of a window.

• Never touch, press, or place anything on the LCD screen. These actions will damage the LCD screen. If you need to clean the LCD screen, follow the instructions in item 35 on page 4.

DANGER: RISK OF SERIOUS PERSONAL

INJURY OR DEATH!

Service

44)

Never attempt to service the TV yourself. Opening and removing the covers may expose you to dangerous voltage or other hazards. Failure to follow this WARNING may result in death or serious injury. Refer all servicing not specified in this manual to a Toshiba Authorized Service Provider.

45) If you have the TV serviced:

• Ask the service technician to use only replacement parts specified by the manufacturer.

• Upon completion of service, ask the service technician to perform routine safety checks to determine that the TV is in safe operating condition.

WARNING:

RISK OF ELECTRIC SHOCK!

Choosing a location for your LCD TV

To Display your LCD TV on the included Pedestal Stand:

Observe the following safety precautions:

1) Read and Follow the pedestal assembly instructions included with the pedestal.

CAUTION: Before beginning pedestal assembly, carefully lay the front of the LCD Panel face down on a flat, cushioned surface such as a quilt or blanket. Leave the bottom of the unit protruding over the edge of the surface and assemble the pedestal as indicated below.

Note: Extreme care should always be used when attaching the pedestal stand to avoid damage to the LCD panel.

2) Place the TV on a sturdy, level surface that can support the weight of the TV.

3) Be sure to secure the TV to a wall, pillar, surface, or other immovable structure. ( item 25, page 4).

To Display your LCD TV using a Wall Bracket:

If you decide to wall mount your LCD TV, always use a UL listed wall bracket appropriate for the size and weight of the LCD TV ( page 2):

1) CAUTION: Two people are required for installation.

2) Unplug and remove any cables and/or other component connectors from the rear of the TV.

3) Remove the screws of the VESA Mounting Pattern show in the next page.

CAUTION: Do not use the screws removed from the back cover to attach the wall mount bracket to the TV.

4) Always use the screws supplied or recommended by the wall mount manufacturer.

5) Follow the instructions provided with your wall bracket. Before proceeding, make sure the appropriate bracket(s) are attached to the wall and the back of the TV as described in the instructions provided with the wall bracket.

6) After attaching the appropriate bracket(s) to the wall and the back of the TV, remove the pedestal stand from the TV as described on the following page.

7) VESA Mounting Pattern

TV Size Hole Pattern (HxV) Screw Size

19” 100x100 mm M4 24” 100x100 mm M4 32” 200x200 mm M6

Removing the Pedestal Stand

1) Carefully lay the front of the unit face down on a flat, cushioned surface such as a quilt or blanket. Leave the stand protruding over the edge of the surface.

Note: Extreme care should always be used when removing the pedestal stand to avoid damage to the LCD panel.

(unit in mm)

2) Remove the four screws shown in the below diagram. This will allow removal of the pedestal stand.

3) Once you have removed the four screws that hold the pedestal stand in place, remove the pedestal stand from the TV.

19” TV

Four screws

24” TV

Four screws

32” TV

VESA Mounting Pattern

Sturdy strap (as short as possible)

VESA Mounting Pattern

Hook Sturdy strap

(as short as possible)

VESA Mounting Pattern

Hook

FCC Declaration of Conformity Compliance Statement (Part 15):

The Toshiba 19SL410U, 24SL410U, and 32SL410U Tel ev isi on s comply with Part 15 of the FCC rules.

Operation is subject to the following two conditions: (1) This device may not cause harmful interference,

and

(2) This device must accept any interference

received, including interference that may cause undesired operation.

The party responsible for compliance to these rules is:

Toshiba America Information Systems, Inc.

9740 Irvine Blvd.; Irvine, CA 92618 Ph: 1-800-631-3811

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by removing and applying power to the equipment, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and the receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Caution: Changes or modifications to this equipment not expressly approved by Toshiba could void the user’s authority to operate this equipment.

Four screws

Hook

Sturdy strap (as short as possible)

ENERGY STAR

ENERGY STAR User Information Statement: the factory default settings of this television meet ENERGY STAR requirements. Changing Picture Settings may increase energy consumption, possibly beyond the limits required for ENERGY STAR qualification.

To ensure your television is operating at optimal energy efficiency, select [Home] mode during initial activation.

User Information

To return to [Home] mode settings, select [Standard] picture mode. [Standard] mode is recommended for normal home use.

ENERGY STAR® qualified TV. Products that earn the ENERGY STAR prevent green house gas emissions by meeting strict guidelines set by the U.S. Environmental Protection Agency. ENERGY STAR and the ENERGY STAR mark are registered U.S. marks.

Important notes about your LCD TV

The following symptoms are technical limitations of LCD Display technology and are not an indication of malfunction; therefore, Toshiba is not responsible for perceived issues resulting from these symptoms.

(1) An afterimage (ghost) may appear on the screen

if a fixed, nonmoving image is displayed for a long period of time. The afterimage is not permanent and will disappear in a short period of time.

(2) The LCD panel contained in this TV is manufac-

tured using an extremely high level of precision technology; however, there may be an occasional pixel (dot of light) that does not operate properly (does not light, remains constantly lit, etc.). This is a structural property of LCD technology, is not a sign of malfunction, and is not covered under your warranty. Such pixels are not visible when the picture is viewed from a normal viewing distance.

Note: Interactive video games that involve shooting a “gun” type of joystick at an onscreen target may not work with this TV.

Trademark Information

• Manufactured under license from Dolby Laboratories.

Dolby and the double-D symbol are trademarks of Dolby Laboratories.

• HDMI, the HDMI logo, and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.

• MPEG Layer-3 audio coding technology licensed from Fraunhofer IIS and Thomson.

Contents

Important Safety Instructions............................. 3

Installation, Care, and Service...........................3

Chapter 1: Introduction.................................... 9

Features of your new TV ............................................... 9

Overview of steps for installing, setting up, and using

your new TV .................................................................. 10

TV front and side panel controls and connections ........ 11

TV back panel connections............................................ 12

Chapter 2: Connecting your TV...........................13

Overview of cable types ................................................ 13

About the connection illustrations ................................. 13

Connecting a VCR and antenna, Cable TV or Camcorder

....................................................................................... 14

Connecting a DVD player with ColorStream®

(component video), a VCR, or a satellite receiver ........ 15

Connecting an HDMI® or DVI device to the

HDMI input ................................................................... 16

REGZA-LINK® connection ......................................... 17

Connecting a digital audio system................................. 18

Connecting a stereo audio system ................................. 18

Connecting a personal computer (PC)........................... 19

Chapter 3: Using the remote control ....................20

Installing the remote control batteries ........................... 20

Remote control effective range...................................... 20

Adjusting the viewing angle .......................................... 20

Learning about the remote control ................................. 21

Chapter 4: Menu layout and navigation .................22

Main menu layout .......................................................... 22

Setup/Installation menu layout ...................................... 23

Navigating the menu system.......................................... 23

Chapter 5: Setting up your TV ............................24

Initial Setup.................................................................... 24

Selecting the menu language ......................................... 24

Configuring the antenna input source for the

ANT/CABLE terminal .................................................. 24

Programming channels into the TV’s channel memory 24

Programming channels automatically ....................... 25

Setting channel skip .................................................. 26

Labeling channels .......................................................... 26

Setting the HDMI® audio mode.................................... 27

Viewing the digital signal meter .................................... 28

Setting the time zone ..................................................... 28

Viewing the system status ............................................. 28

Reset Factory Defaults .............................................. 28

Chapter 6: Using the TV’s features ......................29

Selecting the video input source to view ....................... 29

Labeling the video input sources ................................... 29

To clear the input labels: ........................................... 30

Tuning channels............................................................. 30

Tuning channels using the Channel Browser™ ........ 30

Favorites Browser ..................................................... 30

To open the Channel Browser™: .............................. 31

Elements of the Channel Browser™ ......................... 31

Adding and clearing channels and inputs in the

History List................................................................ 32

Setting the Channel Tuning Mode ............................ 32

Tuning to the next programmed channel................... 32

Tuning to a specific channel (programmed or

unprogrammed) ......................................................... 32

Switching between two channels using Channel

Return ........................................................................ 33

Switching between two channels using SurfLock™. 33

Selecting the picture size ............................................... 33

Scrolling the TheaterWide® picture (TheaterWide 2 and

3 only)............................................................................ 35

Using the auto aspect ratio feature ................................ 35

Selecting the cinema mode ............................................ 35

Using the FREEZE feature ............................................ 36

Adjusting the picture ..................................................... 36

Selecting the picture mode ........................................ 36

Adjusting the picture quality ..................................... 36

Using the closed caption mode ...................................... 37

Base closed captions .................................................. 37

Digital CC Settings .................................................... 37

CC Selector................................................................ 37

Adjusting the audio ........................................................ 38

Muting the sound ....................................................... 38

Using the digital audio selector ................................. 38

Selecting stereo/SAP broadcasts ............................... 38

Adjusting the audio quality........................................ 39

Selecting the optical audio output format.................. 39

Using the Dolby® Digital Dynamic Range Control

feature ........................................................................ 39

Using the Locks menu ................................................... 39

Entering the PIN code................................................ 39

If you cannot remember your PIN code .................... 40

Changing your PIN code ........................................... 40

Blocking TV programs and movies by rating

(V-Chip)..................................................................... 40

Downloading an additional rating system for blocking

TV programs and movies .......................................... 41

Locking channels ....................................................... 42

Unlocking programs temporarily............................... 42

Using the input lock feature....................................... 42

Using the Game Timer® ........................................... 43

Using the control panel lock feature.......................... 43

Using the PC settings feature ......................................... 43

Setting the PC Audio ..................................................... 44

Using the Media Player.................................................. 44

Using the Media Player with USB ............................ 44

To select the Auto Start function ............................... 45

To open the Media Player.......................................... 45

Viewing photo files ................................................... 45

Playing music files..................................................... 46

During playback ........................................................ 46

Viewing photo files and playing music files at same

time ............................................................................ 46

Setting the sleep timer.................................................... 47

Automatic Power Down................................................. 47

No Signal Power Down ................................................. 48

Using REGZA-LINK® .................................................. 48

REGZA-LINK® playback device (DVD player, etc.)

control........................................................................ 48

REGZA-LINK® input source selection .................... 49

VOLUME and MUTE controls of Audio Receiver...49

Other REGZA-LINK® functions .............................. 49

Displaying TV status information .................................. 50

Understanding the last mode memory feature ............... 50

Chapter 7: Using the TV’s advanced features ......... 51

Using the advanced picture settings features ................. 51

Using Dynamic Contrast ........................................... 51

Using the static gamma feature ................................. 51

Selecting the color temperature ................................. 51

Using CableClear® digital noise reduction............... 51

Using MPEG noise reduction .................................... 52

Using the Color Master® feature .............................. 52

Using the Base Color Adjustment ............................. 52

Using the Game Mode feature ................................... 52

Chapter 8: Troubleshooting .............................. 53

General troubleshooting ................................................. 53

Chapter 9: Appendix....................................... 55

Specifications ................................................................. 55

Acceptable signal formats for PC IN and HDMI

terminals......................................................................... 56

Limited United States Warranty for LCD Televisions .. 57 Limited Canadian Warranty for Toshiba Brand Flat

Panel Televisions ........................................................... 58

apter 1: Introduction

Features of your new TV

The following are just a few of the many exciting features of your new Toshiba widescreen, integrated HD, LCD TV:

• Integrated digital tuning (8VSB ATSC and QAM) eliminates the need for a separate digital converter set-top box (in most cases).

• 1366 x 768 (19SL410U and 32SL410U)/1920 x 1080 (24SL410U) output resolution.

• Two H D M I interfaces 1080p input support ( page 16).

• One set of ColorStream component video inputs ( page 15).

• Digital Audio Out optical audio connection with

Dolby

• CableClear page 51).

• PC IN (Analog RGB) computer terminal ( page

19).

• REGZA-LINK allows control of external devices from the TV remote via HDMI connection( page

48).

• Media Player allows you to view photo files and to play music.( page 44).

digital, high-definition multimedia

HD high-resolution

Digital optical output format ( page 18).

digital picture noise reduction (

Chapter 1: Introduction

Overview of steps for installing, setting up, and using your new TV

Follow these steps to set up your TV and begin using its many exciting features.

1 Carefully read the important safety, installation,

care, and service information. Keep this manual for future reference.

2 Observe the following when choosing a location

for the TV:

• Read "Important notes about your LCD TV" ( page 7).

• Place the TV on the floor or a sturdy, level, stable surface that can support the weight of the unit. Secure the TV to a wall, pillar, or other immovable structure ( page 4).

• Place the TV in a location where light does not reflect on the screen.

• Place the TV far enough from walls and other objects to allow proper ventilation. Inadequate ventilation may cause overheating, which will damage the TV. THIS TYPE OF DAMAGE IS NOT COVERED UNDER THE TOSHIBA WARRANTY.

3 Do not plug in any power cords until AFTER you

have connected all cables and devices to your TV.

4 BEFORE connecting cables or devices to the TV,

learn the functions of the TV’s connections and controls ( pages 11-12).

5 Connect your other electronic device(s) to the TV

( pages 13-19).

6 Install the batteries in the remote control ( page

20).

7 See "Learning about the remote control" ( page

21) for an overview of the buttons on the remote control.

8 AFTER connecting all cables and devices, plug in

the power cords for your TV and other devices. Then press POWER on the TV control panel or remote control to turn on the TV. If the TV stops responding to the remote control or TV control panel and you cannot turn the TV off or on, please unplug the power cord for a few seconds then plug it back in and try again.

9 See "Chapter 4: Menu layout and navigation" for

a quick overview of navigating the TV’s menu system ( page 22).

10 Program channels into the TV’s channel

memory ( page 24).

11 For details on using the TV’s features, see

Chapters 6 and 7.

12 For help, refer to "Chapter 8: Troubleshooting". 13 For technical specifications and warranty

information, see Chapter 9.

14 Enjoy your new TV!

Chapter 1: Introduction

TV front and side panel controls and connections

Model 19SL410U is used in this manual for illustration purposes.

Left side panel TV front

Touch sensor

1 Green LED

Power LED (Green) = Power indicator

2 Remote sensor

Point the remote control toward this remote sensor ( "Remote control effective range" on page 20).

3 POWER

Touch to turn the TV on and off.

4 CH (CHANNEL) ST

When no menu is on-screen, these keys change the channel (programmed channels only; page

24).

5 ARROWS ST+ -

When a menu is on-screen, these keys function as up/down/left/right menu navigation buttons.

6 VOL (VOLUME) + -

These keys adjust the volume level.

7 MENU

To access the menu ( pages 22 - 23). When a menu is on-screen, the MENU key functions as the

RETURN button.

8 INPUT

To change the source you are viewing (ANT/ CABLE, Video, ColorStream HD, HDMI 1, HDMI 2, PC). When a menu is on-screen, the INPUT key functions as the OK button.

9 USB port

To access photo or music files.

TV top

Chapter 1: Introduction

TV back panel connections

For an explanation of cable types and connections,see pages 13 - 19.

TV back

Power Cord

1 HDMI

2 DIGITAL AUDIO OUT

3 ANT/CABLE

4 VIDEO IN

High-Definition Multimedia Interface input receives digital audio and uncompressed digital video from an HDMI device or uncompressed digital video from a DVI device.

Optical audio output in Dolby Digital or PCM (pulse-code modulation) format for connecting an external Dolby Digital decoder, amplifier, A/V receiver, or home theater system with optical audio input.

Antenna input that supports analog (NTSC) and digital (ATSC) off-air antenna signals and analog and digital Cable TV (QAM) signals.

Standard (composite) video and standard audio inputs plus for connecting devices with composite video.

Note:

• Standard (composite) video cable carry only

video information; separate audio cables are required for a complete connection.

• The VIDEO IN and ColorStream® HD inputs

share the same audio input terminals.

5 AUDIO OUT

Analog stereo audio output for connecting an external amplifier, A/V receiver, or home theater system with analog stereo audio input.

6 ColorStream

ColorStream input (with standard stereo audio inputs) for connecting devices with component video output, such as a Toshiba DVD player with

ColorStream

Note:

• Component video cables carry only video information; separate audio cables are required for a complete connection.

• The VIDEO IN and ColorStream® HD inputs share the same audio input terminals.

7 PC/HDMI 1 AUDIO IN

PC audio input terminals are shared with HDMI-1 analog audio input terminals, and their use can be configured in the Audio Setup menu ( page

44).

8 RGB/PC IN

For use when connecting a personal computer.

high definition component video

apter 2: Connecting your

Overview of cable types

Cables can be purchased from most stores that sell audio/video devices. Before purchasing any cables, be sure of connector types required by your devices and the length of each cable.

Coaxial (F-type) cable

Coaxial (F-type) cable is used for connecting your antenna, cable TV service, and/or cable converter box to the ANT/CABLE input on your TV.

Standard A/V cables (red/white/yellow)

Standard A/V cables (composite video) usually come in sets of three, and are for use with video devices with analog audio and composite video output. These cables (and the related inputs on your TV) are typically color-coded according to use: yellow for video, red for stereo right audio, and white for stereo left (or mono) audio.

Component video cables (red/green/blue)

Component video cables come in sets of three and are for use with video devices with component video

output. (ColorStream component video.) These cables are typically colorcoded red, green, and blue. Separate audio cables are required for a complete connection.

Note: Component video cables provide better picture performance than a standard (composite) video.

HDMI® cable (with HDMI Logo “ “)

is Toshiba’s brand of

Optical audio cable

Optical audio cable is for connecting receivers with Dolby Digital or PCM (pulse-code modulation) optical audio input to the TV’s DIGITAL AUDIO OUT terminal ( page 18).

Analog RGB (15-pin) computer cable

Analog RGB (15-pin) computer cable is for connecting a PC to the TV’s RGB/PC IN terminal ( page 19).

Note: Separate audio cables are required for a complete connection.

3.5mm Stereo to RCA Y-cable

3.5mm Stereo to RCA Y-Cable is for connecting audio signal from DVI device to TV.

About the connection illustrations

You can connect different types and brands of devices to your TV in several different configurations. The connection illustrations in this manual are representative of typical device connections only. The input/output terminals on your devices may differ from those illustrated herein. For details on connecting and using your specific devices, refer to each device’s owner’s manual.

HDMI (High-Definition Multimedia Interface) cable is for use with devices with an HDMI output. An HDMI cable delivers digital audio and video in its native format. This cable carries both video and audio information; therefore, separate audio cables are not required for a complete HDMI device connection ( page 16 and page 19).

Note: An HDMI cable provides the best audio and picture performance.

Chapter 2: Connecting your TV

Connecting a VCR and antenna, Cable TV or Camcorder

AUDIO

VIDEO

OUT

Camcorder

TV back panel

From Cable TV

or antenna

Coaxial cable

From Cable TV

Standard A/V cables

You will need:

• Coaxial cables

• Standard A/V cables

- If you have a mono VCR, connect L / MONO on the TV to your VCR’s audio out terminal using the white audio cable only.

• Standard audio cables (If you have a mono VCR)

Note: When you use a Cable box, you may not be able to use the remote control to program or access certain features on the TV.

To view the antenna or Cable signal:

Select the ANT/CABLE video input source on the TV.*

To view basic and premium Cable channels:

Turn OFF the VCR. Select the ANT/CABLE video input source on the TV.* Tune the TV to channel 3 or 4 (whichever channel the Cable box output is set to). Use the Cable box controls to change channels.

Stereo VCR

Cable box

To view the VCR:

Turn ON the VCR. Select the Video video input source on the TV.*

To view the camcorder video:

Select the Video video input source on the TV.*

* To select the video input source, press on the

remote control ( page 21).

The unauthorized recording, use, distribution, or revision of television programs, videotapes, DVDs, and other materials is prohibited under the Copyright Laws of the United States and other countries, and may subject you to civil and criminal liability.

Chapter 2: Connecting your TV

Connecting a DVD player with ColorStream® (component video), a VCR, or a satellite receiver

From

antenna

TV back panel

Component video cable

Satellite receiver with component

video or DVD player with

component video

From satellite dish

You will need:

• Coaxial cables

• Standard A/V cables

- If you have a mono VCR, connect L / MONO on the TV to your VCR’s audio out terminal using the white audio cable only.

• Standard audio cables

• Component video cables

- You can connect the component video cables (plus audio cables) from the DVD player or satellite receiver to the ColorStream HD terminals (Y, PB, and PR) on the TV. The ColorStream HD terminals can be used with Progressive (480p, 720p) and Interlaced (480i, 1080i) scan systems. A 1080i signal will provide the best picture performance (1080p is not supported).

- If your DVD player or satellite receiver does not have component video, connect a standard A/V cable to VIDEO on the back panel. If your DVD player has HDMI video, see page 16.

To view antenna or Cable channels:

Select the ANT/CABLE video input source on the TV.*

Stereo VCR

Coaxial cable

Standard A/V cables

To view the DVD player:

Turn ON the DVD player. Select the ColorStream HD video input source on the TV.*

To view satellite programs using the component video connections:

Turn on the satellite receiver. Select the ColorStream HD video input source on the TV.*

To view the VCR or view and record antenna channels:

Turn ON the VCR. Tune the VCR to the channel you want to watch. Select the Video video input source on the TV.*

To record a TV program while watching a DVD:

Turn ON the VCR. Tune the VCR to the channel to record.

* To select the video input source, press on the

remote control ( page 21).

Chapter 2: Connecting your TV

Connecting an HDMI® or DVI device to the HDMI input

The HDMI input on your TV receives digital audio and uncompressed digital video from an HDMI source device, or uncompressed digital video from a DVI (Digital Visual Interface) source device. This input is designed to accept HDCP (High-Bandwidth Digital-Content Protection) program material in

digital form from EIA/CEA-861-D-compliant consumer electronic devices (such as a set-top box or DVD player with HDMI or DVI output).

The HDMI input can accept and display VGA, SVGA, XGA, WXGA, SXGA, 480i (60Hz), 480p (60Hz), 720p (60Hz), 1080i (60Hz) and 1080p (24Hz/60Hz) signal formats. For detailed signal specifications, see page 56.

Supported Audio format: Linear PCM, sampling rate 32/44.1/ 48 kHz

Note: To connect a PC to the HDMI input, see page 19.

To connect an HDMI device, you will need:

• One HDMI cable (type A connector) per HDMI device

- For proper operation, it is recommended that you use an HDMI cable with the HDMI Logo

().

- To display an 1080i/60Hz signal format, you will need a Category 2 cable. Conventional HDMI/DVI cable may not work properly.

- HDMI cable transfers both video and audio. Separate analog audio cables are not required (see illustration).

- See “Setting the HDMI page 27).

TV back panel

HDMI device

audio mode” (

[1]

HDMI cable

To connect a DVI device, you will need:

• One HDMI-to-DVI adapter cable (HDMI type A connector) per DVI device

- For proper operation, the length of an HDMto-DVI adapter cable should not exceed 9.8 ft (3m). The recommended length is 6.6 ft (2m).

• One 3.5mm stereo to RCA Y-cable

- An HDMI-to-DVI adapter cable transfers video only. Separate analog audio cables are required (see illustration).

- See “Setting the HDMI page 27).

TV back panel

HDMI-to-DVI

adapter

cable

DVI device

Note: To ensure that the HDMI or DVI device is reset properly, it is recommended that you follow these procedures:

• When turning on your electronic components, turn on the TV first, and then the HDMI or DVI device.

• When turning off your electronic components, turn off the HDMI or DVI device first, and then the TV.

[1] EIA/CEA-861-D compliance covers the transmission

of uncompressed digital video with high-bandwidth digital content protection, which is being standardized for reception of high-definition video signals. Because this is an evolving technology, it is possible that some devices may not operate properly with the TV.

audio mode” (

To view the HDMI device video:

Select the HDMI 1 or HDMI 2 video input source on the TV.*

* To select the video input source, press on the

remote control ( page 21).

Chapter 2: Connecting your TV

REGZA-LINK® connection

You can control the basic functions of connected audio/video devices using the TV’s remote control if you connect a REGZA-LINK compatible audio receiver or playback device. For an explanation of setup and operations, see page 48.

TV back panel

Playback device

Audio receiver

Playback device (REGZA-LINK DVD player, etc.)

(REGZA-LINK DVD player, etc.)

To connect an Audio Receiver and Playback Devices, you will need:

• HDMI cables ( page 13)

Note:

• If several devices are connected, the REGZA LINK feature may not operate properly.

• For proper operation, it is recommended that you use HDMI cables with the HDMI Logo

().

Before controlling the device(s):

• After completing the above connections, set the

REGZA-LINK Setup menu as you desire ( page 49).

• The connected devices must also be set. For details, see the operation manual for each device.

• The REGZA-LINK feature uses the CEC technology as regulated by the HDMI standard.

• This feature is limited to models incorporating Toshiba’s REGZA-LINK. However, Toshiba is not liable for those operations. Refer to the individual instruction manuals for compatibility information.

Note: This feature may not work properly depending on the devices that are connected.

Chapter 2: Connecting your TV

Connecting a digital audio system

The TV’s DIGITAL AUDIO OUT terminal outputs a

Digital or 2-channel down-mixed PCM

*Dolby (pulse-code modulation) signal for use with an

external Dolby

Digital decoder or other external

audio system with optical audio input.

You will need:

• Optical audio cable (Use an optical audio cable that has the larger “TosLink” connector and not the smaller “mini-optical” connector.)

Dolby Digital decoder or

other digital audio system

Optical

TV back panel

audio cable

To control the audio:

1 Turn on the TV and the digital audio device. 2 Press on the TV’s remote control and open

the Sound menu.

3 Highlight Audio Setup and press .

Note:

• Some audio systems may not be compatible with Dolby Digital bitstream signals. Older audio systems that are not compatible with standard optical out signals may not work properly, creating a high noise level that may damage speakers or headphones. THIS DAMAGE IS NOT COVERED BY YOUR WARRANTY.

• The DIGITAL AUDIO OUT terminal may not output some digital audio sources because of copy restrictions.

* Manufactured under license from Dolby Laboratories.

Dolby, and the double-D symbol are trademarks of Dolby Laboratories.

Connecting a stereo audio system

With the TV’s analog stereo audio output terminals, you can connect the TV to a stereo audio system that is equipped with analog stereo audio input terminals.

You will need:

• One stereo RCA to RCA audio cable

TV back panel

Sound

Digital Audio Selector

Audio Settings

Audio Setup

4 In the Optical Output Format field, select either

Dolby Digital or PCM, depending on your device

( "Selecting the optical audio output format" on page 39).

Audio Setup

PC Audio No

HDMI 1 Audio Auto

MTS Stereo

Language English

Optical Output Format

Dolby Digital Dynamic Range Control

Reset

Dolby Digital

Compressed

Done

Stereo audio system

Stereo RCA to RCA

audio cable

Note: The audio signal from this output is always available. However, the volume is fixed and can only be controlled by the stereo audio system connected.

Chapter 2: Connecting your TV

Connecting a personal computer (PC)

With either the RGB/PC IN or HDMI IN connection, you can watch your computer’s display on the TV and hear the sound from the TV’s speakers.

To connect a PC to the RGB/PC IN terminal on the TV:

When connecting a PC to the RGB/PC IN terminal on the TV, use an analog RGB (15-pin) computer cable and a PC audio cable.

TV back panel

Analog

RGB

computer

cable

PC audio cable

PC audio output

Computer

Conversion adapter

(if necessary)

• To use a PC, set the monitor output resolution on the PC before connecting it to the TV. The RGB/PC IN terminal can accept and display VGA, SVGA, XGA and WXGA signal formats. For detailed signal specifications ( page 56). Other formats or nonstandard signals will not be displayed correctly.

• To display the optimum picture, use the PC setting feature ( "Using the PC settings feature" on page

43).

Note:

• The PC audio input terminal on the TV is

shared with the HDMI 1 analog audio input terminal (

• Some PC models cannot be connected to this

TV.

• An adapter is not needed for computers with a

compatible mini D-sub15-pin terminal.

• Depending on the DVD’s title and the

specifications of the PC on which you are playing the DVD-Video, some scenes may be skipped or you may not be able to pause during multi-angle scenes.

page 44).

• Signal names for mini D-sub 15-pin connector

Pin No.

Signal name

Pin No.

Signal name

Pin No.

Signal name

1R 6Ground11Reserved 2G 7Ground12SDA 3B 8Ground13H-sync 4 Reserved 9 5V 14 V-sync 5 Reserved 10 Ground 15 SCL

To connect a PC to the HDMI IN terminal on the TV:

When connecting a PC to the HDMI IN terminal on the TV, use an HDMI-to-DVI adapter cable and analog audio cables.

If connecting a PC with an HDMI terminal, use an HDMI cable (type A connector). Separate analog cables are not necessary ( page 13).

TV back panel

HDMI-to-DVI

adapter

cable

PC audio cable

PC audio output

Computer

The HDMI IN input can accept and display VGA, SVGA, XGA, WXGA, SXGA, 480i (60Hz), 480p (60Hz), 720p (60Hz), 1080i (60Hz), and 1080p (24Hz/60Hz) signal formats. For detailed signal specifications, see page 56.

Note:

• The edges of the images may be hidden.

• If receiving a 480i (HDMI), 480p (HDMI), 720p, 1080i, or 1080p signal program, Native mode scales the video to display the entire picture within the borders of the screen (i.e. no overscanning).

+ 43 hidden pages
