TomTom 4FI722 User Manual

TomTom BRIDGE

User Manual

Contents

Welcome to the TomTom BRIDGE 5

The TomTom BRIDGE 6

Starting the TomTom BRIDGE .................................................................................... 7

Using gestures ...................................................................................................... 9

Apps on the TomTom BRIDGE .................................................................................. 11

Connecting the TomTom BRIDGE ............................................................................. 12

About connecting TomTom BRIDGE ....................................................................... 12

Connect using Bluetooth .................................................................................... 12

Connect using Portable Wi-Fi Hotspot ................................................................... 13

Reconnecting your smartphone ........................................................................... 13

Unable to get a connection ................................................................................ 14

Features on the TomTom BRIDGE ............................................................................. 15

Sleep settings ................................................................................................. 15

Memory card slot ............................................................................................. 15

Transferring files to your device .......................................................................... 15

System bar .................................................................................................... 16

Updating the software ...................................................................................... 16

Moving and resizing apps and widgets ................................................................... 17

Sending information to TomTom .......................................................................... 19

Clearing personal data ...................................................................................... 19

Taking a screenshot ......................................................................................... 19

Screen locking ................................................................................................ 20

Language .......................................................................................................... 21

Installing in your vehicle ....................................................................................... 22

Charging the TomTom BRIDGE ................................................................................. 23

The TomTom BRIDGE is not starting .......................................................................... 24

Caring for your TomTom navigation app .................................................................... 25

Online Reference Guide ........................................................................................ 26

Getting help ...................................................................................................... 27

TomTom Navigation App 28

Welcome to navigation with TomTom ....................................................................... 29

About TomTom services ........................................................................................ 30

GPS reception .................................................................................................... 31

What's on the TomTom Navigation app screen ............................................................. 32

The map view ................................................................................................. 32

The guidance view ........................................................................................... 34

The route bar ................................................................................................. 36

The quick menu .............................................................................................. 37

Navigation buttons ........................................................................................... 37

Other buttons ................................................................................................. 40

Volume control ............................................................................................... 41

Running in the background ................................................................................. 42

Changing the text and button size ........................................................................ 42

Traffic.............................................................................................................. 43

About TomTom Traffic ...................................................................................... 43

The route bar ................................................................................................. 43

Looking at traffic on the map ............................................................................. 44

Looking at traffic on your route ........................................................................... 45

Traffic incidents ............................................................................................. 46

Approaching a traffic jam warning ....................................................................... 47

Avoiding a traffic jam on your route ..................................................................... 47

Advanced Lane Guidance ................................................................................... 48

Time-dependent speed limits.............................................................................. 48

Using Quick Search .............................................................................................. 50

About search .................................................................................................. 50

Planning a route to a POI using search ................................................................... 50

Planning a route to a POI using online search .......................................................... 52

Entering search terms ....................................................................................... 54

Working with search results ................................................................................ 56

About ZIP codes .............................................................................................. 58

About mapcodes ............................................................................................. 58

List of POI type icons ........................................................................................ 58

Planning a route ................................................................................................. 64

Planning a route to an address using search ............................................................ 64

Planning a route to a city center ......................................................................... 66

Planning a route to a POI using search ................................................................... 68

Planning a route to a POI using online search .......................................................... 71

Planning a route using the internet browser ............................................................ 73

Planning a route using the map ........................................................................... 75

Planning a route using My Places.......................................................................... 77

Planning a route using coordinates ....................................................................... 78

Planning a route using a mapcode ........................................................................ 80

Finding an alternative route ............................................................................... 81

Planning a route in advance ............................................................................... 82

Finding a parking lot ........................................................................................ 84

Finding a gas station ........................................................................................ 86

Changing your route ............................................................................................. 90

The Current Route menu ................................................................................... 90

Avoiding a blocked road .................................................................................... 93

Avoiding part of a route .................................................................................... 93

Types of route ................................................................................................ 94

Route features................................................................................................ 95

Avoiding a route feature on your route .................................................................. 95

Adding a stop to your route from the current route menu ........................................... 95

Adding a stop to your route using the map .............................................................. 95

Deleting a stop from your route ........................................................................... 96

Skipping the next stop on your route .................................................................... 96

Reordering stops on a route................................................................................ 96

My Routes ......................................................................................................... 97

About My Routes ............................................................................................. 97

Saving a route ................................................................................................ 97

Navigating using a saved route ............................................................................ 98

Navigating to a stop on a saved route .................................................................... 99

Adding a stop to a saved route using the map ......................................................... 101

Deleting a route or a track from My Routes ............................................................ 102

Recording and sharing routes ............................................................................. 103

Voice control (Speak & Go) ................................................................................... 105

About voice control ......................................................................................... 105

Starting voice control ...................................................................................... 105

Making your own wake-up phrase ........................................................................ 105

The voice control screen .................................................................................. 106

Some tips for using voice control ........................................................................ 107

What you can use voice control for ...................................................................... 107

Saying commands in different ways ..................................................................... 108

Entering an address using voice control ................................................................ 108

Going home using voice control .......................................................................... 109

Going to a POI using voice control ....................................................................... 109

Changing a setting using voice control .................................................................. 110

Safety Cameras .................................................................................................. 111

About safety cameras ...................................................................................... 111

Safety camera warnings ................................................................................... 111

Changing the way you are warned ....................................................................... 113

Reporting a new safety camera .......................................................................... 113

Confirm or remove a speed trap ......................................................................... 114

Updating locations for cameras and hazards .......................................................... 114

My Places ......................................................................................................... 115

About My Places ............................................................................................. 115

Setting your home and work locations .................................................................. 115

Changing your home location ............................................................................. 116

Adding a location from My Places ........................................................................ 117

Add a location to My Places from the map ............................................................. 117

Adding a location to My Places using search ........................................................... 118

Adding a location to My Places by marking ............................................................ 118

Deleting a recent destination from My Places ......................................................... 118

Deleting a location from My Places ...................................................................... 119

Importing a POI list ......................................................................................... 119

Settings ........................................................................................................... 120

Appearance .................................................................................................. 120

Voices ......................................................................................................... 123

Voice Control ................................................................................................ 124

Maps ........................................................................................................... 124

Route Planning .............................................................................................. 125

Sounds and Warnings ....................................................................................... 125

Units ........................................................................................................... 127

Language ..................................................................................................... 128

Getting Help ..................................................................................................... 129

Help ........................................................................................................... 129

External Camera App 130

Using the External Camera app .............................................................................. 131

Camera settings ................................................................................................. 132

Using the vehicle width guide lines ......................................................................... 133

TomTom Music App 135

Using the TomTom Music app ................................................................................. 136

Addendum and Copyright 138

Addendum ...................................................................... Error! Bookmark not defined.

Welcome to the TomTom BRIDGE

This Reference Guide explains how to use the TomTom BRIDGE and the installed TomTom apps. The Reference Guide has the following sections:

 The TomTom BRIDGE  The TomTom Navigation app  The TomTom Camera app  The TomTom Music app

Important: For other settings and operation instructions for the TomTom BRIDGE, and for instructions about other apps installed on the TomTom BRIDGE, please refer to the applicable User Documentation.

The TomTom BRIDGE

The TomTom BRIDGE starts when it is in its dock and the dock has power. When the TomTom BRIDGE is not in its dock, you can also press the On/Off button until the device starts.

The TomTom BRIDGE home screen is shown.

Note: The TomTom navigation app home screen shown below is an example. The home screen on the TomTom navigation app might look different and have different apps installed.

1. An app running as a widget.

For example the TomTom Navigation app and the External camera app can run in a widget on the home screen. Select the widget to open the app.

Note: A widget is an app that runs in its own panel. You can select a widget to open the full app.

Tip: You can move and resize apps and widgets.

2. The Music app running as a widget.

3. Back button.

Select this button to return to the previous screen that was open.

4. Home button.

Select this button to return to the device home screen.

5. System bar.

You can add shortcuts for your favorite apps to this bar.

6. Software update button.

Starting the TomTom BRIDGE

Shortcut button to open the Software update app. This app lets you update the TomTom navigation app to the latest software version.

7. Status bar.

Touch this area to show app notifications and the device status.

You use gestures to control your device. This Reference Guide explains which gestures to use throughout the guide but here is a complete

list of all the gestures you can use.

Double tap

Touch one finger on the screen twice in rapid succession. Example of when to use this: Zooming in.

Drag

Put one finger on the screen and move it across the screen. Example of when to use this: Scrolling a screen.

Flick

Flick the tip of a single finger across the screen. Example of when to use this: Scrolling a big distance on the screen.

Press and hold

Put one finger on the screen for more than one half second. Example of when to use this: Selecting a location on the map.

Pinch to zoom

Touch the screen with your thumb and a finger. Move them apart to zoom in or move them together to zoom out.

Example of when to use this: Zooming in and out on the screen.

Using gestures

Tap or select

Tap a single finger on the screen. Example of when to use this: Selecting an item in a menu, or opening an

item.

The TomTom BRIDGE is an Android-based device that has different apps installed on it. Some of the apps will be standard Android apps, for example a browser, a clock and a photo-gallery. Specialized apps could be added by the device owner, and TomTom has also added apps.

Note: The TomTom BRIDGE might be secured to prevent you making changes.

You can find other apps on the device by scrolling to the right. To see all the apps on the device, select All apps.

You can also add up to two app quick-launch buttons to the device's System bar for apps you want to use often.

Privacy notices for apps Each installed app has its own privacy notice. Open the Android Settings app then select About your

TomTom device. Select Legal information, then select Your information. Select an app from the

list to read about the function of the app, how the app uses your information, and how your personal data is managed.

Apps on the TomTom BRIDGE

About connecting TomTom BRIDGE

TomTom BRIDGE connects to the internet using your smartphone so you can use the installed apps and access TomTom services. Using your smartphone to connect means that data is sent and received by your smartphone using your cellular service provider.

Your smartphone needs to be compatible with TomTom BRIDGE, and you must have a data plan from a cellular service provider. Go to tomtom.com/connect for more information.

Important: You might have additional costs when you use your smartphone to connect TomTom BRIDGE, especially if you are outside the area covered by your data plan. Check with your cellular service provider for more information.

TomTom BRIDGE can be connected in one of the following ways:

 Connection using Bluetooth tethering or Bluetooth hotspot.  Connection using Portable Wi-Fi hotspot.

Note: To update the TomTom BRIDGE software, use a normal Wi-Fi connection.

Depending on your phone's Operating System, these connection methods may have one of the following names:

 Personal Hotspot  Tethering and portable hotspot

The hotspot functions are likely already in your phone's Operating System, or you can download an app to create one. Please check the user guide for your phone if you are having trouble finding the settings.

Note: Some cellular service providers do not allow users to use a hotspot or Personal Area Network (PAN). If your phone does not have the PAN function, you should contact your service provider for more information.

For more help, go to tomtom.com/connect.

Connect using Bluetooth

To connect your TomTom BRIDGE to your smartphone using Bluetooth, do the following:

8. Turn on Bluetooth tethering or personal hotspot on your phone, and make sure your phone is

discoverable.

9. Press the Home button on your TomTom BRIDGE.

10. Select the Settings app.

11. Turn on Bluetooth.

12. Select Bluetooth, then select SEARCH FOR DEVICES.

The TomTom BRIDGE searches for your phone and shows it as an available device.

Tip: If your TomTom BRIDGE cannot find your phone, make sure your phone is still 'discoverable' or 'visible' for other Bluetooth devices.

13. Select your phone from the list of available devices.

Connecting the TomTom BRIDGE

14. After you have connected your TomTom BRIDGE to your smartphone, you need to check the box

in the Bluetooth profile on the TomTom BRIDGE to enable internet access as shown below.

Your TomTom BRIDGE connects to TomTom services using your phone's internet connection. TomTom services are now active.

The Bluetooth symbol in the Android Status Bar shows that Bluetooth is switched on.

Connect using Portable Wi-Fi Hotspot

Important: You might have additional costs when you use your smartphone to connect TomTom

BRIDGE, especially if you are outside the area covered by your data plan. Check with your cellular service provider for more information.

Note: To update the TomTom BRIDGE software, use a normal Wi-Fi connection.

To connect TomTom BRIDGE to your smartphone using a Portable Wi-Fi Hotspot, do the following:

1. Switch on Portable Wi-Fi Hotspot on your phone. Make a note of the password for the Wi-Fi

connection.

2. Press the Home button on TomTom BRIDGE.

3. Select All apps.

4. Select the Settings app.

5. Turn on Wi-Fi.

6. Select Wi-Fi, then select your phone from the list of Wi-Fi sources.

7. Enter the password for the Wi-Fi connection, then select Connect.

TomTom BRIDGE connects to TomTom services using your phone's internet connection.

Note: Using a Portable Wi-Fi connection can drain your phone's battery quicker.

TomTom services are now active.

Reconnecting your smartphone

You do not need to do anything to reconnect your TomTom BRIDGE to your phone.

Your TomTom BRIDGE will remember your phone and will find it automatically when you have Bluetooth tethering or Portable Wi-Fi hotspot switched on and you are in range of your device. If you have a valid TomTom services subscription, the service starts automatically.

On the TomTom BRIDGE Status bar, check that the TomTom BRIDGE is connected to the internet. If you want to connect using another phone, you must connect using Bluetooth or connect using

Portable Wi-Fi hotspot for that phone.

Tip: If reconnecting automatically to your smartphone using Bluetooth does not work, you can manually reconnect as described in Connect using Bluetooth.

Unable to get a connection

If your TomTom BRIDGE cannot connect to your phone, or you have no internet connection, check the following:

 Your phone is shown on your TomTom BRIDGE.  Your phone's Bluetooth tethering or Portable Wi-Fi hotspot is switched on.  Your data plan with your cellular service provider is active, and you can access the internet on

your phone.

The TomTom BRIDGE uses the Android operating system. TomTom and the device owner have changed the operating system in the following ways:

 Certain Android features have been disabled, either by TomTom or by the device owner. This

makes the device safer and easier to use while driving.

 Some new features and apps have been added, both by TomTom and by the device owner.

These additions customize the device, making it relevant for the functions it will be used for.

The features added by TomTom are as follows:

Sleep settings

You can choose when your TomTom BRIDGE goes to sleep if no apps are running or when it is removed from its dock.

Open Display in the Android Settings app to see the following settings:  Sleep

Sets the delay time before your TomTom navigation app goes to sleep if no apps are running.

 Stay awake when docked

Keeps your TomTom navigation app awake while it is docked and there is power.

 Sleep automatically when disconnecting from power

Puts your TomTom navigation app to sleep when power is removed either from the dock or directly from the TomTom navigation app.

Memory card slot

The TomTom BRIDGE has a memory card slot that is located on the bottom of the device. You can use a memory card to access your personal files, for example photos or music files.

Transferring files to your device

You can transfer personal files, for example POI lists, photos or music files, to the TomTom BRIDGE internal memory. This allows you to use apps on the device to view POIs, photos or play music.

You can also transfer files from the TomTom navigation app internal memory to your computer.

Note: Not all file types can be opened by the device. Note: You can transfer files from a computer running one of the following operating systems:

- Windows 7 or higher

- Apple OS X 10.5 or higher

- Some Linux distributions of version 14.04 or higher.

To transfer files, follow these steps:

1. Connect the TomTom navigation app to your computer using the USB cable supplied with your

TomTom navigation app, then switch your TomTom navigation app on.

Note: Use ONLY the USB cable supplied with your device. Other USB cables may not work.

Features on the TomTom BRIDGE

Note: You cannot use the mount to connect your device to your computer. Note: You should plug the USB cable directly into a USB port on your computer and not into a

USB hub or USB port on a keyboard or monitor.

2. On your computer, open a file manager program.

Your TomTom navigation app appears in your computer's file system as TomTom Bridge.

3. Open the TomTom navigation app Internal Storage folder.

4. Copy files from your computer to a folder on your TomTom navigation app, or from your

TomTom navigation app to your computer.

Tip: To keep the device organized, copy the files to a folder with a relevant name. For example, copy your music files to the Music folder.

5. Disconnect the TomTom navigation app from your computer.

Tip: You can remove all the files you copied to the TomTom navigation app by clearing your

personal data.

System bar

The System bar is at the bottom of the screen and it contains quick-launch buttons, for example the Back and Home buttons. You can add up to two extra buttons to this bar to quickly start apps that you often use.

Tip: Some apps have a full screen setting that hides the system bar when the app is open.

To add a quick-launch button for an app, do the following:

1. Select the Home button.

2. Select the Settings app.

3. In Settings, select System bar.

4. Under Quick Launch Buttons, select Assign app.

5. Select an app from the list to assign to a quick-launch button.

6. Select the Home button.

Your new quick-launch button is added to the System bar.

To remove a quick-launch button, do the following:

1. Select the Home button.

2. Select the Settings app.

3. In Settings, select System bar.

4. Under Quick Launch Buttons, select and hold the button you want to remove.

5. In the pop-up box that appears, select OK to remove the quick-launch button.

6. Select the Home button.

The quick-launch button is removed from the System bar.

Updating the software

The TomTom BRIDGE owner will periodically release new software updates.

Tip: When a software update is available, a notification appears in the Notification bar. Select the bottom right corner of the device screen to open the Notification area.

When you have access to a Wi-Fi connection, you can update the software using the Software update app. Large updates are downloaded in the background when the TomTom navigation app is connected to Wi-Fi. When the Wi-Fi connection is lost, downloading will pause. When the download is complete you will be prompted to install the update.

Note: Software updates can only be downloaded using a Wi-Fi connection.

To update the software on the device, do the following:

1. Select the Home button.

2. Select the Settings app.

3. In Wireless and networks, select Wi-Fi.

Select and connect to a Wi-Fi network.

4. Select the Home button.

5. Select the Software update app.

Your device automatically downloads and installs the software update.

Note: You may have to restart the device to install the software update.

Moving and resizing apps and widgets

You can move apps and widgets to different places on the display. For example, if you often use the

External Camera app, you can move it to the home screen. You can change the size of an app

button or a widget to make it easier to use or see.

Note: The TomTom BRIDGE might be secured to prevent you making changes.

Moving apps and widgets

To move an app or widget, do the following:

1. Select and hold the app or widget that you want to move.

The app or widget changes color.

Tip: If you want to move an app or widget to the home screen, you might first have to move an app or widget from the home screen to make space for it.

2. Drag the app or widget to the edge of the screen.

A white line appears at the edge of the screen to indicate that the adjacent screen will open.

3. Drag the app or widget farther and drop it in the empty space.

An available space is highlighted a different color when the app or widget is dragged over it.

Tip: You can only move an app or widget to an empty space.

Resizing apps and widgets

To resize an app or widget, do the following:

Note: Some widgets and apps have a size limit in one or more directions.

1. Select and hold the app or widget that you want to resize for 2 seconds, then release.

The app or widget changes color and you see a trash can icon and four resize spots.

2. Select and drag a resize spot to make the app or widget larger or smaller.

Tip: The shape you choose for the app or widget depends on the information you want to see. For example, you might choose to make the External Camera widget the size of half the display to make the camera image easier to see.

Deleting an app or widget

To delete an app or widget from the home or apps screen, do the following:

1. Select and hold the app or widget that you want to delete for 2 seconds, then release.

The app or widget changes color and you see a trash can icon and four resize spots.

2. Select the trash can icon.

The app or widget is removed from the home or app screen and placed in the All apps location.

Tip: If you deleted the app or widget by mistake, open All apps and move it back again.

Sending information to TomTom

When you first start the TomTom BRIDGE or you have reset the TomTom BRIDGE, you are informed about how TomTom uses your information. This information includes your location, how you use the services and information you enter. We learn how you use the device so we can continually improve.

Go to the Your information app in the All apps menu to read about how TomTom uses your information.

If you think that your information is not being used for the purpose for which you have provided it to TomTom, contact us at tomtom.com/support.

You can find current and more detailed information at tomtom.com/privacy.

Clearing personal data

The TomTom BRIDGE stores your personal data as you use the apps installed on the device. All photos and music you have transferred to the device is also personal data.

If you have finished using the device it is a good idea to clear your personal data before you pass the device back to the owner.

To clear your personal data, do the following steps:

Note: Software updates can only be downloaded using a Wi-Fi connection.

1. If you are using a personal memory card, remove the memory card from its slot.

2. Select the Settings app.

3. Select Backup & reset.

4. Select Clear personal data.

5. Select Clear, then select Clear again.

Your device automatically switches off and clears your personal data.

Taking a screenshot

If you need to make a picture of the screen of the TomTom BRIDGE, for example to show the owner an error that has occurred, do the following:

1. Press and hold the On/Off button until the pop-up menu is shown.

2. Select Take a screenshot from the pop-up menu.

A screenshot is taken of the screen behind the pop-up menu.

Tip: Open the Gallery app on your TomTom navigation app to view the screenshots you have made.

3. Connect your TomTom navigation app to your computer and transfer the screenshots.

The screenshots are in the pictures folder in the TomTom navigation app Internal Storage.

Screen locking

When using your TomTom BRIDGE, certain apps or features may be locked. The features that are locked and the reasons for doing so are at the discretion of the device owner. Some typical reasons for a device owner to use screen locking are as follows:

 To prevent a customer from speeding.  To increase safety by minimizing driver distraction.  To prevent device theft.

When you select a locked item in the home screen, you see a message. The message may say Screen locked for safety or something else because it can be customized by the device owner.

Even when an item is locked, you can still do the following:

 Use home, back and volume buttons.  Select the screen lock message to make it disappear.  Respond to, for example, a low battery message.

The language used on the TomTom BRIDGE is also used in the apps installed on the device. To change the device language, do the following:

1. Select the Home button.

2. Select the Settings app.

3. Select Language & input, then select Language.

4. Select the language you want, then select OK.

Your device language changes.

Language

Use only the supplied dock and vehicle mount to hold the TomTom BRIDGE when you are using it in your vehicle.

Installing in your vehicle

The battery in the TomTom BRIDGE charges when you install the device in its dock and the dock is powered.

You are warned when the battery level is low or critical. You lose your connection to the internet when the battery level is low or critical. When the battery is empty, the device goes into sleep mode.

Note: Charging your TomTom BRIDGE using your computer is not recommended. The voltage output of computer USB ports varies by manufacturer.

Charging the TomTom BRIDGE

In rare cases, the TomTom BRIDGE may not start correctly or may stop responding. First, check that the battery is charged. To charge the battery, connect your device to power or

install it in the dock. It can take up to 3 hours to fully charge the battery. If this does not solve the problem, you can reset the device. To do this, press and hold the On/Off

button until your device begins to restart.

The TomTom BRIDGE is not starting

It is important to take care of your device:  Do not open the casing of your device under any circumstances. Doing so may be dangerous and

will void the warranty.

 Wipe or dry the screen of your device using a soft cloth. Do not use any liquid cleaners.

Caring for your TomTom navigation app

When you have access to a Wi-Fi connection, you can open the Reference Guide for your TomTom BRIDGE on the device. The language of the Reference Guide is the same as the language you selected in your device settings.

The Online Reference Guide button is on the Home screen or the All apps screen. If a Reference Guide is not available in your device language, the English-language Reference Guide

is opened. You can change the device language in Language & input in the TomTom BRIDGE Settings app. You can also download the Reference Guide in all available languages from tomtom.com/support.

Online Reference Guide

You can get further help by going to tomtom.com/support. For warranty and privacy information, go to tomtom.com/legal.

Getting help

TomTom Navigation App

This Section explains how you use the TomTom Navigation app.

Important: For other TomTom BRIDGE settings and operation instructions, and for instructions about other apps installed on TomTom BRIDGE, please refer to the applicable User Documentation.

The navigation app is installed on the device, either as an app that you have to open, or as a software widget on the Home screen. The widget has some limited functionality, for example you can see your route and route instructions on the widget, but you can't plan a route.

Select the widget to open the full navigation app to use all the navigation features. The Get going chapter is a great place to start. You'll learn all about starting up and setting up the

device, and using the navigation app to plan your first route. You'll see a quick introduction to TomTom services, which includes Traffic & Safety Cameras. To help avoid traffic delays and get you to your destination quicker, you can even use TomTom services on the routes you drive every day.

For information about what you see in the navigation app, go to:

 TomTom Services  What's on the screen  Using gestures  Main menu

Welcome to navigation with TomTom

TomTom services give you real-time information about traffic and speed cameras on your route. To help avoid traffic delays and get you to your destination quicker, you can even use TomTom services on the routes you drive every day.

To get TomTom Services on TomTom BRIDGE, connect TomTom BRIDGE to a network.

Note: TomTom services are not available in all countries or regions, and not all services are available in all countries or regions. For more information on available services in each region, go to tomtom.com/services.

About TomTom services

+ 116 hidden pages
