Toastmaster 999202U User Manual

READ AND SAVE THESE INSTRUCTIONS

WA R N I N G : A risk of fire and electrical shock exists in all electrical appliances
and may cause personal injury or death. Please fo l l ow all safety instructions.

Food Processor Accessor y

Use and Care Guide Model 999202U

Please refer to the fo l l owing info rmation in addition to the 1770U H e av y
Duty Stand Mixer Use and Care Guide for complete instru c t i o n s.

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be fo l l owe d
to reduce the risk of fire, electric shock and injury to persons, including the fo l l ow i n g :

• Keep hands and utensils away from moving blades or disks while processing
food. A scraper may be used but must be used only when the food processor is
not running.

• Blades are sharp. Handle carefully.

• Never place cutting blade or disk on base without first putting bowl properly in
place.

• Be certain cover is securely locked in place before operating appliance.

• Never feed food by hand. Always use food pusher.

• Do not attempt to defeat the cover interlock mechanism.

• Avoid contacting moving parts.

SAVE THESE INSTRUCTIONS

THIS PRODUCT IS FOR HOUSEHOLD USE ONLY

THIS FOOD PROCESSOR ACCESSORY IS DESIGNED
FOR USE ONLY WITH THE TOASTMASTER MODEL
1770U STAND MIXER.

Thank You for purchasing this Food Processor Accessory for the Toastmaster Heavy
Duty Stand Mixer.

Featuring superior technology and craftsmanship, the Global Design Collection is an
exceptional line of kitchen appliances. The state-of-the-art design of the appliances and
accessories is matched only by their excellent performance. Enjoy!

The food processor accessory not only bl e n d s, chops and purees, it also slices and
shreds fo o d s. In addition, it will mix batters and doughs. Your individual taste and
intended use largely affects the time required to process the fo o d s.

Figure 1

a

b
c

d

e

Figure 1 - Stand Mixer in position #5 with Food

Processor Accessory on drive
mechanism “c”

Figure 2 - Bowl / Handle Locking Position

a. cover tab
b. bowl tab
c. handle slot

Figure 3 - Inserting Chopping Blade

a. food pusher / 1 cup measuring cup
b. cover with feed tube
c. chopping blade with removable covers
d. bowl
e. handle

Figure 4 - Inserting Disk

a. slicing disk
b. disk holder
c. bowl
d. handle

Figure 5 - Maximum Fill Line

Figure 3

2

Figure 2

a b

Figure 5

c

a
b

c

d

Figure 4

CHOPPING BLADE AND DISKS

CHOPPING BLADE
Can be used to chop meat, fruits, vegetables, bread, crackers,
and to mix ingredients.

GRATING DISK
Can be used for fru i t s, ve g e t a bl e s, chocolate, cheese.
Reversible to FINE or COARSE.

SLICING DISK
Can be used for fruits, vegetables, chocolate and cheese.
Reversible to FINE or COARSE.

MINCING DISK
Can be used for hard cheeses, chocolate, garlic and nuts.

Be sure to fill out warranty service information.

USING YOUR FOOD PROCESSOR

1. Before using, clean all parts, see CARE AND CLEANING.

2. Place stand mixer on a dry level surface and turn swivel arm to position #5,
(see figure 1). Make sure the speed control dial is in the Off position.

3. Place bowl onto the handle and turn counter clockwise until the bowl tab locks
below the handle slot, (see figure 2).

4. If using the chopping blade, remove covers, insert into bowl, and place food in
bowl, (see figure 3).Or, insert disk holder and disk, (see figure 4).

5. Place the cover onto the bowl so that the arrows on the cover and handle line
up.Turn the cover counter clockwise until the tab on the cover is inserted into
the slot of the handle, (see figure 2). Insert the food pusher into the feed tube.

6. R e m ove cover from dri ve mechanism “ c ” . Place the food processor accessory
onto drive mechanism “c” lining up the arrows on the base of the handle and
the stand mixer. Turn the food processor counter clockwise until securely in
place (1/4 of a turn), (see figure 1).

NOTE:If the food processor drive will not connect to the stand mixer, the cover on
the food processor is not positioned correctly. Repeat steps 5 and 6 above.

7. If using a disk to process food, remove the food pusher and fill the feed tube.

3
