TimEM
Model T433
FM/AM Dual Alarm
Caleiscfar Clock Ra€lso with
imiGLO® mght'llght
CAUTION
RISK OF ELECTRIC SHOCK
A
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE COVER
(OR BACK). NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
WARNING: TO REDUCE THE RISK OF FIRE
OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
DO NOT OPEN.
This device complies with Part 15 of the Federal
Communications Commission Rules. Operation is
subject to the condition that this device does not
cause harmful interference.
A
This symbol is intended to alert the user of the
presence of uninsulated dangerous voltage
within the product's enclosure that may be
A
A
The symbols above are located on the bottom of the unit.
of sufficient magnitude to constitute a risk of
electric shock.
This symbol is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the product.
A Consumer Guide to Product Safety
This unit has been designed and manufactured to assure your personai
safety, improper use can result in potential electricai shock orfire hazards.
Please read ali safety and operating instructions carefuliy before instaliation
and use. Keep these instructions handy forfuture reference. Take special
note, and adhere to all warnings on the unit and in the instruction and
service manuai.
1. Water and Moisture - The unit should not be used near water. For
exampie, near a bathtub, washbowl, kitchen sink, iaundry tub,
swimming pool, or in a wet basement.
2. Ventilation -The unit shouid be situated so that its location or
i position does not interfere with its proper ventilation. For example, it
should not be situated on a bed, sofa, rug, or similar surface that may
block ventilation openings, or placed in a built-in installation, such as
I a bookcase or cabinet that may impede the flow of air through the
I ventilation openings,
3. Heat - The unit should be situated away from heat sources such as
I radiators, heat registers, stoves, or other appliances (including
I amplifiers) that produce heat.
[ 4. Power Sources - The unit should be bonnected to a power supply
! only of the type described in the operating instructions or as marked
i on the appliance.
I 5. Grounding or Polarization - This product is equipped with a
I polarized alternating current line plug (a plug having one blade wider
I than the other). This plug will fit into the power outlet only one way.
j This is a safety feature. If you are unable to insert the plug fully into
|! the outlet, try reversing the plug. If the plug should still fail to fit,
I
contact your electrician to replace your obsolete outlet. Do not defeat
f the safety purpose of the polarized plug.
6. Power-Cord Protection - Power supply cords should be routed
so that they are not likely to be walked on or pinched by items placed
upon or against them. Pay particular attention to cords at plugs,
convenience receptacles and the point at which they exit from the
unit.
7. Cleaning - The unit should be cleaned only as recommended by the
manufacturer.
Nonuse Periods -The power cord of the unit should be unplugged
8.
from the outlet when it is to be left unused for a long period of time.
Object and Liquid Entry - Care should be taken so that objects do
9.
not fall and liquids are not spilled into the enclosure through openings.
10. Damage Requiring Service - The unit should be serviced by
qualified service personnel when:
A, The power-supply cord or plug has been damaged.
B. Objects have fallen into or liquid has been spilled into the enclosure.
C The unit has been exposed to rain.
D. The unit has been dropped or the enclosure damaged.
E. The unit does not appear to operate normally or exhibits
a marked change in performance.
11. Servicing - The user should not attempt to service the unit beyond
that described in the user’s operating instructions. All other servicing
should be referred to qualified service personnel.
12. If you have any questions, call SDI Technologies lnc.,Timex Audio
Products Division Customer Service, 1-800-888-4491.
13. Antenna - Do not connect to an external antenna.
Installation and Maintenance
1. Place the unit on a level surface away from sources of
direct sunlight or excessive heat.
Note: Protect your furniture when placing your unit
on a natural oil or lacquered finish. A cloth or other
protective material should be placed between the
unit and the furniture.
2. Install 2 "AA" batteries. Refer to "Battery Back-up
System", page 5.
3. Fully extend the FM wire antenna.
Note: Do not connect the FM wire antenna to an
external antenna.
4. Plug AC line cord into wall outlet.
Note: If the contents ofthe LCD display is not complete
when power is applied for the first time, unplug the unit
from the wall outlet and remove the batteries, if already
installed. Reinstall the batteries and reconnect the unit.
5. Clean your unit with a soft cloth moistened oniy with
mild soap and water. Stronger cleaning agents can mar
the surface of the case.
Indaglo'^' night-light Operation
Your unit features an Indiglo® night-light to assist you in
reading the time in a darkened room.
1. Brightness Control - Adjust brightness of clock display,
as desired, when room is darkened.
Power Failure Indication
When AC power is interrupted, and optional batteries
are not installed, the time, alarm and calendar settings will
change. After AC power is restored the LCD display will
return to its initial indications (i.e. 12:00 for alarm time, 1 1 for month and day etc.) to indicate that power was
interrupted and you must reset the time, alarm and calendar
settings. To prevent this see “Battery Back-up System.”
Battery Back-Up System
This clock radio is equipped with a back up system that is
powered by two customer-installed "AA" alkaline batteries
(not incjuded). The backup circuit will not operate unless
batteries are installed.
When normal household current is interrupted, or the AC
line cord is unplugged, the batteries power the clock to
keep track of time, alarm and calendar settings. Should
wake-up time occur during the power interruption, the
alarm will sound for 2 minutes, if remaining battery power
is adequate. If Snooze is pressed during the 2-minute
alarm time period, the alarm will go off and come on again
in approximately 9 minutes. Normal operation will resume
after AC power is restored so you will not have to reset
time, alarm or calendar settings.
Note: The display will remain lit' during battery back-up
when batteries are fresh. The display will gradually fade as
the batteries weaken.
Install batteries as follows:
1. Open the battery compartment door located on the
bottom of the radio.
Features
2. Insert 2 "AA" alkaline batteries making sure the polarity
is correct as shown in the compartment.
Note: Alkaline batteries are recommended for longer life.
3. Close the compartment door.
Important: Remove batteries when storing the clock
radio. The batteries will be drained If left connected when
the unit is unplugged, and worn out batteries may leak
chemicals which can badly damage the clock radio.
Dispose of batteries in the proper manner, according to
your state and local regulations.
Brightness Control
Snooze Button
Alarm Select Switch
Mode Switch
> (Slow Forward) Button
< (Slow Reverse) Date - Button
« (Fast Reverse) Date + Button
» (Fast Forward) Month Button
Tuning Control
Volume Control
Time Button
Alarm Button
Reset Button
Sleep Button
Calendar Button
LCD Display
LED Dial Pointer
Setting Clock and Alarm Time
»[Fast Forward) Button
> (Slow Forward) Button
< (Slow Reverse) Button
Setting Clock Time
1. Press the Time and » buttons to rapidly advance the
time forward or the Time and « buttons to rapidly
change the time backward until'the approximate correct
time is displayed. PM is indicated to the right of the time
on the display.
2. Press the Time and > or < buttons until the correct time
is displayed.
Setting Alarm Time
1. Set the Alarm selector switch to ALM1 or ALM2 as
desired.
7
Setting Calendar
.Time Button
-Alarm Button
2. Press the Alarm and » buttons to rapidly advance the
time forward or the Alarm and « buttons to rapidiy
change the time backward until the approximate desired
alarm time is displayed. PM is indicated to the right of
the alarm time on the display.
3. Press the Alarm and > or < buttons until the desired
alarm time is displayed.
4. Repeat steps 1-3 to set the second alarm time.
Note:
• Alarm time cannot be set if the selector switch is in the
Alarm 1+2 position.
Selecting Alarm Time(s)
Wake Switch
Calendar Button
Setting the Calendar
1. Press the Calendar button, then the Month button until
the correct month digit is displayed.
2. Press the Calendar button, then the Date + or Date Buttons until the correct date is displayed.
To Select Alarm Time(s)
You can select Alarm 1, Alarm 2 or Alarm 1 +2 by setting the
Alarm switch to ALM 1 (Alarm 1), ALM 2 (Alarm 2) or ALM
1+2 (Alarm 1 and 2). The selected alarm is indicated by
ALARM 1 or ALARM 2 above the alarm time. When Alarm
1 +2 is selected, the alarm time and alarm indicator alternate.
8
Notes:
• Each alarm has a different tone to identify which alarm
is sounding.
• At the selected wake up time an electronic alarm tone
will sound. It will increase in frequency to wake you up
gradually. This Gentle Wake System does not operate
with the radio alarm.
Operating the Radio
Note: Fully extend the FM wire antenna for best FM
reception. Rotate the radio, as required, for best AM
reception.
1. Mode switch - Set to ON. The Dial Pointer lights.
2. Band switch - Set to AM or FM as desired.
3. Tuning control - Rotate to select desired station on
appropriate diai scale. Tune station for maximum
clarity.
4. Volume control - Adjust for desired volume level.
5. To turn off the radio, set the Mode switch to OFF or
ALARM.
Waking to Radio Alarm
Volume Control
Mode Switch
1. Set alarm time as desired. (See Setting Alarm Time.)
2. Perform steps 1 through 4 of Operating the Radio.
3. Wake switch - Set to RADIO.
4. Mode switch - Set to ALARM. A music note { )
will appear on the display indicating the radio alarm
function is on. The radio is now set to come on
automatically at the alarm time selected.
Note: The radio will play for approximately 1 hour and
turn off automatically. This cycle repeats every 24
hours unless the controls are changed. To play the
radio after the one-hour auto period, set the Mode
switch to ON. Remember to reset the Mode switch to
ALARM so the radio will come on automatically the next
day.
5. Alarm Reset button - Press to turn off the radio. The
radio will come on again the next day automatically at
the same time.
10
Waking to Buzzer Alarm
Mode Switch
1. Set alarm time as desired. (See Setting Alarm Time.)
2. Wake switch - Set to BU2ZER.
3. Mode switch - Set to ALARM. A bell ( -0 ) will appear
on the display indicating the buzzer alarm function is on.
The buzzer alarm is now set to come on automatically
at the alarm time selected.
Note: The buzzer alarm will sound for approximately 1
Snooze Operation
hourandthenturnoffautomatically. Thisoycie repeats
every 24 hours unless the controls are changed. To
play the radio after the buzzer alarm sounds, set the
Mode switch to ON. Remember to reset the Mode
switch to BUZZER so the buzzer alarm comes on the
next day.
4. To shut off the buzzer alarm, press the Alarm Reset
switch. The buzzer will come on the next day at the
same time.
11
Snooze button - Press after the radio or buzzer alarm
sounds. The radio or buzzer alarm will go off and will
come on again in approximately 9 minutes. You may
repeat this cycle several times during the 1 hour alarm
cycle.
12
Sleep Switch Operation
Mode Switch
Sleep Button
1. Mode switch - Set to ALARM if you wish the alarm to
sound the next morning. Set to OFF if you do not want
the alarm to sound,
2. To play the radio for up to 120 minutes:
Press the Sleep button. The display will indicate 120
minutes in the lower right corner and the SLEEP indicator
appears. Release to play 120 minutes.
13
Notes
To play less than 120 minutes:
Press and hold the Sleep button. The display will
"countdown" from 120 in 10-minute increments.
Release the Sleep button when the display indicates
the time you wish the radio to play before shutting off
automatically. The display will continuously indicate the
sleep time remaining.
3. Press the Snooze button to turn off the radio before the
sleep time has elapsed. The SLEEP indicator disappears.
14
Notes
15
Limited 90 Day Warranty
SDÌ Technologies Inc., Tmex Audio Products Division, warrants this
product to be free from defects in workmanship and material under normal
use and conditions for a period of 90 days from the date of original
purchase.
Should service be required by reason of any defect or malfunction, it is best
to first return this product and all parts there of, to the store where it was
originally purchased. If you need to send the product for service and it is
during the first 90 days of the warranty period, SDI Technologies Inc, will
repair, or at its discretion, replace this product with proof of purchase,
without charge (except for a $5.00 charge for handling, packing, return
UPS/postage and insurance). After 90 days the cost of labor is the
customer’s responsibility. The fee for service after the warranty period or
without proof of purchase is $10.00.
Before returning this product for service, replace the batteries (if applicable)
with fresh ones, because exhausted or defective batteries are the most
common cause of problems encountered.
If service is still required:
1. Remove the batteries, (if applicable) and pack the unit in
a well padded, heavy corrugated box.
2. Enclose a photocopy of your sales receipt, credit card statement, or
other proof of the date of purchase, if within the warranty period.
3. Also enclose a check or money order payable to the order of SDI
Technologies Inc., for the sum of $5.00 (or $10.00 after the warranty
period).
4, Send the unit prepaid to the Factory Service Center listed below.
Consumer Repair Department
SDI Technologies Inc.
Timex Audio Products Division
8889 Gateway West
El Paso, Texas 79925
Please Note: This warranty is valid only in the United States of America.
Any applicable implied warranties are also limited to 90 days, and SDÌ
Technologies Inc. will not be liable for consequential damages. (Some
states do not allow limitations on implied warranties or exclusions of
consequential damages, so that these restrictions may not apply to you).
This warranty gives you specific legal rights, and you may also have other
rights which vary from state to state.
For questions or comments regarding this or other
products, please call our toll free number 1 -800-888-4491.
TIMEX is a registered trademark of Timex Corporation in
the U.S. and other countries.
INDIGLO is a registered trademark of Indiglo Corporation
in the U.S, and other countries.
T433-000308-2
Printed in Hong Kong
Loading...
