Model T254
Jumbo Display
Alarm Clock Radio
88
94
100
104
108
AM
53
60
70
100
130
170
x10kHz
For additional information, online registration,
and exclusive special offers visit our website:
www.sdidirect.com
VOL
TUN
For questions or comments regarding this or other products,
please call our toll-free number 1-800-888-4491.
Para instruccionese en Espanol, llame al 1-800-888-4491.
A Consumer Guide to Product Safety
IMPORTANT SAFETY INSTRUCTIONS
When used in the directed manner, this unit has been designed and manufactured to ensure
your personal safety. However, improper use can result in potential electrical shock or fire
hazards. Please read all safety and operating instructions carefully before installation and
use, and keep these instructions handy for future reference. Take special note of all warnings
listed in these instructions and printed on the product.
1. Water and Moisture — The unit should be kept dry and away from water or other
liquids. If liquid is spilled on the unit, or if the unit should fall or be accidentally placed
in or on a wet or damp area, immediately unplug the unit.
2. Ventilation — The unit should be set up in an area and position that does not interfere
with its proper ventilation. Check to see where the ventilation opening is on the product.
Do not set up the unit on a bed, sofa, rug, or similar surface that may block the opening.
Do not keep the unit in a tight-fitting installation, such as a bookcase or cabinet, which
impedes the flow of air through the ventilation openings.
3. Heat — The unit should be situated away from heat sources such as radiators, space
heaters, stoves, or other appliances (including amplifiers) that produce or emit heat.
4. Power Sources — The unit should be connected to a power supply only of the type
described in the operating instructions, or as marked on the appliance.
5. Grounding or Polarization — This unit is equipped with a two-pronged, polarized
alternating-current line plug (a plug having one blade wider than the other). This plug
only fits into your power outlet in one direction. This is a safety feature. If you are having
difficulty inserting the plug fully into your outlet, try reversing the plug blades; do not
force the plug into the outlet. If you are still having difficulty, contact your electrician to
replace your obsolete outlet.
6. Power-Supply Cord Protection — Power-supply cords should be routed so that
they are not likely to be walked on or pinched by items placed upon or against them,
paying particular attention to areas at the outlet and where they exit from the unit.
7. Overloading — Do not overload wall outlets, extension cords, or integral convenience
receptacles as this can result in a risk of fire or electric shock.
8. Cleaning — The unit should be cleaned only as recommended by the manufacturer.
See the Maintenance section of this manual for cleaning instructions.
9. Periods of Nonuse — If the unit is to be left unused for an extensive period of time,
such as longer than a month, the power cord should be unplugged from the outlet.
10. Object and Liquid Entry — Care should be taken so that objects do not fall
and/or liquids do not spill into any openings or vents located on the product.
12. Attachments — Do not use attachments not recommended by the product manufacturer.
13. Damage Requiring Service — The appliance should be serviced by qualified service
personnel when:
A. the power-supply cord or plug has been damaged.
B. objects have fallen and/or liquid has been spilled into openings or vents.
C. the unit has been exposed to rain.
D. the unit has been dropped or the enclosure damaged.
E. the unit exhibits a marked change in performance or does not operate normally.
14. Antenna — The user should not connect an external antenna to the unit.
15. Servicing — The user should not attempt to service the unit beyond methods described
in the operating instructions. Any servicing not covered in the instructions should be left
to qualified service personnel. Please also see the Warranty Information for more
information on product servicing. Please call 1-800-888-4491 if you have any questions.
This device complies with Part 15 of the Federal Communications
Commission Rules. Operation is subject to the condition that
the device does not cause harmful interference.
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
The lightning flash with arrowhead in an equilateral triangle is
intended to alert the user of the presence of uninsulated
“dangerous voltage” within the product’s enclosure that may
be of sufficient magnitude to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended
to alert the user of the presence of important operating and
maintenance (servicing) instructions in the literature
accompanying the appliance.
The symbols above are located at the bottom of the cabinet.
CAUTION: To prevent electric shock, match wide blade of plug to
wide slot. Fully insert.
CAUTION: To prevent electric shock, do not use this (Polarized)
plug with an extension cord receptacle, or other outlets unless
the blades can be fully inserted to prevent blade exposure.
ATTENTION: Pour prévenir les chocs électriques ne pas utiliser
cette fiche polarisée avec un prolongateur. Une prise de courant,
ou une autre sortie de courant sauf si les lames peuvent étre
insérées à fond sans en laisser aucune partie à decouvert.
This device complies with part 15 of the Federal Communications
Commission Rules. Operation is subject to the condition that this
device does not cause harmful interference.
Note: The manufacturer is not responsible for any radio or TV
interference cause by unauthorized modifications to this
equipment. Such modification could void the user’s
authority to operate the equipment.
Controls and Indicators
Mode Switch
Time Set/
Dimmer Switch
Alarm Indicator
Alarm Set/Reset Button
Minute Button
Snooze Button
88
AM
53
Sleep Button
Hour Button
Band Switch
Volume
Control
VOL
94
100
104
108
60
70
100
130
170
x10kHz
TUN
PM Indicator
Tuning
Control
Radio Dial Pointer
Battery Backup Installation
It is strongly recommended that a 9-Volt battery be installed into the unit,
as directed below, in order to activate this product’s Battery Backup feature.
In the event that the AC power cord is disconnected or a power failure or
other interruption occurs, the Battery Backup will maintain clock and alarm
settings for the life of the battery. During any interruptions the clock display
will be blank, but time and alarm settings will be saved and automatically
restored when AC power is again active.
To install the battery:
1. Open the battery compartment cover.
2. Install one 9-Volt battery (alkaline is
recommended for longer life), making
sure that the large terminal matches to
the large outlet.
After installing the battery and reading the Maintenance notes, plug the AC
power cord into an outlet, being sure to match the wide blade of the plug
to the wide slot of the outlet. Never force the plug into an outlet. When the
unit is connected to AC power for the first time, the display may blink until
the time is set.
Battery Compartment
Note: You should replace the battery every six months, or after any extended
power outage that could drain the battery power.
Maintenance
1. Place the unit on a level surface away from direct sunlight or sources
of excessive heat.
2. Protect your furniture when placing the unit on natural wood or wood
with a lacquered finish. A cloth or other protective material should be
placed between the unit and the furniture.
3. Clean the casing with a soft cloth moistened only with mild soap and
water. Stronger cleaning agents, such as thinner, benzine, or similar
materials are not recommended, as they may damage the surface of
the case.
4. If the unit is not to be used for a prolonged period, such as a month or
longer, remove the batteries to prevent possible corrosion. Should the
battery compartment become corroded or dirty, clean the compartment
thoroughly and replace all the batteries.
2
Setting Clock Time and Alarm Time
Setting Clock Time
1. Slide the Time Set/Dimmer Switch, located on the left-hand side
of the cabinet, to the Time Set option.
2. Press the Hour Button and Minute Button until the correct time is
displayed. Remember to set the correct AM or PM setting. A small dot
in the upper-left-hand corner of the display is the PM Indicator.
3. After the time has been set, slide the Time Set/Dimmer Switch to
either the Hi or Lo dimmer display option.
Setting Alarm Time
1. Press and hold the Alarm Set/Reset Button while pressing the Hour
Button until the desired alarm hour is displayed. Again, remember to
set the correct AM or PM setting.
2. Press and hold the Alarm Set/Reset Button while pressing the
Minute Button until the desired alarm time is displayed.
Operating the Alarm and Snooze Features
1. Set the alarm time as indicated in Setting Alarm Time.
2. The alarm can be set to either an electronic beep or a radio station. To
set the alarm to wake to the beep, set the Mode Switch to “Alarm.”
To set the alarm to wake to the radio, set the Mode Switch to “Radio.”
(See Listening to Radio for instructions on setting the radio station that
will play when the alarm sounds.) The Alarm Icon will appear in the
lower-left-hand corner of the clock display, indicating that the alarm has
been set and will play the selected sound at the time selected.
Note: The alarm will play until it is shut off, or for a maximum of two hours.
As long as the Mode Switch is set to “Radio” or “Alarm” the alarm
will sound at the wake time every 24 hours.
3. After the alarm sounds, press the Alarm Set/Reset Button to turn
off the alarm while automatically resetting it for the following day.
4. To turn off the alarm without automatically setting it for the following
day, set the Mode Switch to “Off.” Even if the Alarm Set/Reset
Button was pressed, setting the Alarm Mode Switch to “Off” will
turn off the alarm.
5. To use the snooze feature, press the Snooze Button. The alarm will
turn off for approximately nine minutes before sounding again. You may
repeat this process several times during the two-hour alarm cycle.
3
Listening to Radio
Note: Extend FM wire antenna fully for best FM reception. Rotate radio,
as required, for best AM reception.
1. Slide the Mode Switch on the left-hand side of the top of the unit
to “On” to turn on the radio.
2. Set the Band Switch to the desired band, AM or FM. Rotate the
Tuning Control thumbwheel to select a station. Adjust the Volume
Control thumbwheel as desired.
3. To turn off the radio, slide the Mode Switch back to “Off.”
4. If you have chosen to wake to the radio, the alarm will sound with the
station and volume that you have selected.
Sleeping to Radio
This unit features a radio sleep timer which can be programmed to play the
radio for a set amount of time (maximum 59 minutes) before automatically
turning off.
1. Press the Sleep Button in order to turn on the radio and start the
sleep timer. The timer will start at the maximum 59-minute setting.
2. Select the station and adjust the volume to the desired level (see the
Listening to Radio section).
3. To adjust the sleep timer, press and hold the Sleep Button. The display
will begin counting down from “59.” Release the Sleep Button when
the display reaches your desired sleep time. When the display reaches
“00” the radio will shut off automatically.
4. To stop the radio at any time before the timer reaches “00,” press the
Snooze Button. Changing the Mode Switch to turn off the sleep
timer will affect any alarm settings you have made.
Adjusting the Display Brightness
This unit features the option of either a bright or dim clock display. To set
a bright clock display, slide the Time Set/Dimmer Switch to “Hi.” To set
a less-bright clock display, slide the Time Set/Dimmer Switch to “Lo.”
4
Limited 90-Day Warranty Information
Timex Audio Products, a division of SDI Technologies Inc. (hereafter referred to
as SDI Technologies), warrants this product to be free from defects in workmanship
and materials, under normal use and conditions, for a period of 90 days from the
date of original purchase.
Should this product fail to function in a satisfactory manner, it is best to first return
it to the store where it was originally purchased.
and service still be required by reason of any defect or malfunction during the warranty
period,
SDI Technologies will repair or, at its discretion, replace this product without
charge (except for a $3.00 charge for handling, packing, return UPS/postage, and
insurance). This decision is subject to verification of the defect or malfunction upon
delivery of this product to the Factory Service Center listed below. The product
must include proof of purchase, including date of purchase. The fee for service
after the warranty period or without proof of purchase is $6.00.
Before returning this product for service, please first replace the batteries (if
applicable) with fresh ones, as exhausted or defective batteries are the most
common cause of problems encountered.
If service is still required:
1. Remove batteries (if applicable) and pack the unit in a well-padded,
heavy corrugated box.
Should this fail to resolve the matter
2. Enclose a photocopy of your sales receipt, credit card statement, or other proof
of the date of purchase.
3. Enclose a check or money order payable to the order of Soundesign, for the
sum of $3.00 (or $6.00 if after the warranty period or without proof of purchase).
4. Send the unit prepaid to the Factory Service Center listed below:
Consumer Repair Department
SDI Technologies Inc.
Timex Audio Products Division
1401 Pullman Drive, Suite A
El Paso, TX 79936-7726
NOTE: This warranty is valid only if the product is used for the purpose for which
it was designed. It does not cover (i) products which have been damaged by
negligence, misuse or accident, or which have been modified or repaired by
unauthorized persons; (ii) cracked or broken cabinets, or units damaged by
excessive heat; (iii) damage to tape cassettes (if applicable); (iv) the cost of shipping
this product to the Factory Service Center and its return to the owner.
This warranty is valid only in the United States of America and does not extend
to owners of the product subsequent to the original purchaser. Any applicable
implied warranties are also limited to 90 days, and SDI Technologies will not be
liable for consequential damages. (Some states do not allow limitations on implied
warranties or exclusion of consequential damages, so these restrictions may not
apply to you.) This warranty gives you specific legal rights, and you may also have
other rights which vary from state to state.
For questions or comments regarding this or other products, please
call our toll-free number: 1-800-888-4491.
TIMEX is a registered trademark of Timex Corporation in the
United States and other countries.
T233-011204-0
Printed in China
Loading...
