Timex T236 User Manual
Model T236
Jumbo Display
AM/FM Clock Radio
For additional information, online registration,
and exclusive special offers visit our website:
Questions? Contact Customer Service at 1-800-888-4491
Table of Contents
What’s in the Box................................................................................................................................................................1
Product Care ...................................................................................................................................................................... 1
Controls Overview..............................................................................................................................................................2
Display................................................................................................................................................................................3
Set Up ................................................................................................................................................................................3
Adjusting the Time Zone.....................................................................................................................................................4
Setting the Clock .............................................................................................................................................................5-7
Setting and Using Alarms..............................................................................................................................................8-10
Setting and Using the Radio........................................................................................................................................10-12
Using in Aux-in Audio ..................................................................................................................................................12-13
Sleep Mode ...................................................................................................................................................................... 13
Dimmer............................................................................................................................................................................. 13
Charging Devices Using the USB Port.............................................................................................................................14
Battery Information ...........................................................................................................................................................14
Installing and Replacing Backup Batteries .......................................................................................................................15
Safety Information ............................................................................................................................................................ 16
Troubleshooting................................................................................................................................................................ 17
Warranty Information........................................................................................................................................................18
What’s in the Box
This product ships with the following items. Make sure all are present.
1. T236 Alarm Clock 2. AC adaptor 3. Instruction book
Product Care
• Place the unit on a level surface away from sources of direct sunlight or excessive heat.
• Protect your furniture when placing your unit on a natural wood and lacquered finish. A cloth or other protective
material should be placed between it and the furniture.
• Clean your unit with a soft cloth moistened only with mild soap and water. Stronger cleaning agents, such as Benzene,
thinner or similar materials can damage the surface of the unit.
1
Top Panel
Controls Overview
Tune + /
Hours
Button
Tune – /
Minutes
Button
Rear Panel
Power/
Alarm Reset
Button
HOURS
ALM RESET
TUNE
MINS
Mode
Button
Radio Presets/
Clock
Button
MODE
PRESETS
CLOCK
SNOOZE/SLEEP
DISPLAY DIMMER
Snooze/Sleep
Display Dimmer
Button
AUX-IN
DC 5V
ALARM 1
Alarm 1
Button
ALARM 2 VOL
TIME ZONE DST
Alarm 2
Button
Volume Up
Button
Volume Down
Button
Time Zone
Button
USB
charging
port
DC
jack
Aux-in
jack
2
FM Antenna
DST
(Daylight
Saving Time)
Switch
Display
When lit,
indicates time
Time display
When lit, indicates backup
batteries should be replaced
displayed is PM
When lit,
indicates
Buzzer or
Radio
is Alarm 1
alarm source.
If neither is lit,
Alarm 1 is not
armed
PM
BUZZER
RADIO
BATT LOW
BUZZER
RADIO
When lit,
indicates
Buzzer or
Radio
is Alarm 2
alarm source.
If neither is lit,
Alarm 2 is not
armed
Set Up
Connecting to Power Source
Connect the AC adaptor to the DC jack located on back of the unit. Connect plug into
a working wall outlet that is not controlled by a wall switch. The unit does not operate
on batteries (the battery backup system maintains clock settings during power failures).
PM
BUZZER
AUX-IN
DC 5V
TIME ZONE DST
RADIO
BATT LOW
BUZZER
RADIO
Redi-SET
This unit has a Redi-SET™ clock feature. When connected to power, the display
begins counting down 5-4-3-2-1, then the year flashes, followed by the month/date
and then the time. By default, the unit sets itself to Eastern Standard Time. If
Daylight Saving Time is in effect slide the DST switch on the back panel to the “+1”
position to move the display ahead by one hour.If you live in a different time zone
refer to the Time Zone Adjustment procedure on page 4. You only need to adjust the
Time Zone once and your new zone setting becomes the new default.
3
Adjusting the Time Zone
TIME ZONE
1
2 SECS
If you are NOT in the Eastern time zone, press and hold the Time Zone Button
located on back of the unit. “02” will flash in the display.
01——Atlantic Time
02——Eastern Time˄Default Setting˅
03——Central Time
HOURS
04——Mountain Time
Set Up
05——Pacific Time
06——Yukon Time
07——Hawaiian Time
2
TUNE
MINS
Find the number that matches your time zone above.
Press and release the TUNE+/HOURS Button or TUNE–/MINS Button until that
number appears on the display.
3
TIME ZONE
Press and release the Time Zone Button to confirm time zone setting.
4
Setting the Clock
This unit features Redi-SET and should display the correct time when first connected
to power. If the time is not correct, follow these steps to set the clock manually.
ALM RESET
1
BUZZER
RADIO
PM
BATT LOW
BUZZER
RADIO
Make sure unit is OFF. To confirm unit is off, press and release the Power/Alarm
Reset Button once or twice until OFF appears in the display.
DST
2
BUZZER
RADIO
PM
BATT LOW
BUZZER
RADIO
For quick adjustment for Daylight Saving Time, slide the DST Switch on the back of the
unit to +1 to add an hour. For Standard Time slide switch to -1 to subtract an hour.
3
PRESETS
CLOCK
2 SECS
BUZZER
RADIO
PM
BATT LOW
BUZZER
RADIO
Press and hold the Presets/Clock Button until the time flashes on the display.
5
