THOMSON conecto 300 User Manual
Wireless DECT handset with SOS call function
and medallion
User Manual
Please read and retain this instruction
For instruction manual in another language, check online at
http://www.thomsonphones.eu
1
Summary
Getting started
Important Safety Instructions 4
Presentation 6
Install the main handset 7
Install the medallion 9
First-time use 9
Low battery warning 10
Battery performance 10
Package contents 11
Getting to know your phone
DECT phone buttons 12
DECT phone base 14
Medallion 14
Handset display icons 15
DECT phone menu map 16
Using your DECT phone and Medallion
Using the handset menu 16
Switch the handset on/off 16
Switch the medallion on/off 17
Make a call 17
Preparatory dialing 17
End a call 17
Making a SOS call 17
Cancel a SOS call 17
Handsfree 17
Receiving calls 18
Dialing numbers quickly 18
Adjusting the earpiece volume 18
Mute the speakerphone 18
2
Call timer 18
Flash 18
Redial 18
Make a call from phonebook 18
Copy a number to phonebook 19
Speed dialing 19
Handset volume amplifier 19
Additional handsets, medallions and bases
Internal call 20
Make an internal call 20
Receive an internal call 20
Transfer an external call 20
3-Way call 21
Call log
View the call log 22
Copy a number / Delete a number / Delete all numbers 22
Call back incoming and outgoing numbers 22
Phonebook
To review phonebook list 23
To add a phonebook memory 23
To edit a contact 23
To delete a contact 23
To delete all contacts 24
Reviewing phonebook memory status 24
Base Settings
Delete handset 25
Dial mode 25
Recall time 25
Modify Base PIN code 25
PABX Number 25
3
Language 26
Settings for Conecto 100 26
Selection of your home telecom operator 27
Base default 27
Handset Settings
Alarm 28
Ring setup 28
Key tone 28
Language 28
Auto answer 29
Date & time 29
Select base 29
Contrast 29
Handset default 30
SOS setting
Setting SOS Number 31
Making SOS call 31
Canceling SOS call 31
Contact ID 32
SOS Voice prompt 32
Prior number
Setting prior number 33
Room monitor
Activating room monitor 34
Add extra handsets and medallion to the base 35
Trouble shooting 36
Declaration of conformity 37
4
Getting started
Important safety instructions
To reduce the risk of fire, electric shock and injury, always observe the following
basic precautions when using your telephone:
• This appliance is intended for indoor use only.
• Observe all markings on the product.
• Do not expose your telephone to moisture and avoid contact with liquids.
• To prevent electric shock, do not disassemble the handset or the telephone base.
• Avoid interposing any metal objects (clip, key, etc.) between the battery contacts
and charging contacts.
• Your telephone may have a slight chance of being damaged by lightning. Unplug
the telephone base from the mains and disconnect the telephone line during a
thunderstorm.
• Do not use the telephone in the vicinity of a gas leak.
• Do not use the handset near any intensive care medical equipment. People with
pacemakers should consult their doctor or cardiologist before using this
telephone.
• Clean your telephone with a dry, soft, lint-free cloth. Do not use any cleaning
agents or solvents, especially aggressive ones.
• Exchanges between the telephone base and handset being carried out by radio
signals, wearers of hearing aids may be bothered by a small buzz.
• Your telephone may interfere with other electrical appliances such as answering
machine, television, radio, clock radio or computer when it is sufficiently close to
such equipment. To avoid this, place the telephone base at least one meter away
from other electrical appliances.
• The receiver of the handset may attract small metal objects (staples, pins, etc). Be
careful when placing the handset near these items.
• Your telephone does not work in case of power failure and by consequence
cannot be used for emergency calls. To avoid this problem, you need to insert the
rechargeable batteries provided inside the handset's base, as described later in
this manual. However, it is important to note that the phone will not be able to
operate in case of power failure if you are using an ADSL box: in this case, you
need to have another means of communication, such as a mobile phone.
• To prevent electric shock, do not use your telephone during a thunderstorm.
Refer to the information printed on your telephone directory.
• You can connect this product to a PSTN telephone line or an analog PBX extension
port. Warning: Connecting this telephone to a digital PBX extension port may
cause damage.
5
• Do not overload wall outlets and extension cords as this may cause a fire or
electric shock.
• To eliminate any voltage within the telephone, unplug the power cord from the
mains.
• Observe the polarity indicated while installing the batteries.
• It is dangerous to use other battery types or non-rechargeable batteries: they can
cause interference and/or damage to the product. The manufacturer shall not be
liable for any damages caused by such non-compliance.
• Do not immerse a battery in water and do not throw it in a fire.
• The socket-outlet shall be installed near the equipment and shall be easily
accessible.
• If the appliance is not use for a period of time, please unplug the adapter in order
to save electricity.
• The external flexible cable of the adapter cannot be replaced, If the cord is
destroyed, the adapter should be destroyed.
CAUTION
Please use the bundle adaptor for operates the device only. The adaptor model
number: SW-075060EU
Failure to observe the correct polarity or voltage of the adapter may cause damage
to the telephone base.
For phone models CONECTO 300:
Adapter for the telephone base/charger: SW-075060EU
Input: 100-240V~ 50/60Hz 200mA
Output: DC 7.5V 600mA
6
Presentation
Main handset Medallion
Medallion with belt clip Medallion with necklace
Here are the main functions:
- The handset and the medallion both have an SOS key. On the handset, the SOS
key is to be found at the back of the phone. On the medallion, there is only
one key: just press the front key to start the emergency call.
- With a simple press on the SOS key, up to 8 of your contacts can be called to
be notified about the emergency.
- If the first contact does not pick the phone after five rings, the phone will
automatically try to call the next SOS number.
- You can make and receive calls with the handset. You can also receive calls
7
with the medallion conveniently with the handsfree function.
- You can carry the medallion always with you: in your pocket, on your waist
(belt-clip is provided) or around your neck (necklace provided).
- The medallion is dust and water-proof. Please however make sure not to
immerse the medallion into water for a prolonged time.
Important remark
Range of operation: Both the handset and the medallion use the wireless DECT
technology: the maximum range separating the handset from the base is 300
meters (without obstacles) or 50 meters with obstacles. Thick concrete walls will
reduce the transmission range.
This is therefore a product intended to be used at home. If used outside your
home, the medallion will not be able to receive calls or make emergency calls. If
you are planning to use the medallion outside your home in a garden, for
example, you need to make sure beforehand that all the zones are effectively
within range.
Install the main handset
Installation is easy and must be realized in a few minutes.
Should you have any questions regarding the installation of this product, please
call us at 01 48 12 93 27 (French local call, French speaking operators only), from
Monday to Friday (except public holidays), from 9:00am to 5:30pm.
The telephone base should be placed at least 1 meter away from other electrical
appliances in order to avoid interference. The handset exchanges radio signals with
the telephone base. The strength of these signals depends on the position of the
base. You can obtain a stronger signal by placing the base higher.
Adapter Jack
Telephone Jack
8
1. Insert the plug of the supplied adapter to the bottom of the telephone base and
the other end into an electrical outlet (both adaptors are identical).
2. Plug the telephone line cord to the bottom of the telephone base and the other
end into a telephone wall jack. If necessary, we can provide you a French telecom
plug free of charge. Please contact us at sav@admea.com.
3. Insert the rechargeable 800mAh Li-ion battery (provided) inside the handset.
Close the battery compartment.
4. Insert the four Ni-MH AAA 1.2V batteries provided inside the base, following the
polarity signs (+/-). In case of power failure, your phone will be able to operate
normally.
9
Important remark:
The phone will not be able to operate in case of power failure if you are using an
ADSL box (as the box will be out of power). In this case, it is mandatory to have
another means of communication in case of emergency, such as a mobile phone.
Important
Never insert non-rechargeable batteries inside the base or handset.
5. Place the handset on the telephone base and charge the battery for 24 hours
before using it for the first time.
Install the medallion
Remark:
In order to avoid Larsen effect (loud squeal), do not install the handset base
immediately next to the medallion.
1. Insert the plug of the supplied adapter to the back of the medallion charger and
the other end into an electrical outlet (both adaptors are identical).
2. Place the medallion on the charger and charge the batteries for 24 hours before
using it for the first time.
First-time use
To start the unit, long-press the handset's power key . The below screen will
appear in a short while. The message "Configure" prompts you to select your home
telecom operator, so as to setup the SOS emergency calls correctly.
Adapter Jack
10
Press the MENU/OK side key, and then use the upper/lower keys ▲/▼ so as to
select your home telecom operator. If your operator is not shown on the list, select
"Others". Press the MENU/OK key to confirm.
Remark:
In the particular case that you are using an ADSL box from Numericable, it is
necessary to deactivate the SOS Voice prompt option so that the receiver can
immediately answer the SOS call. Please consult page 32 of this manual.
Low battery warning
When the handset’s battery is very low, flashes on the handset screen and a
warning beep will sound every minute to prompt you to recharge the battery. For
the medallion, an announcement « Low Battery » in French language will come out.
Battery performance
When fully charged, the handset’s battery offer approximately 4 hours of talk time
and 168 hours of standby time under ideal conditions. For the medallion, the battery
standing time is 240 hours in standby and 6 hours in communication. Please note
that a new battery reaches its full capacity after several days of normal use.
The battery capacity decreases over time, reducing the talk time and standby time.
Replace the batteries if necessary.
The batteries and the handset will become hot during charging. This is normal.
Tip
When you are not using your handset, place it on the charger so that you can
always have fully charged batteries.
WARNING
DO NOT USE STANDARD OR ALKALINE BATTERIES. THEY MAY EXPLODE AND CAUSE
INJURY. ONLY USE RECHARGEABLE NI-MH BATTERIES AS INDICATED IN THIS USER
MANUAL.
11
Risk of explosion if you use incompatible batteries
Never use non-rechargeable batteries. Use only batteries that are identical to the
ones supplied with your telephone.
• Do not throw a battery into a fire.
• Do not open or damage batteries. Electrolyte is corrosive and can cause irritation
to eyes and skin. It is also toxic and must not be swallowed.
• If you must handle the batteries, avoid them from coming into contact with metal
objects. This may cause short circuit or overheating and you may burn yourself.
• Do not attempt to recharge the batteries by heating. The battery electrolyte may
leak, and may irritate your eyes or skin.
• Observe the polarity indicated. Reversing the polarity of the battery may result in
electrolyte leakage and explosion.
• Remove the batteries if you do not intend to use your phone for several
months.
• Do not use any other telephone base for charging the handset – the batteries can
be damaged.
Warning: Danger of explosion if batteries are incorrectly installed.
Use only Li-ion battery. The autonomy for the handsets indicated is
based on the original capacity of the batteries.
Dispose of used batteries according to the instructions of your local authorities.
Package contents
Quantity
Wireless DECT phone base
1
Medallion charging base
1
Cordless handset
1
Medallion
1
AC adapter 2
Telephone cable
1
User manual
1
Belt clip
1
Necklace
1
Li-ion battery 3.7V (800mAh)
1
Rechargeable 1.2V Ni-MH battery (600mAh)
4
If necessary, we can provide you a French telecom plug free of charge.
Please contact us at: sav@admea.com.
Loading...
