SGS365FS
36-INCH GAS COOKTOP
MASTERPIECE® SERIES
FEATURES & BENEFITS
- Patented and exclusive Star® Burner provides superior
performance
- Powerful 16,000 BTU center burner
- Continuous grates allow pots and pans to glide smoothly
across the cooktop
- Automatic electronic re-ignition
- Metal knobs feature a safety “push to turn” system
ACCESSORIES (OPTIONAL)
SWOKRINGF
Wok Ring
SGRIDDLEF
Griddle
SNLPKITF
LP Conversion Kit
GENERAL PROPERTIES
Controls Metal Knobs
Sealed Burners Yes
Grate Material Cast Iron
BURNER PERFORMANCE
Total BTU Load (NG / LP) 58,200 / 45,200 BTU
Power of Front Left Burner (NG / LP) 9,100 / 6,000 BTU
Power of Back Left Burner (NG / LP) 12,000 / 9,100 BTU
Power of Center Burner (NG / LP) 16,000 / 15,000 BTU
Power of Back Right Burner (NG / LP) 9,100 / 6,000 BTU
Power of Front Right Burner (NG / LP) 12,000 / 9,100 BTU
TECHNICAL DETAILS
Watts (W) 1,800 W
Circuit Breaker (A) 15 A
Volts (V) 120 V
Frequency (Hz) 60 Hz
Plug Type 3 prong
Power Cord Length (in) 60"
Energy Source Gas
Convertible To LP (Kit Required) Yes
DIMENSIONS & WEIGHT
Overall Appliance Dimensions (HxWxD) (in) 5 3/16" +3 13/16"
Required Cutout Size (HxWxD) (in) 3 13/16" x 34 15/16"
Minimum Distance From Counter Front (in) 1 7/8"
Minimum Distance From Rear Wall (in) 3"
Net Weight (lbs) 39 lbs
WARRANTY
Limited Warranty, Entire Appliance, Parts and
Labor
x 37" x 21 1/4"
x 19 1/8"
2 Year
THERMADOR® EXCLUSIVE
Page 1 of 4
10 / 17
Page 2
SGS365FS
36-INCH GAS COOKTOP
MASTERPIECE® SERIES
36-INCH COOKTOP AND CUTOUT DIMENSIONS
Page 2 of 4
10 / 17
Page 3
SGS365FS
(914
y
36-INCH GAS COOKTOP
MASTERPIECE® SERIES
INSTALLATION ABOVE A THERMADOR BUILT-IN OVEN
36"
mm)
63/4"
(172mm)
Gas
Connection
43/4"
(121mm)
511/16"
(144mm)
11/8"
(28mm)
247/16"
(621mm)
313/16"
COOKTOP
SUMP
OVEN
TOE KICK
(97mm)
3
/8"
(9mm)
271/16"
(687mm)
43/16"
(106mm)
281/4"
(718mm)
COUNTERTOP
3"
(76mm)
291/16"
(738mm)
Note: Dimensions based on standard countertop height (36" with 43/4" toe kick
including base plate).
The built-in oven can be installed below the gas cooktop as long as there is no
contact between the bottom of the cooktop and the top of the oven.
Sump applies to 30-inch Wall Ovens onl
.
Page 3 of 4
10 / 17
Page 4
SGS365FS
36-INCH GAS COOKTOP
MASTERPIECE® SERIES
CABINET REQUIREMENTS
Hood Depth - 24" (61cm) max.
Above Counter - 30" (76 cm) min. to
SGS(X)30 - 30" (76cm) min.
SGS(X)36 - 36" (91cm) min.
Depth from Back Wall
Cabinet 13" (33cm) max.
Combustible Surface
18" (46cm) min.
Left Side
13" (33cm) min.
Dimension requirements are for combustible surfaces. When the surface is protected by a material listed by UL as a Floor Protector
and Wall Shield covered with not less than No. 28 MSG sheet metal 0.015 inch (0.38 mm) stainless steel, 0.024 inch (0.6 mm)
aluminum or copper, it is considered noncombustible and some dimensions may be reduced. For a noncombustible surface over
the cooktop, the minimum clearance is 24" (61 cm) rather than 30" (76 cm).
WARNING: To reduce the risk of ignition of nearby combustible materials, install the countertop with a minimum distance of 13"
(33 cm) from side walls and 3" (8 cm) from back wall.)
NOTE: All measurements given have to be precisely followed. If nonstandard cabinets are used, make sure they are installed with
minimum dimensions shown.
Plan the installation of the unit so that the power cord, gas shut-off valve and gas pressure regulator are accessible from the front of
cabinet.
Centered Over Cooktop
Rear Wall - 3"(8cm)
Right Side
13" (33cm) min.
These warra nties give you specific legal rights and you may have other rights that vary from st ate to state. Full warrant y and limited war rant y from date of inst allation. For complete warranty
details, refer to your Use & Care manual, or ask your deal er.
Specifications are for planning purposes only. Refer to installation instru ctions and con sult your countertop s upplie r prior to m aking counter opening. Consul t with a he ating an d ventilation
engineer for your spec ific ventilation requirement s. For the most de tailed i nforma tion, refer to installation inst ructions accompanying pro duct o r write to Therma dor indicating the mod el
number. Specif ications are co rrec t at time of p rintin g. Ther mador re serves the right to cha nge prod uct specificatio ns or des ign without not ice. Some models are cer tified for use in C anada.
Thermador is n ot responsibl e for prod ucts that are t ransp orted from the U.S. for use i n Canada.
1 800 735 4328 | USA THERMAD OR.COM | CA NADA THERM ADOR.C A | ©2017 BSH HOME A PPLIANCES CORPOR ATION. ALL RIGHTS RESERVED.
