Texas Instruments TLE2061AMJG, TLE2061AMFKB, TLE2061AIP, TLE2061AID, TLE2061ACP Datasheet

TLE206x, TLE206xA, TLE206xB, TLE206xY

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE

µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

D

2× Bandwidth (2 MHz) of the TL06x and
TL03x Operational Amplifiers

D

Low Supply Current ... 290 µA/Ch Typ

D

On-chip Offset Voltage Trimming for
Improved DC Performance

description

The TLE206x series of low-power JFET-input operational amplifiers doubles the bandwidth of the earlier
generation TL06x and TL03x BiFET families without significantly increasing power consumption. Texas
Instruments Excalibur process also delivers a lower noise floor than the TL06x and TL03x. On-chip zener
trimming of offset voltage yields precision grades for dc-coupled applications. The TL206x devices are
pin-compatible with other TI BiFETs; they can be used to double the bandwidth of TL06x and TL03x circuits,
or to reduce power consumption of TL05x, TL07x, and TL08x circuits by nearly 90%.

BiFET operational amplifiers offer the inherently-higher input impedance of the JFET -input transistors, without
sacrificing the output drive associated with bipolar amplifiers. This makes them better suited for interfacing with
high-impedance sensors or very low-level ac signals. They also feature inherently better ac response than
bipolar or CMOS devices having comparable power consumption. The TLE206x family features a
high-output-drive circuit capable of driving 100-Ω loads at supplies as low as ±5 V . This makes them uniquely
suited for driving transformer loads in modems and other applications requiring good ac characteristics, low
power, and high output drive.

D

High Output Drive, Specified into 100-Ω
Loads

D

Lower Noise Floor Than Earlier
Generations of Low-Power BiFETs

Because BiFET operational amplifiers are designed for use with dual power supplies, care must be taken to
observe common-mode input voltage limits and output swing when operating from a single supply . DC biasing
of the input signal is required and loads should be terminated to a virtual ground node at mid-supply. Texas
Instruments TLE2426 integrated virtual ground generator is useful when operating BiFET amplifiers from single
supplies.

The TLE206x are fully specified at ±15 V and ±5 V . For operation in low-voltage and/or single-supply systems,
Texas Instruments LinCMOS families of operational amplifiers (TLC- and TLV-prefixes) are recommended.
When moving from BiFET to CMOS amplifiers, particular attention should be paid to slew rate and bandwidth
requirements, and output loading. The Texas Instrument TLV2432 and TLV2442 CMOS operational amplifiers
are excellent choices to consider.

Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of
Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.

PRODUCTION DATA information is current as of publication date.
Products conform to specifications per the terms of Texas Instruments
standard warranty. Production processing does not necessarily include
testing of all parameters.

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

Copyright  1998, Texas Instruments Incorporated

1

TLE206x, TLE206xA, TLE206xB, TLE206xY

CHIP

CHIP FORM

‡
‡

VIOmax

SMALL OUTLINE

†

CHIP CARRIER

CERAMIC DIP

PLASTIC DIP

T

A

AT 25°C

(D)

(FK)

(J)

(N)

()

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE
µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TLE2061 AVAILABLE OPTIONS

PACKAGED DEVICES

SMALL

OUTLINE

SMALL OUTLINE

TLE2062BCD
TLE2062ACD
TLE2062CD

TLE2062BID
TLE2062AID
TLE2062ID

TLE2062BMD
TLE2062AMD
TLE2062MD

†

(D)

(D)

T

to

to

to

VIOmax
AT 25°C

500 µV — — — — —

1.5 mV TLE2061ACD — — TLE2061ACP —
3 mV TLE2061CD — — TLE2061CP TLE2061CPWLE

500 µV — — — — —

1.5 mV TLE2061AID — — TLE2061AIP —
3 mV TLE2061ID — — TLE2061IP —

500 µV — — TLE2061BMJG — —

1.5 mV TLE2061AMD TLE2061AMFK TLE2061AMJG TLE2061AMP —
3 mV TLE2061MD TLE2061MFK TLE2061MJG TLE2061MP —

VIOmax

A

AT 25°C

1 mV
2 mV
4 mV

1 mV
2 mV
4 mV

1 mV
2 mV
4 mV

T

A

0°C to 70°C

–40°C to 85°C

–55°C to 125°C

†

The D packages are available taped and reeled. Add R suffix to device type (e.g., TLE2061ACDR).Chips are tested at 25°C.

‡

The PW package is available left-end taped and reeled (indicated by the LE suffix on the device type (e.g., TLE2061CPWLE).

§

Chip forms are tested at 25°C only.

0°C

70°C

–40°C

85°C

–55°C

125°C

†

The D packages are available taped and reeled. Add R suffix to device type (e.g., TLE2062ACDR).

‡

Chip forms are tested at 25°C only.

CHIP

CARRIER

(FK)

TLE2062 AVAILABLE OPTIONS

PACKAGED DEVICES

†

CHIP CARRIER

(FK)

—
—
—

—
—
—

TLE2062BMFK
TLE2062AMFK
TLE2062MFK

CERAMIC

DIP

(JG)

CERAMIC DIP

(JG)

—
—
—

—
—
—

TLE2062BMJG
TLE2062AMJG
TLE2062MJG

PLASTIC

DIP

(P)

PLASTIC DIP

TLE2062BCP
TLE2062ACP
TLE2062CP

TLE2062BIP
TLE2062AIP
TLE2062IP

TLE2062BMP
TLE2062AMP
TLE2062MP

TSSOP

(PW)

(P)

TLE2062Y

‡

(Y)

—
—

—
—
—

—
—
—

§

FORM

(Y)

—
—

TLE2061Y

—
—
—

—
—
—

2

TLE2064 AVAILABLE OPTIONS

PACKAGED DEVICES

T

0°C

to

70°C

–40°C

to

85°C

–55°C

to

125°C

†

The D packages are available taped and reeled. Add R suffix to device type, (e.g., TLE2064ACDR).

‡

Chip forms are tested at 25°C only.

2 mV
4 mV
6 mV

2 mV
4 mV
6 mV

2 mV
4 mV
6 mV

—
TLE2064ACD
TLE2064CD

—
TLE2064AID
TLE2064ID

—
TLE2064AMD
TLE2064MD

— —

— —

—
TLE2064AMFK
TLE2064MFK

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

TLE2064BMJ
TLE2064AMJ
TLE2064MJ

TLE2064BCN
TLE2064ACN
TLE2064CN

TLE2064BIN
TLE2064AIN
TLE2064IN

TLE2064BMN
TLE2064AMN
TLE2064MN

CHIP FORM

(Y)

—
—

TLE2064Y

—
—
—

—
—
—

TLE206x, TLE206xA, TLE206xB, TLE206xY

M

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE

µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TLE2061, TLE2061A, AND TLE2061B

D, DB, JG, P, OR PW PACKAGE

(TOP VIEW)

OFFSET N1

V

CC –

TLE2061M, TLE2061AM, TLE2061BM

NC

IN –

NC

IN +

NC

1

IN–

2

IN+

3
4

FK PACKAGE

(TOP VIEW)

NC

OFFSET N1

NCNCNC

3212019

4
5
6
7
8

910111213

NC

NC

CC–

V

NC

8

V

7

OUT

6

OFFSET N2

5

NC

18
17
16
15
14

CC+

NC
V
NC
OUT
NC

CC+

TLE2062, TLE2062A, TLE2062B

D, JG, OR P PACKAGE

(TOP VIEW)

1OUT

1IN–
1IN+

V

CC–

TLE2062M, TLE2062AM, TLE2062BM

NC

1IN–

NC

1IN+

NC

1
2
3
4

FK PACKAGE

(TOP VIEW)

NC

1OUT

3 2 1 20 19

4
5
6
7
8

910111213

NCVNC

CC –

V

8

2OUT

7

2IN–

6

2IN+

5

CC +

NCNCNC

V

18
17
16
15
14

2IN+

CC+

NC
2OUT
NC
2IN–
NC

TLE2064, TLE2064A, TLE2064B

D, J, OR N PACKAGE

(TOP VIEW)

1OUT

1IN–
1IN+

V

2IN+
2IN–

2OUT

TLE2064M, TLE2064AM, TLE2064B

1IN+

NC

V

CC+

NC

2IN+

1
2
3
4

CC +

5
6
7

FK PACKAGE

(TOP VIEW)

1IN –

1OUT

3212019

4
5
6
7
8

910111213

NC

14
13
12
11
10

9
8

4OUT

4IN –

18
17
16
15
14

4OUT
4IN–
4IN+
V

CC–

3IN+
3IN–
3OUT

4IN+
NC
V
NC
3IN+

NC

2IN –

2OUT

3IN –

3OUT

CC–

NC – No internal connection

OFFSET N2

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

3

TLE206x, TLE206xA, TLE206xB, TLE206xY
EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE
µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TLE2061Y chip information

This chip, when properly assembled, displays characteristics similar to the TLE2061. Thermal compression or
ultrasonic bonding may be used on the doped-aluminum bonding pads. Chips may be mounted with conductive
epoxy or a gold-silicon preform.

BONDING PAD ASSIGNMENTS

V

CC+

V

(7)

(4)

CC–

(7) (6)

OFFSET N1

IN+

IN–

OFFSET N2

(1)

(3)

(2)

(5)

(6)

OUT

65

(1)

(2)

45

(5)

(3)

(4)

CHIP THICKNESS: 15 MILS TYPICAL
BONDING PADS: 4 X 4 MILS MINIMUM
TJmax = 150°C
TOLERANCES ARE ± 10%.
ALL DIMENSIONS ARE IN MILS.
PIN (4) IS INTERNALLY CONNECTED

TO BACKSIDE OF CHIP.

4

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

TLE206x, TLE206xA, TLE206xB, TLE206xY

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE

µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TLE2062Y chip information

This chip, when properly assembled, displays characteristics similar to the TLE2062. Thermal compression or
ultrasonic bonding may be used on the doped-aluminum bonding pads. Chips may be mounted with conductive
epoxy or a gold-silicon preform.

75

(1)

(2)

(3)

BONDING PAD ASSIGNMENTS

(8)

(4)

73

(7)

(6)

(5)

V

CC+

+

–

V

CC–

(8)

(4)

(1)

1OUT

(5)

+

–

(6)

2IN+

2IN–

(3)

1IN+

(2)

1IN–

(7)

2OUT

CHIP THICKNESS: 15 MILS TYPICAL
BONDING PADS: 4 × 4 MILS MINIMUM
TJmax = 150°C
TOLERANCES ARE ±10%.
ALL DIMENSIONS ARE IN MILS.
PIN (4) IS INTERNALLY CONNECTED

TO BACKSIDE OF THE CHIP.

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

5

TLE206x, TLE206xA, TLE206xB, TLE206xY
EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE
µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TLE2064Y chip information

This chip, when properly assembled, displays characteristics similar to the TLE2064. Thermal compression or
ultrasonic bonding may be used on the doped-aluminum bonding pads. Chips may be mounted with conductive
epoxy or a gold-silicon preform.

73

(14)

(1)

BONDING PAD ASSIGNMENTS

(2)

(11) (9)

(10)(12)(13)

(5) (6)

(3)

(4)

139

(7)

(8)

V

CC+

+

–

+

–

V

(11)

CC–

(4)

(1)

1OUT

(5)

+

–

+

–

(6)

(8)

(12)

(13)

2IN+

2IN–

3OUT

4IN+

4IN–

(3)

1IN+

(2)

1IN–

3IN+

3IN–

(7)

(10)

(9)

(14)

2OUT

4OUT

CHIP THICKNESS: 15 MILS TYPICAL
BONDING PADS: 4 × 4 MILS MINIMUM
TJmax = 150°C
TOLERANCES ARE ±10%.
ALL DIMENSIONS ARE IN MILS.
PIN (11) IS INTERNALLY CONNECTED

TO BACKSIDE OF CHIP.

6

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

equivalent schematic (each channel)

V

CC+

Q13Q9

Q32

POST OFFICE BOX 655303 DALLAS, TEXAS 75265

• 6–7

Q14

Q4

IN+

IN–

Q1

15 pF

Q2

R1

1.1 kΩ

OFFSET N2

OFFSET N1

NOTES: A. OFFSET N1 AND OFFSET N2 are only availiable on the TLE2061x devices.

B. Component values are nominal.

Q5 Q7Q3

Q6

C1

R4
55 kΩR21.1 kΩ

See Note A

Q8

R3

2.4 kΩ

C2

15 pF

Q10

R5
60 kΩ

Q11

C3

5.3 pF

Q15

Q16

Q19

Q17

Q20

Q21

Q12

Q22

Q18

R6

2.7 kΩ

V

CC–

Q24

Q25

Q23

Q26

Q28

Q27

Q29

R7

600 Ω

Q30

Q31

D1

Q33

Q34

D2

Q35

Q36

Q37

Q38

Q39

Q40

Q41

R8

20 Ω

Q42

R9

100 Ω

OUT

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE

TLE206x, TLE206xA, TLE206xB, TLE206xY

µ

POWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUAR Y 1997 – REVISED MARCH 1998

ACTUAL DEVICE COMPONENT COUNT

COMPONENT TLE2061 TLE2062 TLE2064

Transistors 43 42 42
Resistors 9 9 9
Diodes 1 2 2
Capacitors 3 3 3

TLE206x, TLE206xA, TLE206xB, TLE206xY

UNIT

Common-mode input voltage, V

V

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE
µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

absolute maximum ratings over operating free-air temperature range (unless otherwise noted)

Supply voltage, V
Supply voltage, V
Differential input voltage, V
Input voltage range, V
Input current, I

I

Output current, I
Total current into V
Total current out of V

Duration of short-circuit current at (or below) 25°C (see Note 3) unlimited. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Continuous total dissipation See Dissipation Rating Table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Operating free-air temperature range, T

Storage temperature range –65°C to 150°C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Case temperature for 60 seconds: FK package 260°C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Lead temperature 1,6 mm (1/16 inch) from case for 10 seconds: D, P, or PW package 260°C. . . . . . . . . . . .

Lead temperature 1,6 mm (1/16 inch) from case for 60 seconds: JG package 300°C. . . . . . . . . . . . . . . . . . . .

†

Stresses beyond those listed under “absolute maximum ratings” may cause permanent damage to the device. These are stress ratings only, and
functional operation of the device at these or any other conditions beyond those indicated under “recommended operating conditions” is not
implied. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.

NOTES: 1. All voltage values, except differential voltages, are with respect to the midpoint between V

2. Differential voltages are at IN+ with respect to IN–.

3. The output may be shorted to either supply. Temperature and /or supply voltages must be limited to ensure that the maximum
dissipation rating is not exceeded.

(see Note 1) 19 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

CC+

–19 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

CC–

I

(see Note 2) ±38 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

ID

(any input) ±V

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

(each input) ±1 mA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

±80 mA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

O

80 mA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

CC+

–80 mA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

CC –

: C suffix 0°C to 70°C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

A

I suffix –40°C to 85°C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

M suffix –55°C to 125°C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

CC+

and V

CC–

.

†

CC

PACKAGE

D–8 725 mW 5.8 mW/°C 464 mW 377 mW 145 mW

D–14 950 mW 7.6 mW/°C 608 mW 494 mW 190 mW

FK 1375 mW 11.0 mW/°C 880 mW 715 mW 275 mW

J 1375 mW 11.0 mW/°C 880 mW 715 mW 275 mW

JG 1050 mW 8.4 mW/°C 672 mW 546 mW 210 mW

N 1150 mW 9.2 mW/°C 736 mW 598 mW 230 mW
P 1000 mW 8.0 mW/°C 640 mW 520 mW 200 mW

PW 525 mW 4.2 mW/°C 336 mW — —

TA ≤ 25°C

POWER RATING

DERATING FACTOR

ABOVE TA = 25°C

recommended operating conditions

Supply voltage, V

Operating free-air temperature, T

CC

p

±

V

= ± 5 V –1.6 4 –1.6 4 –1.6 4

IC

A

CC±

V

= ± 15 V –11 13 –11 13 –11 13

CC±

DISSIPATION RATING TABLE

TA = 70°C

POWER RATING

C SUFFIX I SUFFIX M SUFFIX

MIN MAX MIN MAX

±3.5 ±18 ±3.5 ±18 ±3.5 ±18 V

TA = 85°C

POWER RATING

0 70 –40 85 –55 125 °C

TA = 125°C

POWER RATING

MIN

MAX

8

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

TLE206x, TLE206xA, TLE206xB, TLE206xY

†

TLE2061C

VIOInput offset voltage

TLE2061AC

mV

TLE2061BC

V

R

Ω

IIOInput offset current

IIBInput bias current

V

Common-mode input voltage range

R

10 kΩ

V

Maximum positive peak output voltage swing

V

R

100 Ω

R

kΩ

V

Maximum negative peak output voltage swing

V

R

100 Ω

V

R

kΩ

AVDLarge-signal differential voltage amplification

V

R

100 Ω

V/mV

V

0 to –2 V

R

100 Ω

CMRR

Common-mode rejection ratio

V

V

min, R

50 Ω

dB

k

Suppl

oltage rejection ratio (∆V

/∆VIO)

CC±

,

dB

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE

µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TLE2061C electrical characteristics at specified free-air temperature, V

= ±5 V (unless

CC±

otherwise noted)

TLE2061C

PARAMETER TEST CONDITIONS

p

= 0,

α

r

i

c
z

†

Full range is 0°C to 70°C.

NOTE 4: Typical values are based on the input offset voltage shift observed through 168 hours of operating life test at TA = 150°C extrapolated

Temperature coefficient of input offset voltage

VIO

Input offset voltage long-term drift (see Note 4) 25°C 0.04 µV/mo

p

p

ICR

OM+

OM–

Input resistance 25°C 10
Input capacitance 25°C 4 pF

i

Open-loop output impedance IO = 0 25°C 280 Ω

o

pp

SVR

y-v

to TA = 25°C using the Arrhenius equation and assuming an activation energy of 0.96 eV.

p

p

p

p

p

p

p

CC±

IC

=

L

=

L

= 10

L

=

L

= ±2.8 V,

O

= 0 to 2 V,

O

=

O

=

IC

ICR

V

= ±5 V to ±15 V,

RS = 50 Ω

,

S

= 10

L

L

L

=

S

= 50

=

=

T

A

25°C 0.8 3.1

Full range 4

25°C 0.6 2.6

Full range 3.5

25°C 0.5 1.9
Full range 2.4
Full range 6 µV/°C

25°C 1 pA
Full range 0.8 nA

25°C 3 pA
Full range 2 nA

25°C

Full range

25°C 3.5 3.7
Full range 3.3

25°C 2.5 3.1
Full range 2

25°C –3.7 –3.9
Full range –3.3

25°C –2.5 –2.7
Full range –2

25°C 15 80
Full range 2

25°C 0.75 45
Full range 0.5

25°C 0.5 3
Full range 0.25

25°C 65 82
Full range 65

25°C 75 93
Full range 75

TLE2061AC
TLE2061BC

MIN TYP MAX

–1.6

–1.6

–2

to

to

4

to

4

6

12

UNIT

V

V

Ω

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

9

TLE206x, TLE206xA, TLE206xB, TLE206xY

†

ICCSupply current

A

†

SR

Slew rate at unity gain (see Figure 1)

R

C

100 pF

V/µs

VnEquivalent input noise voltage (see Figure 2)

25°C

V/√H

V

Peak-to-peak equivalent input noise voltage

f

25°C

1.1µV

THD

Total harmonic distortion

VD

,,

25°C

0.025%

B1Unity-gain bandwidth (see Figure 3)

25°C

MH

tsSettling time

25°C

s

φ

Phase margin at unity gain (see Figure 3)

25°C

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE
µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TLE2061C electrical characteristics at specified free-air temperature, V
otherwise noted) (continued)

PARAMETER TEST CONDITIONS

pp

∆I

†

Full range is 0°C to 70°C.

Supply-current change over operating temperature range Full range 29 µA

CC

VO = 0, No load

TLE2061C operating characteristics at specified free-air temperature, V

PARAMETER TEST CONDITIONS

p

=

L

N(PP)

I

n

B

OM

m

†

Full range is 0°C to 70°C.

Equivalent input noise current f = 1 kHz 25°C 1

Maximum output-swing bandwidth AVD = 1, RL = 10 kΩ 25°C 140 kHz

p

= 10 kΩ,

L

p

p

f = 10 Hz, RS = 20 Ω
f = 1 kHz, RS = 20 Ω

= 0.1 Hz to 10 Hz

A

= 2, f = 10 kHz,

V

= 2 V, RL = 10 kΩ

O(PP)

RL = 10 kΩ, CL = 100 pF
RL = 100 Ω, CL = 100 pF

0.1%

0.01%

RL = 10 kΩ, CL = 100 pF
RL = 100 Ω, CL = 100 pF

T

A

25°C 280 325

Full range 350

CC±

T

A

MIN TYP MAX

25°C 2.2 3.4

Full range 2.1

°

°

°

°

°

= ±5 V (unless

CC±

TLE2061C
TLE2061AC
TLE2061BC

MIN TYP MAX

= ±5 V

TLE2061C
TLE2061AC
TLE2061BC

59 100
43 60

1.8

1.3
5

10

58°
75°

UNIT

µ

UNIT

n

fA/√Hz

µ

z

z

10

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

TLE206x, TLE206xA, TLE206xB, TLE206xY

†

TLE2061C

VIOInput offset voltage

TLE2061AC

mV

TLE2061BC

V

0

R

50 kΩ

IIOInput offset current

IIBInput bias current

V

Common-mode input voltage range

R

kΩ

V

Maximum positive peak output voltage swing

V

R

600 Ω

R

kΩ

V

Maximum negative peak output voltage swing

V

R

600 Ω

V

±10 V

R

kΩ

AVDLarge-signal differential voltage amplification

V

R

600 Ω

V/mV

V

R

600 Ω

CMRR

Common-mode rejection ratio

V

V

min,R

Ω

dB

k

Suppl

oltage rejection ratio (∆V

/∆VIO)

CC±

,

dB

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE

µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TLE2061C electrical characteristics at specified free-air temperature, V

= ±15 V (unless

CC±

otherwise noted)

TLE2061C

PARAMETER TEST CONDITIONS

p

,

=

α

r

i

c
z

†

Full range is 0°C to 70°C.

NOTE 4: Typical values are based on the input offset voltage shift observed through 168 hours of operating life test at TA = 150°C extrapolated

Temperature coefficient of input offset voltage

VIO

Input offset voltage long-term drift (see Note 4) 25°C 0.04 µV/mo

p

p

ICR

OM+

OM–

Input resistance 25°C 10
Input capacitance 25°C 4 pF

i

Open-loop output impedance IO = 0 25°C 280 Ω

o

pp

SVR

y-v

to TA = 25°C using the Arrhenius equation and assuming an activation energy of 0.96 eV.

p

p

p

p

p

p

p

CC±

IC

= 10

L

=

L

= 10

L

=

L

=

O

= 0 to 8 V,

O

= 0 to –8 V,

O

=

IC

ICR

V

= ±5 V to ±15 V,

RS = 50 Ω

,

=

S

= 10

L

=

L

=

L

= 50

S

T

A

25°C 0.6 3

Full range 3.9

25°C 0.5 1.5

Full range 2.5

25°C 0.3 0.5
Full range 1
Full range 6 µV/°C

25°C 2 pA
Full range 1 nA

25°C 4 pA
Full range 3 nA

25°C

Full range

25°C 13.2 13.7
Full range 13

25°C 12.5 13.2
Full range 12

25°C –13.2 –13.7
Full range –13

25°C –12.5 –13
Full range –12

25°C 30 230
Full range 20

25°C 25 100
Full range 10

25°C 3 25
Full range 1

25°C 72 90
Full range 70

25°C 75 93
Full range 75

TLE2061AC
TLE2061BC

MIN TYP MAX

–11

–12

to

13

–11

to

13

to

16

12

UNIT

V

V

Ω

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

11

TLE206x, TLE206xA, TLE206xB, TLE206xY

†

ICCSupply current

A

O

∆ICCSupply-current change over operating temperature range

Full range

34µA

†

SR

Slew rate at unity gain (see Figure 1)

R

C

100 pF

V/µs

VnEquivalent input noise voltage (see Figure 2)

25°C

V/√H

THD

Total harmonic distortion

VD

,,

25°C

0.025%

B1Unity-gain bandwidth (see Figure 3)

25°C

MH

tsSettling time

25°C

s

φ

Phase margin at unity gain (see Figure 3)

25°C

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE
µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TLE2061C electrical characteristics at specified free-air temperature, V
otherwise noted) (continued)

PARAMETER TEST CONDITIONS

pp

pp

†

Full range is 0°C to 70°C.

p

p

VO = 0, No load

TLE2061C operating characteristics at specified free-air temperature, V

PARAMETER TEST CONDITIONS

=

L

= 100 pF

L

= 100 pF

L

= 100 pF

L

= 100 pF

L

p

V

N(PP)

I

n

B

OM

m

†

Full range is 0°C to 70°C.

Peak-to-peak equivalent input noise voltage f = 0.1 Hz to 10 Hz 25°C 1.1 µV
Equivalent input noise current f = 1 kHz 25°C 1.1

Maximum output-swing bandwidth AVD = 1, RL = 10 kΩ 25°C 40 kHz

= 10 kΩ,

L

p

f = 10 Hz, RS = 20 Ω
f = 1 kHz, RS = 20 Ω

A

= 2, f = 10 kHz,

V

= 2 V, RL = 10 kΩ

O(PP)

RL = 10 kΩ,C
RL = 600 Ω,C

0.1%

0.01%

RL = 10 kΩ,C
RL = 600 Ω,C

T

A

25°C 290 350

Full range 375

CC±

T

A

25°C 2.6 3.4

Full range 2.5

°

°

°

°

°

= ±15 V (unless

CC ±

TLE2061C
TLE2061AC
TLE2061BC

MIN TYP MAX

= ±15 V

TLE2061C

TLE2061AC
TLE2061BC

MIN TYP MAX

70 100
40 60

2

1.5
5

10

60°
70°

UNIT

µ

UNIT

n

fA/√Hz

µ

z

z

12

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

TLE206x, TLE206xA, TLE206xB, TLE206xY

†

T

A

TLE2061I

VIOInput offset voltage

TLE2061AI

mV

TLE2061BI

,

V

IC

0,

IIOInput offset current

IIBInput bias current

V

Common-mode input voltage range

R

10 kΩ

V

Maximum positive peak output voltage swing

V

R

100 Ω

R

10 kΩ

V

Maximum negative peak output voltage swing

V

R

100 Ω

,

V

O

±2.8 V,

,

AVDLarge-signal differential voltage amplification

V

O

V,

V/mV

,

V

O

V,

CMRR

Common-mode rejection ratio

IC ICR

,

dB

k

Suppl

oltage rejection ratio (∆V

/∆VIO)

CC±

dB

ICCSupply current

A

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE

µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TLE2061I electrical characteristics at specified free-air temperature, V

= ±5 V (unless otherwise

CC±

noted)

TLE2061I , TLE2061AI

PARAMETER TEST CONDITIONS

p

V

= 0

α

r

i

c

i

z

o

SVR

∆I

†

Full range is –40°C to 85°C.

NOTE 4: Typical values are based on the input offset voltage shift observed through 168 hours of operating life test at TA = 150°C extrapolated

Temperature coefficient of input offset voltage

VIO

Input offset voltage long-term drift (see Note 4) 25°C 0.04 µV/mo

p

p

ICR

OM+

OM–

Input resistance 25°C 10
Input capacitance 25°C 4 pF
Open-loop output impedance IO = 0 25°C 280 Ω

pp

y-v

pp

Supply-current change over operating

CC

temperature range

to TA = 25°C using the Arrhenius equation and assuming an activation energy of 0.96 eV.

p

p

p

p

p

p

p

CC±

RS = 50 Ω

=

L

=

L

=

L

=

L

V

= ±2.8 V

RL = 10 kΩ
V

= 0 to 2 V

0 to 2

RL = 100 Ω
V

= 0 to –2 V

0 to 2

RL = 100 Ω

V

= V

RS = 50 Ω
V

= ±5 V to ±15 V,

CC±

RS = 50 Ω

VO = 0,
No load

min,

T

25°C 0.8 3.1

Full range 4.4

25°C 0.6 2.6

Full range 3.9

25°C 0.5 1.9
Full range 2.7
Full range 6 µV/°C

25°C 1 pA
Full range 2 nA

25°C 3 pA
Full range 4 nA

25°C –1.6 to 4 –2 to 6 V
Full range –1.6 to 4 V

25°C 3.5 3.7
Full range 3.1

25°C 2.5 3.1
Full range 2

25°C –3.7 –3.9
Full range –3.1

25°C –2.5 –2.7
Full range –2

25°C 15 80
Full range 2

25°C 0.75 45
Full range 0.5

25°C 0.5 3
Full range 0.25

25°C 65 82
Full range 65

25°C 75 93
Full range 65

25°C 280 325
Full range 350

Full range 29 µA

TLE2061BI

MIN TYP MAX

12

UNIT

Ω

µ

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

13

TLE206x, TLE206xA, TLE206xB, TLE206xY

†

SR

Slew rate at unity gain (see Figure 1)

R

C

100 pF

V/µs

VnEquivalent input noise voltage (see Figure 2)

25°C

V/√H

THD

Total harmonic distortion

VD

,,

25°C

0.025%

B1Unity-gain bandwidth (see Figure 3)

25°C

MH

tsSettling time

25°C

s

φ

Phase margin at unity gain (see Figure 3)

25°C

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE
µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TLE2061I operating characteristics at specified free-air temperature, V

PARAMETER TEST CONDITIONS

p

V

N(PP)

I

n

B

OM

m

†

Full range is –40°C to 85°C.

Peak-to-peak equivalent input noise voltage f = 0.1 Hz to 10 Hz 25°C 1.1 µV
Equivalent input noise current f = 1 kHz 25°C 1 fA/√Hz

Maximum output-swing bandwidth AVD = 1, RL = 10 kΩ 25°C 140 kHz

= 10 kΩ,

L

f = 10 Hz, RS = 20 Ω
f = 1 kHz, RS = 20 Ω

A

= 2, f = 10 kHz,

V

= 2 V, RL = 10 kΩ

O(PP)

RL = 10 kΩ, CL = 100 pF
RL = 100 Ω, CL = 100 pF

0.1%

0.01%

RL = 10 kΩ, CL = 100 pF
RL = 100 Ω, CL = 100 pF

p

=

L

T

A

25°C 2.2 3.4

Full range 1.7

°

°

°

°

°

= ±5 V

CC±

TLE2061I
TLE2061AI
TLE2061BI

MIN TYP MAX

59 100
43 60

1.8

1.3
5

10

58°
75°

UNIT

n

z

z

µ

14

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

TLE206x, TLE206xA, TLE206xB, TLE206xY

†

T

A

TLE2061I

VIOInput offset voltage

TLE2061AI

mV

TLE2061BI

IIOInput offset current

IIBInput bias current

V

Common-mode input voltage range

R

kΩ

V

Maximum positive peak output voltage swing

V

R

600 Ω

R

kΩ

V

Maximum negative eak out ut voltage

V

R

600 Ω

,

V

O

±10 V,

,

AVDLarge-signal differential voltage amplification

V

O

V,

V/mV

,

V

O

V,

,

CMRR

Common-mode rejection ratio

V

IC

V

ICR

min,

dB

k

Suppl

oltage rejection ratio (∆V

/∆VIO)

CC±

,

dB

ICCSupply current

A

O

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE

µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TLE2061I electrical characteristics at specified free-air temperature, V

= ±15 V (unless

CC±

otherwise noted)

TLE2061I, TLE2061AI

PARAMETER TEST CONDITIONS

p

α

r

i

c

i

z

o

SVR

∆I

†

Full range is –40°C to 85°C.

NOTE 4: Typical values are based on the input offset voltage shift observed through 168 hours of operating life test at TA = 150°C extrapolated

Temperature coefficient of input offset

VIO

voltage
Input offset voltage long-term drift

(see Note 4)

p

p

ICR

OM+

Maximum negative peak output voltage

OM–

swing

Input resistance 25°C 10
Input capacitance 25°C 4 pF
Open-loop output impedance IO = 0 25°C 280 Ω

pp

y-v

pp

Supply-current change over operating

CC

temperature range

to TA = 25°C using the Arrhenius equation and assuming an activation energy of 0.96 eV.

p

p

p

p

p

CC±

VIC = 0,
RS = 50 Ω

= 10

L

=

L

= 10

L

=

L

V

= ±10 V

RL = 10 kΩ
V

= 0 to 8 V

0 to 8

RL = 600 Ω
V

= 0 to –8 V

0 to 8

RL = 600 Ω

V

= V

RS = 50 Ω
V

= ±5 V to ±15 V,

RS = 50 Ω

VO = 0,
No load

min

T

25°C 0.6 3

Full range 4.3

25°C 0.5 1.5

Full range 2.9

25°C 0.3 0.5

Full range 1.3
Full range 6 µV/°C

25°C 0.04 µV/mo
25°C 2 pA

Full range 3 nA

25°C 4 pA

Full range 5 nA

25°C –11 to 13 –12 to 16 V

Full range –11 to 13 V

25°C 13.2 13.7

Full range 13

25°C 12.5 13.2

Full range 12

25°C –13.2 –13.7

Full range –13

25°C –12.5 –13

Full range –12

25°C 30 230

Full range 20

25°C 25 100

Full range 10

25°C 3 25

Full range 01

25°C 72 90

Full range 65

25°C 75 93

Full range 65

25°C 290 350

Full range 375
Full range 34 µA

TLE2061BI

MIN TYP MAX

12

UNIT

Ω

µ

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

15

TLE206x, TLE206xA, TLE206xB, TLE206xY

†

SR

Slew rate at unity gain (see Figure 1)

R

C

100 pF

V/µs

VnEquivalent input noise voltage (see Figure 2)

25°C

V/√H

THD

Total harmonic distortion

VD

,,

25°C

0.025%

B1Unity-gain bandwidth (see Figure 3)

25°C

MH

tsSettling time

25°C

s

φ

Phase margin at unity gain (see Figure 3)

25°C

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE
µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TLE2061I operating characteristics at specified free-air temperature, V

PARAMETER TEST CONDITIONS

p

V

N(PP)

I

n

B

OM

m

†

Full range is –40°C to 85°C.

Peak-to-peak equivalent input noise voltage f = 0.1 Hz to 10 Hz 25°C 1.1 µV
Equivalent input noise current f = 1 kHz 25°C 1.1

Maximum output-swing bandwidth AVD = 1, RL = 10 kΩ 25°C 40 kHz

= 10 kΩ,

L

f = 10 Hz, RS = 20 Ω
f = 1 kHz, RS = 20 Ω

A

= 2, f = 10 kHz,

V

= 2 V, RL = 10 kΩ

O(PP)

RL = 10 kΩ, CL = 100 pF
RL = 600 Ω, CL = 100 pF

0.1%

0.01%

RL = 10 kΩ, CL = 100 pF
RL = 600 Ω, CL = 100 pF

p

=

L

T

A

25°C 2.6 3.4

Full range 2.1

°

°

°

°

°

= ±15 V

CC±

TLE2061I
TLE2061AI
TLE2061BI

MIN TYP MAX

70 100
40 60

2

1.5
5

10

60°
70°

UNIT

n

fA/√Hz

µ

z

z

16

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

TLE206x, TLE206xA, TLE206xB, TLE206xY

†

TLE2061M

VIOInput offset voltage

TLE2061AM

mV

TLE2061BM

V

0

R

50 Ω

IIOInput offset current

IIBInput bias current

V

Common-mode input voltage range

R

kΩ

V

Maximum positive peak output voltage swing

R

600 Ω

V

R

100 Ω

R

kΩ

V

g

R

600 Ω

V

R

100 Ω

V

R

kΩ

V

R

600 Ω

A

gg

V

R

600 Ω

V/mV

V

R

100 Ω

V

0 to –2 V,R

100 Ω

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE

µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TLE2061M electrical characteristics at specified free-air temperature, V

= ±5 V (unless

CC±

otherwise noted)

TLE2061M

PARAMETER TEST CONDITIONS

p

,

=

α

†

Full range is –55°C to 125°C.

NOTE 4: Typical values are based on the input offset voltage shift observed through 168 hours of operating life test at TA = 150°C extrapolated

Temperature coefficient of input offset voltage

VIO

Input offset voltage long-term drift (see Note 4) 25°C 0.04 µV/mo

p

p

ICR

OM+

Maximum negative peak FK and JG

OM–

output voltage swing packages

Large-signal differential

VD

voltage amplification

to TA = 25°C using the Arrhenius equation and assuming an activation energy of 0.96 eV.

p

p

p

p

D and P
packages

FK and JG
packages

D and P
packages

IC

= 10

L

=

L

=

L

= 10

L

=

L

=

L

= ±2.8 V,

O

= 0 to 2.5 V,

O

= 0 to –2.5 V,

O

= 0 to 2 V,

O

=

O

=

S

= 10

L

=

L

=

L

=

L

=

L

T

A

25°C 0.8 3.1

Full range 6

25°C 0.6 2.6

Full range 4.6

25°C 0.5 1.9
Full range 3.1
Full range 6 µV/°C

25°C 1 pA
Full range 15 nA

25°C 3 pA
Full range 30 nA

25°C

Full range

25°C 3.5 3.7
Full range 3

25°C 2.5 3.6
Full range 2

25°C 2.5 3.1
Full range 2

25°C –3.5 –3.9
Full range –3

25°C –2.5 –3.5
Full range –2

25°C –2.5 –2.7
Full range –2

25°C 15 80
Full range 2

25°C 1 65
Full range 0.5

25°C 1 16
Full range 0.5

25°C 0.75 45
Full range 0.5

25°C 0.5 3
Full range 0.25

TLE2061AM
TLE2061BM

MIN TYP MAX

–1.6

–1.6

–2

to

to

4

6

to

4

UNIT

V

V

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

17

TLE206x, TLE206xA, TLE206xB, TLE206xY

†

CMRR

Common-mode rejection ratio

IC ICR

,

dB

k

SVR

Su ly-voltage rejection ratio (∆V

CC±

/∆VIO)

dB

ICCSupply current

A

V

O

No load

SR

Slew rate at unity gain (see Figure 1)

R

10 kΩ

C

100 pF

3.4

V/µs

VnEquivalent input noise voltage (see Figure 2)

V/√H

V

Peak-to-peak equivalent input noise voltage

f

1.1µV

THD

Total harmonic distortion

VD

,,

0.025%

B1Unity-gain bandwidth (see Figure 3)

MH

tsSettling time

s

φmPhase margin at unity gain (see Figure 3)

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE
µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TLE2061M electrical characteristics at specified free-air temperature, V
otherwise noted) (continued)

PARAMETER TEST CONDITIONS

r

i

c
z

∆I

†

Full range is –55°C to 125°C.

Input resistance 25°C 10
Input capacitance 25°C 4 pF

i

Open-loop output impedance IO = 0 25°C 280 Ω

o

V

= V

min,

RS = 50 Ω
V

= ±5 V to ±15 V,

pp

-

pp

Supply-current change over operating

CC

temperature range

CC±

RS = 50 Ω

= 0,

TLE2061M operating characteristics at specified free-air temperature, V

PARAMETER TEST CONDITIONS

,

=

L
f = 10 Hz, RS = 20 Ω 59
f = 1 kHz, RS = 20 Ω 43

= 0.1 Hz to 10 Hz

A

= 2, f = 10 kHz,

V

= 2 V, RL = 10 kΩ

O(PP)

RL = 10 kΩ,C
RL = 600 Ω,C

0.1% 5

0.01% 10

RL = 10 kΩ,C
RL = 600 Ω,C

N(PP)

I

n

B

OM

p

p

Equivalent input noise current f = 1 kHz 1

Maximum output-swing bandwidth AVD = 1, RL = 10 kΩ 140 kHz

p

T

A

25°C 65 82

Full range 60

25°C 75 93

Full range 65

25°C 280 325

Full range 350
Full range 39 µA

CC±

MIN TYP MAX

p

=

L

= 100 pF 1.8

L

= 100 pF 1.3

L

= 100 pF 58°

L

= 100 pF 75°

L

= ±5 V (unless

CC±

TLE2061M
TLE2061AM
TLE2061BM

MIN TYP MAX

12

= ±5 V, TA = 25°C

TLE2061M

TLE2061AM
TLE2061BM

UNIT

Ω

µ

UNIT

n

fA/√Hz

µ

z

z

18

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

TLE206x, TLE206xA, TLE206xB, TLE206xY

†

T

A

TLE2061M

VIOInput offset voltage

TLE2061AM

mV

TLE2061BM

IIOInput offset current

IIBInput bias current

V

Common-mode input voltage range

R

kΩ

V

Maximum ositive eak out ut voltage

V

R

600 Ω

R

kΩ

V

Maximum negative eak out ut voltage

V

R

600 Ω

,

V

O

±10 V,

,

A

Large signal differential voltage

V

O

V,

V/mV

,

V

O

V,

,

CMRR

Common-mode rejection ratio

V

IC

V

ICR

min,

dB

k

ygj

CC±

,

dB

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE

µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TLE2061M electrical characteristics at specified free-air temperature, V

= ±15 V (unless

CC±

otherwise noted)

TLE2061M ,TLE2061AM

PARAMETER TEST CONDITIONS

p

α

r

i

c
z

†

Full range is –55°C to 125°C.

NOTE 4: Typical values are based on the input offset voltage shift observed through 168 hours of operating life test at TA = 150°C extrapolated

Temperature coefficient of input offset

VIO

voltage
Input offset voltage long-term drift

(see Note 4)

p

p

ICR

Maximum positive peak output voltage

OM+

swing

Maximum negative peak output voltage

OM–

swing

Large-signal differential voltage V

VD

amplification

Input resistance 25°C
Input capacitance 25°C 4 pF

i

Open-loop output impedance IO = 0 25°C 280 Ω

o

Supply-voltage rejection ratio V

SVR

(∆V

to TA = 25°C using the Arrhenius equation and assuming an activation energy of 0.96 eV.

CC±

/∆VIO)

p

VIC = 0,
RS = 50 Ω

= 10

L

=

L

= 10

L

=

L

V

= ±10 V

RL = 10 kΩ

= 0 to 8 V

0 to 8

RL = 600 Ω
V

= 0 to – 8 V

0 to 8

RL = 600 Ω

V

= V

RS = 50 Ω

= ±5 V to ±15 V,

RS = 50 Ω

min

T

25°C 0.6 3

Full range 6

25°C 0.5 1.5

Full range 3.6

25°C 0.3 0.5

Full range 1.7
Full range 6 µV/°C

25°C 0.04 µV/mo
25°C 2 pA

Full range 20 nA

25°C 4 pA

Full range 40 nA

25°C –11 to 13 –12 to 16 V

Full range –11 to 13 V

25°C 13 13.7

Full range 12.5

25°C 12.5 13.2

Full range 12

25°C –13 –13.7

Full range –12.5

25°C –12.5 –13

Full range –12

25°C 30 230

Full range 20

25°C 25 100

Full range 7

25°C 3 25

Full range 1

25°C 72 90

Full range 65

25°C 75 93

Full range 65

TLE2061BM

MIN TYP MAX

12

10

UNIT

Ω

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

19

TLE206x, TLE206xA, TLE206xB, TLE206xY

†

T

A

ICCSupply current

A

V

O

load

†

SR

Slew rate at unity gain (see Figure 1)

R

C

100 pF

V/µs

VnEquivalent input noise voltage (see Figure 2)

V/√H

V

Peak-to-peak equivalent input noise voltage

f

25°C

1.1µV

B1Unity-gain bandwidth (see Figure 3)

MH

tsSettling time

s

BOMMaximum output-swing bandwidth

A

R

kΩ

25°C

40

kH

φmPhase margin at unity gain (see Figure 3)

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE
µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TLE2061M electrical characteristics at specified free-air temperature, V
otherwise noted) (continue)

TLE2061M ,TLE2061AM

PARAMETER TEST CONDITIONS

pp

∆I

†

Full range is –55°C to 125°C.

Supply-current change over operating

CC

temperature range

= 0, No

TLE2061M operating characteristics at specified free-air temperature, V

PARAMETER TEST CONDITIONS

= 10 kΩ,

p

N(PP)

I

n

THD Total harmonic distortion

†

Full range is –55°C to 125°C.

Equivalent input noise current f = 1 kHz 25°C

p

p

L

f = 10 Hz, RS = 20 Ω 25°C 70
f = 1 kHz, RS = 20 Ω 25°C 40

p

= 0.1 Hz to 10 Hz

A

= 2, f = 10 kHz,

VD

V

= 2 V, RL = 10 kΩ

O(PP)

RL = 10 kΩ,C
RL = 600 Ω,C

0.1% 25°C 5

0.01% 25°C 10
= 1,

VD
RL = 10 kΩ,C
RL = 600 Ω,C

L

L
L

L
L

L

T

MIN TYP MAX

25°C 290 350

Full range 375
Full range 46 µA

CC±

T

A

p

=

= 100 pF 25°C 2
= 100 pF 25°C 1.5

= 10
= 100 pF 25°C 60°

= 100 pF 25°C 70°

25°C 2 3.4

Full range 1.8

°

25°C 0.025%

= ±15 V (unless

CC±

TLE2061BM

= ±15 V

TLE2061M
TLE2061AM
TLE2061BM

MIN TYP MAX

1.1

UNIT

µ

UNIT

n

fA/√Hz

µ

z

z

z

20

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

TLE206x, TLE206xA, TLE206xB, TLE206xY

PARAMETER

TEST CONDITIONS

UNIT

V

R

Ω

V

Maximum positive peak output voltage swing

V

V

Maximum negative peak output voltage swing

V

k

Suppl

oltage rejection ratio (∆VCC/∆VIO)

7593dB

PARAMETER

TEST CONDITIONS

UNIT

VnEquivalent input noise voltage (see Figure 2)

V/√H

THD

Total harmonic distortion

VD

,,

0.025%

B1Unity-gain bandwidth (see Figure 3)

MH

tsSettling time

s

φmPhase margin at unity gain (see Figure 3)

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE

µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TLE2061Y electrical characteristics at V

V

α

I

IO

I

IB

V

A

VD

r

i

c

i

z

o

CMRR Common-mode rejection ratio RS = 50 Ω,VIC = V

SVR

Input offset voltage 0.6 3 mV

IO

Input offset voltage long-term drift (see Note 4)

VIO

Input offset current
Input bias current 4 pA

Common-mode input voltage range

ICR

p

OM+

OM–

Large-signal differential voltage amplification

Input resistance
Input capacitance 4 pF
Open-loop output impedance IO = 0 280 Ω

pp

y-v

p

p

p

p

= ±15 V, TA = 25°C (unless otherwise noted)

CC±

= 0,

IC

RL = 10 kΩ 13.2 13.7
RL = 600 Ω 12.5 13.2
RL = 10 kΩ –13.2 –13.7
RL = 600 Ω –12.5 –13
VO = ±10 V, RL = 10 kΩ 30 230
VO = 0 to 8 V, RL = 600 Ω
VO = 0 to – 8 V, RL = 600 Ω 3 25

V

= ±5 V to ±15 V,

CC±

RS = 50 Ω

= 50

S

TLE2061Y

MIN TYP MAX

0.04 µV/mo
2 pA

–11

–12

to

10

to

16

12

13

25 100

min 72 90 dB

ICR

V

V/mV

Ω

I

CC

NOTE 4: Typical values are based on the input offset voltage shift observed through 168 hours of operating life test at TA = 150°C extrapolated

TLE2061Y operating characteristics at V

SR Slew rate at unity gain (see Figure 1) RL = 10 kΩ,C

V
I

n

B

Supply current VO = 0, No load 290 350 µA

to TA = 25°C using the Arrhenius equation and assuming an activation energy of 0.96 eV.

= ±15 V, TA = 25°C

CC±

TLE2061Y

MIN TYP MAX

= 100 pF 2.6 3.4 V/µs

L

f = 10 Hz, RS = 20 Ω 70
f = 1 kHz, RS = 20 Ω 40

A

= 2, f = 10 kHz,

V

= 2 V, RL = 10 kΩ

O(PP)

RL = 10 kΩ,C
RL = 600 Ω,C

0.1% 5

0.01% 10

RL = 10 kΩ,C
RL = 600 Ω,C

= 100 pF 2

L

= 100 pF 1.5

L

= 100 pF 60°

L

= 100 pF 70°

L

N(PP)

OM

p

Peak-to-peak equivalent input noise voltage f = 0.1 Hz to 10 Hz 1.1 µV
Equivalent input noise current f = 1 Hz 1.1

Maximum output-swing bandwidth AVD = 1, RL = 10 kΩ 40 kHz

n

fA/√Hz

µ

z

z

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

21

TLE206x, TLE206xA, TLE206xB, TLE206xY

†

TLE2062C

VIOInput offset voltage

TLE2062AC

mV

TLE2062BC

V

0

R

50 Ω

IIOInput offset current

IIBInput bias current

V

ICR

Common-mode in ut voltage range
R

kΩ

V

Maximum positive peak output voltage swing

V

R

100 Ω

R

kΩ

V

Maximum negative peak output voltage swing

V

R

100 Ω

V

± 2.8 V

R

kΩ

AVDLarge-signal differential voltage amplification

V

R

100 Ω

V/mV

V

R

100 Ω

CMRR

Common-mode rejection ratio

V

V

min

R

Ω

dB

k

Suppl

oltage rejection ratio (∆V

/∆VIO)

CC±

dB

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE
µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TLE2062C electrical characteristics at specified free-air temperature, V

= ±5 V (unless

CC±

otherwise noted)

TLE2062C

PARAMETER TEST CONDITIONS

p

,

=

α

VIO

OM+

OM–

r

i

c

i

z

o

SVR

†

Full range is 0°C to 70°C.

NOTE 4: Typical values are based on the input offset voltage shift observed through 168 hours of operating life test at TA = 150°C extrapolated

Temperature coefficient of input offset voltage
Input offset voltage long-term drift (see Note 4) 25°C 0.04 µV/mo

p

p

-

Input resistance 25°C 10
Input capacitance 25°C 4 pF
Open-loop output impedance IO = 0 25°C 560 Ω

pp

y-v

to TA = 25°C using the Arrhenius equation and assuming an activation energy of 0.96 eV.

p

p

p

p

p

p

p

CC±

IC

= 10

L

=

L

= 10

L

=

L

=

O

= 0 to 2 V,

O

= 0 to –2 V,

O

=

IC

ICR

V

= ± 5 V to ± 15 V,

CC±

RS = 50 Ω

,

=

S

= 10

L

=

L

=

L

,

= 50

S

T

A

25°C 1 5

Full range 5.9

25°C 0.9 4

Full range 4.9

25°C 0.7 3
Full range 3.9
Full range 6 µV/°C

25°C 1 pA
Full range 0.8 nA

25°C 3 pA
Full range 2 nA

25°C

Full range

25°C 3.5 3.7
Full range

25°C 2.5 3.1
Full range 2

25°C –3.7 –3.9
Full range –3.3

25°C –2.5 –2.7
Full range –2

25°C 15 80
Full range 2

25°C 0.75 45
Full range 0.5

25°C 0.5 3
Full range 0.25

25°C 65 82
Full range 65

25°C 75 93
Full range 75

TLE2062AC
TLE2062BC

MIN TYP MAX

–1.6

–1.6

3.3

–2

to

to

to

4

4

6

12

UNIT

V

V

Ω

22

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

TLE206x, TLE206xA, TLE206xB, TLE206xY

†

ICCSupply current

A

V

O

No load

∆I

yg g

Full range

26µA

†

SR

Slew rate at unity gain (see Figure 1)

R

C

100 pF

V/µs

VnEquivalent input noise voltage (see Figure 2)

V/√H

THD

Total harmonic distortion

O(PP)

,

L

,

25°C

0.025%

B1Unity-gain bandwidth (see Figure 3)

MH

Settling time

s

φmPhase margin at unity gain (see Figure 3)

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE

µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TLE2062C electrical characteristics at specified free-air temperature, V
otherwise noted) (continued)

PARAMETER TEST CONDITIONS

pp

Supply-current change over operating

CC

temperature range

†

Full range is 0°C to 70°C.

= 0,

TLE2062C operating characteristics at specified free-air temperature, V

PARAMETER TEST CONDITIONS

=

L

= 10 kΩ,

p

V

N(PP)

I

n

B

OM

†

Full range is 0°C to 70°C.

Peak-to-peak equivalent input noise voltage f = 0.1 Hz to 10 Hz 25°C 1.1 µV
Equivalent input noise current f = 1 kHz 25°C 1 fA/√Hz

Maximum output-swing bandwidth AVD = 1, RL = 10 kΩ 25°C 140 kHz

= 10 kΩ,

L

p

f = 10 Hz, RS = 20 Ω 25°C 59 100
f = 1 kHz, RS = 20 Ω 25°C 43 60

V

= 2 V, R

AVD = 2,
RL = 10 kΩ, CL = 100 pF 25°C 1.8
RL = 100 Ω, CL = 100 pF 25°C 1.3

0.1% 25°C 5

0.01% 25°C 10

RL = 10 kΩ, CL = 100 pF 25°C 58°
RL = 100 Ω, CL = 100 pF 25°C 75°

f = 10 kHz

T

A

25°C 560 620

Full range 635

CC±

T

A

25°C 2.2 3.4

Full range 2.1

°

= ±5 V (unless

CC±

TLE2062C
TLE2062AC
TLE2062BC

MIN TYP MAX

= ±5 V

TLE2062C
TLE2062AC
TLE2062BC

MIN TYP MAX

UNIT

UNIT

n

µ

z

z

µ

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

23

TLE206x, TLE206xA, TLE206xB, TLE206xY

†

TLE2062C

VIOInput offset voltage

TLE2062AC

mV

TLE2062BC

V

R

Ω

IIOInput offset current

IIBInput bias current

V

Common-mode input voltage range

R

10 kΩ

V

Maximum positive peak output voltage swing

V

R

600 Ω

R

kΩ

V

Maximum negative peak output voltage swing

V

R

600 Ω

V

± 10 V

R

kΩ

AVDLarge-signal differential voltage amplification

V

R

600 Ω

V/mV

V

0 to –8 V

R

600 Ω

CMRR

Common-mode rejection ratio

V

V

min,R

50 Ω

dB

k

Suppl

oltage rejection ratio (∆V

/∆VIO)

CC±

dB

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE
µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TLE2062C electrical characteristics at specified free-air temperature, V

= ±15 V (unless

CC±

otherwise noted)

TLE2062C

PARAMETER TEST CONDITIONS

p

= 0,

α

r

i

c
z

†

Full range is 0°C to 70°C.

NOTE 4: Typical values are based on the input offset voltage shift observed through 168 hours of operating life test at TA = 150°C extrapolated

Temperature coefficient of input offset voltage

VIO

Input offset voltage long-term drift (see Note 4) 25°C 0.04 µV/mo

p

p

ICR

OM+

OM–

Input resistance 25°C 10
Input capacitance 25°C 4 pF

i

Open-loop output impedance IO = 0 25°C 560 Ω

o

pp

SVR

y-v

to TA = 25°C using the Arrhenius equation and assuming an activation energy of 0.96 eV.

p

p

p

p

p

p

p

CC±

IC

=

L

=

L

= 10

L

=

L

=

O

= 0 to 8 V,

O

=

O

=

IC

ICR

V

= ± 5 V to ± 15 V,

CC±

RS = 50 Ω

,

= 50

S

= 10

L

=

L

,

=

L

=

S

T

A

25°C 0.9 4

Full range 4.9

25°C 0.8 2

Full range 2.9

25°C 0.5 1
Full range 1.9
Full range 6 µV/°C

25°C 2 pA
Full range 1 nA

25°C 4 pA
Full range 3 nA

25°C

Full range

25°C 13.2 13.7
Full range

25°C 12.5 13.2
Full range 12

25°C –13.2 –13.7
Full range –13

25°C –12.5 –13
Full range –12

25°C 30 230
Full range 20

25°C 25 100
Full range 10

25°C 3 25
Full range 1

25°C 72 90
Full range 70

25°C 75 93
Full range 75

TLE2062AC
TLE2062BC

MIN TYP MAX

–11

–12

to

13

–11

to

13

13

to

16

12

UNIT

V

V

Ω

24

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

TLE206x, TLE206xA, TLE206xB, TLE206xY

†

ICCSupply current

A

V

O

No load

∆I

yg g

Full range

36µA

†

SR

Slew rate at unity gain (see Figure 1)

R

C

100 pF

V/µs

VnEquivalent input noise voltage (see Figure 2)

THD

Total harmonic distortion

O(PP)

,

L

,

25°C

0.025%

B1Unity-gain bandwidth (see Figure 3)

MH

Settling time

s

φmPhase margin at unity gain (see Figure 3)

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE

µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TLE2062C electrical characteristics at specified free-air temperature, V
otherwise noted) (continued)

PARAMETER TEST CONDITIONS

pp

Supply-current change over operating

CC

temperature range

†

Full range is 0°C to 70°C.

= 0 V,

TLE2062C operating characteristics at specified free-air temperature, V

PARAMETER TEST CONDITIONS

=

L

= 10 kΩ,

p

V

N(PP)

I

n

B

OM

†

Full range is 0°C to 70°C.

Peak-to-peak equivalent input noise voltage f = 0.1 Hz to 10 Hz 25°C 1.1 µV
Equivalent input noise current f = 1 kHz 25°C 1.1 fA/√Hz

Maximum output-swing bandwidth AVD = 1, RL = 10 kΩ 25°C 40 kHz

= 10 kΩ,

L

p

f = 10 Hz, RS = 20 Ω 25°C 70 100
f = 1 kHz, RS = 20 Ω 25°C 40 60

V

= 2 V, R

AVD = 2,
RL = 10 kΩ, CL = 10 0 pF 25°C 2
RL = 600 Ω, CL = 100 pF 25°C 1.5

0.1% 25°C 5

0.01% 25°C 10

RL = 10 kΩ, CL = 100 pF 25°C 60°
RL = 600 Ω, CL = 100 pF 25°C 70°

f = 10 kHz

T

A

25°C 625 690

Full range 715

CC±

T

A

25°C 2.6 3.4

Full range 2.5

°

= ±15 V (unless

CC±

TLE2062C
TLE2062AC
TLE2062BC

MIN TYP MAX

= ±15 V

TLE2062C
TLE2062AC
TLE2062BC

MIN TYP MAX

UNIT

µ

UNIT

nV/√Hz

z

µ

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

25

TLE206x, TLE206xA, TLE206xB, TLE206xY

†

TLE2062I

VIOInput offset voltage

TLE2062AI

mV

TLE2062BI

V

0

R

50 Ω

IIOInput offset current

IIBInput bias current

V

Common-mode input voltage range

R

kΩ

V

Maximum positive peak output voltage swing

V

R

100 Ω

R

kΩ

V

Maximum negative peak output voltage swing

V

R

100 Ω

V

± 2.8 V

R

kΩ

AVDLarge-signal differential voltage amplification

V

R

100 Ω

V/mV

V

R

100 Ω

CMRR

Common-mode rejection ratio

V

V

min,R

Ω

dB

k

Suppl

oltage rejection ratio (∆V

/∆VIO)

CC±

dB

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE
µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TLE2062I electrical characteristics at specified free-air temperature, V

= ±5 V (unless otherwise

CC±

noted)

TLE2062I

PARAMETER TEST CONDITIONS

p

,

=

α

VIO

ICR

OM+

OM–

r

i

c

i

z

o

SVR

†

Full range is –40°C to 85°C.

NOTE 4: Typical values are based on the input offset voltage shift observed through 168 hours of operating life test at TA = 150°C extrapolated

Temperature coefficient of input offset voltage
Input offset voltage long-term drift (see Note 4) 25°C 0.04 µV/mo

p

p

p

p

p

p

p

Input resistance 25°C 10
Input capacitance 25°C 4 pF
Open-loop output impedance IO = 0 25°C 560 Ω

pp

y-v

to TA = 25°C using the Arrhenius equation and assuming an activation energy of 0.96 eV.

p

p

CC±

IC

= 10

L

=

L

= 10

L

=

L

=

O

= 0 to 2 V,

O

= 0 to –2 V,

O

=

IC

ICR

V

= ± 5 V to ± 15 V,

CC±

RS = 50 Ω

,

=

S

= 10

L

=

L

=

L

= 50

S

T

A

25°C 1 5

Full range 6.3

25°C 0.9 4

Full range 5.3

25°C 0.7 3
Full range 4.3
Full range 6 µV/°C

25°C 1 pA
Full range 2 nA

25°C 3 pA
Full range 4 nA

25°C

Full range

25°C 3.5 3.7
Full range

25°C 2.5 3.1
Full range 2

25°C –3.7 –3.9
Full range –3.1

25°C –2.5 –2.7
Full range –2

25°C 15 80
Full range 2

25°C 0.75 45
Full range 0.5

25°C 0.5 3
Full range 0.25

25°C 65 82
Full range 65

25°C 75 93
Full range 65

TLE2062AI
TLE2062BI

MIN TYP MAX

–1.6

–1.6

3.1

–2

to

to

to

4

4

6

12

UNIT

V

V

Ω

26

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

TLE206x, TLE206xA, TLE206xB, TLE206xY

†

ICCSupply current

A

V

O

No load

∆I

yg g

Full range

54µA

†

SR

Slew rate at unity gain (see Figure 1)

R

C

100 pF

V/µs

VnEquivalent input noise voltage (see Figure 2)

V/√H

THD

Total harmonic distortion

O(PP)

,

L

,

25°C

0.025%

B1Unity-gain bandwidth (see Figure 3)

MH

Settling time

s

φmPhase margin at unity gain (see Figure 3)

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE

µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TLE2062I electrical characteristics at specified free-air temperature, V

CC±

noted) (continued)

PARAMETER TEST CONDITIONS

pp

Supply-current change over operating

CC

temperature range

†

Full range is –40°C to 85°C.

= 0,

T

A

25°C 560 620

Full range 640

TLE2062I operating characteristics at specified free-air temperature, V

PARAMETER TEST CONDITIONS

V

N(PP)

I

n

B

OM

†

Full range is –40°C to 85°C.

Peak-to-peak equivalent input noise voltage f = 0.1 Hz to 10 Hz 25°C 1.1 µV
Equivalent input noise current f = 1 kHz 25°C 1 fA/√Hz

Maximum output-swing bandwidth AVD = 1, RL = 10 kΩ 25°C 140 kHz

= 10 kΩ,

L

p

f = 10 Hz, RS = 20 Ω 25°C 59 100
f = 1 kHz, RS = 20 Ω 25°C 43 60

V

= 2 V, R

AVD = 2,
RL = 10 kΩ, CL = 100 pF 25°C 1.8
RL = 100 Ω, CL = 100 pF 25°C 1.3

0.1% 25°C 5

0.01% 25°C 10

RL = 10 kΩ, CL = 100 pF 25°C 58°
RL = 100 Ω, CL = 100 pF 25°C 75°

f = 10 kHz

=

L

= 10 kΩ,

p

T

A

25°C 2.2 3.4

Full range 1.7

°

= ±5 V (unless otherwise

TLE2062I
TLE2062AI
TLE2062BI

MIN TYP MAX

= ±5 V

CC ±

TLE2062I
TLE2062AI
TLE2062BI

MIN TYP MAX

UNIT

UNIT

n

µ

z

z

µ

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

27

TLE206x, TLE206xA, TLE206xB, TLE206xY

†

TLE2062I

VIOInput offset voltage

TLE2062AI

mV

TLE2062BI

V

0

R

50 Ω

IIOInput offset current

IIBInput bias current

V

Common-mode input voltage range

R

kΩ

V

Maximum positive peak output voltage swing

V

R

600 Ω

R

kΩ

V

Maximum negative peak output voltage swing

V

R

600 Ω

V

± 10 V

R

kΩ

AVDLarge-signal differential voltage amplification

V

R

600 Ω

V/mV

V

R

600 Ω

CMRR

Common-mode rejection ratio

V

V

min,R

Ω

dB

k

Suppl

oltage rejection ratio (∆V

/∆VIO)

CC±

dB

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE
µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TLE2062I electrical characteristics at specified free-air temperature, V

= ±15 V (unless

CC±

otherwise noted)

TLE2062I

PARAMETER TEST CONDITIONS

p

,

=

α

VIO

ICR

OM+

OM–

r

i

c

i

z

o

SVR

†

Full range is –40°C to 85°C.

NOTE 4: Typical values are based on the input offset voltage shift observed through 168 hours of operating life test at TA = 150°C extrapolated

Temperature coefficient of input offset voltage
Input offset voltage long-term drift (see Note 4) 25°C 0.04 µV/mo

p

p

p

p

p

p

p

Input resistance 25°C 10
Input capacitance 25°C 4 pF
Open-loop output impedance IO = 0 25°C 560 Ω

pp

y-v

to TA = 25°C using the Arrhenius equation and assuming an activation energy of 0.96 eV.

p

p

CC±

IC

= 10

L

=

L

= 10

L

=

L

=

O

= 0 to 8 V,

O

= 0 to –8 V,

O

=

IC

ICR

V

= ± 5 V to ± 15 V,

CC±

RS = 50 Ω

,

=

S

= 10

L

=

L

=

L

= 50

S

T

A

25°C 0.9 4

Full range 5.3

25°C 0.8 2

Full range 3.3

25°C 0.5 1
Full range 2.3
Full range 6 µV/°C

25°C 2 pA
Full range 3 nA

25°C 4 pA
Full range 5 nA

25°C

Full range

25°C 13.2 13.7
Full range

25°C 12.5 13.2
Full range 12

25°C –13.2 –13.7
Full range –13

25°C –12.5 –13
Full range –12

25°C 30 230
Full range 20

25°C 25 100
Full range 10

25°C 3 25
Full range 1

25°C 72 90
Full range 65

25°C 75 93
Full range 65

TLE2062AI
TLE2062BI

MIN TYP MAX

–11

–12

to

13

–11

to

13

13

to

16

12

UNIT

V

V

Ω

28

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

TLE206x, TLE206xA, TLE206xB, TLE206xY

†

ICCSupply current

A

V

O

No load

∆I

yg g

Full range

74µA

†

SR

Slew rate at unity gain (see Figure 1)

R

C

100 pF

V/µs

VnEquivalent input noise voltage (see Figure 2)

V/√H

THD

Total harmonic distortion

O(PP)

,

L

,

25°C

0.025%

B1Unity-gain bandwidth (see Figure 3)

MH

Settling time

s

φmPhase margin at unity gain (see Figure 3)

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE

µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TLE2062I electrical characteristics at specified free-air temperature, V
otherwise noted) (continued)

PARAMETER TEST CONDITIONS

pp

Supply-current change over operating

CC

temperature range

†

Full range is –40°C to 85°C.

= 0,

TLE2062I operating characteristics at specified free-air temperature, V

PARAMETER TEST CONDITIONS

=

L

= 10 kΩ,

p

V

N(PP)

I

n

B

OM

†

Full range is –40°C to 85°C.

Peak-to-peak equivalent input noise voltage f = 0.1 Hz to 10 Hz 25°C 1.1 µV
Equivalent input noise current f = 1 kHz 25°C 1.1 fA/√Hz

Maximum output-swing bandwidth AVD = 1, RL = 10 kΩ 25°C 40 kHz

= 10 kΩ,

L

p

f = 10 Hz, RS = 20 Ω 25°C 70 100
f = 1 kHz, RS = 20 Ω 25°C 40 60

V

= 2 V, R

AVD = 2,
RL = 10 kΩ, CL = 100 pF 25°C 2
RL = 600 Ω, CL = 100 pF 25°C 1.5

0.1% 25°C 5

0.01% 25°C 10

RL = 10 kΩ, CL = 100 pF 25°C 60°
RL = 600 Ω, CL = 100 pF 25°C 70°

f = 10 kHz

T

A

25°C 625 690

Full range 720

CC±

T

A

25°C 2.6 3.4

Full range 2.1

°

= ±15 V (unless

CC±

TLE2062I
TLE2062AI
TLE2062BI

MIN TYP MAX

= ±15 V

TLE2062I
TLE2062AI
TLE2062BI

MIN TYP MAX

UNIT

UNIT

n

µ

z

z

µ

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

29

TLE206x, TLE206xA, TLE206xB, TLE206xY

†

TLE2062M

VIOInput offset voltage

TLE2062AM

mV

TLE2062BM

V

R

Ω

IIOInput offset current

IIBInput bias current

V

Common-mode input voltage range

R

kΩ

V

FK and JG

R

600 Ω

V

D and P

R

100 Ω

R

kΩ

V

g

FK and JG

R

600 Ω

V

D and P

R

100 Ω

V

±2.8 V

R

10 kΩ

V

R

600 Ω

FK and JG

A

gg g

V

0 to –2.5 V

R

600 Ω

V/mV

V

R

100 Ω

D and P

V

R

100 Ω

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE
µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TLE2062M electrical characteristics at specified free-air temperature, V

PARAMETER TEST CONDITIONS

p

= 0,

α

†

Full range is –55°C to 125°C.

NOTE 4: Typical values are based on the input offset voltage shift observed through 168 hours of operating life test at TA = 150°C extrapolated

Temperature coefficient of input offset voltage

VIO

Input offset voltage long-term drift (see Note 4) 25°C 0.04 µV/mo

p

p

ICR

Maximum positive peak output

OM+

voltage swing

Maximum negative peak output

OM–

voltage swing

Large-signal differential voltage

VD

amplification

to TA = 25°C using the Arrhenius equation and assuming an activation energy of 0.96 eV.

p

FK and JG
packages

D and P
packages

FK and JG
packages

D and P
packages

FK and JG
packages

D and P
packages

IC

= 10

L

=

L

=

L

= 10

L

=

L

=

L

=

O

= 0 to 2.5 V,

O

=

O

= 0 to 2 V,

O

= 0 to –2 V,

O

,

= 50

S

=

L

=

L

,

=

L

=

L

=

L

T

A

25°C 1 5

Full range 7

25°C 0.9 4

Full range 6

25°C 0.7 3
Full range 5
Full range 6 µV/°C

25°C 1 pA
Full range 15 nA

25°C 3 pA
Full range 30 nA

25°C

Full range

25°C 3.5 3.7
Full range 3

25°C 2.5 3.6
Full range 2

25°C 2.5 3.1
Full range 2

25°C –3.5 –3.9
Full range –3

25°C –2.5 –3.5
Full range –2

25°C –2.5 –2.7
Full range –2

25°C 15 80
Full range 2

25°C 1 65
Full range 0.5

25°C 1 16
Full range 0.5

25°C 0.75 45
Full range 0.5

25°C 0.5 3
Full range 0.25

= ±5 V

CC±

TLE2062M
TLE2062AM
TLE2062BM

MIN TYP MAX

–1.6

to

4

–1.6

to

4

–2

UNIT

to

6

V

V

30

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

TLE206x, TLE206xA, TLE206xB, TLE206xY

†

CMRR

Common-mode rejection ratio

dB

k

Suppl

oltage rejection ratio (∆V

/∆VIO)

dB

ICCSupply current (two amplifiers)

A

V

O

No load

∆I

yg g

Full range

72µA

VnEquivalent input noise voltage (see Figure 2)

V/√H

THD

Total harmonic distortion

O(PP)

,

L

,

0.025%

B1Unity-gain bandwidth (see Figure 3)

MH

Settling time

s

φmPhase margin at unity gain (see Figure 3)

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE

µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TLE2062M electrical characteristics at specified free-air temperature, V

= ±5 V (unless

CC±

otherwise noted)

TLE2062M
TLE2062AM
TLE2062BM

MIN TYP MAX

12

= ±5 V

CC±

TLE2062M
TLE2062AM
TLE2062BM

MIN TYP MAX

UNIT

UNIT

n

r

i

c

i

z

o

SVR

CC

†

Full range is –55°C to 125°C.

Input resistance 25°C 10
Input capacitance 25°C 4 pF
Open-loop output impedance IO = 0 25°C 560 Ω

pp

y-v

pp

Supply-current change over operating
temperature range (two amplifiers)

PARAMETER TEST CONDITIONS

VIC = V
RS = 50 Ω,

CC±

p

VCC± = ±5 V to ±15 V,
RS = 50 Ω

= 0,

ICR

min

T

A

25°C 65 82

Full range 60

25°C 75 93

Full range 65

25°C 560 620

Full range 650

TLE2062M operating characteristics at specified free-air temperature, TA = 25°C, V

PARAMETER TEST CONDITIONS

SR Slew rate at unity gain (see Figure 1) RL = 10 kΩ, CL = 100 pF 3.4 V/µs

f = 10 Hz, RS = 20 Ω 59
f = 1 kHz, RS = 20 Ω 43

V

= 2 V, R

AVD = 2,
RL = 10 kΩ, CL = 100 pF 1.8
RL = 600 Ω, CL = 100 pF 1.3

0.1% 5

0.01% 10

RL = 10 kΩ, CL = 100 pF 58°
RL = 600 Ω, CL = 100 pF 75°

= 10 kΩ,

f = 10 kHz

V

N(PP)

I

n

B

OM

p

Peak-to-peak equivalent input noise voltage f = 0.1 Hz to 10 Hz 1.1 µV
Equivalent input noise current f = 1 kHz 1 fA/√Hz

Maximum output-swing bandwidth AVD = 1, RL = 10 kΩ 140 kHz

Ω

µ

z

z

µ

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

31

TLE206x, TLE206xA, TLE206xB, TLE206xY

†

TLE2062M

VIOInput offset voltage

TLE2062AM

mV

TLE2062BM

V

0

R

50 Ω

IIOInput offset current

IIBInput bias current

V

Common-mode input voltage range

R

kΩ

V

Maximum positive peak output voltage swing

V

R

600 Ω

R

kΩ

V

Maximum negative peak output voltage swing

V

R

600 Ω

V

± 10 V

R

kΩ

AVDLarge-signal differential voltage amplification

V

R

600 Ω

V/mV

V

R

600 Ω

CMRR

Common-mode rejection ratio

V

V

min

R

Ω

dB

k

Suppl

oltage rejection ratio (∆V

/∆VIO)

CC±

dB

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE
µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TLE2062M electrical characteristics at specified free-air temperature, V

= ±15 V (unless

CC±

otherwise noted)

TLE2062M

PARAMETER TEST CONDITIONS

p

,

=

α

r

i

c

i

z

o

SVR

†

Full range is –55°C to 125°C.

NOTE 4: Typical values are based on the input offset voltage shift observed through 168 hours of operating life test at TA = 150°C extrapolated

Temperature coefficient of input offset voltage

VIO

Input offset voltage long-term drift (see Note 4) 25°C 0.04 µV/mo

p

p

ICR

OM+

OM–

Input resistance 25°C 10
Input capacitance 25°C 4 pF
Open-loop output impedance IO = 0 25°C 560 Ω

pp

y-v

to TA = 25°C using the Arrhenius equation and assuming an activation energy of 0.96 eV.

p

p

p

p

p

p

p

CC±

IC

= 10

L

=

L

= 10

L

=

L

=

O

= 0 to 8 V,

O

= 0 to –8 V,

O

=

IC

ICR

V

= ± 5 V to ± 15 V,

CC±

RS = 50 Ω

,

=

S

= 10

L

=

L

=

L

,

= 50

S

T

A

25°C 0.9 4

Full range 6

25°C 0.8 2

Full range 4

25°C 0.5 1
Full range 3
Full range 6 µV/°C

25°C 2 pA
Full range 20 nA

25°C 4 pA
Full range 40 nA

25°C

Full range

25°C 13 13.7
Full range

25°C 12.5 13.2
Full range 11

25°C –13 –13.7
Full range –12.5

25°C –12.5 –13
Full range –11

25°C 30 230
Full range 20

25°C 25 100
Full range 7

25°C 3 25
Full range 1

25°C 72 90
Full range 65

25°C 75 93
Full range 65

TLE2062AM
TLE2062BM

MIN TYP MAX

–11

–12

to

13

–11

to

13

12.5

to

16

12

UNIT

V

V

Ω

32

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

TLE206x, TLE206xA, TLE206xB, TLE206xY

†

ICCSupply current

A

V

O

No load

∆I

yg g

Full range

97µA

†

SR

Slew rate at unity gain (see Figure 1)

R

C

100 pF

V/µs

VnEquivalent input noise voltage (see Figure 2)

V/√H

B1Unity-gain bandwidth (see Figure 3)

MH

Settling time

s

BOMMaximum output-swing bandwidth

A

R

kΩ

25°C

40

kH

φmPhase margin at unity gain (see Figure 3)

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE

µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TLE2062M electrical characteristics at specified free-air temperature, V
otherwise noted)

PARAMETER TEST CONDITIONS

pp

Supply-current change over operating

CC

temperature range

†

Full range is –55°C to 125°C.

= 0,

TLE2062M operating characteristics at specified free-air temperature, V

PARAMETER TEST CONDITIONS

=

L

= 10

L

p

p

V

N(PP)

I

n

THD Total harmonic distortion

†

Full range is –55°C to 125°C.

Peak-to-peak equivalent input noise voltage f = 0.1 Hz to 10 Hz 25°C 1.1 µV
Equivalent input noise current f = 1 kHz 25°C 1.1 fA/√Hz

p

= 10 kΩ,

L

f = 10 Hz, RS = 20 Ω 25°C 70
f = 1 kHz, RS = 20 Ω 25°C 40

V

= 2 V,

O(PP)

AVD = 2,
RL = 10 kΩ, CL = 100 pF 25°C
RL = 600 Ω, CL = 100 pF 25°C 1.5

0.1% 25°C 5

0.01% 25°C 10
= 1,

VD

RL = 10 kΩ, CL = 100 pF 25°C 60°
RL = 600 Ω, CL = 100 pF 25°C 70°

RL = 10 kΩ,
f = 10 kHz

T

A

25°C 625 690

Full range 730

CC±

T

A

25°C 2 3.4

Full range 1.8

25°C 0.025%

°

= ±15 V (unless

CC±

TLE2062M
TLE2062AM
TLE2062BM

MIN TYP MAX

= ±15 V

TLE2062M
TLE2062AM
TLE2062BM

MIN TYP MAX

2

UNIT

UNIT

n

µ

z

z

µ

z

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

33

TLE206x, TLE206xA, TLE206xB, TLE206xY

PARAMETER

TEST CONDITIONS

UNIT

V

R

Ω

11to12

ICR

gg

V

Maximum positive peak output voltage swing

V

V

Maximum negative peak output voltage swing

V

k

Suppl

oltage rejection ratio (∆VCC/∆VIO)

CC±

,

7593dB

PARAMETER

TEST CONDITIONS

UNIT

VnEquivalent input noise voltage (see Figure 2)

V/√H

B1Unity-gain bandwidth (see Figure 3)

MH

Settling time

s

φmPhase margin at unity gain (see Figure 3)

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE
µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TLE2062Y electrical characteristics at V

V

IO

α

VIO

I

IO

I

IB

V

ICR

OM+

OM–

A

VD

r

i

c

i

z

o

CMRR Common-mode rejection ratio VIC = V

SVR

I

CC

NOTE 4: Typical values are based on the input offset voltage shift observed through 168 hours of operating life test at TA = 150°C extrapolated

Input offset voltage 0.9 4 mV
Input offset voltage long-term drift (see Note 4)
Input offset current
Input bias current 4 pA

Common-mode input voltage range

p

p

Large-signal differential voltage amplification

Input resistance 10
Input capacitance 4 pF
Open-loop output impedance IO = 0 560 Ω

pp

y-v

Supply current VO = 0, No load 625 690 µA

to TA = 25°C using the Arrhenius equation and assuming an activation energy of 0.96 eV.

p

p

p

= ±15 V, TA = 25°C (unless otherwise noted)

CC±

TLE2062Y

MIN TYP MAX

= 0,

IC

RL = 10 kΩ 13.2 13.7
RL = 600 Ω 12.5 13.2
RL = 10 kΩ –13.2 –13.7
RL = 600 Ω –12.5 –13
VO = ±10 V, RL = 10 kΩ 30 230
VO = 0 to 8 V,
VO = 0 to –8 V, RL = 600 Ω 3 25

min, RS = 50 Ω 72 90 dB

ICR

V

= ±5 V to ±15 V,

RS = 50 Ω

= 50

S

–11 –12

13 16

RL = 600 Ω 25 100

0.04 µV/mo
2 pA

to

12

V

V/mV

Ω

TLE2062Y operating characteristics at V

SR Slew rate at unity gain (see Figure 1) RL = 10 kΩ, CL = 100 pF 2.6 3.4 4 V/µs

p

V

N(PP)

I

n

THD Total harmonic distortion

B

OM

Peak-to-peak equivalent input noise voltage f = 0.1 Hz to 10 Hz 1.1 µV
Equivalent input noise current f = 1 Hz 1.1 fA/√Hz

Maximum output-swing bandwidth AVD = 1, RL = 10 kΩ 40 kHz

= ±15 V, TA = 25°C

CC±

f = 10 Hz, RS = 20 Ω 70
f = 1 kHz, RS = 20 Ω 40

V

= 2 V,

O(PP)

AVD = 2,
RL = 10 kΩ, CL = 100 pF 2
RL = 600 Ω, CL = 100 pF 1.5

0.1% 5

0.01% 10

RL = 10 kΩ, CL = 100 pF 60°
RL = 600 Ω, CL = 100 pF 70°

RL = 10 kΩ,
f = 10 kHz

TLE2062Y

MIN TYP MAX

n

0.025%

z

z

µ

34

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

TLE206x, TLE206xA, TLE206xB, TLE206xY

†

TLE2064C

VIOInput offset voltage

TLE2064AC

mV

TLE2064BC

V

0

R

50 Ω

IIOInput offset current

IIBInput bias current

V

Common-mode input voltage range

R

kΩ

V

Maximum positive peak output voltage swing

V

R

100 Ω

R

10 kΩ

V

Maximum negative peak output voltage swing

V

R

100 Ω

V

R

kΩ

AVDLarge-signal differential voltage amplification

V

R

100 Ω

V/mV

V

R

100 Ω

CMRR

Common-mode rejection ratio

V

V

min, R

50 Ω

dB

k

Suppl

oltage rejection ratio (∆V

/∆VIO)

CC±

dB

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE

µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TLE2064C electrical characteristics at specified free-air temperature, V

= ±5 V (unless

CC±

otherwise noted)

TLE2064C

PARAMETER TEST CONDITIONS

p

,

=

α

r

i

c

i

z

o

SVR

†

Full range is 0°C to 70°C.

NOTE 4: Typical values are based on the input offset voltage shift observed through 168 hours of operating life test at TA = 150°C extrapolated

Temperature coefficient of input offset voltage

VIO

Input offset voltage long-term drift (see Note 4) Full range 0.04 µV/mo

p

p

ICR

OM+

OM–

Input resistance 25°C 10
Input capacitance 25°C 4 pF
Open-loop output impedance IO = 0 25°C 560 Ω

pp

y-v

to TA = 25°C using the Arrhenius equation and assuming an activation energy of 0.96 eV.

p

p

p

p

p

p

p

CC±

IC

= 10

L

=

L

=

L

=

L

= ±2.8 V,

O

= 0 to 2 V,

O

= 0 to –2 V,

O

=

IC

ICR

V

= ±5 V to ±15 V,

CC±

RS = 50 Ω

=

S

= 10

L

=

L

=

L

=

S

T

A

25°C 1.2 7

Full range 7.9

25°C 1.2 6

Full range 6.9

25°C 0.8 3.5

Full range 4.4

25°C 6 µV/°C

25°C 1 pA

Full range 0.8 nA

25°C 3 pA

Full range 2 nA

25°C

Full range

25°C 3.5 3.7

Full range 3.3

25°C 2.5 3.1

Full range 2

25°C –3.7 –3.9

Full range –3.3

25°C –2.5 –2.7

Full range –2

25°C 15 80

Full range 2

25°C 0.75 45

Full range 0.5

25°C 0.5 3

Full range 0.15

25°C 65 82

Full range 65

25°C 75 93

Full range 75

TLE2064AC
TLE2064BC

MIN TYP MAX

–1.6

–1.6

–2

to

to

4

to

4

6

12

UNIT

V

V

Ω

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

35

TLE206x, TLE206xA, TLE206xB, TLE206xY

†

ICCSupply current (four amplifiers)

mA

V

O

No load

∆I

yg g

Full range

52µA

†

SR

Slew rate at unity gain (see Figure 1)

R

C

100 pF

V/µs

VnEquivalent input noise voltage (see Figure 2)

25°C

V/√H

THD

Total harmonic distortion

VD

,

,

25°C

0.025%

B1Unity-gain bandwidth (see Figure 3)

25°C

MH

tsSettling time

25°C

s

φ

Phase margin at unity gain (see Figure 3)

25°C

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE
µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TLE2064C electrical characteristics at specified free-air temperature, V

= ±5 V (unless

CC±

otherwise noted) (continued)

TLE2064C

PARAMETER TEST CONDITIONS

pp

CC

VO1/VO2Crosstalk attenuation AVD = 1000, f = 1 kHz 25°C 120 dB

†

Full range is 0°C to 70°C.

Supply-current change over operating
temperature range (four amplifiers)

p

= 0,

T

A

25°C 1.12 1.3

Full range 1.3

TLE2064C operating characteristics at specified free-air temperature, V

V

N(PP)

I

n

B

OM

m

†

Full range is 0°C to 70°C.

Peak-to-peak equivalent input noise voltage f = 0.1 Hz to 10 Hz 25°C 1.1 µV
Equivalent input noise current f = 1 kHz 25°C 1 fA/√Hz

Maximum output-swing bandwidth AVD = 1, RL = 10 kΩ 25°C 140 kHz

PARAMETER TEST CONDITIONS

= 10 kΩ,

L

p

f = 10 Hz, RS = 20 Ω
f = 1 kHz, RS = 20 Ω

A

= 2, f = 10 kHz,

V

= 2 V,

O(PP)

RL = 10 kΩ, CL = 100 pF
RL = 100 Ω, CL = 100 pF

ε = 0.1%
ε = 0.01%

RL = 10 kΩ, CL = 100 pF
RL = 100 Ω, CL = 100 pF

=

L

RL = 10 kΩ

p

T

A

25°C 2.2 3.4

Full range 2.1

°

°

°

°

°

TLE2064AC
TLE2064BC

MIN TYP MAX

= ±5 V

CC±

TLE2064C
TLE2064AC
TLE2064BC

MIN TYP MAX

59 100
43 60

1.8

1.3
5

10

58°
75°

n

UNIT

UNIT

z

z

µ

36

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

TLE206x, TLE206xA, TLE206xB, TLE206xY

†

TLE2064C

VIOInput offset voltage

TLE2064AC

mV

TLE2064BC

V

R

Ω

IIOInput offset current

IIBInput bias current

V

Common-mode input voltage range

R

kΩ

V

Maximum positive peak output voltage swing

V

R

600 Ω

R

10 kΩ

V

Maximum negative peak output voltage swing

V

R

600 Ω

V

±10 V

R

kΩ

AVDLarge-signal differential voltage amplification

V

R

600 Ω

V/mV

V

R

600 Ω

CMRR

Common-mode rejection ratio

V

V

min

R

Ω

dB

k

Suppl

oltage rejection ratio (∆V

/∆VIO)

CC±

,

dB

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE

µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TLE2064C electrical characteristics at specified free-air temperature, V

= ±15 V (unless

CC±

otherwise noted)

TLE2064C

PARAMETER TEST CONDITIONS

p

= 0,

α

r

i

c

i

z

o

SVR

†

Full range is 0°C to 70°C.

NOTE 4: Typical values are based on the input offset voltage shift observed through 168 hours of operating life test at TA = 150°C extrapolated

Temperature coefficient of input offset voltage

VIO

Input offset voltage long-term drift (see Note 4) Full range 0.04 µV/mo

p

p

ICR

OM+

OM–

Input resistance 25°C 10
Input capacitance 25°C 4 pF
Open-loop output impedance IO = 0 25°C 560 Ω

pp

y-v

to TA = 25°C using the Arrhenius equation and assuming an activation energy of 0.96 eV.

p

p

p

p

p

p

p

CC±

IC

= 10

L

=

L

=

L

=

L

=

O

= 0 to 8 V,

O

= 0 to –8 V,

O

=

IC

ICR

V

= ±5 V to ±15 V,

RS = 50 Ω

,

= 50

S

= 10

L

=

L

=

L

,

= 50

S

T

A

25°C 0.9 6

Full range 6.9

25°C 0.9 4

Full range 4.9

25°C 0.7 2

Full range 4

25°C 6 µV/°C

25°C 2 pA

Full range 1 nA

25°C 4 pA

Full range 3 nA

25°C

Full range

25°C 13.2 13.7

Full range 13

25°C 12.5 13.2

Full range 12

25°C –13.2 –13.7

Full range –13

25°C –12.5 –13

Full range –12

25°C 30 230

Full range 20

25°C 25 100

Full range 10

25°C 3 25

Full range 1

25°C 72 90

Full range 70

25°C 75 93

Full range 75

TLE2064AC
TLE2064BC

MIN TYP MAX

–11

–12

to

13

–11

13

to

16

to

12

UNIT

V

V

Ω

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

37

TLE206x, TLE206xA, TLE206xB, TLE206xY

†

ICCSupply current (four amplifiers)

mA

V

No load

∆I

yg g

Full range

72µA

†

SR

Slew rate at unity gain (see Figure 1)

R

C

100 pF

V/µs

VnEquivalent input noise voltage (see Figure 2)

25°C

V/√H

THD

Total harmonic distortion

VD

,

,

25°C

0.025%

B1Unity-gain bandwidth (see Figure 3)

25°C

MH

tsSettling time

25°C

s

φ

Phase margin at unity gain (see Figure 3)

25°C

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE
µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TLE2064C electrical characteristics at specified free-air temperature, V

= ±15 V (unless

CC±

otherwise noted) (continued)

TLE2064C

PARAMETER TEST CONDITIONS

pp

CC

VO1/VO2Crosstalk attenuation AVD = 1000, f = 1 kHz 25°C 120 dB

†

Full range is 0°C to 70°C.

Supply-current change over operating
temperature range (four amplifiers)

p

= 0,

O

T

A

25°C 1.25 1.4

Full range 1.5

TLE2064C operating characteristics at specified free-air temperature, V

V

N(PP)

I

n

B

OM

m

†

Full range is 0°C to 70°C.

Peak-to-peak equivalent input noise voltage f = 0.1 Hz to 10 Hz 25°C 1.1 µV
Equivalent input noise current f = 1 kHz 25°C 1 fA/√Hz

Maximum output-swing bandwidth AVD = 1, RL = 10 kΩ 25°C 40 kHz

PARAMETER TEST CONDITIONS

= 10 kΩ,

L

p

f = 10 Hz, RS = 20 Ω
f = 1 kHz, RS = 20 Ω

A

= 2, f = 10 kHz,

V

= 2 V,

O(PP)

RL = 10 kΩ, CL = 100 pF
RL = 600 Ω, CL = 100 pF

ε = 0.1%
ε = 0.01%

RL = 10 kΩ, CL = 100 pF
RL = 600 Ω, CL = 100 pF

=

L

RL = 10 kΩ

p

T

A

25°C 2.6 3.4

Full range 2.5

°

°

°

°

°

TLE2064AC
TLE2064BC

MIN TYP MAX

= ±15 V

CC±

TLE2064C
TLE2064AC
TLE2064BC

MIN TYP MAX

1.5

50°
70°

70 100
40 60

2

5

10

n

UNIT

UNIT

z

z

µ

38

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

TLE206x, TLE206xA, TLE206xB, TLE206xY

†

TLE2064I

VIOInput offset voltage

TLE2064AI

mV

TLE2064BI

V

0

R

50 Ω

IIOInput offset current

IIBInput bias current

V

Common-mode input voltage range

R

kΩ

V

Maximum positive peak output voltage swing

V

R

100 Ω

R

10 kΩ

V

Maximum negative peak output voltage swing

V

R

100 Ω

V

R

kΩ

AVDLarge-signal differential voltage amplification

V

R

100 Ω

V/mV

V

R

100 Ω

CMRR

Common-mode rejection ratio

V

V

min

R

50 Ω

dB

k

Suppl

oltage rejection ratio (∆V

/∆VIO)

CC±

dB

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE

µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TLE2064I electrical characteristics at specified free-air temperature, V

= ±5 V (unless otherwise

CC±

noted)

TLE2064I

PARAMETER TEST CONDITIONS

p

,

=

α

VIO

ICR

OM+

OM–

r

i

c

i

z

o

SVR

†

Full range is –40°C to 85°C.

NOTE 4: Typical values are based on the input offset voltage shift observed through 168 hours of operating life test at TA = 150°C extrapolated

Temperature coefficient of input offset voltage
Input offset voltage long-term drift (see Note 4) Full range 0.04 µV/mo

p

p

p

p

p

Input resistance 25°C 10
Input capacitance 25°C 4 pF
Open-loop output impedance IO = 0 25°C 560 Ω

pp

y-v

to TA = 25°C using the Arrhenius equation and assuming an activation energy of 0.96 eV.

p

p

p

p

CC±

IC

= 10

L

=

L

=

L

=

L

= ±2.8 V,

O

= 0 to 2 V,

O

= 0 to –2 V,

O

=

IC

ICR

V

= ±5 V to ±15 V,

CC±

RS = 50 Ω

=

S

= 10

L

=

L

=

L

,

=

S

T

A

25°C 1.2 7

Full range 8.3

25°C 1.2 6

Full range 7.3

25°C 0.8 3.5

Full range 4.8

25°C 6 µV/°C

25°C 1 pA

Full range 2 nA

25°C 3 pA

Full range 4 nA

25°C

Full range

25°C 3.5 3.7

Full range 3.1

25°C 2.5 3.1

Full range 2

25°C –3.7 –3.9

Full range –3.1

25°C –2.5 –2.7

Full range –2

25°C 15 80

Full range 2

25°C 0.75 45

Full range 0.5

25°C 0.5 3

Full range 0.15

25°C 65 82

Full range 65

25°C 75 93

Full range 65

TLE2064AI
TLE2064BI

MIN TYP MAX

–1.6

–1.6

–2

to

to

4

to

4

6

12

UNIT

V

V

Ω

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

39

TLE206x, TLE206xA, TLE206xB, TLE206xY

†

ICCSupply current (four amplifiers)

mA

V

No load

∆I

yg g

Full range

108µA

†

SR

Slew rate at unity gain (see Figure 1)

R

C

100 pF

V/µs

VnEquivalent input noise voltage (see Figure 2)

25°C

V/√H

B1Unity-gain bandwidth (see Figure 3)

25°C

MH

tsSettling time

25°C

s

φ

Phase margin at unity gain (see Figure 3)

25°C

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE
µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TLE2064I electrical characteristics at specified free-air temperature, V

= ±5 V (unless otherwise

CC±

noted) (continued)

TLE2064I

PARAMETER TEST CONDITIONS

pp

CC

VO1/VO2Crosstalk attenuation AVD = 1000, f = 1 kHz 25°C 120 dB

†

Full range is –40°C to 85°C.

Supply-current change over operating
temperature range (four amplifiers)

p

= 0,

O

TLE2064I operating characteristics at specified free-air temperature, V

T

A

25°C 1.12 1.3

Full range 1.3

CC±

TLE2064AI
TLE2064BI

MIN TYP MAX

= ±5 V (unless otherwise

noted)

TLE2064I

PARAMETER TEST CONDITIONS

p

V

N(PP)

I

n

THD Total harmonic distortion

B

OM

m

†

Full range is – 40°C to 85°C.

Peak-to-peak equivalent input noise voltage f = 0.1 Hz to 10 Hz 25°C 1.1 µV
Equivalent input noise current f = 1 kHz 25°C 1 fA/√Hz

Maximum output-swing bandwidth AVD = 1, RL = 10 kΩ 25°C 140 kHz

= 10 kΩ,

L

f = 10 Hz, RS = 20 Ω
f = 1 kHz, f = 1 kHz,

A

= 2,

VD

V

= 2 V,

O(PP)

RL = 10 kΩ, CL = 100 pF
RL = 100 Ω, CL = 100 pF

ε = 0.1%
ε = 0.01%

RL = 10 kΩ, CL = 100 pF
RL = 100 Ω, CL = 100 pF

f = 10 kHz,
RL = 10 kΩ

p

=

L

T

A

25°C 2.2 3.4

Full range 1.7

°

25°C 0.025%

°

°

°

TLE2064AI
TLE2064BI

MIN TYP MAX

59 100
43 60

1.8

1.3
5

10

58°
75°

n

UNIT

UNIT

z

z

µ

40

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

TLE206x, TLE206xA, TLE206xB, TLE206xY

†

TLE2064I

VIOInput offset voltage

TLE2064AI

mV

TLE2064BI

V

0

R

50 Ω

IIOInput offset current

IIBInput bias current

V

Common-mode input voltage range

R

kΩ

V

Maximum positive peak output voltage swing

V

R

600 Ω

R

10 kΩ

V

Maximum negative peak output voltage swing

V

R

600 Ω

V

±10 V

R

kΩ

AVDLarge-signal differential voltage amplification

V

R

600 Ω

V/mV

V

R

600 Ω

CMRR

Common-mode rejection ratio

V

V

min

R

50 Ω

dB

k

Suppl

oltage rejection ratio (∆V

/∆VIO)

CC±

dB

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE

µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TLE2064I electrical characteristics at specified free-air temperature, V

= ±15 V (unless

CC±

otherwise noted)

TLE2064I

PARAMETER TEST CONDITIONS

p

,

=

α

r

i

c

i

z

o

SVR

†

Full range is – 40°C to 85°C.

NOTE 4: Typical values are based on the input offset voltage shift observed through 168 hours of operating life test at TA = 150°C extrapolated

Temperature coefficient of input offset voltage

VIO

Input offset voltage long-term drift (see Note 4) Full range 0.04 µV/mo

p

p

ICR

OM+

OM–

Input resistance 25°C 10
Input capacitance 25°C 4 pF
Open-loop output impedance IO = 0 25°C 560 Ω

pp

y-v

to TA = 25°C using the Arrhenius equation and assuming an activation energy of 0.96 eV.

p

p

p

p

p

p

p

CC±

IC

= 10

L

=

L

=

L

=

L

=

O

= 0 to 8 V,

O

= 0 to –8 V,

O

=

IC

ICR

V

= ±5 V to ±15 V,

CC±

RS = 50 Ω

,

=

S

= 10

L

=

L

=

L

,

=

S

T

A

25°C 0.9 6

Full range 7.3

25°C 0.9 4

Full range 5.3

25°C 0.7 2

Full range 3.3

25°C 6 µV/°C

25°C 2 pA

Full range 3 nA

25°C 4 pA

Full range 5 nA

25°C

Full range

25°C 13.2 13.7

Full range 13

25°C 12.5 13.2

Full range 12

25°C –13.2 –13.7

Full range –13

25°C –12.5 –13

Full range –12

25°C 30 230

Full range 20

25°C 25 100

Full range 10

25°C 3 25

Full range 1

25°C 72 90

Full range 65

25°C 75 93

Full range 65

TLE2064AI
TLE2064BI

MIN TYP MAX

–11

–12

to

13

–11

13

to

16

to

12

UNIT

V

V

Ω

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

41

TLE206x, TLE206xA, TLE206xB, TLE206xY

†

ICCSupply current (four amplifiers)

mA

V

No load

∆I

yg g

Full range

148µA

†

SR

Slew rate at unity gain (see Figure 1)

R

C

100 pF

V/µs

VnEquivalent input noise voltage (see Figure 2)

25°C

V/√H

THD

Total harmonic distortion

VD

,

25°C

0.025%

B1Unity-gain bandwidth (see Figure 3)

25°C

MH

tsSettling time

25°C

s

φ

Phase margin at unity gain (see Figure 3)

25°C

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE
µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TLE2064I electrical characteristics at specified free-air temperature, V

= ±15 V (unless

CC±

otherwise noted) (continued)

TLE2064I

PARAMETER TEST CONDITIONS

pp

CC

VO1/VO2Crosstalk attenuation AVD = 1000, f = 1 kHz 25°C 120 dB

†

Full range is – 40°C to 85°C.

Supply-current change over operating
temperature range (four amplifiers)

p

= 0,

O

TLE2064I operating characteristics at specified free-air temperature, V

PARAMETER TEST CONDITIONS

=

L

O(PP)

p

= 2 V,

V

N(PP)

I

n

B

OM

m

†

Full range is – 40°C to 85°C.

Peak-to-peak equivalent input noise voltage f = 0.1 Hz to 10 Hz 25°C 1.1 µV
Equivalent input noise current f = 1 kHz 25°C 1.1 fA/√Hz

Maximum output-swing bandwidth AVD = 1, RL = 10 kΩ 25°C 40 kHz

= 10 kΩ,

L

p

f = 10 Hz, RS = 20 Ω,
f = 1 kHz, RS = 20 Ω

A

= 2, f = 10 kHz,

RL = 10 kΩ,V
RL = 10 kΩ, CL = 100 pF
RL = 600 Ω, CL = 100 pF

ε = 0.1%
ε = 0.01%

RL = 10 kΩ, CL = 100 pF
RL = 600 Ω, CL = 100 pF

T

A

25°C 1.25 1.4

Full range 1.5

CC

T

A

25°C 2.6 3.4

Full range 2.1

°

°

°

°

°

TLE2064AI
TLE2064BI

MIN TYP MAX

= ±15 V

±

TLE2064I
TLE2064AI
TLE2064BI

MIN TYP MAX

70 100
40 60

2

1.5
5

10

60°
70°

n

UNIT

UNIT

z

z

µ

42

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

TLE206x, TLE206xA, TLE206xB, TLE206xY

†

TLE2064M

VIOInput offset voltage

TLE2064AM

mV

TLE2064BM

V

R

Ω

IIOInput offset current

IIBInput bias current

V

Common-mode input voltage range

R

kΩ

V

R

600 Ω

V

R

100 Ω

R

kΩ

V

g

R

600 Ω

V

R

100 Ω

V

R

kΩ

A

gg g

V

R

600 Ω

V/mV

V

0 to –2.5 V

R

600 Ω

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE

µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TLE2064M electrical characteristics at specified free-air temperature, V

= ±5 V (unless

CC±

otherwise noted)

TLE2064M

PARAMETER TEST CONDITIONS

p

= 0,

α

†

Full range is – 55°C to 125°C.

NOTE 4: Typical values are based on the input offset voltage shift observed through 168 hours of operating life test at TA = 150°C extrapolated

Temperature coefficient of input offset voltage

VIO

Input offset voltage long-term drift (see Note 4) Full range 0.04 µV/mo

p

p

ICR

Maximum positive peak output FK and J

OM+

voltage swing packages

Maximum negative peak output FK and J

OM–

voltage swing packages

Large-signal differential voltage

VD

amplification

to TA = 25°C using the Arrhenius equation and assuming an activation energy of 0.96 eV.

p

D and N
packages

D and N
packages

FK and J
packages

IC

= 10

L

=

L

=

L

= 10

L

=

L

=

L

= ±2.8 V,

O

= 0 to 2.5 V,

O

=

O

= 50

S

= 10

L

=

L

,

=

L

T

A

25°C 1.2 7

Full range 9

25°C 1.2 6

Full range 8

25°C 0.8 3.5

Full range 5.5

25°C 6 µV/°C

25°C 1 pA

Full range 15 nA

25°C 3 pA

Full range 30 nA

25°C

Full range

25°C 3.5 3.7

Full range 3

25°C 2.5 3.6

Full range 2

25°C 2.5 3.1

Full range 2

25°C –3.5 –3.9

Full range –3

25°C –2.5 –3.5

Full range –2

25°C –2.5 –2.7

Full range –2

25°C 15 80

Full range 2

25°C 1 65

Full range 0.5

25°C 1 16

Full range 0.5

TLE2064AM
TLE2064BM

MIN TYP MAX

–1.6

–1.6

–2

to

to

4

6

to

4

UNIT

V

V

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

43

TLE206x, TLE206xA, TLE206xB, TLE206xY

†

V

R

100 Ω

A

gg g

V/mV

V

R

100 Ω

CMRR

Common-mode rejection ratio

V

V

min

R

Ω

dB

k

Suppl

oltage rejection ratio (∆V

/∆VIO)

CC±

,

dB

ICCSupply current (four amplifiers)

mA

V

O

No load
VnEquivalent input noise voltage (see Figure 2)

V/√H

THD

Total harmonic distortion

VD

,

0.025%

B1Unity-gain bandwidth (see Figure 3)

MH

tsSettling time

s

φ

Phase margin at unity gain (see Figure 3)

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE
µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TLE2064M electrical characteristics at specified free-air temperature, V

= ±5 V (unless

±

CC

otherwise noted) continued)

TLE2064M

PARAMETER TEST CONDITIONS

= 0 to 2 V,

VD

r

i

c

i

z

o

SVR

∆I

CC

VO1/VO2Crosstalk attenuation AVD = 1000, f = 1 kHz 25°C 120 dB

†

Full range is –55°C to 125°C.

Large-signal differential voltage D and N
amplification packages

Input resistance 25°C 10
Input capacitance 25°C 4 pF
Open-loop output impedance IO = 0 25°C 560 Ω

pp

y-v

pp

Supply-current change over operating
temperature range (four amplifiers)

p

CC±

O

= 0 to –2 V,

O

=

IC

ICR

V

= ±5 V to ±15 V,

RS = 50 Ω

= 0,

=

L

=

L

,

= 50

S

T

A

25°C 0.75 45

Full range 0.25

25°C 0.4 3

Full range 0.15

25°C 65 82

Full range 60

25°C 75 93

Full range 65

25°C 1.12 1.3

Full range 1.3
Full range 144 µA

TLE2064AM
TLE2064BM

MIN TYP MAX

12

UNIT

Ω

TLE2064M operating characteristics, V

PARAMETER TEST CONDITIONS

SR Slew rate at unity gain (see Figure 1) RL = 10 kΩ, CL = 100 pF 3.4 V/µs

p

V

N(PP)

I

n

B

OM

m

Peak-to-peak equivalent input noise voltage f = 0.1 Hz to 10 Hz 1.1 µV
Equivalent input noise current f = 1 kHz 1 fA/√Hz

Maximum output-swing bandwidth AVD = 1, RL = 10 kΩ 140 kHz

= ±5 V, TA = 25°C

CC±

TLE2064M
TLE2064AM
TLE2064BM

MIN TYP MAX

f = 10 Hz, RS = 20 Ω 59
f = 1 kHz, RS = 20 Ω 43

A

= 2, f = 10 kHz,

V

= 2 V,,RL = 10 kΩ

O(PP)

RL = 10 kΩ, CL = 100 pF 1.8
RL = 600 Ω, CL = 100 pF 1.3

ε = 0.1% 5
ε = 0.01% 10

RL = 10 kΩ, CL = 100 pF 58°
RL = 600 Ω, CL = 100 pF 75°

UNIT

n

z

z

µ

44

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

TLE206x, TLE206xA, TLE206xB, TLE206xY

†

TLE2064M

VIOInput offset voltage

TLE2064AM

mV

TLE2064BM

IIOInput offset current

IIBInput bias current

V

Common-mode input voltage range

R

kΩ

V

Maximum positive peak output voltage swing

V

R

600 Ω

R

kΩ

V

Maximum negative peak output voltage swing

V

R

600 Ω

V

±10 V

R

kΩ

AVDLarge-signal differential voltage amplification

V

R

600 Ω

V/mV

V

R

600 Ω

CMRR

Common-mode rejection ratio

V

V

min

R

Ω

dB

k

Suppl

oltage rejection ratio (∆V

/∆VIO)

CC±

dB

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE

µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TLE2064M electrical characteristics at specified free-air temperature, V

= ±15 V (unless

CC±

otherwise noted)

TLE2064M

PARAMETER TEST CONDITIONS

p

α

VIO

ICR

OM+

OM–

r

i

c

i

z

o

SVR

†

Full range is – 55°C to 125°C.

NOTE 4: Typical values are based on the input offset voltage shift observed through 168 hours of operating life test at TA = 150°C extrapolated

Temperature coefficient of input offset voltage
Input offset voltage long-term drift

(see Note 4)

p

p

p

p

Input resistance 25°C 10
Input capacitance 25°C 4 pF
Open-loop output impedance IO = 0 25°C 560 Ω

pp

y-v

to TA = 25°C using the Arrhenius equation and assuming an activation energy of 0.96 eV.

p

p

p

p

p

CC±

VIC = 0, RS = 50 Ω

= 10

L

=

L

= 10

L

=

L

=

O

= 0 to 8 V,

O

= 0 to –8 V,

O

IC

V

CC±

RS = 50 Ω

,

=

= ±5 V to ±15 V,

ICR

,

= 10

L

=

L

=

L

= 50

S

T

A

25°C 0.9 6

Full range 8

25°C 0.9 4

Full range 6

25°C 0.7 2

Full range 4

25°C

Full range 0.04 µV/mo

25°C 2 pA

Full range 20 nA

25°C 4 pA

Full range 40 nA

25°C

Full range

25°C 13 13.7

Full range 12.5

25°C 12.5 13.2

Full range 12

25°C –13 –13.7

Full range –12.5

25°C –13 –13

Full range –12.5

25°C 30 230

Full range 20

25°C 25 100

Full range 7

25°C 3 25

Full range 1

25°C 72 90

Full range 65

25°C 75 93

Full range 65

TLE2064AM
TLE2064BM

MIN TYP MAX

6 µV/°C

–11

–11

13

13

–12

to

to

to

16

12

UNIT

V

V

Ω

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

45

TLE206x, TLE206xA, TLE206xB, TLE206xY

†

ICCSupply current (four amplifiers)

mA

V

No load

∆I

yg g

Full range

194µA

†

SR

Slew rate at unity gain (see Figure 1)

R

C

100 pF

V/µs

VnEquivalent input noise voltage (see Figure 2)

25°C

V/√H

V

Peak-to-peak equivalent input noise voltage

f

25°C

1.1µV

THD

Total harmonic distortion

VD

,

25°C

0.025%

B1Unity-gain bandwidth (see Figure 3)

25°C

MH

tsSettling time

25°C

s

φ

Phase margin at unity gain (see Figure 3)

25°C

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE
µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TLE2064M electrical characteristics at specified free-air temperature, V

= ±15 V (unless

CC±

otherwise noted) (continued)

TLE2064M

PARAMETER TEST CONDITIONS

pp

CC

VO1/VO2Crosstalk attenuation AVD = 1000, f = 1 kHz 25°C 120 dB

†

Full range is – 55°C to 125°C.

Supply-current change over operating
temperature range (four amplifiers)

p

= 0,

O

T

A

25°C 1.25 1.4

Full range 1.5

TLE2064M operating characteristics at specified free-air temperature, V

PARAMETER TEST CONDITIONS

p

N(PP)

I

n

B

OM

m

†

Full range is – 55°C to 125°C.

Equivalent input noise current f = 1 kHz 25°C 1.1 fA/√Hz

Maximum output-swing bandwidth AVD = 1, RL = 10 kΩ 25°C 40 kHz

p

= 10 kΩ,

L

f = 10 Hz, RS = 20 Ω
f = 1 kHz, RS = 20 Ω

p

= 0.1 Hz to 10 Hz

A

= 2, f = 10 kHz,

V

= 2 V,,RL = 10 kΩ

O(PP)

RL = 10 kΩ, CL = 100 pF
RL = 600 Ω, CL = 100 pF

ε = 0.1%
ε = 0.01%

RL = 10 kΩ, CL = 100 pF
RL = 600 Ω, CL = 100 pF

p

=

L

T

A

25°C 2.6 3.4

Full range 1.8

°

°

°

°

°

°

TLE2064AM

TLE2064BM

MIN TYP MAX

= ±15 V

CC±

TLE2064M
TLE2064AM
TLE2064BM

MIN TYP MAX

70
40

2

1.5
5

10

60°
70°

n

UNIT

UNIT

z

z

µ

46

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

TLE206x, TLE206xA, TLE206xB, TLE206xY

PARAMETER

TEST CONDITIONS

UNIT

V

R

Ω

V

Maximum positive peak output voltage swing

V

V

Maximum negative peak output voltage swing

PARAMETER

TEST CONDITIONS

UNIT

VnEquivalent input noise voltage (see Figure 2)

V/√H

THD

Total harmonic distortion

VD

,

0.025%

B1Unity-gain bandwidth (see Figure 3)

MH

tsSettling time

s

φ

Phase margin at unity gain (see Figure 3)

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE

µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TLE2064Y electrical characteristics at V

V

IO

∝

VIO

I

IO

I

IB

V

ICR

OM+

OM–

A

VD

r

i

c

i

z

o

CMRR Common-mode rejection ratio

k

SVR

I

CC

VO1/VO2Crosstalk attenuation AVD = 1000, f = 1 kHz 120 dB

NOTE 4: Typical values are based on the input offset voltage shift observed through 168 hours of operating life test at TA = 150°C extrapolated

Input offset voltage 0.9 6 mV
Input offset voltage long-term drift (see Note 4)
Input offset current
Input bias current 4 pA

Common-mode input voltage range

p

p

Large-signal differential voltage amplification

Input resistance 10
Input capacitance 4 pF
Open-loop output impedance IO = 0 560 Ω

Supply-voltage rejection ratio (∆V
Supply current VO = 0, No load 1.25 1.4 mA

to TA = 25°C using the Arrhenius equation and assuming an activation energy of 0.96 eV.

p

p

p

/∆VIO)

CC±

= ±15 V, TA = 25°C (unless otherwise noted)

CC±

TLE2064Y

MIN TYP MAX

= 0,

IC

RL = 10 kΩ 13.2 13.7
RL = 600 Ω 12.5 13.2
RL = 10 kΩ –13.2 –13.7 V
RL = 600 Ω 12.5 13 V
VO = ±10 V, RL = 10 kΩ 30 230
VO = 0 to 8 V, RL = 600 Ω
VO = 0 to –8 V, RL = 600 Ω 3 25

RS = 50 Ω,
VIC = V

V

CC±

RS = 50 Ω

min,

ICR

= ±5 V to ±15 V,

S

= 50

–11

to

13

25 100

72 90 dB

75 93 dB

0.04 µV/mo
2 pA

–12

to

16

12

V

V/mV

Ω

TLE2064Y operating characteristics at V

SR Slew rate at unity gain (see Figure 1) RL = 10 kΩ, CL = 100 pF 2.6 3.4 V/µs

p

V

N(PP)

I

n

B

OM

m

Peak-to-peak equivalent input noise voltage f = 0.1 Hz to 10 Hz 1.1 µV
Equivalent input noise current f = 1 kHz 1.1 fA/√Hz

Maximum output-swing bandwidth AVD = 1, RL = 10 kΩ 40 kHz

= ±15 V, TA = 25°C

CC±

f = 10 Hz, RS = 20 Ω 70
f = 1 kHz, RS = 20 Ω 40

A
V

O(PP)

RL = 10 kΩ, CL = 100 pF 2
RL = 600 Ω, CL = 100 pF 1.5

ε = 0.1% 5
ε = 0.01% 10

RL = 10 kΩ, CL = 100 pF 60°
RL = 600 Ω, CL = 100 pF 70°

TLE2064Y

MIN TYP MAX

n

= 2, f = 10 kHz,

= 2 V,,RL = 10 kΩ

z

z

µ

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

47

TLE206x, TLE206xA, TLE206xB, TLE206xY
EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE
µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

PARAMETER MEASUREMENT INFORMATION

V

CC+

–

V

O

+

V

I

V

CC–

(see Note A)

NOTE A: CL includes fixture capacitance.

C

L

R

L

2 kΩ

V

CC+

–

V

O

+

V

CC–

R

S

R

S

Figure 1. Slew-Rate Test Circuit

100 Ω

V

I

NOTE A: CL includes fixture capacitance.

10 kΩ

V

CC+

–

+

V

CC–

(see Note A)

Figure 2. Noise-Voltage Test Circuit

V

O

C

L

R

L

Figure 3. Unity-Gain Bandwidth and Phase-Margin Test Circuit

typical values

Typical values presented in this data sheet represent the median (50% point) of device parametric performance.

input bias and offset current

At the picoampere bias current level typical of the TLE206x, TLE2064xA, and TLE206xB, accurate
measurement of the bias current becomes difficult. Not only does this measurement require a picoammeter,
but test socket leakages can easily exceed the actual device bias currents. T o accurately measure these small
currents, Texas Instruments uses a two-step process. The socket leakage is measured using picoammeters
with bias voltages applied but with no device in the socket. The device is then inserted into the socket, and a
second test that measures both the socket leakage and the device input bias current is performed. The two
measurements are then subtracted algebraically to determine the bias current of the device.

48

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

TLE206x, TLE206xA, TLE206xB, TLE206xY

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE

µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TYPICAL CHARACTERISTICS

Table of Graphs

FIGURE

V

IO

I

IB

I

IO

V

ICR

V

OM

V

O(PP)

A

VD

I

OS

z

o

CMRR Common-mode rejection ratio vs Frequency 24
I

CC

V

n

THD T otal harmonic distortion vs Frequency 37, 38
B

1

φ

m

Input offset voltage Distribution 4, 5, 6
Input bias current
Input offset current vs Free-air temperature 8

Common-mode input voltage vs Free-air temperature 9
Maximum peak output voltage

Maximum peak-to-peak output voltage

Large-signal differential voltage amplification

Short-circuit output current
Output impedance vs Frequency 22, 23

Supply current
Voltage-follower small-signal pulse response vs Time 31, 32

Voltage-follower large-signal pulse response vs Time 33, 34
Noise voltage (referred to input) 0.1 to 10 Hz 35
Equivalent input noise voltage vs Frequency 36

Unity-gain bandwidth

Phase margin

Phase shift vs Frequency 18

vs Common-mode input voltage
vs Free-air temperature

vs Output current
vs Supply voltage

vs Frequency
vs Load resistance

vs Frequency
vs Free-air temperature

vs Elasped time
vs Free-air temperature

vs Supply voltage
vs Free-air temperature

vs Supply voltage
vs Free-air temperature

vs Supply voltage
vs Load capacitance
vs Free-air temperature

7
8

10, 11

12, 13, 14

15, 16

17
18

19
20

21

25, 26, 27
28, 29, 30

39
40

41
42
43

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

49

TLE206x, TLE206xA, TLE206xB, TLE206xY

Percentage

of

Amplifiers

%

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE
µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TYPICAL CHARACTERISTICS

TLE2061

DISTRIBUTION OF

INPUT OFFSET VOLTAGE

15

736 Amplifiers Tested From 3 Wafer Lots
V

= ±15 V

CC±

TA = 25°C
P Package

–

10

5

0

VIO – Input Offset Voltage – mV

Figure 4

TLE2064

DISTRIBUTION OF

INPUT OFFSET VOLTAGE

20

2792 Amplifiers Tested From 2 Wafer Lots
V

= ±15 V

CC±

TA = 25°C
N Package

15

TLE2062

DISTRIBUTION OF

INPUT OFFSET VOLTAGE

15

1836 Amplifiers T ested From 1 Wafer Lot

V

= ±15 V

CC±

TA = 25°C
P Package

10

5

Percentage of Amplifiers – %

0

– 2 –1 0 1

43210–1–2–3–4

–3–4

VIO – Input Offset Voltage – mV

234

Figure 5

INPUT BIAS CURRENT

vs

COMMON-MODE INPUT VOLTAGE

2

VID = 0
TA = 25°C

1.5

10

5

Percentage of Amplifiers – %

0

50

VIO – Input Offset Voltage – mV

Figure 6

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

1

– Input Bias Current – nA

0.5

IB

I

V

= ±15 V

CC±

0

86420–2–4–6–8

–20 –15 –10 –5 0 5 10 15 20

VIC – Common-Mode Input Voltage – V

Figure 7

TLE206x, TLE206xA, TLE206xB, TLE206xY

ÎÎ

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE

µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

INPUT BIAS CURRENT

AND INPUT OFFSET CURRENT

vs

FREE-AIR TEMPERATURE

5

10

V

= ±15 V

CC±

VIC = 0

4

10

3

10

I

2

10

1

– Input Bias and Input Offset Currents – pA

10

IO

and I

0

10

IB

I

IB

TA – Free-Air Temperature – ° C

Figure 8

TYPICAL CHARACTERISTICS

+2

V

CC +

+1

V

CC +

V

CC +

+4

I

IO

10585654525

125

V

CC –

V

CC –

– Common-Mode Input Voltage – V

IC

V

V

CC –

+3

+2

†

COMMON-MODE INPUT VOLTAGE

vs

FREE-AIR TEMPERATURE

V

IC +

V

IC –

TA – Free-Air Temperature – ° C

Figure 9

1251007550250–25–50–75

MAXIMUM POSITIVE PEAK

OUTPUT VOLTAGE

vs

OUTPUT CURRENT

20

18

16

14

V

12

10

8

6

4

– Maximum Positive Peak Output Voltage – V

2

OM+

V

0

TA = 25°C

= ±15 V

CC±

V

= ± 5 V

CC±

–60–50–40–30–20–100

IO – Output Current – mA

–20

–18

–16

–14

–12

–10

– Maximum Negative Peak Output Voltage – V

OM –

V

V

–8

–6

–4

–2

0

0 5 10 15 20 25 40

Figure 10

†

Data at high and low temperatures are applicable only within the rated operating free-air temperature ranges of the various devices.

MAXIMUM NEGATIVE PEAK

OUTPUT VOLTAGE

vs

OUTPUT CURRENT

TA = 25°C

= ±15 V

CC±

V

= ±5 V

CC±

IO – Output Current – mA

Figure 11

30 35

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

51

TLE206x, TLE206xA, TLE206xB, TLE206xY
EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE
µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TYPICAL CHARACTERISTICS

20

15

10

5

0

–5

–10

– Maximum Peak Output Voltage – V

OM

V

–15

–20

MAXIMUM PEAK OUTPUT VOLTAGE

vs

SUPPLY VOLTAGE

RL = 10 kΩ
TA = 25°C

| V

| – Supply Voltage – V

CC±

Figure 12

V

OM +

V

OM –

MAXIMUM PEAK OUTPUT VOLTAGE

vs

SUPPLY VOLTAGE

20

RL = 600 Ω
TA = 25°C

15

V

OM +

10

5

0

–5

–10

– Maximum Peak Output Voltage – V

V

OM

V

–15

20181614121086420

–20

0 2 4 6 8 1012141618 20

| V

| – Supply Voltage – V

CC+

OM –

Figure 13

6

4

2

0

–2

– Maximum Peak Output Voltage – V

–4

OM

V

–6

MAXIMUM PEAK OUTPUT VOLTAGE

vs

SUPPLY VOLTAGE

RL = 100 Ω
TA = 25°C

|V

| – Supply Voltage – V

CC±

Figure 14

V

OM +

V

OM –

MAXIMUM PEAK-TO-PEAK

OUTPUT VOLTAGE

vs

FREQUENCY

10

V

= ±5 V

CC±

RL = 10 kΩ

8

6

4

2

– Maximum Peak-to-Peak Output Voltage – V

O(PP)

0

1086420

V

10 k 100 k 1 M 10 M

f – Frequency – Hz

TA = 25°C

Figure 15

52

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

TLE206x, TLE206xA, TLE206xB, TLE206xY

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE

µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TYPICAL CHARACTERISTICS

MAXIMUM PEAK-TO-PEAK

OUTPUT VOLTAGE

vs

FREQUENCY

30

V

= ±15 V

CC±

RL = 10 kΩ

25

20

15

10

5

– Maximum Peak-to-Peak Output Voltage – V

O(PP)

0

V

10 k 100 k 1 M 10 M

f – Frequency – Hz

Figure 16

TA = 25°C

10

8

6

4

2

– Maximum Peak-to-Peak Output Voltage – V

O(PP)

0

V

10

†

MAXIMUM PEAK-TO-PEAK

OUTPUT VOLTAGE

vs

LOAD RESISTANCE

V

= ±5 V

CC

±

TA = 25°C

RL – Load Resistance – Ω

Figure 17

10 k1 k100

LARGE-SIGNAL DIFFERENTIAL VOLTAGE

AMPLIFICATION AND PHASE SHIFT

120

100

80

60

40

20

V

CC±

RL = 10 kΩ

0

CL = 100 pF

– Large-Signal DIfferential Voltage Amplification – dB

VD

A

TA = 25°C

–20

FREQUENCY

Phase Shift

A

VD

= ±15 V

f – Frequency – Hz

Figure 18

vs

LARGE-SIGNAL VOLTAGE AMPLIFICATION

vs

FREE-AIR TEMPERATURE

60°

80°

100°

120°

140°

Phase Shift

160°

180°

200°

10 M1 M100 k10 k1 k1001010.1

400

350

300

250

V

= ±15 V

CC±

200

150

100

V

= ±5 V

50

0

– Large-Signal DIfferential Voltage Amplification – V/mV

VD

A

CC±

TA – Free-Air Temperature – ° C

RL = 10 kΩ

1251007550250–25–50–75

Figure 19

†

Data at high and low temperatures are applicable only within the rated operating free-air temperature ranges of the various devices.

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

53

TLE206x, TLE206xA, TLE206xB, TLE206xY
EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE
µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

SHORT-CIRCUIT OUTPUT CURRENT

vs

ELAPSED TIME

80

VID = – 100 mV

60

40

20

V

= ±15 V

CC±

TA = 25°C

0

VO = 0

–20

–40

– Short-Circuit Output Current – mA

OS

–60

I

–80

t – Elapsed Time – s

TYPICAL CHARACTERISTICS

80

60

40

20

0

–20

–40

– Short-Circuit Output Current – mA

OS

VID = 100 mV

6050403020100

–60

I

–80

– 75 – 50 – 25 0 25 50 75 100 125

†

SHORT-CIRCUIT OUTPUT CURRENT

vs

FREE-AIR TEMPERATURE

V

= ±15 V

CC±

VO = 0

VID = – 100 mV

VID = 100 mV

TA – Free-Air Temperature – ° C

1000

= ±15 V

V

CC

±

TA = 25°C

100

Ω

10

1

0.1

– Output Impedance –

o

z

0.01

0.001

AVD = 100

AVD = 10

AVD = 1

Figure 20

TLE2061

OUTPUT IMPEDANCE

vs

FREQUENCY

f – Frequency – Hz

Figure 22

35

30

25

Ω

20

15

10

– Output Impedance –

o

z

5

0

1 M100 k10 k1 k10010

V

= ±15 V

CC±

TA = 25°C

AVD = 100

Figure 21

TLE2062 AND TLE2064

OUTPUT IMPEDANCE

vs

FREQUENCY

AVD = 10

f – Frequency – Hz

Figure 23

AVD = 1

1 M100 k10 k1 k100

10 M

†

Data at high and low temperatures are applicable only within the rated operating free-air temperature ranges of the various devices.

54

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

TLE206x, TLE206xA, TLE206xB, TLE206xY

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE

µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TYPICAL CHARACTERISTICS

COMMON-MODE REJECTION RATIO

vs

FREQUENCY

100

TA = 25°C

80

V

= ±5 V

CC±

60

40

20

CMRR – Common-Mode Rejection Ratio – dB

0

10 100 1 k 10 k 100 k 1 M

f – Frequency – Hz

Figure 24

10 M

340

VO = 0
No Load

320

Aµ

300

280

– Supply Current –

CC

I

260

240

2

†

TLE2061

SUPPLY CURRENT

SUPPLY VOLTAGE

| V

| – Supply Voltage – V

CC±

Figure 25

vs

TA = 125°C

TA = 25°C

TA = –55°C

2018161412108640

TLE2062

SUPPLY CURRENT

vs

SUPPLY VOLTAGE

700

VO = 0
No Load

675

650

Aµ

625

600

575

CC

ICC – Supply Current – xA

550

I

525

500

024681012

TA = 125°C

|V

CC±

TA = 25°C

TA = –55°C

14 16 18 20

| – Supply Voltage – V

1.4
VO = 0

1.35

1.25

1.15

– Supply Current – mA

CC

I

1.05

No Load

1.3

1.2

1.1

1

| V

Figure 26

†

Data at high and low temperatures are applicable only within the rated operating free-air temperature ranges of the various devices.

TLE2064

SUPPLY CURRENT

vs

SUPPLY VOLTAGE

TA = 125°C

TA = 25°C

TA = – 55°C

| – Supply Voltage – V

CC±

Figure 27

20181614121086420

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

55

TLE206x, TLE206xA, TLE206xB, TLE206xY
EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE
µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

340

VO = 0
No Load

320

Aµ

300

300

280

280

– Supply Current –

CC

I

260

260

240

–75

TYPICAL CHARACTERISTICS

TLE2061

SUPPLY CURRENT

vs

FREE-AIR TEMPERATURE

V

= ±15 V

CC

±

V

= ±5 V

CC

±

TA – Free-Air Temperature – ° C

Figure 28

†

TLE2062

SUPPLY CURRENT

vs

FREE-AIR TEMPERATURE

700

VO = 0
No Load

675

650

Aµ

625

600

575

CC

ICC – Supply Current – xA

550

I

525

1251007550250–25–50

500

– 75 – 50 – 25 0 25 50 75 100 125

TA – Free-Air Temperature – ° C

V

CC±

V

CC±

= ±5 V

= ±15 V

Figure 29

TLE2064

SUPPLY CURRENT

vs

FREE-AIR TEMPERATURE

1.4
VO = 0

No Load

1.35

1.3

1.25

1.2

1.15

– Supply Current – mA

CC

1.1

I

1.05

1

TA – Free-Air Temperature – ° C

V

CC±

V

CC±

= ±5 V

= ±15 V

1251007550250–25–50–75

– Output Voltage – mV

O

V

–50

– 100

100

50

0

Figure 30

†

Data at high and low temperatures are applicable only within the rated operating free-air temperature ranges of the various devices.

VOLTAGE-FOLLOWER

SMALL-SIGNAL

PULSE RESPONSE

V

= ±5 V

CC±

RL = 10 kΩ
CL = 100 pF
TA = 25°C
See Figure 1

0

0.5

1

1.5

t – Time – µs

Figure 31

2

2.5

56

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

TLE206x, TLE206xA, TLE206xB, TLE206xY

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE

µPOWER OPERATIONAL AMPLIFIERS

TYPICAL CHARACTERISTICS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

100

– Output Voltage – mV

O

V

–50

– 100

50

VOLTAGE-FOLLOWER

SMALL-SIGNAL

PULSE RESPONSE

0

V

= ±15 V

CC±

RL = 10 kΩ
CL = 100 pF
TA = 25°C
See Figure 1

3

0

0.5

1

t – Time – µs

1.5

2.5

23

4

3

2

1

– Output Voltage – V

0

O

V

–1

–2

Figure 32

VOLTAGE-FOLLOWER

LARGE-SIGNAL

PULSE RESPONSE

V

= ±5 V

CC±

RL = 10 kΩ
CL = 100 pF
TA = 25°C
See Figure 1

0

t – Time – µs

5

Figure 33

10 15

15

10

5

0

– Output Voltage – V

–5

O

V

–10

–15

VOLTAGE-FOLLOWER

V

= ±15 V

CC±

RL = 10 kΩ
CL = 100 pF
TA = 25°C
See Figure 1

LARGE-SIGNAL

PULSE RESPONSE

t – Time – µs

Figure 34

NOISE VOLTAGE

(REFERRED TO INPUT)

0.1 TO 10 Hz

1

V

= ±15 V

CC±

TA = 25°C

0.5

0

Noise Voltage – V

– 0.5

403020100

–1

t – Time – µs

109876543210

Figure 35

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

57

TLE206x, TLE206xA, TLE206xB, TLE206xY
EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE
µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

TYPICAL CHARACTERISTICS

100

nV/ Hz

80

60

40

20

– Equivalent Input Noise Voltage –

n

V

0

0.6

0.5

EQUIVALENT INPUT NOISE VOLTAGE

vs

FREQUENCY

V

CC±

RS = 20Ω
TA = 25°C
See Figure 2

f – Frequency – Hz

Figure 36

TOTAL HARMONIC DISTORATION

vs

FREQUENCY

AVD = 10
V

= 2 V

O(PP)

TA = 25°C

= ±5 V

TOTAL HARMONIC DISTORTION

vs

FREQUENCY

0.3
AVD = 2
V

= 2 V

O(PP)

TA = 25°C

0.2

V

= ±5 V

CC±

0.1

THD – Total Harmonic Distortion – %

10 k1 k100101

0

Source Signal

100 k10 k1 k10010

f – Frequency – Hz

Figure 37

UNITY-GAIN BANDWIDTH

vs

SUPPLY VOLTAGE

2.5
RL = 10 kΩ

CL = 100 pF
TA = 25°C
See Figure 3

0.4

0.3

0.2
Source Signal

0.1

THD – Total Harmonic Distortion – %

0

10 100 1 k 10 k 100 k

58

V

f – Frequency – Hz

Figure 38

2

= ±5 V

CC±

1.5

– Unity-Gain Bandwidth – MHz

1

B

1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

0

| V

| – Supply Voltage – V

CC±

2018161412108642

Figure 39

TLE206x, TLE206xA, TLE206xB, TLE206xY

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE

µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

UNITY-GAIN BANDWIDTH

FREE-AIR TEMPERATURE

2.5

V

2

V

= ±5 V

CC±

1.5

– Unity-Gain Bandwidth – MHz

1

B

RL = 10 kΩ
CL = 100 pF

See Figure 3

1

TA – Free-Air Temperature – ° C

Figure 40

vs

CC±

= ±15 V

TYPICAL CHARACTERISTICS

62°

RL = 10 kΩ

61°

CL = 100 pF
TA = 25°C
See Figure 3

60°

59°

58°

– Phase Margin

m

φ

57°

56°

55°

0

1251007550250–25–50–75

2 4 6 8101214161820

†

PHASE MARGIN

SUPPLY VOLTAGE

| V

| – Supply Voltage – V

CC±

Figure 41

vs

60°

50°

40°

30°

– Phase Margin

m

20°

φ

10°

0°

PHASE MARGIN

vs

LOAD CAPACITANCE

V

CC±

RL = 10 kΩ
TA = 25°C

See Figure 3

CL – Load Capacitance – pF

Figure 42

= ±15 V

PHASE MARGIN

vs

FREE-AIR TEMPERATURE

66°

RL = 10 kΩ
CL = 100 pF

64°

62°

60°

– Phase Margin

m

φ

58°

56°

10008006004002000

54°

V

= ±5 V

CC±

TA – Free-Air Temperature – ° C

V

CC±

See Figure 3

= ±15 V

1251007550250–25–50–75

Figure 43

†

Data at high and low temperatures are applicable only within the rated operating free-air temperature ranges of the various devices.

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

59

TLE206x, TLE206xA, TLE206xB, TLE206xY
EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE
µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

APPLICATION INFORMATION

input characteristics

The TLE206x, TLE206xA, and TLE206xB are specified with a minimum and a maximum input voltage that if
exceeded at either input could cause the device to malfunction. Because of the extremely high input impedance
and resulting low bias current requirements, the TLE206x, TLE206xA, and TLE206xB are well suited for
low-level signal processing; however, leakage currents on printed-circuit boards and sockets can easily exceed
bias current requirements and cause degradation in system performance. It is good practice to include guard
rings around inputs (see Figure 44). These guards should be driven from a low-impedance source at the same
voltage level as the common-mode input.

R1

R3
R4

+

+

V

V

O

–

R2

R2
R1

R3

R4

I

+

V

O

–

V

I

+

–

V

I

Where

Figure 44. Use of Guard Rings

TLE2061 input offset voltage nulling

The TLE2061 series offers external null pins that can be used to further reduce the input offset voltage. The
circuit of Figure 45 can be connected as shown if the feature is desired. When external nulling is not needed,
the null pins may be left unconnected.

IN–

IN+

–

OUT

+

N2

V

O

60

N1

100 kΩ

5 kΩ

V

CC–

Figure 45. Input Offset Voltage Nulling

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

macromodel information

TLE206x, TLE206xA, TLE206xB, TLE206xY

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE

µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

APPLICATION INFORMATION

Macromodel information provided was derived using Microsim
with Microsim

PSpice

. The Boyle macromodel (see Note 5) and subcircuit in Figure 46 were generated using

Parts

, the model generation software used

the TLE206x typical electrical and operating characteristics at 25°C. Using this information, output simulations
of the following key parameters can be generated to a tolerance of 20% (in most cases):

D

D

Maximum positive output voltage swing

D

Maximum negative output voltage swing

D

Slew rate

D

Quiescent power dissipation

D

Input bias current

D

Open-loop voltage amplification

NOTE 5: G. R. Boyle, B. M. Cohn, D. O. Pederson, and J. E. Solomon, “

V

CC+

IN–

IN+

of Solid-State Circuits

rp

2

dp

1

, SC-9, 353 (1974).

3

rss iss

10

j1 j2

11

12

C1

vc

+

r2

–

53

dc

Macromodeling of Integrated Circuit Operational Amplifiers

egnd

9

+

vb

–

6

gcm

Unity-gain frequency

D

Common-mode rejection ratio

D

Phase margin

D

DC output resistance

D

AC output resistance

D

Short-circuit output current limit

99

+

fb

–

C2

ga

7

vlim

ro2

hlim

8

90

+

–

+

–

dip

din

91

+

–

”,

IEEE Journal

92

–

vinvip

+

rd1

V

CC–

.subckt TLE2062 1 2 3 4 5

c1 11 12 1.457E–12
c2 6 7 15.00E–12
dc 5 53 dx
de 54 5 dx
dlp 90 91 dx
dln 92 90 dx
dp 4 3 dx
egnd 99 0 poly (2) (3,0) (4,0) 0 .5 .5
fb 7 99 poly (5) vb vc ve vlp

+ vln 0 4.357E6 –4E6 4E6 4E6 –4E6

ga 6 0 11 12 188.5E–6
gcm 0 6 10 99 3.352E–9
iss 3 10 dc 51.00E–6
hlim 90 0 vlim 1k
j1 11 2 10 jx
j2 12 1 10 jx
r2 6 9 100.0E3

4

rd2

+–

ve

Figure 46. Boyle Macromodel and Subcircuit

PSpice

and

Parts

are trademarks of MicroSim Corporation.

54

de

ro1

5

OUT

rd1 4 11 5.305E3
rd2 4 12 5.305E3
r01 8 5 280
r02 7 99 280
rp 3 4 113.2E3
rss 10 99 3.922E6
vb 9 0 dc 0
vc 3 53 dc 2
ve 54 4 dc 2
vlim 7 8 dc 0
vlp 91 0 dc 50

vln 0 92 dc 50
.model dx D(Is=800.0E–18)
.model jx PJF(Is=2.000E–12 Beta = 423E–6
+ Vto = –1)
.ends

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

61

TLE206x, TLE206xA, TLE206xB, TLE206xY
EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE
µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

MECHANICAL INFORMATION

D (R-PDSO-G**) PLASTIC SMALL-OUTLINE PACKAGE

14 PIN SHOWN

0.050 (1,27)

14

1

0.069 (1,75) MAX

0.020 (0,51)

0.014 (0,35)
8

7

A

0.010 (0,25)

0.004 (0,10)

DIM

0.157 (4,00)

0.150 (3,81)

PINS **

0.010 (0,25)

0.244 (6,20)

0.228 (5,80)

8

M

Seating Plane

0.004 (0,10)

14

0.008 (0,20) NOM

0°–8°

16

Gage Plane

0.010 (0,25)

0.044 (1,12)

0.016 (0,40)

A MAX

A MIN

NOTES: A. All linear dimensions are in inches (millimeters).

62

B. This drawing is subject to change without notice.
C. Body dimensions do not include mold flash or protrusion, not to exceed 0.006 (0,15).
D. Falls within JEDEC MS-012

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

0.197

(5,00)

0.189

(4,80)

0.344

(8,75)

0.337

(8,55)

0.394

(10,00)

0.386

(9,80)

4040047/D 10/96

TLE206x, TLE206xA, TLE206xB, TLE206xY

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE

µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

MECHANICAL INFORMATION

FK (S-CQCC-N**) LEADLESS CERAMIC CHIP CARRIER

28 TERMINAL SHOWN

A SQ

B SQ

20

22

23

24

25

19

21

12826 27

121314151618 17

0.020 (0,51)

0.010 (0,25)

MIN

0.342

(8,69)

0.442

0.640

0.739

0.938

1.141

A

0.358
(9,09)

0.458

(11,63)

0.660

(16,76)

0.761

(19,32)(18,78)

0.962

(24,43)

1.165

(29,59)

NO. OF

TERMINALS

**

11

10

9

8

7

6

5

432

20

28

44

52

68

84

0.020 (0,51)

0.010 (0,25)

(11,23)

(16,26)

(23,83)

(28,99)

MINMAX

0.307

(7,80)

0.406

(10,31)

0.495

(12,58)

0.495

(12,58)

0.850

(21,6)

1.047

(26,6)

0.080 (2,03)

0.064 (1,63)

B

MAX

0.358

(9,09)

0.458

(11,63)

0.560

(14,22)

0.560

(14,22)

0.858

(21,8)

1.063

(27,0)

0.055 (1,40)

0.045 (1,14)

0.028 (0,71)

0.022 (0,54)

0.050 (1,27)

NOTES: A. All linear dimensions are in inches (millimeters).

B. This drawing is subject to change without notice.
C. This package can be hermetically sealed with a metal lid.
D. The terminals are gold plated.
E. Falls within JEDEC MS-004

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

0.045 (1,14)

0.035 (0,89)

0.045 (1,14)

0.035 (0,89)

4040140/D 10/96

63

TLE206x, TLE206xA, TLE206xB, TLE206xY
EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE
µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

MECHANICAL INFORMATION

J (R-GDIP-T**) CERAMIC DUAL-IN-LINE PACKAGE

14 PIN SHOWN

14

1

B

0.065 (1,65)

0.045 (1,14)

0.100 (2,54)

0.070 (1,78)

8

C

7

0.020 (0,51) MIN

0.200 (5,08) MAX

PINS **

DIM

A MAX

A MIN

B MAX

B MIN

C MAX

C MIN

Seating Plane

0.310

(7,87)

0.290

(7,37)

0.785

(19,94)

0.755

(19,18)

0.280A0.300
(7,11)

0.245

(6,22)

0.310

(7,87)

0.290
(7,37)

0.785

(19,94)

0.755

(19,18)

(7,62)

0.245
(6,22)

181614

0.310

(7,87)

0.290

(7,37)

0.910

(23,10)

0.300

(7,62)

0.245

(6,22)

20

0.310

(7,87)

0.290

(7,37)

0.975

(24,77)

0.930

(23,62)

0.300

(7,62)

0.245

(6,22)

0.130 (3,30) MIN

0.100 (2,54)

0.023 (0,58)

0.015 (0,38)

NOTES: A. All linear dimensions are in inches (millimeters).

B. This drawing is subject to change without notice.
C. This package can be hermetically sealed with a ceramic lid using glass frit.
D. Index point is provided on cap for terminal identification only on press ceramic glass frit seal only.
E. Falls within MIL-STD-1835 GDIP1-T14, GDIP1-T16, GDIP1-T18, and GDIP1-T20

0°–15°

0.014 (0,36)

0.008 (0,20)
4040083/C 08/96

64

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

TLE206x, TLE206xA, TLE206xB, TLE206xY

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE

µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

MECHANICAL INFORMATION

JG (R-GDIP-T8) CERAMIC DUAL-IN-LINE PACKAGE

0.400 (10,20)

0.355 (9,00)

0.063 (1,60)

0.015 (0,38)

0.100 (2,54)

8

1

5

4

0.065 (1,65)

0.045 (1,14)

0.020 (0,51) MIN

0.280 (7,11)

0.245 (6,22)

0.200 (5,08) MAX

0.130 (3,30) MIN

0.023 (0,58)

0.015 (0,38)

0.310 (7,87)

0.290 (7,37)

Seating Plane

0°–15°

0.014 (0,36)

0.008 (0,20)

NOTES: A. All linear dimensions are in inches (millimeters).

B. This drawing is subject to change without notice.
C. This package can be hermetically sealed with a ceramic lid using glass frit.
D. Index point is provided on cap for terminal identification only on press ceramic glass frit seal only.
E. Falls within MIL-STD-1835 GDIP1-T8

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

4040107/C 08/96

65

TLE206x, TLE206xA, TLE206xB, TLE206xY
EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE
µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

MECHANICAL INFORMATION

N (R-PDIP-T**) PLASTIC DUAL-IN-LINE PACKAGE

16 PIN SHOWN

16

1

0.035 (0,89) MAX

PINS **

DIM

A

9

0.260 (6,60)

0.240 (6,10)

8

0.070 (1,78) MAX

0.020 (0,51) MIN

0.200 (5,08) MAX

A MAX

A MIN

Seating Plane

14

0.775

(19,69)

0.745

(18,92)

16

0.775

(19,69)

0.745

(18,92)

18

0.920

(23.37)

0.850

(21.59)

20

0.975

(24,77)

0.940

(23,88)

0.310 (7,87)

0.290 (7,37)

0.100 (2,54)

0.021 (0,53)

0.015 (0,38)

NOTES: A. All linear dimensions are in inches (millimeters).

B. This drawing is subject to change without notice.
C. Falls within JEDEC MS-001 (20 pin package is shorter then MS-001.)

0.010 (0,25)

M

0.125 (3,18) MIN

0°–15°

0.010 (0,25) NOM

14/18 PIN ONL Y

4040049/C 08/95

66

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

TLE206x, TLE206xA, TLE206xB, TLE206xY

EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE

µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

MECHANICAL INFORMATION

P (R-PDIP-T8) PLASTIC DUAL-IN-LINE PACKAGE

0.400 (10,60)

0.355 (9,02)

58

0.260 (6,60)

0.240 (6,10)

41

0.070 (1,78) MAX

0.020 (0,51) MIN

0.200 (5,08) MAX

0.125 (3,18) MIN

0.100 (2,54)

0.021 (0,53)

0.015 (0,38)

NOTES: A. All linear dimensions are in inches (millimeters).

B. This drawing is subject to change without notice.
C. Falls within JEDEC MS-001

0.010 (0,25)

M

0.310 (7,87)

0.290 (7,37)

Seating Plane

0°–15°

0.010 (0,25) NOM

4040082/B 03/95

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

67

TLE206x, TLE206xA, TLE206xB, TLE206xY
EXCALIBUR JFET-INPUT HIGH-OUTPUT-DRIVE
µPOWER OPERATIONAL AMPLIFIERS

SLOS193A – FEBRUARY 1997 – REVISED MARCH 1998

MECHANICAL INFORMATION

PW (R-PDSO-G**) PLASTIC SMALL-OUTLINE PACKAGE

14 PIN SHOWN

0,65

14

1

1,20 MAX

A

7

0,05 MIN

0,30
0,19

8

6,60

4,50
4,30

6,20

M

0,10

Seating Plane

0,10

0,15 NOM

Gage Plane

0,25

0°–8°

0,75
0,50

PINS **

DIM

A MAX

A MIN

NOTES: A. All linear dimensions are in millimeters.

B. This drawing is subject to change without notice.
C. Body dimensions do not include mold flash or protrusion not to exceed 0,15.
D. Falls within JEDEC MO-153

8

3,10

2,90

14

5,10

4,90

16

5,10

20

6,60

6,404,90

24

7,90

7,70

28

9,80

9,60

4040064/E 08/96

68

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

IMPORTANT NOTICE

T exas Instruments and its subsidiaries (TI) reserve the right to make changes to their products or to discontinue
any product or service without notice, and advise customers to obtain the latest version of relevant information
to verify, before placing orders, that information being relied on is current and complete. All products are sold
subject to the terms and conditions of sale supplied at the time of order acknowledgement, including those
pertaining to warranty, patent infringement, and limitation of liability.

TI warrants performance of its semiconductor products to the specifications applicable at the time of sale in
accordance with TI’s standard warranty. Testing and other quality control techniques are utilized to the extent
TI deems necessary to support this warranty . Specific testing of all parameters of each device is not necessarily
performed, except those mandated by government requirements.

CERT AIN APPLICATIONS USING SEMICONDUCTOR PRODUCTS MAY INVOLVE POTENTIAL RISKS OF
DEATH, PERSONAL INJURY, OR SEVERE PROPERTY OR ENVIRONMENTAL DAMAGE (“CRITICAL
APPLICATIONS”). TI SEMICONDUCTOR PRODUCTS ARE NOT DESIGNED, AUTHORIZED, OR
WARRANTED TO BE SUITABLE FOR USE IN LIFE-SUPPORT DEVICES OR SYSTEMS OR OTHER
CRITICAL APPLICA TIONS. INCLUSION OF TI PRODUCTS IN SUCH APPLICATIONS IS UNDERST OOD TO
BE FULLY AT THE CUSTOMER’S RISK.

In order to minimize risks associated with the customer’s applications, adequate design and operating
safeguards must be provided by the customer to minimize inherent or procedural hazards.

TI assumes no liability for applications assistance or customer product design. TI does not warrant or represent
that any license, either express or implied, is granted under any patent right, copyright, mask work right, or other
intellectual property right of TI covering or relating to any combination, machine, or process in which such
semiconductor products or services might be or are used. TI’s publication of information regarding any third
party’s products or services does not constitute TI’s approval, warranty or endorsement thereof.

Copyright  1998, Texas Instruments Incorporated
