MULTIMEDIA PLAYER WITH DVB-T2 RECEIVER МУЛЬТИМЕДИЙНЫЙ ПЛЕЕР С DVB-T2 ПРИЕМНИКОМ

TF-DVBT228

Instruction manual

Руководство по эксплуатации

Table of contents

Dear customer!

Thank you for purchasing our product. For safety, it is strongly recommended to read this manual carefully before connecting, operating and/or adjusting the product and keep the manual for reference in the future.

Table of contents Before you start

Important safeguards Utilization of the product

Connection

Operation

Control elements

Front panel

Rear panel Remote controller

Changing the battery General operation OSD operation

Installation

Program


Channel

Time

Option

USB USB information

PVR and EPG

Time Shift

General information

Troubleshooting Accessories Supported formats Specifications

2 3 3 3 4 4 5 5 5 5 6 6 7 8 8

9 9

10 10 11 11 12 12 13 13 14

Before you start

Important safeguards

• To prevent risk of fire or electric shock, avoid merging the unit into the water or under conditions of high humidity.

• Switch off the device from the socket, if you’re not going to use it for a long time.

• Do not place objects on the device.

• Place the unit in a dry and ventilated area. Eliminate proximity to heaters, do not expose to sunlight, mechanical vibration, humidity and dusty environment.

• It is possible to use a small amount of neutral detergent to clean the device.

• Never use abrasive materials or organic substances (alcohol, gasoline, etc.) to clean the device.

• For repair and maintrnance contact only authorized service centers.

• Before connecting the device to the mains, please make sure the network cable can be easily disabled at any time.

• Unplug from the mains and from the cable television antenna, unless you intend to use it for a long time, or before a thunderstorm. Do not touch the unit, power cord and antenna cable during a thunderstorm!

• Before you turn on the device, please check the reliability of its connection to the power supply and other devices.

• This unit can not receive television signals during the movement of the vehicle.

• After prolonged exposure to cold, before turning on leave the device for 1 hour at a room temperature.

Utilization of the product

If you want to dispose of this product, do not mix it with general household waste. There is a separate collection system for used electronic products in accordance with legislation that requires proper treatment, recovery and recycling.

Please contact your local authorities for the correct method of disposal. By doing so, you will ensure that your disposed product undergoes the necessary treatment, recovery and recycling and thus prevent potential negative effects on the environment and human health.

Before you start

Before using this product, carefully read the manual. After you read, save it for future use. If necessary, contact your local dealer for service.

All the illustrations in this manual are schematic images, which may differ from actual objects.

Connection

Antenna input

• Connect an external DVB-T/T2 antenna

(cable) connector to the antenna input RF IN.

The signal in the block cable antenna can fail to contain DVB-T/T2 signal due to the carrier frequency altered by the cable network operator.

In order to receive digital air TV signal use an indoor or outdoor UHF antenna. Specify the possibility and quality of digital air signal with your local digital TV service providers. The absence of a stable TV signal in your area cannot be a reason for returns or refunds without an additional test of TV signal reception in your area.

To increase the reception quality of the state digital air television in rural areas or at significant distances from a broadcasting center we recomment using individual active outdoor UHF antennae with a high resistance factor, and placing them at maximum possible heights.

Power adaptor input

•

Connect the DC power adaptor to this

input and plug it into the electrical outlet.

Loop output

• Connect the LOOP antenna input using a special adapter (not included) for supplying an analog TV signal.

OUT jack to TV's

CVBS output

• Connect the yellow composite video output to the composite video input on your TV using an RCA cable.

HDMI-out

• If your TV has an HDMI video input, connect it to an HDMI output of this unit using an HDMI cable (included).

S/PDIF output

•

Connect the coaxial digital audio output S/PDIF to the input of an amplifier to transmit the audio signal to the amplifier using a special coaxial cable (not included).

Stereo audio output

Connect the left (white) and right (red)

• terminals of the stereo audio output to the corresponding audio inputs on your TV using an RCA cable.

Controllers

Operation

Front panel

1. USB port

2. IR sensor

3. CH- button

4. CH+ button

5. POWER button

Rear panel

1 2 3 4 5

Operation

6. Antenna input

7. Antenna loop output

8. USB port

9. HDTV output

10. S/PDIF coaxial output

11. CVBS video output

12. Right audio channel

13. Left audio channel

14. DC 5V adapter socket

Operation

Remote controller

YELLOW (ZOOM): Function key (Zoom ). BLUE (TIMER): Function key (Enter Schedule menu). EPG: Shows the electronic program guide. INFO: Display information about the current channel when playing

channel or show the receiver’s software and hardware info when main menu is showing.

UP/DOWN (CH+/-): To switch channel or move the cursor. LEFT/RIGHT (VOL+/-): To increase/decrease volume; Press to

move the cursor. OK: To confirm current setting or display channel list in no-menu mode. MENU: Display main menu on TV screen, and press again to hide the menu.

EXIT: Use this key to quit current menu. (PLAY/PAUSE) : Switch pause/play mode when playback or

timeshift.

(STOP): Stop record, timeshift or stop playback multimedia file. : Fast backward to view the current playing multimedia file or

timeshift channel. : Fast forward to view the current playing multimedia file or timeshift channel. REC ( ): Start to recording when USB disk is available (Go to the previews file in file list). RADIO ( ): Switch between TV and Radio mode (Go to the next file in file list).

0~9: Numeric keys. RECALL: Go back to the previous viewed channel. AUDIO: Switching audio language.

POWER: Switch the receiver between standby

and working mode.

MUTE: To switch on/off volume. FORMAT: Quick change receiver's output

resolution by one key.

ASPECT: Switch Aspect Ratio quickly. FAV: Displays your favorite channels list; press

FAV again to access to the other favorite lists.

TIMESHIFT: Begin to timeshift. RED (TTX): Function key (Switch on teletext, if

current channel has this option, and use EXIT key to quit teletext). GREEN (SUB): Function key (Display subtitle options (availability depends on the channel)).

Changing the battery

1. Remove the battery compartment cover

on the back of the RC.

2. Insert two AAA batteries into the battery compartment making sure that the correct polarity is observed.

3. Install the cover back.

• The RC should be pointed at remote sensor within 8 meters and within 30 degrees at the left or the right side.

• Take the battery out of the RC if it is not used for a long time.

• Do not mix new and used batteries or different types of batteries. Weak batteries can leak and severely damage the RC.

• Do not expose the RC to shock, liquids, and do not place it in an area with high humidity.

Operation

General operations

STANDBY

When this unit is connected to the mains, it goes into operation mode. When the unit is running, press STANDBY button to turn the device into sleep mode. In sleep mode, press STANDBY button on the remote or press and hold this button on the panel to turn the device from sleep mode.

INFO

When viewing a TV channel, press this button to display/hide the menu pages containing various information about the current channel (frequency, reception level etc.).

EPG

Press EPG button to display the menu of the electronic TV guide (Electronic Program Guide), which displays the schedule of programs for a certain period of time for each available channel. Using this function, you can easily find programs you are interested in. Use UP/DOWN cursor buttons to select the desired TV program. Use LEFT/RIGHT cursor buttons to switch pages of the interactive program guide.

EPG-information cannot work if the

service is not provided by operator.

AUDIO

Press AUDIO to select the audio language or audio channel, if this choice is supported by the current channel.

CH+/CH-

Press these buttons to select the previous or next channel.

Cursor

Press these buttons to navigate through the various menus.

OK Press this button to confirm the selection

options in the menu.

VOL-/VOL+ Press these buttons to adjust the sound

volume level.

The number buttons

Press number buttons to enter the channel number you want or other numbers (such as passwords, play time, etc.).

REV/FWD

When playing a media file, press these buttons for fast forward or backward playback.

PLAY/PAUSE When playing a media file, press this button to start or pause the playback.

Red/Green/Yellow/Cyan buttons

Press the colored buttons to perform various operations in the edit menu of channels, teletext recording.

MUTE

Press this button to enab

TTX

Press this button to enable or disable the

Teletext (Teletext is not supported by some TV channels).

REC

When a USB drive is connected to this unit, while watching TV channels press REC to start recording video from the channel to USB. Press STOP button to stop recording.

le/disable the sound.

Operation

if this choice is supported by the current channel.

radio.

channel.

buttons to select previous/next file.

to stop playback.

Operation

SUB Click this button to select subtitle language,

RADIO Press this button to switch between TV and

RECALL Click this button to select the last-viewed

PREV/NEXT When playing a media file, press these

STOP When playing a media file, press this button

Installation

OSD Language

Country

Channel Search

EXIT

Return

•

OSD Language: select the language of the

ОК

Confirm

system menu.

•

Country: select your country.

•

Channel Search: press OK to start automatic channel search.

Program

OSD operation

1. Press MENU button to enter the setting

menu displayed on the screen.

2. Press LEFT/RIGHT cursor buttons on the

RC to select setting page.

3. Press OK button on the RC to go to the

parameter list.

4. Press UP/DOWN cursor buttons on the

RC to select a parameter to adjust.

5. Press LEFT/RIGHT cursor but

RC to adjust the selected parameter.

6. Press MENU button to return to the previous menu page. Press EXIT button on the RC to quit the menu.

Some menu items may be in grey color, in this case they are not adjustable. Pictures of OSD menu are for reference only; they may differ from the real screens.

Installation

When you start the unit for the first time, or after resetting it to factory defaults, you will see the Installation menu on the screen.

tons on the

Program Edit EPG Sort LCN

EXIT ОК

Return Confirm

•

Program Edit: Enter password

(0000

00) to access the channel editor menu.

Program

You can edit the channel list using the following

functions:

favourite, move,

skip,

lock, delete.

Favourite: Select the program you want to add to your list of favouites and press the FAV button.

Move: Select the program that you want to move — press the Red button to mark the program — press UP/DOWN to move it up and down the list and press OK to confirm.

Skip: Select the program you want to skip and press the Green button to skip it.

Lock: Choose a channel and press the Yellow button on the RC; The channel will be locked. You must enter the password

(000000 by default) to unlock it.

Operation

Delete: Choose a channel and press the Blue button on the RC; Press OK to confirm. The channel will be deleted.

• EPG: See «General operations» program

for more details about Electronic Program Guide.

•

Sort

Adjust the way the channels are sorted.

• LCN Set logical channel number on/off.


Aspect Ratio Resolution TV Format Video Output

LED Display Settings

EXIT ОК

Return Confirm

• Aspect Ratio: 4:3 LB/4:3 PS/16:9 FIT/16:9

LB.

• Resolution: 480i/480p/576i/576p/720p/

1080i/1080p/Auto.

• TV Format: PAL/NTSC/Auto.

• Video output: select composite (CVBS)

or HDMI output.

• LED Display Settings: switch the unit

display on and off and adjust its settings.

Channel Search

•

Manual Search: manually seach for each

channel and save it.

•

Country: select your country of residence.

•

Antenna Power: select to enable an

external active antenna (if installed).

Time

Time Offset Country Region Time Zone Sleep

EXIT ОК

•

Time Offset: set the GMT time zones

automatically or manually.

•

set to manual.

Time

Return Confirm

Option

OSD

Language Subtitle Laguage Audio L

Digital A

anguage

udio

Operation

Return

Channel Search

ОК

Confirm

Auto Seach Manual Search Country Antenna Power

EXIT

•

Auto Search: automatically search for

available channels and save them.

EXIT

Return

ОК

Confirm

• OSD language: select the on-screen

menu language.

• Subtitle language: select the subtitle

language.

• Audio language: select the audio track

language if several languages are supported.

• Digital audio output: select the digital

output type (PCM/RAW).

Operation

System

Parental

Guidance Set Password Restore Factory Default Information

Software Update Game Center

EXIT ОК

Return Confirm

•

Parental Guidance: lock viewing of a

channel (first enter the original password 000000 or your own password).

•

Set password: set or change the

password for the locked channels (enter

the original password 000000 or your own password). You will then be asked

to enter a new password. Note: if you forget your password use the master password 888888.

•

Restore Factory Default: reset all

settings to initial factory values. You will be asked to enter the password.

•

Information: view model, hardware and

software information.

• Software Update

software from a USB stick. Only for qualified technicians.

• Game Center:

games.

: update the unit's

to pre-installed

access

USB

Multimedia

Photo Configure Movie Configure

PVR Configure

EXIT ОК

Return Confirm

• Multimedia: if a USB storage containing

media files is connected to this unit, press OK button to show the menu in which you can select an icon to start playback of corresponding supported type file (Music/ Photo/Movie/PVR).

•

Photo Configure: adjust slide time,

mode and aspect ratio.

•

Movie Configure: adjust subtitle size,

background and font color.

•

PVR Configure:

(see below).

setting

The screen menu of your unit can be changed without prior notice and hence differ from the menu represented in this Manual.

PVR and Timeshift
