Trace Oxygen Analyzer
Teledyne Analytical Instruments i
OPERATING INSTRUCTIONS FOR
MODEL 3000ZA
Trace Oxygen Analyzer
DANGER
Toxic gases and or flammable liquids may be present in this monitoring system.
Personal protective equipment may be required when servicing this instrument.
Hazardous voltages exist on certain components internally which may persist
for a time even after the power is turned off and disconnected.
Only authorized personnel should conduct maintenance and/or servicing.
Before conducting any maintenance or servicing, consult with authorized
supervisor/manager.
P/N M75739
4/10/04
3000ZA
Teledyne Analytical Instruments ii
Copyright © 2003 Teledyne Analytical Instruments
All Rights Reserved. No part of this manual may be reproduced, transmitted, transcribed,
stored in a retrieval system, or translated into any other language or computer language in
whole or in part, in any form or by any means, whether it be electronic, mechanical,
magnetic, optical, manual, or otherwise, without the prior written consent of Teledyne
Analytical Instruments, 16830 Chestnut Street, City of Industry, CA 91749-1580.
Warranty
This equipment is sold subject to the mutual agreement that it is warranted by us free
from defects of material and of construction, and that our liability shall be limited to
replacing or repairing at our factory (without charge, except for transportation), or at
customer plant at our option, any material or construction in which defects become
apparent within one year from the date of shipment, except in cases where quotations
or acknowledgements provide for a shorter period. Components manufactured by
others bear the warranty of their manufacturer. This warranty does not cover defects
caused by wear, accident, misuse, neglect or repairs other than those performed by
Teledyne or an authorized service center. We assume no liability for direct or indirect
damages of any kind and the purchaser by the acceptance of the equipment will
assume all liability for any damage which may result from its use or misuse.
We reserve the right to employ any suitable material in the manufacture of our
apparatus, and to make any alterations in the dimensions, shape or weight of any
parts, in so far as such alterations do not adversely affect our warranty.
Important Notice
This instrument provides measurement readings to its user, and serves as a tool by
which valuable data can be gathered. The information provided by the instrument may
assist the user in eliminating potential hazards caused by his process; however, it is
essential that all personnel involved in the use of the instrument or its interface, with the
process being measured, be properly trained in the process itself, as well as all
instrumentation related to it.
The safety of personnel is ultimately the responsibility of those who control process
conditions. While this instrument may be able to provide early warning of imminent
danger, it has no control over process conditions, and it can be misused. In particular,
any alarm or control systems installed must be tested and understood, both as to how
they operate and as to how they can be defeated. Any safeguards required such as
locks, labels, or redundancy, must be provided by the user or specifically requested of
Teledyne at the time the order is placed.
Therefore, the purchaser must be aware of the hazardous process conditions. The
purchaser is responsible for the training of personnel, for providing hazard warning
methods and instrumentation per the appropriate standards, and for ensuring that
hazard warning devices and instrumentation are maintained and operated properly.
Teledyne Analytical Instruments, the manufacturer of this instrument, cannot accept
responsibility for conditions beyond its knowledge and control. No statement
expressed or implied by this document or any information disseminated by the
manufacturer or its agents, is to be construed as a warranty of adequate safety control
under the user’s process conditions.
Trace Oxygen Analyzer
Teledyne Analytical Instruments iii
Specific Model Information
The instrument for which this manual was supplied may
incorporate one or more options not supplied in the standard instrument.
Commonly available options are listed below, with check boxes. Any
that are incorporated in the instrument for which this manual is supplied
are indicated by a check mark in the box.
Instrument Serial Number: _______________________
Options Included in the Instrument with the Above Serial Number:
3000ZA-C: In addition to all the standard features,
this model also has separate ports for
zero and span gases, and built-in
control valves. The internal valves are
entirely under the control of the
3000ZA electronics to automatically
switch between gases in
synchronization with the analyxer’s
operation.
3000ZA-Rack Mnt: The 19" Relay Rack Mount units are
available with either one or two 3000
series analyzers installed in a standard
19" panel and ready to mount in a
standard rack.
3000ZA
Teledyne Analytical Instruments iv
Important Notice
Model 3000ZA complies with all of the requirements of the
Commonwealth of Europe (CE) for Radio Frequency Interference,
Electromagnetic Interference (RFI/EMI), and Low Voltage Directive
(LVD).
The following International Symbols are used throughout the
Instruction Manual. These symbols are visual indicators of important
and immediate warnings and when you must exercise CAUTION while
operating the instrument. See also the Safety Information on the next
page.
STAND-BY: Instrument is on Stand-by, but circuit is active
GROUND: Protective Earth
CAUTION: The operator needs to refer to the manual for
further information. Failure to do so may compromise the
safe operation of the equipment.
CAUTION: Risk of Electrical Shock
Trace Oxygen Analyzer
Teledyne Analytical Instruments v
Safety Messages
Your safety and the safety of others is very important. We have
provided many important safety messages in this manual. Please read
these messages carefully.
A safety message alerts you to potential hazards that could hurt you
or others. Each safety message is associated with a safety alert symbol.
These symbols are found in the manual and inside the instrument. The
definition of these symbols is described below:
GENERAL WARNING/CAUTION: Refer to the
instructions for details on the specific danger. These cautions
warn of specific procedures which if not followed could
cause bodily Injury and/or damage the instrument.
CAUTION: HOT SURFACE WARNING: This warning is
specific to heated components within the instrument. Failure
to heed the warning could result in serious burns to skin and
underlying tissue.
WARNING: ELECTRICAL SHOCK HAZARD: Dangerous
voltages appear within this instrument. This warning is
specific to an electrical hazard existing at or nearby the
component or procedure under discussion. Failure to heed
this warning could result in injury and/or death from
electrocution.
Technician Symbol: All operations marked with this
symbol are to be performed by qualified maintenance
personnel only.
NOTE: Additional information and comments regarding a
specific component or procedure are highlighted in the form
of a note.
No
Symbol
3000ZA
Teledyne Analytical Instruments vi
CAUTION: THE ANALYZER SHOULD ONLY BE USED FOR THE
PURPOSE AND IN THE MANNER DESCRIBED IN
THIS MANUAL.
IF YOU USE THE ANALYZER IN A MANNER OTHER
THAN THAT FOR WHICH IT WAS INTENDED,
UNPREDICTABLE BEHAVIOR COULD RESULT
POSSIBLY ACCOMPANIED WITH HAZARDOUS
CONSEQUENCES.
This manual provides information designed to guide you through
the installation, calibration and operation of your new analyzer. Please
read this manual and keep it available.
Occasionally, some instruments are customized for a particular
application or features and/or options added per customer requests.
Please check the front of this manual for any additional information in
the form of an Addendum which discusses specific information,
procedures, cautions and warnings that may be peculiar to your
instrument.
Manuals do get lost. Additional manuals can be obtained from
Teledyne at the address given in the Appendix. Some of our manuals are
available in electronic form via the internet. Please visit our website at:
www.teledyne-ai.com.
Trace Oxygen Analyzer
Teledyne Analytical Instruments vii
This is a general purpose instrument designed for use in a non-hazardous
area. It is the customer's responsibility to ensure safety especially when
combustible gases are being analyzed since the potential of gas leaks
always exist.
The customer should ensure that the principles of operation of this
equipment is well understood by the user. Misuse of this product in any
manner, tampering with its components, or unauthorized substitution of
any component may adversely affect the safety of this instrument.
Since the use of this instrument is beyond the control of Teledyne, no
responsibility by Teledyne, its affiliates, and agents for damage or injury
from misuse or neglect of this equipment is implied or assumed.
3000ZA
Teledyne Analytical Instruments viii
Table of Contents
Safety Messages..............................................................v
1.1 Overview 1
1.2 Typical Applications 1
1.3 Main Features of the Analyzer 1
1.4 Model Designations 2
1.5 Front Panel (Operator Interface) 3
1.6 Rear Panel (Equipment Interface) 5
Operational Theory..........................................................8
2.1 Introduction 8
2.2 ZrO2 Sensor 8
2.2.1 Principles of Operation 8
2.3 Sample System 9
2.4 Zirconium Oxide Sensor Application Notes 10
2.5 Electronics and Signal Processing 10
Installation......................................................................14
3.1 Unpacking the Analyzer 14
3.2 Mounting the Analyzer 14
3.3 Rear Panel Connections 16
3.3.1 Gas Connections 16
3.3.2 Electrical Connections 18
3.3.2.1 Primary Input Power 18
3.3.2.2 50-Pin Equipment Interface Connector 19
3.3.2.3 RS-232 Port 25
3.4 Installing the Zirconium Oxide Sensor 26
3.5 Testing the System 26
Trace Oxygen Analyzer
Teledyne Analytical Instruments ix
Operation ....................................................................... 28
4.1 Introduction 28
4.2 Using the Data Entry and Function Buttons 29
4.3 The System Function 31
4.3.1 Tracking the Oxygen Readings during Calibration 32
4.3.2 Setting up an Auto-Cal 33
4.3.3 Password Protection 34
4.3.3.1 Entering the Password 34
4.3.3.2 Installing or Changing the Password 35
4.3.4 Logout 37
4.3.5 System Self-Diagnostic Test 37
4.3.6 Version Screen 38
4.3.7 Showing Negative Oxygen Readings 38
4.4 The Zero and Span Functions 39
4.4.1 Zero Cal 40
4.4.1.1 Auto Mode Zeroing 40
4.4.1.2 Manual Mode Zeroing 41
4.4.1.3 Cell Failure 41
4.4.2 Span Cal 42
4.4.2.1 Auto Mode Spanning 42
4.4.2.2 Manual Mode Spanning 43
4.4.3 Span Failure 44
4.5 The Alarms Function 45
4.6 The Range Function 47
4.6.1 Setting the Analog Output Ranges 47
4.6.2 Fixed Range Analysis 48
4.7 The Analyze Function 49
4.8 Signal Output 49
Maintenance................................................................... 52
5.1 Routine Maintenance 52
5.2 Cell Replacement 52
5.2.1 Removing the Sensor 52
3000ZA
Teledyne Analytical Instruments x
5.3 Fuse Replacement 53
5.4 System Self Diagnostic Test 54
5.5 Major Internal Components 55
5.6 Cleaning 56
5.7 Troubleshooting 56
Appendix ........................................................................58
A-1 Specifications 58
A-2 Recommended 2-Year Spare Parts List 60
A-3 Drawing List 61
A-4 19-inch Relay Rack Panel Mount 61
A.5 Application Notes 62
Index ...............................................................................66
Trace Oxygen Analyzer
Teledyne Analytical Instruments xi
List of Figures
Figure 1-1: Model 3000ZA Front Panel 3
Figure 1-2: Model 3000ZA Rear Panel 5
Figure 2-1: Model 3000ZA Sample System 9
Figure 2-2: Flow Diagram with Options 10
Figure 2-3: Component Location 12
Figure 2-4: Electronic Block Diagram 13
Figure 3-1: Front Panel 15
Figure 3-2: Required Front Door Clearance 15
Figure 3-3: Rear Panel 16
Figure 3-4: Equipment Interface Connector Pin Arrangement 19
Figure 3-5: Remote Probe Connections 24
Figure 3-6: FET Series Resistance 24
Figure 4-1: Hierarchy of Available Functions 30
Figure 5-1: Replacing the ZrO2 Sensor 53
Figure 5-2: Removing Fuse Block from Housing 53
Figure 5-3: Installing Fuses 54
Figure 5-4: Rear Panel Removal 55
Figure A-1: Single and Dual 19" Rack Mounts 61
3000ZA
Teledyne Analytical Instruments xii
List of Tables
Table 3-1: Analog Output Connections 20
Table 3-2: Alarm Relay Contact Pins 21
Table 3-3: Remote Calibration Connections 22
Table 3-4: Range ID Relay Connections 23
Table 3-5: Commands via RS-232 Input 25
Table 3-6: Required RS-232 Options 25
Table 4-1: Output Signals 49
Table 4-2: Range ID Output Voltage 50
Table 5-1: Self-test Failure Codes 54
Table 5-2: Troubleshooting 56
Trace Oxygen Analyzer Introduction
Teledyne Analytical Instruments 1
Introduction
1.1 Overview
The Teledyne Analytical Instruments Model 3000ZA Trace
Oxygen Analyzer is a versatile microprocessor-based instrument for
detecting oxygen at the parts-per-million (ppm) level in a variety of
gases. This manual covers the Model 3000ZA General Purpose flushpanel and/or rack-mount units with CE mark. These units are for indoor
use in a non-hazardous environment.
1.2 Typical Applications
A few typical applications of the Model 3000ZA are:
• Monitoring inert gas blanketing
• Air separation and liquefaction
• Chemical reaction monitoring
• Semiconductor manufacturing
• Petrochemical process control
• Quality assurance
• Gas analysis certification.
1.3 Main Features of the Analyzer
The Model 3000ZA Trace Oxygen Analyzer is sophisticated yet
simple to use. The main features of the analyzer include:
• A 2-line alphanumeric display screen, driven by
microprocessor electronics that continuously prompts
and informs the operator.
• High resolution, accurate readings of oxygen content for
low ppm levels. Large, bright, meter readout.
• Zirconium oxide sensor designed for trace analysis. It
has a 0-10 ppm low range with less than a 0.2 ppm
Introduction 3000ZA
Teledyne Analytical Instruments 2
offset and six months warranty and an expected lifetime
of more than three years. 0-1 ppm range is possible too.
• No reference gas required
• Versatile analysis over a wide range of applications.
• Microprocessor based electronics: 8-bit CMOS
microprocessor with 32 kB RAM and 128 kB ROM.
• Three user definable output ranges (from 0-1 ppm
through 0-250 ppm) allow best match to users process
and equipment.
• Auto ranging allows analyzer to automatically select the
proper preset range for a given measurement. Manual
override allows the user to lock onto a specific range of
interest.
• Two adjustable concentration alarms and a system
failure alarm.
• Extensive self-diagnostic testing, at startup and on
demand, with continuous power-supply monitoring.
• CE compliance
• RS-232 serial digital port for use with a computer or
other digital communication device.
• Four analog outputs: two for measurement (0–1 VDC
and Isolated 4–20 mA DC) and two for range
identification.
• Convenient and versatile, steel, flush-panel or rack-
mountable case with slide-out electronics drawer.
1.4 Model Designations
3000ZA: Standard model for sample under pressure
3000ZA-C: In addition to all the standard features, this
model also has separate ports for zero and
span gases, and built-in control valves. The
internal valves are entirely under the control
of the 3000ZA electronics to automatically
switch between gases in synchronization
with the analyxer’s operation.
Trace Oxygen Analyzer Introduction
Teledyne Analytical Instruments 3
3000ZA-M: This model has current output signals (4-20-
mA) for ppm range and range ID, in
addition to voltage outputs.
3000ZA-V: Gas flow through the cell block in this
model is driven by vacuum downstream
from the cell block instead of upstream
pressure. The internal restrictor is located
downstream from the cell block to support
this configuration. All other standard
features are present in this model.
1.5 Front Panel (Operator Interface)
The standard 3000ZA is housed in a rugged metal case with all
controls and displays accessible from the front panel. See Figure 1-1.
The front panel has thirteen buttons for operating the analyzer, a digital
meter, an alphanumeric display, and a window for viewing the sample
flowmeter.
Figure 1-1: Model 3000ZA Front Panel
Introduction 3000ZA
Teledyne Analytical Instruments 4
Function Keys:
Six touch-sensitive membrane switches are used to change the specific
function performed by the analyzer:
• Analyze Perform analysis for oxygen content of a sample
gas.
• System Perform system-related tasks (described in detail
in chapter 4, Operation.).
• Span Span calibrate the analyzer.
• Zero Zero calibrate the analyzer.
• Alarms Set the alarm setpoints and attributes.
• Range Set up the 3 user definable ranges for the
instrument.
Data Entry Keys:
Six touch-sensitive membrane switches are used to input data to the
instrument via the alphanumeric VFD display:
• Left & Right Arrows Select between functions currently
displayed on the VFD screen.
• Up & Down Arrows Increment or decrement values of
functions currently displayed.
• Enter Advances VFD display to the next screen in a series
or returns to the Analyze screen if none remain.
• Escape Backs VFD display to the previous screen in a series
or returns to the Analyze screen if none remain.
Digital Meter Display:
The meter display is a Light Emitting Diode (LED) device that produces
large, bright, 7-segment numbers that are legible in any lighting. It
produces a continuous readout from 0-250 ppm. It is accurate across all
analysis ranges without the discontinuity inherent in analog range
switching.
Alphanumeric Interface Screen:
The VFD screen is an easy-to-use interface from operator to analyzer. It
displays values, options, and messages that give the operator immediate
feedback.
Flowmeter:
Monitors the flow of gas past the sensor. Readout is 0.2 to 2.4 standard
Trace Oxygen Analyzer Introduction
Teledyne Analytical Instruments 5
Standby Button :
The Standby turns off the display and outputs but circuitry is still
operating.
CAUTION: THE POWER CABLE MUST BE UNPLUGGED TO
FULLY DISCONNECT POWER FROM THE
INSTRUMENT. WHEN CHASSIS IS EXPOSED OR
WHEN ACCESS DOOR IS OPEN AND POWER CABLE
IS CONNECTED, USE EXTRA CARE TO AVOID
CONTACT WITH LIVE ELECTRICAL CIRCUITS.
Access Door:
For access to the ZrO2 sensor, the front panel swings open when the
latch in the upper right corner of the panel is pressed all the way in with
a narrow gauge tool. Accessing the main circuit board requires
unfastening rear panel screws and sliding the unit out of the case.
1.6 Rear Panel (Equipment Interface)
The rear panel, shown in Figure 1-2, contains the gas and electrical
connectors for external inlets and outlets. Some of those depicted are
optional and may not appear on your instrument. The connectors are
described briefly here and in detail in Chapter 3 Installation.
Figure 1-2: Model 3000ZA Rear Panel
Introduction 3000ZA
Teledyne Analytical Instruments 6
• Power Connection Universal AC power source.
• Gas Inlet and Outlet One inlet (must be externally valved)
and one exhaust out. Three inlets
when option “C” is ordered.
• 9-Pin RS-232 Port Serial digital concentration signal
output and control input.
• 50-Pin Equipment Interface Port
Analog Outputs: 0–1 VDC oxygen concentration plus
0-1 V dc range ID
Alarm Connections: 2 concentration alarms and 1
system alarm.
Remote Valve: Used in the 3000ZA for controlling
external solenoid valves only.
Remote Span/Zero: Digital inputs allow external
control of analyzer calibration.
Calibration Contact: To notify external equipment that
instrument is being calibrated and readings are not
monitoring sample.
Range ID Contacts: Four separate, dedicated, range
relay contacts. Low, Medium, High, Cal.
Network I/O: Serial digital communications for local
network access. For future expansion. Not currently
implemented.
Optional
• Calibration Gas Ports: Separate fittings for zero, span, and
sample gas input, internal valves
for automatic gas switching.
• Current Signal Output: Additional isolated 4–20 mA
DC plus optional 4–20 mA DC
range ID.
Note: If you require highly accurate Auto-Cal timing, use external
Auto-Cal control where possible. The internal clock in the
Model 3000ZA is accurate to 2-3 %. Accordingly, internally
Trace Oxygen Analyzer Introduction
Teledyne Analytical Instruments 7
scheduled calibrations can vary 2-3 % per day.
Operational Theory 3000ZA
Teledyne Analytical Instruments 8
Operational Theory
2.1 Introduction
The analyzer is composed of three subsystems:
1. Zirconium Oxide (ZrO2) Sensor
2. Sample System
3. Electronic Signal Processing, Display and Control
The sample system is designed to accept the sample gas and
transport it through the analyzer without contaminating or altering the
sample prior to analysis. The ZrO2 sensor is a device that translates the
amount of oxygen present in the sample into an electrical current. The
electronic signal processing, display and control subsystem simplifies
operation of the analyzer and accurately processes the sampled data. The
microprocessor controls all signal processing, input/output and display
functions for the analyzer.
2.2 ZrO2 Sensor
2.2.1 Principles of Operation
Teledyne’s zirconium oxide sensor is a miniature solid state sensor.
It uses a stabilized zirconia disc as an electrolyte with a sensing
electrode (the cathode) and a counter electrode (the anode) on each side
of the disc. The zirconia is heated to a temperature of about 500°C via a
built-in heater. By applying a suitable reference voltage (approximately
0.75 volt) across the cathode and anode, the heated zirconia acts as an
electrolyte which is capable of moving oxygen ions within its crystalline
structure. This allows for the reduction of oxygen molecules reaching
the cathode and the generation of a current equivalent to the parts per
million oxygen in the sample gas.
This sensor has been modified to sense low levels of oxygen—less
than 1 ppm and generate a current proportional to the concentration. The
sensor is designed for long term stability and an operating life of 5 years.
Trace Oxygen Analyzer Operational Theory
Teledyne Analytical Instruments 9
2.3 Sample System
The sample system delivers gases to the ZrO2 sensor from the
analyzer rear panel inlet. Depending on the mode of operation either
sample or calibration gas is delivered.
The Model 3000ZA sample system is designed and fabricated to
ensure that the oxygen concentration of the gas is not altered as it travels
through the sample system.
The sample system for the standard instrument incorporates
compression tube fittings for sample inlet and 1/4” outlet tube
connections at the rear panel. The sample or calibration gas that flows
through the system is monitored by a flowmeter downstream from the
cell. Figure 2-1 shows the piping layout for the standard model.
Figure 2-2 shows the flow diagram for sampling systems used for
the three configurations offered as options for this instrument. In the
standard instrument, calibration gases can be connected directly to the
Sample In port by teeing to the port with appropriate valves.
Figure 2-1: Model 3000ZA Sample System
Operational Theory 3000ZA
Teledyne Analytical Instruments 10
Figure 2-2: Flow Diagram with Options
2.4 Zirconium Oxide Sensor Application Notes
The following sample gases require conditioning prior to entering
the sensor:
• Flammable gases such as methane, alcohol and carbon
monoxide may cause a measurement error. They must be
filtered from the sample gas before entering the cell.
• Gases containing halogen atoms (F, Cl, Br, etc.) such as
Freon, must be filtered before entering the cell. The sensor
will be damaged by the decomposition of Freon.
• Gases containing SOx, H2S, silicone vapor and adhesives
must not enter the sensor. These components adversely affect
the performance of the sensor.
• Dust and oil should be filtered from the sample gas.
• Water vapor in contact with the sensor will damage the
sensor. Use a moisture trap or filter to remove any water
vapor in the sample.
2.5 Electronics and Signal Processing
The Model 3000ZA Trace Oxygen Analyzer uses an 8031
microcontroller with 32 kB of RAM and 128 kB of ROM to control all
signal processing, input/output, and display functions for the analyzer.
System power is supplied from a universal power supply module designed
to be compatible with any international power source. Figure 2-3 shows
the location of the power supply and the main electronic PC boards.
Trace Oxygen Analyzer Operational Theory
Teledyne Analytical Instruments 11
The signal processing electronics including the microprocessor,
analog to digital, and digital to analog converters are located on the
motherboard at the bottom of the case. The preamplifier board is
mounted on top of the motherboard as shown in the figure. These boards
are accessible after removing the back panel. Figure 2-4 is a block
diagram of the analyzer electronics.
In the presence of oxygen the cell generates a current. A current to
voltage amplifier converts this current to a voltage, which is amplified in
the second stage amplifier. The output from the second stage amplifier is
sent to an 18 bit analog to digital converter controlled by the
microprocessor.
The high operating temperature of the ZrO2 sensor is required for
proper operation of the sensor. The amplifier PCB contains a circuit that
drives the heater embedded in the sensor. The voltage across the heater
rises slowly to avoid damaging the heater/sensor assembly. After a few
minutes, the sensor will be at the proper operating temperature.
The digital concentration signal along with input from the control
panel is processed by the microprocessor, and appropriate control
signals are directed to the display, alarms and communications port. The
same digital information is also sent to a 12 bit digital to analog
converter that produces the 4-20 mA dc and the 0-1 VDC analog
concentration signal outputs, and the analog range ID outputs.
Signals from the power supply are also monitored, and through the
microprocessor, the system failure alarm is activated if a malfunction is
detected.
Operational Theory 3000ZA
Teledyne Analytical Instruments 12
Figure 2-3: Component Location
Trace Oxygen Analyzer Operational Theory
Teledyne Analytical Instruments 13
Figure 2-4: Electronic Block Diagram
Installation 3000ZA
Teledyne Analytical Instruments 14
Installation
Installation of the Model 3000ZA Analyzer includes:
1. Unpacking
2. Mounting
3. Gas connections
4. Electrical connections
5. Installing the sensor
6. Testing the system.
3.1 Unpacking the Analyzer
The analyzer is shipped with all the materials you need to install
and prepare the system for operation. Carefully unpack the analyzer and
inspect it for damage. Immediately report any damage to the shipping
agent.
3.2 Mounting the Analyzer
The Model 3000ZA is for indoor use in a general purpose area. It is
NOT for hazardous environments of any type.
The standard model is designed for flush panel mounting. Figure 3-1
is an illustration of the 3000TA standard front panel (the 3000ZA is
similar) and mounting bezel. There are four mounting holes—one in each
corner of the rigid frame. Drawings at the back of this manual illustrate
the dimensions and mounting hole spacing for this unit.
On special order, a 19" rack-mounting panel can be provided. For
rack mounting, one or two 3000 series analyzers can be flush-panel
mounted on the rack panel. See Appendix for dimensions of the
mounting panel.
Trace Oxygen Analyzer Installation
Teledyne Analytical Instruments 15
Figure 3-1: Front Panel of the Model 3000TA (Model 3000ZA similar)
All operator controls, except the flow control needle valve, are
mounted on the control panel, which is hinged on the left edge and
doubles as the door that provides access to the sensor and cell block
inside the instrument. The door latch is spring loaded and will swing
open when the button in the center of the latch (upper right corner) is
pressed all the way in with a narrow gauge tool (less than 0.18 inch
wide). Allow clearance for the door to open in a 90-degree arc of radius
7.125 inches. See Figure 3-2.
Figure 3-2: Required Front Door Clearance
Installation 3000ZA
Teledyne Analytical Instruments 16
3.3 Rear Panel Connections
Figure 3-3 shows the Model 3000ZA rear panel. There are ports for
gas, power, and equipment interface. The Zero In and Span In ports are
not included on the standard model but are available as options.
Figure 3-3: Rear Panel of the Model 3000ZA with Span and Zero Ports
3.3.1 Gas Connections
Before using this instrument, it should be determined if the unit will
be used for pressurized service or vacuum service and low pressure
applications. The kit included with the instrument contains two
restrictors and a union for 1/4” diameter tubing. Notice that there are
two 1-3/4” long, 1/4” diameter restrictors. There is an open end and a
closed end with a small circular orifice. The restrictor without the blue
sticker is for low pressure applications and vacuum service. For high
Trace Oxygen Analyzer Installation
Teledyne Analytical Instruments 17
pressure applications (5-50 psig) use the restrictor that has a blue sticker
on the body.
• Pressurized service: Connect the restrictor with the blue dot
to the Sample In port. The small circular orifice should face
AWAY from the back of the unit (against the direction of gas
flow).
Note: Remove the blue sticker from the restrictor before using.
• Low pressure applications: Connect the restrictor without
the blue sticker in the same manner (less than 5 psig).
• Vacuum Service: For applications involving pressure less
than 5-10 in Hg) connect the restrictor without the blue
sticker to the Exhaust Out port. The small circular orifice
should face TOWARD the back of the unit (against the
direction of gas flow).
CAUTION: OPERATING THE UNIT WITHOUT RESTRICTORS CAN
CAUSE DAMAGE TO THE SENSOR.
The unit is manufactured with 1/4” tube fittings and includes 6 mm
adapters for metric system installations. For a safe connection:
1. Insert the tube into the fitting and finger tighten the nut until
the tubing cannot be rotated freely by hand in the fitting. This
may require an additional 1/8 turn beyond finger tight.
2. Hold the fitting body steady with a backup wrench. using
another wrench, rotate the nut another 1-1/4 turns.
SAMPLE IN:
In the standard model, gas connections are made at the SAMPLE IN and
EXHAUST OUT connections. Calibration gases must be tee'd into the
Sample inlet with appropriate valves.
The inlet gas pressure should be reasonably regulated. Pressures
between 2 and 50 psig are acceptable as long as the pressure, once
established, will keep the front panel flowmeter reading in an acceptable
range (0.5 to 2.0 SLPM). For non-pressurized sample or very low
pressure, (less than 2 psig) vacuum service plumbing is recommended.
Exact figures will depend on your process.
Installation 3000ZA
Teledyne Analytical Instruments 18
If greater sample flow is required for improved response time,
install a bypass in the sampling system upstream of the analyzer input.
EXHAUST OUT:
Exhaust connections must be consistent with the hazard level of the
constituent gases. Check local, state, and federal laws, and ensure that
the exhaust stream vents to an appropriately controlled area, if required.
ZERO IN and SPAN IN (Optional):
These are additional ports for inputting span and zero gas. There are
electrically operated valves inside for automatic switching between
calibration and sample gases. These valves are completely under control
of the 3000ZA electronics. They can be externally controlled only
indirectly through the remote cal inputs as described below.
Pressure, flow, and safety considerations are the same as prescribed for
the SAMPLE IN inlet above.
3.3.2 Electrical Connections
For safe connections, no uninsulated wiring should be able to come
in contact with fingers, tools or clothing during normal operation.
CAUTION: USE SHIELDED CABLES. ALSO, USE PLUGS THAT
PROVIDE EXCELLENT EMI/RFI PROTECTION. THE
PLUG CASE MUST BE CONNECTED TO THE CABLE
SHIELD, AND IT MUST BE TIGHTLY FASTENED TO
THE ANALYZER WITH ITS FASTENING SCREWS.
ULTIMATELY, IT IS THE INSTALLER WHO ENSURES
THAT THE CONNECTIONS PROVIDE ADEQUATE
EMI/RFI SIELDING.
3.3.2.1 Primary Input Power
The power cord receptacle and fuse block are located in the same
assembly. Insert the power cord into the power cord receptacle.
CAUTION: POWER IS APPLIED TO THE INSTRUMENT'S
CIRCUITRY AS LONG AS THE INSTRUMENT IS
CONNECTED TO THE POWER SOURCE. THE RED
SWITCH ON THE FRONT PANEL IS FOR SWITCHING
POWER ON OR OFF TO THE DISPLAYS AND
OUTPUTS ONLY.
The universal power supply requires a n 85–250 VAC, 47-63 Hz
power source.
Trace Oxygen Analyzer Installation
Teledyne Analytical Instruments 19
Fuse Installation: The fuse block, at the right of the power cord
receptacle, accepts US or European size fuses. A jumper replaces the
fuse in whichever fuse receptacle is not used. Fuses are not installed at
the factory. Be sure to install the proper fuse as part of installation. (See
Fuse Replacement in Chapter 5, Maintenance.)
3.3.2.2 50-PIN EQUIPMENT INTERFACE CONNECTOR
Figure 3-4 shows the pin layout of the Equipment Interface
Connector. The arrangement is shown as seen when the viewer faces the
rear panel of the analyzer. The pin numbers for each input/output function
are given where each function is described in the paragraphs below.
Figure 3-4: Equipment Interface Connector Pin Arrangement
Analog Outputs: There are four DC output signal pins—two pins per
output. For polarity, see Table 3-1. The outputs are:
• 0–1 VDC % of Range:Voltage rises linearly with
increasing oxygen, from 0 V at 0
ppm to 1 V at full scale ppm. (Full
scale = 100% of programmable
range.)
• 0–1 VDC Range ID: 0.25 V = Low Range, 0.5 V =
Medium Range, 0.75 V = High
Range.
• 4–20 mA DC % Range: Current increases linearly with
increasing oxygen, from 4 mA at 0
ppm to 20 mA at full scale ppm.
(Full scale = 100% of
programmable range)
• (optional) 4–20 mA DC Range ID: 8 mA = Low Range
12 mA = Medium Range
16 mA = High Range
Installation 3000ZA
Teledyne Analytical Instruments 20
Table 3-1: Analog Output Connections
Pin Function
3 + Range ID, 4-20 mA, floating
4 – Range ID, 4-20 mA, floating
5 + ppm Range, 4-20 mA, floating (optional)
6 – ppm Range, 4-20 mA, floating (optional)
8 + Range ID, 0-1 VDC
23 – Range ID, 0-1 V dc, negative ground
24 + ppm Range, 0-1 VDC
7 – ppm Range, 0-1 VDC, negative ground
Alarm Relays: The nine alarm-circuit connector pins connect to the
internal alarm relay contacts. Each set of three pins provides one set of
Form C relay contacts. Each relay has both normally open and normally
closed contact connections. The contact connections are shown in Table
3-2. They are capable of switching up to 3 amperes at 250 V ac into a
resistive load. The connectors are:
Threshold Alarm 1:
• Can be configured as high (actuates when concentration
is above threshold), or low (actuates when concentration
is below threshold).
• Can be configured as failsafe or non-failsafe.
• Can be configured as latching or non-latching.
• Can be configured out (defeated).
Threshold Alarm 2:
• Can be configured as high (actuates when concentration
is above threshold), or low (actuates when concentration
is below threshold).
• Can be configured as failsafe or non-failsafe.
• Can be configured as latching or non-latching.
• Can be configured out (defeated).
System Alarm:
Trace Oxygen Analyzer Installation
Teledyne Analytical Instruments 21
• Actuates when DC power supplied to circuits is
unacceptable in one or more parameters. Permanently
configured as failsafe and latching. Cannot be defeated.
Actuates if self test fails.
• (Reset by pressing button to remove power. Then
press again and any other button EXCEPT System to
resume.
• Further detail can be found in Chapter 4, Section 4-5.
Table 3-2: Alarm Relay Contact Pins
Pin Contact
45 Threshold Alarm 1, normally closed contact
28 Threshold Alarm 1, moving contact
46 Threshold Alarm 1, normally open contact
42 Threshold Alarm 2, normally closed contact
44 Threshold Alarm 2, moving contact
43 Threshold Alarm 2, normally open contact
36 System Alarm, normally closed contact
20 System Alarm, moving contact
37 System Alarm, normally open contact
Digital Remote Cal Inputs: Accept 0 V (off) or 24 VDC (on) inputs for
remote control of calibration. (See Remote Calibration Protocol below.)
See Table 3-3 for pin connections.
Zero: Floating input. 5 to 24 V input across the + and – pins puts the
analyzer into the Zero mode. Either side may be grounded at
the source of the signal. 0 to 1 volt across the terminals allows
Zero mode to terminate when done. A synchronous signal must
open and close the external zero valve appropriately. See
Remote Probe Connector. (The –C option internal valves
operate automatically.)
Installation 3000ZA
Teledyne Analytical Instruments 22
Span: Floating input. 5 to 24 V input across the + and – pins puts the
analyzer into the Span mode. Either side may be grounded at
the source of the signal. 0 to 1 volt across the terminals allows
Span mode to terminate when done. A synchronous signal
must open and close external span valve appropriately. See
Figure 3-5 Remote Probe Connector. (The –C option internal
valves operate automatically.)
Cal Contact: This relay contact is closed while analyzer is spanning
and/or zeroing. (See Remote Calibration Protocol below.)
Table 3-3: Remote Calibration Connections
Pin Function
9 + Remote Zero
11 – Remote Zero
10 + Remote Span
12 – Remote Span
40 Cal Contact
41 Cal Contact
Remote Calibration Protocol: To properly time the Digital Remote Cal
Inputs to the Model 3000ZA Analyzer, the customer's controller must
monitor the Cal Relay Contact.
When the contact is OPEN, the analyzer is analyzing, the Remote
Cal Inputs are being polled, and a zero or span command can be sent.
When the contact is CLOSED, the analyzer is already calibrating. It
will ignore your request to calibrate, and it will not remember that
request.
Once a zero or span command is sent, and acknowledged (contact
closes), release it. If the command is continued until after the zero or
span is complete, the calibration will repeat and the Cal Relay Contact
(CRC) will close again.
For example:
1. Test the CRC. When the CRC is open, Send a zero command
until the CRC closes (The CRC will quickly close.)
2. When the CRC closes, remove the zero command.
Trace Oxygen Analyzer Installation
Teledyne Analytical Instruments 23
3. When CRC opens again, send a span command until the
CRC closes. (The CRC will quickly close.)
4. When the CRC closes, remove the span command.
When CRC opens again, zero and span are done, and the sample is
being analyzed.
Note: The Remote Valve connections (described below) provides
signals to ensure that the zero and span gas valves will be
controlled synchronously. If you have the –C Internal valve
option—which includes additional zero and span gas
inputs—the 3000ZA automatically regulates the zero, span
and sample gas flow.
Range ID Relays: Four dedicated Range ID relay contacts. The first
three ranges are assigned to relays in ascending order—Low range is
assigned to Range 1 ID, Medium range is assigned to Range 2 ID, and
High range is assigned to Range 3 ID. The fourth range is reserved for
the Air Cal Range (25%). Table 3-4 lists the pin connections.
Table 3-4: Range ID Relay Connections
Pin Function
21 Range 1 ID Contact
38 Range 1 ID Contact
22 Range 2 ID Contact
39 Range 2 ID Contact
19 Range 3 ID Contact
18 Range 3 ID Contact
34 Spare Contact
35 Spare Contact
Network I/O: A serial digital input/output for local network protocol.
At this printing, this port is not yet functional. It is to be used for future
options to the instrument. Pins 13 (+) and 29 (–).
Remote Valve Connections: The 3000ZA is a single-chassis
instrument, which has no Remote Valve Unit. Instead, the Remote Valve
connections are used as a method for directly controlling external
sample/zero/span gas valves. See Figure 3-5.
Installation 3000ZA
Teledyne Analytical Instruments 24
Figure 3-5: Remote Probe Connections
The voltage from these outputs is nominally 0 V for the OFF and
15 VDC for the ON conditions. The maximum combined current that
can be pulled from these output lines is 100 mA. (If two lines are ON at
the same time, each must be limited to 50 mA, etc.) If more current
and/or a different voltage is required, use a relay, power amplifier, or
other matching circuitry to provide the actual driving current.
In addition, each individual line has a series FET with a nominal
ON resistance of 5 ohms (9 ohms worst case). This can limit the
obtainable voltage, depending on the load impedance applied. See
Figure 3-6.
Figure 3-6: FET Series Resistance
Trace Oxygen Analyzer Installation
Teledyne Analytical Instruments 25
3.3.2.3 RS-232 PORT
The digital signal output is a standard, full duplex RS-232 serial
communications port used to connect the analyzer to a computer,
terminal, or other digital device. It requires a standard 9-pin D
connector.
The output data is status information, in digital form, updated every
two seconds. Status is reported in the following order:
• The concentration in ppm or percent
• The range in use (HI, MED, LO)
• The span of the range (0-100 ppm, etc)
• Which alarms—if any—are disabled (AL–x DISABLED)
• Which alarms—if any—are tripped (AL–x ON).
Each status output is followed by a carriage return and line feed.
Three input functions using RS-232 have been implemented to
date. They are described in Table 3-5.
Table 3-5: Commands via RS-232 Input
Command Description
as<enter> Immediately starts an autospan.
az<enter> Immediately starts an autozero.
st<enter> Toggling input. Stops/Starts any
status message output from the
RS-232, until st<enter> is sent
again.
The RS-232 protocol allows some flexibility in its implementation.
Table 3-6 lists certain RS-232 values that are required by the 3000ZA
implementation.
Table 3-6: Required RS-232 Options
Parameter Setting
Baud 2400
Byte 8 bits
Installation 3000ZA
Teledyne Analytical Instruments 26
Parity none
Stop Bits 1
Message Interval 2 seconds. When CRC opens
again, zero and span are done,
and the sample is being analyzed.
Range ID Relays: There are three dedicated Range ID relay contacts.
Three ranges are assigned to relays in ascending order—Low range is
assigned to Range 1 ID, Medium range is assigned to Range 2 ID, and
High range is assigned to Range 3 ID.
Network I/O: A serial digital input/output for local network protocol.
At this printing, this port is not yet functional. It is to be used in future
options to the instrument.
RS-232 Port: The digital signal output is a standard RS-232 serial
communications port used to connect the analyzer to a computer,
terminal, or other digital device. It requires a standard 9-pin D
connector.
The data is status information, in digital form, updated every two
seconds. Status is reported in the following order:
• The concentration in ppm or percent
• The range in use (HI, MED, LO)
• The span of the range (0-100 ppm, etc)
• Which alarms—if any—are disabled (AL–x DISABLED)
• Which alarms—if any—are tripped (AL–x ON).
3.4 Installing the Zirconium Oxide Sensor
The ZrO2 sensor may not installed in the cell block when the
instrument is shipped. It must be installed before the analyzer is placed
in service.
When the ZrO2 sensor needs to be installed or replaced, follow the
procedures in Section 5.2.
3.5 Testing the System
Before plugging the instrument into the power source:
Trace Oxygen Analyzer Installation
Teledyne Analytical Instruments 27
• Check the integrity and accuracy of the gas connections.
Make sure there are no leaks.
• Check the integrity and accuracy of the electrical
connections. Make sure there are no exposed conductors.
• Check that inlet sample pressure is within the accepted range
(see Section 3.3.1).
• Power up the system, and test it by repeating the Self-
Diagnostic Test as described in Chapter 4, Section 4.3.5.
Operation 3000ZA
Teledyne Analytical Instruments 28
Operation
4.1 Introduction
Once the analyzer has been installed, it can be configured for your
application. To do this you will:
• Set system parameters.
• Establish a security password, if desired, requiring Operator
to log in.
• Establish and start an automatic calibration cycle, if desired.
• Calibrate the instrument.
• Define the three user selectable analysis ranges, then choose
autoranging or select a fixed range of analysis, as required.
• Set alarm setpoints, and modes of alarm operation (latching,
failsafe, etc).
Before you configure your 3000ZA, these default values are in
effect:
Ranges: LO = 10 ppm, MED = 100 ppm, HI = 250 ppm.
Auto Ranging: ON
Alarm Relays: Defeated, 10.00 ppm, HI, Not failsafe, Not
latching.
Zero: Auto, every 0 days at 0 hours.
Span: Auto, at 000,008.00 ppm, every 0 days at 0
hours.
If you choose not to use password protection, the default password
is automatically displayed on the password screen when you start up,
and you simply press Enter for access to all functions of the analyzer.
Trace Oxygen Analyzer Operation
Teledyne Analytical Instruments 29
4.2 Using the Data Entry and Function Buttons
Data Entry Buttons: The __ arrow buttons select options from the
menu currently being displayed on the VFD screen. The selected option
blinks.
When the selected option includes a modifiable item, the __ arrow
buttons can be used to increment or decrement that modifiable item.
The Enter button is used to accept any new entries on the VFD
screen. The Escape button is used to abort any new entries on the VFD
screen that are not yet accepted by use of the Enter button.
Figure 4-1 shows the hierarchy of functions available to the
operator via the function buttons. The six function buttons on the
analyzer are:
• Analyze. This is the normal operating mode. The analyzer
monitors the oxygen content of the sample, displays the
percent of oxygen, and warns of any alarm conditions.
• System. The system function consists of seven sub functions
that regulate the internal operations of the analyzer:
• Track or hold values during calibration
• Auto-Cal setup
• Password assignment
• Self -test initiation
• Checking software version
• Logging out.
• Show Negative
• Zero. Used to set up a zero calibration.
• Span. Used to set up a span calibration.
• Alarms. Used to set the alarm setpoints and determine
whether each alarm will be active or defeated, HI or LO
acting, latching, and/or failsafe.
• Range. Used to set up three analysis ranges that can be
switched automatically with auto-ranging or used as
individual fixed ranges.
Operation 3000ZA
Teledyne Analytical Instruments 30
Figure 4-1: Hierarchy of Available Functions
Any function can be selected at any time by pressing the
appropriate button (unless password restrictions apply). The order as
presented in this manual is appropriate for an initial setup.
Each of these functions is described in greater detail in the
following procedures. The VFD screen text that accompanies each
operation is reproduced, at the appropriate point in the procedure, in a
Ariel Narrow Bold type style. Pushbutton names are printed in Oblique
type.
Trace Oxygen Analyzer Operation
Teledyne Analytical Instruments 31
4.3 The System Function
The sub fuctions of the System function are described below.
Specific procedures for their use follow the descriptions:
• Auto-Cal: Used to define an automatic calibration sequence
and/or start an Auto-Cal.
• PSWD: Security can be established by choosing a 5 digit
password (PSWD) from the standard ASCII character set. (See
Installing or Changing the Password, below, for a table of ASCII
characters available.) Once a unique password is assigned and
activated, the operator MUST enter the UNIQUE password to
gain access to set-up functions which alter the instrument's
operation, such as setting the instrument span or zero setting,
adjusting the alarm setpoints, or defining analysis ranges.
• After a password is assigned, the operator must log out to
activate it. Until then, anyone can continue to operate the
instrument without entering the new password.
• Only one password can be defined. Before a unique
password is assigned, the system assigns TETAI by
default. This allows access to anyone. After a unique
password is assigned, to defeat the security, the password
must be changed back to TETAI.
• Logout: Logging out prevents unauthorized tampering with
analyzer settings.
• More: Select and enter More to get a new screen with
additional sub functions listed.
• Self–Test: The instrument performs a self-diagnostic test to
check the integrity of the power supply, output boards and
amplifiers.
• Version: Displays Manufacturer, Model, and Software
Version of instrument.
• Show Negative: The operator selects whether display can
show negative oxygen readings or not.
• TRAK/HLD: The operator sets whether the instrument
analog outputs track the concentration change during
calibration and sets a time delay for the concentration alarms
after calibration
Operation 3000ZA
Teledyne Analytical Instruments 32
4.3.1 Tracking the Oxygen Readings during
Calibration and Alarm delay
The user has the option of setting the preference as to whether the
analog outputs track the display readings during calibration or not. To
set the preference, press the System key once and the first System menu
will appear in the VFD display:
TRAK/HLD Auto-Cal
PSWD Logout More
TRAK/HLD should be blinking. To enter this system menu press the
Enter key once:
Output Sttng: TRACK
Alarm Dly: 10 min
—or—
Output Sttng: HOLD
Alarm Dly: 10 min
In the first line, TRACK or HOLD should be blinking. The operator
can toggle between TRACK and HOLD with the Up or Down keys. When
TRACK is selected, the analog outputs (0-1 VDC and 4-20 ma) and the
range ID contacts will track the instrument readings during calibration
(either zero or span). TRACK is the factory default.
When HOLD is selected, the analog outputs (0-1 VDC and 4-20 ma)
and the range ID contacts will freeze on their last state before entering
one of the calibration modes. When the instrument returns to the
Analyze mode, either by a successful or an aborted calibration, there
will be a three-minute delay before the analog outputs and the range ID
contacts start tracking again.
The concentration alarms freeze on their last state before entering
calibration regardless of selecting HOLD or TRACK. But, when HOLD is
selected the concentration alarms will remain frozen for the time
displayed in the second line of the TRAK/HLD menu after the analyzer
returns to the Analyze mode.
Trace Oxygen Analyzer Operation
Teledyne Analytical Instruments 33
The factory default is three minutes, but the delay time is
programmable. To adjust to delay time use the Left or Right arrow keys.
When the time displayed on the second line blinks, it can be adjusted by
Pressing the Up or Down keys to increase or decrease its value. The
minimum delay is 1 minute, the maximum is 30.
This preference is stored in non-volatile memory so that it is
recovered if power is removed from the instrument.
4.3.2 Setting up an Auto-Cal
When proper automatic valving is connected (see Chapter 3,
Installation), the Analyzer can cycle itself through a sequence of steps
that automatically calibrates the instrument.
Note: If you require highly accurate Auto-Cal timing, use external
Auto-Cal control where possible. The internal clock in the
Model 3000ZA is acurate to 2-3 %. Accordingly, internally
scheduled calibrations can vary 2-3 % per day.
To setup an Auto–Cal cycle:
Choose System from the Function buttons. The LCD will display
five sub functions.
TRAK/HLD Auto—Cal
PSWD Logout More
Use __ arrows to blink Auto—Cal, and press Enter. A new screen
for Span/Zero set appears.
Span OFF Nxt: 0d 0h
Zero OFF Nxt: 0d 0h
Press __ arrows to blink Span (or Zero), then press Enter again.
(You won’t be able to set OFF to ON if a zero interval is entered.) A
Span Every ... (or Zero Every ...) screen appears.
Span Every 0 d
Start 0 h from now
Use __ arrows to set an interval value, then use __ arrows to move
to the start-time value. Use__ arrows to set a start-time value.
To turn ON the Span and/or Zero cycles (to activate Auto-Cal):
Press System again, choose Auto—Cal, and press Enter again. When the
Span/Zero values screen appears, use the __ arrows to blink the Span (or
Operation 3000ZA
Teledyne Analytical Instruments 34
Zero) OFF/ON field. Use __ arrows to set the OFF/ON field to ON. You
can now turn these fields ON because there is a nonzero span interval
defined.
4.3.3 Password Protection
If a password is assigned, then setting the following system
parameters can be done only after the password is entered: span and zero
settings, alarm setpoints, analysis range definitions, switching between
autoranging and manual override, setting up an auto-cal, and assigning a
new password. However, the instrument can still be used for analysis or
for initiating a self-test without entering the password.
If you have decided not to employ password security, use the
default password TETAI. This password will be displayed automatically
by the microprocessor. The operator just presses the Enter key to be
allowed total access to the instrument’s features.
Note: If you use password security, it is advisable to keep a copy
of the password in a separate, safe location.
4.3.3.1 ENTERING THE PASSWORD
To install a new password or change a previously installed
password, you must key in and Enter the old password first. If the
default password is in effect, pressing the Enter button will enter the
default TETAI password for you.
Press System to enter the System mode.
TRAK/HLD Auto—Cal
PSWD Logout More
Use the __ arrow keys to scroll the blinking over to PSWD, and
press Enter to select the password function. Either the default TETAI
password or AAAAA place holders for an existing password will appear
on screen depending on whether or not a password has been previously
installed.
T E T A I
Enter PWD
—or—
A A A A A
Enter PWD
Trace Oxygen Analyzer Operation
Teledyne Analytical Instruments 35
The screen prompts you to enter the current password. If you are
not using password protection, press Enter to accept TETAI as the
default password. If a password has been previously installed, enter the
password using the __ arrow keys to scroll back and forth between
letters, and the __ arrow keys to change the letters to the proper
password. Press Enter to enter the password.
If the password is accepted, the screen will indicate that the
password restrictions have been removed and you have clearance to
proceed.
PSWD Restrictions
Removed
In a few seconds, you will be given the opportunity to change this
password or keep it and go on.
Change Password?
<ENT>=Yes <ESC>=No
Press Escape to move on, or proceed as in Changing the
Password, below.
4.3.3.2 INSTALLING OR CHANGING THE PASSWORD
If you want to install a password, or change an existing password,
proceed as above in Entering the Password. When you are given the
opportunity to change the password:
Change Password?
<ENT>=Yes <ESC>=No
Press Enter to change the password (either the default TETAI or
the previously assigned password), or press Escape to keep the existing
password and move on.
If you chose Enter to change the password, the password
assignment screen appears.
T E T A I
<ENT> To Proceed
—or—
A A A A A
<ENT> To Proceed
Operation 3000ZA
Teledyne Analytical Instruments 36
Enter the password using the __ arrow keys to move back and
forth between the existing password letters, and the __ arrow keys to
change the letters to the new password. The full set of 94 characters
available for password use are shown in the table below.
Characters Available for Password Definition:
A B C D E F G H I J
K L M N O P Q R S T
U V W X Y Z [ ¥ ] ^
_ ` a b c d e f g h
i j k l m n o p q r
s t u v w x y z { |
} ® ! " # $ % & ' (
) * + ' - . / 0 1 2
3 4 5 6 7 8 9 : ; <
= > ? @
When you have finished typing the new password, press Enter. A
verification screen appears. The screen will prompt you to retype your
password for verification.
A A A A A
Retype PWD To Verify
Wait a moment for the entry screen. You will be given clearance to
proceed.
A A A A A
<ENT> TO Proceed
Use the arrow keys to retype your password and press Enter when
finished. Your password will be stored in the microprocessor and the
system will immediately switch to the Analyze screen, and you now
have access to all instrument functions.
If all alarms are defeated, the Analyze screen appears as:
0.0 ppm Anlz
Range: 0 — 100
Trace Oxygen Analyzer Operation
Teledyne Analytical Instruments 37
If an alarm is tripped, the second line will change to show which
alarm it is:
0.0 ppm Anlz
AL—1
Note: If you log off the system using the logout function in the
system menu, you will now be required to re-enter the
password to gain access to Span, Zero, Alarm, and Range
functions.
4.3.4 Logout
The Logout function provides a convenient means of leaving the
analyzer in a password protected mode without having to shut the
instrument off. By entering Logout, you effectively log off the
instrument leaving the system protected against use until the password is
reentered. To log out, press the System button to enter the System
function.
TRAK/HLD Auto—Cal
PSWD Logout More
Use the __ arrow keys to position the blinking over the Logout
function, and press Enter to Log out. The screen will display the
message:
Protected Until
Password Reentered
4.3.5 System Self-Diagnostic Test
The Model 3000ZA has a built-in self-diagnostic testing routine.
Pre-programmed signals are sent through the power supply, output board
and sensor circuit. The return signal is analyzed, and at the end of the
test the status of each function is displayed on the screen, either as OK
or as a number between 1 and 3. (See System Self Diagnostic Test in
Chapter 5 for number code.)
The self diagnostics are run automatically by the analyzer
whenever the instrument is turned on, but the test can also be run by the
operator at any time. To initiate a self diagnostic test during operation:
Press the System button to start the System function.
Operation 3000ZA
Teledyne Analytical Instruments 38
TRAK/HLD Auto—Cal
PSWD Logout More
Use the __ arrow keys to blink More, then press Enter.
Version Self—Test
Use the __ arrow keys again to move the blinking to the Self–Test
function. The screen will follow the running of the diagnostic.
RUNNING DIAGNOSTIC
Testing Preamp — 83
During preamp testing there is a countdown in the lower right
corner of the screen. When the testing is complete, the results are
displayed.
Power: OK Analog: OK
Preamp: 3
The module is functioning properly if it is followed by OK. A
number indicates a problem in a specific area of the instrument. Refer to
Chapter 5 Maintenance and Troubleshooting for number-code
information. The results screen alternates for a time with:
Press Any Key
To Continue...
Then the analyzer returns to the initial System screen.
4.3.6 Version Screen
Move the __ arrow key to More and press Enter. With Version
blinking, press Enter. The screen displays the manufacturer, model, and
software version information.
4.3.7 Showing Negative Oxygen Readings
For software version 1.4.4 or later, the instrument only displays
oxygen readings that are positive or zero. The instrument can be
reconfigured to show negative readings if sensor output drifts below
zero. This situation may arise after the instrument has been zeroed. As
time progresses, the sensor may drift below the zero calibration setpoint.
To show negative oxygen readings on the display:
Press the System key
Trace Oxygen Analyzer Operation
Teledyne Analytical Instruments 39
TRAK/HLD Auto—Cal
PSWD Logout More
Use the __ arrow keys to blink More, then press Enter.
Version Self—Test
Show_Negative=NO
Use the __ arrow keys and select “ Show_Negative = NO”.
Use the __ arrow keys to toggle from NO to YES.
Press the Escape key twice to return to the analyze mode.
This preference is stored in non-volatile memory so the
configuration is remembered after a power shutdown. If the instrument
is cold started, it will go back to the default case where negative oxygen
readings are not shown.
4.4 The Zero and Span Functions
Zeroing is not required in order to achieve the published accuracy
specification of this unit however, zeroing will eliminate offset error
contributed by the sensor, electronics and the internal and external
sampling systems. It will improve performance beyond published
specification limits.
The analyzer is calibrated using zero and span gases.
Any suitable oxygen-free gas can be used for zero gas as long as it
is known to be oxygen free and does not react adversely with the sample
system.
A span gas with a known oxygen concentration in the range of
70–100% of full scale of the range of interest is recommended. In the 010 ppm range, 8 ppm span gas would be best suited.
Connect the calibration gases to the analyzer according to the
instructions given in Section 3.3.1, Gas Connections, observing all the
prescribed precautions.
Shut off the gas pressure before connecting it to the analyzer,
and be sure to limit the pressure to 40 psig or less when turning it
back on.
Readjust the gas pressure into the analyzer until the flowrate (as
read on the analyzer’s SLPM flowmeter) settles between 0.1 and 2.4
SLPM (approximately 0.2 - 5 SCFH).
Operation 3000ZA
Teledyne Analytical Instruments 40
If you are using password protection, you will need to enter your
password to gain access to either of these functions. Follow the
instructions in sections 4.3.3 to enter your password. Once you have
gained clearance to proceed, you can enter the Zero or Span function.
4.4.1 Zero Cal
The Zero button on the front panel is used to enter the zero
calibration function. Zero calibration can be performed in either the
automatic or manual mode. In the automatic mode, an internal
algorithm compares consecutive readings from the sensor to determine
when the output is within the acceptable range for zero. In the manual
mode, the operator determines when the reading is within the acceptable
range for zero. Make sure the zero gas is connected to the instrument. If
you get a CELL FAILURE message skip to Section 4.4.1.3.
4.4.1.1 AUTO MODE ZEROING
Press Zero to enter the zero function mode. The screen allows you
to select whether the zero calibration is to be performed automatically or
manually. Use the __ arrow keys to toggle between AUTO and MAN zero
settling. Stop when AUTO appears, blinking, on the display.
Zero: Settling: AUTO
<ENT> To Begin
Press Enter to begin zeroing.
#### PPM Zero
Slope=#### ppm/s
The beginning zero level is shown in the upper left corner of the
display. As the zero reading settles, the screen displays and updates
information on Slope (unless the Slope starts within the acceptable zero
range and does not need to settle further).
Then, and whenever Slope is less than 0.08 for at least 3 minutes,
instead of Slope you will see a countdown: 5 Left, 4 Left, and so fourth.
These are five steps in the zeroing process that the system must
complete, AFTER settling, before it can go back to Analyze.
#### PPM Zero
4 Left=### ppm/s
Trace Oxygen Analyzer Operation
Teledyne Analytical Instruments 41
The zeroing process will automatically conclude when the output is
within the acceptable range for a good zero. Then the analyzer
automatically returns to the Analyze mode.
4.4.1.2 MANUAL MODE ZEROING
Press Zero to enter the Zero function. The screen that appears
allows you to select between automatic or manual zero calibration. Use
the __ keys to toggle between AUTO and MAN zero settling. Stop when
MAN appears, blinking, on the display.
Zero: Settling: Man
<ENT> To Begin
Press Enter to begin the zero calibration. After a few seconds the
first of five zeroing screens appears. The number in the upper left hand
corner is the first-stage zero offset. The microprocessor samples the
output at a predetermined rate. It calculates the differences between
successive samplings and displays the rate of change as Slope= a value
in parts per million per second (ppm/s).
#### ppm Zero
Slope=#### ppm/s
Note: It takes several seconds for the true Slope value to display.
Wait about 10 seconds. Then, wait until Slope is
sufficiently close to zero before pressing Enter to finish
zeroing .
Generally, you have a good zero when Slope is less than 0.05
ppm/s for about 30 seconds. When Slope is close enough to zero, press
Enter. In a few seconds, the screen will update.
Once zero settling is completed, the information is stored in the
microprocessor, and the instrument automatically returns to the Analyze
mode.
4.4.1.3 CELL FAILURE
Cell failure in the 3000ZA is usually associated with inability to
zero the instrument down to a satisfactorily low ppm reading. When this
occurs, the instrument will still Zero, but the 3000ZA system alarm
trips, and the LCD displays a failure message.
#.# ppm Anlz
Operation 3000ZA
Teledyne Analytical Instruments 42
CELL FAIL/ ZERO HIGH
Before replacing the cell:
a. Check your span gas to make sure it is within specifications.
b. Check for leaks up-stream from the cell, where oxygen may be
leaking into the system.
If there are no leaks and the span gas is within specification,
replace the cell as described in chapter 5, Maintenance.
4.4.2 Span Cal
The Span button on the front panel is used to span calibrate the
analyzer. Span calibration can be performed using the automatic mode,
where an internal algorithm compares consecutive readings from the
sensor to determine when the output matches the span gas concentration.
Span calibration can also be performed in manual mode, where the
operator determines when the span concentration reading is acceptable
and manually exits the function.
4.4.2.1 AUTO MODE SPANNING
Press Span to enter the span function. The screen that appears
allows you to select whether the span calibration is to be performed
automatically or manually. Use the __ arrow keys to toggle between
AUTO and MAN span settling. Stop when AUTO appears, blinking, on the
display.
Span: Settling: AUTO
<ENT> For Next
Press Enter to move to the next screen.
Calib. Holding time
Cal hold: 5 min
This menu allows the operator to set the time the analyzer should
be held in the AUTO span mode, after the readings of the analyzer settle.
Five minutes is the default, but it could be adjusted anywhere from 1 to
60 minutes by using the __ keys.
Press Enter to move to the next screen.
Span Val: 000008.00
<ENT>Span <UP>Mod #
Trace Oxygen Analyzer Operation
Teledyne Analytical Instruments 43
Use the __ arrow keys to enter the oxygen-concentration mode.
Use the __ arrow keys to blink the digit you are going to modify. Use
the __ arrow keys again to change the value of the selected digit. When
you have finished typing in the concentration of the span gas you are
using, press Enter to begin the Span calibration.
#### ppm Span
Slope=#### ppm/s
The beginning span value is shown in the upper left corner of the
display. As the span reading settles, the screen displays and updates
information on Slope. Spanning automatically ends when the span
output corresponds, within tolerance, to the value of the span gas
concentration. Then the instrument automatically returns to the analyze
mode.
4.4.2.2 MANUAL MODE SPANNING
Press Span to start the Span function. The screen that appears
allows you to select whether the span calibration is to be performed
automatically or manually.
Span: Settling:MAN
<ENT> For Next
Use the __ keys to toggle between AUTO and MAN span settling.
Stop when MAN appears, blinking, on the display. Press Enter to move
to the next screen.
Press Enter to move to the next screen.
Calib. Holding time
Cal hold: 5 min
This menu allows the operator to set the time the analyzer should
be held in the AUTO span mode. It does not have any effect in the
MANual mode. Just press Enter key to continue.
Span Val: 000008.00
<ENT>Span <UP>Mod #
Press _ (<UP>) to permit modification (Mod #) of span value.
Use the arrow keys to enter the oxygen concentration of the span
gas you are using. The __ arrows choose the digit, and the __ arrows
choose the value of the digit.
Operation 3000ZA
Teledyne Analytical Instruments 44
Press Enter to enter the span value into the system and begin the
span calibration.
Once the span has begun, the microprocessor samples the output at
a predetermined rate. It calculates the difference between successive
samplings and displays this difference as a Slope on the screen. It takes
several seconds for the first Slope value to display. Slope indicates the
rate of change of the Span reading. It is a sensitive indicator of stability.
#### % Span
Slope=#### ppm/s
When the Span value displayed on the screen is sufficiently stable,
press Enter. (Generally, when the Span reading changes by 1% or less
of the full scale of the range being calibrated, for a period of ten minutes
it is sufficiently stable.) Once Enter is pressed, the Span reading
changes to the correct value. The instrument then automatically enters
the Analyze function.
4.4.3 Span Failure
The analyzer checks the output of the cell at the end of the span. If
the raw output of the cell is too low, the span will not be accepted. The
analyzer will return to the previous calibration values, trigger the System
Alarm, and display in the VFD:
Span Failed!!
This message will be shown for five seconds and the instrument
shall return to the Analyze mode. In the upper right hand corner of the
VFD display “FCAL” will be shown. This message flag will help the
operator troubleshoot in case calibration was initiated remotely. To
reset the alarm and the flag message, the unit must be turned off by
cycling the standby key . It will not reset if the next span cycle is
correct.
A trace cell is unlikely to fail span. As explained before, when the
sensor reaches the end of its useful life, the zero offset begins to rise
until the analyzer finds the zero unsatisfactory. Nevertheless, feeding
the wrong span gas or electronics failure could set this feature off at the
end of the span. Consider this before replacing the cell.
Trace Oxygen Analyzer Operation
Teledyne Analytical Instruments 45
4.5 The Alarms Function
The Model 3000ZA is equipped with 2 fully adjustable
concentration alarms and a system failure alarm. Each alarm has a relay
with a set of form “C" contacts rated for 3 amperes resistive load at 250
VAC. See Table 3-2 in Chapter 3, Installation and/or the
Interconnection Diagram included at the back of this manual for relay
terminal connections.
The system failure alarm has a fixed configuration as described in
chapter 3 Installation.
The concentration alarms can be configured from the front panel as
either high or low alarms by the operator. The alarm modes can be set as
latching or non-latching, and either failsafe or non-failsafe, or, they can
be defeated altogether. The setpoints for the alarms are also established
using this function.
Decide how your alarms should be configured. The choice will
depend upon your process. Consider the following four points:
1. Which if any of the alarms are to be high alarms and which if
any are to be low alarms?
2. Setting an alarm as HIGH triggers the alarm when the
oxygen concentration rises above the setpoint. Setting an
alarm as LOW triggers the alarm when the oxygen
concentration falls below the setpoint.
3. Decide whether you want the alarms to be set as:
• Both high (high and high-high) alarms, or
• One high and one low alarm, or
• Both low (low and low-low) alarms.
4. Are either or both of the alarms to be configured as failsafe?
5. In failsafe mode, the alarm relay de-energizes in an alarm
condition. For non-failsafe operation, the relay is energized
in an alarm condition. You can set either or both of the
concentration alarms to operate in failsafe or non-failsafe
mode.
6. Are either of the alarms to be latching?
7. In latching mode, once the alarm or alarms trigger, they will
remain in the alarm mode even if process conditions revert
Operation 3000ZA
Teledyne Analytical Instruments 46
back to non-alarm conditions. This mode requires an alarm to
be recognized before it can be reset. In the non-latching
mode, the alarm status will terminate when process
conditions revert to non-alarm conditions.
8. Are either of the alarms to be defeated?
9. The defeat alarm mode is incorporated into the alarm circuit
so that maintenance can be performed under conditions
which would normally activate the alarms.
10. The defeat function can also be used to reset a latched alarm.
(See procedures, below.)
If you are using password protection, you will need to enter your
password to access the alarm functions. Follow the instructions in
Section 4.3.3 to enter your password. Once you have clearance to
proceed, enter the Alarm function.
Press the Alarm button on the front panel to enter the Alarm
function. Make sure that AL–1 is blinking.
AL—1 AL—2
Choose Alarm
Set up alarm 1 by moving the blinking over to AL–1 using the __
arrow keys. Then press Enter to move to the next screen.
AL—1 10 ppm HI
Dft—N Fs—N Ltch—N
Five parameters can be changed on this screen:
• Value of the alarm setpoint, AL–1 #### ppm (oxygen);
value can be set from 0 to 10,000.00 ppm although the
sensor output is good only to 250 ppm
• Out-of-range direction, HI or LO
• Defeated? Dft–Y/N (Yes/No)
• Failsafe? Fs–Y/N (Yes/No)
• Latching? Ltch–Y/N (Yes/No).
To define the setpoint, use the __ arrow keys to move the blinking
over to AL–1 ####. Then use the __ arrow keys to change the number.
Holding down the key speeds up the incrementing or decrementing.
(Remember, the setpoint units are ppm O2.)
Trace Oxygen Analyzer Operation
Teledyne Analytical Instruments 47
To set the other parameters use the __ arrow keys to move the
blinking over to the desired parameter. Then use the __ arrow keys to
change the parameter.
Once the parameters for alarm 1 have been set, press Alarms again,
and repeat this procedure for alarm 2 (AL–2).
To reset a latched alarm, go to Dft– and then press either _ two
times or _ two times. (Toggle it to Y and then back to N.)
—or—
Go to Ltch– and then press either _ two times or _ two times.
(Toggle it to N and back to Y.)
4.6 The Range Function
The Range function allows the operator to program up to three
concentration ranges to correlate with the DC analog outputs. If no
ranges are defined by the user, the instrument defaults to:
Low = 0–10 ppm
Med = 0–100 ppm
High = 0–250 ppm.
The Model 3000ZA is set at the factory to default to autoranging.
In this mode, the microprocessor automatically responds to
concentration changes by switching ranges for optimum readout
sensitivity. If the current range limits are exceeded, the instrument will
automatically shift to the next higher range. If the concentration falls to
below 85% of full scale of the next lower range, the instrument will
switch to that range. A corresponding shift in the DC percent-of-range
output, and in the range ID outputs, will be noticed.
The autoranging feature can be overridden so that analog output
stays on a fixed range regardless of the oxygen concentration detected. If
the concentration exceeds the upper limit of the range, the DC output
will saturate at 1 VDC (20 mA at the current output).
However, the digital readout and the RS-232 output of the
concentration are unaffected by the fixed range. They continue to read
accurately with full precision. See Front Panel description in Chapter 1.
4.6.1 Setting the Analog Output Ranges
To set the ranges, enter the range function mode by pressing the
Range button on the front panel.
Operation 3000ZA
Teledyne Analytical Instruments 48
L—10 M—100
H—250 Mode—AUTO
Use the __ arrow keys to blink the range to be set: low (L), medium
(M), or high (H).
Use the __ arrow keys to enter the upper value of the range (all
ranges begin at 0 ppm). Repeat for each range you want to set. Press
Enter to accept the values and return to Analyze mode. (See note
below.)
Note: The ranges must be increasing from low to high, for
example, if range 1 is set as 0–10 ppm and range 2 is set
as 0–100 ppm, range 3 cannot be set as 0– 50 ppm since
it is lower than range 2.
4.6.2 Fixed Range Analysis
The autoranging mode of the instrument can be overridden, forcing
the analyzer DC outputs to stay in a single predetermined range.
To switch from autoranging to fixed range analysis, enter the range
function by pressing the Range button on the front panel.
Use the __ arrow keys to move the blinking over AUTO.
Use the __ arrow keys to switch from AUTO to FX/LO, FX/MED, or
FX/HI to set the instrument on the desired fixed range (low, medium, or
high).
L—10 M—100
H—250 Mode—FX/LO
—or—
L—10 M—10 0
H—250 Mode—FX/MED
—or—
L—10 M—10 0
H—250 Mode—FX/HI
Press Escape to re-enter the Analyze mode using the fixed range.
Note: When performing analysis on a fixed range, if the oxygen
concentration rises above the upper limit (or default value)
Trace Oxygen Analyzer Operation
Teledyne Analytical Instruments 49
as established by the operator for that particular range, the
output saturates at 1 VDC(or 20 mA). However, the digital
readout and the RS-232 output continue to read the true
value of the oxygen concentration regardless of the analog
output range.
4.7 The Analyze Function
Normally, all of the functions automatically switch back to the
Analyze function when they have completed their assigned operations.
Pressing the Escape button in many cases also switches the analyzer
back to the Analyze function. Alternatively, you can press the Analyze
button at any time to return to analyzing your sample.
4.8 Signal Output
The standard Model 3000ZA Trace Oxygen Analyzer is equipped
with two 0–1 VDC analog output terminals accessible on the back panel
(one concentration and one range ID), and two isolated 4–20 mA DC
current outputs (one concentration and one range ID).
See Rear Panel in Chapter 3, Installation for connection details.
The signal output for concentration is linear over the currently
selected analysis range. For example, if the analyzer is set on range that
was defined as 0–100 ppm O2, then the output would be:
Table 4-1: Output Signals
Voltage Signal Current Signal
ppm O
2
Output (VDC) Output (mA DC)
0 0.0 4.0
10 0.1 5.6
20 0.2 7.2
30 0.3 8.8
40 0.4 10.4
50 0.5 12.0
60 0.6 13.6
70 0.7 15.2
Operation 3000ZA
Teledyne Analytical Instruments 50
80 0.8 16.8
90 0.9 18.4
100 1.0 20.0
The analog output signal has a voltage which depends on the
oxygen concentration AND the currently activated analysis range. To
relate the signal output to the actual concentration, it is necessary to
know what range the instrument is currently on, especially when the
analyzer is in the autoranging mode.
To provide an indication of the range, a second pair of analog
output terminals are used. They generate a steady preset voltage (or
current when using the current outputs) to represent a particular range.
The following table gives the range ID output for each analysis range:
Table 4-2: Range ID Output Voltage
Range Voltage (V) Current (mA)
LO 0.25 8
MED 0.50 12
HI 0.75 16
IMPORTANT: In the event of loss of flow through the analyzer, if the
vent is vented to a location of high oxygen content, oxygen will back
diffuse through the vent line and enter the cell. This can saturate the cell
with oxygen and require a long purge down time before the sensor can
recover. However, the ZrO2 sensor recovers faster than the microfuel
oxygen sensor. In the event that flow is to be interrupted into the
analyzer, it is suggested that the user do one of the following:
1. Bag the sensor in nitrogen during this time
2. Install a shut off valve on the vent port of the analyzer or
somewhere within the users sample system.
Trace Oxygen Analyzer Operation
Teledyne Analytical Instruments 51
Maintenance 3000ZA
Teledyne Analytical Instruments 52
Maintenance
5.1 Routine Maintenance
Aside from normal cleaning and checking for leaks at the gas
connections, routine maintenance is limited to replacing the sensor and
fuses, and recalibration. For recalibration, see Section 4.4 Calibration.
WARNING: SEE WARNINGS ON THE TITLE PAGE OF THIS
MANUAL.
5.2 Cell Replacement
The ZrO2 sensor is a sealed transducer with no electrolyte to
change or electrodes to clean. When the cell reaches the end of its useful
life, it is replaced. The spent sensor should be discarded according to
local regulations.
5.2.1 Removing the Sensor
The ZrO2 sensor is located inside the nylon cell block behind the
front panel.
To remove an existing cell (refer to Figure 5-1):
1. Remove power to the instrument by unplugging the power
cord at the power source.
2. Open the front panel door by pressing the release button on
the top right corner of the door all the way in with a narrow
gauge tool.
3. Unscrew the collar on the top assembly of the cell block from
the bottom section of the cell block assembly. The sensor is
attached to pin sockets on the bottom assembly.
Trace Oxygen Analyzer Maintenance
Teledyne Analytical Instruments 53
4. Remove the old sensor and install a new sensor by matching
the orientation notch on the sensor to the silkscreen on the
sensor holder.
Figure 5-1: Replacing the ZrO2 Sensor
5.3 Fuse Replacement
1. Place small screwdriver in notch, and pry cover off, as shown
in Figure 5-2.
Figure 5-2: Removing Fuse Block from Housing
Maintenance 3000ZA
Teledyne Analytical Instruments 54
2. To change between American and European fuses, remove
the single retaining screw, flip Fuse Block over 180 degrees,
and replace screw.
3. Replace fuse as shown in Figure 5-3.
4. Reassemble Housing as shown in Figure 5-2.
American Fuses European Fuses
Figure 5-3: Installing Fuses
5.4 System Self Diagnostic Test
1. Press the System button to enter the system mode.
2. Use the __ arrow keys to move to More, and press Enter.
3. Use the __ arrow keys to move to Self-Test, and press Enter.
The following failure codes apply:
Table 5-1: Self-Test Failure Codes
Power
0 OK
1 5 V Failure
2 15 V Failure
3 Both Failed
Analog
0 OK
1 DAC A (0–1 V Concentration)
2 DAC B (0–1 V Range ID)
3 Both Failed
Trace Oxygen Analyzer Maintenance
Teledyne Analytical Instruments 55
Preamp
0 OK
1 Zero too high
2 Amplifier output doesn't match test input
3 Both Failed
5.5 Major Internal Components
The zirconium sensor is accessed by unlatching and swinging open
the front panel, as described earlier. Other internal components are
accessed by removing the rear panel and sliding out the entire chassis.
See Figure 5-4, below. The gas piping is illustrated in Figures 2-1 and
Figure 2-2 and the major electronic components locations are shown in
Figure 2-3, in Chapter 2.
WARNING: SEE WARNINGS ON THE TITLE PAGE OF THIS
MANUAL.
Figure 5-4: Rear Panel Removal
(Remove only those screws marked with an X)
The 3000ZA contains the following major components:
Maintenance 3000ZA
Teledyne Analytical Instruments 56
• Analysis Section
• Zirconium oxide sensor
• Cell block
• Sample system
• Power Supply
• Microprocessor
• Displays
• 5 digit LED meter
• 2 line, 20 character, alphanumeric, VFD display
• RS-232 Communications Port
See the drawings in the Drawings section in back of this manual for
details.
5.6 Cleaning
If instrument is unmounted at time of cleaning, disconnect the
instrument from the power source. Close and latch the front-panel access
door. Clean outside surfaces with a soft cloth dampened slightly with plain
clean water. Do not use any harsh solvents such as paint thinner or benzene.
For panel-mounted instruments, clean the front panel as prescribed
in the above paragraph. DO NOT wipe front panel while the instrument
is controlling your process.
5.7 Troubleshooting
Table 5-2: Troubleshooting
Problem
Possible Cause
Solution
Erratic readings of the
oxygen concentration
as reported by the
analyzer
Analyzer may have
been calibrated in an
inaccurate fashion.
1. Turn analyzer off,
then back on again.
Press System key
when prompted by
analyzer “Press
System for Default
Values”. This will
return the default
settings to the
Trace Oxygen Analyzer Maintenance
Teledyne Analytical Instruments 57
analyzer.
2. If erratic behavior
continues, replace
sensor.
Atmospheric oxygen
diffusing through vent
and altering the
oxygen level the
sensor sees
Increase flow rate
and/or length of vent
tubing to dilute or
minimize oxygen
diffusion from vent to
sensor.
Inaccurate zero
operation (i.e. user has
zeroed the instrument
using a gas concentration much higher
than normal for a zero
gas).
Turn analyzer off,
then back on again.
Press System key
when prompted by
analyzer “Press
System for Default
Values”. This will
return the analyzer to
default calibration and
zero settings. Now
proceed to carefully
calibrate and zero the
analyzer.
Appendix 3000ZA
Teledyne Analytical Instruments
Appendix
A-1 Specifications
Packaging: General Purpose
• Flush panel mount (Standard)
• Relay rack mount. Contains either one
or two instruments in one 19" relay rack
mountable plate (Optional).
Sensor: Zirconium oxide sensor.
Cell Block: Nylon
Sample System: All wetted parts of 316 stainless steel.
90 % Response Time: 65 seconds at 25 °C (77 °F) on 10 ppm
range, 100 seconds on 1 ppm range
Ranges: Option a:
0–10 to 0–200 ppm O2 (0-1 ppm analysis
possible)
Option b:
0–10 to 0–1000 ppm O2
Autoranging with range ID output.
Alarms: One system-failure alarm contact to detect
power failure or sensor-zero failure.
Two adjustable concentration threshold
alarm contacts with fully programmable
setpoints.
Displays: 2-line by 20-character, VFD screen, and
one 5 digit LED display.
Digital Interface: Full duplex RS-232 communications port.
Trace Oxygen Analyzer Appendix
Teledyne Analytical Instruments
Power: Universal power supply 85-250 V ac, at
47-63 Hz.
Operating Temperature: 5-35 °C
Accuracy: ±2% of full scale at constant temperature
(at ca;obrated ramge).
±5% of full scale over operating
temperature range, except 0-1 ppm
analysis range, once thermal equilibrium
is reached.
±0.2 ppm on 0-1 ppm analysis range, once
thermal equilibrium is reached.
Analog outputs: 0-1 VDC percent-of-range,
0-1 VDC range ID.
4-20 mA DC (isolated) percent-of-range,
4-20 mA DC (isolated) range ID
(optional).
Dimensions: 19 cm high, 24.9 cm wide, 31 cm deep
(6.96 in high, 8.7 in wide, 12.2 in deep).
Appendix 3000ZA
Teledyne Analytical Instruments
A-2 Recommended 2-Year Spare Parts List
Qty. Part Number Description
1 C65507A Back Panel Board
1 C62371-A Front Panel Board
1 C75734A Trace Preamplifier Board
1 C73870-A Main Computer Board
1 F10 Fuse, 2A, 250V 3AG Slow Blow
2 F1296 Fuse, 2A, 250V 5x20mm
Slow Blow
1 A68314 Back Panel Connector Kit
1 A68729 Restrictor kit
A minimum charge is applicable to spare parts orders.
Note: Orders for replacement parts should include the part
number (if available) and the model and serial number of
the instrument for which the parts are intended.
Orders should be sent to:
TELEDYNE Analytical Instruments
16830 Chestnut Street
City of Industry, CA 91749-1580
Phone (626) 934-1500, Fax (626) 961-2538
Web: www.teledyne-ai.com
or your local representative.
Trace Oxygen Analyzer Appendix
Teledyne Analytical Instruments
A-3 Drawing List
D-75739 Final Assembly
D-75738 Outline Drawing
A-4 19-inch Relay Rack Panel Mount
Figure A-1: Single and Dual 19" Rack Mounts
(dimensions in mm)
Appendix 3000ZA
Teledyne Analytical Instruments
A.5 Application Notes
3000 SERIES ANALYZERS
APPLICATION NOTES ON RESTRICTORS,
PRESSURES, AND FLOW RECOMMENDATIONS
The 3000 series analyzers require reasonably regulated sample
pressures. While the 3000 analyzers are not sensitive to variations of
incoming pressure (provided they are properly vented to atmospheric
pressure) the pressure must be maintained to provide a useable flow rate
through the analyzer. Any line attached to sample vent should be 1/4 or
larger in diameter.
FLOW RATE RECOMMENDATIONS:
A usable flow rate for a 3000 series analyzer is one which can be
measured on the flowmeter. This is basically 0.2 - 2.4 SLPM . The
optimum flow rate is 1 SLPM (mid scale). Note that response time is
dependent on flow rate; a low flow rate will result in slow response to
O2 changes in the sample stream. The span flow rate should be the
approximately same as the sample flow rate.
RESTRICTION DEVICES:
For proper operation, all 3000 series analyzers require a flow
restriction device. This device is typically a restrictor or a valve. The
restriction device serves two functions in the sample path.
1. It is used to limit the flow rate of the sample through the
analyzer. A restrictor is chosen to operate over a range of
pressures and provide a useable flow rate over that range.
2. The restriction device provides a pressure drop. This device
is selected to provide the only significant pressure drop in the
sample path.
RESTRICTOR KIT
The current revision of the 3000 series analyzers are supplied with
a kit containing two restrictors and a union which are user installed.
These parts are supplied to give the end user more flexibility when
installing the analyzer. The restrictor kit is suitable for high and low
Trace Oxygen Analyzer Appendix
Teledyne Analytical Instruments
positive pressure applications as well as vacuum service applications
(see manual for installation instructions).
The standard restrictor (BLUE DOT) is recommended for pressures
between 5 and 50 PSIG. For positive low pressure application (5 psig or
less) the unmarked restrictor is better suited . For unpressurized sample
applications the marked restrictor should be used and configured for
vacuum service.
Note: For extremely low positive pressure applications (less then
2 psig) the vacuum service configuration should provide
higher performance (higher flow rates).
For vacuum service, the end user must supply a vacuum pump and
a by-pass valve for the pump. A vacuum level of 5–10 inches of
mercury should provide the optimum flow rate. CAUTION: flow
restrictors have very small orifices and may be plugged by small
particles (.005” dia or larger) A sample filter must be included in the
sample line prior to the restrictor! (A 60 micron filter is recommended).
3000TA EXAMPLES:
Example 1: With a incoming pressure of 10 psig the std restrictor (blue
dot) will provide a flow rate of 0.76 SLPM. Upstream of the restrictor
the sample line pressure will be 10 psig, while down stream (including
the cell) the pressure will be at atmospheric pressure (analyzer vented to
atmospheric pressure). Note, all other pressure drops in the sample path
are insignificant at these flow rates. This insures that the cell operates at
atmospheric pressure. At very high flow rates (off scale of flow-meter),
pressure drops other than the restriction device could become
significant, and result in pressurizing the cell.
Example 2: A 3000TA is configured for vacuum service as follows. The
unmarked restrictor is placed in the sample vent port. The down stream
end of the restrictor is then connected to a vacuum pump and by-pass
valve. The by-pass valve is adjusted to provide a flow rate of 1 SLPM.
The sample pressure between the pump and the restrictor will be
approximately -7 inches of mercury, while the pressure in the balance
of the sample system including the cell will be approximately at
atmospheric pressure (provided the sample flow into the analyzer is not
blocked).
BY-PASS:
Appendix 3000ZA
Teledyne Analytical Instruments
To improve the system response, a by-pass can be added to increase
the sample flow rate to the analyzer by a factor of ten. A by-pass provides
a sample flow path around the analyzer of 2 - 18 SCFH. typically.
CALIBRATION GAS:
3000 series analyzer requirements for units with Auto-Cal options
are as follows:
The customer must supply control valves (or restrictors) for any SPAN
or ZERO gas source which is attached to the Auto-Cal ports. The valve
should be adjusted to the same flow rate as the sample gas. When restrictors
are used, the gas pressure must be adjusted to achieve the proper flow rate.
OPERATION WITHOUT A RESTRICTOR DEVICE:
Operation without a restrictor device is not recommend as
mentioned above. A 3000TA without any flow restrictor device was
tested on 11-19-97. This results in a flow rate of 2.4 SLPM @ 1 PSIG.
This is a cv of 0.023 for the standard sample system.
REFERENCE: FLOW_1.XLS & FLOW_2.XLS for information on
flow rates at various pressures.
TAI PART NUMBERS
Restrictor kit: A68729
Union (SS) U11
LP Restrictor R2323 (low pressure / vac. service)
Std. Restrictor R2324 Blue dot
Nut N73
Ferrule F73
Ferrule F74 Both ferrules are required
CONVERSIONS:
1 PSI = 2.04 inches of mercury (in. Hg.)
Trace Oxygen Analyzer Appendix
Teledyne Analytical Instruments
1 SCFH = 0.476 SLPM
Index 3000ZA
Teledyne Analytical Instruments
Index
AC power connection, 6
accuracy, 58
address, 59
alarm, 57
concentration, 2, 6, 44
configuration, 44
freeze, 31
relay contact pins, 20
relays, 19
setpoint, 45
system failure, 2, 6, 10, 20, 44
threshold 1, 19
threshold 2, 19
ALARMS key, 28
alphanumeric display, 3
amplifier PCB, 10
analog output, 2, 6, 10, 18, 48, 58
freeze, 31
analog output connections, 19
analog to digital converter, 10
analyze function, 48
ANALYZE key, 28
analyzer components, 54
analyzer functions, 4
anode, 7
application notes, 61
applications, 1
auto ranging, 2
AUTO span time interval, 42
AUTOCAL, 30
auto–cal setting up, 32
auto-cal setup, 28
automatic calibration, 30, 32
autoranging, 46, 47
back diffusion, 49
block diagram, 10
by-pass, 63
bypass line, 17
by-pass valve, 62
calibration
automatic-zero, 39
connections, 21
manual-zero, 40
remote cal. protocol, 21
remote control, 20
span, 21
zero, 20
calibration contact, 6, 21
calibration input, 20
calibration port, 6, 15
cathode, 7
caution sign, v
CE mark, 1
cell block, 51, 55, 57
cell failure, 40
cell life, 61
cleaning, 55
contact rating, 19, 44
control panel, 14
copyright, ii
counter electrode, 7
current output, 18
current to voltage amplifier, 10
data entry buttons, 28
data entry keys, 4
default, 32
default ranges, 46
default values, 27
defeat alarm, 45
delay, 31
diffusion rate, 61
digital input. See input
digital meter. See meter
digital signal output. See RS 232
digital to analog converter, 10
dimensions, 58
display, 57
door, 5
door clearance, 14
door latch, 14
drawings, 60
dual rack mounting, 60
electrical connections, 17
ENTER key, 4, 28
equipment interface connector, 18
ESCAPE key, 4, 28
Trace Oxygen Analyzer Index
Teledyne Analytical Instruments
exhaust out, 16, 17
external control, 6
external valves, 22
failsafe, 44
failure codes, 53
features, 1
FET, 23
fixed range, 46, 47
flow range, 16
flow rate, 61
flow restriction devic, 62
flowmeter, 8, 16
flowmeter window, 3
flush panel mount, 13
form C contacts, 44
form C relay contacts, 19
front panel, 3, 14
function hierarchy, 29
fuse, 53
fuse block, 17
fuse block cover, 52
fuse installation, 18
fuse replacement, 52
gas conditioning, 9
gas connections, 6
general purpose instrument, 13
halogens, 9
heater, 7
high alarm. See alarm, concentration
improve performance, 38
incrementing display, 45
input, 6
installation, 13
jumper, 18
keys, 4
latching, 44
LED display, 55
linear output, 48
logging out, 28
logout, 36
LOGOUT, 30
low alarm. See alarm, concentration
low pressure applications, 15
manual override, 2
manuals, additional, vi
measurement error, 9
membrane switches. See keys
meter, 3, 4
microcontroller, 9
microprocessor, 7, 10, 55
model designation, 2
model information, iii
MORE, 30
motherboard, 10
mounting holes, 13
network I/O, 6, 22, 25
non-failsafe, 44
non-latching, 45
normally closed, 19
normally open, 19
operating temperature, 58
operating the analyzer, 27
operator controls, 14
operator interface, 3
options
rack mountable, iii
vacuum service, iii
output range, 2
output saturation, 46
output signal, 48
oxygen concentration mode, 42
oxygen reduction, 7
panel mount, 2
password, 30, 33
available characters, 35
changing, 34
new, 33
password assignment, 28
password protection, 27
PC board location, 10
percent of range output, 18
pin configuration, 18
polarity, 18
power cord receptacle, 17
power supply, 55
signal monitoring, 10
universal, 9, 17, 57
power-supply monitoring, 2
preamplifier board, 10
preference setting, 31
pressure drop, 62
pressure regulation, 16
pressure sensitivity, 61
pressures other than atmospheric, 61
PSWD, 30
rack mount, 2, 13, 60
RAM, 2, 9
range, 1
range function, 46
range ID, 10, 49
Index 3000ZA
Teledyne Analytical Instruments
relay connections, 22
relay contacts, 22
range ID contact, 6
range ID relay contacts, 25
range identification, 2
RANGE key, 28
readout, 4
rear panel, 5, 15
rear panel removal, 54
recovery, 49
remote calibration connections. See
calibration
remote probe, 6
remote probe connections, 23
remote valve, 22
reset latched alarm, 45
response time, 17, 57, 61
restrictor, 15. See flow restriction
device
restrictor kit, 62
ROM, 2, 9
routine maintenance, 51
RS-232, 2, 25
RS-232 commands, 24
RS-232 port, 6, 24, 55, 57
safety information, v
sample in, 16
sample system, 7, 8, 55
second stage amplifier, 10
self diagnostic test
initiating, 36
self -diagnostic test initiation, 28
self-diagnostic test, 2, 26, 36, 53
SELF-TEST, 30
sensor
zirconium oxide sensor, 57
sensor operating temperature, 10
sensor removal, 51
serial number, iii
serial port, 2
setpoint. See alarm, setpoint
setpoint units, 45
setting ranges, 46
show negative, 28
SHOW NEGATIVE, 30
signal processing, 9
slope, 39, 40, 42, 43
software version, 28
solenoid valve, 6
span calibration. See calibration, span
span failure, 43
span flow rate, 61
span gas concentration, 38
SPAN key, 28
span settling, 41
spare parts, 59
specifications, 57
stability indicator, 43
standby button, 5
subsystems, 7
symbols, iv
system alarm, 40
system function, 30
SYSTEM key, 28
Teledyne address, 59
testing the system, 25
tracking oxygen readings, 31
TRAK/HLD, 30
troubleshooting, 55
unpacking the analyzer, 13
unpressurized sample, 62
vacuum fluorescent display, 1, 4
vacuum pump, 62
vacuum service, 15, 62
VCR fittings, 8
vent, 61
version, 37
VERSION, 30
VFD display, 55
voltage output, 18
warning sign, v
warranty, ii
water vapor, 9
web address, 59
website address, vi
zero calibration. See calibration, zero
ZERO key, 28
zero settling, 39, 40
zirconium oxide sensor, 5, 7, 54, 55,
57.
