TSG95 PAL/NTSC Signal
Generator.
Features
Specs
Ordering Information
Pricing Information
Request a Quote
Handheld Generator
Pathfinder
TM
TSG95
Characteristics
PAL Test Signal Characteristics
Luminance Amplitude Accuracy - ±1% of 700 mV.
Chrominance-to-luminance Gain - ±2% of 700 mV.
Subcarrier Stability - 4.43361875 MHz ±10 Hz.
Chrominance-to-luminance Delay - <10 ns.
SCH Phase - 0° ±5°.
Frequency Response -
To 4.8 MHz: Flat within ±2%.
To 5.8 MHz: Flat within ±3%.
Field Tilt - <0.5%.
Line Tilt - <0.5%.
Differential Gain - <1%.
Differential Phase - <1%.
2T Pulse K-factor - <0.5%.
NTSC Test Signal Characteristics
Luminance Amplitude Accuracy - ±1% of 714.3 mV (100
±1 IRE).
Chrominance-to-luminance Gain - ±2% of 714.3 mV (100
±2 IRE).
Subcarrier Stability - 3.579545 MHz ±10 Hz.
Chrominance-to-luminance Delay - <15 ns.
SCH Phase - 0° ±5°.
Frequency Response - Flat within ±2% to 4.2 MHz.
Field Tilt - <0.5%.
Line Tilt - <0.5%.
Differential Gain - <1%.
Differential Phase - <1%.
2T Pulse K-factor - <0.5%.
Power
DC Input -
Range: 9 to 15 V input.
Polarity: Negative center.
Typical Battery Life -
Alkaline AA Cells: 7 to 10 hours.
Rechargeable Pack: 3 to 4 hours.
Environmental
Temperature -
Operating: 0°C to +40°C.
Nonoperating: -30°C to + 65°C.
Certifications
EMC - Certified to the EMC Directive 89/336/EEC.
Physical Characteristics
Dimensions mm in.
Height 190.5 7.5
Width 91.44 3.6
Depth 55.8 2.2
Weight kg lbs.
Net (no batteries) 0.48 1.06
Shipping 1.5 3.31
