Tektronix TSG95 Specifications Sheet

Editing ID messages

Á

Á

Á

Á

Press ID Edit. The current ID will appear on the display.

A

symbol indicates a blank; while the active test signal is obscured by

a space, it will not be obscured by a blank.

A

symbol indicates that this (right−hand) portion of the text line is
outside of the safe action area. To enter text in that region, move the ID
message to the left (to a lower-numbered H position; see below).

Use the arrow and alphanumeric keys to enter the desired text.

To Set ID position:

To move the current ID message to a different location on the screen or
into the vertical interval, first press
sor (arrow) keys to reposition the message. The vertical interval choice is
above V=1.

Shift, then ID Edit. Then use the cur-

Special Settings

Change the following settings through the Utility menu. Enter the Utility
menu by pressing the
Then use the Y and B keys to scroll to the desired menu item.

Video Standard (SELECT STNDRD)

A and " keys to select among the available video standards and

Use the
signal sets: PAL, NTSC, NTSC JAPAN, and USER.

User Signal Set (SEL USER SIGS)

Enter to edit the User Signal Set; see the User manual for details.

Press

Auto Power Down (AUTO PWR DOWN)
Auto Power Down will switch the TSG 95 off after ten minutes without a

key press. Use the

VITS Insertion (VITS SIGNALS)

A and " keys to toggle the VITS (in selected test signals) On/

Use the
Off.

Battery Type

A and " keys to select between disposable (Alkaline) and re-

Use the
chargeable (NiCad) batteries. Select rechargeable when you are using the
optional battery pack.

On key while holding the Lock Out key down.

A and " keys to select between disabled and enabled.

CopyrightE Tektronix, Inc. All rights reserved.

Available Signals/Direct Signal Selection

TSG 95 test signals may be selected with Test Signal or through “Direct
Signal Selection.” To select from the list of available signals, press Test

repeatedly—or press that key once and then use the Y and B keys

Signal

to scroll through the list.

When the instrument is in normal operation and no menu is active, you
may also “Direct-Select” the desired signal by pressing the appropriate
letter key. The available signals and corresponding keys are listed below.

PAL
Signal Set

ÁÁÁÁ

75% Bars
100% Bars
75% Bars/Red
100% Bars/Red
Convergence
Pluge
Safe Area
Green Field
Blue Field
Red Field
100% Flat Field
50% Flat Field
0% Flat Field
Multiburst
60% Sweep
5-Step
Mod. 5-Step
Matrix
Field Square Wave
Bounce



* No (0%) setup.

or scroll to the “Exit Menu” item and press Enter

NTSC
Signal Set

ÁÁÁÁ

SMPTE Bars
75% Bars
Convergence
Safe Area
Red Field
50IRE Flat Field
100IRE Flat Field
Black Burst
5-Step
Multiburst
NTC7 Composite
NTC7 Combination
FCC Composite
Cable Multiburst
Cable Sweep
SIN X/X
Matrix
0IRE, no Burst
Field Square Wave
Bounce



NTSC JAPAN
Signal Set

ÁÁÁ

SMPTE Bars*
75% Bars*
SNG Bars*
Convergence
Safe Area
Red Field*
50IRE Flat Field
100IRE Flat Field
Black Burst*
5-Step
Multiburst
NTC7 Composite
NTC7 Combination
FCC Composite
Cable Multiburst
Cable Sweep
SIN X/X
Matrix*
0IRE, no Burst
Field Square Wave
Bounce

To exit a menu, press any rectangular key

Key

Á

A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U

Instructions

TSG95 Pathfinder
PAL/NTSC Signal Generator

070-8915-00
