Tektronix TSG-422 User Manual

Instruction Manual

TSG-422
Digital Component Generator

070-7022-02

Please check for change information at the rear
of this manual.

WARRANTY

T ektronix warrants that this product will be free from defects in materials and workmanship for a period of one (1)
year from the date of shipment. If any such product proves defective during this warranty period, T ektronix, at its
option, either will repair the defective product without charge for parts and labor, or will provide a replacement in
exchange for the defective product.

In order to obtain service under this warranty, Customer must notify Tektronix of the defect before the expiration
of the warranty period and make suitable arrangements for the performance of service. Customer shall be
responsible for packaging and shipping the defective product to the service center designated by T ektronix, with
shipping charges prepaid. Tektronix shall pay for the return of the product to Customer if the shipment is to a
location within the country in which the T ektronix service center is located. Customer shall be responsible for
paying all shipping charges, duties, taxes, and any other charges for products returned to any other locations.

This warranty shall not apply to any defect, failure or damage caused by improper use or improper or inadequate
maintenance and care. T ektronix shall not be obligated to furnish service under this warranty a) to repair damage
resulting from attempts by personnel other than T ektronix representatives to install, repair or service the product;
b) to repair damage resulting from improper use or connection to incompatible equipment; or c) to service a
product that has been modified or integrated with other products when the effect of such modification or
integration increases the time or difficulty of servicing the product.

THIS WARRANTY IS GIVEN BY TEKTRONIX WITH RESPECT TO THIS PRODUCT IN LIEU OF
ANY OTHER WARRANTIES, EXPRESSED OR IMPLIED. TEKTRONIX AND ITS VENDORS
DISCLAIM ANY IMPLIED WARRANTIES OF MERCHANT ABILITY OR FITNESS FOR A
P ARTICULAR PURPOSE. TEKTRONIX’ RESPONSIBILITY TO REPAIR OR REPLACE DEFECTIVE
PRODUCTS IS THE SOLE AND EXCLUSIVE REMEDY PROVIDED TO THE CUSTOMER FOR
BREACH OF THIS WARRANTY. TEKTRONIX AND ITS VENDORS WILL NOT BE LIABLE FOR ANY
INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES IRRESPECTIVE OF
WHETHER TEKTRONIX OR THE VENDOR HAS ADVANCE NOTICE OF THE POSSIBILITY OF
SUCH DAMAGES.

Contacting Tektronix

Product
Support

Service
Support

For other
informa­tion

To write us Tektronix, Inc.

For application-oriented questions about a Tektronix
measurement product, call toll free in North America:
1-800-TEK-WIDE (1-800-835-9433 ext. 2400)
6:00 a.m. – 5:00 p.m. Pacific time

Or contact us by e-mail:
[e-mail]

For product support outside of North America, contact
your local Tektronix distributor or sales office.

Contact your local Tektronix distributor or sales office.
Or visit our web site for a listing of worldwide service
locations.

http://www.tektronix.com
In North America:

1-800-TEK-WIDE (1-800-835-9433)
An operator will direct your call.

P.O. Box 1000
Wilsonville, OR 97070-1000

General Safety Summary
Service Safety Summary

i-11
i-12

Table 3 12 Certifications and Compliances

3 37

General Safety Summary

Review the following safety precautions to avoid injury and prevent damage to
this product or any products connected to it. To avoid potential hazards, use this
product only as specified.

Only qualified personnel should perform service procedures.

To Avoid Fire or
Personal Injury

Use Proper Power Cord. Use only the power cord specified for this product and

certified for the country of use.
Ground the Product. This product is grounded through the grounding conductor

of the power cord. To avoid electric shock, the grounding conductor must be
connected to earth ground. Before making connections to the input or output
terminals of the product, ensure that the product is properly grounded.

Observe All Terminal Ratings. To avoid fire or shock hazard, observe all ratings
and markings on the product. Consult the product manual for further ratings
information before making connections to the product.

Do not apply a potential to any terminal, including the common terminal, that
exceeds the maximum rating of that terminal.

Do Not Operate Without Covers. Do not operate this product with covers or panels
removed.

Use Proper Fuse. Use only the fuse type and rating specified for this product.
Avoid Exposed Circuitry. Do not touch exposed connections and components

when power is present.
Wear Eye Protection. Wear eye protection if exposure to high-intensity rays or

laser radiation exists.

TSG-422

Do Not Operate With Suspected Failures. If you suspect there is damage to this
product, have it inspected by qualified service personnel.

Do Not Operate in Wet/Damp Conditions.
Do Not Operate in an Explosive Atmosphere.
Keep Product Surfaces Clean and Dry .
Provide Proper Ventilation. Refer to the manual’s installation instructions for

details on installing the product so it has proper ventilation.

i-11

General Safety Summary

Symbols and Terms

T erms in this Manual. These terms may appear in this manual:

WARNING. Warning statements identify conditions or practices that could result
in injury or loss of life.

CAUTION. Caution statements identify conditions or practices that could result in
damage to this product or other property.

T erms on the Product. These terms may appear on the product:
DANGER indicates an injury hazard immediately accessible as you read the

marking.
WARNING indicates an injury hazard not immediately accessible as you read the

marking.
CAUTION indicates a hazard to property including the product.
Symbols on the Product. The following symbols may appear on the product:

CAUTION

Refer to Manual

Service Safety Summary

Only qualified personnel should perform service procedures. Read this Service
Safety Summary and the General Safety Summary before performing any service

procedures.
Do Not Service Alone. Do not perform internal service or adjustments of this

product unless another person capable of rendering first aid and resuscitation is
present.

Disconnect Power. To avoid electric shock, switch off the instrument power, then
disconnect the power cord from the mains power.

Use Care When Servicing With Power On. Dangerous voltages or currents may
exist in this product. Disconnect power, remove battery (if applicable), and
disconnect test leads before removing protective panels, soldering, or replacing
components.

WARNING

High Voltage

Double

Insulated

Protective Ground

(Earth) Terminal

Not suitable for

connection to

the public telecom-

munications network

i-12

To avoid electric shock, do not touch exposed connections.

TSG-422

Introduction

Operating Instructions

Specifications

Emissions FCC 47 CFR Part 15, Subpart B, Class A

Refer to frontmatter for EC declaration of compliance

T able 3–12: Certifications and compliances

Category Standards or description

TSGĆ422 Ċ SPECIFICATIONS

EC Declaration of Conformity –

1

EMC

Meets intent of Directive 89/336/EEC for Electromagnetic Compatibility. Compliance was
demonstrated to the following specifications as listed in the Official Journal of the European Union:

EN 50081-1 Emissions:

EN 55022 Class B Radiated and Conducted Emissions

EN 50082-1 Immunity:

IEC 801-2 Electrostatic Discharge Immunity
IEC 801-3 RF Electromagnetic Field Immunity

IEC 801-4 Electrical Fast T ransient/Burst Immunity
FCC Compliance Emissions comply with FCC Code of Federal Regulations 47, Part 15, Subpart B, Class A Limits.
Installation (Overvoltage)

Category

Terminals on this product may have different installation (overvoltage) category designations. The
installation categories are:

CA T III Distribution-level mains (usually permanently connected). Equipment at this level is

typically in a fixed industrial location.

CA T II Local-level mains (wall sockets). Equipment at this level includes appliances, portable

tools, and similar products. Equipment is usually cord-connected.

CA T I Secondary (signal level) or battery operated circuits of electronic equipment.

Pollution Degree A measure of the contaminates that could occur in the environment around and within a product.

Typically the internal environment inside a product is considered to be the same as the external.
Products should be used only in the environment for which they are rated.

Pollution Degree 2 Normally only dry, nonconductive pollution occurs. Occasionally a

temporary conductivity that is caused by condensation must be
expected. This location is a typical office/home environment.
Temporary condensation occurs only when the product is out of
service.

Safety Standards

U.S. Nationally Recognized

UL1244 Standard for electrical and electronic measuring and test equipment.

Testing Laboratory Listing
Canadian Certification CAN/CSA C22.2 No. 231 CSA safety requirements for electrical and electronic measuring and

test equipment.

European Union Compliance Low Voltage Directive 73/23/EEC, amended by 93/69/EEC

EN 61010-1 Safety requirements for electrical equipment for measurement,

control, and laboratory use.

Additional Compliance IEC61010-1 Safety requirements for electrical equipment for measurement,

control, and laboratory use.

Safety Certification Compliance

T emperature, operating +5 to +40_ C
Altitude (maximum operating) 2000 meters
Equipment Type Test and measuring
Safety Class Class 1 (as defined in IEC 1010-1, Annex H) – grounded product
Overvoltage Category Overvoltage Category II (as defined in IEC 1010-1, Annex J)
Pollution Degree Pollution Degree 2 (as defined in IEC 1010-1). Note: Rated for indoor use only.

1

High quality shielded cables must be used to ensure compliance to the listed specifications.

3Ć37

TSGĆ422 Ċ SPECIFICATIONS

3Ć38

Installation

Performance Checks & Adjustment

Procedures
