Instructions
Training Board 2
Demonstration Board for Oscilloscopes,
Logic Analyers, and Probes
071-1137 -00
This document applies to firmware version 1.1
and above.
Warning
The servicing instructions are for use by qualified
personnel only. To avoid personal injury, do not
perform any servicing unless you are qualified to
do so. Refer to all safety summaries prior to
performing service.
www.tektronix.com
*P071113700*
071113700
Copyright © Tektronix, Inc. All rights reserved.
Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supercedes
that in all previously published material. Specifications and price change privileges reserved.
Tektronix, Inc., P.O. Box 500, Beaverton, OR 97077
TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.
Table of Contents
General Safety Summary iii..........................................
Service Safety Summary v..........................................
Contacting Tektronix vi.............................................
General Information 1.......................................
Overall Description 3........................................
Signals 4.........................................................
Applying Power to the Training Board 2 6..............................
Detailed Signal Description 7..................................
Fast Edge, J11 and J14 7............................................
1.25Gb/s or 625Mb/s Signals, J7 Electrical and J23 Optical 8...............
Optical Small Form Factor Transceiver Module Connectors, J23 and J28 9....
Low Jitter SAW oscillators 9.........................................
Clean Edge Signal 10...............................................
LVDS Signal 11....................................................
USB 2.0 Test Packet 12..............................................
Logic Analysis Probe Signals 13.......................................
J24 and J25 Arbitrary Waveform Generator Input 13.......................
Switching Power Supply Signals: V SWITCH, I SWITCH 14...............
AMI Signal, Test Point TP3 14........................................
Mixed Signal Waveform 16...........................................
Staircase 17.......................................................
Demonstration Board for Oscilloscopes, Logic Analyzers, and Probes
i
Table of Contents
List of Figures
Figure 1: Tektronix training board 2 1..........................
Figure 2: Training and demonstration board 2...................
Figure 3: Training Board 2 signal and test points 3...............
Figure 4: Fast edge and eye diagram 8..........................
Figure 5: Eye diagrams 9.....................................
Figure 6: Jitter analysis demonstrations 10.......................
Figure 7: Signal fidelity 11.....................................
Figure 8: LVDS signal 11......................................
Figure 9: USB 2.0 test packet 12................................
Figure 10: J24 and J25 arbitrary waveform input 13...............
Figure 11: Power supply signals 14..............................
Figure 12: AMI signal at TP3 15................................
Figure 13: AMI signal in the ANSI T1.102 Mask 15................
Figure 14: AMI signal and Instavu 16...........................
Figure 15: Mixed signal waveform 17............................
Figure 16: Staircase 18........................................
ii
Demonstration Board for Oscilloscopes, Logic Analyzers, and Probes
General Safety Summary
Review the following safety precautions to avoid injury and prevent damage to
this product or any products connected to it. To avoid potential hazards, use this
product only as specified.
Only qualified personnel should perform service procedures.
While using this product, you may need to access other parts of the system. Read
the General Safety Summary in other system manuals for warnings and cautions
related to operating the system.
Observe All Terminal Ratings. To avoid fire or shock hazard, observe all ratings
and markings on the product. Consult the product manual for further ratings
information before making connections to the product.
Use Proper Fuse. Use only the fuse type and rating specified for this product.
Avoid Exposed Circuitry. Do not touch exposed connections and components
when power is present.
Do Not Operate With Suspected Failures. If you suspect there is damage to this
product, have it inspected by qualified service personnel.
Do Not Operate in Wet/Damp Conditions.
Symbols and Terms
Do Not Operate in an Explosive Atmosphere.
Keep Product Surfaces Clean and Dry.
Terms in this Manual. These terms may appear in this manual:
WARNING. Warning statements identify conditions or practices that could result
in injury or loss of life.
CAUTION. Caution statements identify conditions or practices that could result in
damage to this product or other property.
Symbols on the Product. The following symbols may appear on the product:
CAUTION
Refer to Manual
Protective Ground
(Earth) Terminal
Demonstration Board for Oscilloscopes, Logic Analyzers, and Probes
iii
General Safety Summary
iv
Demonstration Board for Oscilloscopes, Logic Analyzers, and Probes
Service Safety Summary
Only qualified personnel should perform service procedures. Read this Service
Safety Summary and the General Safety Summary before performing any service
procedures.
Do Not Service Alone. Do not perform internal service or adjustments of this
product unless another person capable of rendering first aid and resuscitation is
present.
Disconnect Power. To avoid electric shock, switch off the instrument power, then
disconnect the power cord from the mains power.
Use Care When Servicing With Power On. Dangerous voltages or currents may
exist in this product. Disconnect power, remove battery (if applicable), and
disconnect test leads before removing protective panels, soldering, or replacing
components.
To avoid electric shock, do not touch exposed connections.
Demonstration Board for Oscilloscopes, Logic Analyzers, and Probes
v
Service Safety Summary
Contacting Tektronix
Phone 1-800-833-9200*
Address Tektronix, Inc.
Department or name (if known)
14200 SW Karl Braun Drive
P.O. Box 500
Beaverton, OR 97077
USA
Web site www.tektronix.com
Sales support 1-800-833-9200, select option 1*
Service support 1-800-833-9200, select option 2*
Technical support Email: techsupport@tektronix.com
1-800-833-9200, select option 3*
6:00 a.m. -- 5:00 p.m. Pacific time
* This phone number is toll free in North America. After office hours, please leave a
voice mail message.
Outside North America, contact a Tektronix sales office or distributor; see the
Tektronix web site for a list of offices.
vi
Demonstration Board for Oscilloscopes, Logic Analyzers, and Probes
General Information
Training and Demonstration Board for High Performance Oscilloscopes, Logic
Analyzers and Probes. Training Board 2 generates signals that demonstrate
features for high performance electrical and optical oscilloscopes, logic analyzers
and probes.
Figure 1: Tektronix training board 2
Demonstration Board for Oscilloscopes, Logic Analyzers, and Probes
1
General Information
Figure 2: Training and demonstration board
2
Demonstration Board for Oscilloscopes, Logic Analyzers, and Probes
Overall Description
Bit-Rate select
jumper
24 MHz recovered
USB clock
USB 2.0
(480 MBPS)
test packet
J2880
TP29
TP1
GLITCH
J1
Low jitter clocks
Low speed signals
TP6
J6
TP2
TP21
TP20
TP93
TP4
J41
J12
TP311
J2
TP3
Low speed
signals
62.2 MHz or 125 MHz
recovered clock from
adjustable bit-rate signals
TP312
Clean edge
622 MBPS or 1.25 Gb/s
signal
Pseudo random data signals
J15
-- 5 V
J29
1.6 V
J4
2.5 V
J20
J5
3.3 V
J16
J17
J7
J8
J10
J26
J23
J18
J28
J11
Pseudo random
data signals
J14
J24
2.5 Gb/s
125 MHz
J19
J3
J21
J22
J9
J2890
J25
recovered clock
from 2.5 Gb/s signals
Power switch
Standby
Logic analysis
signals
12 V input
jack
On
Figure 3: Training Board 2 signal and test points
Demonstration Board for Oscilloscopes, Logic Analyzers, and Probes
3
Overall Description
Signals
The following signals are available on Training Board 2:
Table 1: Signal Specifications
Signal Specification
J1 Switching power supply voltage signal Approximately ±5V square wave at approximately 270 kHz
amplitude and frequency depend on power supply loading.
3.3 V 3.3 V power supply test point 3.3V ±5%
1.6 V 1.6 V power supply test point 1.2 V to 2.0 V
2.5 V 2.5 V power supply test point 2.5 V ±5%
-- 5 V --5 V power supply test point -- 5 . 0 V ±5%
TP1 Ground test point
TP29 Ground test point
J6 Staircase waveform with glitches. Frequency: 700 Hz
Amplitude 4.0 Vpp.
TP4 Staircase “cheat” signal Positive TTL pulse that signifies a waveform glitch on the
staircase waveform.
J29 External reference for Clean Edge TTL input, R762 must be removed and R761 must be installed.
J5 Clean Edge Output including a probing point. --0.25 V baseline steps to 0 V with a risetime between 200 ps
and 300 ps. Falltime is between 5 ns and 10 ns. Source
impedance is 50 ohms.
J8 1.25 Gb/s or 0.625 Gb/s select jumper Select as marked on board.
J24 and J25 External signal input.. Intended to be used with an arbitrary waveform generator. It
allows connections to probes.
J26 Current probe jumper Disconnect to insert a current probe.
J7 1.25 Gb/s or 0.625 Gb/s output Output level is LVPECL minus 1.2 V.
J18 LVDS Output LVDS voltage levels at J7’s output data rate. Insertion of optical
module affects output -- the least overshoot occurs with the
module installed.
J23 1.25 Gb/s or 0.625 Gb/s optical module Insert appropriate module such as the SFP size optical
transceiver.
J11 and J14 Fast Edge Output Vol = 700 mV, Voh = 1.1 V (RSECL output minus 0.5 V) at a 2.5
Gb/s data rate. Edge rate is less than 50 ps (20% to 80%).
J28 2.5 Gb/s optical module Insert appropriate module such as the SFP size optical
transceiver.
4
Demonstration Board for Oscilloscopes, Logic Analyzers, and Probes
Table 1: Signal Specifications (Cont.)
Signal Specification
Overall Description
TP6 Random Anomalies (Mixed Signal): 400 kHz
square with random signals such as runts, glitches,
staircases, and other signals.
Errata: The auxiliary signals TP2, TP20 and TP21
are actually as follows:
TP2 = Eyeclk
TP21 = Eye Data
TP20 = Cheat
TP20 Mixed signal “Cheat” TTL pulse indicating the presence of an anomaly
TP3 AMI 2 Mb/s
An alternate mark inversion signal
J2 Time Stamp Out A varying exponential signal to display a unique waveform for
TP93 AMI “cheat” signal TTL pulse indicating the presence of an anomaly
J3 and J9 Logic Analyzer connectors for a LASIV probe 125 MHz, 12 bit parallel signal with ECL (500 ps) edges
J19 and J22 Logic Analyzer Test Point A specially conditioned signal derived from J3 and J9
J12 USB 2.0 signals
Frequency: 400 kHz
Amplitude: 4.0 Vpp
Anomaly repetition: approx 1 per 750 ms
Frequency: 2.0 Mb/s
Amplitude: 4.0 V pk-pk
T1.102 DS1A Mask
Telecom Trigger: Isolated +1
Isolated --1
Eye Diagram
each frame in a FastFrame sequence
480 Mbits/s
The connector is terminated with 100 ohms at the
header (use a Hi--Z probe)
J41 USB Output Clock 3.3 V TTL, 24 MHz
J16 Low Jitter 125 MHz Clock Signal Frequency: 125 MHz
J15 Low Jitter 132 MHz Clock Signal Frequency: 132 MHz
J17 Recovered Clock for the 1.25 Gb/s or 0.625 Gb/s
signal
Vhigh = +400 mV
Vlow = 0.00 V
Vdifferential -- ±400 m V (800 mV pp)
Amplitude: LVPECL
Rise/Fall Time: 900 ps
Jitter < 6 ps rms
Amplitude: LVPECL
Rise/Fall Time: 900 ps
Jiter < 6 ps rms
1/10 the serial data frequency of J7. Either 125 MHz or 62.5 MHz
depending on the setting of J8.
Demonstration Board for Oscilloscopes, Logic Analyzers, and Probes
5
Overall Description
Table 1: Signal Specifications (Cont.)
Signal Specification
J10 Recovered Clock for the 2.5 Gb/s Fast Rise Signal 1/20 the serial data rate or 125 MHz
J2880 Voltage on the current loop circuit board run
Probe Connections
Special connections are included to connect the following probes:
P6330, P6248, P7330, P6245, P6249, P7260, and LASI--V
Applying Power to the Training Board 2
Training Board 2 requires a 12 V, 1 A power supply. The power input jack, see
Figure 3 on page 3, requires the equivalent of a Switchcraft S760 2.0 mm plug
with the center conductor positive.
Compatible power supplies are: the Tektronix part number 119-4812-01, Ault
PW118KA1202F02 and the Astrodyne SPU15A-3.
6
Demonstration Board for Oscilloscopes, Logic Analyzers, and Probes
Detailed Signal Description
Fast Edge, J11 and J14
A 2.5 Gb/s 8b/10b encoded serial data stream with sub 100 ps edges.
Description
Intended Demonstrations
This signal is a differential data stream at the 2.5 Gb/s data rate. The signal level
is from an RSECL logic device. This is currently the fastest logic family that is
commercially available. The data is generated from a 7-bit pseudorandom
sequence generator. A 125 MHz recovered clock is available on J10. The output
level of the signal is one schottky diode drop below the RSECL logic levels and
was not AC coupled because of the signal degradation that would have occurred
from board mounted coupling capacitors. External coaxial AC coupling
capacitors such as the Tektronix part number 015-1013-00 SMA DC Block, or
the 015-0221-00 BNC DC Block can be used if desired to remove this offset.
High Speed. This signal was designed to demonstrate the need for fast oscilloscope risetimes. This signal is produced with “off the shelf” logic that is now
being produced with extremely fast edges. Signal integrity issues such as
overshoot and ringing are also increasingly important to measure since signal
defects are very easy to generate with signals that have fast edges such as these.
Use Advanced -- Width triggers to stabilize the display on the 7-bit pseudorandom sequence.
Communication Signals. This signal is also modulated as a 2.5 Gb/s communication signal. This is the type of signal that would be seen in one of the new serial
bus standards such as Infiniband or 3GIO. This signal could be used to demonstrate clock recovery, mask testing, etc.
Probe Connections. Special circuit board run shapes have been included to
connect the latest probes to these circuits. The rectangle shaped pads are ground
points to minimize loop area of the probe’s ground connection.
Demonstration Board for Oscilloscopes, Logic Analyzers, and Probes
7
Detailed Signal Description
Fast Edge Tr, Tf Measured with a TDS6604
Figure 4: Fast edge and eye diagram
2.5Gb/s Eye
1.25 Gb/s or 625 Mb/s Signals, J7 Electrical and J23 Optical
Description
Intended Demonstrations
This signal is generated from a 7 bit pseudorandom sequence generator at either
the 1.25 Gb/s or 625 Mb/s data rate. The rate is selectable by a jumper installed
on J8.
This signal is a general--purpose communication signal that can be used to
demonstrate clock recovery, mask testing and serial triggering.
8
Demonstration Board for Oscilloscopes, Logic Analyzers, and Probes
Detailed Signal Description
1.25 Gb/s Eye
Figure 5: Eye diagrams
622 Mb/s Eye
Optical Small Form Factor Transceiver Module Connectors, J23 and J28
Two small form factor (SFF) connectors are available. One is connected to the
2.5 Gb/s data rate and the other is connected to the 1.25/0.625 Gb/s data rate.
Any transceiver that uses 3.3 V and can accept the indicated data rates can be
used in the module socket.
Low Jitter SAW oscillators
Two available oscillator jitter measurements, 125 MHz and 132 MHz. These
oscillators have less than 6 ps rms jitter.
Use these signals for Jitter Analysis demonstrations.
Demonstration Board for Oscilloscopes, Logic Analyzers, and Probes
9
Detailed Signal Description
Figure 6: Jitter analysis demonstrations
Clean Edge Signal
This signal steps from --0.25 V to 0.0 0V at a rise time of about 270 ps. There is
very little overshoot or ringing on the waveform.
This signal is intended to be used to demonstrate signal fidelity. This signal must
be terminated into 50 ohms, even when a probe is used on the “probe point”
circuit board pads.
10
Demonstration Board for Oscilloscopes, Logic Analyzers, and Probes
Figure 7: Signal fidelity
Detailed Signal Description
LVDS Signal
LVDS level signals are available on J18. These signals follow the signaling rate
(1.25 Gb/s or 625 Gb/s) that is selected on J8. Overshoot can be removed by
inserting an optical module into the 1.25/0.622 Gb/s receptacle J23.
LVDS Single Sample LVDS “Eye”
Figure 8: LVDS signal
Demonstration Board for Oscilloscopes, Logic Analyzers, and Probes
11
Detailed Signal Description
USB 2.0 Test Packet
This signal is a differential USB 2.0 signal transmitting the test mode
“T est_Packet” signal defined in section 7.1.20 of the Universal Serial Bus
Specification Revision 2.0.
USB 2.0 TBST Packet
“Single Ended”
”Differential”
“Eye”
Figure 9: USB 2.0 test packet
12
Demonstration Board for Oscilloscopes, Logic Analyzers, and Probes
Logic Analysis Probe Signals
Detailed Signal Description
Description
Intended Demonstration
The 2.5 Gb/s signal, see Figure 9, on page 12, is recovered and de-serialized to
form a 16 bit parallel output. This output is routed about 3 inches across the
board. A TLA style connector, the “LASI-V” is present at the beginning and at
the end of the 3 inch signal route. Some of the signals have intentional shorted
stubs added to emulate circuit routing problems. Other signals have up to
9 inches of additional routing length added to mismatch delays. The edge speed
of the output is about 500 ps.
This signal was designed to show the ability of our latest logic analyzers to
easily display an analog waveform from any of the displayed logic signals.
Defects on the signal will be easily seen on the analog waveform and can point
to why an incorrect logic signal occurred.
J24 and J25 Arbitrary Waveform Generator Input
These inputs drive specially shaped circuit board runs that out latest probes can
connect to. J26 can be used to connect the CT6 current probe to these signals. An
arbitrary waveform generator, or any generator including the other Training
Board 2 signals, can be cabled to these inputs. There are no active components
on these traces. J24 and J25 connect to 50-ohm transmission lines and terminate
in 50-ohm resistors.
Figure 10: 24 and J25 arbitrary waveform input
Demonstration Board for Oscilloscopes, Logic Analyzers, and Probes
13
Detailed Signal Description
Switching Power Supply Signals: V SWITCH, I SWITCH
The V SWITCH and I SWITCH signals are derived from the board’s switching
power supply. This power supply switches at about 260 kHz. These signals were
included to demonstrate the oscilloscope’s current, voltage and power measure-
ment capabilities.
Figure 11: Power supply signals
AMI Signal, Test Point TP3
AMI simulates an “alternate mark inversion” signal at the DS1A data rate
(2.048 Mb/s). This signal will look like the following Figure.
14
Demonstration Board for Oscilloscopes, Logic Analyzers, and Probes
Detailed Signal Description
Figure 12: AMI signal at TP3
Figure 13: AMI signal in the ANSI T1.102 Mask
This signal also has built in anomalies that are useful for demonstrating Instavu.
Demonstration Board for Oscilloscopes, Logic Analyzers, and Probes
15
Detailed Signal Description
Mixed Signal Waveform
Figure 14: AMI signal and Instavu
Mixed signal is a 400 kHz waveform with a number of intermittent anomalies as
shown in Figure 15, on page 17.
16
Demonstration Board for Oscilloscopes, Logic Analyzers, and Probes
Detailed Signal Description
Figure 15: Mixed signal waveform
Staircase
The staircase waveform is a 687 Hz waveform that steps every 164 s(6.1kHz).
Noise is added to the waveform to demonstrate HiRes. A fast negative going
glitch exists at the end of the third step to demonstrate advanced triggering. This
is difficult to trigger on because of the presence of noise. Normal glitch
triggering will not work very well. One way to trigger on this pulse is shown in
Figure 16, on page 18. Finally, intermittent glitches and double steps exist in the
waveform to demonstrate FastAcq.
Demonstration Board for Oscilloscopes, Logic Analyzers, and Probes
17
Detailed Signal Description
Figure 16: Staircase
18
Demonstration Board for Oscilloscopes, Logic Analyzers, and Probes
Loading...
