CI3 350 NF
TKI2 325 DD
CI2 350 NF
Please read this user manual first!
Dear Customer,
We hope that your product, which has been produced in modern plants and
checked under the most meticulous quality control procedures, will provide you
an effective service.
Therefore, read this entire user manual carefully before using the product and
keep it as a reference. If you handover the product to someone else, give the
user manual as well.
The user manual will help you use the product in a fast and safe way.
• Read the manual before installing and operating the product.
• Make sure you read the safety instructions.
• Keep the manual in an easily accessible place as you may need it later.
• Read the other documents given with the product.
Remember that this user manual is also applicable for several other models.
Differences between models will be identified in the manual.
Explanation of symbols
Throughout this user manual the following symbols are used:
CImportant information or useful tips.
AWarning against dangerous conditions for life and property.
BWarning against electric voltage.
Recycling
This product is supplied with the selective sorting symbol for waste electrical
and electronic equipment (WEEE).
This means that this product must be handled pursuant to European Directive
2002/96/EC in order to be recycled or dismantled to minimise its impact on
the environment. For further information, please contact your local or regional
authorities.
Electronic products not included in the selective sorting process are potentially
dangerous for the environment and human health due to the presence of
hazardous substances.
EN
1
CONTENTS
1 Your refrigerator 3
2 Important Safety
Warnings
Intended use .....................................4
General safety ...................................4
For products with a water dispenser; ...6
Child safety ........................................6
HCA warning .....................................6
Things to be done for energy saving .. 6
3 Installation
Points to be considered when
re-transporting your refrigerator..........
Before you start the refrigerator, .........
Electrical connection ..........................
Disposing of the packaging ...............
Disposing of your old refrigerator .......
Placing and Installation ......................
Replacing the interior lamp ............
Reversing the doors ..........................
4
4 Preparation 10
5 Using your refrigerator 11
Control panel...................................11
Using interior compartment
Cooling......
Freezing
Defrost ............................................12
Zero temperature compartment ......1
......................................12
...........................................12
s.............12
6 Maintenance and
4
cleaning
Protection of plastic surfaces ..........14
7 Troubleshooting
1
5
1
3
EN
2
1 Your refrigerator
1
2
3
4
3
15
5
6
7
8
9
10
16
10
10
11
11
12
11
13
14
Control panel
1.
2. Interior light
3. Adjustable shelves
4. Wine rack
5. 0 °C Compartment
6. Defrost water collection channel
-drain tube
7. Crisper cover
Ice bank
9.
Freezer compartment drawers
10.
Adjustable door shelves
11.
Egg tray
12.
Bottle shelf
13.
Freezer fan
14.
Fridge compartment
15.
Freezer compartment
16.
8. Crisper
C Figures that take place in this instruction manual are schematic and may not
correspond exactly with your product. If the subject parts are not included in
the product you have purchased, then it is valid for other models.
EN
3
2 Important Safety Warnings
Please review the following information.
Failure to observe this information may
cause injuries or material damage.
Otherwise, all warranty and reliability
commitments will become invalid.
Original Spare parts will be provided
for 10 years, following the product
purchasing date.
Intended use
This product is intended to be used
• indoors and in closed areas such as
homes;
• in closed working environments
• in closed accommodation areas
• It should not be used outdoors.
General safety
• When you want to dispose/scrap
• Consult your authorized service for
• For products with a freezer
• For products with a freezer
as stores and offices;
such
such as farm houses, hotels,
pensions.
the product, we recommend you to
consult the authorized service in
to learn the required
order
information and authorized bodies.
all your questions and problems
related to the refrigerator. Do not
intervene or let someone intervene to
the refrigerator without notifying the
authorised services.
compartment; Do not eat cone ice
cream and ice cubes immediately
after you take them out of the freezer
compartment! (This may cause
frostbite in your mouth.)
compartment; Do not put bottled
and canned liquid beverages in the
freezer compartment. Otherwise,
these may burst.
• Do not touch frozen food by hand;
they may stick to your hand.
• Unplug your refrigerator before
cleaning or defrosting.
• Vapor and vaporized cleaning
materials should never be used in
cleaning and defrosting processes of
your refrigerator. In such cases, the
vapor may get in contact with the
electrical parts and cause short circuit
or electric shock.
• Never use the parts on your
refrigerator such as the door as a
means of support or step.
• Do not use electrical devices inside
the refrigerator.
• Do not damage the parts, where
the refrigerant is circulating, with
drilling or cutting tools. The refrigerant
that might blow out when the gas
channels of the evaporator, pipe
extensions or surface coatings are
punctured causes skin irritations and
eye injuries.
• Do not cover or block the ventilation
holes on your refrigerator with any
material.
• Electrical devices must be repaired
by only authorised persons. Repairs
performed by incompetent persons
create a risk for the user.
• In case of any failure or during
a maintenance or repair work,
disconnect your refrigerator’s mains
supply by either turning off the
relevant fuse or unplugging your
appliance.
• Do not pull by the cable when pulling
off the plug.
• Place the beverage with higher proofs
tightly closed and vertically.
EN
4
• Never store spray cans containing
flammable and explosive substances
in the refrigerator.
• Do not use mechanical devices
or other means to accelerate the
defrosting process, other than those
recommended by the manufacturer.
• This product is not intended to be
used by persons with physical,
sensory or mental disorders or
unlearned or inexperienced people
(including children) unless they are
attended by a person who will be
responsible for their safety or who will
instruct them accordingly for use of
the product
• Do not operate a damaged
refrigerator. Consult with the service
agent if you have any concerns.
• Electrical safety of your refrigerator
shall be guaranteed only if the earth
system in your house complies with
standards.
• Exposing the product to rain, snow,
sun and wind is dangerous with
respect to electrical safety.
• Contact authorized service when
there is a power cable damage to
avoid danger.
• Never plug the refrigerator into
the wall outlet during installation.
Otherwise, risk of death or serious
injury may arise.
• This refrigerator is intended for only
storing food items. It must not be
used for any other purpose.
• Label of technical specifications is
located on the left wall inside the
refrigerator.
• Never connect your refrigerator to
electricity-saving systems; they may
damage the refrigerator.
• If there is a blue light on the
refrigerator, do not look at the blue
light with optical tools.
• For manually controlled refrigerators,
wait for at least 5 minutes to start the
refrigerator after power failure.
• This operation manual should be
handed in to the new owner of the
product when it is given to others.
• Avoid causing damage on power
cable when transporting the
refrigerator. Bending cable may cause
fire. Never place heavy objects on
power cable.
• Do not touch the plug with wet hands
when plugging the product.
• Do not plug the refrigerator if the
wall outlet is loose.
• Water
should not be sprayed on
inner or outer parts of the product
for safety purposes.
• Do not spray substances containing
inflammable gases such as propane
gas near the refrigerator to avoid fire
and explosion risk.
• Never place containers filled with
water on top of the refrigerator; in
the event of spillages, this may
cause electric shock or fire.
• Do not overload the refrigerator with
food. If overloaded, the food items
may fall down and hurt you and
damage refrigerator when you open
the door.
• Never place objects on top of the
refrigerator; otherwise, these
objects may fall down when you
open or close the refrigerator's
door.
EN
5
• As they require a precise
temperature, vaccines, heatsensitive medicine and scientific
materials and etc. should not be
kept in the refrigerator.
• If not to be used for a long time,
refrigerator should be unplugged.
possible problem in power cable
may cause fire.
• The plug's tip should be cleaned
regularly with a dry cloth; otherwise,
it may cause fire.
• Refrigerator may move if adjustable
legs are not properly secured on the
floor. Properly securing adjustable
legs on the floor can prevent the
refrigerator to move.
• When carrying the refrigerator, do
not hold it from door handle.
Otherwise, it may be snapped.
• When you have to place your
product next to another refrigerator
or freezer, the distance between
devices should be at least 8cm.
Otherwise, adjacent side walls may
be humidified.
A
For products with a water
dispenser;
Pressure of water mains should be
minimum 1 bar. Pressure of water
mains should be maximum 8 bars.
• Use only potable water.
Child safety
• If the door has a lock, the key should
be kept away from reach of children.
• Children must be supervised to
prevent them from tampering with
the product.
HCA warning
If your product's cooling system
contains R600a:
This gas is flammable. Therefore, pay
attention to not damaging the cooling
system and piping during usage and
transportation.
In the event of damage, keep your
product away from potential fire
sources that can cause the product
catch a fire and ventilate the room in
which the unit is placed. Ignore this
warning if your product's cooling
system contains R134a.
Type of gas used in the product is
stated in the type label which is on the
left wall inside the refrigerator.
Never throw the product in fire for
disposal.
Things to be done for energy
saving
• Do not leave the doors of your
refrigerator open for a long time.
• Do not put hot food or drinks in your
refrigerator.
• Do not overload your refrigerator so
that the air circulation inside of it is
not prevented.
• Do not install your refrigerator
under direct sunlight or near heat
emitting appliances such as
dishwashers or radiators. Keep your
refrigerator at least 30cm away from
heat emitting sources and at least
5cm from electrical ovens.
• Pay attention to keep your food in
closed containers.
• For products with a freezer
compartment; You can store
maximum amount of food items in
the freezer when you remove the
shelf or drawer of the freezer. Energy
consumption value stated for your
refrigerator has been determined
by removing freezer shelf or drawer
and under maximum load. There
is no harm to use a shelf or drawer
according to the shapes and size of
food to be frozen.
• Thawing frozen food in fridge
compartment will both provide
energy saving and preserve the food
quality.
ovens,
EN
6
3 Installation
B In case the information which are
given in the user manual are not
taken into account, manufacturer will
not assume any liability for this.
Points to be considered
when re-transporting your
refrigerator
1.
Your refrigerator must be emptied
and cleaned prior to any transportation.
2.Shelves, accessories, crisper and etc.
in your refrigerator must be fastened
securely by adhesive tape against any
jolt before repackaging.
3.Packaging must be tied with thick
tapes and strong ropes and the
rules of transportation printed on the
package must be followed.
Please do not forget…
Every recycled material is an
indispensable source for the nature
and for our national resources.
If you wish to contribute to recycling
the packaging
further information from the
environmental bodies or local authorities.
materials, you can get
Before you start the
refrigerator,
Check the following before you start to
use your refrigerator:
1. Is the interior of the refrigerator dry
and can the air circulate freely in the
rear of it?
2. Clean the interior of the refrigerator
recommended in the
as
“Maintenance and cleaning” section.
3. Connect the plug of the refrigerator
to the wall socket. When the fridge
door is opened, fridge internal lamp
will turn on.
4. When the compressor starts to
operate, a sound will be heard. The
liquid and gases sealed within the
refrigeration system may also give rise
to noise, even if the compressor is
not running and this is quite normal.
5. Front edges of the refrigerator may
feel warm. This is normal. These
areas are designed to be warm to
avoid condensation.
Electrical connection
Connect your product to a grounded
socket which is being protected by a
fuse with the appropriate capacity.
Important:
The connection must be in compliance
with national regulations.
• The power plug must be easily
accessible after installation.
• Electrical safety of your refrigerator
shall be guaranteed only if the earth
system in your house complies with
standards.
• The voltage stated on the label
located at left inner side of your
product should be equal to your
network voltage.
• Extension cables and multi plugs
must not be used for connection.
B A damaged power cable must be
replaced by a qualified electrician.
B Product must not be operated before
it is repaired! There is the risk of
electric shock!
EN
Disposing of the packaging
The packing materials may be
dangerous for children. Keep the
packing materials out of the reach
of children or dispose of them by
classifying them in accordance with
the waste instructions stated by your
local authorities. Do not throw away
with regular house waste, throw away
on packaging pick up spots
designated by the local authorities.
The packing of your refrigerator is
produced from recyclable materials.
Disposing of your old
refrigerator
Dispose of your old refrigerator without
giving any harm to the environment.
• You may consult your authorized
dealer or waste collection center of
your municipality about the disposal
of your refrigerator.
Before disposing of your refrigerator,
cut out the electric plug and, if there
are any locks on the door, make them
inoperable in order to protect childr
against any danger.
en
Placing and Installation
A If the entrance door of the room
where the refrigerator will be installed is
not wide enough for the refrigerator to
pass through, then call the authorized
service to have them remove the
doors of your refrigerator and pass it
sideways through the door.
1. Install your refrigerator to a place
that allows ease of use.
2. Keep
heat
direct sunlight.
3. There must be appropriate air
ventilation around your refrigerator
in order to achieve an efficient
operation. If the refrigerator is to be
placed in a recess in the wall, there
must be at least 5 cm distance with
the ceiling and at least 5 cm with
the wall. Do not place your product
on the materials such as rug or
carpet.
4. Place your refrigerator on an even
floor surface to prevent jolts.
5. Do not keep your refrigerator in
ambient temperatures under 10°C.
refrigerator
your
sources, humid places and
away
from
Replacing the interior lamp
To change the Bulb/LED used for
illumination of your refrigerator,
call your AuthorisedService.
The lamp(s) used in this appliance is
not suitable for household room
illumination. The intended purpose of
this lamp is to assist the user to place
foodstuffs in the refrigerator/freezer in
a safe and comfortable way.
The lamps used in this appliance have
to withstand extreme physical
conditions such as temperatures
below -20°C.
EN
Reversing the doors
Proceed in numerical order
7
8
9
10
18
1
2
3
4
5
6
19
17
16
13
11
20
14
12
15
EN
4 Preparation
• Your refrigerator should be installed at
least 30 cm away from heat sources
such as hobs, ovens, central heater
and stoves and at least 5 cm away
from electrical ovens and should not
be located under direct sunlight.
• The ambient temperature of the room
where you install your refrigerator
should at least be 10°C. Operating
your refrigerator under cooler
conditions is not recommended with
regard to its effciency.
• Please make sure that the interior
of your refrigerator is cleaned
thoroughly.
• If two refrigerators are to be installed
side by side, there should be at least
2 cm distance between them.
• When you operate your refrigerator
for the f rst time, please observe the
following instructions during the initial
six hours.
• The door should not be opened
frequently.
• It must be operated empty without
any food in it.
• Do not unplug your refrigerator. If
a power failure occurs out of your
control, please see the warnings in
the “Recommended solutions for the
problems” section.
• Original packaging and foam
materials should be kept for future
transportations or moving.
1
EN
5 Using your refrigerator
Control Panel
71 2 3 4 5 6
1- On/Off function
Press the On/Off button for 3
seconds to turn off or turn on the
fridge.
2- Fridge Set Function
This function allows you to make the
fridge compartment temperature
setting.
Press this button to set the
temperature of the fridge compartment
to - (warmest), --, ---, ---(coldest) respectively.
3- Fridge Compartment
Temperature Setting Indicator
Indicates the temperature set for the
Fridge Compartment. Settings are (warmest), --, ---, ---- (coldest)
4- High Temperature Error /
Warning Indicator
This light comes on during high
temperature failures and error
warnings.
5- Quick Fridge Indicator
This icon lits when the Quick Fridge
function is active.
6-Quick Fridge Function
When you press Quick Fridge button,
the temperature of the compartment
will be colder than the adjusted values.
This function can be used for food
placed in the fridge compartment and
required to be cooled down rapidly.
If you want to cool large amounts of
fresh food, it is recommended to active
this feature before putting the food
into the fridge. Quick Fridge indicator
will remain lit when the Quick Fridge
function is enabled. To cancel this
function press Quick Fridge button
again. Quick Fridge indicator will turn
off and return to its normal settings.
If you do not cancel it, Quick Fridge
will cancel itself automatically after 2
hours or when the fridge compartment
reaches to the required temperature.
This function is not recalled when
power restores after a power failure.
7- Alarm Off
When the fridge door is opened for 2
minutes or when there a sensor failure,
a sound alarm turns on. Alarm can be
turned off by pressing "Alarm Off"
button.
Sensor failure alarm will not sound till
power failure. If you close the door
and then open again "Door open
alarm" will be activated again after 2
minutes later .
1
EN
Using interior compartments
Movable shelves: Distance between
the shelves can be adjusted when
necessary.
Vegetable drawer: Vegetables and
fruits can be stored in this
compartment for long periods without
decaying.
Bottle shelf: Bottles, jars and tins can
be placed in these shelves.
Cooling
Food storage
The fridge compartment is for the
short-term storage of fresh food and
drinks.
Bottles can be stored in the bottle
shelf of the door.
Raw meat is best kept in a
polyethylene bag in the 0 °C
compartment.
Allow hot foods and beverages to
cool to room temperature prior to
placing them in the refrigerator.
Freezing
Freezing food
The freezing compartment is marked
with this symbol.
You can use the appliance for freezing
fresh food as well as for storing
pre-frozen food.
Please refer to the recommendations
given on the packaging of your food.
Defrost
A) Fridge compartment
Fridge compartment performs fullautomatic defrosting. Water drops and
a frosting up to 7-8 mm can occur on
the inner rear wall of the fridge
compartment while your refrigerator
cools down. Such formation is normal
as a result of the cooling system.
The frost formation is defrosted by
performing automatic defrosting
with certain intervals thanks to the
automatic defrosting system of the rear
wall. User is not required to scrape the
frost or remove the water drops. Water
resulting from the defrosting passes
from the water collection groove and
flows into the evaporator through the
drain pipe and evaporates here by
itself.
Check regularly to see if the drain pipe
is clogged or not and clear it with the
stick in the hole when necessary.
1
EN
B) Freezer compartment
The freezer compartment defrosts
automatically.
Warnings!
The fan inside the freezer compartment
circulates cold air. Never insert any
object through the guard. Do not allow
children to play with the freezer fan.
Never store products that contain
inflammable propellant gas (eg
dispensers, spray cans etc.) or
explosive substances.
Don’t cover the shelves with any
protective materials, which may
obstruct air circulation.
Do not allow children to play with
appliance or tamper with the controls.
Do not obstruct the freezer fan guard
to ensure that you obtain the best
possible performance from your
appliance.
Zero temperature
compartment
This compartment has been designed
to store frozen food which would be
thawed slowly (meat, fish, chicken,etc.)
as required. Zero temperature
compartment is the coldest place of
your refrigerator in which dairy
products (cheese, butter), meat, fish or
chicken may be kept at ideal storage
conditions.
Vegetables and/or fruits must not be
placed in this compartment.
1
EN
6 Maintenance and cleaning
A Never use gasoline, benzene or
similar substances for cleaning
purposes.
B We recommend that you unplug the
appliance before cleaning.
B Never use any sharp abrasive
instrument, soap, household
cleaner, detergent and wax polish for
cleaning.
C Use lukewarm water to clean the
cabinet of your refrigerator and wipe it
dry.
C Use a damp cloth wrung out in
a solution of one teaspoon of
bicarbonate of soda to one pint of
water to clean the interior and wipe it
dry.
B Make sure that no water enters the
lamp housing and other electrical
items.
B If your refrigerator is not going to be
used for a long period of time, unplug
the power cable, remove all food,
clean it and leave the door ajar.
C Check door seals regularly to ensure
they are clean and free from food
particles.
A To remove door racks, remove all the
contents and then simply push the
door rack upwards from the base.
ANever use cleaning agents or water
that contain chlorine to clean the
outer surfaces and chromium coated
parts of the product. Chlorine causes
corrosion on such metal surfaces.
Protection of plastic
surfaces
Do not put the liquid oils or oil-cooked
C
meals in your refrigerator in unsealed
containers as they damage the
plastic surfaces of your refrigerator. In
case of spilling or smearing oil on the
plastic surfaces, clean and rinse the
relevant part of the surface at once
with warm water.
1
EN
7 Troubleshooting
Please review this list before calling the service. It will save your time and
money. This list includes frequent complaints that are not arising from defective
workmanship or material usage. Some of the features described here may not
exist in your product.
The refrigerator does not operate.
• The plug is not inserted into the socket correctly. >>>Insert the plug into the
socket securely.
• The fuse of the socket which your refrigerator is connected to or the main fuse
have blown out. >>>Check the fuse.
Condensation on the side wall of the fridge compartment (MULTIZONE, COOL
CONTROL and FLEXI ZONE).
• Ambient is very cold. >>>Do not install the refrigerator in places where the
temperature falls below 10 °C.
• Door has been opened frequently. >>>Do not open and close the door of
refrigerator frequently.
• Ambient is very humid. >>>Do not install your refrigerator into highly humid
places.
• Food containing liquid is stored in open containers. >>>Do not store food with
liquid content in open containers.
• Door of the refrigerator is left ajar. >>>Close the door of the refrigerator.
• Thermostat is set to a very cold level. >>>Set the thermostat to a suitable level.
• Compressor is not running
• Protective thermic of the compressor will blow out during sudden power
failures or plug-out plug-ins as the refrigerant pressure in the cooling system
of the refrigerator has not been balanced yet. The refrigerator will start running
approximately after 6 minutes. Please call the service if the refrigerator does not
startup at the end of this period.
• The fridge is in defrost cycle. >>>This is normal for a full-automatically defrosting
refrigerator. Defrosting cycle occurs periodically.
• The refrigerator is not plugged into the socket. >>>Make sure that the plug is ft
into the socket.
• Temperature settings are not made correctly. >>>Select the suitable temperature
value.
• There is a power outage. >>>Refrigerator returns to normal operation when the
power restores.
1
EN
