CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user
to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may
be of sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO
NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
5-DISC DVD/CD CHANGER
OWNER’S MANUAL
DVDC96
2
Safety Precautions
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated
‘dangerous voltage’ within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the
appliance.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN
OR MOISTURE.
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
ATTENTION:
POUR EVITER LES CHOCS ELECTRIQUE, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS
LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOUD.
CAUTION: This Digital Video Disc Player employs a Laser System.
To ensure proper use of this product, please read this owner’s manual carefully and retain for future reference, should the unit require maintenance, contact an authorized service location-see service procedure.
Use of controls, adjustments or the performance of procedures other than those specified may result in hazardous radiation exposure.
To prevent direct exposure to laser beam, do not try to open the enclosure. Visible laser radiation is present
when cabinet is removed from the enclosure. DO NOT STARE INTO BEAM.
FCC NOTICE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
There is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connect
ed.
- Consult the dealer or an experienced radio/TV technician for help.
FCC WARNING: Changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
INDUSTRY CANADA REQUIREMENT :
This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment
Regulations.
Cet appareil numéruque de la classe B respecte toutes les exigences du Règlement sur le matériel brouilleur
du Canada.
WARNING
AVERTISSEMENT
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING : TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
RISQUE DE CHOC ELECTRIQUE NE
PAS OUVRIR
RECORD YOUR MODEL NUMBER (Now, while you can see it)
The model and serial number of your new DVD
player are located on the back of the DVD player cabinet. For your future convenience, we suggest that you record these numbers here:
MODEL NO.____________________________________
SERIAL NO.____________________________________
3
Table of Contents
Introduction
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Important Safety Instructions . . . . . . . . . . . . . . . . . . 4-5
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Notes on Discs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Identification of Controls
. . . . . . . . . . . . . . . . . . . . . . . 8-11
Front Panel/Display window . . . . . . . . . . . . . . . . . . . . . . . . 8
Rear Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Preparing the Remote Control . . . . . . . . . . . . . . . . . . . . . 11
Operating with the Remote Control . . . . . . . . . . . . . . . . . . 11
Connections
Connecting to a TV. . . . . . . . . . . . . . . . . . . . . . . . . . 12
Connecting to an Audio System (STEREO) . . . . . . . 13
Connecting to Optional Audio System . . . . . . . . . 14-17
With Dolby Digital (AC-3) Sound. . . . . . . . . . . . . . . . . . . . 14
With Dolby Pro Logic Surround Sound . . . . . . . . . . . . . . . 15
Techwood model ddr94. . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Techwood model ddr95. . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Basic Operations
Basic Playback . . . . . . . . . . . . . . . . . . . . . . . . . . 18-21
Various speed playback
. . . . . . . . . . . . . . . . . . . . . . 22
Initial Settings
Audio set-up. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Common procedures of initial settings . . . . . . . . . . . 24
Selecting disc Languages. . . . . . . . . . . . . . . . . . . . . 25
Selecting rating level and password . . . . . . . . . . . 26-27
Selecting TV Aspect . . . . . . . . . . . . . . . . . . . . . . . . . 28
Selecting Menu Language . . . . . . . . . . . . . . . . . . . . 29
Selecting TV output . . . . . . . . . . . . . . . . . . . . . . . . . 29
Table of Languages and Their Abbreviations. . . . . . . 30
Operation Using GUI Menu Icons
General Information about GUI menu icons . . . . . . . 31
Detailed description of each GUI menu icon . . . . . . . 32
Advanced Operation
Using a title menu . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Using a DVD menu. . . . . . . . . . . . . . . . . . . . . . . . . . 33
Changing subtitle language . . . . . . . . . . . . . . . . . . . 34
Changing audio soundtrack language . . . . . . . . . . . . 34
Viewing from another angle . . . . . . . . . . . . . . . . . . . 35
Producing a 3D Surround effect . . . . . . . . . . . . . . . . 35
Repeat Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Storing markers in memory to be
viewed (listened to) again. . . . . . . . . . . . . . . . . . . . . 37
Zoom Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Random Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Memorizing Settings for Viewed DVDs . . . . . . . . . . . 39
Program Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Mp3 Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41~42
Reference
Disc Requirements/Copyright Information . . . . . . . . . 43
Before Calling Service Personnel . . . . . . . . . . . . . . . 44
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
4
CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS IN THIS OWNER’S MANUAL AND THOSE
MARKED ON THE UNIT. RETAIN THIS BOOKLET FOR FUTURE REFERENCE.
This set has been designed and manufactured to assure personal safety. Improper use can result in electric shock or fire hazard.
The safeguards incorporated in this unit will protect you if you observe the following procedures for installation, use and servicing.
This unit is fully transistorized and does not contain any parts that can be repaired by the user.
DO NOT REMOVE THE CABINET COVER, OR YOU MAY BE EXPOSED TO DANGEROUS VOLTAGE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL ONLY.
1. Read owner’s manual
After unpacking this product, read the owner’s
manual carefully, and follow all the operating and other
instructions.
2. Power Sources
This product should be operated only from the type of
power source indicated on the marking label. If you are
not sure of the type of power supply in your home, consult
your product dealer or local power company. For products
intended to operate from battery power, or other sources,
refer to the operating instructions.
3. Grounding or Polarization
This product is equipped with a polarized alternating current line plug (a plug having one blade wider than the
other). This plug will fit into the power outlet only one way.
This is a safety feature. If you are unable to insert the
plug fully into the outlet, try reversing the plug. If the plug
should still fail to fit, contact your electrician to replace
your obsolete outlet. Do not defeat the safety purpose of
the polarized plug.
4. Ventilation
Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to
protect it from overheating. These openings must not be
blocked or covered. The openings should never be blocked
by placing the product on a bed, sofa, rug or other similar
surface. This product should not be placed in a built-in
installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have
been adhered to.
5. Heat
The product should be situated away from heat sources
such as radiators, heat registers, stoves, or other products
(including amplifiers) that produce heat.
6. Water and Moisture
Do not use this product near water-for example, near a
bath tub, wash bowl, kitchen sink. or laundry tub; in a wet
basement; or near a swimming pool and the like.
7. Cleaning
Unplug this product from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol cleaners.
Use a damp cloth for cleaning.
8. Power-Cord Protection
Power-supply cords should be routed so that they are not
likely to be walked on or pinched by items placed upon or
against them, playing particular attention to cords at
plugs, convenience receptacles, and the point where they
exit from the product.
9. Overloading
Do not overload wall outlets, extension cords, or
integral convenience receptacles as this can result in a
risk of fire or electric shock.
10. Lightning
For added protection of this product during storms, or
when it is left unattended and unused for long
periods of time, unplug it from the wall outlet.
This will prevent damage to the product due to
lightning and power-line surges.
11. Object and Liquid Entry
Never push objects of any kind into this product through
openings as they may touch dangerous
voltage points or short-out parts that could result in a fire
or electric shock. Never spill liquid of any kind on the
product.
12. Attachments
Do not use attachments not recommended by the product
manufacturer as they may cause hazards.
Important safety instructions
5
13. Accessories
Do not place this product on an unstable cart, stand, tripod, bracket, or table. The product may fall, causing serious injury to a child or adult, and
serious damage to the
product. Use only with a cart,
stand, tripod, bracket, or table
recommended by the manufacturer, or sold with the product. Any
mounting of the product should
follow the manufacturer’s instructions, and should use a mounting accessory recommended by the manufacturer. A product and cart combination
should be moved with care. Quick stops, excessive force,
and uneven surfaces may cause the product and cart
combination to overturn.
14. Disc Tray
Keep your fingers well clear of the disc tray as it is closing. It may cause serious personal injury.
15. Burden
Do not place a heavy object on or step on the
product. The object may fall, causing serious
personal injury and serious damage to the product.
16. Connecting
When you connect the product to other equipment, turn
off the power and unplug all of the equipment from the
wall outlet. Failure to do so may cause an electric shock
and serious personal injury. Read the owner’s manual of
the other equipment carefully and follow the instructions
when making any connections.
17. Sound Volume
Reduce the volume to the minimum level before you turn
on the product. Otherwise, sudden high volume sound
may cause hearing or speaker damage.
18. Sound Distortion
Do not allow the product to output distorted sound for a
longtime. It may cause speaker overheating and fire.
19. Headphones
When you use the headphones, keep the volume at a
moderate level. If you use the headphones
continuously with high volume sound, it may cause hearing damage.
20. Laser Beam
Do not look into the opening of the disc tray or ventilation
opening of the product to see the source of the laser
beam. It may cause sight damage.
21. Disc
Do not use a cracked, deformed, or repaired disc. These
discs are easily broken and may cause serious personal
injury and product malfunction.
22. Damage Requiring Service
Unplug this product from the wall outlet and refer
servicing to qualified service personnel under the
following conditions:
a) When the power-supply cord or plug is
damaged.
b) If liquid has been spilled, or objects have fallen
into the product.
c) If the product has been exposed to rain or water.
d) If the product does not operate normally by
following the operating instructions. Adjust only those
controls that are covered by the operating instructions
as an improper adjustment of other controls may
result in damage and will often require extensive work
by a qualified technician to restore the product to its
normal operation.
e) If the product has been dropped or damaged in any
way.
f) When the product exhibits a distinct change in
performance-this indicates a need for service.
23. Servicing
Do not attempt to service this product yourself as opening
or removing covers may expose you to
dangerous voltage or other hazards. Refer all
servicing to qualified service personnel.
24. Replacement parts
When replacement parts are required, be sure the service
technician has used replacement parts
specified by the manufacturer or have the same
characteristics as the original part. Unauthorized
substitutions may result in fire, electric shock, or other
hazards.
25. Safety Check
Upon completion of any service or repairs to this product,
ask the service technician to perform safety checks to
determine that the product is in proper operating condition.
Important safety instructions
6
Precautions
When shipping the DVD player, always use the original shipping carton and packing materials.
For maximum protection, repack the unit as it was originally packed at the factory.
Do not use volatile liquids, such as insect spray, near the
DVD player. Do not leave rubber or plastic products in contact with the DVD player for a long time. They will leave
marks on the finish.
The top and rear panels of the DVD player may becomewarm after a long period of use. This is normal and not a
malfunction.
When the DVD player is not in use, be sure to remove the
disc and turn off the power.
If you do not use the DVD player for a long period, the unit
may not function properly in the future. Turn on and use the
DVD player occasionally.
When you place this DVD player near a TV, radio, or VCR, the
playback picture may become poor and the sound may be
distorted. In this case, move the DVD player away from the
TV, radio, or VCR.
Use a soft, dry cloth for cleaning.
For stubborn dirt, soak the cloth in a weak detergent solution, wring well and wipe. Use a dry cloth to wipe it dry. Do
not use any type of solvent, such as thinner and benzine,
as they may damage the surface of the DVD player.
If you use a chemical saturated cloth to clean the unit, follow that product’s instructions.
Warning: Cleaning and adjustment of lenses and/or
other components of playback mechanism should be performed by a qualified service technician.
The DVD player is a high technology, precision device. If the
optical pick-up lens and disc drive parts are dirty or worn
down, the picture quality becomes poor. To obtain a clear picture, we recommend regular inspection and maintenance
(cleaning or parts replacement) every 1,000 hours of use
depending on the operating environment. For details, contact
your nearest dealer.
Moisture condensation damages the DVD player. Please
read the following carefully.
Moisture condensation occurs, for example, when you
pour a cold drink into a glass on a warm day. Drops of
water form on the outside of the glass. In the same way,
moisture may condense on the optical pick-up lens inside
this unit, one of the most crucial internal parts of the DVD
player.
Moisture condensation occurs during the following
cases.
When you bring the DVD player directly from a cold place
to a warm place.
When you use the DVD player in a room where you just
turned on the heater, or a place where the cold wind from
the air conditioner directly hits the unit.
In summer, when you use the DVD player in a hot and
humid place just after you move the unit from an air conditioned room.
When you use the DVD player in a humid place.
Do not use the DVD player when moisture condensation may occur.
If you use the DVD player in such a situation, it may damage discs and internal parts. Remove the disc, connect
the power cord of the DVD player to the wall outlet, turn on
the DVD player and leave it “ON” for two or three hours.
After two or three hours, the DVD player will have
warmed up and evaporated any moisture. Keep the DVD
player connected to the wall outlet and moisture condensation will seldom occur.
Notes on handling
Notes on Locating
Notes on Cleaning
To Obtain a Clear Picture
Notes on Moisture Condensation
7
Notes on Discs
About This Owner’s Manual
This owner’s manual explains the basic
instructions of this DVD player.
Some DVD video discs have functions that
may not be explained in this owner’s manual.
Therefore, some instructions may differ from
this owner’s manual, and there may be extra
instructions. In this case, follow the instructions
displayed on the TV screen or package.
“ ” may appear on the TV screen
during operation. This icon means the
function explained in this owner’s manual is
not available on that specific DVD video disc.
This section shows you how to handle, clean, and store discs.
On Handling Discs
Do not touch the playback side of the disc.
Do not attach paper or tape to discs.
On Storing Discs
Do not store discs in a place subject to direct
sunlight or near heat sources.
Do not store discs in places subject to
moisture and dust such as a bathroom or near
a humidifier.
Store discs vertically in a case. Stacking or
placing objects on discs outside of their case
may cause warping.
On Cleaning Discs
Fingerprints and dust on the disc cause
picture and sound deterioration. Wipe the disc
from the center outward with a soft cloth.
Always keep the disc clean.
If you cannot wipe off the dust with a soft
cloth, wipe the disc lightly with a slightly moistened soft cloth and finish with a dry cloth.
Do not use any type of solvents such as
thinner, benzine, commercially available
cleaners or anti-static spray for vinyl LPs. They
may damage the disc.
8
Identifications of Controls
Front Panel
Display Window
OPEN/CLOSE button
POWER button
DISC SELECT button
DISC SKIP button
MENU button
OPERATING STATUS indicator
CD indicator
MP3 indicator
DVD indicator
PROGRAM indicator
RANDOM indicator
Repeat playback
mode indicators
CHP/TRK NUMBER indicator
TOTAL PLAYING TIME/ELAPSED TIME indicator
REMOTE SENSOR
EXCHANGE button
DISPLAY WINDOW
SKIP/SCAN buttons
ARROW buttons
ENTER buttons
DISC TRAY
PLAY button
PAUSE/STEP button
TITLE NUMBER indicator
DISC 1-5 indicator
ANGLE ICON indicator
REPEAT button
STOP button
RANDOM button
9
Identifications of Controls
Rear Panel
S-VIDEO OUT jack
COMPOSITE VIDEO OUT jack
ANALOG AUDIO OUT jack
COMPONENT VIDEO OUT jack
OPTICAL DIGITAL AUDIO OUT jack
Remove the dust protection cap from the connector and connect the optical digital cable (not supplied) firmly so that the
configurations of both the cable and the connector match. Keep the dust protection cap and always reattach the cap when
not using the connector to protect against dust.
Dust protection cap
DIGITAL COAXIAL
AUDIO OUT jack
DIGITAL OPTICAL
AUDIO OUT jack
POWER CORD
CONNECT TO AN AC120V 60Hz
OUTLET ONLY
10
REMOTE CONTROL
Identification of Controls (Continued)
You will find instructions for each of the remote control functions in the appropriate sections of this instruction manual.
*MENU button
Use the MENU button to display the
menu screen included on DVD video
discs. To operate a menu screen,
follow the instructions in “Using a
DVD Menu” (page 33).
** Directional arrow buttons
(up, down, left, right) for use in highlighting a selection on a GUI menu
screen, TITLE and MENU screen.
***TITLE button
Use the TITLE button to display the
title screen included on DVD video
discs. To operate a menu screen,
follow the instructions in “Using a Title
Menu” (page 33).
Identification of Controls (Continued)
Preparing the Remote Control
Insert the batteries into the remote control so you can use it
to operate the DVD player.
Open the battery cover.
Insert batteries (AAA size).
Make sure to match the + and - on the batteries to the
marks inside the battery compartment.
Close the cover.
Operating with the Remote Control
This section shows you how to use the remote control.
Point the remote control at the remote
sensor and press the
buttons.
Distance: About 23 ft (7 m) from the front of the remote
sensor
Angle: About 30° in each direction of the front of the remote
sensor
* Do not expose the remote sensor of the DVD
player to a strong light source such as direct
sunlight or illumination. If you do so, you may not be able
to operate the DVD player with the remote control.
Notes on batteries
Improper use of batteries may cause battery leakage and corrosion.
To operate the remote control correctly, follow the instructions.
Do not insert the batteries into the remote control in the wrong
direction.
Do not charge, heat, open, or short-circuit the batteries. Do not
throw the batteries into fire.
Do not leave dead or exhausted batteries in the remote control.
Do not use different types of batteries together, or mix old and
new batteries.
If you do not use the remote control for a long period of time,
remove the batteries to avoid possible damage from battery corrosion.
If the remote control does not function correctly or if the operating range becomes reduced, replace all batteries with new ones.
If battery leakage occurs, wipe the battery liquid from the battery
compartment, then insert new batteries.
The batteries should last about one year with normal use.
Notes on the remote control
Direct the remote control at the remote sensor of the DVD
player.
Do not drop or give the remote control a shock.
Do not leave the remote control near extremely hot or humid
place.
Do not spill water or put anything wet on the remote control.
Do not open the remote control.
11
12
Connecting directly to a TV
Connect the DVD player to your TV
Refer to the owner’s manual of your TV as well.
When you connect the DVD player to your TV, be sure to turn off the power and unplug both units from the wall outlet before making any connections.
Connect the DVD player to your TV directly. If you connect the DVD player to a VCR, the playback picture will be distorted because DVD video
discs are copy protected.
Warning
Do not set the Digital Audio Output of this DVD player to “Dolby Digital” unless you are connecting the DIGITAL AUDIO jack of this DVD player
to an AV decoder that has the Dolby Digital (AC-3) decoding function. High volume sound may damage your hearing as well as the speakers.
(Refer to “Selecting Digital Audio Output” on page 23.)
Notes
For the best picture, If
the TV has an S-video
input, connect the DVD
player with the S-video
cable otherwise, use the
composite video out jack.
T
o
S
e
V
o component Video
ut if not using an
-video or Composit
ideo cable
13
Connecting to Optional Audio System with Stereo only
You can listen to the sound of audio CDs and DVD video discs in stereo.
For the best picture, if the TV has an S-video
input, connect the DVD player with the S-video
cable. otherwise, use the composite video out jack.
Refer to the owner’s manual of your audio system as well.
When you connect the DVD player to other equipment, be sure to turn off the power and unplug all of the equipment from the wall outlet
before making any connections.
If you place the DVD player near a tuner or radio, the radio broadcast sound might be distorted. In this case, move the DVD player away from
the tuner and radio.
The output sound of the DVD player has a wide dynamic range. Be sure to adjust the receiver’s volume to a moderate
listening level. Otherwise, the speakers may be damaged by a sudden high volume sound.
Turn off the receiver before you connect or disconnect the DVD player’s power cord. If you leave the receiver power on, the speakers may
be damaged.
Warning
Do not set the Digital Audio Output of this DVD player to “Dolby Digital” unless you are connecting the DIGITAL AUDIO jack of this DVD player
to an AV decoder that has the Dolby Digital (AC-3) decoding function. High volume sound may damage your hearing as well as the speakers.
(Refer to “Selecting Digital Audio Output” on page 23.)
Notes
14
Connecting to Optional Audio System with Dolby Digital
You can enjoy the high quality dynamic sound of Dolby Digital (AC-3), Dolby Pro Logic, 2 Channel Digital Stereo and DTS.
Dolby Digital (AC-3)
Dolby Digital is the surround sound technology used in theaters showing the latest movies, and is now available to reproduce this
realistic effect in the home. You can enjoy motion picture and live concert DVD video discs with this dynamic realistic sound by
connecting the DVD player to a 6 channel receiver equipped with a Dolby Digital (AC-3) decoder and DTS decoder
To enjoy Dolby Digital (AC-3)
sound from this DVD player
you need the following:
DVD recorded in Dolby Digital
(AC-3)
6 channel receiver equipped
with a Dolby Digital (AC-3)
decoder, or Dolby Digital
(AC-3) processor and power
Amplifier
5 speakers
To enjoy Dolby Digital (AC-3)
sound
You need to select “Dolby Digital”
on the SETUP menu.
* Manufactured under license from Dolby Laboratories Licensing
Corporation. “Dolby”, “AC-3” and the double-D symbol are trademarks of
Dolby Laboratories Licensing Corporation.
Confidential Unpublished Works. 1992-1997 Dolby Laboratories, Inc. All
rights reserved.
C
15
Connecting to Optional Audio System with Dolby Pro Logic
If your A/V receiver has a Dolby Pro Logic decoder refer to the following connection diagram.
To listen in Dolby Pro Logic
with a receiver equipped with Dolby Pro Logic (AC-3)
Connect the equipment the same way as described in “Enjoying Dolby Digital (AC-3) Sound” on the previous page. Refer to that receiver’s
owner’s manual and set the receiver so you can enjoy Dolby Pro Logic Surround sound.
16
Connecting to Optional Techwood DDR94
Refer to the owner’s manual of your receiver as well.
When you connect the DVD player to other equipment, be sure to turn off the power and unplug all of the equipment from the wall outlet
before making any connections.
The output sound of the DVD player has a wide dynamic range. Be sure to adjust the receiver’s volume to a moderate listening level.
Otherwise, the speakers may be damaged by a sudden high volume sound.
Turn off the receiver before you connect or disconnect the DVD player’s power cord. If you leave the receiver power on, the speakers may
be damaged.
Notes
You can enjoy the high quality dynamic sound of Digital (AC-3), Dolby Pro logic, 2 Channel Digital Stereo and DTS.
Dolby Digital (AC-3)
Dolby Digital is the surround sound technology used in theaters showing the latest movies, and is now available to reproduce this
realistic effect in the home. You can enjoy motion picture and live concert DVD video discs with this dynamic realistic sound by
connecting the DVD player to the DDR95 6 channel receiver equipped with a Dolby Digital (AC-3) decoder and DTS decoder
To enjoy Dolby Digital (AC-3)
sound from this DVD player
you need the following:
DVD recorded in Dolby Digital
(AC-3)
6 channel receiver equipped
with a Dolby Digital (AC-3)
decoder, or Dolby Digital
(AC-3) processor and power
Amplifier
5 speakers
To enjoy Dolby Digital (AC-3)
sound
You need to select “Dolby Digital”
on the SETUP menu.
* Manufactured under license from Dolby Laboratories Licensing
Corporation. “Dolby”, “AC-3” and the double-D symbol are trademarks of
Dolby Laboratories Licensing Corporation.
Confidential Unpublished Works. 1992-1997 Dolby Laboratories, Inc. All
rights reserved.
C
17
Connecting to Optional Techwood DDR95
Refer to the owner’s manual of your receiver as well.
When you connect the DVD player to other equipment, be sure to turn off the power and unplug all of the equipment from the wall outlet
before making any connections.
The output sound of the DVD player has a wide dynamic range. Be sure to adjust the receiver’s volume to a moderate listening level.
Otherwise, the speakers may be damaged by a sudden high volume sound.
Turn off the receiver before you connect or disconnect the DVD player’s power cord. If you leave the receiver power on, the speakers may
be damaged.
Notes
You can enjoy the high quality dynamic sound of Digital (AC-3), Dolby Pro logic, 2 Channel Digital Stereo and DTS.
Dolby Digital (AC-3)
Dolby Digital is the surround sound technology used in theaters showing the latest movies, and is now available to reproduce this
realistic effect in the home. You can enjoy motion picture and live concert DVD video discs with this dynamic realistic sound by
connecting the DVD player to the DDR95 6 channel receiver equipped with a Dolby Digital (AC-3) decoder and DTS decoder
To enjoy Dolby Digital (AC-3)
sound from this DVD player
you need the following:
DVD recorded in Dolby Digital
(AC-3)
6 channel receiver equipped
with a Dolby Digital (AC-3)
decoder, or Dolby Digital
(AC-3) processor and power
Amplifier
5 speakers
To enjoy Dolby Digital (AC-3)
sound
You need to select “Dolby Digital”
on the SETUP menu.
* Manufactured under license from Dolby Laboratories Licensing
Corporation. “Dolby”, “AC-3” and the double-D symbol are trademarks of
Dolby Laboratories Licensing Corporation.
Confidential Unpublished Works. 1992-1997 Dolby Laboratories, Inc. All
rights reserved.
C
Basic Playback
This section shows you the basics on how to play back a DVD video disc.
Preparations
When you want to play back DVD video discs, turn on the TV and select
the video input source connected to the DVD player.
If connected to an audio system,
DVDvideo discs or audio CDs from the audio system, turn on the audio
system and select the input source connected to the DVD player.
For connection details, see pages 12 through 17.
Set the playback picture size according to the aspect ratio of the con-
nected TV at the SETUP menu (TV Aspect).
If you do not have the necessary equipment to enjoy Dolby Digital (AC-
3) sound, set the Digital Audio Output at the SETUP (Digital Audio
Output) menu to “PCM”.
Press POWER.
The D VDplayer turns on and the power indicator turn off.
Press OPEN/CLOSE.
The disc tray opens.
You can open the disc tray by pressing this button even if the DVD player is in standby mode.
when you want to enjoy the sound of
Place a disc on the disc tray with the
playback side down.
There are two different disc sizes. Place the disc in the
correct guide on the disc tray. If the disc is out of the guide, it may damage the disc and cause the DVD player to malfunction.
Do not place anything except 3” discs or 5” discs on the disc tray.
Discs can be loaded one at a time by pressing DISC SKIP or DISC
SELECT (1 - 5) to rotate the carousel.
Caution: Do not touch the loading drawer and carousel
while they are in motion, and do not attempt to rotate
the carousel by hand; doing so could result in incorrect
operation of the player and/or damage to the discs.
Press OPEN/CLOSE to close the loading drawer.
The disc on the tray 1 is ready to be played back. Playback
may begin automatically depending on some DVDs.
If no disc is loaded on the disc tray 1, select another disc by
following step 5.
Do not close the loading drawer by hand.
If the disc is placed in upside down (and it is a single sided disc), “NO
DISC” or “DISC ERROR” appears on the TV screen.
Operating status indicator
If you insert an audio CD, the CD indicator lights up in the DVD
display. The title number does not appear.
After playing back all of the chapters in the title, the DVD player automatically stops and returns to the menu screen.
18
Basic Playback
If you want to select another disc, press DISC SKIP
on the remote control once or more, or press DISC
SELECT (1 - 5) on the front panel.
Press PLAY to begin playback.
Playback begins.
You can skip this step if the disc is already played back automatically.
When a menu screen appears on theTV screen.
In case of interactive DVDs with control, a menu screen appears on the TV
screen. Perform step as below.
Press
and press SELECT/ENTER, or press
the numeric button(s), to select the desired item.
Play of the selected item now begins.
1
2
OR
3
4
Example of interactive DVD On-Screen Menu
For further info, also refer to the jacket or case of the disc you are
playing.
After operation
When the unit is not in use, remove the disc and press POWER to turn
off the power.
Notes
Do not move the DVD player during playback. Doing so may damage the
disc and the DVD player.
Use the OPEN/CLOSE button on the remote control or DVD player to open
and close the disc tray. Do not push the disc tray while it is moving.Doing
so may cause the DVD player to malfunction.
Do not push up the disc tray or put any objects other than discs on the disc
tray. Doing so may cause the DVD video player to malfunction.
Keep your fingers well clear of the disc tray as it is closing. Be especially
careful with children’s fingers around the closing disc tray as there is a risk
of personal injury.
When “ ” appears on the TV screen while a button is pressed, it means
that this function is not available on the disc you are playing.
Depending on the DVD disc, some operations may be different or restricted. Refer to the jacket or case of the disc you are playing.
19
Basic Playback
Exchanging discs during playback
Press DISC EXCHANGE during playback to open
the loading drawer.
Press DISC SKIP to rotate the disc trays to the
desired position.
The carousel will move clockwise by one disc tray.
Note: The disc tray which was in the play position can not
be exchanged.
Exchange the discs and press DISC EXCHANGE or
OPEN/CLOSE to close the loading drawer.
Skipping discs
Press DISC SKIP during play or in the stop mode.
Each time the button is pressed, the next disc tray is selected.
Notes
When the DISC SKIP is pressed during play or in the stop mode, the
disc trays rotate and play begins from the beginning of the next disc.
If there is no disc on the selected disc tray, the disc tray of the next number will be selected.
When DISC SKIP is pressed during playbackof disc 5, playback of disc
1 will start.
Exchanging the disc and starting playback
Press OPEN/CLOSE during playback or in the
stop mode.
Play is stopped (if pressed during playback), the
loading drawer is opened and the disc tray which was in the
play position comes to the center position.
Exchange the disc in the center position.
Center position
Press OPEN/CLOSE or PLAY again.
The loading drawer is closed, the disc tray returns to the
play position and play begins from the new disc.
20
Basic Playback
Stopping Play
Press STOP during playback.
Resume Play
When play is stopped, the unit records the point where STOP
was pressed (RESUME function).
Press PLAY and play will resume from this point.
The RESUME fcunction works only with discs for which the
elapsed playingtime appears on the window display during playback.
Notes
Resume function will be cleared when STOP is pressed a second time
while in the STOP mode.
Resume function will be cleared when the power is turned off and then
on.
Opening the disc tray cancels Resume function.
The Resume function may not be available on some DVD discs.
If the player is left in the stop mode for more than 8 minutes, the
power shuts off automatically.
Still Picture (Pause)
Press PAUSE/STEP during playback.
DVD
The player will be placed in the still picture mode.
CD
The player will be placed in the pause mode.
Frame advance (DVD only)
Press PAUSE/STEP during still playback.
(Each time you press PAUSE/STEP, the picture advances one
frame)
To resume normal playback, press PLAY.
Skipping forward or back
Skipping f
Skipping f
Press SKIP
A chapter (DVD) or a track (CD) is skipped each time the
button is pressed.
orwardd
orwar
during playback.
Skipping backk
Skipping bac
Press SKIP
When the button is pressed once midway through a
chapter/track, the player returns to the star t of that
chapter/track. When it is pressed again, a chapter/track is
skipped each time the button is pressed.
21
during playback.
Various speed playback
You can play backVideo discs at various speeds, and
resume normal playback.
To play in slow-motion
Press SLOW - or SLOW + during playback.
During slow playback, the playback speed and direction can be
selected with SLOW - or SLOW +.
To increase the playback speed, press one button as the playback
direction.
To reverse the playback direction, press the other button opposite
to the playback direction.
With Video CD, reverse play is not possible.
To return to normal playback, press PLAY button.
To scan at fast forward or fast reverse.
For Fast forward and reverse press SCAN - or SCAN + on remote
control unit during playback.
On the front panel, hold down the or button to
scan.
During fast playback, the playback speed and direction can be
selected with SCAN - or SCAN +.
To increase the playback speed, press one button as the playback
direction.
To reverse the playback direction, press the other button opposite
to the playback direction.
To return to normal playback, press PLAY.
Notes
The DVD player does not play back sound during slow-motion playback,
high speed reverse and forward playback of DVD video discs.
However, the DVD player plays back sound during fast forward or fast
reverse playback of audio CDs.
Subtitles do not appear on the screen during slow motion and scan playback.
The DVD player provides four (4) scan speeds for DVD movie play. Only
two (2) scan speeds are available during Audio CD play.
The player does not play back in slow-motion when playing audio CD.
22
23
Audio set-up Selecting Digital Audio output
Each DVD disc has a variety of audio output options.
Set the player’s Digital Audio Output according to the
type of audio system you use.
Press SETUP in stop or playback mode
At the SETUP screen, press to select Digital
Audio Output and press .
Press to select the desired output and press
ENTER.
When connecting this DVD changer to a receiver or other equipment using a digital cable (coax or optical), you must select an
audio output on the DVD changer that corresponds to the type of
receiver being used.
DOLBY DIGITAL/PCM: Select this audio output setting if you
are connecting the DVD changer with a digital cable (coax or optical) to a receiver equipped with DOLBY DIGITAL (AC-3) surround
sound but not equipped with DTS.
Stream/PCM: Select this audio output setting if you are connect-
ing the DVD changer with a digital cable (coax or optical) to a
receiver equipped with DOLBY DIGITAL and DTS.
Note: Use Stream/PCM setting when connecting to Techwood
A/V receivers DDR94 and DDR95.
PCM: Select this audio output setting if you are connecting the
DVD changer with a digital cable (coax or optical) to an amplifier
or other equipment equipped only with a linear PCM input or to a
MD recorder or DAT deck.
Disc Subtitle
Disc Menu
Rating
Password
TV Aspect
Menu Language
TV Output Select
Pseudo PAL
Digital Audio Output
5.1 Speaker Setup
Disc Audio
DOLBY
DIGITAL
/PCM
Stream/PCM
PCM
Disc Subtitle
Disc Menu
Rating
Password
TV Aspect
Menu Language
TV Output Select
Pseudo PAL
Digital Audio Output
5.1 Speaker Setup
Disc Audio
DOLBY
DIGITAL
/PCM
Stream/PCM
PCM
Notes
If you connect this DVD changer to a receiver or other equipment with a
digital cable (coax or optical) and the receiver does not have a built-in
digital decoder, a very loud noise may be produced which can permanently damage the speakers.
Only use a digital cable (coax or optical) if your receiver has a builtin Dolby Digital decoder.
DVD discs recorded in DTS can only be played back in DTS format if the
DVD changer is connected to a receiver with a built-in DTS decoder.
Also, the digital audio output on the DVD changer must be set to
“Stream/PCM” to playback in DTS mode.
If you connect this DVD changer to a regular stereo or use analog audio
cables to connect to a surround sound receiver, any audio output setting
may be selected.
Playback OUTPUT
Disc Dolby Digital/ Stream/PCM PCM only
PCM
96 kHz PCM PCM PCM
Linear PCM
DVD
DTS DVD Not Output DTS bit Stream Not output
Dolby Digital Dolby Digital Dolby Digital PCM
DVD bit Stream bit Steam
MPEG DVD PCM MPEG bit Steam PCM
Audio CD PCM PCM PCM
DTS Audio CD DTS bit Stream DTS bit Stream DTS bit Stream
24
Common procedures of initial settings
Common procedures of initial settings
Press SETUP in the stop or playback mode.
The SETUP menu is displayed.
Press to select the desired item.
The screen will show the current setting for the
selected item, and the alternate setting(s).
• Disc Audio (see page 25)
• Disc Subtitle (see page 25)
• Rating (see page 26)
• Password (see page 27)
• TV Aspect (see page 28)
• Menu Language (see page 29)
• Digital Audio Output (see page 23)
Press and then to select the desired setting and press ENTER.
• Some items require additional steps. (See the respective
page.)
When the alternate setting is selected the screen returns to the
Initial Settings display.
To exit SETUP menu
Press SETUP, RETURN or PLAY.
Once the initial settings have been completed, the
player can always be operated under the same conditions (especially with DVD discs).
The settings will be retained in the memory until they
are changed, even if the power is switched off.
Disc Subtitle
Disc Menu
Rating
Password
TV Aspect
Menu Language
TV Output Select
Pseudo PAL
Digital Audio Output
5.1 Speaker Setup
Disc Audio
Original
Spanish
English
Chinese
Polish
Hungarian
Russian
French
German
Italian
Other — — — —
25
Selecting disc languages
With a disc inserted and ready to play,
At the setup screen, press to select “Disc
Audio” and press .
Press to select the desired language and then
press ENTER.
Original :The original language of each disc will be selected.
English : English will be Selected.
Other : Another language can be selected. You can input
4-digit language code. (Refer to the language codes on
page 30. Press CLEAR if an incorrect language code is
entered.)
The “Disc Subtitle” and “Disc Menu” are selected by the same
method.
If the language selected is not available on the disc, the original language designated by each disc will be selected.
This is to select the audio soundtrack language, subtitle language and the language used in title menus or
DVD menus which will always be used for every disc to
be played back.
When you play back a DVD video disc, the DVD player
automatically displays the pre-selected subtitle language if it is included on the disc.
Note
Disc Subtitle
Disc Menu
Rating
Password
TV Aspect
Menu Language
TV Output Select
Pseudo PAL
Digital Audio Output
5.1 Speaker Setup
Disc Audio
Original
Spanish
English
Chinese
Polish
Hungarian
Russian
French
German
Italian
Other — — — —
26
Selecting rating level and password
Selecting rating level (DVD only)
At the SETUP screen, press to select
“Rating” and press .
Press to select the desired level and press
ENTER.
You cannot play DVD video discs rated higher than the level you
selected unless you cancel the parental lock function.
For example, when you select level 7, discs rated higher than level
7 are blocked and cannot be played.
The parent lock level is equivalent to the following USA movie ratings.
Level 7: NC-17 Level 6: R Level 4: PG 13
Level 3: PG Level 1: G
• Some titles do not match with the rating level described as
above.
If you change the level and enter a password, playback of all
DVDs with ratings higher than your selection will be blocked,
unless the correct password is entered again. For example: if you
change the level to “5”, the DVD player will not play discs with ratings of “6”, “7” or “8” unless the correct password is entered on the
remote control.
This is to prohibit the playing of specified DVDs which
are unsuitable for children.
Some DVD discs contain a restriction level which
enables parents to remove scenes or prevent playback of discs by children. DVD players are equipped
with a password designed to prevent children changing the level.
Disc Audio
Disc Subtitle
Disc Menu
Rating
Password
TV Aspect
Menu Language
TV Output Select
Pseudo PAL
Digital Audio Output
5.1 Speaker Setup
Disc Audio
Disc Subtitle
Disc Menu
Rating
Password
TV Aspect
Menu Language
TV Output Select
Pseudo PAL
Digital Audio Output
5.1 Speaker Setup
8
7
6
5
4
3
2
1
Unlock
8 Blocked
7 Blocked
6
5
4
3
2
1
Unlock
27
Selecting rating level and password
Setting your password (DVD only)
If you change the rating level to “7” or lower, you must enter a 4digit “password” to prevent playback of discs with higher ratings.
At the SETUP screen, press to select “Pass-
word” and press .
Input a 4-digit password and press ENTER.
Example : 1234
Do not forget your password.
Input the 4-digit password again and press ENTER
to verify.
Setting is finished.
The rating is locked. Any discs whose rating is higher than the
setting cannot be played back unless the correct
password is entered.
To change/clear memorized password
At the SETUP screen, press to select “Pass-
word” and press .
Input your password and Press ENTER.
To change or clear your password, press to
select the “Change” or “Clear” and press ENTER.
Disc Subtitle
Disc Menu
Rating
Password
TV Aspect
Menu Language
TV Output Select
Pseudo PAL
Digital Audio Output
5.1 Speaker Setup
Disc Audio
Change
Clear
To clear your 4-digit password
Follow the step-by-step procedure below if you
forgot or do not know the 4 digit password.
1 Turn on the SETUP screen
2 Press to select and highlight“Pass-
word”
3 Enter the following 6-digit nomber and
press enter: 210499 ENTER
Note: The #210499 will not appear in the
screen.
3 Enter a new password following the
instructions in the “setting your password” section.
Disc Audio
Disc Subtitle
Disc Menu
Rating
Password
TV Aspect
Menu Language
TV Output Select
Pseudo PAL
Digital Audio Output
5.1 Speaker Setup
NEW
————
28
Selecting TV Aspect
At the SETUP screen, press to select “TV
Aspect” and press .
Press to select the desired Aspect and press
ENTER.
NOTE :
Use panscan sething for regulal TV’s
You must select the type of TV picture (aspect ratio) that corresponds to the type of TV you are connecting to the DVD changer
Conventional televisions have 4:3 screen ratios. Wide-screen televisions have 16:9 ratios.
If you are connecting to a conventional television, it is recommended that you select the 4:3 Panscan mode. If you are connecting to
a Wide-screen television select 16:9 Wide.
4:3 Letterbox : The video material not formatted in the Pan &
Scan style is played back in the letterbox style (black bands
appear at top and bottom of screen).
4:3 Panscan : Select when a conventional TV set is
connected. The video material formatted in the Pan & Scan style is
played back in that style (the left and right edges are cut off).
16:9 Wide : Select when a wide-screen TV set is connected.
Played in “FULL” size. (Setting the wide-screen TV to “FULL” mode
is also necessary.)
* Each screen shows an example when the video material for a
wide-screen is played.
(This setting does not affect the video material for
conventional size.)
Disc Subtitle
Disc Menu
Rating
Password
TV Aspect
Menu Language
TV Output Select
Pseudo PAL
Digital Audio Output
5.1 Speaker Setup
Disc Audio
4:3 Letterbox
4:3 Panscan
16:9 Wide
Select the appropriate screen type according to your
TV set; conventional size screen (4:3) or wide-screen
(16:9).
16:9 Wide
4:3 Panscan
Cut Off
4:3 Letterbox
Disc Subtitle
Disc Menu
Rating
Password
TV Aspect
Menu Language
TV Output Select
Pseudo PAL
Digital Audio Output
5.1 Speaker Setup
Disc Audio
4:3 Letterbox
4:3 Panscan
16:9 Wide
29
Disc Subtitle
Disc Menu
Rating
Password
TV Aspect
Menu Language
TV Output Select
Pseudo PAL
Digital Audio Output
5.1 Speaker Setup
Disc Audio
English
Spanish
French
German
Selecting Menu Language
Selecting TV Output
At the SETUP screen, press to select “Menu
Language” and press .
Press to select the desired Language and
press ENTER.
Disc Subtitle
Disc Menu
Rating
Password
TV Aspect
Menu Language
TV Output Select
Pseudo PAL
Digital Audio Output
5.1 Speaker Setup
Disc Audio
English
Spanish
French
German
Selects language for DVD menus and displays on the
TV.
Disc Subtitle
Disc Menu
Rating
Password
TV Aspect
Menu Language
TV Output Select
Pseudo PAL
Digital Audio Output
5.1 Speaker Setup
Disc Audio
English
Spanish
French
German
At the SETUP screen, press to select “TV
Output Select” and press .
Press to select the desired TV Output and
press ENTER.
Disc Subtitle
Disc Menu
Rating
Password
TV Aspect
Menu Language
TV Output Select
Pseudo PAL
Digital Audio Output
5.1 Speaker Setup
Disc Audio
English
Spanish
French
German
It can be used to select the video output between
S-VIDEO OUT and COMPONENT VIDEO OUT.
Disc Subtitle
Disc Menu
Rating
Password
TV Aspect
Menu Language
TV Output Select
Pseudo PAL
Digital Audio Output
5.1 Speaker Setup
Disc Audio
English
Spanish
French
German
Disc Audio
Disc Subtitle
Disc Menu
Rating
Password
TV Aspect
Menu Language
TV Output Select
Pseudo PAL
Digital Audio Output
5.1 Speaker Setup
English
Spanish
French
German
30
Table of Language and Their Abbreviations
Code Language
6565 Afar
6566 Abkhazian
6570 Afrikaans
6577 Ameharic
6582 Arabic
6583 Assamese
6588 Aymara
6590 Azerbaijani
6665 Bashkir
6669 Byelorussian
6671 Bulgarian
6672 Bihari
6678 Bengali; Bangla
6679 Tibetan
6682 Breton
6765 Catalan
6779 Corsican
6783 Czech
6789 Welsh
6865 Danish
6869 German
6890 Bhutani
6976 Greek
6978 English
6979 Esperanto
6983 Spanish
6984 Estonian
6985 Basque
7065 Persian
7073 Finnish
7074 Fiji
Code Language
7079 Faroese
7082 French
7089 Frisian
7165 Irish
7168 Scots Gaelic
7176 Galician
7178 Guarani
7185 Gujarati
7265 Hausa
7273 Hindi
7282 Croatian
7285 Hungarian
7289 Armenian
7365 Interlingua
7378 Indonesian
7383 Icelandic
7384 Italian
7387 Hebrew
7465 Japanese
7473 Yiddish
7487 Javanese
7565 Georgian
7575 Kazakh
7576 Greenlandic
7577 Cambodian
7578 Kannada
7579 Korean
7583 Kashmiri
7585 Kurdish
7589 Kirghiz
7665 Latin
Code Language
7678 Lingala
7679 Laothian
7684 Lithuanian
7686 Latvian, Lettish
7771 Malagasy
7773 Maori
7775 Macedonian
7776 Malayalam
7778 Mongolian
7779 Moldavian
7782 Marathi
7783 Malay
7784 Maltese
7789 Burmese
7865 Nauru
7869 Nepali
7876 Dutch
7879 Norwegian
7982 Oriya
8065 Panjabi
8076 Polish
8083 Pashto, Pushto
8084 Portuguese
8185 Quechua
8277 Rhaeto-Romance
8279 Rumanian
8285 Russian
8365 Sanskrit
8368 Sindhi
8372 Serbo-Croatian
8373 Singhalese
Code Language
8375 Slovak
8376 Slovenian
8377 Samoan
8378 Shona
8379 Somali
8381 Albanian
8382 Serbian
8385 Sundanese
8386 Swedish
8387 Swahili
8465 Tamil
8469 Telugu
8471 Tajik
8472 Thai
8473 Tigrinya
8475 Turkmen
8476 Tagalog
8479 Tonga
8482 Turkish
8484 Tatar
8487 Twi
8575 Ukrainian
8582 Urdu
8590 Uzbek
8673 Vietnamese
8679 Volapük
8779 Wolof
8872 Xhosa
8979 Yoruba
9072 Chinese
9085 Zulu
Enter the appropriate code number for the initial settings “Audio”, “Subtitle” and/or “Menu” (See page 25).
31
General Information about GUI menu icons
This unit features GUI Menu Icons showing disc
information (title/chapter/track number, elapsed playing time,
audio/subtitle language, angle, and sound) and player information (repeat play, play mode, marker, etc.). Some icons
only show the indicated information. Other icons allow the
settings to be changed.
Common procedures
Press GUI during playback.
Note: If the GUI button is pressed while the player is in stop
mode, only the “T” icon (title number) will appear in the
screen. the other GUI indicators will not appear.
Press to select the desired item.
The currently selected item is indicated by a yellow frame
on its GUI menu icons.
Press to select the desired setting.
When numbers are displayed (e.g. title No.), the numeric
buttons can also be used for setting instead of .
For some functions, the setting will be registered immedi-
ately; for others,ENTER must be pressed.
To clear the GUI Menu Icons, press GUI.
1
1
0:16:57
1 ENG
D
6 CH
OFF
1
NORM.
1
16:57
STER.
NORM.
Examples of GUI Menu Icons.
(The screens may differ depending on the disc contents.)
(DVD GUI) (CD GUI)
(DVD and CD GUI)
1/5
CHAPT
OFF
A B
32
Detailed description of each GUI menu icon
You can view information about a disc and its operational status on the TV screen.
To show the current title No.
and to jump to the desired title No.
To show the current chapter No.
and to jump to the desired chapter No.
To show the elapsed time
and directly select scenes by the desired time.
To show the current audio soundtrack language,
encoding method, channel No.
and to change the settings.
To show the current subtitles language
and to change the setting.
To show the current angle No.
and to change the angle.
To show the current sound (NORMAL or 3D SURROUND)
and to change the setting.
To show the current track No.
and to jump to the desired track No.
To show the elapsed time.
(Display only)
To show the current audio (STEREO, LEFT, RIGHT)
and to select to the desired audio channel.
To show the current sound (NORMAL or 3D SURROUND)
and to change the setting.
1
1
0:16:57
1 ENG
D
6 CH
OFF
1
NORM.
1
16:57
STER.
NORM.
FUNCTION
(Press to select desired item)
, or
Numeric
SELECT/ENTER
,or Numeric
SELECT/ENTER
SKIP
Numeric
SELECT/ENTER
,
AUDIO
,
SUBTITLE
,
ANGLE
,
SOUND
SKIP, ,
,
AUDIO
,
SOUND
Press GUI during
playback.
[TV screen] DVD GUI
SELECTION
METHOD
Press GUI during
playback.
[TV screen] CD GUI
FUNCTION
(Press to select desired item)
SELECTION
METHOD
Note
Some DVD discs may not provide all of the above GUI menu icons.
33
Using a title menu
Using a DVD menu
Press TITLE.
A list of the titles on the disc is displayed.
Press TITLE again to resume play from the scene
when TITLE was first pressed.
Resume play may not be possible on certain discs.
Press and press ENTER or PLAY, or
press the numeric button(s), to select desired
title.
The selected title now starts playing.
Press DVD MENU during play.
The DVD menu available on the disc is now displayed.
Pressing MENU again resumes play from the scene
when MENU was first pressed.
• Resume play may not be possible on certain discs.
Press and press ENTER, or press the
numeric button(s), to select desired item.
The selected item is now executed.
Some movie discs may contain two or more titles. If the disc
has a title menu recorded on it, the TITLE button can be
used to select the movie title. (The details of operation differ
depending on the disc used.)
Selecting a title may not be possible on certain DVD
discs.
Some DVDs have unique menu structures called DVD
menus. For example, DVDs programmed with complex contents provide guide menus, and those recorded with various languages provide menus for audio and subtitle language. Although the DVD menu’s contents and operation
differ from disc to disc, the following explains the basic
operation when this feature is used.
1
2
3
4
34
Changing subtitle language
Changing audio soundtrack language
It is possible to change the subtitle language to a
different language from the one selected at the initial settings.
(See page 25 for further info.)
This operation works only with discs on which multiple subtitle languages are recorded.
Press SUBTITLE during playback.
When no subtitles are recorded, “OFF” will be displayed instead of the language number.
Press repeatedly SUBTITLE until the desired
language is selected.
Number of the subtitle language being played back.
To eliminate the On Screen Subtitles.
Press SUBTITLE repeatedly to select OFF at step 2.
In some cases, the subtitle language is not changed to the selected one immediately.
When a disc supporting closed caption is played, the subtitle and
the closed caption may overlap each other on the TV screen. In
this case, turn the subtitle off.
When the desired language is not selected even after pressing
the button several times, it means that the language is not available on the disc.
When the power is turned on or the disc is removed, subtitles
appear in the language selected at the initial settings. If this language is not recorded on the disc, the disc’s priority language
appears.
Notes
It is possible to change the audio soundtrack language to a
different language from the one selected at the
initial settings in case of DVD disc. (See page 25 for further
info.) This operation works only with discs on which multiple
audio soundtrack languages are recorded.
And it is possible to change the audio channel in case of
audio CD.
• DVD
Press AUDIO during play.
Number of the audio soundtrack language being
played back.
Press AUDIO repeatedly until the desired language is selected.
• CD
Press AUDIO during play.
Press AUDIO repeatedly until the desired
sound is selected.
Notes
1 ENG
D
6 CH
2 FRE
D
6 CH
STER.
LEFT
When the desired language is not selected even after pressing
the button several times, it means that the language is not available on the disc.
When the power is turned on or the disc is removed, the language
heard is the one selected at the initial settings. If this language is
not recorded on the disc, only the available language on the disc
will be heard.
Some discs may not respond to Audio feature.
OFF
1 ENG
35
Viewing from another angle
Some DVDs may contain scenes which have been shot
simultaneously from a number of different angles. For these
discs, the same scene can be viewed from each of these
different angles using the ANGLE button. (The recorded
angles differ depending on the disc used.)
Press ANGLE during playback.
Number of angle
being played back.
Press ANGLE repeatedly until the desired
angle is selected.
For your reference
•
The ANGLE indicator will blink in the DVD display window at
scenes recorded at different angles to indicate that angle
switching is possible.
•
The angle number can be programmed beforehand; the angle
will be switched to the selected number when the ANGLE indicator blinks.
This function only works for discs having scenes recorded at different angles.
Note
This unit can produce a 3D Surround effect, using
SpatializerTMN-2-2TMtechnology, which simulates multi-channel audio playback from two conventional stereo speakers
instead of the five or more speakers normally required to listen to multi-channel audio from a home theater. This feature
works with DVD discs encoded with Dolby Pro Logic, Dolby
Digital (AC-3) and DTS multi-channel audio tracks.
Press SOUND during playback.
Each time this button is pressed, the TV screen
display changes:
Press SOUND repeatedly until the desired
sound is selected.
This 3D Surround effect may not be available on some DVD discs,
such as those recorded with a mono audio soundtrack.
Turn off the TV surround sound and other surround effects when
using this 3D surround effect.
For best 3D Surround effect using only two speakers it is
recommended that the two speakers be positioned
approximately 2m to 2.5m apart, and the listening
position should be 2m to 2.5m away from the speakers.
Notes
1
2
NORM.
3D SUR
1 2 3
Producing a 3D SURROUND effect
36
Repeat Play
Repeating viewing (listening)
Press REPEAT during playback.
Each time this button is pressed, the TV screen changes as
shown below and the disc will repeat a chapter or title (DVD)
or a track (CD).
• DVD
Repeat of
chapter being
played
Repeat of title
being played
Cancel repeat mode
(normal play)
• CD
Repeat of track
being played
Repeat of entire
disc contents
Cancel repeat mode
(normal play)
To return to normal play
Press REPEAT several times until “OFF” is displayed.
Repeating sections between two
specific points (A-B repeat)
Press A-B during play at the point where
repeat play is to start (A).
Press A-B during play at the point where
repeat play is to be concluded (B).
Repeat play of the selection between points A and B
starts.
To return to normal play
Press A-B once “OFF” is displayed.
Notes
Repeat play works only with discs for which the elapsed playing
time appears in the DVD display window during playback.
Repeat play may not work correctly with some DVDs.
A-B repeat play works only within a title DVD or a track CD.
A-B repeat play works only with discs for which the elapsed playing time appears in the DVD display window during playback.
Some subtitles recorded around point A or B may fail to appear
(DVD).
OFF
OFF
CHAPT
TITLE
TRACK
ALL
OFF
A *
A B
37
Storing markers in memory to be viewed (listened to) again
Storing a MARKER in the DVD memory is similar to
marking your page in a book. It allows you to quickly
return to any point on the disc.
Storing a marker in the memory
Press MARKER during play at the starting point
to be viewed (listened to) again.
Indicates “1/5” is stored in the memory.
Up to 5 markers can be stored in the memory.
Recalling/Clearing a marker
Press SEARCH during playback.
Press to select the marker to be
recalled/cleared.
Press PLAY or ENTER to recall a marker. or
Press CLEAR to clear a marker.
Play resumes from the point corresponding to the
selected marker, or the selected marker is cleared.
The “Present Picture” is not cleared.
These operations work only with discs for which the elapsed
playing time appears in the DVD display window during playback or
stop.
Some subtitles recorded around the marker may fail to appear (DVD).
All the markers are cleared when the power is turned off or the disc is
removed and when TV Aspect mode is changed at the SETUP menu.
The marker is not stored when the DVD or title menu is
displayed on the TV screen.
Notes
1/5
Maker
Picture 1
Maker
Picture 2
Maker
Picture 3
Maker
Picture 4
Maker
Picture 5
Present
38
Zoom feature
Random play
Press ZOOM during normal playback or still
playback.
• The square frame will be displayed in the center of the picture. If any button is not pressed for more than 10 seconds,
the square frame will disappear.
• Each press of the ZOOM button changes the magnification
from normal to 4 times to 16 times. To return to normal press
the ZOOM button repeatedly until Nomal appears on the
screen.
• The magnification level will be displayed in the upper right
corner of the zoom area.
If you press buttons the zoom point shifts.
Press ENTER.
The selected frame is displayed in full size on the TV
screen.
To resume normal playback
Press ZOOM again to cancel Zoom feature and resume
normal playback or still playback.
Some discs may not respond to Zoom feature.
Zoom does not work on subtitles or menus included on DVD video
discs.
The Zoom feature allows you to “ZOOM-IN” and enlarge
the picture on the screen to either 4 times (X4) or 16 times
(X16) its normal size.
Note: This function only works with karaoke DVD and with
audio CD discs. Random does not work with DVD movies.
You can playback titles, or tracks in random order.
(Random playback)
The DVD player automatically selects the titles in a DVD
video karaoke disc only and plays them back
randomly.
Notes
Random play (DVD)
Press RANDOM during stop.
The DVD player starts random playback.
If you press the RANDOM during normal playback, the DVD
player will randomly select another title and begin random
playback immediately.
To resume normal playback, press
RANDOM.
The RANDOM indicator in the DVD display
window disappears.
Random play (CD)
The player plays the tracks in the one disc being played in random order.
Press RANDOM during stop.
The random playback screen appears on the TV screen.
If you press the RANDOM button during normal playback,
the DVD player immediately selects another track and
begins random playback.
To resume normal playback, press
RANDOM during random playback.
The RANDOM indicator in the DVD display
window disappears.
Random playback may not be possible on certain discs.
If you press the SKIP button during random playback,
the DVD player goes to another track randomly and starts
playback.
Notes
X4
X16
(X4) (X16) (Normal)
39
Memorizing Settings for Viewed DVDs (Condition Memory)
Load the DVD that has memorized.
It will appear on the TV screen as below
If the screen is left for more than 7 seconds, play
back will start automtically.
Press 2 to select “Yes”
The memorized settings are automatically recalled.
Memorized Disc
Resume?
1. No 2. Yes
This unit can store in memory settings for DVDs you
watched. Settings remain in memory even if you remove
the disc from the player, or switch power to the player
OFF. If you load a disc that has its settings memorized,
the “Memorized Disc Resume?” message will appear on
the TV screen. When you start playing the disc, the
memorized settings are automatically recalled.
You can memorize details for the following six settings.
Last Stop Position (Page 21)
TV Aspect (Page 28)
Disc Audio Language (Page 34)
Disc Subtitle Language (Page 34)
Disc Menu Language (Page 25)
Angle (Page 35)
Settings are stored in memory for use any time.
You can store settings for up to 15 DVDs in memory. lf you memorize
settings for more than 15 DVDs previously memorized settings will be
erased. Subsequently, if you try to call up these previously memorized
settings, you will ger the latest settings that have taken their place.
Switching of the audio mode etc., is automatic on some discs.
Notes
40
Program play
Press PROGRAM during playback or stop mode.
The program playback screen appears on the TV screen.
• To exit the screen, press PLAY, PROGRAM.
Press and press the numeric
button(s), to select the desired track number.
• Repeat step 2 to select another track.
• Up to 20 tracks can be programmed.
Press PLAY or ENTER to exit the screen.
The selected track is stored in the memory and play now
begins in the programmed sequence.
If you press PROGRAM to exit the screen, the selected tracks
are not memorized.
After playback of all tracks programmed
Play is stopped.
Clearing the program
To clear the program one by one
Press to select the unwanted No. and then press
CLEAR.
To clear all the programs
Press to select the “Clear All” and press ENTER. Press
PLAY or ENTER to exit the screen. If you press PROGRAM to exit
the screen, the programs are not cleared. (The programs are also
cleared when the power is turned off or the disc is removed.)
Step
Total Time100:00
Program
Clear All
Step
Total Time
3
08:32
5119
Program
Clear All
The player plays the tracks on the disc in an order you
specify.
Note: Program play function is possible only with
audio CDs. It does not work with DVD movie discs.
41
Playback with MP3
To play an MP3 file
Load an MP3 disc.
The MP3 menu is displayed.
Press buttonx to select the directory where
MP3 files that you want to play are located and
then press ENTER
Press buttonx to select the desired MP3 file
of the selected directory on your disc.
If you want to return to the previous menu, press RETURN
button.
Press ENTER or PLAY to start playback of a file
For your reference
• Press SKIP
or SKIP to play the next file or previous
file duning playback.
• Press TITLE to move to 1’st page of current directory during
playback and press TITLE again to move to the next page
with in 5 seconds.
• Press MENU to move to the Root Directory duning playback
To play an MP3 file repeatedly
If you press REPEAT button once during Play, the
current MP3 file will play repeatedly.
If you press REPEAT button twice during play, the
directory will play repeatedly.
If you press REPEAT button three times, the repeat
play will be cancelled.
REPEAT symbol
The directory and file name is only to display with English.
If there is a impossible code to dispalay. it will be displayed
with under lined (_)instead of English.
If a directory has no MP3 file, the “ ” is displayed with the
directory name.
If you select another file by pressing
during playback,
the file is played after 5 seconds automatically.
If you select a directory by pressing
during playback,
the playback is stopped after 5 seconds.
Notes
MP3 Program
ABCD
MP3-1
MP3-2
MP3-3
MP3-4
MP3-5
MP3-6
MP3-7
MP3-8
MP3-9
Clear All
MP3
MP3-1
..
TRACK_1
TRACK_2
TRACK_3
TRACK_4
TRACK_5
TRACK_6
TRACK_7
TRACK_8
MP3
MP3-1
..
TRACK_1
TRACK_2
TRACK_3
TRACK_4
TRACK_5
TRACK_6
TRACK_7
TRACK_8
MP3
MP3-1
..
TRACK_1
TRACK_2
TRACK_3
TRACK_4
TRACK_5
TRACK_6
TRACK_7
TRACK_8
Program
Clear All
MP3
MP3-1
..
TRACK_1
TRACK_2
TRACK_3
TRACK_4
TRACK_5
TRACK_6
TRACK_7
TRACK_8
Program
Clear All
42
Playback with MP3
To program play an MP3 file
Follow steps 1 to 2 on previous page.
Select an MP3 file to program with
.
Press PROGRAM button to add an MP3 file on
the program list.
• Repeat steps 2-3 to select another track.
• Up to 60 files can be programmed
Press button and select the desired MP3 file
and press ENTER or PLAY button to play.
If you want to enter the main menu, press button.
After playback all tracks programmed
Play is stopped.
To play an MP3 file repeatedly
If you press REPEAT button once during Play, the
current MP3 file will play repeatedly.
If you press REPEAT button twice during play, the
directory will play repeatedly.
If you press REPEAT button three times, the repeat
play will be cancelled.
REPEAT symbol
Clearing the program
To clear the program one by one
Press to select the unwanted MP3 file on the
program list and then press CLEAR.
To clear all the programs
Press to select the “Clear All” and press
ENTER.
MP3
TRACK_2
TRACK_7
TRACK_6
TRACK_9
MP3-1
..
TRACK_1
TRACK_2
TRACK_3
TRACK_4
TRACK_5
TRACK_6
TRACK_7
Clear All Clear All
TRACK_8
ProgramProgram
TRACK_2
TRACK_7
TRACK_6
TRACK_9
MP3
MP3-1
..
TRACK_1
TRACK_2
TRACK_3
TRACK_4
TRACK_5
TRACK_6
TRACK_7
TRACK_8
Program
Clear All
MP3
MP3-1
..
TRACK_1
TRACK_2
TRACK_3
TRACK_4
TRACK_5
TRACK_6
TRACK_7
TRACK_8
Program
TRACK_2
TRACK_7
TRACK_6
TRACK_9
Clear All
MP3
MP3-1
..
TRACK_1
TRACK_2
TRACK_3
TRACK_4
TRACK_5
TRACK_6
TRACK_7
TRACK_8
Program
TRACK_2
TRACK_7
TRACK_6
TRACK_9
Clear All
43
Disc Requirements/Copyright Information
Playable Discs
This DVD player can play back the following discs.
You cannot playback discs other than those listed above. ( CD-ROM, CD-G, photo CD, CD-R and CD-i
discs can not be played on this DVD player.)
DVD video discs
Audio CDs
(CD-R,CD-RW,
MP3)
Disc mark Contents
Audio+Video
(moving pictures)
Audio
Disc size
12 cm
8 cm
12 cm
8 cm
Maximum playback time
Approx. 4 hours (single sided disc)
Approx. 8 hours (double sided disc)
Approx. 80 minutes (single sided disc)
Approx. 160 minutes (double sided disc)
74 minutes
20 minutes
Region Management Information: This DVD Player is designed and manufactured to respond to the Region
Management Information that is recorded on a DVD disc. If the Region number described on the DVD disc does
not correspond to the Region number of this DVD player, this DVD player cannot play that disc.
The Region number of this DVD player is .
You may not be able to play back some DVD video discs on this player if they were purchased from outside your
geographic area or made for business purposes.
When you try to play back an unauthorized disc, “Check Regional Code” appears on the TV screen.
It is forbidden by law to copy, broadcast, show, broadcast on cable, play in public, and rent copyrighted material
without permission.
DVD video discs are copy protected, and any recordings made from these discs will be distorted.
This product incorporates copyright protection technology that is protected by method claims of certain U.S.
patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of
this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home
and other limited viewing uses only, unless otherwise authorized by Macrovision Corporation. Reverse
engineering or disassembly is prohibited.
Notes on Unauthorized Discs
Region Management Information
Notes on Copyright
“Certain audio features of this product manufactured under a license from Desper Products, Inc.,
Spatializer® 3-D Stereo, Spatializer N-2-2 (TM) and the circle-in-square device are trademarks owned by Desper
Products, Inc,.”
1
44
Before Calling Service Personnel
Check the following guide for the possible cause of failure before contacting your dealer or warranty center.
Symptoms and Correction
Symptom
No power.
power is on, but DVD
player does not work.
No picture.
No sound.
Picture is poor.
DVD player does not
start playback.
Remote control does
not work properly.
Cause
• Power cord is disconnected
• Power cord is connected to switched outlet on rear of receiver and receiver is
turned off.
• No disc is inserted.
• DVD requires set-up before playback.
• A/V receiver is not set on DVD function
(if connected to audio/video receiver)
• TV is not set to correct input to receive
DVD signal output
• TV does not recognize video cable type.
• Video cable is not connected securely.
• Receiver or TV power is off.
• A/V receiver is not set on DVD function
(if connected to audio/video receiver).
• Digital audio output of DVD is set incorrectly.
• Digital input on A/V receiver is set incorrectly.
• Audio cable is not connected securely.
• Receiver or TV power is off.
• Disc is dirty.
• No disc is inserted.
• An unplayable disc is inserted.
• Disc is upside down.
• Disc is not in tray guide.
• Disc is dirty.
• A menu stays on the screen
• Rating level is set
• Remote is not pointed at sensor on player.
• Remote control is too far from player.
• Obstacle is in path of remote signal.
• Batteries are dead.
Correction
• Plug the power cord into the wall outlet.
• Turn receiver on to provide power to DVD
player.
• Insert a disc. Confirm that the DVD or
audio CD indicator in the DVD display is
lit.
• Follow the menu set-up instructions and
make selections as required.
• Set A/V receiver to DVD function.
• Select the appropriate video input on the
TV(ie: TV, Video 1, Video 2) so the picture from DVD player appears on screen.
• If TV requires selection of cable type, set
on S-video or composite as required.
• Connect video cable into jacks securely.
• Turn on receiver and TV as applicable.
• Set A/V receiver to DVD function.
• Set the Digital Output of the DVD to the
desired setting.
• Set the digital input on receiver according
to the connection method used (analog,
coaxial, digital 1 or digital 2).
• Connect audio cable into jacks securely,
• Turn on receiver and TV as applicable.
• Clean the disc.
• Insert a disc. Confirm DVD or CD indicator in display is lit.
• Insert a playable disc. Check the disc
type, color system and Regional code.
• Place disc with the playback side facing
down.
• Place the disc on the disc tray correctly
inside the guide.
• Clean the disc.
• Select set-up options as required, press
enter and then play.
• If menu remains on sereen, press the
SETUP button to turn off.
• Cancel the rating function or change the
rating level.
• Point the remote control directly at player.
• Operate the remote control within 20 feet.
• Remove obstacles between remote and
player.
• Replace batteries.
45
Specifications
DVD player/Outputs/Supplied Accessories
* Designs and specifications are subject to change without notice.
Power supply AC120V, 60 Hz
Power consumption 15 W
Mass 5.6 kg
External dimensions (W X H X D) 435 x 122.5 x 423.5 mm
Signal system NTSC
Laser Semiconductor laser, wavelength 650 nm
Frequency range (audio) 4 Hz to 20 kHz
Signal-to-noise ratio (audio) More than 100 dB (EIAJ)
Dynamic range (audio) More than 95 dB (EIAJ)
Harmonic distortion (audio) 0.008 %
Wow and flutter
Below measurable level (less than + 0.001 % (W.PEAK)) (EIAJ)
Operating conditions Temperature: 41°F to 95°F, Operation status: Horizontal
Video output 1.0 V (p-p), 75 , negative sync., RCA jack x 1
S-video output (Y) 1.0 V (p-p), 75 , negative sync., Mini DIN 4-pin x 1
(C) 0.286 V (p-p), 75 ,
Audio output (digital audio) 0.5 V (p-p), 75 , RCA jack x 1
Audio output (optical audio) Optical connector x 1
Audio output (analog audio) 2.0 Vrms(1 KHz, 0 dB), 330 , RCA jack (L, R) x 2
S-Video cable ......................................................1
Composite Video cable ........................................1
Audio cable
Digital Coaxial (75
) Audio Cable.....................1
Analog Audio cable (L/R).....................................1
Remote control ....................................................1
Battery .................................................................2
NOTE: Optional digital optical audio cable is not supplied
[DVD player]
[Outputs]
[Supplied
Accessories]
WELTON U.S.A.
11625 COLUMBIA CENTER DR. SUITE 100
DALLAS, TEXAS 75229
PHONE: 972-243-5602
FAX: 972-243-5958
KQX1A701Z
Loading...
