OPERATING INSTRUCTIONS

19884HDDVD

C O L O U R T E L E V I S I O N W I T H R E M O T E C O N T R O L

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER

PLEASE CONTACT THE TECHWOOD HELP LINE ON 0845 543 0485

- 1 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELPLINE ON 0845 543 0485

Contents

Package Contents .................................................. 2

Features ................................................................. 2

Introduction ............................................................. 3

Preparation ............................................................. 3

Safety Precautions ................................................. 3

Information for users in the EU ............................... 4

Connection to a Television Distribution System

(Cable TV etc.) from Tuner ................................. 4

Remote Control Handset ........................................ 5

Inserting Batteries ............................................... 5

Remote Control Buttons ......................................... 6

TV and Operating Buttons ...................................... 7

Viewing the Connections - Back Connectors ......... 7

Viewing the Connections - Side Connectors .......... 8

Aerial Connection ................................................... 9

Power Connection .............................................. 9

Switching On/Off ..................................................... 9

To Switch the TV On ........................................... 9

To Switch the TV Off ........................................... 9

First Time Installation.............................................. 9

Connecting to a DVD Player................................. 10

Using USB Media ................................................. 10

USB Memory Connection ..................................11

Connecting the TV to a PC ....................................11

Using Side AV Connectors ....................................11

Input Selection .......................................................11

Basic Operations .................................................. 12

Operation with the Buttons on the TV ............... 12

Operation with the Remote Control .................. 12

Viewing Electronic Programme Guide (EPG) ....... 12

EPG Timeline Schedule .................................... 12

EPG Channel Schedule .................................... 13

EPG Now and Next........................................... 13

Installation ............................................................ 13

Auto Channel Scan (Retune) Menu Operation .. 13

Manual Tuning ..................................................... 13

Digital Manual Search....................................... 14

Analogue Manual Search ................................. 14

Analogue Fine Tune.......................................... 14

Managing Stations: Channel List .......................... 14

Operating the Channel List ............................... 14

Moving a Channel ............................................. 14

Deleting a Channel ........................................... 14

Renaming a Channel ........................................ 15

Locking a Channel ............................................ 15

Managing Stations: Favourites ............................. 15

Button Functions ............................................... 15

Managing Stations: Sorting the Channel List ....... 15

On-Screen Information ......................................... 15

Media Playback Using Media Browser ................. 16

Viewing Videos via USB .................................. 16

Viewing Photos via USB ................................... 16

Slideshow Options ............................................ 16

Playing Music via USB ..................................... 17

Media Browser Settings .................................... 17

Changing Image Size: Picture Formats ................ 17

Conﬁ guring Picture Settings ................................. 18

Operating Picture Settings Menu Items ............ 18

Picture Settings Menu Items ............................. 18

PC Picture Settings........................................... 19

Conﬁ guring Sound Settings .................................. 19

Operating Sound Settings Menu Items ............. 19

Sound Settings Menu Items.............................. 20

Conﬁ guring Your TV’s Settings ............................. 20

Operating Settings Menu Items ........................ 20

Settings Menu Items ......................................... 20

Using a Conditional Access Module

(not included) ........................................................ 21

Viewing Conditional Access Menu (*) ............... 21

Conﬁ guring Language Preferences ...................... 21

Parental Control.................................................... 22

Parental Settings Menu Operation ................... 22

Timers ................................................................... 22

Setting Sleep Timer .......................................... 22

Setting Programme Timers ............................... 22

Conﬁ guring Date/Time Settings ............................ 23

Conﬁ guring Source Settings ................................. 23

Conﬁ guring Other Settings ................................... 23

Operation .......................................................... 23

Other Features ..................................................... 24

Teletext ................................................................. 25

Tips ....................................................................... 25

Appendix A: PC Input Typical Display Modes ....... 26

Appendix B: AV and HDMI Signal Compatibility

(Input Signal Types) .............................................. 26

Appendix C: Supported DVI Resolutions.............. 27

Appendix D: Software Upgrade ............................ 27

Appendix E : Supported File Formats for USB

Mode..................................................................... 28

Speciﬁ cations ....................................................... 29

Important Instruction ............................................. 30

- 2 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELPLINE ON 0845 543 0485

Package Contents

INFO

EPG

FAV

PRESETS

SUBTITLE

RETURN

SOURCE

SLEEP

SCREEN

LANG.

Remote Control

LCD TV

Instruction Book

Batteries: 2 X AAA

Note: You should check the contents after opening your purchase and make sure that every item is included.

Features

Remote controlled colour LCD TV.•

Fully integrated Terrestrial digital TV (DVB-T MPEG2).•

HDMI connectors for digital video and audio.•

USB input.•

1000 programmes (analogue+digital).•

On Screen Display (OSD) menu system.•

•Integrated tuner DVB-T, MPEG 2

compatible.

Scart socket for external devices.•

Stereo sound system. (Nicam)•

Teletext, fastext, TOP text.•

Headphone connection.•

Automatic programming system.•

Forward or backward manual tuning.•

Sleep timer / Child lock.•

Automatic sound mute when no transmission.•

NTSC playback. •

AVL (Automatic Volume Limiting).•

Auto power down.•

PLL (Frequency Search).•

PC input. •

Plug&Play for Windows 98, ME, 2000, XP, Vista, • Windows 7.

Game Mode •

- 3 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELPLINE ON 0845 543 0485

Introduction

Thank you for choosing this product. This manual will guide you through the proper operation of your TV. Before operating the TV, please read this manual thoroughly. Please keep this manual in a safe place for future reference.

This device is intended to receive and display TV programmes. The different connection options make an additional expansion of the reception and display sources possible (receiver, DVD player, DVD recorder, VCR, PC etc.).

This device is only suitable for dry indoor use. This appliance is intended solely for private domestic use and may not be used for industrial and commercial purposes. We exclude liability in principle, if the device is not used as intended, or unauthorized modiﬁ cations have been made. To operate your LCD TV in extreme ambient conditions may cause the damage of the device.

Preparation

For ventilation, leave a free space of at least 10 cm all around the set. To prevent any fault and unsafe situations, please do not place any objects on top of the set. Use this device in moderate climates.

10 cm

Safety Precautions

Read the following recommended safety precautions carefully.

Power Source

The TV set should be operated only from a 220-240V AC, 50 Hz outlet. Ensure that you select the correct voltage setting for your convenience.

Power Cord

Do not place the set, a piece of furniture, etc. on the power cord or pinch the cord. Handle the power cord by the plug. Do not unplug the appliance by pulling from the power cord and never touch the power cord with wet hands as this could cause a short circuit or electric shock. Never make a knot in the cord or tie it with other cords. The power cord should be placed in such a way that they are not likely to be stepped on. A damaged power cord can cause ﬁ re or give you an electric shock. When it is damaged and needs to be replaced, it should be done by qualiﬁ ed personnel.

Moisture and Water

Do not use this device in a humid and damp place (avoid the bathroom, the sink in the kitchen etc). Do not expose this device to rain or water, as this may be dangerous and do not place objects ﬁ lled with liquids, such as ﬂ ower vases, on top.

If any solid object or liquid falls into the cabinet, unplug the TV and have it checked by qualiﬁ ed personnel before operating it any further.

Cleaning

Before cleaning, unplug the TV set from the wall outlet. Do not use liquid or aerosol cleaners. Use a soft, dry cloth.

Ventilation

The slots and openings on the TV set are intended for ventilation and to ensure reliable operation. To prevent overheating, these openings must not be blocked or covered in anyway.

Heat and Flames

The set should not be placed near to open ﬂ ames or sources of intense heat such as an electric heater. Ensure that no open ﬂ ame sources, such as candles, are placed on top of the TV. Batteries should not be exposed to excessive heat such as sunshine, ﬁ re or the like.

Lightning

In case of storm and lightning or when going on holiday, disconnect the power cord from the wall outlet.

Replacement Parts

When replacement parts are required, make sure that the service technician has used replacement parts, which are speciﬁ ed by the manufacturer or have the same speciﬁ cations as the original one. Unauthorized substitutions may result in ﬁ re, electrical shock or other hazards.

Servicing

Please refer all servicing to qualiﬁ ed personnel. Do not remove the cover yourself as this may result in an electric shock.

Waste Disposal

Instructions for waste disposal:

• Packaging and packaging aids are recyclable and should principally be recycled. Packaging materials, such as a foil bag, must be kept away from children.

- 4 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELPLINE ON 0845 543 0485

TRADEMARK ACKNOWLEDGMENT

“Dolby” and the double-D symbol are trademarks of Dolby Laboratories.

Licence Notiﬁ cation (Optional)

Manufactured under license from Dolby Laboratories.

Electrical devices not in the hands of children

Never let children use electrical devices unsupervised. Children cannot always recognize properly any possible danger. Batteries / accumulators can be life threatening when swallowed. Store batteries out of the reach of small children. In case of swallowing a battery, medical aid has to be sought immediately. Also keep the packaging away from children as there is danger of suffocation.

The Standby button does not fully switch off this product. Moreover, the device continues to consume power in standby mode. In order to separate the device completely from mains, the mains plug has to be pulled from the mains socket. Because of that the device should be set up in a way, that an unobstructed access to the mains socket is guaranteed, so that in case of emergency the mains plug can be pulled immediately. During periods of prolonged non-use, the TV should be disconnected from the mains power supply.

• Batteries, including those which are heavy metalfree, should not be disposed of with household waste. Please dispose of used batteries in an environmentally friendly manner. Find out about the legal regulations which apply in your area.

Do not try to recharge batteries, there is a danger • of explosion. Replace batteries only with the same or equivalent type.

Information for users in the EU

This symbol on the product or on its packaging means that your electrical device should be disposed at the end of its service life separately from your household wastes. There are separate collection systems for recycling in the EU. For more information, please contact the local authority or the dealer where you purchased the product.

Disconnecting the Device

The mains plug is used to disconnect the TV set from the mains and therefore it must remain readily operable.

Headphone Volume

Excessive sound pressure from earphones and headphones can cause hearing loss.

Installation

To prevent injury, this device must be securely attached to the wall in accordance with the installation instructions when mounted to the wall (if the option is available).

LCD Screen

The LCD panel is a very high technology product with about a million thin ﬁ lm transistors, giving you ﬁ ne picture details. Occasionally, a few non-active pixels may appear on the screen as a ﬁ xed blue, green or red point. Please note that this does not affect the performance of your product.

Warning! Do not leave your TV in standby or operating mode when you leave your house.

Connection to a Television Distribution System (Cable TV etc.) from Tuner

Devices connected to the protective earthing of the building installation through the mains connection or through other apparatus with a connection to protective earthing-and to a television distribution system using a coaxial cable, may in some circumstances create a ﬁ re hazard.

Connection to a cable distribution system has therefore to be provided through a device providing electrical isolation below a certain frequency range (galvanic isolator, see EN 60728-11).

- 5 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELPLINE ON 0845 543 0485

Remote Control Handset

Inserting Batteries

Remove the battery cover located on the back of the handset by gently pulling backwards from the indicated • part.

Insert two • AAA/R3 or equivalent type batteries inside. Observe the correct polarity (+/-) when inserting batteries and replace the battery cover.

Note: Remove the batteries from the remote control handset when it is not to be used for a long period. Otherwise it can be damaged due to any leakage of batteries. Remote range is approximately 7m/23ft.

- 6 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELPLINE ON 0845 543 0485

Remote Control Buttons

INFO

EPG

FAV

PRESETS

SUBTITLE

RETURN

SOURCE

SLEEP

SCREEN

LANG.

Standby1.

Image size2.

Sleep timer3.

Numeric buttons4.

Return / Exit / Index page (in TXT mode)5.

Cursor up6.

Cursor left7.

Programme up (Page down)8.

Programme down (Page up)9.

Mono-Stereo / Dual I-II / Current language 10. (in DVB channels)

Previous Programme11.

Electronic programme guide 12.

Info / Reveal (in TXT mode)13.

Picture mode selection14.

Source selection15.

Red button 16.

Green button17.

Yellow button18.

Menu on-off19.

Blue button20.

OK / Edit Channel list / Hold (in TXT mode)21.

Cursor right / Subpage (in TXT mode)22.

Cursor down23.

Volume up24.

Volume down25.

Mute26.

Teletext / Mix 27.

Subtitle on-off (in DVB channels)28.

Favourite channels29.

No Function30.

Media Browser playback buttons31.

Note: Buttons that are not indicated with a number on the remote control illustration are not functional in TV mode.

- 7 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELPLINE ON 0845 543 0485

TV and Operating Buttons

FRONT and REAR VIEW Control switch VIEW Control Switch

Up direction1.

Down direction2.

Programme/Volume / AV / 3. Standby-On selection switch

Note:You can move the switch,

upward or downward to change the volume. If you want to change the channel, press the middle of the switch once (Position 3) and then move upward or downward. If you press the middle of the switch once more, the source OSD will be displayed. To select desired source, move the switch upward or downward and release. If you press the middle of the switch and hold for a few seconds, the TV will switch to standby mode. The Main menu OSD cannot be displayed via the control buttons on the TV.

Viewing the Connections - Back Connectors

DMI

SPDIF

Coax.OUT

HDMI 1: HDMI Input1. HDMI Inputs are for connecting a device that has a HDMI socket. Your TV is capable of displaying

High Deﬁ nition pictures from devices such as a High Deﬁ nition Satellite Receiver or DVD Player. These devices must be connected via the HDMI or Component source. These sockets can accept either 720p or 1080i signals. No sound connection is needed for a HDMI to HDMI connection.

RF Input2. connects to an aerial antenna system. Note: If you use a decoder or a media recorder, you should connect the aerial cable through the device to

the television with an appropriate antenna cable, as shown in the illustration in the following pages.

SCART 3. input or output for external devices. Connect the SCART cable between the SCART socket on the TV and the SCART socket on your external device (such as a decoder, a VCR or a DVD player).

Note: If an external device is connected via the SCART socket, the TV will automatically switch to AV mode. Note: S-VHS signal is supported via the scart socket(optional).

- 8 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELPLINE ON 0845 543 0485

VGA Input4. is for connecting a personal computer to the TV set. Connect the PC cable between the PC INPUT on the TV and the PC output on your PC.

SPDIF Out5. outputs audio signals of the currently watched source. Use an SPDIF cable to trasfer audio signals to a device that has SPDIF input.

Viewing the Connections - Side Connectors

The CI Slot is used for inserting a CI card. A CI card allows you to view all 1. the channels that you subscribe to. For more information, see “Conditional Access” section.

Side USB input.2.

Video Input is used for connecting video signals of external 3. devices.Connect the video cable between the VIDEO IN socket on the TV and the VIDEO OUT jack on your device.

Audio Inputs are used for connecting audio signals of external devices. 4. Connect the audio cable between the AUDIO INPUTS on the TV and the AUDIO OUTPUT jacks on your device.

The headphone jack is used for connecting an external headphone to 5. the system. Connect to the HEADPHONE jack to listen to the TV from headphones.

The Control switch allows you to control the Volume/ Programme/ Source 6. and Standby-On functions of the TV.

To change volume: Increase the volume by pushing the button up. Decrease

the volume by pushing the button down.

To change channel: Press the middle of the button, the channel information

banner will appear on screen. Scroll through the stored channels by pushing the button up or down

To change source: Press the middle of the button twice, the source list will

appear on screen. Scroll through the available sources by pushing the button up or down.

To turn the TV off: Press the middle of the button down and hold it down for a few seconds, the TV will

turn into standby mode.

Note: If you connect a device to the TV via the VIDEO INPUT, you should also connect your device with an audio cable to the AUDIO INPUTS of the TV to enable audio.

MODE

5Vdc-Max500mA

- 9 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELPLINE ON 0845 543 0485

Aerial Connection

Connect the aerial to the • AERIAL INPUT (ANT) socket located at the rear of the TV.

HDMI 1

SPDIF

Coax.OUT

Power Connection

IMPORTANT: The TV set is designed to operate on 220-240V AC, 50 Hz.

After unpacking, allow the TV set to reach the • ambient room temperature before you connect the set to the mains.

Switching On/Off

To Switch the TV On

Connect the power cord to the 220-240V AC, 50 Hz. • Then the standby LED lights up (The led will blink during the standby On/Off).

To switch the TV on from standby mode either:•

Press the “•

” button, P+ or P- or a numeric button

on the remote control.

Press the control switch on the left hand side of the • TV. The TV will then switch on.

Note: If you switch on your TV via P+ or P- buttons on the remote control or on the TV set, the programme that you were watching last will be reselected.

To Switch the TV Off

Press the “• ” button on the remote control or hold the on the TV until shut down, so the TV will switch to standby mode.

To power down the TV completely, unplug the • power cord from the mains socket.

Note: When the TV is switched to standby mode, the standby LED can blink to indicate that features such as Standby Search, Over Air Download or Timer is active

First Time Installation

IMPORTANT: Ensure that the aerial is connected and a Common Interface module is not inserted before switching on the TV for the first time installation.

When the TV is operated for the ﬁ rst time, the • installation wizard will guide you through the process. First, the language selection screen will be displayed:

Use “• ” or “ ” buttons to select your language and press OK button to set the selected language and continue.

After selecting the language, “• Welcome!” screen will be displayed, requiring you to set Country,Teletext Language and Scan Encrypted options.

By pressing “• ” or “ ” button, select the country you want to set and press “

” button to highlight Teletext Language option. Use “ ” or “ ” button to select desired Teletext Language.

Press “•

” button after setting Teletext Language option. Scan Encrypted will be then highlighted. You should set the Scan Encrypted as Yes if you want to scan coded stations.Afterwards select the desired Teletext Language.

Press • OK button on the remote control to continue and the following message will be displayed on the screen:

- 10 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELPLINE ON 0845 543 0485

To select the “Yes” or “No” option, highlight the item by using “ ” or “ ” buttons and press OK button.

Afterwards the following OSD will be displayed on the screen and the TV will search for both digital and analogue TV broadcasts.

Note: You can press • “MENU” button to cancel.

End of the search process, “Choose Region” osd will be displayed on the screen (if any multiple region variants are detected).Please select country and region choice then press OK to continue.

After all the available stations are stored, Channel • List will be displayed on the screen. If you like the sort channels, according to the LCN, please select “Yes” and than press “OK”.

Press • OK button to quit channel list and watch TV

Connecting to a DVD Player

If you want to connect a DVD player to your TV, you can use the connectors of the TV set. DVD players may have different connectors. Please refer to your DVD player’s instruction book for additional information. Power off both the TV and the device before making any connections.

Note: Cables shown in the illustration are not supplied.

If your DVD player has an • HDMI socket, you can connect via HDMI. When you connect to a DVD player as illustrated below, switch to the HDMI source. See “Input Selection” section.

DVD players can also be connected through • COMPONENT SOCKETS. YPbPr can be used only when you connect a device that has a YPbPr output through the PC input with YPbPr to PC cable (YPbPr cable is not supplied).

You may also connect through the SCART sockets. • Use a SCART cable as shown below.

Note: These three methods of connection perform the

same function but in different levels of quality. It is not necessary to connect by all three methods.

Video Connection

HDMI inputs

Scart socket

DVD Player

YPbPr to PC

cable (optional)

Using USB Media

You can connect USB devices to your TV by using • the USB input of the TV. This feature allows you to display/play JPG, MP3 and video ﬁ les stored on a USB stick.

It is possible that certain types of USB devices (e.g. • MP3 Players) may not be compatible with this TV.

You should back up your ﬁ les before making any • connections to the TV set in order to avoid any possible data loss. Note that the manufacturer will not be responsible for any ﬁ le damage or data loss.

Do not pull out USB module while playing a ﬁ le.•

CAUTION: Quickly plugging and unplugging USB devices, is a very hazardous operation. Do not repeatedly quickly plug and unplug the drive. This may cause physical damage to the USB player and especially the USB device itself.

- 11 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELPLINE ON 0845 543 0485

SIDE VIEW USB MEMORY

5Vdc

Max:500mA

USB

USB Memory Connection

IMPORTANT: The TV should be switched off while plugging or unplugging a USB device. Plug your

USB devices to the USB input of the TV. You can connect a USB device to your TV by using the USB input of the TV.

Note: It is possible certain types of hard disk drives are not supported.

Connecting the TV to a PC

For displaying your computer’s screen image on your TV, you can connect your computer to the TV set. Power off both computer and display before making any connections. Use a 15-pin D-sub display cable to connect a PC to the TV. When the connection is made, switch to PC source. See the Input selection section. Set the resolution that suits your viewing requirements. Resolution information can be found in the appendix.

PC audio cable

(not supplied)

to AUDIO INPUTS

on the TV

PC RGB cable (not supplied) to PC input

Audio Inputs

PC Input

Note: If you connect a PC to the TV using HDMI connection, radio interference may occur. Therefore this type of connection is not recommended. You should use VGA connection instead.

Using Side AV Connectors

You can connect a range of optional equipment to your TV using the side connectors of the TV.

For connecting a camcorder, connect to the VIDEO • IN socket and the AUDIO SOCKETS. Do not connect the camcoder to VIDEO IN socket at the same time since it can cause noise in the picture. For selecting the related source, see the section “Input selection” in the following parts.

Afterwards, you should switch to • Side AV source. See the section Input selection in the following sections for more information.

Camcorder

Headphone

To listen the TV sound from headphones, you • should connect headphones to your TV by using the

HEADPHONE jack as illustrated above.

Input Selection

Once you have connected external systems to your TV, you can switch to different input sources. Press “SOURCE” button on your remote control consecutively for directly changing sources.

Note : YPbPr mode can be used only when you connect a device that has a YPbPr output through the PC input with YPbPr to PC cable (not supplied).

- 12 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELPLINE ON 0845 543 0485

Viewing Electronic Programme Guide (EPG)

You can view the electronic programme guide (EPG) to see information about available programmes.To view the EPG menu please press EPG button on the remote control.

Press “•

”/“ ” buttons to navigate through channels.

Press “• ”/“ ” buttons to navigate through the programme list.

Please note that event information is updated • automatically. If there is no event information data available for channels, the EPG will be displayed with blanks.

EPG Timeline Schedule

Red button (Prev Day): Displays the programmes

of previous day.

Green button (Next day): Displays the programmes of the next day.

Yellow button (Zoom): Expands programme information.

Blue button (Filter): Views ﬁ ltering options.

Numeric buttons (Jump): Jumps to the preferred

channel directly via numeric buttons.

INFO (Details): Displays the programmes in detail.

OK (Options): Displays programme options including

“Select Channel” option.

“

” (Search): Displays “Guide Search” menu.

SUBTTL: Press SUBTITLE button to view Select

Genre menu. Using this feature, you can search the programme guide database in accordance with the genre. Info available in the programme guide will be searched and results matching your criteria will be listed.

“

”(Now) : Shows the current programme.

Basic Operations

You can operate your TV using both the remote control and onset buttons.

Operation with the Buttons on the TV

Volume Setting

You can use the control switch to change the • volume of the TV. To increase volume, please move the switch upward. Move the switch downward to decrease the volume. A volume level scale (slider) will be displayed on the screen.

Programme Selection

First press the control switch once to change • channel. You can move the switch upward to select the next programme or move it downward to select the previous programme.

Viewing Main Menu

The Main Menu screen cannot be displayed by using • the control switch on the TV.

AV Mode

Press the control switch consecutively until the • source OSD is displayed on the screen.

Operation with the Remote Control

The remote control of your TV is designed to control • all the functions of the model you selected. The functions will be described in accordance with the menu system of your TV.

Volume Setting

Press “• V+” button to increase the volume. Press “V-” button to decrease the volume. A volume level scale (slider) will be displayed on the screen.

Programme Selection (Previous or Next Programme)

Press • P- button to select the previous programme.

Press • P+ button to select the next programme.

Programme Selection (Direct Access)

Press the numeric buttons on the remote control to • select programmes between 0 and 9. The TV will switch to the selected programme.

- 13 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELPLINE ON 0845 543 0485

EPG Channel Schedule

/ / / : Navigate

Red button (Prev Time Slice): Displays the programmes of previous time slice.

Green button (Next Time Slice): Displays the programmes of the next time slice.

Yellow button (Prev Day): Displays the programmes of previous day.

Blue button (Next day): Displays the programmes of the next day.

“

” button (Filter): Views ﬁ ltering options.

Numeric buttons (Jump): Jumps to the preferred

channel directly via numeric buttons.

OK (Options): Displays programme options including “Select Channel” option.

INFO (Details): Displays the programmes in detail.

EPG Now and Next

OK (Options): Displays programme options including

“Select Channel” option.

Blue button (Filter): Views ﬁ ltering options.

INFO (Event Details): Displays the programmes in

detail.

Green button: Programme schedule will be listed

Yellow button: Display EPG data in accordane with

timeline schedule

Installation

Press MENU button on the remote control and select Installation by using “ ” or “ ” button. Press OK button and the following menu screen will be displayed.

Select Automatic Channel Scan (Retune) by using “ ”/“ ” button and press OK button. Automatic Channel Scan (Retune) options will be displayed. You can select options by using “ ”/“ ” and OK buttons.

Auto Channel Scan (Retune) Menu Operation

Analogue: Searches and stores analogue stations.

Digital & Analogue: Searches and stores both

analogue and aerial DVB stations.

Whenever you select an automatic search type and • press OK button, a conﬁ rmation screen will appear on the screen. To start installation process, select Yes, to cancel select No by using .“

” or “ ” and

OK button.

After the auto channel scan type is set and selected • and conﬁ rmed, the installation process will start and the progress bar will move along. Press “MENU” button to cancel process. Located channels are not stored if the process is cancelled.

Manual Tuning

HINT: This feature can be used for direct broadcast entry.

Select • Manual Channel Scan from the Installation menu by using “

”/“ ” and OK buttons. Manual

Scan options screen will be displayed.

Select the desired • Search Type using “

” or “ ” button. Manual search options will change accordingly. Use “ ”/“ ” button to highlight an item and then press “ ” or “ ” button to set an option. You can press “MENU” button to cancel.

- 14 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELPLINE ON 0845 543 0485

Digital Manual Search

In manual channel scan, the number of the multiplex or frequency are entered manually and only that multiplex or frequency are searched for the channels. After selecting search type as Digital, you can enter the multiplex or frequency number using the numeric buttons and press OK button to search.

Analogue Manual Search

After selecting search type as analogue, you can use “

”/“ ” button to highlight an item and then press “

” or “ ” button to set an option.

Enter the channel number or frequency using the numeric buttons. You can then press OK button to search. When the channel is located, any new channels that are not on the list will be stored.

Analogue Fine Tune

Select • Analogue Fine Tune from the Installation menu by using “

” or “ ” and OK buttons. The analogue ﬁ ne tune screen will be displayed. The Analogue Fine Tune feature will not be available if there are no analogue channels, digital channels

and external sources stored.

Press • OK button to proceed. Use “

” or “ ” button to set Fine Tune. When ﬁ nished, press OK button again.

Managing Stations: Channel List

The TV sorts all stored stations in the Channel List. You can edit this channel list, set favourites or set active stations to be listed by using the Channel List options.

Press • MENU button to view main menu. Select the Channel List item by using “

” or “ ” button. Press

OK to view menu contents.

Select Edit Channel List to manage all stored channels. Use “

” or “ ” and OK buttons to select

Edit Channel List.

Operating the Channel List

Press “• ” or “ ” button to select the channel that will be processed. Press “ ” or “ ” button to select a function on Channel List menu.

Use • P+ or P- buttons to move page up or down.

Press • BLUE button to view ﬁ ltering options.

Press • MENU button to exit.

Moving a Channel

First select the desired channel. Select Move option • in the channel list and press the OK button.

Edit Number screen will be displayed. Enter the • desired channel number by using the numeric buttons on the remote control. If there is a previously stored channel on that number, a warning screen will be displayed. Select Yes if you want to move the channel and press OK.

Press the • OK button to process. Selected channel is now moved.

Deleting a Channel

You can press GREEN button to tag/untag all channels; YELLOW button to tag/untag channel.

Select the channel that you want to delete and select • Delete option. Press the OK button to continue.

A warning screen will appear. Select • YES to delete, select No to cancel. Press the OK button to continue.

- 15 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELPLINE ON 0845 543 0485

Renaming a Channel

Select the channel that you want to rename and • select Edit Name option. Press OK button to continue.

Pressing “•

” or “ ” button moves to the previous/

next character. Pressing “

” or “ ” button toggles the current character, i.e., ‘b’ character becomes ‘a’ by “

” and ‘c’ by “ ”. Pressing the numeric buttons ‘0...9’ replaces the highlighted character with the characters printed above the button one by one as the button is pressed.

When ﬁ nished, press the • OK button to save. Press

MENU to cancel.

Locking a Channel

You can press GREEN button to tag/untag all channels; YELLOW button to tag/untag a single channel.

Select the channel that you want to lock and select • Lock option. Press OK button to continue.

You will be asked to enter parental control PIN. • Default PIN is set as 0000. Enter the PIN number.

Press • OK button when the desired channel is highlighted to lock/unlock the channel. The Lock symbol will be displayed next to the selected channel.

Managing Stations: Favourites

You can create a list of favourite programmes.

Press • MENU button to view the main menu. Select Channel List item by using “

” or “ ” button. Press

OK to view menu contents.

Select • Favourites to manage favourite list. Use “ ”/“ ” and OK buttons to select Favourites.

You can set various channels as favourites so that • only the favourite channels are navigated.

Select a channel by using “• ” or “ ” button. Press OK button to add selected channel to favourites list. Press OK button again to remove.

Button Functions

OK• : Add/remove a station.

YELLOW• : Tag/untag a channel.

GREEN• : Tag/untag all channels.

BLUE• : Displays ﬁ ltering options.

Managing Stations: Sorting the Channel List

You can select broadcasts to be listed in the channel list. To display speciﬁ c types of broadcast, you should use the Active channel list setting.

Select Active channel list from the Channel list menu by using “

” or “ ” button. Press OK button

to continue.

You can select a broadcast type option from the list by using “

” /“ ” and OK buttons.

On-Screen Information

You can press INFO button to display on-screen information. Details of the station and current programme will be displayed on the information banner.

The information banner gives information on the channel selected and the programmes on it. The name of the channel is displayed, along with its channel list number.

Hint: Not all channels broadcast the programme data. If the name and time of the programme are not available, then the information banner will be displayed with blanks.

If the selected channel is locked, you must enter the correct four-digit numeric code to view the channel (default code is 0000). “Enter PIN” will be displayed on the screen.

- 16 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELPLINE ON 0845 543 0485

Media Playback Using Media Browser

If the USB stick is not recognized after power off/on or First Time Installation, unplug the USB device, turn the TV off and on again and re-insert the USB device.

To display the Media Browser window, press either “MENU” button on the remote control and then select Media Browser by pressing “

” or “ ” button. Press OK button to continue. Media Browser menu options will be displayed.

Also, when you insert USB devices, the media browser screen will be displayed automatically:

You can play music, picture and video ﬁ les from the connected USB memory stick. Use “ ” or “ ” button to select Videos, Photos, Music or Settings.

Viewing Videos via USB

When you select Videos from the main options, the available video ﬁ les will be ﬁ ltered and listed on this screen. You can use “

” or “ ” button to select a video ﬁ le and press OK button to play a video. If you select a subtitle ﬁ le and press OK button, you can select or deselect that subtitle ﬁ le. The following menu will be displayed while playing a video ﬁ le:

Play ( button): Starts the video playback.

Stop (

button): Stops the video playback.

Pause (

button): Pause the video playback.

Rewind ( button): Goes backward.

Forward (

button): Goes forward.

Subtitle/Audio (LANG. button): Sets subtitle/Audio.

Jump(GREEN button): Jumps to the preferred

channel.

Yellow: Opens subtitle time correction menu.

Press YELLOW button to conﬁ m.

Press “

” button for clear.

Press “

”(Cancel) button to switch back to previous

menu.

Viewing Photos via USB

When you select Photos from the main options, available image ﬁ les will be ﬁ ltered and listed on this screen.

Jump (Numeric buttons):Jump to selected ﬁ le using the numeric buttons.

OK: Views the selected picture in full screen.

Slideshow (

button): Starts the slideshow using

all images.

GREEN button: Views images in thumbnails.

RED button: Sorts ﬁ les by date.

YELLOW button: Toggles viewing style.

BLUE button: Changes media type.

Slideshow Options

Pause ( button) : Pauses the slideshow.

Continue (

button) : Continues the slideshow.

Loop/Shufﬂ e (GREEN button): Press once to disable

Loop. Press again to disable both Loop and Shufﬂ e. Press once more to enable only Shufﬂ e. Press again

- 17 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELPLINE ON 0845 543 0485

to enable all. You can follow the disabled functions with the change of the icons.

Previous/Next (Left/Right buttons): Jumps to previous or next ﬁ le on slideshow.

Rotate (Up/Down buttons): Rotates the image using up/down buttons.

RETURN (Exit): Back to ﬁ le list.

INFO: Displays help screen.

Playing Music via USB

When you select Music from the main options, available audio ﬁ les will be ﬁ ltered and listed on this

screen.

Play ( button): Starts the playback.

Stop (

button) : Stops playback.

Pause (

button) : Pauses the selected playback.

FAV button: Sorts ﬁ les by Title,Artist or Album.

Loop/Shufﬂ e (BLUE button): Press once to disable

Loop. Press again to disable both Loop and Shufﬂ e. Press once more to enable only Shufﬂ e. Press again to enable all. You can follow the disabled functions with the change of the icons.

0..9 (Numeric buttons): The TV will jump to the ﬁ le starting with the letter you input via the numeric buttons on your remote control.

Play This (OK button) : Plays the selected ﬁ le.

Previous/Next (Left/Right buttons) : Jumps to

previous or next ﬁ le to play.

INFO: Changes ﬁ lter options.

Media Browser Settings

You can set your Media Browser preferences by using the Settings dialog. Press “ ” or “ ” button to highlight an item and use “ ” or “ ” button to set.

View Style: Sets default browsing mode.

Slide Show Interval: Sets slide show interval time.

Show Subtitle: Sets subtitle enabling preference.

Subtitle Language: Sets supported subtitle

language.

Subtitle Position: Sets subtitle position as up or down.

Subtitle Font Size: Sets subtitle font size (max. 54pt).

Changing Image Size: Picture Formats

You can change the aspect ratio (image size) of • the TV for viewing the picture in different zoom modes.

Press the • SCREEN button repeatedly to change the image size. Available zoom modes are listed below.

Auto

When AUTO is selected, the aspect ratio of the screen is adjusted by the information provided by the selected source(if available)

Note: Auto mode only will be available in HDMI, YPbPr and DTV sources.

16:9

This uniformly stretches the left and right sides of a normal picture (4:3 aspect ratio) to ﬁ ll the wide TV screen.

For 16:9 aspect ratio pictures that have been • squeezed into a normal picture (4:3 aspect ratio), use the 16:9 mode to restore the picture to its original shape.

Subtitle

This zooms up the wide picture (16:9 aspect ratio) with subtitles to the full screen.

Note: You can shift to screen up or down by pressing “ ” / “ ” buttons while picture zoom is selected as panaromic, 14:9 Zoom, Cinema or Subtitle.

- 18 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELPLINE ON 0845 543 0485

14:9

This zooms up the wide picture (14:9 aspect ratio) to the upper and lower limits of the screen.

14:9 Zoom

This option zooms to the 14:9 picture.

4:3

Use to view a normal picture (4:3 aspect ratio) as this is its original size.

Panoramic

This stretches the left and right sides of a normal picture (4:3 aspect ratio) to ﬁ ll the screen, without making the picture appear unnatural.

The top and bottom of the picture are slightly cut off.

Cinema

This zooms up the wide picture (16:9 aspect ratio) to the full screen.

Conﬁ guring Picture Settings

You can use different picture settings in detail.

Press MENU button and select the Picture icon by using “

” or “ ” button. Press OK button to view

Picture Settings menu.

Operating Picture Settings Menu Items

Press “• ” or “ ” button to highlight a menu item.

Use “•

” or “ ” button to set an item.

Press • MENU button to exit.

Picture Settings Menu Items

Mode: For your viewing requirements, you can set

various screen modes. The Picture mode can be set to one of these options: Cinema,Game,Dynamic and Natural.

Contrast: Sets the lightness and darkness values of the screen.

Brightness: Sets the brightness value for the screen.

Sharpness: Sets the sharpness value for the objects displayed on the screen.

Colour: Sets the colour value, adjusting the colors.

Backlight : This setting controls the backlight level

and it can be set to Auto, Maximum, Minimum, Medium and Eco Mode (optional).

- 19 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELPLINE ON 0845 543 0485

Note: Backlight can not be activate in VGA or Media Browser mode or while picture mode is set as Game.

Noise Reduction: If the broadcast signal is weak and the picture is noisy, use Noise Reduction setting to reduce the noise amount. Noise Reduction can be set to one of these options: Low, Medium, High or Off.

Advanced Settings

Colour Temp• : Sets the desired colour tone.

Setting Cool option gives white colours a slight blue stress.

For normal colours, select Normal option.

Setting Warm option gives white colours a slight red stress.

Picture Zoom• :Sets the picture size to Auto,16:9, Subtitle,14:9, 14:9 Zoom, 4:3, Panoramic or Cinema.

HDMI True Black:• While watching from HDMI

source, this feature will be visible in the Picture Settings menu. You can use this feature to enhance blackness in the picture. You can set this feature as “On” for activating HDMI True Black mode.

Film Mode• : Films are recorded at a different number of frames per second to normal television programmes. Press “

” or “ ” buttons to select Film mode. Press “ ” or “ ” buttons to set this feature Auto or Off. Turn this feature to Auto when you are watching ﬁ lms to see the fast motion scenes clearly.

Colour Shift:• Adjust the desired colour tone.

Reset: Resets the picture settings to factory default

settings.

While in VGA (PC) mode, some items in Picture menu will be unavailable. Instead, VGA mode settings will be added to the Picture Settings while in PC mode.

PC Picture Settings

For adjusting PC picture items, do the following:

Press “

” or “ ” button to select Picture icon. Picture

menu appears on the screen.

Contrast, Brightness, Colour, Colour Temp and Picture Zoom settings in this menu are identical

to settings deﬁ ned in TV picture menu under “Main Menu System”.

Sound,Settings and Source settings are identical to the settings explained in main menu system.

PC Position: Select this to display PC position menu items.

Autoposition: Automatically optimizes the display. Press OK to optimize.

H Position: This item shifts the image horizontally to right hand side or left hand side of the screen.

V Position: This item shifts the image vertically towards the top or bottom of the screen.

Dot Clock: Dot Clock adjustments correct the interference that appear as vertical banding in dot intensive presentations like spreadsheets or paragraphs or text in smaller fonts.

Phase: Depending on the resolution and scan frequency that you input to the TV set, you may see a hazy or noisy picture on the screen. In such a case you can use this item to get a clear picture by trial and error.

Conﬁ guring Sound Settings

Sound settings can be conﬁ gured according to your personal preferences.

Press MENU button and select the Sound icon by using “

” or “ ” button. Press OK button to view

Sound Settings menu.

Operating Sound Settings Menu Items

Press “• ” or “ ” button to highlight a menu item.

Use “•

” or “ ” button to set an item.

Press • MENU button to exit.

- 20 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELPLINE ON 0845 543 0485

Sound Settings Menu Items

Volume: Adjusts volume level.

Equalizer: Press OK button to view equalizer sub-

menu.

In the equalizer menu, the preset can be changed to Music, Movie, Speech, Flat, Classic and User. Press the MENU button to return to the previous menu.

Note: Equalizer menu settings can be changed manually only when the Equalizer Mode is in User.

Balance: This setting is used for emphasizing left or right speaker balance.

Headphone: Sets headphone volume.

Sound Mode: You can select Mono, Stereo, Dual I

or Dual II mode, only if the selected channel supports that mode.

AVL : Automatic Volume Limiting (AVL) function sets the sound to obtain ﬁ xed output level between programmes (For instance, volume level of advertisements tend to be louder than programmes).

Dynamic Bass: Dynamic Bass is used to increase bass effect of the TV set.

Digital Out: Sets digital out audio type.

Conﬁ guring Your TV’s Settings

Detailed settings can be configured to suit your personal preferences.

Press MENU button and select Settings icon by using “

” or “ ” button. Press OK button to view Settings

menu.

Operating Settings Menu Items

Press “• ” or “ ” button to highlight a menu item.

Press • OK button to select an item.

Press • MENU button to exit.

Settings Menu Items

Conditional Access: Controls conditional access

modules when available.

Language: Conﬁ gures language settings.

Parental: Conﬁ gures parental settings.

Timers: Sets timers for selected programmes.

Date/Time: Sets date and time.

Sources: Enables or disables selected source

options.

Other Settings: Displays other setting options of the TV set.

- 21 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELPLINE ON 0845 543 0485

Using a Conditional Access Module (not included)

IMPORTANT: Insert or remove the CI module only when the TV is SWITCHED OFF.

In order to watch certain digital channels, a conditional • access module (CAM) may be necessary. This module must be inserted in the CI slot of your TV.

Obtain the Conditional Access Module (CAM) and • the viewing card by subscribing to a pay channel company, then insert those to the TV using the following procedure.

Insert the CAM and then the viewing card to the • slot that is located in the terminal cover at the rear side of the TV.

The CAM should be correctly inserted, it is • impossible to insert fully if reversed. The CAM or the TV terminal may be damaged if the CAM is forcefully inserted.

Connect the TV to the mains supply, switch on and then wait for few moments until the card is activated.

When no module is inserted, “• No Common Interface module detected” message appears on the screen.

Refer to the module instruction manual for details • of the settings.

Viewing Conditional Access Menu (*)

(*) These menu settings may change depending on the service provider.

Press MENU button and select the icon by using “

” or “ ” button. Press OK button to view Settings

menu. Use “ ” or “ ” button to highlight Conditional

Access and press OK to view menu items.

Conﬁ guring Language Preferences

You can operate the TV’s language settings using this menu.

Press MENU button and select the Settings icon by using “

” or “ ” button. Press OK button to view

Settings menu. Use “

” or “ ” button to highlight

Language and press OK to continue:

Use “ ” or “ ” button to set an item. Settings are stored automatically.

Menu: displays the system language.

Preferred

These settings will be used if available. Otherwise the current settings will be used.

Audio• : Sets the preferred audio language.

Subtitle• : Sets the subtitle language. Selected

language will be seen in subtitles.

Teletext• : Sets teletext language.

Guide• : Sets the preferred Guide language.

Current (*)

(*) These settings can be changed if only the broadcaster supports. Otherwise, settings will not be available to be changed.

Audio• : Changes the audio language for the current channel.

Subtitle• : Sets the subtitle language for the current channel.

- 22 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELPLINE ON 0845 543 0485

Parental Control

To prohibit viewing of certain programmes, channels and menus can be locked by using the parental control system.

This function enables or disables the menu protection system and allows the PIN code to be changed.

Press MENU button and select the Settings icon by using “

” or “ ” button. Press OK button to view Settings menu. Use “ ” or “ ” button to highlight Parental and press OK to continue:

To display parental lock menu options, the PIN number should be entered. The factory default PIN number is 0000.

After coding the correct PIN number, parental settings menu will be displayed:

Parental Settings Menu Operation

Select an item by using “• ” or “ ” button.

Use “•

” or “ ” button to set an item.

Press• OK button to view more options.

Menu Lock: Menu lock setting enables or disables the menu access. You can disable access to the installation menu or the whole menu system.

Child Lock: When Child Lock is set, the TV can only be controlled by the remote control. In this case the control panel buttons will not work. Hence, if one of those buttons is pressed, Child Lock Is On will be displayed on the screen when the menu screen is not visible.

Set PIN: Deﬁ nes a new PIN number. Use numeric buttons to enter a new pin number. You will need to enter your new pin a second time for veriﬁ cation purposes.

IMPORTANT: The factory default pin number is 0000, if you change the pin number make sure you write it down and keep it safe.

Timers

To view Timers menu, press MENU button and select Settings icon by using “ ” or “ ” button. Press OK button to view Settings menu. Use “

” or “ ” button

to highlight Timers and press OK to continue:

Setting Sleep Timer

This setting is used for setting the TV to turn off after a certain time.

Highlight Sleep Timer by using “•

” or “ ” button.

Use “•

” or “ ” button to set. The timer can be programmed between Off and 2.00 hours (120 minutes) in steps of 30 minutes.

Setting Programme Timers

You can set programme timers for a particular programme using this feature.

Press “

” button to set timers on an event. Programme timer function buttons will be displayed on the screen.

Adding a Timer

Press • YELLOW button on the remote control to add a timer. The following menu appears on the screen:

Channel: Changes network type by using “

” or “ ”.

Timer Type: This feature is unavailable to be set.

Date: Enter a date using the numeric buttons.

Start: Enter a starting time using the numeric

buttons.

End: Enter an ending time using the numeric buttons.

Duration: Displays duration between the starting and ending time.

Repeat: Sets a timer to be repeated as Once, Daily or Weekly. Use “ ” or “ ” buttons to select an option.

Press • GREEN button to save the timer. Press RED button to cancel.

Change/Delete:Controls parental settings on timers.

Editing a Timer

Select the timer you want to edit by pressing “• ” or “ ” button.

Press • GREEN button. Edit Timer menu screen will be displayed.

When ﬁ nished with editing, press • GREEN button to save. You can press MENU button to cancel.

Deleting a Timer

Select the timer you want to delete by pressing “• ” or “ ” button.

Press • RED button.

Select • YES by using “

” or “ ” buttons to delete the

timer. Select NO to cancel.

- 23 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELPLINE ON 0845 543 0485

Conﬁ guring Date/Time Settings

Select Date/Time in the Settings menu to conﬁ gure Date/Time settings. Press OK button.

Use “• ” or “ ” buttons to highlight Date/Time.

Date,Time,Time Settings Mode and Time Zone Setting will be available.

Use “

” or “ ” buttons to highlight the Time Settings Mode. Time Settings Mode is set using “ ” or “ ” buttons. It can be set to AUTO or MANUAL.

When AUTO is selected, Date/Time and Time Zone options will not be available to be set. If MANUAL option is selected as the Time Zone can be altered:

• By pressing “

” or “ ” buttons select Time Zone.

Use “

” or “ ” buttons to change the Time Zone between GMT-12 or GMT+12. Date/Time on the top of the menu list will then change according to the selected Time Zone.

Changes are automatically stored. Press • MENU to exit.

Conﬁ guring Source Settings

You can enables or disable selected source options. The TV will not switch to the disabled source options when SOURCE button is pressed.

Select • Sources in the Settings menu and press OK button.

Press“•

” or “ ” buttons to select a source.

Use “•

” or “ ” button to enable or disable the selected source. Changes are automatically stored.

Note : YPbPr mode can be used only when you connect a device that has a YPbPr output through the PC input with YPbPr to PC cable (not supplied).

Conﬁ guring Other Settings

To view general conﬁ guration preferences, select Other Settings in the Settings menu and press OK button.

Operation

Press “• ” or “ ” buttons to select an item.

Use “•

” or “ ” button to set an option.

Press• OK button to view a sub-menu.

Menu Timeout: Changes timeout duration for menu screens.

Scan Encrypted Channels: When this setting is on, search process will locate the encrypted channels as well. If it is set as Off, encrypted channels will not be located in automatic search or manual search.

Blue Background (Optional): Activates or deactivates blue background system when the signal is weak or absent.

Software Upgrade: To ensure that your TV always has the most update information, you can use this setting. In order for the proper operation, please ensure that the TV is set to standby mode.

You can enable or disable automatic upgrade by setting Automatic Scanning option.

- 24 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELPLINE ON 0845 543 0485

You can manually search for new software by selecting Scan for upgrade.

Application version: Displays the current application version.

Hard of Hearing: If the broadcaster enables any special signal concerning the audio, you can set this setting as On to receive such signals.

Audio Description: Audio description refers to an additional narration track for blind and visually impaired viewers of visual media, including television and movies. The description narrator talks through the presentation, describing what is happening on the screen during the natural pauses in the audio (and sometimes during dialogue, if deemed necessary). You can use this feature, only if the broadcaster supports that additional narration track.

Auto TV Off: You can set the timeout value of auto off feature.After the timeout value is reached and the TV is not operated for selected time, the TV will go off.

Standby Search (optional): Use “

” or “ ” button

to select Standby Search and then press “ ” or “

” button to set this setting as On or Off. If you change Standby Search to Off, this function will be unavailable.To use Standby search please make sure that you select Standby Search as On.

Other Features

Displaying TV Information: Programme Number,

Programme Name, Sound Indicator, time, teletext, channel type and resolution information is displayed on the screen when a new programme is entered or “INFO” button is pressed.

Mute Function: Press “

” button to disable sound. Mute indicator will be displayed in the upper side of the screen. To cancel mute, there are two alternatives; the ﬁ rst one is pressing the “

” button and the second

one is increasing the volume level.

Picture Mode Selection: By pressing PRESETS button, you can change Picture Mode settings in accordance with your viewing requirements. Available options are Dynamic, Natural, Cinema and Game.

Displaying Subtitles: You can enable subtitles by pressing the SUBTITLE button of the remote control. Press SUBTITLE button again to disable subtitle function.

If “Subtitle” is On, pressing the “ ” button causes the following warning message display on the screen (** for UK only)

- 25 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELPLINE ON 0845 543 0485

Teletext

The teletext system transmits information such as news, sports and weather on your TV. Note that if the signal degrades, for example in poor/adverse weather conditions, some text errors may occur or the teletext mode may be aborted.

Teletext function buttons are listed below:

“

” Teletext / Mix : Activates teletext mode when

pressed once. Press again to place the teletext screen over the programme (mix).Pressing again will quit the teletext mode.

“RETURN” Index: Selects the teletext index page.

“INFO”Reveal: Shows hidden information (e.g.

solutions of games).

“OK” Hold: Holds a text page when convenient. Press again to resume.

“

”/“ ” Subcode Pages : Selects subcode pages if

available when the teletext is activated.

P+ or P- and numbers (0-9): Press to select a page.

Note: Most TV stations use code 100 for their index pages.

Coloured Buttons (RED/GREEN/YELLOW/ BLUE)

Your TV supports both FASTEXT and TOP text systems. When these systems are available, the pages are divided into groups or topics. When FASTEXT system is available, sections in a teletext page will become colour-coded and can be selected by pressing the coloured buttons. Press a coloured button that corresponds to with your needs. The coloured writings will appear, showing you which coloured buttons to use when TOP text transmission is present. Pressing “ ” or “ ” commands will request the next or previous page respec tively.

Digital Teletext

• Press the “ ” button.

The digital teletext information appears.•

Operate it with the coloured buttons, cursor buttons • and OK button.

The operation method may differ depending on the contents of the digital teletext.

Follow the instructions displayed on the digital teletext screen.

When the • “

” button is pressed, the TV returns

to television broadcasting.

The aspect ratio (picture shape) when watching • a channel with just digital teletext broadcasting is the same as the aspect ratio of the picture viewed previously.

Tips

Screen Care: Clean the screen with a slightly damp,

soft cloth. Do not use abrasive solvents as they may damage the coating layer of the TV screen. For your safety, unplug the mains plug when cleaning the set. When moving the TV, hold it properly from the bottom of the unit.

Image Persistence: Please note that ghosting may occur while displaying a persistent image. On LED TVs’ image persistence may disappear after a short time. Try turning the TV off for a while.

To avoid this, do not leave the screen in still picture for extended periods.

No Power: If your TV system has no power, please check the main power cable and connection to the mains socket outlet.

Poor Picture: Have you selected the correct TV system? Is your TV set or house aerial located too close to a non-earthed audio equipment or neon lights, etc.? Mountains or high buildings can cause double pictures or ghost images. Sometimes you can improve the picture quality by changing the direction of the aerial. Is the picture or teletext unrecognisable? Check if you have entered the correct frequency. Please retune the channels. The picture quality may degrade when two peripherals are connected to the TV at the same time. In such a case, disconnect one of the peripherals.

No Picture: Is the aerial connected properly? Are the plugs connected tightly to the aerial socket? Is the aerial cable damaged? Are suitable plugs used to connect the aerial? If you are in doubt, consult your dealer. No Picture means that your TV is not receiving a transmission. Have you selected the correct button on the remote control? Try once more. Also make sure the correct input source has been selected.

Sound: If you cannot hear any sound, check to see if the “ ” button has been pressed. If sound is coming from only one speaker, check if the audio balance has been set to one extreme.

Remote Control: Your TV no longer responds to the remote control. Perhaps the batteries are exhausted. If so you can still use the local buttons on the TV.

Input Sources: If you cannot select an input source, it is possible that no device is connected. Check the AV cables and connections if you have tried to connect a device

- 26 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELPLINE ON 0845 543 0485

Appendix A: PC Input Typical Display Modes

The display has a maximum resolution of 1920 x 1200. The following table is an illustration of some of the typical video display modes. Your TV may not support different resolutions. Supported resolution modes are listed below. If you switch your PC to an unsupported mode, a warning OSD will appear on the screen.

Index Resolution Frequency

640x350 85 Hz

640x400 70 Hz

640x480

60Hz-66Hz-72Hz

-75Hz-85Hz

800x600

56Hz-60Hz-70Hz-72Hz

-75Hz-85Hz

832x624 75 Hz

1024x768

60Hz-66Hz-70Hz-72Hz

-75Hz

1152x864

60Hz-70Hz-75Hz

-85 Hz

1280x768 60 HzA

1280x768 60 HzB

1280x768 75Hz-85Hz

1280x960

60Hz-75Hz-85Hz

1280x1024

60Hz-75Hz-85Hz

1360x768 60 Hz

1400x1050 60 HzA

1400x1050 60 HzB

1400x1050

75Hz-85Hz

1400x900

65Hz-75Hz

1600x1200 60 Hz

1680x1050 60 Hz

1920x1080 60 HzA

1920x1080 60 HzB

1920x1200 60HzA

1920x1200 60Hz

Appendix B: AV and HDMI Signal Compatibility (Input Signal Types)

Source Supported Signals Available

EXT

(SCART )

PAL 50/60 O

NTSC 60 O

RGB 50 O

RGB 60 O

Side AV

PAL 50/60 O

NTSC 60 O

YPbPr

480I 60Hz O

480P 60Hz O

576I 50Hz O

576P 50Hz O

720P 50Hz O

720P 60Hz O

1080I 50Hz O

1080I 60Hz O

1080P 50Hz O

1080P 60Hz O

HDMI

480I 60Hz O

480P 60Hz O

576I 50Hz O

576P 50Hz O

720P 50Hz O

720P 60Hz O

1080I 50Hz O

1080I 60Hz O

1080P 24Hz O

1080P 25Hz O

1080P 30Hz O

1080P 50Hz O

1080P 60Hz O

(X: Not Available, O: Available)

In some cases a signal on the LCD TV may not be displayed properly. The problem may be an inconsistency with standards from the source equipment (DVD, Set-top box, etc. ). If you do experience such a problem please contact your dealer and also the manufacturer of the source equipment.

- 27 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELPLINE ON 0845 543 0485

Appendix C: Supported DVI Resolutions

When connecting devices to your TV’s connectors by using DVI to HDMI cables (not supplied), you can refer to the following resolution information.

Index Resolution Frequency

640x400

70Hz

640x480

60Hz-66Hz-72Hz

-75Hz

800x600

56Hz-60Hz-70Hz-

72Hz -75Hz

832x624

75 Hz

1024x768

60Hz-66Hz-70Hz-

72Hz -75Hz

1152x864

60Hz-70Hz-75Hz

1152x870

75Hz

1280x768

60 HzA

1280x768

60 HzB

1280x768

75Hz

1280x960

60Hz-75Hz

1280x1024

60Hz-75Hz

1360x768

60 Hz

1400x1050

60 HzA

1400x1050

60 HzB

1400x1050

75Hz

1400x900

65Hz-75Hz

1600x1200

60 Hz

1680x1050

60 Hz

1920x1080

60 HzA

1920x1080

60 HzB

1920x1200

60HzA

1920x1200

60Hz

480i-480p

60Hz

576i-576p

50Hz

Appendix D: Software Upgrade

• Your TV is capable of ﬁ nding and updating new software upgrades over broadcast channels.

• For broadcast channels search, the TV looks at the available channels stored in your settings. So before the software upgrade search, it is advised to auto search and update all available channels.

1) Software upgrade search via user interface

• It is possible to manually to check if there is a new software upgrade for your TV set.

• Simply navigate on your main menu. Choose

Settings and select Other Settings menu. In Other Settings menu navigate on to the Software Upgrade

item and press OK button to open Upgrade Options menu.

• In Upgrade Options menu select Scan for upgrade and press OK button.

• If a new upgrade is found, it starts to download the upgrade. A progress bar indicates the remaining download progress. When the download completes successfully a message is displayed for reboot to activate new software. Press OK to continue with the reboot operation.

2) 3.AM search and upgrade mode

• If Automatic scanning in Upgrade Options menu is enabled, the TV wakes up at 03:00 and searches the broadcast channels for new software upgrade. If new software is found and downloaded successfully, with the next power up the TV opens with new software version.

Note on reboot operation: Reboot is the last step in software upgrade operation if download of new software is ﬁ nished successfully. During reboot TV makes ﬁ nal initializations. In the reboot sequence panel power is closed and front led indicates the activity with blinking. Around 5 minutes later TV restarts with new software activated.

• If your TV fails to restart in 10 minutes, unplug power for 10 minutes and re-plug again. TV should open with new software safely. If you still can not get TV working, please kindly repeat unplug and plug sequence a few times more. If your set still can not operate, please call the service personnel to ﬁ x the problem for you.

Caution: While the LED is blinking during reboot do not unplug your TV’s power. Doing this may cause your TV not to re-start again and can only be ﬁ xed by service personnel.

- 28 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELPLINE ON 0845 543 0485

Appendix E : Supported File Formats for USB Mode

Supported Players

Player Stream Video Decoder (MSVD) Audio Decoder (MSAD)

Audio MP3 None MP3

Audio WAV/AIFF None-- LPCM

MPEG1 Program

Stream

MPEG-1 MPEG1 MP3, AC-3 and PCM

MPEG2 Program

Stream

MPEG-2 MPEG2 MP3, AC-3 and PCM

AVI (Xvid) XVID MPEG2 MP3, AC-3 and PCM

Products

Battery

Information for Users on Disposal of old Equipment and Batteries

[European Union only]

These symbols indicate that equipment with these symbols should not be disposed of as general household waste. If you want to dispose of the product or battery, please consider the collection systems or facilities for appropriate recycling.

Notice: The sign Pb below the symbol for batteries indicates that

this battery contains lead.

- 29 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELPLINE ON 0845 543 0485

Speciﬁ cations

TV BROADCASTING

PAL/SECAM B/G D/K K’ I/I’ L/L’

RECEIVING CHANNELS

VHF (BAND I/III)

UHF (BAND U)

HYPERBAND

NUMBER OF PRESET CHANNELS

1000

CHANNEL INDICATOR

On Screen Display

RF AERIAL INPUT

75 Ohm (unbalanced)

OPERATING VOLTAGE

220-240V AC, 50 Hz

AUDIO

German + Nicam Stereo

AUDIO OUTPUT POWER (W

RMS.

) (10% THD)

2 x 2,5

POWER CONSUMPTION (W)

45 W (max)

< 0,5 W (Standby)

PANEL

16:9 display, 19” Screen Size

DIMENSIONS (mm)

DxLxH (With foot): 155 x 460 x 354

Weight (Kg): 4,85

DxLxH (Without foot): 70 x 460 x 315

Weight (Kg): 4,70

Digital

Reception

DVB-T

MHEG-5 ENGINE compliant with ISO/IEC 13522-5 UK engine Proﬁ le 1

for UKObject carousel support compliant with ISO/IEC 135818-6 and UK DTT proﬁ le

Frequency range: 474-850 MHz for UK models

170-862 MHz for EU models

Transmission standard: DVB-T. MPEG-2

Demodulation: COFDM with 2K/8K FFT mode

FEC: all DVB modes

Video: MP@ML, PAL, 4:3/16:9

Audio: MPEG Layer I&II 32/44.148kHz.

- 30 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELPLINE ON 0845 543 0485

Important Instruction

For your own safety read following instruction carefully before attempting to connect this unit to the mains supply.

MAINS (AC) OPERATION

The wires in the mains lead are coloured in accordance with the following code :

IMPORTANT

As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows:

The wire which is coloured green and yellow must be connected to the terminal which is marked with the letter E, or by the earth symbol, or coloured green or green and yellow.

The wire which is coloured blue or black must be connected to the terminal which is marked with the letter N or coloured Black.

The wire which is coloured brown or red must be connected to the terminal which is marked with the letter L or coloured Red.

For continued protection against risk of ﬁ re, replace only with same type and rating of fuse (ASTA approved 5A 250VAC fuse).

CAUTION

TO PREVENT ELECTRIC SHOCK DISCONNECT FROM THE MAINS BEFORE REMOVING COVER. NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

SAFETY PRECAUTION

THIS EQUIPMENT MUST BE DISCONNECTED FROM THE MAINS WHEN NOT IN USE. DO NOT ALLOW THIS UNIT TO BE EXPOSED TO RAIN OR MOISTURE.

GREEN

YELLOW

(Earth)

(if there is earth cable)

FUSE

BROWN

(Live)

BLUE

(Neutral)

- 31 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELPLINE ON 0845 543 0485

Contents

Features ............................................................... 31

General Properties............................................ 31

Safety Information ................................................ 32

Notes on Discs ..................................................... 32

On handling discs ............................................. 32

On cleaning....................................................... 32

Licence Notiﬁ cation .............................................. 32

How to Watch a DVD ............................................ 32

DVD Control Panel Buttons .................................. 33

Overview of the Remote Control .......................... 33

General Operation ................................................ 34

General Playback ................................................. 35

Basic Play ......................................................... 35

For your reference ........................................ 35

Notes on Playback ............................................ 35

Setup Menu Items ................................................ 35

Vıdeo Setup Page............................................. 35

TV Type ......................................................... 35

Language Setup ............................................... 35

OSD LANG ................................................... 35

AUDIO .......................................................... 35

DISC MENU .................................................. 35

SUBTITLE ..................................................... 35

Preferences ...................................................... 36

DEFAULT ...................................................... 36

DOWNMIX .................................................... 36

PASSWORD (Change Password) ................ 36

SPDIF OUTPUT ............................................ 36

Troubleshooting .................................................... 36

The picture quality is poor (DVD)...................... 36

Disc does not play ............................................ 36

Wrong OSD language ....................................... 36

Some functions (Angle, Zoom etc) do not work ... 37

No picture ......................................................... 37

No sound .......................................................... 37

Distorted sound................................................. 37

No response from remote control ..................... 37

If nothing works................................................. 37

Deﬁ nition of Terms ................................................ 37

Disc Types Compatible with This Unit .................. 38

Speciﬁ cations ....................................................... 38

Features

General Properties

• DVD / CD / CD-R / CD-RW / MP3 / JPEG / MPEG playback.

• NTSC/PAL playback (according to disc content)

• LPCM audio via coaxial digital audio output. (optional).

• Multi-Audio (up to 8) support (According to disc content)

• Multi-Subtitle (up to 32) support (According to disc content)

• Multi-Angle (up to 9) support (According to disc content)

• 8 level parental control

• Fast forward and rewind in 5 different speeds. (2x, 4x, 8x, 16x, 32x)

• Slow motion playback in 4 different speeds. (1/2x, 1/4x, 1/8x, 1/16x forward)

• Frame by frame forward playback.

• Search Mode

• Repeat

• Coaxial audio output (optional)

• Copied disks may be incompatible.

Note

• This DVD player may not support some MP3 recordings due to differences in recording formats or disc type.

• Please read the owner’s manual about MP3 playback.

• CD-R/CD-RW discs recorded by CD-DA method can be played. Some CD-R/CD-RW discs may be incompatible due to laser pick-up and disc design.

• DVD-R/RW discs recorded by DVD-Video method can be played . Some DVD-R/RW discs may be incompatible due to laser pick-up and disc design.

• Some discs may be incompatible with JPEG Viewer function due to different recording format or condition of the discs.

Note: For proper operation, only 12 cm discs must be used.

- 32 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELPLINE ON 0845 543 0485

Safety Information

CAUTION

DVD Player is a class 1 laser product. However this product uses a visible laser beam which could cause hazardous radiation exposure. Be sure to operate the player correctly as instructed.

CLASS 1

LASER PRODUCT

RISK OF ELECTRIC SHOCK

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufﬁ cient magnitude to constitute a risk of electric shock of persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

Notes on Discs

On handling discs

• To keep the disc clean, handle the disc by its edge. Do not touch the surface.

• Do not stick paper or tape on the disc.

• If the disc is contaminated with any substance like glue remove before using it.

• Do not expose the disc to direct sunlight or heat sources such as hot air ducts, or leave it in a car parked in direct sunlight as the temperature can rise quickly and damage the disc.

• After playing, store the disc in its case.

On cleaning

• Before playing, clean the disc with a cleaning cloth. Wipe the disc from the center out.

• Do not use solvents such as benzine, thinner, commercially available cleaners or anti-static spray intended for vinyl LPs.

Licence Notiﬁ cation

• This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Rovi Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Rovi Corporation. Reverse engineering and disassembly are prohibited.

How to Watch a DVD

When placing a disc into the loader, labeled side of the disc should be on the front:

When TV set is turned on, ﬁ rst switch to DVD source by using the SOURCE button on the remote control. Press play on the remote control, or directly press play button at the front panel. If there is no disc inside the loader, place a DVD ﬁ rst and press play.

- 33 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELPLINE ON 0845 543 0485

DVD Control Panel Buttons

A. Disc loader

B. Play / Pause

Plays/pauses the disc. When DVD menu (root menu) is active, this button functions as “button select” (selects the highlighted item in menu) if this is not prohibited by the disc.

C. Stop / Eject

Stop playing disc / Eject or Load the disc Note:

• You cannot eject the disc via the remote control.

• While playing a ﬁ le, you should press STOP button three times to eject.

Overview of the Remote Control

Standby1.

Numeric buttons2.

Return back3.

Language selection (Set language)4.

Display time / DVD menu5.

Clear6.

Stop7.

No function8.

Rapid Reverse9.

Rapid advance10.

Info11.

Zoom12.

Repeat13.

Root14.

Menu15.

Title16.

OK / Select17.

Navigation Buttons18.

Subtitle19.

Angle20.

Search mode21.

Play22.

Pause23.

Skip next24.

Skip previous25.

INFO

EPG

FAV

PRESETS

SUBTITLE

RETURN

SOURCE

SLEEP

SCREEN

LANG.

- 34 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELPLINE ON 0845 543 0485

General Operation

You can operate DVD, movie CD, music or picture CD’s content by using the proper buttons on your remote control. Below are main functions of commonly used remote control buttons.

Buttons on the Remote Control

DVD

Playback

Movie

Playback


Playback

Music

Playback

Play Play Play Play

Pause Pause Pause Pause

Stop Stop Stop Stop

/ Skip

backward/forward

Skip

backward/forward

Previous / Next Previous / Next

Shifts the zoomed picture left or right (if available).

Highlights a menu item. / Shifts the zoomed picture down or up (if available).

/ Fast reverse / Fast forward

ANGLE

Views the scene from different angles (if

available).

Changes slide

effect (depends

on the

content).

C Clears digit (if available).

DISPLAY

Displays time / Views main setup menu

INFO Time counter mode selection (during playback). Press repeatedly to switch

between modes.

LANG. Audio language. X X MENU

Displays TV menu.

OK / SELECT Enter / View / Play

REPEAT

Displays repeat options.

RETURN

Returns back to the previous menu (if available).

ROOT

Goes back to the root folder (if available).

SEARCH MODE (*)

Direct selection of scenes or time.

Selects the desired file.

SUBTITLE Subtitle on-off. Press repeatedly to switch

between subtitle options.

X X

TITLE

Displays disc menu

(if available).

Displays disc menu

(if available).

X X

ZOOM Zooms picture. Press repeatedly to switch between zoom options.

Other Functions – Button Combinations

(During playback)

Slow forward.

[ + ] +

Sets slow forward speed.

Sets fast forward speed.

Sets fast reverse speed.

Confirms stop command.

Press repeatedly to advance manually.

(*) You can switch to title by pressing numeric keys directly. You need to press 0 and then digit key to switch one digit titles (example: to select 5, press 0 and 5).

- 35 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELPLINE ON 0845 543 0485

General Playback

Basic Play

Press on the power button1.

Please insert a disc to the loader.2.

The disc will be automatically loaded and play commences if the disc does not have any menus recorded on it.

A menu may appear on the TV screen after a few moments or the ﬁ lm may start immediately after the introduction of the Film Company. This behaviour depends on the disc content and may change.

Note: Step 3 and 4 is available only when a menu is recorded on the disc.

Press “3.

” / “ ” / / or the number button

(s) to select the preferred title.

Press SELECT.4.

Play of the selected items now starts.The played item may be a motion picture, a still picture or another submenu depending on the disc.

For your reference:

If an action corresponding to a button is prohibited the

“

” symbol appears.

Notes on Playback:

No sound will be heard during Rapid advance 1. or Rapid reverse.

No sound will be heard during Slow motion play.2.

Reverse slow motion play is not available.3.

In some cases, the subtitle language is not 4. changed immediately to the selected one.

When the preferred language is not selected even 5. after pressing the button several times, it means that the language is not available on the disc.

When the player is restarted or the disc is 6. changed, the subtitle selection is automatically changed back to the initial settings.

If a language is selected, not supported by the 7. disc, the subtitle language will automatically be set to the disc’s priority language.

Usually a circulation will happen while switching 8. to another language, that is you can cancel the subtitle by pressing this button a number of times until “Subtitle Off” appears on the screen.

When the power is turned on or the disc is 9. removed, the language heard is the one selected at the initial settings. If this language is not recorded on the disc, only the available language on the disc will be heard.

Some DVDs may not contain root and/or title 10. menus.

Reverse stepping is not available.11.

For your convenience:12.

If you attempt to enter a number greater than the total time of the current title, the time search box disappears

and “

Input Invalid” message appears on up-left

corner of screen.

Slide Show is disabled when the ZOOM mode 13. is on.

Setup Menu Items

Vıdeo Setup Page

TV Type

TV Type is only available as ‘PAL’. The TV set also supports NTSC signal; however, the signal will be converted to PAL when it appears on the screen.

Language Setup

OSD LANG

You can select the default OSD language of the player menus

AUDIO

You can select the default audio language if supported by the DVD disc.

DISC MENU

You can select the DVD’s disc menu language among these languages. Disc menu appears in the selected language, if supported by the DVD disc.

SUBTITLE

You can select the default subtitle language if supported by the DVD disc.

- 36 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELPLINE ON 0845 543 0485

Preferences

DEFAULT

If you choose RESET and press SELECT, the factorypresets are loaded. Parental level and parental password does not change.

DOWNMIX

This mode can be selected when the digital audio output of the TV is used.

SURROUND: Surround sound output.

STEREO: Two channels stereo.

PARENTAL (Parental Level)

Playing some DVDs can be limited depending on the age of users. The “Parental Control” function allows playback limitation level to be set by the parent.

Parental Level can be adjusted to one of the eight levels. Level “8 ADULT” adjustment let you watch all of the DVD titles ignoring the DVD disc’s parental level. You can watch the DVD discs, which has the same or lower parental level than the player’s level only.

PASSWORD (Change Password):

Using this item you can change the current password.

To change the password you will be prompted to enter your old password. After you have entered your old password, you can now enter the new 4-digit password.

You can use C key to delete the incorrect entry.

Note: Factory preset of the password is “0000”. You have to enter XXXX digital password every time you want to change the parental level. If you forget your password please contact technical service.

SPDIF OUTPUT

You can set Spdif Output as PCM or RAW. If you select PCM from SPDIF Output in DVD menu and play DVD with Dolby audio, you can get audio output with two channels via the speakers and the SPDIF Out. If you select RAW from SPDIF Output in DVD menu and play DVD with Dolby audio, speakers will be muted and you can get 5+1 Dolby audio via the SPDIF Out.

Troubleshooting

The picture quality is poor (DVD)

• Make sure the DVD disc surface is not damaged. (Scratch, ﬁ ngerprint etc.)

• Clean the DVD disc and try again.

See instructions described in “Notes on Discs” to clean your disc properly.

• Ensure that the DVD disc is in the drawer with the label uppermost.

• A damp DVD disc or condensation may effect the equipment. Wait for 1 to 2 hours in Stand-by to dry the equipment.

Disc does not play

• No disc in the machine.

Place a disc into the loader.

• Disc incorrectly loaded.

Ensure that the DVD disc is in the drawer with the label uppermost.

• Wrong type of disc. The machine cannot play CDROMS etc.

• The region code of the DVD must match the player.

Wrong OSD language

• Select the language in the set-up menu.

• The language for the sound or subtitles on a DVD cannot be changed.

• Multilingual sound and/or subtitles not recorded on the DVD.

• Try to change the sound or subtitles using DVD’s title menu. Some DVD’s do not allow the user to change these settings without using the disc’s menu

- 37 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELPLINE ON 0845 543 0485

Some functions (Angle, Zoom etc) do not work

• These functions are not available on the DVD.

• Angle can only be changed when the angle symbol is displayed.

No picture

• Have you pressed the correct buttons on the remote control? Try once more.

No sound

• Check the volume is set to an audible level.

• Make sure you have not switched the sound off accidentally.

Distorted sound

• Check that the appropriate listening mode setting is correct.

No response from remote control

• Make sure the remote control is in the correct mode.

• Check batteries are ﬁ tted correctly.

• Change the batteries.

If nothing works

If you have tried the above solutions and none seem to work, try switching your TV-DVD off and on again. If this does not work, contact your supplier or TV-DVD repair technician. Never attempt to repair a defective TV-DVD yourself.

Deﬁ nition of Terms

Angle

Recorded onto some DVD discs are scenes, which have been simultaneously shot from a number of different angles (the same scene is shot from the front, from the left side, from the right side, etc.). With such discs, the ANGLE button can be used to view the scene from different angles.

Chapter Number

These numbers are recorded on DVD discs. A title is subdivided into many sections, each of which are numbered, and speciﬁ c parts of video presentations can be searched quickly using these numbers.

DVD

This refers to a high-density optical disc on which high-quality pictures and sound have been recorded by means of digital signals. Incorporating a new video compression technology (MPEG II) and high-density recording technology. DVD enables aesthetically pleasing full-motion video to be recorded over long periods of time (for instance, a whole movie can be recorded).

DVD has a structure consisting of two 0.6-mm thin discs, which are adhered to each other. Since the thinner the disc, the higher the density at which the information can be recorded, a DVD disc has a greater capacity than a single 1.2 mm thick disc. Since the two thin discs are adhered to each other, there is the potential to achieve double-sided play sometime in the future for even longer duration play.

Subtitles

These are printed lines appearing at the bottom of the screen, which translate or transcribe the dialogue. They are recorded on the DVD discs.

Time Number

This indicates the playtime, which has elapsed from the start of a disc or a title. It can be used to ﬁ nd a speciﬁ c scene quickly. (Not all discs permit the time search feature to be used. Availability is determined by the disc’s manufacturer.)

Title Number

These numbers are recorded on DVD discs. When a disc contains two or more movies, these movies are numbered as title 1, title 2, etc.

Track Number

These numbers are assigned to the tracks, which are recorded on AudioCDs. They enable speciﬁ c tracks to be located quickly.

LPCM

LPCM stands for Pulse Code Modulation and is digital audio.

MPEG

Short for Moving Picture Experts Group. This is an international standard for compression of moving images. On some DVDs digital audio has been compressed and recorded in this format.

- 38 -

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER PLEASE CONTACT THE TECHWOOD HELPLINE ON 0845 543 0485

Disc Types Compatible with This Unit

DIGITAL AUDIO

DVD

AUDIO-CD

Audio

Video

12 cm

Audio

12 cm

Audio

(xxxx.mp3)

MP3-CD

JPEG

READABLE

PICTURE-CD

Video

(still picture)

•

MP3 is recorded as a Digital Signal with

better audio quality, less distortion and

less deterioration of audio quality

over time.

•

JPEG is recorded as a Digital Signal with

better picture quality over time.

READABLE

Disc Types

(Logos)

Recording

Types

Disc Size Max.

Playing

Time

74 min.

Single -

sided; 240 min.

Double -

sided; 480 min.

Characteristics

•

DVD contains excellent sound and video

due to Dolby Digital and MPEG-2 System.

•

Various screen and audio functions can be

easily selected through the on screen

menu.

•

CD is recorded as a

Digital Signal with better audio quality,

less distortion and less deterioration of

audio quality over time.

12 cm

Speciﬁ cations

Types of Discs

Supported

DVD: SS/SL 4.7” (DVD-5)

SS/DL 4.7” (DVD-9)

DS/SL 4.7” (DVD-10)

DS/DL 4.7” (DVD-18)

CD-DA

CD-R

CD-RW

MP-3/JPEG

Video Type

MPEG-2 Video Standard Decoding (MPEG-1 supported)

Full-Screen Video Display of 720 x 576 (PAL) & 720 x 480 (NTSC) pixels

50 and 60 Hz frame refresh rates (PAL & NTSC)

Digital bit-stream processing rate up to 108Mbits/sec

Line resolution more than 500 lines

Audio Type

MPEG Multichannel Decoding

LPCM

Audio Output

Analog Outputs:

24 bit /48, 44.1kHz down-sampling DAC

50192877

IF YOU NEED ANY ASSISTANCE OR A CUSTOMER REFERENCE NUMBER

PLEASE CONTACT THE TECHWOOD HELP LINE ON 0845 543 0485

TECHWOOD 19884HDDVD, 22884 HD DVD Digital Operating Instructions Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
