Teac MC-DX220i, Micro Hi-Fi System User Manual

Z

This appliance has a serial number located on the rear panel. Please record
the model number and serial number and retain them for your records.

Model number Serial number

TEAC CORPORATION

3-7-3, Nakacho, Musashino-shi, Tokyo 180-8550, Japan Phone: [phone]

TEAC AMERICA, INC. 7733 Telegraph Road, Montebello, California 90640 Phone: [phone]

TEAC CANADA LTD. 5939 Wallace Street, Mississauga, Ontario L4Z 1Z8, Canada Phone: [phone]

TEAC MEXICO, S.A. De C.V Campesinos N°184, Colonia Granjas Esmeralda, Delegacion Iztapalapa, CP 09810, México DF Phone: [phone]

TEAC UK LIMITED Unit 19 & 20, The Courtyards, Hatters Lane, Watford, Hertfordshire, WD18 8TE, U.K. Phone: [phone]

TEAC EUROPE GmbH Bahnstrasse 12, 65205 Wiesbaden-Erbenheim, Germany Phone: [phone]

TEAC AUSTRALIA PTY., LTD. 30 Tullamarine Park Road, Tullamarine, VIC 3043, Australia Phone: [phone]
A.B.N. 11 113 998 048

0806.MA-1110A

UK

9A10505800

Z

Micro Hi-Fi System

OWNER’S MANUAL

MC-DX220i

Includes adapters for:

iPod nano

iPod with video

iPod mini

iPod with Click Wheel

iPod with color display

Adapters sold separately:

iPod with dock connector

31

Specifications

AMPLIFIER section

Output Power (L+R) . . . . . . . . . . . . . . . . . . . . . . . 5 W + 5 W

Output Power (Subwoofer) . . . . . . . . . . . . . . . . . . . . . . 15 W

Input Sensitivity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 300 mV

Frequency Response. . . . . . . . . . . . . . . . . . . 50 to 20,000 Hz

TUNER Section (FM)

Frequency Range . . . . . . . . . . . . . . . . . 87.50 to 108.00 MHz

Sensitivity (S/N30dB). . . . . . . . . . . . . . . . . . . . . . . 20 dBµV/m

TUNER Section (AM)

Frequency Range . . . . . . . . . . . . . . . . . . . . 522 to 1,620 kHz

Sensitivity (S/N20dB). . . . . . . . . . . . . . . . . . . . . . . 54 dBµV/m

CD PLAYER Section

Frequency Response . . . . . . . . . . . . . 20 to 20,000 Hz (±1 dB)

Signal-to-Noise Ratio . . . . . . . . . . . . . . . . . . . . . . . . . . 55 dB

Wow and Flutter . . . . . . . . . . . . . . . . . . . . . . . Unmeasurable

SPEAKER

Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Full range flat type

Impedance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 ohms

SUBWOOFER

Impedance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 ohms

GENERAL

Power Requirements . . . . . . . . . . . . . . . . . . 230 V AC, 50 Hz

Power Consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . 80 W

Dimension (W x H x D)

Main Unit . . . . . . . . . . . . . . . . . . . . 255 x 169.5 x 115 mm

L & R Speakers . . . . . . . . . . . . . . . . . 210 x 169.5 x 81 mm

Subwoofer. . . . . . . . . . . . . . . . . . . . . 160 x 245 x 335 mm

Weight (Net)

Main Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.4 kg

L & R Speakers. . . . . . . . . . . . . . . . . . . . . . . . . 0.7 kg each

Subwoofer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.3 kg

Standard Accessories

Remote Control Unit (RC-1103) x 1
Battery for Remote Control Unit x 1
Subwoofer Cable x 1
Speaker Cable x 2
FM Antenna x 1
AM Antenna x 1
Stereo mini plug cable x 1

Dock adapter x 8
(adapter “60GB (color) + Photo 40GB/60GB” premounted)
Cover for the Dock x 1

Wall Mount Brackets x 2
Screw (short) x 8
Screw (long) x 4
Tapered Plastic Wall Anchor x 4
Guide sheet for wall mounting x 2

Owner’s Manual x 1
Warranty Card x 1

• Design and specifications are subject to change without
notice.

• Weight and dimensions are approximate.

• Illustrations may differ slightly from production models.

2

IMPORTANT SAFETY INSTRUCTIONS

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.

8) Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that
produce heat.

9) Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided plug
does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.

10)Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.

11)Only use attachments/accessories specified by the
manufacturer.

12)Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination to
avoid injury from tip-over.

13)Unplug this apparatus during lightning storms or when
unused for long periods of time.

14) Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK). NO USER­SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to
persons.

The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.

30

If you have problems with your system, look through this chart
and see if you can solve the problem yourself before calling your
dealer or TEAC service center.

General

No power

e Check the connection to the AC power supply. Check and

make sure the AC source is not a switched outlet and that,
if it is, the switch is turned on. Make sure there is power to
the AC outlet by plugging another item such as a lamp or
fan into the outlet.

No sound from speakers.

e Select the source by pressing the FUNCTION button.
e Check the connection to the speakers.
e Adjust the volume.
e Pull out the headphone’s plug from the PHONES jack.
e If “MUTING” is blinking, press the MUTING button.

The sound is noisy.

e The unit is too close to a TV or similar appliances. Install the

unit apart from them, or turn them off.

Remote control doesn’t work.

e Press the STANDBY/ON switch to turn the unit on.
e When the battery has run out, put in a new one.
e Use remote control unit within the range (5 m) and point at

the front panel.

e Clear obstacles between the remote control unit and the

main unit.

e If a strong light is near the unit, turn it off.

CD Player

Will not play.

e Load a disc with the playback side facing away.
e If the disc is dirty, clean the surface of the disc.
e A blank disc has been loaded. Load a prerecorded disc.
e Depending on the disc, etc. it may not be possible to play

back CD-R/RW discs. Try again with another disc.

e You cannot play back unfinalized CD-R/RW discs. Finalize

such a disc in a CD recorder and try again.

Sound skips.

e Place the unit on a stable place to avoid vibration and shock.
e If the disc is dirty, clean the surface of the disc.
e Don’t use scratched, damaged or warped discs.

iPod Player

Cannot insert the iPod.

e Check the dock adapter.
e Remove dust or obstacles from the Dock connector of the

MC-DX220i and the iPod, and insert the iPod again.

Will not play.

e Remove the iPod from the dock, wait a few seconds, and

insert it again.

e Software update may solve the problem. Visit the Apple

website and download the latest iPod Software.

Tuner

Cannot listen to any station, or signal is too weak.

e Tune in the station properly.
e Rotate the FM or AM antenna for the best reception

position.

Though the broadcast is stereo, it sounds monaural.

e Press the FM MODE button.

If normal operation cannot be recovered, unplug the
power cord from the outlet and plug it again.

If the power switch of the subwoofer turned off, the
settings kept in memory (clock, preset stations, timer
setting) will be erased.

Troubleshooting

Beware of condensation

When the unit (or a disc) is moved from a cold to a warm
place, or used after a sudden temperature change, there is a
danger of condensation; vapor in the air could condense on
the internal mechanism, making correct operation erratic or
impossible. To prevent this, or if this occurs, leave the unit for
one or two hours with the power turned on. The unit will
stabilize at the temperature of its surroundings.

Maintenance

If the surface of the unit gets dirty, wipe with a soft cloth or
use diluted mild liquid soap. Never spray liquid directly on this
unit. Apply your cleaner to your cleaning cloth and wipe
gently. Be sure to remove any excess completely. Do not use
thinner, benzene or alcohol as they may damage the surface
of the unit. Allow the surface of the unit to dry completely
before using.

3

Disposal of your old appliance

1.When this crossed-out wheeled bin
symbol is attached to a product it means
the product is covered by the European
Directive 2002/96/EC.

2.All electrical and electronic products
should be disposed of separately from
the municipal waste stream via designated collection
facilities appointed by the government or the local
authorities.

3. The correct disposal of your old appliance will help prevent
potential negative consequences for the environment and
human health.

4. For more detailed information about disposal of your old
appliance, please contact your city office, waste disposal
service or the shop where you purchased the product.

CAUTION

< DO NOT REMOVE THE EXTERNAL CASES OR CABINETS TO

EXPOSE THE ELECTRONICS. NO USER SERVICEABLE PARTS
ARE WITHIN!

< IF YOU ARE EXPERIENCING PROBLEMS WITH THIS PRODUCT,

CONTACT TEAC FOR A SERVICE REFERRAL. DO NOT USE THE
PRODUCT UNTIL IT HAS BEEN REPAIRED.

< USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF

PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY
RESULT IN HAZARDOUS RADIATION EXPOSURE.

WARNING: TO PREVENT FIRE OR SHOCK
HAZARD, DO NOT EXPOSE THIS APPLIANCE
TO RAIN OR MOISTURE.

< Do not expose this apparatus to drips or splashes.

< Do not place any objects filled with liquids, such as vases, on

the apparatus.

< Do not install this apparatus in a confined space such as a

book case or similar unit.

< The apparatus draws nominal non-operating power from the

AC outlet with its POWER switch in the off position.

< The apparatus should be located close enough to the AC

outlet so that you can easily grasp the power cord plug at any
time.

< An apparatus with Class !construction shall be connected to

an AC outlet with a protective grounding connection.

< Batteries (battery pack or batteries installed) shall not be

exposed to excessive heat such as sunshine, fire or the like.

Contents

Thank you for choosing TEAC. Read this manual carefully
to get the best performance from this unit.

Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Before Using the Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Remote Control Unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Discs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Wall Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Getting started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Unit Functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Basic Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

iPod

Listening to iPod . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

CD/MP3

Listening to CD/MP3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Search Mode (MP3 only). . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Shuffle Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Programmed Playback. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Repeat Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

TUNER

Listening to the Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Preset Tuning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

RDS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

RDS (PTY Search) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

AUX

Listening to an External Source . . . . . . . . . . . . . . . . . . . . . . . . 26

Setting the Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Setting the Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

29

Press the SKIP button (.//) to select a source
(TUNER, CD or iPod), and then press the TIMER button.

6

Press the SKIP button (.//) to set the volume, and
then press the TIMER button.

7

The clock and the TIMER indicator are displayed.
The unit will turn on and off at the specified time every day.

Don’t forget to turn the unit off (standby), or the timer
won’t work.

If the power switch of the subwoofer turned off, the
settings kept in memory (clock, preset stations, timer
setting) will be erased.

< Playback volume will gradually increase up to your set volume

when the unit is turned on by timer.

< If the source is set to “iPod” but no iPod is set, the unit will

turn on into TUNER mode.

< If the source is set to “CD” but no disc is set, the unit will

turn on into TUNER mode.

< When the source is set to “TUNER” and the unit turns on, it

will tune in to the station you selected last time.

Prepare the source.

If you selected “TUNER” in step , tune in a station.
If you selected “CD” in step , set a disc.
If you selected “iPod” in step , insert an iPod.

6

6

6

8

When you don’t use the timer, press the TIMER button to
turn it off. (The TIMER indicator disappears from the display.)
Press the TIMER button again to turn it on.

< When the timer is turned on, the timer settings are displayed

one by one, and the TIMER indicator lights on the display.

Setting the timer is now completed and the timer is turned on.
Your timer setting is displayed one by one, and the TIMER
indicator lights on the display.

To turn on or off the timer

Press the STANDBY/ON button to turn the unit off
(standby).

9

4

Before Using the Unit

Read this before operation

< As the unit may become warm during operation, always leave

sufficient space around the unit for ventilation.
The ventilation holes should not be covered. Make sure there
is at least 5 cm of space on each side of the unit. Do NOT
place anything on top of the unit.

< The voltage supplied to the unit should match the voltage as

printed on the rear panel. If you are in any doubt regarding
this matter, consult an electrician.

< Choose the installation location of your unit carefully. Avoid

placing it in direct sunlight or close to a source of heat. Avoid
locations subject to vibrations and excessive dust, heat, cold
or moisture.

< Do not place the unit on any other electronic components.

< Do not open the cabinet as this might result in damage to the

circuitry or electrical shock. If a foreign object should fall into
the unit, contact your dealer or service company as soon as
possible.

< When removing the power plug from a wall outlet, always

pull directly on the plug. Do not pull on the line cord.

< To keep the laser pickup clean, do not touch it and always

close the CD door after each use.

< Do not attempt to clean the unit with chemical solvents as

this might damage the finish. Use a clean, dry, lint-free cloth.

< Keep this manual in a safe place for future reference.

CAUTION: DO NOT MOVE THE UNIT DURING PLAYBACK

During playback, the disc rotates at high speeds. Do NOT lift
or move the unit during playback. Doing so may damage the
disc or the unit.

WHEN MOVING THIS UNIT

When changing places of installation or packing the unit for
moving, be sure to remove the disc. Moving this unit with the
disc loaded may result in malfunction or other damage.

NXT is a trademark of New Transducers Ltd.

Remote Control Unit

Remove the battery compartment cover.

Put in the lithium battery (CR2032, 3V).

Close the cover.

Battery Replacement

If the distance required between the remote control unit and
main unit decreases, the battery is exhausted. In this case,
replace the battery with a new one.

Precautions concerning batteries

Do not heat or disassemble batteries and never dispose of old
batteries by throwing them in a fire.

3

2

1

The provided Remote Control Unit allows the unit to be operated
from a distance.
When operating the remote control unit, point it towards the
remote sensor on the front panel of the unit.

< Even if the remote control unit is operated within the effective

range, remote control operation may be impossible if there
are any obstacles between the unit and the remote control.

< If the remote control unit is operated near other products

which generate infrared rays, or if other remote control
devices using infrared rays are used near the unit, it may
operate incorrectly. Conversely, the other products may also
operate incorrectly.

Battery Installation

1

2

3

28

Setting the Timer

< The unit can be programmed to turn on and off at a specified

time.

< Adjust the clock before setting the timer.

Press and hold the TIMER button until the TIMER
indicator and “ON” appear on the display.

1

The “hour” value starts flashing.

< When no button is pressed for 10 seconds, the timer setting

mode will be cancelled.

The “minutes” value starts flashing.

Press the SKIP button (.//) to set the start time
(minute), and then press the TIMER button.

3

“TIMER” and “OFF” indiactors appear on the display and the
“hour” value starts flashing.

Press the SKIP button (.//) to set the start time
(hour), and then press the TIMER button.

2

Press the SKIP button (.//) to set the stop time
(minute), and then press the TIMER button.

5

The “minutes” value starts flashing.

Press the SKIP button (.//) to set the stop time
(hour), and then press the TIMER button.

4

5

Discs

Discs which can be played on this unit:

• Conventional audio CDs bearing the COMPACT DISC
DIGITAL AUDIO logo on the label:

• Properly finalized CD-R and CD-RW discs

• MP3 CDs

Note:

< Depending on the quality of the disc and/or the condition of

the recording, some CD-R/CD-RW discs may not be playable.

< Copy-protected discs and other discs that do not conform to

the CD standard may not play back correctly in this player. If
you use such discs in this unit, TEAC Corporation and its
subsidiaries cannot be responsible for any consequences or
guarantee the quality of reproduction. If you experience
problems with such non-standard discs, you should contact
the producers of the disc.

MP3 compatibility

< File names of MP3 should be alphanumeric characters. This

unit cannot display symbols and full-size or 2 bytes-wide
characters (such as Japanese, Chinese, etc.) correctly. Also, be
sure to use the file extension “.mp3”.

< The disc must be finalized in order to play.

< The CD-ROM must be ISO 9660 compatible.

< When more than 200 files or folders are recorded on the disc,

the unit might not be able to play it correctly.

< The file must be mono or stereo MPEG-1 Audio Layer 3

format, 44.1 or 48 kHz, fixed bit-rate.

How to remove the disc How to hold the disc

< Always place the disc on the disc tray with the label side up.

(Compact discs can be played or recorded only on one side.)

< To remove a disc from its storage case, press down on the

center of the case and lift the disc out, holding it carefully by
the edges.

< CD-R and CD-RW discs are more sensitive to the effects of

heat and ultraviolet rays than ordinary CDs. It is important
that they are not stored in a location with direct sunlight and
keep your discs away from sources of heat such as radiators
or heat-generating electrical devices.

< Printable discs aren’t recommended because the label side

might be sticky (or contain glue), which will damage the unit.

< Do not stick papers or protective sheets on the discs and do

not use any protective coating spray.

< Use a soft oil-based felt-tipped pen to write information on

the label side of a disc. Never use a ball-point or hard-tipped
pen, as this may cause damage to the recorded side of the
disc.

< Never use a stabilizer. Using commercially available CD

stabilizers with this unit will damage the mechanisms and
cause them to malfunction.

< Do not use irregular shape CDs (octagonal, heart shaped,

business card size, etc.). CDs of this sort can damage the unit:

< If you are in any doubt as to the care and handling of any

disc, read the precautions supplied with the disc, or contact
the disc manufacturer directly.

< Should the disc become dirty, wipe the surface from the

center hole outward towards the outer edge with a soft, dry,
lint-free cloth:

< Never use chemicals such as record (LP) sprays, antistatic

sprays or fluids, benzine or thinner to clean the discs. Such
chemicals will do irreparable damage to the disc’s plastic
surface.

< Discs should be returned to their cases after each use to avoid

dust and scratches that may eventually cause your disc to
skip.

< Do not expose discs to direct sunlight, high humidity, or high

temperatures for extended periods. Long exposure to high
temperatures will warp the disc.

< Do not play any disc that is warped, scratched, deformed or

damaged. Playing such discs may cause irreparable harm to
the playback mechanism.

TIMER

/
