65DP628
65 "
Slim 4K UHD TV with
HDR and Smart TV 3.0
4K HDR
superb contrast, vivid
accurate colours and nest details
Share Unique TV Moments in 4K HDR !
Micro Diming
analyses the TV picture in
separate zones to adapt the brightness
Picture Performance Index
allows to valuate picture
quality
Dolby Audio
delivers rich, clear,
powerful sound in your TV
SMART TV 3.0
for easy access to
4K HDR contents
Freeview Play
Go The Other Way with
Freeview Play
NETFLIX
now, available in
4K UHD HDR quality
YouTube
now, available in
4K UHD HDR quality
65DP628
DISPLAY CONTROL
Screen size (inches/cm) 65 / 165.1
Visible screen size : diagonal(inches/cm) 64.5 / 164
Panel resolution UHD
Wide color Technology HDR (High Dynamic Range) Yes
HDR formats HDR10, PQ10, HLG
HDR brightness Picture Performance Index* 1200
Resolution 3840x2160
Curved / Curvature 10 bit panel Yes
Dynamic contrast Mega
Picture processing Pure Image Ultra HD
Dimming Yes
Ultra AR coating UHD upscaling UHD
Color management UHD Color Extender
Digital Noise Reduction Yes
Film Mode Yes
* Picture performance Index
AUDIO
Sound power 2x8 W
Music sound power 2x16 W
Dolby Dolby Digital Plus
Sound Processing Dolby Audio
Equaliser Yes
Speaker type Down Firing
Audio quality by Speakers Full range
Digital Pure Sound Woofer Auto volume control Yes
SMART CONTENT
Processor Dual Core
SmartTV 3.0 (33 languages)
Android OS GuideOn (Internet EPG) 4K Netix, YouTube
Applications Yes
Social Yes
Web browser Ye s
HbbTV 2.0.1
Voice search Internal memory -
CONVENIENCE
Smartphone / Tablet remote support Yes
USB multimedia* Yes
Caption(Subtitle) Yes
Divx compatibility Clock & On/Off timer Game mode Yes
Sports mode Yes
Multipicture PAT
Sleep timer Yes
Hotel mode Yes w. OTT purge
OSD Languages 30
HDMI CEC (T-link) Full
HDMI quick switch Yes
* USB key not included
CONVERGENCE
Bluetooth DLNA 1.5 Ye s
Wi display (Miracast) T-cast
USB HID support Yes
Remote control batteries Yes
Remote Control RC802N3
TUNER/BROADCASTING
DTV Tuner DVB-T2/C/S2
Video decoding H.265 UHD, H.264, MPEG-2
Analogue tuner Yes
Analogue tuner systems
CI+ Yes (1.3)
EPG (DVB EIT/SI) up to 8 days
Auto channel search Yes
Teletext Yes
CONNECTIVITY
HDMI 3 x 2.0b
HDCP 2.2 All HDMIs
USB 2 x 2.0
YPbPr CVBS Optional
DVI-in (video) via HDMI3
Ethernet (LAN RJ-45) Yes
Wi Built-in b/g/n
Digital Audio Out Optical
Headphone Yes
RF in (IEC Terrestial/Cable) 1
RF in (F Sat) 1
Sat: Diseq / SCD Yes v.1.0 / No
CI slot 1
HDMI ARC via HDMI3
HDMI max resolution 2160P/60Hz 12bit
MHL Power cable Detachable, 1.5 m
DESIGN
Color Black
Vesa size 400 x 200 mm
Stand type Fixed
POWER
Energy efcency class* A+
Auto power off Yes
Power supply 220-240V~50Hz
Power consumption (standby)* 0.24 W
Power consumption (network standby)* 0.68 W
Power consumption (on mode IEC62087 Ed.2)* 118 W
Annual power consumption (EU standard)* 173 kWh
Peak luminance ratio 75%
Power consumption (maximum)* 145 W
Mercury content 0.0 mg
Presence of Lead Yes
*estimation
DIMENSIONS & WEIGHT
Product Size 1465 / 920 / 298 mm
Stand width 1290 mm
Product size w/o stand 1465 / 850 / 14-45-78 mm
Packaging size 1640 / 990 / 190 mm
Product / packaging 18.60 / 25.80 kg
Without stand 18.20 kg
EAN 5901292513030
Manual - languages number 30
Incl. 3D glasses -
PAL/SECAM/NTSC (AV) BG/DK/I/LL’
Specications are subject to change without notice. Photos are not contractual.
TCL is a registered trademark.
www.tcl.com
04/06/2020
