Taylor 3724-21 User Manual
3724-21
Mechanical Kitchen Scale
Instruction Manual
Thank you for purchasing a Taylor®scale. Please read this instruction
manual carefully before use. Keep these instructions handy for future reference.
GENERAL WEIGHING OPERATION
1. Place the scale base on a hard, level surface. Place the weighing
bowl so that it is stable on top of the base unit.
2. The pointer should indicate "0" before objects to be weighed are
placed on the scale. To adjust the scale to "0", rotate the scale ring,
which has the measurement increments printed on it.
3. You may also use the scale ring to tare, or offset, the weight of one
ingredient before adding another ingredient to the same bowl. For
example, if a recipe calls for 1/2 lb. rice and 1/2 lb. beans, place the
rice into the bowl, then rotate the scale ring back to "0". Add the
beans until the pointer shows 1/2. Both ingredients have been accurately weighed in the same bowl.
4. Carry the scale by holding the base unit. If the scale is relocated,
readjustment to "0" may be required. To do so, repeat steps 1 and 2.
CARE AND MAINTENANCE
1. The scale base is not dishwasher safe. Immersing the scale in water
may trap liquid between the lens and the body that cannot be effectively dried-out.
2. An occasional wiping with a soft cloth and mild soap will keep your
scale clean and attractive. Do not use abrasive cleaners. Your
scale does not require oiling or lubrication of any kind.
3. The bowl is top-shelf dishwasher safe.
4. Do not put either the base unit or the bowl in a microwave.
5. Protect the scale from flames, heat, direct sunlight and high humidity.
6. Do not tamper with the scale's internal components. Doing so may
cause damage. The scale contains no user-serviceable parts.
2
ONE YEAR LIMITED WARRANTY
Taylor® warrants this product to be free from defects in material or
workmanship for one (1) year for the original purchaser from date of
original purchase. It does not cover damages or wear resulting from
accident, misuse, abuse, commercial use, or unauthorized adjustment
and/or repair. If service is required, do not return to retailer. Should this
product require service (or replacement at our option), please pack
the item carefully and return it prepaid, along with store receipt showing the date of purchase and a note explaining reason for return to:
TAYLOR Precision Products
2220 Entrada Del Sol, Suite A
Las Cruces, New Mexico, 88001 USA
www.taylorusa.com
There are no express warranties except as listed above. This warranty
gives you specific legal rights, and you may have other rights which
vary from state to state.
For additional product information, or warranty information outside the
USA, please contact us through www.taylorusa.com.
Made in China to our exact specifications. Not Legal for Trade.
© 2009 Taylor Precision Products and its affiliated companies, all rights
reserved. Taylor® and Leading the Way in Accuracy® are registered
trademarks of Taylor Precision Products and its affiliated companies. All
rights reserved.
www.taylorusa.com
3
