Models 358 & 359

Thick Shake Freezers

Operating Instructions

056788-M

8/2/10 (Original Publication)

(Updated 3/18/11)

Complete this page for quick reference when service is required:

Taylor Distributor: Address: Phone: Service: Parts: Date of Installation:

Information found on the data label:

Model Number: Serial Number: Electrical Specs: Voltage Cycle

Phase Maximum Fuse Size: A Minimum Wire Ampacity: A

E August, 2010 Taylor

The word Taylor and the Crown design are registered trademarks in the United States of America and certain other countries.

Taylor Company 750 N. Blackhawk Blvd. Rockton, IL 61072

Table of Contents

Section 1 To th e Installer 1............................................

Installer Safety 1........................................................

Site Preparation 1.......................................................

Air Cooled Units 2.......................................................

Electrical Connections 2.................................................

Beater Rotation 2.......................................................

Refrigerant 3...........................................................

Section 2 To the Operator 4...........................................

Section 3 Safety 5....................................................

Section 4 Operator Parts Id entification 7...............................

Model 358 7............................................................

Model 359 8............................................................

Beater and Door Assembly 9.............................................

Accessories 10..........................................................

Section 5 Important: To the Operator 11.................................

Power Switch 11.........................................................

Indicator Light - “Mix Out” 12..............................................

Reset Button 12.........................................................

Air Tube 12.............................................................

Section 6 Operating Procedures 13.....................................

Assembly 13............................................................

Sanitizing 16............................................................

Priming 17..............................................................

Closing Procedure 18....................................................

Draining Product From the Freezing Cylinder 18.............................

Rinsing 18..............................................................

Models 358 & 359 Table of Contents

Table of Contents - Page 2

Cleaning 19.............................................................

Disassembly 19..........................................................

Brush Cleaning 19.......................................................

Section 7 Important: Operator Checklist 21..............................

During Cleaning and Sanitizing 21.........................................

Troubleshooting Bacterial Count 21........................................

Regular Maintenance Checks 21...........................................

Winter Storage 22........................................................

Section 8 Troubleshooting Guide 23....................................

Section 9 Parts Replacement Schedule 26...............................

Section 10 Parts List 27.................................................

Wiring Diagrams 34......................................................

Note: Continuing research results in steady improvements; therefore, information in this manual is subject to change without notice.

E August, 2010 Taylor (Original Publication)

The word Taylor and the Crown design are registered trademarks in the United States of America and certain other countries.

Table of Contents Models 358 & 359

Taylor Company 750 N. Blackhawk Blvd. Rockton, IL 61072

Section 1 To the Installer

The following are general installation instructions. For complete installation details, please see the checkout card.

Installer Safety

In all areas of the world, equipment should be installed in accordance with existing local codes. Please contact your local authorities if you have any questions.

Care should be taken to ensure that all basic safety practices are followed during the installation and servicing activities related to the installation and service of Taylor equipment.

S Only authorized Taylor service personnel

should perform installation and repairs on the equipment.

S Authorized service personnel should consult

OSHA Standard 29CFRI910.147 or the applicable code of the local area for the industry standards on lockout/tagout procedures before beginning any installation or repairs.

S Authorized service personnel must ensure

that the proper PPE is available and worn when required during installation and service.

S Authorized service personnel must remove

all metal jewelry, rings, and watches before working on electrical equipment.

The main power supply(s) to the freezer must be disconnected prior to performing any repairs. Failure to follow this instruction may result in personal injury or death from electrical shock or hazardous moving parts as well as poor performance or damage to the equipment.

Note:Allrepairsmustbeperformedbyan authorized Taylor Service Technician.

This unit has many sharp edges that can

cause severe injuries.

Site Preparation

Review the area where the unit will be installed before uncrating the unit. Make sure all possible hazards to the user or equipment have been addressed.

For Indoor Use Only: This unit is designed to operate indoors, under normal ambient temperatures of 70_-75_F(21_-24_C). The freezer has successfully performed in high ambient temperatures of 104_(40_C) at reduced capacities.

This unit must NOT beinstalledinanarea where a water jet or hose can be used. NEVER use a water jet or hose to rinse or clean the unit. Failure to follow this instruction may result in electrocution.

This unit must be installed on a level surface to avoid the hazard of tipping. Extreme care should be taken when moving this equipment for any reason. Two or more persons are required to safely move this unit. Failure to comply may result in personal injury or equipment damage.

Uncrate the unit and inspect it for damage. Report any damage to your Taylor Distributor.

This piece of equipment is made in the USA and has USA sizes of hardware. All metric conversions are approximate and vary in size.

Models 358 & 359 To the Installer

Air Cooled Units

DO NOT obstruct air intake and discharge openings:

Air cooled units require a minimum of 3” (76 mm) of clearance around all sides of the freezers and 3-1/2” (89 mm) on the bottom. Model 359 only: Installation of air deflector is required. Failure to allow adequate clearance can reduce the refrigeration capacity of the freezers and possibly cause permanent damage to the compressors.

Electrical Connections

In the United States, this equipment is intended to be installed in accordance with the National Electrical Code (NEC), ANSI/NFPA 70-1987. The purpose of the NEC code is the practical safeguarding of persons and property from hazards arising from the use of electricity. This code contains provisions considered necessary for safety. In all other areas of the world, equipment should be installed in accordance with the existing local codes. Please contact your local authorities.

FOLLOW YOUR LOCAL ELECTRICAL CODES!

S Stationary appliances which are not

equipped with a power cord and a plug or another device to disconnect the appliance from the power source must have an all-pole disconnecting device with a contact gap of at least 3 mm installed in the external installation.

S Appliances that are permanently connected

to fixed wiring and for which leakage currents may exceed 10 mA, particularly when disconnected, not used for long periods, or during initial installation, shall have protective devices such as a GFI to protect against the leakage of current, installed by authorized personnel to the local codes.

S Supply cords used with this unit shall be

oil-resistant, sheathed flexible cable, not lighter than ordinary polychloroprene or other equivalent synthetic elastomer-sheathed cord (Code designation 60245 IEC 57) installed with the proper cord anchorage to relieve conductors from strain, including twisting, at the terminals and protect the insulation of the conductors from abrasion.

Each freezer requires one power supply for each data label on the freezer. Check the data label(s) on the freezer for branch circuit overcurrent protection or fuse, circuit ampacity and other electrical specifications. Refer to the wiring diagram provided inside the control box for proper power connections.

CAUTION: THIS EQUIPMENT MUST BE PROPERLY GROUNDED! FAILURE TO DO SO CAN RESULT IN SEVERE PERSONAL INJURY FROM ELECTRICAL SHOCK!

This unit is provided with an equipotential grounding lug that is to be properly attached to the rear of the frame by the authorized installer. The installation location is marked by the equipotential bonding symbol (5021 of IEC 60417-1) on both the removable panel and the equipment's frame.

110318

Beater Rotation

Beater rotation must be clockwise as

viewed looking into the freezing cylinder. Note: The following procedures must be performed

by an authorized Taylor service technician. To correct the rotation on a three-phase unit,

interchange any two incoming power supply lines at the freezer main terminal block only.

To correct rotation on a single-phase unit, change the leads inside the beater motor. (Follow the diagram printed on the motor.)

Electrical connections are made directly to the terminal block provided in the small junction box located behind the left side panel on the bottom of the frame.

Models 358 & 359To the Installer

Refrigerant

In consideration of our environment, Taylor proudly uses only earth friendly HFC refrigerants. The HFC refrigerant used in this unit is R404A. This refrigerant is generally considered non-toxic and non-flammable, with an Ozone Depleting Potential (ODP) of zero (0).

However, any gas under pressure is potentially hazardous and must be handled with caution.

NEVER fill any refrigerant cylinder completely with liquid. Filling the cylinder to approximately 80% will allow for normal expansion.

Refrigerant liquid sprayed onto the skin may cause serious damage to tissue. Keep eyes and skin protected. If refrigerant burns should occur, flush immediately with cold water. If burns are severe, apply ice packs and contact a physician immediately.

Taylor reminds technicians to be cautious of government laws regarding refrigerant recovery, recycling, and reclaiming systems. If you have any questions regarding these laws, please contact the factory Service Department.

WARNING: R404A refrigerant used in conjunction with polyolester oils is extremely moisture absorbent. When opening a refrigeration system, the maximum time the system is open must not exceed 15 minutes. Cap all open tubing to prevent humid air or water from being absorbed by the oil.

Models 358 & 359 To the Installer

Section 2 To the Operator

Your freezers have been carefully engineered and manufactured to give you dependable operation. These units, when properly operated and cared for, will produce a consistent quality product. Like all mechanical products, they will require cleaning and maintenance. A minimum amount of care and attention is necessary if the operating procedures outlined in this manual are followed closely.

This Operator's Manual should be read before operating or performing any maintenance on your equipment.

Your Taylor freezer will NOT eventually compensate and correct for any errors during the set-up or filling operations. Thus, the initial assembly and priming procedures are of extreme importance. It is strongly recommended that all personnel responsible for the equipment's operation study these procedures together in order to be properly trained and to make sure that no misunderstandings exist.

In the event you should require technical assistance, please contact your local authorized Taylor Distributor.

Note: Warranty is valid only if the parts are authorized Taylor parts, purchased from an authorized Taylor Distributor, and the required service work is provided by an authorized Taylor service technician. Taylor reserves the right to deny warranty claims on equipment or parts if non-approved parts or refrigerant were installed in the machine, system modifications were performed beyond factory recommendations, or it is determined that the failure was caused by neglect or abuse.

Note: Constant research results in steady improvements; therefore, information in this manual is subject to change without notice.

If the crossed out wheeled bin symbol is affixed to this product, it signifies that this product is compliant with the EU Directive as well as other similar legislation in effect after August 13, 2005. Therefore, it must be collected separately after its use is completed, and cannot be disposed as unsorted municipal waste.

The user is responsible for returning the product to the appropriate collection facility, as specified by your local code.

For additional information regarding applicable local laws, please contact the municipal facility and/or local distributor.

Compressor Warranty Disclaimer

The refrigeration compressors on this machine are warranted for the term indicated on the warranty card accompanying this machine. However, due to the Montreal Protocol and the U.S. Clean Air Act Amendments of 1990, many new refrigerants are being tested and developed, thus seeking their way into the service industry. Some of these new refrigerants are being advertised as drop-in replacements for numerous applications. It should be noted that, in the event of ordinary service to this machine's refrigeration system, only the refrigerant

specified on the affixed data label should be used. The unauthorized use of alternate refrigerants

will void your compressor warranty. It will be the owner's responsibility to make this fact known to any technician he employs.

It should also be noted that Taylor does not warrant the refrigerant used in its equipment. For example, if the refrigerant is lost during the course of ordinary service to this machine, Taylor has no obligation to either supply or provide its replacement either at billable or unbillable terms. Taylor does have the obligation to recommend a suitable replacement if the original refrigerant is banned, obsoleted, or no longer available during the five year warranty of the compressor.

Taylor will continue to monitor the industry and test new alternates as they are being developed. Should a new alternate prove, through our testing, that it would be accepted as a drop-in replacement, then the above disclaimer would become null and void. To find out the current status of an alternate refrigerant as it relates to your compressor warranty, call the local Taylor Distributor or the Taylor Factory. Be prepared to provide the Model/Serial Number of the unit in question.

Models 358 & 359To the Operator

Section 3 Safety

We, at Taylor Company, are concerned about the safety of the operator when he or she comes in contact with the freezer and its parts. Taylor has gone to extreme efforts to design and manufacture built-in safety features to protect both you and the service technician. As an example, warning labels have been attached to the freezer to further point out safety precautions to the operator.

IMPORTANT - Failure to adhere to the following safety precautions may result in severe personal injury or death. Failure to comply with these warnings may damage the machine and its components. Component damage will result in part replacement expense and service repair expense.

DO NOT operate the freezer without

reading this Operator's Manual. Failure to follow this instruction may result in equipment damage, poor freezer performance, health hazards, or personal injury.

Per IEC 60335-1 and its part 2 standards, “This appliance is to be used only by trained personnel. It is not intended for use by children or people with reduced physical, sensory, or mental capabilities, or lack of experience and knowledge, unless given supervision or instruction concerning the use of the appliance by a person responsible for their safety.”

S DO NOT operate the freezer unless it is

properly grounded.

S DO NOT operate the freezer with larger

fuses than specified on the freezer data label.

S All repairs must be performed by an

authorized Taylor service technician. The main power supplies to the machine must be disconnected prior to performing any repairs.

S Cord Connected Units: Only Taylor

authorized service technicians may install a plug on this unit.

S Stationary appliances which are not

S Appliances that are permanently connected

S Supply cords used with this unit shall be

DO NOT use a water jet to clean or rinse the freezer. Failure to follow these instructions may result in serious electrical shock.

Models 358 & 359 Safety

Failure to follow these instructions may result in electrocution. Contact your local authorized Taylor Distributor for service.

S DO NOT allow untrained personnel to

operate this machine.

S DO NOT operate the freezer unless all

service panels and access doors are

restrained with screws.

S DO NOT remove any internal operating

parts (examples: freezer door, beater,

scraper blades, etc.) unless all control

switches are in the OFF position. Failure to follow these instructions may result in severe personal injury to fingers or hands from hazardous moving parts.

This unit has many sharp edges that can

cause severe injuries.

S DO NOT put objects or fingers in the door

spout. This may contaminate the product

and cause severe personal injury from blade

contact.

S USE EXTREME CAUTION when removing

the beater asssembly. The scraper blades

are very sharp.

Cleaning and sanitizing schedules are governed by your state or local regulatory agencies and must be followed accordingly. Please refer to the cleaning section of this manual for the proper procedure to clean this unit.

DO NOT obstruct air intake and discharge openings: Air cooled units require a minimum of 3” (76 mm) of

clearance around all sides of the freezers and 3-1/2” (89 mm) on the bottom. Model 359 only: Installation of air deflector is required. Failure to allow adequate clearance can reduce the refrigeration capacity of the freezers and possibly cause permanent damage to the compressors.

For Indoor Use Only: This unit is designed to operate indoors, under normal ambient temperatures of 70_ -75_F(21_ -24_C). The freezer has successfully performed in high ambient temperatures of 104_F(40_C) at reduced capacities.

This freezer must be placed on a level surface. Failure to comply may result in personal injury or equipment damage.

NOISE LEVEL: Airborne noise emission does not exceed 78 dB(A) when measured at a distance of

1.0 meter from the surface of the machine and at a height of 1.6 meters from the floor.

Models 358 & 359Safety

Section 4 Operator Parts Identification

Model 358

Figure 1

ITEM DESCRIPTION PART NO.

1 COVER A.-HOPPER INSUL X51658 2 TUBE-FEED-NONREVERS 015176-5 3 PANEL-REAR 046021 4 PANEL-SIDE *358* RIGHT 046023-SP1 5 FILTER A.-13 X 16-7/8 X 7/16 046044 6 STUD-NOSE CONE 054748 7 CHANNEL A.-CONTROL X63534 8 CASTER-SWIVEL 3/4 - 10 ST. 021279

Models 358 & 359 Operator Parts Identification

ITEM DESCRIPTION PART NO.

9 SCREW-1/4-20 X 5/8 SLOTTED 005542 10 CASTER-LOCKING SWIVEL 030307 11 PANEL-SERVICE 048267 12 PANA.-DRIP X50879 13 SHIELD-SPLASH 066697 14 TRAY-DRIP 066696 15 PANEL-SIDE *358*LEFT 046022

Model 359

ITEM DESCRIPTION PART NO.

1 PANEL-SIDE-LEFT 065250 2 COVER ASSEMBLY-HOPPER X51658 3 TUBE-FEED-NONREVERSIBLE 015176-5 4 PANEL-REAR 065271 5 FILTER-AIR 18 L X 13.5 H X .70 052779-3 6 CASTER-3”SWIVEL 3/4-10STM 021279 7 PANEL-SIDE-RIGHT 065251 8 DEFLECTOR-AIR 065200

Figure 2

ITEM DESCRIPTION PART NO.

9 SCREW-1/4-20 X 5/8 SLOTTED 005542 10 CASTER-3” SWV 3/4-10 LOCK 030307 11 PANEL-SERVICE FRONT 065268 12 TRAY-DRIP 19-5/8 L X 4-7/8 033812 13 SHIELD-SPLASH-WIRE 033813 14 PANA.-DRIP X50879 15 STUD-NOSE CONE 054748

Models 358 & 359Operator Parts Identification

Beater and Door Assembly

Figure 3

ITEM DESCRIPTION PART NO.

1 SEAL-DRIVE SHAFT 032560 2 SHAFT-BEATER 033235 3 BEATER A.-7 QT. - 1 PIN X46233 4 BEARING-FRONT 013116 5 GASKET-DOOR - 5.177 ID X

5.9380

016672

Models 358 & 359 Operator Parts Identification

ITEM DESCRIPTION PART NO.

6 VALVE A.-DRAW X46028

7 O-RING - 1-1/16 OD x .139 W 020571

8 DOOR-PARTIAL 1 SPOUT X30272-SER

9 NUT-STUD 021508 10 CLIP-SCRAPER BLADE 8.75” 046238 11 BLADE-SCRAPER PLASTIC 046237

Accessories

ITEM DESCRIPTION PART NO.

KIT ASSEMBLY-TUNE UP *358

KIT ASSEMBLY-TUNE UP *359 2 BRUSH-REARBEARING 013071 3 BRUSH-DOUBLEENDED 013072

X46050 X36356

Figure 4

ITEM DESCRIPTION PART NO.

4 BRUSH-DRAWVALVE 014753 5 BRUSH-HOPPER3” x 7” 023316 6 LUBRICANT-TAYLOR 4 OZ. 047518

*7 SANITIZER-STERA-SHEEN SEE NOTE

*Note: A sample container of sanitizer is sent with the unit. For reorders,orderStera Sheen part no. 055492 (100 packs) or Kay-5 part no. 041082 (125 packs).

Models 358 & 359Operator Parts Identification

Section 5 Important: To the Operator

Model 358

Figure 5 Figure 6

Model 359

ITEM DESCRIPTION

1 POWER SWITCH 2 MIXOUT INDICATOR 3 RESET BUTTON

ITEM DESCRIPTION

1 MIXOUT INDICATOR-LEFT SIDE 2 POWERSWITCH-LEFTSIDE 3 MIXOUT INDICATOR-RIGHT SIDE 4 POWERSWITCH-RIGHTSIDE 5 RESET BUTTON

Models 358 & 359 Important: To the Operator

Power Switch

The middle position is “OFF”. The left position is “WASH”, which activates the beater motor only. The right position is “AUTO”, which activates the beater motor and the refrigeration system.

Figure 7

Indicator Light - “Mix Out”

The “MIX OUT” light is located on the front of the machine. When the “MIX OUT” light begins to flash, the mix hopper has been almost completely exhausted and has an insufficient supply of mix to operate the freezer. Only a small amount of mix (less than 1 pint) is left in the hopper.

At this time the “AUTO” mode is locked out and the freezer shuts down, protecting the freezer from costly damage due to a freeze-up. To initiate the refrigeration system, add mix to the mix hopper. The freezer will automatically begin operation.

Reset Button

Note: Do not use metal objects to press

the reset button. Failure to follow this instruction

may result in serious electrical shock. The reset button is located in the left side panel on

the Model 358. The reset buttons are located in the lower front panel on the Model 359. The reset mechanism protects the beater motor from an overload condition. Should an overload occur, the reset mechanism will trip.

To properly reset the freezer, place the power switch in the “OFF” position. Press the reset button firmly. Place the power switch in the “WASH” position and observe the freezer's performance. Open the side access panel to check if the beater motor is turning the drive shaft in a clockwise (from operator end) direction without binding.

If it is turning properly, place the power switch in the “AUTO” position to resume normal operation. If the freezer shuts down again, contact a service technician.

Air Tube

The air tube is designed with a hole on one end. After priming the machine, install the air tube into the mix inlet hole with the hole end down. Every time the draw handle is raised, new mix and air from the hopper will flow down into the freezing cylinder. This will keep the freezing cylinder properly loaded and maintain overrun.

Figure 8

Figure 9

Models 358 & 359Important: To the Operator

Section 6 Operating Procedures

The Model 358 has been selected to show you the pictured step-by-step operating procedures for both models contained in this manual. These models, for practical purposes of operation, are the same.

These models store 20 quarts (18.9 liters) of mix in each hopper. The mix flows by gravity from the hopper to the freezing cylinder through an air tube.

We begin our instructions at the point where we enter the store in the morning and find the parts disassembled and laid out to air dry from the previous night's cleaning.

These opening procedures will show you how to assemble these parts into the freezer, sanitize them, and prime the freezer with fresh mix in preparation to serve your first portion.

Figure 10

If you are disassembling the machine for the first time or need information to get to this starting point in our instructions, turn t o page 19 “Disassembly”, and start there.

Assembly

Note: When lubricating parts, use an approved food

grade lubricant (example: Taylor Lube).

MAKE SURE THE POWER SWITCH IS IN

THE “OFF” POSITION. Failure to do so may cause

injury from hazardous moving parts, or electrocution.

Step 1

Lubricate the groove and shaft portion that comes in contact with the bearing on the beater drive shaft. Slide the seal over the shaft and groove until it snaps into place. DO NOT lubricate the hex end of the drive shaft. Fill the inside portion of the seal with 1/4” more lubricant and lubricate the flat side of the seal that fits onto the rear shell bearing.

Step 2

Install the drive shaft into the freezing cylinder, hex end first, and into the rear shell bearing until the seal fits securely over the rear shell bearing. Engage the hex end firmly into the drive coupling. Be sure the drive shaft fits into the drive coupling without binding.

Figure 11

Models 358 & 359 Operating Procedures

Step 3

Check the scraper blades for any nicks or signs of wear. If any nicks are present, replace both blades. If the blades are in good condition, install the scraper blade clips on the scraper blades. Place the rear scraper blade over the rear holding pin on the beater assembly.

Figure 12

Note: The hole on the scraper blade must fit securely over the pin to prevent costly damage.

Step 4

Holding the rear blade on the beater, slide the beater halfway into the freezing cylinder. Install the front scraper blade over the front holding pin. Slide the beater assembly the rest of the way into the freezing cylinder.

Step 5

Make sure the beater assembly is in position over the drive shaft. Turn the beater slightly to be certain the beater is properly seated. When in position, the beater will not protrude beyond the front of the freezing cylinder.

Step 6

Slide the two o-rings into the grooves on the draw valve and lubricate.

Figure 14

Step 7

Lubricate the inside of the freezer door spout, top and bottom, and insert the draw valve into the freezer door from the top (“THIS END UP”).

Figure 13

Figure 15

Models 358 & 359Operating Procedures

Step 8

Place the freezer door gasket into the groove on the back of the freezer door. Slide the white plastic front bearing over the baffle rod onto the bearing hub, making certain the flanged end of the bearing is resting against the freezer door. DO NOT LUBRICATE THE GASKET OR THE FRONT BEARING.

Figure 16

Step 9

Insert the baffle rod through the opening in the beater and set the door flush with the freezing cylinder. With the door seated on the freezer studs, install the handscrews. Tighten the handscrews equally in a criss-cross pattern to insure the door is snug.

Step 10

Lay the air tube in the bottom of the mix hopper for sanitizing.

Figure 18

Step 11

Slide the drive shaft drip pan into the hole in the front panel.

Figure 17

Figure 19

Repeat Steps 1 through 11 for the other side of the freezer on the Model 359.

Step 12

Install the front drip tray and splash shield under the door spout.

Figure 20

Models 358 & 359 Operating Procedures

Sanitizing

Step 1

Prepare an approved 100 PPM sanitizing solution (examples: 2-1/2 gal. [9.5 liters] of Kay-5R or 2 gal. [7.6 liters] of Stera-SheenR). USE WARM WATER AND FOLLOW THE MANUFACTURER'S SPECIFICATIONS.

Step 2

Pour the sanitizing solution into the hopper and allow it to flow into the freezing cylinder.

Figure 21

Step 4

Place the power switch in the “WASH” position. This will cause the sanitizing solution in the freezing cylinder to be agitated. Allow it to agitate for five minutes.

Figure 23

Step 5

Place an empty pail beneath the door spout and raise the draw handle. Draw off all the sanitizing solution. When the sanitizer stops flowing from the door spout, lower the draw handle and place the power switch in the “OFF” position.

Step 3

While the solution is flowing into the freezing cylinder, brush clean the mix hopper. In cleaning the hopper, take particular care in brushing the mix level sensing probe, the mix inlet hole and the air tube.

Figure 22

Figure 24

Note: You have just sanitized the freezer.

Be sure your hands are sanitized before going on

in these instructions.

Models 358 & 359Operating Procedures

Step 6

Stand the air tube in the corner of the mix hopper.

Figure 25

Repeat Steps 1 through 6 for the other side of the freezer on the Model 359.

Step 2

When the mix stops bubbling down into the freezing cylinder, install the air tube in the mix inlet hole.

Figure 27

Priming

Step 1

With a pail beneath the door spout, raise the draw handle. Pour two gallons (7.6 liters) of fresh mix into the mix hopper and allow it to flow into the freezing cylinder. This will force out any remaining sanitizing solution. When full strength mix is flowing from the door spout, lower the draw handle.

Note: Use only fresh mix when priming the freezer.

Figure 26

Step 3

Place the power switch in the “AUTO” position. Raise the draw switch to activate the refrigeration system. When the unit cycles off, the product will be at serving viscosity.

Figure 28

Step 4

Fill the hopper with fresh mix.

Models 358 & 359 Operating Procedures

Step 5

Place the mix hopper cover in position over the mix hopper.

Figure 29

Note: For additional information regarding the proper use of rerun, see item 5 on page 21.

Note: If local health codes DO NOT permit the use of rerun, the product must be discarded.

Follow the instructions in the previous step, except drain the product into a mix pail and properly discard the mix.

ALWAYS FOLLOW LOCAL HEALTH CODES.

Repeat Steps 1 through 2 for the other side of the

freezer on the Model 359.

Repeat Steps 1 through 5 for the other side of the freezer on the Model 359.

Closing Procedure

To disassemble your unit, the following items will be needed:

S Two cleaning pails S Sanitized NSF approved stainless steel

rerun can(s) with lid(s)

S Necessary brushes (provided with freezer) S Cleaner S Single service towels

Draining Product From the Freezing Cylinder

Step 1

Remove the hopper cover and the air tube. Take them to the sink for cleaning.

Rinsing

Step 1

Pour two gallons (7.6 liters) of cool clean water into the mix hopper. With the brushes provided, scrub the mix hopper, the mix level sensing probe and the mix inlet hole.

Step 2

With a pail beneath the door spout, place the power switch in the “WASH” position and raise the draw handle. Drain all the rinse water from the freezing cylinder and the mix hopper. When the rinse water stops flowing from the door spout, lower the draw handle and place the power switch in the “OFF” position.

Step 2 If local health codes permit the use of rerun,

place a sanitized, NSF approved stainless steel rerun container beneath the door spout. Place the power switch in the “WASH” position. Raise the draw handle and drain the remaining product from the freezing cylinder and the mix hopper. When the flow of product stops, place the power switch in the “OFF” position and lower the draw handle. Place a sanitized lid on the rerun container and place it in the walk-in cooler.

Figure 30

Repeat these procedures until the rinse water being drawn from the freezing cylinder is clear.

Repeat Steps 1 through 2 for the other side of the freezer on the Model 359.

Models 358 & 359Operating Procedures

Cleaning

Disassembly

Step 1

Prepare an approved 100 PPM cleaning solution (examples: 2-1/2 gal. [9.5 liters] of Kay-5R or 2 gal. [7.6 liters] of Stera-SheenR). USE WARM WATER AND FOLLOW THE MANUFACTURER'S SPECIFICATIONS.

Step 2

Pour the cleaning solution into the mix hopper.

Figure 31

MAKE SURE THE POWER SWITCH IS IN

THE “OFF” POSITION. Failure to do so may cause

injury from hazardous moving parts or electrocution.

Step 1

Remove the freezer door, beater, scraper blades, and the drive shaft from the freezing cylinder. Take them to the sink for cleaning.

Repeat for the other side of the freezer on the Model 359.

Step 2

Remove the front drip tray and the splash shield.

Brush Cleaning

Step 1

Prepare a sink with an approved cleaning solution (example: Kay-5R or Stera-SheenR). USE WARM WATER AND FOLLOW THE MANUFACTURER'S SPECIFICATIONS

IMPORTANT: Follow label directions, as too STRONG of a solution can cause parts damage, while too MILD of a solution will not provide adequate cleaning. Make sure all brushes provided with the freezer are available for brush cleaning.

Step 3

While the solution is flowing into the freezing cylinder, brush clean the mix hopper, the mix level sensing probe and the mix inlet hole.

Step 4

Place the power switch in the “WASH” position. This will cause the cleaning solution in the freezing cylinder to be agitated.

Step 5

Place an empty pail beneath the door spout and raise the draw handle. Draw off all the cleaning solution. When the solution stops flowing from the door spout, lower the draw handle and place the power switch in the “OFF” position.

Repeat Steps 1 through 5 for the other side of the freezer on the Model 359.

Step 2

Remove the seal(s) from the drive shaft(s).

Step 3

Remove the scraper blade clips from the scraper blades.

Step 4

From the freezer door(s) remove:

S gasket(s) S front bearing(s) S draw valve(s)

Remove all o-rings. Note: To remove o-rings, use a single service towel

to grasp the o-ring. Apply pressure in an upward direction until the o-ring pops out of its groove. With the other hand, push the top of the o-ring forward. It will roll out of the groove and can be easily removed. If there is more than one o-ring to be removed, always remove the rear o-ring first. This will allow the o-ring to slide over the forward rings without falling into the open grooves.

Models 358 & 359 Operating Procedures

Step 5

Return to the freezer with a small amount of cleaning solution. With the black bristle brush, brush clean the rear shell bearing(s) at the back of the freezing cylinder(s).

Figure 32

Step 6

Remove the drive shaft drip pan(s) from the front panel and take to the sink for cleaning.

Note: If the drive shaft drip pan is filled with an excessive amount of mix, refer to the Troubleshooting Guide.

Step 7

Thoroughly brush clean all disassembled parts in the cleaning solution, making sure all lubricant and mix film is removed. Take particular care to brush clean the draw valve core in the freezer door. Place all the cleaned parts on a clean dry surface to air dry overnight.

Step 8

Wipe clean all exterior surfaces of the freezer.

Models 358 & 359Operating Procedures

Section 7 Important: Operator Checklist

During Cleaning and Sanitizing

ALWAYS FOLLOW LOCAL HEALTH CODES.

Cleaning and sanitizing schedules are governed by federal, state, or local regulatory agencies, and must be followed accordingly. If the unit has a “Standby mode”, it must not be used in lieu of proper cleaning and sanitizing procedures and frequencies set forth by the ruling health authority. The following check points should be stressed during the cleaning and sanitizing operations.

CLEANING AND SANITIZING MUST BE

PERFORMED DAILY.

Troubleshooting Bacterial Count

j 5. IF LOCAL HEALTH CODES PERMIT THE

USE OF RERUN, make sure the mix rerun is stored in a sanitized, covered, NSF approved stainless steel rerun container and used the following day. DO NOT prime the machine with rerun. When using rerun, skim off the foam and discard; then mix the rerun with fresh mix in a ratio of 50/50 during the day's operation.

j 6. On a designated day of the week, run the mix

as low as feasible and discard after closing. This will break the rerun cycle and reduce the possibility of high bacteria and coliform counts.

j 7. Properly prepare the cleaning and sanitizing

solutions. Read and follow the label directions carefully. Too strong of a solution may damage the parts and too weak of a solution will not do an adequate job of cleaning or sanitizing.

j 8. The temperature of the mix in the mix hopper

and walk-in cooler should be below 40_F. (4.4_C.).

j 1. Thoroughly clean and sanitize the machine

regularly, including complete disassembly and brush cleaning.

j 2. Use all brushes supplied for thorough

cleaning. The brushes are specially designed to reach all mix passageways.

j 3. Use the white bristle brush to clean the mix

inlet hole which extends from the mix hopper down to the rear of the freezing cylinder.

j 4. Use the black bristle brush to thoroughly

clean the rear shell bearing located at the rear of the freezing cylinder. Be sure there is a generous amount of cleaning solution on the brush.

Regular Maintenance Checks

j 1. Replace scraper blades that are nicked or

damaged. Before installing the beater, be certain that the scraper blades are properly attached.

j 2. Check the rear shell bearing for signs of wear

(excessive mix leakage in the drive shaft drip pan) and be certain it is properly cleaned.

j 3. Using a screwdriver and cloth towel, keep the

rear shell bearing and the female hex drive socket clean and free of lubricant and mix deposits.

Models 358 & 359 Important: Operator Checklist

j 4. Dispose of o-rings and seals if they are worn,

torn, or fit too loosely, and replace with new ones.

j 5. Follow all lubricating procedures as outlined in

“Assembly”.

j 6. If your machine is air cooled, check the

condenser for accumulation of dirt and lint. Dirty condensers will reduce the efficiency and capacity of the machine. Condensers should be cleaned monthly with a soft brush.

Never use screwdrivers or other metal probes to clean between the fins.

Winter Storage

If the place of business is to be closed during the winter months, it is important to protect the freezer by following certain precautions, particularly if the building is subject to freezing conditions.

Disconnect the freezer from the main power source to prevent possible electrical damage.

On water cooled freezers, disconnect the water supply. Use air pressure to blow out any water remaining in the condensers. This is extremely important. Failure to follow this procedure may cause severe and costly damage to the refrigeration system.

Note: For machines equipped with an air filter, it will be necessary to vacuum clean the filters on a monthly schedule.

CAUTION: Always disconnect electrical power prior to cleaning the condenser. Failure to follow this instruction may result in electrocution.

Your local Taylor Distributor can perform this service for you.

Wrap detachable parts of the freezer such as beater, blades, drive shaft, and freezer door. Place these parts in a protected, dry place. Rubber trim parts and gaskets can be protected by wrapping them with moisture-proof paper. All parts should be thoroughly cleaned of dried mix or lubrication, which attract mice and other vermin.

Models 358 & 359Important: Operator Checklist

Section 8 Troubleshooting Guide

PROBLEM PROBABLE CAUSE REMEDY PAGE

REF.

1. No product is being dispensed with draw valve

a. Beater motor is out on

reset.

a. Reset the freezer.

open and machine in the “AUTO” mode.

b. Circuit breaker off or

blown fuse.

c. Inadequate mix in the mix

hopper.

d. Freeze-up in mix inlet

hole.

b. Turn breaker on or

replace fuse.

c. Fill the mix hopper with

mix.

d. Contact an authorized

service technician to adjust the mix hopper temperature.

e. Beater is rotating

counterclockwise (from operator end).

e. Contact an authorized

service technician to correct rotation to clockwise.

2. The product is too stiff. a. Inadequate mix in hopper. a. Fill the hopper with mix.

b. Thermistor control is set

too cold.

b. Contact an authorized

service technician.

3. The product is too soft. a. Worn scraper blades. a. Replace regularly.

b. Not enough air space is

around the unit.

b. Allow for adequate air flow

across the condenser.

- -

4. The mix in the mix hopper is too cold.

5. The mix in the mix hopper is too warm.

c. Dirty condenser. c. Clean monthly. d. Out-of-date mix. d. Use only fresh mix. e. Thermistor control is set

too warm.

a. The temperature is out of

adjustment.

a. The mix hopper cover is

not in position.

b. Warm mix was placed in

the hopper.

e. Contact an authorized

service technician.

a. Contact an authorized

service technician.

a. Place the hopper cover in

position.

b. Mix should be below 40_F

(4.4_C) when placed in hopper.

c. The temperature is out of

adjustment.

Models 358 & 359 Troubleshooting Guide

c. Contact an authorized

service technician.

- -

PROBLEM PROBABLE CAUSE REMEDY PAGE

REF.

6. The drive shaft is stuck in the drive coupling.

7. The freezing cylinder walls are scored.

8. Excessive mix leakage into the drive shaft drip pan.

9. Excessive mix leakage from the door spout.

a. Mix and lubricant collected

in the drive coupling.

b. Rounded corners of drive

shaft, coupling or both.

a. Brush clean the rear shell

bearing area regularly.

b. Call an authorized service

technician to correct the cause and replace the necessary components. Do not lubricate the hex end of the drive shaft.

a. Missing or worn front

bearing on freezer door.

b. The beater assembly is

bent.

a. Install or replace the front

bearing.

b. Call an authorized service

technician to repair or replace the beater and to correct the cause of insufficient mix in freezing cylinder.

a. Missing or worn drive

a. Install or replace regularly.

shaft seal on drive shaft.

b. The drive shaft seal is

b. Install the seal properly.

installed inside out. c. Lack of lubrication. c. Lubricate properly. d. Worn rear shell bearing. d. Contact an authorized

service technician to replace the rear shell bearing.

a. Missing or worn draw

a. Install or replace regularly.

valve o-rings.

- -

15 / 26

- -

13 / 26

- -

14 / 26

10. No freezer operation after placing the unit in “AUTO”.

b. Inadequate lubrication of

b. Lubricate properly.

draw valve o-rings.

c. Wrong type of lubricant is

being used (example:

c. Use proper lubricant

(example: Taylor Lube).

petroleum base lubricant).

a. The unit is unplugged. a. Plug into wall receptacle.

b.Thereisnomixinthemix

hopper.

c. Circuit breaker off or

blown fuse.

b. Fill the mix hopper with

mix.

c. Turn breaker on or

replace fuse.

d. Beater motor out on reset. d. Reset the freezer.

- -

Models 358 & 359Troubleshooting Guide

PROBLEM PROBABLE CAUSE REMEDY PAGE

REF.

11. Product is not feeding into the freezing cylinder.

a. Inadequate level of mix in

the mix hopper.

b. Mix inlet hole frozen up. b. Mix hopper temperature

a. Fill the mix hopper with

mix.

needs adjustment. Contact an authorized service technician.

- -

Models 358 & 359 Troubleshooting Guide

Section 9 Parts Replacement Schedule

PART

DESCRIPTION

EVERY 3 MONTHS

EVERY 4 MONTHS

EVERY 6 MONTHS

ANNUALLY 358

QTY.

359

QTY.

Drive Shaft Seal X 1 2 Scraper Blade X 2 4 Freezer Door Gasket X 1 2 Front Bearing X 1 2 Draw Valve O-Ring X 2 4 Black Bristle Brush, 1” x 2” Inspect & Replace

Minimum 1 1

if Necessary

Double Ended Brush Inspect & Replace

Minimum 1 1

if Necessary

White Bristle Brush, 1” x 2” Inspect & Replace

Minimum 1 1

if Necessary

White Bristle Brush, 3” x 7” Inspect & Replace

Minimum 1 1

if Necessary

Models 358 & 359Parts Replacement Schedule

Section 10 Parts List

REMARKS

WARR.

CLASS

QTY.

DESCRIPTION PART

359

358

NUMBER

+BRACKET-IDLER ARM 045912 1 2 103

ARM A.-IDLER *356* X64892 1 2 103

Models 358 & 359

+BOLT-IDLER PULLEY *358* 046039 1 2 103

+SCREW-SHOULDER 046048 1 2 000

+SPRING-EXTENSION.500X.063X4.00 046046 1 2 103

BEARING-FRONT 013116 1 2 000

BEARING-REAR SHELL *NICK.PLATE 031324 1 2 000

+GUIDE-DRIP SEAL 028992 1 2 000

+NUT-BRASS BEARING 028991 1 2 000

+O-RING-1/2OD X .070W 024278 2 4 000

+WASHER-BEARING LOCK 012864 1 2 000

BOOT-CAPACITOR-INSULATING 031314 1 000

CAPACITOR-RUN 7.5UF/370V 034749 1 103

MOTOR-FAN 208-230V 50/60 HZ 053481-27 1 103

+BLADE-SCRAPER-PLASTIC 9-13/16L 046237 2 4 000

+CLIP-SCRAPER BLADE*8.75 INCH* 046238 2 4 103

BEARING-UNIT REAR 025629 1 2 103 DIRECT DRIVE UNIT

BEATER A.-7QT-1 PIN-SUPPORT X46233 1 2 103

BELT-POLY V-450J10 044056 1 2 000

BLOCK-TERMINAL 2P L1,L2 039422 1 103 208-230V 60HZ 1PH

BLOCK-TERMINAL 3P-L1,L2,L3 039423 1 1 103 208-230V 60HZ 3PH

BLOWER A. X53725-27 1 103

SCREEN-BLOWER 053729 1 103

BRUSH-DOUBLE ENDED-PUMP&FEED 013072 1 1 000

BRUSH-DRAW VALVE 1-1/2"OD X 3 " 014753 1 1 000

BRUSH-MIX PUMP BODY-3"X7"WHITE 023316 1 1 000

BRUSH-REAR BRG 1IN.DX2IN.LGX14 013071 1 1 000

Parts List

BUSHING-SNAP 11/16 ID X 7/8OD 010548 1 8 103

110318

BUSHING-PANEL 013289 4 103

CAPACITOR-RUN- 4UF-440V 051785 1 103 CONDENSER FAN

QTY.

PART

CLASS

359

358

NUMBER

DESCRIPTION REMARKSWARR.

+O-RING-1-1/16 OD X.139W 020571 2 4 000

+CAPACITOR-START-189-227UF/250 V 053106 1 103 208-230V 60HZ 1PH

+CAPACITOR-RUN- 35UF/440V 048132 1 103 208-230V 60HZ 1PH

+RELAY-START-COMPRESSOR 051957-27 1 103 208-230V 60HZ 1PH

+KIT-MOUNTING COMPRESSOR 052197 1 000

CAPACITOR-RUN 7.5UF/370V 034749 1 103 BLOWER FAN

CASTER-LOCKING SWIVEL 3 IN. 030307 2 2 103

CASTER-SWV-3/4-10 ST. 3IN WHL 021279 2 2 103

COMPRESSOR CS18K6E 052397-27E 1 512 208-230V 60HZ 1PH - K0078823/UP COPELAWELD

Parts List Models 358 & 359

COMPRESSOR CS18K6E-TF5-238 052397-33 1 2 512 208-230V 60HZ 3PH

CONDENSER-AC-12LX18HX4.3-5ROW 019558 1 103

CONDENSER-AC 12LX18HX3.12T-5RW 055813-1 1 103

CONDENSER-AC 12LX18HX3.12T-5RW 055813-2 1 103

CONTROL-THERMISTOR-MIXLVL X63019-SER 1 2 103

COVER A.-HOPPER*358* X51658 1 2 103

DECAL-DEC-TAYLOR 358 056569 1 000

DECAL-DEC-TAYLOR 021872 1 000

DECAL-INST-CLNHPR 019029 1 1 000

DECAL-TROUBLESHOOTING 038374 1 000

DIAGRAM-WIRING *358* 063532-27 1 000 208-230V 60HZ 1PH

DIAGRAM-WIRING *358* 063532-33 1 000 208-230V 60HZ 3PH

DIAGRAM-WIRING *359* 065467-33 1 000

DOOR A.-1 SPT-7 QT X30272-SER 1 2 103

+GASKET-DOOR 5.177ID X 5.938OD 016672 1 2 000

+VALVE A.-DRAW *358* X46028 1 2 103

DRYER-FILTER-HP62-3/8 X 1/4S 048901 1 2 000

ELEMENT-HEATER 014174- 1 000 NO LONGER USED AFTER J5050000

FASTENER-CLIP 1/4-20 U-TYPE 045865 8 18 000

FILTER-AIR13X16-7/8X7/16 046044 1 000

FILTER-AIR-18.00LX13.50HX.70W 052779-3 2 000

QTY.

PART

CLASS

359

358

NUMBER

DESCRIPTION REMARKSWARR.

FILTER-CORCOM 2VR1 032567 1 2 000

GUIDE A.-DRIP PAN*358*W/SHROUD X68531 1 000 208-230V 60HZ 1PH

GUIDE A.-DRIP PAN *358*359 X45985 1 2 103 208-230V 60HZ 3PH

Models 358 & 359

HARNESS A.-WIRE *358*BTR MTR X58286 1 103 208-230V 60HZ 1PH

HARNESS-WIRE-POWER*358* 059448-27 1 103 208-230V 60HZ 1PH

HARNESS-WIRE-POWER*358* 059448-33G 1 103 208-230V 60HZ 3PH

HARNESS-WIRE *359* COMPR 065506-G 2 103

HARNESS-WIRE *359* BTR MTR 065507 2 103

HARNESS-WIRE *359* CTRL BX/CHN 065508 2 103

HARNESS-WIRE *359* MAIN POWER 065509 1 103

HARNESS-WIRE *359* BLOWER 065512 1 103

KIT A.-WENDY'S*358*SPACER&GRIP X51432 1 103 DRAW SWITCH ASSEMBLY

KIT A.-TUNE UP*358* X46050 1 000

BEARING-FRONT 013116 1 000

GASKET-DOOR 5.177ID X 5.938OD 016672 1 000

O-RING-.643 OD X .077W 018572 2 000

O-RING-1-1/16 OD X.139W 020571 2 000

SEAL-DRIVE SHAFT 032560 1 000

TOOL- 0-RING REMOVAL 048260-WHT 1 000

KIT A.-TUNE UP X36356 1 000

BEARING-FRONT 013116 2 000

GASKET-DOOR 5.177ID X 5.938O 016672 2 000

O-RING-.643 OD X .077W 018572 4 000

O-RING-1-1/16 OD X.139W 020571 4 000

SEAL-DRIVE SHAFT 032560 2 000

TOOL-O-RING REMOVAL-FREEZER 048260-WHT 1 000

LABEL-3PH MTR PROT/1PH C- 025949 1 1 000 208-230V 60HZ 3PH

LABEL-CK MTR ROTATE-CCW-M 046867 1 1 000 208-230V 60HZ 3PH

Parts List

LABEL-DOOR-MOVE PART 032749 1 1 000

LABEL-SW-WASH/OFF/AUTO-SYMBOL 014502 1 2 000

QTY.

PART

CLASS

359

358

NUMBER

DESCRIPTION REMARKSWARR.

+FAN-5 BLADE 12" PUSH 26DEG CCW 029771 1 103

+CAPACITOR-RUN 7.5UF/370V 034749 1 103

LABEL-WARN-CONDENSER-SHARP 059287 1 3 000

LABEL-WARN-COVER 051433 5 5 000

LIGHT-AMBER 075724 1 2 103

LUBRICANT-TAYLOR 4 OZ. 047518 1 1 000

MAN-OPER 358/359 056788-M 1 1 000

MOTOR-1.5 HP 021522-27 1 212 208-230V 60HZ 1PH

MOTOR-1.5 HP 021522-33 1 2 212 208-230V 60HZ 3PH

MOTOR-FAN 80 WATT 1550 RPM CW 051744-27 1 103

MOTOR-FAN 208-230V 50/60 HZ 053481-27 1 103

NUT-STUD *GENERAL USAGE* 021508 4 8 103 HANDSCREWS

PAN A.-DRIP *358* X50879 1 2 103

PANEL A.-FRONT *358* X45987 1 103

PANEL-REAR *358* 046021 1 103

PANEL-SERVICE *358* 048267 1 103

PANEL-SIDE *358*LEFT 046022 1 103

PANEL-SIDE-RIGHT *358*AC 046023-SP1 1 103

PANEL A.-FRONT *359* X65223 1 103

PANEL-REAR *359* 065271 1 103

PANEL-SERVICE FRONT *359* 065268 1 103

PANEL-SIDE-LEFT *359* 065250 1 103

PANEL-SIDE-RIGHT *359* 065251 1 103

PLATE-DEC-358 046010 1 103

PLATE-DEC *359* 065276 1 103

PROBEA.-MIXOUT-SQUAREHOLE X46024 1 2 103

PROBE-THERMISTOR-BARREL-2%TOL 038061-BLK 1 2 103

PULLEY-10J- 1.125PD-5/8BORE 028857 1 2 103 BEATER MOTOR

PULLEY-10J-11"PD-5/8BORE 025570 1 2 103 GEAR

PULLEY-IDLER 3.00PD X 1.49" 054826 1 2 103

Parts List Models 358 & 359

QTY.

PART

CLASS

359

358

NUMBER

DESCRIPTION REMARKSWARR.

+BOLT-IDLER PULLEY *358* 046039 1 2 103

RELAY-3 POLE-20A-208/240 50/60 066795-33 1 2 103

RELAY-DPDT-20A-120/240/277V 026581-27 2 103

Models 358 & 359

SANITIZER-STERA SHEEN -GREEN 055492 1 1 000

SHAFT-BEATER 033235 1 2 103

+SEAL-DRIVE SHAFT 032560 1 2 000

SHELL A.-INSULATED *358* X45916-SER 1 512

+STUD-NOSE CONE 054748 4 103

SHELL A.-INSULATED DUAL *359 X68132 1 512

+STUD-NOSE CONE 054748 8 103

SHIELD-SPLASH 066697 1 103

SHIELD-SPLASH-WIRE-19-3/4 L 033813 1 103

STARTER-1 PHASE 6.3 TO 10 AMP 066794-27K 1 103 208-230V 60HZ 1PH

OVERLOAD-THERMAL-1P-6.3/10A 067461-1K 1 103

STARTER-3 PHASE 4 TO 6.5 AMP 066794-33J 1 2 103 208-230V 60HZ 3PH

OVERLOAD-THERMAL-3P-4.0/6.5A 067461-3J 2 103

SWITCH A.-DRAW *358* X51432 1 103

ACTUATOR-SWITCH 032247 1 103

BEARING-SWITCH 054385 2 103

BRACKET-SWITCH *358* 054277 1 103

E-RING 5/16 SS 016422 1 000

INSULATOR-SWITCH1/64 ARMITE 029099 1 000

ROD-SWITCH *350-1-450-1* 029135 1 103

SPRING-COMP.480X.047X2.00 SS 025452 1 103

SWITCH-PLUNGER-SPDT15A125-25 032260 2 103

SWITCH A.-DRAW *359* X65212-SER 2 103

ACTUATOR-SWITCH 032247 2 103

BEARING-SWITCH 054385 4 103

Parts List

BRACKET-SWITCH *358* 054277 1 103

E-RING 5/16 SS 016422 2 000

QTY.

PART

CLASS

359

358

NUMBER

DESCRIPTION REMARKSWARR.

INSULATOR-SWITCH1/64 ARMITE 029099 2 000

ROD-SWITCH *350-1-450-1* 029135 2 103

SPRING-COMP.480X.047X2.00 SS 025452 2 103

SWITCH-PLUNGER-SPDT15A125-25 032260 4 103

Parts List Models 358 & 359

SWITCH-PRESSURE 405 PSI-SOLD 052663 1 2 103 DISCHARGE LINE

GUARD-POWER SWITCH 034830-1 1 2 103 K4013676/UP

SWITCH-TOGGLE-DPDT*ON-OFF-ON 014464 1 2 103 POWER

TRANS.-240V PR1/24V SEC 10 VA 030132-27 1 2 103

TRAY-DRIP 066696 1 103

SWITCH-PRESSURE 440 PSI-SOLDER 048230 1 103 H4102700/UP

SWITCH-PRESSURE 025749 1 103 H4102699/PRIOR

TRAY-DRIP-19-5/8 L X 4-7/8 033812 1 103

TUBE-CAPILLARY .021ID X 9 FT 020059 1 2 103 LINE A.-LIQUID

TUBE-FEED-NON REVERS 1/4 HOLE 015176-5 1 2 103 J7030970/UP

VALVE-ACCESS-1/4MFL X 3/8ODS 053565 2 4 103 ACCESS LINE - DISCHARGE LINES

VALVE-ACCESS 1/4FL X 1/4SOLDER 044404 1 2 103 EPR VALVE

VALVE-EPR 1/4S 022665 1 2 103

+BOOT-EXPANSION VALVE 050900 1 2 000

VALVE-EXP-AUTO-1/4SX1/4 FPT 046365 1 2 103 J4102700/UP

VALVE-ACCESS 1/4FL X 3/8SOLDER 043232 1 103 HEAT EXCHANGER

VALVE-ACCESS-1/4 MFLX1/4 S-90 047016 1 103 USE W/ 047519-27 COMPRESSOR

VALVE-ACCESS-1/4FLX5/16SOLDER 053026 1 103 USE W/ 047519-27F COMPRESSOR

QTY.

PART

CLASS

359

358

NUMBER

DESCRIPTION REMARKSWARR.

WATER COOLED

ACCUMULATOR-COPPER 2"DIA 10" 047062 1 103

ADAPTOR-3/8MP X 1/2 BARB- 011021 1 103

Models 358 & 359

BLOWER-100 CFM 012796-27 1 103

CONDENSER-WC-COAX 048287 1 103

COUPLING-ANCHOR 3/8FPTX1- 046203 1 103

GUARD-BLOWER 022505 1 103

HOSE-RUBBER 1/2 ID X 7/8 OD R50200 5' 000

PANEL-SIDE-RIGHT *358*WC 046023 1 103

VALVE-ACCESS-1/4MFL X 3/8ODS 053565 1 103

SWITCH-PRESSURE 350 PSI-SOLD 048231 1 103

VALVE-WATER 3/8 REG/HEAD 046686 1 103

Parts List

Model 358 063532-27 Rev. 3/11

Model 358 063532-33 Rev. 3/11

Model 359 065467-33 Rev. 3/11

Taylor 358, 359 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
