MANUFACTURER

Manufacturer: Shenzhen NearbyExpress Technology Development Co.,Ltd. Address: Floor 7, Building E, Galaxy World Phase II, Shenzhen, China

HM-AH005_V1.2_EN

USER GUIDE

Model: HM-AH005

Homech Top-Fill

Ultrasonic Cool Mist Humidiﬁer

STATEMENT

SAFETY INSTRUCTIONS

IMPORTANT SAFETY INSTRUCTIONS

BEFORE USING THE HUMIDIFIER

WHEN USING THE HUMIDIFIER

AFTER USING THE HUMIDIFIER

PACKAGE CONTENTS

SPECIFICATIONS

PRODUCT DIAGRAM

OPERATIONS AND FUNCTIONS

Add water

Standby Mode

LED Display

Power On / Off

Mist Level Adjustment

Auto OFF Timer/Auto On Timer

AUTO Mode

LED Display ON / OFF

Low Water Protection

Water Tank Off Place

Memory Function

CLEANING AND MAINTENANCE

Caution

Daily Maintenance

Weekly Maintenance

Scale Removal Instructions

Disinfecting Instructions

End-Of-Season Care and Storage

TROUBLESHOOTING GUIDE

WARRANTY

CONTACT / HOMECH CUSTOMER CARE

CONTENTS

04/05

STATEMENT

Thank you for purchasing a Homech product that has been tested to meet our stringent quality

standards. This product is covered with Homech product and labor warranty for 12 months from the

date of its original purchase.

IMPORTANT SAFETY INSTRUCTIONS

BEFORE USING THIS APPLIANCE READ ALL INSTRUCTIONS AND CAUTIONARY MARKINGS IN

YOUR USER GUIDE AND ON THE APPLIANCE

Please email us with your order ID and problem or issue via support@homech.net, we will respond

within 24 hours.

Please read the User Guide thoroughly. Clean and maintain the product as instructed. If any

abnormalities occur, please refer to the Troubleshooting Guide ﬁrst.

This warranty is void if the defect is caused by accidental damage, misuse, abuse, neglect, improper

repair or alteration by unauthorized persons, or a failure to follow operating instructions provided

with the product including adding essential oils directly into the tank and base. This warranty does

not apply to normal wear and tear or commercial use.

In no event shall liability exceed the purchase price paid by the purchaser of the product. Under no

circumstances shall there be liability for any loss – direct, indirect or incidental – or consequential

damage arising out of, or in connection with the use of the product.

SAFETY INSTRUCTIONS

The humidiﬁer was made with safe and environmental protection materials, it has been certiﬁed

and complied with the requirement of sale regions’ related regulations or laws.

IMPORTANT: Please READ AND SAVE THESE SAFETY INSTRUCTIONS before using the device.

Basic precautions should always be followed to reduce the risk of ﬁre, electrical shock, and injury

to persons or damage to the product.

When using an electrical appliance, basic precautions should always be followed, including

the following:

1. This is an electrical appliance and requires attention when in use. This appliance is not

intended for use by persons (including children) with reduced physical, sensory or mental

capabilities or lack of experience and knowledge, unless they have been given supervision or

instruction concerning use of the appliance by a person responsible for their safety. Children

should always be supervised to ensure that they do not play with the appliance.

2. WARNING: Do not attempt to reﬁll humidiﬁer without ﬁrst unplugging the unit from its

electrical outlet. Failure to heed this warning may cause personal injury. Be sure to unplug the

unit by pulling on the plug and not the cord.

3. WARNING: Do not touch the water in the humidiﬁer when the humidiﬁer is connected into

power supplies. Always turn off and unplug the power cord before cleaning or maintenance.

4. WARNING: The best suitable working environment temperature for the humidiﬁer is 5°C

-40°C (41°F -102°F),and the relative humidity shall NOT excess 80%RH. Run humidiﬁer in an

environment out of this situation may cause damage to the humidiﬁer and damage of

properties.

5. When using the humidiﬁer for the ﬁrst time after being removed from its original box, it is

recommended to place the unit at room temperature for about 30 minutes before operation.

6. Do not use hot water, always use clean water with temperature no higher than 40°C (102°F)

for this humidiﬁer.

7. Use this appliance only for intended household use as described in this manual. Any other use

not recommended by the manufacturer may cause ﬁre, electric shock, or injury to persons.

The use of attachments not recommended or sold by the manufacturer may cause hazards.

8. DO NOT allow the Moisture Outlet to directly face the wall. Moisture could cause damage,

particularly to wall paper.

9. Do not use humidiﬁer in an area where humidity level is in excess of 60%. A humidity level

below 20% can be unhealthy and uncomfortable. The recommended humidity level is between

40%-60%. Excessive humidity in a room can cause water condensation on windows and

some furniture. If this happens, turn the humidiﬁer OFF.

10. NEVER use humidiﬁer in a closed room, particularly where a child may be sleeping, resting, or

playing (a closed room may result in excessive humidity). If moisture forms on the walls,

ﬂoors or windows of the room, turn off the humidiﬁer. The room already has plenty of

humidity and additional moisture may cause damage.

11. This humidiﬁer requires daily maintenance and regular cleaning to prevent the growth of

bacteria. If you do not follow the recommended care and maintenance guidelines, micro-or-

ganisms may be able to grow in the water within the water tank or the base reservoir. You

must routinely follow the cleaning procedures that follow in order to ensure proper, efﬁcient

operation of your humidiﬁer. Proper maintenance and cleaning is essential to the continued

performance of your unit and the avoidance of algae or bacteria build-up. Refer to the

CLEANING instructions provided. Never clean the humidiﬁer in any manner other than as

instructed in this manual.

12. The humidiﬁer should always be unplugged and emptied when not in operation or while being

serviced or cleaned.

13. DO NOT operate your humidiﬁer without the water tank in place or if the unit is empty.

14. NEVER drop or insert any object into any openings of the humidiﬁer.

BEFORE USING THE HUMIDIFIER

1. Please extend the cord and check any signs of damage. Do not use the humidiﬁer if the cord

has been damaged.

2. DO NOT place this humidiﬁer in wet environments.

Please always keep the humidiﬁer out of reach of patients & children & pet.

READ AND SAVE THESE INSTRUCTIONS

30 CM

1. Please always place the unit on a smooth, ﬂat, lint-free, non-metallic, waterproof and level

surface and keep it away from direct sunlight.

2. Always place the unit 2 feet (60 cm) above the ﬂoor, 12 inches (30 cm) away from the wall,

other appliances or wooden furniture.

30 CM

60 CM

WHEN USING THE HUMIDIFIER

1. DO NOT place the humidiﬁer near naked ﬂames and heat sources, such as stove tops, ovens, radiators or computers.

2. DO NOT run cord under carpeting. Do not cover cord with throw rugs, runners or the like. Do not route cord under furniture or appliances. Arrange cord away from trafﬁc area and where it will not be tripped over.

1. DO NOT plug the unit with wet hands.

2. DO NOT use your hand or any other object to cover the nozzle while the unit is on to avoid

damaging the product or causing injury.

1. DO NOT move or tilt the humidiﬁer while it is in operation.

2. DO NOT clean the unit while it is connected to a power source or while it is on.

Humidity

40% 60%

The most comfortable environmental humidity

is between 40%-60%. Please adjust the mist as

needed.

AFTER USING THE HUMIDIFIER

1. Always disconnect from a power source by pulling the plug when not in use.

2. Humidiﬁer requires regular cleaning. Please refer to, and follow the Cleaning and

Maintenance instructions.

PACKAGE CONTENTS

· 1 x Homech Humidiﬁer (Model: HM-AH005)

· 1 x Power Adapter

· 1 x Cleaning Brush

· 1 x Thank You Card

· 1 x User Guide

SPECIFICATIONS

Model

HM-AH005

1. DO NOT clean the humidiﬁer right after turning it off if the humidiﬁer has been working for a

long time. Allow the humidiﬁer to completely cool down before cleaning.

2. DO NOT attempt to repair or adjust any electrical or mechanical functions on this humidiﬁer.

Doing so will void your warranty.

Operating Voltage

Rated Power

Water Tank Capacity

Mist Output

Working Time on a Full Tank

Recommended Room Size

Noise

US/CA: 100-120V~ 50 / 60Hz

23W

4L / 1.06Gal

250 ml/h (High) 180 ml/h (Medium) 100 ml/h (Low)

15~40h

10-30 m²/107-321 ft²

≤28dB

OPERATIONS AND FUNCTIONS

1. Nozzle

2. Tank Cover

3. Water Tank

4. LED Display

5. Control Buttons

6. Base

PRODUCT DIAGRAM

7. DC IN Port

8. Mufﬂer

9. Water Distribution Component

10. Air Outlet

11. Water Reservoir

12. Atomizer

1 2

Add water

1. Remove the tank cover.

2. Fill the tank with ﬁltered or puriﬁed water.

3. Place the tank cover back.

1 3

1. If tap water is too hard, it is recommended to use ﬁltered or distilled water to avoid white

dust. DO NOT use hot water.

2. DO NOT add any essential oils or medicinal tablets into the water tank.

3. DO NOT move the humidiﬁer while the water tank is full of water to avoid leakage or

base overﬁlling.

Standby Mode

• Insert the power adapter into the humidiﬁer, and then connect it to a power source. The unit is in

Standby mode now with the LED display lighting up for 2 seconds.

LED Display

• Shows the current environmental %humidity level (Relative Humidity).

• Shows the set mist level (1, 2, 3) while setting.

• Shows the set time (0 ~ 12H) while setting.

Auto OFF Timer

• When the unit is on, repeatedly press the Timer Button to cycle through 01H -> 02 H -> 03 H ->… -> 12 H -> Timer OFF. The timer will ﬂash to conﬁrm your setting. When time is up, the unit will automatically turn off.

• To quickly skip to the desired time, press and hold the Timer button.

• To cancel Timer setting, keep pressing the Timer button to OFF.

Auto ON Timer:

• When the unit is in Standby mode (connected to an electrical outlet), repeatedly press the Timer Button to set the number of hours you want the unit to start running automatically (01H -> 02 H -> 03 H ->… -> 12 H -> Timer OFF). When time is up, the unit will start running automatically.

• To quickly skip to the desired time, press and hold the Timer button.

• When Auto ON timer is set, pressing the Power Button to turn on the unit will cancel Auto ON timer.

AUTO Mode

• Press the Power Button once to turn the humidiﬁer ON with Auto Mode ON by default.

• When AUTO mode is activated, the humidiﬁer will adjust the mist level automatically to a recommended comfortable and healthy level based on the environmental humidity.

• Once 65% humidity is reached and the humidiﬁer has been operated for more than 5 minutes, the humidiﬁer will shut off automatically. When the environmental humidity is below 60%, the unit will restart working again.

Power On / Off

• Press the Power Button once to turn the humidiﬁer ON with default settings: Auto Mode ON (ﬁrst time power on).

• Press it again to turn the humidiﬁer OFF (Standby Mode).

Mist Level Adjustment

• When the unit is on, repeatedly press the Mist Button to cycle through Low (level 1) -> Medium (level 2) -> High (level 3) -> Auto (AI) Mode. The corresponding mist level will light up on the LED Display.

• When Auto Mode is selected, and (humidity) will light up on the LED Display showing the current humidity.

LED Display ON / OFF

• If no operation is done within 40 seconds, the LED display will turn off automatically.

• To turn the display back on, tap any button (except Power Button) on the control panel to wake it up.

Low Water Protection

• When there is not enough water inside the water reservoir, the humidiﬁer will stop working and Low Water Protection will be activated with ﬂashing for 40 seconds on the display.

Water Tank Off Place

• When the water tank is lifted up, the humidiﬁer will stop working with ﬂashing for 40 seconds on the display.

Memory Function

• If power is not disconnected, the humidiﬁer will always remember your last set mist level once you turn it on again.

CLEANING AND MAINTENANCE

Caution

1. DO NOT submerge the base in water.

2. Make sure water does not enter the base through the air outlet, air inlet,

or the control buttons and LED display.

3. DO NOT wash any part of this humidiﬁer in dish washer which will

MIST +/-

Daily Maintenance

Turn off the humidiﬁer, unplug it from the power source. Drain water from the tank, reservoir

and base.

damage the humidiﬁer and void the warranty.

15-20

minutes

Weekly Maintenance

1. To properly clean your humidiﬁer, we recommend you to remove scale and disinfect the

humidiﬁer separately.

2. DO NOT mix vinegar and bleach solutions together. Do not use more than 1 tsp. of bleach per

gallon of water to avoid damaging your humidiﬁer.

Scale Removal Instructions

1 2

1. Turn off and unplug the humidiﬁer.

2. Remove the water tank from the base and

pour out any remaining water.

3. Fill the water tank half full. Add in 1 teaspoon

of undiluted distilled white vinegar.

4. Place the water tank onto the base. The vinegar solution will enter the water reservoir to loosen

mineral buildup (scale) on the atomizer, water ﬂoater and the bottom of the water tank. Set it still for

15-20 minutes.

5. Water reservoir: Clean all parts of the water reservoir with a soft cloth. For small parts and gaps, clean

with the included cleaning brush to remove any mineral buildup.

6. Water tank: Press both sides of the mufﬂer to pull it out. Clean the mufﬂer with the included cleaning

brush to remove any mineral buildup.

7. Rinse both the water reservoir and water tank until the smell of vinegar (for scale removal) or bleach

solution (for disinfecting, see below) is gone.

Disinfecting Instructions

Disinfecting the humidiﬁer removes any remaining bacteria or mold after cleaning both the water

tank and water reservoir. It is recommended to disinfect your humidiﬁer at least once a week with

regular use as well as before and after storing for long periods of time.

1. Clean the water tank and water reservoir as instructed in the previous section.

2. Fill the water tank half full. Add in ½ tsp of bleach.

3. Allow the solution to soak for at least 30 minutes, but no longer than 1 hour.

4. Pour out the solution and rinse both the water tank and water reservoir under cold water. Allow all

parts to air dry before reassembling.

Troubleshooting Guide

Problem Possible Causes Solution

LED display does not light up

Waterless indicator ﬂashes

Power cord is not properly plugged in.

No power from power outlet. Try another power outlet.

Not enough water inside the water reservoir.

Water tank is lifted up.

Ensure the power adapter is properly plugged in.

Add water into the water tank and then press the Power Button to turn on the mist.

Place the water tank back onto the base.

End-Of-Season Care and Storage

1. Follow the cleaning instructions when the humidiﬁer will not be used for at least one week,

or at the end of the season. Remove any accessories used with the humidiﬁer and allow the

humidiﬁer and accessories to dry completely before storing.

2. DO NOT store with water inside the base, water reservoir, or tank.

3. Pack the unit safely and store in a cool, dry location.

TROUBLESHOOTING GUIDE

1. If the information listed in the troubleshooting guide can’t solve your problem, please email

us at support@homech.net.

2. Failure to keep this unit clean from mineral deposits may affect operation of this unit.

3. Customer failure to follow these instructions may void the warranty.

Not enough water inside the

LED display is on, no mist or little mist is produced

Mist height is low, damping surrounding desk or ﬂoor. Condensation forms around humidiﬁer or on windows and walls

Bad / Strange odor Unit needs to be cleaned.

Strange water noise

Humidiﬁer is getting too hot

water reservoir.

Mist level is set too low. Adjust to the maximum mist.

Mineral buildup on the atomizer. Clean the atomizer as instructed.

Mist level is set too high for the room size.

Air inlet is blocked.

Low indoor temperature leads to liquefaction.

Water is going down to the water reservoir.

Unit works for long period of time.

Add water into the water tank.

1.Check if the room is too humid and adjust to lower mist.

2.Open door and windows, or change to a larger room.

Humidiﬁer should be placed on a hard ﬂat surface, 2 feet above the ﬂoor and 12 inches away from the wall. Point nozzle away from wall or window.

Raise the room temperature to 25°C/77°F.

1.Clean the humidiﬁer as instructed.

2.Leave the empty and opened water tank in a cool place for 12 hours without the tank cap attached.

This is normal while it is working.

Power off and place in a wellventilated place for 10 minutes.

WARRANTY

This product is covered with Homech product and labor warranty for 12 months from the date of its

original purchase. You will be given a warranty extension of 18 months if the product is registered on

our website (www.homech.net).

Any defective part will be, at the discretion of SUNVALLEYTEK INTERNATIONAL INC. , repaired or

replaced at no charge if the appliance has not been tampered with and has been used according to

these printed directions.

If any problems occur, please contact Homech support (support@homech.net) immediately to

launch a warranty claim. Specify model number and your Amazon order number. Our Consumer

Service Representative will respond within 1 business day, advise you how to correct the problem

yourself, or instruct you on how to return the defective unit back to us for repair or replacement.

We can only provide after sales service for products that are sold by Homech or Homech authorized

retailers and distributors. If you have purchased your unit from a different place, please contact your

seller for return and warranty issues.

FCC Compliance

This device complies with Part 18 of the FCC Rules.

This equipment has been tested and found to comply with the limits for a Consumer ISM equipment,

pursuant to part 18 of the FCC Rules. These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment generates uses and can radiate radio

frequency energy and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that interference will not occur in a

particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged to try to correct the interference

by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help

Changes or modiﬁcations not expressly approved by the party responsible for compliance could void the

user's authority to operate the equipment.

CONTACT / HOMECH CUSTOMER CARE

PLEASE CONTACT US BEFORE RETURNING THIS PRODUCT TO THE STORE. EMAIL HOMECH

CUSTOMER CARE FOR PROBLEMS AND QUESTIONS. WE WILL RESPOND WITHIN 1 BUSINESS DAY.

E-mail: support@homech.net

Website: www.homech.net

www.homech.net

尺寸：145*200mm 装订成册材质：封面128克铜版纸内页80克书纸

Model:

HM-AH005

Taotronics DOTR1069 user guide

Specifications and Main Features

Frequently Asked Questions

User Manual
