Swan SR11010BLN, SR11010BN, SR11010CN, SR11010GN, SR11010LN Instruction manual

Retro Topmount

Refrigerator

Installation and User Guide

For model: SR11010 (all colours)

Swan Service Helpline

0845 610 4118

SR11010.indd 1

21/07/2014 10:42

Important Safeguards

•Do not connect your appliance to the electricity supply until all packing and transit protectors have been removed.

•Leave to stand upright for at least 4 hours before switching on to allow compressor oil to settle

•This fridge/freezer must only be used for its intended purpose i.e the storing and freezing of edible foodstuff.

•Do not dispose of the appliance on a fire. Your appliance contains non CFC/HFC natural substances in the cooling system and in the insulation, which are potentially flammable if exposed to fire. Therefore, take care not to damage, the cooling circuit

or pipes of the appliance in transportation and in use. In case of damage do not expose the appliance to fire or potential ignition source and immediately ventilate the room where the appliance is situated.

•We suggest you contact your local authority for disposal

information and facilities available.

•See installation section for information on suitable location.

•On delivery, check to make sure that the product is not damaged and that all the parts and accessories are in perfect condition.

•Ensure that the plug remains readily accessible. Do not use multiple adaptor or extension cables

.

•Failure to observe these instructions may invalidate your right to free service during the guarantee period.

•Keep ventilation openings, in the appliance enclosure or in the builtin structure, clear of obstruction.

WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.

WARNING: Do not use mechanical devices or other

2

SR11010.indd 2

21/07/2014 10:42

Important Safeguards

means to accelerate the defrosting

process, other than those recommended by the manufacturer.

WARNING: Do not damage the refrigerant circuit.

WARNING: Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer.

•We suggest you keep these instructions in a safe place for easy reference.

•This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use

of the appliance by a person responsible for their safety.

•If the supply cord is damaged,

it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.

•The plug must be accessible after the installation.

•Children should be supervised to ensure that they do not play with the appliance.

CAUTION: In order to avoid a hazard due to inadvertent

resetting of the thermal cutout, this appliance must not be supplied through an external switching device, such as a timer, or connected to a circuit that is regularly switched on and off by the utility company

This appliance should only be connected to an earthed,

switched mains socket. Do not use an extension cord with this appliance

3

SR11010.indd 3

21/07/2014 10:42

Your Refrigerator

Freezer section

Freezer shelf

Thermostat & bulb

Service label

Wire wine rack

Refrigerator shelf

Refrigerator shelf

Drain hole

Vegetable drawer

Salad crisper

Dairy & multipurpose guards

CHANGING THE BULB

1.Turn off the refrigerator and disconnect the plug from the outlet.

2.Using a Phillips screwdriver to remove the bulb lens

3.Remove the old bulb by turning it counterclockwise.

4.Replace a new bulb (10W) clockwise making sure you have correctly positioned the bulb.

5.Replace the light cover in original location and click to put in place.

6.Reconnect the refrigerator to the electrical outlet and switch on.

4

SR11010.indd 4

Dairy & multipurpose guards

Dairy & multipurpose guards
