Super Systems 9120 RPS User Manual
M4560 - Model 9120 Redundant Probe System
P/N 13362
9120 Redundant Probe
System (RPS)
USER’S MANUAL
Super Systems Inc.
7205 Edington Drive
Cincinnati, OH 45249
513-772-0060, 800-666-4330
Fax: 513-772-9466
www.supersystems.com
Super Systems Inc. help desk:
1-800-666-4330
M4560 - Model 9120 RPS Page 1 of 11
M4560 - Model 9120 Redundant Probe System
Table of Contents:
Table of Contents: ...............................................................................................................................2
Safety: ...............................................................................................................................................3
Wiring Terminals .................................................................................................................................4
9120 Wiring Terminations ....................................................................................................................4
About the Model 9120 – RPS: ...............................................................................................................5
Electrical Installation: ...........................................................................................................................5
Model 9120-RPS Function: ...................................................................................................................5
Configuration ......................................................................................................................................6
Configuration – Deviation Band .............................................................................................................6
Configuration – Alarm Delay .................................................................................................................7
Configuration – Probe (Prb) Select Mode ...............................................................................................7
Configuration – Manual Probe (Prb) Select .............................................................................................7
Typical Electrical Drawing: ...................................................................................................................9
Spare Parts: ...................................................................................................................................... 10
Revision History: ............................................................................................................................... 11
M4560 - Model 9120 RPS Page 2 of 11
M4560 - Model 9120 Redundant Probe System
Safety:
Safety Symbols
•
Grounding of the temperature sensor shield
•
temperature sensor while the controller is still powered up. Under these conditions, as additional
protection against electric shock, it is recommend that the shield of the temperature sensor be
grounded.
Installation requirements for EMC
•
installation precautions are necessary. When using relay or triac outputs, it may be necessary to fit a
filter suitable for suppressing the emissions. The filter requirements will depend on the type of load. For
typical applications, it is recommended to use Schaffner FN321 or FN612.
Routing of wires
•
routed away from high-current power cables. This will minimize the pick-up of electrical noise. When it
is impractical to do this, use shielded cables with the shield grounded at one end.
- Various symbols are used on the instrument. They have the following meaning:
Caution (refer to the accompanying documents)
!
- In some installations, it is common practice to replace the
Do not rely on grounding through the framework of the machine
- To ensure compliance with the European EMC directive, certain
- The wiring for the low voltage DC, and particularly the sensor, input should be
.
M4560 - Model 9120 RPS Page 3 of 11
M4560 - Model 9120 Redundant Probe System
Wiring Terminals
9120 Wiring Terminations
M4560 - Model 9120 RPS Page 4 of 11
