Supermicro X9DRW-iF operation manual

X9DRW-3F

X9DRW-iF

USER’S MANUAL

Revision 1.1a

The information in this User’s Manual has been carefully reviewed and is believed to be accurate. The vendor assumes no responsibility for any inaccuracies that may be contained in this document, and makes no commitment to update or to keep current the information in this manual, or to notify any person or organization of the updates. Please Note: For the most up-to-date version of this

manual, please see our Website at www.supermicro.com.

Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product described in this manual at any time and without notice. This product, including software and documentation, is the property of Supermicro and/or its licensors, and is supplied only under a license. Any use or reproduction of this product is not allowed, except as expressly permitted by the terms of said license.

IN NO EVENT WILL SUPER MICRO COMPUTER, INC. BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL, SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, SUPER MICRO COMPUTER, INC. SHALL NOT HAVE LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.

Any disputes arising between the manufacturer and the customer shall be governed by the laws of Santa Clara County in the State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.

FCC Statement: This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the manufacturer’s instruction manual, may cause harmful interference with radio communications. Operation of this equipment in a residential area is likely to cause harmful interference, in which case you will be required to correct the interference at your own expense.

California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate warning applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”.

WARNING: Handling of lead solder materials used in this product may expose you to lead, a chemical known to the State of California to cause birth defects and other reproductive harm.

Manual Revision 1.1a

Release Date: November 12, 2013

Unless you request and receive written permission from Super Micro Computer, Inc., you may not copy any part of this document.

Information in this document is subject to change without notice. Other products and companies referred to herein are trademarks or registered trademarks of their respective companies or mark holders.

Printed in the United States of America

Preface

This manual is written for system integrators, PC technicians and

knowledgeable PC users. It provides information for the installation and use of the

X9DRW-3F/X9DRW-iF motherboard.

About This Motherboard

The Super X9DRW-3F/X9DRW-iF motherboard supports dual Intel E5-2600(v2)

Series Processors (Socket R LGA 2011) and Intel QPI (QuickPath Interface) Tech-

nology (V.1.1), providing point-to-point connections with transfer speeds of up to 8.0

TG/s. With the Intel PCH C606/C602 chipset built in, the X9DRW-3F/X9DRW-iF

motherboard supports Intel® Intelligent Power Node Manager (IPNM), Management

Engine (ME), Digital Media Interface (DMI), PCI-E Gen. 3.0, and up to 1866 MHz

DDR3 memory. These features greatly enhance system performance for 1U/2U

servers. This motherboard is ideal for high-end server platforms. Please refer to our

Website (http://www.supermicro.com) for processor and memory support updates.

Manual Organization

Chapter 1 describes the features, specications and performance of the mother-

board. It also provides detailed information about the Intel PCH C606/C602 chipset.

Chapter 2 provides hardware installation instructions. Read this chapter when in-

stalling the processor, memory modules, and other hardware components into the

system. If you encounter any problems, see Chapter 3, which describes trouble-

shooting procedures for video, memory, and system setup stored in the CMOS.

Chapter 4 includes an introduction to the BIOS, and provides detailed information

on how to congure the CMOS Setup settings.

Appendix A provides BIOS Error Beep Codes.

Appendix B lists software installation instructions.

Preface

iii

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

Conventions Used in the Manual

Pay special attention to the following symbols to install your system properly and

to prevent damage to your system or injury to yourself:

Warning: Important information given to ensure proper system installation or to avoid

damaging the components

Note: Additional information provided to differentiate between various

models or to provides information for proper system setup.

Contacting Supermicro

Headquarters

Address: Super Micro Computer, Inc.

980 Rock Ave.

San Jose, CA 95131 U.S.A.

Tel: +1 (408) 503-8000

Fax: +1 (408) 503-8008

Email: marketing@supermicro.com (General Information)

support@supermicro.com (Technical Support)

Web Site: www.supermicro.com

Europe

Address: Super Micro Computer B.V.

Het Sterrenbeeld 28, 5215 ML

's-Hertogenbosch, The Netherlands

Tel: +31 (0) 73-6400390

Fax: +31 (0) 73-6416525

Email: sales@supermicro.nl (General Information)

support@supermicro.nl (Technical Support)

rma@supermicro.nl (Customer Support)

Preface

Asia-Pacic

Address: Super Micro Computer, Inc.

3F, No. 150, Jian 1st Rd.

Zhonghe Dist., New Taipei City 23511

Taiwan (R.O.C)

Tel: +886-(2) 8226-3990

Fax: +886-(2) 8226-3992

Web Site: www.supermicro.com.tw

Technical Support:

Email: support@supermicro.com.tw

Tel: +886-(2)-8226-3990

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

Table of Contents

Preface

Chapter 1 Overview

1-1 Overview ......................................................................................................... 1-1

1-2 Processor and Chipset Overview...................................................................1-11

1-3 Special Features ........................................................................................... 1-12

1-4 PC Health Monitoring .................................................................................... 1-12

1-5 ACPI Features ............................................................................................... 1-13

1-6 Power Supply ................................................................................................ 1-13

1-7 Super I/O ....................................................................................................... 1-14

1-8 Advanced Power Management ..................................................................... 1-14

Intel® Intelligent Power Node Manager (NM) (Available when the NMView

utility is installed in the system) .................................................................... 1-14

Management Engine (ME) ............................................................................ 1-14

1-9 Introduction to the IPMI Controller ............................................................... 1-14

BMC Subsystem Features ............................................................................ 1-15

Chapter 2 Installation

2-1 Standardized Warning Statements ................................................................. 2-1

Battery Handling .............................................................................................. 2-1

Product Disposal ............................................................................................. 2-3

2-2 Static-Sensitive Devices .................................................................................. 2-4

Precautions ..................................................................................................... 2-4

Unpacking ....................................................................................................... 2-4

2-3 Processor and Heatsink Installation................................................................ 2-5

Installing the LGA2011 Processor .................................................................2-5

Installing a Passive CPU Heatsink ................................................................. 2-9

Removing the Passive Heatsink ..................................................................... 2-9

2-4 Installing and Removing the Memory Modules ............................................. 2-10

Installing & Removing DIMMs ....................................................................... 2-10

Removing Memory Modules ..........................................................................2-11

2-5 Motherboard Installation ................................................................................ 2-17

Tools Needed ................................................................................................ 2-17

Location of Mounting Holes .......................................................................... 2-17

Installing the Motherboard ............................................................................ 2-18

2-6 Control Panel Connectors and I/O Ports ...................................................... 2-19

Back Panel Connectors and I/O Ports .......................................................... 2-19

Back Panel I/O Port Locations and Denitions ........................................... 2-19

Table of Contents

Universal Serial Bus (USB) ...................................................................... 2-20

Serial Ports ............................................................................................... 2-21

Video Connection ..................................................................................... 2-21

Ethernet Ports .......................................................................................... 2-22

Unit Identier Switch ................................................................................ 2-23

Front Control Panel ....................................................................................... 2-24

Front Control Panel Pin Denitions............................................................... 2-25

NMI Button ............................................................................................... 2-25

Power LED .............................................................................................. 2-25

HDD LED .................................................................................................. 2-26

NIC1/NIC2 LED Indicators ....................................................................... 2-26

Overheat (OH)/Fan Fail/PWR Fail/UID LED ............................................ 2-27

Power Fail LED ........................................................................................ 2-27

Reset Button ........................................................................................... 2-28

Power Button ........................................................................................... 2-28

2-7 Connecting Cables ........................................................................................ 2-29

Power Connectors ................................................................................... 2-29

Fan Headers ............................................................................................. 2-30

Chassis Intrusion ..................................................................................... 2-30

Internal Speaker ....................................................................................... 2-31

Overheat/Fan Fail LED ............................................................................ 2-31

Port 80 Header ......................................................................................... 2-32

Standby Power Connector ....................................................................... 2-32

Power SMB (I2C) Connector .................................................................... 2-33

IPMB ......................................................................................................... 2-33

T-SGPIO 1/2 Headers .............................................................................. 2-34

DOM Power Connector ............................................................................ 2-34

Power LED/Speaker ................................................................................. 2-35

2-8 Jumper Settings ............................................................................................ 2-36

Explanation of Jumpers ................................................................................ 2-36

GLAN Enable/Disable .............................................................................. 2-36

CMOS Clear ............................................................................................. 2-37

Watch Dog Enable/Disable ...................................................................... 2-37

VGA Enable .............................................................................................. 2-38

BMC Enable ............................................................................................ 2-38

Management Engine (ME) Recovery ...................................................... 2-39

Manufacture Mode Select ........................................................................ 2-39

2-9 Onboard LED Indicators ............................................................................... 2-41

vii

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

GLAN LEDs .............................................................................................. 2-41

IPMI_Dedicated_LAN LEDs ..................................................................... 2-41

Onboard Power LED ............................................................................... 2-42

Rear UID LED ......................................................................................... 2-42

BMC Heartbeat LED ................................................................................ 2-43

2-10 SATA/SCU Connections ................................................................................ 2-44

SATA/SCU Ports ....................................................................................... 2-44

Chapter 3 Troubleshooting

3-1 Troubleshooting Procedures ........................................................................... 3-1

3-2 Technical Support Procedures ........................................................................ 3-5

3-3 Battery Removal and Installation .................................................................... 3-6

3-4 Frequently Asked Questions ........................................................................... 3-7

3-5 Returning Merchandise for Service................................................................. 3-8

Chapter 4 BIOS

4-1 Introduction ...................................................................................................... 4-1

4-2 Main Setup ...................................................................................................... 4-2

4-3 Advanced Setup Congurations...................................................................... 4-3

4-4 Event Logs .................................................................................................... 4-23

4-5 IPMI ............................................................................................................... 4 -25

4-6 Boot ............................................................................................................... 4-27

4-7 Security ......................................................................................................... 4-28

4-8 Save & Exit ................................................................................................... 4-29

Appendix A BIOS Error Beep Codes

A-1 BIOS Error Beep Codes .................................................................................A-1

Appendix B Software Installation Instructions

B-1 Installing Software Programs ..........................................................................B-1

B-2 Conguring SuperDoctor® III ..........................................................................B-2

viii

Chapter 1: Overview

Chapter 1

Overview

1-1 Overview

Checklist

Congratulations on purchasing your computer motherboard from an acknowledged

leader in the industry. Supermicro boards are designed with the utmost attention to

detail to provide you with the highest standards in quality and performance.

Please check that the following items have all been included with your motherboard.

If anything listed here is damaged or missing, contact your retailer.

The following items are included in the retail box.

• One (1) Supermicro Mainboard

• Two (2) Serial ATA cables (CBL-0044Lx2)

• Two (2) I-Pass to Serial ATA cables (CBL-0097L-03 x2) (X9DRW-3F)

• One (1) I-Pass to Serial ATA cable (CBL-0097L-03) (X9DRW-iF)

•One (1) Quick Reference Guide (MNL-1278-QRG)

Note: For your system to work properly, please follow the links below to

download all necessary drivers/utilities and the user's manual for your

motherboard.

SMCI product manuals: http://www.supermicro.com/support/manuals/

Product Drivers and utilities: ftp://ftp.supermicro.com/

If you have any questions, please contact our support team at support@supermicro.

com.

1-1

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

Motherboard Image

Note: All graphics shown in this manual were based upon the latest PCB

Revision available at the time of publishing of the manual. The motherboard

you've received may or may not look exactly the same as the graphics

shown in this manual.

1-2

Motherboard Layout

I-SATA0

I-SATA3

Chapter 1: Overview

SXB1A

UID

JUIDB

B1B2A1A2B1B2A1

SXB2: CPU2 PCI-E3.0 X16

VGA

LED3

LAN CTRL

LAN1

LAN2

USB2/3

USB0/1

IPMI-LAN

COM1

JPL1

PHY

JPW4

CPU2

CPU1

OPEN 1st

CLOSE 1st

OPEN 1st

P1-DIMMG2

P1-DIMMH2

P1-DIMMG1

P1-DIMMH1

JPW3

P1-DIMMA2

P1-DIMMB2

P1-DIMMA1

P1-DIMMB1

JPI2C1

SP1

JPW2

JPW1

FAN2

FAN1

SXB1B: CPU PCI-E 3.0 x16 + x16

P1-DIMMF1

P1-DIMME1

P1-DIMME2

P1-DIMMC2

P1-DIMMC1

P1-DIMMD1

P1-DIMMD2

FAN3

P1-DIMMF2

CLOSE 1st

JVR1

X9DRW-3F/iF Rev.1.02

JTAG OF CPLD

FAN4

SXB1C

LED1

COM2

JSM2

JSD1

SCU4~7

BMC CTRL

JVRM_I2C1

JPG1

BIOS

JVRM_I2C2

PCH

JBAT1

SCU0~3

SATA/

LED2

JF1

JOH1

JD1

JSM1

FANA

USB4/5

JPB1

JSTBY1

T-SGPIO1

JIPMB1

T-SGPIO2

JI2C1

JI2C2

JLPC1

JP3

JPME2

I-SATA5

JBT1

JPME1

I-SATA4

JWD1

I-SATA2

I-SATA1

SATA/

FANB

JL1

Note 1: Changing BMC log-in information is recommended during initial

system power-on. The default username is ADMIN and password is

ADMIN. For BMC best practices, please refer to: http://www.supermicro.

com/products/nfo/les/IPMI/Best_Practices_BMC_Security.pdf

Note 2: " " indicates the location of "Pin 1".

Note 3: Jumpers/LED Indicators not indicated are for testing only. Also,

components that are not documented in this manual are reserved for

internal use only.

Note 4: Use only the correct type of onboard CMOS battery as specied

by the manufacturer. Do not install the onboard battery upside down to

avoid possible explosion.

1-3

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

SP1

JPW3

JPW2

JPW4

JPB1

FAN2

FAN1

FAN4

FANA

FAN3

JPI2C1

LED3

LED1

COM2

JTAG OF CPLD

SXB1A

SXB1B: CPU PCI-E 3.0 x16 + x16

UID

SXB2: CPU2 PCI-E3.0 X16

LAN2

LAN1

USB2/3

USB0/1

IPMI-LAN

COM1

X9DRW-3F/iF Rev.1.02

VGA

LAN CTRL

BIOS

BMC CTRL

JPW1

PHY

JPL1

B1B2A1A2B1B2A1

SXB1C

JVRM_I2C2

JVRM_I2C1

JPG1

JIPMB1

JSTBY1

JSD1

JD1

JI2C1

JI2C2

JL1

JF1

I-SATA1

I-SATA0

JLPC1

JSM1

JSM2

T-SGPIO1

T-SGPIO2

I-SATA3

I-SATA2

I-SATA5

I-SATA4

JBAT1

JPME2

JWD1

JPME1

JP3

FANB

LED2

SATA/

USB4/5

PCH

JBT1

SCU0~3

SATA/

SCU4~7

JVR1

JUIDB

JOH1

P1-DIMMA1

P1-DIMMA2

P1-DIMMB1

P1-DIMMB2

P1-DIMMD2

P1-DIMMD1

P1-DIMMC2

P1-DIMMF1

P1-DIMME2

P1-DIMME1

P1-DIMMG1

P1-DIMMG2

P1-DIMMH1

P1-DIMMH2

CLOSE 1st

OPEN 1st

CPU1

CLOSE 1st

OPEN 1st

CPU2

P1-DIMMC1

P1-DIMMF2

X9DRW-3F/X9DRW-iF Quick Reference

1-4

Pins 1-2 (Normal)

X9DRW-3F/X9DRW-iF Jumpers

Jumper

JBT1

JI2C1/JI2C2 SMB to PCI-E Slots Open (Normal)

JPB1 BMC Enable Pins 1-2 (Enabled)

JPG1 VGA Enable Pins 1-2 (Enabled)

JPL1 LAN1/LAN2 Enable Pins 1-2 (Enabled)

JPME1 Management Engine (ME)

Note: Components not documented are reserved for internal use only.

Description Default Setting

Clear CMOS See Chapter 2

Recovery Mode Enable

Chapter 1: Overview

JPME2 Management Engine (ME)

Manufacture Mode Select

JWD1 Watch Dog Pins 1-2 (Reset)

X9DRW-3F/X9DRW-iF Connectors

Connectors Description

COM1/COM2 Backplane COM Port1/Front Accessible COM2 Header

FAN1~4,FANA, FANB CPU/System Fan Headers

I-SATA 0~5 Intel PCH SATA Connectors 0~5

JBAT1 Onboard Battery (See Chpt. 3 for Used Battery Disposal)

JD1 Speaker/Power LED Connector (Pins 1~3: PWR LED, Pins

6~7: Onboard Buzzer/Pins 4~7: External Speaker)

JF1 Front Panel Control Header

JIPMB1 4-pin External BMC I2C Header (for an IPMI Card)

JL1 Chassis Intrusion

JLPC1 Port80 Header

JOH1 Overheat/Fan Fail LED

JPI2C1 Power Supply SMBbus I2C Header

JPW1 ATX 24-Pin Power Connector (See Warning on Pg. 1-6)

JPW2/3 12V 8-Pin Power Connectors (See Warning on Pg. 1-6)

JPW4 12V 4-Pin Power Connector (See Warning on Pg. 1-6)

JSD1 SATA DOM (Device_On_Module) Power Connector

JSTBY1 Standby Power Connector

LAN1/2 G-bit Ethernet Ports 1/2

(IPMI) LAN IPMI_Dedicated LAN

SATA/SCU 0~3, 4~7 Serial_Link SATA/SCU Connections 0~3, 4~7 (for X9DRW-

3F), SCU 0~3 (for X9DRW-iF)

SP1 Onboard Buzzer (Internal Speaker)

SXB1A SMC-Proprietary SPEC Slot (See Note 1 below.)

SXB1B SMC-Proprietary PCI-E 3.0 x16 + x16 Add-on Card Slot

(Left) (See Note 1 below.)

SXB1C SMC-Proprietary SPEC Slot (See Note 1 below.)

SXB2 SMC-Proprietary PCI-E 3.0 x16 Add-on Card Slot (Right)

(See Note 2)

Pins 1-2 (Normal)

Note 1: For SXB1A/SXB1B/SXB1C PCI-Exp. slots to work properly, please

use an SMC-proprietary riser card (eg. RSC-RIUW-2E16) in the slots.

Note 2: For SXB2 PCI-Exp. slot to work properly, please use the SMC-

proprietary riser card RSC-R2UW-2EBR or RSC-R1UW-E8R in the slot.

1-5

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

T-SGPI0 1/2 Serial-Link General_Purpose IO Headers 1/2

USB 0/1, 2/3 Back Panel USB 0/1, 2/3 Ports

USB 4/5 Front Panel Accessible USB 4/5 Connections

UID Switch UID (Unit Identier) Switch

VGA1 Backpanel VGA Port 1/Front Panel VGA Port2

X9DRW-3F/X9DRW-iF LED Indicators

LED Description State Status

LED1 BMC Green: Blinking Normal

LED2 Power LED Green: On SB Power On

LED3 UID LED Blue: On Unit Identied

Warning: To avoid damaging your motherboard and components, please use a

power supply that supports a 24-pin, two 8-pin power and one 4-pin connectors. Be

sure to connect the 24-pin and the 8-pin power connectors to your power supply

for adequate power delivery to your system. The 4-pin power connector is optional;

however, Supermicro recommends that this connector also be plugged in for optimal

power delivery.

1-6

Motherboard Features

Chapter 1: Overview

CPU

Memory

Chipset

Expansion

Slots

Graphics

Network

I/O Devices

• Dual Intel

R LGA 2011); each processor supports two full-width

Intel QuickPath Interconnect (QPI) links of up to 8.0

GT/s per QPI link and with data transfer rate of up to

16 GB/s direction peak bandwidth per port.

E5-2600(v2) Series Processors (Socket

Note: For Intel E5-2600(v2) processor support,

BIOS version 3.0 or above is required.

• Integrated memory controller supports up to 1 TB

of Load Reduced (LRDIMM), 512 GB of Registered

(RDIMM) or 128 GB of Unbuffered (UDIMM) ECC/

Non-ECC DDR3 800/1066/1333/1600/1866 MHz

240-pin 4-channel memory modules in 16 DIMM

slots.

Note 1: 1866 MHz memory speed is dependent

on Intel E5-2600v2 CPUs.

Note 2: For the latest memory updates, please

refer to the Tested Memory List posted on our

website (http://www.supermicro.com/products/

motherboard).

• Virtualization: VT-x, VT-d, and VT-c

• Intel® PCH 606/602 Chipset

• One (1) SMC-Proprietary PCI-E 3.0 x16 slot (Right)

(SXB2) (See Note 2 on Page 1-5),

• One (1) SMC-Proprietary PCI-E 3.0 x16 + x16 slot

(Left) (SXB1B) (See Note 1 on Page 1-5),

• Two (2) SMC-Proprietary SPEC slot (SXB1A/

SXB1C) (See Note 1 on Page 1-5.)

• Renesas BMC Video Controller

• One Intel I350 Gigabit Dual-Channel Ethernet Con-

troller for LAN1/LAN2 ports.

• Renesas Baseboard (BMC) Controller (SH7757)

supports IPMI_LAN 2.0

SATA Connections

• SATA Ports Six (6) SATA ports total: two

SATA 3.0 and four SATA 2.0

ports

• RAID (Win-

dows)

RAID 0, 1, 5, 10

1-7

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

• RAID (Linux) RAID 0, 1, 10

SAS/SATA/SCU Connection

• Eight (8) SAS/SATA Connections 0~3, 4~7 (For

X9DRW-3F)

RAID 0, 1, 10

• Four (4) SATA Connections 0~3 (For X9DRW-iF)

RAID 0, 1, 5, 10

IPMI 2.0

• IPMI 2.0 supported by the Renesas BMC

Serial (COM) Port

• Two (2) Fast UART 16550 connections: 9-pin RS-

232 port

Note: COM2 does not support modem func-

tion)

VGA

• Backplane VGA Port 1

Peripheral Devices

USB Devices

• Four (4) USB ports on the rear I/O panel (USB 0/1,

USB 2/3),

• Two (2) Front Panel USB headers (USB 4/5)

BIOS

• 16 MB AMI BIOS

Flash EEPROM

• APM 1.2, PCI 2.3, ACPI 1.0/2.0/3.0/4.0, USB Key-

board, Plug & Play (PnP) and SMBIOS 2.3

Power

Management

• ACPI/ACPM Power Management

• Main switch override mechanism

• Power-on mode for AC power recovery

• Keyboard Wake-up from Soft-off

• Intel

Intelligent Power Node Manager (Available

when the NMView utility is installed in the system)

• Management Engine

PC Health

Monitoring

CPU Monitoring

• Onboard voltage monitors for onboard chipset,

memory, processors, standby power, and other criti-

cal components.

• CPU 6-Phase switching voltage regulator

• CPU/System overheat LED and control

1-8

System Management

Dimensions

Chapter 1: Overview

• CPU Thermal Trip support

• Thermal Monitor 2 (TM2) support

Fan Control

• Fan status monitoring with rmware thermal man-

agement via IPMI 2.0

• Low noise fan speed control

LED Indicators

• System/CPU Overheat LED

• Suspend-state LED

System Management

• UID/Remote UID LED

• PECI (Platform Environment Conguration Interface)

2.0 support

• System resource alert via SuperDoctor® III

• Dual Cooling Zones

• Thermal Monitor 2 (TM2) support

• PECI (Platform-Environment Conguration Interface)

support

• SuperDoctor® III, Watch Dog, NMI

• Chassis Intrusion Header and Detection

• 13.05" (L) x 12.29" (W) (331.47 mm x 312.17 mm)

Note 1: For IPMI Conguration Instructions, please refer to the Embedded

IPMI Conguration User's Guide available @ http://www.supermicro.com/

support/manuals/.

Note 2: Changing BMC log-in information is recommended during initial

system power-on. The default username is ADMIN and password is ADMIN.

For BMC best practices, please refer to: http://www.supermicro.com/products/

nfo/les/IPMI/Best_Practices_BMC_Security.pdf

1-9

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

Right Slot

PCIE 3.0x16

DDR3 DIMM

Lane Reversal & Polarity Inversion

Left Slot

PCIE 3.0x16+x16

JLAN1

P0PE3

I350AM2

RJ45

DDR3 DIMM

x16

UL1

JLAN2

RJ45

PE3 PE2 PE1

x16

CPU Rear

Socket 01

PROCESSOR

P0P0P1

QPI

CPU Front

Socket 00

PROCESSOR

x4 (Lane4~7)

DMI

QPI

DMI

PE1PE2PE3

DMI: Lane Reversal

JSM2(SCU4~7)

JSM1(SCU0~3)

(3F only)

DDR3 RAM

#1#2#1

DDR3 DIMM

DMI PEG [0...3]

SSB

PCH C602/C606

Gen 3 [1...7]

PET8 USB [10,11] LPC

Renesas

BMC

VGA

PHY

CONN

RTL8211E

IPMI LAN

RJ45

DDR3 DIMM

SPI Flash

SATA [0...5]

USB [0...9]

DDR3 DIMM

BIOS

SPI

SATA Gen3

6Gbps

SATA0

SATA1

REAR

TPM Chip

OEM SKU only

Super I/O

W83527

SATA Gen2

3Gbps

SATA2

SATA3

SATA4

REAR

HW Monitor NCT7904D

SATA5

HDR 2X5

System Block Diagram

Notes: This is a general block diagram and may not exactly represent

the features on your motherboard. See the Motherboard Features pages

for the actual specications of each motherboard. This block diagram is

intended for your reference only.

1-10

Chapter 1: Overview

1-2 Processor and Chipset Overview

Built upon the functionality and the capabilities of the Intel E5-2600(v2) Series

Processors (Socket R LGA 2011) and the PCH-C606/C602 chipset, the X9DRW-

3F/X9DRW-iF motherboard provides the performance and feature sets required

for dual_ processor-based, high-performance WIO platforms.

With support of Intel QuickPath interconnect (QPI) Technology, the X9DRW-3F/

X9DRW-iF motherboard offers point-to-point serial interconnect interface with a

transfer speed of up to 8.0 GT/s, providing superb system performance.

The PCH C606/C602 chipset provides extensive IO support, including the follow-

ing functions and capabilities:

•PCI-Express Rev. 2.0 support

•PCI-Express Gen. 3 uplink supported by some SKUs

•ACPI Power Management Logic Support Rev. 3.0b or Rev. 4.0

•USB host interface backplane and front access support

•Intel Rapid Storage Technology supported

•Intel Virtualization Technology for Directed I/O (Intel VT-d) supported

•Intel Trusted Execution Technology supported

•Serial Peripheral Interface (SPI) Supported

•Digital Media Interface (DMI) supported

•Advanced Host Controller Interface (AHCI) supported

Note: For Intel E5-2600(v2) processor support, BIOS version 3.0 or

above is required.

1-11

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

1-3 Special Features

Recovery from AC Power Loss

The Basic I/O System (BIOS) provides a setting that determines how the system will

respond when AC power is lost and then restored to the system. You can choose for

the system to remain powered off (in which case you must press the power switch

to turn it back on), or for it to automatically return to the power-on state. See the

Advanced BIOS Setup section for this setting. The default setting is Last State.

1-4 PC Health Monitoring

This section describes the features of PC health monitoring of the motherboard.

This motherboard has an onboard System_Hardware_Monitor chip that supports

PC health monitoring. An voltage monitor will scan the voltages of onboard chips,

memory modules, processors, battery, and other critical components continuously.

Once a voltage becomes unstable, a warning is given, or an error message is sent

to the screen. The user can adjust the voltage thresholds to dene the sensitivity

of the voltage monitor.

Environmental Temperature Control

A thermal control sensor monitors the CPU temperature in real time and will turn

on the thermal control fan whenever the CPU temperature exceeds a user-dened

threshold. The overheat circuitry runs independently from the CPU. Once it detects

that the CPU temperature is too high, it will automatically turn on the thermal fan

control to prevent the CPU from overheating. The onboard chassis thermal circuitry

can monitor the overall system temperature and alert the user when the chassis

temperature is too high.

Note: To avoid possible system overheating, please be sure to provide

adequate airow to your system.

System Resource Alert

This feature is available when used with SuperDoctor® III in the Windows OS

environment or used with SuperDoctor II in Linux. SuperDoctor is used to notify

the user of certain system events. For example, you can congure SuperDoctor to

provide you with warnings when system temperature, CPU temperature, voltages

and fan speeds go beyond a predened range.

1-12

Chapter 1: Overview

1-5 ACPI Features

ACPI stands for Advanced Conguration and Power Interface. The ACPI specica-

tion denes a exible and abstract hardware interface that provides a standard

way to integrate power management features throughout a PC system, including

hardware, operating system and application software. This enables the system to

automatically turn on and off peripherals such as CD-ROMs, network cards, hard

disk drives and printers.

In addition to enabling operating_system-directed power management, ACPI also

provides a generic system event mechanism for Plug and Play, and an operating

system-independent interface for conguration control. ACPI leverages the Plug and

Play BIOS data structures, while providing a processor architecture-independent

implementation that is compatible with Windows Vista, Windows 2008 and Windows

7 Operating Systems.

Slow Blinking LED for Suspend-State Indicator

When the CPU goes into a suspend state, the chassis power LED will start blinking

to indicate that the CPU is in suspend mode. When the user presses any key, the

CPU will "wake up" and the LED will automatically stop blinking and remain on.

1-6 Power Supply

As with all computer products, a stable power source is necessary for proper and

reliable operation. It is even more important for processors that have high CPU

clock rates.

The X9DRW-3F/X9DRW-iF motherboard accommodates 24-pin ATX power sup-

plies. Although most power supplies generally meet the specications required

by the CPU, some are inadequate. In addition, two 12V 8-pin power connections

(JPW2/JPW3) are also required to ensure adequate power supply to the system.

Your power supply must also supply 1.5A for the Ethernet ports.

Warning: To avoid damaging your motherboard and components, please use a

power supply that supports a 24-pin, two 8-pin power and one 4-pin connectors. Be

sure to connect the 24-pin and the 8-pin power connectors to your power supply

for adequate power delivery to your system. The 4-pin power connector is optional;

however, Supermicro recommends that this connector also be plugged in for optimal

power delivery.

It is strongly recommended that you use a high quality power supply that meets ATX

power supply Specication 2.02 or above. It must also be SSI compliant. (For more

information, please refer to the website at http://www.ssiforum.org/). Additionally, in

areas where noisy power transmission is present, you may choose to install a line

1-13

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

lter to shield the computer from noise. It is recommended that you also install a

power surge protector to help avoid problems caused by power surges.

1-7 Super I/O

The Super I/O provides functions that comply with ACPI (Advanced Conguration

and Power Interface), which includes support of legacy and ACPI power manage-

ment through an SMI or SCI function pin. It also features auto power management

to reduce power consumption.

1-8 Advanced Power Management

The new advanced power management features supported by the motherboard

includes the following:

Intel® Intelligent Power Node Manager (NM) (Available when the NMView utility is installed in the system)

The Intel® Intelligent Power Node Manager (IPNM) provides your system with

real-time thermal control and power management for maximum energy efciency.

Although IPNM Specication Version 1.5/20 is supported by the BMC (Baseboard

Management Controller), your system must also have IPNM-compatible Manage-

ment Engine (ME) rmware installed to use this feature.

Note: Support for IPNM Specication Version 1.5 or Version 2.0 depends

on the power supply used in the system.

Management Engine (ME)

The Management Engine, which is an ARC controller embedded in the PCH, pro-

vides Server Platform Services (SPS) to your system. The services provided by

SPS are different from those provided by the ME on client platforms.

1-9 Introduction to the IPMI Controller

This motherboard incorporates the Renesas IPMI Controller, which integrates a

RISC (Reduced _Instruction_Set_Computing) CPU Core with peripheral capabili-

ties required for a Baseboard Management Controller (BMC). The Renesas IPMI

Controller offers the user a superb solution to manage PC server systems with

great efciency.

The BMC controller supports a 32Kb_instruction cache and a 32Kb_operand cache,

which can be switched between write-back and write-through. The instruction cache

1-14

Chapter 1: Overview

offers a 4-way full-associative instruction TBL (Translation Lookaside Buffer) and a

64-way full-associative shared TBL. The memory management unit, which is embed-

ded on the chip, provides access to 4 Gb virtual address space. In addition, this

controller also supports 32 Kb on-chip SRAM, allowing for faster access which is

especially critical to time-sensitive, high-density/high-performance server platforms.

The BMC supports VGA Graphic Cores for remote video displaying and editing. It

also provides a video data compressor for Keyboard/Video/Mouse (KVM) support if

keyboard/mouse are installed in the system. With two Ethernet controllers built in,

the BMC controller supports USB media hosting, an LPC bus interface, an I2C bus

interface, a NAND Flash Timer Interface and serial communication interfaces. The

BMC controller offers great system enhancement at a low cost.

BMC Subsystem Features

•CPU speed: 576MHz

•System Memory: 256MB

•Flash Memory: 32MB

•Network connections: Two Gigabit connections (One dedicated LAN connection

and one shared LAN with an on-board LAN controller)

•Resolutions:

•Supports 1680 x 1200 resolution at 32 bpp and 75 Hz

•Supports 1680 x 1050 wide screen resolution at 32 bpp and 60 Hz

Note: The term "IPMI controller" and the term "BMC controller" can be

used interchangeably in this section.

1-15

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

Notes

1-16

Chapter 2: Installation

Chapter 2

Installation

2-1 Standardized Warning Statements

The following statements are industry-standard warnings, provided to warn the user

of situations which have the potential for bodily injury. Should you have questions or

experience difculty, contact Supermicro's Technical Support department for assis-

tance. Only certied technicians should attempt to install or congure components.

Read this section in its entirety before installing or conguring components in the

Supermicro chassis.

Battery Handling

Warning!

There is a danger of explosion if the battery is replaced incorrectly. Replace the

battery only with the same or equivalent type recommended by the manufacturer.

Dispose of used batteries according to the manufacturer's instructions

電池の取り扱い

電池交換が正しく行われなかった場合、破裂の危険性があります。交換する電池はメーカーが推奨する型、または同等のものを使用下さい。使用済電池は製造元の指示に従

って処分して下さい。

警告电池更换不当会有爆炸危险。请只使用同类电池或制造商推荐的功能相当的电池更换原有电池。请按制造商的说明处理废旧电池。

警告電池更換不當會有爆炸危險。請使用製造商建議之相同或功能相當的電池更換原有電池。請按照製造商的說明指示處理廢棄舊電池。

Warnung

Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr. Ersetzen Sie die

Batterie nur durch den gleichen oder vom Hersteller empfohlenen Batterietyp.

Entsorgen Sie die benutzten Batterien nach den Anweisungen des Herstellers.

2-1

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

Attention

Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer

que par une pile de type semblable ou équivalent, recommandée par le fabricant.

Jeter les piles usagées conformément aux instructions du fabricant.

¡Advertencia!

Existe peligro de explosión si la batería se reemplaza de manera incorrecta. Re-

emplazar la batería exclusivamente con el mismo tipo o el equivalente recomen-

dado por el fabricante. Desechar las baterías gastadas según las instrucciones

del fabricante.

!הרהזא

תנכס תמייקץוציפ .הניקת אל ךרדב הפלחוהו הדימב הללוסה לש ףילחהל שי

גוסב הללוסה תא מ םאותה תרבחלמומ ןרציתצ.

תוללוסה קוליס תושמושמה עצבל שי .ןרציה תוארוה יפל









경고!

배터리가 올바르게 교체되지 않으면 폭발의 위험이 있습니다. 기존 배터리와 동일 하거나 제조사에서 권장하는 동등한 종류의 배터리로만 교체해야 합니다. 제조사 의 안내에 따라 사용된 배터리를 처리하여 주십시오.

Waarschuwing

Er is ontplofngsgevaar indien de batterij verkeerd vervangen wordt. Vervang de

batterij slechts met hetzelfde of een equivalent type die door de fabrikant aan-

bevolen wordt. Gebruikte batterijen dienen overeenkomstig fabrieksvoorschriften

afgevoerd te worden.

2-2

Chapter 2: Installation

Product Disposal

Warning!

Ultimate disposal of this product should be handled according to all national laws

and regulations.

製品の廃棄

この製品を廃棄処分する場合、国の関係する全ての法律・条例に従い処理する必要が

あります。

警告本产品的废弃处理应根据所有国家的法律和规章进行。

警告本產品的廢棄處理應根據所有國家的法律和規章進行。

Warnung

Die Entsorgung dieses Produkts sollte gemäß allen Bestimmungen und Gesetzen

des Landes erfolgen.

¡Advertencia!

Al deshacerse por completo de este producto debe seguir todas las leyes y regla-

mentos nacionales.

Attention

La mise au rebut ou le recyclage de ce produit sont généralement soumis à des

lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de

l'organisme compétent.

רצומה קוליס

!הרהזא

ו תויחנהל םאתהב תויהל בייח הז רצומ לש יפוס קוליס.הנידמה יקוח

2-3

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

 

경고!

이 제품은 해당 국가의 관련 법규 및 규정에 따라 폐기되어야 합니다.

Waarschuwing

De uiteindelijke verwijdering van dit product dient te geschieden in overeenstemming

met alle nationale wetten en reglementen.

2-2 Static-Sensitive Devices

Electrostatic Discharge (ESD) can damage electronic com ponents. To avoid dam-

aging your system board, it is important to handle it very carefully. The following

measures are generally sufcient to protect your equipment from ESD.

Precautions

•Use a grounded wrist strap designed to prevent static discharge.

•Touch a grounded metal object before removing the board from the antistatic

bag.

•Handle the board by its edges only; do not touch its components, peripheral

chips, memory modules or gold contacts.

•When handling chips or modules, avoid touching their pins.

•Put the motherboard and peripherals back into their antistatic bags when not

in use.

•For grounding purposes, make sure that your system chassis provides excellent

conductivity between the power supply, the case, the mounting fasteners and

the motherboard.

Unpacking

The motherboard is shipped in antistatic packaging to avoid static damage. When

unpacking the board, make sure that the person handling it is static-protected.

2-4

Chapter 2: Installation

2-3 Processor and Heatsink Installation

Warning: When handling the processor package, avoid placing direct pressure on

the label area.

Notes:

•Always connect the power cord last, and always remove it before adding,

removing or changing any hardware components. Make sure that you install

the processor into the CPU socket before you install the CPU heatsink.

•If you buy a CPU separately, make sure that you use an Intel-certied multi-

directional heatsink only.

•Make sure to install the system board into the chassis before you install

the CPU heatsink.

•When receiving a server board without a processor pre-installed, make sure

that the plastic CPU socket cap is in place and none of the socket pins are

bent; otherwise, contact your retailer immediately.

•Refer to the Supermicro website for updates on CPU support.

Installing the LGA2011 Processor

1. There are two load levers on the LGA2011 socket. To open the socket cover,

rst press and release the load lever labeled 'Open 1st'.

WARNING!

OPEN 1st

Press down

labeled 'Open 1st'.

WARNING!

OPEN 1st

Load Lever

2-5

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

1. Press the second load lever labeled 'Close 1st' to release the load plate that

covers the CPU socket from its locking position.

Press down on

Lever 'Close 1st'

WARNING!

OPEN 1st

Load

Pull lever away from

the socket

WARNING!

OPEN 1st

2. With the lever labled 'Close 1st' fully retracted, gently push down on the

'Open 1st' lever to open the load plate. Lift the load plate to open it com-

pletely.

Gently push down to pop the load plate open.

1 2

WARNING!

OPEN 1st

WARNING!

2-6

Chapter 2: Installation

1. Using your thumb and the index nger, remove the ' WARNING' plastic cap

from the socket.

WARNING!

2. Use your thumb and index nger to hold the CPU on its edges. Align the CPU

keys, which are semi-circle cutouts, against the socket keys.

Socket Keys

CPU Keys

3. Once they are aligned, carefully lower the CPU straight down into the socket.

(Do not drop the CPU on the socket. Do not move the CPU horizontally or

vertically. Do not rub the CPU against the surface or against any pins of the

socket to avoid damaging the CPU or the socket.)

Warning: You can only install the

CPU inside the socket in one direc-

tion. Make sure that it is properly

inserted into the CPU socket before

closing the load plate. If it doesn't

close properly, do not force it as it

may damage your CPU. Instead,

open the load plate again and dou-

ble-check that the CPU is aligned

properly.

2-7

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

1. With the CPU inside the socket, inspect the four corners of the CPU to make

sure that the CPU is properly installed.

2. Close the load plate with the CPU inside the socket. Lock the lever labeled

'Close 1st' rst, then lock the lever labeled 'Open 1st'. Use your thumb to

gently push the load levers down to the lever locks.

Gently close

1 2

the load plate.

Push down and lock

lever labeled 'Close 1st'.

OPEN 1st

Lever Lock

OPEN 1st

Push down and

lock lever labeled

'Open 1st'.

OPEN 1st

Lever Lock

2-8

Chapter 2: Installation

Installing a Passive CPU Heatsink

1. Apply the proper amount of thermal grease (with thickness of up to 0.13 mm)

to the heatsink.

2. Place the heatsink on top of the CPU so that the two mounting holes on the

heatsink are aligned with those on the retention mechanism.

3. Insert two push-pins on the sides of the heatsink through the mounting holes

on the motherboard, and turn the push-pins clockwise to lock them.

1U Heatsink (SNK-P0044P) 2U/4U Heatsink (SNK-P0045P)

Notes: For optimized airow, please follow your chassis airow direction

to install the correct CPU heatsink direction. Graphic drawings included

in this manual are for reference only. They might look different from the

components installed in your system.

Removing the Passive Heatsink

Warning: We do not recommend that the CPU or the heatsink be removed. However,

if you do need to remove the heatsink, please follow the instructions below to uninstall

the heatsink to avoid damaging the CPU or other components.

1. Unplug the power cord from the power supply.

2. Press down the push-pin on the heatsink, and turn counter-clock-wise to

loosen it. Repeat the same step to loosen the second push-pin.

3. Hold the heatsink as shown in the picture below, and gently wriggle the heat-

sink to loosen it. (Do not use excessive force when wriggling the heatsink.)

Note: For instructions on CPU/Heatsink installation and removal, please

refer to the CPU/Heatsink Instructions posted on our website at http://www.

supermicro.com/support/manuals/.

2-9

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

4. Once the heatsink is loosened, remove it from the motherboard.

Note: To reinstall the CPU and/or the heatsink, clean the surface of the

CPU and/or the heatsink to get rid of the old thermal grease. Reapply the

proper amount of thermal grease on the surface before reinstalling them

on the motherboard.

2-4 Installing and Removing the Memory Modules

Note: Check Supermicro's website for recommended memory modules.

CAUTION

Exercise extreme care when installing or removing DIMM

modules to prevent any possible damage.

Installing & Removing DIMMs

1. Insert the desired number of DIMMs into the memory slots, starting with

P1-DIMMA1. (For best memory performance, please use the modules of the

same type and speed in the same bank.)

2. Push the release tabs outwards on both ends of the DIMM slot to unlock it.

VGA

LED3

UID

JUIDB

LAN CTRL

SXB1A

B1B2A1A2B1B2A1

SXB2: CPU2 PCI-E3.0 X16

SXB1B: CPU PCI-E 3.0 x16 + x16

P1-DIMMF1

P1-DIMME1

P1-DIMME2

P1-DIMMF2

COM2

USB4/5

JPB1

JSTBY1

T-SGPIO1

JIPMB1

T-SGPIO2

JI2C1

JI2C2

JLPC1

JP3

JPME2

I-SATA5

PCH

JBT1

JPME1

I-SATA4

JWD1

JSD1

I-SATA2

I-SATA3

I-SATA1

SCU4~7

SATA/

I-SATA0

FANB

JSM2

JL1

SXB1C

LED1

X9DRW-3F/iF

P1-DIMMD1

P1-DIMMD2

P1-DIMMC2

P1-DIMMC1

BMC CTRL

JVRM_I2C1

JPG1

BIOS

JVRM_I2C2

JBAT1

SCU0~3

SATA/

LED2

JF1

JOH1

JD1

JSM1

FANA

Rev.1.02

CPU1

CLOSE 1st

JTAG OF CPLD

OPEN 1st

FAN4

JVR1

FAN3

COM1

USB0/1

JPL1

PHY

LAN1

LAN2

USB2/3

JPW4

IPMI-LAN

CPU2

CLOSE 1st

OPEN 1st

P1-DIMMG2

P1-DIMMH2

P1-DIMMG1

P1-DIMMH1

JPW3

P1-DIMMA2

P1-DIMMB2

P1-DIMMA1

P1-DIMMB1

JPI2C1

SP1

JPW2

JPW1

FAN2

FAN1

Release Tabs

Notches

3. Align the DIMM module key with the receptive point on the memory slot.

4. Align the notches on the both ends of the module with the receptive points on

ends of the slot.

5. Use two thumbs together to press the notches of the module straight down

into the slot until the module snaps into place.

6. Press the release tabs to the locked positions to secure the DIMM module

into the slot.

2-10

Chapter 2: Installation

I-SATA0

I-SATA3

Press both notches straight

down into the memory slot at

the same time.

Notes:

1. For proper memory installation, be sure to install a DIMM module into

the P2-DIMMG1 slot before inserting a 4-pin power connector into JPW4

as shown in the graphics below.

2. To provide clearance for proper memory installation, please lock the

release tab at the end of P1-DIMMA1, marked "A", into the locking posi-

tion before inserting a DIMM module into the P2-DIMMH2 slot. Also, lock

the tab, marked "B", before installing a DIMM module into P1-DIMMA1.

VGA

LED3

UID

JUIDB

LAN CTRL

B1B2A1A2B1B2A1

P1-DIMMF2

SXB2: CPU2 PCI-E3.0 X16

P1-DIMMF1

P1-DIMME1

P1-DIMME2

P1-DIMMD1

P1-DIMMD2

P1-DIMMC2

P1-DIMMC1

FAN3

VGA

X9DRW-3F/iF Rev.1.02

CLOSE 1st

JVR1

P1-DIMMF2

LAN CTRL

CLOSE 1st

CPU1

X9DRW-3F/iF Rev.1.02

JVR1

LAN2

OPEN 1st

LAN2

CPU1

OPEN 1st

LAN1

CLOSE 1st

SXB1A

SXB1B: CPU PCI-E 3.0 x16 + x16

COM2

USB4/5

JPB1

JSTBY1

T-SGPIO1

JIPMB1

T-SGPIO2

JI2C1

JI2C2

JLPC1

JP3

JPME2

I-SATA5

PCH

JBT1

JPME1

I-SATA4

JWD1

JSD1

I-SATA2

JBAT1

I-SATA1

SCU0~3

SATA/

SCU4~7

SATA/

FANB

JSM1

JSM2

COM2

BMC

USB4/5

JPB1

CTRL

JSTBY1

T-SGPIO1

JIPMB1

T-SGPIO2

JI2C1

JVRM_I2C1

JPG1

JI2C2

JLPC1

JVRM_I2C2 JP3

JPME2

I-SATA5

PCH

JBT1

JPME1

I-SATA4

JWD1

JSD1

I-SATA2

I-SATA3

JBAT1

I-SATA1

SCU0~3

SATA/

SCU4~7

SATA/

I-SATA0

LED2

JF1

FANB

JOH1

JD1

JSM1

JSM2

JL1

SXB1C

LED1

BMC CTRL

JVRM_I2C1

JPG1

BIOS

JVRM_I2C2

JTAG OF CPLD

LED2

JF1

FAN4

JOH1

JD1

FANA

LED3

UID

JUIDB

SXB1A

B1B2A1A2B1B2A1

SXB2: CPU2 PCI-E3.0 X16

SXB1B: CPU PCI-E 3.0 x16 + x16

P1-DIMMF1

P1-DIMME1

P1-DIMME2

SXB1C

LED1

P1-DIMMD1

P1-DIMMD2

P1-DIMMC2

P1-DIMMC1

BIOS

JTAG OF CPLD

FAN4

FANA

FAN3

COM1

USB0/1

JPL1

PHY

LAN1

USB2/3

JPW4

IPMI-LAN

CPU2

CLOSE 1st

OPEN 1st

P1-DIMMG2

P1-DIMMH2

P1-DIMMG1

P1-DIMMH1

JPW3

P1-DIMMA2

P1-DIMMB2

P1-DIMMA1

P1-DIMMB1

JPI2C1

SP1

JPW2

JPW1

FAN2

FAN1

COM1

USB0/1

JPL1

PHY

USB2/3

JPW4

IPMI-LAN

CPU2

OPEN 1st

P1-DIMMG2

P1-DIMMH2

P1-DIMMG1

P1-DIMMH1

JPW3

P1-DIMMA2

P1-DIMMB2

P1-DIMMA1

P1-DIMMB1

JPI2C1

SP1

JPW2

JPW1

FAN2

FAN1

Removing Memory Modules

Press both notches on the ends of the DIMM module to unlock it. Once it is loos-

ened, remove it from the memory slot.

2-11

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

Memory Support for the X9DRW-3F/X9DRW-iF Motherboard

The X9DRW-3F/X9DRW-iF motherboard supports up to 1 TB of Load Reduced

(LRDIMM), 512 GB of Registered (RDIMM) or 128 GB of Unbuffered (UDIMM)

ECC/Non-ECC DDR3 800/1066/1333/1600/1866 MHz 240-pin 4-channel memory

modules in 16 DIMM slots.

Note: For the latest memory updates, please refer to the Tested Memory

List posted on our website (http://www.supermicro.com/products/mother-

board).

Processor & Memory Module Population Conguration

For memory to work properly, follow the tables below for memory population.

Processors and their Corresponding Memory Modules

CPU# Corresponding DIMM Modules

CPU 1 P1-

DIMMA1

CPU2 P2-

DIMME1

Processor and Memory Module Population for Optimal Performance

Number of

CPUs+DIMMs

1 CPU &

2 DIMMs

1 CPU &

4 DIMMs

1 CPU &

5~8 DIMMs

2 CPUs &

4 DIMMs

2 CPUs &

6 DIMMs

2 CPUs &

8 DIMMs

2 CPUs &

10~16 DIMMs

2 CPUs & 16 DIMMs

P1DIMMA2

P2DIMME2

CPU1 P1-DIMMA1/P1-DIMMB1

CPU1 P1-DIMMA1/P1-DIMMB1, P1-DIMMC1/P1-DIMMD1

CPU1 P1-DIMMA1/P1-DIMMB1, P1-DIMMC1/P1-DIMMD1 + Any memory pairs in P1DIMMA2/P1-DIMMB2/P1-DIMMC2/P1-DIMMD2 slots

CPU1 + CPU2 P1-DIMMA1/P1-DIMMB1, P2-DIMME1/P2-DIMMF1

CPU1 + CPU2 P1-DIMMA1/P1-DIMMB1/P1-DIMMC1/P1-DIMMD1, P2-DIMME1/P2-DIMMF1

CPU1 + CPU2 P1-DIMMA1/P1-DIMMB1/P1-DIMMC1/P1-DIMMD1, P2-DIMME1/P2-DIMMF1/P2DIMMG1/P2-DIMMH1

CPU1/CPU2 P1-DIMMA1/P1-DIMMB1/P1-DIMMC1/P1-DIMMD1, P2-DIMME1/P2-DIMMF1/P2DIMMG1/P2-DIMMH1 + Any memory pairs in P1, P2 DIMM slots

CPU1/CPU2 P1-DIMMA1/P1-DIMMB1/P1-DIMMC1/P1-DIMMD1, P2-DIMME1/P2-DIMMF1/P2-DIMMG1/P2-DIMMH1,P1-DIMMA2/P1-DIMMB2/P1-DIMMC2/P1-DIMMD2, P2-DIMME2/ P2-DIMMF2/P2-DIMMG2/P2-DIMMH2

P1DIMMB1

P2DIMMF1

P1DIMMB2

P2DIMMF2

CPUandMemoryPopulationCongurationTable

P1DIMMC1

P2DIMMG1

P1DIMMC2

P2DIMMG2

P1DIMMD1

P2DIMMH1

P1DIMMD2

P2DIMMH2

Notes: 1866 MHz memory speed is dependent on Intel E5-2600v2 CPUs.

For Intel E5-2600(v2) processor support, BIOS version 3.0 or above is

required.

2-12

Chapter 2: Installation

Populating UDIMM (ECC/Non-ECC) Memory Modules

Intel E5-2600(v2) Series Processor UDIMM Memory Support

Ranks

Per

DIMM

& Data

Width

SRx8 Non-

ECC

DRx8 Non-

ECC

SRx16

Non-

ECC

SRx8

ECC

DRx8

ECC

Note: For detailed information on memory support and updates, please refer to the SMC Recommended

Memory List posted on our website at http://www.supermicro.com/support/resources/mem.cfm.

Memory Capacity

Per DIMM

(See the Note below)

1GB 2GB 4GB NA 1066,

2GB 4GB 8GB NA 1066,

512MB 1GB 2GB NA 1066,

1GB 2GB 4GB 1066,

2GB 4GB 8GB 1066,

Speed (MT/s) and Voltage Validated by Slot per Channel (SPC) and

2 Slots Per Channel 3 Slots Per Channel

1DPC 2DPC 1DPC 2DPC

1.35V 1.5V 1.35V 1.5V 1.35V 1.5V 1.35V 1.5v

1333, 1600,

1866

1333, 1600,

1866

1333, 1600,

1866

1066,

1333

1333, 1600,

1866

1066,

1333

1333, 1600,

1866

DIMM Per Channel (DPC)

NA 1066,

1066,

1333

1066,

1333

1333, 1600

1066, 1333, 1600

N/A 1066,

1066, 1333

1333, 1600, 1866

1066, 1333, 1600, 1866

N/A 1066,

1333,

1600

N/A 1066,

1333,

1600

N/A 1066,

1333,

1600

1066,

1333

1333,

1600

1066,

1333

1333,

1600

Populating RDIMM (ECC) Memory Modules

Intel E5-2600(v2) Series Processor RDIMM Memory Support

Ranks

DIMM

Width

SRx8 1GB 2GB 4GB 1066,

DRx8 2GB 4GB 8GB 1066,

SRx4 2GB 4GB 8GB 1066,

DRx4 4GB 8GB 16GB 1066,

QRx4 8GB 16GB 32GB 800 800

QRx8 4GB 8GB 16GB 800 800

Note: For detailed information on memory support and updates, please refer to the SMC Recommended Memory List posted on

our website at http://www.supermicro.com/support/resources/mem.cfm.

Per

Data

(See the Note Below)

Memory Capacity

Per DIMM

Speed (MT/s) and Voltage Validated by Slot per Channel (SPC) and DIMM Per Channel

2 Slots Per Channel 3 Slots Per Channel

1DPC 2DPC 1 DPC 2DPC 3DPC

1.35V 1.5V 1.35V 1.5V 1.35V 1.5V 1.35V 1.5V 1.35V 1.5v

1066,

1333

1333, 1600, 1866

1066, 1333, 1600, 1866

1066

1066,

1333

1333,

1600

1066,

1333

1333,

1600

1066,

1333

1333,

1600

1066,

1333

1333,

1600

800 800 800 800,

1066, 1333

(DPC)

1066,

1333,

1333 1600, 1866

1066,

1066, 1333,

1333 1600, 1866

1066,

1066, 1333,

1333 1600, 1866

1066,

1066, 1333,

1333 1600, 1866

800 800 N/A N/A

1066

800 800 N/A N/A

1066

1066, 1333,

1600

1066, 1333,

1600

1066, 1333,

1600

1066, 1333,

1600

800 800,

1066

800 800,

1066

800 800,

1066

800 800,

1066

2-13

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

Populating UDIMM (ECC/Non-ECC) Memory Modules

Intel E5-2600 Series Processor UDIMM Memory Support

Ranks

Per

DIMM

& Data

Width

SRx8 Non-

ECC

DRx8 Non-

ECC

SRx16

Non-

ECC

SRx8

ECC

DRx8

ECC

Note: For detailed information on memory support and updates, please refer to the SMC Recommended

Memory List posted on our website at http://www.supermicro.com/support/resources/mem.cfm.

Memory Capacity

Per DIMM

(See the Note below)

1GB 2GB 4GB NA 1066,

2GB 4GB 8GB NA 1066,

512MB 1GB 2GB NA 1066,

1GB 2GB 4GB 1066,

2GB 4GB 8GB 1066,

Speed (MT/s) and Voltage Validated by Slot per Channel (SPC) and

2 Slots Per Channel 3 Slots Per Channel

1DPC 2DPC 1DPC 2DPC

1.35V 1.5V 1.35V 1.5V 1.35V 1.5V 1.35V 1.5v

1333

1066,

1333

1066,

1333

DIMM Per Channel (DPC)

NA 1066,

1066 1066,

1333

N/A 1066,

1066 1066,

1333,

1333

1333,

N/A 1066,

1333

N/A 1066,

1333

N/A 1066,

1333

1066,

1333

1066,

1333

Populating RDIMM (ECC) Memory Modules

Intel E5-2600 Series Processor RDIMM Memory Support

Ranks

DIMM

Width

SRx8 1GB 2GB 4GB 1066,

DRx8 2GB 4GB 8GB 1066,

SRx4 2GB 4GB 8GB 1066,

DRx4 4GB 8GB 16GB 1066,

QRx4 8GB 16GB 32GB 800 1066 800 800 800 1066 800 800 N/A N/A

Per

Data

(See the Note Below)

Memory Capacity

Per DIMM

Speed (MT/s) and Voltage Validated by Slot per Channel (SPC) and DIMM Per Channel

2 Slots Per Channel 3 Slots Per Channel

1DPC 2DPC 1 DPC 2DPC 3DPC

1.35V 1.5V 1.35V 1.5V 1.35V 1.5V 1.35V 1.5V 1.35V 1.5v

1066,

1333

1333,

1600

1066, 1333,

1600

1066, 1333,

1600

1066, 1333,

1600

1333

1066, 1333

1066, 1333,

1600

1066, 1333,

1600

1066, 1333,

1600

1066, 1333,

1600

1066, 1333

(DPC)

1066, 1333, 1600

1066, 1333

1066, 1333, 1600

N/A 800,

1066

QRx8 4GB 8GB 16GB 800 1066 800 800 800 1066 800 800 N/A N/A

Note: For detailed information on memory support and updates, please refer to the SMC Recommended Memory List posted on

our website at http://www.supermicro.com/support/resources/mem.cfm.

2-14

Chapter 2: Installation

Populating LRDIMM (ECC) Memory Modules

Intel E5-2600(v2) Series Processor LRDIMM Memory Support

Ranks

DIMM

Data

Width

QRx4

(DDP)

8Rx4

(QDP)

Note: For detailed information on memory support and updates, please refer to the SMC Recommended Memory

List posted on our website at http://www.supermicro.com/support/resources/mem.cfm.

Ranks

DIMM

Data

Width

QRx4

(DDP)

Memory

Per

Capacity

Per DIMM

(See the Note

Below)

16GB 32GB 1066,

32GB 64GB 1066 1066 1066 1066 1066 1066 1066 1066 1066 1066

Speed (MT/s) and Voltage Validated by Slot per Channel (SPC) and DIMM Per

2 Slots Per Channel 3 Slots Per Channel

1DPC 2DPC 1DPC 2DPC 3DPC

1.35V 1.5V 1.35V 1.5V 1.35V 1.5V 1.35V 1.5V 1.35V 1.5V

1066, 1333, 1600,

1866

1066, 1333,

1600

1333,

1600

1066, 1333,

1600

Channel (DPC)

1066,

1333,

1600

1600, 1866

1066, 1333, 1600

1066, 1333,

1600

Intel E5-2600 Series Processor LRDIMM Memory Support

Memory

Per

Capacity

Per DIMM

(See the Note

Below)

16GB 32GB 1066 1066,

Speed (MT/s) and Voltage Validated by Slot per Channel (SPC) and DIMM Per

2 Slots Per Channel 3 Slots Per Channel

1DPC 2DPC 1DPC 2DPC 3DPC

1.35V 1.5V 1.35V 1.5V 1.35V 1.5V 1.35V 1.5V 1.35V 1.5V

1066 1066,

1333

Channel (DPC)

1066 1066,

1333

1066 1066,

1333

1066 1066

QRx8

8GB 16GB 1066 1066,

(QDP)

Note: For detailed information on memory support and updates, please refer to the SMC Recommended Memory

List posted on our website at http://www.supermicro.com/support/resources/mem.cfm.

1333

1066 1066,

1333

1066 1066 1066 1066 1066 1066

Other Important Notes and Restrictions

•For the memory modules to work properly, please install DIMM modules of the same

type, same speed and same operating frequency on the motherboard. Mixing of

RDIMMs, UDIMMs or LRDIMMs is not allowed. Do not install both ECC and Non-ECC

memory modules on the same motherboard.

•Using DDR3 DIMMs with different operating frequencies is not allowed. All channels

in a system will run at the lowest common frequency.

•Due to memory allocation to system devices, the amount of memory that remains

available for operational use will be reduced when 4 GB of R AM is used. The

reduction in memory availability is disproportional. See the table on the next

page for details.

2-15

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

Possible System Memory Allocation & Availability

System Device Size Physical Memory

Firmware Hub ash memory (System BIOS) 1 MB 3.99

Local APIC 4 KB 3.99

Area Reserved for the chipset 2 MB 3.99

I/O APIC (4 Kbytes) 4 KB 3.99

PCI Enumeration Area 1 256 MB 3.76

PCI Express (256 MB) 256 MB 3.51

PCI Enumeration Area 2 (if needed) -Aligned on 256MB boundary-

TSEG 1 MB 2.84

Memory available to OS and other applications 2.84

512 MB 3.01

Remaining (-Available)

(4 GB Total System

Memory)

2-16

Chapter 2: Installation

I-SATA0

I-SATA3

2-5 Motherboard Installation

All motherboards have standard mounting holes to t different types of chassis.

Make sure that the locations of all the mounting holes for both motherboard and

chassis match. Although a chassis may have both plastic and metal mounting fas-

teners, metal ones are highly recommended because they ground the motherboard

to the chassis. Make sure that the metal standoffs click in or are screwed in tightly.

Then use a screwdriver to secure the motherboard onto the motherboard tray.

Tools Needed

•Phillips Screwdriver

•Pan head screws (7 pieces)

•Standoffs (7 pieces, if needed)

Location of Mounting Holes

There are seven (7) mounting holes on this motherboard indicated by the arrows.

VGA

LED3

UID

JUIDB

SXB1A

B1B2A1A2B1B2A1

SXB1B: CPU PCI-E 3.0 x16 + x16

COM2

USB4/5

JSTBY1

T-SGPIO1

T-SGPIO2

JI2C1

JLPC1

JP3

JPME2

I-SATA5

I-SATA4

JWD1

I-SATA1

FANB

BMC

JPB1

CTRL

JIPMB1

JI2C2

JBT1

JPME1

I-SATA2

SATA/

JSM2

JSD1

SCU4~7

JVRM_I2C1

JPG1

JVRM_I2C2

PCH

JBAT1

SCU0~3

SATA/

LED2

JF1

JOH1

JD1

JSM1

FANA

SXB1C

LED1

P1-DIMMC1

BIOS

JTAG OF CPLD

FAN4

SXB2: CPU2 PCI-E3.0 X16

P1-DIMMF1

P1-DIMME1

P1-DIMME2

P1-DIMMF2

P1-DIMMD1

P1-DIMMD2

P1-DIMMC2

CLOSE 1st

JVR1

FAN3

LAN CTRL

X9DRW-3F/iF Rev.1.02

CPU1

OPEN 1st

LAN1

LAN2

USB2/3

CPU2

CLOSE 1st

FAN2

OPEN 1st

USB0/1

IPMI-LAN

JPL1

COM1

PHY

P1-DIMMH2

P1-DIMMH1

P1-DIMMB2

P1-DIMMB1

P1-DIMMG2

P1-DIMMA2

FAN1

P1-DIMMG1

P1-DIMMA1

JPW4

JPW3

JPI2C1

SP1

JPW2

JPW1

Caution: 1) To avoid damaging the motherboard and its components,

please do not use a force greater than 8 lb/inch on each mounting screw

during motherboard installation. 2) Some components are very close to the

mounting holes. Please take precautionary measures to avoid damaging

components when installing the motherboard to the chassis.

2-17

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

Installing the Motherboard

1. Install the I/O shield into the chassis.

2. Locate the mounting holes on the motherboard.

3. Locate the matching mounting holes on the chassis. Align the mounting holes

on the motherboard with the mounting holes on the chassis.

4. Install standoffs in the chassis as needed.

5. Install the motherboard into the chassis carefully to avoid damaging mother-

board components.

6. Using the Phillips screwdriver, insert a Pan head #6 screw into a mounting

hole on the motherboard and its matching mounting hole on the chassis.

7. Repeat Step 5 to insert #6 screws into all mounting holes.

8. Make sure that the motherboard is securely placed in the chassis.

Note: Images displayed are for illustration only. Your chassis or compo-

nents might look different from those shown in this manual.

2-18

Chapter 2: Installation

I-SATA0

I-SATA3

1234567

2-6 Control Panel Connectors and I/O Ports

The I/O ports are color coded in conformance with the PC 99 specication. See

the picture below for the colors and locations of the various I/O ports.

Back Panel Connectors and I/O Ports

COM2

USB4/5

JPB1

JSTBY1

T-SGPIO1

JIPMB1

T-SGPIO2

JI2C1

JI2C2

JLPC1

JP3

JPME2

I-SATA5

PCH

JBT1

JPME1

I-SATA4

JWD1

JSD1

I-SATA2

I-SATA1

SCU4~7

SATA/

FANB

JSM2

LED1

BMC CTRL

JVRM_I2C1

JPG1

BIOS

JVRM_I2C2

JTAG OF CPLD

JBAT1

SCU0~3

SATA/

LED2

JF1

FAN4

JOH1

JD1

JSM1

FANA

LED3

UID

JUIDB

SXB1A

B1B2A1A2B1B2A1

SXB2: CPU2 PCI-E3.0 X16

SXB1B: CPU PCI-E 3.0 x16 + x16

P1-DIMME1

P1-DIMME2

SXB1C

P1-DIMMD1

P1-DIMMC2

P1-DIMMC1

P1-DIMMF1

P1-DIMMD2

FAN3

P1-DIMMF2

VGA

LAN CTRL

X9DRW-3F/iF Rev.1.02

CLOSE 1st

JVR1

COM1

USB0/1

JPL1

LAN1

LAN2

CLOSE 1st

CPU1

OPEN 1st

PHY

USB2/3

CPU2

FAN2

JPW4

IPMI-LAN

OPEN 1st

P1-DIMMG2

P1-DIMMH2

P1-DIMMG1

P1-DIMMH1

JPW3

P1-DIMMA2

P1-DIMMB2

P1-DIMMA1

P1-DIMMB1

JPI2C1

SP1

JPW2

JPW1

FAN1

BackPanelI/OPortLocationsandDenitions

1. COM Port 1 (Turquoise)

2. Back Panel USB Port 0

3. Back Panel USB Port 1

4. IPMI_LAN

5. Back Panel USB Port 2

6. Back Panel USB Port 3

7. Gigabit LAN 1

8. Gigabit LAN 2

9. VGA (Blue)

10. UID Switch

2-19

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

SP1

JPW3

JPW2

JPW4

JPB1

FAN2

FAN1

FAN4

FANA

FAN3

JPI2C1

LED3

LED1

COM2

JTAG OF CPLD

SXB1A

SXB1B: CPU PCI-E 3.0 x16 + x16

UID

SXB2: CPU2 PCI-E3.0 X16

LAN2

LAN1

USB2/3

USB0/1

IPMI-LAN

COM1

X9DRW-3F/iF Rev.1.02

VGA

LAN CTRL

BIOS

BMC CTRL

JPW1

PHY

JPL1

B1B2A1A2B1B2A1

SXB1C

JVRM_I2C2

JVRM_I2C1

JPG1

JIPMB1

JSTBY1

JSD1

JD1

JI2C1

JI2C2

JL1

JF1

I-SATA1

I-SATA0

JLPC1

JSM1

JSM2

T-SGPIO1

T-SGPIO2

I-SATA3

I-SATA2

I-SATA5

I-SATA4

JBAT1

JPME2

JWD1

JPME1

JP3

FANB

LED2

SATA/

USB4/5

PCH

JBT1

SCU0~3

SATA/

SCU4~7

JVR1

JUIDB

JOH1

P1-DIMMA1

P1-DIMMA2

P1-DIMMB1

P1-DIMMB2

P1-DIMMD2

P1-DIMMD1

P1-DIMMC2

P1-DIMMF1

P1-DIMME2

P1-DIMME1

P1-DIMMG1

P1-DIMMG2

P1-DIMMH1

P1-DIMMH2

CLOSE 1st

OPEN 1st

CPU1

CLOSE 1st

OPEN 1st

CPU2

P1-DIMMC1

P1-DIMMF2

123

Universal Serial Bus (USB)

Four Universal Serial Bus ports (USB

0/1, 2/3) are located on the I/O back

panel. In addition, one USB header,

located next to COM2 port, provides

two front-accessible USB connections

(USB 4/5). (Cables are not included).

See the tables on the right for pin

denitions.

Backplane USB

(USB 0/1, 2/3)

PinDenitions

Pin# Denition

1 +5V

2 PO-

3 PO+

4 Ground

5 NA

FP USB (4/5)

PinDenitions

USB 4

Pin # Denition

USB 5

Pin # Denition

1 +5V 1 +5V

2 PO- 2 PO-

3 PO+ 3 PO+

4 Ground 4 Ground

5 NC 5 Key

(NC= No connection)

1. Backpanel USB 0

2. Backpanel USB 1

3. Backpanel USB 2

2-20

4. Backpanel USB 3

5. Front Accessible USB 4/5

Chapter 2: Installation

SP1

JPW3

JPW2

JPW4

JPB1

FAN2

FAN1

FAN4

FANA

FAN3

JPI2C1

LED3

LED1

COM2

JTAG OF CPLD

SXB1A

SXB1B: CPU PCI-E 3.0 x16 + x16

UID

SXB2: CPU2 PCI-E3.0 X16

LAN2

LAN1

USB2/3

USB0/1

IPMI-LAN

COM1

X9DRW-3F/iF Rev.1.02

VGA

LAN CTRL

BIOS

BMC CTRL

JPW1

PHY

JPL1

B1B2A1A2B1B2A1

SXB1C

JVRM_I2C2

JVRM_I2C1

JPG1

JIPMB1

JSTBY1

JSD1

JD1

JI2C1

JI2C2

JL1

JF1

I-SATA1

I-SATA0

JLPC1

JSM1

JSM2

T-SGPIO1

T-SGPIO2

I-SATA3

I-SATA2

I-SATA5

I-SATA4

JBAT1

JPME2

JWD1

JPME1

JP3

FANB

LED2

SATA/

USB4/5

PCH

JBT1

SCU0~3

SATA/

SCU4~7

JVR1

JUIDB

JOH1

P1-DIMMA1

P1-DIMMA2

P1-DIMMB1

P1-DIMMB2

P1-DIMMD2

P1-DIMMD1

P1-DIMMC2

P1-DIMMF1

P1-DIMME2

P1-DIMME1

P1-DIMMG1

P1-DIMMG2

P1-DIMMH1

P1-DIMMH2

CLOSE 1st

OPEN 1st

CPU1

CLOSE 1st

OPEN 1st

CPU2

P1-DIMMC1

P1-DIMMF2

COM1

COM2

COM1

COM2

Serial Ports

Two COM connections (COM1 &

COM2) are located on the mother-

board. COM1 is located on the Back-

plane I/O panel. COM2, located next

to Front Accessible USB 4/5, is used to

provide front access serial support. See

the table on the right for pin denitions.

Video Connection

One video (VGA) port (VGA1) is lo-

cated next to LAN Port 2 on the I/O

backplane. Refer to the board layout

below for the location.

Serial COM) Ports

PinDenitions

Pin # Denition Pin # Denition

1 DCD 6 DSR

2 RXD 7 RTS

3 TXD 8 CTS

4 DTR 9 RI

5 Ground 10 N/A

1. COM1

2. COM2

3. VGA1

2-21

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

SP1

JPW3

JPW2

JPW4

JPB1

FAN2

FAN1

FAN4

FANA

FAN3

JPI2C1

LED3

LED1

COM2

JTAG OF CPLD

SXB1A

SXB1B: CPU PCI-E 3.0 x16 + x16

UID

SXB2: CPU2 PCI-E3.0 X16

LAN2

LAN1

USB2/3

USB0/1

IPMI-LAN

COM1

X9DRW-3F/iF Rev.1.02

VGA

LAN CTRL

BIOS

BMC CTRL

JPW1

PHY

JPL1

B1B2A1A2B1B2A1

SXB1C

JVRM_I2C2

JVRM_I2C1

JPG1

JIPMB1

JSTBY1

JSD1

JD1

JI2C1

JI2C2

JL1

JF1

I-SATA1

I-SATA0

JLPC1

JSM1

JSM2

T-SGPIO1

T-SGPIO2

I-SATA3

I-SATA2

I-SATA5

I-SATA4

JBAT1

JPME2

JWD1

JPME1

JP3

FANB

LED2

SATA/

USB4/5

PCH

JBT1

SCU0~3

SATA/

SCU4~7

JVR1

JUIDB

JOH1

P1-DIMMA1

P1-DIMMA2

P1-DIMMB1

P1-DIMMB2

P1-DIMMD2

P1-DIMMD1

P1-DIMMC2

P1-DIMMF1

P1-DIMME2

P1-DIMME1

P1-DIMMG1

P1-DIMMG2

P1-DIMMH1

P1-DIMMH2

CLOSE 1st

OPEN 1st

CPU1

CLOSE 1st

OPEN 1st

CPU2

P1-DIMMC1

P1-DIMMF2

Ethernet Ports

Two Gigabit Ethernet ports (LAN1/2)

are located on the I/O backplane on

the motherboard to provide internet

connections. In addition, an IPMI_

Dedicated LAN, located above USB

0/1 ports on the backplane, provides

KVM support for IPMI 2.0. All these

ports accept RJ45 type cables.

Note: Please refer to the

LED Indicator Section for

LAN LED information.

LAN Ports

PinDenition

Pin# Denition

1 P2V5SB 10 SGND

2 TD0+ 11 Act LED

3 TD0- 12 P3V3SB

4 TD1+ 13 Link 100 LED (Yel-

5 TD1- 14 Link 1000 LED

low, +3V3SB)

(Yellow, +3V3SB)

6 TD2+ 15 Ground

7 TD2- 16 Ground

8 TD3+ 17 Ground

9 TD3- 18 Ground

(NC: No Connection)

1. GLAN1

2. GLAN2

3. IPMI_LAN

2-22

Chapter 2: Installation

SP1

JPW3

JPW2

JPW4

JPB1

FAN2

FAN1

FAN4

FANA

FAN3

JPI2C1

LED3

LED1

COM2

JTAG OF CPLD

SXB1A

SXB1B: CPU PCI-E 3.0 x16 + x16

UID

SXB2: CPU2 PCI-E3.0 X16

LAN2

LAN1

USB2/3

USB0/1

IPMI-LAN

COM1

X9DRW-3F/iF Rev.1.02

VGA

LAN CTRL

BIOS

BMC CTRL

JPW1

PHY

JPL1

B1B2A1A2B1B2A1

SXB1C

JVRM_I2C2

JVRM_I2C1

JPG1

JIPMB1

JSTBY1

JSD1

JD1

JI2C1

JI2C2

JL1

JF1

I-SATA1

I-SATA0

JLPC1

JSM1

JSM2

T-SGPIO1

T-SGPIO2

I-SATA3

I-SATA2

I-SATA5

I-SATA4

JBAT1

JPME2

JWD1

JPME1

JP3

FANB

LED2

SATA/

USB4/5

PCH

JBT1

SCU0~3

SATA/

SCU4~7

JVR1

JUIDB

JOH1

P1-DIMMA1

P1-DIMMA2

P1-DIMMB1

P1-DIMMB2

P1-DIMMD2

P1-DIMMD1

P1-DIMMC2

P1-DIMMF1

P1-DIMME2

P1-DIMME1

P1-DIMMG1

P1-DIMMG2

P1-DIMMH1

P1-DIMMH2

CLOSE 1st

OPEN 1st

CPU1

CLOSE 1st

OPEN 1st

CPU2

P1-DIMMC1

P1-DIMMF2

UnitIdentierSwitch

A Unit Identier (UID) Switch and two

LED Indicators are located on the

motherboard. The UID Switch is lo-

cated next to the VGA port. The Rear

UID LED (LED3) is located next to

the UID Switch. The Front Panel UID

LED is located at pins 7/8 of the Front

Control Panel at JF1. Connect a cable

to pin 8 on JF1 for Front Panel UID

LED indication. When you press the

UID switch, both Rear UID LED and

Front Panel UID LED Indicators will

be turned on. Press the UID switch

again to turn off both LED Indicators.

These UID Indicators provide easy

identication of a system unit that

may be in need of service.

Note: UID can also be trig-

gered via IPMI on the moth-

erboard. For more informa-

tion on IPMI, please refer

to the IPMI User's Guide

posted on our website @

http://www.supermicro.com.

UID Switch

Pin# Denition

1 Ground

2 Ground

3 Button In

4 Ground

UID LED

Status

Color/State OS Status

Blue: On Windows OS Unit Identied

Blue: Blinking

FP PWRLED

HDD LED

NIC1 Link LED

NIC2 Link LED

Blue+ (OH/Fan Fail/ PWR FaiL/UID LED)

Power Fail LED

Linux OS Unit Identied

Ground

1920

Reset

PWR

NMI

3.3 V

ID_UID_SW/3/3V Stby

NIC1 Activity LED

NIC2 Activity LED

Red+ (Blue LED Cathode)

3.3V

Reset Button

Power Button

1. UID Switch

2. Rear UID LED (LED3)

3. Front UID LED

2-23

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

SP1

JPW3

JPW2

JPW4

JPB1

FAN2

FAN1

FAN4

FANA

FAN3

JPI2C1

LED3

LED1

COM2

JTAG OF CPLD

SXB1A

SXB1B: CPU PCI-E 3.0 x16 + x16

UID

SXB2: CPU2 PCI-E3.0 X16

LAN2

LAN1

USB2/3

USB0/1

IPMI-LAN

COM1

X9DRW-3F/iF Rev.1.02

VGA

LAN CTRL

BIOS

BMC CTRL

JPW1

PHY

JPL1

B1B2A1A2B1B2A1

SXB1C

JVRM_I2C2

JVRM_I2C1

JPG1

JIPMB1

JSTBY1

JSD1

JD1

JI2C1

JI2C2

JL1

JF1

I-SATA1

I-SATA0

JLPC1

JSM1

JSM2

T-SGPIO1

T-SGPIO2

I-SATA3

I-SATA2

I-SATA5

I-SATA4

JBAT1

JPME2

JWD1

JPME1

JP3

FANB

LED2

SATA/

USB4/5

PCH

JBT1

SCU0~3

SATA/

SCU4~7

JVR1

JUIDB

JOH1

P1-DIMMA1

P1-DIMMA2

P1-DIMMB1

P1-DIMMB2

P1-DIMMD2

P1-DIMMD1

P1-DIMMC2

P1-DIMMF1

P1-DIMME2

P1-DIMME1

P1-DIMMG1

P1-DIMMG2

P1-DIMMH1

P1-DIMMH2

CLOSE 1st

OPEN 1st

CPU1

CLOSE 1st

OPEN 1st

CPU2

P1-DIMMC1

P1-DIMMF2

Front Control Panel

JF1 contains header pins for various buttons and indicators that are normally lo-

cated on a control panel at the front of the chassis. These connectors are designed

specically for use with Supermicro's server chassis. See the gure below for the

descriptions of the various control panel buttons and LED indicators. Refer to the

following section for descriptions and pin denitions.

FP PWRLED

NIC1 Link LED

NIC2 Link LED

Blue+ (OH/Fan Fail/ PWR FaiL/UID LED)

Power Fail LED

Ground

HDD LED

Ground

JF1 Header Pins

1920

2-24

NMI

3.3 V

ID_UID_SW/3/3V Stby

NIC1 Activity LED

NIC2 Activity LED

Red+ (Blue LED Cathode)

3.3V

Reset

PWR

Reset Button

Power Button

FrontControlPanelPinDenitions

SP1

JPW3

JPW2

JPW4

JPB1

FAN2

FAN1

FAN4

FANA

FAN3

JPI2C1

LED3

LED1

COM2

JTAG OF CPLD

SXB1A

SXB1B: CPU PCI-E 3.0 x16 + x16

UID

SXB2: CPU2 PCI-E3.0 X16

LAN2

LAN1

USB2/3

USB0/1

IPMI-LAN

COM1

X9DRW-3F/iF Rev.1.02

VGA

LAN CTRL

BIOS

BMC CTRL

JPW1

PHY

JPL1

B1B2A1A2B1B2A1

SXB1C

JVRM_I2C2

JVRM_I2C1

JPG1

JIPMB1

JSTBY1

JSD1

JD1

JI2C1

JI2C2

JL1

JF1

I-SATA1

I-SATA0

JLPC1

JSM1

JSM2

T-SGPIO1

T-SGPIO2

I-SATA3

I-SATA2

I-SATA5

I-SATA4

JBAT1

JPME2

JWD1

JPME1

JP3

FANB

LED2

SATA/

USB4/5

PCH

JBT1

SCU0~3

SATA/

SCU4~7

JVR1

JUIDB

JOH1

P1-DIMMA1

P1-DIMMA2

P1-DIMMB1

P1-DIMMB2

P1-DIMMD2

P1-DIMMD1

P1-DIMMC2

P1-DIMMF1

P1-DIMME2

P1-DIMME1

P1-DIMMG1

P1-DIMMG2

P1-DIMMH1

P1-DIMMH2

CLOSE 1st

OPEN 1st

CPU1

CLOSE 1st

OPEN 1st

CPU2

P1-DIMMC1

P1-DIMMF2

Chapter 2: Installation

NMI Button

The non-maskable interrupt button

header is located on pins 19 and 20

of JF1. Refer to the table on the right

for pin denitions.

Power LED

The Power LED connection is located

on pins 15 and 16 of JF1. Refer to the

table on the right for pin denitions.

NMI Button

PinDenitions(JF1)

Pin# Denition

19 Control

20 Ground

Power LED

PinDenitions(JF1)

Pin# Denition

15 3.3V

16 PWR LED

A. NMI

B. PWR LED

Ground

NIC1 Link LED

NIC2 Link LED

Blue+ (OH/Fan Fail/ PWR FaiL/UID LED)

Power Fail LED

2-25

FP PWRLED

HDD LED

Ground

NIC1 Activity LED

Reset

PWR

NMI

3.3 V

ID_UID_SW/3/3V Stby

NIC2 Activity LED

Red+ (Blue LED Cathode)

3.3V

Reset Button

Power Button

1920

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

I-SATA0

I-SATA3

HDD LED

The HDD LED connection is located

on pins 13 and 14 of JF1. Attach a

cable here to indicate HDD activ-

ity. See the table on the right for pin

denitions.

NIC1/NIC2 LED Indicators

The NIC (Network Interface Control-

ler) LED connections for GLAN port 1

are located on pins 11 and 12 of JF1,

and the LED connection for GLAN

Port 2 are on Pins 9 and 10. Attach

the NIC LED cables here to display

network activity. Refer to the table on

the right for pin denitions.

HDD LED

PinDenitions(JF1)

Pin# Denition

13 3.3V Standby

14 HD Active

GLAN1/2 LED

PinDenitions(JF1)

Pin# Denition

9 NIC 2 Activity LED

10 NIC 2 Link LED

11 NIC 1 Activity LED

12 NIC 1 Link LED

A. HDD LED

B. NIC1 Link LED

C. NIC1 Activity LED

D. NIC2 Link LED

E. NIC2 Activity LED

VGA

LED3

UID

JUIDB

LAN CTRL

SXB2: CPU2 PCI-E3.0 X16

P1-DIMMF1

P1-DIMME1

P1-DIMME2

P1-DIMMD1

P1-DIMMD2

P1-DIMMC2

P1-DIMMC1

FAN3

P1-DIMMF2

X9DRW-3F/iF Rev.1.02

CLOSE 1st

JVR1

LAN2

CLOSE 1st

CPU1

OPEN 1st

SXB1A

B1B2A1A2B1B2A1

SXB1B: CPU PCI-E 3.0 x16 + x16

COM2

BMC

USB4/5

JPB1

CTRL

JSTBY1

T-SGPIO1

JIPMB1

T-SGPIO2

JI2C1

JPG1

JI2C2

JLPC1

JP3

JPME2

I-SATA5

PCH

JBT1

JPME1

I-SATA4

JWD1

JSD1

I-SATA2

JBAT1

I-SATA1

SCU0~3

SATA/

SCU4~7

SATA/

FANB

JSM1

JSM2

JL1

SXB1C

LED1

JVRM_I2C1

BIOS

JVRM_I2C2

JTAG OF CPLD

LED2

JF1

FAN4

JOH1

JD1

FANA

COM1

USB0/1

JPL1

PHY

LAN1

USB2/3

CPU2

FAN2

JPW4

IPMI-LAN

Ground

FP PWRLED

HDD LED

JPW3

JPI2C1

Blue+ (OH/Fan Fail/ PWR FaiL/UID LED)

SP1

JPW2

Power Fail LED

JPW1

NIC1 Link LED

NIC2 Link LED

Ground

OPEN 1st

P1-DIMMG2

P1-DIMMH2

P1-DIMMG1

P1-DIMMH1

P1-DIMMA2

P1-DIMMB2

P1-DIMMA1

P1-DIMMB1

FAN1

1920

NIC1 Activity LED

Reset

PWR

NMI

3.3 V

ID_UID_SW/3/3V Stby

NIC2 Activity LED

Red+ (Blue LED Cathode)

3.3V

Reset Button

Power Button

2-26

Chapter 2: Installation

SP1

JPW3

JPW2

JPW4

JPB1

FAN2

FAN1

FAN4

FANA

FAN3

JPI2C1

LED3

LED1

COM2

JTAG OF CPLD

SXB1A

SXB1B: CPU PCI-E 3.0 x16 + x16

UID

SXB2: CPU2 PCI-E3.0 X16

LAN2

LAN1

USB2/3

USB0/1

IPMI-LAN

COM1

X9DRW-3F/iF Rev.1.02

VGA

LAN CTRL

BIOS

BMC CTRL

JPW1

PHY

JPL1

B1B2A1A2B1B2A1

SXB1C

JVRM_I2C2

JVRM_I2C1

JPG1

JIPMB1

JSTBY1

JSD1

JD1

JI2C1

JI2C2

JF1

I-SATA1

I-SATA0

JLPC1

JSM1

JSM2

T-SGPIO1

T-SGPIO2

I-SATA3

I-SATA2

I-SATA5

I-SATA4

JBAT1

JPME2

JWD1

JPME1

JP3

FANB

LED2

SATA/

USB4/5

PCH

JBT1

SCU0~3

SATA/

SCU4~7

JVR1

JUIDB

JOH1

P1-DIMMA1

P1-DIMMA2

P1-DIMMB1

P1-DIMMB2

P1-DIMMD2

P1-DIMMD1

P1-DIMMC2

P1-DIMMF1

P1-DIMME2

P1-DIMME1

P1-DIMMG1

P1-DIMMG2

P1-DIMMH1

P1-DIMMH2

CLOSE 1st

OPEN 1st

CPU1

CLOSE 1st

OPEN 1st

CPU2

P1-DIMMC1

P1-DIMMF2

Overheat (OH)/Fan Fail/PWR Fail/ UID LED

Connect an LED cable to pins 7 and

8 of Front Control Panel to use the

Overheat /Fan Fail/Power Fail and

UID LED connections. The Red LED

on pin 7 provides warnings of over-

heat, fan failure or power failure. The

Blue LED on pin 8 works as the front

panel UID LED indicator. The Red

LED takes precedence over the Blue

LED by default. Refer to the table on

the right for pin denitions.

Power Fail LED

The Power Fail LED connection is

located on pins 5 and 6 of JF1. Re-

fer to the table on the right for pin

denitions.

OH/Fan Fail/ PWR Fail/Blue_UID

LEDPinDenitions(JF1)

Pin# Denition

7 Red_LED-Cathode/OH/Fan Fail/

Power Fail5.5V.SB

8 Blue_UID LED

OH/Fan Fail/PWR Fail

LED Status (Red LED)

State Denition

Off Normal

On Overheat

Flashing Fan Fail

PWR Fail LED

PinDenitions(JF1)

Pin# Denition

5 3.3V

6 PWR Supply Fail

A. OH/Fail/PWR Fail LED (Red)/UID

(Blue)

B. Blue LED Cathode

C. PWR Supply Fail

Ground

NIC1 Link LED

Blue+ (OH/Fan Fail/ PWR FaiL/UID LED)

Power Fail LED

2-27

FP PWRLED

HDD LED

NIC2 Link LED

Ground

1920

NMI

3.3 V

ID_UID_SW/3/3V Stby

NIC1 Activity LED

NIC2 Activity LED

Red+ (Blue LED Cathode)

3.3V

Reset

PWR

Reset Button

Power Button

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

I-SATA0

I-SATA3

Reset Button

The Reset Button connection is located

on pins 3 and 4 of JF1. Attach it to a

hardware reset switch on the computer

case. Refer to the table on the right for

pin denitions.

Power Button

The Power Button connection is located

on pins 1 and 2 of JF1. Momentarily

contacting both pins will power on/off

the system. This button can also be con-

gured to function as a suspend button

(with a setting in the BIOS - See Chapter

4). To turn off the power when the system

is in suspend mode, press the button for

4 seconds or longer. Refer to the table on

the right for pin denitions.

Reset Button

PinDenitions(JF1)

Pin# Denition

3 Reset

4 Ground

Power Button

PinDenitions(JF1)

Pin# Denition

1 Signal

2 Ground

A. Reset Button

B. PWR Button

VGA

LED3

UID

JUIDB

LAN CTRL

B1B2A1A2B1B2A1

P1-DIMMC1

SXB2: CPU2 PCI-E3.0 X16

P1-DIMMF1

P1-DIMME1

P1-DIMME2

P1-DIMMF2

P1-DIMMD1

P1-DIMMD2

P1-DIMMC2

FAN3

X9DRW-3F/iF Rev.1.02

CLOSE 1st

JVR1

LAN2

CPU1

OPEN 1st

SXB1A

SXB1B: CPU PCI-E 3.0 x16 + x16

COM2

USB4/5

JPB1

JSTBY1

T-SGPIO1

JIPMB1

T-SGPIO2

JI2C1

JI2C2

JLPC1

JP3

JPME2

I-SATA5

PCH

JBT1

JPME1

I-SATA4

JWD1

JSD1

I-SATA2

JBAT1

I-SATA1

SCU0~3

SATA/

SCU4~7

SATA/

FANB

JSM1

JSM2

SXB1C

LED1

BMC CTRL

JVRM_I2C1

JPG1

BIOS

JVRM_I2C2

JTAG OF CPLD

LED2

JF1

FAN4

JOH1

JD1

FANA

COM1

USB0/1

JPL1

PHY

LAN1

USB2/3

JPW4

IPMI-LAN

CPU2

CLOSE 1st

OPEN 1st

P1-DIMMG2

P1-DIMMH2

P1-DIMMG1

P1-DIMMH1

JPW3

P1-DIMMA2

P1-DIMMB2

P1-DIMMA1

P1-DIMMB1

Blue+ (OH/Fan Fail/

JPI2C1

PWR FaiL/UID LED)

SP1

JPW2

JPW1

FAN2

FAN1

Ground

FP PWRLED

HDD LED

NIC1 Link LED

NIC2 Link LED

Power Fail LED

Ground

1920

NMI

NIC1 Activity LED

NIC2 Activity LED

Reset

PWR

3.3 V

ID_UID_SW/3/3V Stby

Red+ (Blue LED Cathode)

3.3V

Reset Button

Power Button

2-28

Chapter 2: Installation

SP1

JPW3

JPW2

JPW4

JPB1

FAN2

FAN1

FAN4

FANA

FAN3

JPI2C1

LED3

LED1

COM2

JTAG OF CPLD

SXB1A

SXB1B: CPU PCI-E 3.0 x16 + x16

UID

SXB2: CPU2 PCI-E3.0 X16

LAN2

LAN1

USB2/3

USB0/1

IPMI-LAN

COM1

X9DRW-3F/iF Rev.1.02

VGA

LAN CTRL

BIOS

BMC CTRL

JPW1

PHY

JPL1

B1B2A1A2B1B2A1

SXB1C

JVRM_I2C2

JVRM_I2C1

JPG1

JIPMB1

JSTBY1

JSD1

JD1

JI2C1

JI2C2

JL1

JF1

I-SATA1

I-SATA0

JLPC1

JSM1

JSM2

T-SGPIO1

T-SGPIO2

I-SATA3

I-SATA2

I-SATA5

I-SATA4

JBAT1

JPME2

JWD1

JPME1

JP3

FANB

LED2

SATA/

USB4/5

PCH

JBT1

SCU0~3

SATA/

SCU4~7

JVR1

JUIDB

JOH1

P1-DIMMA1

P1-DIMMA2

P1-DIMMB1

P1-DIMMB2

P1-DIMMD2

P1-DIMMD1

P1-DIMMC2

P1-DIMMF1

P1-DIMME2

P1-DIMME1

P1-DIMMG1

P1-DIMMG2

P1-DIMMH1

P1-DIMMH2

CLOSE 1st

OPEN 1st

CPU1

CLOSE 1st

OPEN 1st

CPU2

P1-DIMMC1

P1-DIMMF2

2-7 Connecting Cables

Power Connectors

A 24-pin main power supply connector(JPW1), two

8-pin CPU power connectors (JPW2/JPW3) and a

4-pin power connector are located on the mother-

board. These power connectors meet the SSI EPS

12V specication. These power connectors must

also be connected to your power supply. See the

table on the right for pin denitions.

Warning: To avoid damaging your motherboard and

components, please use a power supply that supports

a 24-pin, two 8-pin power and one 4-pin connectors.

Be sure to connect the 24-pin and the 8-pin power

connectors to your power supply for adequate power

delivery to your system. The 4-pin power connector

is optional; however, Supermicro recommends that

this connector also be plugged in for optimal power

delivery.

ATX Power 24-pin Connector

PinDenitions

Pin# Denition Pin # Denition

13 +3.3V 1 +3.3V

14 -12V 2 +3.3V

15 COM 3 COM

16 PS_ON 4 +5V

17 COM 5 COM

18 COM 6 +5V

19 COM 7 COM

20 Res (NC) 8 PWR_OK

21 +5V 9 5VSB

22 +5V 10 +12V

23 +5V 11 +12V

24 COM 12 +3.3V

12V 8-pin PWR Con-

nector

PinDenitions

Pins Denition

1 through 4 Ground

5 through 8 +12V

(Required)

A. JPW1: 24-pin ATX

PWR (Req'd)

B. JPW2: 8-pin Processor

PWR (Req'd)

C. JPW3: 8-pin Processor

PWR, or

D. JPW4: 4-pin PWR (rec-

ommended)

2-29

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

I-SATA0

I-SATA3

Fan Headers

This motherboard has six system/CPU

fan headers (Fan 1~Fan 4, Fan A, Fan B)

on the motherboard. All these 4-pin fans

headers are backward compatible with

the traditional 3-pin fans. The fan speeds

are controlled by rmware thermal man-

agement via IPMI 2.0. See the table on

the right for pin denitions.

Chassis Intrusion

A Chassis Intrusion header is located

at JL1 on the motherboard. Attach an

appropriate cable from the chassis to

inform you of a chassis intrusion when

the chassis is opened.

VGA

LED3

UID

JUIDB

SXB1A

B1B2A1A2B1B2A1

SXB1B: CPU PCI-E 3.0 x16 + x16

SXB2: CPU2 PCI-E3.0 X16

LAN CTRL

LAN2

CLOSE 1st

Fan Header

PinDenitions

Pin# Denition

1 Ground

2 +12V

3 Tachometer

4 Firmware Thermal

Control

Chassis Intrusion

PinDenitions

Pin# Denition

1 Intrusion Input

2 Ground

COM1

USB0/1

JPL1

IPMI-LAN

PHY

LAN1

USB2/3

A. Fan 1

B. Fan 2

JPW4

C. Fan 3

D. Fan 4

CPU2

E. Fan A

F. Fan B

G. Chassis Intrusion

P1-DIMMF1

P1-DIMME1

P1-DIMME2

P1-DIMMF2

COM2

USB4/5

JSTBY1

T-SGPIO1

T-SGPIO2

JI2C1

JI2C2

JLPC1

JP3

JPME2

I-SATA5

JPME1

I-SATA4

JWD1

I-SATA1

FANB

JL1

BMC

JPB1

CTRL

JIPMB1

JBT1

JSD1

I-SATA2

SATA/

JSM2

SCU4~7

JVRM_I2C1

JPG1

JVRM_I2C2

PCH

JBAT1

SCU0~3

SATA/

LED2

JF1

JOH1

JD1

JSM1

FANA

SXB1C

LED1

BIOS

JTAG OF CPLD

FAN4

P1-DIMMC2

P1-DIMMC1

P1-DIMMD1

P1-DIMMD2

FAN3

X9DRW-3F/iF Rev.1.02

CPU1

CLOSE 1st

JVR1

OPEN 1st

2-30

OPEN 1st

P1-DIMMG2

P1-DIMMH2

P1-DIMMG1

P1-DIMMH1

JPW3

P1-DIMMA2

P1-DIMMB2

P1-DIMMA1

P1-DIMMB1

JPI2C1

SP1

JPW2

JPW1

FAN2

FAN1

Chapter 2: Installation

SP1

JPW3

JPW2

JPW4

JPB1

FAN2

FAN1

FAN4

FANA

FAN3

JPI2C1

LED3

LED1

COM2

JTAG OF CPLD

SXB1A

SXB1B: CPU PCI-E 3.0 x16 + x16

UID

SXB2: CPU2 PCI-E3.0 X16

LAN2

LAN1

USB2/3

USB0/1

IPMI-LAN

COM1

X9DRW-3F/iF Rev.1.02

VGA

LAN CTRL

BIOS

BMC CTRL

JPW1

PHY

JPL1

B1B2A1A2B1B2A1

SXB1C

JVRM_I2C2

JVRM_I2C1

JPG1

JIPMB1

JSTBY1

JSD1

JD1

JI2C1

JI2C2

JL1

JF1

I-SATA1

I-SATA0

JLPC1

JSM1

JSM2

T-SGPIO1

T-SGPIO2

I-SATA3

I-SATA2

I-SATA5

I-SATA4

JBAT1

JPME2

JWD1

JPME1

JP3

FANB

LED2

SATA/

USB4/5

PCH

JBT1

SCU0~3

SATA/

SCU4~7

JVR1

JUIDB

JOH1

P1-DIMMA1

P1-DIMMA2

P1-DIMMB1

P1-DIMMB2

P1-DIMMD2

P1-DIMMD1

P1-DIMMC2

P1-DIMMF1

P1-DIMME2

P1-DIMME1

P1-DIMMG1

P1-DIMMG2

P1-DIMMH1

P1-DIMMH2

CLOSE 1st

OPEN 1st

CPU1

CLOSE 1st

OPEN 1st

CPU2

P1-DIMMC1

P1-DIMMF2

Internal Speaker

The Internal Speaker, located at SP1,

can be used to provide audible indica-

tions for various beep codes. See the

table on the right for pin denitions.

Refer to the layout below for the loca-

tions of the Internal Buzzer (SP1).

Overheat/Fan Fail LED

The JOH1 header is used to connect

an LED indicator to provide warnings

of chassis overheating and fan failure.

This LED will blink when a fan failure

occurs. Refer to the table on right for

pin denitions.

Internal Buzzer (SP1)

PinDenition

Pin# Denitions

Pin 1 Pos. (+) Beep In

Pin 2 Neg. (-) Alarm

OH/Fan Fail LED

Speaker

Status

State Message

Solid Overheat

Blinking Fan Fail

A. Internal Speaker (Buzz-

er)

B. OH LED

2-31

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

SP1

JPW3

JPW2

JPW4

JPB1

FAN2

FAN1

FAN4

FANA

FAN3

JPI2C1

LED3

LED1

COM2

JTAG OF CPLD

SXB1A

SXB1B: CPU PCI-E 3.0 x16 + x16

UID

SXB2: CPU2 PCI-E3.0 X16

LAN2

LAN1

USB2/3

USB0/1

IPMI-LAN

COM1

X9DRW-3F/iF Rev.1.02

VGA

LAN CTRL

BIOS

BMC CTRL

JPW1

PHY

JPL1

B1B2A1A2B1B2A1

SXB1C

JVRM_I2C2

JVRM_I2C1

JPG1

JIPMB1

JSTBY1

JSD1

JD1

JI2C1

JI2C2

JL1

JF1

I-SATA1

I-SATA0

JLPC1

JSM1

JSM2

T-SGPIO1

T-SGPIO2

I-SATA3

I-SATA2

I-SATA5

I-SATA4

JBAT1

JPME2

JWD1

JPME1

JP3

FANB

LED2

SATA/

USB4/5

PCH

JBT1

SCU0~3

SATA/

SCU4~7

JVR1

JUIDB

JOH1

P1-DIMMA1

P1-DIMMA2

P1-DIMMB1

P1-DIMMB2

P1-DIMMD2

P1-DIMMD1

P1-DIMMC2

P1-DIMMF1

P1-DIMME2

P1-DIMME1

P1-DIMMG1

P1-DIMMG2

P1-DIMMH1

P1-DIMMH2

CLOSE 1st

OPEN 1st

CPU1

CLOSE 1st

OPEN 1st

CPU2

P1-DIMMC1

P1-DIMMF2

Standby Power Connector

The Standby Power connection head-

er is located at JSTBY1 on the moth-

erboard. See the table on the right for

pin denitions. (You must also have a

cable to use this feature.)

Standby Power

PinDenitions

Pin# Denition

1 +5V Standby

2 Ground

3 Wake-up

A. Standby PWR Connector

2-32

Chapter 2: Installation

SP1

JPW3

JPW2

JPW4

JPB1

FAN2

FAN1

FAN4

FANA

FAN3

JPI2C1

LED3

LED1

COM2

JTAG OF CPLD

SXB1A

SXB1B: CPU PCI-E 3.0 x16 + x16

UID

SXB2: CPU2 PCI-E3.0 X16

LAN2

LAN1

USB2/3

USB0/1

IPMI-LAN

COM1

X9DRW-3F/iF Rev.1.02

VGA

LAN CTRL

BIOS

BMC CTRL

JPW1

PHY

JPL1

B1B2A1A2B1B2A1

SXB1C

JVRM_I2C2

JVRM_I2C1

JPG1

JIPMB1

JSTBY1

JSD1

JD1

JI2C1

JI2C2

JL1

JF1

I-SATA1

I-SATA0

JLPC1

JSM1

JSM2

T-SGPIO1

T-SGPIO2

I-SATA3

I-SATA2

I-SATA5

I-SATA4

JBAT1

JPME2

JWD1

JPME1

JP3

FANB

LED2

SATA/

USB4/5

PCH

JBT1

SCU0~3

SATA/

SCU4~7

JVR1

JUIDB

JOH1

P1-DIMMA1

P1-DIMMA2

P1-DIMMB1

P1-DIMMB2

P1-DIMMD2

P1-DIMMD1

P1-DIMMC2

P1-DIMMF1

P1-DIMME2

P1-DIMME1

P1-DIMMG1

P1-DIMMG2

P1-DIMMH1

P1-DIMMH2

CLOSE 1st

OPEN 1st

CPU1

CLOSE 1st

OPEN 1st

CPU2

P1-DIMMC1

P1-DIMMF2

Power SMB (I2C) Connector

Power System Management Bus (I2C)

Connector (JPI2C1) monitors power

supply, fan and system temperatures.

See the table on the right for pin

denitions.

IPMB

A System Management Bus header

for IPMI 2.0 is located at JIPMB1.

Connect the appropriate cable here

to use the IPMB I2C connection on

your system.

PWR SMB

PinDenitions

Pin# Denition

1 Clock

2 Data

3 PWR Fail

4 Ground

5 +3.3V

IPMB Header

PinDenitions

Pin# Denition

1 Data

2 Ground

3 Clock

4 No Connection

A. JPI2C1

B. IPMB

2-33

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

SP1

JPW3

JPW2

JPW4

JPB1

FAN2

FAN1

FAN4

FANA

FAN3

JPI2C1

LED3

LED1

COM2

JTAG OF CPLD

SXB1A

SXB1B: CPU PCI-E 3.0 x16 + x16

UID

SXB2: CPU2 PCI-E3.0 X16

LAN2

LAN1

USB2/3

USB0/1

IPMI-LAN

COM1

X9DRW-3F/iF Rev.1.02

VGA

LAN CTRL

BIOS

BMC CTRL

JPW1

PHY

JPL1

B1B2A1A2B1B2A1

SXB1C

JVRM_I2C2

JVRM_I2C1

JPG1

JIPMB1

JSTBY1

JSD1

JD1

JI2C1

JI2C2

JL1

JF1

I-SATA1

I-SATA0

JLPC1

JSM1

JSM2

T-SGPIO1

T-SGPIO2

I-SATA3

I-SATA2

I-SATA5

I-SATA4

JBAT1

JPME2

JWD1

JPME1

JP3

FANB

LED2

SATA/

USB4/5

PCH

JBT1

SCU0~3

SATA/

SCU4~7

JVR1

JUIDB

JOH1

P1-DIMMA1

P1-DIMMA2

P1-DIMMB1

P1-DIMMB2

P1-DIMMD2

P1-DIMMD1

P1-DIMMC2

P1-DIMMF1

P1-DIMME2

P1-DIMME1

P1-DIMMG1

P1-DIMMG2

P1-DIMMH1

P1-DIMMH2

CLOSE 1st

OPEN 1st

CPU1

CLOSE 1st

OPEN 1st

CPU2

P1-DIMMC1

P1-DIMMF2

T-SGPIO 1/2 Headers

Two SGPIO (Serial-Link General

Purpose Input/Output) headers are

located on the motherboard. These

headers support Serial_Link interface

for onboard SATA connections. See

the table on the right for pin deni-

tions.

DOM Power Connector

A power connector for SATA DOM

(Disk_On_Module) devices is located

at JSD1. Connect an appropriate

cable here to provide power support

for your DOM devices.

T-SGPIO

PinDenitions

Pin# Denition Pin Denition

1 NC 2 NC

3 Ground 4 Data

5 Load 6 Ground

7 Clock 8 NC

Note: NC= No Connection

DOM PWR

PinDenitions

Pin# Denition

1 +5V

2 Ground

3 Ground

A. T-SGPIO1

B. T-SGPIO2

C. SATA DOM PWR

2-34

Chapter 2: Installation

SP1

JPW3

JPW2

JPW4

JPB1

FAN2

FAN1

FAN4

FANA

FAN3

JPI2C1

LED3

LED1

COM2

JTAG OF CPLD

SXB1A

SXB1B: CPU PCI-E 3.0 x16 + x16

UID

SXB2: CPU2 PCI-E3.0 X16

LAN2

LAN1

USB2/3

USB0/1

IPMI-LAN

COM1

X9DRW-3F/iF Rev.1.02

VGA

LAN CTRL

BIOS

BMC CTRL

JPW1

PHY

JPL1

B1B2A1A2B1B2A1

SXB1C

JVRM_I2C2

JVRM_I2C1

JPG1

JIPMB1

JSTBY1

JSD1

JD1

JI2C1

JI2C2

JL1

JF1

I-SATA1

I-SATA0

JLPC1

JSM1

JSM2

T-SGPIO1

T-SGPIO2

I-SATA3

I-SATA2

I-SATA5

I-SATA4

JBAT1

JPME2

JWD1

JPME1

JP3

FANB

LED2

SATA/

USB4/5

PCH

JBT1

SCU0~3

SATA/

SCU4~7

JVR1

JUIDB

JOH1

P1-DIMMA1

P1-DIMMA2

P1-DIMMB1

P1-DIMMB2

P1-DIMMD2

P1-DIMMD1

P1-DIMMC2

P1-DIMMF1

P1-DIMME2

P1-DIMME1

P1-DIMMG1

P1-DIMMG2

P1-DIMMH1

P1-DIMMH2

CLOSE 1st

OPEN 1st

CPU1

CLOSE 1st

OPEN 1st

CPU2

P1-DIMMC1

P1-DIMMF2

Power LED/Speaker

On JD1 header, pins 1-3 are used for

power LED indication, and pins 4-7

are for the speaker. See the tables

on the right for pin denitions. Please

note that the speaker connector

pins (4-7) are used with an external

speaker. If you wish to use the on-

board speaker, you should close pins

6-7 with a jumper.

PWR LED Connector

PinDenitions

Pin Setting Denition

Pin 1 Anode (+)

Pin2 Cathode (-)

Pin3 NA

Speaker Connector

Pin Settings

Pin Setting Denition

Pins 4-7 External Speaker

Pins 6-7 Internal Speaker

A. PWR LED/Speaker

2-35

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

SP1

JPW3

JPW2

JPW4

JPB1

FAN2

FAN1

FAN4

FANA

FAN3

JPI2C1

LED3

LED1

COM2

JTAG OF CPLD

SXB1A

SXB1B: CPU PCI-E 3.0 x16 + x16

UID

SXB2: CPU2 PCI-E3.0 X16

LAN2

LAN1

USB2/3

USB0/1

IPMI-LAN

COM1

X9DRW-3F/iF Rev.1.02

VGA

LAN CTRL

BIOS

BMC CTRL

JPW1

PHY

JPL1

B1B2A1A2B1B2A1

SXB1C

JVRM_I2C2

JVRM_I2C1

JPG1

JIPMB1

JSTBY1

JSD1

JD1

JI2C1

JI2C2

JL1

JF1

I-SATA1

I-SATA0

JLPC1

JSM1

JSM2

T-SGPIO1

T-SGPIO2

I-SATA3

I-SATA2

I-SATA5

I-SATA4

JBAT1

JPME2

JWD1

JPME1

JP3

FANB

LED2

SATA/

USB4/5

PCH

JBT1

SCU0~3

SATA/

SCU4~7

JVR1

JUIDB

JOH1

P1-DIMMA1

P1-DIMMA2

P1-DIMMB1

P1-DIMMB2

P1-DIMMD2

P1-DIMMD1

P1-DIMMC2

P1-DIMMF1

P1-DIMME2

P1-DIMME1

P1-DIMMG1

P1-DIMMG2

P1-DIMMH1

P1-DIMMH2

CLOSE 1st

OPEN 1st

CPU1

CLOSE 1st

OPEN 1st

CPU2

P1-DIMMC1

P1-DIMMF2

Connector

Pins

Jumper

Cap

Setting

2-8 Jumper Settings

Explanation of Jumpers

To modify the operation of the mother-

board, jumpers can be used to choose

between optional settings. Jumpers cre-

ate shorts between two pins to change

the function of the connector. Pin 1

is identied with a square solder pad

on the printed circuit board. See the

motherboard layout pages for jumper

locations.

Note: On two-pin jumpers,

"Closed" means the jumper

is on and "Open" means the

jumper is off the pins.

GLAN Enable/Disable

Use JPL1 to enable/disable LAN Por ts

1/2. See the table on the right for

jumper settings. The default setting is

Enabled.

LAN1/2 Enable

Jumper Settings

Jumper Setting Denition

1-2 Enabled (default)

2-3 Disabled

3 2 1

Pin 1-2 short

A. GLAN1/2 Enable

2-36

Chapter 2: Installation

SP1

JPW3

JPW2

JPW4

JPB1

FAN2

FAN1

FAN4

FANA

FAN3

JPI2C1

LED3

LED1

COM2

JTAG OF CPLD

SXB1A

SXB1B: CPU PCI-E 3.0 x16 + x16

UID

SXB2: CPU2 PCI-E3.0 X16

LAN2

LAN1

USB2/3

USB0/1

IPMI-LAN

COM1

X9DRW-3F/iF Rev.1.02

VGA

LAN CTRL

BIOS

BMC CTRL

JPW1

PHY

JPL1

B1B2A1A2B1B2A1

SXB1C

JVRM_I2C2

JVRM_I2C1

JPG1

JIPMB1

JSTBY1

JSD1

JD1

JI2C1

JI2C2

JL1

JF1

I-SATA1

I-SATA0

JLPC1

JSM1

JSM2

T-SGPIO1

T-SGPIO2

I-SATA3

I-SATA2

I-SATA5

I-SATA4

JBAT1

JPME2

JWD1

JPME1

JP3

FANB

LED2

SATA/

USB4/5

PCH

JBT1

SCU0~3

SATA/

SCU4~7

JVR1

JUIDB

JOH1

P1-DIMMA1

P1-DIMMA2

P1-DIMMB1

P1-DIMMB2

P1-DIMMD2

P1-DIMMD1

P1-DIMMC2

P1-DIMMF1

P1-DIMME2

P1-DIMME1

P1-DIMMG1

P1-DIMMG2

P1-DIMMH1

P1-DIMMH2

CLOSE 1st

OPEN 1st

CPU1

CLOSE 1st

OPEN 1st

CPU2

P1-DIMMC1

P1-DIMMF2

CMOS Clear

JBT1 is used to clear CMOS. Instead of pins, this "jumper" consists of contact pads

to prevent accidental clearing of CMOS. To clear CMOS, use a metal object such

as a small screwdriver to touch both pads at the same time to short the connection.

Always remove the AC power cord from the system before clearing CMOS.

Note 1: For an ATX power supply, you must completely shut down the

system, remove the AC power cord, and then short JBT1 to clear CMOS.

Note 2: Be sure to remove the onboard CMOS Battery before you short

JBT1 to clear CMOS.

Note 3: Clearing CMOS will also clear all passwords.

Watch Dog Enable/Disable

Watch Dog (JWD1) is a system monitor that

can reboot the system when a software appli-

cation hangs. Close pins 1-2 to reset the sys-

tem if an application hangs. Close pins 2-3 to

generate a non-maskable interrupt signal for

Watch Dog

Jumper Settings

Jumper Setting Denition

Pins 1-2 Reset (default)

Pins 2-3 NMI

Open Disabled

the application that hangs. See the table on

the right for jumper settings. Watch Dog must

also be enabled in the BIOS.

2-37

A. Clear CMOS

B. Watch Dog Enable

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

SP1

JPW3

JPW2

JPW4

JPB1

FAN2

FAN1

FAN4

FANA

FAN3

JPI2C1

LED3

LED1

COM2

JTAG OF CPLD

SXB1A

SXB1B: CPU PCI-E 3.0 x16 + x16

UID

SXB2: CPU2 PCI-E3.0 X16

LAN2

LAN1

USB2/3

USB0/1

IPMI-LAN

COM1

X9DRW-3F/iF Rev.1.02

VGA

LAN CTRL

BIOS

BMC CTRL

JPW1

PHY

JPL1

B1B2A1A2B1B2A1

SXB1C

JVRM_I2C2

JVRM_I2C1

JPG1

JIPMB1

JSTBY1

JSD1

JD1

JI2C1

JI2C2

JL1

JF1

I-SATA1

I-SATA0

JLPC1

JSM1

JSM2

T-SGPIO1

T-SGPIO2

I-SATA3

I-SATA2

I-SATA5

I-SATA4

JBAT1

JPME2

JWD1

JPME1

JP3

FANB

LED2

SATA/

USB4/5

PCH

JBT1

SCU0~3

SATA/

SCU4~7

JVR1

JUIDB

JOH1

P1-DIMMA1

P1-DIMMA2

P1-DIMMB1

P1-DIMMB2

P1-DIMMD2

P1-DIMMD1

P1-DIMMC2

P1-DIMMF1

P1-DIMME2

P1-DIMME1

P1-DIMMG1

P1-DIMMG2

P1-DIMMH1

P1-DIMMH2

CLOSE 1st

OPEN 1st

CPU1

CLOSE 1st

OPEN 1st

CPU2

P1-DIMMC1

P1-DIMMF2

VGA Enable

Jumper JPG1 allows the user to enable

the onboard VGA connector. The default

setting is 1-2 to enable the connection.

See the table on the right for jumper

settings.

BMC Enable

Jumper JPB1 allows you to enable the

embedded the Renesas BMC (Base-

board Management) Controller to pro-

vide IPMI 2.0/KVM support on the

motherboard. See the table on the right

for jumper settings.

VGA Enable

Jumper Settings

Jumper Setting Denition

1-2 Enabled (Default)

2-3 Disabled

BMC Enable

Jumper Settings

Jumper Setting Denition

Pins 1-2 BMC Enable

Pins 2-3 Normal (Default)

A. VGA Enabled

B. BMC Enabled

2-38

Chapter 2: Installation

SP1

JPW3

JPW2

JPW4

JPB1

FAN2

FAN1

FAN4

FANA

FAN3

JPI2C1

LED3

LED1

COM2

JTAG OF CPLD

SXB1A

SXB1B: CPU PCI-E 3.0 x16 + x16

UID

SXB2: CPU2 PCI-E3.0 X16

LAN2

LAN1

USB2/3

USB0/1

IPMI-LAN

COM1

X9DRW-3F/iF Rev.1.02

VGA

LAN CTRL

BIOS

BMC CTRL

JPW1

PHY

JPL1

B1B2A1A2B1B2A1

SXB1C

JVRM_I2C2

JVRM_I2C1

JPG1

JIPMB1

JSTBY1

JSD1

JD1

JI2C1

JI2C2

JL1

JF1

I-SATA1

I-SATA0

JLPC1

JSM1

JSM2

T-SGPIO1

T-SGPIO2

I-SATA3

I-SATA2

I-SATA5

I-SATA4

JBAT1

JPME2

JWD1

JPME1

JP3

FANB

LED2

SATA/

USB4/5

PCH

JBT1

SCU0~3

SATA/

SCU4~7

JVR1

JUIDB

JOH1

P1-DIMMA1

P1-DIMMA2

P1-DIMMB1

P1-DIMMB2

P1-DIMMD2

P1-DIMMD1

P1-DIMMC2

P1-DIMMF1

P1-DIMME2

P1-DIMME1

P1-DIMMG1

P1-DIMMG2

P1-DIMMH1

P1-DIMMH2

CLOSE 1st

OPEN 1st

CPU1

CLOSE 1st

OPEN 1st

CPU2

P1-DIMMC1

P1-DIMMF2

Management Engine (ME) Recovery

Use Jumper JPME1 to select ME Firm-

ware Recovery mode, which will limit

resource allocation for essential system

operation only in order to maintain nor-

mal power operation and management.

In the single operation mode, online

upgrade will be available via Recovery

mode. See the table on the right for

jumper settings.

Manufacture Mode Select

Close pins 2 and 3 of Jumper JPME2 to

bypass SPI ash security and force the

system to operate in the Manufacture

Mode, allowing the user to flash the

system rmware from a host server for

system setting modications. See the

table on the right for jumper settings.

ME Recovery

Jumper Settings

Jumper Setting Denition

1-2 Normal (Default)

2-3 ME Recovery

ME Mode Select Jumper Settings

Jumper Setting Denition

1-2 Normal (Default)

2-3 Manufacture Mode

A. JPME1

B. JPME2

2-39

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

I-SATA0

I-SATA3

I2C Bus to PCI-Exp. Slots

Jumpers JI2C1 and JI2C2 allow you to

connect the System Management Bus

(I2C) to PCI-Express slots. The default

setting is Open to disable the connec-

tion. See the table on the right for jumper

settings.

VGA

LED3

UID

JUIDB

SXB1A

B1B2A1A2B1B2A1

SXB2: CPU2 PCI-E3.0 X16

LAN CTRL

LAN2

I2C to PCI-Exp

Jumper Settings

Jumper Setting Denition

Closed Enabled

Open Disabled (Default)

COM1

USB0/1

JPL1

IPMI-LAN

PHY

JPW4

LAN1

USB2/3

A. JI2C1

B. JI2C2

CPU2

SXB1B: CPU PCI-E 3.0 x16 + x16

P1-DIMMF1

P1-DIMME1

P1-DIMME2

P1-DIMMF2

COM2

USB4/5

JSTBY1

T-SGPIO1

T-SGPIO2

JI2C1

JLPC1

JP3

JPME2

I-SATA5

I-SATA4

JWD1

I-SATA1

FANB

JL1

BMC

JPB1

CTRL

JIPMB1

JI2C2

JBT1

JPME1

I-SATA2

SATA/

JSM2

JSD1

SCU4~7

JVRM_I2C1

JPG1

JVRM_I2C2

PCH

JBAT1

SCU0~3

SATA/

LED2

JF1

JOH1

JD1

JSM1

FANA

SXB1C

LED1

BIOS

JTAG OF CPLD

FAN4

P1-DIMMC2

P1-DIMMC1

P1-DIMMD1

P1-DIMMD2

FAN3

X9DRW-3F/iF Rev.1.02

CLOSE 1st

JVR1

CLOSE 1st

OPEN 1st

P1-DIMMG2

P1-DIMMH2

P1-DIMMG1

P1-DIMMH1

JPW3

P1-DIMMA2

P1-DIMMB2

P1-DIMMA1

CPU1

OPEN 1st

FAN2

P1-DIMMB1

FAN1

JPI2C1

SP1

JPW2

JPW1

2-40

Chapter 2: Installation

SP1

JPW3

JPW2

JPW4

JPB1

FAN2

FAN1

FAN4

FANA

FAN3

JPI2C1

LED3

LED1

COM2

JTAG OF CPLD

SXB1A

SXB1B: CPU PCI-E 3.0 x16 + x16

UID

SXB2: CPU2 PCI-E3.0 X16

LAN2

LAN1

USB2/3

USB0/1

IPMI-LAN

COM1

X9DRW-3F/iF Rev.1.02

VGA

LAN CTRL

BIOS

BMC CTRL

JPW1

PHY

JPL1

B1B2A1A2B1B2A1

SXB1C

JVRM_I2C2

JVRM_I2C1

JPG1

JIPMB1

JSTBY1

JSD1

JD1

JI2C1

JI2C2

JL1

JF1

I-SATA1

I-SATA0

JLPC1

JSM1

JSM2

T-SGPIO1

T-SGPIO2

I-SATA3

I-SATA2

I-SATA5

I-SATA4

JBAT1

JPME2

JWD1

JPME1

JP3

FANB

LED2

SATA/

USB4/5

PCH

JBT1

SCU0~3

SATA/

SCU4~7

JVR1

JUIDB

JOH1

P1-DIMMA1

P1-DIMMA2

P1-DIMMB1

P1-DIMMB2

P1-DIMMD2

P1-DIMMD1

P1-DIMMC2

P1-DIMMF1

P1-DIMME2

P1-DIMME1

P1-DIMMG1

P1-DIMMG2

P1-DIMMH1

P1-DIMMH2

CLOSE 1st

OPEN 1st

CPU1

CLOSE 1st

OPEN 1st

CPU2

P1-DIMMC1

P1-DIMMF2

LAN 1/LAN 2

2-9 Onboard LED Indicators

GLAN LEDs

The LAN 1/2 ports are located on the IO

Backplane. Each Ethernet LAN port has

two LEDs. The Yellow LED on the right

indicates activity. The Link LED on the left

may be green, amber or off to indicate the

speed. See the tables on the right for more

information.

IPMI_Dedicated_LAN LEDs

In addition to the Gigabit Ethernet ports,

an IPMI Dedicated LAN is also located

above the Backplane USB ports 0/1 on the

motherboard. The amber LED on the right

indicates activity, while the green LED on

the left indicates the speed of the connec-

tion. See the table on the right for more

information.

Link LED

Activity LED

Rear View (when facing the rear side of the chassis)

GLAN Activity Indicator (Right)

LED Settings

Color Status Denition

Yellow Flashing Active

GLAN Link Indicator (Left)

LED Settings

LED Color Denition

Off No Connection or 10 Mbps

Green 100 Mbps

Amber 1 Gbps

IPMI LAN

Link LED

IPMI LAN Link LED (Left) &

Activity LED (Right)

Color/State Denition

Link (Left) Green: Solid

Amber: Solid

Activity (Right) Amber: Blinking Active

Activity LED

100 Mbps 1 Gbps

A. Ethernet Port

LEDs

B. IPMI LAN LEDs

2-41

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

SP1

JPW3

JPW2

JPW4

JPB1

FAN2

FAN1

FAN4

FANA

FAN3

JPI2C1

LED3

LED1

COM2

JTAG OF CPLD

SXB1A

SXB1B: CPU PCI-E 3.0 x16 + x16

UID

SXB2: CPU2 PCI-E3.0 X16

LAN2

LAN1

USB2/3

USB0/1

IPMI-LAN

COM1

X9DRW-3F/iF Rev.1.02

VGA

LAN CTRL

BIOS

BMC CTRL

JPW1

PHY

JPL1

B1B2A1A2B1B2A1

SXB1C

JVRM_I2C2

JVRM_I2C1

JPG1

JIPMB1

JSTBY1

JSD1

JD1

JI2C1

JI2C2

JL1

JF1

I-SATA1

I-SATA0

JLPC1

JSM1

JSM2

T-SGPIO1

T-SGPIO2

I-SATA3

I-SATA2

I-SATA5

I-SATA4

JBAT1

JPME2

JWD1

JPME1

JP3

FANB

LED2

SATA/

USB4/5

PCH

JBT1

SCU0~3

SATA/

SCU4~7

JVR1

JUIDB

JOH1

P1-DIMMA1

P1-DIMMA2

P1-DIMMB1

P1-DIMMB2

P1-DIMMD2

P1-DIMMD1

P1-DIMMC2

P1-DIMMF1

P1-DIMME2

P1-DIMME1

P1-DIMMG1

P1-DIMMG2

P1-DIMMH1

P1-DIMMH2

CLOSE 1st

OPEN 1st

CPU1

CLOSE 1st

OPEN 1st

CPU2

P1-DIMMC1

P1-DIMMF2

Onboard Power LED

An Onboard Power LED is located at

LED2 on the motherboard. When this

LED is on, the system is on. Be sure to

turn off the system and unplug the power

cord before removing or installing compo-

nents. See the table on the right for more

information.

Rear UID LED

The rear UID LED is located at LED3 on

the rear of the motherboard. This LED

is used in conjunction with the rear UID

switch to provide easy identication of a

system that might be in need of service.

Refer to UID Switch on page 2-23 for

more information.

Onboard PWR LED Indicator

LED Settings

LED Color Status

Off System Off (PWR cable

not connected)

Green System On

Green: Flashing Quickly

ACPI S1 State

UID LED

Status

Color/State Status

Blue: On Unit Identied

A. PWR LED

B. Rear UID LED

2-42

Chapter 2: Installation

SP1

JPW3

JPW2

JPW4

JPB1

FAN2

FAN1

FAN4

FANA

FAN3

JPI2C1

LED3

LED1

COM2

JTAG OF CPLD

SXB1A

SXB1B: CPU PCI-E 3.0 x16 + x16

UID

SXB2: CPU2 PCI-E3.0 X16

LAN2

LAN1

USB2/3

USB0/1

IPMI-LAN

COM1

X9DRW-3F/iF Rev.1.02

VGA

LAN CTRL

BIOS

BMC CTRL

JPW1

PHY

JPL1

B1B2A1A2B1B2A1

SXB1C

JVRM_I2C2

JVRM_I2C1

JPG1

JIPMB1

JSTBY1

JSD1

JD1

JI2C1

JI2C2

JL1

JF1

I-SATA1

I-SATA0

JLPC1

JSM1

JSM2

T-SGPIO1

T-SGPIO2

I-SATA3

I-SATA2

I-SATA5

I-SATA4

JBAT1

JPME2

JWD1

JPME1

JP3

FANB

LED2

SATA/

USB4/5

PCH

JBT1

SCU0~3

SATA/

SCU4~7

JVR1

JUIDB

JOH1

P1-DIMMA1

P1-DIMMA2

P1-DIMMB1

P1-DIMMB2

P1-DIMMD2

P1-DIMMD1

P1-DIMMC2

P1-DIMMF1

P1-DIMME2

P1-DIMME1

P1-DIMMG1

P1-DIMMG2

P1-DIMMH1

P1-DIMMH2

CLOSE 1st

OPEN 1st

CPU1

CLOSE 1st

OPEN 1st

CPU2

P1-DIMMC1

P1-DIMMF2

BMC Heartbeat LED

A BMC Hear tbeat LED is located at LED1

on the motherboard. When LED1 is blink-

ing, BMC functions normally. See the

table on the right for more information.

BMC Heartbeat LED

Status

Color/State Denition

Green: Blinking

BMC: Normal

A. BMC Heartbeat

LED

2-43

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

I-SATA0

I-SATA3

2-10 SATA/SCU Connections

SATA/SCU Ports

There are six Serial ATA ports (I- SATA0~I-

SATA 5) located on the motherboard, in-

cluding four SATA2 ports and two SATA3

ports. There are also eight SCU por ts

(0~3, 4~7) located on the X9DRW-3F, and

four SCU por ts (SCU 0~3) located on the

X9DRW-iF. These ports provide serial-link

signal connections, which are faster than

the connections of Parallel ATA. See the

table on the right for pin denitions.

Note: For more information on SATA HostRAID conguration, please refer

to the Intel SATA HostRAID User's Guide posted on our website @ http://

www.supermicro.com.

Pin# Denition

1 Ground

2 TX_P

3 TX_N

4 Ground

5 RX_N

6 RX_P

7 Ground

SATA/SCU

PinDenitions

LED3

UID

JUIDB

SXB1A

B1B2A1A2B1B2A1

SXB2: CPU2 PCI-E3.0 X16

SXB1B: CPU PCI-E 3.0 x16 + x16

VGA

LAN CTRL

LAN1

LAN2

USB2/3

CPU2

CLOSE 1st

USB0/1

IPMI-LAN

COM1

JPL1

PHY

A. I-SATA0

B. I-SATA1

JPW4

C. I-SATA2

D. I-SATA3

E. I-SATA4

F. I-SATA5

G. SCU 0~3

(for X9DRW-

JPW3

JPI2C1

SP1

JPW2

3F/iF)

H. SCU 4~7

(for X9DRW-

3F)

P1-DIMMF1

P1-DIMME1

P1-DIMME2

P1-DIMMF2

COM2

USB4/5

JSTBY1

T-SGPIO1

T-SGPIO2

JI2C1

JLPC1

I-SATA5

I-SATA4

I-SATA1

FANB

JL1

BMC

JPB1

CTRL

JIPMB1

JI2C2

JP3

JPME2

JBT1

JPME1

JWD1

I-SATA2

SATA/

JSM2

JSD1

SCU4~7

JVRM_I2C1

JPG1

JVRM_I2C2

PCH

JBAT1

SCU0~3

SATA/

LED2

JF1

JOH1

JD1

JSM1

FANA

SXB1C

LED1

BIOS

JTAG OF CPLD

FAN4

P1-DIMMC2

P1-DIMMC1

P1-DIMMD1

P1-DIMMD2

FAN3

X9DRW-3F/iF Rev.1.02

CLOSE 1st

JVR1

CPU1

OPEN 1st

2-44

OPEN 1st

P1-DIMMG2

P1-DIMMH2

P1-DIMMG1

P1-DIMMH1

P1-DIMMA2

P1-DIMMB2

P1-DIMMA1

P1-DIMMB1

JPW1

FAN2

FAN1

Chapter 3: Troubleshooting

Chapter 3

Troubleshooting

3-1 Troubleshooting Procedures

Use the following procedures to troubleshoot your system. If you have followed all

of the procedures below and still need assistance, refer to the ‘Technical Support

Procedures’ and/or ‘Returning Merchandise for Service’ section(s) in this chapter.

Always disconnect the AC power cord before adding, changing or installing any

hardware components.

Before Power On

1. Make sure that there are no short circuits between the motherboard and

chassis.

2. Disconnect all ribbon/wire cables from the motherboard, including those for

the keyboard and mouse, if any.

3. Remove all add-on cards.

4. Install CPU 1 rst (making sure it is fully seated) and connect the front panel

connectors to the motherboard.

No Power

1. Make sure that there are no short circuits between the motherboard and the

chassis.

2. Make sure that the ATX power connectors are properly connected

3. Check that the 115V/230V switch on the power supply is properly set, if avail-

able.

4. Turn the power switch on and off to test the system, if applicable.

5. The battery on your motherboard may be old. Check to verify that it still sup-

plies ~3VDC. If it does not, replace it with a new one.

3-1

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

No Video

1. If the power is on, but you have no video, remove all the add-on cards and

cables.

2. Use the speaker to determine if any beep codes exist. Refer to Appendix A

for details on beep codes.

System Boot Failure

If the system does not display POST or does not respond after the power is turned

on, check the following:

1. Check for any error beep from the motherboard speaker.

•If there is no error beep, try to turn on the system without DIMM modules in-

stalled. If there is still no error beep, try to turn on the system again with only

one processor installed in CPU Socket#1. If there is still no error beep, replace

the motherboard.

•If there are error beeps, clear the CMOS settings by unplugging the power

cord and contracting both pads on the CMOS Clear Jumper (JBT1). (Refer to

Section 2-8 in Chapter 2.)

2. Remove all components from the motherboard, especially the DIMM mod-

ules. Make sure that the system's power is on, and memory error beeps are

activated.

3. Turn on the system with only one DIMM module installed. If the system

boots, check for bad DIMM modules or slots by following the Memory Errors

Troubleshooting procedure in this Chapter.

LosingtheSystem’sSetupConguration

1. Please be sure to use a high quality power supply. A poor quality power sup-

ply may cause the system to lose CMOS setup information. Refer to Section

1-6 for details on recommended power supplies.

2. The battery on your motherboard may be old. Check to verify that it still sup-

plies ~3VDC. If it does not, replace it with a new one.

3. If the above steps do not x the Setup Conguration problem, contact your

vendor for repairs.

3-2

Chapter 3: Troubleshooting

Memory Errors

When a No-Memory Beep Code is issued by the system, check the following:

1. Make sure that the memory modules are compatible with the system and that

the DIMM modules are properly and fully installed. (For memory compatibility,

refer to the Memory Compatibility Chart posted on our Website @ http://www.

supermicro.com.)

2. Check if different speeds of DIMMs have been installed. It is strongly recom-

mended that you use the same RAM speed for all DIMMs in the system.

3. Make sure that you are using the correct type of Registered (RDIMM)/Load

Reduced (LRDIMM) ECC or Unbuffered (UDIMM) ECC/Non-ECC DDR3

800/1066/1333/1600/1866 MHz modules recommended by the manufacturer.

4. Check for bad DIMM modules or slots by swapping a single module among

all memory slots and check the results.

5. Make sure that all memory modules are fully seated in their slots. Follow the

instructions given in Section 2-4 in Chapter 2.

6. Please follow the instructions given in the DIMM Population Tables listed in

Section 2-4 to install your memory modules.

When the System Becomes Unstable

A. When the system becomes unstable during or after OS installation, check

the following:

1. CPU/BIOS support: Make sure that your CPU is supported, and you have the

latest BIOS installed in your system.

2. Memory support: Make sure that the memory modules are supported by test-

ing the modules using memtest86 or a similar utility.

Note: Refer to the product page on our website http://www.supermicro.

com for memory and CPU support and updates.

3. HDD support: Make sure that all hard disk drives (HDDs) work properly. Re-

place the bad HDDs with good ones.

4. System cooling: Check system cooling to make sure that all heatsink fans,

and CPU/system fans, etc. work properly. Check Hardware Monitoring set-

tings in the BIOS to make sure that the CPU and System temperatures are

3-3

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

within the normal range. Also check the front panel Overheat LED, and make

sure that the Overheat LED is not on.

5. Adequate power supply: Make sure that the power supply provides adequate

power to the system. Make sure that all power connectors are connected.

Please refer to our website for more information on minimum power require-

ment.

6. Proper software support: Make sure that the correct drivers are used.

B. When the system becomes unstable before or during OS installation, check

the following:

1. Source of installation: Make sure that the devices used for installation are

working properly, including boot devices such as CD/DVD disc, CD/DVD-

ROM.

2. Cable connection: Check to make sure that all cables are connected and

working properly.

3. Using minimum conguration for troubleshooting: Remove all unnecessary

components (starting with add-on cards rst), and use minimum conguration

(with a CPU and a memory module installed) to identify the trouble areas.

Refer to the steps listed in Section A above for proper troubleshooting proce-

dures.

4. Identifying bad components by isolating them: If necessary, remove a compo-

nent in question from the chassis, and test it in isolation to make sure that it

works properly. Replace a bad component with a good one.

5. Check and change one component at a time instead of changing several

items at the same time. This will help isolate and identify the problem.

6. To nd out if a component is good, swap this component with a new one to

see if the system will work properly. If so, then the old component is bad.

You can also install the component in question in another system. If the new

system works, the component is good and the old system has problems.

3-4

Chapter 3: Troubleshooting

3-2 Technical Support Procedures

Before contacting Technical Support, please make sure that you have followed all

the steps listed below. Also, Note that as a motherboard manufacturer, Supermicro

does not sell directly to end users, so it is best to rst check with your distributor or

reseller for troubleshooting services. They should know of any possible problem(s)

with the specic system conguration that was sold to you.

1. Please go through the ‘Troubleshooting Procedures’ and 'Frequently Asked

Question' (FAQ) sections in this chapter or see the FAQs on our website

(http://www.supermicro.com/) before contacting Technical Support.

2. BIOS upgrades can be downloaded from our website (http://www.supermicro.

com).

3. If you still cannot resolve the problem, include the following information when

contacting Supermicro for technical support:

•Motherboard model and PCB revision number

•BIOS release date/version (This can be seen on the initial display when your

system rst boots up.)

•System conguration

4. An example of a Technical Support form is on our website at (http://www.

supermicro.com).

•Distributors: For immediate assistance, please have your account number ready

when placing a call to our technical support department. We can be reached by

e-mail at support@supermicro.com.

3-5

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

3-3 Battery Removal and Installation

Battery Removal

To remove the onboard battery, follow the steps below:

1. Power off your system and unplug your power cable.

2. Locate the onboard battery as shown below.

3. Using a tool such as a pen or a small screwdriver, push the battery lock out-

wards to unlock it. Once unlocked, the battery will pop out from the holder.

4. Remove the battery.

Proper Battery Disposal

Warning: Please handle used batteries carefully. Do not damage the battery in any

way; a damaged battery may release hazardous materials into the environment. Do

not discard a used battery in the garbage or a public landll. Please comply with the

regulations set up by your local hazardous waste management agency to dispose of

your used battery properly.

Battery Installation

1. To install an onboard battery, follow the steps 1 & 2 above and continue

below:

2. Identify the battery's polarity. The positive (+) side should be facing up.

3. Insert the battery into the battery holder and push it down until you hear a

click to ensure that the battery is securely locked.

Warning: When replacing a battery, be sure to only replace it with the same type.

3-6

Chapter 3: Troubleshooting

3-4 Frequently Asked Questions

Question: What are the various types of memory that my motherboard can

support?

Answer: The motherboard supports Registered/Load Reduced ECC or Unbuffered

ECC/Non-ECC DDR3 DIMM modules. To enhance memory performance, do not mix

memory modules of different speeds and sizes. Please follow all memory installation

instructions given on Section 2-4 in Chapter 2.

Question: How do I update my BIOS?

It is recommended that you do not upgrade your BIOS if you are not experiencing

any problems with your system. Updated BIOS les are located on our website

at http://www.supermicro.com. Please check our BIOS warning message and the

information on how to update your BIOS on our website. Select your motherboard

model and download the BIOS le to your computer. Also, check the current BIOS

revision to make sure that it is newer than your BIOS before downloading. You can

choose from the zip le and the .exe le. If you choose the zip BIOS le, please

unzip the BIOS le onto a bootable USB device. Run the batch le using the format

AMI.bat lename.rom from your bootable USB device to ash the BIOS. Then, your

system will automatically reboot.

Warning: Do not shut down or reset the system while updating the BIOS to prevent

possible system boot failure!)

Note: The SPI BIOS chip used on this motherboard cannot be removed.

Send your motherboard back to our RMA Department at Supermicro for

repair. For BIOS Recovery instructions, please refer to the AMI BIOS

Recovery Instructions posted at http://www.supermicro.com.

Question: How do I handle the used battery?

Answer: Please handle used batteries carefully. Do not damage the battery in any

way; a damaged battery may release hazardous materials into the environment.

Do not discard a used battery in the garbage or a public landll. Please comply

with the regulations set up by your local hazardous waste management agency to

dispose of your used battery properly.

3-7

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

3-5 Returning Merchandise for Service

A receipt or copy of your invoice marked with the date of purchase is required before

any warranty service will be rendered. You can obtain service by calling your ven-

dor for a Returned Merchandise Authorization (RMA) number. When returning the

motherboard to the manufacturer, the RMA number should be prominently displayed

on the outside of the shipping carton, and the shipping package is mailed prepaid

or hand-carried. Shipping and handling charges will be applied for all orders that

must be mailed when service is complete. For faster service, you can also request

a RMA authorization online (http://www.supermicro.com/RmaForm/).

This warranty only covers normal consumer use and does not cover damages in-

curred in shipping or from failure due to the alternation, misuse, abuse or improper

maintenance of products.

During the warranty period, contact your distributor rst for any product problems.

3-8

Chapter 4: AMI BIOS

Chapter 4

BIOS

4-1 Introduction

This chapter describes the AMI BIOS Setup utility for the X9DRW-3F/X9DRW-iF. It

also provides the instructions on how to navigate the AMI BIOS Setup utility screens.

The AMI ROM BIOS is stored in a Flash EEPROM and can be easily updated.

Starting BIOS Setup Utility

To enter the AMI BIOS Setup utility screens, press the <Del> key while the system

is booting up.

Note: In most cases, the <Del> key is used to invoke the AMI BIOS setup

screen. There are a few cases when other keys are used, such as <F3>,

<F4>, etc.

Each main BIOS menu option is described in this manual. The Main BIOS setup

menu screen has two main frames. The left frame displays all the options that can

be congured. Grayed-out options cannot be congured. Options in blue can be

congured by the user. The right frame displays the key legend. Above the key

legend is an area reserved for a text message. When an option is selected in the

left frame, it is highlighted in white. Often a text message will accompany it.

Note: The AMI BIOS has default text messages built in. The manufacturer

retains the option to include, omit, or change any of these text mes-

sages.

The AMI BIOS Setup utility uses a key-based navigation system called "hot keys."

Most of the AMI BIOS setup utility "hot keys" can be used at any time during setup

navigation. These keys include <F3>, <F4>, <Enter>, <ESC>, arrow keys, etc.

Note 1: Options printed in Bold are default settings.

Note 2: <F3> is used to load optimal default settings. <F4> is used to save

the settings and exit the setup utility.

Note 3: For AMI UEFI BIOS Recovery, please refer to the UEFI BIOS Re-

covery User Guide posted @http://www.supermicro.com/support/manuals/.

4-1

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

Warning: Do not upgrade the BIOS unless your system has a BIOS-related issue.

Flashing the wrong BIOS can cause irreparable damage to the system. In no event

shall the manufacturer be liable for direct, indirect, special, incidental, or consequential

damage arising from a BIOS update. If you have to update the BIOS, do not shut down

or reset the system while the BIOS is being updated to avoid possible boot failure.

4-2 Main Setup

When you rst enter the AMI BIOS Setup utility, you will enter the Main setup screen.

You can always return to the Main setup screen by selecting the Main tab on the

top of the screen. The Main BIOS Setup screen is shown below.

The AMI BIOS main menu displays the following information:

System Date

This item displays the system date in Day MM/DD/YY format (e.g. Wed 10/12/2011).

System Time

This item displays the system time in HH:MM:SS format (e.g. 15:32:52).

Supermicro X9DRW (Motherboard Model Name)

Version

This item displays the SMC version of the BIOS ROM used in this system.

Build Date

This item displays the date that the BIOS ROM was built.

4-2

Chapter 4: AMI BIOS

Memory Information

Total Memory

This displays the amount of memory that is available in the system.

4-3 AdvancedSetupCongurations

Use the arrow keys to select Advanced Setup and press <Enter> to access the

following submenu items.

Boot Features

Quiet Boot

This feature allows the user to select bootup screen display between POST mes-

sages and the OEM logo. Select Disabled to display the POST messages. Select

Enabled to display the OEM logo instead of the normal POST messages. The op-

tions are Enabled and Disabled.

AddOn ROM Display Mode

Use this item to set the display mode for the Option ROM. Select Keep Current to

use the current AddOn ROM Display setting. Select Force BIOS to use the Option

ROM display mode set by the system BIOS. The options are Force BIOS and

Keep Current.

Bootup Num-Lock

Use this feature to set the Power-on state for the Numlock key. The options are

Off and On.

4-3

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

Wait For 'F1' If Error

Select Enabled to force the system to wait until the 'F1' key is pressed if an error

occurs. The options are Disabled and Enabled.

Interrupt 19 Capture

Interrupt 19 is the software interrupt that handles the boot disk function. When this

item is set to Enabled, the ROM BIOS of the host adaptors will "capture" Interrupt 19

at bootup and allow the drives that are attached to these host adaptors to function

as bootable disks. If this item is set to Disabled, the ROM BIOS of the host adap-

tors will not capture Interrupt 19, and the drives attached to these adaptors will not

function as bootable devices. The options are Enabled and Disabled.

PowerConguration

Watch Dog Function

If enabled, the Watch Dog timer will allow the system to reboot when it is inactive

for more than 5 minutes. The options are Enabled and Disabled.

Power Button Function

If this feature is set to Instant Off, the system will power off immediately as soon

as the user presses the power button. If this feature is set to 4 Seconds Override,

the system will power off when the user presses the power button for 4 seconds or

longer. The options are Instant Off and 4 Seconds Override.

Restore on AC Power Loss

Use this feature to set the power state after a power outage. Select Stay Off for the

system power to remain off after a power loss. Select Power-On for the system

power to be turned on after a power loss. Select Last State to allow the system

to resume its last state before a power loss. The options are Stay Off, Power On,

and Last State.

CPUConguration

This submenu displays the information of the CPU as detected by the BIOS. It also

allows the user to congure the CPU settings.

Socket 1 CPU Information/Socket 2 CPU Information

This submenu displays the following information regarding the CPUs installed

in Socket 1/ Socket 2.

4-4

•Type of CPU

•CPU Signature

•Microcode Patch

•CPU Stepping

•Maximum CPU Speed

•Minimum CPU Speed

•Processor Cores

•Intel HT (Hyper-Threading) Technology

•Intel VT-x Technology

•Intel SMX Technology

•L1 Data Cache

•L1 Code Cache

Chapter 4: AMI BIOS

•L2 Cache

•L3 Cache

CPU Speed

This item displays the speed of the CPU installed in Socket 1/Socket 2.

64-bit

This item indicates if the CPU installed in Socket 1 or Socket 2 supports 64-bit technology.

Clock Spread Spectrum

Select Enable to enable Clock Spectrum support, which will allow the BIOS to moni-

tor and attempt to reduce the level of Electromagnetic Interference caused by the

components whenever needed. The options are Disabled and Enabled.

Hyper-threading

Select Enabled to support Intel Hyper-threading Technology to enhance CPU per-

formance. The options are Enabled and Disabled.

4-5

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

Active Processor Cores

Set to Enabled to use a processor's second core and above. (Please refer to Intel's

website for more information.) The options are All, 1, 2, and 4.

Limit CPUID Maximum

This feature allows the user to set the maximum CPU ID value. Enable this function

to boot the legacy operating systems that cannot support processors with extended

CPUID functions. The options are Disabled (for the Windows OS), and Enabled.

Execute Disable Bit Capability (Available if supported by the OS & the CPU)

Select Enabled to enable the Execute Disable Bit which will allow the processor to

designate areas in the system memory where an application code can execute and

where it cannot, thus preventing a worm or a virus from ooding illegal codes to

overwhelm the processor or damage the system during an attack. The options are

Enabled and Disabled. (Refer to Intel and Microsoft Web sites for more information.)

Intel® AES-NI

Select Enable to use the Intel Advanced Encryption Standard (AES) New Instruc-

tions (NI) to ensure data security. The options are Enabled and Disabled.

Hardware Prefetcher (Available when supported by the CPU)

If set to Enabled, the hardware prefetcher will prefetch streams of data and instruc-

tions from the main memory to the L2 cache to improve CPU performance. The

options are Disabled and Enabled.

Adjacent Cache Line Prefetch (Available when supported by the CPU)

The CPU prefetches the cache line for 64 bytes if this feature is set to Disabled.

The CPU prefetches both cache lines for 128 bytes as comprised if this feature is

set to Enabled.

DCU Streamer Prefetcher (Available when supported by the CPU)

Select Enabled to support Data Cache Unite (DCU) prefetch to speed up data

accessing and processing in the DCU to enhance CPU performance. The options

are Disabled and Enabled.

DCU IP Prefetcher

Select Enabled for DCU (Data Cache Unit) IP Prefetcher support, which will prefetch

IP addresses to improve network connectivity and system performance. The options

are Enabled and Disabled.

4-6

Chapter 4: AMI BIOS

Intel® Virtualization Technology (Available when supported by the CPU)

Select Enabled to suppor t Intel Virtualization Technology, which will allow one

platform to run multiple operating systems and applications in independent parti-

tions, creating multiple "virtual" systems in one physical computer. The options

are Enabled and Disabled.

Note: If there is any change to this setting, you will need to power off and

restart the system for the change to take effect. Please refer to Intel’s

website for detailed information.)

 CPUPowerManagementConguration

This submenu allows the user to congure the following CPU Power Management

settings.

Power Technology

Select Energy Efcient to support power-saving mode. Select Custom to cus-

tomize system power settings. Select Disabled to disable power-saving settings.

The options are Disabled, EnergyEfcient, and Custom. If the option is set to

Custom, the following items will display:

EIST (Available when Power Technology is set to Custom)

EIST (Enhanced Intel SpeedStep Technology) allows the system to au-

tomatically adjust processor voltage and core frequency to reduce power

consumption and heat dissipation. The options are Disabled (GV3 Disabled),

and Enabled (GV3 Enabled). (Note: GV3 is Intel Speedstep support used

on older platforms.)Please refer to Intel’s website for detailed information.)

Turbo Mode (Available when Power Technology is set to Custom)

Select Enabled to use the Turbo Mode to boost system performance. The

options are Enabled and Disabled.

C1E (Available when Power Technology is set to Custom)

Select Enabled to enable Enhanced C1 Power State to maximize energy

efciency. The options are Enabled and Disabled.

CPU C3 Report (Available when Power Technology is set to Custom)

Select Enabled to allow the BIOS to report the CPU C3 State (ACPI C2) to

the operating system. During the CPU C3 State, the CPU clock generator

is turned off. The options are Enabled and Disabled.

4-7

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

CPU C6 Report (Available when Power Technology is set to Custom)

Select Enabled to allow the BIOS to report the CPU C6 State (ACPI C3) to

the operating system. During the CPU C6 State, the power to all cache is

turned off. The options are Enabled and Disabled.

CPU C7 Report (Available when Power Technology is set to Custom)

Select Enabled to allow the BIOS to report the CPU C7 State (ACPI C3) to

the operating system. CPU C7 State is a processor-specic low C-State.

The options are Enabled and Disabled.

Package C-State limit (Available when Power Technology is set to

Custom)

This feature allows the user to set the limit on the C-State package register.

The options are C0, C2, C6, and No Limit.

Factory Long Duration Power Limit

This item displays the power limit set by the manufacturer during which long

duration power is maintained.

Long Duration Power Limit

This item displays the user-dened power limit (in watts) during which long

duration power is maintained.

Factory Long Duration Maintained (Available when Power Technology

is set to Custom)

This item displays the period of time set by the manufacturer during which

long duration power is maintained.

Long Duration Maintained

This item displays the period of time in seconds during which long duration

power is maintained.

Recommended Short Duration Power

This item displays the short duration power settings recommended by the

manufacturer.

Short Duration Power Limit

This item displays the time period during which short duration power is

maintained.

4-8

Chapter 4: AMI BIOS

ChipsetConguration

North Bridge

This feature allows the user to congure the settings for the Intel North Bridge.

IntegratedIOConguration

Intel VT-d

Select Enabled to enable Intel Virtualization Technology support for Direct I/O VT-d by reporting the I/O device assignments to the VWM (Virtual Working

Memory) through the DMAR ACPI Tables. This feature offers fully-protected

I/O resource sharing across Intel platforms, providing greater reliability, security

and availability in networking and data-sharing. The options are Disabled and

Enabled.

Intel I/OAT

The Intel I/OAT (I/O Acceleration Technology) signicantly reduces CPU over-

head by leveraging CPU architectural improvements, freeing the system resource

for other tasks. The options are Disabled and Enabled.

DCA Support

Select Enabled to use Intel's DCA (Direct Cache Access) Technology to improve

data transfer efciency. The options are Disabled and Enabled.

IIO 1 PCIe Port Bifurcation Control/ IIO 2 PCIe Port Bifurcation Control

This submenu congures the following IO PCIe Port Bifurcation Control settings

for IIO 1 PCIe ports or IIO 2 PCIe ports to determine how the available PCI-

Express lanes are distributed between the PCI-Express Root Ports.

IIO 2 PCIe Port

This item congures IOU2-PCIe Port settings. The options are: x4x4x4x4,

x4x4x8, x8x4x4, x8x8, x16 and Auto.

IIO 3 PCIe Port

This item congures IOU3-PCIe Port settings. The options are: x4x4x4x4,

x4x4x8, x8x4x4, x8x8, x16 and Auto.

4-9

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

QPIConguration

Current QPI Link

This item displays the current status of the QPI Link.

Current QPI Frequency

This item displays the frequency of the QPI Link.

Isoc

Select Enabled to enable Isochronous support to meet QoS (Quality of Service)

requirements. This feature is especially important for virtualization technology.

The options are Enabled and Disabled.

QPI (Quick Path Interconnect) Link Speed Mode

Use this feature to select data transfer speed for QPI Link connections. The

options are Fast and Slow.

QPI Link Frequency Select

Use this feature to select the desired QPI frequency. The options are Auto, 6.4

GT/s, 7.2 GT/s, and 8.0 GT/s.

DIMMConguration

This section displays the following DIMM information.

Current Memory Mode

This item displays the current memory mode.

Current Memory Speed

This item displays the current memory speed.

Mirroring

This item displays if memory mirroring is supported by the motherboard. Memory

mirroring creates a duplicate copy of the data stored in the memory to enhance

data security.

Sparing

This item displays if memory sparing is supported by the motherboard. Memory

sparing enhances system performance.

4-10

Chapter 4: AMI BIOS

DIMM Information

The status of the memory modules specied below will be displayed as detected

by the BIOS.

CPU Socket 1 DIMM Information

P1-DIMMA1/P1-DIMMB1/P1-DIMMC1/P1-DIMMD1/P1-DIMMA2/P1-DIMMB2/

P1-DIMMC2/P1-DIMMD2

CPU Socket 2 DIMM Information

P2-DIMME1/P2-DIMMF1/P2-DIMMG1/P2-DIMMH1/P2-DIMME2/P2-DIMMF2/

P2-DIMMG2/P2-DIMMH2

Memory Mode

When Independent is selected, all DIMMs are available to the operating system.

When Mirroring is selected, the motherboard maintains two identical copies of all

data in memory for data backup. When Lockstep is selected, the motherboard

uses two areas of memory to run the same set of operations in parallel. The

options are Independent, Mirroring, and Lockstep.

DRAM RAPL Mode

RAPL (Running Average Power Limit) provides mechanisms to enforce power

consumption limits on supported processors The options are Disabled, DRAM

RAPL MODE0 , and DRAM RAPL MODE1.

DDR Speed

Use this feature to force a DDR3 memory module to run at a frequency other

than what is specied in the specication. The options are Auto, Force DDR3-

800, Force DDR3-1066, Force DDR3-1333, Force DDR3-1600 and Force SPD.

Channel Interleaving

This feature selects from the different channel interleaving methods. The options

are Auto, 1 Way, 2 Way, 3, Way, and 4 Way.

Rank Interleaving

This feature allows the user to select a rank memory interleaving method. The

options are Auto, 1 Way, 2 Way, 4, Way, and 8 Way.

Patrol Scrub

Patrol Scrubbing is a process that allows the CPU to correct correctable memory

errors detected on a memory module and send the correction to the requestor

(the original source). When this item is set to Enabled, the IO hub will read and

write back one cache line every 16K cycles, if there is no delay caused by internal

4-11

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

processing. By using this method, roughly 64 GB of memory behind the IO hub

will be scrubbed every day. The options are Enabled and Disabled.

Demand Scrub

Demand Scrubbing is a process that allows the CPU to correct correctable

memory errors found on a memory module. When the CPU or I/O issues a

demand-read command, and the read data from memory turns out to be a

correctable error, the error is corrected and sent to the requestor (the original

source). Memory is updated as well. Select Enabled to use Demand Scrubbing

for ECC memory correction. The options are Enabled and Disabled.

Data Scrambling

Select Enabled to enable data scrubbing to ensure data security and integrity.

The options are Disabled and Enabled.

Device Tagging

Select Enabled to support device tagging. The options are Disabled and En-

abled.

Thermal Throttling

Throttling improves reliability and reduces power consumption in the proces-

sor via automatic voltage control during processor idle states. The options are

Disabled and CLTT (Closed Loop Thermal Throttling).

SouthBridgeConguration

This feature allows the user to congure the settings for the Intel PCH chip.

PCH Information

This feature displays the following PCH information.

Name: This item displays the name of the PCH chip.

Stepping: This item displays the status of PCH stepping.

USB Devices: This item displays the USB devices detected by the BIOS.

All USB Devices

This feature enables all USB ports/devices. The options are Disabled and Enabled.

(If set to Enabled, EHCI Controller 1 and Controller 2 will appear.)

4-12

Chapter 4: AMI BIOS

EHCI Controller 1/EHCI Controller 2 (Available when All USB Devices are set to Enabled)

Select Enabled to enable EHCI (Enhanced Host Controller Interface) Controller 1

or Controller 2. The options are Disabled and Enabled.

Legacy USB Support (Available when USB Functions is not Disabled)

Select Enabled to support legacy USB devices. Select Auto to disable legacy sup-

port if USB devices are not present. Select Disable to have USB devices available

for EFI (Extensive Firmware Interface) applications only. The settings are Disabled,

Enabled and Auto.

Port 60/64 Emulation

Select Enabled to enable I/O port 60h/64h emulation support for the legacy USB

keyboard so that it can be fully supported by the operating systems that does not

recognize a USB device. The options are Disabled and Enabled.

EHCI Hand-Off

This item is for operating systems that do not support Enhanced Host Controller

Interface (EHCI) hand-off. When enabled, EHCI ownership change will be claimed

by the EHCI driver. The options are Disabled and Enabled.

SATAConguration

When this submenu is selected, the AMI BIOS automatically detects the presence

of IDE or SATA devices and displays the following items.

SATA Port0~SATA Port5: The AMI BIOS displays the status of each SATA port

as detected by the BIOS.

SATA Mode

Use this feature to congure SATA mode for a selected SATA port. The options are

Disabled, IDE Mode, AHCI Mode and RAID Mode. The following are displayed

depending on your selection:

IDE Mode

The following items are displayed when IDE Mode is selected:

SATA (Serial-ATA) Controller 0/SATA (Serial-ATA) Controller 1

Use this feature to activate/deactivate and to set the SATA mode for SATA

Controller 0 or SATA Controller 1. The options for Controller 0 are Disabled,

Enhanced and Compatible. The Options for Controller 1 are Disabled and

Enhanced.

4-13

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

AHCI Mode

The following items are displayed when the AHCI Mode is selected.

Aggressive Link Power Management

Select Enabled to enable Aggressive Link Power Management support for

Cougar Point B0 stepping and beyond. The options are Enabled and Disabled.

Port 0~5 Hot Plug

Select Enabled to enable hot-plug support for a particular port, which will allow

the user to change a hardware component or device without shutting down the

system. The options are Enabled and Disabled.

Staggered Spin Up

Select Enabled to enable Staggered Spin-up support to prevent excessive

power consumption caused by multiple HDDs spinning-up simultaneously.

The options are Enabled and Disabled.

RAID Mode

The following items are displayed when RAID Mode is selected:

Port 0~5 Hot Plug

Select Enabled to enable hot-plug support for the particular port. The options

are Enabled and Disabled.

SCU(StorageControlUnit)Conguration

Storage Controller Unit

Select Enabled to enable PCH SCU storage devices. The options are Disabled

and Enabled.

OnChip SCU Option ROM

Select Enabled to support the onboard SCU Option ROM to boot up the system via

a storage device. The options are Disabled and Enabled.

SCU Port 0~CU Port 7: The AMI BIOS will automatically detect the onboard SCU

devices and display the status of each SCU device as detected.

PCIe/PCI/PnPConguration

PCI ROM Priority

Use this feature to select the Option ROM to boot the system when there are mul-

tiple Option ROMs available in the system. The options are EFI Compatible ROM

and Legacy ROM.

4-14

Chapter 4: AMI BIOS

PCI Latency Timer

Use this feature to set the latency Timer of each PCI device installed on a PCI bus.

Select 64 to set the PCI latency to 64 PCI clock cycles. The options are 32, 64, 96,

128, 160, 192, 224 and 248.

Above 4G Decoding (Available if the system supports 64-bit PCI decoding)

Select Enabled to decode a PCI device that supports 64-bit in the space above 4G

Address. The options are Enabled and Disabled.

PERR# Generation

Select Enabled to allow a PCI device to generate a PERR number for a PCI Bus

Signal Error Event. The options are Enabled and Disabled.

SERR# Generation

Select Enabled to allow a PCI device to generate an SERR number for a PCI Bus

Signal Error Event. The options are Enabled and Disabled.

Maximum Payload

Select Auto to allow the system BIOS to automatically set the maximum payload

value for a PCI-E device to enhance system performance. The options are Auto,

128 Bytes, 256 Bytes, 512 Bytes, 1024 Bytes, 2048 Bytes, and 4096 Bytes.

Maximum Read Request

Select Auto to allow the system BIOS to automatically set the maximum Read

Request size for a PCI-E device to enhance system performance. The options are

Auto, 128 Bytes, 256 Bytes, 512 Bytes, 1024 Bytes, 2048 Bytes, and 4096 Bytes.

ASPM Support

This feature allows the user to set the Active State Power Management (ASPM)

level for a PCI-E device. Select Force L0 to force all PCI-E links to operate at L0

state. Select Auto to allow the system BIOS to automatically set the ASPM level for

the system. Select Disabled to disable ASPM support. The options are Disabled,

Force L0, and Auto.

Warning: Enabling ASPM support may cause some PCI-E devices to fail!

CPU1 SXB 1A OPROM/CPU1 SXB 1B OPROM/CPU1 SXB 1C OPROM/CPU2 SXB2 PCI-E 3.0 x16 OPROM

Select Enabled to enable Option ROM support to boot the computer using a

network interface from the slots specied above. The options are Enabled and

Disabled.

4-15

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

Onboard LAN Option ROM Select

Select iSCSI to use the iSCSI Option ROM to boot the computer using a network

device. Select PXE (Preboot Execution Environment) to use an PXE Option ROM

to boot the computer using a network device. The options are iSCSI and PXE.

Load Onboard LAN1 Option ROM/Load Onboard LAN2 Option ROM

Select Enabled to enable the onboard LAN1 Option ROM/LAN2 Option ROM. This

is to boot the computer using a network device. The default setting for LAN1 Op-

tion ROM is Enabled, and the default setting for L AN2 Option ROM is Disabled.

VGA Priority

This feature allows the user to select the graphics adapter to be used as the primary

boot device. The options are Onboard, and Offboard.

Network Stack

Select Enabled enable PXE (Preboot Execution Environment) or UEFI (Unied

Extensible Firmware Interface) for network stack support. The options are Enabled

and Disabled.

SuperIOConguration

Super IO Chip: This item displays the Super IO chip used in the motherboard.

SerialPort1Conguration

Serial Port

Select Enabled to enable a serial port specied by the user. The options are En-

abled and Disabled.

Device Settings

This feature indicates whether or not a reset is required for a serial port specied.

Change Settings

This option species the base I/O port address and the Interrupt Request address

of Serial Port 1 and Serial Port 2. The options for Serial Port 1 are: Auto, IO=3F8h;

IRQ=4; IO=3F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; IO=2F8h; IRQ=3, 4, 5, 6, 7, 9,

10, 11, 12; IO=3E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; and IO=2E8h; IRQ=3, 4, 5,

6, 7, 9, 10, 11, 12.

4-16

Chapter 4: AMI BIOS

SerialPort2Conguration

Serial Port

Select Enabled to enable a serial port specied by the user. The options are En-

abled and Disabled.

Device Settings

This item displays the settings of Serial Port 2.

Change Settings

This option species the base I/O port address and the Interrupt Request address

of Serial Port 1 and Serial Port 2. The options for Serial Port 2 are: Auto, IO=2F8h;

IRQ=3; IO=3F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; IO=2F8h; IRQ=3, 4, 5, 6, 7, 9,

10, 11, 12; IO=3E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; and IO=2E8h; IRQ=3, 4, 5,

6, 7, 9, 10, 11, 12.

Serial Port 2 Attribute

Use this feature to select the attribute for serial port 2. The options are SOL (Serial

On LAN), and COM.

Serial Port Console Redirection

•COM 1 and SOL/COM 2

These two submenus allow the user to congure the following Console Redirection

settings for a COM Port selected by the user.

Console Redirection

Select Enabled to use a COM Port selected by the user for Console Redirection.

The options are Enabled and Disabled. The default setting for COM1 is Disabled,

and for COM2 is Enabled.

Console Redirection Settings

This feature allows the user to specify how the host computer will exchange data

with the client computer, which is the remote computer used by the user.

Terminal Type

This feature allows the user to select the target terminal emulation type for Con-

sole Redirection. Select VT100 to use the ASCII Character set. Select VT100+ to

add color and function key support. Select ANSI to use the Extended ASCII Char-

acter Set. Select VT-UTF8 to use UTF8 encoding to map Unicode characters

into one or more bytes. The options are ANSI, VT100, VT100+, and VT-UTF8.

4-17

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

Bits Per second

Use this feature to set the transmission speed for a serial port used in Console

Redirection. Make sure that the same speed is used in the host computer and

the client computer. A lower transmission speed may be required for long and

busy lines. The options are 9600, 19200, 57600 and 115200 (bits per second).

Data Bits

Use this feature to set the data transmission size for Console Redirection. The

options are 7 Bits and 8 Bits.

Parity

A parity bit can be sent along with regular data bits to detect data transmission

errors. Select Even if the parity bit is set to 0, and the number of 1's in data bits

is even. Select Odd if the parity bit is set to 0, and the number of 1's in data bits

is odd. Select None if you do not want to send a parity bit with your data bits

in transmission. Select Mark to add a mark as a parity bit to be sent along with

the data bits. Select Space to add a Space as a parity bit to be sent with your

data bits. The options are None, Even, Odd, Mark and Space.

Stop Bits

A stop bit indicates the end of a serial data packet. Select 1 Stop Bit for standard

serial data communication. Select 2 Stop Bits if slower devices are used. The

options are 1 and 2.

Flow Control

This feature allows the user to set the ow control for Console Redirection to

prevent data loss caused by buffer overow. Send a "Stop" signal to stop send-

ing data when the receiving buffer is full. Send a "Start" signal to start sending

data when the receiving buffer is empty. The options are None and Hardware

RTS/CTS.

VT-UTF8 Combo Key Support

Select Enabled to enable VT-UTF8 Combination Key support for ANSI/VT100

terminals. The options are Enabled and Disabled.

Recorder Mode

Select Enabled to capture the data displayed on a terminal and send it as text

messages to a remote server. The options are Disabled and Enabled.

Resolution 100x31

Select Enabled for extended-terminal resolution support. The options are Dis-

abled and Enabled.

4-18

Chapter 4: AMI BIOS

Legacy OS Redirection

Use this feature to select the number of rows and columns used in Console

Redirection for legacy OS support. The options are 80x24 and 80x25.

Putty KeyPad

This feature selects Function Keys and KeyPad settings for Putty, which is a

terminal emulator designed for the Windows OS. The options are VT100, Linux,

XTERMR6, SC0, ESCN, and VT400.

Serial Port for Out-of-Band Management/Windows Emergency

Management Services (EMS)

The submenu allows the user to congure Console Redirection settings to

support Out-of-Band Serial Port management. The options are Enabled and

Disabled.

Console Redirection Settings

The feature allows the user to congure console redirection settings for a local

machine to communicate with a remote server.

ACPI Setting

Use this feature to congure Advanced Conguration and Power Interface (ACPI)

power management settings for your system.

ACPI Sleep State

Use this feature to select the ACPI State when the system is in sleep mode. Select

S1 (CPU_Stop_Clock) to erase all CPU caches and stop executing instructions.

Power to the CPU(s) and RAM is maintained, but RAM is refreshed. Select Suspend

to use power-reduced mode. Power will only be supplied to limited components

(such as RAMs) to maintain the most critical functions of the system. The options

are S1 (CPU_Stop_Clock), Suspend and Disabled.

High Precision Event Timer

Select Enabled to activate the High Precision Event Timer (HPET) that produces

periodic interrupts at a much higher frequency than a Real-time Clock (RTC) does

in synchronizing multimedia streams, providing smooth playback, reducing the de-

pendency on other timestamp calculation devices, such as an x86 RDTSC Instruc-

tion embedded in the CPU. The High Performance Event Timer is used to replace

the 8254 Programmable Interval Timer. The options are Enabled and Disabled.

4-19

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

Trusted Computing (Available when a TPM device is detected by the BIOS)

Conguration

TPM Support

Select Enabled on this item and enable the TPM jumper on the motherboard to

enable TPM support to improve data integrity and network security. The options

are Enabled and Disabled.

TPM State

Select Enabled to enable TPM security settings to improve data integrity and

network security. The options are Disabled and Enabled.

Pending Operation: This item displays the status of a pending operation.

Current Status Information: This item displays the information regarding the

current TPM status.

TPM Enable Status

This item displays the status of TPM Support to indicate if TPM is currently

enabled or disabled.

TPM Active Status

This item displays the status of TPM Support to indicate if TPM is currently ac-

tive or deactivated.

TPM Owner Status

This item displays the status of TPM Ownership.

IntelTXT(LT-SX)Conguration

Intel TXT (LT-SX) Hardware Support

This feature indicates if the following hardware components support the Intel

Trusted Execution Technology.

CPU: TXT (Trusted Execution Technology) Feature

Chipset: TXT (Trusted Execution Technology) Feature

IntelTXT(LT-SX) Conguration

This feature displays the following TXT conguration setting.

4-20

Chapter 4: AMI BIOS

TXT (LT-SX) Support: This item indicated if the Intel TXT support is enabled

or disabled.

Intel TXT (LT-SX) Dependencies

This feature displays the features that need to be enabled for the Intel Trusted

Execution Technology to work properly in the system.

VT-d Support: Intel Virtualization Technology with Direct I/O support

VT Support: Intel Virtualization Technology support

TPM Support: Trusted Platform support

TPM State: Trusted Platform state

IntelMESubsystemConguration

This feature displays the following ME Subsystem Conguration settings.

•ME BIOS Interface Version

•ME Version

iSCSIConguration: This item displays iSCSI conguration information:

iSCSI Initiation Name: This item displays the name of the iSCSI Initiator, which is a unique name used in the world.

Add an Attempt

Delete Attempts

Commit Changes and Exit

Save the changes and exit from the page.

Discard Changes and Exit

Discard the changes and exit from the page.

4-21

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

Change Attempt Order

Commit Changes and Exit

Save the changes and exit from the page.

Discard Changes and Exit

Discard the changes and exit from the page.

Intel® I350 Gigabit Network Connections: These items display the following information on the Intel I350 LAN connections.

PortCongurationMenu

NICConguration

Link Speed

This item allows the user to set the link speed for your network connections.

The Options are AutoNeg (Auto Negotiation), 10 Mbps Half, 10 Mbps Full, 100

Mbps Half, and 10 Mbps Full.

Wake On LAN (WOL)

Select Enabled to wake up the system with a device (a magic packet). The op-

tions are Disabled and Enabled.

Blink LEDs (Range 0~15 seconds)

This item sets the duration of blinking for NIC LEDs. The range of duration is from

0 second to 15 seconds. The default setting is 0 second.

PortCongurationInformation

This menu displays the following information for a NIC port specied.

•UEFI Driver

•Adapter PBA

•Chip Type

•PCI Device ID

•PCI Bus: Device: Function:

•Link Status: This item displays the link status of network connections.

•Factory MAC Address

4-22

•Alternate MAC Address

4-4 Event Logs

Use this feature to congure Event Log settings.

Change SMBIOS Event Log Settings

This feature allows the user to congure SMBIOS Event settings.

Chapter 4: AMI BIOS

Enabling/Disabling Options

SMBIOS Event Log

Select Enabled to enable SMBIOS (System Management BIOS) Event Logging

during system boot. The options are Enabled and Disabled.

Runtime Error Logging Support

Select Enabled to support Runtime Error Logging. The options are Enabled and

Disabled.

Memory Correctable Error Threshold

This feature allows the user to enter the threshold value for correctable memory

errors. The default setting is 10.

PCI Error Logging Support

Select Enabled to support error event logging for PCI slots. The options are Enabled

and Disabled.

4-23

X9DRW-3F/X9DRW-iF Motherboard User’s Manual

Erasing Settings

Erase Event Log

Select Enabled to erase the SMBIOS (System Management BIOS) Event Log, which

is completed before a event logging is initialized upon system reboot. The options

are No; Yes, next Reset; and Yes, every reset.

When Log is Full

Select Erase Immediately to immediately erase SMBIOS error event logs that ex-

ceed the limit when the SMBIOS event log is full. Select Do Nothing for the system

to do nothing when the SMBIOS event log is full. The options are Do Nothing and

Erase Immediately.

SMBIOS Event Log Standard Settings

Log System Boot Event

Select Enabled to log system boot events. The options are Disabled and Enabled.

MECI (Multiple Event Count Increment)

Enter the increment value for the multiple event counter. Enter a number between

1 to 255. The default setting is 1.

METW (Multiple Event Count Time Window)

This item allows the user to decide how long (in minutes) should the multiple event

counter wait before generating a new event log. Enter a number between 0 to 99.

The default setting is 60.

View SMBIOS Event Log

This item allows the user to view the event in the SMBIOS event log. Select this

item and press <Enter> to view the status of an event in the log as shown below:

Date/Time/Error Code/Severity

View System Event Log

This item allows the user to view the event in the system event log. Select this

item and press <Enter> to view the status of an event in the log as shown below:

Date/Time/Sensor/Type

4-24

Supermicro X9DRW-iF operation manual

Specifications and Main Features

Frequently Asked Questions

User Manual
