Supermicro X9DRi-LN4F+ operation manual

X9DR3-LN4F+

X9DRi-LN4F+

USER’S MANUAL

Revision 1.1c

The information in this user’s manual has been carefully reviewed and is believed to be accurate. The vendor assumes no responsibility for any inaccuracies that may be contained in this document, and makes no commitment to update or to keep current the information in this manual, or to notify any person or organization of the updates. Please Note: For the most up-to-date version of this

manual, please see our Website at www.supermicro.com.

Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product described in this manual at any time and without notice. This product, including software and documentation, is the property of Supermicro and/or its licensors, and is supplied only under a license. Any use or reproduction of this product is not allowed, except as expressly permitted by the terms of said license.

IN NO EVENT WILL SUPER MICRO COMPUTER, INC. BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL, SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, SUPER MICRO COMPUTER, INC. SHALL NOT HAVE LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.

Any disputes arising between the manufacturer and the customer shall be governed by the laws of Santa Clara County in the State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.

FCC Statement: This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the manufacturer’s instruction manual, may cause harmful interference with radio communications. Operation of this equipment in a residential area is likely to cause harmful interference, in which case you will be required to correct the interference at your own expense.

California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate warning applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”.

WARNING: Handling of lead solder materials used in this product may expose you to lead, a chemical known to the State of California to cause birth defects and other reproductive harm.

Manual Revision 1.1c

Release Date: April 1, 2014

Unless you request and receive written permission from Super Micro Computer, Inc., you may not copy any part of this document.

Information in this document is subject to change without notice. Other products and companies referred to herein are trademarks or registered trademarks of their respective companies or mark holders.

Printed in the United States of America

Preface

This manual is written for system integrators, PC technicians and

knowledgeable PC users. It provides information for the installation and use of the

X9DR3-LN4F+/X9DRi-LN4F+ motherboard.

About This Motherboard

The Super X9DR3-LN4F+/X9DRi-LN4F+ motherboard supports dual Intel E5-

2600(v2) Series Processors (Socket R LGA 2011) that offer QPI (Intel QuickPath

Interface) Technology (V.1.1), providing point-to-point connection with a transfer

speed of up to 8.0 TG/s. With the C606/C602 chipset built in, the X9DR3/i-LN4F+

motherboard provides support for Intel® Management Engine (ME), Rapid Stor-

age Technology, Digital Media Interface (DMI), PCI-E Gen. 3.0, and up to 1866

MHz DDR3 memory, greatly enhancing system performance for high end server

platforms. This motherboard is ideal for HPC/Cluster/Database servers. Please

refer to our website (http://www.supermicro.com) for processor and memory sup-

port updates.

Manual Organization

Preface

Chapter 1 describes the features, specications and performance of the mother-

board. It also provides detailed information about Intel C606/C602 chipset.

Chapter 2 provides hardware installation instructions. Read this chapter when in-

stalling the processor, memory modules, and other hardware components into the

system. If you encounter any problems, see Chapter 3, which describes trouble-

shooting procedures for video, memory, and system setup stored in the CMOS.

Chapter 4 includes an introduction to the BIOS, and provides detailed information

on running the CMOS setup utility.

Appendix A provides BIOS Error Beep Codes.

Appendix B lists software installation instructions.

iii

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

Conventions Used in the Manual

Pay special attention to the following symbols for proper system installation and to

prevent damage to the system or injury to yourself:

Warning: Important information given to ensure proper system installation or to prevent

damage to the components

Note: Additional information given to differentiate between various models

or provides information for correct system setup.

Contacting Supermicro

Headquarters

Address: Super Micro Computer, Inc.

980 Rock Ave.

San Jose, CA 95131 U.S.A.

Tel: +1 (408) 503-8000

Fax: +1 (408) 503-8008

Email: marketing@supermicro.com (General Information)

support@supermicro.com (Technical Support)

Web Site: www.supermicro.com

Europe

Address: Super Micro Computer B.V.

Het Sterrenbeeld 28, 5215 ML

's-Hertogenbosch, The Netherlands

Tel: +31 (0) 73-6400390

Fax: +31 (0) 73-6416525

Email: sales@supermicro.nl (General Information)

support@supermicro.nl (Technical Support)

rma@supermicro.nl (Customer Support)

Web Site: www.supermicro.com

Preface

Asia-Pacic

Address: Super Micro Computer, Inc.

3F, No. 150, Jian 1st Rd.

Zhonghe Dist., New Taipei City 235

Taiwan (R.O.C)

Tel: +886-(2) 8226-3990

Fax: +886-(2) 8226-3992

Email: support@supermicro.com.tw

Tel: +886-(2)-8226-3990

Web Site: www.supermicro.com.tw

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

Table of Contents

Preface

Chapter 1 Overview

1-1 Overview ......................................................................................................... 1-1

1-2 Processor and Chipset Overview...................................................................1-11

1-3 Special Features ........................................................................................... 1-12

1-4 PC Health Monitoring .................................................................................... 1-12

1-5 ACPI Features ............................................................................................... 1-13

1-6 Power Supply ................................................................................................ 1-13

1-7 Super I/O ....................................................................................................... 1-14

1-8 Advanced Power Management ..................................................................... 1-14

Intel® Intelligent Power Node Manager (NM) (Available when the NMView

utility is installed in the system) .................................................................... 1-14

Management Engine (ME) ............................................................................ 1-14

1-9 Overview of the Nuvoton WPCM450 Controller ........................................... 1-15

Chapter 2 Installation

2-1 Standardized Warning Statements ................................................................. 2-1

Battery Handling .............................................................................................. 2-1

Product Disposal ............................................................................................. 2-3

2-2 Static-Sensitive Devices .................................................................................. 2-4

Precautions ..................................................................................................... 2-4

Unpacking ....................................................................................................... 2-4

2-3 Processor and Heatsink Installation................................................................ 2-5

Installing the LGA2011 Processor .................................................................2-5

Installing a Passive CPU Heatsink ................................................................. 2-9

Removing the Heatsink ................................................................................. 2-10

2-4 Installing and Removing the Memory Modules ..............................................2-11

Installing & Removing DIMMs ........................................................................2-11

Removing Memory Modules ..........................................................................2-11

2-5 Motherboard Installation ................................................................................ 2-16

Tools Needed ................................................................................................ 2-16

Location of Mounting Holes .......................................................................... 2-16

Installing the Motherboard ............................................................................ 2-17

2-6 Control Panel Connectors and I/O Ports ...................................................... 2-18

Back Panel Connectors and I/O Ports .......................................................... 2-18

Back Panel I/O Port Locations and Denitions ........................................... 2-18

Serial Ports ............................................................................................... 2-19

Video Connection ..................................................................................... 2-19

Table of Contents

Universal Serial Bus (USB) ...................................................................... 2-20

Ethernet Ports .......................................................................................... 2-21

Unit Identier Switch ................................................................................ 2-22

Front Control Panel ....................................................................................... 2-23

Front Control Panel Pin Denitions............................................................... 2-24

NMI Button ............................................................................................... 2-24

Power LED .............................................................................................. 2-24

HDD LED .................................................................................................. 2-25

NIC1/NIC2 LED Indicators ....................................................................... 2-25

Overheat (OH)/Fan Fail/PWR Fail/UID LED ............................................ 2-26

Power Fail LED ........................................................................................ 2-26

Reset Button ........................................................................................... 2-27

Power Button ........................................................................................... 2-27

2-7 Connecting Cables ........................................................................................ 2-28

Power Connectors ................................................................................... 2-28

Fan Headers ............................................................................................. 2-29

Chassis Intrusion ..................................................................................... 2-29

Internal Speaker ....................................................................................... 2-30

Power LED/Speaker ................................................................................. 2-30

TPM Header/Port 80 ................................................................................ 2-31

Power SMB (I2C) Connector .................................................................... 2-32

Overheat/Fan Fail LED ............................................................................ 2-32

T-SGPIO 1/2 Headers .............................................................................. 2-33

DOM Power Connector ............................................................................ 2-33

IPMB ......................................................................................................... 2-34

2-8 Jumper Settings ............................................................................................ 2-35

Explanation of Jumpers ................................................................................ 2-35

GLAN Enable/Disable .............................................................................. 2-35

CMOS Clear ............................................................................................. 2-36

Watch Dog Enable/Disable ...................................................................... 2-36

VGA Enable .............................................................................................. 2-37

BMC Enable ............................................................................................ 2-37

Management Engine (ME) Recovery ...................................................... 2-38

Manufacture Mode Select ........................................................................ 2-38

2-9 Onboard LED Indicators ............................................................................... 2-39

GLAN LEDs .............................................................................................. 2-39

IPMI Dedicated LAN LEDs ....................................................................... 2-39

Onboard Power LED ............................................................................... 2-40

Rear UID LED ......................................................................................... 2-40

vii

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

BMC Heartbeat LED ................................................................................ 2-41

2-10 Serial ATA Connections ................................................................................. 2-42

Serial ATA (SATA) Ports ........................................................................... 2-42

SCU Ports ................................................................................................ 2-42

Chapter 3 Troubleshooting

3-1 Troubleshooting Procedures ........................................................................... 3-1

3-2 Technical Support Procedures ........................................................................ 3-5

3-3 Battery Removal and Installation .................................................................... 3-6

3-4 Frequently Asked Questions ........................................................................... 3-7

3-5 Returning Merchandise for Service................................................................. 3-8

Chapter 4 BIOS

4-1 Introduction ...................................................................................................... 4-1

4-2 Main Setup ...................................................................................................... 4-2

4-3 Advanced Setup Congurations...................................................................... 4-3

4-4 Event Logs .................................................................................................... 4-24

4-5 IPMI ............................................................................................................... 4-26

4-6 Boot ............................................................................................................... 4-28

4-7 Security ......................................................................................................... 4-30

4-8 Save & Exit ................................................................................................... 4- 31

Appendix A BIOS Error Beep Codes

A-1 BIOS Error Beep Codes .................................................................................A-1

Appendix B Software Installation Instructions

B-1 Installing Software Programs ..........................................................................B-1

B-2 Conguring SuperDoctor® III ..........................................................................B-2

viii

Chapter 1: Overview

Chapter 1

Overview

1-1 Overview

Checklist

Congratulations on purchasing your computer motherboard from an acknowledged

leader in the industry. Supermicro boards are designed with the utmost attention to

detail to provide you with the highest standards in quality and performance.

Please check that the following items have all been included with your motherboard.

If anything listed here is damaged or missing, contact your retailer.

The following items are included in the retail box:

• One (1) Supermicro Mainboard

• Two (2) Serial ATA cables (CBL-0044Lx2)

•Two (2) I-Pass to Serial ATA cables (CBL-097L-03 x2) (for X9DR3-F)

•One (1) I-Pass to Serial ATA cables (CBL-097L-03) (for X9DRi-F)

• One (1) I/O Shield (MCP-260-00042-0N)

• One (1) Quick Reference Guide (MNL-1258-QRG)

Note: For your system to work properly, please follow the links below to

download all necessary drivers/utilities and the user's manual for your

motherboard.

Supermicro product manuals: http://www.supermicro.com/support/manuals/

Product Drivers and utilities: ftp://ftp.supermicro.com/

If you have any questions, please contact our support team at support@supermicro.

com.

1-1

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

Motherboard Image

Note: All graphics shown in this manual were based upon the latest PCB

Revision available at the time of publishing of the manual. The motherboard

you've received may or may not look exactly the same as the graphics

shown in this manual.

1-2

JPG1

JTPM1

IPMB

JPME2

J17

JBMC1

JSTBY1

J21

COM2

JI2C2 JI2C1

USB9

JL1

USB6/7

USB4/5

JWD1

I-SATA4

JPME1

I-SATA2

I-SATA0

J18

CTRL

LEM1

CPU1 Slot1 PCI-E 3.0 x16

SAS

CTRL

JBT1

XDP-PCH

I-SATA5

JRK1

I-SATA3

BIOS

I-SATA1

JSD1

SAS4~7

BMC

JPB1

CTRL

CPU1 Slot2 PCI-E 3.0 x4 (in X8 slot)

CPU2 Slot4 PCI-E 3.0 x16

CPU1 Slot3 PCI-E 3.0 x16

JP7

JP6

BIOS BOX

XDP-CPU

PCH

JWP1

SAS0~3

FANB

SP1

JOH1

JF2

FANA

JD1

Motherboard Layout

LE2

JPL1

LAN

CPU2 Slot6 PCI-E 3.0 x8

CPU2 Slot5 PCI-E 3.0 x16

JBAT1

FAN4

SW1

UID

VGA

Alaways populate DIMMx1 first

P1 DIMMC1

P1 DIMMC2

P1 DIMMC3

P1 DIMMD1

FAN3

JF1

USB 2/3

LAN1/3

LAN2/4

P2 DIMME1

P2 DIMMF3

P2 DIMMF2

P2 DIMME3

P2 DIMME2

P2 DIMMF1

CPU2

Alaways populate DIMMx1 first

X9DR3-LN4F+/X9DRi-LN4F+

Rev. 1.10

CPU1

P1 DIMMD2

P1 DIMMD3

LE1

Chapter 1: Overview

USB 0/1

COM1

FAN6

IPMI_LAN

P2 DIMMG3

P2 DIMMG2

P2 DIMMH1

P2 DIMMH2

P2 DIMMH3

P2 DIMMG1

P1 DIMMA2

P1 DIMMB3

P1 DIMMB2

P1 DIMMB1

P1 DIMMA1

P1 DIMMA3

FAN2

FAN5

PHY

JPI2C1

JPW3

JPW2

JPW1

FAN1

Note: For the latest CPU/Memory updates, please refer to our website at

http://www.supermicro.com/products/motherboard/ for details.

1-3

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

X9DR3-LN4F+/X9DRi-LN4F+ Quick Reference

USB 2/3

CPU1

CPU2

USB 0/1

IPMI_LAN

P1 DIMMB3

P1 DIMMB2

P2 DIMMH2

P2 DIMMH3

P1 DIMMA2

P1 DIMMB1

P1 DIMMA1

P1 DIMMA3

FAN2

JPG1

JTPM1

IPMB

JPME2

J17

JBMC1

JSTBY1

J21

COM2

JI2C2

JI2C1

USB9

JL1

USB6/7

USB4/5

JWD1

I-SATA4

JPME1

I-SATA2

I-SATA0

J18

CTRL

LEM1

CPU1 Slot1 PCI-E 3.0 x16

SAS

CTRL

JBT1

XDP-PCH

I-SATA5

JRK1

I-SATA3

BIOS

I-SATA1

JSD1

SAS4~7

BMC

JPB1

CTRL

CPU1 Slot2 PCI-E 3.0 x4 (in X8 slot)

CPU2 Slot4 PCI-E 3.0 x16

CPU1 Slot3 PCI-E 3.0 x16

JP7

JP6

BIOS BOX

JBAT1

XDP-CPU

PCH

JWP1

SAS0~3

SP1

JOH1

FANB

JF2

FANA

JD1

JPL1

LAN

CPU2 Slot6 PCI-E 3.0 x8

CPU2 Slot5 PCI-E 3.0 x16

FAN4

LE2

SW1

UID

LAN1/3

LAN2/4

VGA

P2 DIMME1

P2 DIMMF3

P2 DIMMF2

P2 DIMME3

P2 DIMME2

P2 DIMMF1

Alaways populate DIMMx1 first

X9DR3-LN4F+/X9DRi-LN4F+

Rev. 1.10

Alaways populate DIMMx1 first

P1 DIMMD2

P1 DIMMC1

P1 DIMMC2

P1 DIMMC3

P1 DIMMD1

P1 DIMMD3

FAN3

LE1

JF1

COM1

FAN6

P2 DIMMG3

P2 DIMMG2

P2 DIMMH1

P2 DIMMG1

FAN5

PHY

JPI2C1

JPW3

JPW2

JPW1

FAN1

Notes:

•See Chapter 3 for detailed information on jumpers, I/O ports and JF1 front panel

connections.

•" " indicates the location of "Pin 1".

•Jumpers/LED Indicators not indicated are for testing only. Also, components that

are not documented in this manual are reserved for internal use only.

•Use only the correct type of onboard CMOS battery as specied by the manufac-

turer. Do not install the onboard battery upside down to avoid possible explosion.

1-4

Chapter 1: Overview

X9DR3-LN4F+/X9DRi-LN4F+ Jumpers

Jumper

JBT1

JI2C1/JI2C2 SMB to PCI-E Slots Off (Normal)

JPB1 BMC Enabled Pins 1-2 (Enabled)

JPG1 VGA Enabled Pins 1-2 (Enabled)

JPL1 GLAN1/GLAN2 Enable Pins 1-2 (Enabled)

JPME1 Management Engine (ME)

JPME2 Management Engine (ME)

JWD Watch Dog Pins 1-2 (Reset)

Connectors Description

COM1/COM2 Backplane COM Port1/Front Accessible COM2 Header

CPU1 Slot1/Slot3 CPU2 Slot4/Slot5

CPU2 Slot6 PCI-E 3.0 x8 Slot

CPU1 Slot2 PCI-E 3.0 x4 in x8 Slot

FAN1~6, FANA, FANB

IPMB 4-pin External BMC I2C Header (for an IPMI Card)

I-SATA 0~5 Intel SB SATA Connectors 0~5

J17/J18 Serial-Link General_Purpose IO Headers (T-SGPIO 1/2)

JBAT1 Onboard CMOS Battery (See Chapter 3 for Used Battery Disposal)

JD1 Speaker/Power LED Indicator

JF1 Front Panel Control Header

JPI2C1 System Management SMBbus I2C Header

JL1 Chassis Intrusion

JOH1 Overheat/Fan Fail LED

JPI2C1 Power Supply SMBbus I2C Header

JPW1 ATX 24-Pin Power Connector (See Warning on Page 1-6.)

JPW2/JPW3 12V 8-Pin Power Connectors (See Warning on Page 1-6.)

JSD1 SATA DOM (Device_On_Module) Power Connector

JSTBY1 Standby Header

JTPM1 TPM (Trusted Platform Module)/Port 80

Description Default Setting

Clear CMOS See Chapter 2

Pins 1-2 (Normal)

Recovery Mode Enable

Pins 1-2 (Normal)

Manufacture Select

X9DR3-LN4F+/X9DRi-LN4F+ Connectors

PCI-E 3.0 x16 Slots

CPU/System Fan Headers

1-5

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

KB/Mouse PS2 Keyboard/Mouse

LAN1/3, LAN2/4 G-bit Ethernet Ports 1/3, 2/4

(IPMI) LAN IPMI_Dedicated LAN

SP1 Onboard Buzzer (Internal Speaker)

USB 0/1 Back Panel USB 0/1

USB 2/3 Back Panel USB 2/3

USB 4/5, USB 6/7 Front Panel Accessible USB Connections 4/5, 6/7

USB 9 Front Panel Type A USB 9 Port

UID Switch UID (Unit Identier) Switch

VGA Backpanel VGA Port

X9DR3-LN4F+/X9DRi-LN4F+ LED Indicators

LED Description State Status

LE1 Standby PWR LED Green: On SB Power On

LE2 UID LED Blue Unit Identied

LEM1 BMC Heartbeat LED Green: Blinking Normal

Warning: To prevent damage to the power supply or motherboard, please use a power

supply that contains a 24-pin and two 8-pin power connectors. Be sure to connect

these power supply connectors to the 24-pin power connector (JPW1) and two 8-pin

power connectors (JPW2, JPW3) on the motherboard. Failure in doing so will void the

manufacturer warranty on your power supply and motherboard.

1-6

Motherboard Features

Chapter 1: Overview

CPU

Memory

Chipset

Expansion

Slots

Graphics

Network

I/O Devices

• Dual Intel

LGA 2011); each processor supports four full-width Intel

QuickPath Interconnect (QPI) links (with support of up to

25.6 GT/s per QPI link and with Data Transfer Rate of up

to 8.0 GT/s per direction).

E5-2600(v2) Series Processors (Socket R

Note: For E5-2600(v2) processor support, BIOS

version 3.0 or above is required.

• Integrated memory controller supports up to 1.5 TB

of Load Reduced (LRDIMM), 768 Gb of Registered

(RDIMM) or 128 GB of Unbuffered (UDIMM) ECC/Non-

ECC DDR3 800/1066/1333/1600/1866 MHz 240-pin

4-channel memory in 24 DIMM slots.

Note 1: 1866 MHz memory support is dependent

on Intel E5-2600v2 CPUs.

Note 2: For the latest memory updates, please

refer to the Tested Memory List posted on our

website (http://www.supermicro.com/products/

motherboard).

• Virtualization: VT-x, VT-d, and VT-c

• Intel® C606/C602 Chipset

• Four (4) PCI Express 3.0 x16 slots (CPU1 Slot1/Slot3,

CPU2 Slot4/Slot5)

• One (1) PCI Express 3.0 x8 slot (CPU2 Slot6)

• One (1) PCI Express 3.0x4 in x8 slot (CPU1 Slot2)

• Winbond Matrox MGA 200 Video Controller

• One Intel i350A Gigabit (100/1000 Mb/s) Ethernet Quad/

Dual-Channel Controller for LAN1~LAN4 ports.

• Winbond WPCM450R Baseboard Controller (BMC) sup-

ports IPMI_LAN 2.0

SATA Connections

• SATA Ports Six (6): Two (2) SATA 3.0, Four (4)

SATA 2.0 Ports

Four (4) SATA 2.0 Ports from SCU

(X9DRi-LN4F+)

• RAID RAID 0, 1, 5, 10 (Windows)

RAID 0, 1, 5, 10 (Linux)

1-7

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

SCU Connections

• SCU SAS/

SATA2 Ports

0~3, 4~7 (X9DR3-LN4F+ Only)

• RAID RAID 0, 1, 10 (Windows/Linux)

Integrated IPMI 2.0

• IPMI 2.0 supported by the Winbond WPCM 450R

BMC

Serial (COM) Port

• Two (2) Fast UART 16550 Connection: 9-pin RS-

232 port

Keyboard/Mouse

• Backplane USB Keyboard/Mouse

VGA

• Backplane VGA Port

Peripheral Devices

USB Devices

• Four (4) USB ports on the rear I/O panel (USB 0/1,

USB 2/3),

• Four (4) USB connections for front access (USB

4/5, USB 6/7),

• One (1) Type A USB connector for front access

(USB 9)

BIOS

• 16MB AMI Flash ROM

• APM 1.2, DMI 2.3, PCI 2.3, ACPI 1.0/2.0/3.0, USB

Keyboard, Plug & Play (PnP) and SMBIOS 2.3

Power

Cong.

• ACPI/ACPM Power Management

• Main switch override mechanism

• Keyboard Wake-up from Soft-Off

• Power-on mode for AC power recovery

• Intel

Intelligent Power Node Manager (NM) (Avail-

able when the NMView utility is installed in the

system)

• Management Engine (ME)

PC Health

Monitoring

CPU Monitoring

• Onboard voltage monitors for 1.8V, +3.3V, 3.3VSB,

+5V Standby, 1.35V, 1.5V, Chipset Voltage, and

Battery Voltage.

• CPU 6-Phase switching voltage regulator

1-8

System Management

Dimensions

Chapter 1: Overview

• CPU/System overheat LED and control

• CPU Thermal Trip support

• Thermal Monitor 2 (TM2) support

Fan Control

• Fan status monitoring with rmware thermal man-

agement via IPMI 2.0

• Low noise fan speed control

LED Indicators

• System/CPU Overheat LED

• Suspend-state LED

• UID/Remote UID LED

• PECI (Platform Environment Conguration Interface)

2.0 support

• System resource alert via SuperDoctor® III

• Thermal Monitor 2 (TM2) support

• SuperDoctor® III, Watch Dog, NMI

• Chassis Intrusion Header and Detection

• 13.68" (L) x 13.05" (W) (347.47 mm x 331.47 mm)

Note 1: For IPMI Conguration Instructions, please refer to the Embedded

IPMI Conguration User's Guide available @ http://www.supermicro.com/

support/manuals/.

Note 2: Changing BMC log-in information is recommended during initial

system power-on. The default username is ADMIN and password is ADMIN.

For BMC best practices, please refer to: http://www.supermicro.com/products/

nfo/les/IPMI/Best_Practices_BMC_Security.pdf

1-9

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

DDR3 DIMM

#2 C

DDR3 DIMM

PCI-E x16 Slot

DDR3 DIMM

x16

PCI-E x8 Slot

PCI-E x16 Slot

PE3

DDR3 DIMM

PE3 PE2 PE1 DMI

x16

PCI-E x16 Slot

PE2

CPU REAR

Socket 2

PROCESSOR

QPI

CPU FRONT

Socket 1

PROCESSOR

x16

[7.4]

RJ45 RJ45

PE1

DDR III

LAN

DMI

DDR3 DIMM

QPI

SYSTEM

BIOS

DMI

[3.0]

PEG0

PEG1 [4:1]

PEG1_8

BMC VGA

DDR3 DIMM

SPI

SSB

Intel C606/C602

DDR3 DIMM

#1~#6

USB

LPC

SATA

(4 SATA2 for X9DRi

-LN4F+ Only) (For X9DR3

-LN4F+ Only)

USB

TPM HDR

0,1

REAR

2,3

REAR

#1~#8

SCU

HDR 2X5

4,5

TYPE-A

HDR 2X5

6, 7

VGA CONN

PHY1

RTL8211

LAN

SIO W83527

System Block Diagram

Note: This is a general block diagram and may not exactly represent the

features on your motherboard. See the Motherboard Features pages for

the actual specications of each motherboard. 2. This block diagram is

intended for your reference only.

1-10

Chapter 1: Overview

1-2 Processor and Chipset Overview

Built upon the functionality and the capability of the Intel E5 -2600(v2) Series

Processors (Socket R LGA 2011) and the C606/C602 chipset, the X9DR3-LN4F+/

X9DRi-LN4F+ motherboard provides the performance and feature sets required

for dual_ processor-based HPC/Cluster/Database servers.

With support of Intel QuickPath interconnect (QPI) Technology, the X9DR3-LN4F+/

X9DRi-LN4F+ offers point-to-point serial interconnect interface with a transfer

speed of up to 8.0 GT/s, providing superb system performance.

The C606/C602 chipset provides extensive IO support, including the following

functions and capabilities:

•PCI-Express Rev. 2.0 support

•PCI-Express Gen. 3 uplink supported by some SKUs

•ACPI Power Management Logic Support Rev. 3.0b or Rev. 4.0

•USB host interface backplane and front access support

•Intel Rapid Storage Technology supported

•Intel Virtualization Technology for Directed I/O (Intel VT-d) supported

•Intel Trusted Execution Technology supported

•Serial Peripheral Interface (SPI) Supported

•Digital Media Interface (DMI) supported

•Advanced Host Controller Interface (AHCI) supported

Note: For Intel E5-2600(v2) processor support, BIOS version 3.0 or above

is required.

1-11

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

1-3 Special Features

Recovery from AC Power Loss

The Basic I/O System (BIOS) provides a setting that determines how the system will

respond when AC power is lost and then restored to the system. You can choose for

the system to remain powered off (in which case you must press the power switch

to turn it back on), or for it to automatically return to the power-on state. See the

Advanced BIOS Setup section for this setting. The default setting is Last State.

1-4 PC Health Monitoring

This section describes the features of PC health monitoring of the motherboard.

This motherboard has an onboard System_Hardware_Monitor chip that supports PC

health monitoring. An onboard voltage monitor will scan the voltages for processor,

memory, chipset, and battery continuously. Once a voltage becomes unstable, a

warning is given, or an error message is sent to the screen. The user can adjust

the voltage thresholds to dene the sensitivity of the voltage monitor.

Fan Status Monitor with Firmware Control

The PC health monitor chip can check the RPM status of a cooling fan. The onboard

CPU and chassis fans are controlled by rmware thermal management via IPMI 2.0.

Environmental Temperature Control

A thermal control sensor monitors the CPU temperature in real time and will turn

on the thermal control fan whenever the CPU temperature exceeds a user-dened

threshold. The overheat circuitry runs independently from the CPU. Once the

thermal management rmware detects that the CPU temperature is too high, it will

automatically turn on the thermal fan control to prevent the CPU from overheating.

The onboard chassis thermal circuitry can monitor the overall system temperature

and alert the user when the chassis temperature is too high.

Note: To avoid possible system overheating, please be sure to provide

adequate airow to your system.

System Resource Alert

This feature is available when used with SuperDoctor® III in the Windows OS

environment or used with SuperDoctor II in Linux. SuperDoctor is used to notify

the user of certain system events. For example, you can congure SuperDoctor

to provide you with warnings when the system temperature, CPU temperatures,

1-12

Chapter 1: Overview

voltages and fan speeds go beyond a predened range.

1-5 ACPI Features

ACPI stands for Advanced Conguration and Power Interface. The ACPI specica-

tion denes a exible and abstract hardware interface that provides a standard

way to integrate power management features throughout a PC system, including

its hardware, operating system and application software. This enables the system

to automatically turn on and off peripherals such as CD-ROMs, network cards, hard

disk drives and printers.

In addition to enabling operating_system-directed power management, ACPI also

provides a generic system event mechanism for Plug and Play, and an operating

system-independent interface for conguration control. ACPI leverages the Plug and

Play BIOS data structures, while providing a processor architecture-independent

implementation that is compatible with Windows 7, Windows Vista and Windows

2008 Operating Systems.

Slow Blinking LED for Suspend-State Indicator

When the CPU goes into a suspend state, the chassis power LED will start blinking

to indicate that the CPU is in suspend mode. When the user presses any key, the

CPU will "wake up" and the LED will automatically stop blinking and remain on.

1-6 Power Supply

As with all computer products, a stable power source is necessary for proper and

reliable operation. It is even more important for processors that have high CPU

clock rates.

The X9DR3-LN4F+/X9DRi-LN4F+ motherboard accommodates 24-pin ATX power

supplies. Although most power supplies generally meet the specications required

by the CPU, some are inadequate. In addition, two 12V 8-pin power connections are

also required to ensure adequate power supply to the system. Your power supply

must also supply 1.5A for the Ethernet ports.

Warning: To prevent damage to the power supply or motherboard, please use a power

supply that contains a 24-pin and two 8-pin power connectors. Be sure to connect these

power supply connectors to the 24-pin (JPW1) and two 8-pin power connectors (JPW2,

JPW3) on the motherboard. Failure to do so will void the manufacturer warranty on

your power supply and motherboard.

It is strongly recommended that you use a high quality power supply that meets ATX

power supply Specication 2.02 or above. It must also be SSI compliant. (For more

information, please refer to the website at http://www.ssiforum.org/). Additionally, in

1-13

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

areas where noisy power transmission is present, you may choose to install a line

lter to shield the computer from noise. It is recommended that you also install a

power surge protector to help avoid problems caused by power surges.

1-7 Super I/O

The Super I/O supports two high-speed, 16550 compatible serial communication

ports (UARTs). Each UART includes a 16-byte send/receive FIFO, a programmable

baud rate generator, complete modem control capability and a processor interrupt

system. Both UARTs provide legacy speed with baud rate of up to 115.2 Kbps

as well as an advanced speed with baud rates of 250 K, 500 K, or 1 Mb/s, which

support higher speed modems.

The Super I/O provides functions that comply with ACPI (Advanced Conguration

and Power Interface), which includes support of legacy and ACPI power manage-

ment through an SMI or SCI function pin. It also features auto power management

to reduce power consumption.

1-8 Advanced Power Management

The following advanced power management features are supported by this moth-

erboard:

Intel® Intelligent Power Node Manager (NM) (Available when the NMView utility is installed in the system)

The Intel® Intelligent Power Node Manager (IPNM) provides your system with

real-time thermal control and power management for maximum energy efciency.

Although IPNM Specication Version 1.5/2.0 is supported by the BMC (Baseboard

Management Controller), your system must also have IPNM-compatible Manage-

ment Engine (ME) rmware installed to use this feature.

Note: Support for IPNM Specication Version 1.5 or Vision 2.0 depends

on the power supply used in the system.

Management Engine (ME)

The Management Engine, which is an ARC controller embedded in the PCH, pro-

vides Server Platform Services (SPS) to your system. The services provided by

SPS are different from those provided by the ME on client platforms.

1-14

Chapter 1: Overview

1-9 Overview of the Nuvoton WPCM450 Controller

The Nuvoton WPCM450R Controller, a Baseboard Management Controller (BMC),

supports 2D/VGA-compatible Graphic Cores with PCI interface, creating multi-media

virtualization via Keyboard/Video/Mouse Redirection (KVMR). The WPCM450R

Controller is ideal for remote system management.

The WPCM450R Controller interfaces with the host system via PCI connections

to communicate with the graphics cores. It supports USB 2.0 and 1.1 for remote

keyboard/mouse/virtual media emulation. It also provides LPC interface support to

control Super IO functions. The WPCM450R Controller is connected to the network

via an external Ethernet PHY module or shared NCSI connections.

The WPCM450R communicates with onboard components via six SMBus inter-

faces, PECI (Platform Environment Control Interface) buses, and General Purpose

I/O ports.

Other Features Supported by the WPCM BMC Controller

The WPCM450R supports the following features:

•IPMI 2.0

•Serial over LAN

•KVM over LAN

•LAN Alerting-SNMP Trap

•Event Log

•X-Bus parallel interface for I/O expansion

•Multiple ADC inputs, Analog and Digital Video outputs

•SPI Flash Host BIOS and rmware bootstrap program supported

•Reduced Media Independent Interface (RMII)

•OS (Operating System) Independency

•Provides remote Hardware Health Monitoring via IPMI. Key features

1-15

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

•Provides Network Management Security via remote access/console redirection.

•Supports the following Management tools: IPMIView, CLI (Command Line

Interface)

•RMCP+ protocol supported

Note 1: For more information on IPMI conguration, please refer to the

IPMI User's Guide posted on our website at http://www.supermicro.com/

support/manuals/.

Note 2: The term "IPMI controller" and the term "BMC controller" can be

used interchangeably in this section.

1-16

Chapter 2: Installation

Chapter 2

Installation

2-1 Standardized Warning Statements

The following statements are industry-standard warnings, provided to warn the user

of situations which have the potential for bodily injury. Should you have questions or

experience difculty, contact Supermicro's Technical Support department for assis-

tance. Only certied technicians should attempt to install or congure components.

Read this section in its entirety before installing or conguring components in the

Supermicro chassis.

Battery Handling

Warning!

There is a danger of explosion if the battery is replaced incorrectly. Replace the

battery only with the same or equivalent type recommended by the manufacturer.

Dispose of used batteries according to the manufacturer's instructions

電池の取り扱い

電池交換が正しく行われなかった場合、破裂の危険性があります。交換する電池はメーカーが推奨する型、または同等のものを使用下さい。使用済電池は製造元の指示に従って処分して下さい。

警告电池更换不当会有爆炸危险。请只使用同类电池或制造商推荐的功能相当的电池更换原有电池。请按制造商的说明处理废旧电池。

警告電池更換不當會有爆炸危險。請使用製造商建議之相同或功能相當的電池更換原有電池。請按照製造商的說明指示處理廢棄舊電池。

Warnung

Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr. Ersetzen Sie die

Batterie nur durch den gleichen oder vom Hersteller empfohlenen Batterietyp.

Entsorgen Sie die benutzten Batterien nach den Anweisungen des Herstellers.

2-1

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

Attention

Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer

que par une pile de type semblable ou équivalent, recommandée par le fabricant.

Jeter les piles usagées conformément aux instructions du fabricant.

¡Advertencia!

Existe peligro de explosión si la batería se reemplaza de manera incorrecta. Re-

emplazar la batería exclusivamente con el mismo tipo o el equivalente recomen-

dado por el fabricante. Desechar las baterías gastadas según las instrucciones

del fabricante.

!הרהזא

תנכס תמייקץוציפ .הניקת אל ךרדב הפלחוהו הדימב הללוסה לש ףילחהל שי

גוסב הללוסה תא מ םאותה תרבחלמומ ןרציתצ.

תוללוסה קוליס תושמושמה עצבל שי .ןרציה תוארוה יפל









경고!

배터리가 올바르게 교체되지 않으면 폭발의 위험이 있습니다. 기존 배터리와 동일 하거나 제조사에서 권장하는 동등한 종류의 배터리로만 교체해야 합니다. 제조사 의 안내에 따라 사용된 배터리를 처리하여 주십시오.

Waarschuwing

Er is ontplofngsgevaar indien de batterij verkeerd vervangen wordt. Vervang de

batterij slechts met hetzelfde of een equivalent type die door de fabrikant aan-

bevolen wordt. Gebruikte batterijen dienen overeenkomstig fabrieksvoorschriften

afgevoerd te worden.

2-2

Chapter 2: Installation

Product Disposal

Warning!

Ultimate disposal of this product should be handled according to all national laws

and regulations.

製品の廃棄

この製品を廃棄処分する場合、国の関係する全ての法律・条例に従い処理する必要があります。

警告本产品的废弃处理应根据所有国家的法律和规章进行。

警告本產品的廢棄處理應根據所有國家的法律和規章進行。

Warnung

Die Entsorgung dieses Produkts sollte gemäß allen Bestimmungen und Gesetzen

des Landes erfolgen.

¡Advertencia!

Al deshacerse por completo de este producto debe seguir todas las leyes y regla-

mentos nacionales.

Attention

La mise au rebut ou le recyclage de ce produit sont généralement soumis à des

lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de

l'organisme compétent.

2-3

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

2-2 Static-Sensitive Devices

Electrostatic Discharge (ESD) can damage electronic com ponents. To avoid dam-

aging your system board, it is important to handle it very carefully. The following

measures are generally sufcient to protect your equipment from ESD.

Precautions

•Use a grounded wrist strap designed to prevent static discharge.

•Touch a grounded metal object before removing the motherboard from the

antistatic bag.

•Handle the board by its edges only; do not touch its components, peripheral

chips, memory modules or gold contacts.

•When handling chips or modules, avoid touching their pins.

•Put the motherboard and peripherals back into their antistatic bags when not

in use.

•For grounding purposes, make sure that your system chassis provides excellent

conductivity between the power supply, the case, the mounting fasteners and

the motherboard.

Unpacking

The motherboard is shipped in antistatic packaging to avoid static damage. When

unpacking the board, make sure that the person handling it is static protected.

2-4

Chapter 2: Installation

2-3 Processor and Heatsink Installation

Warning: When handling the processor package, avoid placing direct pressure on

the label area.

Notes:

•Always connect the power cord last, and always remove it before adding,

removing or changing any hardware components. Make sure that you install

the processor into the CPU socket before you install the CPU heatsink.

•If you buy a CPU separately, make sure that you use an Intel-certied multi-

directional heatsink only.

•Make sure to install the system board into the chassis before you install

the CPU heatsink.

•When receiving a server board without a processor pre-installed, make sure

that the plastic CPU socket cap is in place and none of the socket pins are

bent; otherwise, contact your retailer immediately.

•Refer to the Supermicro website for updates on CPU support.

Installing the LGA2011 Processor

1. There are two load levers on the LGA2011 socket. To open the socket cover,

rst press and release the load lever labeled 'Open 1st'.

WARNING!

OPEN 1st

Press down

labeled 'Open 1st'.

WARNING!

OPEN 1st

Load Lever

2-5

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

2. Press the second load lever labeled 'Close 1st' to release the load plate that

covers the CPU socket from its locking position.

Press down on

Load the

Lever labeled 'Close 1st'

Pull lever away from the socket

WARNING!

OPEN 1st

WARNING!

OPEN 1st

3. With the lever labeled 'Close 1st' fully retracted, gently push down on the

'Open 1st' lever to open the load plate. Lift the load plate to open it com-

pletely.

Gently push down to pop the

WARNING!

OPEN 1st

load plate open.

WARNING!

2-6

Chapter 2: Installation

1. Using your thumb and the index nger, remove the ' WARNING' plastic cap

from the socket.

WARNING!

2. Use your thumb and index nger to hold the CPU on its edges. Align the CPU

keys, which are semi-circle cutouts, against the socket keys.

Socket Keys

CPU Keys

3. Once they are aligned, carefully lower the CPU straight down into the socket.

(Do not drop the CPU on the socket. Do not move the CPU horizontally or

vertically. Do not rub the CPU against the surface or against any pins of the

socket to avoid damaging the CPU or the socket.)

Warning: You can only install the

CPU inside the socket in one direc-

tion. Make sure that it is properly

inserted into the CPU socket before

closing the load plate. If it doesn't

close properly, do not force it as it

may damage your CPU. Instead,

open the load plate again and dou-

ble-check that the CPU is aligned

properly.

2-7

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

4. With the CPU inside the socket, inspect the four corners of the CPU to make

sure that the CPU is properly installed.

5. Close the load plate with the CPU inside the socket. Lock the lever labeled

'Close 1st' rst, then lock the lever labeled 'Open 1st' second. Use your

thumb to gently push the load levers down to the lever locks.

1 2

Gently close

the load plate.

Push down and lock the

level labeled 'Close 1st'.

OPEN 1st

Lever Lock

Push down and

lock the lever

labeled 'Open 1st'

OPEN 1st

Lever Lock

2-8

Chapter 2: Installation

Installing a Passive CPU Heatsink

1. Do not apply any thermal grease to the heatsink or the CPU die -- the re-

quired amount has already been applied.

2. Place the heatsink on top of the CPU so that the four mounting holes are

aligned with those on the Motherboard's and the Heatsink Bracket under-

neath.

3. Screw in two diagonal screws (i.e., the #1 and the #2 screws) until just snug

(-do not over-tighten the screws to avoid possible damage to the CPU.)

4. Finish the installation by fully tightening all four screws.

Screw#4

Screw#1

OPEN 1st

Screw#2

Mounting Holes

Motherboard

Notes: 1. For optimized airow, please follow your chassis airow direc-

tion to install the correct CPU heatsink direction. 2. Graphic drawings

included in this manual are for reference only. They might look different

from the components installed in your system.

2-9

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

Removing the Heatsink

Warning: We do not recommend that the CPU or the heatsink be removed. However,

if you do need to uninstall the heatsink, please follow the instructions below to uninstall

the heatsink to prevent damage done to the CPU or the CPU socket.

1. Unscrew the heatsink screws from the motherboard in the sequence as

shown in the illustration below.

2. Gently wriggle the heatsink to loosen it from the CPU. (Do not use excessive

force when wriggling the heatsink!)

3. Once the CPU is loosened, remove the CPU from the CPU socket.

4. Remove the used thermal grease and clean the surface of the CPU and the

heatsink, Reapply the proper amount of thermal grease on the surface before

reinstalling the CPU and the heatsink. (Do not reuse old thermal grease!)

Loosen screws in sequence as shown.

Screw#4

Screw#1

Screw#2

Screw#3

Motherboard

Warning: Do not reuse old thermal grease!

2-10

Chapter 2: Installation

FAN5

2-4 Installing and Removing the Memory Modules

Note: Check Supermicro's website for recommended memory modules.

CAUTION

Exercise extreme care when installing or removing DIMM

modules to prevent any possible damage.

Installing & Removing DIMMs

1. Insert the desired number of DIMMs into the memory slots, starting with

P1-DIMMA1. (For best performance, please use the memory modules of the

same type and speed in the same bank.)

2. Push the release tabs outwards on both ends of the DIMM slot to unlock it.

JPL1

BMC

CTRL

JPB1

LAN

CTRL

LEM1

JPG1

JBMC1

CPU1 Slot1 PCI-E 3.0 x16

JSTBY1

J21

COM2

JI2C2

JI2C1

JTPM1

SAS

CTRL

USB9

JL1

USB6/7

USB4/5

XDP-PCH

IPMB

JWD1

JPME2

I-SATA4

I-SATA5

JPME1

JRK1

I-SATA3

I-SATA2

BIOS

I-SATA1

I-SATA0

JSD1

J18

SAS4~7

J17

CPU1 Slot2 PCI-E 3.0 x4 (in X8 slot)

CPU1 Slot3 PCI-E 3.0 x16

JBT1

PCH

JWP1

SAS0~3

FANB

BIOS BOX

XDP-CPU

FANA

CPU2 Slot4 PCI-E 3.0 x16

JP7

JP6

JBAT1

SP1

JOH1

JF2

FAN4

JD1

CPU2 Slot5 PCI-E 3.0 x16

CPU2 Slot6 PCI-E 3.0 x8

LE2

SW1

UID

LAN2/4

VGA

P2 DIMME1

P2 DIMME3

P2 DIMME2

P2 DIMMF1

Alaways populate DIMMx1 first

X9DR3-LN4F+/X9DRi-LN4F+

Rev. 1.10

Alaways populate DIMMx1 first

P1 DIMMD2

P1 DIMMC1

P1 DIMMC2

P1 DIMMC3

P1 DIMMD1

P1 DIMMD3

FAN3

LE1

JF1

USB 2/3

USB 0/1

LAN1/3

COM1

FAN6

PHY

IPMI_LAN

P2 DIMMF3

P2 DIMMF2

P2 DIMMG3

P2 DIMMG2

P2 DIMMH1

P2 DIMMH2

P2 DIMMH3

P2 DIMMG1

CPU2

JPI2C1

CPU1

JPW3

JPW2

JPW1

P1 DIMMA2

P1 DIMMB3

P1 DIMMB2

P1 DIMMB1

P1 DIMMA1

P1 DIMMA3

FAN2

FAN1

Notches

Release Tabs

3. Align the key of the DIMM module with the receptive point on the memory

slot.

4. Align the notches on both ends of the module against the receptive points on

the ends of the slot.

5. Use two thumbs together to press the notches on both ends of the module

straight down into the slot until the module snaps into place.

6. Press the release tabs to the locking positions to secure the DIMM module

into the slot.

Press both notches straight

down into the memory slot at

the same time.

Removing Memory Modules

Press both notches at the ends of a DIMM module to unlock it. Once it is loosened,

remove the DIMM module from the motherboard.

2-11

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

Memory Support for the X9DR3-LN4F+/X9DRi-LN4F+ Motherboard

The X9DR3-LN4F+/X9DRi-LN4F+ motherboard supports up to 1.5 TB of Load

Reduced (LRDIMM), 768 Gb of Registered (RDIMM) or 128 GB of Unbuffered

(UDIMM) ECC/Non-ECC DDR3 800/1066/1333/1600/1866 MHz of 240-pin 4-chan-

nel memory in 24 DIMM slots.

Note: For the latest memory updates, please refer to the Tested Memory

List posted on our website (http://www.supermicro.com/products/mother-

board).

Processor & Memory Module Population Conguration

For memory to work properly, follow the tables below for memory installation.

Processor and Memory Module Population

Number of

CPUs+DIMMs

1 CPU & 2 DIMMs

1 CPU & 4 DIMMs

1 CPU &

5~8 DIMMs

1 CPU &

9~12 DIMMs

2 CPUs &

4 DIMMs

2 CPUs &

6 DIMMs

2 CPUs &

8 DIMMs

2 CPUs &

9~12 DIMMs

2 CPUs &

13 DIMMs~24

DIMMs

CPU1 P1-DIMMA1/P1-DIMMB1

CPU1 P1-DIMMA1/P1-DIMMB1, P1-DIMMC1/P1-DIMMD1

CPU1 P1-DIMMA1/P1-DIMMB1, P1-DIMMC1/P1-DIMMD1, P1-DIMMA2/P1-DIMMB2, P1-DIMMC2/ P1-DIMMD2

CPU1 P1-DIMMA1/P1-DIMMB1, P1-DIMMC1/P1-DIMMD1, P1-DIMMA2/P1-DIMMB2, P1DIMMC2/P1-DIMMD2, P1-DIMMA3/P1-DIMMB3, P1-DIMMC3/P1-DIMMD3

CPU1 + CPU2 P1-DIMMA1/P1-DIMMB1, P2-DIMME1/P2-DIMMF1

CPU1 + CPU2 P1-DIMMA1/P1-DIMMB1, P2-DIMME1/P2-DIMMF1, P1-DIMMC1/P1-DIMMD1

CPU1 + CPU2 P1-DIMMA1/P1-DIMMB1, P2-DIMME1/P2-DIMMF1, P1-DIMMC1/P1-DIMMD1, P2-DIMMG1/ P2-DIMMH1

CPU1/CPU2 P1-DIMMA1/P1-DIMMB1, P2-DIMME1/P2-DIMMF1, P1-DIMMC1/P1-DIMMD1, P2-DIMMG1/ P2-DIMMH1, P1-DIMMA2/P1-DIMMB2, P2-DIMME2/P2-DIMMF2

CPU1/CPU P1-DIMMA1/P1-DIMMB1, P2-DIMME1/P2-DIMMF1, P1-DIMMC1/P1-DIMMD1, P2-DIMMG1/ P2-DIMMH1, P1-DIMMA2/P1-DIMMB2, P2-DIMME2/P2-DIMMF2, P1-DIMMC2/P1-DIMMD2, P2-DIMMG2/P2-DIMMH2, P1-DIMMA3/P1-DIMMB3, P2-DIMME3/ P2-DIMMF3, P1-DIMMC3/P1-DIMMD3, P2-DIMMG3/P2-DIMMH3

CPU and Memory Population Conguration Table

Note: 1866 MHz memory support is dependent on Intel E5-2600v2 CPUs.

For Intel E5-2600(v2) processor support, BIOS version 3.0 or above is

required.

2-12

Chapter 2: Installation

Populating UDIMM (ECC/Non-ECC) Memory Modules

Intel E5-2600(v2) Series Processor UDIMM Memory Support

Ranks

Per

DIMM

& Data

Width

SRx8

Non-

ECC

DRx8

Non-

ECC

SRx16

Non-

ECC

SRx8

ECC

DRx8

ECC

Note: For detailed information on memory support and updates, please refer to the SMC Recommended

Memory List posted on our website at http://www.supermicro.com/support/resources/mem.cfm.

Memory Capacity

Per DIMM

(See the Note below)

1GB 2GB 4GB NA 1066,

2GB 4GB 8GB NA 1066,

512MB 1GB 2GB NA 1066,

1GB 2GB 4GB 1066,

2GB 4GB 8GB 1066,

Speed (MT/s) and Voltage Validated by Slot per Channel (SPC) and

2 Slots Per Channel 3 Slots Per Channel

1DPC 2DPC 1DPC 2DPC

1.35V 1.5V 1.35V 1.5V 1.35V 1.5V 1.35V 1.5v

1333, 1600,

1866

1333, 1600,

1866

1333, 1600,

1866

1066,

1333

1333, 1600,

1866

1066,

1333

1333, 1600,

1866

DIMM Per Channel (DPC)

NA 1066,

1066,

1333

1066,

1333

1333,

1600

1333,

1600

1333,

1600

1066, 1333,

1600

1066, 1333,

1600

N/A 1066,

1066, 1333

1333, 1600,

1866

1333, 1600,

1866

1333, 1600,

1866

1066, 1333, 1600,

1866

1066, 1333, 1600,

1866

N/A 1066,

1333,

1600

N/A 1066,

1333,

1600

N/A 1066,

1333,

1600

1066,

1333

1333,

1600

1066,

1333

1333,

1600

Populating RDIMM (ECC) Memory Modules

Intel E5-2600(v2) Series Processor RDIMM Memory Support

Ranks

Memory Capacity

Per

DIMM

& Data

Width

SRx8 1GB 2GB 4GB 1066,

DRx8 2GB 4GB 8GB 1066,

SRx4 2GB 4GB 8GB 1066,

DRx4 4GB 8GB 16GB 1066,

QRx4 8GB 16GB 32GB 800 800

QRx8 4GB 8GB 16GB 800 800

Note: For detailed information on memory support and updates, please refer to the SMC Recommended Memory List posted

on our website at http://www.supermicro.com/support/resources/mem.cfm.

Per DIMM

(See the Note

Below)

Speed (MT/s) and Voltage Validated by Slot per Channel (SPC) and DIMM Per Chan-

2 Slots Per Channel 3 Slots Per Channel

1DPC 2DPC 1 DPC 2DPC 3DPC

1.35V 1.5V 1.35V 1.5V 1.35V 1.5V 1.35V 1.5V 1.35V 1.5v

1066,

1333

1066,

1333,

1333

1600,

1866

1066,

1333,

1333

1600,

1866

1066,

1333,

1333

1600,

1866

1066,

1333,

1333

1600,

1866

800 800 800 800,

1066

800 800 800 800,

1066

1066, 1333,

1600

1066, 1333,

1600

1066, 1333,

1600

1066, 1333,

1600

nel (DPC)

1066, 1333

1066,

1333,

1333 1600, 1866

1066,

1066, 1333,

1333 1600, 1866

1066,

1066, 1333,

1333 1600, 1866

1066,

1066, 1333,

1333 1600, 1866

800 800 N/A N/A

1066

800 800 N/A N/A

1066

1066, 1333, 1600

800 800,

1066

800 800,

1066

800 800,

1066

800 800,

1066

2-13

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

Populating UDIMM (ECC/Non-ECC) Memory Modules

Intel E5-2600 Series Processor UDIMM Memory Support

Ranks

Per

DIMM

& Data

Width

SRx8 Non-

ECC

DRx8 Non-

ECC

SRx16

Non-

ECC

SRx8

ECC

DRx8

ECC

Note: For detailed information on memory support and updates, please refer to the SMC Recommended

Memory List posted on our website at http://www.supermicro.com/support/resources/mem.cfm.

Memory Capacity

Per DIMM

(See the Note below)

1GB 2GB 4GB NA 1066,

2GB 4GB 8GB NA 1066,

512MB 1GB 2GB NA 1066,

1GB 2GB 4GB 1066,

2GB 4GB 8GB 1066,

Speed (MT/s) and Voltage Validated by Slot per Channel (SPC) and

2 Slots Per Channel 3 Slots Per Channel

1DPC 2DPC 1DPC 2DPC

1.35V 1.5V 1.35V 1.5V 1.35V 1.5V 1.35V 1.5v

1333

1066,

1333

1066,

1333

DIMM Per Channel (DPC)

NA 1066,

1066 1066,

1333

N/A 1066,

1066 1066,

1333,

1333

1333,

N/A 1066,

1333

N/A 1066,

1333

N/A 1066,

1333

1066,

1333

1066,

1333

Populating RDIMM (ECC) Memory Modules

Intel E5-2600 Series Processor RDIMM Memory Support

Ranks

DIMM

Width

SRx8 1GB 2GB 4GB 1066,

DRx8 2GB 4GB 8GB 1066,

SRx4 2GB 4GB 8GB 1066,

DRx4 4GB 8GB 16GB 1066,

QRx4 8GB 16GB 32GB 800 1066 800 800 800 1066 800 800 N/A N/A

Memory Capacity

Per

Data

(See the Note Below)

Per DIMM

Speed (MT/s) and Voltage Validated by Slot per Channel (SPC) and DIMM Per Channel

2 Slots Per Channel 3 Slots Per Channel

1DPC 2DPC 1 DPC 2DPC 3DPC

1.35V 1.5V 1.35V 1.5V 1.35V 1.5V 1.35V 1.5V 1.35V 1.5v

1066,

1333

1333,

1600

1066, 1333,

1600

1066, 1333,

1600

1066, 1333,

1600

1333

1066,

1333

1066,

1333

1066,

1333

1066, 1333, 1600

1066, 1333

(DPC)

1066, 1333,

1600

1066, 1333,

1600

1066, 1333,

1600

1066, 1333,

1600

1066, 1333

1066, 1333,

1600

1066, 1333,

1600

1066, 1333,

1600

1066, 1333,

1600

N/A 800,

1066

QRx8 4GB 8GB 16GB 800 1066 800 800 800 1066 800 800 N/A N/A

Note: For detailed information on memory support and updates, please refer to the SMC Recommended Memory List posted on

our website at http://www.supermicro.com/support/resources/mem.cfm.

2-14

Chapter 2: Installation

Populating LRDIMM (ECC) Memory Modules

Intel E5-2600(v2) Series Processor LRDIMM Memory Support

Ranks

Per

DIMM

Data

Width

QRx4

(DDP)

8Rx4

(QDP)

Note: For detailed information on memory support and updates, please refer to the SMC Recommended Memory

List posted on our website at http://www.supermicro.com/support/resources/mem.cfm.

Ranks

Per

DIMM

Data

Width

QRx4

(DDP)

Memory

Capacity

Per DIMM

(See the Note

Below)

16GB 32GB 1066,

32GB 64GB 1066 1066 1066 1066 1066 1066 1066 1066 1066 1066

Speed (MT/s) and Voltage Validated by Slot per Channel (SPC) and DIMM Per

2 Slots Per Channel 3 Slots Per Channel

1DPC 2DPC 1DPC 2DPC 3DPC

1.35V 1.5V 1.35V 1.5V 1.35V 1.5V 1.35V 1.5V 1.35V 1.5V

1066, 1333, 1600, 1866

1066, 1333, 1600

1333,

1600

1066, 1333, 1600

Channel (DPC)

1066,

1333,

1600

1600, 1866

1066,

1333,

1600

1066, 1333,

1600

Intel E5-2600 Series Processor LRDIMM Memory Support

Memory

Capacity

Per DIMM

(See the Note

Below)

16GB 32GB 1066 1066,

Speed (MT/s) and Voltage Validated by Slot per Channel (SPC) and DIMM Per

2 Slots Per Channel 3 Slots Per Channel

1DPC 2DPC 1DPC 2DPC 3DPC

1.35V 1.5V 1.35V 1.5V 1.35V 1.5V 1.35V 1.5V 1.35V 1.5V

1066 1066,

1333

Channel (DPC)

1066 1066,

1333

1066 1066,

1333

1066 1066

QRx8

8GB 16GB 1066 1066,

(QDP)

Note: For detailed information on memory support and updates, please refer to the SMC Recommended Memory

List posted on our website at http://www.supermicro.com/support/resources/mem.cfm.

1333

1066 1066,

1333

1066 1066 1066 1066 1066 1066

Other Important Notes and Restrictions

•For the memory modules to work properly, please install DIMM modules of the same

type, same speed and same operating frequency on the motherboard. Mixing of

RDIMMs, UDIMMs or LRDIMMs is not allowed. Do not install both ECC and Non-ECC

memory modules on the same motherboard.

•Using DDR3 DIMMs with different operating frequencies is not allowed. All channels

in a system will run at the lowest common frequency.

2-15

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

2-5 Motherboard Installation

All motherboards have standard mounting holes to t different types of chassis.

Make sure that the locations of all the mounting holes for both motherboard and

chassis match. Although a chassis may have both plastic and metal mounting fas-

teners, metal ones are highly recommended because they ground the motherboard

to the chassis. Make sure that the metal standoffs click in or are screwed in tightly.

Then use a screwdriver to secure the motherboard onto the motherboard tray.

Tools Needed

•Phillips Screwdriver

•Pan head screws (12 pieces)

•Standoffs (12 pieces, if needed)

Location of Mounting Holes

There are twelve (12) mounting holes on this motherboard indicated by the arrows.

USB 2/3

USB 0/1

LAN1/3

LAN2/4

JTPM1

IPMB

JPME2

JPG1

JBMC1

JSTBY1

J21

JI2C2 JI2C1

JL1

USB6/7

USB4/5

JWD1

I-SATA4

JPME1

I-SATA2

I-SATA0

J17

LEM1

COM2

CTRL

USB9

I-SATA5

I-SATA3

I-SATA1

JSD1

J18

BMC

CTRL

CPU1 Slot2 PCI-E 3.0 x4 (in X8 slot)

CPU1 Slot1 PCI-E 3.0 x16

SAS

JBT1

XDP-PCH

PCH

JRK1

BIOS

JWP1

SAS4~7

SAS0~3

FANB

JPB1

CTRL

CPU2 Slot4 PCI-E 3.0 x16

CPU1 Slot3 PCI-E 3.0 x16

JP7

JP6

BIOS BOX

XDP-CPU

SP1

JOH1

JF2

FANA

JD1

LAN

CPU2 Slot5 PCI-E 3.0 x16

JBAT1

FAN4

LE2

SW1

JPL1

CPU2 Slot6 PCI-E 3.0 x8

VGA

UID

X9DR3-LN4F+/X9DRi-LN4F+

Rev. 1.10

Alaways populate DIMMx1 first

P1 DIMMC1

P1 DIMMC2

P1 DIMMC3

P1 DIMMD1

FAN3

JF1

P2 DIMME1

P2 DIMMF3

P2 DIMMF2

P2 DIMME3

P2 DIMME2

P2 DIMMF1

Alaways populate DIMMx1 first

P1 DIMMD2

P1 DIMMD3

LE1

CPU1

CPU2

IPMI_LAN

P1 DIMMB3

COM1

FAN6

P2 DIMMG3

P2 DIMMG2

P2 DIMMH1

P2 DIMMH2

P2 DIMMH3

P2 DIMMG1

P1 DIMMA2

P1 DIMMB2

P1 DIMMB1

P1 DIMMA1

P1 DIMMA3

FAN2

FAN5

PHY

JPI2C1

JPW3

JPW2

JPW1

FAN1

Caution: 1) To avoid damaging the motherboard and its components,

please do not use a force greater than 8 lb/inch on each mounting screw

during motherboard installation. 2) Some components are very close to the

mounting holes. Please take precautionary measures to prevent damage

to these components when installing the motherboard to the chassis.

2-16

Chapter 2: Installation

Installing the Motherboard

1. Install the I/O shield into the chassis.

2. Locate the mounting holes on the motherboard.

3. Locate the matching mounting holes on the chassis. Align the mounting holes

on the motherboard against the mounting holes on the chassis.

4. Install standoffs in the chassis as needed.

5. Install the motherboard into the chassis carefully to avoid damaging mother-

board components.

6. Using the Phillips screwdriver, insert a Pan head #6 screw into a mounting

hole on the motherboard and its matching mounting hole on the chassis.

7. Repeat Step 5 to insert #6 screws into all mounting holes.

8. Make sure that the motherboard is securely placed in the chassis.

Note: Images displayed are for illustration only. Your chassis or compo-

nents might look different from those shown in this manual.

2-17

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

345

2-6 Control Panel Connectors and I/O Ports

The I/O ports are color coded in conformance with the PC 99 specication. See

the picture below for the colors and locations of the various I/O ports.

Back Panel Connectors and I/O Ports

USB 2/3

USB 0/1

LAN1/3

LAN2/4

VGA

LE2

SW1

UID

JPL1

BMC

CTRL

JPB1

LAN

CTRL

LEM1

JPG1

JBMC1

CPU1 Slot1 PCI-E 3.0 x16

JSTBY1

J21

COM2

JI2C2 JI2C1

JTPM1

SAS

CTRL

USB9

JBT1

JL1

USB6/7

USB4/5

XDP-PCH

IPMB

JWD1

JPME2

I-SATA4

I-SATA5

JPME1

JRK1

I-SATA3

I-SATA2

BIOS

I-SATA1

I-SATA0

JSD1

J18

SAS4~7

J17

CPU2 Slot4 PCI-E 3.0 x16

CPU1 Slot2 PCI-E 3.0 x4 (in X8 slot)

CPU1 Slot3 PCI-E 3.0 x16

BIOS BOX

XDP-CPU

PCH

JWP1

SAS0~3

FANB

FANA

JD1

JP7

JP6

SP1

JOH1

JBAT1

JF2

FAN4

CPU2 Slot5 PCI-E 3.0 x16

CPU2 Slot6 PCI-E 3.0 x8

X9DR3-LN4F+/X9DRi-LN4F+

Rev. 1.10

Alaways populate DIMMx1 first

P1 DIMMD2

P1 DIMMC1

P1 DIMMC2

P1 DIMMC3

P1 DIMMD1

P1 DIMMD3

FAN3

JF1

Back Panel I/O Port Locations and Denitions

P2 DIMME1

P2 DIMMF3

P2 DIMMF2

P2 DIMME3

P2 DIMME2

P2 DIMMF1

Alaways populate DIMMx1 first

LE1

COM1

FAN6

FAN5

IPMI_LAN

CPU2

CPU1

P1 DIMMB3

P1 DIMMB2

PHY

P2 DIMMG3

P2 DIMMG2

P2 DIMMH1

P2 DIMMH2

P2 DIMMH3

P2 DIMMG1

JPI2C1

JPW3

JPW2

JPW1

P1 DIMMA2

P1 DIMMB1

P1 DIMMA1

P1 DIMMA3

FAN2

FAN1

1. COM Port 1 (Turquoise)

2. Back Panel USB Port 0

3. Back Panel USB Port 1

4. IPMI_Dedicated LAN

5. Back Panel USB Port 2

6. Back Panel USB Port 3

7. Gigabit LAN 1

8. Gigabit LAN 3

9. Gigabit LAN 2

10. Gigabit LAN 4

11. Back Panel VGA (Blue)

12. UID Switch

2-18

Chapter 2: Installation

COM1

COM2

COM1

COM2

123

Serial Ports

Two COM connections (COM1 &

COM2) are located on the motherboard.

COM1 is located on the Backplane I/O

panel. COM2, located close to CPU1

Slot1 PCI-E slot, provides front access

support. See the table on the right for

pin denitions.

Video Connection

A Video (VGA) port is located next

to USB 2/3 on the I/O backplane.

Refer to the board layout below for

the location.

Serial COM) Ports

Pin Denitions

Pin # Denition Pin # Denition

1 DCD 6 DSR

2 RXD 7 RT S

3 TXD 8 CTS

4 DTR 9 RI

5 Ground 10 N/A

JPG1

J21

JTPM1

IPMB

JPME2

J17

BMC

CTRL

LEM1

JBMC1

CPU1 Slot2 PCI-E 3.0 x4 (in X8 slot)

CPU1 Slot1 PCI-E 3.0 x16

JSTBY1

COM2

JI2C2 JI2C1

SAS

CTRL

USB9

JBT1

JL1

USB6/7

USB4/5

XDP-PCH

JWD1

I-SATA4

I-SATA5

JPME1

JRK1

I-SATA3

I-SATA2

BIOS

JWP1

I-SATA1

I-SATA0

JSD1

J18

SAS4~7

SAS0~3

FANB

JPB1

CPU1 Slot3 PCI-E 3.0 x16

BIOS BOX

XDP-CPU

PCH

FANA

LAN

CTRL

CPU2 Slot4 PCI-E 3.0 x16

CPU2 Slot5 PCI-E 3.0 x16

JP7

JP6

JBAT1

SP1

JOH1

JF2

FAN4

JD1

LE2

SW1

UID

JPL1

CPU2 Slot6 PCI-E 3.0 x8

LAN2/4

VGA

P2 DIMME1

P2 DIMME3

P2 DIMME2

P2 DIMMF1

Alaways populate DIMMx1 first

X9DR3-LN4F+/X9DRi-LN4F+

Rev. 1.10

Alaways populate DIMMx1 first

P1 DIMMD2

P1 DIMMC1

P1 DIMMC2

P1 DIMMC3

P1 DIMMD1

P1 DIMMD3

FAN3

LE1

JF1

USB 2/3

USB 0/1

LAN1/3

COM1

FAN6

FAN5

IPMI_LAN

P2 DIMMF3

P2 DIMMF2

CPU2

CPU1

P1 DIMMB3

P1 DIMMB2

P1 DIMMB1

FAN2

PHY

P2 DIMMG3

P2 DIMMG2

P2 DIMMH1

P2 DIMMH2

P2 DIMMH3

P2 DIMMG1

JPI2C1

JPW3

JPW2

JPW1

P1 DIMMA2

P1 DIMMA1

P1 DIMMA3

FAN1

1. COM1

2. COM2

3. VGA

2-19

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

Universal Serial Bus (USB)

Four Universal Serial Bus ports

(USB 0/1, USB 2/3) are located on

the I/O back panel. In addition, two

USB headers, located close to the

Intel PCH chip, provides four front-

accessible USB connections (USB

4/5, USB 6/7). One Type A connec-

tor (USB9) also support front panel

USB connections. (Cables are not

included). See the tables on the right

for pin denitions.

Backplane USB

(USB 0/1, 2/3)

Pin Denitions

Pin# Denition

1 +5V

2 PO-

3 PO+

4 Ground

5 NA

FP USB (4/5, 6/7)

Pin Denitions

USB 4, 6, 9

Pin # Denition

USB 5, 7

Pin # Denition

1 +5V 1 +5V

2 PO- 2 PO-

3 PO+ 3 PO+

4 Ground 4 Ground

5 NC 5 Key

(NC= No connection)

1. Backpanel USB 0

2. BP USB 1

USB 2/3

USB 0/1

LAN1/3

LAN2/4

VGA

LE2

SW1

UID

JWP1

SAS0~3

JPB1

CPU1 Slot3 PCI-E 3.0 x16

BIOS BOX

XDP-CPU

PCH

FANB

FANA

LAN

CTRL

CPU2 Slot4 PCI-E 3.0 x16

CPU2 Slot5 PCI-E 3.0 x16

JP7

JP6

JBAT1

SP1

JOH1

JF2

FAN4

JD1

JPL1

CPU2 Slot6 PCI-E 3.0 x8

P2 DIMME1

P2 DIMME2

Alaways populate DIMMx1 first

X9DR3-LN4F+/X9DRi-LN4F+

Rev. 1.10

Alaways populate DIMMx1 first

P1 DIMMD2

P1 DIMMC1

P1 DIMMC2

P1 DIMMC3

P1 DIMMD1

P1 DIMMD3

FAN3

LE1

JF1

BMC

CTRL

LEM1

JPG1

JBMC1

CPU1 Slot2 PCI-E 3.0 x4 (in X8 slot)

CPU1 Slot1 PCI-E 3.0 x16

JSTBY1

J21

COM2

JI2C2 JI2C1

JTPM1

SAS

CTRL

USB9

JBT1

JL1

USB6/7

USB4/5

XDP-PCH

IPMB

JWD1

JPME2

I-SATA4

I-SATA5

JPME1

JRK1

I-SATA3

I-SATA2

BIOS

I-SATA1

I-SATA0

JSD1

J18

SAS4~7

J17

COM1

FAN6

FAN5

IPMI_LAN

P2 DIMMF3

P2 DIMMF2

P2 DIMME3

P2 DIMMF1

CPU2

PHY

P2 DIMMG3

P2 DIMMG2

P2 DIMMH1

P2 DIMMH2

P2 DIMMH3

P2 DIMMG1

3. BP USB 2

4. BP USB 3

5. FP USB 4/5

6. FP USB 6/7

7. FP USB 9

JPI2C1

CPU1

P1 DIMMB3

P1 DIMMB2

JPW3

JPW2

JPW1

P1 DIMMA2

P1 DIMMB1

P1 DIMMA1

P1 DIMMA3

FAN2

FAN1

2-20

Chapter 2: Installation

345

Ethernet Ports

Four Gigabit Ethernet ports (LAN1/3,

LAN2/4) are located on the I/O back-

plane on the motherboard. In addition,

an IPMI_Dedicated LAN is located

above USB 0/1 ports on the back-

plane to provide KVM support for

IPMI 2.0. All these ports accept RJ45

type cables.

Note: Please refer to the

LED Indicator Section for

LAN LED information.

LAN Ports

Pin Denition

Pin# Denition

1 P2V5SB 10 SGND

2 TD0+ 11 Act LED

3 TD0- 12 P3V3SB

4 TD1+ 13 Link 100 LED (Yel-

5 TD1- 14 Link 1000 LED

low, +3V3SB)

(Yellow, +3V3SB)

6 TD2+ 15 Ground

7 TD2- 16 Ground

8 TD3+ 17 Ground

9 TD3- 18 Ground

(NC: No Connection)

1. GLAN1

2. GLAN3

3. GLAN2

4. GLAN4

USB 2/3

USB 0/1

LAN1/3

LAN2/4

VGA

LE2

SW1

UID

JPL1

BMC

CTRL

JPB1

LAN

CTRL

LEM1

JPG1

JBMC1

CPU1 Slot1 PCI-E 3.0 x16

JSTBY1

J21

COM2

JI2C2 JI2C1

JTPM1

SAS

CTRL

USB9

JBT1

JL1

USB6/7

USB4/5

XDP-PCH

IPMB

JWD1

JPME2

I-SATA4

I-SATA5

JPME1

JRK1

I-SATA3

I-SATA2

BIOS

I-SATA1

I-SATA0

JSD1

J18

SAS4~7

J17

CPU1 Slot2 PCI-E 3.0 x4 (in X8 slot)

CPU1 Slot3 PCI-E 3.0 x16

BIOS BOX

XDP-CPU

PCH

JWP1

SAS0~3

FANB

FANA

CPU2 Slot4 PCI-E 3.0 x16

JP7

JP6

JBAT1

SP1

JOH1

JF2

FAN4

JD1

CPU2 Slot6 PCI-E 3.0 x8

CPU2 Slot5 PCI-E 3.0 x16

X9DR3-LN4F+/X9DRi-LN4F+

Rev. 1.10

Alaways populate DIMMx1 first

P1 DIMMD2

P1 DIMMC1

P1 DIMMC2

P1 DIMMC3

P1 DIMMD1

P1 DIMMD3

FAN3

JF1

P2 DIMME1

P2 DIMMF3

P2 DIMMF2

P2 DIMME3

P2 DIMME2

P2 DIMMF1

Alaways populate DIMMx1 first

LE1

COM1

FAN6

FAN5

IPMI_LAN

CPU2

CPU1

P1 DIMMB3

P1 DIMMB2

PHY

P2 DIMMG3

P2 DIMMG2

P2 DIMMH1

P2 DIMMH2

P2 DIMMH3

P2 DIMMG1

JPI2C1

JPW3

JPW2

JPW1

P1 DIMMA2

P1 DIMMB1

P1 DIMMA1

P1 DIMMA3

FAN2

FAN1

5. IPMI_LAN

2-21

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

Unit Identier Switch

A Unit Identier (UID) Switch and two LED

Indicators are located on the motherboard.

The UID Switch is located next to the LAN

2/4 ports on the backplane. The Rear UID

LED (LE2) is located next to the UID Switch.

The Front Panel UID LED is located at pins

7/8 of the Front Control Panel at JF1. Con-

nect a cable to pin 8 on JF1 for Front Panel

UID LED indication. When you press the

UID switch, both Rear UID LED and Front

Panel UID LED Indicators will be turned on.

Press the UID switch again to turn off both

LED Indicators. These UID Indicators provide

easy identication of a system unit that may

be in need of service.

Note: UID can also be triggered via

IPMI on the motherboard. For more

information on IPMI, please refer to

the IPMI User's Guide posted on

our website @ http://www.super-

micro.com.

USB 2/3

USB 0/1

LAN1/3

LAN2/4

VGA

LE2

SW1

UID

JPL1

BMC

CTRL

JPB1

LAN

CTRL

LEM1

JPG1

JBMC1

CPU1 Slot1 PCI-E 3.0 x16

JSTBY1

J21

COM2

JI2C2 JI2C1

JTPM1

SAS

CTRL

USB9

JBT1

JL1

USB6/7

USB4/5

XDP-PCH

IPMB

JWD1

JPME2

I-SATA4

I-SATA5

JPME1

JRK1

I-SATA3

I-SATA2

BIOS

I-SATA1

I-SATA0

JSD1

J18

SAS4~7

J17

CPU2 Slot4 PCI-E 3.0 x16

CPU1 Slot2 PCI-E 3.0 x4 (in X8 slot)

CPU1 Slot3 PCI-E 3.0 x16

BIOS BOX

XDP-CPU

PCH

JWP1

SAS0~3

FANB

FANA

JD1

JP7

JP6

SP1

JOH1

JBAT1

JF2

FAN4

CPU2 Slot5 PCI-E 3.0 x16

CPU2 Slot6 PCI-E 3.0 x8

X9DR3-LN4F+/X9DRi-LN4F+

Rev. 1.10

Alaways populate DIMMx1 first

P1 DIMMD2

P1 DIMMC1

P1 DIMMC2

P1 DIMMC3

P1 DIMMD1

P1 DIMMD3

FAN3

JF1

P2 DIMME1

P2 DIMMF3

P2 DIMMF2

P2 DIMME3

P2 DIMME2

P2 DIMMF1

Alaways populate DIMMx1 first

LE1

COM1

FAN6

IPMI_LAN

P2 DIMMG3

P2 DIMMG2

P2 DIMMH1

P2 DIMMH2

P2 DIMMH3

P2 DIMMG1

CPU2

CPU1

P1 DIMMA2

P1 DIMMB3

P1 DIMMB2

P1 DIMMB1

P1 DIMMA1

P1 DIMMA3

FAN2

FAN5

PHY

JPI2C1

JPW3

JPW2

JPW1

FAN1

Blue+ (OH/Fan Fail/ PWR FaiL/UID LED)

Ground

FP PWRLED

HDD LED

NIC1 Link LED

NIC2 Link LED

Power Fail LED

UID Switch

Pin# Denition

1 Ground

2 Ground

3 Button In

4 Ground

UID LED (LE2)

Color/State Status

Blue Unit Identied

1. UID Switch

2. Rear UID LED (LE2)

3. Front UID LED

1920

NMI

Ground

NIC1 Activity LED

Reset

PWR

3.3 V

ID_UID_SW/3/3V Stby

NIC2 Activity LED

Red+ (Blue LED Cathode)

3.3V

Status

Reset Button

Power Button

2-22

Chapter 2: Installation

Front Control Panel

JF1 contains header pins for various buttons and indicators that are normally lo-

cated on a control panel at the front of the chassis. These connectors are designed

specically for use with Supermicro's server chassis. See the gure below for the

descriptions of the various control panel buttons and LED indicators. Refer to the

following section for descriptions and pin denitions.

USB 2/3

USB 0/1

LAN1/3

LAN2/4

JPB1

BIOS BOX

XDP-CPU

FANA

LAN

CTRL

CPU2 Slot4 PCI-E 3.0 x16

CPU2 Slot5 PCI-E 3.0 x16

JP7

JP6

JBAT1

SP1

JOH1

JF2

FAN4

JD1

JPL1

CPU2 Slot6 PCI-E 3.0 x8

P2 DIMME1

P2 DIMMF3

P2 DIMMF2

P2 DIMME3

P2 DIMME2

P2 DIMMF1

Alaways populate DIMMx1 first

X9DR3-LN4F+/X9DRi-LN4F+

Rev. 1.10

Alaways populate DIMMx1 first

P1 DIMMD2

P1 DIMMC1

P1 DIMMC2

P1 DIMMC3

P1 DIMMD1

P1 DIMMD3

FAN3

LE1

JF1

BMC

CTRL

LEM1

JPG1

JBMC1

CPU1 Slot2 PCI-E 3.0 x4 (in X8 slot)

CPU1 Slot3 PCI-E 3.0 x16

CPU1 Slot1 PCI-E 3.0 x16

JSTBY1

J21

COM2

JI2C2 JI2C1

JTPM1

SAS

CTRL

USB9

JBT1

JL1

USB6/7

USB4/5

XDP-PCH

IPMB

JPME2

PCH

JWD1

I-SATA4

I-SATA5

JPME1

JRK1

I-SATA3

I-SATA2

BIOS

JWP1

I-SATA1

I-SATA0

JSD1

J18

SAS4~7

SAS0~3

J17

FANB

VGA

LE2

SW1

UID

COM1

FAN6

IPMI_LAN

P2 DIMMG3

P2 DIMMG2

P2 DIMMH1

P2 DIMMH2

P2 DIMMH3

CPU2

CPU1

P1 DIMMA2

P1 DIMMB3

P1 DIMMB2

P1 DIMMB1

P1 DIMMA1

P1 DIMMA3

FAN2

FAN5

PHY

P2 DIMMG1

JPI2C1

JPW3

JPW2

JPW1

FAN1

Ground

FP PWRLED

HDD LED

NIC1 Link LED

NIC2 Link LED

Blue+ (OH/Fan Fail/ PWR FaiL/UID LED)

Power Fail LED

Ground

JF1 Header Pins

1920

NMI

3.3 V

ID_UID_SW/3/3V Stby

NIC1 Activity LED

NIC2 Activity LED

Red+ (Blue LED Cathode)

3.3V

Reset

PWR

2-23

Reset Button

Power Button

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

Front Control Panel Pin Denitions

NMI Button

The non-maskable interrupt button

header is located on pins 19 and 20

of JF1. Refer to the table on the right

for pin denitions.

Power LED

The Power LED connection is located

on pins 15 and 16 of JF1. Refer to the

table on the right for pin denitions.

NMI Button

Pin Denitions (JF1)

Pin# Denition

19 Control

20 Ground

Power LED

Pin Denitions (JF1)

Pin# Denition

15 3.3V

16 PWR LED

A. NMI

B. PWR LED

1920

NMI

NIC1 Activity LED

Reset

PWR

3.3 V

ID_UID_SW/3/3V Stby

NIC2 Activity LED

Red+ (Blue LED Cathode)

3.3V

Reset Button

Power Button

USB 2/3

USB 0/1

LAN1/3

LAN2/4

VGA

LE2

SW1

UID

PCH

SAS0~3

FANB

JPB1

CPU2 Slot4 PCI-E 3.0 x16

CPU1 Slot3 PCI-E 3.0 x16

BIOS BOX

XDP-CPU

JOH1

FANA

JD1

JP7

JP6

SP1

JF2

LAN

CTRL

CPU2 Slot5 PCI-E 3.0 x16

JBAT1

FAN4

JPL1

CPU2 Slot6 PCI-E 3.0 x8

P2 DIMME1

P2 DIMME3

P2 DIMME2

Alaways populate DIMMx1 first

X9DR3-LN4F+/X9DRi-LN4F+

Rev. 1.10

Alaways populate DIMMx1 first

P1 DIMMD2

P1 DIMMC1

P1 DIMMC2

P1 DIMMC3

P1 DIMMD1

P1 DIMMD3

FAN3

LE1

JF1

BMC

CTRL

LEM1

JPG1

JBMC1

CPU1 Slot2 PCI-E 3.0 x4 (in X8 slot)

CPU1 Slot1 PCI-E 3.0 x16

JSTBY1

J21

COM2

JI2C2 JI2C1

JTPM1

SAS

CTRL

USB9

JBT1

JL1

USB6/7

USB4/5

XDP-PCH

IPMB

JWD1

JPME2

I-SATA4

I-SATA5

JPME1

JRK1

I-SATA3

I-SATA2

BIOS

JWP1

I-SATA1

I-SATA0

JSD1

J18

SAS4~7

J17

COM1

FAN6

FAN5

IPMI_LAN

P2 DIMMF3

P2 DIMMF2

P2 DIMMF1

CPU2

PHY

P2 DIMMG3

P2 DIMMG2

P2 DIMMH1

P2 DIMMH2

P2 DIMMH3

P2 DIMMG1

Ground

FP PWRLED

HDD LED

NIC1 Link LED

JPI2C1

NIC2 Link LED

CPU1

P1 DIMMB3

P1 DIMMB2

P1 DIMMB1

FAN2

JPW3

Blue+ (OH/Fan Fail/ PWR FaiL/UID LED)

Power Fail LED

JPW2

JPW1

P1 DIMMA2

P1 DIMMA1

P1 DIMMA3

FAN1

Ground

2-24

Chapter 2: Installation

HDD LED

The HDD LED connection is located

on pins 13 and 14 of JF1. Attach a

cable here to indicate HDD activ-

ity. See the table on the right for pin

denitions.

NIC1/NIC2 LED Indicators

The NIC (Network Interface Control-

ler) LED connection for GLAN port 1 is

located on pins 11 and 12 of JF1, and

the LED connection for GLAN Port 2 is

on pins 9 and 10. Attach the NIC LED

cables here to display network activity.

Refer to the table on the right for pin

denitions.

HDD LED

Pin Denitions (JF1)

Pin# Denition

13 3.3V Standby

14 HD Active

GLAN1/2 LED

Pin Denitions (JF1)

Pin# Denition

9 NIC 2 Activity LED

10 NIC 2 Link LED

11 NIC 1 Activity LED

12 NIC 1 Link LED

A. HDD LED

B. NIC1 Link LED

C. NIC1 Activity LED

D. NIC2 Link LED

E. NIC2 Activity LED

USB 2/3

USB 0/1

LAN1/3

LAN2/4

VGA

LE2

SW1

UID

PCH

SAS0~3

FANB

JPB1

CPU2 Slot4 PCI-E 3.0 x16

CPU1 Slot3 PCI-E 3.0 x16

BIOS BOX

XDP-CPU

JOH1

FANA

JD1

JP7

JP6

SP1

LAN

CTRL

JBAT1

JF2

FAN4

CPU2 Slot5 PCI-E 3.0 x16

JPL1

CPU2 Slot6 PCI-E 3.0 x8

P2 DIMME1

P2 DIMME2

Alaways populate DIMMx1 first

X9DR3-LN4F+/X9DRi-LN4F+

Rev. 1.10

Alaways populate DIMMx1 first

P1 DIMMD2

P1 DIMMC1

P1 DIMMC2

P1 DIMMC3

P1 DIMMD1

P1 DIMMD3

FAN3

LE1

JF1

BMC

CTRL

LEM1

JPG1

JBMC1

CPU1 Slot2 PCI-E 3.0 x4 (in X8 slot)

CPU1 Slot1 PCI-E 3.0 x16

JSTBY1

J21

COM2

JI2C2 JI2C1

JTPM1

SAS

CTRL

USB9

JBT1

JL1

USB6/7

USB4/5

XDP-PCH

IPMB

JWD1

JPME2

I-SATA4

I-SATA5

JPME1

JRK1

I-SATA3

I-SATA2

BIOS

JWP1

I-SATA1

I-SATA0

JSD1

J18

SAS4~7

J17

COM1

FAN6

FAN5

IPMI_LAN

P2 DIMMF3

P2 DIMMF2

P2 DIMME3

P2 DIMMF1

CPU2

PHY

P2 DIMMG3

P2 DIMMG2

P2 DIMMH1

P2 DIMMH2

P2 DIMMH3

P2 DIMMG1

JPI2C1

CPU1

P1 DIMMB3

P1 DIMMB2

JPW3

JPW2

JPW1

P1 DIMMA2

P1 DIMMB1

P1 DIMMA1

P1 DIMMA3

FAN2

FAN1

Ground

FP PWRLED

HDD LED

NIC1 Link LED

NIC2 Link LED

Blue+ (OH/Fan Fail/ PWR FaiL/UID LED)

Power Fail LED

Ground

1920

Reset

PWR

NMI

3.3 V

ID_UID_SW/3/3V Stby

NIC1 Activity LED

NIC2 Activity LED

Red+ (Blue LED Cathode)

3.3V

Reset Button

Power Button

2-25

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

Overheat (OH)/Fan Fail/PWR Fail/ UID LED

Connect an LED cable to pins 7 and

8 of Front Control Panel to use the

Overheat /Fan Fail/Power Fail and

UID LED connections. The Red LED

on pin 7 provides warnings of over-

heat, fan failure or power failure. The

Blue LED on pin 8 works as the front

panel UID LED indicator. The Red

LED takes precedence over the Blue

LED by default. Refer to the table on

the right for pin denitions.

Power Fail LED

The Power Fail LED connection is

located on pins 5 and 6 of JF1. Re-

fer to the table on the right for pin

denitions.

OH/Fan Fail/ PWR Fail/Blue_UID

LED Pin Denitions (JF1)

Pin# Denition

7 Red_LED-Cathode/OH/Fan Fail/

Power Fail5.5V.SB

8 Blue_UID LED

OH/Fan Fail/PWR Fail

LED Status (Red LED)

State Denition

Off Normal

On Overheat

Flashing Fan Fail

PWR Fail LED

Pin Denitions (JF1)

Pin# Denition

5 3.3V

6 PWR Supply Fail

A. OH/Fail/PWR Fail LED (Red)/UID (Blue)

B. Blue LED Cathode

C. PWR Supply Fail

USB 2/3

USB 0/1

LAN1/3

LAN2/4

VGA

LE2

SW1

UID

PCH

SAS0~3

FANB

JPB1

CPU2 Slot4 PCI-E 3.0 x16

CPU1 Slot3 PCI-E 3.0 x16

BIOS BOX

XDP-CPU

FANA

JD1

CTRL

JP7

JP6

SP1

JOH1

JF2

LAN

CPU2 Slot5 PCI-E 3.0 x16

JBAT1

FAN4

JPL1

CPU2 Slot6 PCI-E 3.0 x8

P2 DIMME1

P2 DIMME2

Alaways populate DIMMx1 first

X9DR3-LN4F+/X9DRi-LN4F+

Rev. 1.10

Alaways populate DIMMx1 first

P1 DIMMD2

P1 DIMMC1

P1 DIMMC2

P1 DIMMC3

P1 DIMMD1

P1 DIMMD3

FAN3

LE1

JF1

BMC

CTRL

LEM1

JPG1

JBMC1

CPU1 Slot2 PCI-E 3.0 x4 (in X8 slot)

CPU1 Slot1 PCI-E 3.0 x16

JSTBY1

J21

COM2

JI2C2 JI2C1

JTPM1

SAS

CTRL

USB9

JBT1

JL1

USB6/7

USB4/5

XDP-PCH

IPMB

JWD1

JPME2

I-SATA4

I-SATA5

JPME1

JRK1

I-SATA3

I-SATA2

BIOS

JWP1

I-SATA1

I-SATA0

JSD1

J18

SAS4~7

J17

COM1

FAN6

FAN5

IPMI_LAN

P2 DIMMF3

P2 DIMMF2

P2 DIMME3

P2 DIMMF1

CPU2

PHY

P2 DIMMG3

P2 DIMMG2

P2 DIMMH1

P2 DIMMH2

P2 DIMMH3

P2 DIMMG1

Ground

FP PWRLED

HDD LED

NIC1 Link LED

JPI2C1

CPU1

P1 DIMMB3

P1 DIMMB2

JPW3

JPW2

JPW1

P1 DIMMA2

P1 DIMMB1

P1 DIMMA1

P1 DIMMA3

FAN2

FAN1

NIC2 Link LED

Blue+ (OH/Fan Fail/

PWR FaiL/UID LED)

Power Fail LED

Ground

1920

NIC1 Activity LED

Reset

PWR

NMI

3.3 V

ID_UID_SW/3/3V Stby

NIC2 Activity LED

Red+ (Blue LED Cathode)

3.3V

Reset Button

Power Button

2-26

Chapter 2: Installation

Reset Button

The Reset Button connection is located

on pins 3 and 4 of JF1. Attach it to a

hardware reset switch on the computer

case. Refer to the table on the right for

pin denitions.

Power Button

The Power Button connection is located

on pins 1 and 2 of JF1. Momentarily

contacting both pins will power on/off

the system. This button can also be con-

gured to function as a suspend button

(with a setting in the BIOS - See Chapter

4). To turn off the power when the system

is in suspend mode, press the button for

4 seconds or longer. Refer to the table on

the right for pin denitions.

Reset Button

Pin Denitions (JF1)

Pin# Denition

3 Reset

4 Ground

Power Button

Pin Denitions (JF1)

Pin# Denition

1 Signal

2 Ground

A. Reset Button

B. PWR Button

1920

NMI

NIC1 Activity LED

NIC2 Activity LED

Reset

PWR

3.3 V

ID_UID_SW/3/3V Stby

Red+ (Blue LED Cathode)

3.3V

Reset Button

Power Button

USB 2/3

USB 0/1

LAN1/3

LAN2/4

VGA

LE2

SW1

UID

JWP1

SAS0~3

JPB1

CPU1 Slot3 PCI-E 3.0 x16

BIOS BOX

XDP-CPU

PCH

FANB

FANA

LAN

CTRL

CPU2 Slot4 PCI-E 3.0 x16

JP7

JP6

JBAT1

SP1

JOH1

JF2

FAN4

JD1

JPL1

CPU2 Slot6 PCI-E 3.0 x8

CPU2 Slot5 PCI-E 3.0 x16

P2 DIMME1

P2 DIMME2

Alaways populate DIMMx1 first

X9DR3-LN4F+/X9DRi-LN4F+

Rev. 1.10

Alaways populate DIMMx1 first

P1 DIMMD2

P1 DIMMC1

P1 DIMMC2

P1 DIMMC3

P1 DIMMD1

P1 DIMMD3

FAN3

LE1

JF1

BMC

CTRL

LEM1

JPG1

JBMC1

CPU1 Slot2 PCI-E 3.0 x4 (in X8 slot)

CPU1 Slot1 PCI-E 3.0 x16

JSTBY1

J21

COM2

JI2C2 JI2C1

JTPM1

SAS

CTRL

USB9

JBT1

JL1

USB6/7

USB4/5

XDP-PCH

IPMB

JWD1

JPME2

I-SATA4

I-SATA5

JPME1

JRK1

I-SATA3

I-SATA2

BIOS

I-SATA1

I-SATA0

JSD1

J18

SAS4~7

J17

COM1

FAN6

FAN5

IPMI_LAN

P2 DIMMF3

P2 DIMMF2

P2 DIMME3

P2 DIMMF1

CPU2

CPU1

P1 DIMMB3

P1 DIMMB2

P1 DIMMB1

FAN2

PHY

P2 DIMMG3

P2 DIMMG2

P2 DIMMH1

P2 DIMMH2

P2 DIMMH3

P2 DIMMG1

JPI2C1

Blue+ (OH/Fan Fail/

JPW3

PWR FaiL/UID LED)

JPW2

JPW1

P1 DIMMA2

P1 DIMMA1

P1 DIMMA3

FAN1

Ground

FP PWRLED

HDD LED

NIC1 Link LED

NIC2 Link LED

Power Fail LED

Ground

2-27

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

2-7 Connecting Cables

Power Connectors

A 24-pin main power supply connector(JPW1)

and two 8-pin CPU PWR connectors

(JPW2/3) are located on the motherboard.

These power connectors meet the SSI EPS

12V specication. These power connectors

must also be connected to your power

supply. See the table on the right for pin

denitions.

Warning: To provide adequate power supply to

the motherboard, be sure to connect the 24-pin

ATX PWR (JPW1) and two 8-pin PWR connec-

tors (JPW2, JPW3) to the power supply. Failure

to do so will void the manufacturer warranty on

your power supply and motherboard.

ATX Power 24-pin Connector

Pin Denitions

Pin# Denition Pin # Denition

13 +3.3V 1 +3.3V

14 -12V 2 +3.3V

15 COM 3 COM

16 PS_ON 4 +5V

17 COM 5 COM

18 COM 6 +5V

19 COM 7 COM

20 Res (NC) 8 PWR_OK

21 +5V 9 5VSB

22 +5V 10 +12V

23 +5V 11 +12V

24 COM 12 +3.3V

12V 8-pin PWR Con-

nector

Pin Denitions

Pins Denition

1 through 4 Ground

5 through 8 +12V

(Required)

IPMB

JPME2

JPG1

J21

JTPM1

JL1

USB6/7

J17

JBMC1

JSTBY1

COM2

JI2C2 JI2C1

USB9

USB4/5

JWD1

I-SATA4

I-SATA5

JPME1

I-SATA3

I-SATA2

I-SATA1

I-SATA0

JSD1

J18

CTRL

LEM1

CPU1 Slot1 PCI-E 3.0 x16

SAS

CTRL

JBT1

XDP-PCH

JRK1

BIOS

SAS4~7

BMC

JPB1

CPU2 Slot4 PCI-E 3.0 x16

CPU1 Slot2 PCI-E 3.0 x4 (in X8 slot)

CPU1 Slot3 PCI-E 3.0 x16

JP7

JP6

BIOS BOX

XDP-CPU

PCH

JWP1

SP1

JOH1

JF2

SAS0~3

FANB

FANA

JD1

LAN

CTRL

CPU2 Slot5 PCI-E 3.0 x16

JBAT1

FAN4

LE2

JPL1

CPU2 Slot6 PCI-E 3.0 x8

SW1

UID

VGA

Alaways populate DIMMx1 first

P1 DIMMC1

P1 DIMMC2

FAN3

USB 2/3

LAN1/3

LAN2/4

P2 DIMME1

P2 DIMMF3

P2 DIMMF2

P2 DIMME3

P2 DIMME2

P2 DIMMF1

Alaways populate DIMMx1 first

X9DR3-LN4F+/X9DRi-LN4F+

Rev. 1.10

CPU1

P1 DIMMD2

P1 DIMMC3

P1 DIMMD1

P1 DIMMD3

LE1

JF1

USB 0/1

IPMI_LAN

CPU2

P1 DIMMB3

2-28

COM1

FAN6

P2 DIMMG3

P2 DIMMG2

P2 DIMMH1

P2 DIMMH2

P2 DIMMH3

P2 DIMMG1

A. JPW1: 24-pin ATX

FAN5

PHY

PWR (Req'd)

B. JPW2: 8-pin Processor

PWR (Req'd)

C. JPW3: 8-pin Processor

PWR (Req'd)

JPI2C1

JPW3

JPW2

JPW1

P1 DIMMA2

P1 DIMMB2

P1 DIMMB1

P1 DIMMA1

P1 DIMMA3

FAN2

FAN1

Chapter 2: Installation

FAN5

Fan Headers

This motherboard has eight system/CPU

fan headers (Fan 1~Fan 6, Fan A, Fan

B) on the motherboard. All these 4-pin

fans headers are backward compatible

with the traditional 3-pin fans. However,

fan speed control is available for 4-pin

fans only. The fan speeds are controlled

by Firmware Thermal Management via

IPMI 2.0. See the table on the right for

pin denitions.

Chassis Intrusion

A Chassis Intrusion header is located

at JL1 on the motherboard. Attach an

appropriate cable from the chassis to

inform you of a chassis intrusion when

the chassis is opened.

LAN2/4

VGA

LE2

SW1

UID

LAN

CTRL

CPU2 Slot4 PCI-E 3.0 x16

CPU2 Slot5 PCI-E 3.0 x16

JP7

JP6

JBAT1

SP1

JOH1

JF2

FAN4

JD1

JPL1

CPU2 Slot6 PCI-E 3.0 x8

P2 DIMME1

P2 DIMME2

Alaways populate DIMMx1 first

X9DR3-LN4F+/X9DRi-LN4F+

Rev. 1.10

Alaways populate DIMMx1 first

P1 DIMMD2

P1 DIMMC1

P1 DIMMC2

P1 DIMMC3

P1 DIMMD1

P1 DIMMD3

FAN3

LE1

JF1

IPMB

JPME2

JPG1

J21

JTPM1

JL1

USB6/7

USB4/5

I-SATA4

JPME1

I-SATA2

I-SATA0

J17

LEM1

JBMC1

JSTBY1

COM2

JI2C2 JI2C1

USB9

JWD1

I-SATA5

I-SATA3

I-SATA1

JSD1

J18

BMC

CTRL

CPU1 Slot2 PCI-E 3.0 x4 (in X8 slot)

CPU1 Slot1 PCI-E 3.0 x16

SAS

CTRL

JBT1

XDP-PCH

JRK1

BIOS

JWP1

SAS4~7

CPU1 Slot3 PCI-E 3.0 x16

PCH

SAS0~3

FANB

JPB1

BIOS BOX

XDP-CPU

FANA

Fan Header

Pin Denitions

Pin# Denition

1 Ground

2 +12V

3 Tachometer

4 Firmware Thermal

Management

Chassis Intrusion

Pin Denitions

Pin# Denition

1 Intrusion Input

2 Ground

USB 2/3

USB 0/1

LAN1/3

P2 DIMMF3

P2 DIMMF2

P2 DIMME3

P2 DIMMF1

CPU2

IPMI_LAN

COM1

FAN6

P2 DIMMG3

P2 DIMMG2

P2 DIMMH1

P2 DIMMH2

P2 DIMMH3

P2 DIMMG1

PHY

A. Fan 1

B. Fan 2

C. Fan 3

D. Fan 4

E. Fan 5

F. Fan 6

G. Fan A

H. Fan B

JPI2C1

I. Chassis Intrusion

CPU1

P1 DIMMA2

P1 DIMMB3

P1 DIMMB2

P1 DIMMB1

P1 DIMMA1

P1 DIMMA3

FAN2

JPW3

JPW2

JPW1

FAN1

2-29

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

JPME2

IPMB

Internal Speaker

The Internal Speaker, located at SP1,

can be used to provide audible indica-

tions for various beep codes. See the

table on the right for pin denitions.

Refer to the layout below for the loca-

tions of the Internal Buzzer (SP1).

Power LED/Speaker

On JD1 header, pins 1-3 are used for

power LED indication, and pins 4-7

are for the speaker. See the tables

on the right for pin denitions. Please

note that the speaker connector

pins (4-7) are used with an external

speaker. If you wish to use the on-

board speaker, you should close pins

6-7 with a jumper.

Internal Buzzer (SP1)

Pin Denition

Pin# Denitions

Pin 1 Pos. (+) Beep In

Pin 2 Neg. (-) Alarm

PWR LED Connector

Pin Denitions

Speaker

Pin Setting Denition

Pin 1 Anode (+)

Pin2 Cathode (-)

Pin3 NA

Speaker Connector

Pin Settings

Pin Setting Denition

Pins 4-7 External Speaker

Pins 6-7 Internal Speaker

VGA

LE2

SW1

UID

BMC

CTRL

JPB1

LEM1

JPG1

JBMC1

CPU1 Slot2 PCI-E 3.0 x4 (in X8 slot)

CPU1 Slot3 PCI-E 3.0 x16

CPU1 Slot1 PCI-E 3.0 x16

JSTBY1

J21

COM2

JI2C2 JI2C1

JTPM1

SAS

CTRL

USB9

JL1

USB6/7

USB4/5

JWD1

I-SATA4

I-SATA5

JPME1

I-SATA3

I-SATA2

I-SATA1

I-SATA0

JSD1

J18

J17

BIOS BOX

JBT1

XDP-CPU

XDP-PCH

PCH

JRK1

BIOS

JWP1

SAS4~7

SAS0~3

FANB

FANA

LAN

CTRL

CPU2 Slot4 PCI-E 3.0 x16

CPU2 Slot5 PCI-E 3.0 x16

JP7

JP6

JBAT1

SP1

JOH1

JF2

FAN4

JD1

JPL1

CPU2 Slot6 PCI-E 3.0 x8

P2 DIMME1

P2 DIMMF3

P2 DIMMF2

P2 DIMME3

P2 DIMME2

P2 DIMMF1

Alaways populate DIMMx1 first

X9DR3-LN4F+/X9DRi-LN4F+

Rev. 1.10

Alaways populate DIMMx1 first

P1 DIMMD2

P1 DIMMC1

P1 DIMMC2

P1 DIMMC3

P1 DIMMD1

P1 DIMMD3

FAN3

LE1

JF1

CPU1

COM1

FAN6

IPMI_LAN

P2 DIMMG3

P2 DIMMG2

P2 DIMMH1

P2 DIMMH2

P2 DIMMH3

P2 DIMMG1

CPU2

P1 DIMMA2

P1 DIMMB3

P1 DIMMB2

P1 DIMMB1

P1 DIMMA1

P1 DIMMA3

FAN2

USB 2/3

USB 0/1

LAN1/3

LAN2/4

A. Internal Speaker (Buzzer)

FAN5

B. PWR LED/Speaker

PHY

JPI2C1

JPW3

JPW2

JPW1

FAN1

2-30

Chapter 2: Installation

TPM Header/Port 80

A Trusted Platform Module/Port 80

header is located at JTPM1 to provide

TPM support and Port 80 connection.

Use this header to enhance system

performance and data security. See

the table on the right for pin deni-

tions.

TPM/Port 80 Header

Pin Denitions

Pin # Denition Pin # Denition

1 LCLK 2 GND

3 LFRAME# 4 <(KEY)>

5 LRESET# 6 +5V (X)

7 LAD 3 8 LAD 2

9 +3.3V 10 LAD1

11 LAD0 12 GND

13 SMB_CLK4 14 SMB_DAT4

15 +3V_DUAL 16 SERIRQ

17 GND 18 CLKRUN# (X)

19 LPCPD# 20 LDRQ# (X)

IPMB

JPME2

JPG1

J21

JTPM1

JL1

J17

JBMC1

JSTBY1

COM2

JI2C2 JI2C1

USB9

USB6/7

USB4/5

JWD1

I-SATA4

I-SATA5

JPME1

I-SATA3

I-SATA2

I-SATA1

I-SATA0

JSD1

J18

CTRL

LEM1

CPU1 Slot1 PCI-E 3.0 x16

SAS

CTRL

JBT1

XDP-PCH

JRK1

BIOS

SAS4~7

BMC

JPB1

CPU2 Slot4 PCI-E 3.0 x16

CPU1 Slot2 PCI-E 3.0 x4 (in X8 slot)

CPU1 Slot3 PCI-E 3.0 x16

JP7

JP6

BIOS BOX

XDP-CPU

PCH

JWP1

SP1

JOH1

SAS0~3

FANB

FANA

JD1

LAN

CTRL

CPU2 Slot5 PCI-E 3.0 x16

JBAT1

JF2

FAN4

LE2

SW1

JPL1

CPU2 Slot6 PCI-E 3.0 x8

UID

VGA

Alaways populate DIMMx1 first

P1 DIMMC1

P1 DIMMC2

P1 DIMMC3

FAN3

JF1

USB 2/3

LAN1/3

LAN2/4

P2 DIMME1

P2 DIMMF3

P2 DIMMF2

P2 DIMME3

P2 DIMME2

P2 DIMMF1

CPU2

Alaways populate DIMMx1 first

X9DR3-LN4F+/X9DRi-LN4F+

Rev. 1.10

CPU1

P1 DIMMD2

P1 DIMMD1

P1 DIMMD3

LE1

2-31

USB 0/1

IPMI_LAN

P1 DIMMB3

COM1

FAN6

P2 DIMMG3

P2 DIMMG2

P2 DIMMH1

P2 DIMMH2

P2 DIMMH3

P2 DIMMG1

P1 DIMMA2

P1 DIMMB2

P1 DIMMB1

P1 DIMMA1

P1 DIMMA3

FAN2

A. TPM/Port 80 Header

FAN5

PHY

JPI2C1

JPW3

JPW2

JPW1

FAN1

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

Power SMB (I2C) Connector

Power System Management Bus (I2C)

Connector (JPI2C1) monitors power

supply, fan and system temperatures.

See the table on the right for pin

denitions.

Overheat/Fan Fail LED

The JOH1 header is used to connect

an LED indicator to provide warnings

of chassis overheating and fan failure.

This LED will blink when a fan failure

occurs. Refer to the table on right for

pin denitions.

PWR SMB

Pin Denitions

Pin# Denition

1 Clock

2 Data

3 PWR Fail

4 Ground

5 +3.3V

OH/Fan Fail LED

Status

State Message

Solid Overheat

Blinking Fan Fail

JTPM1

IPMB

JPME2

JPG1

JBMC1

JSTBY1

J21

COM2

JI2C2 JI2C1

JL1

USB6/7

USB4/5

JWD1

I-SATA4

JPME1

I-SATA2

I-SATA0

J17

LEM1

CPU1 Slot1 PCI-E 3.0 x16

SAS

CTRL

USB9

XDP-PCH

I-SATA5

JRK1

I-SATA3

BIOS

I-SATA1

JSD1

J18

SAS4~7

BMC

CTRL

JPB1

CPU1 Slot2 PCI-E 3.0 x4 (in X8 slot)

CPU1 Slot3 PCI-E 3.0 x16

BIOS BOX

JBT1

XDP-CPU

PCH

JWP1

SAS0~3

FANB

FANA

LAN

CTRL

CPU2 Slot4 PCI-E 3.0 x16

CPU2 Slot5 PCI-E 3.0 x16

JP7

JP6

JBAT1

SP1

JOH1

JF2

FAN4

JD1

LE2

JPL1

CPU2 Slot6 PCI-E 3.0 x8

SW1

UID

VGA

Alaways populate DIMMx1 first

P1 DIMMC1

P1 DIMMC2

P1 DIMMC3

FAN3

JF1

USB 2/3

LAN1/3

LAN2/4

P2 DIMME1

P2 DIMMF3

P2 DIMMF2

P2 DIMME3

P2 DIMME2

P2 DIMMF1

CPU2

Alaways populate DIMMx1 first

X9DR3-LN4F+/X9DRi-LN4F+

Rev. 1.10

CPU1

P1 DIMMD2

P1 DIMMD1

P1 DIMMD3

LE1

2-32

IPMI_LAN

P1 DIMMB3

A. JPI

USB 0/1

COM1

FAN6

P2 DIMMG3

P2 DIMMG2

P2 DIMMH1

P2 DIMMH2

P2 DIMMH3

P2 DIMMG1

P1 DIMMA2

P1 DIMMB2

P1 DIMMB1

P1 DIMMA1

P1 DIMMA3

FAN2

FAN5

PHY

JPI2C1

JPW3

JPW2

JPW1

FAN1

B. OH LED

Chapter 2: Installation

T-SGPIO 1/2 Headers

Two SGPIO (Serial-Link General

Purpose Input/Output) headers are lo-

cated at J17/J18 on the motherboard.

These headers support Serial_Link

interface for onboard SATA connec-

tions. See the table on the right for

pin denitions.

DOM Power Connector

A power connector for SATA DOM

(Disk_On_Module) devices is located

at JSD1. Connect an appropriate

cable here to provide power support

for your DOM devices.

T-SGPIO

Pin Denitions

Pin# Denition Pin Denition

1 NC 2 NC

3 Ground 4 Data

5 Load 6 Ground

7 Clock 8 NC

Note: NC= No Connection

DOM PWR

Pin Denitions

Pin# Denition

1 +5V

2 Ground

3 Ground

IPMB

JPME2

JPG1

J21

JTPM1

J17

JBMC1

JSTBY1

COM2

JI2C2 JI2C1

USB9

JL1

USB6/7

USB4/5

JWD1

I-SATA4

JPME1

I-SATA2

I-SATA0

J18

LEM1

CPU1 Slot1 PCI-E 3.0 x16

SAS

CTRL

XDP-PCH

I-SATA5

JRK1

I-SATA3

BIOS

I-SATA1

JSD1

SAS4~7

JBT1

BMC

CTRL

JPB1

CPU2 Slot4 PCI-E 3.0 x16

CPU1 Slot2 PCI-E 3.0 x4 (in X8 slot)

CPU1 Slot3 PCI-E 3.0 x16

BIOS BOX

XDP-CPU

PCH

JWP1

SAS0~3

FANB

FANA

CTRL

JP7

JP6

SP1

JOH1

JF2

JD1

LAN

CPU2 Slot5 PCI-E 3.0 x16

JBAT1

FAN4

LE2

SW1

JPL1

CPU2 Slot6 PCI-E 3.0 x8

VGA

UID

X9DR3-LN4F+/X9DRi-LN4F+

Rev. 1.10

Alaways populate DIMMx1 first

P1 DIMMC1

P1 DIMMC2

P1 DIMMC3

P1 DIMMD1

FAN3

JF1

LAN2/4

P2 DIMME1

P2 DIMMF3

P2 DIMMF2

P2 DIMME3

P2 DIMME2

P2 DIMMF1

Alaways populate DIMMx1 first

P1 DIMMD2

P1 DIMMD3

LE1

LAN1/3

CPU1

USB 2/3

CPU2

2-33

USB 0/1

IPMI_LAN

P1 DIMMB3

COM1

FAN6

P2 DIMMG3

P2 DIMMG2

P2 DIMMH1

P2 DIMMH2

P2 DIMMH3

P2 DIMMG1

P1 DIMMA2

P1 DIMMB2

P1 DIMMB1

P1 DIMMA1

P1 DIMMA3

FAN2

FAN5

PHY

JPI2C1

JPW3

JPW2

JPW1

FAN1

A. T-SGPIO1

B. T-SGPIO2

C. DOM PWR

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

IPMB

A System Management Bus header for

IPMI 2.0 is located at IPMB. Connect the

appropriate cable here to use the IPMB

I2C connection on your system.

IPMB Header

Pin Denitions

Pin# Denition

1 Data

2 Ground

3 Clock

4 No Connection

IPMB

JPME2

JPG1

J21

JTPM1

JL1

J17

JBMC1

JSTBY1

COM2

JI2C2 JI2C1

USB9

USB6/7

USB4/5

JWD1

I-SATA4

I-SATA5

JPME1

I-SATA3

I-SATA2

I-SATA1

I-SATA0

JSD1

J18

CTRL

LEM1

CPU1 Slot1 PCI-E 3.0 x16

SAS

CTRL

JBT1

XDP-PCH

JRK1

BIOS

SAS4~7

BMC

JPB1

CPU2 Slot4 PCI-E 3.0 x16

CPU1 Slot2 PCI-E 3.0 x4 (in X8 slot)

CPU1 Slot3 PCI-E 3.0 x16

JP7

JP6

BIOS BOX

XDP-CPU

PCH

JWP1

SP1

JOH1

SAS0~3

FANB

FANA

JD1

LAN

CTRL

CPU2 Slot5 PCI-E 3.0 x16

JBAT1

JF2

FAN4

LE2

JPL1

CPU2 Slot6 PCI-E 3.0 x8

SW1

UID

VGA

Alaways populate DIMMx1 first

P1 DIMMC1

P1 DIMMC2

P1 DIMMC3

FAN3

JF1

USB 2/3

LAN1/3

LAN2/4

P2 DIMME1

P2 DIMMF3

P2 DIMMF2

P2 DIMME3

P2 DIMME2

P2 DIMMF1

CPU2

Alaways populate DIMMx1 first

X9DR3-LN4F+/X9DRi-LN4F+

Rev. 1.10

CPU1

P1 DIMMD2

P1 DIMMD1

P1 DIMMD3

LE1

2-34

USB 0/1

IPMI_LAN

P1 DIMMB3

COM1

FAN6

P2 DIMMG3

P2 DIMMG2

P2 DIMMH1

P2 DIMMH2

P2 DIMMH3

P2 DIMMG1

P1 DIMMA2

P1 DIMMB2

P1 DIMMB1

P1 DIMMA1

P1 DIMMA3

FAN2

FAN5

PHY

JPI2C1

JPW3

JPW2

JPW1

FAN1

A. IPMB

2-8 Jumper Settings

Connector

Pins

Jumper

Cap

Setting

JRK1

JF1

JPI2C1

JPW3

JPW2

JPW1

JSD1

SP1

J18

J17

JBAT1

JP6

JP7

JI2C2 JI2C1

JL1

JOH1

FANB

FANA

FAN4

FAN3

FAN2

FAN6

FAN1

SW1

J21

JBT1

LEM1

JWP1

JPG1

JWD1

JPL1

USB4/5

JTPM1

XDP-PCH

BIOS BOX

SAS0~3

SAS4~7

I-SATA0

I-SATA1

P2 DIMMF3

P2 DIMMF1

P2 DIMMF2

P2 DIMME3

P2 DIMME2

P2 DIMME1

P2 DIMMG1

P2 DIMMH1

P2 DIMMG3

P2 DIMMG2

P2 DIMMH2

P2 DIMMH3

COM1

USB6/7

UID

IPMI_LAN

Alaways populate DIMMx1 first

P1 DIMMA2

P1 DIMMA1

P1 DIMMB3

P1 DIMMB2

P1 DIMMB1

P1 DIMMA3

P1 DIMMC1

P1 DIMMC2

P1 DIMMC3

P1 DIMMD1

P1 DIMMD2

P1 DIMMD3

I-SATA5

I-SATA4

I-SATA3

I-SATA2

LAN2/4

VGA

XDP-CPU

COM2

BMC

CTRL

LAN1/3

USB 0/1

JPME2

PHY

FAN5

BIOS

LAN

CTRL

PCH

LE1

X9DR3-LN4F+/X9DRi-LN4F+

Alaways populate DIMMx1 first

USB9

SAS

CTRL

USB 2/3

JSTBY1

IPMB

JD1

JF2

LE2

JPB1

JBMC1

Rev. 1.10

JPME1

CPU1

CPU2

CPU1 Slot1 PCI-E 3.0 x16

CPU1 Slot2 PCI-E 3.0 x4 (in X8 slot)

CPU2 Slot6 PCI-E 3.0 x8

CPU2 Slot5 PCI-E 3.0 x16

CPU2 Slot4 PCI-E 3.0 x16

CPU1 Slot3 PCI-E 3.0 x16

Chapter 2: Installation

Explanation of Jumpers

To modify the operation of the mother-

board, jumpers can be used to choose

between optional settings. Jumpers cre-

ate shorts between two pins to change

the function of the connector. Pin 1

is identied with a square solder pad

on the printed circuit board. See the

motherboard layout pages for jumper

locations.

Note: On two-pin jumpers,

"Closed" means the jumper

is on and "Open" means the

jumper is off the pins.

GLAN Enable/Disable

JPL1 enables or disables the GLAN

ports on the motherboard. See the

table on the right for jumper settings.

The default setting is Enabled.

3 2 1

Pin 1-2 short

GLAN Enable

Jumper Settings

Jumper Setting Denition

1-2 Enabled (default)

2-3 Disabled

A. GLAN1 Enable

2-35

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

CMOS Clear

JBT1 is used to clear CMOS. Instead of pins, this "jumper" consists of contact pads

to prevent accidental clearing of CMOS. To clear CMOS, use a metal object such

as a small screwdriver to touch both pads at the same time to short the connection.

Always remove the AC power cord from the system before clearing CMOS.

Note 1: For an ATX power supply, you must completely shut down the

system, remove the AC power cord, and then short JBT1 to clear CMOS.

Note 2: Be sure to remove the onboard CMOS Battery before you short

JBT1 to clear CMOS.

Note 3: Clearing CMOS will also clear all passwords.

Watch Dog Enable/Disable

Watch Dog (JWD1) is a system monitor that

can reboot the system when a software ap-

plication hangs. Close pins 1-2 to reset the

system if an application hangs. Close pins

2-3 to generate a non-maskable interrupt

signal for the application that hangs. See the

table on the right for jumper settings. Watch

Watch Dog

Jumper Settings

Jumper Setting Denition

Pins 1-2 Reset (default)

Pins 2-3 NMI

Open Disabled

Dog must also be enabled in the BIOS.

IPMB

JPME2

JPG1

J21

JTPM1

J17

JBMC1

JSTBY1

COM2

JI2C2 JI2C1

USB9

JL1

USB6/7

USB4/5

JWD1

I-SATA4

JPME1

I-SATA2

I-SATA0

J18

LEM1

CPU1 Slot1 PCI-E 3.0 x16

SAS

CTRL

JBT1

XDP-PCH

I-SATA5

JRK1

I-SATA3

BIOS

I-SATA1

JSD1

SAS4~7

BMC

CTRL

JPB1

CPU1 Slot2 PCI-E 3.0 x4 (in X8 slot)

CPU1 Slot3 PCI-E 3.0 x16

BIOS BOX

XDP-CPU

PCH

JWP1

SAS0~3

FANB

FANA

LAN

CTRL

CPU2 Slot4 PCI-E 3.0 x16

CPU2 Slot5 PCI-E 3.0 x16

JP7

JP6

JBAT1

SP1

JOH1

JF2

FAN4

JD1

LE2

JPL1

CPU2 Slot6 PCI-E 3.0 x8

SW1

UID

VGA

Alaways populate DIMMx1 first

P1 DIMMC1

P1 DIMMC2

P1 DIMMC3

FAN3

USB 2/3

LAN1/3

LAN2/4

P2 DIMME1

P2 DIMMF3

P2 DIMMF2

P2 DIMME3

P2 DIMME2

P2 DIMMF1

CPU2

Alaways populate DIMMx1 first

X9DR3-LN4F+/X9DRi-LN4F+

Rev. 1.10

CPU1

P1 DIMMD2

P1 DIMMD1

P1 DIMMD3

LE1

JF1

2-36

USB 0/1

IPMI_LAN

P1 DIMMB3

COM1

FAN6

P2 DIMMG3

P2 DIMMG2

P2 DIMMH1

P2 DIMMH2

P2 DIMMH3

P2 DIMMG1

P1 DIMMA2

P1 DIMMB2

P1 DIMMB1

P1 DIMMA1

P1 DIMMA3

FAN2

A. Clear CMOS

B. Watch Dog Enable

FAN5

PHY

JPI2C1

JPW3

JPW2

JPW1

FAN1

Chapter 2: Installation

VGA Enable

Jumper JPG1 allows the user to en-

able the onboard VGA connectors. The

default setting is 1-2 to enable the con-

nection. See the table on the right for

jumper settings.

BMC Enable

Jumper JPB1 allows you to enable the

embedded Winbond WPCM450R BMC

(Baseboard Management) Controller to

provide IPMI 2.0/KVM support on the

motherboard. See the table on the right

for jumper settings.

VGA Enable

Jumper Settings

Jumper Setting Denition

1-2 Enabled (Default)

2-3 Disabled

BMC Enable

Jumper Settings

Jumper Setting Denition

Pins 1-2 BMC Enable

Pins 2-3 Disabled

IPMB

JPME2

JTPM1

JPG1

JBMC1

JSTBY1

J21

JI2C2

JI2C1

JL1

USB6/7

USB4/5

JWD1

I-SATA4

JPME1

I-SATA2

I-SATA0

J17

LEM1

COM2

CTRL

USB9

I-SATA5

I-SATA3

I-SATA1

JSD1

J18

BMC

CTRL

CPU1 Slot2 PCI-E 3.0 x4 (in X8 slot)

CPU1 Slot1 PCI-E 3.0 x16

SAS

JBT1

XDP-PCH

JRK1

BIOS

JWP1

SAS4~7

SAS0~3

JPB1

CPU1 Slot3 PCI-E 3.0 x16

BIOS BOX

XDP-CPU

PCH

FANB

FANA

LAN

CTRL

CPU2 Slot4 PCI-E 3.0 x16

CPU2 Slot5 PCI-E 3.0 x16

JP7

JP6

JBAT1

SP1

JOH1

JF2

FAN4

JD1

LE2

JPL1

CPU2 Slot6 PCI-E 3.0 x8

SW1

UID

VGA

Alaways populate DIMMx1 first

P1 DIMMC1

P1 DIMMC2

P1 DIMMC3

FAN3

JF1

USB 2/3

LAN1/3

LAN2/4

P2 DIMME1

P2 DIMMF3

P2 DIMMF2

P2 DIMME3

P2 DIMME2

P2 DIMMF1

CPU2

Alaways populate DIMMx1 first

X9DR3-LN4F+/X9DRi-LN4F+

Rev. 1.10

CPU1

P1 DIMMD2

P1 DIMMD1

P1 DIMMD3

LE1

2-37

IPMI_LAN

P1 DIMMB3

USB 0/1

COM1

FAN6

P2 DIMMG3

P2 DIMMG2

P2 DIMMH1

P2 DIMMH2

P2 DIMMH3

P2 DIMMG1

P1 DIMMA2

P1 DIMMB2

P1 DIMMB1

P1 DIMMA1

P1 DIMMA3

FAN2

FAN5

PHY

JPI2C1

JPW3

JPW2

JPW1

FAN1

A. VGA Enabled

B. BMC Enabled

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

Management Engine (ME) Recovery

Use jumper JPME1 to select ME Firm-

ware Recovery mode, which will limit

resource allocation for essential system

operation only in order to maintain nor-

mal power operation and management.

In the single operation mode, online

upgrade will be available via Recovery

mode. See the table on the right for

jumper settings.

Manufacture Mode Select

Close pins 2 and 3 of Jumper JPME2 to

bypass SPI ash security and force the

system to operate in the Manufacture

Mode, allowing the user to flash the

system rmware from a host server for

system setting modications. See the

table on the right for jumper settings.

ME Recovery

Jumper Settings

Jumper Setting Denition

1-2 Normal (Default)

2-3 ME Recovery

ME Mode Select

Jumper Settings

Jumper Setting Denition

1-2 Normal (Default)

2-3 Manufacture Mode

IPMB

JPME2

JPG1

JTPM1

J17

JBMC1

JSTBY1

J21

JI2C2

JI2C1

JL1

USB6/7

USB4/5

JWD1

I-SATA4

JPME1

I-SATA2

I-SATA0

LEM1

COM2

CTRL

USB9

I-SATA5

I-SATA3

I-SATA1

JSD1

J18

BMC

CTRL

CPU1 Slot2 PCI-E 3.0 x4 (in X8 slot)

CPU1 Slot1 PCI-E 3.0 x16

SAS

JBT1

XDP-PCH

JRK1

BIOS

JWP1

SAS4~7

SAS0~3

JPB1

CPU2 Slot4 PCI-E 3.0 x16

CPU1 Slot3 PCI-E 3.0 x16

BIOS BOX

XDP-CPU

PCH

FANB

FANA

CTRL

JP7

JP6

SP1

JOH1

JF2

JD1

LAN

CPU2 Slot5 PCI-E 3.0 x16

JBAT1

FAN4

LE2

JPL1

CPU2 Slot6 PCI-E 3.0 x8

SW1

UID

VGA

Alaways populate DIMMx1 first

P1 DIMMC1

P1 DIMMC2

P1 DIMMC3

FAN3

JF1

USB 2/3

LAN1/3

LAN2/4

P2 DIMME1

P2 DIMMF3

P2 DIMMF2

P2 DIMME3

P2 DIMME2

P2 DIMMF1

CPU2

Alaways populate DIMMx1 first

X9DR3-LN4F+/X9DRi-LN4F+

Rev. 1.10

CPU1

P1 DIMMD2

P1 DIMMD1

P1 DIMMD3

LE1

2-38

IPMI_LAN

P1 DIMMB3

USB 0/1

COM1

FAN6

P2 DIMMG3

P2 DIMMG2

P2 DIMMH1

P2 DIMMH2

P2 DIMMH3

P2 DIMMG1

P1 DIMMA2

P1 DIMMB2

P1 DIMMB1

P1 DIMMA1

P1 DIMMA3

FAN2

FAN5

PHY

JPI2C1

JPW3

JPW2

JPW1

FAN1

A. JPME1

B. JPME2

2-9 Onboard LED Indicators

LAN 1/LAN 2

JTPM1

GLAN LEDs

The Gigabit LAN ports are located on the

IO Backplane on the motherboard. Each

Ethernet LAN port has two LEDs. The Yel-

low LED indicates activity. The Link LED

may be green, amber or off to indicate the

speed of the connection. See the tables

on the right for more information.

IPMI Dedicated LAN LEDs

In addition to the Gigabit Ethernet ports,

an IPMI Dedicated LAN is also located

above the Backplane USB ports 0/1 on the

motherboard. The amber LED on the right

indicates activity, while the green LED on

the left indicates the speed of the connec-

tion. See the table on the right for more

information.

Chapter 2: Installation

Link LED

Rear View (when facing the rear side of the chassis)

GLAN Activity Indicator (Left)

LED Settings

Color Status Denition

Yellow Flashing Active

GLAN Link Indicator

LED Settings

LED Color Denition

Off No Connection or 10 Mbps

Green 100 Mbps

Amber 1 Gbps

IPMI LAN

Link LED Activity LED

IPMI LAN Link LED (Left) &

Activity LED (Right)

Color/State Denition

Link (Left) Green: Solid 100 Mbps

Activity (Right) Amber: Blinking Active

Activity LED

JPG1

JBMC1

JSTBY1

J21

COM2

JI2C2

JI2C1

USB9

JL1

USB6/7

USB4/5

JWD1

I-SATA4

JPME1

I-SATA2

I-SATA0

J18

J17

LEM1

CPU1 Slot1 PCI-E 3.0 x16

SAS

CTRL

XDP-PCH

I-SATA5

JRK1

I-SATA3

BIOS

I-SATA1

JSD1

SAS4~7

BMC

CTRL

JPB1

CPU1 Slot2 PCI-E 3.0 x4 (in X8 slot)

CPU1 Slot3 PCI-E 3.0 x16

BIOS BOX

JBT1

XDP-CPU

PCH

JWP1

SAS0~3

FANB

CPU2 Slot4 PCI-E 3.0 x16

JP7

JP6

SP1

JOH1

FANA

JD1

LAN

CTRL

CPU2 Slot5 PCI-E 3.0 x16

JBAT1

JF2

FAN4

LE2

JPL1

CPU2 Slot6 PCI-E 3.0 x8

SW1

UID

VGA

Alaways populate DIMMx1 first

P1 DIMMC1

FAN3

LAN1/3

LAN2/4

P2 DIMME1

P2 DIMMF3

P2 DIMMF2

P2 DIMME3

P2 DIMME2

P2 DIMMF1

Alaways populate DIMMx1 first

X9DR3-LN4F+/X9DRi-LN4F+

Rev. 1.10

CPU1

P1 DIMMD2

P1 DIMMC2

P1 DIMMC3

P1 DIMMD1

P1 DIMMD3

LE1

JF1

USB 2/3

USB 0/1

COM1

FAN6

IPMI_LAN

P2 DIMMG3

P2 DIMMH1

P2 DIMMH2

P2 DIMMH3

CPU2

P1 DIMMA2

P1 DIMMB3

P1 DIMMB2

P1 DIMMB1

P1 DIMMA1

P1 DIMMA3

FAN2

FAN5

PHY

P2 DIMMG2

P2 DIMMG1

JPI2C1

JPW3

JPW2

JPW1

FAN1

A. LAN1/2 LEDs

B. LAN3/4 LEDs

C. IPMI LAN LEDs

2-39

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

Onboard Power LED

An Onboard Power LED is located at LE1

on the motherboard. When this LED is on,

the system is on. Be sure to turn off the

system and unplug the power cord before

removing or installing components. See

the table on the right for more information.

Rear UID LED

The rear UID LED is located at LE2 on

the rear of the motherboard. This LED

is used in conjunction with the rear UID

switch to provide easy identication of a

system that might be in need of service.

Refer to UID Switch on page 2-17 for

more information.

LAN2/4

VGA

LE2

SW1

UID

JPG1

J21

JTPM1

JL1

USB6/7

USB4/5

J17

LEM1

JBMC1

JSTBY1

COM2

JI2C2

JI2C1

USB9

JWD1

I-SATA4

I-SATA5

JPME1

I-SATA3

I-SATA2

I-SATA1

I-SATA0

JSD1

J18

BMC

CTRL

CPU1 Slot2 PCI-E 3.0 x4 (in X8 slot)

CPU1 Slot1 PCI-E 3.0 x16

SAS

CTRL

JBT1

XDP-PCH

JRK1

BIOS

JWP1

SAS4~7

JPB1

CPU1 Slot3 PCI-E 3.0 x16

PCH

SAS0~3

FANB

BIOS BOX

XDP-CPU

FANA

LAN

CTRL

CPU2 Slot4 PCI-E 3.0 x16

CPU2 Slot5 PCI-E 3.0 x16

JP7

JP6

JBAT1

SP1

JOH1

JF2

FAN4

JD1

JPL1

CPU2 Slot6 PCI-E 3.0 x8

P2 DIMME1

P2 DIMME2

Alaways populate DIMMx1 first

X9DR3-LN4F+/X9DRi-LN4F+

Rev. 1.10

Alaways populate DIMMx1 first

P1 DIMMD2

P1 DIMMC1

P1 DIMMC2

P1 DIMMC3

P1 DIMMD1

P1 DIMMD3

FAN3

LE1

JF1

Onboard PWR LED Indicator (LE1)

LED Settings

LED Color Status

Off System Off (PWR cable

not connected)

Green System On

Green: Flashing Quickly

ACPI S1 State

UID LED

Status

Color/State Status

Blue Unit Identied

USB 2/3

USB 0/1

LAN1/3

P2 DIMMF3

P2 DIMMF2

P2 DIMME3

P2 DIMMF1

CPU1

CPU2

IPMI_LAN

P1 DIMMB3

COM1

FAN6

P2 DIMMG3

P2 DIMMG2

P2 DIMMH1

P2 DIMMH2

P2 DIMMH3

P2 DIMMG1

JPI2C1

JPW3

JPW2

P1 DIMMA2

P1 DIMMB2

P1 DIMMB1

P1 DIMMA1

P1 DIMMA3

FAN2

JPW1

FAN1

FAN5

PHY

A. PWR LED

B. Rear UID LED

2-40

Chapter 2: Installation

BMC Heartbeat LED

A BMC Hear tbeat LED is located at LEM1

on the motherboard. When LEM1 is blink-

ing, BMC functions normally. See the

table at right for more information.

LAN2/4

VGA

LE2

SW1

UID

LAN

CTRL

CPU2 Slot4 PCI-E 3.0 x16

CPU2 Slot5 PCI-E 3.0 x16

JP7

JP6

JBAT1

SP1

JOH1

JF2

FAN4

JD1

JPL1

CPU2 Slot6 PCI-E 3.0 x8

P2 DIMME1

Alaways populate DIMMx1 first

X9DR3-LN4F+/X9DRi-LN4F+

Rev. 1.10

Alaways populate DIMMx1 first

P1 DIMMD2

P1 DIMMC1

P1 DIMMC2

P1 DIMMC3

P1 DIMMD1

P1 DIMMD3

FAN3

LE1

JF1

IPMB

JPME2

JPG1

JBMC1

JSTBY1

J21

JI2C2

JI2C1

JTPM1

JL1

USB6/7

USB4/5

JWD1

I-SATA4

JPME1

I-SATA2

I-SATA0

J17

LEM1

COM2

CTRL

USB9

I-SATA5

I-SATA3

I-SATA1

JSD1

J18

BMC

CTRL

CPU1 Slot2 PCI-E 3.0 x4 (in X8 slot)

CPU1 Slot1 PCI-E 3.0 x16

SAS

JBT1

XDP-PCH

JRK1

BIOS

JWP1

SAS4~7

SAS0~3

JPB1

CPU1 Slot3 PCI-E 3.0 x16

BIOS BOX

XDP-CPU

PCH

FANB

FANA

BMC Heartbeat LED

Status

Color/State Denition

Green: Blinking

BMC: Normal

A. BMC Heartbeat LED

USB 2/3

USB 0/1

LAN1/3

P2 DIMMF3

P2 DIMMF2

P2 DIMME3

P2 DIMME2

P2 DIMMF1

CPU1

CPU2

IPMI_LAN

P1 DIMMB3

COM1

FAN6

P2 DIMMG3

P2 DIMMG2

P2 DIMMH1

P2 DIMMH2

P2 DIMMH3

P2 DIMMG1

P1 DIMMA2

P1 DIMMB2

P1 DIMMB1

P1 DIMMA1

P1 DIMMA3

FAN2

FAN5

PHY

JPI2C1

JPW3

JPW2

JPW1

FAN1

2-41

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

2-10 Serial ATA Connections

Serial ATA (SATA) Ports

There are six Serial ATA Ports (I-SATA0~I-SATA

5) located on the motherboard, including two

SATA3 ports (I-SATA0/1) and four SATA2 ports

(I-SATA2~5). These por ts provide serial-link signal

connections, which are faster than the connections

of Parallel ATA. See the table on the right for pin

denitions.

SCU Ports

Eight Storage Control Unit (SCU) SAS/SATA2 Ports

(SCU 0~3, 4~7) are located on the X9DR3-LN4F+,

and four SCU SATA2 ports (SCU 0~3) are on the

X9DRi-LN4F+ to provide serial link connections.

These por ts are supported by the Intel PCH chip.

See the table on the right for pin denitions.

Note: For more information on SATA HostRAID conguration, please refer

to the Intel SATA HostRAID User's Guide posted on our website @ http://

www.supermicro.com.

USB 2/3

LAN1/3

LAN2/4

VGA

LE2

SW1

UID

BMC

CTRL

CPU1 Slot2 PCI-E 3.0 x4 (in X8 slot)

CPU1 Slot1 PCI-E 3.0 x16

SAS

JBT1

XDP-PCH

JRK1

BIOS

JWP1

SAS4~7

SAS0~3

JPB1

CPU1 Slot3 PCI-E 3.0 x16

BIOS BOX

XDP-CPU

PCH

FANB

FANA

LEM1

JPG1

JBMC1

JSTBY1

J21

COM2

JI2C2 JI2C1

JTPM1

CTRL

USB9

JL1

USB6/7

USB4/5

IPMB

JWD1

JPME2

I-SATA4

I-SATA5

JPME1

I-SATA3

I-SATA2

I-SATA1

I-SATA0

JSD1

J18

J17

LAN

CTRL

CPU2 Slot4 PCI-E 3.0 x16

CPU2 Slot5 PCI-E 3.0 x16

JP7

JP6

JBAT1

SP1

JOH1

JF2

FAN4

JD1

JPL1

CPU2 Slot6 PCI-E 3.0 x8

P2 DIMME1

P2 DIMMF3

P2 DIMMF2

P2 DIMME3

P2 DIMME2

P2 DIMMF1

Alaways populate DIMMx1 first

X9DR3-LN4F+/X9DRi-LN4F+

Rev. 1.10

CPU1

Alaways populate DIMMx1 first

P1 DIMMD2

P1 DIMMC1

P1 DIMMC2

P1 DIMMC3

P1 DIMMD1

P1 DIMMD3

FAN3

LE1

JF1

CPU2

USB 0/1

IPMI_LAN

P1 DIMMB3

SATA/SCU

Pin Denitions

Pin# Denition

1 Ground

2 TX_P

3 TX_N

4 Ground

5 RX_N

6 RX_P

7 Ground

COM1

FAN6

P2 DIMMG3

P2 DIMMG2

P2 DIMMH1

P2 DIMMH2

P2 DIMMH3

P2 DIMMG1

FAN5

PHY

A. I-SATA0

B. I-SATA1

C. I-SATA2

D. I-SATA3

E. I-SATA4

F. I-SATA5

G. SCU 0~3:

X9DRi-LN4F+

H. SCU 4~7

(SCU 0~3, 4~7:

JPI2C1

X9DR3-LN4F+)

JPW3

JPW2

P1 DIMMA2

P1 DIMMB2

P1 DIMMB1

P1 DIMMA1

P1 DIMMA3

FAN2

JPW1

FAN1

2-42

Chapter 3: Troubleshooting

Chapter 3

Troubleshooting

3-1 Troubleshooting Procedures

Use the following procedures to troubleshoot your system. If you have followed all

of the procedures below and still need assistance, refer to the ‘Technical Support

Procedures’ and/or ‘Returning Merchandise for Service’ section(s) in this chapter.

Warning: Always disconnect the power cord before adding, changing or installing any

hardware components.

Before Power On

1. Make sure that there are no short circuits between the motherboard and

chassis.

2. Disconnect all ribbon/wire cables from the motherboard, including keyboard

and mouse cables.

3. Remove all add-on cards.

4. Install CPU 1 rst (-making sure it is fully seated), and connect the front panel

connectors to the motherboard.

No Power

1. Make sure that they are no short circuits between the motherboard and the

chassis.

2. Make sure that the ATX power connectors are properly connected.

3. Check that the 115V/230V switch on the power supply is properly set, if avail-

able.

4. Turn the power switch on and off to test the system, if applicable.

5. The battery on your motherboard may be old. Check to verify that it still sup-

plies ~3VDC. If it does not, replace it with a new one.

3-1

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

No Video

1. If the power is on, but you have no video, remove all add-on cards and

cables.

2. Use the speaker to determine if any beep codes exist. Refer to Appendix A

for details on beep codes.

System Boot Failure

If the system does not display POST or does not respond after the power is turned

on, check the following:

1. Check for any error beeps from the motherboard speaker.

•If there is no error beep, try to turn on the system without any DIMM module

installed. If there is still no error beep, try to turn on the system again with only

one processor installed in CPU Socket#1. If there is still no error beep, replace

the motherboard.

•If there are error beeps, clear the CMOS setting by unplugging the power cord

and contacting both pads on the CMOS Clear Jumper (JBT1). (Refer to Sec-

tion 2-8 in Chapter 2.)

2. Remove all components from the motherboard, especially the DIMM mod-

ules. Make sure that the system's power is on, and memory error beeps are

activated.

3. Turn on the system with only one DIMM module installed. If the system boots,

check for bad DIMM modules or slots by following the procedure of memory-

error troubleshooting in this chapter.

Losing the System’s Setup Conguration

1. Make sure that you are using a high quality power supply. A poor quality

power supply may cause the system to lose the CMOS setup information.

Refer to Section 1-6 for details on recommended power supplies.

2. The battery on your motherboard may be old. Check to verify that it still sup-

plies ~3VDC. If it does not, replace it with a new one.

3. If the steps indicated above do not x setup conguration problems, contact

your vendor for repairs.

3-2

Chapter 3: Troubleshooting

Memory Errors

When a No_Memory_Beep_Code is issued by the system, check the following:

1. Make sure that the memory modules are compatible with the system and that

the DIMM modules are properly and fully installed. (For memory compatibility,

refer to the Memory Compatibility Chart posted on our website at http://www.

supermicro.com.)

2. Check if different speeds of DIMMs have been installed. It is strongly recom-

mended that you use the memory modules of the same speed and same type

for all DIMMs in the system.

3. Make sure that you are using the correct type of DDR3 DIMM modules rec-

ommended by the manufacturer.

4. Check for bad DIMM modules or slots by swapping a single module among

all memory slots and check the results.

5. Make sure that all memory modules are fully seated in their slots. Follow the

instructions given in Section 2-4 in Chapter 2.

6. Please follow the instructions given in the DIMM Population Tables listed in

Section 2-4 to install your memory modules.

When the System Becomes Unstable

A. The system becomes unstable during or after OS system installation

When the system becomes unstable during or after OS system installation, check

the following:

1. CPU/BIOS support: Make sure that your CPU is supported, and you have the

latest BIOS installed in your system.

2. Memory support: Make sure that the memory modules are supported by test-

ing the modules using memtest86 or a similar utility.

Note: Refer to the product page on our website at http://www.supermicro.

com for memory and CPU support and updates.

3. HDD support: Make sure that all hard disk drives (HDDs) work properly. Re-

place the bad HDDs with good ones.

4. System cooling: Check system cooling to make sure that all cooling fans and

system fans work properly. Check Hardware Monitoring settings in the BIOS

3-3

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

to make sure that the CPU and System temperatures are within the normal

range. Also check the front panel Overheat LED, and make sure that the

Overheat LED is not on.

5. Adequate power supply: Make sure that the power supply provides adequate

power to the system. Make sure that all power connectors are connected.

Please refer to our website for more information on minimum power require-

ment.

6. Proper software support: Make sure that the correct disk drivers are used.

B. The system becomes unstable before or during OS installation

When the system becomes unstable before or during OS installation, check the

following:

1. Source of installation: Make sure that the devices used for installation are

working properly, including boot devices such as CD/DVD disc, CD/DVD-

ROM.

2. Cable connection: Check to make sure that all cables are connected and

working properly.

3. Using minimum conguration for troubleshooting: Remove all unnecessary

components (-starting with add-on cards rst), and use minimum congura-

tion (with a CPU and a memory module installed) to identify the problematic

areas. Refer to the steps listed in Section A above for proper troubleshooting

procedures.

4. Identifying bad components by isolating them: If necessary, remove a compo-

nent in question from the chassis, and test it in isolation to make sure that it

works properly. Replace a bad component with a good one.

5. Check and change one component at a time instead of changing several

items at the same time. This will help isolate and identify the problem.

6. To nd out if a component is good, swap the component with a new one to

see if the system will work properly. If so, then the old component is bad.

You can also install the component in question in another system. If the new

system works, the component is good and the old system has problems.

3-4

Chapter 3: Troubleshooting

3-2 Technical Support Procedures

Before contacting Technical Support, please take the following steps. Also, please

note that as a motherboard manufacturer, Supermicro also sells motherboards

through its channels, so it is best to rst check with your distributor or reseller for

troubleshooting services. They should know of any possible problem(s) with the

specic system conguration that was sold to you.

1. Please go through the ‘Troubleshooting Procedures’ and 'Frequently Asked

Question' (FAQ) sections in this chapter or see the FAQs on our website

(http://www.supermicro.com/) before contacting Technical Support.

2. BIOS upgrades can be downloaded from our website (http://www.supermicro.

com).

3. If you still cannot resolve the problem, include the following information when

contacting Supermicro for technical support:

•Motherboard model and PCB revision number

•BIOS release date/version (This can be seen on the initial display when your

system rst boots up.)

•System conguration

4. An example of a Technical Support form is on our website at (http://www.

supermicro.com).

•Distributors: For immediate assistance, please have your account number ready

when placing a call to our technical support department. We can be reached by

e-mail at support@supermicro.com.

3-5

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

3-3 Battery Removal and Installation

Battery Removal

To remove the onboard battery, follow the steps below:

1. Power off your system and unplug your power cable.

2. Locate the onboard battery.

3. Using a tool such as a pen or a small screwdriver, push the battery lock out-

wards to unlock it. Once unlocked, the battery will pop out from the holder.

4. Remove the battery.

Proper Battery Disposal

Warning: Please handle used batteries carefully. Do not damage the battery in any

way; a damaged battery may release hazardous materials into the environment. Do

not discard a used battery in the garbage or a public landll. Please comply with the

regulations set up by your local hazardous waste management agency to dispose of

your used battery properly.

Battery Installation

1. To install an onboard battery, follow the steps 1 & 2 above and continue

below:

2. Identify the battery's polarity. The positive (+) side should be facing up.

3. Insert the battery into the battery holder and push it down until you hear a

click to ensure that the battery is securely locked.

Warning: When replacing a battery, be sure to only replace it with the same type.

3-6

Chapter 3: Troubleshooting

3-4 Frequently Asked Questions

Question: What are the various types of memory that my motherboard can

support?

Answer: The motherboard supports Registered/LRDIMM ECC or UDIMM ECC/

Non-ECC DDR3 DIMM modules. To enhance memory performance, do not mix

memory modules of different speeds and sizes. Please follow all memory installa-

tion instructions given on Section 2-4 in Chapter 2.

Question: How do I update my BIOS?

It is recommended that you do not upgrade your BIOS if you are not experiencing

any problems with your system. Updated BIOS les are located on our website

at http://www.supermicro.com. Please check our BIOS warning message and the

information on how to update your BIOS on our website. Select your motherboard

model and download the BIOS le to your computer. Also, check the current BIOS

revision to make sure that it is newer than your BIOS before downloading. You can

choose from the zip le and the .exe le. If you choose the zip BIOS le, please

unzip the BIOS le onto a bootable USB device. Run the batch le using the format

AMI.bat lename.rom from your bootable USB device to ash the BIOS. Then, your

system will automatically reboot.

Warning: Do not shut down or reset the system while updating the BIOS to prevent

possible system boot failure!)

Note: The SPI BIOS chip used on this motherboard cannot be removed.

Send your motherboard back to our RMA Department at Supermicro for

repair. For BIOS Recovery instructions, please refer to the AMI BIOS

Recovery Instructions posted at http://www.supermicro.com.

Question: How do I handle the used battery?

Answer: Please handle used batteries carefully. Do not damage the battery in any

way; a damaged battery may release hazardous materials into the environment. Do

not discard a used battery in the garbage or a public landll. Please comply with the

regulations set up by your local hazardous waste management agency to dispose

of your used battery properly. (Refer to Section 3-3 on Page 3-6.)

3-7

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

3-5 Returning Merchandise for Service

A receipt or copy of your invoice marked with the date of purchase is required before

any warranty service will be rendered. You can obtain service by calling your ven-

dor for a Returned Merchandise Authorization (RMA) number. When returning the

motherboard to the manufacturer, the RMA number should be prominently displayed

on the outside of the shipping carton, and the shipping package is mailed prepaid

or hand-carried. Shipping and handling charges will be applied for all orders that

must be mailed when service is complete. For faster service, you can also request

a RMA authorization online (http://www.supermicro.com/RmaForm/).

This warranty only covers normal consumer use and does not cover damages in-

curred in shipping or from failure due to the alternation, misuse, abuse or improper

maintenance of products.

During the warranty period, contact your distributor rst for any product problems.

3-8

Chapter 4: AMI BIOS

Chapter 4

BIOS

4-1 Introduction

This chapter describes the AMI BIOS setup utility for the X9DR3-LN4F+/X9DRiLN4F+. It also provides the instructions on how to navigate the AMI BIOS setup

utility screens. The AMI ROM BIOS is stored in a Flash EEPROM and can be

easily updated.

Starting BIOS Setup Utility

To enter the AMI BIOS setup utility screens, press the <Del> key while the system

is booting up.

Note: In most cases, the <Del> key is used to invoke the AMI BIOS setup

screen. There are a few cases when other keys are used, such as <F3>,

<F4>, etc.

Each main BIOS menu option is described in this manual. The Main BIOS setup

menu screen has two main frames. The left frame displays all the options that can

be congured. Grayed-out options cannot be congured. Options in blue can be

congured by the user. The right frame displays the key legend. Above the key

legend is an area reserved for a text message. When an option is selected in the

left frame, it is highlighted in white. Often a text message will accompany it.

Note: The AMI BIOS has default text messages built in. The manufacturer

retains the option to include, omit, or change any of these text mes-

sages.

The AMI BIOS setup utility uses a key-based navigation system called "hot keys."

Most of the AMI BIOS setup utility "hot keys" can be used at any time during setup

navigation. These keys include <F3>, <F4>, <Enter>, <ESC>, arrow keys, etc.

Note 1: Options printed in Bold are default settings.

Note 2: <F3> is used to load optimal default settings. <F4> is used to save

the settings and exit the setup utility.

How To Change the Conguration Data

The conguration data that determines the system parameters may be changed by

entering the AMI BIOS setup utility. This setup utility can be accessed by pressing

<F2> at the appropriate time during system boot.

4-1

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

Note: For AMI UEFI BIOS Recovery, please refer to the UEFI BIOS Re-

covery User Guide posted @http://www.supermicro.com/support/manuals/.

Starting the Setup Utility

Normally, the only visible Power-On Self-Test (POST) routine is the memory test.

As the memory is being tested, press the <F2> key to enter the main menu of

the AMI BIOS setup utility. From the main menu, you can access the other setup

screens. An AMI BIOS identication string is displayed at the left bottom corner of

the screen below the copyright message.

Warning: Do not upgrade the BIOS unless your system has a BIOS-related issue.

Flashing the wrong BIOS can cause irreparable damage to the system. In no event

shall the manufacturer be liable for direct, indirect, special, incidental, or consequential

damage arising from a BIOS update. If you have to update the BIOS, do not shut down

or reset the system while the BIOS is being updated to avoid possible boot failure.

4-2 Main Setup

When you rst enter the AMI BIOS setup utility, you will enter the Main setup screen.

You can always return to the Main setup screen by selecting the Main tab on the

top of the screen. The Main BIOS Setup screen is shown below.

The AMI BIOS main menu displays the following information:

System Date

This item displays the system date in Day MM/DD/YY format (e.g. Wed 10/12/2011).

4-2

Chapter 4: AMI BIOS

System Time

This item displays the system time in HH:MM:SS format (e.g. 15:32:52).

Supermicro X9DRi-LN4+/X9DR3-LN4+

Version

This item displays the SMC version of the BIOS ROM used in this system.

Build Date

This item displays the date that the BIOS setup utility was built.

Memory Information

Total Memory

This displays the amount of memory that is available in the system.

4-3 Advanced Setup Congurations

Use the arrow keys to select Advanced Setup and press <Enter> to access the

following submenu items.

Boot Features

Quiet Boot

Use this feature to select bootup screen display between POST messages and

the OEM logo. Select Disabled to display the POST messages. Select Enabled

to display the OEM logo instead of the normal POST messages. The options are

Enabled and Disabled.

4-3

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

AddOn ROM Display Mode

Use this item to set the display mode for the Option ROM. Select Keep Current to

use the current AddOn ROM Display setting. Select Force BIOS to use the Option

ROM display mode set by the system BIOS. The options are Force BIOS and

Keep Current.

Bootup Num-Lock

Use this feature to set the Power-on state for the Numlock key. The options are

Off and On.

Wait For 'F1' If Error

Select Enabled to force the system to wait until the <F1> key is pressed if an error

occurs. The options are Disabled and Enabled.

Interrupt 19 Capture

Interrupt 19 is the software interrupt that handles the boot disk function. When this

item is set to Enabled, the ROM BIOS of the host adaptors will "capture" Interrupt 19

at bootup and allow the drives that are attached to these host adaptors to function

as bootable disks. If this item is set to Disabled, the ROM BIOS of the host adap-

tors will not capture Interrupt 19, and the drives attached to these adaptors will not

function as bootable devices. The options are Enabled and Disabled.

Re-try Boot

If this item is enabled, the BIOS will automatically reboot the system from a speci-

ed boot device after its initial boot failure. The options are Disabled, Legacy

Boot, and EFI Boot.

Power Conguration

Watch Dog Function

If enabled, the Watch Dog timer will allow the system to reboot when it is inactive

for more than 5 minutes. The options are Enabled and Disabled.

Power Button Function

If this feature is set to Instant Off, the system will power off immediately as soon

as the user presses the power button. If this feature is set to 4 Seconds Override,

the system will power off when the user presses the power button for 4 seconds or

longer. The options are Instant Off and 4 Seconds Override.

Restore on AC Power Loss

Use this feature to set the power state after a power outage. Select Power-Off for

the system power to remain off after a power loss. Select Power-On for the system

4-4

Chapter 4: AMI BIOS

power to be turned on after a power loss. Select Last State to allow the system to

resume its last state before a power loss. The options are Power-On, Power-Off

and Last State.

CPU Conguration

This submenu displays the information of the CPU as detected by the BIOS. It also

allows the user to conguration CPU settings.

Socket 1 CPU Information/Socket 2 CPU Information

This submenu displays the following information regarding the CPUs installed

in Socket 1/ Socket 2.

•Type of CPU

•CPU Signature

•Microcode Patch

•CPU Stepping

•Maximum CPU Speed

•Minimum CPU Speed

•Processor Cores

•Intel HT (Hyper-Threading) Technology

•Intel VT-x Technology

•Intel SMX Technology

•L1 Data Cache

•L1 Code Cache

•L2 Cache

•L3 Cache

CPU Speed

This item displays the speed of the CPU installed in Socket 1/Socket 2.

4-5

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

64-bit

This item indicates if the CPU installed in Socket 1 or Socket 2 supports 64-bit technology.

Clock Spread Spectrum

Select Enable to enable Clock Spectrum support, which will allow the BIOS to moni-

tor and attempt to reduce the level of Electromagnetic Interference caused by the

components whenever needed. The options are Disabled and Enabled.

RTID (Record Types IDs)

This feature displays the total number of Record Type IDs for local and remote

pools. The options are Optimal and Alternate.

Hyper-threading

Select Enabled to support Intel Hyper-threading Technology to enhance CPU per-

formance. The options are Enabled and Disabled.

Active Processor Cores

Set to Enabled to use a processor's second core and above. (Please refer to Intel's

website for more information.) The options are All, 1 and 2.

Limit CPUID Maximum

Use this feature to set the maximum CPU ID value. Enable this function to boot

the legacy operating systems that cannot support processors with extended CPUID

functions. The options are Enabled and Disabled (for the Windows OS).

Execute-Disable Bit Capability (Available if supported by the OS & the CPU)

Select Enabled to enable the Execute Disable Bit which will allow the processor

to designate areas in the system memory where an application code can execute

and where it cannot, thus preventing a worm or a virus from ooding illegal codes

to overwhelm the processor or damage the system during an attack. The default is

Enabled. (Refer to Intel and Microsoft Web sites for more information.)

Intel® AES-NI

Select Enable to use the Intel Advanced Encryption Standard (AES) New Instruc-

tions (NI) to ensure data security. The options are Enabled and Disabled.

MLC Streamer Prefetcher (Available when supported by the CPU)

If set to Enabled, the MLC (Mid-Level Cache) Streamer prefetcher will prefetch

streams of data and instructions from the main memory to the L2 cache to improve

CPU performance. The options are Disabled and Enabled.

4-6

Chapter 4: AMI BIOS

MLC Spatial Prefetcher (Available when supported by the CPU)

If set to Enabled, the MLC (Mid-Level Cache) Spatial prefetcher will prefetch the

both cache lines for 128 bytes as comprised. If set to Disabled, the MLC (Mid-Level

Cache) Spatial prefetcher will prefetch the adjacent cache line for 64 bytes. The

options are Disabled and Enabled.

DCU Streamer Prefetcher (Available when supported by the CPU)

Select Enabled to support Data Cache Unite (DCU) prefetch to speed up data

accessing and processing in the DCU to enhance CPU performance. The options

are Disabled and Enabled.

DCU IP Prefetcher

Select Enabled for DCU (Data Cache Unit) IP Prefetcher support, which will prefetch

IP addresses to improve network connectivity and system performance. The options

are Enabled and Disabled.

Intel® Virtualization Technology (Available when supported by the CPU)

Select Enabled to suppor t Intel Virtualization Technology, which will allow one

platform to run multiple operating systems and applications in independent parti-

tions, creating multiple "virtual" systems in one physical computer. The options

are Enabled and Disabled.

Note: If there is any change to this setting, you will need to power off and

restart the system for the change to take effect. Please refer to Intel’s

website for detailed information.)

 CPU Power Management Conguration

This submenu allows the user to congure the following CPU Power Management

settings.

Power Technology

Select Energy Efciency to support power-saving mode. Select Custom to cus-

tomize system power settings. Select Disabled to disable power-saving settings.

The options are Disabled, Energy Efciency, and Custom. If the option is set

to Custom, the following items will display:

EIST (Available when Power Technology is set to Custom)

EIST (Enhanced Intel SpeedStep Technology) allows the system to au-

tomatically adjust processor voltage and core frequency to reduce power

consumption and heat dissipation. The options are Disabled (GV3 Disabled),

and Enabled (GV3 Enabled). (Note: GV3 is Intel Speedstep support used

on older platforms.)Please refer to Intel’s website for detailed information.)

4-7

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

Turbo Mode (Available when Power Technology is set to Custom)

Select Enabled to use the Turbo Mode to boost system performance. The

options are Enabled and Disabled.

C1E (Available when Power Technology is set to Custom)

Select Enabled to enable Enhanced C1 Power State to boost system per-

formance. The options are Enabled and Disabled.

CPU C3 Report (Available when Power Technology is set to Custom)

Select Enabled to allow the BIOS to report the CPU C3 State (ACPI C2) to

the operating system. During the CPU C3 State, the CPU clock generator

is turned off. The options are Enabled and Disabled.

CPU C6 Report (Available when Power Technology is set to Custom)

Select Enabled to allow the BIOS to report the CPU C6 State (ACPI C3) to

the operating system. During the CPU C6 State, the power to all cache is

turned off. The options are Enabled and Disabled.

CPU C7 Report (Available when Power Technology is set to Custom)

Select Enabled to allow the BIOS to report the CPU C7 State (ACPI C3) to

the operating system. CPU C7 State is a processor-specic low C-State.

The options are Enabled and Disabled.

Package C-State limit (Available when Power Technology is set to

Custom)

This feature allows the user to set the limit on the C-State package register.

The options are C0, C2, C6, and No Limit.

Energy/Performance Bias

Use this feature to select an appropriate fan setting to achieve maximum

system performance (with maximum cooling) or maximum energy efciency

with maximum power saving). The fan speeds are controlled by the rm-

ware management via IPMI 2.0. The options are Performance, Balanced

Performance, Balanced Energy, and Energy Efcient.

Factory Long Duration Power Limit

This item displays the power limit set by the manufacturer during which long

duration power is maintained.

4-8

Chapter 4: AMI BIOS

Long Duration Power Limit

This item displays the power limit set by the manufacturer during which long

duration power is maintained.

Factory Long Duration Maintained (Available when Power Technology

is set to Custom)

This item displays the period of time set by the manufacturer during which

long duration power is maintained.

Long Duration Maintained

This item displays the period of time during which long duration power is

maintained.

Recommended Short Duration Power

This item displays the short duration power settings recommended by the

manufacturer.

Short Duration Power Limit

This item displays the time period during which short duration power is

maintained.

Chipset Conguration

North Bridge

This feature allows the user to congure the settings for the Intel North Bridge.

Integrated IO Conguration

Intel VT-d

Select Enabled to enable Intel Virtualization Technology support for Direct I/O VT-d by reporting the I/O device assignments to the VWM (Virtual Working

Memory) through the DMAR ACPI Tables. This feature offers fully-protected

I/O resource sharing across Intel platforms, providing greater reliability, security

and availability in networking and data-sharing. The options are Enabled and

Disabled.

Ageing Timer Rollover

Use this feature to congure the Ageing timer setting. Use the default setting

to comply with the BIOS setting. The options are Disabled, 32 us, 128 us, and

512 us.

4-9

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

Intel I/OAT

The Intel I/OAT (I/O Acceleration Technology) signicantly reduces CPU over-

head by leveraging CPU architectural improvements, freeing the system resource

for other tasks. The options are Disabled and Enabled.

DCA Support

Select Enabled to use Intel's DCA (Direct Cache Access) Technology to improve

data transfer efciency. The options are Enabled and Disabled.

MMCFG (Memory Mapped Conguration) BASE

This item allows the user to set the default PCI MMIO base address. The lower

the MMIO base address is, the less available the system memory is in a 32-bit

OS. The default setting is [0x80000000].

IIO 1 PCIe Port Bifurcation Control

This submenu congures the following IO PCIe Port Bifurcation Control settings

for IIO 1 PCIe ports to determine how the available PCI-Express lanes to be

distributed between the PCI-Exp. Root Ports.

Uplink Link Speed

This feature allows the user to select target link speed. The options are Gen1

(Generation 1), Gen2 and Gen3.

CPU1 Slot2 PCI-E 3.0 x4 Link Speed

This feature allows the user to set the PCI-Exp bus speed for the slot specied

above. The options are Gen1 (Generation 1), Gen2 and Gen3.

CPU1 Slot3 PCI-E 3.0 x16 Link Speed

This feature allows the user to set the PCI-Exp bus speed for the slot specied

above. The options are Gen1 (Generation 1), Gen2 and Gen3.

CPU1 Slot1 PCI-E 3.0 x16 Link Speed

This feature allows the user to set the PCI-Exp bus speed for the slot specied

above. The options are Gen1 (Generation 1), Gen2 and Gen3.

IIO 2 PCIe Port Bifurcation Control

This submenu congures the following IO PCIe Port Bifurcation Control settings

for IIO 2 PCIe ports to determine how the available PCI-Express lanes to be

distributed between the PCI-Exp. Root Ports.

CPU2 Slot6 PCI-E 3.0 x8 Link Speed

This feature allows the user to set the PCI-Exp bus speed for the slot specied

above. The options are Gen1 (Generation 1), Gen2 and Gen3.

4-10

Chapter 4: AMI BIOS

CPU2 Slot5 PCI-E 3.0 x 16 Link Speed

This feature allows the user to set the PCI-Exp bus speed for the slot specied

above. The options are Gen1 (Generation 1), Gen2 and Gen3.

CPU2 Slot4 PCI-E 3.0 x 16 Link Speed

This feature allows the user to set the PCI-Exp bus speed for the slot specied

above. The options are Gen1 (Generation 1), Gen2 and Gen3.

QPI Conguration

Current QPI Link

This item displays the current status of the QPI Link.

Current QPI Frequency

This item displays the frequency of the QPI Link.

Isoc

Select Enabled to enable Ischronous support to meet QoS (Quality of Service)

requirements. This feature is especially important for virtualization technology.

The options are Enabled and Disabled.

QPI (Quick Path Interconnect) Link Speed Mode

Use this feature to select data transfer speed for QPI Link connections. The

options are Fast and Slow.

QPI Link Frequency Select

Use this feature to select the desired QPI frequency. The options are Auto, 6.4

GT/s, 7.2 GT/s, and 8.0 GT/s.

DIMM Conguration

This section displays the following DIMM information.

Current Memory Mode

This item displays the current memory mode.

Current Memory Speed

This item displays the current memory speed.

Mirroring

This item displays if memory mirroring is supported by the motherboard. Memory

mirroring creates a duplicate copy of the data stored in the memory to enhance

data security.

4-11

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

Sparing

This item displays if memory sparing is supported by the motherboard. Memory

sparing enhances system performance.

DIMM Information

CPU Socket 1 DIMM Information

P1-DIMMA1~3, P1-DIMMB1~3, P1-DIMMC1~3, P1-DIMMD1~3

CPU Socket 2 DIMM Information

P1-DIMME1~3, P1-DIMMF1~3, P1-DIMMG1~3, P1-DIMMH1~3

The status of the memory modules specied above will be displayed as detected

by the BIOS.

Memory Mode

When Independent is selected, all DIMMs are available to the operating system.

When Mirroring is selected, the motherboard maintains two identical copies of all

data in memory for data backup. When Lockstep is selected, the motherboard

uses two areas of memory to run the same set of operations in parallel. The

options are Independent, Mirroring, and Lockstep.

DRAM RAPL Mode

RAPL (Running Average Power Limit) provides mechanisms to enforce power

consumption limits on supported processors The options are DRAM RAPL

MODE0 , DRAM RAPL MODE1, and Disabled.

DDR Speed

Use this feature to force a DDR3 memory module to run at a frequency other

than what is specied in the specication. The options are Auto, Force DDR3-

800, Force DDR3-1066, Force DDR3-1333, Force DDR3-1600 and Force SPD.

Channel Interleaving

This feature selects from the different channel interleaving methods. The options

are Auto, 1 Way, 2 Way, 3, Way, and 4 Way.

Rank Interleaving

This feature allows the user to select a rank memory interleaving method. The

options are Auto, 1 Way, 2 Way, 4, Way, and 8 Way.

Patrol Scrub

Patrol Scrubbing is a process that allows the CPU to correct correctable memory

errors detected on a memory module and send the correction to the requestor

4-12

Chapter 4: AMI BIOS

(the original source). When this item is set to Enabled, the IO hub will read and

write back one cache line every 16K cycles, if there is no delay caused by internal

processing. By using this method, roughly 64 GB of memory behind the IO hub

will be scrubbed every day. The options are Enabled and Disabled.

Demand Scrub

Demand Scrubbing is a process that allows the CPU to correct correctable

memory errors found on a memory module. When the CPU or I/O issues a

demand-read command, and the read data from memory turns out to be a

correctable error, the error is corrected and sent to the requestor (the original

source). Memory is updated as well. Select Enabled to use Demand Scrubbing

for ECC memory correction. The options are Enabled and Disabled.

Data Scrambling

Select Enabled to enable data scrubbing to ensure data security and integrity.

The options are Enabled and Disabled.

Device Tagging

Select Enabled to support device tagging. The options are Disabled and En-

abled.

Thermal Throttling

Throttling improves reliability and reduces power consumption in the proces-

sor via automatic voltage control during processor idle states. The options are

Disabled and CLTT (Closed Loop Thermal Throttling).

Double Refresh

Select Enabled to support double refresh for onboard memory to enhance

memory and system performance. The options are Auto, Enabled, and Disabled.

South Bridge Conguration

This feature allows the user to congure the settings for the Intel PCH chip.

PCH Information

This feature displays the following PCH information.

Name: This item displays the name of the PCH chip.

Stepping: This item displays the status of the PCH stepping.

USB Devices: This item displays the USB devices detected by the BIOS.

4-13

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

All USB Devices

This feature enables all USB ports/devices. The options are Disabled and Enabled.

(If set to Enabled, EHCI Controller 1 and Controller 2 will appear.)

EHCI Controller 1/EHCI Controller 2 (Available when All USB Devices is set to Enabled)

Select Enabled to enable EHCI (Enhanced Host Controller Interface) Controller 1

or Controller 2. The options are Disabled and Enabled.

Legacy USB Support (Available when USB Functions is not Disabled)

Select Enabled to support legacy USB devices. Select Auto to disable legacy sup-

port if USB devices are not present. Select Disable to have USB devices available

for EFI (Extensive Firmware Interface) applications only. The settings are Disabled,

Enabled and Auto.

Port 60/64 Emulation

Select Enabled to enable I/O port 60h/64h emulation support for the legacy USB

keyboard so that it can be fully supported by the operating systems that does not

recognize a USB device. The options are Disabled and Enabled.

EHCI Hand-Off

This item is for operating systems that do not support Enhanced Host Controller

Interface (EHCI) hand-off. When enabled, EHCI ownership change will be claimed

by the EHCI driver. The options are Disabled and Enabled.

SATA Conguration

When this submenu is selected, the AMI BIOS automatically detects the presence

of IDE or SATA devices and displays the following items.

SATA Port0~SATA Port5: The AMI BIOS displays the status of each SATA port

as detected by the BIOS.

SATA Mode

Use this feature to congure SATA mode for a selected SATA port. The options are

Disabled, IDE Mode, AHCI Mode and RAID Mode. The following are displayed

depending on your selection:

4-14

Chapter 4: AMI BIOS

IDE Mode

The following items are displayed when IDE Mode is selected:

SATA (Serial-ATA) Controller 0~1

Use this feature to activate or deactivate the SATA controller, and set the

compatibility mode. The options for Controller 0 are Enhanced and Com-

patible. The default of SATA Controller 1 is Enhanced.

AHCI Mode

The following items are displayed when the AHCI Mode is selected.

Aggressive Link Power Management

Select Enabled to enable Aggressive Link Power Management support

for Cougar Point B0 stepping and beyond. The options are Enabled and

Disabled.

Port 0~5 Hot Plug

Select Enabled to enable hot-plug support for a particular port, which will

allow the user to change a hardware component or device without shutting

down the system. The options are Enabled and Disabled.

Staggered Spin Up

Select Enabled to enable Staggered Spin-up support to prevent excessive

power consumption caused by multiple HDDs spinning-up simultaneously.

The options are Enabled and Disabled.

RAID Mode

The following items are displayed when RAID Mode is selected:

Port 0~5 Hot Plug

Select Enabled to enable hot-plug support for the particular port. The options

are Enabled and Disabled.

SCU (Storage Control Unit) Conguration

Storage Controller Unit

Select Enabled to enable PCH SCU storage devices. The options are Disabled

and Enabled.

4-15

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

SCU RAID Option ROM/UEFI Driver

Select Enabled to support the onboard SCU Option ROM to boot up the system via

a storage device. The options are Disabled and Enabled.

SCU Port 0~SCU Port 7: The AMI BIOS will automatically detect the onboard SCU

devices and display the status of each SCU device as detected.

PCIe/PCI/PnP Conguration

Launch Storage OpROM Policy

This feature controls how the system executes UEFI (Unied Extensible Firmware

Interface) and legacy storage OpROM. Select Legacy only to boot the system us-

ing a legacy storage device. Select UEFI only to use UEFI Storage Option ROM to

boot the system. The options are UEFI only and Legacy only.

PCI Latency Timer

Use this feature to set the latency timer for each PCI device installed on a PCI bus.

Select 64 to set the PCI latency to 64 PCI clock cycles. The options are 32 PCI clock

cycles, 64 PCI clock cycles, 96 PCI clock cycles, 128 PCI clock cycles, 160 PCI

clock cycles, 192 PCI clock cycles, 224 PCI clock cycles, and 248 PCI clock cycles.

PERR# Generation

Select Enabled to allow a PCI device to generate a PERR number for a PCI Bus

Signal Error Event. The options are Enabled and Disabled.

SERR# Generation

Select Enabled to allow a PCI device to generate an SERR number for a PCI Bus

Signal Error Event. The options are Enabled and Disabled.

Maximum Payload

Select Auto to allow the system BIOS to automatically set the maximum payload

value for a PCI-E device to enhance system performance. The options are Auto,

128 Bytes, 256 Bytes, 512 Bytes, 1024 Bytes, 2048 Bytes, and 4096 Bytes.

Maximum Read Request

Select Auto to allow the system BIOS to automatically set the maximum Read

Request size for a PCI-E device to enhance system performance. The options are

Auto, 128 Bytes, 256 Bytes, 512 Bytes, 1024 Bytes, 2048 Bytes, and 4096 Bytes.

ASPM Support

Use this feature to set the Active State Power Management (ASPM) level for a PCI-E

device. Select Force L0 to force all PCI-E links to operate at L0 state. Select Auto

4-16

Chapter 4: AMI BIOS

to allow the system BIOS to automatically set the ASPM level for the system. Select

Disabled to disable ASPM support. The options are Disabled, Force L0, and Auto.

Warning: Enabling ASPM support may cause some PCI-E devices to fail!

Above 4G Decoding (Available if the system supports 64-bit PCI decoding)

Select Enabled to decode a PCI device that supports 64-bit in the space above 4G

Address. The options are Enabled and Disabled.

SMBus Address Resolution Protocol

Select Enabled to dynamically assign a new unique address to a device installed

in each slave drive in the SMBus (System Management Bus) when a address

conict arises to resolve an address conict in SMBus slave drives. The options

are Enabled and Disabled.

CPU1 Slot 1 PCI-E 3.0 x16 OPROM/CPU1 Slot 2 PCI-E 3.0 x4 OPROM/CPU1 Slot 3 PCI-E 3.0 x16 OPROM/CPU2 Slot 4 PCI-E 3.0 x16 OPROM/CPU2 Slot 5 PCI-E 3.0 x16 OPROM/CPU2 Slot 6 PCI-E 3.0 x8 OPROM

Select Enabled to enable Option ROM support to boot the computer using a

network interface from the slots specied above. The options are Enabled and

Disabled.

Onboard LAN Option ROM Select

Select iSCSI to use the iSCSI Option ROM to boot the computer using a network

device. Select PXE (Preboot Execution Environment) to use an PXE Option ROM

to boot the computer using a network device. The options are iSCSI and PXE.

Load Onboard LAN1 Option ROM/Load Onboard LAN2 Option ROM/ Load Onboard LAN3 Option ROM/Load Onboard LAN4 Option ROM

Select Enabled to enable the onboard LAN1 Option ROM~L AN4 Option ROM.

This is to boot the computer using a network device. The default setting for LAN1

Option ROM is Enabled, and the default settings for LAN2 Option ROM/LAN3

Option ROM/LAN4 Option ROM are Disabled.

VGA Priority

Use this feature to select the graphics adapter to be used as the primary boot

device. The options are Onboard and Offboard.

Network Stack

Select Enabled enable PXE (Preboot Execution Environment) or UEFI (Unied

Extensible Firmware Interface) for network stack support. The options are Enabled

and Disabled.

4-17

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

Super IO Conguration

Super IO Chip: This item displays the Super IO chip used in the motherboard.

Serial Port 1 Conguration

Serial Port

Select Enabled to enable a serial port specied by the user. The options are En-

abled and Disabled.

Device Settings

This item displays the IP address and IRQ (Interrupt Request) address of Serial

Port 1.

Change Settings

Use this feature to set the optimal Environment_Control_Interface (PECI) setting for

a serial port specied. The default setting is Auto, which will allow the AMI BIOS

to automatically select the best setting for the PECI platform.

Device Mode

Use this feature to select the desired mode for a serial port specied. The options

are Normal and High Speed.

Serial Port 2 Conguration

SOL (Serial_Over_LAN) Serial Port

Select Enabled to enable a serial port specied by the user to be used as the Se-

rial _Over_ LAN port. The options are Enabled and Disabled.

Device Settings

This item displays the IP address and IRQ (Interrupt Request) address of Serial

Port 2.

SOL Change Settings

Use this feature to set the optimal Environment_Control_Interface (PECI) setting for

a serial port specied. The default setting is Auto, which will allow the AMI BIOS

to automatically select the best setting for the PECI platform.

SOL Device Mode

Use this feature to select the desired mode for a serial port specied. The options

are Normal and High Speed.

4-18

Chapter 4: AMI BIOS

Serial Port 2 Attribute

Use this feature to select the attribute for serial port 2. The options are SOL (Serial

On LAN), and High Speed.

Serial Port Console Redirection

•COM 1/COM 2

These two submenus allow the user to congure the following Console Redirection

settings for a COM Port specied by the user.

Console Redirection

Select Enabled to use a COM Port selected by the user for Console Redirection.

The options are Enabled and Disabled. The default setting for COM1 is Disabled,

and for COM2/SOL is Enabled.

Console Redirection Settings

This feature allows the user to specify how the host computer will exchange data

with the client computer, which is the remote computer used by the user.

Terminal Type

Use this feature to select the target terminal emulation type for Console Redirec-

tion. Select VT100 to use the ASCII Character set. Select VT100+ to add color

and function key support. Select ANSI to use the Extended ASCII Character Set.

Select VT-UTF8 to use UTF8 encoding to map Unicode characters into one or

more bytes. The options are ANSI, VT100, VT100+, and VT-UTF8.

Bits Per second

Use this feature to set the transmission speed for a serial port used in Console

Redirection. Make sure that the same speed is used in the host computer and

the client computer. A lower transmission speed may be required for long and

busy lines. The options are 9600, 19200, 57600 and 115200 (bits per second).

Data Bits

Use this feature to set the data transmission size for Console Redirection. The

options are 7 Bits and 8 Bits.

Parity

A parity bit can be sent along with regular data bits to detect data transmission

errors. Select Even if the parity bit is set to 0, and the number of 1's in data bits

is even. Select Odd if the parity bit is set to 0, and the number of 1's in data bits

is odd. Select None if you do not want to send a parity bit with your data bits

4-19

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

in transmission. Select Mark to add a mark as a parity bit to be sent along with

the data bits. Select Space to add a Space as a parity bit to be sent with your

data bits. The options are None, Even, Odd, Mark and Space.

Stop Bits

A stop bit indicates the end of a serial data packet. Select 1 Stop Bit for standard

serial data communication. Select 2 Stop Bits if slower devices are used. The

options are 1 and 2.

Flow Control

This feature allows the user to set the ow control for Console Redirection to

prevent data loss caused by buffer overow. Send a "Stop" signal to stop send-

ing data when the receiving buffer is full. Send a "Start" signal to start sending

data when the receiving buffer is empty. The options are None, Hardware RTS/

CTS, and Software Xon/Xoff.

VT-UTF8 Combo Key Support

Select Enabled to enable VT-UTF8 Combination Key support for ANSI/VT100

terminals. The options are Enabled and Disabled.

Recorder Mode

Select Enabled to capture the data displayed on a terminal and send it as text

messages to a remote server. The options are Disabled and Enabled.

Resolution 100x31

Select Enabled for extended-terminal resolution support. The options are Dis-

abled and Enabled.

Legacy OS Redirection Resolution

Use this feature to select the number of rows and columns used in Console

Redirection for legacy OS support. The options are 80x24 and 80x25.

Putty KeyPad

This feature selects Function Keys and KeyPad settings for Putty, which is a

terminal emulator designed for the Windows OS. The options are VT100, Linux,

XTERMR6, SC0, ESCN, and VT400.

Redirection After BIOS Post

Use this feature to enable or disable Legacy Console Redirection after BIOS

POST (Power_On_Self_Test). When this feature is set to Bootloader, Legacy

Console Redirection is disabled before the OS is initialized. When this feature

is set to Always Enable, Legacy Console Redirection remains enabled during

OS bootup. The options are Always Enable and Bootloader.

4-20

Chapter 4: AMI BIOS



Console Redirection Settings (for EMS)

Use this feature to specify how the host computer will exchange data with the

client computer, which is the remote computer used by the user.

Out-of-Band Management Port

The feature selects a serial port used by the Microsoft Windows Emergency

Management Services (EMS) to communicate with a remote server. The options

are COMA and SOL.

Terminal Type

This feature allows the user to select the target terminal emulation type for Con-

sole Redirection. Select VT100 to use the ASCII character set. Select VT100+

to add color and function key support. Select ANSI to use the extended ASCII

character set. Select VT-UTF8 to use UTF8 encoding to map Unicode characters

into one or more bytes. The options are ANSI, VT100, VT100+, and VT-UTF8.

Bits Per Second

This item sets the transmission speed for a serial port used in Console Redirec-

tion. Make sure that the same speed is used in the host computer and the client

computer. A lower transmission speed may be required for long and busy lines.

The options are 9600, 19200, 57600, and 115200 (bits per second).

Flow Control

This feature allows the user to set the ow control for Console Redirection to

prevent data loss caused by buffer overow. Send a "Stop" signal to stop send-

ing data when the receiving buffer is full. Send a "Start" signal to start sending

data when the receiving buffer is empty. The options are None, Hardware RTS/

CTS, and Software Xon/Xoff.

Data Bits, Parity, Stop Bits

The status of these features is displayed.

4-21

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

Trusted Computing (Available when a TPM device is detected by the BIOS)

Conguration

TPM Support

Select Enabled on this item and enable the TPM jumper on the motherboard to

enable TPM support to improve data integrity and network security. The options

are Enabled and Disabled.

TPM State

Select Enabled to enable TPM security settings to improve data integrity and

network security. The options are Disabled and Enabled.

Pending Operation: This item displays the status of a pending operation.

Current Status Information: This item displays the information regarding the

current TPM status.

TPM Enable Status

This item displays the status of TPM Support to indicate if TPM is currently

enabled or disabled.

TPM Active Status

This item displays the status of TPM Support to indicate if TPM is currently ac-

tive or deactivated.

4-22

Chapter 4: AMI BIOS

TPM Owner Status

This item displays the status of TPM Ownership.

ACPI Setting

Use this feature to congure Advanced Conguration and Power Interface (ACPI)

power management settings for your system.

ACPI Sleep State

Use this feature to select the ACPI State when the system is in sleep mode. Select

S1 (CPU_Stop_Clock) to erase all CPU caches and stop executing instructions.

Power to the CPU(s) and RAM is maintained, but RAM is refreshed. Select Suspend

to use power-reduced mode. Power will only be supplied to limited components

(such as RAMs) to maintain the most critical functions of the system. The options

are S1 (CPU_Stop_Clock), Suspend and Disabled.

NUMA (NON-Uniform Memory Access)

This feature enables the Non-Uniform Memory Access ACPI support. The options

are Enabled and Disabled.

High Precision Event Timer

Select Enabled to activate the High Precision Event Timer (HPET) that produces

periodic interrupts at a much higher frequency than a Real-time Clock (RTC) does

in synchronizing multimedia streams, providing smooth playback, reducing the de-

pendency on other timestamp calculation devices, such as an x86 RDTSC Instruc-

tion embedded in the CPU. The High Performance Event Timer is used to replace

the 8254 Programmable Interval Timer. The options are Enabled and Disabled.

Intel ME Subsystem Conguration

This feature displays the following ME Subsystem Conguration settings.

•ME BIOS Interface Version

•ME Version

4-23

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

4-4 Event Logs

Use this feature to congure Event Log settings.

Change SMBIOS Event Log Settings

This feature allows the user to congure SMBIOS Event settings.

Enabling/Disabling Options

SMBIOS Event Log

Select Enabled to enable SMBIOS (System Management BIOS) Event Logging

during system boot. The options are Enabled and Disabled.

Runtime Error Logging Support

Select Enabled to support Runtime Error Logging. The options are Enabled and

Disabled.

Memory Correctable Error Threshold

This feature allows the user to enter the threshold value for correctable memory

errors. The default setting is 10.

PCI Error Logging Support

Select Enabled to support error event logging for PCI slots. The options are Enabled

and Disabled.

4-24

Chapter 4: AMI BIOS

Erasing Settings

Erase Event Log

Select Enabled to erase the SMBIOS (System Management BIOS) Event Log,

which is completed before a event logging is initialized upon system reboot. The

options are No and Yes.

When Log is Full

Select Erase Immediately to immediately erase SMBIOS error event logs that ex-

ceed the limit when the SMBIOS event log is full. Select Do Nothing for the system

to do nothing when the SMBIOS event log is full. The options are Do Nothing and

Erase Immediately.

SMBIOS Event Log Standard Settings

Log System Boot Event

Select Enabled to log system boot events. The options are Disabled and Enabled.

MECI (Multiple Event Count Increment)

Enter the increment value for the multiple event counter. Enter a number between

1 to 255. The default setting is 1.

METW (Multiple Event Count Time Window)

This item allows the user to decide how long (in minutes) should the multiple event

counter wait before generating a new event log. Enter a number between 0 to 99.

The default setting is 60.

View SMBIOS Event Log

This item allows the user to view the event in the SMBIOS event log. Select this

item and press <Enter> to view the status of an event in the log.

Date/Time/Error Code/Severity

View System Event Log

This item allows the user to view the event in the system event log. Select this item

and press <Enter> to view the status of an event in the log.

Date/Time/Sensor/Type

4-25

X9DR3-LN4F+/X9DRi-LN4F+ Motherboard User’s Manual

4-5 IPMI

Use this feature to congure Intelligent Platform Management Interface (IPMI)

settings.

IPMI Firmware Revision

This item indicates the IPMI rmware revision used in your system.

IPMI Status

This item indicates the status of the IPMI rmware installed in your system.

System Event Log

Enabling/Disabling Options

SEL Components

Select Enabled for all system event logging at bootup. The options are Enabled

and Disabled.

Erasing Settings

Erase SEL

Select Yes, On next reset to erase all system event logs upon next system reboot.

Select Yes, On every reset to erase all system event logs upon each system reboot.

Select No to keep all system event logs after each system reboot. The options are

No, Yes, On next reset, and Yes, On every reset.

4-26

Supermicro X9DRi-LN4F+ operation manual

Specifications and Main Features

Frequently Asked Questions

User Manual
