Sunbeam PB7650 User Manual

MultiBlender™ Platinum

800 watt blender with 1.6L square glass jug

Instruction/Recipe Booklet

PB7650

Please read these instructions carefully
and retain for future reference.

Contents

Sunbeam’s Safety Precautions 1

Features of your MultiBlender Platinum 2

The Control Dial 4

Before using your MultiBlender Platinum 5

Using your MultiBlender Platinum 6

Feature uses of the MultiBlender Platinum 7

A Guide to your MultiBlender Platinum 8
Handy Blending Hints 9
Care and Cleaning 10
Recipes
Dips/Starters/Pastes 11
Desserts 18
Soups 20
Mains 23
Drinks 24
Cocktails 25
Thick Shakes 27
Milk Shakes 28

Sunbeam’s Safety Precautions

SAFETY PRECAUTIONS FOR YOUR SUNBEAM

MULTIBLENDER PB7650.

• Ensure fingers are kept well away from the blades
when in use.

• Do not blend hot ingredients. Always cool
ingredients to room temperature.

• Always operate on a flat surface.

Sunbeam is very safety conscious when designing

and manufacturing consumer products, but it is
essential that the product user also exercise care
when using an electrical appliance. Listed below are
precautions which are essential for the safe use of
an electrical appliance:

• Read carefully and save all the instructions
provided with an appliance.

• Always turn the power off at the power outlet
before you insert or remove a plug. Remove
by grasping the plug - do not pull on the cord.

• Turn the power off and remove the plug when the
appliance is not in use and before cleaning.

• Do not use your appliance with an extension cord
unless this cord has been checked and tested by
a qualified technician or service person.

• Always use your appliance from a power outlet of
the voltage (A.C. only) marked on the appliance.

• This appliance is not intended for use by persons
(including children) with reduced physical,
sensory or mental capabilities, or lack of
experience and knowledge, unless they have been
given supervision or instruction concerning use
of the appliance by a person responsible for their
safety.

• Children should be supervised to ensure that they
do not play with the appliance.

• The temperature of accessible surfaces may be
high when the appliance is operating.

• Never leave an appliance unattended while
in use.

• Ensure the control dial is in the off ‘O’ position
before plugging into the power outlet.

• Do not operate this blender for more than 2
minutes using heavy loads. None of the recipes
in this booklet are considered heavy loads.

• Care shall be taken when handling the sharp
cutting blades, emptying the bowl and during
cleaning.

• Do not use an appliance for any purpose other
than its intended use.

• Do not place an appliance on or near a hot gas
flame, electric element or on a heated oven.

• Do not place on top of any other appliance.

• Do not let the power cord of an appliance hang
over the edge of a table or bench top or touch any
hot surface.

• Do not operate any electrical appliance with a
damaged cord or after the appliance has been
damaged in any manner. If damage is suspected,
return the appliance to the nearest Sunbeam
Appointed Service Centre for examination, repair
or adjustment.

• For additional protection, Sunbeam recommend
the use of a residual current device (RCD)
with a tripping current not exceeding 30mA in
the electrical circuit supplying power to your
appliances.

• Do not immerse the appliance in water or any
other liquid unless recommended.

• Appliances are not intended to be operated by
means of an external timer or separate remote
control system.

• This appliance is intended to be used in
household and similar applications such as: staff
kitchen areas in shops, offices and other working
environments; farm houses; by clients in hotels,
motels and other residential type environments;
bed and breakfast type environments.

If you have any concerns regarding the performance and use of your appliance,

please visit www.sunbeam.com.au or contact the Sunbeam Consumer Service Line.

Ensure the above safety precautions are understood.

1

HIGH

MILKS HAKE

COCKTAI LS

PUREE

PULSE

1600

mL

1250

1000

750

500

1

2

3

Features of your MultiBlender
Platinum

Ingredient cup

Handy 70ml ingredient cup. Also acts as a
device to unscrew the blade assembly from the
base of the jug.

Flexible lid with pouring hole

To provide the necessary safety, the lid seals
tightly to the glass jug and features a pouring
hole, that allows you to add ingredients during
the blending process.

1.6 litre heat-resistant glass jug

The large 1.6 litre glass jug features specially
designed internal ribs to cycle ingredients back
into the blade system for consistant blending
results.

The heat-resistant glass jug is ideal for pureeing
warm soups.

CUPS 6

5

4

3

2

Detachable blade system assembly

The detachable blade assembly unit unscrews
from the glass blending jug for convenient and
thorough cleaning.

Motor base

The brushed metal base houses a powerful
800 watt motor.

Non-slip feet

Keeps the blender secure on the bench top
during use.

2

LOW

SMOOT HIE

THICK SHAKE

MIX

CRUSH ICE

OFF

PULSE

OFF

1600

1250

1000

mL

Serrated stainless steel six-blade system

Specially designed for extra durability, the
heavy-duty, serrated stainless steel blade with
a six-blade construction, crushes ice cubes to
flakes, produces a smooth consistency when
pureeing and combines ingredients perfectly
for a frappé.

1

750

500

MILKS HAKE

COCKTAI LS

PUREE

PULSE

3 speed control

The easy to grip control dial allows you to
select one of three speeds ranging from low
to high.

Pulse button

Increases the intensity of the standard
blending action to assist in the most
demanding blending tasks.

Cord storage facility

For tidy, convenient storage of the cord

2

3

HIGH

underneath the motor base.

3

The Control Dial

PULSE

OFF

1

2

3

Pulse

• Ice cubes

• Meat

• Breadcrumbs

• Biscuits

• Finely ground nuts

• Chocolate

• Self cleaning the unit

Speed 1

• Whipping cream

• Puree vegetables & fruit

• Curry pastes

• Coffee beans

• Mayonnaise

Speed 2

• Smoothies with fruit

• Soups

• Raw vegetables

• Cake batters

Speed 3

• Cocktails

• Laksa pastes

• Milkshakes

4

Before using your MultiBlender

500

250

1

2

500

250

1

2

Platinum

Important: Always ensure your blender is
unplugged from the power outlet before
fitting or removing the blade assembly.
Always handle the blade assembly with
caution, as the blades are extremely sharp.

To assemble the six-blade system in the glass
jug (see Figure 1).

1. Place the silicone rubber seal over the six­blade assembly, as shown in figure 1.

Figure 1

Six-blade
assembly

Silicone
seal

2. Place the six-blade assembly into the
glass jug and turn clockwise to secure
firmly into position (see figure 2).

Figure 2

Note: The blender jug will leak if the six­blade system is not assembled correctly.

Note: Do not attempt to remove the

stainless steel blades from the blade
assembly.

3. Plug the power cord into a 230-240 volt
power outlet and turn the power ‘ON’.

5

Using your MultiBlender Platinum

1. Place the blender jug onto the motor base.

Note: Do not switch ‘ON’ the MultiBlender

Platinum without the lid in position.

2. Place ingredients into the glass jug. Do
not exceed the maximum indicated level
– 1.6 litres.

3. Position the lid with ingredient cup onto
the blender jug. Ensure the lid is firmly in
place.

4. Using the selector dial, select the desired
blending speed 1, 2, 3 or PULSE.

Settings 1, 2, 3 will provide continuous

blending until the dial is turned off.

The Blending Guide on page 8 shows the

functions that can be performed and the
suggested speeds to use.

Note: Although the lid fits firmly to the

glass jug, we advise when blending liquid
ingredients, to place your hand on the lid
as you initially select the blending speed/
function. As the powerful 800 watt motor
could cause the liquid to surge up causing
leakage. Once you have started blending
you can remove your hand.

Note: Do not operated for more than 2

minutes at a time.

Further ingredients can also be added

whilst blending by removing the ingredient
cup and pouring ingredients through the
hole in the lid.

5. After you have completed blending, turn
the control dial off.

Note: When removing the six-blade

assembly from the glass jug you may need
to slightly tilt the blade so that it slides
out easily. You shouldn’t force the blades
out of the glass jug as this will ultimately
damage the blades.

6

Feature uses of the MultiBlender
Platinum

Crushing Ice

Simply add ice to the blender then press the
‘Pulse’ function and hold for 1-2 seconds
and release. Continue this process and in
seconds your ice is fluffy and snow flake-like.

Pulse setting

The pulse function provides short bursts of
power, so that you can prepare breadcrumbs,
grind chocolate, finely grind nuts and
biscuits.

You can also use the Pulse function for
cleaning the blender. Simply pour in some

warm water and a small amount of detergent,
press the ‘Pulse’ function for 1-2 seconds
and release. Repeat 3-4 times. The unit will
clean itself, without you having to handle the
sharp blades. Rinse and dry, being careful as
the blades are sharp.

7

A Guide to your MultiBlender
Platinum

Processing Task Food Suggested Setting Suggested Processing Procedure

Aerating Milkshakes, 2 & 3 Use chilled milk. Blend until desired
Smoothies consistency is achieved.

Chopping Nuts, Chocolate, PULSE Pulse ½ cup at a time, to ensure
Garlic or Herbs evenly sized pieces.

Crumbing Bread Crumbs PULSE & 2 Tear bread roughly. Blend until
desired consistency.

Biscuit Crumbs PULSE & 2 Break into pieces and as desired pulse
or blend until crumbed.

Crushing Ice PULSE Use the PULSE button several times
until crushed as desired consistency.

Emulsifying Salad Dressing 1 Blend until well combined. Oil may
be added to the mixture during
processing through the pouring hole
in the lid.

Mixing Batters, Cakes 1 & 2 Blend ingredients until just combined.
DO NOT OVERPROCESS.

Pureeing Soups, 2 & 3 Blend until smooth.

Vegetables,
Fruits

8
