R |
CORDLESS GRASS SHEAR |
||||
|
|
+ HEDGE TRIMMER |
|||
|
|
7.2-V LITHIUM-ION |
|
||
OPERATOR’S MANUAL |
|
|
|||
|
|
|
|
||
A Division of Snow Joe®, LLC |
Model HJ604C |
|
Form No. SJ-HJ604C-880E-MR5 |
||
IMPORTANT! |
|
|
including children and pets, should be kept a safe |
||
|
|
|
3. Keep bystanders and children away. All bystanders, |
||
Safety Instructions |
|
|
distance away from the work area. |
||
|
Electrical Safety |
||||
All Operators Must Read These |
|||||
1. |
Snow Joe® + Sun Joe® customer service center at |
||||
Instructions Before Use |
If the battery charger cable is damaged, please call the |
||||
2. |
1-866-SNOWJOE (1-866-766-9563). |
||||
Always follow these safety guidelines. Failure to do so may |
If charging the power tool in a damp location is |
||||
result in serious bodily injury or death. |
|
|
unavoidable, use a residual current device (RCD) |
||
General Safety WARNINGS! |
|
protected power supply. The using of an RCD reduces the |
|||
|
risk of electric shock. |
||||
Notice the personal safety alert symbol m used in this manual |
3. Power tool plugs must match the outlet. Never modify |
||||
to draw your attention to a WARNING given along with the |
|
the plug in any way. Do not use any earthed (grounded) |
|||
particular operating instruction. This means that the operation |
|
power tools or battery chargers. Unmodified plugs and |
|||
|
matching outlets will reduce risk of electric shock. |
||||
requires special ATTENTION, CAUTION, and AWARENESS. |
|
||||
4. Avoid body contact with earthed or grounded surfaces |
|||||
When using this power tool, basic safety precautions, including |
|||||
|
such as pipes, radiators, ranges and refrigerators. |
||||
the following, should always be followed to reduce the risk of |
|
||||
|
There is an increased risk of electric shock if your body is |
||||
fire, electric shock, personal injury and material damage. |
|
||||
|
earthed or grounded. |
||||
mWARNING! This unit can be dangerous! Careless or |
5. Do not expose power tools to rain or wet conditions. |
||||
improper use can cause serious injury. |
|
|
Water entering a power tool will increase the risk of |
||
|
|
electric shock. |
|||
mWARNING! The rotating blades can cut you. Keep |
|
||||
6. Do not abuse the charging cord. Never use the cord |
|||||
hands and feet away from the blades and the cutting area. |
|
for carrying, pulling or unplugging the power tool. Keep |
|||
Retain this manual for future reference and reread it at the start |
|
cord away from heat, oil, sharp edges or moving parts. |
|||
|
Damaged or entangled cords increase the risk of electric |
||||
of each trimming season. |
|
|
shock. |
||
mWARNING! This battery-operated power tool must be |
7. |
Battery charger is for indoor use only. Only charge this |
|||
recharged only with the specific charging unit for the battery. A |
|
battery-powered tool indoors. |
|||
Personal Safety |
|||||
charging unit that may be suitable for one type of battery may |
|||||
create a risk of fire when used with another battery type. |
1. Stay alert. Watch what you are doing and use common |
||||
• Avoid accidental starting. |
|
||||
|
|
sense when operating a power tool. Do not use the |
|||
• When the tool is not in use, keep it away from other metal |
|
power tool while you are tired or under the influence of |
|||
objects. |
|
|
drugs, alcohol or medication. A moment of inattention |
||
• Before operating the tool, read the entire manual carefully |
|
while operating power tool may result in serious personal |
|||
|
injury. |
||||
and make sure you know how to switch the tool OFF in an |
|
||||
2. Use personal protective equipment. Always wear eye |
|||||
emergency. |
|
||||
Work Area Safety |
|
|
protection. Protective equipment such as safety glasses, |
||
|
|
a dusk mask, non-skid safety shoes, a hard hat, and |
|||
1. Keep work area clean and well lit. Cluttered and dark |
|
hearing protection, when used for appropriate conditions, |
|||
|
will reduce the possibility of personal injuries. |
||||
areas invite accidents. |
|
|
|||
|
3. Avoid unintentional starting. Ensure the switch is in the |
||||
2. Do not operate power tools in explosive atmospheres, |
|||||
|
OFF position before connecting to the power source/ |
||||
such as in the presence of flammable liquids, gases or |
|
||||
|
battery charger, or before picking up or carrying the tool. |
||||
dust. Power tools create sparks which may ignite the dust |
|
||||
|
Carrying power tools with your finger on the switch or |
||||
or fumes. |
|
|
|||
|
|
charging power tools with the switch ON can lead to |
|||
|
|
|
|
||
© 2019 by Snow Joe®, LLC |
|
|
accidents. |
||
|
|
SAVE THESE INSTRUCTIONS |
|||
All rights reserved. Original instructions. |
|
1 |
|||
|
|
|
|
4.Remove any adjusting key or wrench before starting the power tool. A wrench or a key left attached to a rotating part of the power tool may result in personal injury.
5.Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.
6.Dress properly. Do not wear loose clothing or jewelry. Dangling articles such as these can become caught in moving parts. Using work gloves and substantial footwear is recommended when working outdoors. Wear
a protective hair covering to contain long hair.
7.Use dust-reducing equipment (e.g. dust masks) when available. Using these devices can greatly reduce dust-related hazards.
Power Tool Use and Care
1.Do not force the appliance. It will do the job better with less likelihood of injury if it is used at the rate for which it was designed.
2.Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled by the switch is dangerous and must be repaired.
3.Disconnect the battery pack from the power tool before making any adjustments, changing accessories or storing the power tool. Such preventative safety measures reduce the risk of starting the power tool accidentally.
4.Store idle appliances indoors. When not in use, appliances should be stored indoors in a dry and high or locked-up place out of the reach of children.
5.Maintain appliance with care. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the power tool's operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly maintained power tools.
6.Keep cutting blades sharp and clean. Properly maintained cutting blades with sharp edges are less likely to bind and are easier to control.
7.Use the power tool and accessories in accordance with these instructions and in the manner intended for the particular use of the power tool, taking into account the working conditions and the work to be performed. Using the power tool for operations different from those intended could result in a hazardous situation.
8.Keep all parts of the body away from the cutter blade.
Do not remove cut material or hold material to be cut when blades are moving. Make sure the switch is off when clearing jammed material. A moment of inattention while operating the product may result in serious personal injury.
9.Carry the product by the handle with the cutter blade stopped. When transporting or storing the product always fit the cutting device cover. Proper handling of the product will reduce possible personal injury from the cutter blades.
10.Hold the power tool by insulated gripping surfaces only, because the cutter blade may contact hidden wiring.
Cutter blades contacting a "live" wire may make exposed metal parts of the power tool "live" and could give the operator an electric shock.
11.Check the hedge for foreign objects before operation, e.g. wire fences. Take care that the cutting device does not come into contact with wire or other metal objects.
12.Hold the product properly, e.g. with both hands if two handles are provided. Loss of control can cause personal injury.
Service
1.If your power tool requires service, contact an authorized Snow Joe® + Sun Joe® dealer or call the Snow Joe® + Sun Joe® customer service center at
1-866-SNOWJOE (1-866-766-9563). Only identical replacement parts should be utilized for repairs. This will ensure that the safety of the power tool is maintained.
2.If the battery charger cable is damaged, it must be immediately replaced to avoid a hazard. Contact the Snow Joe® + Sun Joe® customer service center at 1-866-SNOWJOE (1-866-766-9563) for assistance.
Battery Safety Warnings
This manual contains important safety and operating instructions for your battery and charger.
1.Before using the charging, thoroughly read all instructions and cautionary markings on the charger, the telescoping pole, and the cordless grass shear + hedge trimmer.
mWARNING! If the grass shear + hedge trimmer housing is cracked or damaged, do not insert the charging adaptor into the power tool or plug the power tool into the mains outlet.
There is a danger of electric shock or electrocution.
2.This charger is ONLY intended to charge this rechargeable battery. Any other use poses a risk of fire, electric shock or electrocution.
3.Do not place any object on top of the charger or place the charger on a soft surface that may result in excessive internal heat. Keep the charger away from any heat source.
4.To reduce the risk of damaging the electric plug and cord, pull the plug, not the cord, when disconnecting the charger from the electric outlet.
5.Make sure the battery charging cable is located in a safe place so that it will not be stepped on, tripped over or otherwise subjected to damage or stress.
6.An extension cord should not be used unless absolutely necessary. Using an improper extension cord poses a risk of fire, electric shock or electrocution.
2
7.Do not operate the charger if it has received a sharp blow or has become damaged in any way. Contact the Snow Joe® + Sun Joe® customer service center
at 1-866-SNOWJOE (1-866-766-9563) before continuing use.
8.Do not disassemble the charger. If the charger requires service or repair, contact an authorized Snow Joe® + Sun Joe® dealer or call the Snow Joe® + Sun Joe® customer service center at 1-866-SNOWJOE (1-866-766-9563). Incorrect reassembly poses a risk of electric shock, electrocution or fire.
9.To reduce the risk of electric shock, unplug the charger from the outlet before cleaning the unit.
10.Never attempt to connect two (2) chargers together.
11.DO NOT store or use the tool and battery pack in locations where the temperature may reach or exceed 104 ºF (40 ºC). Dangerous storing locations include outdoor sheds or metal buildings in the summer.
12.The charger is designed to operate on standard household electrical power (120 V). Do not attempt to use it with any other voltage!
NOTE: The integrated battery is not fully charged out of the carton. Read the safety instructions and then follow the charging notes and procedures.
13.The longest life and best performance can be obtained if the integrated battery is charged when the air temperature is between 64.4ºF – 75.2ºF (18ºC – 24ºC). Do not charge the battery pack when the air temperature falls below 50ºF (10ºC) or above 104ºF (40ºC). Following these safety measures will prevent damage to the battery pack.
14.Do not incinerate the integrated battery even if it is seriously damaged or completely worn out. The battery can explode in a fire.
15.Battery chemicals cause serious burns – Never let a damaged battery pack contact the skin, eyes or mouth. Under abusive conditions, liquid may be ejected from the battery; avoid contact. Liquid ejected from the battery may cause irritation or burns. If a damaged battery pack leaks battery chemicals, use rubber or neoprene gloves to safely dispose of it. If skin is exposed to battery fluids, wash the affected area with soap and water and rinse with vinegar. If eyes are exposed to battery chemicals, immediately flush with water for 20 minutes and seek medical attention. Remove and dispose of contaminated clothing.
Grass Shear + Hedge
Trimmer Safety Warnings
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
3
Safety Symbols
The following table depicts and describes safety symbols that may appear on this product. Read, understand and follow all instructions on this tool before attempting to assemble and operate.
Symbols |
Descriptions |
Symbols |
Descriptions |
|
|
|
|
|
|
|
|
READ THE OPERATOR'S |
|
|
|
|
MANUAL(S) – Read, understand |
|
SAFETY ALERT – Indicates a |
|
|
and follow all instructions in the |
|
|
|
|
|
precaution, a warning or a danger. |
|
|
|
user manual(s) before attempting |
|
|
|
|
|
||
|
|
to assemble and operate. |
|
|
|
|
|
|
|
|
|
WARNING! Do not expose the |
|
Battery charger contains a |
|
|
unit to rain or wet conditions. |
|
|
|
|
|
safety transformer. |
|
|
|
Keep dry. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Wear protective gloves and |
|
Wear protective, slip-resistant |
|
|
non-slip footwear when using the |
|
footwear during operation to |
|
|
machine and handling debris. |
|
protect feet. |
|
|
|
|
|
|
|
|
|
Risk of Injury. Use safety |
|
|
Only use battery charger indoors. |
|
glasses, hearing protection |
|
|
|
|
and dust mask. |
Thrown objects and rotating |
|
Keep bystanders a safe distance |
||
blade can cause severe injury. |
|
|
|
away from the work area. |
|
|
|||
|
|
|
|
|
DANGER! Keep hands away from |
|
|
|
WARNING! The cutting attachment |
|
|
|
continues to move after the motor |
|
blade. |
|
|
|
|
|
|
|
is switched OFF. |
|
|
|
|
|
4
Know Your Cordless Grass Shear + Hedge Trimmer
1.Grass shear + hedge trimmer handle
2.Safety lock-off button
3.Charge level indicator
4.Power ON/OFF trigger switch
5.Charging socket
6. |
Motor housing |
1 |
|
7. |
Blade cover |
2 |
|
8. |
Grass shear blade sheath |
||
|
|||
9. |
Grass shear blade |
|
|
10. |
Hedge trimmer blade |
6 |
|
11. |
Hedge trimmer blade sheath |
||
|
|||
12. |
Battery charger |
|
|
13. |
Charger plug |
|
|
|
8 |
|
3
4 |
5 |
7 |
Handle back
9
|
10 |
|
12 |
|
|
|
|
|
|
|
|
11 |
|
|
|
|
|
|
13 |
Technical Data |
|
|
Battery Runtime Max |
40 min |
Battery Voltage*............................... |
7.2 |
V |
||
Battery Capacity.............................. |
1.5 |
Ah |
Charging Time Max....................................... |
5 hours |
Battery Type..................................... |
Lithium-ion |
Grass Shear Blade........................................ |
4 in. (10.2 cm) |
|
Charger............................................ |
Included |
Hedge Trimmer Blade................................... |
6 in. (15.2 cm) |
|
Charger Input................................... |
100 – 125 V ~ 50/60 Hz |
Hedge Trimmer Cutting Diameter................. |
0.3 in. (0.8 cm) |
|
Charger Output................................ |
9 V |
0.4 A |
No Load Speed............................................. |
1250 ± 10% rpm |
|
|
|
Weight........................................................... |
2.5 lbs (1.14 kg) |
* Initial no-load voltage, when fully charged, peaks at 8.4 volts; nominal voltage under typical load is 7.2 volts
5
