CORDLESS LAWN + GARDEN MULTI-TOOL SYSTEM

OPERATOR’S MANUAL

A Division of Snow Joe®, LLC Model GTS4001C Form No. SJ-GTS4001C-880E-MR3

IMPORTANT!

Safety Instructions

All Operators Must Read These Instructions Before Use

Always follow these safety guidelines. Failure to do so may result in serious bodily injury or death.

General Safety

WARNING! This appliance is not intended for use

by children or by unassisted, unsupervised persons whose physical, sensory or mental capabilities prevent them from using it safely. Children should be supervised to ensure that they do not play with the appliance.

Before starting up your machine, please check it carefully for

any defects. If you nd any, do not start up your machine.

Contact your authorized Snow Joe call the Snow Joe 1-866-SNOWJOE (1-866-766-9563).

+ Sun Joe® customer service center at

mWARNING! When using the power tool, basic safety

precautions should always be followed to reduce the risk of

re, electric shock, and personal injury. These include:

1. Keep work area clean and well-lit – Cluttered, dark areas invite accidents.

2. Avoid dangerous environments – Do not use the power tool in rain, in damp or wet locations, or in bad weather, especially when there is a risk of lighting. This decreases the risk of being struck by lighting. Do not operate the power tool in gaseous or explosive atmospheres or use

the power tool near ammable or combustible liquids.

Motors in these tools normally spark, and the sparks might ignite fumes.

3. Know your product – Know how to start and stop the machine. Be thoroughly familiar with the controls.

4. Keep children, bystanders, and pets away – All spectators, including pets, should be kept a safe distance away from the work area.

5. Dress properly – Do not wear loose clothing or jewelry. They can get caught in moving parts. Protective rubber gloves and non-slip footwear are recommended when working outdoors.

24-VOLT MAX* | POLE HEDGE TRIMMER | POLE CHAIN SAW | POLE LEAF BLOWER

mCAUTION! – Exercise caution to avoid slipping or

falling. Wear protective footwear that will protect your feet and improve your footing on slippery surfaces.

7. Stay alert – Watch what you are doing. Use common sense. Do not operate the power tool when you are tired,

or under the inuence of alcohol or drugs.

+ Sun Joe® dealer or

8. Do not overreach –

at all times.

9. Avoid unintentional starting – Do not carry the power

tool with your nger on the trigger. Make sure the switch is o before inserting the battery.

10. Use the right appliance – Do not use the power tool for any applications other than those for which it was intended.

11. Blades are sharp – Don't grasp the exposed cutting blades or cutting edges when picking up or holding the power tool.

12. Use two hands – Hold the telescoping pole and handle with both hands to avoid loss of control.

13. Remove the battery – Remove the battery from the power tool when it is not in use, before servicing it, when changing accessories, and when performing any other maintenance task.

14. Use safety glasses – Also use safety footwear, snug-tting clothing, protective gloves, hearing and head protection.

15. Use head protection – Always use head protection when operating the power tool overhead. Falling debris can result in serious personal injury.

16. Do not force the tool – It will perform better with less likelihood of personal or mechanical injury if it is used at the rate for which it was designed.

17. Store indoors – When not in use, the power tool should be stored indoors in a dry and high or locked-up place out of the reach of children.

18. Check for damaged parts – Before further use of the appliance, all guards and parts should be carefully checked to determine that it will operate properly and perform its intended function. Check for alignment of moving parts, binding of moving parts, breakage of parts,

mounting, and any other condition that may aect its

operation. A guard or other part that is damaged should be properly repaired or replaced. Contact the Snow Joe + Sun Joe (1-866-766-9563) for assistance.

customer service center at 1-866-SNOWJOE

Keep proper footing and balance

SAVE THESE INSTRUCTIONS

19. Maintain the power tool with care – Keep the cutting edges sharp and clean for optimal performance and to reduce the risk of injury. Keep the handles dry, clean, and free from oil and grease. Follow the additional recommendations described in the maintenance section of this manual.

20. Do not use the power tool if the switch does not turn it on

and o. Any power tool that cannot be controlled with the

switch is dangerous and must be repaired.

21. Keep all parts of the body away from the cutting blades or chain. Do not remove cut material or hold material to be cut

when blades are moving. Make sure the switch is o when

clearing jammed material. The blades or chain will continue

moving for a while after the tool is turned o. A moment

of inattention while operating the power tool may result in serious personal injury.

22. Carry the power tool by the handle with the cutting blade or chain stopped. When transporting or storing the power tool, always keep the blades or chain bar covered. Proper handling of the garden tool will reduce possible personal injury from the cutting blades or chain.

23. Hold the product by insulated gripping surfaces only, because the cutting blade or chain may contact hidden wiring. Cutting blades or chain contacting a “live” wire may make exposed metal parts of the product “live”and could give the operator an electric shock.

24. The unit has not been designed to provide protection from electric shock in the event of contact with overhead electric lines. Never use the power tool near any electrical power lines. Contact with or use near power lines may cause serious injury or electric shock resulting in death. Maintain a minimum clearance of 50 ft (15 m) from all power lines.

mWARNING! Starting, stopping, and restarting an

electric motor repeatedly within a few seconds can generate a great deal of heat and damage the motor. To protect the life of your cordless power tool, always wait at least ve seconds after stopping before restarting the unit.

mWARNING! Electrical Shock Hazard – Before starting

up your machine, please check it carefully for any defects. If you nd any, do not start up your machine and contact your distributor.

NOTE: Take care of small parts that are removed during assembly or when making adjustments. Keep them secure to avoid loss.

Please contact an authorized Snow Joe or call the Snow Joe at 1-866-SNOWJOE (1-866-766-9563) for all maintenance or operations not foreseen in this manual. Any operation

performed in an unauthorized service center or by unqualied

personnel will completely invalidate the warranty.

+ Sun Joe® customer service center

+ Sun Joe® dealer

mWARNING! For your safety and that of others:

• Correct maintenance is essential to maintain the original eciency and safety of the machine over time.

• Keep all nuts, bolts, and screws tight to be sure the equipment is in safe working condition.

• Never use the machine with worn or damaged parts.

Damaged parts are to be replaced and never repaired.

mWARNING! Always wear protective gloves during

maintenance operations.

mWARNING! Before inspecting, cleaning, or servicing

the machine, remove the battery and wait for all moving parts to stop. Failure to follow these instructions can result in serious personal injury or property damage.

mWARNING! Do not use this appliance without reading

this instruction manual.

mWARNING! Do not use the appliance within range of

persons unless they are wearing protective clothing.

mWARNING! Do not operate the cordless power tool in

a tree, on a ladder, or on a scaold. Using the tool under such

circumstances is extremely dangerous.

mWARNING! Do not let familiarity with this type of tool

prevent you from taking all necessary precautions.

Remember that a careless fraction of a second is sucient to inict serious injury.

mWARNING! The garden tool system must be fully

assembled before operation! Do not use the tool that is only partly assembled or assembled with damaged parts!

mWARNING! Use only original manufacturer’s

replacement parts, accessories and attachments. Failure to do so can cause possible injury and poor performance.

To order genuine replacement parts or accessories for the Sun Joe please visit sunjoe.com or contact the Snow Joe customer service center at 1-866-SNOWJOE (1-866-766-9563).

GTS4001C cordless pole garden tool system,

+ Sun Joe®

Cleaning the Tool

mWARNING! Never let any liquid get inside the motor

housing and NEVER immerse any part of the housing in liquid.

1. Stop the motor and remove the battery.

2. Clean dirt and debris from the body of the tool,

using a damp cloth with a mild detergent.

NOTE: Do not use any strong detergents on the plastic

housing or the handle, as they can be damaged by certain aromatic oils such as pine and lemon, and by solvents such as kerosene.

Storage

Kickback

WARNING! Do not at any time let brake uids, gasoline,

petroleum-based products, penetrating oils, etc., come in contact with plastic parts. Chemicals can damage, weaken, or destroy plastic which may result in serious personal injury.

1. Stop the motor and remove the battery.

2. Clean the garden tool system thoroughly before storing.

3. Always place the blade cover on the blade and bar sheath

on the chain bar before storing or transporting the garden tool system. Use caution to avoid the sharp teeth of the blade and the chain.

4. Store the garden tool system indoors, in a dry place that is inaccessible to children. Keep away from corrosive agents such as garden chemicals and de-icing salts.

5. We recommend using the original package for storage or covering the product with a suitable cloth or enclosure to protect it against dust.

Specic Safety Warnings for Pole Chain Saw

1. Only the pole chain saw operator should be in the

work area.

2. Do not use the pole chain saw to cut down trees.

3. Always use two hands when operating the pole chain saw.

Grip the pole chain saw securely with one hand on the trigger and the other hand on the pole.

4. Before starting the pole chain saw, make sure that the saw chain is not in contact with any object.

5. Do not allow the pole chain saw to make contact with grounded objects such as pipes, fences, and metal posts.

6. Do not force the pole chain saw while cutting. Apply light

pressure. It will perform more eectively and safely if it is

used at the rate for which it was designed.

7. Use extreme caution when cutting a limb that is under tension. When wood tension is released, the limb could spring back and strike the operator, causing severe injury or death.

8. During transport, hold the pole at its balance point, with the guide bar and chain facing to the rear.

9. Do not cut small brush and saplings with the pole chain saw. Small branches may catch in the chain and be whipped towards the operator, which could pull the

operator o balance.

10. Never stand directly under the limb you are trimming. Always position yourself outside the path of falling debris.

11. Keep a rm, steady pressure on the pole chain saw while

cutting. Do not try to cut limbs larger in diameter than the length of the guide bar.

12. Keep other people and pets away from the cutting end of the pole chain saw and at a safe distance away from the work area.

mWARNING! Kickback may occur when the nose or tip

of the guide bar touches an object, or when the wood closes in and pinches the saw chain in the cut.

AVOID CONTACTING THE GUIDE BAR TIP WITH ANY OBJECT. In some cases, when the tip makes contact with an

object, it may cause a fast reverse reaction, kicking the guide bar up and back towards the operator. Pinching the saw chain along the top of the guide bar may also push the guide bar rapidly back towards the operator. Either of these reactions may cause you to lose control of the pole chain saw, which could result in serious personal injury.

• Kickback safety devices on this pole chain saw include

a skip chain and a low kickback guide bar. These will reduce, but not entirely prevent, kickbacks. Follow the necessary precautions indicated in this operator's manual to avoid kickbacks.

• Always use two hands when operating the pole chain saw,

one hand gripping the trigger and the other hand gripping

the pole. Use a rm grip. Thumbs and ngers must wrap

around the trigger and the pole.

• Keep all guards in place on the pole chain saw. Make sure

they are in proper working order.

• Do not overreach or extend arms above shoulder height.

• Keep solid footing and balance at all times.

• Never try cutting through two branches at the same time.

Only cut one at a time.

• Do not bury the guide bar nose or try to cut by boring the

guide bar nose into the wood.

• Watch for shifting of wood or other forces that may pinch

the chain.

• Use extreme caution when re-entering a previous cut.

• Use the low-kickback chain and guide bar supplied with

this pole chain saw. Only use genuine Snow Joe Sun Joe with this pole chain saw.

• Never use a dull or loose chain. Keep the chain sharp and

properly tensioned.

replacement parts designed specically for use

Specic Safety Warnings for Pole Hedge Trimmer

1. Remove any adjusting key or wrench before turning

the power tool on. A wrench or key left attached to the rotating part of the power tool may result in personal injury.

2. Remove any blade that has been damaged. Always make sure that the blade is installed correctly and securely fastened before each use. Failure to do so can cause serious injury.

3. Never cut any material over 0.6 in. (1.5 cm) in diameter.

4. Maintain a rm grip on the handle and the pole while

cutting with the blade. Keep the blade away from body.

5. Use the pole hedge trimmer and accessories in accordance with these instructions, taking into account the working conditions the work to be performed.

Use of the power tool for operations dierent from

intended use could lead to a hazardous situation.

Do not modify or attempt to repair the appliance or the battery pack except as indicated in the instructions for use and care.

Have your battery pack serviced by a qualied repair person

using only identical replacement parts. This will ensure that the safety of the battery pack is maintained.

Specic Safety Warnings for Pole Leaf Blower

1. The blower has been designed to clear light debris and

leaves from hard surfaces – not for clearing grassed areas.

2. When operating the unit, never point the blower nozzle in the direction of people or pets or in the direction of windows. Use extra caution when blowing debris near solid objects, such as trees, automobiles, and walls.

3. Be sure to secure the unit when transporting it.

4. Use extra care when cleaning on stairs.

5. Do not put any object into the tool's openings. Do not use

the tool with any opening blocked; keep openings free of

dust, lint, hair, or any other object that may reduce air ow.

6. Check the work area before each use. Remove all objects such as rocks, broken glass, nails, wire, or string, which can be thrown or become entangled in the machine.

7. Never run the unit without the proper equipment attached.

Always ensure the blower tube is properly installed.

Battery & Charger Safety Instructions

We pay a great deal of attention to the design of every battery pack to ensure that we supply you with batteries that are safe, durable and have a high energy density. The battery cells have a wide range of safety devices. Each individual cell is initially formatted and its electrical characteristic curves are recorded. This data is then used exclusively to be able to assemble the best possible battery packs.

Despite all the safety precautions, caution must always be exercised when handling batteries. The following points must be obeyed at all times to ensure safe use. Safe use can only be guaranteed if undamaged cells are used. Incorrect handling of the battery pack can cause cell damage.

IMPORTANT! Analyses conrm that incorrect use and poor

care of high-performance batteries are the main factors responsible for personal and/or product damage.

mWARNING! Use only approved replacement batteries;

other batteries may damage the power tool and cause it to malfunction, which can lead to serious personal injury.

mCAUTION! To reduce the risk of injury, charge the

24V iON+ lithium-ion battery pack only in its designated 24V iON+ lithium-ion charger. Other types of chargers present

risk of re, personal injury and damage. Do not wire a battery

pack to a power supply plug or car cigarette lighter. Such misuse will permanently disable or damage the battery pack.

• Avoid dangerous environments – Do not charge the battery pack in rain, snow or in damp or wet locations. Do not use the battery pack or charger in the presence of

explosive atmospheres (gaseous fumes, dust or ammable

materials) because sparks may be generated when inserting

or removing the battery pack, which could lead to a re.

• Charge in a well-ventilated area – Do not block the

charger vents. Keep them clear to allow for proper

ventilation. Do not allow smoking or open ames near a

charging battery pack. Vented gases may explode.

NOTE: The safe temperature range for the battery is

40°F (4.5°C) to 105°F (40.5°C). Do not charge the battery outside in freezing weather; charge it at room temperature.

• Maintain charger cord – When unplugging the charger, pull the plug, not the cord, from the receptacle to reduce the risk of damage to the electrical plug and cord. Never carry the charger by its cord or yank it by the cord to disconnect it from the receptacle. Keep the cord away from heat, oil and sharp edges. Make sure the cord will not be stepped on, tripped over or subjected to damage or stress when the charger is in use. Do not use the charger with a damaged cord or plug. Replace a damaged charger immediately.

• Do not use an extension cord unless it is absolutely necessary – Using the wrong, damaged or improperly

wired extension cord poses a risk of re and electric shock.

If an extension cord must be used, plug the charger into a properly wired 16 gauge or larger extension cord with the female plug matching the male plug on the charger. Make sure that the extension cord is in good electrical condition.

• Charger 24VCHRG-AC is rated for 100 – 240 volt AC only – The charger must be plugged into an appropriate

receptacle.

• Use only recommended attachments – Use of an attachment not recommended or sold by the battery charger or battery pack manufacturer may result in risk

of re, electric shock or personal injury.

• Unplug charger when not in use – Make sure to remove

battery packs from unplugged chargers.

mWARNING! Do not use a battery pack or appliance that

is damaged or modied. Damaged or modied batteries may exhibit unpredictable behavior resulting in re, explosion or risk

of injury.

mWARNING! To reduce the risk of electric shock,

always unplug the charger before performing any cleaning

or maintenance. Do not allow water to ow into the charger.

Use a Ground Fault Circuit Interrupter (GFCI) to reduce shock hazards.

• Do not burn or incinerate battery packs – Battery packs may explode, causing personal injury or damage. Toxic fumes and materials are created when battery packs are burned.

• Do not crush, drop or damage battery packs – Do not use the battery pack or charger if they have sustained a sharp blow, been dropped, run over or have been damaged in any way (i.e. pierced with a nail, hit with a hammer, stepped on, etc.).

• Do not disassemble – Incorrect reassembly may pose a serious risk of electric shock, re or exposure to toxic

battery chemicals. If the battery or charger are damaged, contact an authorized Snow Joe call the Snow Joe

+ Sun Joe® customer service center at

+ Sun Joe® dealer or

1-866-SNOWJOE (1-866-766-9563) for assistance.

• Battery chemicals cause serious burns – Never let a damaged battery pack contact the skin, eyes or mouth. If a damaged battery pack leaks battery chemicals, use rubber or neoprene gloves to safely dispose of it. If skin is

exposed to battery uids, wash the aected area with soap

and water and rinse with vinegar. If eyes are exposed to battery chemicals, immediately ush with water for 20 minutes and seek medical attention. Remove and dispose of contaminated clothing.

• Do not short circuit – A battery pack will short circuit if a metal object makes a connection between the positive and negative contacts on the battery pack. Do not place a battery pack near anything that may cause a short circuit, such as paper clips, coins, keys, screws, nails and other metallic objects. A short-circuited battery pack poses a risk

of re and severe personal injury.

• Store your battery pack and charger in a cool, dry

place – Do not store the battery pack or charger where temperatures may exceed 105ºF (40.5ºC), such as in direct sunlight or inside a vehicle or metal building during the summer.

Information about the battery

1. The battery pack supplied with your cordless power tool is

only partially charged. The battery pack has to be charged

completely before you use the tool for the rst time.

2. For optimum battery performance, avoid low discharge

cycles by charging the battery pack frequently.

3. Store the battery pack in a cool place, ideally at 59°F (15°C) and charged to at least 40%.

4. Lithium-ion batteries are subject to a natural aging process. The battery pack must be replaced at the latest when its capacity falls to just 80% of its capacity when new. Weakened cells in an aged battery pack are no

longer capable of meeting the high power requirements

needed for the proper operation of your garden tool system, and therefore pose a safety risk.

5. Do not throw battery packs into an open re as this poses

a risk of explosion.

6. Do not ignite the battery pack or expose it to re.

7. Do not exhaustively discharge batteries. Exhaustive

discharge will damage the battery cells. The most common cause of exhaustive discharge is lengthy storage or non-use of partially discharged batteries. Stop working as soon as the performance of the battery falls noticeably or the electronic protection system triggers. Place the battery pack in storage only after it has been fully charged.

8. Protect batteries and the tool from overloads. Overloads

will quickly result in overheating and cell damage inside

the battery housing even if this overheating is not apparent externally.

9. Avoid damage and shocks. Immediately replace batteries that have been dropped from a height of more than 3 feet (1 meter) or those that have been exposed to violent shocks, even if the housing of the battery pack appears to be undamaged. The battery cells inside the battery may

have suered serious damage. In such instances, please

read the waste disposal information for proper battery disposal.

10. If the battery pack suers overloading and overheating, the integrated protective cuto will switch o the equipment for safety reasons.

IMPORTANT! Do not press the ON/OFF switch any more

if the protective cut-o has been activated. This may

damage the battery pack.

11. Use only original battery packs. The use of other batteries

poses a re risk and may result in injuries or an explosion.

Information about the charger and the charging process

1. Please check the data marked on the rating plate of the

battery charger. Be sure to connect the battery charger to a power supply with the voltage marked on the rating

plate. Never connect it to a dierent mains voltage.

2. Protect the battery charger and its cord from damage. Keep the charger and its cord away from heat, oil and sharp edges. Have damaged cords repaired without delay

by a qualied technician at an authorized Snow Joe

Sun Joe

dealer or call the Snow Joe® + Sun Joe® customer service center at 1-866-SNOWJOE (1-866-766-9563).

3. Electrical plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with

grounded appliances. Unmodied plugs and matching

outlets will reduce the risk of electric shock.

4. Keep the battery charger, battery pack(s) and the cordless tool out of the reach of children.

5. Do not use the supplied battery charger to charge other cordless tools.

6. During periods of heavy use, the battery pack will become warm. Allow the battery pack to cool to room temperature before inserting it into the charger to recharge.

7. Do not overcharge batteries. Do not exceed the maximum charging times. These charging times only apply to

discharged batteries. Frequent insertion of a charged or

partially charged battery pack will result in overcharging and cell damage. Do not leave batteries in the charger for days on end.

8. Never use or charge batteries if you suspect that it has been more than 12 months since the last time they were charged. There is a high probability that the battery pack

has already suered dangerous damage (exhaustive

discharge).

9. Charging batteries at a temperature below 50°F (10°C) will

cause chemical damage to the cells and may cause a re.

10. Do not use batteries that have been exposed to heat during the charging process, as the battery cells may have

suered dangerous damage.

11. Do not use batteries that have suered curvature or

deformation during the charging process or those that exhibit other atypical symptoms (gassing, hissing, cracking, etc.).

12. Never fully discharge the battery pack (maximum recommended depth of discharge is 80%). A complete discharge of the battery pack will lead to premature aging of the battery cells.

8. Prevent the lithium-ion battery pack from freezing. Battery packs that were stored below 32°F (0°C) for more than 60 minutes must be discarded.

9. When handling batteries, be wary of electrostatic charge. Electrostatic discharges can damage the electronic protection system and the battery cells. Avoid electrostatic charging and never touch the battery poles.

Protection from environmental inuences

1. Wear suitable work clothes. Wear safety goggles.

2. Protect your cordless tool and the battery charger from

moisture and rain. Moisture and rain can cause dangerous cell damage.

3. Do not use the cordless tool or the battery charger near

vapors and ammable liquids.

4. Use the battery charger and cordless tools only in dry conditions and at an ambient temperature of 40°F – 105°F (4.5°C – 40.5°C).

5. Do not keep the battery charger in places where the temperature is liable to reach over 104°F (40°C). In particular, do not leave the battery charger in a car that is parked in the sunshine.

6. Protect batteries from overheating. Overloads, overcharging and exposure to direct sunlight will result in overheating and cell damage. Never charge or work with batteries that have been overheated – replace them immediately, if possible.

7. Store the charger and your cordless tool only in dry locations with an ambient temperature of 40°F – 105°F (4.5°C – 40.5°C). Store your lithium-ion battery pack in a cool, dry place at a temperature of 50°F – 68°F (10°C – 20°C). Protect the battery pack, charger and cordless tool from humidity and direct sunlight. Only place fully charged batteries in storage (charged to at least 40%).

Safety Symbols

The following table depicts and describes safety symbols that may appear on this product. Read, understand, and follow all instructions on the machine before attempting to assemble and operate.

Symbols SymbolsDescriptions Descriptions

READ THE OPERATOR'S MANUAL(S) – Read, understand,

and follow all instructions in the user manual(s) before attempting to assemble and operate.

WARNING! Do not expose the unit to rain or wet conditions. Keep dry.

SAFETY ALERT – Indicates a precaution, a warning, or a danger.

WEAR EYE AND HEARING PROTECTION – For protection

against injury, wear ear defenders and safety goggles.

50 ft

(15 m)

Wear protective gloves and non-slip footwear when using the machine and handling debris.

WARNING! SHOCK HAZARD –

Keep at least 50 ft (15 m) away from power lines. Do not overreach. Keep proper footing and balance at all times.

Thrown objects and rotating blade can cause severe injury.

Indoor use only. Only use battery charger indoors.

DANGER! ROTATING BLADES – Keep hands and feet away from

openings while the saw is running.

Keep bystanders a minimum distance of 50 ft (15 m) away from the work area.

Know Your Cordless Pole Garden Tool System

Read the owner’s manual and safety instructions carefully before operating the cordless garden care system. Compare the illustration below to the cordless garden tool system in order to familiarize yourself with the location of the various controls and adjustments. Save this manual for future reference.

1. Hedge trimmer blade cover

2. Hedge trimmer head

3. Lock tab

4. Rotating button

5. Hedge trimmer blade

6. Blower tube

7. Blower tube lock tab

8. Blower head 18

9. Telescoping pole

10. Soft grip

11. Handle

12. Safety lock switch

13. On/O switch

14. Battery compartment

15. Telescoping lock

16. Assembly lock

17. Air vent

18. 24V iON+ lithium-ion charger (24VCHRG-AC)

19. Charger plug

20. Charge socket

21. Push button for battery indicator

22. Battery indicators

23. Push lock button

24. 24V iON+ lithium-ion battery (24VBAT-LTE)

featuring exclusive EcoSharp

technology

20 21

3 4

15 16

Bottom of the blower head

3 4

Back of the chain saw head

25. Chain saw head

26. Oil cap

27. Chain saw bar sheath

28. 8 in. cutting chain

29. 8 in. guide bar

30. Chain tensioner ring

31. Chain/sprocket end cover knob

32. Chain/sprocket end cover

33. Oil level window

3031

2829

Technical Data

Motor .......................................... hedge trimmer: 250 W

....................................................pole saw: 350 W

....................................................leaf blower: 300 W

Battery Voltage* ..........................24 V D.C.

Battery Capacity ......................... 2.0 Ah

Battery Charge Time Max...........80 min

Battery Run Time Max ................ 40 min for pole chain saw

....................................................55 min for pole hedge trimmer

....................................................17 min for pole leaf blower

Charger Input..............................100 – 240 V 50/60Hz

Charger Output ...........................26 V DC 1.5 A

Chain saw Bar/Chain Length......8 in. (20.3 cm)

Chain Saw Cutting Thickness ....Max: 7.5 in. (19 cm)

....................................................

*Initial no-load voltage, when fully charged, peaks at 24 volts; nominal voltage under typical load is 21.6 volts.

Recommended: 6.5 in. (16.5 cm)

Chain Saw Oil Tank Capacity ..........................2.7  oz (80 ml)

Chain Saw Overhead Reach ...........................7.2 ft (2.2 m)

Chain Saw Head Angles ..................................0° to 30°

Hedge Trimmer Blade Length .........................17.7 in. (45 cm)

Hedge Trimmer Cutting Diameter ....................0.6 in. (1.5 cm)

Hedge Trimmer Head Angles ..........................-45° to 90°

Blower Air Speed Max .....................................124 MPH

Blower Air Flow Max .......................................440 CFM

Blower Head Angles ........................................-30° to 105°

Telescoping Pole Length .................................3.7 ft to 5.3 ft

.........................................................................(1.1 m to 1.6 m)

Weight (pole chain saw + battery) ...................7.7 lbs (3.5 kg)

Weight (pole leaf blower + battery) ..................6.2 lbs (2.8 kg)

Weight (pole hedge trimmer + battery) ............7.7 lbs (3.5 kg)

Unpacking

Carton Contents

• Telescoping pole

• Chain saw head with chain and bar pre-mounted

• Chain saw bar sheath

• Hex key wrench

• Hedge trimmer head with blade

• Hedge trimmer blade sheath

• Leaf blower head

• Blower tube

• 24V iON+ lithium-ion battery

• 24V iON+ lithium-ion charger

• Manuals with registration card

1. Carefully remove the garden tool system and check to see that all of the above items are supplied.

2. Inspect the product carefully to make sure no breakage or

damage occurred during shipping. If you nd damaged or

missing parts, DO NOT return the unit to the store. Please call the Snow Joe

1-866-SNOWJOE (1-866-766-9563).

NOTE: Do not discard the shipping carton and packaging

material until you are ready to use your new cordless garden tool system. The packaging is made of recyclable materials. Properly dispose of these materials in accordance with local regulations.

IMPORTANT! The equipment and packaging material are not toys. Do not let children play with plastic bags, foils, or small parts. These items can be swallowed and pose a

suocation risk!

+ Sun Joe® customer service center at

Battery + Charger

Battery Pack Operation

The equipment is powered by a lithium-ion battery. The battery

pack is completely sealed and maintenance free.

Light IndicatorsLights

Charge level button

The battery is at 30% capacity

and requires charging

The battery is at 60% capacity

and requires charging soon

The battery is at full capacity

NOTE: If the charge level button does not appear to be working, insert the charger and charge as needed.

NOTE: Immediately after using the battery pack, the charge level button may display a lower charge than it will if checked a few minutes later. The battery cells “recover” some of their charge after resting.

Charger Operation

WARNING! Charge only 24V iON+ lithium-ion battery

packs with its compatible 24V iON+ lithium-ion charger. Other types of batteries may cause personal injury and damage.

To reduce the risk of electric shock, do not allow water to ow

into the charger's AC/DC plug.

When to Charge the iON+ 24VBAT-LTE Lithium-iON Battery

NOTE: The iON+ 24VBAT-LTE lithium-ion battery packs do

not develop a "memory" when charged after only a partial discharge. Therefore, it is not necessary to run down the battery pack before inserting the charger plug.

• Use the battery indicator lights to determine when to charge

your iON+ 24VBAT-LTE lithium-ion battery pack.

• You can "top-o" your battery pack's charge before starting

a big job or after a long day of use.

Battery Charge Level Indicator

The battery pack is equipped with a push button for checking the charge level. Simply press the push button to read o the battery charge level from the LEDs of the battery indicator:

• All 3 level monitoring LEDs are lit: Battery charge level

is high.

• 2 level monitoring LEDs are lit: Battery charge level is

decreasing. Stop work as soon as possible.

• 1 level monitoring LED is lit: Battery is at. Stop work

IMMEDIATELY and charge the battery. Otherwise the battery’s service life will be greatly shortened.

Charging the Battery

1. Push the push lock button on the battery to pull the battery pack out from the battery compartment (Fig. 1).

IMPORTANT! Never allow the battery pack to become fully discharged as this will cause irreversible damage to the battery.

Fig. 1

Push button

2. Check that the mains voltage is the same as that marked

on the rating plate of the battery charger. Then, plug the charger adaptor into an appropriate AC power outlet. Connect the charger plug into the charge socket of the battery to start charging (Fig. 2).

Fig. 2

Battery indicators

Pole Chain Saw

Assembly

DANGER! Never start the motor before installing the

guide bar, chain, and chain/sprocket end cover. Without all

these parts in place, the clutch can y o or explode, exposing

the user to potentially serious injuries.

Installing/Replacing Guide Bar And Cutting Chain

Tools and supplies required:

• Hex key wrench (provided)

• Heavy-duty work gloves

NOTE: When replacing the guide bar and chain, use only identical replacement parts. Make sure the pole chain saw is disconnected with the battery before proceeding with installation.

1. Remove the hex bolt by screwing it counterclockwise with the hex key wrench (Fig. 3).

Fig. 3

3. The battery will take approximately 80 minutes to charge.

The battery indicator LEDs will twinkle and illuminate one by one during the charging process. Unplug the charger immediately when the 3 LEDs are all illuminated.

mCAUTION! FIRE HAZARD. When disconnecting the

charger from the battery, be sure to unplug the charger from

the outlet rst, then disconnect the charger from the battery

mWARNING! This charger does not automatically

turn o when the battery is fully charged. Please take care not to leave the battery plugged into the charger. Switch

o or unplug the charger at the mains when charging is

complete.

4. Timely recharging of the battery will help prolong the

battery's life. You must recharge the battery pack when

you notice a drop in the equipment's power.

Chain/sprocket end cover

2. Screw the chain/sprocket end cover knob

counterclockwise to release chain/sprocket end cover (Figs. 4 – 5).

Fig. 4

Chain/sprocket end cover

Hex key wrench

Hex bolt

Chain/sprocket end cover knob

Fig. 5

Chain/sprocket end cover

3. Remove the bar and chain from the mounting surface

(Fig. 6).

NOTE: Make certain of the direction of the chain

If the chain is mounted backwards, the saw will vibrate abnormally and will not cut.

Fig. 8

Fig. 6

Guide bar

Cutting chain

4. Remove the old chain from the bar.

5. Lay out the new saw chain in a loop and straighten any kinks. THE SHARP SIDE OF THE TEETH MUST FACE AWAY FROM YOU IN THE DIRECTION OF THE CHAIN ROTATION INDICATED ON THE GUIDE BAR

. If

the teeth face backwards, turn the loop over (Fig. 7).

Fig. 7

Sharp cutting edge

Fig. 9

Loop

7. Hold the chain in position on the bar and place the loop

around the sprocket. Fit the bar ush against the mounting surface so that the bar studs are in the long slot of the bar and the adjusting pin is in the chain tension pin hole (Fig. 10).

Fig. 10

Adjusting pin

Chain drive link

Chain rotation

6. Starting at the tip, mount the chain drive links into the

bar groove, leaving a loop at the back of the bar. The chain will loosely t until it is placed on the sprocket (Figs. 8 – 9).

Sprocket

Chain tension pin hole

8. Replace the chain/sprocket end cover by positioning the

cover onto the saw head. Tighten the end cover knob, but leave the bar free to move for tension adjustment. Put back the hex bolt by screwing it clockwise with the hex key wrench.

9. Remove all slack from the chain by turning the chain tensioner ring clockwise until the chain seats snugly against the bar with the drive links in the bar groove (Fig. 11).

NOTE: The chain is correctly tensioned when there is no

sag on the underside of the guide bar; the chain is snug,

but can be rotated by hand without binding. For more

information on chain tensioning, see the maintenance section beginning on pg. 15.

Fig. 11

3. To remove the chain saw head, release the On/O switch

and remove the battery. Unlock the assembly lock. Push the lock tabs on both sides, and pull the chain saw head out (Fig. 13).

Operation

Starting and Stopping

1. Slide the battery into the battery compartment until it

clicks to lock it into position (Fig. 14).

Chain/sprocket end cover

Chain tensioner ring

Connecting to the Telescoping Pole

1. Open the assembly lock on the telescoping pole, and

push the chain saw head into the opening on the end of the pole (Fig. 12).

Fig. 12

Chain saw head

Assembly lock

Telescoping pole

2. When the lock tabs snap in, lock back the assembly lock,

the pole chain saw will be ready to use (Fig. 13).

Fig. 13

Lock tab

Fig. 14

Battery

2. To turn the pole chain saw ON, push and hold the safety

lock switch (located on the handle) forward with your

thumb and then squeeze the On/O switch with your ngers. Once the tool is running, you can release the

safety lock switch (Fig. 15).

Fig. 15

Safety lock switch

On/O switch

3. To turn the tool OFF, release the On/O switch (Fig. 15).

Adjusting the Telescoping Pole

This machine is equipped with a telescoping pole which

provides up to 7.2 ft (2.2 m) of overhead reach. To adjust the telescoping pole, follow the instructions below.

1. Disconnect the saw from the power supply by removing the battery from the compartment.

2. Unclip the telescoping lock to release the pole. Extend the pole to the desired length (Fig. 16).

NOTE: Push poles toward each other to shorten the pole

or pull them away from each other to lengthen the pole. Only extend the pole to the minimum length required to reach the limb.

Assembly lock

Fig. 16

Pull Pull

Telescoping lock

3. Lock the pole in position by closing the telescoping lock

(Fig. 17), and ensure that the pole is secured.

Fig. 17

Fig. 19

Front Side

Rotating button

2. Release the buttons when the chain saw head is set to the

desired angle.

NOTE: Failure to properly secure the chain saw head may

result in personal injury and/or property damage.

Back Side

Rotating button

Telescoping lock

mWARNING! Failure to lock the telescoping lock as

directed could result in personal injury.

Adjusting the Multi-Angle Head

The pole chain saw head can be rotated for dierent cutting

angles for 0º, 15º, and 30º (Fig. 18). Follow the below instructions to adjust angles.

Fig. 18

0º

15º

30º

1. Rotate the chain saw head to the desired cutting angle

while pressing the rotating buttons located on both sides simultaneously (Fig. 19).

mWARNING! Always ensure the chain saw head is

securely locked! Do not attempt to use the pole chain saw with the head in any other position or unlocked!

Cutting Tips for Pole Chain Saw

mCAUTION!

• Before starting the saw, remove the oil tank cap and add bar & chain oil to the top of the oil level window (Fig. 20). One minute of use will consume approximately 0.15  oz

(4 ml) of oil. Rell when the oil level drops to 1/4 of a tank.

NOTE: Your pole chain saw head is equipped with an

automatic oil pump for bar and chain oiling. You must add bar and chain oil or your pole chain saw will not function.

Fig. 20

Oil level window

Oil tank cap

mWARNING! Be sure that the chain is not in contact with

any object when you start the motor.

mWARNING! Keep hands away from chain. Keep hands

on handles. Do not overreach.

A good, rm grip on the tool using both hands will help you

maintain control. Place one hand on the soft grip or the telescoping pole, and the other hand on the handle with your

thumbs and ngers encircling the pole and handle. A rm grip

combined with proper positioning of the handle against your body will help you maintain control of the saw. Do not let go of the saw while it is in operation.

mCAUTION! The chain will continue to run for several

seconds after turning o the tool.

Do not use the pole chain saw under wet conditions. Use extreme caution when cutting small brush, saplings, or limbs under tension because slender and tense material may catch

the saw and be whipped toward you, pull you o balance, or

spring back.

Do not use the pole chain saw to cut vines and/or small underbrush.

Prior to each cutting session, run through the daily checklist (see pg. 18).

mWARNING! Do not cut trees near electrical wires. mWARNING! Failure to lubricate the chain will cause

damage to the bar and chain. Use only a good quality bar and chain oil designed specically for use with chain saws. One minute of use will consume approximately 0.15  oz.

(4 ml) of oil.

NOTE: It is normal for oil to seep from the saw when not in use. To prevent seepage, empty the oil tank after each use. When storing the unit for a long period of time (3 months or longer), be sure the chain is lightly lubricated; this will prevent rust on the chain and bar sprocket.

Proper Cutting Stance

• Balance your weight with both feet on solid ground.

• Your body should always be to the left of the chain line.

• The most typical cutting application is to position the unit at an angle of 60° or less depending on the specic

situation (Fig. 22). As the angle of the pole chain saw shaft to the ground increases, the diculty of making the rst cut (from the underside of limb) increases.

Fig. 22

60º MAXIMUM

Fig. 21

KICKBACK DANGER ZONE

mWARNING! Kickback may occur when the moving

chain contacts an object at the upper portion of the tip of the guide bar or when the wood closes in and pinches the chain saw in the cut (Fig. 21). Contact at the upper portion of the tip of the guide bar can cause the chain to dig into the object and stop the chain for an instant. The result is a lightning-fast reverse reaction, which kicks the guide bar up and back toward the operator. If the chain saw is pinched along the top of the guide bar, the guide bar can be driven rapidly back toward the operator. Either of these reactions can cause loss of saw control, which can throw the operator

o balance and result in serious injury. Do not rely exclusively

upon the safety devices built into the saw. As a user, you should take several precautions to keep your cutting jobs free from accident or injury.

Basic Cutting Procedure

This unit with the chain saw head is designed for trimming small branches and limbs up to recommended 6.5 in. (16.5 cm), not to exceed a Max. cut of 7.5 in. (19 cm) in diameter depending on type of wood. Practice cutting a few

small limbs using the following technique to get the “feel” of

using the saw before you begin a major sawing operation.

• Take the proper stance in front of the tree with the saw OFF (Fig. 22).

• Squeeze the On/O switch and let the chain accelerate to full speed before entering the cut.

• Keep the saw running the entire time you are cutting;

maintain a steady speed.

• Allow the chain to cut for you; exert only light downward pressure. If you force the cut, damage to the bar, chain, or unit can result.

• PUSH and PULL – This reaction force is always opposite to the direction the chain is moving when it is in contact with the wood. Thus, the operator must be ready to control the PULL when cutting on the bottom edge of the bar, and PUSH when cutting along the top edge.

• Do not put pressure on the saw at the end of the cut.

Pruning

Pruning is the process of trimming limbs from a live tree.

• Remove long branches in several stages.

• Cut lower branches rst to allow the top branches more

room to fall.

• When pruning trees, it is important not to make the nishing cut next to the main limb or trunk until you have cut o the farthest lying limb. This will reduce the weight

and prevent stripping the bark from the main member.

• Under cut the branch 1/3 through for your rst cut. Your second cut should over cut to drop the branch o

(Fig. 23). Be prepared to balance the weight of the pole chain saw when the limb falls.

Limbing

Limbing is the process of removing branches from a fallen tree.

• You should cut limbs one at a time. Remove the cut limbs from the work area often to help keep the work area clean and safe.

• Cut branches under tension from the bottom up to avoid binding the bar and chain.

• Keep the tree between you and the pole chain saw while limbing. Cut from the side of the tree opposite the branch you are cutting.

If the Saw Becomes Pinched or Trapped

1. Wait for the blade to stop, wait ve minutes for the saw to

cool, remove the battery, and wear gloves to protect your hands from the chain teeth.

2. If you can reach the limb from the ground, lift the limb while holding the saw. This should release the “pinch” and free the saw.

3. If the saw is still trapped, call a professional for assistance.

Load

Second Cut

First Cut 1/3 Diameter

Finishing Cut

Fig. 23

9. When re-starting the motor, always keep the ON/O

switch pressed.

NOTE: The motor only runs when the ON/O switch

is operated and shuts o when the ON/O switch is released.

• Now make your nishing cut from the topside of the

branch smoothly and neatly against the main member so the bark will grow back to seal the wound.

• Release the On/O switch as soon as the cut is completed. Failure to follow proper cutting procedures will result in the bar and chain binding and becoming pinched or trapped in the limb.

Maintenance + Care

WARNING! Always remove the battery before

performing any adjustments, maintenance, or repairs to your cordless pole chain saw.

• Use protective gloves when handling the bar and chain.

• Keep the bar encased in its sheath, except when working

directly on the bar or the chain.

• Never dispose of oils or other polluting materials in unauthorized places.

Chain Tension

Check the chain tension before using the saw when the chain is cold. The correct tension of a cold chain is when there is no slack on the underside of the guide bar; the chain is snug, but you can rotate it by hand without binding.

During normal saw operation, the temperature of the chain will increase. The drive links of a correctly tensioned warm chain will hang approximately 0.050 in. (1.25 mm) out of the bar groove (Fig. 23). Be aware that a chain tensioned while warm, may be too tight upon cooling. Check the “cold tension” before

next use. The chain must be re-tensioned whenever the ats

on the drive links hang out of the bar groove (Fig. 24).

Fig. 24

Flats are not visible here

Properly Adjusted Warm Chain

Approximately 0.050 in. (1.25 mm)

Chain Needs Tensioning

Flats are visible here

NOTE: A new chain tends to stretch. Check the chain tension

frequently and re-tension as needed.

Nuts and Screws

Periodically check that all the nuts and screws are tightened securely. Check that the telescoping lock and assembly lock are intact and in proper working order.

Sharpen the chain as follows (Fig. 25):

• Secure the bar rmly, with the chain mounted, in a

suitable vise.

• Tighten the chain if it is loose.

• Mount the le in the guide and then insert it in the tooth at

a constant angle from the cutting edge.

• Sharpen in a forward motion a few times and repeat this on all the cutting edges facing the same way (right or left).

• To move the chain forward, use a screwdriver.

• Turn the bar over in the vise and repeat on all the other

cutting edges.

• Check that the depth limiter tooth does not stick out farther than the inspection tool and le any projecting

parts with a at le, rounding o the edges (Fig. 25).

• After sharpening, remove all traces of ling and dust

and lubricate the chain in an oil bath. Replace the chain

whenever:

– The length of the cutting edges decreases to 5 mm

or less;

– There is too much play between the links and the rivets.

Chain Sharpening

mWARNING! To ensure that the saw works safely and

eciently, it is essential that the cutting components are

well-sharpened. It is highly recommended to replace the chain once it loses its ability to cut cleanly and safely.

It is possible, however, to sharpen the existing chain if the sharpening is carefully performed. Any work on the chain

and bar requires specic experience and special tools. For

safety purposes, we recommend you contact an authorized Snow Joe Sun Joe (1-866-766-9563).

Sharpening is necessary when:

• The sawdust looks like dust;

• Cutting becomes more dicult;

• The cut is not straight;

• Vibrations increase.

An authorized service center will sharpen the chain using the right tools to ensure minimum removal of material and even sharpness on all the cutting edges.

If you sharpen the chain yourself, use special round-section

les with the right diameter depending on the type of chain

(see “Chain Maintenance Table” on pg. 17). You need a certain amount of skill and experience to avoid damaging the cutting edges.

+ Sun Joe® dealer or call the Snow Joe® +

customer service center at 1-866-SNOWJOE

Fig. 25

Cutting edge

Inspection tool

Depth limiter tooth

Guide Bar Maintenance

When the guide bar shows signs of wear, turn it over on the saw to distribute the wear for maximum bar life. Feathering or burring of the bar rails is a normal process of bar wear. You

should smooth such faults with a le as soon as they occur.

Replace a bar with any of the following faults:

• wear inside the bar rails permitting the chain to

lay over sideways

• bent guide bar

• cracked or broken rails

• spread rails

Turn the saw over, check the underside of the guide bar, and make sure that the lubrication holes and chain groove are free from impurities.

Chain Sprocket

Regularly check the condition of the sprocket and replace it when wear exceeds 0.5 mm (Fig. 26).

Do not mount a new chain with a worn sprocket or vice-versa.

Troubleshooting

Troubleshooting Tips

Most diculties are easy to x. Consult the troubleshooting

table for common problems and their solutions. If you continue to experience problems or need repairs beyond these minor adjustments, please call 1-866-SNOWJOE (1-866-766-9563) for assistance.

mWARNING! Always remove the battery before

performing any adjustments, maintenance, or repairs to your cordless chain saw.

Troubleshooting Table

Problems Corrective Action

The saw motor fails to start

• Check that you have inserted the battery properly

and the battery has enough power to work.

• Make sure that you fully depress, push forward

and hold the safety lock switch before squeezing

the ON/OFF trigger switch.

Fig. 26

< 0.5 mm

Chain Maintenance Table

Drive Links Chain Pitch Chain Gauge

The saw runs, but the chain speed is low

Bar and chain running hot and smoking

The saw motor runs, but the chain is not turning

• The chain is too tight; re-tension.

• The chain tension is too tight; re-tension.

• The chain oil tank is empty; rell.

• The lubrication holes are plugged; clean them out.

• The chain tension is too tight; re-tension.

• The guide bar or chain is damaged; inspect

and replace the damaged part.

File Diameter

inches mm

3/8

9.5 0.050 1.3 45/32

inches

mm inches mm

Daily Checklist, Cleaning and Storage

Pole Leaf Blower

Daily Checklist

To help maintain your pole chain saw for optimum performance, we recommend you complete this checklist prior to each work session.

mWARNING! Do not insert the battery until you have

completed all of the daily checks.

• Inspect for any visible damage to the chain, guide bar, or

motor housing.

• Inspect the oil port and guide bar rails and clean them to

remove any debris.

• Check the chain tension.

• Check the chain teeth for sharpness.

• Check the bar and chain oil level; ll with only new chain oil specically formulated for chain saws.

NOTE: If you notice anything unusual, such as a vibration or an odd sound, shut the saw OFF immediately. Remove the battery and check the saw for any damage.

If you cannot nd the cause of the problem or are uncertain

what to do, then have the saw inspected by an authorized Snow Joe Sun Joe (1-866-766-9563) before using it.

+ Sun Joe® dealer or call the Snow Joe® +

customer service center at 1-866-SNOWJOE

Assembly

WARNING! To prevent serious personal injury, make

sure the battery is removed and the impeller has come to a complete stop before attaching or removing tubes.

Attaching the Blower Tube

1. Inserting the blower head into the blower tube until the

blower tube lock tab snaps in (Fig. 27).

Fig. 27

Blower tube

Tube lock tab

Leaf blower head

mCAUTION!

• Remove the battery and wait at least ve minutes for the

saw to cool before servicing or storing your unit.

• If you drop the saw, carefully inspect it for damage. If the guide bar is bent, the housing is cracked, the handle is

broken, or if you see any other condition that may aect

the saw’s operation, DO NOT USE the tool. Instead, have it serviced at an authorized Snow Joe dealer or call the Snow Joe center at 1-866-SNOWJOE (1-866-766-9563).

+ Sun Joe® customer service

+ Sun Joe®

2. To remove the blower tube, push the tube lock tab while pulling the tube away from the blower head.

Connecting to the Telescoping Pole

1. Open the assembly lock on the telescoping pole, and push

the leaf blower head into the opening on the end of the pole (Fig. 28).

Fig. 28

Blower head

Assembly lock

Telescoping pole

2. When the lock tabs snap in, lock back the assembly lock, and the pole leaf blower will be ready to use (Fig. 29).

Fig. 29

Lock tab

Adjusting the Telescoping Pole

This machine is equipped with a telescoping pole which can

telescope from 3.7 ft (1.1 m) to 5.3 ft (1.6 m). To adjust the telescoping pole, follow the instructions below.

1. Disconnect the blower from the power supply by removing the battery from the compartment.

2. Unclip the telescoping lock to release the pole. Extend the pole to the desired length (Fig. 32).

NOTE: Push poles toward each other to shorten the pole

or pull them away from each other to lengthen the pole. Only extend the pole to the minimum length required to reach the leaf/debris.

Assembly lock

3. To remove the leaf blower head, release the On/O switch

and remove the battery. Unlock the assembly lock, push the lock tabs on both sides, and pull the blower head out (Fig. 29).

Operation

Starting and Stopping

1. Slide the battery into the battery compartment until it

clicks to lock it into position (Fig. 30).

Fig. 30

Battery

2. To turn the pole blower ON, push and hold the safety lock

switch (located on the handle) forward with your thumb

and then squeeze the On/O switch with your ngers.

Once the tool is running, you can release the safety lock switch (Fig. 31).

Fig. 31

Safety lock switch

Fig. 32

Pull Pull

Telescoping lock

3. Lock the pole in position by closing the telescoping lock

(Fig. 33), and ensure that the pole is secured.

Fig. 33

Telescoping lock

mWARNING! Failure to lock the telescoping lock as

directed could result in personal injury.

Adjusting the Multi-Angle Head

The pole leaf blower head can be rotated for 10 dierent

cutting angles for -30º, -15º, 0º, 15º, 30º, 45º, 60º, 75º, 90º, and 105º. Follow the below instructions to adjust angles.

1. Rotate the leaf blower head to desired angle while pressing the rotating buttons located on both sides of the unit simultaneously (Fig. 34).

On/O switch

3. To turn the tool OFF, release the On/O switch (Fig. 31).

Fig. 34

Rotating buttons

Front side Back side

2. Release the buttons when the leaf blower head is xed

into the desired angle.

NOTE: Failure to properly secure the blower head may

result in personal injury and/or property damage.

mWARNING! Always ensure the blower head is securely

locked! Do not attempt to use the pole leaf blower with the head in any other position or unlocked!

Operating Tips

mWARNING! Use the pole blower only in daylight or

good articial light.

• When using the pole blower, plant your feet rmly on the

ground and place your dominant hand on the handle to control the unit. Use your other hand to grab the pole on the soft grip to steady the unit.

• Wear personal protective equipment during your work

session. This includes boots, safety glasses/goggles, ear defenders, long pants and a long-sleeve shirt.

• Make sure the blower tube is not directed at anybody or

any loose debris before starting the unit.

• Verify that the unit is in good working condition. Make

sure the tubes and guards are in place and secure.

• Keep a rm grip on the unit while in use.

• To reduce the risk of hearing loss associated with increased sound levels, hearing protection is required.

• Operate power equipment only at reasonable hours—not

early in the morning or late at night when people might be disturbed. Comply with times listed in local ordinances. Usual recommendations are 9:00 am to 5:00 pm, Monday through Saturday.

• To reduce noise levels, limit the number of pieces of power equipment used at any one time and operate

power blowers at the lowest possible speed setting necessary to do the job.

• Use rakes and brooms to loosen debris before blowing.

• In dusty conditions, slightly dampen surfaces.

• Conserve water by using power blowers instead of hoses

for many lawn and garden applications, including areas such as gutters, screens, patios, grills, porches and gardens.

• Blow debris into a safe, open area away from children,

pets, open windows or freshly washed cars.

• Clean up after using leaf blowers and other lawn equipment. Dispose of debris appropriately.

mWARNING! To avoid serious personal injury, wear

ear defenders, goggles or safety glasses at all times when operating this unit. Wear a face mask or dust mask in dusty locations.

mWARNING! To prevent serious personal injury or

damage to the unit, make sure the blower tube is in place before operating the unit.

Air Vents

Never cover air vents. Keep them free from obstructions and debris. They must always remain clear for proper motor cooling.

mWARNING! To avoid serious personal injury, do not

wear loose tting clothing or articles such as scarves, strings,

chains, ties, etc., that could get drawn into the air vents. To make sure long hair does not get drawn into the air vents, tie back long hair.

Blowing Operation

• Hold the blower rmly with your dominant hand on the

unit handle and the other hand on the soft grip. Sweep from side to side with the blower tube several

inches above the ground or oor (Fig. 35).

Fig. 35

• Slowly advance the unit, keeping the accumulated pile of

debris in front of you.

Maintenance + Care

1. Keep the tool’s air vents unclogged and clean at all times.

2. Remove dust and dirt regularly. Cleaning is best done with

a rag or brush.

4. Never use caustic agents to clean plastic parts.

Troubleshooting

2. When the lock tabs snap in, lock back the assembly lock,

and the pole hedge trimmer will be ready to use (Fig. 37).

Fig. 37

mWARNING! Always remove the battery before

performing any adjustments, maintenance, or repairs to your cordless pole blower.

Problems Corrective Action

Motor fails to start when switch is turned on.

• Check that you have inserted the battery properly

and the battery has enough power to work.

• Make sure that you fully depress, push forward

and hold the safety lock switch before squeezing

the ON/OFF trigger switch.

Pole Hedge Trimmer

Assembly

Connecting to the Telescoping Pole

The hedge trimmer head comes fully assembled. To use the machine as a pole hedge trimmer, connect the hedge trimmer head with the telescoping pole as indicated below.

1. Open the assembly lock on the telescoping pole, and push the hedge trimmer head into the opening on the end of the pole (Fig. 36).

Lock tab

Assembly lock

3. To remove the hedge trimmer head, release the On/O

switch and remove the battery. Unlock the assembly lock. Push the lock tabs on both sides, and pull the hedge trimmer head out (Fig. 37).

Operation

Starting and Stopping

1. Slide the battery into the battery compartment until it

clicks to lock it into position (Fig. 38).

Fig. 38

Fig. 36

Hedge trimmer head

Assembly lock

Telescoping pole

Battery

2. To turn the pole hedge trimmer ON, push and hold the

safety lock switch (located on the handle) forward with

your thumb and then squeeze the On/O switch with your ngers. Once the tool is running, you can release the

safety lock switch (Fig. 39).

Fig. 39

Safety lock switch

On/O switch

3. To turn the tool OFF, release the On/O switch (Fig. 39).

Adjusting the Telescoping Pole

This machine is equipped with a telescoping pole which can

telescope from 3.7 ft (1.1 m) to 5.3 ft (1.6 m). To adjust the telescoping pole, follow the instructions below.

1. Disconnect the hedge trimmer from the power supply by removing the battery from the compartment.

2. Unclip the telescoping lock to release the pole. Extend the pole to the desired length (Fig. 40).

NOTE: Push poles toward each other to shorten the pole

or pull them away from each other to lengthen the pole. Only extend the pole to the minimum length required to reach the hedges.

Fig. 40

Pull Pull

Telescoping lock

3. Lock the pole in position by closing the telescoping lock

(Fig. 41), and ensure that the pole is secured.

Fig. 41

Telescoping lock

Fig. 42

Rotating buttons

Front side Back side

2. Release the buttons when the trimmer head is xed into

the desired angle.

NOTE: Failure to properly secure the trimmer head may

result in personal injury and/or property damage.

mWARNING! Always ensure the hedge trimmer head is

securely locked! Do not attempt to use the pole hedge trimmer with the head in any other position or unlocked!

Before Operation

1. Check the tool, the battery as well as accessories for

damage before each use. Do not use the tool if it is damaged or shows wear.

2. Double check that the accessories and attachments are

properly xed.

3. Always hold the tool by its handle and soft grip. Keep the handles dry to ensure safe support.

4. Ensure that the air vents are always unobstructed and clear. Clean them if necessary with a soft brush. Blocked air vents may lead to overheating and damage the tool.

5. Switch the tool o immediately if you are disturbed

while working by other people entering the working area. Always let the tool come to a complete stop before putting it down.

6. Do not overwork yourself. Take regular breaks to ensure you can concentrate on the work and have full control over the tool.

mWARNING! Failure to lock the telescoping lock as

directed could result in personal injury.

Adjusting the Multi-Angle Head

The hedge trimmer head can be rotated for 10 dierent cutting

angles for -45º, -30º, -15º, 0º, 15º, 30º, 45º, 60º, 75º, and 90º. Follow the below instructions to adjust angles.

1. Rotate the trimmer head to the desired cutting angle while pressing the rotating buttons located on both sides of the unit simultaneously (Fig. 42).

Trimming Times

Green leaf hedges June to October

Evergreens April to August

Conifers and other fast growing shrubs

Every 6 – 8 weeks

Cutting Tips

mWARNING! Always hold the pole hedge trimmer with

both hands. Never hold shrubs with one hand and operate the pole hedge trimmer with the other. Failure to heed this warning can result in serious injury.

mWARNING! Clear the area to be cut before each use.

Remove all objects such as cords, lights, wire, or loose string which can become entangled in the cutting blade and create a risk of serious personal injury.

• Do not force the pole hedge trimmer through heavy

shrubbery. This can cause the blades to bind and slow down. If the blades slow down, reduce the pace.

• Do not attempt to cut stems or twigs that are larger than

0.6 in. (1.5 cm) thick, or those obviously too large to feed into the cutting blade. Use a non-powered hand saw or pruning saw to trim large stems.

• If blades do become jammed, stop the motor, allow the

blades to stop, and remove the battery from the power tool before attempting to remove the obstruction.

• If desired, you can use a string to help cut your hedge level.

Decide how high you want the hedge. Stretch a piece of string along the hedge at the desired height. Trim the hedge just above the guide line of string. Trim the side of a hedge so that it will be slightly narrower at the top. More of the hedge will be exposed when shaped this way, and it will be more uniform.

• Wear gloves when trimming thorny or prickly growth. When

trimming new growth, use a wide sweeping action, so that the stems are fed directly into the cutting blade. Older growth will have thicker stems and will be trimmed easiest by using a sawing movement.

• Hold unit rmly with both hands. Always keep your left

hand on the telescoping pole and your right hand on the rear handle. The unit is used for cutting in either direction in a slow, sweeping action from side to side.

• Stand so that you are stable and balanced on both feet.

• Inspect and clear the area of any hidden objects.

• To protect yourself from electrocution, do not operate within

33 feet (10 m) of overhead electrical lines.

• Never use the pole hedge trimmer near power lines,

fencing, posts, buildings, or other immovable objects.

• Never use a blade after hitting a hard object without rst

inspecting it for damage. Do not use if any damage is detected.

1. To use the pole hedge trimmer for trimming tall, hard-to-read hedges or shrubs, hold the trimmer at the position shown below (Fig. 43). Pivot the power head to several dierent positions to shape or sculpt shrubs or hedges.

Fig. 43

2. To use pole hedge trimmer for trimming the bottoms and

sides of hedges and shrubs, hold the pole trimmer at the position shown below (Fig. 44).

Fig. 44

3. To use pole hedge trimmer for trimming low-lying foliage

or ground cover, hold the pole hedge trimmer at the position as shown below (Fig. 45).

Fig. 45

mCAUTION! Do not use the pole hedge trimmer for

cutting stems greater than 0.6 inch (1.5 cm) thick.

Use the pole hedge trimmer only for cutting normal shrubbery found around houses and buildings.

Do not force the pole hedge trimmer through dense growth. A slight back and forth sawing action may ease the cutting of larger, more dense growth. If the pole hedge trimmer begins to slow down, reduce the rate of speed at which you are trying to cut. If the pole hedge trimmer becomes jammed, immediately

turn the trimmer o. Remove the battery and clear the jammed

debris from the cutter blades.

Care + Maintenance

WARNING! Blades are sharp. When handling the blade

assembly, wear non-slip, heavy-duty protective gloves. Do not

place your hand or ngers between blades or in any position

where they could get pinched or cut. NEVER touch the blades or service the unit with the battery inserted.

Lubricate the Blades

For easier operation and longer blade life, lubricate the pole hedge trimmer blade before and after each use.

1. Stop the motor and remove the battery.

2. Lay the pole hedge trimmer on a at surface. Apply

lightweight machine oil along the edge of the top blade (Fig. 46).

Disposal

Recycling the tool

• Do not dispose of electrical appliances as unsorted municipal waste. Use separate collection facilities.

• Contact your local government agency for information regarding the collection systems available.

• If electrical appliances are disposed of in landlls

or dumps, hazardous substances can leak into the groundwater and get into the food chain, damaging your health and well-being.

• When replacing old appliances with new ones, the retailer is legally obligated to take back your old appliance for disposal at least free of charge.

Recycling + Disposal

The product comes in a package that protects it against damage during shipping. Keep the package until you are sure that all parts have been delivered and the product is functioning properly. Recycle the package afterwards or keep it for long-term storage.

WEEE symbol. Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your local authority or local store for recycling regulations.

Fig. 46

If you will be using the pole hedge trimmer for an extended period, it is advisable to stop work intermittently in order to re-oil the blade.

NOTE: Do not oil while the pole hedge trimmer is running.

Battery Caution + Disposal

Always dispose of your battery pack according to federal, state, and local regulations. Contact a recycling agency in your area for recycling locations.

mCAUTION! Even discharged battery packs contain

some energy. Before disposing, use electrical tape to cover the terminals to prevent the battery pack from shorting,

which could cause a re or explosion.

mWARNING! To reduce the risk of injury or explosion,

never burn or incinerate a battery pack even if it is damaged, dead or completely discharged. When burned, toxic fumes and materials are emitted into the surrounding atmosphere.

1. Batteries vary according to device. Consult your manual

for specic information.

2. Install only new batteries of the same type in your product (where applicable).

3. Failure to insert batteries in the correct polarity, as indicated in the battery compartment or manual, may shorten the life of the batteries or cause batteries to leak.

4. Do not mix old and new batteries.

5. Do not mix Alkaline, Standard (Carbon-Zinc) or

Rechargeable (Nickel Cadmium, Nickel Metal Hydride, or Lithium-Ion) batteries.

6. Do not dispose of batteries in re.

7. Batteries should be recycled or disposed of as per state

and local guidelines.

24VCHRG-AC

Federal Communications Commission (FCC)

Support

If your Sun Joe requires service or maintenance, please call 1-866-SNOWJOE (1-866-766-9563) for assistance.

iON+ GTS4001C cordless garden tool system

Model + Serial Number

When contacting the company, reordering parts, or arranging service from an authorized dealer, you will need to provide the model and serial numbers, which can be found on the decal located on the housing of the unit. Copy these numbers into the space provided below.

Record the following numbers from the housing or handle of your new product:

G T S 4 0 0 1 C

Model #:

Serial #:

mWARNING! Any changes or modications to this

unit not expressly approved by the party responsible for compliance could void the user's authority to operate the

equipment.

Class B device:

NOTE: This equipment has been tested and found to comply

with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance

with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the

equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and

receiver.

• Connect the equipment into an outlet on a circuit dierent

from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician

for help.

Optional Accessories

mWARNING! ALWAYS use only authorized Snow Joe

+ Sun Joe® replacement parts and accessories. NEVER use replacement parts or accessories that are not intended for use with this cordless garden tool system. Contact Snow Joe Sun Joe

if you are unsure whether it is safe to use a particular replacement part or accessory with your cordless garden tool

system. The use of any other attachment or accessory can be dangerous and could cause injury or mechanical damage.

ModelAccessories Item

24V iON+ 2.0 Ah Lithium-Ion Battery

Battery Charge Time Max:

24VCHRG-AC: 1 hr 20 min 24VCHRG-QC: 55 min

Battery Run Time Max: Pole chain saw: 40 min Pole hedge trimmer: 55 min Pole leaf blower: 17 min

24V iON+ 2.5 Ah Lithium-Ion Battery

Battery Charge Time Max:

24VCHRG-AC: 1 hr 40 min 24VCHRG-QC: 1 hr 10 min

Battery Run Time Max:

Pole chain saw: 50 min Pole hedge trimmer: 68 min Pole leaf blower: 21 min

24V iON+ 4.0 Ah Lithium-Ion Battery

Battery Charge Time Max:

24VCHRG-AC: 2 hrs 40 min 24VCHRG-QC: 1 hr 50 min

Battery Run Time Max:

Pole chain saw: 1 hr 20 min Pole hedge trimmer: 1 hr 50 min Pole leaf blower: 34 min

24V iON+ 5.0 Ah Lithium-Ion Battery

Battery Charge Time Max:

24VCHRG-AC: 3 hrs 20 min 24VCHRG-QC: 2 hrs 20 min

Battery Run Time Max:

Pole chain saw: 1 hr 40 min Pole hedge trimmer: 2 hr 16 min Pole leaf blower: 42 min

24VBAT-LTE

24VBAT-LT

24VBAT

24VBAT-XR

24V iON+ Lithium-Ion Battery Quick Charger

24VCHRG-QC

24V iON+ Lithium-Ion Battery Charger

8-inch (20.3 cm) replacement chain

8-inch (20.3 cm) replacement bar

NOTE: Accessories are subject to change without any obligation on the part of Snow Joe® + Sun Joe® to provide notice of such changes. Accessories can be ordered online at sunjoe.com or via phone by contacting the Snow Joe service center at 1-866-SNOWJOE (1-866-766-9563).

24VCHRG-AC

SWJ-8CHAIN

SWJ805E-BAR

+ Sun Joe® customer

SNOW JOE® + SUN JOE® CUSTOMER PROMISE

ABOVE ALL ELSE, Snow Joe® + Sun Joe® are dedicated to you, our customer. We strive to make your experience as pleasant

as possible. Unfortunately, there are times when a product does not work or breaks under normal operating conditions. We think it’s important that you know what you can expect from us. That’s why we created the Snow Joe® + Sun Joe® promise.

OUR PROMISE: Snow Joe® + Sun Joe® warrant new products for two years from the date of purchase. If your product does

not work, or there’s an issue with a specic part, we will x this by either sending you a free replacement part or by sending

you a new or comparable product at no charge. How cool is that! Before you know it, you’ll be back in action cutting, sawing, mowing, washing and…?

PRODUCT REGISTRATION:

Snow Joe

, LLC (“Snow Joe® + Sun Joe®”) strongly encourages you to register your purchase. You can register online at snowjoe.com/ProductRegistration, or by printing and mailing in a registration card available online from our website, or calling our Customer Service Department at 1-866-SNOWJOE (1-866-766-9563), or by e-mailing us at help@snowjoe.com. Failure to register your product purchase will not diminish your warranty rights. However, registering your purchase will allow

Snow Joe

+ Sun Joe® to better serve you with any of your

customer service needs.

WHO CAN SEEK WARRANTY COVERAGE?

This Warranty is extended by Snow Joe

+ Sun Joe® to the owner of this Machine (a “Machine” consists of a product powered by a motor) for residential and personal household use only. This Warranty does not apply to products used for commercial, rental or re-sale purposes. Should ownership of this machine change during the 2-year period, please update the Machine’s owner information at snowjoe.com/ProductRegistration.

WHAT IS COVERED?

Snow Joe

+ Sun Joe® warrants to the owner that if this Machine fails within 2 years from the date of purchase due to a defect in material or workmanship or as a result of normal wear and tear

from ordinary household use, Snow Joe

+ Sun Joe® will send a replacement part or product, as needed, free of charge and with free shipping to the original purchaser.

If, in Snow Joe cannot be repaired with a part, Snow Joe

+ Sun Joe®’s sole discretion, the failed Machine

+ Sun Joe® will elect to either (A) send a new Machine at no charge and with free shipping or (B) refund the full purchase price to the owner.

WHAT IS NOT COVERED?

This Warranty does not apply to the Machines that have been used commercially or in non-household applications. This Warranty

does not cover cosmetic changes that do not aect performance.

This Warranty is only valid if the Machine is used and maintained in accordance with the instructions, warnings and safeguards

contained in the owner’s manual. Snow Joe

+ Sun Joe® will not be responsible for the cost of any unauthorized warranty repairs. This warranty does not cover any cost or expense incurred by

the purchaser in providing substitute equipment or service during

reasonable periods of malfunction or non-use of this product while waiting for a replacement part or unit under this warranty.

Wearing parts like belts, augers, chains and tines are not covered under this warranty, and can be purchased at snowjoe.com or by calling 1-866-SNOWJOE (1-866-766-9563). Batteries are covered in full for 90-days from the date of purchase.

Repair, replacement or refund of the purchase price are the exclusive remedies of purchaser and the sole liability of Snow Joe

+ Sun Joe of Snow Joe

under this warranty. No employee or representative

+ Sun Joe® is authorized to make any additional

warranty or any modication to this warranty which may be

binding upon Snow Joe

+ Sun Joe®. Accordingly, purchaser

should not rely upon any additional statements made by any

employee or representative of Snow Joe

+ Sun Joe®. In no event,

whether based on contract, indemnity, warranty, tort (including

negligence), strict liability or otherwise, shall Snow Joe

Sun Joe

be liable for any special, indirect, incidental, or

consequential damages, including, without limitation, loss of prot or revenue.

Some states do not allow limits on warranties. In such states, the above limitations may not apply to you.

Outside the USA, other warranties may apply.
