OPERATOR’S MANUAL
A Division of Snow Joe®, LLC
R
CORDLESS PORTABLE SPRAY WASHER
Model 24V-PSW2.5-SJG Form No. SJ-24V-PSW2.5-SJG-880E-M
IMPORTANT!
Safety Instructions
All Operators Must Read These
Instructions Before Use
mWARNING! This indicates a hazardous situation, which,
if not avoided, could result in death or serious injury.
mCAUTION! This indicates a hazardous situation, which,
if not avoided, could result in minor or moderate injury.
mDANGER! This indicates a hazardous situation, which,
if not followed, will result in death or serious injury.
General Safety
mWARNING! This appliance is not intended for use
by children or by unassisted, unsupervised persons whose
physical, sensory, or mental capabilities prevent them from
using it safely. Children should be supervised to ensure that
they do not play with the appliance.
Before starting up your machine, please check it carefully for
any defects. If you nd any, do not start up your machine.
Contact your authorized Snow Joe® + Sun Joe® dealer or
call the Snow Joe® + Sun Joe® customer service center at
1-866-SNOWJOE (1-866-766-9563).
mWARNING! When using the spray washer, basic safety
precautions should always be followed to reduce the risk of
re, electric shock, and personal injury. These include:
• Know your product – Know how to stop the machine and
bleed pressure quickly. Thoroughly familiarize yourself with
the controls.
• Keep bystanders away – All visitors and pets should be
kept a safe distance away from the work area.
• Use the right product – Do not use this machine for any
job except that for which it is intended.
• mCAUTION! – Exercise caution to avoid slipping or falling.
Wear protective footwear that will protect your feet and
improve your footing on slippery surfaces.
• Stay alert – Watch what you are doing. Use common
sense. Do not operate the spray washer when you are tired,
or under the inuence of alcohol or drugs.
• Do not overreach – Keep proper footing and balance at
all times.
© 2019 by Snow Joe®, LLC
All rights reserved. Original instructions.
• Avoid unintentional starting – Do not carry the spray
washer with your nger on the switch. Make sure the switch
is o before inserting the battery.
• Check the water temperature – This spray washer is not
meant to pump hot water. NEVER ll it with hot water as it
will signicantly reduce the life of the pump.
• Store indoors – NEVER store the spray washer
outdoors or where it could freeze. The pump could
be seriously damaged.
mWARNING! Do not use this appliance without reading
this instruction manual.
mWARNING! Do not use the appliance within range of
other people unless they are wearing protective clothing.
mWARNING! High-pressure jets can be dangerous if
subject to misuse. The jet must not be directed at persons,
pets, live electrical equipment, or the appliance itself.
• Do not direct the jet at yourself or others in order to clean
clothes or footwear.
• Risk of explosion – Do not spray ammable liquids.
• Remove the battery – Remove the battery from the
compartment before performing any maintenance task.
• Keep children away – To reduce the risk of injury, close
supervision is necessary when the spray washer is used
near children. This spray washer must not be used by
children or untrained personnel.
• Before transporting the unit, make sure the stopper plug is
inserted securely into the water outlet, and use the handle
to transport the unit.
• To ensure appliance safety, use only original replacement
parts from the manufacturer or those approved by the
manufacturer.
• Disconnect spray hose and drain unit completely before
transporting. When transporting with water, always be
sure to use the included stopper plug, and take additional
precautions such as enclosing the unit in a leak-proof
plastic bin or tray to protect against water damage.
• When transporting, ensure the unit is properly secured to
avoid tipping, which could result in leakage.
• Follow the maintenance instructions specied in
the manual.
mWARNING! During cleaning, maintenance, or when
replacing parts, disconnect the machine from its power source
by removing the battery from the compartment.
SAVE THESE INSTRUCTIONS
1
mWARNING! High-pressure hoses, ttings, and
couplings are important for the safe operation of the
appliance. Use only hoses, ttings, and couplings
recommended by the manufacturer.
mWARNING! Electrical Shock Hazard – Before starting
up your machine, please check it carefully for any defects.
If you nd any, do not start up your machine and contact
your distributor.
IMPORTANT: Only use water without any impurities.
If there is a risk of running sand into the inlet water (i.e. from
your own well), an additional lter should be installed.
Despite all the safety precautions, caution must always be
exercised when handling batteries. The following points must
be obeyed at all times to ensure safe use. Safe use can only
be guaranteed if undamaged cells are used. Incorrect handling
of the battery pack can cause cell damage.
IMPORTANT! Analyses conrm that incorrect use and poor
care of high-performance batteries are the main factors
responsible for personal and/or product damage.
mWARNING! Use only approved replacement batteries;
other batteries may damage the power tool and cause it to
malfunction, which can lead to serious personal injury.
mWARNING! Do not ll any other liquid except clean
water in the water tank.
• Check for damaged parts – Do not use the appliance if
any important part of the appliance are damaged
(e.g. safety devices, hoses, spray nozzle).
• This cordless spray washer must not be used at
temperatures below 32ºF (0°C).
• Keep the machine on a stable, at surface during operation,
handling, transportation, and storage.
• In the event of an accident or breakdown, switch o the
machine immediately.
Electrical Safety
1. If the battery charger cord is damaged, please call the
Snow Joe® + Sun Joe® customer service center at
1-866-SNOWJOE (1-866-766-9563).
2. If charging the power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected power supply. The using of an RCD reduces the
risk of electric shock.
3. Do not abuse the charging cord. Never use the cord
for carrying, pulling or unplugging the charger. Keep
cord away from heat, oil, sharp edges or moving
parts. Damaged or entangled cords increase the risk
of electric shock.
4. Battery charger is for indoor use only. Do not charge the
spray washer in rain, or in wet locations.
Battery & Charger
Safety Instructions
We pay a great deal of attention to the design of every battery
pack to ensure that we supply you with batteries that are safe,
durable and have a high energy density. The battery cells have
a wide range of safety devices. Each individual cell is initially
formatted and its electrical characteristic curves are recorded.
This data is then used exclusively to be able to assemble the
best possible battery packs.
mWARNING! Do not use a battery pack or appliance that
is damaged or modied. Damaged or modied batteries may
exhibit unpredictable behavior resulting in re, explosion or risk
of injury.
Do not modify or attempt to repair the appliance or the battery
pack except as indicated in the instructions for use and care.
Have your battery pack serviced by a qualied repair person
using only identical replacement parts. This will ensure that the
safety of the battery pack is maintained.
mCAUTION! To reduce the risk of injury, charge the
24V iON+ lithium-ion battery pack only in its designated
24V iON+ lithium-ion charger. Other types of chargers present
risk of re, personal injury and damage. Do not wire a battery
pack to a power supply plug or car cigarette lighter. Such
misuse will permanently disable or damage the battery pack.
• Avoid dangerous environments – Do not charge the
battery pack in rain, snow or in damp or wet locations.
Do not use the battery pack or charger in the presence of
explosive atmospheres (gaseous fumes, dust or ammable
materials) because sparks may be generated when inserting
or removing the battery pack, which could lead to a re.
• Charge in a well-ventilated area – Do not block the
charger vents. Keep them clear to allow for proper
ventilation. Do not allow smoking or open ames near a
charging battery pack. Vented gases may explode.
NOTE: The safe temperature range for the battery is
41°F (5°C) to 105°F (40.5°C). Do not charge the battery
outside in freezing weather; charge it at room temperature.
• Maintain charger cord – When unplugging the charger, pull
the plug, not the cord, from the receptacle to reduce the
risk of damage to the electrical plug and cord. Never carry
the charger by its cord or yank it by the cord to disconnect
it from the receptacle. Keep the cord away from heat, oil
and sharp edges. Make sure the cord will not be stepped
on, tripped over or subjected to damage or stress when the
charger is in use. Do not use the charger with a damaged
cord or plug. Replace a damaged charger immediately.
2
• Do not use an extension cord unless it is absolutely
necessary – Using the wrong, damaged or improperly
wired extension cord poses a risk of re and electric shock.
If an extension cord must be used, plug the charger into a
properly wired 16 gauge or larger extension cord with the
female plug matching the male plug on the charger. Make
sure that the extension cord is in good electrical condition.
• Use only recommended attachments – Use of an
attachment not recommended or sold by the battery
charger or battery pack manufacturer may result in risk of
re, electric shock or personal injury.
• Unplug charger when not in use – Make sure to remove
battery packs from unplugged chargers.
mWARNING! To reduce the risk of electric shock,
always unplug the charger before performing any cleaning or
maintenance. Do not allow water to ow into the charger.
Use a Ground Fault Circuit Interrupter (GFCI) to reduce
shock hazards.
• Do not burn or incinerate battery packs – Battery
packs may explode, causing personal injury or damage.
Toxic fumes and materials are created when battery packs
are burned.
• Do not crush, drop or damage battery packs – Do not
use the battery pack or charger if they have sustained a
sharp blow, been dropped, run over or have been damaged
in any way (i.e. pierced with a nail, hit with a hammer,
stepped on, etc.).
• Do not disassemble – Incorrect reassembly may pose
a serious risk of electric shock, re or exposure to toxic
battery chemicals. If the battery or charger are damaged,
contact an authorized Snow Joe® + Sun Joe® dealer or
call the Snow Joe® + Sun Joe® customer service center at
1-866-SNOWJOE (1-866-766-9563) for assistance.
• Battery chemicals cause serious burns – Never let a
damaged battery pack contact the skin, eyes or mouth.
If a damaged battery pack leaks battery chemicals, use
rubber or neoprene gloves to safely dispose of it. If skin
is exposed to battery uids, wash the aected area with
soap and water and rinse with vinegar. If eyes are exposed
to battery chemicals, immediately ush with water for 20
minutes and seek medical attention. Remove and dispose
of contaminated clothing.
• Do not short circuit – A battery pack will short circuit if
a metal object makes a connection between the positive
and negative contacts on the battery pack. Do not place a
battery pack near anything that may cause a short circuit,
such as paperclips, coins, keys, screws, nails and other
metallic objects. A short-circuited battery pack poses a risk
of re and severe personal injury.
• Store your battery pack and charger in a cool, dry
place – Do not store the battery pack or charger where
temperatures may exceed 105ºF (40.5ºC), such as in
direct sunlight or inside a vehicle or metal building
during the summer.
Information about the battery
1. The battery pack supplied with your cordless power tool is
only partially charged. The battery pack has to be charged
completely before you use the tool for the rst time.
2. For optimum battery performance, avoid low discharge
cycles by charging the battery pack frequently.
3. Store the battery pack in a cool place, ideally at
59°F (15°C) and charged to at least 40%.
4. Lithium-ion batteries are subject to a natural aging
process. The battery pack must be replaced at the latest
when its capacity falls to just 80% of its capacity when
new. Weakened cells in an aged battery pack are no
longer capable of meeting the high power requirements
needed for the proper operation of your cordless spray
washer, and therefore pose a safety risk.
5. Do not throw battery packs into an open re as this poses
a risk of explosion.
6. Do not ignite the battery pack or expose it to re.
7. Do not exhaustively discharge batteries. Exhaustive
discharge will damage the battery cells. The most
common cause of exhaustive discharge is lengthy
storage or non-use of partially discharged batteries.
Stop working as soon as the performance of the battery
falls noticeably or the electronic protection system
triggers. Place the battery pack in storage only after it
has been fully charged.
8. Protect batteries and the tool from overloads. Overloads
will quickly result in overheating and cell damage inside
the battery housing even if this overheating is not
apparent externally.
9. Avoid damage and shocks. Immediately replace batteries
that have been dropped from a height of more than
3 feet (1 meter) or those that have been exposed to
violent shocks, even if the housing of the battery pack
appears to be undamaged. The battery cells inside the
battery may have suered serious damage. In such
instances, please read the waste disposal information for
proper battery disposal.
10. If the battery pack suers overloading and overheating,
the integrated protective cuto will switch o the
equipment for safety reasons.
IMPORTANT! Do not press the ON/OFF switch any more
if the protective cut-o has been activated. This may
damage the battery pack.
11. Use only original battery packs. The use of other batteries
poses a re risk and may result in injuries or an explosion.
3
Information about the charger and the
charging process
1. Please check the data marked on the rating plate of the
battery charger. Be sure to connect the battery charger
to a power supply with the voltage marked on the rating
plate. Never connect it to a dierent mains voltage.
2. Protect the battery charger and its cord from damage.
Keep the charger and its cord away from heat, oil and
sharp edges. Have damaged cords repaired without delay
by a qualied technician at an authorized Snow Joe® +
Sun Joe® dealer or call the Snow Joe® + Sun Joe®
customer service center at 1-866-SNOWJOE
(1-866-766-9563).
3. Electrical plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs with
grounded appliances. Unmodied plugs and matching
outlets will reduce the risk of electric shock.
4. Keep the battery charger, battery pack(s) and the cordless
tool out of the reach of children.
5. Do not use the supplied battery charger to charge other
cordless tools.
6. During periods of heavy use, the battery pack will become
warm. Allow the battery pack to cool to room temperature
before inserting it into the charger to recharge.
7. Do not overcharge batteries. Do not exceed the maximum
charging times. These charging times only apply to
discharged batteries. Frequent insertion of a charged or
partially charged battery pack will result in overcharging
and cell damage. Do not leave batteries in the charger for
days on end.
8. Never use or charge batteries if you suspect that it has
been more than 12 months since the last time they were
charged. There is a high probability that the battery pack
has already suered dangerous damage (exhaustive
discharge).
9. Charging batteries at a temperature below 41°F (5°C) will
cause chemical damage to the cells and may cause a re.
10. Do not use batteries that have been exposed to heat
during the charging process, as the battery cells may have
suered dangerous damage.
11. Do not use batteries that have suered curvature or
deformation during the charging process or those that
exhibit other atypical symptoms (gassing, hissing,
cracking, etc.).
12. Never fully discharge the battery pack (maximum
recommended depth of discharge is 80%). A complete
discharge of the battery pack will lead to premature aging
of the battery cells.
Protectionfromenvironmentalinuences
1. Wear suitable work clothes. Wear safety goggles.
2. Protect your cordless tool and the battery charger from
moisture and rain. Moisture and rain can cause dangerous
cell damage.
3. Do not use the cordless tool or the battery charger near
vapors and ammable liquids.
4. Use the battery charger and cordless tools only in dry
conditions and at an ambient temperature of 41°F – 105°F
(5°C – 40.5°C).
5. Do not keep the battery charger in places where the
temperature is liable to reach over 104°F (40°C).
In particular, do not leave the battery charger in a car that
is parked in the sunshine.
6. Protect batteries from overheating. Overloads,
overcharging and exposure to direct sunlight will result
in overheating and cell damage. Never charge or work
with batteries that have been overheated – replace them
immediately, if possible.
7. Store the charger and your cordless tool only in dry
locations with an ambient temperature of 40°F – 105°F
(4.5°C – 40.5°C). Store your lithium-ion battery pack in a
cool, dry place at a temperature of 50°F – 68°F
(10°C – 20°C). Protect the battery pack, charger and
cordless tool from humidity and direct sunlight. Only
place fully charged batteries in storage (charged to at
least 40%).
8. Prevent the lithium-ion battery pack from freezing. Battery
packs that were stored below 32°F (0°C) for more than
60 minutes must be discarded.
9. When handling batteries, be wary of electrostatic charge.
Electrostatic discharges can damage the electronic
protection system and the battery cells. Avoid electrostatic
charging and never touch the battery poles.
Risk of explosion
• Do not spray ammable liquids.
• Do not use acids, bases, solvents, or any ammable
material in this product. These substances can cause
physical injuries to the operator and irreversible damage to
the machine.
Additional safety instructions
• High-pressure: keep clear of nozzle.
• Injection hazard: equipment can cause serious injury if the
spray penetrates the skin.
• Do not point the jet at anyone or at any part of the body.
• Before servicing, cleaning, or removing any parts, shut o
the power and relieve pressure.
4
Product Description
Purpose
• This cordless spray washer is intended for residential
use only. It is designed for light-to-medium duty cleaning
jobs on boats, motorcycles, RVs, ATVs, trailers, decks,
barbecues, siding, patio furniture, and more.
Areas of application
• Never use the machine in potentially explosive areas under
any circumstances!
• The operating temperature must be between 32ºF (0ºC) and
140ºF (60ºC).
• Do not cover or modify the spray nozzle in any way.
• The cordless spray washer is designed to be used with
cold or lukewarm water; higher temperatures can damage
the pump.
• Do not use water that is dirty, gritty, or contains any
chemical products, as such impurities could impair
operation and shorten the life of the machine.
5
Safety Symbols
The following table depicts and describes safety symbols that may appear on this product. Read, understand, and follow all
instructions on the machine before attempting to assemble and operate.
Symbols SymbolsDescriptions Descriptions
READ THE OPERATOR'S
MANUAL(S) – Read, understand,
and follow all instructions in the
user manual(s) before attempting
to assemble and operate.
WARNING! Do not expose the unit
to rain or wet conditions. Keep dry.
To reduce the risk of injury, don’t
spray toward all bystanders,
animals and electric appliances
with plug.
SAFETY ALERT – Indicates a
precaution, a warning, or a danger.
WEAR EYE AND HEARING
PROTECTION – For protection
against injury, wear ear defenders
and safety goggles.
Wear safety gloves during
use to protect hands.
Store indoors. Never store the
spray washer outdoors.
If the pump freezes, permanent
damage may result.
Indoor use only. Only use battery charger indoors.
Wear non-slip footwear that will
protect your feet and improve your
footing on slippery surfaces.
6
Know Your Cordless Portable Spray Washer
Read the owner’s manual and safety rules carefully before operating the spray washer. Compare the illustration below to the
spray washer in order to familiarize yourself with the location of the various controls and adjustments. Save this manual for
future reference.
1
9
10
1. Tank cap
2. Handle
3. Water tank
4. ON/OFF switch
5. Stopper plug
6. Water outlet/Hose connection
7. Battery compartment cover
8. Storage compartment
9. Adjustable nozzle
10. Trigger
11. Spray attachment
FRONT BACK
11
12
2
3
8
467
5
14 15
13
16
18 17
12. Spray gun
13. Hose
14. Charger socket
15. Push button for battery indicators
16. Battery indicators
17. Push lock buttons
18. 24V iON+ lithium-ion battery (24VBAT-LTW)
featuring exclusive EcoSharp® technology
19. 24V lithium-ion charger (XZ2600-0450)
20. Charger plug
19
20
Technical Data
Battery Voltage* ........................................24 V D.C.
Battery Capacity ....................................... 1.3 Ah
Battery Runtime Max ................................ 25 min
Charger Input............................................100 – 240 V AC,
50/60 Hz, 0.4 A
Charger Output .........................................26 V DC 450 mA
Charge Time Max .....................................3 hours
*Initial no-load voltage, when fully charged, peaks at 24 volts; nominal voltage under typical load is 21.6 volts
Max Water Inlet Temperature ........................... 140ºF (60ºC)
Max Flow .......................................................... 1.5 GPM
Rated Pressure .................................................90 PSI
Max Pressure ....................................................116 PSI
Water Tank Capacity ........................................ 2.5 Gallon (9.5 L)
Weight (Spray washer only) ..............................8 lbs (3.7 kg )
Weight (with battery installed) ..........................9.5 lbs (4.3 kg)
7
Unpacking
Carton Contents
• Cordless portable spray washer
• Hose
• Spray gun
• Spray attachment
• 24V iON+ lithium-ion battery
• 24V iON+ lithium-ion charger
• Manuals with registration card
1. Carefully remove the portable spray washer and check to
see that all of the above items are supplied.
2. Inspect the product carefully to make sure no breakage or
damage occurred during shipping. If you nd damaged or
missing parts, DO NOT return the unit to the store. Please
call the Snow Joe® + Sun Joe® customer service center at
1-866-SNOWJOE (1-866-766-9563).
NOTE: Do not discard the shipping carton and packaging
material until you are ready to use your new cordless
spray washer. The packaging is made of recyclable
materials. Properly dispose of these materials in
accordance with local regulations.
IMPORTANT! The equipment and packaging material are
not toys. Do not let children play with plastic bags, foils,
or small parts. These items can be swallowed and pose a
suocation risk!
NOTE: The unit is equipped with a stopper plug to
prevent leaking when the hose is not connected, or during
transport. Be sure to insert the stopper plug completely to
ensure a secure, leak-proof connection.
2. Connect the other end of the hose to the spray gun
(Fig. 2). To connect, pull back the connector collar, align
with the end of the spray gun, and release the collar.
You will feel a click when it snaps in.
Fig. 2
Spray gun
Hose
NOTE: To disconnect the hose, pull back the collar and
pull the hose away from the connector.
mWARNING! Keep hose away from sharp objects.
Bursting hoses may cause injury. Examine hoses regularly and
replace if damaged. Do not attempt to mend a damaged hose.
mWARNING! Do not insert the battery until assembly is
complete. Failure to comply could result in accidental starting
and possible serious personal injury.
Assembly
1. Flip up the stopper plug and attach the quick-connect end
of the hose to the water outlet/hose connection (Fig. 1).
To connect, pull back the connector collar and align the
connector with the water outlet, and release the collar.
You will feel a click when it snaps in.
Fig. 1
Stopper plug
Hose
Water
outlet
Connector
collar
Battery Pack Operation
The equipment is powered by a lithium-ion battery. The battery
pack is completely sealed and maintenance free.
Battery Charge Level Indicator
The battery pack is equipped with a push button for checking
the charge level. Simply press the push button to read o the
battery charge level from the LEDs of the battery indicator:
• All 3 level monitoring LEDs are lit: Battery charge level
is high.
• 2 level monitoring LEDs are lit: Battery charge level is
decreasing. Stop work as soon as possible.
• 1 level monitoring LED is lit: Battery is at. Stop work
IMMEDIATELY and charge the battery. Otherwise the
battery’s service life will be greatly shortened.
8
Light IndicatorsLights
Charge level button
The battery is at 30% capacity
and requires charging
The battery is at 60% capacity
and requires charging soon
The battery is at full capacity
NOTE: If the charge level button does not appear to be
working, insert the charger and charge as needed.
NOTE: Immediately after using the battery pack, the charge
level button may display a lower charge than it will if checked
a few minutes later. The battery cells “recover” some of their
charge after resting.
Charger Operation
mWARNING! Charge only 24V iON+ lithium-ion battery
packs with its compatible 24V iON+ lithium-ion charger.
Other types of batteries may cause personal injury and
damage. To reduce the risk of electric shock, do not allow
water to ow into the charger's AC/DC plug.
When to Charge the iON+ 24VBAT-LTW
Lithium-iON Battery
NOTE: The iON+ 24VBAT-LTW lithium-ion battery packs do
not develop a "memory" when charged after only a partial
discharge. Therefore, it is not necessary to run down the
battery pack before inserting the charger plug.
• Use the battery indicator lights to determine when to charge
your iON+ 24VBAT-LTW lithium-ion battery pack.
• You can "top-o" your battery pack's charge before starting
a big job or after a long day of use.
Charging the Battery
1. Open the battery compartment cover, and push the push
lock button on the battery to pull the battery out from the
battery compartment (Fig. 3).
Fig. 3
Battery
Push lock
button
Battery
compartment
cover
2. Check that the mains voltage is the same as that marked
on the rating plate of the battery charger. Then, plug the
charger adapter into an appropriate AC power outlet.
Connect the charger plug into the charge socket of the
battery to start charging (Fig. 4).
Fig. 4
Battery
indicators
3. The battery will take approximately 3 hours to charge.
The battery indicator LEDs will twinkle and illuminate one
by one during the charging process. Unplug the charger
immediately when the 3 LEDs are all illuminated.
mCAUTION! FIRE HAZARD. When disconnecting the
charger from the battery, be sure to unplug the charger from
the outlet rst, then disconnect the charger from the battery.
mWARNING! This charger does not automatically
turnowhenthebatteryisfullycharged.Please take
care not to leave the battery plugged into the charger.
Switchoorunplugthechargeratthemainswhen
charging is complete.
9
4. Timely recharging of the battery will help prolong the
battery's life. You must recharge the battery pack when
you notice a drop in the equipment's power.
IMPORTANT! Never allow the battery pack to become
fully discharged as this will cause irreversible damage to
the battery.
Operation
Starting + Stopping
mIMPORTANT! This spray washer is equipped with a
micro-switch sensitive to water ow. This Total Stop System
(TSS) senses water ow in the pump. When the trigger is
released, water stops owing through the pump. The TSS then
automatically turns the motor o to protect the pump from
overheating, thus saving energy and prolonging pump life.
mWARNING! Always remove battery before lling
with water. NEVER immerse unit in water. Close battery
compartment door securely before lling. Always use
caution when handling or using any powered product
where water is present.
1. Fill the water tank with clean water (Fig. 5).
Fig. 6
Battery
3. Position the washer as CLOSE as possible to the
object that need to be cleaned.
NOTE: The washer must be used on a secure and stable
surface in a standing, upright position.
4. Press the ON (I) side of the ON/OFF switch to start the
portable washer and squeeze the spray gun trigger to use
the machine (Fig. 7).
Fig. 5
mWARNING! The intake water temperature must not
exceed 140ºF/60ºC.
mCAUTION! The washer must only be used with clean
water; use of unltered water containing corrosive chemicals
will damage the washer.
2. Open the battery compartment cover and slide the battery
in until it clicks to lock it into position, then close the
battery compartment cover (Fig. 6).
Fig. 7
ON/OFF switch
NOTE: It's recommended to bleed the air in the hose
every time before starting the spray washer. Follow the
instructions in Maintenance section to bleed the air.
5. To shut down the unit, push the OFF(O) side of the ON/
OFF switch (Fig. 7), and remove the battery.
10
Using the Spray Gun
mWARNING! High-pressure jets can be dangerous if
subject to misuse. The jet must not be directed at persons,
pets, live electrical equipment, or the appliance itself.
1. To use the spray gun, pull back the trigger to start the
water ow. Release the trigger to stop the water ow
(Fig. 8).
Fig. 8
Trigger
Pull back to
startwaterow
4. The spray gun is equipped with an adjustable nozzle and a
spray attachment. To assemble the spray attachment, rst
grab the end of the adjustable nozzle and unscrew it fully
to remove (Fig. 11).
Fig. 11
Adjustable nozzle
2. For continuous operation, push the trigger and lock it in
position 1 or position 2 (Fig. 9).
Fig. 9
Position 2
Position 1
3. The water ow can also be adjusted from wide, fan spray
to tight, pencil spray. Turn the nozzle counterclockwise for
pencil spray and clockwise for fan spray (Fig. 10).
Fig. 10
5. Insert the spray attachment rmly, as shown, and rotate
clockwise to lock it in place (Fig. 12).
Fig. 12
Spray attachment
Fan spray
Pencil spray
11
Maintenance
mCAUTION! Before working on the portable spray
washer, switch o the unit and remove the battery from
the compartment.
Bleeding the Air
During normal use, air may get trapped in the hose, which
will cause the pressure to drop. Bleeding the air before
using will allow air to escape and discharge residual pressure
in the hose.
1. Make sure the water tank is lled with clean water.
2. With the water tank cap removed and spray gun pointing
into the water tank, squeeze the trigger and start the
machine (Fig. 13).
Fig. 13
3. Wait for a few seconds until the water ow is steady.
The unit is ready for use.
Storage
mCAUTION! Always store your cordless spray washer in
a location where the temperature will not fall below 32ºF (0ºC).
The pump in this machine is susceptible to permanent damage
if it freezes. FREEZE DAMAGE IS NOT COVERED BY THE
WARRANTY.
• Store the spray washer indoors in a dry, covered area
where it is not subject to adverse weather conditions.
• It is important to store this product in a frost-free area.
• Always empty water from all hoses, the pump, and the
water tank before storing.
mCAUTION! The use of a pump protector is
recommended to prevent cold weather damage during storage
over the winter months.
Winterizing + long-term storage
If you must store your spray washer in a location where the
temperature falls below 32ºF (0ºC), you can minimize the
chance of damage to your machine by utilizing the following
procedure:
• Turn on the machine for a few seconds until the remaining
water in the pump exits. Turn o immediately.
• Do not allow the hose to become kinked.
• Store the machine and accessories in a room that does
not reach freezing temperatures.
• Do not store near a furnace or other sources of heat that
may dry out the pump seals.
• Operate the spray washer with non-corrosive/non-toxic
anti-freeze, a pump saver, or a pump protector before
storing for the winter.
mWARNING! Before reusing, completely ush the unit
out with clear water. Anti-freeze products can damage
paintwork, so you must ensure there is no anti-freeze left in the
system before using it again.
Disposal
Recycling the washer
• Do not dispose of appliances as unsorted municipal
waste. Use separate collection facilities.
• Contact your local government agency for information
regarding the collection systems available.
• If appliances are disposed of in landlls or dumps,
hazardous substances can leak into the groundwater and
get into the food chain, damaging your health and wellbeing.
• When replacing old appliances with new ones, the retailer
is legally obligated to take back your old appliance for
disposal at least free of charge.
Battery Caution + Disposal
Always dispose of your battery pack according to federal,
state, and local regulations. Contact a recycling agency in your
area for recycling locations.
mCAUTION! Even discharged battery packs contain
some energy. Before disposing, use electrical tape to cover
the terminals to prevent the battery pack from shorting, which
could cause a re or explosion.
mWARNING! To reduce the risk of injury or explosion,
never burn or incinerate a battery pack even if it is damaged,
dead or completely discharged. When burned, toxic fumes and
materials are emitted into the surrounding atmosphere.
12
1. Batteries vary according to device. Consult your manual
for specic information.
2. Install only new batteries of the same type in your product
(where applicable).
3. Failure to insert batteries in the correct polarity, as
indicated in the battery compartment or manual, may
shorten the life of the batteries or cause batteries to leak.
4. Do not mix old and new batteries.
5. Do not mix Alkaline, Standard (Carbon-Zinc) or
Rechargeable (Nickel Cadmium, Nickel Metal Hydride,
or Lithium-Ion) batteries.
6. Do not dispose of batteries in re.
7. Batteries should be recycled or disposed of as per state
and local guidelines.
Service + Support
If your Sun Joe® 24V-PSW2.5-SJG cordless portable spray
washer requires service or maintenance, please call the
Snow Joe® + Sun Joe® customer service center at
1-866-SNOWJOE (1-866-766-9563).
Model + Serial Numbers
When contacting the company, reordering parts, or arranging
service from an authorized dealer, you will need to provide the
model and serial numbers, which can be found on the decal
located on the housing of the unit. Copy these numbers into
the space provided below.
Record the following numbers from the housing or handle of your
new product:
2 4 V - P S W 2 . 5 - S J G
Model #:
Serial #:
13
Troubleshooting
• Remove battery from the unit before carrying out maintenance on the machine or when checking that its parts are in proper
working order.
• To avoid unnecessary hassles, consult the following table before contacting customer service with any mechanical issues.
Problems Possible Cause Possible Solution
Machine refuses
to start
Fluctuating pressure
Machine stops
Machine pulsating
Machine starts, but
no water comes out
• Battery is at.
• The battery protection system is
active.
• Pump sucking air.
• Valves dirty, worn out, or stuck.
• Pump seals worn out.
• Battery is at.
• Nozzle partially blocked.
• Inadequate supply of mains water.
• Nozzle partially blocked.
• Water lter blocked.
• Hose kinked.
• Pump/hoses or accessories frozen.
• No water supply.
• Water inlet lter blocked.
• Nozzle blocked.
• Charging the battery.
• Turn o the unit and wait for 10 minutes, then turn on
the unit again
• Check the hoses and connections are airtight.
• Clean or replace valves/seals.
• Please call the Snow Joe® + Sun Joe® customer
service center at 1-866-SNOWJOE (1-866-766-9563)
for assistance.
• Charging the battery.
• Clean the nozzle.
• Check that the water tank is lled.
• Clean the nozzle.
• Clean the water inlet lter.
• Straighten out the hose to remove any kinks/blockages.
• Wait for pump/hoses or accessories to thaw.
• Fill water in the water tank
• Clean the lter.
• Clean the nozzle.
14
Optional Accessories
mWARNING! ALWAYS use only authorized Snow Joe
®
+ Sun Joe® replacement parts and accessories. NEVER use
replacement parts or accessories that are not intended for use with this cordless spray washer. Contact Snow Joe® + Sun Joe® if
you are unsure whether it is safe to use a particular replacement part or accessory with your spray washer. The use of any other
attachment or accessory can be dangerous and could cause injury or mechanical damage.
ModelAccessories Item
1
2
3
4
5
24V iON+ 1.3 Ah Lithium-Ion Battery
Battery Charge Time Max:
24VCHRG-QC: 35 min | 24VCHRG-DPC: 35 min
Battery Runtime Max: 25 min
24V iON+ 2.0 Ah Lithium-Ion Battery
Battery Charge Time Max:
24VCHRG-QC: 55 min | 24VCHRG-DPC: 55 min
Battery Runtime Max: 38 min
24V iON+ 2.5 Ah Lithium-Ion Battery
Battery Charge Time Max:
24VCHRG-QC: 1 hr 20 min | 24VCHRG-DPC: 1 hr 10 min
Battery Runtime Max: 48 min
24V iON+ 4.0 Ah Lithium-Ion Battery
Battery Charge Time Max:
24VCHRG-QC: 1 hr 50 min | 24VCHRG-DPC: 1 hr 50 min
Battery Runtime Max: 76 min
24V iON+ 5.0 Ah Lithium-Ion Battery
Battery Charge Time Max:
24VCHRG-QC: 2 hr 20 min | 24VCHRG-DPC: 2 hr 30 min
Battery Runtime Max: 96 min
24VBAT-LTW
24VBAT-LTE
24VBAT-LT
24VBAT
24VBA-XR
6
24V iON+ Lithium-Ion Battery Quick Charger
24VCHRG-QC
7
24V iON+ Lithium-Ion Battery Charger 24VCHRG-DPC
NOTE: Accessories are subject to change without any obligation on the part of Snow Joe® + Sun Joe® to provide notice of such
changes. Accessories can be ordered online at sunjoe.com or via phone by contacting the Snow Joe® + Sun Joe® customer
service center at 1-866-SNOWJOE (1-866-766-9563).
15
NOTES
16
NOTES
17
NOTES
18
SNOW JOE® + SUN JOE® CUSTOMER PROMISE
ABOVE ALL ELSE, Snow Joe® + Sun Joe® are dedicated to you, our customer. We strive to make your experience as pleasant
as possible. Unfortunately, there are times when a product does not work or breaks under normal operating conditions. We
think it’s important that you know what you can expect from us. That’s why we created the Snow Joe® + Sun Joe® promise.
OUR PROMISE: Snow Joe® + Sun Joe® warrant new products for two years from the date of purchase. If your product does
not work, or there’s an issue with a specic part, we will x this by either sending you a free replacement part or by sending
you a new or comparable product at no charge. How cool is that! Before you know it, you’ll be back in action cutting,
sawing, mowing, washing and…?
PRODUCT REGISTRATION:
Snow Joe®, LLC (“Snow Joe® + Sun Joe®”) strongly encourages
you to register your purchase. You can register online at
snowjoe.com/ProductRegistration, or by printing and mailing
in a registration card available online from our website, or
calling our Customer Service Department at 1-866-SNOWJOE
(1-866-766-9563), or by e-mailing us at help@snowjoe.com.
Failure to register your product purchase will not diminish your
warranty rights. However, registering your purchase will allow
Snow Joe® + Sun Joe® to better serve you with any of your
customer service needs.
WHO CAN SEEK WARRANTY COVERAGE?
This Warranty is extended by Snow Joe® + Sun Joe® to the owner
of this Machine (a “Machine” consists of a product powered by
a motor) for residential and personal household use only. This
Warranty does not apply to products used for commercial, rental
or re-sale purposes. Should ownership of this machine change
during the 2-year period, please update the Machine’s owner
information at snowjoe.com/ProductRegistration.
WHAT IS COVERED?
Snow Joe® + Sun Joe® warrants to the owner that if this Machine
fails within 2 years from the date of purchase due to a defect in
material or workmanship or as a result of normal wear and tear
from ordinary household use, Snow Joe® + Sun Joe® will send a
replacement part or product, as needed, free of charge and with
free shipping to the original purchaser.
If, in Snow Joe® + Sun Joe®’s sole discretion, the failed Machine
cannot be repaired with a part, Snow Joe® + Sun Joe® will elect to
either (A) send a new Machine at no charge and with free shipping
or (B) refund the full purchase price to the owner.
WHAT IS NOT COVERED?
This Warranty does not apply to the Machines that have been used
commercially or in non-household applications. This Warranty
does not cover cosmetic changes that do not aect performance.
This Warranty is only valid if the Machine is used and maintained
in accordance with the instructions, warnings and safeguards
contained in the owner’s manual. Snow Joe® + Sun Joe® will not
be responsible for the cost of any unauthorized warranty repairs.
This warranty does not cover any cost or expense incurred by
the purchaser in providing substitute equipment or service during
reasonable periods of malfunction or non-use of this product
while waiting for a replacement part or unit under this warranty.
Wearing parts like belts, augers, chains and tines are not covered
under this warranty, and can be purchased at snowjoe.com or
by calling 1-866-SNOWJOE (1-866-766-9563). Batteries are
covered in full for 90-days from the date of purchase.
Repair, replacement or refund of the purchase price are the
exclusive remedies of purchaser and the sole liability of Snow Joe®
+ Sun Joe® under this warranty. No employee or representative
of Snow Joe® + Sun Joe® is authorized to make any additional
warranty or any modication to this warranty which may be
binding upon Snow Joe® + Sun Joe®. Accordingly, purchaser
should not rely upon any additional statements made by any
employee or representative of Snow Joe® + Sun Joe®. In no event,
whether based on contract, indemnity, warranty, tort (including
negligence), strict liability or otherwise, shall Snow Joe® +
Sun Joe® be liable for any special, indirect, incidental, or
consequential damages, including, without limitation, loss of
prot or revenue.
Some states do not allow limits on warranties. In such states, the
above limitations may not apply to you.
Outside the USA, other warranties may apply.
19
sunjoe.com
Loading...
