Models
HV38
HV48
HV56
HV74
HVK48
HVK56
HVK74
Encore Series - HV Non-Refrigerated Service Case
Applications
• Service
merchandiser for
non-refrigerated
bakery items.
EXTERIOR COLOR
INTERIOR COLOR
REAR EXTERIOR COLOR
TRIM COLOR
END PANELS
FRONT GLASS
FRONT PANEL
REAR DOORS
SHELVING
LIGHTS
ELECTRICAL CONNECT
MISCELLANEOUS
□ Painted
□ Black
□ White
□ Black
□ None (Specify per line-up)
□ Curved single pane, lift-up front glass
on HV(L) models and Flat angled
single pane, lift-up front glass on
HVK(L) models
□ Clear glass rear sliding doors
□ Wire rack shelf(s), lighted
□ T-8 top & shelf lights
□ Leads
Options Features Standard
□ Laminated (confirm pattern/grain direction)
□ Stainless steel
□ Stainless steel
□ White
□ Black
□ Stainless steel
□ Silver
□ Case to case glass end
□ Cutaway with glass
□ Full with mirror
□ Flat front panel
□ Reflective glass rear sliding doors
□ LED top & shelf lights
□ 6' straight blade power cord (self-cont.)
□ 1'' bumper on front & ends
□ Angled deck (n/a w/display step/riser)
□ Price tag moulding
Revised
20014268
4/17/2015
ONE PART PASSION, TWO PARTS SCIENCE
(Lengths do not include 1 " end panels)
(Lengths do not include 1 " end panels)
Encore Series HV Non-Refrigerated Service Case
HV38 38"L x 42"D x 51-1/4"H
Model
HV48 48"L x 42"D x 51-1/4"H
HV56 56"L x 42"D x 51-1/4"H
HV74 74"L x 42"D x 51-1/4"H
Model
HVK48 48"L x 42"D x 51-1/4"H
HVK56 56"L x 42"D x 51-1/4"H
HVK74 74"L x 42"D x 51-1/4"H
L x D x H
L x D x H
STANDARD
FLAT GLASS OPTIONS
IMPORTANT
NOTES:
1) 43'' minimum door entry
clearance required
(without shipping skid).
2) Units are supplied with
levelers which must be
adjusted during
installation to ensure the
unit is level and plumb.
3) Dimensions reflect
levelers extended 1-1/4''.
INTENDED
ENVIRONMENT
Designed to operate in
ambient conditions of 75°F
with 55% relative humidity.
INTEGRATED AVG
PRODUCT TEMP
Zone Temp (°F)
Ambient All
INTENDED USE OF
DISPLAY AREAS
Zone Intended Use
Unpackaged
All
non-refrigerated
products
INFORMATION IS SUBJECT TO CHANGE WITHOUT NOTICE. Visit www.structuralconcepts.com for the most current specs.
888 E. Porter Rd. Muskegon, MI 49441 231-798-8888
For more information on any
of our products or services
please visit us on the web at:
www.structuralconcepts.com
Revised
4/17/2015
