Models
HV3
HV4
HV5
HV6
HV8
HV10
Applicati ons
• For refriger ated or non-
refriger ated products.
• Forced air ref ri ger ation
• Medium temperature
integrated average
41ºF
• Designed to be used
with HVO & HVAD
models
HV Series - HVG Service Cases
Service merchandisers for bakery produc ts
Standard Features
• Black interior
• Painted exterior
• Black trim
• No end panel s (specify en ds per lin eup)
• Curved single pane li ft- up fro nt glas s
• Clear glass rear sliding doors
• White rear exterior
• Lighted clear glass shelves on
refrigerated models; wire racks on
non-refrigerated models
• T-8 top & shelf lights
• Electrical leads
• Rear electrical access
• Levelers
• Remote refrige ration with TXV
• ABS front panel
• ETL certified to CAN/CSA 22.2,
conforms to U L 65, UL 471, NSF2 &
NSF 7
• White or stai nless steel interior
• Stainless steel or laminated exterior
• Silver trim
• Full w/mirror , cutaway or case to case end
• Straight single pane lift-up front glass
• Reflective glass rear sliding doors
• Black or stainless steel rear exterior
• Lighted smok e glass shelves on refrigerated
• 1” bumper on front & ends
• Breeze™ self- c ontained refrigeration wit h 6’
• Price tag molding
• Angled deck
• Non-refri ger ated for ambient display
Options
panels.
models
power cord - specif y l ev eler s, c aster s or 6”H
legs
ONE PART PASSION, TWO PARTS SCIENCE
Specifications - HVG Cases
STANDARD
Model L*xDxH
HV3 38”x42”x51-1/4”
HV4 48”x42”x51-1/4”
HV5 56”x42”x51-1/4”
HV6 74”x42”x51-1/4”
HV8 96”x42”x51-1/4”
HV10 112”x42”x51-1/4”
*without 1” end panel s
Non-refrigerated
IMPORTANT NOTES
43” minimum door entry c learance
required (without shi ppi ng skid).
Units are suppl ied with levelers which
must be adjusted during in stallation to
ensure the unit is level and pl umb.
Dimensi ons reflect l evelers ext ended
1-1/4”.
INTENDED ENVIRONMENT
Design ed t o op er ate in ambient
conditi ons of 75 °F w it h 55% relati ve
humidity.
Integrated average product
temperature of 41° F.
Ambient product temperature (nonrefrig er ated option) .
INTENDED USE
Unpack ag ed products
For more information on any of
our products or services please
visit us on the web at:
www.structuralconcepts.com
INFORMATION IS SUBJECT TO CHANGE WITHOUT NOTICE.
888 E. Porter Rd. Muskegon, MI 49441 231-798-8888
5/5/2010 REV: A
