Models
DP58H
DP610H
DP812H
DP1016H
Food Bars - DPHSS Heated Pan Modular Self-Service Inline
Case
Applications
• One-sided Inline
hot-well modular unit
for self-service pans.
• Heated pan module
designed to be used
with refrigerated pan
& soup modules.
EXTERIOR COLOR
PACKAGE LEDGE
STORAGE AREA
WELL ASSEMBLY
SNEEZE GUARD
UPPER BACK PANEL
LIGHTS
ELECTRICAL CONNECT
HEATED WELLS
MISCELLANEOUS
□ Laminated (confirm pattern/grain
direction)
□ Solid surface (specify color & mfr.)
□ None
□ Stainless steel
□ Clear glass top, sides & sneeze guard
□ Mirror back panel
□ T-8 top light
□ Leads
□ Independently heated wells controlled
by thermostat
□ Removable sign channel
Options Features Standard
□ Stainless steel
□ Dry storage drawer in base
□ Open back panel
□ LED top light
Revised
20015242
4/22/2015
ONE PART PASSION, TWO PARTS SCIENCE
(Lengths include end panels)
Food Bars DPHSS Heated Pan Modular Self-Service Inline
Case
DP58H 68"L x 40-3/8"D x 58-1/2"H
Model
DP610H 81"L x 40-3/8"D x 58-1/2"H
DP812H 94"L x 40-3/8"D x 58-1/2"H
DP1016H 120"L x 40-3/8"D x 58-1/2"H
L x D x H
STANDARD
IMPORTANT
NOTES:
INTENDED
ENVIRONMENT
Designed to operate in
ambient conditions of 75°F
with 55% relative humidity.
INTEGRATED AVG
PRODUCT TEMP
Zone Temp (°F)
160 All
INTENDED USE OF
DISPLAY AREAS
Zone Intended Use
Unpackaged heated
All
product
INFORMATION IS SUBJECT TO CHANGE WITHOUT NOTICE. Visit www.structuralconcepts.com for the most current specs.
888 E. Porter Rd. Muskegon, MI 49441 231-798-8888
For more information on any
of our products or services
please visit us on the web at:
www.structuralconcepts.com
