STIHL SE 122
Instruction Manual
Notice d’emploi
G Instruction Manual
1 - 14
F Notice d’emploi
15 - 29
Contents
English
Guide to Using this Manual 2
Safety Precautions and Working
Techniques 2
Lock the machine in position 5
Assembling the Unit 5
Connecting to Power Supply 6
Switching On 7
Working 8
Original Instruction ManualPrinted on chlorine-free paper
Switching Off 8
After Finishing Work 9
Emptying the container 9
Cleaning the filter element 10
Replacing the filter element 10
Maintenance and Care 11
Troubleshooting 12
Main Parts 13
Specifications 14
Maintenance and Repairs 14
Disposal 14
Printing inks contain vegetable oils, paper can be recycled.
Dear Customer,
Thank you for choosing a quality
engineered STIHL product.
It has been built using modern
production techniques and
comprehensive quality assurance.
Every effort has been made to ensure
your satisfaction and trouble-free use of
the product.
Please contact your dealer or our sales
company if you have any queries
concerning this product.
Your
Dr. Nikolas Stihl
© ANDREAS STIHL AG & Co. KG, 2022
0458-649-8221-B. VA0.M21.
0000004025_012_GB
SE 122, SE 122 E
This instruction manual is protected by copyright. All rights reserved, especially the rights to reproduce, translate and process
with electronic systems.
1
English
Guide to Using this Manual Safety Precautions and
Working Techniques
Pictograms
All the pictograms attached to the
machine are shown and explained in this
manual.
Symbols in text
WARNING
Warning where there is a risk of an
accident or personal injury or serious
damage to property.
NOTICE
Caution where there is a risk of
damaging the machine or its individual
components.
Engineering improvements
STIHL's philosophy is to continually
improve all of its products. For this
reason we may modify the design,
engineering and appearance of our
products periodically.
Therefore, some changes, modifications
and improvements may not be covered
in this manual.
WARNING
– Minors should never be allowed to
operate this power tool. Supervise
children to make sure that they do
not play with the unit.
– Do not pass on or lend the unit to
persons who are not familiar with
this model and its handling – always
include the User Manual.
– Disconnect plug from wall outlet
before performing any work on the
machine, e.g. cleaning,
maintenance, replacing parts.
Observe all applicable local safety
regulations, e.g., by employers' liability
insurance associations, social insurance
systems, occupational safety
authorities, etc.
When the unit is not in use, shut it off so
that it does not endanger others. Secure
it against unauthorized use and
disconnect the mains plug.
Special safety precautions are necessary when
using the unit. The power
supply is a particular
source of danger.
Before commissioning, it
is important to read and
understand the User
Manual and to keep it in a
safe place for future reference. Failure to
observe the User Manual
may lead to serious or
even fatal injury.
The unit may only be used by persons
who have been instructed in its use and
handling or who can demonstrate that
they can operate the tool safely.
The unit can be used by persons with
limited physical, sensory or mental
capacity or with little experience and
know-how as long as they are
supervised and have been instructed on
how to handle the unit safely and
understand the risks associated with it.
The user is responsible for accidents or
risks involving third parties or their
property.
If you have not used this unit before:
Have your dealer or a trained expert
show you how to operate it safely.
Before each use, check that the unit is in
proper condition. Pay special attention
to the connecting cable, mains plug and
safety devices.
Inspect the connecting cable regularly
for signs of damage and aging. Never
use the unit if the connecting cable is
damaged – Danger of electrocution!
Do not use the connecting cable to pull
or transport the unit.
Connect only electric power tools to the
socket outlet – see "Connecting the tool
to the power supply" and "Turning on the
tool".
Do not use a high-pressure washer to
clean the unit. The solid jet of water may
damage parts of the unit.
Never spray the upper part of the
vacuum cleaner with water – Danger of
a short circuit!
2
SE 122, SE 122 E
English
Accessories and Spare Parts
Only use parts and accessories that are
explicitly approved for this power tool by
STIHL or are technically identical. If you
have any questions in this respect,
consult your dealer. Use only high
quality parts and accessories.
Otherwise, there is a risk of accidents
and damage to the unit.
STIHL recommends the use of original
STIHL parts and accessories. They are
specifically designed to match the
product and meet your performance
requirements.
Never attempt to modify your power tool
in any way since this may increase the
risk of personal injury. STIHL excludes
all liability for personal injury and
damage to property caused while using
unauthorized attachments.
Applications
The unit is suitable for commercial use,
such as in hotels, schools, hospitals,
industry, stores, offices and rental
property businesses.
Vacuum dry, non-flammable materials
(dust, dirt, broken pieces of glass, wood
chips, shavings, sand, etc.) and nonflammable liquids (wastewater, spilled
juice, etc.)
Do not vacuum hot materials (hot ashes,
flammable explosive
dust, glowing cigarette
butts, etc.), flammable
liquids (gasoline, thinners, etc.) or aggressive
liquids (acids, alkalis) –
Danger of fire or
explosion!
The unit is not suitable for harmful dusts.
Other uses of the unit are not permitted
and may lead to accidents or damage to
the unit. The unit must not be modified in
any way – this may also lead to
accidents or damage to the unit.
Transporting the Unit
For safe transportation in and on
vehicles, attach the unit with straps so
that it does not slide or tip over.
Do not tilt the unit if there is liquid in the
tank.
Before transporting it, engage all locks
on the tank.
Before Starting Work
Check the unit
– It must be possible to move the
switch to the 0 position easily
– The switch must be in the 0 position.
To reduce the risk of accidents and
personal injury, do not operate the unit if
it is not in proper condition!
Only operate the unit if all of its
components are undamaged and
securely mounted.
Before vacuuming liquids or wet
materials, remove the filter bag and
check the functioning of the float. Always
use the filter element when working.
Never attempt to modify the controls or
safety devices.
Electrical connection.
Reduce the risk of electric shock:
– Voltage and frequency of the
machine (see rating plate) and the
voltage and frequency of your
power supply must be the same.
– Examine the connecting cord,
power plug and extension cord for
damage. Damaged cords,
couplings and plugs or connecting
cords that do not comply with the
regulations must not be used
– Only connect electrical connector to
a properly installed wall outlet.
– Only use extension cords that
comply with the regulations for the
intended application.
– Check that the insulation of the
connection cable, extension cord,
plug and coupling is in good
condition.
Position the connection cable and
extension cord correctly:
– Check minimum cross section of
wires (wire gauge) – see
"Connecting to Power Supply".
– To reduce the risk of stumbling,
position and mark the connecting
cord so that it cannot be damaged
or endanger others.
SE 122, SE 122 E
3
English
– Using unsuitable extension cords
can be dangerous. Only use
extension cords that are approved
for outdoor use, are appropriately
labeled and have a sufficient cable
cross-section.
– The plug and coupling of the
extension cord must be waterproof
or routed in such a way that they
cannot come into contact with water
– the plug and coupling of the
extension cord must not be
immersed in water.
– Do not allow cord to rub on edges or
pointed or sharp objects.
– don't trap or squeeze the cord in or
under doors or windows
– If cords are twisted – unplug the
power tool and straighten them out
– Always unwind the extension cord
completely from the cable reel to
reduce the risk of fire from
overheating.
While Working
If the power cord is damaged, immediately
disconnect the plug from
the wall outlet to avoid
the risk of electric shock.
Avoid damage to the power supply cord.
Do not drive over it, pinch or tug it.
Never pull the connection cable to
disconnect it from the wall outlet. To
unplug, grasp the mains plug, not the
cable.
Only touch the mains plug, connection
cable and extension cord and electrical
plug connections with dry hands.
Never spray electrical devices with
water – Danger of a short circuit!
To reduce the risk of a
short circuit or electrocution, never work with the
vacuum cleaner in the
rain or in wet or very
damp locations!
In the event of imminent danger or in an
emergency – move switch to 0 .
Never leave a running unit unattended.
Do not leave the unit outdoors in the
rain.
Only operate the unit while standing. Do
not cover the unit; ensure adequate
motor ventilation.
Only vacuum with undamaged filter
element.
If foam develops or liquid leaks, end
work immediately, pull mains plug and
empty tank.
If the unit is subjected to unusual stress
for which it was not designed (e.g.,
heavy impact or a fall), always check
that it is in safe operating condition
before continuing work – see also
"Before Starting Work". Make sure the
safety devices are working properly. Do
not continue operating the machine if it
is damaged. In case of doubt, contact a
dealer.
Before leaving the unit unattended: Turn
it off and disconnect the mains plug.
After Finishing Work
Disconnect the mains plug from the wall
outlet.
Never jerk the connecting cord to
disconnect it from the wall outlet. To
unplug, grasp the plug, not the cord.
Always clean dust and dirt off the unit –
do not use any grease solvents for this
purpose.
Maintenance and repairs
WARNING
Before starting any work
on the machine: Always
disconnect the machine
from the mains power
supply.
– Use only high-quality spare parts.
Otherwise, there may be a risk of
accidents and damage to the unit. If
you have any questions in this
respect, consult a servicing dealer.
– To avoid risks, work on the machine
(e. g. replacing a damaged
connecting cord) may only be
carried out by authorized dealers or
qualified electricians.
Clean plastic parts with a cloth. Harsh
detergents may damage the plastic.
Clean ventilation slots in motor housing
as needed.
The machine must be serviced regularly.
Do not attempt any maintenance or
repair work not described in the
Instruction Manual. All other work should
be carried out by a servicing dealer.
4
SE 122, SE 122 E
English
649BA006 KN
649BA001 KN
1
2
1
STIHL recommends the use of genuine
STIHL spare parts. Such parts have
been optimized for the machine and the
user's requirements.
STIHL recommends that maintenance
and repair work be carried out only by
authorized STIHL dealers. STIHL
dealers receive regular training and are
supplied with technical information.
Lock the machine in position
Apply the brake on the caster to lock the
machine in a particular position.
Assembling the Unit
Various accessory parts must be
mounted on the machines before
starting for the first time.
WARNING
Do not plug the power cord into the
outlet until the machine is completely
assembled.
N Release the latches (1)
N Lift the upper part of the vacuum
SE 122, SE 122 E
cleaner (2) vertically up and off
N Remove the accessories from the
container
5
English
649BA002 KN
3
649BA003 KN
4
5
649BA004 KN
A
649BA005 KN
6
8
7
N Push filter bag sleeve onto intake
port as far as possible (see
instructions on filter bag)
N Refit the upper part of the vacuum
cleaner (2) and close the latches (1)
– ensure that the latches engage
properly
N Push the suction hose into the
connector
N Push the handle tube (3) into the
sleeve of the suction hose
N Push extension tube (4) onto the
handle tube
To connect other tools (e. g., grinding
machine):
N Fit adapter for power tools (5)
(supplied with the model SE 122 E)
to suction hose instead of handle
tube
N Mount extension tube holder at a
distance (A) of approx. 20 cm from
the bottom edge of the extension
tube
N Depending on the intended use of
the vacuum, fit the crevice tool (6),
all-purpose tool (7) or floor tool (8)
onto the extension tube.
Connecting to Power Supply
The voltage and frequency of the
machine (see rating plate) must match
the voltage and frequency of the power
connection.
The minimum fuse protection of the
power connection must comply with the
specifications – see "Specifications".
The machine must be connected to the
power supply via an earth-leakage
circuit breaker to disconnect the power
supply if the differential current to earth
exceeds 30 mA.
The power connection must correspond
to IEC 60364 and relevant national
regulations.
Extension Cords
Make sure your electrical cord set is in
good condition and suitable for outdoor
use. When using an extension cord, be
sure to use one heavy enough to carry
the current your product will draw. An
undersized extension cord may cause a
drop in line voltage resulting in loss of
power and overheating. The table below
shows the correct size (AWG) to use for
your machine (Cord types SJW or
SJTW) depending on cord length and
nameplate ampere rating. If in doubt,
use the next heavier gauge. The smaller
the gauge number, the heavier the cord.
Cord length (ft) Wire gage (AWG)
50 16
100 14
150 12
6
SE 122, SE 122 E
English
645BA017 KN
649BA007 KN
1
0
auto
I
2
Appropriate extension cords are
available in special stores for electrical
equipment or from your STIHL dealer.
Connection to the power supply socket
Before connection to the power supply,
check that the machine is switched off –
see "Switching off the machine"
N Plug the power cord or extension
cord into a properly installed outlet
Switching On
SE 122
Switch positions
Switch position 0 – vacuum cleaner is
switched off
Switch position I – vacuum cleaner is
switched on
N To switch on, turn master switch to I
SE 122 E
N Switch off the vacuum cleaner and
the electric power tool that is to be
connected prior to connection to the
machine socket (1).
N The machine is switched on and off
or to automatic mode by means of
the switch (2). The suction power is
adjusted manually by turning the
switch.
Switch positions
Switch position 0 – Vacuum cleaner is
switched off, the socket outlet cannot be
used.
Switch position I – Vacuum cleaner is
switched on, the socket outlet cannot be
used.
Switch position auto – The power tool
connected to the machine socket
switches the vacuum cleaner on and off
via the automatic function.
The connected power tool must be
switched off before setting the master
switch to the "auto" position.
The motor runs on for a few seconds
after switching off in order to empty the
suction hose.
N To switch on, set master switch to
the corresponding switch position
SE 122, SE 122 E
Power tools can be plugged into the
machine socket (1). Do not exceed the
maximum connected load of the
machine socket – see "Specifications".
7
English
auto
649BA020 KN
SE 122
SE 122 E
Working Switching Off
Vacuuming dry materials
WARNING
Flammable materials must not be
vacuumed.
Always make sure that the filter bag has
been fitted in the container before
vacuuming dry materials. The
vacuumed material can then be
disposed of without difficulty. Dry
materials can also be vacuumed without
filter bag.
NOTICE
Never use the vacuum cleaner with a
damaged filter element or without the
filter element.
Vacuuming liquids
material is vacuumed while it is still
damp. For this reason, the filter element
should be dried or replaced by a dry filter
element before vacuuming dry
materials.
N Turn the master switch to 0
N Unplug the power plug from the
socket
WARNING
Flammable liquids must not be
vacuumed.
Always remove the filter bag and check
operation of the float before vacuuming
liquids. The float switches off the air
stream when the container is full. If the
machine is exclusively used for wetvacuuming, the filter element should be
replaced by a special insert (special
accessory).
The filter element is damp after
vacuuming liquids. The filter element is
likely to clog up more quickly if dry
8
SE 122, SE 122 E
Loading...
