STIHL AL 1
Instruction Manual
Manual de instrucciones
WARNING
Read Instruction Manual thoroughly before use and
follow all safety precautions – improper use can cause
serious or fatal injury.
ADVERTENCIA
Antes de usar la máquina lea y siga todas las precauciones
de seguridad dadas en el manual de instrucciones – el uso
incorrecto puede causar lesiones graves o mortales.
Instruction Manual
1 - 13
Manual de instrucciones
14 - 26
Contents
English
1 INTRODUCTION
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 GUIDE TO USING THIS MANUAL
2.1 Signal Words
2.2 Symbols in Text
3 MAIN PARTS
3.1 Charger
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4 SAFETY SYMBOLS ON THE PRODUCT
4.1 Charger
Original Instruction ManualPrinted on chlorine-free paper
5 IMPORTANT SAFETY INSTRUCTIONS
5.1 Introduction
5.2 Intended Use
5.3 Warnings and Instructions
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . .
6 MAINTENANCE, REPAIR AND STORAGE
6.1 Warnings and Instructions
7 CHARGING THE BATTERY
7.1 Setting up the Charger
7.2 Charging
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7.3 Mounting the Charger on a Wall
8 LED DIAGNOSTICS
8.1 LED on the Charger
9 TRANSPORTING
9.1 Charger
Printing inks contain vegetable oils, paper can be recycled.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
10 STORING
10.1 Charger
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
11 INSPECTION AND MAINTENANCE
11.1 Charger
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
12 TROUBLESHOOTING GUIDE
12.1 Charger
13 SPECIFICATIONS
13.1 STIHL AL 1
13.2 Symbols on the Charger
13.3 Engineering Improvements
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . .
. . . . . . . . . . . . .
. . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . .
13.4 FCC 15 Information to the User
2
13.5 Supplier's Declaration of Conformity
2
14 REPLACEMENT PARTS AND EQUIPMENT
2
14.1 Genuine STIHL Replacement Parts
2
15 DISPOSAL
2
15.1 Disposal of the Charger
2
16 LIMITED WARRANTY
3
16.1 STIHL Incorporated Limited Warranty Policy
3
17 TRADEMARKS
3
17.1 Registered Trademarks
3
17.2 Common Law Trademarks
3
18 ADDRESSES
4
18.1 STIHL Incorporated
5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5
6
6
6
7
7
7
8
8
8
8
8
8
10
10
11
11
11
11
. . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . .
. . . . . . .
. . . . . . . . . . . . . . . .
. . . . . . .
11
12
12
12
12
12
12
12
12
12
13
13
13
© ANDREAS STIHL AG & Co. KG 2020
0458-967-8621-A. VA2.K20.
0000008781_002_GB
0458-967-8621-A
This instruction manual is protected by copyright. All rights reserved, especially the rights to reproduce, translate and process
with electronic systems.
1
English
1 INTRODUCTION
1 INTRODUCTION
Thank you for your purchase. The information contained in
this manual will help you receive maximum performance and
satisfaction from your STIHL charger and, if followed,
reduce the risk of injury from its use.
SAVE THIS MANUAL!
Special safety precautions must be observed to
reduce the risk of personal injury.
Read this instruction manual thoroughly before
use and periodically thereafter. Follow all safety
precautions. Careless or improper use of the
charger can cause serious or fatal injury.
Do not lend or rent your charger without this instruction
manual. Allow only persons who fully understand the
information in this manual to operate the charger.
For further information, or if you do not understand any of
the instructions in this manual, please go to
www.stihlusa.com (for Canada: www.stihl.ca) or contact
your authorized STIHL servicing dealer.
2 GUIDE TO USING THIS
MANUAL
2.1 Signal Words
This manual contains safety information that requires your
special attention. Such information is introduced with the
following symbols and signal words:
DANGER
Indicates a hazardous situation that, if not avoided, will
result in death or serious injury.
WARNING
Indicates a hazardous situation that, if not avoided, could
result in death or serious injury.
NOTICE
Indicates a risk of property damage, including damage to the
machine or its individual components.
2.2 Symbols in Text
The following symbol is included to assist you with the use
of the manual:
Refers to a designated chapter or sub-chapter in this
instruction manual.
3 MAIN PARTS
3.1 Charger
2
3
1
#
1Charger LED
Indicates the operating status of the charger.
2 Power Supply Cord
Supplies the charger with electricity when plugged into
an electrical outlet.
3Plug
Connects the power supply cord to an electrical outlet.
0000-GXX-9294-A1
2
0458-967-8621-A
4 SAFETY SYMBOLS ON THE PRODUCT
English
# Rating Plate
Contains electrical information and the product's serial
number.
4 SAFETY SYMBOLS ON THE
PRODUCT
4.1 Charger
The following safety symbols are found on the charger:
To reduce the risk of injury, follow the specified
safety precautions.
Read and follow all safety precautions in the
instruction manual. Improper use can lead to
serious or fatal personal injury or property
damage.
To reduce the risk of personal injury or property
damage from fire or electric shock, keep the
charger dry. Protect it from rain, water, liquids
and damp conditions. For indoor use only, @ 5.
5 IMPORTANT SAFETY
INSTRUCTIONS
5.1 Introduction
This section contains the prescribed general safety
warnings and instructions for battery chargers. Additional
important warnings and instructions are provided in
subsequent sections of this manual.
READ ALL INSTRUCTIONS BEFORE USING THE
CHARGER!
WARNING
￭ When using battery chargers, basic safety precautions
should always be followed to reduce the risk of fire,
electric shock and personal injury and property damage,
including the following:
1)SAVE THESE INSTRUCTIONS – This manual contains
important safety instructions for the STIHL AL 1 battery
charger.
2)Before using the battery charger, read all instructions and
cautionary markings on the charger, battery and product
using the battery.
3)CAUTION – To reduce the risk of injury, use the STIHL
AL 1 to charge only genuine STIHL AS series batteries.
Other types of batteries may burst causing serious
personal injury and property damage.
5.2 Intended Use
WARNING
￭ The STIHL AL 1 charger is designed for charging
STIHL AS series batteries only.
￭ Improper use could result in personal injury or property
damage, including damage to the charger.
– Use the charger only as described in this manual.
– Never attempt to modify or override the charger's
controls or safety devices in any way.
– Never use a charger that has been modified or
altered from its original design.
0458-967-8621-A
3
English
5 IMPORTANT SAFETY INSTRUCTIONS
5.3 Warnings and Instructions
WARNING
￭ To reduce the risk of fire, electric shock and other
personal injury or property damage:
– Before using the charger, read this instruction
manual and all instructions and warnings on the
charger, battery and product using the battery.
– Use the STIHL AL 1 to charge only genuine
STIHL AS series batteries. Other batteries may
burst, catch fire or explode, resulting in personal
injury and property damage.
– For indoor use only.
– Keep the charger dry. Protect it from
rain, water, liquids and damp conditions.
Never insert a wet battery or use a wet
charger.
– Do not handle the charger, including power supply
cord and plug, with wet hands.
– Never use a damaged charger.
– Never charge malfunctioning, damaged, cracked,
leaking or deformed batteries.
– Never store a battery in the charger.
– Operate the charger only indoors, in dry rooms.
– Never operate the charger at ambient temperatures
below - 4 °F (- 20 °C) or above 122 °F (50 °C). For
optimum performance, STIHL recommends
operating the charger within an ambient temperature
range of 41 °F to 86 °F (5 °C to 30 °C).
– Keep the charger out of the reach of children.
– Always plug the charger into a properly installed
electrical outlet matching the voltage and electrical
frequency stated on the charger.
– Never use power strips to operate multiple chargers
or other devices from the same outlet or on the same
circuit.
– Do not operate a charger that has received a sharp
or heavy blow, has been dropped or is otherwise
damaged in any way.
– Do not attempt to repair, open or disassemble the
charger. There are no user-serviceable parts inside.
￭ To reduce the risk of electric shock or fire from a short
circuit:
– Make sure the battery and charger are completely
dry before starting the charging process.
– Never bridge the contacts of the charger with wires
or other metallic objects.
– Do not insert any objects into the charger’s cooling
slots.
￭ The charger heats up during the charging process. To
reduce the risk of fire:
– Do not operate on a combustible surface (e.g.,
paper, cardboard, textiles) or in a combustible
environment.
– Allow the charger to cool down normally. Do not
cover it.
￭ Chargers can produce sparks which may ignite
combustible gases, liquids, vapors, dusts or other
combustible materials. To reduce the risk of fire and
explosion:
– Do not operate in a location where combustible
gases, liquids, vapors, dusts or other combustible
materials are present.
￭ Using a damaged power supply cord or plug may result in
fire, electric shock and other personal injury or property
damage. To reduce these risks:
– Check the charger’s power supply cord
and plug regularly for damage. If
damaged, immediately disconnect the
plug from the electrical outlet.
– Have a damaged power supply cord replaced by an
authorized STIHL servicing dealer.
– Unplug the power supply cord from the outlet when
the charger is not in use.
4
0458-967-8621-A
6 MAINTENANCE, REPAIR AND STORAGE
English
– Never jerk the power supply cord to disconnect it
from the electrical outlet. To unplug, grasp the plug,
not the power supply cord.
– Do not use the power supply cord for carrying or
hanging up the charger.
– Make sure the power supply cord is located or
marked so that it will not be stepped on, tripped over,
come in contact with sharp objects or moving parts,
or otherwise be subjected to damage or stress.
￭ An extension cord should not be used unless absolutely
necessary. Overloading an extension cord can result in
overheating and fire. If an extension cord must be used:
– Use only a properly wired 16 gauge (AWG 16) or
heavier gauge extension cord.
– Never connect more than one charger or other
device to an extension cord.
– Never use an extension cord with a wattage rating
lower than the wattage on your charger’s rating
plate.
– Never use an extension cord if the blades on its plug
are different from the blades on the charger plug in
number, size or shape.
– Do not link (chain) extension cords.
￭ A typical household electrical circuit is between 15 and
20 amps. A single STIHL AL 1 charger draws
approximately 0.275 amps. To reduce the risk of fire from
overloading an electrical circuit:
– Ensure the electrical system is rated to withstand the
expected electrical draw before charging your
battery.
– Charge multiple batteries one at a time or on
separate circuits, unless you know your circuit can
handle the total expected draw from multiple
chargers.
￭ In case of fire, or if the charger or the battery it is charging
emits smoke, an unusual smell, feels hot or appears
abnormal in any other way:
– Immediately disconnect the charger from the outlet
and prepare to contact the authorities in the event of
fire or explosion.
￭ To reduce the risk of electric shock and other personal
injury or property damage when mounting the charger:
– Ensure that no electrical cables, pipes or other
service lines run behind the wall where the charger
is to be mounted.
– Mount the charger only as described in this manual.
– Remove the battery before mounting the charger.
6 MAINTENANCE, REPAIR
AND STORAGE
6.1 Warnings and Instructions
WARNING
￭ There are no user-authorized repairs for the charger. To
reduce the risk of fire, electric shock or other personal
injury and property damage:
– Do not attempt to repair, open or disassemble the
charger. There are no user-serviceable parts inside.
– Users may carry out only the cleaning and
maintenance operations described in this manual.
￭ To reduce the risk of electric shock:
– Unplug the charger from the electrical outlet before
inspecting or cleaning the charger.
– Regularly check the electrical contacts of the
charger and ensure that the insulation of the power
cord and plug are in good condition and show no
signs of aging (brittleness), wear or damage.
– Have a damaged power supply cord replaced by an
authorized STIHL servicing dealer.
0458-967-8621-A
5
English
7 CHARGING THE BATTERY
￭ Improper storage can result in unauthorized use, damage
to the charger, and an increased risk of fire, electric shock
and other personal injury or property damage.
– Never store the charger with the battery inserted.
– Before storing, always unplug the charger from the
electrical outlet and remove the battery.
– Store the charger indoors in a dry, secure place that
cannot be accessed by children or other
unauthorized users.
SAVE THESE
INSTRUCTIONS
7 CHARGING THE BATTERY
7.1 Setting up the Charger
WARNING
Read and follow the safety precautions on the battery and
charger and the warnings and instructions in this manual,
@ 5. To reduce the risk of short circuit, which could lead to
electric shock, fire and explosion, make sure the charger
and its components are dry and not damaged; operate the
charger indoors at an appropriate ambient temperature,
@ 5.
WARNING
Since the battery and charger heat up during the charging
process, do not operate the charger on a combustible
surface or in a location where combustible gases, liquids,
vapors, dusts or other materials are present, @ 5.
To set up the charger:
4
3
1
► Insert the plug (3) into a properly installed wall outlet (4)
matching the voltage and electrical frequency stated on
the rating plate on the charger.
The charger runs a self-test immediately after it is plugged
in. The LED (1) will glow green for about 1 second, then it
will glow red briefly before going out. Once the LED goes
out, the self-test is complete and the charger is ready to
charge the battery.
► Position the power supply cord (2) so that it will not be
stepped on, tripped over, come in contact with sharp
objects or moving parts or otherwise be subjected to
damage or stress.
2
7.2 Charging
WARNING
STIHL batteries contain safety features and devices which,
if damaged, may allow the battery to generate heat, rupture,
leak, ignite or explode. Never charge a malfunctioning,
damaged, cracked, leaking or deformed battery or use a
charger that has been damaged, @ 5. Make sure the
charger and the battery to be charged are both completely
dry before charging, @ 5.3. Follow all product-specific
warnings and instructions accompanying your battery.
0000-GXX-9295-A0
6
0458-967-8621-A
8 LED DIAGNOSTICS
a
1
2 3
b
c
e
d
f
f
0000-GXX-8802-A1
English
To charge the battery:
To mount the wall charger:
1
2
3
0000-GXX-9296-A0
► Push the battery (1) into the charger (2) until it stops.
The LED on the charger (3) glows or flashes green when
the battery is charging.
When the LED on the charger goes out, the charging
process is complete and the charger will shut itself off. The
battery can be removed from the charger.
► Disconnect the power supply cord from the electrical
outlet when the charger is not in use.
A battery is not fully charged when it ships from the factory.
STIHL recommends that you fully charge the battery before
using it the first time.
Operate the charger indoors in a dry room. For optimum
performance, STIHL recommends operating the charger
within an ambient temperature range of 41 °F to 86 °F (5 °C
to 30 °C).
The battery heats up during operation. If a hot battery is
inserted into the charger, it may be necessary for it to cool
down before charging starts. The charging process begins
only after the battery has cooled down sufficiently.
Charging time depends on a number of factors, including
battery condition and the ambient temperature. For a
complete list of approximate charging times, see
www.stihl.com/charging-times.
► Mount the charger indoors in a dry room near an electrical
outlet.
► Sink the screws into a wall stud. Use appropriate screw-in
wall anchors or other similar mounting devices if an
appropriate wall stud is not available.
► Align the charger as shown above. Mount to a wall with the
following dimensions:
– a = minimum 18 in. (450 mm)
– b = minimum 3.9 in. (100 mm)
– c = 2.1 in. (54 mm)
– d = 0.2 in. (4.5 mm)
– e = 0.4 in. (9 mm)
– f = 0.1 in. (2.5 mm)
8 LED DIAGNOSTICS
8.1 LED on the Charger
One LED shows the status of the charger and battery. The
LED can glow or flash green or red.
If the LED glows green continuously or flashes
green: the battery is being charged.
7.3 Mounting the Charger on a Wall
Before mounting, ensure that no electrical cables, pipes or
other service lines run in the wall behind the charger.
0458-967-8621-A
7
English
If the LED flashes red: there is no contact
between the battery and the charger. Remove
and reinsert the battery.
or
The battery has a malfunction and must be
replaced. Do not use or charge the battery.
or
The charger has a malfunction. Have it checked
by an authorized STIHL servicing dealer before
use.
If the LED glows red continuosly: The battery is
too hot or too cold for charging. Allow the battery
to warm up or cool down gradually at an ambient
temperature of about 50 °F to 68 °F (10 °C to
20 °C).
For more information, @ 12.
9 TRANSPORTING
10STORING
10.1 Charger
To properly store the charger:
► Disconnect the charger from the electrical outlet.
► Remove the battery from the charger.
1
2
9 TRANSPORTING
9.1 Charger
To properly transport the charger:
► Disconnect the charger from the electrical outlet.
► Remove the battery from the charger.
► Wrap the power supply cord and attach it to the charger.
► When transporting the charger in a vehicle, secure and
position the charger to prevent turnover, impact and
damage.
8
0000-GXX-8804-A0
► Wrap the power supply cord and attach it to the charger.
► Store the charger indoors in a dry and secure location.
► Keep it out of the reach of children and other unauthorized
persons.
11INSPECTION AND
MAINTENANCE
11.1 Charger
WARNING
To reduce the risk of personal injury from short circuit and
fire, do not attempt to repair, open or disassemble the
charger. There are no user-serviceable parts inside. Always
unplug the charger before cleaning.
0458-967-8621-A
Loading...
