Page 1
Owner’s Manual
5 Gallon Air Tank
SP-CT5
WARNING! To Reduce The Risk Of Injury, User
Must Read And Understand Instruction Manual.
www.steele-products.com
Page 2
Air Tank
LIMITED WARRANTY
STEELE® warrants to the original purchaser who uses the product in a consumer
application (personal, residential or household usage) that all products covered under this
Warranty are free from defects in material and workmanship for one year from the date of
purchase. All products covered by this limited Warranty which are used in commercial
applications (i.e. income producing) are warranted to be free of defects in material and
workmanship for 90 days from the date of original purchase. Products covered under this
Warranty include air compressors, air tools, service parts, pressure washers and generators.
STEELE® will repair or replace at STEELE® sole option, products or components which
have failed within the warranty period. Service will be scheduled according to the normal
work flow and business hours at the service center location, and the availability of
replacement parts. All decisions of STEELE® with regard to this limited warranty shall be
final. This warranty gives you specific legal rights, and you may also have other rights
which vary from state to state.
RESPONSIBILITY OF ORIGINAL PURCHASER (Initial User):
To process a warranty claim on this product, DO NOT return item to the retailer. The
product must be evaluated by an Authorized Warranty Service Center. For the location of
the nearest Authorized Warranty Service Center contact the retailer or place of purchase.
Retain original cash register sales receipt as proof of purchase for warranty work.
Use reasonable care in the operation and maintenance of the product as described in the
Owner’s Manual(s).
Deliver or ship the product to the nearest Authorized Warranty Service Center. Freight
costs, if any, must be paid by the purchaser.
Air compressors with 60 and 80 gallon tanks will be inspected at the site of installation.
Contact the nearest Authorized Warranty Service Center that provides on-site service calls
for service call arrangements.
If the purchaser does not receive satisfactory results from the Authorized Warranty Service
Center, the purchaser should contact STEELE®.
2
Page 3
Owner’s Manual
LIMITED WARRANTY (cont’d)
THIS WARRANTY DOES NOT COVER:
Merchandise sold as reconditioned, used as rental equipment, or floor or display
models.
Merchandise that has become damaged or inoperative because of ordinary wear,
misuse, cold, heat, rain, excessive humidity, freeze damage, use of improper
chemicals, negligence, accident, failure to operate the product in accordance
with the instructions provided in the Owner’s Manual(s) supplied with the
product, improper maintenance, the use of accessories or attachments not
recommended by STEELE®, or unauthorized repair or alterations.
Repair and transportation costs of merchandise determined not to be defective.
Costs associated with assembly, required oil, adjustments or other installation and
start-up costs.
Expendable parts or accessories supplied with the product which are expected to
become inoperative or unusable after a reasonable period of use.
Merchandise sold by STEELE® which has been manufactured by and
identified as the product of another company, such as gasoline engines. The
product manufacturer's Warranty, if any, will apply.
ANY INCIDENTAL, INDIRECT OR CONSEQUENTIAL LOSS, DAMAGE, OR
EXPENSE THAT MAY RESULT FROM ANY DEFECTS, FAILURE OR
MALFUNCTION OF THE PRODUCT IS NOT COVERED BY THIS
WARRANTY. Some states do not allow the exclusion, so it may not apply to you.
IMPLIED WARRANTIES, INCLUDING THOSE OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO ONE YEAR
FROM THE DATE OF ORIGINAL PURCHASE. Some states do not allow
limitations on how long an implied warranty lasts, so the above limitations may not apply.
3
Page 4
Air Tank
PORTABLE AIR TANK
1
2
3
4
1. Portable air tank
2. Carrying handle
3. Welded steel legs
4. Standard tire air chuck
5. 200 psi test air hose
6. Intake valve
7. Intake valve control wheel
8. Safety valve
9. Automatic bypass valve
10. Pressure gauge
10
9
8
7
6
5
SPECIFICATIONS
Model: SP-CT5
Gallons: 5
Max PSI: 125
4
Page 5
Owner’s Manual
GENERAL SAFETY MEASURES
GENERAL SAFETY MEASURES AND PRECAUTIONS
1.Store only compressed air in the tank.
2.Regularly check pressure gauge.If left unused for extended periods of time, the tank
pressure may need to be brought up.
3.Refill the tank when the air pressure is low.
4.To prevent the tank from rusting, store in clean and dry area.
5.Do not expose to moisture or heat.
6.If minor rust appears, sand the tank with a steel wool or sandpaper and repaint it. In
case of severe rust, dispose of tank.
7.Release all pressure from the tank before removing or replacing fittings.
8.Do not use the tank for medical purpose.
9.Do not use the tank as a portable breathing device.
10.Do not use the tank if it is defective, return it to replace of purchase if still under
warranty. If no longer under warranty, dispose of tank following the guidelines below.
11.WARNING: Do not fill air tank from compressed air cylinder charged with more than
125 psi. Air tank pressure must not exceed 125 psi. Overfilling could burst cylinder and
result in serious personal injury. Failure to read and follow instructions may result in
personal injury and, or property damage.
5
Page 6
Air Tank
OPERATION
TO FILL
• Fill air tank only at a service station or use a low pressure air compressor (0 – 100 psi).
• Press air compressor chuck against the intake valve until the tank is filled.
• Fill air tank pressure to between 75 and 125 psi only. Pressure gauge indicates the
level of air pressure inside the tank.
• Do not overfill. Tank pressure must not exceed 125 psi.
TO USE
• To open, turn the red intake valve control wheel counterclockwise to allow air to flow
from the tank through hose.
• Press the chuck onto tire’s valve stem.
• To close, turn the intake valve control wheel clockwise to stop air from flowing through
the hose.
TO RELEASE PRESSURE:
• Pull on the safety valve attached to the automatic bypass valve.
• When the tank is empty, the pressure gauge will register zero.
CAUTION!
• Do not overfill.Tank pressure
must not exceed 125 psi.
• The built-in pressure gauge
will provide an estimated
reading only.
• The built-in pressure gauge
cannot use to measure tire
pressure.
• Keep out of reach of children.
TO CONTROL AIR FLOW
Open
6
Close
Release Pressure
Page 7
Owner’s Manual
OPERATION
TO STORE
• Turn the intake valve control wheel clockwise to stop air from flowing through the hose.
• Store indoors in a clean and dry area.
MAINTENANCE
• To prevent tank from rusting, store in clean and dry area.
• If minor rust appears, sand the tank with a steel wool or sandpaper and repaint it. In
case of severe rust, dispose of the tank.
DISPOSAL OF THE TANK
• Before disposal, empty the tank completely and leave valve open.
• Dispose of the tank on or before expiry date stamped on footrest. Using the tank after
the disposal date may result in the cylinder bursting and causing serious personal injury.
• Dispose of the tank in accordance with the federal and provincial regulations.
7
