Keil™ starter kit for STM32F4 series microcontrollers
Features
■ The Keil MDK-Lite development tools:
– µVision®4 IDE/Debugger for application
programming and debugging
– ARM C/C++ compiler
– RTX real-time kernel, a multi-tasking
operating system for embedded
applications
– MDK-Lite supports applications with up to
32 KB code-size
■ ULINK-ME in-circuit debugger/programmer
with USB interface to host PC and 20-pin JTAG
or 10-pin CoreSight debug interface
■ Full-featured Keil evaluation board with a
168 MHz STM32F407IG MCU
STM3240G-SK/KEI
(STM32F407IG MCU)
Table 1. Device summary
Reference Order code
Data brief
Description
The Keil starter kit is a complete, cost-effective
solution for starting application development and
evaluating the STMicroelectronics STM32F4
series ARM Cortex™-M4 processor-based
microcontrollers.
The STM3240G-SK/KEI starter kit provides all the
hardware and software you need to start
developing applications for the STM32 ARM corebased families of microcontrollers. It comes
complete with a full-featured evaluation board
(including Ethernet, USB HS, VGA camera,
external memories, CAN, USARTs, Audio, and
QVGA Touchscreen LCD), Keil's MDK-ARM Lite
Edition (32 KB) development tools, and the
ULINK-ME™ (USB/JTAG) adapter.
Keil starter kits are available for a full range of ST
ARM core-based microcontrollers.
Keil™ starter kit for STM32F4
series microcontrollers
STM3240G-SK/KEI
May 2012 Doc ID 022486 Rev 2 1/4
For further information contact your local STMicroelectronics sales office.
www.st.com
4
Starter kit architecture STM3240G-SK/KEI
Starter kit architecture
Keil development software is a suite of software development tools for creating and
debugging microcontroller applications that includes:
● µVision® integrated development environment, which integrates the ARM
Compilation Tools and Keil’s debugging software so that users can quickly and easily
develop and debug their applications while they run on a target microcontroller.
● ARM Compilation Tools (RVCT) 32 Kbyte code-size limited version of the optimizing
C/C++ compiler for ARM™ core-based microcontrollers.
● ULINK-ME™ USB/JTAG in-circuit debugger / programmer, which integrates fully
with µVision, allowing users to download the application to the target and debug it while
it runs on the ST ARM core-based microcontroller on the evaluation board.
● Keil™ evaluation board, an application board that provides a full range of features to
help users evaluate and start developing applications for the included STM32F407IG
microcontroller. The Keil MCBSTM32F400 evaluation board includes the following key
features:
– 168 MHz STM32F407IG ARM Cortex-M4 processor-based MCU in 176-pin BGA
package
– On-chip memory: 1 MB Flash, 192 KB SRAM
– On-board memory: 2 MB SRAM, 8 MB NOR Flash, 512 MB NAND Flash, 8 KB
EEPROM (I
– 2.4 inch color QVGA TFT LCD with resistive touch-screen
– 10/100 Ethernet port
– USB 2.0 Full Speed - USB, USB-OTG, and USB Host
– USB 2.0 High Speed - USB, USB-OTG, and USB Host
– CAN interface
– Serial/UART port
– MicroSD Card interface
– 5-position joystick
– Push-buttons for Reset, Wakeup, Tamper and User
– 8 LEDs directly connected to port pins
– 3-axis digital Accelerometer
– 3-axis digital Gyroscope
– Analog voltage control for ADC input (potentiometer)
– Audio CODEC/DAC with line-in/out and speaker/microphone
– Digital microphone
– Digital VGA camera
– All MCU signals are connected to headers grouped by ports
– Two jumpers to select boot mode
– Power supply via: High Speed (micro) USB connector, Full Speed (micro) USB
connector, Power jack (8 V-12 V)
– Debug interface connectors: 20-pin JTAG (0.1 inch connector), 10-pin Cortex
debug (0.05 inch connector), 20-pin Cortex debug + ETM Trace (0.05 inch
connector)
2
C) with NFC (wireless near field communication) interface
2/4 Doc ID 022486 Rev 2
STM3240G-SK/KEI Revision history
Ordering information
Keil starter kits can be ordered from Keil or from your nearest ST distributor or sales office
for STM32F4 series microcontroller (ST order code: STM3240G-SK/KEI).
For more information and complete documentation, please refer to the Keil web site or the
STMicroelectronics microcontroller support site on www.st.com.
