ST19WR02
Obsolete Product(s) - Obsolete Product(s)
Dual C ontactl ess Sm artcard M CU
With 2 Kbytes EEPROM
DATA BRIEF
PRODUCT FEATURES
■ ENHANCED 8 BIT CPU WITH EXTENDED
ADDRESSING MODE S
■ 64 KBYTES USER ROM WITH
PARTITIONING
■ 1 KBYTES USER RAM WITH
■ POWER SAVING STANDBY MODE
■ CONTACT ASSIGNMENT COM PAT IBLE
ISO 7816-2
■ SERIAL ACCESS I/O, ISO 7816-3
COMPATIBLE
■ ESD PROTECTION GREATER THA N 5000 V
PARTITIONING
■ 2 KBYTES USER EEPROM WITH
Figure 1. Delivery Form
PARTITIONING plus 128 BYTES USER and
ST OTP AREA:
– Highly reliable CMOS EEPROM
submicron technology
– Error Correction Code for si ngle bit fa il
correction within a byte
– 10 year data retention
– 500,000 Erase/Write cycles endurance
– 1 to 32 bytes Erase or Program in 1 ms
■ SECURITY FIREWALLS FOR MEMORIES,
Micromodule Wafer
and DES ACCELERATOR.
■ VERY HIGH SECURITY FEATURES
INCLUDING EEPROM FLASH
PROGRAMMING AND CLOCK
MANAGEMENT.
■ 2x8 BIT TIMERS WITH INTERRUPT
CAPABILITY
■ HARDWARE DES ACCELERATOR WITH
LIBRARY SUPPORT FOR SY MMETRICAL
ALGORITHMS:
– DES, triple DES, DESX computations and
CBC chaining mode...
■ ISO 3309 CRC CALCULATION BLOCK
■ FIPS 140-2 COMPLIANT RANDOM
NUMBER GENERATOR WITH TWO GUN
REGISTERS (Generators of Unpredictabl e
Number)
■ 2.7 V TO 5.5 V SUPPLY VOLTAG E
■ EXTERNAL CLOCK FREQUENCY UP TO
10 MHz
■ HIGH PERFORMANCE PROVIDED USING
INTERNAL CLOCK FREQUENCY
■ UNIQUE SERIAL NUMBER ON EACH DIE
Triple DES (with keys loaded) 24 µs
Single DES (with keys loaded) 15 µs
1. Typical values, independent from external clock frequency
and supp l y voltage.
CONTACTLESS SPECIFIC FEATURES
■ BASED UPON ISO 14443 TYPE B
■ 13.56 MHz CARRIER FREQUENCY
■ HIGH SPEED DATA TRANSFER
CAPABILITY UP TO 424 KBAUDS
■ RF FRAME UP TO 256 BYTES
■ 10% AMPLITUDE MODULATION
RECEPTION (READER TO CARD)
■ BPSK - NRZ LOAD MODULATION (CARD
TO READER)
■ INTERFACE WITH RF READERS
SUPPORTED THROUGH A LIBRAR Y OF
EMBEDDED SOFTWARE FUNCTIONS
COMPATIBLE WITH ISO 14443 STANDARD
■ ESD PROTECTION ON ANTENNA PADS
GREATER THAN 3000 V
Function
259a.ai
Speed
(1)
April 2004
For further information contact your local ST sales office.
1/3
3
Obsolete Product(s) - Obsolete Product(s)
ST19WR02
HARDWARE DESCRIPTION
The product, member of the ST19W platform, is a
serial access microcontroller specially designed
for cost effective secure portable applications.
It is manufactured using an advanced highly reliable ST CMOS EEPROM technology.
It is based on the STMicroelectronics 8 bit CPU already implemented o n the ST19X produc t family
and includes on-chip memories: User ROM, User
RAM and EEPROM with state of the art security
featur es. ROM, RAM and EEPROM memo ries can
be configured into partitions with customized access rules .
Figure 2. Block Diagram
RAM
EEPROM
USER ROM
An additional ST ROM contains all ST provided
functions and libraries.
Access from any memory area to another are protected by hardware FIREWALLS. Access rules are
User defined and can be selected by mask options.
The chip includes a DES accelerator which is accessible via crypt o gr aphi c so ftware libraries located in ST ROM.
As with all the other S T19W products, a serial interface fully compatible with the ISO7816 standard
for Smartcard applications is available.
A CRC calculation block is also available and i s directly accessible by the User.
ST ROM, RF
and DES
LIBRARIES
DES
ACCELE
-RATOR
MEMORY ACCESS FIREWALL
INTERNAL BUS
CLOCK
CRC
MODULE
GENE-
RATOR
MODULE
CLK
SOFTWARE DEVELOPMENT
Software development and firmware generation
(ROM and options) a re supported by a com prehensive set of development tools, dedicated at development and validation of softwares:
– Smartcard ICs Emulator,
2 X
8 BIT
TIMERS
SECU-
RITY
ADMIN.
RESET
GUN A
&
GUN B
Vcc
8 BIT
CPU
GND
– ST19X simulation package,
– ScDevTools pack environ men t for all
Windows
TM
based stations,
– Powerful C/C++ compiler and debugger are
also available (third party tools).
– RF contactless demo kit based upon ISO
ST ROM, and
DES FIREWALL
1 X
SERIAL
INTER-
FACE
I/O
AC0
RF
INTER-
FACE
AC1
516
14443 type B standard.
