ST SPEAr310 User Manual

Embedded MPU with ARM926 core, flexible memory support,

LFBGA289 (15 x 15 x 1.7 mm)

extended set of powerful connectivity features

Features

■ ARM926EJ-S 333 MHz core

■ High-performance 8-channel DMA

■ Dynamic power-saving features

■ Configurable peripheral functions multiplexed

on 102 shared I/Os

■ Memory:

– 32 KB ROM and 8 KB internal SRAM
– LPDDR-333/DDR2-666 external memory

interface
– Serial Flash Memory interface (SMI)
– Flexible static memory controller (FSMC)

up to 16-bit data bus width, supporting

NAND Flash
– External memory interface (EMI) up to 32-

bit data bus width, supporting NOR Flash

and FPGAs

■ Connectivity

– 2 x USB 2.0 Host
– USB 2.0 Device
– 1 x fast Ethernet MII port
– 4 x fast Ethernet SMII ports
– 1 x SSP Synchronous serial peripheral

(SPI, Microwire or TI protocol) with 4 chip

selects
–1 x I
– 1 x fast IrDA interface
– 6 x UART interface
– 1x TDM/E1 HDLC interface with 128/32

– 2x RS485 HDLC ports

■ Security

– C3 Cryptographic accelerator

■ Miscellaneous functions

– Integrated real time clock, watchdog, and

– 8-channel 10-bit ADC, 1 Msps

2

C

timeslots per frame respectively

system controller

SPEAr310

– JPEG CODEC accelerator
– Six 16-bit general purpose timers with

programmable prescaler, 4 capture inputs

– Up to 102 GPIOs with interrupt capability

Applications

The SPEAr310 embedded MPU is configurable
for a range of telecom and networking
applications such as:

■ Routers, switches and gateways

■ Remote apparatus control

■ Metering concentrators

Table 1. Device summary

Order code

SPEAR310-2 -40 to 85

Temp

range, ° C

Package Packing

LFBGA289

(15x15 mm,

pitch 0.8 mm)

Tr ay

March 2010 Doc ID 16482 Rev 2 1/72
