Spektrum SPM18000 DX18 User Manual

Download

Bedienungsanleitung

Manuale di Istruzioni

Instruction Manual

Manuel d’utilisation

NOTICE

All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon Hobby, Inc. For up-to-date product literature, visit horizonhobby.com and click on the support tab for this product.

Meaning of Special Language

The following terms are used throughout the product literature to indicate various levels of potential harm when operating this product: NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND little or no possibility of injury. CAUTION: Procedures, which if not properly followed, create the probability of physical property damage AND a possibility of serious injury. WARNING: Procedures, which if not properly followed, create the probability of property damage, collateral damage and serious injury OR create a high probability of superﬁ cial injury.

WARNING: Read the ENTIRE instruction manual to become familiar with the features of the product before operating.

Failure to operate the product correctly can result in damage to the product, personal property and cause serious injury.

This is a sophisticated hobby product. It must be operated with caution and common sense and requires some basic mechanical ability. Failure to operate this Product in a safe and responsible manner could result in injury or damage to the product or other property. This product is not intended for use by children without direct adult supervision. Do not attempt disassembly, use with incompatible components or augment product in any way without the approval of Horizon Hobby, Inc. This manual contains instructions for safety, operation and maintenance. It is essential to read and follow all the instructions and warnings in the manual, prior to assembly, setup or use, in order to operate correctly and avoid damage or serious injury.

WARNING AGAINST COUNTERFEIT PRODUCTS

Thank you for purchasing a genuine Spektrum product. Always purchase from a Horizon Hobby, Inc. authorized dealer to ensure authentic high-quality Spektrum product. Horizon Hobby, Inc. disclaims all support and warranty with regards, but not limited to, compatibility and performance of counterfeit products or products claiming compatibility with DSM or Spektrum.

NOTICE: This product is only intended for use with unmanned, hobby-grade, remote-controlled vehicles and aircraft. Horizon Hobby disclaims all liability outside of the intended purpose and will not provide warranty service related thereto.

Age Recommendation: Not for Children under 14 years. This is not a toy.

WARRANTY REGISTRATION

Visit community.spektrumrc.com today to register your product.

NOTICE: While DSMX allows you to use more than 40 transmitters simultaneously, when using DSM2 receivers, DSMX receivers in

DSM2 mode or transmitters in DSM2 mode, do not use more than 40 transmitters simultaneously.

GENERAL NOTES

• Models are hazardous when operated and maintained incorrectly.

• Always install and operate a radio control system correctly.

• Always pilot a model so the model is kept under control in all conditions.

• Please seek help from an experienced pilot or your local hobby store.

• Contact local or regional modeling organizations for guidance and instructions about ﬂ ying in your area.

• When working with a model, always power on the transmitter ﬁ rst and power off the transmitter last.

• After a model is bound to a transmitter and the model is set up in the transmitter, always bind the model to the transmitter again to establish failsafe settings.

PILOT SAFETY

• Always make sure all batteries are fully charged before ﬂ ying.

• Time ﬂ ights so you can ﬂ y safely within the time allotted by your battery.

• Perform a range check of the transmitter and the model before ﬂ ying the model.

• Make sure all control surfaces correctly respond to transmitter controls before ﬂ ying.

• Do NOT ﬂ y a model near spectators, parking areas or any other area that could result in injury to people or damage to property.

• Do NOT ﬂ y during adverse weather conditions. Poor visibility, wind, moisture and ice can cause pilot disorientation and/or loss of control of a model.

• When a ﬂ ying model does not respond correctly to controls, land the model and correct the cause of the problem.

2 SPEKTRUM DX18 • TRANSMITTER INSTRUCTION MANUAL

Welcome to a new era of RC precision and freedom. With the DX18 you can ﬂ y just about anything you want exactly the way you want to. And you’ll do so with less hassle than ever before.

Its wide array of Spektrum™ AirWare™ programming functions is the most powerful ever made available in a handheld transmitter. Not only do you get a wealth of programming options for airplanes, helicopters and sailplanes, but you can freely assign any switch, stick, lever or slider to perform just about any function you want. You can perfectly balance the output of CCPM servos or multiple servos on a single control surface. You can even program an intricate sequence of events over multiple channels that are activated by a single switch.

Perhaps best of all, the DX18 gives you all these expert features without requiring you be a programming expert to use them. If anything, its intuitive SimpleScroll™ programming interface and menu screens make model setup so simple, you just might ﬁ nd yourself trying all kinds of new and exciting ﬂ ying challenges that you never would have before.

That’s why you must read this manual before you ﬂ y with the DX18 for the ﬁ rst time. There is so much this transmitter is capable of that you don’t want to miss a thing. These pages will help you get the most from it all. You’ll also ﬁ nd important binding instructions as well as a handy troubleshooting guide.

BEFORE USING YOUR TRANSMITTER: Before going any further, visit the Spektrum Community website at community.spektrumrc.com to register your transmitter and download the latest AirWare ﬁ rmware updates. A registration reminder screen occasionally appears until you register your transmitter. When you register your transmitter, the reminder screen does not appear again.

BOX CONTENTS

• 2600mAh LiPo Transmitter Pack (Installed in transmitter)

• SD Card

• 12V DC Global Power Supply

• SPMAR9020 9-Channel Receiver (Not included with Transmitter-only versions)

• SPM6803 Male/Female Bind plug

• Manual

• Hex Wrench

• DX18 Neck Strap

• DX18 Decal Sheet

3SPEKTRUM DX18 • TRANSMITTER INSTRUCTION MANUAL

TABLE OF CONTENTS

Chapter 1

Transmitter Batteries ....................................................5

Charging Your Transmitter .............................................5

Transmitter Functions ...................................................6

Main Screen ................................................................8

Navigation ...................................................................8

Binding........................................................................9

Programming Failsafe Positions ..................................10

X-Plus .......................................................................11

SD Card ....................................................................11

Model Type Programming guide ..................................12

Common System Setup FunctIons

System Setup ............................................................13

Model Select .............................................................13

Model Type ................................................................13

Model Name ..............................................................13

F-Mode Setup ............................................................14

Flight Mode Name Setup ............................................14

Channel Assignment ..................................................14

Channel Input Conﬁ guration ........................................15

X-Plus Input Conﬁ guration ..........................................15

Trim Setup .................................................................15

Model Copy ...............................................................16

Model Reset ..............................................................16

Warnings ...................................................................16

Telemetry ..................................................................16

Preﬂ ight Setup ..........................................................17

Frame Rate ................................................................17

Bind ..........................................................................17

Trainer.......................................................................18

Analog Switch Setup ..................................................18

System Settings .........................................................19

Extra Settings ............................................................20

Serial Number ............................................................20

Calibrate....................................................................21

Transfer SD Card .......................................................21

Function List

Servo Setup ..............................................................22

D/R & Exponential ......................................................23

Differential (Air and Sail Types only) .............................23

V-Tail Differential (Air and Sail Types only) ....................24

Throttle Cut ...............................................................24

Throttle Curve ............................................................24

Mixing .......................................................................25

Sequencer .................................................................26

Range Test ................................................................27

Timer ........................................................................27

Telemetry ..................................................................27

Monitor .....................................................................28

X-Plus Monitor ...........................................................28

Chapter 2 ACRO (Airplane)

Aircraft Type ..............................................................29

Recommended Servo Connections ..............................29

Elevon Servo Control ..................................................29

Flap System ..............................................................30

ACRO Mixing ............................................................30

Acro Gyro Function ....................................................30

Chapter 3 HELI (Helicopter)

Swash Type ...............................................................31

Pitch Curve ...............................................................31

Swashplate ................................................................31

Gyro ..........................................................................32

Governor ...................................................................32

Tail Curve .................................................................32

Heli Mixing ...............................................................32

Chapter 4 SAIL (Sailplane)

Sailplane Type ............................................................33

Camber Preset ...........................................................33

Camber System .........................................................33

Sail Mixing .................................................................34

Chapter 5 Receiver Installation and Power System Requirements

AR9020 Receiver Speciﬁ cations: ................................34

Receiver Installation ...................................................34

Power System Requirements ......................................35

Recommended Power System Guidelines ....................35

Chapter 6 Physical Transmitter Adjustments

Mode Conversion .......................................................35

Adjust Stick Tension ..................................................35

Control Stick Length Adjustment ................................35

Adjust Throttle Friction Straps ....................................36

Throttle Ratchet Strip Installation .................................36

2.4Ghz Troubleshooting Guide ....................................37

Parts list ....................................................................37

AMA National Model Aircraft Safety Code ....................38

FCC Information .........................................................39

FAA Information .........................................................39

1-Year Limited Warranty .............................................40

Warranty and Service Contact Information ...................41

Parts Contact Information ...........................................41

Compliance Information for the European Union ...........41

4 SPEKTRUM DX18 • TRANSMITTER INSTRUCTION MANUAL

TRANSMITTER BATTERIES

Battery and Charging Precautions and Warnings

Failure to exercise caution while using this product and comply with the following warnings could result in product malfunction, electrical issues, excessive heat, FIRE, and ultimately injury and property damage.

• Read all safety precautions and literature prior to use of this product

• Never allow minors to charge battery packs

• Never drop charger or batteries

• Never attempt to charge damaged batteries

• Never attempt to charge a battery pack containing different types

of batteries

• Never charge a battery if the cable has been pinched or shorted

• Never allow batteries or battery packs to come into contact with

moisture at any time

• Never charge batteries in extremely hot or cold places (recom-

mended between 50–80 degrees F or 10–27 degrees C) or place in direct sunlight

• Always disconnect the battery after charging, and let the charger

cool between charges

• Always inspect a new battery before charging

• Always terminate all processes and contact Horizon Hobby if the

product malfunctions

• Always keep batteries and charger away from any material that

could be affected by heat (such as ceramic and tile), as they can get hot

• Always end the charging process if the charger or battery be-

comes hot to the touch or starts to change form (swell) during the charge process

Charging Your Transmitter

The DX18 has an internal charger designed to charge the included 2-cell LiPo battery at a charge rate of 200mAh. The charge port on the right side of the transmitter is not polaritydependent.

NOTICE: Never connect an external battery charger to your

DX18 transmitter. If you wish to charge the LiPo battery using a LiPo charger, you must remove the battery from the transmitter before charging.

The ﬁ rst time you charge the transmitter battery, the charge time may be 12-15 hours. Always charge the transmitter on a heat resistant surface.

1. Power off your transmitter.

2. Connect the power supply connector to the transmitter charge port.

3. Connect the power supply to a power outlet using the appropriate adapter.

4. The blue LED on the front of the transmitter turns on during charging and turns off when the battery is fully charged.

5. Disconnect the transmitter from the power supply once charging is complete and disconnect the power supply from the power outlet.

CAUTION: Never leave a charging battery unattended.

LED indicators

The blue LED indicates the transmitter battery is charging. The orange LED indicates the transmitter is powered on and there is radio transmission.

Battery Alarm

The System Settings Screen allows you to change the battery type and low alarm settings. See “System Settings” for more information.

• An alarm will sound when the battery reaches the low voltage limit (4.3V for NiMH, 6.4V for LiPo).

CAUTION: Never change the low voltage limit for LiPo

batteries from 6.4V. Doing so could over-discharge the

battery and damage both battery and transmitter.

5SPEKTRUM DX18 • TRANSMITTER INSTRUCTION MANUAL

TRANSMITTER FUNCTIONS

Antenna 1

RIght Trim

Right Knob

Switch E

Switch H

Switch G

Switch F

Function

Throttle/Aileron Stick (Mode 1)

Elevator/Aileron Stick (Mode 2) Throttle/Rudder Stick (Mode 3) Elevator/Rudder Stick (Mode 4)

Elevator Trim (Mode 2, 4)

Throttle Trim (Mode 1, 3) Aileron Trim (Mode 1,2)

Rudder Trim (Mode 3,4) Roller

Charge Port

On/Off Switch

LCD

Function

Clear Button

Back Button

Speaker Grill

Rudder Trim (Mode 1,2)

Aileron Trim (Mode 3,4) Elevator Trim (Mode 1,3)

Throttle Trim (Mode 2,4) Elevator/Rudder Stick (Mode 1)

Throttle/Rudder Stick (Mode 2) Elevator/Aileron Stick (Mode 3) Throttle/AileronStick (Mode 4)

Switch C

Function

Switch B

Switch A

Switch D

Bind/Switch I

Left Trim

LED

The transmitter comes with a thin, clear plastic ﬁ lm applied to some front panels for protection during shipping. Humidity and use may cause this ﬁ lm to come off. Carefully remove this ﬁ lm as desired.

15 16

6 SPEKTRUM DX18 • TRANSMITTER INSTRUCTION MANUAL

Throttle Spring Tension

Adjustment (Mode 2,4) Left Lever

Left Rear Grip

Trainer Port

SD Card

Battery Cover

Function

Charge Port

Throttle Spring Tension

Adjustment (Mode 1,3) Right Rear Grip

Right Lever

Gimbal Stick Tension Adjust-

ment Handle/Antenna 2

7SPEKTRUM DX18 • TRANSMITTER INSTRUCTION MANUAL

Main Screen

Function

Model Memory

Model Name

Transmitter Battery Charge Level

Digital Battery Voltage

(an alarm sounds and the screen ﬂ ashes when battery charge gets down to 4.3V when using an NiMH battery or 6.4V for a LiPo battery.)

Model Type

Elevator Trim (Modes 2 and 4)

Throttle Trim (Modes 1 and 3) Aileron Trim (Modes 1 and 2)

Rudder Trim (Modes 3 and 4)

Model Memory Timer

Rudder Trim (Modes 1 and 2)

Aileron Trim (Modes 3 and 4) Throttle Trim (Mode 2 and 4)

Elevator Trim (Mode 1 and 3)

Timer

Also displays R Trim values when the Right

Also displays L Trim values when the Left

Trim button is pressed

NAVIGATION

• Turn the scroll wheel to move through the screen content or change programming values. Press the scroll wheel to make a selection.

• Use the Back button to go to the previous screen (for example, to go from the Mixing Screen to the Function List).

• Use the Clear button to return a selected value on a screen to the default setting.

• Direct Model Access enables you to access the Model Select screen without powering off the transmitter. Anytime the transmitter power is on, press the Clear and Back buttons to access the Model Select screen.

• Press and hold the roller while powering on the transmitter to show the System Setup list. No radio transmission occurs when a System Setup screen is displayed, preventing accidental damage to linkages and servos during changes to programming.

Tip: The tick mark below shows the current switch position. Rolling and clicking the roller turns the selected box black, indicating that the value or condition will act on that position.

• The Main Screen appears when you power on the transmitter. Press the scroll wheel once to display the Function List.

• When you want to change a value in a screen for a particular control position, move the control to the desired position to highlight the value you want to change, such as 0/1/2, up/down or left/right.

Turn HoldPress

Enter, Choose or Exit

Move between options or change value in an option

Hold for 3 seconds and release to move to the Main Screen

8 SPEKTRUM DX18 • TRANSMITTER INSTRUCTION MANUAL

BINDING

Binding is the process of programming the receiver to recognize the GUID (Globally Unique Identiﬁ er) code of a single speciﬁ c transmitter. The DX18 and AR9020 are pre-bound at the factory. You will need to rebind after the model programming is initially set up to fully program the model’s failsafe positions.

Binding Using the Receiver and Receiver Battery

2. 3.

Hold button while powereing on

Mode 2 shown

1. Move the throttle stick to the lowest position and power off the transmitter.

2. Insert the bind plug into the BIND/DATA port on the receiver.

3. Connect a fully charged receiver pack to any open port on the receiver. The orange LED on the receiver rapidly ﬂ ashes when the receiver is in bind mode.

Binding Using the Receiver and ESC

Hold button while powereing on

2. 3.

4. Press and hold the transmitter bind button while powering the transmitter on.

5. Release the Bind button when the transmitter screen displays “Binding”. Binding is complete when the orange transmitter and receiver LEDs are on solid.

6. Power off the receiver and remove the bind plug.

Mode 2 shown

1. Lower throttle to the lowest position and make sure the transmitter is powered off.

2. Insert the bind plug into the BIND/DATA port.

3. Insert the ESC plug into the THRO port.

4. Connect battery to ESC and turn on ESC switch, if available. The receiver’s LED will rapidly ﬂ ash when the receiver is

5. While pressing the Bind button, power on the transmitter.

6. Release the Bind button after the receiver has stopped ﬂ ashing rapidly, once the receiver’s LED stays illuminated; this indicates the receiver is bound to the transmitter. The screen also provides binding information.

7. Remove the bind plug from the receiver.

ready to bind.

CAUTION: When using the DX18 with parkﬂ yer receivers, only use such receivers in parkﬂ yer-type aircraft. (small electric

airplanes or mini and micro helicopters). Installing park ﬂ yer receivers in larger aircraft could cause signal blocking and loss of connection.

9SPEKTRUM DX18 • TRANSMITTER INSTRUCTION MANUAL

PROGRAMMING FAILSAFE POSITIONS

You establish failsafe positions when you bind your transmitter and receiver. If radio signal connection is lost between the transmitter and receiver, the receiver immediately moves the aircraft control surfaces to the failsafe positions. The Spektrum AR9020 receiver has three failsafes programming options: SmartSafe, Hold Last Command, and Preset. If you assign the receiver THRO channel to a transmitter channel other than throttle , we recommend using Preset failsafe with the throttle in the low position.

NOTICE: Failsafe features vary according to receiver. Always consult the receiver instruction manual for failsafe features. Before ﬂ ight, ALWAYS conﬁ rm the failsafe functions as you would expect.

SmartSafe Failsafe

SmartSafe is a failsafe acting only on the throttle channel that offers the following beneﬁ ts:

• Prevents electric motors from operating when the receiver power is on and the transmitter power is off.

• Prevents the speed controller from arming until the throttle is moved to the low throttle position.

• Powers off an electric motor and reduces gas/glow engines to idle if signal is lost.

To Program SmartSafe, move the throttle to the low or off position before putting the transmitter in bind mode.

Hold Last Command

The Hold Last Command failsafe maintains the last command on all channels except throttle; if radio signal is lost, the aircraft maintains the commanded heading until the receiver regains signal. To program Hold Last Command, follow the provided binding instructions in this instruction manual.

Preset Failsafe

The Preset failsafe moves all channels to their programmed failsafe positions. We recommend using Preset failsafe to deploy spoilers on sailplanes to prevent a ﬂ yaway if radio signal is lost.

To program Preset failsafe:

1. Insert the bind plug in the bind port on the receiver and power on the receiver.

2. Remove the bind plug when the orange LED on the main receiver and all attached remote receivers ﬂ ash rapidly. The orange receiver LEDs continue ﬂ ashing.

To Test the SmartSafe

1. Power the transmitter and receiver on.

2. Power off the transmitter. The throttle should immediately move to the failsafe position.

CAUTION: Make sure the aircraft is restrained on the

ground. If failsafe is not set, your aircraft might advance to mid or full throttle.

To Test Hold Last Command

1. Power on the transmitter and receiver.

2. Move one of the control sticks and hold the input.

3. While holding the control input, for example, a small amount of rudder, power off the transmitter. The rudder should maintain the input command.

CAUTION: Make sure the aircraft is restrained on the

ground. If the failsafe does not function as you would expect, the aircraft throttle might advance to mid or full throttle.

3. Move the transmitter control sticks and switches to the desired Preset failsafe position. Power the transmitter on.

4. Failsafe programming is complete when the orange LEDs on the transmitter and all receivers are on solid.

CAUTION: Make sure the aircraft is restrained on the

ground. If the failsafe does not function as you would

expect, the aircraft throttle might advance to mid or full throttle.

10 SPEKTRUM DX18 • TRANSMITTER INSTRUCTION MANUAL

X-PLUS™

X-Plus Channels and Failsafe

Failsafe is not supported for servos connected to the X-Plus Module. We recommend that no failsafe should be expected or attempted for a servo connected through the X-Plus Module. However, servos connected to the X-Plus Module will hold last command in the event of a failsafe condition.

To Activate X-Plus

1. Open the Frame Rate Menu in System Setup.

2. Scrolll to X-Plus and press the scroll wheel to activate. The X-Plus Inputs screen is now active in the Channel Assign menu.

AUX6 and AUX7 channels are available on 12-channel receivers when X-Plus is active. AUX6 and AUX7 are 2048 resolution and 22ms frame rate (12-channel receivers only).

Channels X+1 and X+2 are duplicate channels of channels 11 and 12 on a 12 channel receiver with X-Plus active. If channels 11 and 12 require any adjustment for travel adjust, servo reversing, sub trim or any other function, adjust channels X+1 and X+2. Note that channels 11 and 12 will also show on the X-Plus monitor as channels X+1 and X+2.

If you select 11ms frame rate before you activate X-Plus, the transmitter reverts to 22ms frame rate when X-Plus is active.

CAUTION: Do NOT connect throttle or any primary

control surface to the X-Plus Module. The X-Plus channels are intended to be used for auxiliary functions only. X-Plus channels have a resolution of 512 and variable latency from 22ms to about 88ms. When X-Plus is active, the ﬁ rst 10 channels default to 22ms.

Refer to community.spektrumrc.com for more information about X-Plus options.

SD CARD

Installing the SD Card

The included SD Card enables you to:

• Import (copy) models from another DX18 transmitter

• Export (transfer) models to another DX18 transmitter

• Update AirWare™ software in the transmitter

To install the SD Card:

1. Power off the transmitter.

2. Remove the battery door.

3. Press the SD Card into the card slot with the card label facing upward.

4. Install the battery door.

Exporting the Transmitter Serial Number to the SD Card

Exporting the transmitter serial number to the SD Card allows you to copy and paste the serial number into the registration screen at community.spektrumrc.com .

To export the serial number:

1. Press and hold the scroll wheel while powering the transmitter on until the System Setup list appears.

2. Scroll to the System Settings menu. Press the scroll wheel once to open the menu.

from Channel Assign menu

3. Select NEXT on the System Settings and Extra Settings screens.

4. When the Serial Number screen appears, select EXPORT.

5. Power off the transmitter and remove the SD Card from the transmitter.

6. Insert the SD Card in your computer and open the .txt ﬁ le on the card.

7. Copy and Paste the serial number into the Registration screen on the Spektrum Community site ( community. spektrumrc.com ).

11SPEKTRUM DX18 • TRANSMITTER INSTRUCTION MANUAL

MODEL TYPE PROGRAMMING GUIDE

Menu options show upon model type selection. These menu options vary between Model Types (Airplane Helicopter and Sailplane), but are identical for all models in that type. Subsequent aircraft type (AIrcraft, Swashplate or Sailplane) selections make other menu options appear.

System Setup List: Model Select

Model Type

Model Name

Aircraft Type

F-Mode Setup Channel Assign Trim Setup Model Copy Model Reset Warnings Telemetry Preflight Setup

Frame Rate

Bind Trainer Analog Switch Setup System Settings Transfer SD Card

System Setup List: Model Select

Model Type

Model Name

Swashplate Type

F-Mode Setup Channel Assign Trim Setup Model Copy Model Reset Warnings Telemetry Preflight Setup

Frame Rate

Bind Trainer Analog Switch Setup System Settings Transfer SD Card

Function List: Servo Setup D/R and Expo Differential V-Tail Differential Throttle Cut Throttle Curve Gyro1 Gyro2 Flap System Mixing Sequencer Range Test Timer Telemetry Monitor XPlus Monitor

Function List: Servo Setup D/R and Expo Throttle Cut Throttle Curve Pitch Curve Swashplate Gyro Governor Tail Curve Mixing Sequencer Range Test Timer Telemetry Frame Rate Monitor XPlus Monitor

System Setup List: Model Select

Model Type

Model Name

Sailplane Type

F-Mode Setup Channel Assign Trim Setup Model Copy Model Reset Warnings Telemetry Preflight Setup

Frame Rate

Bind Trainer Analog Switch Setup System Settings Transfer SD Card

Function List: Servo Setup D/R and Expo Differential V-Tail Differential Throttle Cut Motor Curve Camber Presets Camber System Mixing Sequencer Range Test Timer Telemetry Frame Rate Monitor XPlus Monitor

12 SPEKTRUM DX18 • TRANSMITTER INSTRUCTION MANUAL

COMMON SYSTEM SETUP FUNCTIONS

SYSTEM SETUP

Model Select

Model Select enables you to access any of the 50 internal model memory locations in the Model Select list.

1. Scroll to the desired model memory in the Model Select list.

2. When the desired model memory is highlighted, press the scroll wheel once to select the model. The transmitter returns to the System Setup List.

Model Type

Select from Airplane, Helicopter or Sailplane model types. IMPORTANT: When you select a new model type, you will delete

any programming data in the current model memory. Always conﬁ rm the desired model memory before changing model types.

It will be necessary to re-bind after resetting the model type.

To change the model type:

1. Scroll to the desired model type and press the scroll wheel. The Conﬁ rm Model Type screen appears.

Direct Model Access

Press the Clear and Back buttons from the Main Screen or a telemetry screen to access Model Select.

2. Select Yes and press the scroll wheel to conﬁ rm the model type. All data will be reset. Selecting No will exit the Conﬁ rm Model Type screen and return to the Model Type screen.

Model Name

Model Name enables you to assign a custom name to the current model memory. Model names can include up to 20 characters including spaces.

To add letters to a Model Name:

1. Scroll to the desired letter position and press the scroll wheel once. A ﬂ ashing box appears.

2. Scroll left or right until the desired character appears. Press the scroll wheel once to save the character.

3. Scroll to the next desired letter position. Repeat Step 1 and 2 until the Model Name is complete.

4. Select BACK to return to the System Setup list.

13SPEKTRUM DX18 • TRANSMITTER INSTRUCTION MANUAL

F-Mode Setup

Use the Flight Mode Setup menu to assign switches to ﬂ ight modes.

Mode Number of Switches Number of Flight Modes

Aircraft 2 5

Heli 3 (including Throttle Hold) 5 (including Throttle Hold)

Sailplane Flight Mode Setup

You can assign up to ten ﬂ ight modes using any combination of up to three switches. You can also assign a priority switch. When the priority switch position is active, only the current ﬂ ight mode is active, regardless of other switch positions.

Flight Mode Name Setup

Enables you to assign custom names to the Flight Mode positions. Flight Mode names can include up to 20 characters including spaces.

Number of Flight Modes

Switch 1 (number of positions)

Switch 2 (number of positions)

Flight Mode 1

2 Cruise Cruise Cruise Cruise Cruise Cruise

3 Land Land Land

4 Thermal Thermal Thermal Thermal

5 Speed Speed

*Must be set up in a 4/5 ﬂ ight mode.

2 3 3* 4 4 5

2P 3P 2P 2P 3P 3P

2P 3P 2P 3P

Launch Launch Launch Launch Launch Launch

To change the Flight Mode name:

1. Scroll to the Flight Mode name you wish to change and press the scroll wheel.

2. Scroll to the character position you wish to change and press the scroll wheel once. A ﬂ ashing box appears.

3. Scroll left or right until the desired character appears. Press the scroll wheel once to save the character.

Channel Assignment

The Channel Assignment screen allows you to reassign almost any receiver channel to a different transmitter channel. For example, the receiver gear channel could be re-assigned to the transmitter throttle channel. When X-Plus is active in the transmitter, the DX18 recognizes channels 11 and 12 (AUX 6 and AUX 7) on a 12-channel receiver. Channels 11 and 12 will have 22ms frame rate and 2048 resolution. X-Plus allows for up to 8 additional channels over the 10 primary channels.

1. Scroll to the receiver channel you wish to change.

4. Repeat Steps 2 and 3 until the Model Name is complete.

5. Select BACK to return to the Flight Mode Names list.

2. Press the scroll wheel once and scroll left or right to change the receiver input selection.

3. Press the scroll wheel a second time to save the selection.

14 SPEKTRUM DX18 • TRANSMITTER INSTRUCTION MANUAL

Channel Input Conﬁ guration

The Channel Input Conﬁ guration screen enables you to assign a transmitter channel to a different control stick or switch.

1. Select NEXT on the RX Port Assignments screen to access the Channel Input Conﬁ guration screen.

2. Scroll to the transmitter channel you wish to re-assign and press the scroll wheel. The box around the current input selection ﬂ ashes.

X-Plus Input Conﬁ guration

The X-Plus Input Conﬁ guration screen enables you to assign any X-Plus channel to any transmitter input.

1. Select NEXT on the Channel Input Conﬁ g screen to access the X-Plus Input Conﬁ g screen.

2. Scroll to the X-Plus channel you wish to change.

3. Press the scroll wheel once and scroll left or right to change the X-Plus Input for that X-Plus channel.

3. Scroll left or right to select the desired control stick or switch.

4. Press the scroll wheel to save the selection.

Trim Setup

Use the Trim Setup screen to change the size of the trim step and the trim type.

Trim Step

Adjusting the trim step value determines how many “clicks” of trim you input each time you press the trim button. Changing the trim step value to 0 disables the trim for the channel.

To change the trim step value:

1. Scroll to the trim step channel you wish to change.

2. Select the trim step value and scroll left or right to change the value.

3. Press the scroll wheel to save the selection.

Trim Type

The two Trim Type options are Common and F Mode. Common trim type maintains the same trim values for all ﬂ ight modes. F Mode trim type enables you to save trim values for individual ﬂ ight modes if you ﬁ nd, for example, the aircraft requires aileron trim in Flight Mode 1 but not in Flight Mode 2.

Trim Assignment

In a few instances, you can reassign a trim to a different location.

Aircraft Model Type

Throttle

- Throttle Digital trim button (default)

- Left Analog lever

- Right Analog lever

Helicopter Model Type

Throttle and Pitch Hover Trim-Used to trim the throttle and pitch setting for precision hovering. Note: This does not affect normal throttle trim operation.

-Right Knob

-Left Analog Lever

-Right Analog Lever

-L Trim

-R Trim

Active Gyro and Governor Trim-Used to trim the gyro and governor settings in ﬂ ight.

-L Trim

-R Trim.

Trim Location

Normal and Cross trim types are available. Normal trims align with the control stick; for example, the throttle trim is next to the throttle stick. Cross trims reverse the position of the trims; for example, the Throttle trim is next to the Elevator stick and vice versa. To change the Trim Position from Normal to Crossed, select Normal at the bottom of the Trim Setup screen and press the scroll wheel. IMPORTANT: Crossed trims will cross both sets of trims for both gimbals.

15SPEKTRUM DX18 • TRANSMITTER INSTRUCTION MANUAL

Model Copy

The Model Copy menu enables you to duplicate model programming from one Model List location to another. Use Model Copy to:

• Sort the models in the Model List by brand, model type or power source

• Save a default model copy before experimenting with programming values

• Expedite programming for a model using a similar programming setup.

IMPORTANT: Copying a model program from one model memory to another will erase any programming in the “To” model memory.

To copy model programming:

1. Make sure the model program you wish to copy is active. If the desired model program is not active, select Cancel and change the active model in the Model Select menu.

Model Reset

Use the Model Reset menu to delete all model programming in the active model memory. Reset returns all model settings to the default settings and erases all programming in the selected model. After a model reset it is necessary to re-bind.

Warnings

The Warnings menu enables you to program a tone or vibration alert during power on of the transmitter for any selected switch or channel position. The alarm activates and an alert message appears on the screen if a speciﬁ c switch or control stick is in an unsafe position when you power the transmitter on. Return the switch or control stick to the safe position to silence the alarm.

2. Select the model memory next to “To” and scroll to the desired model memory. Press the scroll wheel once to save the selection.

3. Select Copy and the Conﬁ rm Copy screen appears.

4. Select Copy to conﬁ rm. Selecting Cancel will return to the Model Copy screen.

You cannot use the Model Copy screen to copy model programming to an SD Card. To copy model programming to the SD Card, please see “Transfer SD Card”.

For safety reasons, the default Throttle alarm activates if the throttle position is above 10%.

Telemetry

Installing the optional telemetry module and sensors enables the display of aircraft performance data on the transmitter screen. You can also enable Data Logging to save a telemetry ﬁ le on the SD Card and view the data in the Spektrum STi(TM) mobile application.

Telemetry Settings

Display

Telemetry display options include:

Tele: When you press the scroll wheel, the Telemetry

screens appear and the Main Screen is disabled.

Main: Telemetry alerts appear on the Main screen, but all

Telemetry screens are disabled.

16 SPEKTRUM DX18 • TRANSMITTER INSTRUCTION MANUAL

Roller (Default): Allows you to toggle between the Telem-

etry screens and the main screen by pressing the scroll wheel.

Auto: The Telemetry screen automatically appears as soon

as the transmitter receives data from the telemetry module.

Units

Scroll to Units and press the scroll wheel to change between US and Metric.

File Settings

This is used to select the data logging settings.

File Name

1. Select File Name to assign a custom ﬁ le name.

2. The File Name screen appears, allowing you to name the ﬁ le as you would for a Model Name or Flight Mode Name. The ﬁ le name can include a maximum of 8 characters.

3. Press BACK to save the name.

Start

1. Select Start to assign a speciﬁ c switch position or stick position that activates Data Logging.

2. Press the scroll wheel once to save the selection.

Enabled

When Enabled is set to NO, Data Logging is turned off. Select YES to save Telemetry data to the SD Card. The SD Card must be installed in the transmitter to select YES.

Preﬂ ight Setup

The Preﬂ ight Setup menu option enables you to program a pre-ﬂ ight checklist that appears each time you power on the transmitter or when you select a new model memory. Each item on the list must be conﬁ rmed before you can access the Main Screen.

Frame Rate

The Frame Rate menu enables you to change the frame rate, modulation mode and activate XPLUS. Select the option you wish to change and press the scroll wheel.

Frame Rate

You must use digital servos if you select 11ms frame rate. Analog or digital servos can be used with 22ms frame rate.

Modulation Mode

We recommend using DSMX (default) modulation mode. When DSMX is active, the transmitter operates in DSMX with DSMX receivers and DSM2 with DSM2 receivers. The transmitter automatically detects DSM2 or DSMX during binding and changes the mode accordingly to match the receiver type you are using. If you select DSM2, the transmitter operates in DSM2 regardless of whether it is bound to a DSM2 or DSMX receiver.

X-Plus Activation

Activate X-Plus channels in the Frame Rate Screen. You can set X-Plus to INH (inhibit) or Act (activate).

CAUTION: If you access the Telemetry menu from the

Function List, you may see a Frame Loss appear when you exit the menu. The Frame Loss is not an error, however there is a momentary loss of radio signal when exiting the Telemetry screen. Do NOT access the Telemetry menu during ﬂ ight.

NOTICE: While DSMX allows you to use more than 40 trans-

mitters simultaneously, do not use more than 40 transmitters simultaneously when using a DSM2 receiver or a transmitter in DSM2 mode.

CAUTION: Do NOT connect throttle or any primary

Bind

The Bind menu enables you to bind a transmitter and receiver without powering off the transmitter. This menu is helpful if you are programming a model and need to bind the receiver for failsafe positions. See “Programming Failsafe Positions” for more information.

17SPEKTRUM DX18 • TRANSMITTER INSTRUCTION MANUAL

Trainer

The DX18 features a programmable trainer function with 4 trainer modes. The transmitter assigns the trainer function to Switch I. The 4 trainer modes include:

Slave

Use Slave mode when using the DX18 as a slave transmitter and PilotLink is active in the master transmitter.

Inhibit

In Inhibit, the slave transmitter must have the same programming as the master transmitter (e.g., servo reversing, travel adjust, sub-trim, trims).

Programmable

Programmable mode enables you to program the master transmitter to transfer any or all individual channels when you activate the trainer switch. This mode is ideal for beginners learning to control individual channels while the master transmitter maintains control of all other channels. The slave transmitter should be in PilotLink Slave mode, if available. It is not necessary to have model programming in the slave transmitter.

Pilot Link Master

When Pilot Link Master is active, the slave transmitter controls the primary stick functions (Throttle, aileron, elevator and rudder) while the master maintains control of all other channels and functions (including dual rates and auxillary switch positions). PilotLink Master is ideal for complex models as the master transmitter maintains control of all secondary functions, for example ﬁ lght modes, retracts, ﬂ aps and brakes.

Analog Switch Setup

Allows all sticks and pots to be used as a kick point to turn on functions like mixes. To add a kick point:

1. Move the control stick, lever or knob to the desired kick point position.

2. Scroll to the desired kick point and press the scroll wheel once to save the selection.

To delete a kick point, scroll to the desired kick point and press the Clear button.

DX18 Trainer Operation

1. Bind the master transmitter to the model.

2. Connect the trainer cord (SPM6805) to the back of the master transmitter.

3. Make sure the master and slave transmitter battery packs are fully charged.

4. Make sure the slave transmitter is powered off; the slave transmitter receives power when you connect the trainer cord.

5. Connect the trainer cord to the slave transmitter.

6. The slave transmitter screen displays information but does not send a signal to the model.

7. Press the trainer button on the master transmitter to transfer model control from the master to the slave.

8. Release the trainer button and the master transmitter regains control of the model..

18 SPEKTRUM DX18 • TRANSMITTER INSTRUCTION MANUAL

System Settings

The System Settings menu consists of four screens: System Settings, Extra Settings, Serial Number and Calibrate. Select NEXT or PREV to move between screens.

User Name

The User Name ﬁ eld displays your name in the lower right corner of the main screen.

To Program a User Name

1. Scroll to User Name and press the scroll wheel. The User Name screen appears.

2. Scroll to the desired character position and press the scroll wheel. Scroll left or right to change the character and press the scroll wheel to save the selection. The User Name can contain a maximum of 20 characters, including spaces.

3. Press the Back button to save the User Name and return to the System Settings screen.

Contrast

To adjust the screen contrast:

1. Scroll to Contrast and press the scroll wheel.

2. Scroll left or right to adjust the contrast value. Lower numbers lighten the contrast, higher numbers darken it.

3. Press the scroll wheel once to save the selection.

Backlight

The Backlight ﬁ eld adjusts the backlight appearance time and brightness. You have the option to turn the backlight off for models you ﬂ y during the day and turn the backlight on for night ﬂ ying models.

The backlight time options are:

Off: Appears for a short time when you power on the transmit-

ter.

On: The backlight is always on. Set Time: The backlight is on for 3, 10, 20, 30, 45 or 60 sec-

onds before automatically turning off. Press the scroll wheel once to turn the backlight on.

The backlight percentage adjusts the backlight intensity and it is adjustable in 10% increments from 10% (darker) to 100% (brighter).

Mode

You can change the control stick mode from Mode 2 to Mode 4 or Mode 1 to Mode 3. Mode changes that require movement of complete gimbal

assemblies must be performed by a Horizon Hobby service center.

To change the gimbal stick mode:

1. Scroll to Mode and press the scroll wheel.

2. Scroll left or right to change the gimbal stick mode. Press the scroll wheel to save the selection.

3. Select NEXT in the lower left corner until the Calibration screen appears.

4. Move all transmitter controls to the center position and complete the calibration process before exiting the System Settings menu. See “Calibrating Your Transmitter” for more information.

Battery Alarm

Battery Alarm enables you to change the transmitter battery type and the alarm voltage limit. The alarm activates when the battery reaches the low voltage limit.

To change the battery alarm:

1. Scroll to the battery type and press the scroll wheel once to change the type to LiPo or NiMH.

CAUTION: Never select NiMH when a LiPo battery is installed in the transmitter. Doing so may over-discharge

the LiPo battery and damage the battery, transmitter or both.

2. Scroll to the battery voltage and press the scroll wheel. Turn the scroll wheel left or right to change the voltage level. Press the scroll wheel again to save the selection.

CAUTION: Never adjust the low voltage limit for the LiPo battery pack below 6.4V. Doing so could over-discharge

the battery pack and damage both battery pack and transmitter.

Selecting a Language

In the Systems Settings screen, rotate the roller to highlight Language then press the roller to select the Language function.

Rotate the roller to select the desired Language. When the desired Language is selected, press the roller to accept that Language. Names you input will not be affected by language change.

Selecting a Region (EU Version)

The Region ﬁ eld enables you to change the region of operation and power output for transmitters sold in the European Union. Region options include:

EU-328 FR-328

If you are using the transmitter in France, you must select FR-328 to comply with power output regulations in France.

To change the region:

1. Scroll to Region and press the scroll wheel.

2. Scroll left or right to change the region and press the scroll wheel once to save the selection.

Transmitters sold outside of Europe do not have the option to change the region from US-247.

19SPEKTRUM DX18 • TRANSMITTER INSTRUCTION MANUAL

Inactive Alarm

An alarm activates if the transmitter sees a period of inactivity for a certain amount of time. The alarm is helpful in reminding you to power off the transmitter and avoiding a situation when the transmitter battery completely discharges. The Inactive Alarm options are:

• Inh (No alarm sounds)

• 5 min

Extra Settings

The Extra Settings screen enables you to:

• Turn sounds off or on

• Turn vibration off or on

• Change the appearance of the trim indicators

System Sounds

Scrolling to System Sounds and pressing the scroll wheel turns sounds on (Active) or off (Inhibit).

Vibrator

Scrolling to Vibrator and pressing the scroll wheel turns vibration alerts on (Active) or off (Inhibit).

Trim Display

Trim display changes the shape of the trim indicators on the Main Screen. Display options include:

• Boxed Boxes (Default) The indicators appear as an outlined box when you adjust the trim.

• 10 min (Default)

• 30 min

• 60 min

To change the Inactive alarm time:

1. Scroll to the current alarm time and press the scroll wheel.

2. Scroll left or right to change the alarm time. Press the scroll wheel to save the selection.

• Boxed Arrows The indicators appear as outlined arrows

when you adjust the trim. Inhibit Removes all trim bars and indicators from the Main Screen.

To change the Trim Display:

1. Scroll to Trim Display and press the scroll wheel once.

2. Scroll left or right to change the Trim Display option. Press the scroll wheel to save the selection.

Serial Number

The Serial Number screen displays the transmitter serial number and AirWare version.

Reference the Serial Number screen any time you need to register your transmitter or update the AirWare from the Spektrum Community website.

Exporting the Serial Number to the SD Card

You may ﬁ nd it helpful to export the transmitter serial number to a text ﬁ le for your personal records or when you are registering the transmitter on the Spektrum Community.

To export the transmitter serial number:

1. Insert an SD Card in the card slot on the transmitter.

2. Scroll to EXPORT and press the scroll wheel. The SD Status screen appears and should display MY_DX18.xml in the middle of the screen.

3. Press the scroll wheel again to return to the Serial Number screen.

4. Power off the transmitter and remove the SD Card from the transmitter.

5. Install the SD Card in a card reader connected to your computer.

6. Open the MY_DX18.xml ﬁ le from the SD Card location. You can then copy and paste the serial number into your personal records or to the Spektrum Community website.

Locating the Transmitter AirWare Version

The transmitter AirWare version appears between PREV and NEXT at the bottom of the Serial Number screen. Register your DX18 to get AirWare updates and other news at community.SpektrumRC.com

IMPORTANT: AirWare ﬁ les are speciﬁ c to the transmitter serial number and you cannot transfer AirWare ﬁ les between transmitters, ie., downloading an AirWare update once and attempting to install it on multiple transmitters.

20 SPEKTRUM DX18 • TRANSMITTER INSTRUCTION MANUAL

Calibrate

The Calibration screen stores the potentiometer endpoints for all proportional controls. It is mandatory to complete the calibration after changing the stick mode selection.

Calibrating the Transmitter

1. Carefully move the gimbal sticks in a + shape moving from left to right, then up and down. Press gently on the gimbals at the stops to achieve an accurate calibration. Return both gimbal sticks to the center position.

2. Move the Left and Right Side Levers to the top and bottom positions, then move the side levers to the center position.

IMPORTANT: Only move one side lever at a time during calibration.

Transfer SD Card

Import Model

To import an individual model ﬁ le from the SD Card:

1. Save the model ﬁ le to the SD Card.

2. Select the Model List location where you wish to import the new model ﬁ le.

3. In the SD Card menu, scroll to Select Option and press the scroll button once.

4. Scroll to Import Model and press the scroll button again to save the selection. The Select File screen appears.

5. Select the model ﬁ le you wish to import. The Overwrite screen appears.

IMPORTANT: When you select Import, the transmitter

leaves the System Setup List.

6. Select Import to conﬁ rm overwriting the current model ﬁ le. The transmitter activates the new model ﬁ le and the Main Screen appears.

NOTICE: A Preﬂ ight Checklist may appear prior to the Main Screen if the checklist was active during the model ﬁ le export. Select MAIN to exit the Preﬂ ight Checklist.

See “Preﬂ ight Setup” for more information.

Import All Models

To import all models from the SD Card, select Import All Models, and then conﬁ rm by selecting IMPORT.

NOTICE: This function overwrites the model memories. Ensure that the models currently in your transmitter are saved on an SD card separate from the transmitter before performing this function.

You can import a model to any location you want. If you prefer to use Import All, you can use your PC to rename the SPM ﬁ le. The ﬁ rst two digits (01 to 50) are the destination model number. Your SD card can only contain 50 models. Save ﬁ les to folders on the card then remove from the card all unused models. Files are selected by their position in the directory table.

3. Move the Knob to the full clockwise and counter-clockwise positions, then return the Knob to the center position.

4. Select SAVE to store the calibration.

Export Model

You can use the Export Model option to export a single model ﬁ le to the SD Card.

1. Make sure the active model ﬁ le is the one you wish to Export.

2. Scroll to Select Option and press the scroll button once.

3. Scroll to Export Model and press the scroll button again to save the selection. The Export to SD screen appears. The ﬁ rst two characters of the ﬁ le name correspond to the Model List number (01, for example).

4. (Optional) If you wish to rename the model ﬁ le before exporting it to the SD Card:

a. Scroll to “Save to:” and press the scroll wheel. The File

Name screen appears.

b. Assign a new ﬁ le name. The ﬁ le name can contain up to

25 characters including the .SPM ﬁ le extension.

c. When you are done assigning the new ﬁ le name, press

the Back button to return to the Export to SD screen.

5. Select Export to save the ﬁ le to the SD Card. When the export is complete, the transmitter returns to the SD Card Menu screen.

Export All Models

To export all models to the SD Card:

1. Select Export All Models in the SD Card Menu options. The Export All Models screen appears.

IMPORTANT: Export All Models will overwrite any model

ﬁ les that are:

a. Already saved on the SD Card and b. You are exporting a model ﬁ le with the same

name. Always save model ﬁ les to a different SD Card if you are not sure.

2. Select Export to overwrite ﬁ les on the SD Card or Cancel to return to the SD Card Menu.

Update AirWare

IMPORTANT: The orange LED Spektrum bars ﬂ ash and a status bar appears on the screen when AirWare updates are installing. Never power off the transmitter when AirWare updates are installing. Doing so may damage the system ﬁ les.

Before installing any AirWare ﬁ les, always Export All Models to an SD Card separate from the SD Card containing the AirWare update. The AirWare update may erase all model ﬁ les.

For more information on AirWare updates, visit Community.SpektrumRC.com

21SPEKTRUM DX18 • TRANSMITTER INSTRUCTION MANUAL

Automatically Installing AirWare Updates

To install the most recent AirWare update:

1. Download the update from Community.SpektrumRC.com and save it to the SD Card.

2. Power off the transmitter and install the SD Card in the transmitter.

3. Power on the transmitter and the update automatically installs in the transmitter.

FUNCTION LIST

Servo Setup

The Servo Setup menu contains the following functions:

• Travel Adjust

• Sub-Trim

• Reverse

• Speed

• Abs. (Absolute) Travel

• Balance

Travel Adjust

Travel Adjust sets the overall travel or endpoints of the servo arm movement. To adjust travel values:

1. Scroll to the channel you wish to adjust and press the scroll wheel. When adjusting travel values assigned to a control stick:

a. Center the control stick to adjust both directions at the

same time.

b. To adjust travel in one direction only, move the control

stick in the direction you wish to adjust. Continue holding the control stick in the desired direction while you are adjusting the travel value.

2. Scroll left or right to adjust the travel value. Press the scroll wheel to save the selection.

Manually Installing AirWare Updates

1. Save the desired AirWare version to the SD Card.

2. Select Update Firmware in the SD Card Menu options. The Select File screen apepars.

3. Select the desired AirWare version from the File List. When updates are installing, the transmitter screen is dark. The orange LED Spektrum bars ﬂ ash and the update status bar appears on the screen.

NOTICE: Do not power off the transmiter when updates are installing. Doing so will damage the transmitter.

Reverse

Use the Reverse menu to reverse the channel direction, for example, if the elevator servo moves up and it should move down. To reverse a channel direction:

1. Scroll to Travel and press the scroll wheel. Scroll left until Reverse appears and press the scroll wheel again to save the selection.

2. Scroll to the channel you wish to reverse and press the scroll wheel.

CAUTION: If you reverse the Throttle channel, a

conﬁ rmation screen appears. Select YES to reverse the channel. A second screen appears, reminding you to bind your transmitter and receiver. Failure to re-bind the transmitter and receiver will result in the throttle moving to full throttle if failsafe activates.

CAUTION: Always perform a control test after making

adjustments to conﬁ rm the model responds properly. After adjusting servos, always rebind the transmitter and receiver to set the failsafe position.

Select this when X-Plus channels are active

Sub-Trim

Sub-Trim adjusts the servo travel center point. If X-Plus is active, sub-trim for X-Plus channels appears on the second screen.

CAUTION Use only small sub-trim values or you may

cause damage to the servo.

22 SPEKTRUM DX18 • TRANSMITTER INSTRUCTION MANUAL

Speed

The Speed menu enables you to increase the response time on any individual channel such as retracts. The Speed is adjustable in the following ranges:

• Nor (No Delay) - 0.9s in 0.1 second increments

• 1s - 2s in 0.2 second increments

• 2s - 8s in 1 second increments

To adjust the Speed:

1. Scroll to the channel you wish to adjust and press the scroll wheel.

2. Scroll left or right to adjust the speed and press the scroll wheel to save the selection.

Absolute (Abs.) Travel

The Abs. Travel function limits the amount of travel on a channel. Adjust the Abs. Travel value to prevent a throttle servo or helicopter cyclic servo from binding when a mix is applied.

D/R & Exponential

Dual Rates and exponentials is available on the aileron, elevator and rudder channels. To adjust the Dual Rate and Exponential:

1. Scroll to the channel and press the scroll wheel once. Scroll left or right to select the channel you wish to change and press the scroll wheel again to save the selection.

2. Scroll to dual rate and press the scroll wheel. Scroll left or right to change the value and press the scroll wheel again to save the selection.

Balance

Balance is available on all channels to ﬁ ne-tune the servo position at up to 7 points. This is a precision curve mix that is normally used to prevent binding when multiple servos are used on a single control surface. You can also use the Balance menu option to match throttle response on twin engine aircraft or level the swashplate on a helicopter.

Exponential affects control response sensitivity around center but has no affect on overall travel. Positive exponential decreases the sensitivity around the center of gimbal movement.

Differential (Air and Sail Types only)

The Differential screen enables you to increase or decrease the amount of differential between aileron control surface throws. Positive Differential values decrease the amount of “up” travel without affecting the “down” travel on the opposite control surface. Negative Differential values decrease the amount of “down” travel without affecting the amount of “up” travel on the opposite control surface. The Differential menu option only appears when a multi-servo aileron wing type is active in Aircraft Type.

To adjust the Differential:

1. Scroll to Switch and press the scroll wheel. Scroll right to select On (Differential is always on) or assign the differential to a switch position.

2. Press the scroll wheel a second time to save the selection.

3. Scroll to Diff: and press the scroll wheel once to change the value.

4. Press the scroll wheel again to save the selection.

23SPEKTRUM DX18 • TRANSMITTER INSTRUCTION MANUAL

V-Tail Differential (Air and Sail Types only)

The V-Tail Differential screen enables you to increase or decrease the amount of differential between control surface throws. Positive Differential values decrease the amount of “up” travel without affecting the “down” travel on the opposite control surface. Negative Differential values decrease the amount of “down” travel without affecting the amount of “up” travel on the opposite control surface. The V-Tail Differential menu option only appears when V-Tail A or V-Tail B is active in Aircraft Type.

Throttle Cut

The Throttle Cut menu option enables you assign a switch position to stop an engine or motor. Throttle Cut activates regardless of Flight Mode. When you activate Throttle Cut, the throttle channel moves to the pre-programmed position (normally Off). You may need to use a negative value to move the Throttle channel to the off position.

To adjust the V-Tail Differential:

1. Scroll to Switch and press the scroll wheel. Scroll right to select On (Differential is always on) or assign the differential to a switch position.

2. Press the scroll wheel a second time to save the selection.

3. Scroll to Diff: and press the scroll wheel once to change the value.

4. Press the scroll wheel again to save the selection.

CAUTION: Always test the model after making adjustments

to make sure the model responds to controls as desired.

Throttle Curve

You can use the Throttle Curve menu option to optimize the throttle response. A maximum of 7 points are available on the throttle curve.

To add points to a Throttle Curve:

1. Move the throttle stick to the position where you wish to add the new point.

2. Scroll to Add Pt. and press the scroll wheel to add the point.

To remove points from a Throttle Curve:

1. Move the Throttle stick until the cursor is near the point you wish to remove.

2. Scroll to Remove Pt. and press the scroll wheel once to remove the point.

If you program multiple throttle curves and you wish to edit one of the curves, that curve must be active in the Throttle Curve screen before you can make any changes.

24 SPEKTRUM DX18 • TRANSMITTER INSTRUCTION MANUAL

Mixing

Mixing allows control input for a channel to affect more than one channel at a time. Mixing functions support:

• Mixing a channel to another channel.

• Mixing a channel to itself.

• Assigning offset to a channel

• Linking primary to secondary trim.

These mixes are available for each model memory: 16 programmable mixes

• Cyclic to Throttle (HELI)

• Swashplate (HELI)

• Elevator to Flap (ACRO)

• Aileron to Rudder (ACRO)

• Rudder to Aileron/Elevator (ACRO).

Select a channel for master and slave. Inputs for the master channel control both the master and slave channels. For example Elevator to Flap makes elevator the master channel and ﬂ ap the slave channel.

Offset

Change the offset value to move the effective center position of the slave channel. Positive or negative value determines the direction of the offset. Offset is not available for curve mixes.

• Aileron>Rudder (SAIL)

• Aileron>Flap (SAIL)

• Elevator>Flap (SAIL)

• Flap>Elevator (SAIL)

CAUTION: Always do a Control Test of your model

after changing mixes.

Combo Mixing

Combination Mixing is available to create OR mixing where you can assign 2 conditions and the mix activates if either condition occurs. You can also create AND mixing where 2 conditions must occur to activate the mix. To program Combination Mixing:

1. Activate a mix.

2. Select Combo Sw. in the Switch Selection. The Combo screen appears.

3. Select the desired switch and active switch position for Switch 1.The mix is Active when the switch position box is ﬁ lled.

4. Select the Relation (AND, OR)

5. Select the desired switch and active switch position for Switch 2.The mix is Active when the switch position box is ﬁ lled.

6. Press the BACK button to save the Combination Mix.

Trim

If the master channel trim should also adjust the slave channel, set Trim to Act. A channel monitor on the left side of the screen shows how channels respond to input. To view a switch-assigned mix on the monitor, the mix switch must be in the active position.

Assigning a Mix to a Switch

If you wish to assign a mix to a switch position:

1. Scroll to Switch and press the scroll wheel.

2. Scroll left or right to the switch you wish to use and press the scroll wheel to save the selection.

3. Scroll to the switch position where you want the mix to be active.

The mix is Active when the box is ﬁ lled and Inactive when the box is open. You can assign a mix to be active in multiple switch positions (0,1 or 2).

The Master (left side) names are inputs. For example, “Aileron” refers to the Aileron Stick. The Slave (right side) name is the name of the channel receiving the mix command when the Master channel moves.

Back Mixing

Back Mixing applies a mix to all related servos in a wing or tail type. For example, if you select 2 AIL, 2FLAP in the Aircraft Type screen, a mix to one aileron channel affects both aileron servos. The mix response, however, depends on the aileron channel included in the mix. A Back Mix also enables you to use fewer mixes to achieve the desired response, for example adding roll to a split elevator.

25SPEKTRUM DX18 • TRANSMITTER INSTRUCTION MANUAL

Sequencer

The Sequencer menu option provides this-then-that mixing with a time delay. Five different sequences (S1 through S5) are available to control 2 functions each (A and B), in 2 timing directions (forward or reverse). Sequences appear throughout function screens as assignable switches.

CAUTION: Always review the action of a sequence on

the Monitor or X-Plus Monitor screen BEFORE operating the model to ensure controls act as desired. Failure to do so could cause a crash, resulting in property damage and or injury.

You can program multiple functions to sequentially activate in response to an assigned switch. For example, an assigned Gear switch can open gear doors, lower the gear, then close the doors. In reverse, gear doors open, the gear retracts and the gear doors close. You can assign each Sequencer function to a switch in most Function screens such as Flight Mode, Dual Rate, Mixing, Throttle Curve, Pitch Curve, etc. You can assign several functions to a sequence to decrease the number of controls you need to touch during complex ﬂ ight transitions, for example, applying your assigned dual rates and exponential when the landing gear deploys and the ﬂ ight mode changes. If you select an S-Number-A sequence, for example, S3A, the sequence operates as a timed 5-position switch. An S-NumberB sequence operates as a timed 3-position switch. The 5 positions correspond to the sequencer values shown on the time delay graph in the second Sequencer screen. In a function screen, highlight each point (0-4) and select the switch position desired for a function to be active. When S1B (or another sequence-number-B) is selected as a switch in a function, the sequence will operate as a timed 3-position switch. The 3 positions act as ‘kick points’ of the movement at ﬁ xed percentages (equal thirds) of the sequencer output. In a function screen, highlight each point (0-2) and select the switch position desired for a function to be active.

Sequencer Set Up

1. In the ﬁ rst Sequencer screen, select 1 of the 5 available sequences.

2. In the second Sequencer screen, assign a switch to the sequence. We recommend using a 2-position switch.

Tip: If you need to use a 3-position switch, you must assign

one direction to two adjacent switch positions, for example, 0 and 1. Assign the opposite direction to the third switch position.

3. Assign the timing for the Forward and Reverse directions as desired. There is no delay when you use the Nor option. You may also select a delay time between 0 and 30 seconds.

4. Assign names for each sequencer function, as desired.

5. Select either Step (S) or Proportional (P) for the Sequencer output.Step: The sequence only changes at kick points. Otherwise, there is a delay in the sequence until it reaches the next kick point. Proportional: The sequence movement is proportional between kick points. The sequence maintains rate and direction until it reaches the next kick point.

6. Adjust the Sequencer motion percentages in the third screen. For example, you may move points 1, 2 and 3 closer to the

beginning of the sequence so the motion occurs earlier. This results in a delay between point 3 and point 4 at the end of the sequence.

Testing the Sequence

The Sequencer function determines the response for channels included in the sequence. Refer to the Monitor screen to see how respective channels interact in the Sequencer.

26 SPEKTRUM DX18 • TRANSMITTER INSTRUCTION MANUAL

Range Test

The Range Test function reduces the power output. This allows for a range test to conﬁ rm the RF link is operating correctly. Perform a range check at the beginning of each ﬂ ying session to conﬁ rm system operation.

To Access the Range Test screen

With the transmitter on and the main or telemetry screen displayed, press the roller. The Function list displays. Rotate the roller to highlight Range Test then press the roller to access the Range Test function. With the Range Test screen displayed, push and hold the trainer button. The screen displays Reduced Power. In this mode the RF output is reduced allowing for an operational range test of your system. If you let go of the trainer button, the transmitter will go back to Full Power.

Timer

The DX18 Timer function allows you to program a countdown timer or stop watch (count up timer) to display on the main screen. An alarm sounds when the programmed time is reached. You can program the timer to start using the assigned switch position or automatically when throttle is raised above a programmed position. Two independent timers can be set up as desired per model. An internal timer that shows run time for a speciﬁ c model displays on the Main Screen. A total system timer is also available.

Range Testing the DX18

1. With the model restrained on the ground, stand 30 paces (approx. 90 feet/28 meters) away from the model.

2. Face the model with the transmitter in your normal ﬂ ying position and place the transmitter into Range Test mode (see above) and push the trainer button reducing the power output.

3. Operate the controls. You should have total control of your model with the transmitter in Range Test mode.

4. If control issues occur contact the appropriate Horizon Product Support ofﬁ ce for assistance.

5. If performing a range test while a telemetry module is active, the display will show ﬂ ight log data.

Telemetry

Telemetry is in both the system setup and the function list so you can access the telemetry functions from either list. You must power off the receiver and transmitter, then power them both on to reset the telemetry data. You can reset min/max values by pressing the CLEAR button NEVER change Telemetry settings when the aircraft is powered on. There is a brief interruption in RF output when exiting the Telemetry screen.

27SPEKTRUM DX18 • TRANSMITTER INSTRUCTION MANUAL

Monitor

The Monitor screen displays the servo positions for each channel graphically and numerically. This is useful to verify programming functions, trim settings, mix directions, etc. The numeric value is directly relative to the travel adjust and mix values (e.g., 100% travel adjust equals 100% value in the Monitor).

X-Plus Monitor

Use of the X-Plus Monitor requires X-Plus to be active. The X-Plus Monitor screen displays the output position for each X-Plus channel graphically and numerically. This is useful to verify programming functions, trim settings, mix directions, etc. The numeric value is directly relative to the travel adjust and mix values (e.g., 100% travel adjust equals 100% value in the X-Plus Monitor). The X-Plus Monitor shows the additional channels and requires servos which can be connected to the optional X-Plus module and an X-Plus-capable receiver. X+1 and X+2 channels also serve as the monitor for channels 11 and 12 on a 12 channel receiver.

CAUTION: Do NOT connect throttle or any primary control sur face to the X-Plus Module.

28 SPEKTRUM DX18 • TRANSMITTER INSTRUCTION MANUAL

CHAPTER 2 ACRO (Airplane)

NOTICE: Refer to your airplane manual for recommended control throws.

CAUTION: Always do a Control Test of your model with the transmitter after programming to make

sure your model responds as desired.

Aircraft Type

Use the Aircraft Type Screen to select wing and tail types to match your airplane model. Diagrams and setup names show on the transmitter screen to show the available setups.

Refer to community.spektrumrc.com for more information about new DX18 AirWare updates to support these options.

Wing

Normal Flaperon* Dual Aileron* Flaperon* 1 Aileron 1 Flap* 1 Aileron 2 Flaps* 2 Ailerons 1 Flap* 2 Ailerons 2 Flaps* Elevon A* Elevon B* 4 Aileron*

Tail

Normal V-Tail A** V-Tail B** Dual Elevator Dual Rudder Dual Rudder/Elevator

NEXT screen

Gyro 1

Gyro 2

*Selection of multiple ailerons activates the Differential menu option. **Selection of either of these activates the V-Tail Differential menu option

Activates the Gyro menu option in the Function List.

Select wing and tail types before doing other programming.

Recommended Servo Connections

Dual Aileron Wing Type Connection

Elevon Wing Type Connection

V-Tail Type Connection

A AUX1 servo port (left aileron) B AILE servo port (right aileron)

C ELEV servo port (left V-tail) D RUDD servo port (right V-tail)

E AILE servo port (left aileron) F ELEV servo port (right aileron)

Elevon Servo Control

The possible servo reversing options for a delta wing model are:

Aileron Elevator

Normal Reverse

Normal Normal Reverse Reverse Reverse Normal

Tip: If you test all servo reversing options and the control surfaces do not move in the correct direction, change the Elevon wing type in the System Setup list from Elevon-A to Elevon-B.

Left Rudder

Right Rudder

Up Elevator

Down Elevator

Left Aileron

Right Aileron

29SPEKTRUM DX18 • TRANSMITTER INSTRUCTION MANUAL

Flap System

The Flap System menu option enables ﬂ ap programming as well as elevator mixing. You must select a ﬂ ap-enabled wing type in Aircraft Type or the Flap System menu does not appear. To activate the Flap System:

1. Access the System Setup list and select Aircraft Type.

2. Select a ﬂ ap-enabled wing type and exit the System Setup list.

3. Access the Function List from the Main Screen and select Flap System.

4. Select Inhibit and scroll to the switch or lever you wish to use to control the ﬂ ap channel.

ACRO Mixing

5. Assign the Flap travel values and any desired Elevator mixing.

6. Select a Flap speed, if desired. Norm (default) does not have a delay. Flap speed options range from 0.1s to 30 seconds.

Rudder to Aileron/Elevator

Rudder to Aileron/Elevator mixing corrects coupling in knife edge ﬂ ight.

• Add Elevator mixing if the aircraft pitches toward the landing gear or canopy

• Add Aileron mixing if the aircraft rolls in knife edge ﬂ ight.

Acro Gyro Function

The Gyro menu option enables you to create up to 7 gyro gain points on a maximum of 4 curves. Gyro gain curves also provide ﬂ exibility in reducing gyro gain as the control stick moves farther away from the center.

To program a Gyro curve:

1. Access the Gyro 1 or Gyro 2 menu option from the Function list.

2. Assign either Aircraft or Heli to the Gyro Type and select NEXT.

3. Scroll to Inh > Inh.

a. Select the ﬁ rst Inh and assign the input channel for the

Gyro. For example, if the gyro is installed to assist on the ailerons, select Ail.

b. Select the second Inh and assign the output channel for

the Gyro, for example, the Gear channel.

4. Select the Curve you wish to edit.

5. Add the desired gyro gain values to the points on the curve.

6. Assign the switch positions to activate the gyro curve. The curve is active when the box is solid.

Aileron to Rudder

Use Aileron to Rudder mixing to overcome adverse yaw characteristics with certain types of aircraft such as high-wing aircraft.

Elevator to Flap

Elevator to Flap mixing enables Flap movement when the Elevator stick moves. Use Elevator to Flap mixing to add the spoileron function to 3D aerobatic aircraft.

To access the Gyro screen

1. In the System Setup List Highlight Aircraft Type

2. In the Aircraft Type Screen, select NEXT at the bottom right of the screen. This will access the Aircraft Options screen. Activate the desired Gyro function(s). When the gyro function is active the Gyro function appears in the Function List.

30 SPEKTRUM DX18 • TRANSMITTER INSTRUCTION MANUAL

CHAPTER 3 HELI (Helicopter)

NOTICE: Refer to your helicopter, gyro and governor manuals for programming recommendations.

CAUTION: Always do a Control Test of your model with the transmitter after programming changes

to make sure your model responds as desired.

Swash Type

The Swash Type menu option assigns the swash type for your particular helicopter model.

Select the Swash Type before completing any programming in the Function List. The Swash Type will affect menu options in the Function List.

Collective Type

The collective type is used to turn on “Pull” collective for reversed collective. Available settings are Normal and Reverse. The Collective Type allows the throttle/pitch stick to operate in reverse and ensures trims, curves and all other functions that are to work in reverse funtion properly.

Pitch Curve

This function supports adjustment of collective pitch in 5 ﬂ ight modes.

To adjust the Pitch Curve:

1. Select the Pitch Curve you wish to edit (N, 1 or 2).

2. Scroll right to select the points on the curve and edit the respective values.

3. Press the BACK button to save the Pitch Curves and return to the Function List.

Swashplate

The Swashplate menu option enables you to adjust the following:

• Swashplate Mix

• Exponential

• E-Ring

• Elevator Compensation

Use positive or negative Swashplate mix values as needed for correct direction response of the helicopter.

Before making adjustments to the Swashplate mix, make sure the throttle/collective pitch input moves the entire swashplate up or down. If the servos are not moving in the same direction, reverse them as necessary in the Servo Setup menu option. When the entire swashplate moves up or down:

1. Adjust the mix value for the Aileron and Elevator channels. If the servos do not move in the correct direction, change the direction of the mix, for example, a positive value instead of a negative value.

2. Adjust the mix value for the Pitch. If the swashplate does not move in the correct direction, change the direction of the value (negative instead of positive).

Always enable Expo when using a standard rotating-arm servo. The Expo delivers linear movement of the swashplate from a standard rotary servo. When Expo is inhibited, the arm on a rotary servo moves on a curved path, with decreased swashplate movement at the extremes of the servo arm travel.

NOTICE: Do not enable Expo when using a linear servo.

Electronic E-Ring

This feature prevents overdriving servos by limiting servo travel if the sum of your cyclic and pitch inputs exceed servo limits.

31SPEKTRUM DX18 • TRANSMITTER INSTRUCTION MANUAL

Gyro

The Gyro menu option enables you to assign a gyro gain value to an independent switch or a Flight Mode. Assign the receiver channel connected to the gyro, then assign the switch for gyro options. You can also assign values to available switch positions (from 1 to 5 rates are available, depending on the switch assigned). Make sure the gyro operates correctly and compensates in the correct direction.

Governor

The Governor function adjusts the engine RPM. You can program values for each switch position or ﬂ ight mode. RPM values can be programmed in 0.5% steps.

Programming the Governor Function

1. Access the Governor menu option.

2. Program the RPM values by rotating the scroll wheel to the desired value.

3. Press the scroll wheel and rotate it to the desired value. Press the scroll wheel again to save the value.

NOTICE: The value in the display is the corrected value.

0% is 1.5ms or OFF for most governors. Repeat this for all governor settings.

Tail Curve

The Tail Curve function mixes tail rotor input with the throttle/ collective function to counter torque from the main rotor blades when using a non-heading hold (tail lock) gyro or when using rate mode on a gyro. See Pitch Curve for more information on programming curves.

Mixing

Cyclic to Throttle

Cyclic-to-throttle mix prevents rpm loss when aileron, elevator or rudder inputs are given. This mix advances the throttle position with cyclic or rudder control to maintain rpm. At full throttle, Cyclic-to-Throttle mixing prevents the throttle from overdriving the servo.

IMPORTANT: Do not use Cyclic to throttle mix when using a governor.

To verify that the Cyclic to Throttle mix is working properly and in the correct direction, move the ﬂ ight mode switch to one of the active positions. Move the programmed cyclic or rudder channel noting the throttle position. The throttle position should increase.

If the throttle decreases then the opposite value (positive vs. negative) is needed.

4. Assign the output channel for the Governor. The Governor and the Gyro must be on different channels. We recommend using AUX2 for the Governor output channel.

5. Select a switch to control the Governor.

6. Press the BACK button to save the selections and return to the Function List.

Swashplate

The Swashplate Mix typically corrects swashplate timing issues by mixing Aileron to Elevator and Elevator to Aileron. When adjusted correctly, the Swashplate causes the helicopter to roll and pitch accurately with minimal interaction.

32 SPEKTRUM DX18 • TRANSMITTER INSTRUCTION MANUAL

CHAPTER 4 SAIL (Sailplane)

NOTICE: Refer to your sailplane manual for recommended control throws.

CAUTION: Always do a Control Test of your model with the transmitter after programming to

make sure your model responds as desired.

Sailplane Type

Use the Sailplane Type Screen to select wing and tail types to match your sailplane model. Diagrams and setup names show on the transmitter screen to show the available setups.

Refer to community.spektrumrc.com for more information about new DX18 AirWare updates to support these options.

Wing

1 Servo 2 Aileron* 2 Aileron 1 Flap*

Camber Preset

Camber Preset is only available when 2 or 4 aileron wing type is selected in Sailplane Type. The Camber Preset function enables you to program the ailerons, ﬂ aps, wing tips and elevator for a speciﬁ c position in each Flight Mode.

If ﬂ ight modes are not active, only one preset position is available and it is always active.

The Camber Preset Speed enables the control surfaces to transition over a period of time, up to 30 seconds, when you change ﬂ ight modes.

2 Aileron 2 Flap* 4 Aileron 2 Flap*

Tail

Normal V-Tail A** V-Tail B**

Motor

Inhibit Assign to a Switch (optional)

*Selection of multiple ailerons activates the Differential menu option. **Selection of either of these activates the V-Tail Differential menu option

Move the ﬂ ight mode switch to the desired position to change the Camber Preset values.

Camber System

Camber System is only available when 2 or 4 aileron wing type is selected in Sailplane Type. The Camber System allows in-ﬂ ight camber adjustment and is also used as the braking system, often referred to as Crow or Butterﬂ y. The Camber System enables you to assign the Camber System to a different switch in each ﬂ ight mode.

33SPEKTRUM DX18 • TRANSMITTER INSTRUCTION MANUAL

SAIL Mixing

For each of these mixes, you can program each ﬂ ight mode with different mix values or at 0% if no mix is desired for that speciﬁ c ﬂ ight mode. Programming values include independent control of the direction and amount a slave surface moves in relationship to the master surface.

Aileron to Rudder

The Aileron to Rudder mix is a commonly used for coordinated turns. When active, as aileron is applied the rudder moves in the same direction as the turn (right aileron input results in right rudder output). If you assign the ﬂ ight mode to a switch, a Sub Switch option allows you to assign an additional switch to activate up to 3 Aileron to Rudder mixes for that ﬂ ight mode.

Aileron to Flap

The Aileron to Flap mix allows the entire trailing edge of the wing (aileron and ﬂ ap) to operate as ailerons. When the mix is active, the ﬂ aps move with the ailerons.

Elevator to Flap

Elevator to Flap mix creates additional lift, allowing a tighter turn. The entire trailing edge of the wing (aileron and ﬂ ap) operate as ﬂ aps (camber increase) when you apply elevator. An offset is provided which is typically used for Snap Flaps. With Snap Flap, no Elevator to Flap mix occurs until the offset value is reached. Typically this offset is at 70% up elevator so that beyond 70% the down ﬂ ap mix comes in, providing additional lift for more aggressive turning (for tight thermals or racing turns).

Flap to Elevator

Flap to Elevator mix prevents pitch up tendency that occurs when you apply Crow or Butterﬂ y. This mix is typically used only with the Camber System. The Flap to Elevator mix operates as a curve, so that the elevator moves down the most during the ﬁ rst 20% of ﬂ ap deployment, decreases over the next 40% then remains the same from 60 to 100% of ﬂ ap travel.

For sailplanes with ailerons/tips/ﬂ aps, make sure an appropriate Sailplane Type is selected so that tips appear in the transmitter as RAIL and LAIL. Decrease or increase travel on the tip ailerons by creating an AIL > RAIL mix.

CHAPTER 5 RECEIVER INSTALLATION AND POWER SYSTEM REQUIREMENTS

AR9020 Receiver Speciﬁ cations:

Weight: 0.42 oz (11.9 g) Voltage Range: 3.5V-9.6V Length: 1.61 in (41mm) Width: 0.91 in (23mm) Height: 0.79 in (20mm) Range: Full Number Of Channels: 9 Band: 2.4GHz Model Type: Airplane/Heli/Sailplane Telemetry: Yes

Features:

• 9-channel full range receiver

• Patented MultiLink™ receiver technology

• Includes one internal and two remote receiver

• An optional third remote receiver can also be used (SPM9645)

• SmartSafe™ failsafe system

• QuickConnect™

• Flight Log and Telemetry compatible (optional)

• 2048 Resolution

• High-speed 11ms operation when used with capable transmitters

Receiver Installation

For optimum RF link performance, mount the main receiver and remote antennas in an orientation that allows for the best possible signal reception when the aircraft is in all possible attitudes and positions. Where supplied with the transmitter, install the primary receiver in your model. Put the primary receiver in protective foam and install the receiver in the model using rubber bands or hook-and-loop straps. Use thick double-sided foam tape to install the primary receiver in electric airplanes or helicopters. Mount each remote receiver at least 2 inches (51mm) away from the primary receiver, primary antenna and each other using double-sided foam tape. Orient the antennas perpendicular to each other; typically one vertical and one horizontal (see manufacturer’s receiver installation instructions). This gives tremendous improvements in path diversity as each receiver can “see” a different RF environment. This is key to maintaining a solid RF link, especially in aircraft that have substantial conductive materials (e.g., larger gas engines, carbon ﬁ ber, pipes, etc.), which can weaken or block the signal. In airplanes, we recommend mounting the primary receiver in the center of the fuselage on the servo tray and the remote receivers on the side of the fuselage or in the turtle deck (space behind the canopy and in front of the vertical stabilizer). In helicopters, install receivers in the radio tray, where there is usually sufﬁ cient room for receiver separation. Where there is not sufﬁ cient room, install a receiver on an external receiver mount made of clear plastic.

34 SPEKTRUM DX18 • TRANSMITTER INSTRUCTION MANUAL

NOTICE: The DSMX DX18 is compatible with all current Spe-

ktrum DSM2 and DSMX aircraft receivers, but NOT compatible with the original DSM AR6000 receiver.

Power System Requirements

Set up and operate a model so power to the receiver is NEVER interrupted while ﬂ ying. This is especially critical on giant-scale models that use several high-torque or high-current servos. Power systems unable to provide minimum receiver voltage in ﬂ ight are the number-one cause of in-ﬂ ight failures. Some components that cause a receiver to have too little power supply include:

• Receiver battery (number of cells, capacity, cell type, state of charge)

• Switch harness

• Battery leads

• Regulator (where used),

• Power bus (where used)

A Spektrum receiver’s minimum operational voltage is 3.5 volts. This battery charge capacity compensates for discharge during ﬂ ight or for ﬂ ight loads larger than ground test loads.

CAUTION: We recommend that you DO NOT ﬂ y a model

with battery charges at less than 5.3-volts.

Recommended Power System Guidelines

1. When setting up large or complex aircraft with multiple hightorque servos, use a current and voltmeter (HAN172). Plug the voltmeter in an open channel port in the receiver, and with the system on, load the control surfaces on your aircraft by applying pressure with your hand. Monitor the current as you load control surfaces. The voltage should remain above

4.8 volts even when all servos are heavily loaded.

2. With the current meter inline with the receiver battery lead, load control surfaces while monitoring the current. The maximum continuous recommended current for a single heavy-duty servo/battery lead is 3 amps. Short-duration current spikes of up to 5 amps are acceptable. If your system draws more than these currents, you need to use multiple packs of the same capacity with multiple switches and multiple leads plugged into the receiver.

3. If using a regulator, perform tests for a 5-minute period. A regulator may provide adequate short-term power, but this tests its ability to maintain voltage at signiﬁ cant power levels over time.

4. For really large aircraft or complex models, multiple battery packs with multiple switch harnesses are necessary. No matter what power systems you choose, always carry out test #1. Make sure the receiver is constantly provided with

4.8 volts or more under all conditions.

CAUTION: When charging any brand of NiMH battery

pack, make sure the battery is fully charged. Due to the nature of peak charges and variations in charging rates, heat development, and cell types–the capacity reading of a battery charged on a fast peak charger may only reach 80% of its nominal value. Use a charger that displays total charge capacity. Note the number of mAh put into a discharged pack to verify the charge is at full capacity.

CHAPTER 6 PHYSICAL TRANSMITTER ADJUSTMENTS

Mode Conversion

You can perform mode changes in the System Settings screen. However, if you desire to change modes between 1 and 2 or between 3 and 4, please contact Horizon Hobby for assistance due to requirements for changing gimbals.

Adjust Stick Tension

Adjust stick tension using the screws on the stick gimbals through holes in the back of the transmitter.

1. Remove rubber plugs from holes marked with a vertical arrow or a horizontal arrow.

2. Turn the screws in these holes a small amount using a small Phillips screwdriver to adjust tension on the vertical and horizontal gimbals.

NOTICE: Always do a test of stick tension while turning these screws to ensure stick tension is not too loose or too tight. Tightening a screw too much can damage a spring. Loosening a screw too much can let a spring fall off and cause short-circuit in the transmitter.

CAUTION: Always power off the transmitter, disconnect

and remove the battery before adjusting stick tension or friction straps. Not doing so could result in property damage or injury.

Control Stick Length Adjustment

1. Adjust control stick length using a 2mm Allen wrench.

2. Turn the setscrew in the stick counterclockwise to loosen it. Make the stick shorter by turning it clockwise or longer by turn ing it counterclockwise.

3. After adjustment of stick length, tighten the setscrew.

35SPEKTRUM DX18 • TRANSMITTER INSTRUCTION MANUAL

Throttle friction strip tension

screws

Gimbal spring covers

Friction straps access screws

(Throttle Ratchet Strip installation)

Function

Adjust Throttle Friction Straps

• Pull up the top of the rear grip on the back of the transmitter to adjust the friction strip on the throttle gimbal. Only the top of the grip must be pulled up to access the adjustment screw, the entire grip does not need to be removed.

• Use a small Phillips screwdriver to tighten or loosen the screw for friction strip.

Throttle Ratchet Strip Installation

The transmitter is manufactured with a smooth friction strip and the included optional ratchet strip may be installed if desired.

CAUTION: Always power off the transmitter, disconnect

and remove the battery before opening the transmitter

case. Not doing so could result in property damage or injury.

1. Remove the battery door and disconnect the battery from your transmitter.

2. Carefully pull up the top of the left and right rear hand grips on the back of the transmitter to expose the 2 case screws. Tip: Only the top portion of the grip needs to be pulled back, the entire grip does not need to be removed to access the case screws.

3. Carefully remove and keep 4 screws from the back of the

• Reinstall the top of the rear grip after completing the adjustment as desired.

transmitter (2 in lower corners and 2 under the back hand grips).

4. Carefully open the transmitter case so no wires are stretched or pulled.

5. Remove and keep 2 screws from the installed throttle ratchet strip.

6. Do not remove grease from plastic part under the strip.

7. Attach the strip to the gimbal using the 2 screws.

8. Tighten the spring tension screw to get desired stick tension.

CAUTION: Make sure no wires or components are

pinched or damaged while installing the back cover.

9. Carefully close the transmitter case using the 4 screws and re-install the hand grips.

10. Connect the battery to your transmitter.

36 SPEKTRUM DX18 • TRANSMITTER INSTRUCTION MANUAL

2.4GHz TROUBLESHOOTING GUIDE

Problem Possible Cause Solution

Move powered transmitter a few feet from aircraft, disconnect and reconnect ﬂ ight battery to aircraft

Move the aircraft or transmitter away from the large metal object

Install bind plug in bind port and bind the aircraft to the transmitter

Move powered transmitter a few feet from aircraft, disconnect and reconnect ﬂ ight battery to aircraft

Move the aircraft or transmitter away from the large metal object

Rebind transmitter to the aircraft and remove the bind plug before cycling power

Select correct model memory on transmitter

Bind aircraft to transmitter

Replace or contact Horizon Product Support

Install main and remote receivers at least 2 inches (51mm) apart and perpendicular to each other

Do a check of the wires and connection between battery and receiver. Repair or replace wires and/or connectors

If stand is pressing bind button, remove from stand and rebind

Power off transmitter when receiver is powered off

Reposition remote receivers for improved RF signal path diversity

Check for and stop feedback from servos or motor systems to the ESC or receiver

Check aircraft power draw and increase battery power or decrease power demand by installed systems Ensure all aircraft batteries are fully charged. nsure the installed BEC for an electric aircraft is adequate for the power demand

Aircraft will not Bind (during binding) to transmitter

Aircraft will not link (after binding) to transmitter

The receiver goes into failsafe mode a short distance away from the transmitter

Receiver quits responding during operation

Receiver loses its bind

Receiver slowly blinking at landing

(DSM2 Only)

Flight log registers undesirable number of fades, losses or holds or aircraft responds irregularly to controls

Transmitter too near aircraft during binding process

Aircraft or transmitter is too close to large metal object

The bind plug is not installed correctly in the bind port

Flight battery/Transmitter battery charge is too low Replace/recharge batteries

Transmitter too near aircraft during linking process

Aircraft or transmitter is too close to large metal object

Bind plug left installed in bind port

Aircraft bound to different model memory (ModelMatch™ radios only)

Flight battery/Transmitter battery charge is too low Replace/recharge batteries Transmitter may have been bound using different DSM

protocol Check the receiver antenna to be sure it is not cut or

damaged

Main and remote receivers too near each other

Low battery voltage Completely recharge ﬂ ight battery Loose or damaged wires or connectors between

battery and receiver Transmitter stand or tray could be pressing the bind

button Bind button pressed before transmitter powered on Rebind by performing binding instructions Loss of power to the receiver during flight Check battery voltage System powered on and connected then receiver pow-

ered off without powering off transmitter

Poor signal reception

Electronic feedback

Low power

PARTS LIST

Number Description

SPMB2600LPTX 2600 mAh Tx Battery: DX18 SPMA3070 Battery Door: DX18 SPMA3071 Back Grips (Left/Right) SPMA3072 Side Grips (Left/Right) SPMA3073 Rubber Plugs: DX18 SPMA3074 Replacement Antenna: DX18 SPM9551 International 12V Transmitter AC Adapter

Number Description

SPM6708 Spektrum Single Stand Up Transmitter Case SPM6709 Spektrum Single Stand Up Transmitter Case

Foam SPM6803 Male/Female Universal Bind Plug SPM9540 Spektrum Flight Log HAN172 Digital Servo and Receiver Current Meter:

Hangar 9 SPM6805 Trainer Cord

37SPEKTRUM DX18 • TRANSMITTER INSTRUCTION MANUAL

AMA NATIONAL MODEL AIRCRAFT SAFETY CODE

Effective January 1, 2011

A. GENERAL: A model aircraft is a non-human-carrying aircraft

capable of sustained ﬂ ight in the atmosphere. It may not exceed limitations of this code and is intended exclusively for sport, recreation and/or competition. All model ﬂ ights must be conducted in accordance with this safety code and any additional rules speciﬁ c to the ﬂ ying site.

1. Model aircraft will not be ﬂ own: (a) In a careless or reckless manner. (b) At a location where model aircraft activities are prohibited.

2. Model aircraft pilots will: (a) Yield the right of way to all man carrying aircraft. (b) See and avoid all aircraft and a spotter must be used

when appropriate. (AMA Document #540-D-See and Avoid Guidance.)

level within three (3) miles of an airport, without notifying the airport operator.

(d) Not interfere with operations and trafﬁ c patterns at any

airport, heliport or seaplane base except where there is a mixed use agreement.

(e) Not exceed a takeoff weight, including fuel, of 55 pounds

unless in compliance with the AMA Large Model Aircraft program. (AMA Document 520-A)

(f) Ensure the aircraft is identiﬁ ed with the name and address

or AMA number of the owner on the inside or afﬁ xed to the outside of the model aircraft. (This does not apply to model aircraft ﬂ own indoors).

(g) Not operate aircraft with metal-blade propellers or with

gaseous boosts except for helicopters operated under the provisions of AMA Document #555.

(h) Not operate model aircraft while under the inﬂ uence of

alcohol or while using any drug which could adversely affect the pilot’s ability to safely control the model.

(i) Not operate model aircraft carrying pyrotechnic devices

which explode or burn, or any device which propels a projectile or drops any object that creates a hazard to persons or property.

Exceptions:

• Free Flight fuses or devices that burn producing smoke and are securely attached to the model aircraft during ﬂ ight.

• Rocket motors (using solid propellant) up to a G-series size may be used provided they remain attached to the model during ﬂ ight. Model rockets may be ﬂ own in accordance with the National Model Rocketry Safety Code but may not be launched from model aircraft.

• Ofﬁ cially designated AMA Air Show Teams (AST) are authorized to use devices and practices as deﬁ ned within the Team AMA Program Document (AMA Document #718).

(j) Not operate a turbine-powered aircraft, unless in compliance

with the AMA turbine regulations. (AMA Document #510-A).

3. Model aircraft will not be ﬂ own in AMA sanctioned events, air shows or model demonstrations unless:

(a) The aircraft, control system and pilot skills have successfully

demonstrated all maneuvers intended or anticipated prior to the speciﬁ c event.

(b) An inexperienced pilot is assisted by an experienced pilot.

4. When and where required by rule, helmets must be properly worn and fastened. They must be OSHA, DOT, ANSI, SNELL or NOCSAE approved or comply with comparable standards.

B. RADIO CONTROL (RC)

1. All pilots shall avoid ﬂ ying directly over unprotected people, vessels, vehicles or structures and shall avoid endangerment of life and property of others.

2. A successful radio equipment ground-range check in accordance with manufacturer’s recommendations will be completed before the ﬁ rst ﬂ ight of a new or repaired model aircraft.

3. At all ﬂ ying sites a safety line(s) must be established in front of which all ﬂ ying takes place (AMA Document #706-Recommended Field Layout):

(a) Only personnel associated with ﬂ ying the model aircraft are

allowed at or in front of the safety line.

(b) At air shows or demonstrations, a straight safety line must be

established.

spectators.

(d) Intentional ﬂ ying behind the safety line is prohibited.

4. RC model aircraft must use the radio-control frequencies currently allowed by the Federal Communications Commission (FCC). Only individuals properly licensed by the FCC are authorized to operate equipment on Amateur Band frequencies.

5. RC model aircraft will not operate within three (3) miles of any pre-existing ﬂ ying site without a frequency-management agreement (AMA Documents #922-Testing for RF Interference; #923- Frequency Management Agreement)

6. With the exception of events ﬂ own under ofﬁ cial AMA Competition Regulations, excluding takeoff and landing, no powered model may be ﬂ own outdoors closer than 25 feet to any individual, except for the pilot and the pilot’s helper(s) located at the ﬂ ight line.

7. Under no circumstances may a pilot or other person touch a model aircraft in ﬂ ight while it is still under power, except to divert it from striking an individual. This does not apply to model aircraft ﬂ own indoors.

8. RC night ﬂ ying requires a lighting system providing the pilot with a clear view of the model’s attitude and orientation at all times.

9. The pilot of a RC model aircraft shall:

(a) Maintain control during the entire ﬂ ight, maintaining visual

contact without enhancement other than by corrective lenses prescribed for the pilot.

(b) Fly using the assistance of a camera or First-Person View

(FPV) only in accordance with the procedures outlined in AMA Document #550.

Please see your local or regional modeling association’s guidelines for proper, safe operation of your model aircraft.

38 SPEKTRUM DX18 • TRANSMITTER INSTRUCTION MANUAL

FCC INFORMATION

This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

CAUTION: Changes or modiﬁ cations not expressly ap-

proved by the party responsible for compliance could void the user’s authority to operate the equipment. This product contains a radio transmitter with wireless technology which has been tested and found to be compliant with the applicable regulations governing a radio transmitter in the

2.400GHz to 2.4835GHz frequency range.

This product contains a radio transmitter with wireless technology which has been tested and found to be compliant with the applicable regulations governing a radio transmitter in the

2.400GHz to 2.4835GHz frequency range.

FAA INFORMATION

ANTENNA SEPARATION DISTANCE

When operating your Spektrum transmitter, please be sure to maintain a separation distance of at least 5 cm between your body (excluding ﬁ ngers, hands, wrists, ankles and feet) and the antenna to meet RF exposure safety requirements as determined by FCC regulations. The following illustrations show the approximate 5 cm RF exposure area and typical hand placement when operating your Spektrum transmitter.

Prior to ﬂ ying, contact your local or regional modeling organizations for guidance and familiarize yourself with the current local rules and FAA regulations governing model aviation in your location.

More information about model aviation can be found at

http://www.modelaircraft.org

The Federal Aviation Administration can be found online at

http://www.faa.gov

39SPEKTRUM DX18 • TRANSMITTER INSTRUCTION MANUAL

1-YEAR LIMITED WARRANTY

What this Warranty Covers

Horizon Hobby, Inc., (Horizon) warrants to the original purchaser that the product purchased (the “Product”) will be free from defects in materials and workmanship for a period of 1 years from the date of purchase.

What is Not Covered

This warranty is not transferable and does not cover (i) cosmetic damage, (ii) damage due to acts of God, accident, misuse, abuse, negligence, commercial use, or due to improper use, installation, operation or maintenance, (iii) modiﬁ cation of or to any part of the Product, (iv) attempted service by anyone other than a Horizon Hobby authorized service center, (v) Product not purchased from an authorized Horizon dealer, or (vi) Product not compliant with applicable technical regulations.

OTHER THAN THE EXPRESS WARRANTY ABOVE, HORIZON MAKES NO OTHER WARRANTY OR REPRESENTATION, AND HEREBY DISCLAIMS ANY AND ALL IMPLIED WARRANTIES, INCLUDING, WITHOUT LIMITATION, THE IMPLIED WARRANTIES OF NON-INFRINGEMENT, MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. THE PURCHASER ACKNOWLEDGES THAT THEY ALONE HAVE DETERMINED THAT THE PRODUCT WILL SUITABLY MEET THE REQUIREMENTS OF THE PURCHASER’S INTENDED USE.

Purchaser’s Remedy

Horizon’s sole obligation and purchaser’s sole and exclusive remedy shall be that Horizon will, at its option, either (i) service, or (ii) replace, any Product determined by Horizon to be defective. Horizon reserves the right to inspect any and all Product(s) involved in a warranty claim. Service or replacement decisions are at the sole discretion of Horizon. Proof of purchase is required for all warranty claims. SERVICE OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE PURCHASER’S SOLE AND EXCLUSIVE REMEDY.

Limitation of Liability

HORIZON SHALL NOT BE LIABLE FOR SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES, LOSS OF PROFITS OR PRODUCTION OR COMMERCIAL LOSS IN ANY WAY, REGARDLESS OF WHETHER SUCH CLAIM IS BASED IN CONTRACT, WARRANTY, TORT, NEGLIGENCE, STRICT LIABILITY OR ANY OTHER THEORY OF LIABILITY, EVEN IF HORIZON HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Further, in no event shall the liability of Horizon exceed the individual price of the Product on which liability is asserted. As Horizon has no control over use, setup, ﬁ nal assembly, modiﬁ cation or misuse, no liability shall be assumed nor accepted for any resulting damage or injury. By the act of use, setup or assembly, the user accepts all resulting liability. If you as the purchaser or user are not prepared to accept the liability associated with the use of the Product, purchaser is advised to return the Product immediately in new and unused condition to the place of purchase.

Law

These terms are governed by Illinois law (without regard to conﬂ ict of law principals). This warranty gives you speciﬁ c legal rights, and you may also have other rights which vary from state to state. Horizon reserves the right to change or modify this warranty at any time without notice.

WARRANTY SERVICES Questions, Assistance, and Services

Your local hobby store and/or place of purchase cannot provide warranty support or service. Once assembly, setup or use of the Product has been started, you must contact your local distributor or Horizon directly. This will enable Horizon to better answer your questions and service you in the event that you may need any assistance. For questions or assistance, please visit our website at www.horizonhobby.com, submit a Product Support Inquiry, or call 877.504.0233 toll free to speak to a Product Support representative.

Inspection or Services

If this Product needs to be inspected or serviced and is compliant in the country you live and use the Product in, please use the Horizon Online Service Request submission process found on our website or call Horizon to obtain a Return Merchandise Authorization (RMA) number. Pack the Product securely using a shipping carton. Please note that original boxes may be included, but are not designed to withstand the rigors of shipping without additional protection. Ship via a carrier that provides tracking and insurance for lost or damaged parcels, as Horizon is not responsible for merchandise until it arrives and is accepted at our facility. An Online Service Request is available at http://www. horizonhobby.com/content/_service-center_render-service-center. If you do not have internet access, please contact Horizon Product Support to obtain a RMA number along with instructions for submitting your product for service. When calling Horizon, you will be asked to provide your complete name, street address, email address and phone number where you can be reached during business hours. When sending product into Horizon, please include your RMA number, a list of the included items, and a brief summary of the problem. A copy of your original sales receipt must be included for warranty consideration. Be sure your name, address, and RMA number are clearly written on the outside of the shipping carton.

Notice: Do not ship LiPo batteries to Horizon. If you have any issue with a LiPo battery, please contact the appropriate Horizon Product Support ofﬁ ce.

Warranty Requirements For Warranty consideration, you must include your original sales

receipt verifying the proof-of-purchase date. Provided warranty

conditions have been met, your Product will be serviced or replaced free of charge. Service or replacement decisions are at the sole discretion of Horizon.

Non-Warranty Service Should your service not be covered by warranty service will be completed and payment will be required without notiﬁ cation or estimate of the expense unless the expense exceeds 50% of the retail purchase cost. By submitting the item for service you

are agreeing to payment of the service without notiﬁ cation. Service estimates are available upon request. You must include this request with your item submitted for service. Non-warranty service estimates will be billed a minimum of ½ hour of labor. In addition you will be billed for return freight. Horizon accepts money orders and cashier’s checks, as well as Visa, MasterCard, American Express, and Discover cards. By submitting any item to Horizon for service, you are agreeing to Horizon’s Terms and Conditions found on our website http://www.horizonhobby. com/content/_service-center_render-service-center.

NOTICE: Horizon service is limited to Product compliant in the country of use and ownership. If non-compliant product is received by Horizon for service, it will be returned unserviced at the sole expense of the purchaser.

40 SPEKTRUM DX18 • TRANSMITTER INSTRUCTION MANUAL

WARRANTY AND SERVICE CONTACT INFORMATION

Country of Purchase Horizon Hobby Address Phone Number/Email Address

Horizon Service Center

United States of America

(Electronics and engines)

Horizon Product Support (All other products)

United Kingdom Horizon Hobby Limited

Germany

Horizon Technischer Service

France Horizon Hobby SAS

China Horizon Hobby – China

4105 Fieldstone Rd Champaign, Illinois, 61822 USA

Units 1-4 Ployters Rd Staple Tye Harlow, Essex CM18 7NS, United Kingdom

Christian-Junge-Straße 1 25337 Elmshorn, Germany

11 Rue Georges Charpak 77127 Lieusaint

Room 506, No. 97 Changshou Rd. Shanghai, China 200060

877-504-0233 Online Repair Request: visit www.horizonhobby.com/service

877-504-0233 productsupport@horizonhobby.com

+44 (0) 1279 641 097 sales@horizonhobby.co.uk

+49 (0) 4121 2655 100 service@horizonhobby.de

+33 (0) 1 60 18 34 90 infofrance@horizonhobby.com

+86 (021) 5180 9868 info@horizonhobby.com.cn

PARTS CONTACT INFORMATION

Country of Purchase Horizon Hobby Address Phone Number/Email Address

United States Sales

United Kingdom Horizon Hobby Limited

Germany Horizon Hobby GmbH

France Horizon Hobby SAS

China Horizon Hobby – China

4105 Fieldstone Rd Champaign, Illinois, 61822 USA

Units 1-4 Ployters Rd Staple Tye Harlow, Essex CM18 7NS United Kingdom

Christian-Junge-Straße 1 25337 Elmshorn, Germany

11 Rue Georges Charpak 77127 Lieusaint

Room 506, No. 97 Changshou Rd. Shanghai, China 200060

800-338-4639 sales@horizonhobby.com

+44 (0) 1279 641 097 sales@horizonhobby.co.uk

+49 (0) 4121 2655 100 service@horizonhobby.de

+33 (0) 1 60 18 34 90 infofrance@horizonhobby.com

+86 (021) 5180 9868 info@horizonhobby.com.cn

COMPLIANCE INFORMATION FOR THE EUROPEAN UNION

Declaration of Conformity

(in accordance with ISO/IEC 17050-1) No. HH20120501

Product(s): SPM DX18 Transmitter Item Number(s): SPM18000EU, SPM180001EU Equipment class: 2 The object of declaration described above is in conformity with the requirements of the speciﬁ cations listed below, following the provisions of the European R&TTE directive 1999/5/EC, EMC Directive 2004/108/ EC and LVD Directive 2006/95/EC:

EN 300-328 V1.7.1: 2006 EN 301 489-1 V1.7.1: 2006 EN 301 489-17 V1.3.2: 2008 EN 60950-1:2006+A12:2011

EN55022: 2010 EN55024: 2010 EN61000-3-2:2006+A1:2009+A2:2009 EN61000-3-3:2008

Signed for and on behalf of: Horizon Hobby, Inc. Champaign, IL USA May 1, 2011

Executive Vice President and Chief Operating Ofﬁ cer

International Operations and Risk Management

Steven A. Hall

Horizon Hobby, Inc.

AT BE BG CZ CY DE DK ES FI FR GR HU IE IT LT LU LV MT NL PL PT

RO SE SI SK UK

Instructions for disposal of WEEE by users in the European Union

This product must not be disposed of with other waste. Instead, it is the user’s responsibility to dispose of their waste equipment by handing it over to a designated collections point for the recycling of waste electrical and electronic equipment. The separate collection and recycling of your waste

equipment at the time of disposal will help to conserve natural resources and ensure that it is recycled in a manner that protects human health and the environment. For more information about where you can drop off your waste equipment for recycling, please contact your local city ofﬁ ce, your household waste disposal service or where you purchased the product.

41SPEKTRUM DX18 • TRANSMITTER INSTRUCTION MANUAL

The Spektrum trademark is used with permission of Bachmann Industries, Inc.

DSM2, AirWare, SimpleScroll, JR, Vibe, X-Plus and Bind-N-Fly are trademarks or registered trademarks of

Horizon Hobby, Inc. DSMX is a trademark of Horizon Hobby, Inc., registered in the US.

SD Logo is a trademark of SD-3C, LLC

US 7,391,320. Other patents pending.

www.spektrum-rc.com

Created 8/12 28994.1 SPM18000, SPM18000EU, SPM180001EU

Spektrum SPM18000 DX18 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
