Page 1

DATA PROJECTOR

VPL-PX35

DATA PROJECTOR

VPL-PX40

DATA PROJECTOR

VPL-FX51

PROTOCOL MANUAL 1st Edition (Revised 3)

Page 2

! WARNING

This manual is intended for qualified service personnel only. To reduce the risk of electric shock, fire or injury, do not perform any servicing other than that contained in the operating instructions unless you are qualified to do so. Refer all servicing to qualified service personnel.

! WARNUNG

Die Anleitung ist nur für qualifiziertes Fachpersonal bestimmt. Alle Wartungsarbeiten dürfen nur von qualifiziertem Fachpersonal ausgeführt werden. Um die Gefahr eines elektrischen Schlages, Feuergefahr und Verletzungen zu vermeiden, sind bei Wartungsarbeiten strikt die Angaben in der Anleitung zu befolgen. Andere als die angegeben Wartungsarbeiten dürfen nur von Personen ausgeführt werden, die eine spezielle Befähigung dazu besitzen.

! AVERTISSEMENT

Ce manual est destiné uniquement aux personnes compétentes en charge de l’entretien. Afin de réduire les risques de décharge électrique, d’incendie ou de blessure n’effectuer que les réparations indiquées dans le mode d’emploi à moins d’être qualifié pour en effectuer d’autres. Pour toute réparation faire appel à une personne compétente uniquement.

VPL-PX35/PX40/FX51

Page 3

1. Introduction .............................................................................................. 1

2. RS-232C

2-1. Communication Specifications ...................................................................... 1

2-2. Command Block Format ................................................................................ 2

2-3. Block Format.................................................................................................. 3

2-4. Connection ..................................................................................................... 4

2-5. Communication Procedure............................................................................. 4

2-5-1. Outline of Communication............................................................ 4

2-6. Communication Rules .................................................................................... 5

2-7. Approximate Return Waiting Times .............................................................. 5

3. NETWORK

3-1. Introduction .................................................................................................... 6

3-1-1. Advertisement ............................................................................... 6

3-1-1-1. Function ..................................................................... 6

3-1-1-2. Setup Items ................................................................ 6

3-1-2. Remote Control ............................................................................. 7

3-1-2-1. Function ..................................................................... 7

3-1-2-2. Setup Items ................................................................ 7

3-2. SDAP Protocol ............................................................................................... 8

3-3. SDCP Protocol ............................................................................................... 9

3-3-1. Format ........................................................................................... 9

3-3-1-1. Header ........................................................................ 9

3-3-1-2. Community ................................................................ 9

3-3-1-3. Command ................................................................. 10

3-3-1-4. SET Request ............................................................ 11

3-3-1-5. GET Request ............................................................ 11

3-3-1-6. ERROR Response .................................................... 11

3-3-2. Items ............................................................................................ 12

3-3-2-1. Model Dependent Category ..................................... 12

3-3-2-2. Equipment Information Acquisition (80**h) .......... 12

3-3-2-3. Network Information Acquisition (90**h) .............. 13

3-3-3. Error Code ................................................................................... 14

3-3-3-1. Item Error ................................................................. 15

3-3-3-2. Community Error ..................................................... 15

3-3-3-3. Request Error ........................................................... 16

3-3-3-4. Network Error .......................................................... 16

3-3-3-5. Comm Error ............................................................. 17

3-3-3-6. NVRAM Error ......................................................... 17

VPL-PX35/PX40/FX51

Page 4

Appendix A. Setup Method For VPL-PX35 and PX40

A-1. Command ..................................................................................................... 18

A-1-1. Setting ......................................................................................... 18

A-1-2. Display ........................................................................................ 19

A-2. Setting Command ......................................................................................... 20

Appendix B ..................................................................................................... 21

VPL-PX35/PX40/FX51

Page 5

1. Introduction

This protocol manual describes the basic configuration and basic operations of various commands used for projector. Projector can be controlled using the commands provided in “Appendix”. Using an external CONTROLLER , etc., inputs can be switched and the power can also be turned on and off. In the following paragraphs, “CONTROLLER” means an external device such as a PC which controls projector using these commands.

2. RS-232C

2-1. Communication Specifications

<RS-232C Communication Signal>

. Full duplex communication channels (Flow control not performed.) . Start-stop synchronism system . Baud rate: 38.4 kbps (bits per second) . The bit configuration is defined as follows.

1 START Bit + 8 DATA Bits + 1 PARITY Bit + 1 STOP Bit

START D3D2D1D0

BIT

D4 D5 D6 D7

(MSB)(LSB) (EVEN) BIT

EVEN Parity.....Total number of “1”s from D0 to D7 is an even number.

PARITY STOP

VPL-PX35/PX40/FX51

Page 6

2-2. Command Block Format

The code from B0 to B7 as described below are transmitted.

Transmission from

the Master side

B0 B1

B2 B3

B4 B5 B6 B7

ITEM NUMBER ACK / NAK ITEM NUMBER

SET / GET ACK

DATA

B0 START CORD

Common in the all FORMAT

B6 CHECK SUM

B1 to B5 are calculated by OR;

0 x A9 1010 1001 0 x A9 1010 1001 0 x A9 1010 1001 0 x 9A 1001 1010 Answer 1010 1001 Answer 1011 1011

Reception in

the Master side

START CODE : 0 x A9

DUMMY DATA

CHECK SUM

END CODE : 0 x 9A

Reception in the Master side

0 x A9 0 x BB

(With Data)

DATA

B7 END CODE

Common in the all FORMAT

VPL-PX35/PX40/FX51

Page 7

2-3. Block Format

B0 B1

B2 B3

B4 B5 B6 B7

B1 B2

B4 B5 B6 B7

Transmission from the Master side

START CODE

ITEM NUMBER

SET / GET

DATA

CHECK SUM

END CODE

Reception in the Master side

START CODEB0

ACK / NAK

ACK

DUMMY DATA

CHECK SUM

END CODE

Data transmission to the Projector

Start of Command Set the Data Category Value desired.

Refer to the Appendix B Table 1 for details. SET: 0 x 00 (Set data)

GET: 0 x 01 (Get data) SET: Data to be set (Refer to the Appendix B Table 2)

GET: Unused. Set Dummy data [0 x 00, 0 x 00] Check Sum End of Command

Receive results of the data transmission from the Projector.

Start of Command Results correspond with the data transmission

Refer to the Appendix B Table 3 for the data in detail. [0 x 03]

Express Reply data either of ACK, or NAK This data does not mean any senses.

Dummy Data [0 x 00, 0 x 00] is stored. Check Sum

End of Command

Reception in the Master side (With Data)

START CODEB0

B1 B2

B4 B5 B6 B7

ITEM NUMBER

DATA

CHECK SUM

END CODE

Receive data from the Projector

Start of Command Data to acquire

Refer to the Appendix B Table 1 in detail. [0 x 02]

Express data to be Reply data Received data

Refer to the Appendix B Table 2 in detail. Check Sum End of Command

VPL-PX35/PX40/FX51

Page 8

2-4. Connection

<RS-232C Connection>

Communication is enabled by the use of a D-Sub 9 Pin cross (reverse) cable. The pin assignment of D-Sub 9 Pin and D-Sub 25 Pin is as follows.

D-Sub 9 Pin

Shell = FG

3 2 7 8 6 5 1 4 9

D-Sub 25 Pin

1 2 3 4 5 6 7

8 20 22

Name

Grounding for safety protection or cable shield

TxD

Transmission data

RxD

Reception data

RTS

Transmission request

CTS

Transmission permission

DSR

Data set ready

GND for signal

DCD

Data channel signal carrier detection

DTR

Data terminal ready

Calling display (Presence/absence of calling signal)

Pins indicated as D-Sub 25 Pin are not used. Assured cable length: 15 m (However, assurance may not be applicable for some cables.)

The software for controlling the projector from a PC is intended for performing transmission and reception for only the TxD and RxD lines. Therefore there is no handshake normally performed by RS-232C.

2-5. Communication Procedure

2-5-1. Outline of Communication

All communication between CONTROLLER (PC, etc.) and DEVICE (PROJECTOR) is performed by the command block format. Communication is started by the issue of a command at CONTROLLER and ended when the return Data is sent to CONTROLLER after DEVICE receives the command. CONTROLLER is prohibited from sending several commands at one time. This means that after CONTROLLER sends one command, it cannot send other commands until DEVICE returns the return Data. DEVICE sends the return Data after processing the command. The time from when CONTROLLER sends the command until the return Data is returned differs according to the contents of the command.

When Sircs Direct Command is sent, return Data may not be returned in some cases.

VPL-PX35/PX40/FX51

Page 9

2-6. Communication Rules

. When sending a command from CONTROLLER, the return Data from PROJECTOR should be

received first before sending the next command. Even if the next command is sent before receiving the return Data, since PROJECTOR will not be able to receive that command, it does not return a response to CONTROLLER. Consequently, no error code is also sent. The following lists the approximate waiting times for PROJECTOR to return the return Data after CONTROLLER sends the command.

. When a communication error occurs, PROJECTOR ignores the Data received until now, and set into

the reception standby state.

. For undefined commands or commends determined as invalid by PROJECTOR, PROJECTOR will

send the “NAK” return Data to CONTROLLER .

. Take note that when Data is written when the input signal of PROJECTOR is unstable, that Data

(value) will not be incorporated.

. When INDEX specified SIRCS direct command is transmitted, leave an interval of 45 msec until the

next transmission. (Do not return the return Data (ACK, NAK) when the SIRCS direct command is received.)

2-7. Approximate Return Waiting Times

The await-return time is approx. 30 msec.

This is the case, unless the communications are interfered anyway.

VPL-PX35/PX40/FX51

Page 10

3. NETWORK

3-1. Introduction

This section describes the specifications, performance and operations of the network service that is going to be installed in the target projector.

3-1-1. Advertisement

The advertisement service is provided to facilitate development of a PC application that can automatically detect a projector on the network. This function is achieved by broadcasting the equipment information periodically to the network.

3-1-1-1. Function

The equipment information shown below is transmitted as the broadcast packet periodically (at certain intervals).

Information Description

Category Category of the equipment Equipment name Name of the equipment Serial number Serial number of the equipment Installation information Installation location of the equipment Community Community name of the equipment Power status Power status of the equipment

m . The category of projector is 0x0a. . The power status sets ffffh if communication error occurs.

Protocol

The SDAP protocol is defined in order to provide this service.

Item Description

Protocol name SDAP (Simple Display Advertisement Protocol) Transport UDP Port number 53862 BC interval Once every 30 seconds (initial value)

3-1-1-2. Setup Items

The items that can be set for the advertisement service are described below.

Setup items Description

Port Port number Interval Broadcast interval

VPL-PX35/PX40/FX51

Page 11

3-1-2. Remote Control

The remote control service is provided that can control the target equipment from remote location via network. The SDCP protocol that serves to acquire the basic information such as equipment name and serial numbers is installed in this projector.

3-1-2-1. Function

This responds to the control command and requests for acquiring the status and information supplied from clients.

Control request

Enables the input to be selected and picture control to be adjusted.

SIRCS request

Enables remote control by sending the SIRCS code.

Status request

Enables equipment status information such as power status, error information and power-on time to be acquired.

Information request

Enables equipment information such as equipment name, serial number and installation information to be acquired.

Protocol

Item Description

Protocol name SDCP (Simple Display Control Protocol) Transport TCP Port number 53484 TCP connection timeout 30 seconds

3-1-2-2. Setup Items

The items that can be set for the remote control service are described below.

Setup item Description

Port Port number Timeout TCP connection timeout time

VPL-PX35/PX40/FX51

Page 12

3-2. SDAP Protocol

This section describes the SDAP packet structure.

Header

(4)

Community

(4)

Product name

(12)

Serial No.

Fig.1 Packet structure

(4)

Power Status

(2)

Location

(24)

1) Header The header consists of ID (16 bit), version (8 bit) and category (8 bits).

110 234567098 012345 76 890123 54 678901

Version (8)“DA” (16) Category (8)

Fig. 2 Header

It is fixed to “DA”.

Version

This indicates the version number of protocol. It is fixed to 01h (version 1).

3-3. SDCP Protocol

This section describes the packet structure of version 2.

Header

(2)

Community

(4)

Command

(4)

Data (n)

Fig. 1 Packet structure

3-3-1. Format

3-3-1-1. Header

The header consists of Version (8 bits) and Category (8 bits).

(Bit position)

110 234567098 012345

Version (8) Category (8)

Fig. 2 Header structure

Version

This indicates the version number of protocol. It is fixed to 02h (version 2).

3-3-1-2. Community

When the community Data matches the community that is set in the display equipment, the request is executed. Community consists of four alphanumeric characters (case sensitive). All display equipment has the default value “SONY” when shipped from the factory.

110 234567098 012345 76 890123 54 678901

Community (32)

Community should be entered with four characters. Three characters or less are not accepted.

(Bit position)

VPL-PX35/PX40/FX51

Page 14

3-3-1-3. Command

This section describes the format of the request command and the response command.

110 234567098 012345 76 890123 54 678901

Item No (16) Data Length (8)Request/Response (8)

(1) Request This section describes the format of the request command that is issued from the host PC to the projector.

Community

This is the same alphanumeric characters as those of community that is set in the projector to which request is going to be sent.

Request

There are only two types of request. One is the GET request to acquire the projector information and status. The other is the SET request to modify the projector setup.

Request Contents

SET (00h) SET (01h) Used to acquire the installation information, equipment status and various setup values.

Used to control turning the power on/off and to control the input selector, and to change the various setups.

Item No.

This is the item number of the request target.

Data Length

This is the length of the Data accompanying the request. The maximum length is 128 bytes. If there is no Data, it is 0.

(Bit position)

Data

This is the Data accompanying the request.

(2) Response This section describes the format of the response command which is used to return a response to the host PC from the projector.

Community

The same alphanumeric characters as those of the request is entered.

Response

The response returns the result of executing the request from the host PC.

Response Contents

NG (00h) Indicates that the request is illegal or cannot be executed. OK (01h) Indicates that the request was executed correctly.

Item No.

The same value as those of the request is entered.

Data Length

This is the length of the Data accompanying the response. The maximum length is 128 bytes. If there is no Data, it is 0.

Data

This is the Data accompanying the response.

VPL-PX35/PX40/FX51

Page 15

3-3-1-4. SET Request

The SET request is used to set a new value in the specified item. Details of the request and the response are described below.

Request

00h Item No. n Set Data (n byte)

Item No.

Data

Length

Data

Response

OK (01h) Item No. 0

3-3-1-5. GET Request

The GET request is used to acquire the value of the specified item. Details of the request and the response are described below.

Request

01h Item No. 0

Item No.

Data

Length

Response

OK (01h) Item No. n Get Data (n byte)

3-3-1-6. ERROR Response

When an error occurs in the contents of a request or in the result of execution, NG is returned as the response.

NG (00h) Item No. 2 Error Code (16)

VPL-PX35/PX40/FX51

Page 16

3-3-2. Items

Category Contents SET GET

00**h Used to control and to change the various setups. OO 01**h Used to acquire the status. O 03**h Used to reset memory. O 17**h Sircs (15 bit category) O 19**h Sircs (20 bit category) O 80**h Used to acquire equipment information. O 90**h Used to acquire network setup information. O

3-3-2-1. Model Dependent Category

The supported contents of 00**h, 01**h, 03**h, 17**h and 19**h change depending on the model. Details are shown on Appendix.

3-3-2-2. Equipment Information Acquisition (80**h)

Used to acquire the equipment information.

Lower byte Contents SET GET

00h Category Code O 01h Model name O 02h Serial number O 03h Installation location OO

0x8000 Category code

1 byte

0x8001 Model name

Alphanumeric 12 characters If the number of characters is less than 12, the remaining digits are filled with 00h.

0x8002 Serial number

4 bytes

The serial number is in the range of 00000000 to 99999999.

0x8003 Installation location

Alphanumeric 24 characters If the number of characters is less than 24, the remaining digits are filled with 00h.

VPL-PX35/PX40/FX51

Page 17

3-3-2-3. Network Information Acquisition (90**h)

Used to acquire the network setup information.

Lower bytes Contents SET GET

00h MAC Address O 01h IP Address O 02h Subnet Mask O 03h Default Gateway O 04h DHCP O

0x9000 Mac Address

6 bytes

0x9001 IP Address

4 bytes

0x9002 Subnet Mask

4 bytes

0x9003 Default Mask

4 bytes

0x9004 DHCP

1 byte DHCP invalid DHCP valid

VPL-PX35/PX40/FX51

Page 18

3-3-3. Error Code

The error code list is shown below with a detailed description of each.

Category Error Error Code

Item Error (01**h) Invalid Item 01h

Invalid Item Request 02h Invalid Length 03h Invalid Data 04h Short Data 11h

Not Applicable Item 80h Community Error (02**h) Different Community 01h Request Error (10**h) Invalid Version 01h

Invalid Category 02h

Invalid Request 03h

Short Header 11h

Short Community 12h

Short Command 13h Network Error (20**h) Timeout 01h Comm Error (F0**h) Timeout 01h

Check Sum Error 10h

Framing Error 20h

Parity Error 30h

Over Run Error 40h

Other Comm Error 50h

Unknown Response F0h NVRAM Error (F1**h) Read Error 10h

Write Error 20h

VPL-PX35/PX40/FX51

Page 19

3-3-3-1. Item Error

This error occurs when the Item No. of a request is illegal or its Data is illegal. The conditions for occurrence of the respective errors are shown below.

Invalid Item

An unsupported Item No. is specified.

Example 1: The unsupported category 0xA** is specified. Example 2: The unsupported Item No. 0x8010 is specified.

Invalid Item Request

The Item No. is supported but an unsupported Request is issued.

Example: An attempt is made to set Data in the Model Name (0x8001).

Invalid Length

Data Length of the specified Item No. is too long.

Example: An attempt is made to set 25 byte Data in the installation location (0x8003).

Invalid Data

Data of the specified Item No. is outside the setting range.

Example: An attempt is made to set 101 in the Item when the setting range of the Item is 1 to 100.

Short Data

The length of Data is shorter than the value specified by the Data Length.

Example: The actual Data length is 9 bytes but Data Length is 10.

Not Applicable Item

An item that is not valid at present is specified.

Example: The item to switch the display is specified when the main power is off.

3-3-3-2. Community Error

This error occurs when community is different.

Example: “ABCD” is specified when “SONY” is set.

VPL-PX35/PX40/FX51

Page 20

3-3-3-3. Request Error

This error occurs when Header or Command is illegal. The conditions of occurrence of the respective errors are shown below.

Invalid Version

The version of the Header is other than 2.

When another version is supported, an error occurs in all versions other than the supported version.

Invalid Category

The category does not match.

Example: 0x0B is specified in the device of Category = 0x0A.

Invalid Request

An unsupported request is specified.

Example: Request = 0x02 is specified.

Short Header

The received Data is 1 byte.

Short Community

The received Data is in the range of 2 to 5 bytes.

Short Command

The received Data is in the range of 6 to 9 bytes.

3-3-3-4. Network Error

This is an error that occurs in TCP/IP. The conditions of occurrence of the respective errors are shown below.

Timeout

Communication was interrupted.

VPL-PX35/PX40/FX51

Page 21

3-3-3-5. Comm Error

This is an error in communication with the main control microprocessor of the display.

Timeout

Reception Data is not returned after Data is sent.

Check Sum Error

A check sum error occurred in the main control microprocessor of the display.

Framing Error

A framing error occurred.

Parity Error

A parity error occurred.

Over Run Error

An overrun error occurred.

Other Comm Error

Another error occurred.

Unknown Response

The Data cannot be processed was received.

3-3-3-6. NVRAM Error

Read Error

Reading from NVRAM was failed.

Write Error

Writing to NVRAM was failed.

VPL-PX35/PX40/FX51

Page 22

Appendix A. Setup Method For VPL-PX35 and PX40

Establishing the network setup such as IP address can be implemented from the PC browser, and the information such as installation location can be viewed on the PC browser.

A-1. Command

A-1-1. Setting

Enter the following command using the format shown below in a browser as URL, and then the simple response is returned.

Format

http://IP address/Item?Value

IP address The IP address that is assigned to the network block Item Name of the setup item Value Setting value

Response

The following HTML is returned that enables to confirm OK or NG simply.

<HTML> <TITLE> IP address </TITLE> <BODY> < Equipment name: Serial number><BR><BR> Result [Item = Value] </BODY> </HTML>

IP address The IP address that is assigned to the network block Equipment name Name of the equipment in which setup is implemented Serial number Serial number of the equipment in which setup is implemented Result Result (OK or NG) is displayed. Item Name of the setup item Value Setting value

VPL-PX35/PX40/FX51

Page 23

A-1-2. Display

Enter the following command using the format shown below in a browser as URL, and then value of the setting item is displayed.

Format

http://IP address/Item

IP address The IP address that is assigned to the network block Item Name of the setup item

Response

The following HTML is returned.

<HTML> <TITLE> IP address </TITLE> <BODY> < Equipment name: Serial number><BR><BR> Result [Item = Value] </BODY> </HTML>

IP address The IP address that is assigned to the network block Equipment name Name of the equipment that has acquired the setup value Serial number Serial number of the equipment that has acquired the setup value Result Result (OK or NG) is displayed. Item Name of the setup item Value Setting value

VPL-PX35/PX40/FX51

Page 24

A-2. Setting Command

Each setting item is described below.

Equipment information

Item Description Default

location Sets location of the equipment installation. (Maximum 24 alphanumeric characters) _ Community Sets the equipment community. (Maximum 4 alphanumeric characters) SONY

Location and community do not support Japanese character.

Network setup

Item Description Default

dhcp Specifies method of setting IP address. No ipaddr IP address 192.168.0.1 subnet Subnet mask 255.255.0.0 gateway Default gateway 0.0.0.0 restart Restarts the network block to make the network setup effective.

m . When the network setup is changed, execute restart to make the setup effective. . For the setup of dhcp, set 1 to make DHCP effective and set 0 to make DHCP ineffective.

Service setup

Item Description Default

ad_port Port number of the Advertisement service 53862 ad_interval Broadcast interval of the Advertisement service (in units of second) 30 (seconds) ad_ip IP address of the Advertisement service 0.0.0.0 rc_port Port number of the Remote Control service 53484 rc_timeout TCP connection timeout time of the Remote Control service (in units of second) 30 (seconds)

m . When network setup is changed, executing restart is required to make the network setup effective. . When ad_Interval value is set to 0, the advertisement service is stopped. . The ad_Interval can be set to 0 or a value in the range of 10 to 65535. . The rc_timeout can be set to a value in the range of 0 to 65535.

VPL-PX35/PX40/FX51

Page 25

Appendix B

(VPL-FX51)

Item Number Data

Item Upper byte Lower byte Data Upper byte Lower byte

VIDEO 00h 00h Set/Get

S VIDEO 00h 01h

INPUT 00h 01h INPUT A 00h 02h

INPUT B 00h 03h INPUT C 00h 04h

CONTRAST 00h 10h Setting value (0 to 100) 00h 00h to 64h

BRIGHTNESS 00h 11h Setting value (0 to 100) 00h 00h to 64h

COLOR 00h 12h Setting value (0 to 100) 00h 00h to 64h

HUE 00h 13h Setting value (0 to 100) 00h 00h to 64h

SHARPNESS 00h 14h Setting value (0 to 100) 00h 00h to 64h

RGB ENHANCER 00h 15h Setting value (0 to 100) 00h 00h to 64h

COL TEMP 00h 17h

DDE 00h 18h PROGRESSIVE 00h 01h

ASPECT 00h 20h

SCAN CONV 00h 21h

PICTURE MUTING 00h 30h

INPUT A 00h 32h COMPONENT 00h 01h

LAMP MODE 00h 40h

GAIN RED 00h 80h Setting value (0 to 255) 00h 00h to FFh

GAIN GREEN 00h 81h Setting value (0 to 255) 00h 00h to FFh

GAIN BLUE 00h 82h Setting value (0 to 255) 00h 00h to FFh

BIAS RED 00h 83h Setting value (0 to 255) 00h 00h to FFh

BIAS GREEN 00h 84h Setting value (0 to 255) 00h 00h to FFh

BIAS BLUE 00h 85h Setting value (0 to 255) 00h 00h to FFh

STATUS ERROR 01h 01h COVER ERROR 00h 04h

LOW 00h 00h

HIGH 00h 01h

OFF 00h 00h

FILM 00h 02h

16 : 9 00h 00h

4 : 3 00h 01h OFF 00h 00h

ON 00h 01h

OFF 00h 00h

ON 00h 01h

COMPUTER 00h 00h

VIDEO GBR 00h 02h

HIGH 00h 00h

STANDARD 00h 01h

NO ERROR 00h 00h Get only

LAMP ERROR 00h 01h

FAN ERROR 00h 02h

TEMP ERROR 00h 08h

D5V ERROR 00h 10h

POWER ERROR 00h 20h

WARNING ERROR 00h 40h

Remarks

VPL-PX35/PX40/FX51

Page 26

(VPL-FX51)

Item Number Data

Item Upper byte Lower byte Data Upper byte Lower byte

STANBY 00h 00h Get only

START UP 00h 01h

STARTUP LAMP 00h 02h

POWER ON 00h 03h

STATUS POWER 01h 02h COOLING1 00h 04h

COOLING2 00h 05h SAVING COOLING1 00h 06h SAVING COOLING2 00h 07h

SAVING STABY 00h 08h

CONTROL MODE SEL 01h 05h

LAMP TIMER 01h 13h USE TIME 0000h-ffffh*1

ROM VERSION 01h 1Dh MAIN ROM VERSION *2

SC ROM VERSION 01h 1Eh SC ROM VERSION *2

Channel Memory Reset 01h Set only

Status Memory Reset 02h

Set Memory Reset

W/B All Save 04h

W/B Low Save 05h

W/B High Save 06h

Sircs (15bit category) 17h Refer to table 4 _ 00h 00h Set only*3 Sircs (20bit category) 19h Refer to table 5 _ 00h 00h

*1 Example) In case the lamp timer indicates 1000H, return values are [03h] upper byte and [E8h] lower byte. *2 Example) In case the software version is 1.03, return values are [01h] upper byte and [03h] lower byte. *3 It is corresponded to single command only.

03h

USER 00h 00h

SERVICE 00h 01h

00h 00h

Remarks

(VPL-FX51)

Item Number Data Item Data Upper byte Lower byte ACK _ 00h 00h

Undefined Command 01h

Size Error 04h Select Error 01h 05h Range Over 06h

NAK Not Applicable 0Ah

Check Sum Error 10h

Framing Error 20h

Parity Error F0h 30h

Over Rub Error 40h

Other Comm Error 50h

Approximate Return Waiting Times The await-return time is approx. 50 msec.

This is the case, unless the communications are interfered anyway.

VPL-PX35/PX40/FX51

Page 27

(VPL-PX35, PX40)

Item Number Data

Item Upper byte Lower byte Data Upper byte Lower byte

Input 00h 01h Video 00h 00h Set/Get

S-Video 00h 01h

Input-A 00h 02h Input-B 00h 03h Input-C 00h 04h Input-D 00h 05h

Picture Mode 00h 02h Dynamic 00h 00h

Standard 00h 01h

Contrast 00h 10h Setting value (0-100) 00h 00h to 64h

Brightness 00h 11h Setting value (0-100) 00h 00h to 64h

Color 00h 12h Setting value (0-100) 00h 00h to 64h

Hue 00h 13h Setting value (0-100) 00h 00h to 64h

Sharpness 00h 14h Setting value (0-100) 00h 00h to 64h

RGB Enhancer 00h 15h Setting value (0-100) 00h 00h to 64h

Volume 00h 16h Setting value (0-100) 00h 00h to 64h

ColTemp 00h 17h High 00h 00h

Low 00h 01h

DDE 00h 18h Off 00h 00h

Progressive 00h 01h

Film 00h 02h

Wide Mode 00h 20h Off 00h 00h

On 00h 01h

Scan Conv 00h 21h Off 00h 00h

On 00h 01h

Picture Muting 00h 30h Off 00h 00h

On 00h 01h

Audio Muting 00h 31h Off 00h 00h

On 00h 01h

Input-D Signal Sel 00h 33h Computer 00h 00h

Component 00h 01h

Video GBR 00h 02h

Lamp Mode 00h 40h High 00h 00h

Standard 00h 01h

GAIN RED 00h 80h Setting value (0-255) 00h 00h to FFh

GAIN GREEN 00h 81h Setting value (0-255) 00h 00h to FFh

GAIN BLUE 00h 82h Setting value (0-255) 00h 00h to FFh

BIAS RED 00h 83h Setting value (0-255) 00h 00h to FFh

BIAS GREEN 00h 84h Setting value (0-255) 00h 00h to FFh

BIAS BLUE 00h 85h Setting value (0-255) 00h 00h to FFh

Remarks

VPL-PX35/PX40/FX51

Page 28

(VPL-PX35, PX40)

Item Number Data

Item Upper byte Lower byte Data Upper byte Lower byte

STATUS ERROR 01h 01h NO ERROR 00h 00h Get only

LAMP ERROR 00h 01h

FAN ERROR 00h 02h

COVER ERROR 00h 04h

TEMP ERROR 00h 08h

D5V ERROR 00h 10h

POWER ERROR 00h 20h

WARNING ERROR 00h 40h

STATUS POWER 01h 02h STANBY 00h 00h

START UP 00h 01h

STARTUP LAMP 00h 02h

POWER ON 00h 03h

COOLING1 00h 04h

COOLING2 00h 05h SAVING COOLING1 00h 06h SAVING COOLING2 00h 07h

SAVING STABY 00h 08h

CONTROL MODE SEL 01h 05h USER MODE 00h 00h

SERVICE MODE 00h 01h

LAMP TIMER 01h 13h LAMP USE TIME 0000h-ffffh*1

ROM VERSION 01h 1Dh MAIN ROM VERSION *2

SC ROM VERSION 01h 1Eh SC ROM VERSION *2

STATUS SECURITY*3 01h 1Fh Disable 00h 00h

Enable 00h 01h

Channel Memory Reset 03h 01h _ 00h 00h Set only

Status Memory Reset 02h

Set Memory Reset 03h

W/B All Save 04h

W/B Low Save 05h

W/B High Save 06h Sircs (15 bit category) 17h Refer to table 6 _ 00h 00h Set only*4 Sircs (20 bit category) 19h Refer to table 7 _ 00h 00h

(VPL-PX35, PX40)

Item Number Data

Item Data Upper byte Lower byte ACK _ 00h 00h NAK Undefined Command 01h 01h

Size Error 04h

Select Error 05h

Range Over 06h

Not Applicable 0Ah

Check Sum Error F0h 10h

Framing Error 20h

Parity Error 30h

Over Rub Error 40h

Other Comm Error 50h

*1 Example) In case the lamp timer indicates

1000H, return values are [03h] upper byte and [E8h] lower byte.

*2 Example) In case the software version is 1.03,

return values are [01h] upper byte and [03h] lower byte.

*3 While the set is security locked, after power

switch is turned on, you can check that pass sword input screen is indicated or not. During pass word input screen indicating, return values are [00h] upper byte and [01h] lower byte.

*4 It is corresponded to single command only.

Approximate Return Waiting Times The await-return time is approx. 50 msec.

This is the case, unless the communications are interfered anyway.

Remarks

VPL-PX35/PX40/FX51

Page 29

POWER

ON/OF

HUE

PURPLISH

HUE

GREENISH

SHARPNESS

SHARP

SHARPNESS

SOFT

ADJ R ADJ G

ADJ B

W/B

GAIN

W/B

BIAS


MUTING

STATUS

OFF

CURSOR

→

CURSOR

←

CURSOR

↑

LENS

SHIFT ↑

LENS

SHIFT ↓

CURSOR

↓

FOCUS F FOCUS N ZOOM L ZOOM S

CONTRAST

HIGH

CONTRAST

LOW

COLOR

HIGH

COLOR

LOW

BRITNESS

BRIGHT

BRITNESS

DARK

MENU VIDEO INPUT A INPUT B

POWER

OFF

RGB SIZE RGB SHIFT

INPUT

SELECT

BLANKING ENTER MEMORY S VIDEO

INPUT C

RESET PATTERN

x1 x2 x3 x4 x5 x6 x7 x8 x9 xA xB xC xD xE xF

VPL-PX35/PX40/FX51

List of SIRCS CODE

(1) 15BIT Category (VPL-FX51 only)

Page 30

x1 x2 x3 x4 x5 x6 x7 x8 x9 xA xB xC xD xE xF

APA

DOT

PHASE

LENS

ZOOM

LENS

SHIFT

LENS

FOCUS

FREEZE

LENS

TOGGLE

DIGITAL

ZOOM +

KEYSTONE

DIGITAL

ZOOM –

(2) 20BIT Category (VPL-FX51 only)

VPL-PX35/PX40/FX51

Page 31

POWER

ON/OF

AUDIO

MUTING

VOLUME-

DOWN

VOLUME+

HUE

PURPLISH

HUE

GREENISH

SHARPNESS

SHARP

ADJ GADJ R ADJ B

W/B

GAIN

W/B

BIAS

SHARPNESS

SOFT


MUTING

STATUS

OFF

CURSOR

→

CURSOR

←

CURSOR

↑

INPUT D

CURSOR

↓

CONTRAST

HIGH

CONTRAST

LOW

COLOR

HIGH

COLOR

LOW

BRITNESS

BRIGHT

BRITNESS

DARK

MENU VIDEO INPUT A INPUT B

POWER

OFF

RGB SIZE RGB SHIFT

INPUT

SELECT

ENTER MEMORY S VIDEO

INPUT C

RESET

x1 x2 x3 x4 x5 x6 x7 x8 x9 xA xB xC xD xE xF

VPL-PX35/PX40/FX51

(3) 15BIT Category (VPL-PX35, PX40)

Page 32

x1 x2 x3 x4 x5 x6 x7 x8 x9 xA xB xC xD xE xF

APA

DOT

PHASE

FREEZE

LENS

CONT

TOGGLE

DIGITAL

ZOOM +

KEYSTONE

DDE

TOGGLE

DIGITAL

ZOOM –

(4) 20BIT Category (VPL-PX35, PX40)

VPL-PX35/PX40/FX51

Page 33

The material contained in this manual consists of information that is the property of Sony Corporation. Sony Corporation expressly prohibits the duplication of any portion of this manual or the use thereof for any purpose other than the operation or maintenance of the equipment described in this manual without the express written permission of Sony Corporation.

Le matériel contenu dans ce manuel consiste en informations qui sont la propriété de Sony Corporation. Sony Corporation interdit formellement la copie de quelque partie que ce soit de ce manuel ou son emploi pour tout autre but que des opérations ou entretiens de l’équipement à moins d’une permission écrite de Sony Corporation.

Das in dieser Anleitung enthaltene Material besteht aus Informationen, die Eigentum der Sony Corporation sind. Die Sony Corporation untersagt ausdrücklich die Vervielfältigung jeglicher Teile dieser Anleitung oder den Gebrauch derselben für irgendeinen anderen Zweck als die Bedienung oder Wartung der in dieser Anleitung beschriebenen Ausrüstung ohne ausdrückliche schriftliche Erlaubnis der Sony Corporation.

VPL-PX35/PX40/FX51

Page 34

VPL-PX35 (SY) VPL-PX40 (SY) VPL-FX51 (SY) E 9-870-346-64

Printed in Japan

Sony Corporation 2003. 4 16

Sony VPL-PX35, VPL-FX51, VPL-PX40 User Manual 4

Table of Contents

1. Introduction

2. RS-232C

2-1. Communication Specifications

2-2. Command Block Format

2-3. Block Format

2-4. Connection

2-5. Communication Procedure

2-5-1. Outline of Communication

2-6. Communication Rules

2-7. Approximate Return Waiting Times

3. NETWORK

3-1. Introduction

3-1-1. Advertisement

3-1-1-1. Function

3-1-1-2. Setup Items

3-1-2. Remote Control

3-1-2-1. Function

3-1-2-2. Setup Items

3-2. SDAP Protocol

3-3. SDCP Protocol

3-3-1. Format

3-3-1-1. Header

3-3-1-2. Community

3-3-1-3. Command

3-3-1-4. SET Request

3-3-1-5. GET Request

3-3-1-6. ERROR Response

3-3-2. Items

3-3-2-1. Model Dependent Category

3-3-2-2. Equipment Information Acquisition (80**h)

3-3-2-3. Network Information Acquisition (90**h)

3-3-3. Error Code

3-3-3-1. Item Error

3-3-3-2. Community Error

3-3-3-3. Request Error

3-3-3-4. Network Error

3-3-3-5. Comm Error

3-3-3-6. NVRAM Error

Appendix A. Setup Method For VPL-PX35 and PX40

A-1. Command

A-1-1. Setting

A-1-2. Display

A-2. Setting Command

Appendix B
