Important Information
Before you use your device, please read the
Important
Information
provided in your device regarding warranty,
safety and handling information.
Protecting your device from water
and dust
Your device has IP (Ingress Protection) ratings of IP65 and
IP68. These ratings mean that your device is dust tight and
is protected against low pressure water stream as well as
against the effects of submersion for 30 minutes in fresh
(non-saline) water up to 1.5 metres deep.
Always firmly attach all covers to ensure the water and dust
resistance of the device. If liquid is detected inside the
device, for example, underneath one of the covers, your
warranty will be void.
Before using your device in water and in dusty conditions,
refer to the relevant section of the User guide for your
device for more detailed information. An online User guide
as well as a downloadable version is available at
www.sonymobile.com/support
.
After using your device in water, wait for the USB port to
dry before you insert a cable into the port.
Overview
1 2 54
6
7
8
3
15
13
16
14
9 1110 12
1. Headset jack
2. Memory card slot cover
3. Light sensor
4. Front camera lens
5. Charging/Notification light
6. Charger/USB port
7. Speaker
8. Speaker
9. GPS antenna
10. Microphone
11. Wi-Fi sub antenna
12. Wi-Fi main/BT antenna
13. Main camera
14. NFC™ detection area
15. Power key
16. Volume/Zoom key
Assembly
To insert a memory card
1
2
3
micro SD
OFF
1
Detach the memory card slot cover.
2
Place the memory card in the memory card slot, then push
the memory card all the way into the slot until you hear a
clicking sound.
3
Re-attach the memory card slot cover.
Basics
Turning on the device
Make sure that the battery is charged for at least 30 minutes
before you turn on the device for the first time.
To turn on the device
1
Press and hold down the power key until the device
vibrates.
2
Wait a while for the device to start.
Waking up the screen
To activate the screen
•
Briefly press the power key
.
Setting up your device
Setup guide
The first time you start your device, a setup guide opens to
help you configure basic settings, sign in to some accounts
(for example, your Google™ account), and personalise your
device. You can also manually access the setup guide at a
later stage.
To access the setup guide manually
1
From the Home screen, tap
.
2
Tap > Setup guide.
Accessing settings
View and change settings for your device from the Settings
menu. The Settings menu is accessible from both the
Application screen and the Quick settings panel.
To access your device settings
1
From your Home screen, tap
.
2
Find and tap .
Transferring your contacts
Xperia™ Transfer is an application that helps you to collect
contacts from your old device and transfer them to your new
device. Xperia™ Transfer, which you can access from within
the PC Companion program, supports mobile devices that
run on several operating systems, including iOS, Android™,
Windows® and BlackBerry™.
To use Xperia™ Transfer, you need:
•
An Internet-connected computer.
•
A USB cable for your old device.
•
A USB cable for your new Android™ device.
•
Your old device.
•
Your new Android™ device.
To transfer contacts to your new device
1
Search and download PC Companion (on a PC) from
www.sonymobile.com
if the application is not already
installed.
2
After successful installation, open the PC Companion
application, then click
Xperia™ Transfer
and follow the
relevant instructions to transfer your contacts.
Finding your way
Using the keys
Back navigation key
•
Go back to the previous screen within an application
or close the application.
Home navigation key
•
Exit an application and go back to the Home screen.
Task navigation key
•
Open the recently used applications window and the
small apps bar.
Application screen
•
Open the Application screen.
Basic applications and settings
Go to Google Play™ to download free and paid
applications for your device.
Optimise the device settings to suit your own
requirements.
Status and notifications
To open or close the Notification panel
1
To open the Notification panel, drag the status bar
downwards.
2
To close the Notification panel, drag the panel upwards.
Support on the web
Visit
www.sonymobile.com/support
to access a range of
support options for your device, including downloads,
troubleshooting tips and a User guide.
Legal information
Sony SGP712
This Startup guide is published by Sony Mobile
Communications Inc. or its local affiliated company, without
any warranty. Improvements and changes to this Startup
guide necessitated by typographical errors, inaccuracies of
current information, or improvements to programs and/or
equipment, may be made by Sony Mobile Communications
Inc. at any time and without notice. Such changes will,
however, be incorporated into new editions of this Startup
guide. All illustrations are for illustration only and may not
accurately depict the actual device.
See regulatory information such as the CE mark in the
relevant label tray in the device.
All product and company names mentioned herein are the
trademarks or registered trademarks of their respective
owners. Any rights not expressly granted herein are reserved.
Visit
www.sonymobile.com/us/legal/
for more information.
Product compliance: This product has been manufactured by
or on behalf of Sony Mobile Communications Inc., 1-8-15
Konan, Minato-ku, Tokyo 108-0075, Japan. Inquiries related
to product compliance based on national legislation shall be
addressed to Sony Mobile Quality Office, Sony Mobile
Communications Inc., 1-8-15 Konan, Minato-ku, Tokyo
108-0075, Japan. For any service or guarantee matters,
please refer to the contact details provided in the separate
service or guarantee documents.
© 2015 Sony Mobile Communications Inc. All rights reserved.
To view the CE mark and the FCC ID
1
Detach the memory card slot cover.
2
Place your fingernail just under the tip on the label tray,
then drag out the tray. The information is displayed on the
tray.
To view the regulatory compliance mark
1
From your Home screen, tap .
2
Find and tap Settings > About tablet > Legal information >
Certificates.
Startup guide
Xperia™ Tablet Xxx
SGP712
Sony Mobile Communications Inc.
1-8-15 Konan, Minato-ku, Tokyo 108-0075, Japan
