Sony STR-DA4400ES User Manual

Printed in Malaysia

©2008 Sony Corporation

STR-DA4400ES

3-875-807-13(1)

Operating Instructions GB

Mode d’emploi

FR

Multi Channel
AV Receiver

WARNING

To reduce the risk of fire or electric
shock, do not expose this apparatus to
rain or moisture.

Owner’s Record

The model and serial numbers are located on the rear
of the unit. Record these numbers in the space
provided below. Refer to them whenever you call
upon your Sony dealer regarding this product.
Model No.

Serial No.

Do not install the appliance in a confined space, such
as a bookcase or built-in cabinet.

To reduce the risk of fire or electric shock, do not
expose this apparatus to dripping or splashing, and
do not place objects filled with liquids, such as
vases, on the apparatus.

As the main plug is used to disconnect the unit from
the mains, connect the unit to an easily accessible
AC outlet. Should you notice an abnormality in the
unit, disconnect the main plug from the AC outlet
immediately.

Do not expose batteries or apparatus with battery­installed to excessive heat such as sunshine, fire or
the like.

The unit is not disconnected from the mains as long
as it is connected to the AC outlet, even if the unit
itself has been turned off.

For customers in the United
States

The following FCC statement
applies only to the version of
this model manufactured for
sale in the U.S.A. Other
versions may not comply with
FCC technical regulations.

NOTE:

This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However,
there is no guarantee that interference will not occur
in a particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to try
to correct the interference by one or more of the
following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment

and receiver.

– Connect the equipment into an outlet on a circuit

different from that to which the receiver is
connected.

– Consult the dealer or an experienced radio/TV

technician for help.

This symbol is intended to alert the
user to the presence of uninsulated
“dangerous voltage” within the
product’s enclosure that may be of
sufficient magnitude to constitute a
risk of electric shock to persons.
This symbol is intended to alert the
user to the presence of important
operating and maintenance
(servicing) instructions in the
literature accompanying the
appliance.

GB

2

CAUTION

You are cautioned that any changes or modifications
not expressly approved in this manual could void
your authority to operate this equipment.

Note to CATV system installer:

This reminder is provided to call CATV system
installer’s attention to Article 820-40 of the NEC
that provides guidelines fo r proper grounding and, in
particular, specifies that the cable ground shall be
connected to the grounding system of the building,
as close to the point of cable entry as practical.

About This Manual

• The instructions in this manual are for model
STR-DA4400ES. Check your model number by
looking at the lower right corner of the front panel.

• The instructions in this manual describe the
controls on the supplied remote. You can also use
the controls on the receiver if they have the same
or similar names as those on the remote.

On Copyrights

• “Neural-THX” and “neural THX” introduced in
the Operating Instructions and displayed in the
display window and on the GUI menu screen mean
Neural-THX Surround.

This receiver incorporates Dolby* Digital and Pro
Logic Surround and the DTS** Digital Surround
System.
* Manufactured under license from Dolby

Laboratories.
Dolby, Pro Logic, Surround EX, and the double­D symbol are trademarks of Dolby Laboratories.

** Manufactured under license under U.S. Patent

#’s: 5,451,942; 5,956,674; 5,974,380 ; 5,978,762;
6,226,616; 6,487,535 & other U.S. and
worldwide patents issued & pending. DTS is a
registered trademark and the DTS logos,
Symbol, DTS-HD and DTS-HD Master Audio
are trademarks of DTS, Inc. © 1996-2007 DTS,
Inc. All Rights Reserved.

This receiver incorporates High-Definition
Multimedia Interface (HDMI™) technology.

This product using Neural-THX
manufactured under license from Neural Audio
Corporation and TH X Ltd. Sony Corporation hereby
grants the user a non-exclusive, non-transferable,
limited right of use to this product under USA and
foreign patent, patent pending and other technology
or trademarks owned by Neural Audio Corporation
and THX Ltd. “Neural Surround”, “Neural Audio”,
“Neural” and “NRL” are trademarks and logos
owned by Neural Audio Corporation, THX is a
trademark of THX Ltd., which may be registered in
some jurisdictions. All rights reserved.

The font type (Shin Go R) installed in this receiver
is provided by MORISAWA & COMPANY LTD.
These names are the trademarks of MORISAWA &
COMPANY LTD., and the copyright of the font also
belongs to MORISAWA & COMPANY LTD.

iPod is a trademark of Apple Inc., registered in the
U.S. and other countries.
All other trademarks and registered trademarks are
of their respective holders. In this manual, ™ and ®
marks are not specified.

The Bluetooth word mark and logos are owned by
the Bluetooth SIG, Inc. and any use of such marks
by Sony Corporation is under license.
Other trademarks and trade names are those of their
respective owners.

“M-crew Server” is a trademark of Sony
Corporation.

“BRAVIA” is a trademark of Sony Corporation.

®

Surround is

GB

HDMI, the HDMI logo and High-Definition
Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing LLC.

®

XM Ready
Satellite Radio Inc. All rights reserved.

©2008 SIRIUS Satellite Radio Inc. “SIRIUS” and
the SIRIUS dog logo are registered trademarks of
SIRIUS Satellite Radio Inc.

is a registered trademark of XM

GB

3

Table of Contents

Getting Started

1: Installing speakers ..................................19

2: Connecting speakers ...............................21

3: Connecting the monitor ..........................23

4a: Connecting the audio components ........25

4b: Connecting the video components .......30

5: Connecting the antennas (aerials) ...........39

6: Preparing the receiver and the remote ....40

7: Displaying the GUI menu on the TV

screen .....................................................41

8: Setting the speakers ................................42

9: Calibrating the appropriate speaker settings

automatically (Auto Calibration) ...........44

Guide to on-screen display operation .........51

Playback

Enjoying sound/images from the component

connected to the receiver .......................53

Enjoying sound/images from the components

connected to the DIGITAL MEDIA

PORT .....................................................55

Operating the TDM-iP1/iP50/TDM-NC1

using the GUI menu of the receiver .......56

Tuning

Listening to FM/AM radio .........................60

Presetting FM/AM radio stations ...............62

Listening to satellite radio ..........................63

Connecting a satellite radio tuner ...............65

Preparing to listen to a satellite radio .........65

Selecting a channel of the satellite radio ....67

Presetting satellite radio channels ..............68

Restricting access to specific channels

(Parental Lock) (SIRIUS only) ..............69

Enjoying Surround Sound

Playing back with 2-channel sound ........... 73

Playing back with multi-channel

surround ................................................ 74

Enjoying a surround effect for music .........77

Enjoying a surround effect for movies ....... 79

Using Multi-zone Features

What you can do with the Multi-zone

function ................................................. 83

Making a multi-zone connection ............... 84

Setting the speakers in zone 2 .................... 86

Switching the zone setting of the remote ... 87
Operating the receiver from another zone

(ZONE 2/ZONE 3 operations) .............. 87

Using Other Features

Using “BRAVIA” Sync features ................ 89

Switching between digital and analog

audio ...................................................... 92

Enjoying the sound/images from other inputs

(Input Assign) .......................................93

Using the sleep timer ................................. 96

Enjoying the surround effect at low volume

levels ..................................................... 96

Recording using the receiver ...................... 97

Switching the command mode of the receiver

and the remote ....................................... 99

Using a bi-amplifier connection ............... 100

GB

4

Adjusting Settings

Using the setting menu ............................. 102

Auto Calibration ....................................... 103

Speaker settings ........................................105

Surround settings ...................................... 109

EQ settings ...............................................110

Multi Zone settings .................................. 111

Audio settings .......................................... 112

Video settings ........................................... 113

HDMI settings ..........................................115

System settings .........................................116

Operating without connecting to a TV .....116

Using the Remote

Operating each component using the

remote .................................................122

Programming the remote ..........................124

Performing several commands in sequence

automatically (Macro Play) .................127

Setting remote commander codes that are not

stored in the remote ............................. 129

Clearing all the contents of the remote’s

memory ...............................................131

Additional Information

Glossary ................................................... 132

Precautions ...............................................135

Troubleshooting ....................................... 136

Specifications ........................................... 141

Index .........................................................143

GB

5

Description and location of parts

Front panel

To remove the cover

Press PUSH.
When you remove the cover, keep it out
of reach from children.

Status of the POWER button

Off
The receiver is turned off (initial
setting).
Press POWER to turn the receiver on.
You cannot turn the receiver on using
the remote.

On/Standby

?/1 on the remote to turn the

Press
receiver on or set it to the standby mode.
When you press POWER on the
receiver, the receiver will be turned off.

GB

6

Name Function

A POWER Press to turn the

receiver on or off.

B AUTO CAL MIC

jack

Connects to the
supplied optimizer
microphone for the
Digital Cinema Auto
Calibration function
(page 45).

C TONE MODE Adjusts FRONT/

TONE

CENTER/
SURROUND/
SURROUND BACK
BASS and TREBLE.
Press TONE MODE
repeatedly to select
BASS or TREBLE,
then turn TONE to
adjust the level.

D MEMORY/

ENTER
TUNING MODE

Press to operate a tuner
(FM/AM) and satellite
radio (XM/SIRIUS).

TUNING

E Remote sensor Receives signals from

remote commander.

F DIMMER Press repeatedly to

adjust brightness of the
display.

G DISPLAY Press repeatedly to

select information
displayed on the
display.

H INPUT MODE Press to select the input

mode when the same
components are
connected to both
digital and analog jacks
(page 92).

I Display

window

The current status of
the selected component
or a list of selectable
items appears here
(page 9).

Name Function

J 2CH/A.DIRECT Press to select sound

A.F.D.
MOVIE

field (page 73, 74, 77,

79).

MUSIC

K ZONE/

POWER,
SELECT

Press SELECT
repeatedly to select
zone 2, zone 3 or main
zone. Each time you
press POWER, the
output signals for the
selected zone will be
turned on or off
(page 83).

L HDMI IN Press to select the input

signal from the
component connected
to the HDMI IN jacks
(page 31).

M MULTI IN Press to select the

component connected
to the MULTI
CHANNEL INPUT
jack (page 28).

N PHONES jack Connects to

headphones.

O SPEAKERS

(OFF/A/B/A+B)

Switch to OFF, A, B,
A+B of the front
speakers (page 44).

P VIDEO 2 IN/

PORTABLE AV
IN jacks

Connect to a portable
audio/video c omponent
such as a camcorder or
video game.

Q MULTI

CHANNEL
DECODING

Lights up when multi­channel audio signals
are decoded.

lamp

continued

GB

7

Name Function

R INPUT

SELECTOR

Turn to select the input
source to play back.
To select the input
source for zone 2 or
zone 3, press ZONE/
SELECT (
zone 2 or zone 3 first
(“ZONE 2 INPUT” or
“ZONE 3 INPUT”
appears on the display),
then turn INPUT
SELECTOR to select
the input source.

S MASTER

VOLUME

Turn to adjust the
volume level of all
speakers at the same
time.

qa) to select

GB

8

Indicators on the display

Name Function

A SW Lights up when subwoofer

is connected and the audio
signal is output from the
SUBWOOFER jack. While
this indicator lights up, the
receiver creates a
subwoofer signal based on
the L.F.E. signal in the disc
being played back or the
low frequency components
of the front channels.

continued

GB

9

Name Function

B Playback

channel
indicators

The letters (L, C, R, etc.)
indicate the channels being
played back. The boxes
around the letters vary to
show how the receiver
downmixes the source
sound (based on the speaker

settings).
L Front Left
RFront Right
C Center (monaural)
SL Surround Left
SR Surround Right
S Surround (monaural or the

surround components

obtained by Pro Logic

processing)
SBL Surround Back Left
SBR Surround Back Right
SB Surround Back (the

surround back components

obtained by 6.1 channel

decoding)

Example:

Recording format (Front/

Surround): 3/2.1

Output channel: Surround

speakers are set to “NO.”

Sound Field: A.F.D. AUTO

LSW

CR

SL

SR

Name Function

C Input

indicators

Light up to indicate the
current input.

INPUT Lights up constantly with

either following the
corresponding indicators
that indicate the current
input status.

HDMI The receiver recognizes a

component connected via
an HDMI IN jacks.

DMPORT The DIGITAL MEDIA

PORT adapter is connected
and “DMPORT” is
selected.

MULTI IN The multi-channel input is

selected.

AUTO Lights up with the

corresponding indicators
that indicate the current
input when INPUT MODE
is set to “Auto.”

COAX Digital signal is input

through the COAXIAL
jack.

OPT Digital signal is input

through the OPTICAL jack.

ANALOG No digital signal is being

input. When INPUT
MODE is set to “Analog,”
or when the “2ch Analog
Direct” is being selected, it
also lights up.

D EQ Lights up when the

equalizer is activated.

E D.C.A.C. Lights up when auto

calibration is activated.

F ZONE 2/

ZONE 3

Lights up while operation in
zone 2/zone 3 is being
enabled.

G SLEEP Lights up when the sleep

timer is activated.

10

GB

Name Function

H L.F.E. Lights up when the disc

being played back contains
an L.F.E. (Low Frequency
Effects) channel and the
L.F.E. channel signal is
actually being reproduced,
the bars underneath the
letters light up to indicate
the level. Since the L.F.E.
signal is not recorded in all
parts of the input signal the
bar indication will fluctuate
(and may turn off) during
playback.

I DSD Lights up when the receiver

is receiving DSD (Direct
Stream Digital) signals
(page 31).

J Tuning

indicators

Lights up when the receiver
tunes in radio stations, or

satellite radio stations.
STEREO Stereo broadcast
MONO Monaural broadcast
XM The XM Mini Tuner and

Home Dock are connected

and “XM” is selected.
SIRIUS The SiriusConnect Home

tuner is connected and

“SIRIUS” is selected.
CAT The category mode is

selected during the satellite

radio operation.
PRESET The tuning mode is set to

the preset mode.
MEMORY A memory function, such as

Name Input, etc., is

activated.

K BI-AMP Lights up when surround

back speakers selection is

set to “BI-AMP.”

Name Function

L D.RANGE Lights up when dynamic

range compression is
activated.

M VOLUME Displays the current

volume.

N Dolby

Digital
Surround
indicators

Lights up one of the
respective indicators when
the receiver is decoding the
corresponding Dolby
Digital format signals.

;D Dolby Digital
;D+ Dolby Digital Plus
;D EX Dolby Digital Surround EX

Note

When playing a Dolby Digital
format disc, be sure that you
have made digital connections
and that INPUT MODE is not
set to “Analog.”

O DTS-HD

indicators

Light up when the receiver
is decoding DTS-HD.

DTS-HD Lights up constantly with

the one of the following

indicators.
MSTR DTS-HD Master Audio
LBR DTS-HD Low Bit Rate

Audio
HI RES DTS-HD High Resolution

Audio

P ;TrueHD Lights up when the receiver

is decoding Dolby TrueHD.

Q L-PCM Lights up when Linear

PCM (Pulse Code

Modulation) signals are

input.

continued

11

GB

Name Function

R Dolby

Pro Logic
indicators

Lights up one of the
respective indictors when
the receiver applies Dolby
Pro Logic processing to 2
channel signals in order to
output the center and
surround channel signals.

;PL Dolby Pro Logic
;PLII Dolby Pro Logic II
;PLIIx Dolby Pro Logic IIx

Note

This indicator does not light
when either the center speaker
and surround speaker is not
connected.

S DTS(-ES)

indicators

Light up when DTS or
DTS-ES signals are input.

DTS Lights up when the receiver

is decoding DTS signals.
Either 96/24 or NEO:6 also
lights up depending on the
input signal format or
decoding format.

96/24 DTS 96/24 (96 kHz/24 bit)

decoding
NEO:6 DTS Neo:6 Cinema/Music
DTS-ES Lights up with the either

following indicator

depending on the input

signal decoding format.
DISCRETE DTS-ES Discrete 6.1
MATRIX DTS-ES Matrix 6.1

Note

When playing a DTS format

disc, be sure that you have

made digital connections and

that INPUT MODE is no t set to

“Analog.”

T Neural-THX Lights up when the receiver

applies Neural-THX

processing to input signals.

12

GB

Rear panel

A DIGITAL INPUT/OUTPUT section

OPTICAL IN/
OUT jacks

COAXIAL IN
jacks

HDMI IN/
OUT* jacks

Connect to a DVD
player, Super Audio
CD player, etc. The
COAXIAL jack
provides a better
quality sound (page
23, 26, 31, 34, 35).

Connect to a DVD
player, Blu-ray Disc
Player, or a satellite
tuner. An image and
the sound are output
to TV or a projector
(page 23, 31).

B Control jacks for Sony equipment

and other external components

IR REMOTE
IN/OUT jacks

TRIGGER
OUT jacks

Connect an IR
repeater (page 83).

Connect to interlock
on/off of the power
supply of other 12V
TRIGGER
compliant
components, or the
amplifier/receiver of
zone 2 or zone 3
(page 111).

C DMPORT

D ANTENNA section

FM ANTENNA
jack

AM
ANTENNA
jack

XM jack Connects to the XM

SIRIUS jack Connects to a

Connect to a Sony
DIGITAL MEDIA
PORT adapter
(page 26).

Connects to the FM
wire antenna (aerial)
supplied with this
receiver (page 39).

Connects to the AM
loop antenna (aerial)
supplied with this
receiver (page 39).

Mini Tuner and
Home Dock (not
supplied) (page 65).

SiriusConnect Home
tuner (not supplied)
(page 65).

continued

13

GB

E COMPONENT VIDEO INPUT/

OUTPUT section

Y, PB/CB, PR/

IN/OUT*

C

R

jacks

Connect to a DVD
player, TV, or a
satellite tuner (page
23, 34, 35).

F RS-232C port

Used for
maintenance and
service.

G AUDIO INPUT/OUTPUT section

AUDIO IN/
OUT jacks

MULTI
CHANNEL
INPUT jacks

PRE OUT jacks Connect to an

Connect to a tape
deck or MD d eck, etc
(page 26, 29).

Connect to a Super
Audio CD player or
DVD player with an
analog audio jack for

7.1 channel or 5.1
channel sound
(page 28).

external power
amplifier.

H VIDEO/AUDIO INPUT/OUTPUT

section

AUDIO IN/
OUT jacks

VIDEO IN/
OUT* jacks

AUDIO OUT
jacks
VIDEO OUT
jack

EXT VIDEO IN
jack

Connect to a VCR or
a DVD player etc.
(page 23, 34, 35, 36).

Connect to the
component in zone 2
or zone 3 (page 83).

Connects to the
component when
you want to watch in
PIP (Picture in
Picture) window.

I SPEAKERS section

Connects to speakers
(page 21).

14

* You can watch the selected input image when you

connect the HDMI OUT jack or MONITOR OUT
jacks to a TV (page 23). You can operate this
receiver using a GUI (Graphical User Interface)
(page 41).

GB

Remote commander

You can use the supplied remote to operate the
receiver and to control the Sony audio/video
components that the remote is assigned to
operate.

Main remote commander
(RM-AAL016)

The RM-AAL016 remote is used for
illustration purpose.

Name Function

A AV ?/1 (on/

standby)

B ?/1 (on/

standby)

Press to turn on or off the audio/
video components that the
remote is assigned to operate
(page 124).
If you press ?/1 (2) button at
the same time, it will turn off
the receiver and other Sony
components (SYSTEM
STANDBY).

Note

The function of the AV ?/1
switch changes automatically
each time you press the input
button (5).

Press to turn the receiver on or
off.
If zone 2 or zone 3 is selected,
only the main receiver is turned
on or off with this button. To
turn off all components
including an amplifier in zone 2
or zone 3, press ?/1 and AV ?/
1 (1) at the same time
(SYSTEM STANDBY).

Saving the power in
standby mode.

When “Control for HDMI”
(page 115) and “RS-232C
Control” (page 116) are set to
“OFF.”

C ZONE Press to switch the zone 2 or

D AMP Press to enable the receiver

E Input

buttons

F TV INPUT Press TV (wf), then press TV

G WIDE Press TV (wf), then press

zone 3 operation (page 83).

operation (page 41).
Press one of the buttons to

select the component you want
to use. When you press any of
the input buttons, the receiver
turns on. The buttons are
factory assigned to control Sony
components (page 53, 87). You
can program the remote to
control non-Sony components
following the steps in
“Programming the remote”
(page 124).

INPUT to select the input sig nal
of a TV.

WIDE repeatedly to select the
wide picture mode.

continued

15

GB

Name Function

H D.TUNING Press SHIFT (wg), then press to

I CLEAR Press SHIFT (wg), then press to

J ENT/MEM Press SHIFT (wg), then press

K MOVIE Press to select sound field for

L MUSIC Press to select sound field for

M NIGHT

MODE

N SLEEP Press to activate the sleep timer

O GUI MODE Press to switch the display

P

V/v/B/b

Q OPTIONS

TOOLS

R MENU

HOME

enter direct tuning mode
(page 61, 67).

– clear a mistake when you

press the incorrect numeric
button.

– return to continuous

playback, etc. of the satellite
tuner or DVD player.

ENT/MEM to enter the value
after selecting a channel, disc,
or track using the numeric
buttons, or to store a station
during tuner operation.

movies (page 79).

music (page 77).
Press AMP (4), then press

NIGHT MODE to activate the
NIGHT MODE function
(page 96).

function and the duration which
the receiver turns off
automatically (page 96).

mode of the menu between GUI
MODE (to display the menu on
the TV screen) and DISPLAY
MODE (to display the menu in
the display window).

Press V/v/B/b to select the
menu items. Then press to
enter the selection.

Press to display and select items
from option menus for receiver,
DVD player, TV, or Blu-ray
Disc Player, etc.

Press to display the menu used
to operate audio/video
components or a TV.

Name Function

S m/M

T PRESET

U F1/F2 Press BD or DVD (5), then

V RM SET UP Press to set up the remote

W THEATER Press to turn the Theater mode

X TV Press to enable the TV

Y SHIFT Press to light up the button. It

a)

a)

x

a)

X

a) b)

N
./>

Press to operate the DVD
player, Blu-ray Disc Player, CD
player, MD deck, tape deck, or
component connected to the

a)

DIGITAL MEDIA PORT
adapter etc.

CATEGORY
MODE

Press to select the category
mode for satellite tuner.

TUNING +/– Press to select station.

b)

/–

+

Press to register FM/AM/
satellite tuner stations or to
select preset stations.

b)

TV CH +

/– Press TV (wf), then press TV

CH + /– to operate the TV,
satellite tuner, VCR, etc.

press F1 or F2 to select a
component to operate.

• HDD recorder
F1: HDD
F2: DVD player, Blu-ray Disc
Player

• DVD/VHS combo player
F1: DVD player, Blu-ray Disc
Player
F2: VHS

INPUT
MODE

Press AMP (4), then press
INPUT MODE to select the
input mode when the same
components are connected to
both digital and analog jacks
(page 92).

(page 99).

on and off when connecting the
receiver to products featuring
“BRAVIA” Sync.

operation.

changes the remote button
function to activate the buttons
with pink printing.

16

GB

Name Function

Z Numeric

buttons

wj -/-- Press to select

wk A.F.D. Press to select sound field

wl 2CH/

A.DIRECT

e;

RESOLUTION

ea PIP Press PIP to switch the image of

es DISPLAY Press to select information

Press SHIFT (wg), then press to
– preset/tune to preset stations.
– select track numbers of the

CD player, DVD player, Blu­ray Disc Player or MD deck.
Press -/-- (wj) to select track
number 10.

– select channel numbers of

the VCR or satellite tuner.

– After pressing TV (wf),

press the numeric buttons to
select the TV channels.

– track numbers over 10 of the

VCR, satellite tuner, CD
player or MD deck.

– channel numbers of the

Digital CATV terminal.

(page 74).
Press to select sound field or to

switch the audio of the selected
input to analog signal without
any adjustment (page 73).

Press RESOLUTION
repeatedly to change the
resolution of signals output
from the HDMI OUT or
COMPONENT VIDEO
MONITOR OUT jack.

the PIP (Picture in Picture)
window. The image of the PIP
window is the one from the
EXT VIDEO IN jack. You can
swap the position of the main
screen and the PIP window by
pressing (qh).

Note

The HDMI video signals are not
output while the PIP window is
displayed.

displayed in the display
window, TV screen of the VCR,
satellite tuner, CD player, DVD
player, Blu-ray Disc Player, or
MD deck.

Note

In the GUI MODE, press the
button to display the menu on
the TV screen.

Name Function

ed RETURN/

EXIT O

ef CATEGORY

+/–
B·/·b Press to select an album.

eg DISC SKIP Press to skip a disc when using

eh MASTER

VOL +/–
TV VOL +/– Press TV (wf), then press TV

ej MUTING Press to turn off the sound

ek BD/DVD/

TOP MENU,
MENU

MACRO1,
MACRO2

a)

See the table on page 123 for information on the
buttons that you can use to control each
component.

b)

The tactile dot is attached to these buttons (TV/5,
N, PRESET +/TV CH +). Use as a mark of
operation.

Press to return to the previous
menu or exit the menu while the
menu or on-screen guide of the
VCR, DVD player, or satellite
tuner is displayed on the TV
screen.

Press to select the category for
satellite tuner.

a multi-disc changer.
Press to adjust the volume level

of all speakers at the same time.

VOL +/– to adjust the volume
level of the TV.

temporarily. Press the button
again to restore the sound.

Press to display the menus of
the DVD player on the TV
screen. Then use V/v/B/b and

to perform a menu

operations.
Press AMP (4), then press

MACRO 1 or MACRO 2 to set
up the macro function
(page 127).

Notes

• Some functions explained in this section may not
work depending on the model.

• The above explanation is intended to serve as an
example only. Therefore, depending on the
component, the above operation may not be
possible or may operate differently than described.

continued

17

GB

Sub remote commander (RM­AAU038)

This remote can only be used to operate the
receiver. You can control the main functions of
the receiver with simple operations using this
remote.

Name Function

A ?/1 (on/

standby)

B 2CH/

A.DIRECT
A.F.D.
MOVIE
MUSIC

C GUI MODE Press to switch the display

D

V/v/B/b

Press to turn a receiver on or off.

Press to select sound field
(page 73, 74, 77, 79).

mode of the menu between GUI
MODE (to display the menu on
the TV screen) and DISPLAY
MODE (to display the menu in
the display window).

After pressing GUI MODE
(3), press V/v/B/b to select
the menu item. Then press
to enter the selection.

Name Function

E OPTIONS Press to display and select items

F MENU Press to display the menu to

G DMPORT Press to operate the component

N Starts play.
x Stops play.
./> Skips tracks.

H INPUT

SELECTOR

I MASTER

VOLUME +/–

J MUTING Press to turn off the sound

K RETURN/

EXIT

L DISPLAY Press to select information

M PIP Press PIP to switch the image of

from option menus.

operate the receiver.

connected to the DIGITAL
MEDIA PORT adapter
(page 55).

Press to select the input source
to play back.

Press to adjust the volume level.

temporarily. Press the button
again to restore the sound.

Press to return to the previous
menu or exit the menu.

displayed in the display
window.

Note

In the GUI MODE, press the
button to display the menu on
the TV screen.

the PIP (Picture in Picture)
window. The image will be
changed as follows. EXT
VIDEO t ZONE 2 VIDEO
t OFF. You can swap the
position of the main screen and
the PIP window (swap) by
pressing the (4). You can
expand or shrink the window
using V/v (4). You can also
change the window’s position
using B/b (4).

Note

The HDMI video signals are not
output while the PIP window is
displayed.

18

GB

Getting Started

1: Installing speakers

This receiver allows you to use a 7.1 channel system (7 speakers and one subwoofer).

Getting Started

Enjoying a 5.1/7.1 channel
system

To fully enjoy theater-like multi-channel
surround sound requires five speakers (two
front speakers, a center speaker, and two
surround speakers) and a subwoofer (5.1
channel system).

Example of a 5.1 channel
speaker system configuration

You can enjoy high fidelity reproduction of
DVD or Blu-ray Disc software recorded sound
in the Surround EX format if you connect one
additional surround back speaker (6.1 channel
system) or two surround back speakers (7.1
channel system.)

Example of a 7.1 channel
speaker system configuration

AFront left speaker
BFront right speaker
CCenter speaker
DSurround left speaker
ESurround right speaker
HSubwoofer

AFront left speaker
BFront right speaker
CCenter speaker
DSurround left speaker
ESurround right speaker
FSurround back left speaker
GSurround back right speaker
HSubwoofer

continued

19

GB

Tips

•The angle A should be the same.

• When you connect a 6.1 channel speaker system,
place the surround back speaker behind the seating
position.

• Since the subwoofer does not emit highly
directional signals, you can place it wherever you
want.

GB

20

2: Connecting speakers

Before connecting cords, make sure to disconnect the AC power cord (mains lead).

Getting Started

HG F

B

A

BB

B

E

FRONT SPEAKERS
B terminals

a)

A Monaural audio cord (not supplied)
B Speaker cords (not supplied)

AFront speaker A (L)
BFront speaker A (R)
CCenter speaker
DSubwoofer
ESurround back speaker (L)
FSurround back speaker (R)

b)

c)
c)

GSurround speaker (L)
HSurround speaker (R)

C

BAD

a)

If you have an additional front speaker
system, connect them to the FRONT
SPEAKERS B terminals. You can select
the front speaker system you want to use
with the SPEAKERS switch (OFF/A/B/
A+B) on the front panel (page 44).

continued

21

GB

b)

When you connect a subwoofer with an auto
standby function, turn off the function when
watching movies. If the auto standby
function is set to on, it turns to standby mode
automatically based on the level of the input
signal to a subwoofer, then sound may not be
output.

c)

If you connect only one surround back
speaker, connect it to the SURROUND
BACK SPEAKERS L terminals.

Notes

• When you connect all the speakers with a nominal
impedance of 8 ohms or higher, set “Impedance” in
the Speaker settings menu to “8 Ω.” In other
connections, set it to “4 Ω.” For details, see “8:
Setting the speakers” (page 42).

• Before connecting the AC power cord (mains
lead), make sure that metallic wires of the speaker
cords are not touching each other between the
SPEAKERS terminals.

Tip

To connect certain speakers to another power
amplifier, use the PRE OUT jacks. The same signal
is output from both the SPEAKERS terminals and
the PRE OUT jacks. For example, if you want to
connect just the front speakers to another amplifier,
connect that amplifier to the PRE OUT FRONT L
and R jacks.

ZONE 2 connection

You can assign the SURROUND BACK
SPEAKERS terminals E and F to the
speakers of the zone 2. Set “Sur Back Assign”
to “ZONE2” in the Speaker settings menu.
See “Using Multi-zone Features” (page 83)
for details on connection and operation in zone

2.

GB

22

3: Connecting the monitor

You can watch the selected input image when you connect the HDMI OUT jack or MONITOR
OUT jacks to a TV. You can operate this receiver using a GUI (Graphical User Interface).
It is not necessary to connect all the cables. Connect audio and video cords according to the jacks
of your components.

TV monitor

Audio signals

Video signals

Getting Started

AB

CD E

A Optical digital cord (not supplied)
B Audio cord (not supplied)
C Component video cord (not supplied)
D HDMI cable (not supplied)
E Video cord (not supplied)

continued

23

GB

Notes

• Before connecting cords, make sure to disconnect
the AC power cord (mains lead).

• Connect image display components such as a TV
monitor or a projector to the MONITOR VIDEO
OUT jack on the receiver. You may not be able to
record, even if you connect recording components.

• Turn on the receiver when the video and audio of a
playback component are being output to a TV via
the receiver. If the power supply of the receiver is
not turned on, neither video nor audio is
transmitted.

• Depending on the status of the connection between
the TV and the antenna (aerial), the image on the
TV screen may be distorted. In this case, place the
antenna (aerial) farther away from the receiver.

Tips

• The receiver has a video conversion function. For
details, see “Notes on converting video signals”
(page 38).

• The sound of the TV is output from the speakers
connected to the receiver if you connect the audio
output jack of the TV and the TV IN jacks of the
receiver. In this configuration, set the sound output
jack of the TV to “Fixed” if it can be switched
between either “Fixed” or “Variable.”

• The screen saver is activated when the GUI menu
is displayed on the TV screen and there has been no
operation attempted for 15 minutes.

24

GB

4a: Connecting the audio components

How to hook up your
components

This section describes how to hook up your
components to this receiver. Before you begin,
refer to “Component to be connected” below
for the pages which describe how to connect
each component.
After hooking up all your components,
proceed to “5: Connecting the antennas
(aerials)” (page 39).

Component to be connected Page

Super Audio CD
player/ CD player

MD player With digital audio

Tape deck, Analog disc turntable 29

With digital audio
output

With multi-channel
audio output

With analog audio
output only

output

With analog audio
output only

26

28

29

26

29

Getting Started

25

GB

Connecting components with digital audio input/output jacks

The following illustration shows how to connect a Super Audio CD player, CD player, an MD deck
and DIGITAL MEDIA PORT adapter.

DIGITAL MEDIA PORT

adapter

MD deck

A

Super Audio CD
player, CD player

BBC

A Optical digital cord (not supplied)
B Audio cord (not supplied)
C Coaxial digital cord (not supplied)

Notes

• When connecting optical digital cords, insert the
plugs straight in until they click into place.

• Do not bend or tie optical digital cords.

• Before connecting cords, make sure to disconnect
the AC power cord (mains lead).

• To disconnect the DIGITAL MEDIA PORT
adapter, observe the following precautions.
– Remove the DIGITAL MEDIA PORT adapter

after removing the cord when cords are
connected to the COMPONENT VIDEO jack.

GB

26

– Remove the DIGITAL MEDIA PORT adapter

by squeezing the sides of the connector, since
the connector is locked in place.

Tip

All the digital audio jacks are compatible with
32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz and 96 kHz
sampling frequencies.

Notes on playing a Super Audio
CD on a Super Audio CD player

• No sound is output when playing a Super
Audio CD on a Super Audio CD player
connected to only the COAXIAL SA-CD/
CD IN jack on this receiver. When you play
a Super Audio CD, connect the player to the
MULTI CHANNEL INPUT or SA-CD/CD
IN jacks. Refer to the operating instructions
supplied with the Super Audio CD player.

• Connect a player which can output DSD
signals from the HDMI jack to the receiver
using an HDMI cable.

• You cannot make digital recordings of a
Super Audio CD.

• When connecting optical digital cords, insert
the plugs straight in until they click into
place.

• Do not bend or tie optical digital cords.

If you want to connect several
digital components, but cannot
find an unused input

See “Enjoying the sound/images from other
inputs (Input Assign)” (page 93).

Getting Started

27

GB

Connecting components with multi-channel output jacks

If your DVD player, Blu-ray Disc Player or Super Audio CD player is equipped with multi-channel
output jacks, you can connect them to the MULTI CHANNEL INPUT jacks of this receiver to
enjoy multi-channel sound. Alternatively, the multi-channel input jacks can be used to connect an
external multi-channel decoder.

DVD player,
Blu-ray Disc Player,
Super Audio CD player,
etc.

A

B

A Audio cord (not supplied)
B Monaural audio cord (not supplied)

Notes

• Before connecting cords, make sure to disconnect
the AC power cord (mains lead).

• DVD player, Blu-ray Disc Player and Super Audio
CD players may not have the SURROUND BACK
jacks.

• When “Sur Back Assign” is set to “BI-AMP” or
“ZONE2” in the Speaker settings menu, the input
to the SUR BACK jacks is invalid.

GB

28

• Audio input signals from MULTI CHANNEL
INPUT jacks are not output to any audio output
jacks. The signals cannot be recorded.

Connecting components with analog audio jacks

The following illustration shows how to connect a component with analog jacks, such as tape deck,
turntable, etc.

Getting Started

A

Super Audio CD player,
CD player

A

Tape deck

A

A

Tu rn t ab l e

A Audio cord (not supplied)

Notes

• If your turntable has a ground (earth) wire, connect

it to the (U) SIGNAL GND terminal.

• Before connecting cords, make sure to disconnect
the AC power cord (mains lead).

MD deck

29

GB

4b: Connecting the video components

How to hook up your
components

This section describes how to hook up your
components to this receiver. Before you begin,
refer to “Component to be connected” below
for the pages which describe how to connect
each component.
After hooking up all your components,
proceed to “5: Connecting the antennas
(aerials)” (page 39).

Component to be connected Page

TV monitor 23

With HDMI jack 31

DVD player, Blu-ray Disc Player 34

Satellite tuner, Set-top box 35

DVD recorder, VCR 36

Camcorder, video game, etc. 36

Video input/output jacks to be
connected

The image quality depends on the connecting
jack. Refer to the illustration that follows.
Select the connection according to the jacks on
your components.

Digital Analog

High quality image

30

GB

Connecting components with
HDMI jacks

HDMI is the abbreviated name for High­Definition Multimedia Interface. It is an
interface which transmits video and audio
signals in digital format.

HDMI features

• A digital audio signals transmitted by HDMI

can be output from the speakers and the PRE
OUT jacks on this receiver. This signal
supports Dolby Digital, DTS, DSD, and
linear PCM.

• Linear PCM (sampling frequency less than

192 kHz) with digital audio signals of up to
8 channels can be received with this receiver
using the HDMI IN jack.

• Analog video signals input to the VIDEO

jack, or COMPONENT VIDEO jacks can be
output as HDMI signals. Audio signals are
not output from an HDMI OUT jack when
the image is converted.

• This receiver supports DSD transmission

(Super Audio CD), extended by HDMI
ver1.2.

• This receiver supports High Bitrate Audio

(DTS-HD Master Audio, Dolby TrueHD),
Deep Color and xvYCC transmission,
extended by HDMI ver1.3.

• The HDMI jacks of this receiver support the

Control for HDMI function. The HDMI
OUT B jack, however, does not support the
Control for HDMI function.

• HDMI IN 6 is input which is considered

sound quality. Input IN 6 when you need
higher quality sound. You can also use IN 6
jack in the same manner as the HDMI IN 1
to IN 5 jacks.

Getting Started

continued

31

GB

DVD player Satellite tuner/Set-top box Blu-ray Disc Player, PS3™,

Audio/video
signals

Audio/video
signals

hard disk recorder

Audio/video
signals

To TV OPTICAL
IN jacks

A

Audio signals

AA

TV monitor, projector, etc.

CBA

Audio/
video
signals

A HDMI cable (not supplied)

We recommend that you use a Sony HDMI cable.

B Optical digital cord (not supplied)
C Audio cord (not supplied)

To enjoy TV multi channel
surround sound broadcasting

You can listen to TV multi channel surround
sound broadcasting from the speakers
connected to the receiver.
Connect the OPTICAL output jack of the TV
to the OPTICAL IN jack of the receiver.

GB

32

Tip

Connect to at least one of the audio cords (B or C).

Notes on connecting cables

• We recommend that you use an HDMI cable

with the HDMI logo (made by Sony) for the
HDMI jack corresponding to high speed (an
HDMI version1.3a, category 2 cable) when
you view images or listen to sound during a
Deep Color transmission or when you watch
a video image of 1080p or higher.

• We do not recommend using an HDMI-DVI

conversion cable. When you connect an
HDMI-DVI conversion cable to a DVI-D
component, the sound and/or the image may
not be output. Connect other audio cords or
digital connecting cords, then set “Input
Assign” in the Input Option menu when the
sound is not output correctly.

• Before connecting cables, make sure to

disconnect the AC power cord (mains lead).

Notes on HDMI connections

• Check the setup of the connected component

if an image is poor or the sound does not
come out of a component connected via the
HDMI cable.

• An audio signal input to the HDMI IN jack

is output from the speaker output jacks,
HDMI OUT jack and PRE OUT jacks. It is
not output from any other audio jacks.

• A video signal input to the HDMI IN jack

can only be output from the HDMI OUT
jack. The video input cannot be output from
the VIDEO OUT jacks or MONITOR
VIDEO OUT jacks.

• The audio and video signals of HDMI input

are not output from the HDMI OUT jack
while the receiver menu is displayed.

• When you want to listen to the sound from

the TV speaker, set “Audio Out” to
“TV+AMP” in the HDMI settings menu. If
set to “AMP,” the sound is not output from
the TV speaker.

• Be sure to turn on the receiver when video

and audio signals of a playback component
are being output to a TV through this
receiver. Unless the power is on, neither
video nor audio signals will be transmitted.

• Audio signals (sampling frequency, bit
length, etc.) transmitted from an HDMI jack
may be suppressed by the connected
component. Check the setup of the
connected component if an image is poor or
the sound does not come out of a component
connected via the HDMI cable.

• Sound may be interrupted when the
sampling frequency, the number of channels
or audio format of audio output signals from
the playback component is switched.

• When the connected component is not
compatible with copyright protection
technology (HDCP), the image and/or the
sound from the HDMI OUT jack may be
distorted or may not be output.
In this case, check the specification of the
connected component.

• Refer to the operating instructions of each
component connected for details.

• You can enjoy High Bitrate Audio (DTS-HD
Master Audio, Dolby TrueHD), DSD, multi­channel Linear PCM only with an HDMI
connection.

• Set the image resolution of the player to
more than 720p/1080i to enjoy High Bitrate
Audio (DTS-HD Master Audio, Dolby
TrueHD).

• The image resolution of player may need
certain settings be made before you can
enjoy DSD and multi-channel Linear PCM.
Refer to the operating instructions of the
player.

• Not every HDMI component supports all
functions that are defined by the specified
HDMI version. For example, components
that support HDMI, ver. 1.3a, may not
support Deep Color.

Getting Started

33

GB

Connecting a DVD player, Blu-ray Disc Player

The following illustration shows how to connect a DVD player, Blu-ray Disc Player.
It is not necessary to connect all the cables. Connect audio and video cords according to the jacks
of your components.

DVD player, Blu-ray Disc Player

Audio signals Video signals

ABC

A Optical digital cord (not supplied)
B Coaxial digital cord (not supplied)
C Audio cord (not supplied)

* When you connect a component equipped with an

OPTICAL jack, set “Input Assign” in the Input
menu.

D

E

D Component video cord (not supplied)
E Video cord (not supplied)

Notes

• To output multi-channel digital audio, set the
digital audio output setting on the DVD player,
Blu-ray Disc Player. Refer to the operating
instructions supplied with the DVD player, Blu-ray
Disc Player.

• Before connecting cords, make sure to disconnect
the AC power cord (mains lead).

34

GB

Connecting a satellite tuner, Set-top box

The following illustration shows how to connect a satellite tuner, Set-top box.
It is not necessary to connect all the cables. Connect audio and video cords according to the jacks
of your components.

Satellite tuner, Set-top box

Audio signals Video signals

AB CD

Getting Started

A Optical digital cord (not supplied)
B Audio cord (not supplied)
C Component video cord (not supplied)
D Video cord (not supplied)

Note

Before connecting cords, make sure to disconnect
the AC power cord (mains lead).

35

GB

Connecting components with analog video and audio jack

The following illustration shows how to connect a component which has analog jacks such as a
DVD recorder or VCR, etc.
It is not necessary to connect all the cables. Connect audio and video cords according to the jacks
of your components.

DVD recorder, VCR

Audio signals Video signals

AB

A Audio cord (not supplied)
B Video cord (not supplied)

GB

36

Remove the cover.

Getting Started

To the VIDEO 2 IN/
PORTABLE AV IN jacks

C Audio/video cord (not supplied)

C

Note

Before connecting cords, make sure to disconnect
the AC power cord (mains lead).

Camcorder,
video game

Function for conversion of video signals

This receiver is equipped with a function for converting video signals.

• Composite video signals can be output as HDMI video and component video signals.

• Component video signals can be output as HDMI video and video signals.

As the initial setting, video signals input from the connected component are output to the HDMI
OUT jack or MONITOR OUT jacks as shown in the table below.
We recommend you set the video conversion function to match the resolution of the monitor you
are using.
For details on the video converting function, see “ Video settings” (page 113).

OUTPUT jack

INPUT jack

HDMI IN 1/2/3/4/5/6 a ––
VIDEO IN aa a
COMPONENT VIDEO IN aa a

HDMI OUT

COMPONENT VIDEO

MONITOR OUT

MONITOR VIDEO OUT

a : Video signals are output.

– : Video signals are not output.

continued

37

GB

Notes on converting video
signals

• When video signals from a VCR, etc., are
converted on this receiver and then output to
your TV, depending on the status of the
video signal output, the image on the TV
screen may appear distorted horizontally or
no image may be output.

• HDMI video signals cannot be converted to
component video signals and video signals.

• The converted video signals are output only
from the MONITOR OUT jacks. They are
not output from VIDEO OUT jack or the
ZONE 2 VIDEO OUT jack.

• When you play a VCR with an image
improvement circuit, such as TBC, the
images may be distorted or may not be
output. In this case, set the image
improvement circuit function to off.

• The resolution of the signals output to the
COMPONENT VIDEO MONITOR OUT
jacks is converted up to 1080i. The
resolution of the signals output to the HDMI
OUT jack is converted up to 1080p.

• COMPONENT VIDEO MONITOR OUT
jacks have restrictions on resolution when
the resolution of video signals protected by
copyright technology is converted.
Resolution of up to 480p can be output to the
COMPONENT VIDEO MONITOR OUT
jacks. The HDMI OUT jack has no
restriction on resolution.

• Video signals for which the resolution has
been converted cannot be output from either
the COMPONENT VIDEO MONITOR
OUT jacks or the HDMI OUT jack. The
video signals are output from the HDMI
OUT jack when both are connected.

• Set “Resolution” to “AUTO” or “480i/576i”
in the Video settings menu to output the
video signals from the MONITOR VIDEO
OUT, COMPONENT VIDEO MONITOR
OUT jacks when both are connected.

To display Closed Caption

Set “Resolution” to “DIRECT” in the Video
settings menu when receiving a signal that
supports Closed Captions.
Use the same kind of cords for the input/output
signals.

To connect a recording
component

When recording, connect the recording
component to the VIDEO OUT jack of the
receiver. Connect cords for input and output
signals to the same type of jack, as VIDEO
OUT jack do not have an up-conversion
function.

Note

Signals output from the MONITOR OUT jacks may
not be recorded properly.

38

GB

5: Connecting the antennas (aerials)

Connect the supplied AM loop antenna (aerial) and FM wire antenna (aerial).

AM loop antenna (aerial)

FM wire antenna (aerial) (supplied)

* The shape of the connector varies depending on

the area.

Notes

• To prevent noise pickup, keep the AM loop antenna
(aerial) away from the receiver and other
components.

• Be sure to fully extend the FM wire antenna
(aerial).

• After connecting the FM wire antenna (aerial),
keep it as horizontal as possible.

• Before connecting cords, make sure to disconnect
the AC power cord (mains lead).

(supplied)

Getting Started

39

GB

6: Preparing the receiver
and the remote

Connecting the AC power cord
(mains lead)

Connect the supplied AC power cord (mains
lead) to the AC IN terminal on the receiver,
then connect the AC power cord (mains lead)
to a wall outlet.

Notes

• Before connecting the AC power cord (mains
lead), make sure that metallic wires of the speaker
cords are not touching each other between the
SPEAKERS terminals.

• Connect the AC power cord (mains lead) firmly.

Performing initial setup
operations

Before using the receiver for the first time,
initialize the receiver by performing the
following procedure. This procedure can also
be used to return settings you have made to
their factory defaults.

POWER

TONE MODE HDMI IN

AC IN terminal

To the wall outlet

AC power cord
(mains lead)
(supplied)

A several space is left between the plug and the
rear panel even when the power cord (mains
lead) is inserted firmly. The cord is supposed
be connected this way. This is not malfunction.

1 Press POWER to turn off the

receiver.

2 Hold down POWER while

pressing TONE MODE and
HDMI IN to turn on the receiver.

3 Release the TONE MODE and

HDMI IN after a few seconds.

After “MEMORY CLEARING...”
appears on the display for a while,
“MEMORY CLEARED.” appears.
All the settings you have changed or
adjusted are reset to the initial settings.

40

GB

Inserting batteries into the
remote

Insert two R6 (size-AA) batteries in the RM­AAL016 remote commander.
Insert two R6 (size-AA) batteries in the RM­AAU038 remote control.
Observe the correct polarity when installing
batteries.

7: Displaying the GUI
menu on the TV screen

You can select the functions or change the
settings of the receiver by using the GUI menu
on the TV screen. Follow the procedure below
to make the settings so that the GUI menu
appears on the TV screen.

Tip

Refer to “Operating without connecting to a TV”
(page 116) if you want to operate the receiver
without connecting to a TV.

Getting Started

RM-AAL016 RM-AAU038

Notes

• Do not leave the remote in an extremely hot or
humid place.

• Do not use a new battery with old ones.

• Do not mix manganese batteries and other kinds of
batteries.

• Do not expose the remote sensor to direct sunlight
or lighting apparatuses. Doing so may cause a
malfunction.

• If you do not intend to use the remote for an
extended period of time, remove the batteries to
avoid possible damage from battery leakage and
corrosion.

• When you replace the batteries, the programmed
remote codes may be cleared. If this happens,
program the remote codes again (page 124).

Tip

When the remote no longer operates the receiver,
replace all the batteries with new ones.

?/1

AMP

GUI
MODE

MENU

1 Connect a TV monitor to this

receiver.

Refer to “3: Connecting the monitor”
(page 23).

2 Turn on the receiver and the TV.
3 Press AMP.

The receiver can be operated using the
remote.

continued

41

GB

4 Press GUI MODE.

After “GUI MODE ON” has appeared in
the display window of the receiver, “GUI
MODE” appears.

The receiver menu is displayed on the TV
screen.

8: Setting the speakers

Setting the speaker impedances

Set the appropriate speaker impedance for the
speakers you are using.

AMP

Tip

You can select the language to be used for messages
on the GUI menu on the TV screen from English,
Spanish, French and German. For details, see
“ System settings” (page 116).

To exit the menu

Press MENU.

GB

42

V/v/b,

MENU

1 Press AMP.

The receiver can be operated using the
remote.

2 Press MENU.

The menu is displayed on the TV screen.

3 Press V/v repeatedly to select

“ Settings,” then press or
b.

The Settings menu list appears on the TV
screen.

4 Press V/v repeatedly to select

“Speaker,” then press or b.

5 Press V/v repeatedly to select

“Impedance,” then press .

Getting Started

To exit the menu

Press MENU.

Notes

• If you are not sure of the impedances of the
speakers, refer to the operating instructions
supplied with your speakers. (This information is
often on the back of the speaker.)

• When you connect all speakers with a normal
impedance of 8 ohms or higher, set “Impedance” to
“8 Ω.” When connecting other types of speakers,
set it to “4 Ω.”

• When you connect front speakers to both the
SPEAKERS A and B terminals, connect the
speakers with a normal impedance of 8 ohms or
higher.
– When you connect speakers with impedance of

16 ohms or higher in both “A” and “B”
configuration:
Set “Impedance” to “8 Ω” in the Speaker
settings menu.

– For other types of speakers in other

configurations:
Set “Impedance” to “4 Ω” in the Speaker
settings menu.

6 Press V/v repeatedly to select

“4 Ω” or “8 Ω” depending on
the speakers you are using,
then press .

The parameter you have selected is
entered.

43

GB

Selecting the front speakers

You can select the front speakers you want to
drive.

SPEAKERS switch

Set the SPEAKERS switch to select
the front speaker system you want
to drive.

Note

This setting is not available when headphones are
connected.

Set to To select

A The speakers connected to the

FRONT SPEAKERS A terminals.

B The speakers connected to the

FRONT SPEAKERS B terminals.

A+B The speakers connected to both the

FRONT SPEAKERS A and B
terminals (parallel connection).

OFF No audio signals are output from

any speaker terminals, or the PRE
OUT jacks.

9: Calibrating the
appropriate speaker
settings automatically

(Auto Calibration)

The DCAC (Digital Cinema Auto Calibration)
function allows you to perform automatic
calibration, such as checking the connection
between each speaker and the receiver,
adjusting the speaker level, and measuring the
distance of each speaker from your seating
position automatically.

Before you perform the auto
calibration

Before you perform the auto calibration, set up
and connect the speakers (page 19-22).

• The AUTO CAL MIC jack is used for the
supplied optimizer microphone only. Do not
connect other microphones. Doing so may
damage the receiver and the microphone.

• During the measurement, the sound that
comes out of the speakers is very loud. The
volume of the sound cannot be adjusted. Pay
attention to the presence of children or to the
effect on your neighborhood.

• Perform the measurement in a quiet
environment to avoid the effect of noise and
get a more accurate measurement.

• If there are any obstacles in the path between
the optimizer microphone and the speakers,
the calibration cannot be performed
correctly. Remove any obstacle from the
measurement area to avoid measurement
error.

• When you use a bi-amplifier connection, set
“Sur Back Assign” to “BI-AMP” in the
Speaker settings menu before you perform
auto calibration.

Notes

• The auto calibration function does not work if

headphones are connected.

• Cancel MUTING if it is set to on.

44

GB

Optimizer microphone

1 Connect the supplied optimizer

microphone to the AUTO CAL
MIC jack.

2 Set up the optimizer

microphone.

Place the optimizer microphone at your
seating position. Use a stool or tripod so
that the optimizer microphone remains at
the same height as your ears.

On setting up the active
subwoofer

• When a subwoofer is connected, turn on the
subwoofer and turn up the volume
beforehand. Turn the MASTER VOLUME
knob to just before the mid-point.

• If you connect a subwoofer with the
crossover frequency function, set the value
to maximum.

• If you connect a subwoofer with an auto
standby function, set it to off (deactivated).

Note

Depending on the characteristics of the subwoofer
you are using, the setup distance value may be
further away from the actual position.

To use the receiver as a pre­amplifier

You can use the auto calibration function when
you use the receiver as a pre-amplifier.
In this case, the distance value shown on the
display may differ from the actual distance
value. However, there will be no problems
even if you continue to use the receiver with
that value.

Performing auto calibration

The auto calibration function allows you to
measure the following:

• Speaker connections

• Polarity of speakers

• Speaker distance

• Speaker size

• Speaker level

• Frequency characteristics

a) This receiver corrects signals by analog

downmix processing only for the center speaker
and subwoofer when the multi-channel input is
selected. The correction is invalid for other
speakers.

b) The measurement result is not utilized when the

multi-channel input is selected.

c) •Signals with a sampling frequency of higher

than 96 kHz are always played back at either

44.1 kHz or 48 kHz.

a)

b)

b)

c)

Getting Started

continued

45

GB

• The measurement result is not utilized in the
following cases.
–The multi-channel input is selected.
–“2ch Analog Direct” is being used.

• The measurement result is not utilized when
Dolby TrueHD signals with a sampling
frequency of higher than 96 kHz are being
received.

AMP

V/v/B/b,

MENU

3 Press V/v repeatedly to select

“ Settings,” then press or
b.

The Settings menu list appears on the TV
screen.

4 Press V/v repeatedly to select

“Auto Calibration,” then press

or b.

1 Press AMP.

The receiver can be operated using the
remote.

2 Press MENU.

The menu is displayed on the TV screen.

GB

46

5 Press V/v repeatedly to select

“Quick Setup,” then press .

The screen on which you can select the
item to be measured appears.

6 Press V/v repeatedly and to

un-check the items you do not
want to measure, then press b.

The confirmation screen, asking whether
you are ready to start measurement,
appears.

7 Press to select “Start.”

The measurement starts in five seconds.
When the measurement ends, a beep
sounds and the measurement result
appears on the TV screen.

Getting Started

Note

When the speaker(s) is (are) out of the phase, “Out
Phase” is displayed on the TV screen. The “+” and
“–” terminals of the speaker may be connected the
other way around. However, depending on the
speakers, “Out Phase” appears on the TV screen
even though the speakers are connected properly.
This is because of the speakers’ specifications. In
this case, you can continue to use the receiver.

Tips

• Operations other than turning the receiver on or off
are deactivated during the measurement.

• In the following situations, the measurements have
not been performed correctly or auto calibration
cannot be performed.
– when connecting special speakers, such as

dipole speakers.

– when using the zone 2/zone 3 function in zone 2/

zone 3.

• You can change the unit of distance use in
“Distance Unit” in the Speaker settings menu.

8 Press to select “Next.”

“Save auto calibration (auto speaker
setup)?” appears. To save the
measurement results, follow the steps in
“Saving the measurement results”
(page 48).
If a warning message or error code
appears on the screen, see “Message list
after auto calibration measurement”
(page 49).

To cancel the measurement

The measurement is cancelled when you
change the volume, switch functions, change
the setting of the SPEAKERS switch, or
connect headphones.

47

GB

Saving the measurement results

To save the measurement results obtained in
“Performing auto calibration” (page 45),
proceed with the following steps.

1 Press B/b to select “Yes” in

step 8 in “Performing auto
calibration,” then press .

The selecting screen of the calibration
type appears.

2 Press V/v repeatedly to select

the auto calibration type, then
press .

Parameter Explanation

Full Flat Makes the measurement of

frequency from each
speaker flat.

Engineer Sets the frequency to one

that matches that of the
Sony listening room
standard.

Front Reference Adjusts the characteristics

of all the speakers to match
the characteristics of the
front speaker.

OFF Sets the auto calibration EQ

to off.

The measurement results are saved.

4 Press .

Notes

• After reflecting the results of a compensation for a
frequency characteristic, signals with a sampling
frequency of higher than 96 kHz are always played
back at either 44.1 kHz or 48 kHz.

• The frequency response measurement result is not
utilized in the following cases.
– The multi-channel input is selected.
– “2ch Analog Direct” is being used.

• The measurement result is not utilized when Dolby
TrueHD signals with a sampling frequency of
higher than 96 kHz are being received.

Tip

The size of a speaker (LARGE/SMALL) is
determined by the low characteristics. The
measurement results may vary, depending on the
position of the optimizer microphone and speakers,
and the shape of the room. It is recommended that
you follow the measurement results. However, you
can change those settings in the Speaker settings
menu. Save the measurement results first, then try to
change the settings if you want.

3 Press b.

The exit screen appears.

GB

48

Checking the auto calibration
results

then press .

3 Repeat steps 6 to 8 in

2 Press B/b to select “Retry,”

If a warning message or error code appears in
step 8 of “Performing auto calibration”
(page 45), check the problem of the error and
perform auto calibration again.

1 Press B/b to select “Yes,” then

press when “Error occurred
during calibration, press to
investigate.” appears on the
screen.

Confirm the details of the measurement
results, then proceed with the appropriate
remedy.

Message list after auto calibration measurement

Display Explanation

Code 30 Headphones are connected. Remove the headphones and perform the auto calibration again.
Code 31 SPEAKERS (OFF/A/B/A+B) is set to OFF. Set it to others and re-perform the measurement.
Code 32 None of the speakers were detected. Make sure that the optimizer microphone is connected

Code 33 • None of the front speakers are connected or only one front speaker is connected.

Warning 40 The measurement has completed. However, the noise level is high. You may be able to

Warning 41
Warning 42

Warning 43 The distance and position of a subwoofer cannot be detected. Or the angle of the speaker

properly and reperform the measurement.
If the optimizer microphone is connected properly but the error code appears, the optimizer
microphone cable may be damaged or improperly connected.

• The optimizer microphone is not connected.

• Either the left or right surround speakers is not connected.

• Surround back speakers are connected even though surround speakers are not connected.
Connect the surround speaker(s) to the SURROUND terminals.

• The surround back speaker is connected only to the SURROUND BACK SPEAKERS R
terminals. When you connect only one surround back speaker, connect it to the
SURROUND BACK SPEAKERS L terminals.

perform the measurement properly if you try it again, even though the measurement cannot
be performed in all environments. Try to perform the measurement in a quiet environment.

The input from the microphone is too big.

• It may be too close the distance between the speaker and the microphone.

Retry the measurement after setting apart from each other.

• It may be that the volume is too big when you use the receiver as a preamp.

position cannot be detected. This may be caused by noise. Try to perform the measurement
in a quiet environment.

“Performing auto calibration”
(page 45).

To save measurement results
that caused an error without
taking a remedy

Press B/b to select “No”, then press

1

when “Error occurred during
calibration, press to investigate.”
appears on the screen.

2 Follow the steps in “Saving the

measurement results” (page 48) to
save the measurement results.

Getting Started

continued

49

GB

Display Explanation

NO WARNING There is no warning information.

---------- No speakers are connected.

Tip

Depending on the position of the subwoofer, the
measurement results for polarity may vary.
However, there will be no problems even if you
continue to use the receiver with that value.

50

GB

Guide to on-screen
display operation

You can display the menu of the receiver on
the TV screen and select the function you want
to use on the TV screen by pressing V/v/B/b
and on the remote.
To display the menu of the receiver on the TV
screen, make sure that the receiver is in “GUI
MODE” following the steps in “7: Displaying
the GUI menu on the TV screen” (page 41).

Getting Started

3 Press V/v repeatedly to select

the menu you want, then press

or b to enter the menu

mode.

The menu item list appears on the TV
screen.

RETURN/

EXIT O

Using the menu

1 Press AMP.

The receiver can be operated using the
remote.

AMP

GUI
MODE

V/v/b,

OPTIONS

MENU

Example: When you select “ Input”

4 Press V/v repeatedly to select

the menu item you want to
adjust, then press to enter
the menu item.

5 Repeat steps 3 and 4 to select

the parameter you want.

To return to the previous screen

Press RETURN/EXIT O.

To exit the menu

Press MENU.

2 Press MENU.

The menu is displayed on the TV screen.

continued

51

GB

To exit “GUI MODE”

Press GUI MODE. “GUI MODE OFF”
appears and you can operate the receiver
using the menu in the display window of
the receiver.

3 Press V/v repeatedly to select a

menu you want, then press
or b to enter the menu mode.

The menu item list appears on the TV
screen.

Overview of the main menus

Menu icon Description

Input Selects the input source

Music Selects the music from the

FM/AM/XM/
SIRIUS

Settings You can adjust the settings of

component connected to the
receiver (page 53).

audio component connected
to the DIGITAL MEDIA
PORT adapter (page 55).

Selects the built-in FM/AM
radio or satellite tuner
connected (page 60, 63).

the speakers, the surround
effect, equalizer, audio,
video and other inputs
connected to the HDMI jacks
(page 102).

Using the option menus

When you press OPTIONS, the option menus
for the selected main menu are displayed. You
can select a related function without
reselecting the menu.

1 Press AMP.

The receiver can be operated using the
remote.

2 Press MENU.

The menu is displayed on the TV screen.

Example: When you select “ Input”

4 Press OPTIONS while the menu

item list is displayed.

The option menu appears.

5 Press V/v repeatedly to select

the option menu item you want,
then press .

6 Press V/v repeatedly to select

the parameter you want, then
press .

To exit the menu

Press MENU.

52

GB

Playback

Enjoying sound/images
from the component
connected to the receiver

AMP

V/v/B/b,

OPTIONS

MENU

MASTER

VOL

MUTING

1

Press AMP.

The receiver can be operated using the
remote.

2 Press MENU.

The menu is displayed on the TV screen.

3 Press V/v repeatedly to select

“ Input,” then press or b.

The menu item list appears on the TV
screen.

4 Press V/v repeatedly to select

the component you want, then
press .

The menu screen disappears and the
playback screen of the external input
appears.

Selected input Components that

Video1,
Video2

BD Blu-ray Disc Player,

DVD DVD player, etc.,

SAT Satellite tuner, etc.,

TV TV connec ted to the TV

TAPE Tape deck, etc.,

MD MD deck, etc.,

SA-CD/CD Super Audio CD or CD

Phono Turntable, etc.,

MULTI IN Component connected

HDMI1, 2, 3,
4, 5, 6

can be used

VIDEO 1, 2 VCR, etc.,
connected to the
VIDEO 1 or VIDEO 2
jack.

etc., connected to the
BD jack.

connected to the DVD
jack.

connected to the SAT
jack.

jack.

connected to the TAPE
jack.

connected to the MD
jack.

player, etc., connected
to the SA-CD/CD jack.

connected to the
PHONO jack.

to the MULTI
CHANNEL INPUT
jack.

HDMI components
connected to the
HDMI1, HDMI2,
HDMI3, HDMI4,
HDMI5, or HDMI6 jack.

continued

53

Playback

GB

5 Turn on the component and

start playback.

6 Press MASTER VOL +/– to

adjust the volume.

Tips

• You can adjust the volume differently depending
on the speed with which you turn the MASTER
VOLUME knob.
To turn the volume up or down quickly: turn the
knob quickly.
To make fine adjustment: turn the knob slowly.

• You can adjust the volume differently depending
on the length of time you press and hold the
MASTER VOL +/– button on the remote.
To turn the volume up or down quickly: press and
hold the button.
To make a fine adjustment: press the button and
release it immediately.

4 Press V/v/B/b to select a

character one by one, then
press .

5 Press V/v/B/b to select

“Finish,” then press .

The name you entered is registered.

To cancel naming input

Press V/v/B/b to select “Cancel,” then
press .

Changing the display items (List
Mode)

When you select “ Input,” you can change
the items to be displayed.

To activate the muting function

Press MUTING on the remote. To cancel,
press MUTING on the remote again or press
MASTER VOL + to raise the volume.

To avoid damaging your
speakers

Before you turn off the receiver, be sure to turn
down the volume level.

Naming the input (Name Input)

You can enter a name of up to 8 characters for
inputs and display it.
This is convenient for labeling the jacks with
the names of the connected components.

1 Press V/v repeatedly on the

“ Input” screen to select the
input you want to name.

2 Press OPTIONS.

The option menu appears.

3 Press V/v repeatedly to select

“Name Input,” then press .

The soft keyboard appears on the screen.

1 Press V/v repeatedly on the

“ Input” screen to select the
input you want.

2 Press OPTIONS.

The option menu appears.

3 Press V/v repeatedly to select

“List Mode,” then press .

4 Press V/v repeatedly to select

the item you want to display,
then press .

• Input Assign
Input name and audio/video input jack
assigned to the input are displayed in a
list.

• Sound Field
Input name and the sound field selected
for the input are displayed in a list.

•A/V Sync
Input name and the delay set on the “A/
V Sync” menu for the input are
displayed in a list.

54

GB

Enjoying sound/images
from the components
connected to the DIGITAL
MEDIA PORT

The DIGITAL MEDIA PORT is for enjoying
sound/images from a portable audio source or
computer by connecting a DIGITAL MEDIA
PORT adapter.
Available DIGITAL MEDIA PORT adapters
vary in each area.
For details on connecting the DIGITAL
MEDIA PORT adapter, see “Connecting
components with digital audio input/output
jacks” (page 26).

Sony offers the following DIGITAL MEDIA
PORT adapters:

• TDM-BT1 Bluetooth™ Wireless Audio
Adapter

• TDM-NW1/NW10 DIGITAL MEDIA
PORT Adapter

• TDM-NC1 Wireless Network Audio Client

• TDM-iP1/iP10/iP50 DIGITAL MEDIA
PORT Adapter

• TPM-MP10 DIGITAL MEDIA PORT
Adapter

The DIGITAL MEDIA PORT adapter is an
optional product.

AMP

Playback

V/v/b,

MENU

MASTER

VOL

1 Press AMP.

The receiver can be operated using the
remote.

Notes

• Do not connect an adapter other than the DIGITAL

MEDIA PORT adapter.

• Before disconnecting t he DIGITAL MEDIA PORT

adapter, make sure to turn the receiver off using the
remote.

• Do not connect or disconnect the DIGITAL

MEDIA PORT adapter to/from the receiver while
the system is turned on.

• Depending on the type of DIGITAL MEDIA

PORT adapter, the images are also output.

2 Press MENU.

The menu is displayed on the TV screen.

3 Press V/v repeatedly to select

“ Music,” then press or b.

4 Press V/v repeatedly to select

“DMPORT,” or a component
connected to the DIGITAL
MEDIA PORT adapter, then
press .

continued

55

GB

The component connected to the
DIGITAL MEDIA PORT adapter is
recognized and “DMPORT” on the screen
will change to the respective component’s
name with an icon. If the adapter
connected cannot be recognized,
“DMPORT” is displayed on the TV
screen.

Icon Component that is

DMPORT

iPod The iPod model recognized

Network
Client

Bluetooth The Bluetooth drive

Mobile
Phone

connected

A component other than one
of the following is
connected.

is connected.
The Network Client

recognized is connected.

recognized is connected.
The Mobile Phone

recognized is connected.

5 Select a track you want to play

using the component
connected to the DIGITAL
MEDIA PORT adapter.

Operating the TDM-iP1/
iP50/TDM-NC1 using the
GUI menu of the receiver

Make sure that “System GUI” is selected in
step 4 in “Changing the operation screen using
the DIGITAL MEDIA PORT” (page 58).

AMP

V/v,

6 Press MASTER VOL +/– to

adjust the volume.

GB

56

OPTIONS

MENU

1 Press AMP.

The receiver can be operated using the
remote.

2 Press MENU.

The menu is displayed on the TV screen.

3 Press V/v repeatedly to select

“ Music,” then press .

4 Press V/v repeatedly to select

the component connected to
the DIGITAL MEDIA PORT
adapter you want to play, then
press .

The contents list appears.

5 Press V/v/B/b and to select

track from the track list.

In case of iPod

Music Playlists > Playlist > Track

Artists > Artist > Album > Track
Albums > Album > Track
Songs > Track
Genres > Genre > Artist > Album > Track
Composers > Composer > Album > Track
Audiobooks > Track

In case of Network Client

a)

Music Surfin’

> Albumc) > Track

a)

Playlist

> Playlist > Track
Web Radio
Music Library

a)

> Station > Program

b)

> Album > Track

2 Press OPTIONS.

The option menu appears.

3 Press V/v repeatedly to select

the playback mode you want
from the following.

x Shuffle (TDM-iP1/iP50 only)

Plays all the tracks in random order.

•Off
Deactivates the shuffle play mode.

•Albums
Plays all the tracks on an album in random
order.

• Songs
Plays all the tracks in “Songs” in random
order.

x Repeat (TDM-iP1/iP50 only)

Plays one or all the tracks repeatedly.

•Off
Deactivates the repeat play mode.

•One
Plays one track repeatedly.

•All
Plays all the tracks repeatedly.

Playback

a)

Displayed only when M-crew Server is
connected.

b)

Displayed only when a DLNA server other
than M-crew Server is connected.

c)

Displayed as “Genre,” “Artist” or “Album,”
depending on setting of “List Mode.”

6 Press MASTER VOL +/– to

adjust the volume.

Selecting the playback mode

1 Play back the track you want to

listen to following the steps
outlined in “Operating the TDM­iP1/iP50/TDM-NC1 using the
GUI menu of the receiver”
(page 56).

x List Mode (TDM-NC1 only)

Selects a range of tracks to be played back.

•Genre
Plays back tracks in the selected genre.

• Artist
Plays back tracks of the selected artist.

•Album
Plays back tracks in the selected album.

continued

57

GB

DIGITAL MEDIA PORT message
list

Message appears Explanation

No Adapter The adapter is not connected.
No Device There is no device connected

to the adapter.
No Audio No audio file was found.
Loading The data is being read.
No Server* There is no server connected.
No Track* No track was found.
No Item* No item was found.
Connecting* Connecting to the server.
Configuring* The network is setting up.
Warning* Check the display of the

DIGITAL MEDIA PORT

adapter.
Party Mode* The unit is currently in party

mode “Guest.”
Searching* Searching the server.

* TDM-NC1 only.

Changing the operation screen
using the DIGITAL MEDIA PORT

You can change the operation screen using the
GUI menu. The DMPORT Control mode is
supported by the DIGITAL MEDIA PORT
adapters like TDM-iP1/iP50, TDM-NC1. This
mode is not supported by other adapters.

1 Press V/v repeatedly on the

“ Music” screen to select the
DIGITAL MEDIA PORT adapter
you want, then press or b.

2 Press OPTIONS.

The option menu appears.

3 Press V/v to select “DMPORT

Control,” then press .

If “DMPORT Control” is not displayed,
see the operating instructions supplied
with component for details on operating
that component.

4 Press V/v repeatedly to select

the mode you want, then press

.

You can select the following modes in this
menu;

•System GUI
This mode is for the TDM-iP1/iP50 and
TDM-NC1. The list of tracks will be
displayed on the GUI screen of the
receiver. You can select a track you want
and play back it on each GUI screen.

• Adapter GUI
This mode is for the TDM-iP1/iP50 and
TDM-NC1. The menu of the adapter
will be displayed on the TV screen.

•iPod
This mode can be selected only when
the TDM-iP1/iP50 is connected.

58

GB

To operate the TDM-iP1/iP50 or
TDM-NC1 using the adapter
menu

Make sure that “Adapter GUI” is selected in
step 4 in “Changing the operation screen using
the DIGITAL MEDIA PORT” (page 58).
For details on operating the adapter using the
adapter GUI menu, refer to the operating
instructions supplied with the adapter you are
using.

To operate the TDM-iP1/iP50
using the iPod menu

Make sure that “iPod” is selected in step 4 in
“Changing the operation screen using the
DIGITAL MEDIA PORT” (page 58).
For details on operating the iPod, refer to the
operating instruction supplied with the iPod.

Playback

59

GB

Tuning

Tuning into a station
automatically (Auto Tuning)

Listening to FM/AM radio

You can listen to FM and AM broadcasts
through the built-in tuner. Before operation,
make sure you have connected the FM and
AM antennas (aerials) to the receiver
(page 39).

Tip

The tuning scale for direct tuning is shown below.

• FM band 100 kHz

• AM band 10 kHz

SHIFT

Numeric

buttons

The AM tuning scale can be changed
(page 61).

AMP

V/v/B/b,

OPTIONS

MENU

1 Press AMP.

The receiver can be operated using the
remote.

2 Press MENU.

The menu is displayed on the TV screen.

3 Press V/v repeatedly to select

“ FM” or “ AM,” then press

or b.

The FM or AM menu list appears on the
TV screen.

4 Press V/v to select “Auto

Tuning,” then press .

5 Press V/v.

Press V to scan from low to high, press v
to scan from high to low.
The receiver stops scanning whenever a
station is received.

In case of poor FM stereo
reception

Tune in the station you want to listen to

1

using Auto Tuning, Direct Tuning
(page 61), or select the preset station
you want (page 62).

2 Press OPTIONS.

The option menu appears.

3 Press V/v to select “FM Mode,” then

press .

4 Press V/v to select “MONO,” then

press .

60

GB

Tuning into a station directly
(Direct Tuning)

Enter the frequency of a station directly by
using the numeric buttons.

1 Press AMP.

The receiver can be operated using the
remote.

2 Press MENU.

The menu is displayed on the TV screen.

3 Press V/v repeatedly to select

“FM” or “AM,” then press

or b.

4 Press V/v to select “Direct

Tuning,” then press .

5 Press SHIFT, then press the

numeric buttons to enter the
frequency, then press .

Example 1: FM 102.50 MHz
Select 1 b 0 b 2 b 5
Example 2: AM 1,350 kHz
Select 1 b 3 b 5 b 0

Tip

If you have tuned in an AM station, adjust the
direction of the AM loop antenna (aerial) for
optimum reception.

Changing the AM tuning scale

You can change the AM tuning scale to either
9 kHz or 10 kHz on the receiver.

POWER

TUNING MODE

Tuning

1 Press POWER to turn off the

receiver.

2 While holding down TUNING

MODE, press POWER on the
receiver.

3 Change the current AM tuning

scale to 9 kHz (or 10 kHz).

To reset the scale to 10 kHz (or 9 kHz),
repeat the procedure above.

Note

All preset stations will be erased when you change
the tuning scale.

If you cannot tune in a station

“– – – .– – MHz” appears and then the display
returns to the current frequency.
Make sure you have entered the right
frequency. If not, repeat step 5. If you still
cannot tune in a station, the frequency is not
used in your area.

61

GB

Presetting FM/AM radio
stations

4 Press V/v to select a preset

number, then press .

The station is stored as the selected preset
number.

You can preset up to 30 FM and 30 AM
stations. Then you can easily tune in the
stations you often listen to.

AMP

V/v/B/b,

OPTIONS

MENU

1 Tune in the station that you

want to preset using Auto
Tuning (page 60) or Direct
Tuning (page 61).

In case of poor FM stereo reception,
switch the FM reception mode (page 60).

5 Repeat steps 1 to 4 to preset

another station.

You can store stations as follows:

• AM band: AM1 to AM30

• FM band: FM1 to FM30

Tuning to preset stations

1 Press AMP.

The receiver can be operated using the
remote.

2 Press MENU.

The menu is displayed on the TV screen.

3 Press V/v repeatedly to select

“ FM” or “ AM,” then press

or b.

4 Press V/v to select the preset

number station you want.

Preset numbers from 1 to 30 are available.

Naming preset stations (Name
Input)

1 On “ FM” or “ AM” screen,

press V/v to select the preset
number on which you have
stored the station and which
you want to name.

2 Press OPTIONS.

The option menu appears.

3 Press V/v to select “Memory,”

then press .

GB

62

2 Press OPTIONS.

The option menu appears.

3 Press V/v repeatedly to select

“Name Input,” then press .

The soft keyboard appears on the screen.

4 Press V/v/B/b to select a

character one by one, then
press .

5 Press V/v/B/b to select

“Finish,” then press .

The name you entered is registered.

Listening to satellite
radio

You can listen to XM Radio and SIRIUS
Satellite Radio by connecting a satellite tuner,
not supplied, to the receiver.

To cancel naming input

Press V/v/B/b to select “Cancel,” then
press .

XM Radio service

About XM Radio

XM is North America’s number one satellite
radio company, offering an extraordinary
variety of commercial-free music, plus the
best in premier sports, news, talk radio,
comedy, children’s and entertainment
programming, broadcast in superior digital
audio quality coast to coast. For more
information, or to subscribe, U.S. customers
visit xmradio.com or call XM Listener Care at
1-800-XMRADIO (1-800-967-2346);
Canadian customers visit xmradio.ca or call
XM Listener Care at 1-877-GETXMSR (1­877-438-9677).

XM Ready® Legal

XM monthly service subscription sold
separately. XM Mini-Tuner and Home Dock
required (each sold separately) to receive XM
service. It is prohibited to copy, decompile,
disassemble, reverse engineer, hack,
manipulate or otherwise make available any
technology or software incorporated in
receivers compatible with the XM satellite
Radio System. Installation costs and other fees
and taxes, including a one-time activation fee
may apply. All fees and programming subject
to change. Channels with frequent explicit
language are indicated with an XL. Channel
blocking is available for XM radio receivers by
calling 1-800-XMRADIO (U.S. residents) and
1-877-GETXMSR (Canadian residents). Only
available in the 48 contiguous United States
and Canada. ©2008 XM Satellite Radio Inc.
All rights reserved.

Tuning

continued

63

GB

XM Ready® Subscription

Once you have installed the XM Mini-Tuner
Home Dock, inserted the XM Mini-Tuner,
connected the XM Mini-Tuner Home Dock to
your XM Ready
the antenna, you are ready to subscribe and
begin receiving XM programming. There are
three places to find your eight character XM
Radio ID: On the XM Mini-Tuner, on the XM
Mini-Tuner package, and on XM Channel 0.
Record the Radio ID below for reference.

®

audio system, and installed

ssssssss

Note

The XM Radio ID does not use the letters “I”, “O”,
“S” or “F”.

Activate your XM Satellite Radio service in
the U.S. online at http://activate.xmradio.com
or call 1-800-XMRADIO (1-800-967-2346).
Activate your XM Satellite Radio service in
Canada online at https://activate.xmradio.ca or
call 1-877-GETXMSR (1-877-438-9677).
You will need a major credit card. XM will
send a signal from the satellites to activate the
full channel lineup. Activation normally takes
10-15 minutes, but during peak busy periods
you may need to keep your XM Ready audio
system on for up to an hour. When you can
access the full lineup on your XM Ready audio
system you are done.

Programming is subject to change. Visit
sirius.com or siriuscanada.ca for the most
complete and up-to-date channel lineup and
product information. “ SIRIUS” and the
SIRIUS dog logo and related marks are
trademarks of SIRIUS Satellite Radio Inc. All
rights reserved.

To Subscribe to SIRIUS Satellite
Radio

Purchase and connect a SiriusConnect Home
Tuner to your Sirius Ready home audio
system.
You are then ready to activate and subscribe to
Sirius by either calling 1.888.539.SIRIUS
(7474) or log on to sirius.com (US),
siriuscanada.ca (Canada). It is that easy.

SIRIUS Satellite Radio service

SIRIUS Satellite Radio: The Best
Radio On Radio

SIRIUS brings all your favorite entertainment
including 100% commercial-free music, plus
superior sports coverage, uncensored talk and
comedy, world-class entertainment, news,
weather and more for your car, home or office.
Sirius is available in the US for subscribers with
addresses in the continental US and is available
in Canada for subscribers with a Canadian
address. Required subscription plus compatible
SiriusConnect Home Tuner with antenna are
required and sold separately. SIRIUS

GB

64

Connecting a satellite

Preparing to listen to a

radio tuner

XM jackSIRIUS jack

To connect to the XM jack

Before operating the system, connect the XM
Mini-Tuner and Home Dock to the XM jack.

Note

To ensure optimal reception of XM’s satellite signal,
move your antenna to various window locations
around your home to see where the best reception
will be received. Most XM customers place the
antenna in a south-facing window with a clear view
to the sky.

To connect to the SIRIUS jack

Connect the SiriusConnect Home tuner. When
you use the SiriusConnect Home tuner with
this receiver, be sure to connect the AC power
adaptor supplied with the tuner to a wall outlet.
Keep the SiriusConnect Home tuner, antenna,
and AC power adaptor away from the speaker
cords and the power cord to avoid picking up
noise.

satellite radio

AMP

V/v/b,

OPTIONS

MENU

Checking the ID number

1

Press AMP.

The receiver can be operated using the
remote.

2 Press MENU.

The menu is displayed on the TV screen.

3 Press V/v repeatedly to select

“ XM” or “ SIRIUS,” then
press or b.

Tuning

continued

65

GB

4 Press V/v to select “ALL,” then

press or b.

When the Preset Mode screen is
displayed, change the tuning mode to
“Category Mode,” then select “ALL.”
Press OPTIONS, then press V/v
repeatedly to select “Category Mode.”

5 Press V/v to select the channel

0, then press .

6 Check the XM Radio ID or Sirius

ID on the TV screen and write it
in the space provided here.

XM Radio ID:_____________________
Sirius ID:_________________________

You can also check the XM Radio ID and
Sirius ID using the display on the
receiver.

Checking receiving conditions
(Antenna Aiming)

1 Press AMP.

The receiver can be operated using the
remote.

6 While checking the quality of

the reception, adjust the
direction of the antenna to
obtain the best reception.

To exit the menu

Press MENU.

2 Press MENU.

The menu is displayed on the TV screen.

3 Press V/v repeatedly to select

“ XM” or “ SIRIUS,” then
press or b.

4 Press OPTIONS.

The option menu appears.

5 Press V/v repeatedly to select

“Antenna Aiming,” then press

.

The Antenna Aiming screen appears.

GB

66

Selecting a channel of the
satellite radio

AMP

V/v/b,

5 Press V/v repeatedly to select

the category, then press .

• ALL: You can select a channel from all
the categories.

• (category name): You can select a
channel from one category.

When the “Preset Mode” screen is
displayed, press OPTIONS, then press V/
v repeatedly to select “Category Mode.”

6 Press V/v to select the channel,

then press .

The selected channel is being received.
The channel information is displayed on
the TV screen.

Note

When you select a channel in the “Category Mode,”
the channel you selected may not be the one in the
category you want. This is because one channel may
belong to more than one category.

Tuning

OPTIONS

MENU

Selecting a channel by category
(Category Mode)

You can select a channel from one category or
all the categories.

1 Press AMP.

The receiver can be operated using the
remote.

2 Press MENU.

The menu is displayed on the TV screen.

3 Press V/v repeatedly to select

“XM” or “SIRIUS,” then
press or b.

4 Press OPTIONS.

The option menu appears.

Selecting a channel by inputting
the channel number directly
(Direct Tuning)

1 Press AMP.

The receiver can be operated using the
remote.

2 Press MENU.

The menu is displayed on the TV screen.

3 Press V/v repeatedly to select

“ XM” or “ SIRIUS,” then
press or b.

4 Press OPTIONS.

The option menu appears.

5 Press V/v to select “Direct

Tuning,” then press .

6 Press the numeric buttons to

enter the channel number.

continued

67

GB

7 Press .

The selected channel is tune in.

Presetting satellite radio
channels

You can select the channels you want directly
by presetting them using the preset numbers.
You can preset up to 30 XM Radio channels
and 30 SIRIUS Satellite Radio channels.

AMP

V/v/b,

68

OPTIONS

MENU

1 Select a channel you want to

preset using Category Mode
(page 67) or Direct Tuning
(page 67).

2 Press OPTIONS.

The option menu appears.

3 Press V/v to select “Memory,”

then press .

The preset number selection screen
appears.

GB

4 Press V/v repeatedly to select

the preset number you want to
use as the preset channel, then
press .

Preset channels from 1 to 30 are available,
and a default channel is preset for all the
preset channels when you purchase the
receiver.
The selected channel is registered as the
preset channel you selected in step 1.

5 Repeat steps 1 to 4 to preset

another channel.

You can store channels from 1 to 30.

Selecting preset channels

Restricting access to
specific channels

(Parental Lock) (SIRIUS only)

You can restrict access to certain channels
using your own lock code. The lock code is set
to “0000” as the default.
Change the lock code before you use this
function for the first time. See “To change the
lock code (Lock Code)” (page 70).

Tuning

1 Press AMP.

The receiver can be operated using the
remote.

2 Press MENU.

The menu is displayed on the TV screen.

3 Press V/v repeatedly to select

“XM” or “SIRIUS,” then
press or b.

4 Press V/v to select the preset

number from the preset list,
then press .

You can select stored preset channels
from 1 to 30.

Notes

• The channel information you have preset may be
changed if XM Satellite Radio Inc. or SIRIUS
Satellite Radio Inc. change their channel
programming.

• When the “Category Mode” screen is displayed,
press OPTIONS, then press V/v to select “Preset
Mode.”

Numeric

buttons

V/v/b,

RETURN/

EXIT O

OPTIONS

1 Select a channel you want to

lock using Category Mode
(page 67) or Direct Tuning
(page 67).

2 Press OPTIONS.

The option menu appears.

3 Press V/v to select “Parental

Lock,” then press or b.

continued

69

GB

4 Press V/v repeatedly to select

“ON,” then press .

“Enter your 4-digit lock code.” appears.

2 Enter your 4-digit lock code using the

numeric buttons.

The channel is tuned in.

5 Enter your 4-digit lock code

using the numeric buttons.

“The channel has been locked.” appears
and the Parental Lock is set.
To delete the numbers you have entered,
go back to step 2 by pressing RETURN/
EXIT O, and then repeat the procedure
above from step 2.

To change the lock code (Lock
Code)

Select a channel you want to change

1

the lock code using Category Mode
(page 67) or Direct Tuning (page 67).

2 Press OPTIONS.

The option menu appears.

3 Press V/v to select “Lock Code,” then

press .

“Enter your 4-digit lock code.” appears.

4 Enter your 4-digit lock code using the

numeric buttons.

“Enter a new lock code.” appears.

5 Enter a new 4-digit lock code using the

numeric buttons.

“To confirm, enter your new lock code
again.” appears.

To cancel the Parental Lock

Select a channel you want to unlock

1

using Category Mode (page 67) or
Direct Tuning (page 67).

2 Press OPTIONS.

The option menu appears.

3 Press V/v to select “Parental Lock,”

then press or b.

4 Press V/v repeatedly to select “OFF,”

then press .

“Enter your 4-digit lock code.” appears.

5 Enter your 4-digit lock code using the

numeric buttons.

“The channel has been unlocked.” appears
and the channel is unlocked.

Notes

• When you select a channel using Category Mode,
locked channels are skipped.

• When the receiver is reset to the factory settings,
the lock code returns to the default (0000), but the
Parental Lock settings are not removed.

• You cannot preset locked channels. If you set the
Parental Lock for a preset channel, the preset
information for that channel returns to the default.

• You cannot set the Parental Lock for channel 0 or
channel 184.

6 Reenter the new lock code with the

numeric buttons.

“The lock code has been changed.”
appears.

To listen to the locked channels

Select a locked channel you want to

1

listen to using Category Mode
(page 67) or Direct Tuning (page 67).

“The channel is locked. Enter your 4-digit
lock code.” appears.

GB

70

Message list

SIRIUS Satellite Radio message list

Message
appears

Antenna Error The antenna is not connected properly. Check the connection between the SiriusConnect

Acquiring Signal The receiving condition is not good. Try moving the antenna to another location. For

Call 888-539­SIRI

Check Sirius
Tuner

Invalid Channel You have entered an invalid channel

Locked
Channel

Subscription
Updated

Updating
Channels
xx%
Completed
(xx are for
integers)

Firmware
Updating

––––– There is no text information in the

Explanation Remedies

Home tuner and the antenna.

details about the antenna location, see the
instructions supplied with the SiriusConnect
Home tuner.

You have not subscribed for the selected
channel.

The SiriusConnect Home tuner is not
connected properly.

number.

The selected channel is locked. —

The subscription information has been
updated.

Channel information is being updated. —

The SiriusConnect Home tuner
firmware is being updated.

channel.

—

Check all the connections, and then turn the
system on again. Also make sure if the AC adaptor
supplied with the SiriusConnect Home tuner is
connected to a wall socket.

The channel to be tuned-in is void due to the
change by the broadcast service, or the receiving
condition is not good.

—

—

This is not an error. The text information may not
be displayed depending on the system condition,
for example, right after the system has received a
channel.

Tuning

XM Radio message list

Message
appears

Check Antenna The XM antenna is not connected to the

Explanation Remedies

XM Mini-Tuner Dock or the XM
antenna cable is damaged.

Check that the XM antenna is securely connected
to the XM Mini-Tuner Dock and check the
antenna cable for damage.
Replace the XM antenna if the cable is damaged.

continued

71

GB

Message

Explanation Remedies

appears

CH Unauthorized You selected an XM channel that is

blocked or cannot be received with your
XM subscription package.

No Signal The XM Mini-Tuner is not receiving the

XM satellite signal. Something may be
blocking the XM antenna’s view of the
satellites or the antenna is not properly
aimed.

Loading The XM Mini-Tuner is acquiring audio

or program information from the XM
satellite signal. This message can also
occur in weak XM signal conditions.
Note that the receiver may not respond
to some buttons while this message is
displayed.

Off Air You selected an XM channel is not

currently broadcasting.

(space)–––– No artist name or song title is available

for this selection.

CH Unavailable The selected channel is not available.

The channel may have been reassigned
to a different channel number.
This message may occur initially with a
new radio or a radio that has not received
XM’s signal for an extended period.

Check XM Tuner The XM Mini-Tuner is not installed or

not fully seated in the XM Mini-Tuner
Dock or the XM Mini-Tuner dock is not
connected to the receiver.

Consult the latest channel guide at
www.xmradio.com for the current list of channels.
For information on receiving this channel, visit
www.xmradio.com or contact XM Satellite Radio
at 1-800-967-2346.

Check for antenna obstructions and reposition the
XM antenna to get better signal reception. Use the
Antenna Aiming option to optimize the antenna
position (page 66).
See instructions supplied with the XM Mini-Tuner
and Home Dock for antenna installation
information.

This message should disappear in a few seconds in
good signal conditions.
If you see this message often, reposition the XM
antenna for better signal reception.
Use the Antenna Aiming option to optimize the
antenna position (page 66).

Check back later; in the mean time, select another
channel.

No action required

Consult the latest channel guide at
www.xmradio.com for the current list of channels.
For cases of a new radio or a radio that has not
received XM’s signal for an extended period,
allow the radio to receive the XM satellite signal
for at least 5 minutes and then try to select the
channel again.

Confirm the XM Mini-Tuner is fully seated in the
dock and check the XM Mini-Tuner dock cable is
connected to the receiver.

72

GB

Enjoying Surround Sound

Playing back with 2-channel sound

You can switch the output sound to 2-channel sound regardless of the recording formats of the
software you are using, the playback component connected, or the sound field settings of the
receiver.

2CH/

A.DIRECT

Press 2CH/A.DIRECT repeatedly to select the 2-channel sound mode of the
sound output you want.

Enjoying Surround Sound

2CH mode Effect

2ch Stereo The receiver outputs the sound from the front left/right speakers only. There is

no sound from the subwoofer.
Standard 2 channel stereo sources completely bypass the soun d fi eld processing
and multi-channel surround formats are downmixed to 2 channel.

2ch Analog Direct You can switch the audio of the selected input to 2 channel analog input. This

function enables you to enjoy high quality analog sources.
When using this function, only the volume and front speaker balance can be
adjusted.

Note

No sound is output from the subwoofer in the 2ch
Stereo mode. To listen to 2 channel stereo sources
using the front left/right speakers and a subwoofer,
select “A.F.D. Auto.”
When you select “A.F.D. Auto,” the receiver will
generate a low frequency signal for output to the
subwoofer from a 2 channel signal, even if there is
no L.F.E. signal.

73

GB

Playing back with multi-channel surround

The Auto Format Direct (A.F.D.) mode allows you to listen to higher fidelity sound and select the
decoding mode for listening to a 2 channel stereo sound as multi-channel sound.

AMP

A.F.D.

V/v/b,

MENU

Press A.F.D. repeatedly to select the A.F.D. mode you want.

A.F.D. mode Multi-channel

A.F.D. Auto (Detecting

Multi Stereo (Multi Stereo) Outputs 2 channel left/right signals from all speakers.
Enhanced Surround – You can select the surround sound effect you want. For

GB

74

audio after
decoding

automatically)

Effect

Presets the sound as it was recorded/encoded without
adding any surround effects.

details on available surround sound effects and how to
set one, see “Setting a multi-channel surround sound
effect” (page 75).

Setting a multi-channel
surround sound effect

1 Start playing a sound source

you want to listen to (CD, DVD,
etc.).

2 Press AMP.

The receiver can be operated using the
remote.

3 Press MENU.

The menu is displayed on the TV screen.

4 Press V/v repeatedly to select

“ Settings,” then press or
b.

The Settings menu list appears on the TV
screen.

5 Press V/v repeatedly to select

“Surround,” then press or b.

6 Press V/v repeatedly to select

“Enhanced Sur Mode,” then
press .

The menu for surround sound effect
appears.

7 Press V/v repeatedly to select

the A.F.D. mode you want, then
press or b.

Enjoying Surround Sound

A.F.D. mode Multi-channel

audio after
decoding

PLII* 5-channel signals Performs Dolby Pro Logic II mode decoding. This

PLIIx* 7-channel signals Performs Dolby Pro Logic IIx mode decoding. This

Neo:6 Cinema 7-channel signals Performs DTS Neo:6 Cinema mode decoding.
Neo:6 Music 7-channel signals Performs DTS Neo:6 Music mode decoding. This setting

Neural-THX 7-channel signals Next generation of Neural-THX

* You can select “PLII” when there is no surround back speaker on the Speaker Pattern menu, or you can select

“PLIIx” when there is a surround back speaker. You cannot select both settings at the same time.

Effect

setting is ideal for movi es encoded in Dolby Surround. In
Addition, this mode can reproduce sound in 5.1 channel
system for watching videos of overdubbed or old
movies.

setting is ideal for movi es encoded in Dolby Surround. In
addition, this mode can reproduce sound in 7.1 channel
system for watching videos of overdubbed or old
movies.

is ideal for normal stereo sources such as CDs.

®

to stereo enhancement processing and pure discrete 5.1
surround sound, now capable of full 360° 7.1 surround
sound playback from Neural-THX
content.

Surround. In addition

®

Surround encoded

continued

75

GB

Notes

• This function does not work when the multi­channel input is selected.

• This function does not work when DTS-HD signals
with a sampling frequency of higher than 48 kHz
are being received.

• This function does not work when Dolby TrueHD
signals with a sampling frequency of higher than
96 kHz are being received.

• If you set up the sound field effect while the
receiver is receiving signals with a sampling
frequency of higher than 48 kHz, the signals will
always be played back at either 44.1 kHz or
48 kHz.

• If you set up the sound field during DTS 96/24
signal reception, the signal will be played back
only at 48 kHz.

• The beginning of the sound stream may be dropped
out when Neural-THX processing is turned on or
off.

Tips

• We usually recommend “A.F.D. Auto.”

• You can identify the encoding format of DVD
software, etc., by looking at the logo on the
package.

• Dolby Pro Logic IIx decoding is effective, when
2 channel or 5.1 channel signals are input.

• Neural-THX is effective when 2 channel or

5.1 channel signals are input.

76

GB

Enjoying a surround effect for music

You can take advantage of surround sound simply by selecting one of the receiver’s pre­programmed sound fields. They bring the exciting and powerful sound of concert halls into your
home.

MUSIC

Press MUSIC repeatedly to select the surround effect you want for music.

Sound field Effect

D.Concert Hall A Uses 3D sound imaging to reproduce the sou nd characteristics of a concert hall,

which simulates a large sound stage produced by reflectivity.

D.Concert Hall B Uses 3D sound imaging to reproduce the sound characteristics of a concert hall,

which simulates resonant and unique reverberative sound.
Jazz Club Reproduces the acoustics of a jazz club.
Live Concert Reproduces the acoustics of a 300-seat live house.
Stadium Reproduces the feeling of a large open-air stadium.
Sports Reproduces the feeling of sports broadcasting.
Portable Audio Reproduces a clear enhanced sound image from your portable audio device.

This mode is ideal for MP3 and other compressed music.

Enjoying Surround Sound

continued

77

GB

To listen to music through headphones connected to the receiver

Sound field Effect

Headphone (2ch) This mode is selected automatically if you use headphones when “2ch Stereo”

Headphone Theater DCS This mode is selected automatically when you use headphones when sound

Headphone (Direct) Outputs the analog signals without processing by the tone, sound field, etc.
Headphone (Multi) This mode is selected automatically if you use headphones when the multi-

mode or A.F.D. mode is selected. Standard 2 channel stereo sources completely
bypass the sound field processing and multi-channel surround formats are
downmixed to 2 channels.

field is selected for movie/music. It allows you to experience a theater-like
environment while listening through a pair of headphones.

channel input is selected. Outputs the front analog signals from the MULTI
CHANNEL INPUT jacks.

To turn off the surround effect for MUSIC

Press 2CH/A.DIRECT or A.F.D.

Notes

• The sound fields for music do not work when the
multi-channel input is selected.

• The sound fields for music do not work when DTS­HD signals with a sampling frequency of higher
than 48 kHz are being received.

• The sound fields for music do not work when
Dolby TrueHD signals with a sampling frequency
of higher than 96 kHz are being received.

• If you set up the sound field during DTS 96/24
signal reception, the signal will be played back
only at 48 kHz.

• If you set up the sound field effect while the
receiver is receiving signals with a sampling
frequency of higher than 48 kHz, the signals will
always be played back at either 44.1 kHz or
48 kHz.

• When one of the sound fields for music is selected,
no sound is output from the subwoofer if all the
speakers are set to “LARGE” in the Speaker
settings menu. However, the sound will be output
from the subwoofer if the digital input signal
contains L.F.E. signals, or if the front or surround
speakers are set to “SMALL,” the sound field for
movie is selected, or “Portable Audio” is selected.

78

GB

Enjoying a surround effect for movies

You can take advantage of surround sound simply by selecting one of the receiver’s pre­programmed sound fields. They bring the exciting and powerful sound of movie theaters into your
home.

MOVIE

Press MOVIE repeatedly to select the surround effect you want for movies.

Sound field Effect

Cinema Studio EX A

DCS

Cinema Studio EX B

DCS

Cinema Studio EX C

DCS

V.Multi Dimension

DCS

Reproduces the sound characteristics of the Sony Pictures Entertainment “Cary
Grant Theater” cinema production studio. This is a standard mode, great for
watching almost any type of movie.

Reproduces the sound characteristics of the Sony Pictures Entertainment “Kim
Novak Theater” cinema production studio. This mode is ideal for watching
science-fiction or action movies with lots of sound effects.

Reproduces the sound characteristics of the Sony Pictures Entertainment
scoring stage. This mode is ideal for watching musicals or films where
orchestra music is featured in the soundtrack.

Creates many virtual speakers from a single pair of actual surround speakers.

Enjoying Surround Sound

To turn off the surround effect for MOVIE

Press 2CH/A.DIRECT or A.F.D.

continued

79

GB

Notes

• The sound fields for movies do not work when the
multi-channel input is selected.

• The sound fields for movies do not work when
DTS-HD signals with a sampling frequency of
higher than 48 kHz are being received.

• The sound fields for movies do not work when
Dolby TrueHD signals with a sampling frequency
of higher than 96 kHz are being received.

• If you set up the sound field during DTS 96/24
signal reception, the signal will be played back
only at 48 kHz.

• If you set up the sound field effect while the
receiver is receiving signals with a sampling
frequency of higher than 48 kHz, the signals will
always be played back at either 44.1 kHz or
48 kHz.

• The effects provided by the virtual speakers may
cause increased noise in the playback signal.

• When listening with sound fields that employ the
virtual speakers, you will not be able to hear any
sound coming directly from the surround speakers.

Tips

• Sound fields with DCS marks use DCS
technology. See “Glossary” (page 132).

• When the sound field’s DCS mark is selected,
the Digital Cinema Sound lamp lights up on the
display.

80

GB

Digital audio formats supported by the receiver

Digital audio formats that this receiver can decode depend on digital audio input jacks for the
components connected.
This receiver supports the following audio formats.

Connection of the playback component and

the receiver

COAXIAL/OPTICAL HDMI

aa

Audio format

Dolby Digital

Maximum number

of channels

5.1ch

Dolby Digital EX

Dolby Digital Plus

Dolby TrueHD

a)

a)

DTS

DTS-ES

DTS 96/24

DTS-HD
High Resolution Audio

6.1ch

7.1ch

7.1ch

5.1ch

6.1ch

5.1ch

a)

7.1ch

aa

× a

× a

aa

aa

aa

× a

Enjoying Surround Sound

DTS-HD
Master Audio

a) b)

7.1ch

× a

continued

81

GB

DSD

Audio format

a)

Maximum number

of channels

5.1ch

Connection of the playback component and

the receiver

COAXIAL/OPTICAL HDMI

× a

Multi channel Linear PCM

a)

7.1ch

× a

a)Audio signals are output in another format if the playback component does not correspond to the format. For

details, refer to the operating instructions of the playback component.

b)Signals with a sampling frequency of higher than 96 kHz are played back at 96 kHz or 88.2 kHz.

82

GB

Using Multi-zone Features

What you can do with the
Multi-zone function

You can enjoy images and sounds from a
component connected to the receiver in a zone
(zone 2 or zone 3) other than the main zone.
For example, you can watch the DVD in the
main zone and listen to the CD in zone 2 or
zone 3.
When using an IR repeater (not supplied), you
can operate both a component in the main zone
and Sony receiver in zone 2 or zone 3 from
zone 2 or zone 3.

To operate the receiver from
zone 2 or zone 3

You can operate the receiver without pointing
the remote toward the IR repeater of the
receiver if you connect an IR repeater (not
supplied) to the IR REMOTE jack.
Use an IR repeater when you install the
receiver in a place where signals from the
remote cannot reach.

Using Multi-zone Features

83

GB

Making a multi-zone connection

1:Zone 2 connections

1 Outputs sound from speakers in zone 2 using the SURROUND

BACK SPEAKERS terminals of the receiver.

Main zone Zone 2

STR-DA4400ES

IR REMOTE IN

TV

monitor

A

ZONE 2 VIDEO

OUT*

SURROUND BACK

SPEAKERS

B

RM-AAL016

B

2 Outputs sound from speakers in zone 2 using the receiver and

another amplifier.

Main zone Zone 2

TV

monitor

C

A

IR REMOTE IN

ZONE 2 VIDEO OUT*

BB

STR-DA4400ES

ZONE 2 AUDIO OUT

A IR repeater (not supplied)
B Speakers
C Sony Amplifier/Receiver

* You can also connect to the COMPONENT VIDEO ZONE 2 OUT jack.

GB

84

RM-AAL016

2:Zone 3 connections

Main room Zone 3

BB

IR REMOTE IN

ZONE 3 AUDIO OUT

STR-DA4400ES

A IR repeater (not supplied)
B Speakers
C Sony Amplifier/Receiver

A

RM-AAL016

C

Using Multi-zone Features

85

GB

Setting the speakers in
zone 2

5 Press V/v to select “Speaker

Pattern,” to select the pattern
that has no surround back
speakers.

When the speakers in zone 2 are connected to
the SURROUND BACK SPEAKERS
terminals of the receiver (page 84), make the
setting so that the sound selected in zone 2 is
output from the speakers connected to the
SURROUND BACK SPEAKERS terminals.

AMP

V/v/b,

RETURN/

EXIT O

MENU

6 Press RETURN/EXIT O.
7 Press V/v repeatedly to select

“Sur Back Assign,” then press

.

8 Press V/v to select “ZONE2,”

then press .

To exit the menu

Press MENU.

1 Press AMP.

The receiver can be operated using the
remote.

2 Press MENU.

The menu is displayed on the TV screen.

3 Press V/v repeatedly to select

“ Settings,” then press or
b.

4 Press V/v repeatedly to select

“Speaker,” then press or b.

GB

86

Switching the zone

Operating the receiver

setting of the remote

The remote commanders are initially set to be
used in zone 2. If you want to use them in zone
3, switch the zone setting of the remote.

RM SET

UP

SHIFT

?/1

ZONE

2, 3

ENT/
MEM

1 Press ?/1 while pressing RM

SET UP.

The AMP and ZONE buttons flash.

2 Press ZONE.

The AMP button goes off, the ZONE
button keeps flashing and the SHIFT
button lights up.

from another zone

(ZONE 2/ZONE 3 operations)

The following operations are described for
connecting an IR repeater and operating the
receiver in zone 2 or zone 3. When an IR
repeater is not connected, use this receiver in
the main zone.

ZONE

?/1

Input
buttons

Using Multi-zone Features

3 Press the numeric button 2 for

the zone 2, or 3 for the zone 3
while the ZONE button is
flashing.

The ZONE button lights up.

4 Press ENT/MEM.

The ZONE button flashes twice and the
remote switches to zone 2 or zone 3
mode.

MASTER

VOL

1 Turn on the main receiver (this

receiver).

2 Turn on the amplifier in zone 2

or zone 3.

continued

87

GB

3 Press ZONE.

The remote switches to zone 2 or zone 3.
Change the zone setting of the remote to
zone 3 in advance (page 87).

4 Press ?/1.

The zone function is activated.

5 Press one of the input buttons

on the remote to select the
source signals you want to
output.

For zone 2, analog video and audio
signals are output. For the zone 3, only
analog audio signals are output. When
you select SOURCE, the signals of the
current input of the main zone are output.

6 Adjust to a suitable volume.

• In the case of illustration 1-1
(page 84), adjust the volume using
MASTER VOL +/– on the remote.

• In the case of illustration 1-2 (page 84)
or 2 (page 85), adjust the volume using
the receiver of zone 2 or zone 3.

To finish the zone 2/zone 3
operation

Press ?/1 after pressing ZONE.

Tips

• Even when this receiver is standby mode (press

?/1 on the remote to turned off this receiver), the
receiver in zone 2 or zone 3 remains turned on. To
turn off all receivers, press ?/1 and AV ?/1 on the
main remote at the same time (SYSTEM
STANDBY).

• Only signals from components connected to the
analog input jacks are output through the ZONE 2
or ZONE 3 jacks. No signals are output from
components connected to only the digital input
jacks.

• When SOURCE is selected, the signals input to the
MULTI CHANNEL INPUT jacks are not output
from the ZONE 2 OUT or ZONE 3 OUT jacks
even when the multi-channel input is selected. The
analog audio signals of the current function are
output.

GB

88

Using Other Features

Using “BRAVIA” Sync
features

We recommend that you connect the receiver
to products featuring “BRAVIA” Sync.

Note

Depending on the connected component, the
Control for HDMI function may not work. See the
operating instructions of the component.

What is “BRAVIA” Sync?

“BRAVIA” Sync is compatible with a Sony
TV, Blu-ray Disc/DVD player, AV amplifier,
etc., that is equipped with the Control for
HDMI function.
By connecting Sony components that are
compatible with the “BRAVIA” Sync with a
HDMI cable (not supplied), operation is
simplified as below:

• One-Touch Play: When you play back a
component such as a DVD/Blu-ray Disc
Player, the receiver and the TV are turned on
automatically and switch to the appropriate
HDMI input.

• System Audio Control: While watching TV,
you can select to output the sound from the
TV speaker or the speakers connected to the
receiver.

• System Power Off: When you turn off the
TV, the receiver and connected components
are also turned off simultaneously.

Control for HDMI is a mutual control function
standard used by HDMI CEC (Consumer
Electronics Control) for HDMI (High­Definition Multimedia Interface).

The Control for HDMI function
does not work in the following
cases:

• When you connect the receiver to a
component which is not correspond with
Sony’s Control for HDMI function.

• When you connect the receiver and
components using other than HDMI
connection.

Preparing for the “BRAVIA”
Sync

To use the “BRAVIA” Sync, turn the Control
for HDMI function on for both the receiver
and the connected component. The receiver is
compatible with the “Control for HDMI-Easy
Setting” function.

When your TV is compatible
with the “Control for HDMI-Easy
Setting” function

When you connect a Sony TV with the
“Control for HDMI-Easy Setting” function,
the Control for HDMI function of the receiver
can be turned on simultaneously by turning the
Control for HDMI function of the TV on.

1 Make sure that the receiver, TV, and

playback components are connected
using an HDMI cable (not supplied).
(The respective components must be
compatible with the Control for HDMI
function.)

2 Turn on the receiver, TV and playback

components.

3 Turn the Control for HDMI function of

the TV on.

The Control for HDMI function of the
receiver and all the connected components
are simultaneously turned on. During
setup, “SCANNING” appears in the
display window of the receiver, and once
setting is completed, “COMPLETE” will
appear. Wait until the setup is complete.

For details on setup of the TV, refer to the
operating instructions of your TV.

Using Other Features

continued

89

GB

Notes

• When you pull out the HDMI cable or change the
connection, perform the steps given in “When your
TV is compatible with the “Control for HDMI­Easy Setting” function” (page 89) or “When your
TV is not compatible with the “Control for HDMI­Easy Setting” function.”

• When you assign the component video input to the
HDMI input using the Input Assign function, you
cannot set “Control for HDMI” to “ON.”

• While “Control for HDMI-Easy Setting” is being
set, you cannot use functions such as One-Touch
Play or System Audio Control.

• When you set up the receiver using the “Control for
HDMI-Easy Setting” from a TV, turn on the TV,
the receiver and the playback components
beforehand.

• When you set up the receiver using the “Control for
HDMI-Easy Setting” from a TV, before you make
the “Control for HDMI-Easy Setting” function
effective, make the Control for HDMI function of
the components that are not compatible with the
“Control for HDMI-Easy Setting” function
effective.

When your TV is not compatible
with the “Control for HDMI-Easy
Setting” function

Turn the Control for HDMI function of the
receiver and the connected component on
individually.

?/1

AMP

HDMI
input
buttons

GUI
MODE

V/v/b,

MENU

90

1 Perform the steps given in “When your

TV is compatible with the “Control for
HDMI-Easy Setting” function”
(page 89).

2 Press AMP.

The receiver can be operated using the
remote.

3 Press MENU.

The menu is displayed on the TV screen.

4 Press V/v repeatedly to select

“ Settings,” then press or b.

5 Press V/v repeatedly to select “HDMI,”

then press or b.

6 Press V/v repeatedly to select “Control

for HDMI,” then press or b.

GB

7 Press V/v repeatedly to select “ON,”

then press .

The Control for HDMI function of the
receiver is activated.

8 Press GUI MODE to exit the GUI menu.

If the GUI menu is displayed, the Control
for HDMI function of the playback
components will not work properly.

9 Press one of the HDMI input buttons to

display the image of the playback
components for which you want to set
the Control for HDMI function.

10Turn the Control for HDMI function of

the connected component on.

For details on setting the connected
component, refer to its operating
instructions.

11Repeat steps 9 and 10 to set the

Control for HDMI function and to
display the image of all the playback
components you want to use.

Playing back components with
one-touch operation (One-Touch
Play)

By a simple operation (one-touch),
components connected to the receiver with
HDMI connections start automatically.
You can enjoy the sound/image using
connected components.

Play back a connected component.

The receiver and TV are turned on
simultaneously, and sound and image are
output from the receiver and TV.

Note

Depending on the TV, the start of the content may
not be output.

Enjoying the TV sound from the
speakers connected to the
receiver (System Audio Control)

You can enjoy the TV sound from the speakers
connected to the receiver by a simple
operation.
Depending on the TV settings, while you are
watching the TV, the receiver turns on and
switches to the “TV” function automatically.
TV sound is output from the speakers
connected to the receiver, and the volume of
the TV is minimized simultaneously.
You can use the System Audio Control
function as follows.

• The sound of the TV is output from the
speakers connected to the receiver when you
turn the receiver on while the sound is being
output from the TV speaker.

• You can adjust the receiver’s volume when
you adjust the TV volume.

You can also operate this function using the
TV menu. For details, see the operating
instructions of the TV.

Notes

• When “Control for HDMI” is set to “ON,” the

“Audio Out” settings in the HDMI settings menu
will set automatically depending on the System
Audio Control settings.

• When you connect a TV that does not have System

Audio Control function, the System Audio Control
function does not work.

• If the TV is turned on before turning on the

receiver, the TV sound will not be output for a
moment.

Turning off the receiver with the
TV (System Power Off)

When you turn the TV off by using the power
button on the TV’s remote, the receiver and
the connected components turn off
automatically.
You can also use the receiver’s remote to turn
off the TV.

Using Other Features

continued

91

GB

AV ?/1

Switching between

TV

Press TV, then press AV ?/1.

The TV, receiver and connected components
are turned off.

Notes

• Set the TV power supply interlock function to on
before using the System Power Off function. For
details, see the operating instructions of the TV.

• Depending on the status, the connected
components may not be turned off. For details, see
the operating instructions of the connected
components.

digital and analog audio

When you connect components to both digital
and analog audio input jacks on the receiver,
you can fix the audio input mode to either of
them, or switch from one to the other,
depending on the type of material you intend
to watch.

AMP

Input
buttons

92

INPUT
MODE

GB

1 Press the input button.

You can also use INPUT SELECTOR on
the receiver.

2 Press AMP.
3 Press INPUT MODE repeatedly

to select the audio input mode.

The selected audio input mode appears on
the TV screen.

•Auto
Gives priority to digital audio signals
when there are both digital and analog
connections.
If there are no digital audio signals,
analog audio signals are selected.

•Analog
Specifies the analog audio signals input
to the AUDIO IN (L/R) jacks.

Notes

• Some audio input modes may not be set up
depending on the input.

• When either HDMI input, satellite tuner or
DIGITAL MEDIA PORT adapter is selected,
“------” appears on the display, and you cannot
select other modes. Select an input mode other than
the HDMI input, satellite tuner and DIGITAL
MEDIA PORT adapter then set the audio input
mode.

• When “2ch Analog Direct” is being used, or the
multi-channel input is selected, audio input is set to
“Analog.” You cannot select other modes.

Enjoying the sound/
images from other inputs

(Input Assign)

You can reassign video and/or audio signals to
another input.
Example) Connect the OPTICAL OUT jack of
the DVD player to the OPTICAL VIDEO 1 IN
jack of this receiver when you want to input
the only digital optical audio signals from the
DVD player.
Connect the component video jack of the DVD
player to the COMPONENT VIDEO IN 1/
COMPONENT VIDEO IN 2, or
COMPONENT VIDEO IN 3 jack of this
receiver when you want to input the video
signals from the DVD player. Assign video
and/or audio signals to the DVD input jack
using “Input Assign” in the Input menu.

AMP

Using Other Features

V/v/B/b,

OPTIONS

MENU

continued

93

GB

1 Press AMP.

The receiver can be operated using the
remote.

2 Press MENU.

The menu is displayed on the TV screen.

3 Press V/v repeatedly to select

“ Input,” then press or b.

4 Press V/v to select the input

name you want to assign.

5 Press OPTIONS.

The option menu appears.

6 Press V/v to select “Input

Assign,” then press .

7 Press V/v/B/b to select the

audio and/or video signals you
want to assign to the input
selected in step 4, then press

.

94

GB

Input name

VIDEO1 VIDEO2 BD DVD SAT TAPE MD SA-CD/CDMULTI INHDMI1 HDMI2 HDMI3 HDMI4 HDMI5 HDMI6

Assignable
video input
jacks

Video1
Composite

Video2

a)

a

––––––– –––––––

a)

– a

–––––– –––––––

Composite

BD

––a ––––– –––––––

Composite

DVD

–––a –––– –––––––

Composite

SAT

––––a ––– –––––––

Composite

Component1

Component2

Component3

aaaa)aaaa a a ab)ab)ab)ab)ab)a

aaaaa)aaa a a ab)ab)ab)ab)ab)a

aaaaaa)aa a a ab)ab)ab)ab)ab)a

HDMI1 aaaaaaaaaaa)–––––

a)

HDMI2 aaaaaaaaa– a

HDMI3 aaaaaaaaa––a

HDMI4 aaaaaaaaa–––a

HDMI5 aaaaaaaaa––––a

––––

a)

–––

a)

––

a)

HDMI6 aaaaaaaaa–––––a

Assignable
audio input
jacks

Video1
OPT

Video2

a)

a

– aa –––a –––––––

a)

– a

aa –––a –––––––

OPT

SAT OPT – – aaa

Tape OPT – – aa – a

MD OPT – – aa ––a

BD COAX aaa

DVD

aa– a

a)

a)

––a –––––––

a)

– a –––––––

a)

a –––––––

– aaa – –––––––

a)

aaa ––––––––

COAX

SA-CD/CD

aa––a aaa

a)

–––––––

COAX

a)

Initial setting

b)

When you assign a component video input to the HDMI input via the Input Assign menu, component video
signals are not converted to HDMI video signals and are not output from the HDMI OUT jack. Component
video signals are output from the COMPONENT VIDEO MONITOR OUT jack. In this case, the resolution
of the GUI output is set to “480p” for both component video input and HDMI video input.

Notes

• You cannot assign optical signals from an input
source to the optical input jacks on the receiver, and
you cannot assign coaxial signals from the input
source to the coaxial input jacks on the receiver.

• When you assign the digital audio input, the

• You cannot reassign more than one digital audio
input to the same input.

• You cannot reassign more than one component
video input to the same input.

• When you assign a component video input to the
HDMI input, set “Control for HDMI” to “OFF.”

INPUT MODE setting may change automatically.

• You cannot reassign more than one HDMI input to
the same input.

b)

b)

b)

–

a)

Using Other Features

95

GB

Using the sleep timer

Enjoying the surround

You can set the receiver to turn off
automatically at a specified time.

SLEEP

Press SLEEP repeatedly.

Each time you press SLEEP, the display
changes cyclically as follows:

When sleep timer is being used, “SLEEP”
lights up in the display window of the receiver.

Tip

To check the remaining time before the receiver
turns off, press SLEEP. The remaining time appears
on the display. If you press SLEEP again, the sleep
timer will be changed.

effect at low volume
levels

This function allows you to retain a theater like
environment at low volume levels. This
function can be used with other sound fields.
When watching a movie late at night, you will
be able to hear the dialog clearly even at a low
volume level.

AMP

NIGHT
MODE

1 Press AMP.

The receiver can be operated using the
remote.

2 Press NIGHT MODE.

The NIGHT MODE function is activated.
The NIGHT MODE is set to on and off as
you press NIGHT MODE.

96

Notes

• This function does not work when the multi­channel input is selected.

• This function does not work when Dolby TrueHD
signals with a sampling frequency of higher than
96 kHz are being received.

GB

• If the NIGHT MODE function is turned on while
the receiver is receiving signals with a sampling
frequency of higher than 96 kHz, the signals will
always be played back at either 44.1 kHz or
48 kHz.

Tip

While this function is on, the Bass, Treble, and
Effect Levels increase, and “D. Range Comp” is
automatically set to “MAX.”

Recording using the
receiver

You can record from a video/audio component
using the receiver. Refer to the operating
instructions supplied with your recording
component.

Input
buttons

Using Other Features

Recording onto a MiniDisc or
audio tape

You can record onto a MiniDisc or audio tape
using the receiver. See the operating
instructions supplied with your MD deck or
tape deck.

1 Press the input button of the

playback component.

2 Prepare the playback

component for playing.

For example, insert a CD into the CD
player.

3 Prepare the recording

component.

Insert a blank MD or tape into the
recording deck and adjust the recording
level.

continued

97

GB

4 Start recording on the

recording deck, then start
playback on the playback
component.

Notes

• Sound adjustments do not affect the signal output
from the MD OUT jacks.

• The audio input signals from the MULTI
CHANNEL INPUT jacks are not output.

To record digital sound

Connect a component for playback to the
digital audio input (OPTICAL IN) jack, and
connect the recording component to the
OPTICAL MD OUT jack.

Recording onto recording media

1 Press the input button of the

playback component.

2 Prepare the component for

playing.

For example, insert the video tape you
want to copy into the VCR.

• Only digital input signals are output from the
digital output jack (for recording).

• HDMI sound cannot be recorded.

3 Prepare the recording

component.

Insert a blank video tape, etc., into the
recording component (VIDEO 1) for
recording.

4 Start recording on the

recording component, then
start playback on the playback
component.

Notes

• Some sources contain copy guards to prevent
recording. In this case, you may not be able to
record from the sources.

• The audio input signals from the MULTI
CHANNEL INPUT jacks are not output.

• Only analog input signals are output from the
analog output jack (for recording).

GB

98

Switching the command
mode of the receiver and
the remote

You can switch the command mode
(COMMAND MODE AV 1 or COMMAND
MODE AV 2) of the receiver and the remote.
Switch the command mode from the initial
setting to the appropriate setting, if other Sony
component is operated accidentally by the
same remote, when you are operating the
receiver using the remote supplied with the
receiver.
The command modes of both the receiver and
the remote are those of the initial setting
(COMMAND MODE AV 2).
The receiver and the remote, on the contrary,
should use the same command mode. If the
command modes of the receiver and the
remote are different, you cannot use the
remote to operate the receiver.

Switching the command mode of
the receiver

2CH/A.DIRECT

Switching the command mode of
the main remote commander

RM SET

UP

SHIFT

1, 2

?/1

AMP

ZONE

ENT/
MEM

1 Press ?/1 while pressing RM

SET UP.

The AMP and ZONE buttons flash.

2 Press AMP.

The ZONE button goes off, the AMP
button keeps flashing and the SHIFT
button lights up.

3 Press the numeric button 1 or 2

while the AMP button is
flashing.

When you press 1, the command mode is
set to AV SYSTEM 1. When you press 2,
the command mode is set to AV SYSTEM

2.
The AMP button lights up.

Using Other Features

Turn on the receiver while pressing
2CH/A.DIRECT.

When the command mode is set to “AV2,”
“COMMAND MODE [AV2]” appears on the
display.
When the command mode is set to “AV1,”
“COMMAND MODE [AV1]” appears on the
display.

4 Press ENT/MEM.

The AMP button flashes twice, then the
command mode setting process is
completed.

99

GB

Switching the command mode of
the sub remote commander

DISPLAY

Using a bi-amplifier
connection

If you are not using surround back speakers,
you can use the SURROUND BACK
SPEAKERS terminals for the front speakers
for use with a bi-amplifier connection.

To connect speakers

MUTING

Press MUTING and at the same
time while pressing DISPLAY.

Front speaker

(R)

Hi

Lo

Connect the jacks on the Lo (or Hi) side of the
front speakers to the FRONT SPEAKERS A
terminals, and connect the jacks on the Hi (or
Lo) side of the front speakers to the
SURROUND BACK SPEAKERS terminals.
Make sure that metal fittings of Hi/Lo attached
to the speakers have been removed from the
speakers. Not doing so may cause a
malfunction of the receiver.

Front speaker

(L)

Hi

Lo

100

To set up speakers

Press AMP.

1

The receiver can be operated using the
remote.

2 Press MENU.

The menu is displayed on the TV screen.

GB
