SRG-300SE
Full HD PTZ Remote Camera
30x
Optical
Zoom
SRG-300SE
Delivering New Value in a Remote Camera
•IP H.264 full HD 1080/60p video and AAC audio streaming
•Simultaneous transmission of 3G-SDI and H.264 full HDvideo
•Two-way audio input interfaces
•Web-viewing function for remote camera control
IP H.264 Full HD 1080/60p Video and AAC Audio Streaming
The SRG-300SE supports an IP network interface to transmit H.264 full HD video and
AAC audio streaming.* This is useful, for example, in a remote learning application –
streaming content from the camera can be shared remotely with multiple audience
members over an IP network, both in real time and as on-demand content.
* No audio is supported with 3G-SDI baseband.
Local site
IP streaming
SRG-300SE
Recorder
Remote site
Simultaneous Transmission of 3G-SDI and IP H.264 Full HD Video
The two-way output interfaces can be used simultaneously, and serve different
purposes:
3G-SDI
1080/60p Baseband video
IP
1080/60p H.264 video
Two-way audio input interfaces
The SRG-300SE is equipped with two-way audio input interfaces: an external LINE
input and a MIC input.*1 The LINE input allows users to connect an audio mixer for
a mid-to-large sized classroom. The MIC input allows users to connect an optional
microphone*2 for a smaller classroom. In addition, users can connect a simple
external audio effect equalizer over the IP network – this achieves clearer speaker
output by effectively cutting specific audio ranges.
*1 The LINE and MIC are selectable.
*2 Sony PCS-A1 and SCA-M30 microphones are recommended.
Simple audio
Effect equalizer
MIC input
LINE input
Web-viewing Function for Remote Camera Control
Up to 20 clients can view streaming video.*
The web-viewing function allows users to
intuitively control the SRG-300SE camera
via the IP network.
* Up to 10 clients can receive video and audio
combined streaming.
2
Other Features and Benefits Applications
30x High Power Zoom
The SRG-300SE provides up to a 30x optical zoom and 12x digital zoom. Therefore,
this camera can capture a wide viewing range, and is ideal for large meeting
rooms and auditoriums.
30x Optical
Zoom
Wide-end Tele-end
* Simulated images
View-DR & XDNR™ Technology
View-DR technology optimizes the brightness of each pixel to highlight shadows,
while subduing areas of the image that are too bright, allowing operation in lessthan-ideal lighting conditions.
XDNR technology reduces noise and provides clear images of both moving and
still objects under low light conditions.
The perfect choice for an expandable lecture capture
application
The 3G-SDI baseband and IP H.264
simultaneous streaming capabilities
are very useful. 3G-SDI baseband
video is suitable for local video
archiving in broadcast quality.
H.264 compressed video is easily
transmitted over the IP network.
By combining IP server systems for transmission and recording over the IP network,
users can build a perfect lecture capture system for in-house corporate training
and for educational applications.
RTP/RTCP protocols for audio and video optimized streaming
Audio and video can be naturally reproduced with optimally minimized processing
latency. Accurate audio/video synchronization is achieved using the camera's
time stamp in the network-attached recorder.
Remote site
SRG-300SE
Local site
3G-SDI
RTSP
LINE input
Recorder
Without View-DR function With View-DR function
Simulated images
XDNR image
Up to 256 camera preset positions*
Users can preset up to 256 camera positions using a plug-in free viewer and
ActiveX viewer.
* Position number from 17th to 256th are stored PTZF only.
Recorder
Open design concept for easy system integration
This remote camera incorporates the RTSP (real-time streaming protocol), and its
open design gives access to the widest range of partner and system integrator
options.
Wide range of applications
The SRG-300SE is ideal for small venues such as houses of worship, large
classrooms, and much more.
3
Specications
Camera
Image Sensor 1/2.8 Exmor CMOS
Image Sensor (Number of Effective Pixels) Approx. 2.1 Megapixels
Signal System 1080/59.94p(A/B),50p(A/B),29.97p,25p
Minimum Illumination (50 IRE) 1.4 lux (F1.6, highsensitivitymode OFF, 30fps)
S/N Ratio 50 dB
Gain Auto/Manual (0 to +43 dB)
Shutter Speed 1/1 to 1/10000 sec(59.94 Hz system)
Exposure Control Auto, Manual, Priority AE(Shutter,Iris), Exposure
White Balance Auto, Indoor, Outdoor, One-push auto, ATW,Manual
Optifal Zoom 30x
Digital Zoom 12x
Focusing System Auto/Manual
Horizontal Viewing Angle 63.7 degree(Wide)
Focal Length f=4.3mm(wide) to 129 mm(Tele)
Minimum Object Distance 10 mm(Wide)~1200 mm(Tele)
Pan/Tilt Angle Pan: ±170° Tilt: +90°/-20°
Pan/Tilt Speed (Max.) Pan 100°/sec Tilt 90°/sec
Preset Position 256 (position number from 17th to 256th are stored
Camera Features
Day/Night ICR Yes
Wide Dynamic Range Yes (View-DR)
Noise Reduction Yes
Image Stabilization Yes
Image Flip Yes
Superimpose Number 3 independent positions for characters (Codec, Date &
Superimpose Language English
Menu Language English, Japanese,Chinese (simplied),
Smartphone viewer Yes (not support audio transmission)
Video
Resolution 1920 x 1080, 1280 x 720,1024 x 576, 720 x 576,
Compression Format H.264, JPEG
Maximum Frame Rate H.264: 60 fps (1920 x 1080)
Bitrate Compression Mode CBR/VBR (selectable)
Range of Bitrate Setting 64 Kbps to 32 Mbps
1080/59.94i,50i,720/59.94p,50p,29.97p,25p
2.8 lux (F1.6, highsensitivitymode OFF, 60fps)
0.35 lux (F1.6, highsensitivitymode ON, 30fps)
0.7 lux (F1.6, highsensitivitymode ON, 60fps)
1/1 to 1/10000 sec(50Hz system)
compensation, Blight
F1.6 to 4.7
PTZF only)
Time, Event, Text (Max. 64 characters)),
1 independent position for a logo mark
Chinese (traditional), French,Spanish, German,
Italian,Korean, Portuguese, Russian,Arabic, Hindi,
Vietnamese,Thai
*OSD menu support only English.
720 x 480, 704 x 576,640 x 480, 640 x 360,
352 x 288, 320 x 184(H.264, JPEG)
JPEG: 30 fps (1920 x 1080)
Image Cropping No
Adaptive Rate Control H.264
Bandwidth Control JPEG
Multi Streaming Capability Triple streaming
Number of Clients 20 (Up to 10 clients can receive video and audio
Audio
Compression Format AAC-LC (64 kbps/128 kbps)
System Requirements
Operating System Mac OS (Plug-in free viewer only)
Processor Intel Corei7 2.8 GHz <
Memory 2 GB <
Web Browser Microsoft Internet Explorer Ver. 8.0, Ver. 9.0, Ver 10.0,
Network
Protocols IPv4, TCP, UDP, ARP, ICMP, IGMP, HTTP, DHCP, DNS,
QoS DiffServ (DSCP)
Multicast Streaming Support Yes
ONVIF Conformance No
Wireless Network No
Authenticatoin IEEE802.1X
Interface
HD Video Output 3G-SDI (No audio is supported)
SD Video Output MIC Input Mini jack (Monaural): 2.5 V DC plug-in power
LINE Input RCA (Monaural)
Network Port 10BASE-T /100BASE-TX (RJ-45)
Serial Interface RS-422
General
Power Requirements DC 12V (DC 10.8 V to 13.2 V)
Power Consumption 16.8 W
Operating Temperature 0 °C to 40 °C, 32 °F to 104 °F
Storage Temperature -20 °C to +60 °C, -4 °F to +140 °F
Dimensions (W x H x D)*1 157 x 164 x 163mm, 6 1/4 × 6 1/2 × 6 1/2 inches
Mass 1.4 kg, 3 lb 1.4 oz
Body Color White/Black
Wide Conversion Lens Attachable No
Mountable Angle <±15°
Ceiling Mount Ye s
Supplied Accessories AC power adaptor (1), AC power cable (1)
*1 The values for dimensions are approximate.
combined streaming)
Android/ iOS (Smart phone viewer only)
Windows Vista (32 bit) Ultimate,Business Edition
Windows 7 (32/64 bit) Ultimate, Professional Edition
Windows 8 Pro (32/64 bit), Microsoft DirectX 9.0c <
Ver 11.0, Firefox Ver. 19.02 (Plug-in free viewer only)
Safari Ver. 5.1 (Plug-in free viewer only)
Google Chrome Ver. 25.0 (Plug-in free viewer only)
No audio is output if the Plug-in free viewer is used.
NTP, RTP/RTCP,RTSP over TCP, RTSP over HTTP, IPv6,
HTTPS,SNMP (v1, v2c, v3), SSL
Ceiling bracket (2), RS-422 connector plug (1)
Wire rope(1), Screw M3 x 8(8)
Peripheral Equipment
RS-422 serial VISCA control
RM-IP10
• Comfortable P/T/Z operation with the optical
three-axis joystick
• Versatile camera adjustment by simple panel
operation
REAR PANEL
Dimensions
