Sony PM0960 User Manual

Draft

User guide

Xperia™ E5

F3311/F3313

Getting started...............................................................................	6
About this User guide........................................................................	6
Overview............................................................................................	6
Assembly...........................................................................................	7
Screen protection..............................................................................	8
Starting your device for the first time.................................................	8
Why do I need a Google™ account?.................................................	8
Charging your device.........................................................................	9

Device security.............................................................................	11
Making sure your device is protected..............................................	11
Screen lock......................................................................................	11
Unlocking your device automatically...............................................	13
SIM card protection.........................................................................	17
Finding the identification number of your device.............................	17
Finding a lost device .......................................................................	18

Learning the basics......................................................................	20
Using the touchscreen.....................................................................	20
Locking and unlocking the screen...................................................	21
Home screen....................................................................................	22
Application screen...........................................................................	23
Navigating applications....................................................................	24
Widgets............................................................................................	25
Shortcuts and folders......................................................................	25
Background and themes..................................................................	26
Battery and power management.....................................................	27
Taking a screenshot.........................................................................	28
Notifications.....................................................................................	29
Icons in the status bar.....................................................................	31
Applications overview......................................................................	33

Downloading applications............................................................	34
Downloading applications from Google Play™...............................	34
Downloading applications from other sources................................	34
Internet and networks..................................................................	35
Browsing the web............................................................................	35
Internet and MMS settings ..............................................................	35
Wi-Fi®..............................................................................................	36
Sharing your mobile data connection..............................................	37
Controlling data usage.....................................................................	39
Selecting mobile networks...............................................................	40
2

This is an Internet version of this publication. © Print only for private use.

Virtual private networks (VPNs)........................................................

Synchronising data on your device..............................................	42
Synchronising with online accounts................................................	42
Synchronising with Microsoft® Exchange ActiveSync®.................	42
Basic settings...............................................................................	44
Accessing settings...........................................................................	44
Sound volume and settings.............................................................	44
Do not disturb mode........................................................................	45
Screen settings................................................................................	46
Application settings.........................................................................	47
Resetting your applications.............................................................	48
Daydream.........................................................................................	49
Language settings............................................................................	49
Date and time...................................................................................	49
Enhancing the sound output............................................................	50
Multiple user accounts.....................................................................	50
Typing text...................................................................................	53
On-screen keyboard........................................................................	53
Phonepad.........................................................................................	54
Entering text using voice input........................................................	55
Editing text.......................................................................................	55
Personalising the on-screen keyboard............................................	55
Calling..........................................................................................	57
Making calls.....................................................................................	57
Receiving calls.................................................................................	58
Ongoing calls...................................................................................	60
Using the call log.............................................................................	60
Forwarding calls...............................................................................	61
Restricting calls................................................................................	61
Multiple calls....................................................................................	62
Conference calls..............................................................................	62
Voicemail..........................................................................................	63
Emergency calls...............................................................................	63
Contacts.......................................................................................	64
Transferring contacts.......................................................................	64
Searching and viewing contacts......................................................	65
Adding and editing contacts............................................................	66
Adding medical and emergency contact information......................	67
Favourites and groups.....................................................................	68
Sending contact information............................................................	69
Avoiding duplicate entries in the Contacts application...................	69
Backing up contacts........................................................................	69
3

This is an Internet version of this publication. © Print only for private use.

Messaging and chat.....................................................................	71
Reading and sending messages......................................................	71
Organising your messages..............................................................	72
Calling from a message...................................................................	72
Messaging settings..........................................................................	73
Instant messaging and video chat...................................................	73

Email.............................................................................................	74
Setting up email...............................................................................	74
Sending and receiving email messages..........................................	74
Organising your email messages.....................................................	75
Email account settings.....................................................................	76
Gmail™............................................................................................	77

Music............................................................................................	78
Transferring music to your device...................................................	78
Listening to music............................................................................	78
Music home screen menu................................................................	79
Playlists............................................................................................	80
Sharing music..................................................................................	81
Enhancing the sound.......................................................................	81

FM radio.......................................................................................	82
Listening to the radio.......................................................................	82
Favourite radio channels..................................................................	83
Sound settings.................................................................................	83

Camera.........................................................................................	84
Taking photos and recording videos...............................................	84
Adding geographical positions to your photos................................	85
General camera settings..................................................................	85
Still camera settings.........................................................................	87
Video camera settings.....................................................................	90

Photos and videos in Album........................................................	92
Viewing photos and videos..............................................................	92
Sharing and managing photos and videos......................................	93
Editing photos with the Photo editor application.............................	94
Editing videos with the Video editor application..............................	94
Hiding photos and videos................................................................	95
Album home screen menu...............................................................	95
Viewing your photos on a map........................................................	96

Videos..........................................................................................	98
The Video application......................................................................	98
Transferring video content to your device.......................................	99
Managing video content..................................................................	99
4

This is an Internet version of this publication. © Print only for private use.

Connectivity...............................................................................	100
Sharing content with DLNA Certified™ devices............................	100
NFC................................................................................................	101
Bluetooth® wireless technology....................................................	103
Travel and maps.........................................................................	106
Using location services..................................................................	106
Google Maps™ and navigation.....................................................	106
Using data traffic when travelling..................................................	106
Airplane mode................................................................................	107
Calendar and alarm clock..........................................................	108
Calendar.........................................................................................	108
Alarm and clock.............................................................................	108
Accessibility...............................................................................	111
Magnification gestures...................................................................	111
Large text.......................................................................................	111
Colour correction...........................................................................	111
TalkBack........................................................................................	111
Support and maintenance..........................................................	113
Support for your device.................................................................	113
Computer tools..............................................................................	113
Updating your device.....................................................................	113
Memory and storage......................................................................	115
Managing files using a computer...................................................	116
Backing up and restoring content.................................................	116
Running diagnostic tests on your device.......................................	119
Restarting and resetting your device.............................................	119
Warranty, SAR and usage guidelines............................................	121
Limitations to services and features..............................................	121
Legal information...........................................................................	121

This is an Internet version of this publication. © Print only for private use.

Getting started

About this User guide

This is the Xperia™ E5 User guide for the Android™ 6.0 software version. If you're not sure which software version your device is running, you can check it in the

Settings menu. For more information about software updates, see Updating your device on page 113.

To check the current software version of your device

1	From your Home screen, tap .
2	Find and tap Settings > About phone > Android™ version.

Overview

This is an Internet version of this publication. © Print only for private use.

1.	Charging/Notification light	11.	Main camera lens
2.	Headset jack	12.	Main camera light
3.	Proximity/Light sensor	13.	Second microphone
4.	Ear speaker	14.	Nano SIM/Memory card slot cover
5.	Front camera lens	15.	NFC™ detection area

6.Volume/Zoom key

7.Power key

8.Main loudspeaker

9.Charger/USB cable port

10.Wi-Fi/Bluetooth/GPS antenna area

Assembly

Your device only supports nano SIM cards.

To insert the nano SIM card

Your device only supports nano SIM cards. Make sure you use the nano SIM card holder and don’t confuse the nano SIM card slot with the memory card slot.

1Open the cover for the nano SIM and memory card slots.

2Using a fingernail or other similar object, drag out the nano SIM card holder.

3Place the nano SIM card in the holder, then re-insert the holder.

4Close the cover.

If you insert a nano SIM card while the device is powered on, the device restarts automatically.

To insert a memory card

1Open the cover for the nano SIM card and memory card slots.

2Place the memory card in the memory card slot, then push the memory card all the way into the slot until you hear a clicking sound.

3Close the cover.

Make sure you insert the memory card in the correct orientation.

To remove the nano SIM card

1Open the cover for the nano SIM card and memory card slots.

2Using a fingernail or other similar object, drag out the nano SIM card holder.

3Remove the nano SIM card, then re-insert the holder.

4Close the cover.

To remove the memory card

This is an Internet version of this publication. © Print only for private use.

1Either turn off the device, or unmount the memory card under Settings >

Storage & memory > > Advanced > Storage > next to SD card, then open the cover for the nano SIM card and memory card slots.

2Press the memory card inwards and then release it quickly.

3Drag out the memory card fully and remove it.

4Close the cover.

Screen protection

Before using your device, remove the transparent protection film by pulling up on the protruding tab.

It is recommended to protect your device with a Sony branded screen cover or a protector intended for your Xperia™ model. The use of third party screen protection accessories may prevent your device from working correctly by covering sensors, lenses, speakers, or microphones and can invalidate the warranty.

Starting your device for the first time

The first time you start your device, a setup guide opens to help you configure basic settings, sign in to some accounts and personalise your device. For example, if you have a Google™ account, you can sign in to it here and get set up straight away.

To turn on the device

Make sure that the battery is charged for at least 30 minutes before you turn on the device for the first time.

1Press and hold down the power key until the device vibrates.

2Enter your SIM card PIN when requested, then tap .

3Wait a while for the device to start.

Your SIM card PIN is initially supplied by your network operator, but you can change it later from the Settings menu. To correct a mistake made while entering your SIM card PIN, tap .

To turn off the device

1 Press and hold down the power key until the options menu opens.

2 In the options menu, tap Power off.

It may take a while for the device to shut down.

Why do I need a Google™ account?

Your Xperia™ device from Sony runs on the Android™ platform developed by Google™. A range of Google™ applications and services is available on your device when you purchase it, for example, Gmail™, Google Maps™, YouTube™ and the Play Store™ application, which gives you access to the Google Play™ online store for downloading Android™ applications. To get the most out of these services, you

This is an Internet version of this publication. © Print only for private use.

need a Google™ account. For example, a Google™ account is mandatory if you want to:

•Download and install applications from Google Play™.

•Synchronise email, contacts and the calendar using Gmail™.

•Chat with friends using the Hangouts™ application.

•Synchronise your browsing history and bookmarks using the Google Chrome™ web browser.

•Identify yourself as the authorised user after a software repair using Xperia™ Companion.

•Remotely find, lock or clear a lost or stolen device using the my Xperia™ or

Android™ Device Manager services.

For more information about Android™ and Google™, go to http://support.google.com.

It is crucial that you remember your Google™ account username and password. In some situations, you may need to identify yourself for security reasons using your Google™ account. If you fail to give your Google™ username and password in such situations, your device is locked. Also, if you have more than one Google™ account, make sure to enter the details for the relevant account.

To set up a Google™ account on your device 1 From your Home screen, tap .

2Find and tap Settings > Account sync > Add account > Google.

3Follow the registration wizard to create a Google™ account, or sign in if you already have an account.

You can also sign in to or create a Google™ account from the setup guide the first time you start your device. Or you can go online and create an account at www.google.com/accounts.

To remove a Google™ account 1 From your Home screen, tap .

2Tap Settings > Account sync > Google.

3Select the Google™ account that you want to remove.

4Tap > Remove account.

5Tap Remove account again to confirm.

If you remove your Google™ account, any security features that are linked to your Google™ account will no longer be available.

If you are lending your device to someone to use for an extended period, it is recommended that you remove your Google™ account from the device.

Charging your device

Your device has an embedded, rechargeable battery that should be replaced only by Sony or an authorised Sony repair centre. You should never try to open or take apart the device yourself. Opening the device can cause damage that voids your warranty.

The battery is partly charged when the device is shipped from the factory. Depending on how long your device was in the box before you purchased it, the battery level may be quite low. It is therefore recommended that you charge the battery for at least 30 minutes before starting up your device for the first time. You can still use your device while it is charging. To read more about how to improve the battery performance, see Battery and power management on page 27.

This is an Internet version of this publication. © Print only for private use.

To charge your device

1Plug the charger into a power outlet.

2Plug one end of the USB cable into the charger (or into the USB port of a computer).

3Plug the other end of the cable into the micro USB port on your device, with the USB symbol facing up. The notification light illuminates when charging begins.

4When the device is fully charged, disconnect the cable from your device by pulling it straight outwards. Make sure not to bend the connector.

If the battery is completely discharged, it may take a few minutes before the notification light illuminates and the charging icon appears.

Battery notification light status

Green	The battery is charging and the battery charge level is greater than 90%

Red	The battery is charging and the battery charge level is less than 15%

Orange	The battery is charging and the battery charge level is less than 90%

This is an Internet version of this publication. © Print only for private use.

Device security

Making sure your device is protected

You can prevent other people from using your device without your permission. For example, if your device is lost, stolen, or wiped, only someone with your Google™ account or screen lock information can use the device. To make sure that your device is protected, it is important that you set a secure screen lock and add your Google™ account on your device. It is crucial that you remember both your screen lock information and your Google™ account credentials. To make sure your device is protected, you can:

•Set a secure screen lock on your device, that is, a PIN, password, or pattern screen lock to prevent anyone from resetting your device. For more information, see Screen lock on page 11.

•Add a Google™ account to prevent others from using your device if it gets stolen and/or wiped. For more information, see Why do I need a Google™ account? on page 8.

•Activate either the “Protection by my Xperia” or the Android™ Device Manager web service. Using one of these services, you can remotely locate, lock or erase a lost device. For more information, see Finding a lost device on page 18 .

Verifying the ownership of your device

When your device is protected, you need to either unlock your screen with your PIN, password, pattern, or enter your Google™ account information depending on the protection features you are using. Below are examples of protection features and some of the required credentials:

Factory Data Reset	You must unlock your screen before you are allowed to perform a Factory Data
protection	Reset.
Protection by my	If you remotely reset your device using this service, you must enter the
Xperia	username and password for a Google™ account associated with the service.
	The device must be connected to the Internet before the setup process can be
	completed. Otherwise, you will not be able to use your device after the reset.
Android™ Device	If you remotely reset your device using this service, you must enter the
Manager	username and password for a Google™ account. The device must be connected
	to the Internet before the setup process can be completed. Otherwise, you will
	not be able to use your device after the reset.
Software repair	If you use the Xperia™ Companion software to perform a software repair, you’re
	asked to enter your Google™ account username and password when you start
	the device after the repair is complete.

For Android™ Device Manager, it is necessary to enter information from a Google™ account. This can be any Google™ account which you have set up on the device. If you cannot provide the relevant account information during a setup process, you won't be able to use the device at all.

Screen lock

Fingerprint functionality is not available in the US market.

There are several ways to unlock the screen. The security level of each lock type is listed below in order of weakest to strongest:

•Swipe – no protection, but you have quick access to the Home screen.

•Pattern – draw a simple pattern with your finger to unlock your device.

•PIN – enter a numeric PIN of at least four digits to unlock your device.

This is an Internet version of this publication. © Print only for private use.

•Password – enter an alpha-numeric password to unlock your device.

It is very important that you remember your screen unlock pattern, PIN or password. If you forget this information, it may not be possible to restore important data such as contacts and messages.

If you have set up a Microsoft® Exchange ActiveSync® (EAS) account on your Xperia™ device, the EAS security settings may limit the lock screen type to only a PIN or password. This occurs when your network administrator specifies a specific lock screen type for all EAS accounts for enterprise security reasons. Contact the network administrator of your company or organisation to check what network security policies are implemented for mobile devices.

To create a screen lock pattern 1 From your Home screen, tap .

2Find and tap Settings > Lock screen & security > Screen lock > Pattern.

3Follow the instructions on your device.

	If you enter an incorrect lock pattern five times in a row, you must wait 30 seconds before
	trying again.
	To change screen lock type
1	From your Home screen, tap .
2	Find and tap Settings > Lock screen & security .
	To change the screen lock pattern
1	From your Home screen, tap .

2Find and tap Settings> Lock screen & security > Screen lock.

3Draw your screen unlock pattern.

4Tap Pattern and follow the instructions on your device.

To create a screen lock PIN

1 From your Home screen, tap .

2Find and tap Settings > Lock screen & security > Screen lock > PIN.

3Enter a numeric PIN, then tap Continue.

4Re-enter and confirm your PIN, then tap OK.

To create a screen lock password 1 From your Home screen, tap .

2Find and tap Settings > Lock screen & security > Screen lock > Password.

3Enter a password, then tap Continue.

4Re-enter and confirm your password, then tap OK.

To activate the Swipe unlock function 1 From your Home screen, tap .

2Find and tap Settings > Lock screen & security > Screen lock.

3Draw your screen unlock pattern, or enter your PIN or password depending on which of these screen lock types is enabled.

4Tap Swipe.

Resetting a forgotten screen lock

If you’ve forgotten your screen lock PIN, password or pattern, you might be able to reset it using the Protection by my Xperia service. No content on your device is lost after you have performed a screen lock reset using the Protection by my Xperia service.

To activate the Protection by my Xperia service, see Finding a lost device on page 18.

This is an Internet version of this publication. © Print only for private use.

To reset the screen lock using Protection by my Xperia

1Make sure you know your Google™ account username and password and that you have enabled the Protection by my Xperia service on your device.

2Go to myxperia.sonymobile.com using any Internet-connected device.

3Sign in using the same Google™ account that you have set up on your device.

4Click the picture of your device under Your devices.

5Select Lock or Change PIN2 to replace the current screen lock with a new PIN code.

6Follow the on-screen instructions provided by Protection by my Xperia.

Depending on your security settings, your device may lock after a screen lock reset. You then need to enter your Google™ account username and password in order to use the device.

Unlocking your device automatically

The Smart Lock feature makes unlocking your device easier by letting you set it to unlock automatically in certain situations. You can keep your device unlocked, for example, when it’s connected to a Bluetooth® device or when you’re carrying it with you.

To prepare your device to unlock automatically, you first need to perform the following steps in the order given:

•Make sure you have an active Internet connection, preferably a Wi-Fi® connection to limit data traffic charges.

•Make sure that all your apps are updated using the Play Store™ application in order to ensure that the Google Play™ services app is updated. Having an up-to-date Google Play™ services app ensures that you can use the latest Smart Lock features.

•Enable Smart Lock.

•Set when you want your device to unlock automatically.

The Smart Lock feature is developed by Google™ and the exact functionality may change over time due to updates from Google™.

The Smart Lock feature may not be available in every market, country or region.

To enable Smart Lock

1Make sure that you’ve set a pattern, PIN or password for your screen lock.

2From your Home screen, tap .

3Find and tap Settings > Lock screen & security > Trust agents.

4Drag the slider beside Smart Lock (Google) to the right.

5Tap the back arrow next to Trust agents.

6Find and tap Smart Lock.

7Enter your pattern, PIN or password. You need to enter this screen lock any time you want to change your Smart Lock settings.

8Select a Smart Lock type.

Setting when to keep the device automatically unlocked

You can set Smart Lock to keep your device unlocked using the following settings:

•Trusted devices — Keep your device unlocked when a trusted Bluetooth® or NFC device is connected.

•Trusted places — Keep your device unlocked when you're in a trusted location.

•On-body detection — Keep your device unlocked when you're carrying your device with you.

•Trusted face —Unlock your phone by looking at it.

•Trusted voice — Set up voice recognition to search in any screen.

You have to manually unlock your device when you don't use it for 4 hours and after you restart it.

This is an Internet version of this publication. © Print only for private use.

Connecting to trusted Bluetooth® devices

You can designate a connected Bluetooth® device as a trusted device and keep your

Xperia™ device unlocked while it’s connected to it. So if you have Bluetooth® devices that you connect to regularly, for example, a car speaker or home entertainment system, a Bluetooth® watch or a fitness tracker, you can add them as trusted devices and bypass the added security of the lockscreen to save time. This feature is suitable if you’re normally in a relatively secure place when you use these devices. In some cases, you may still need to manually unlock your device before a trusted device can be connected.

It is not recommended to add devices that are constantly connected to your device as trusted devices, for example, Bluetooth® keyboards or cases.

As soon as a trusted Bluetooth® device is switched off or moves out of range, your screen locks and you need your PIN, pattern or password to unlock it.

To add a trusted Bluetooth® device

1Make sure your device is paired and connected to the Bluetooth® device that you want to add as a trusted device.

2In the Smart Lock menu, tap Trusted devices.

3Tap Add trusted device > Bluetooth.

4Tap a device name to select it from the list of connected devices. Only paired devices appear in this list.

5Depending on the security of your connection, you may need to manually unlock your device before the trusted device can keep it unlocked.

To remove a trusted Bluetooth® device 1 From your Home screen, tap .

2Find and tap Settings > Lock screen & security > Smart Lock > Trusted devices.

3Tap the device that you want to remove.

4Tap Remove trusted device.

Making sure you're secure when using trusted devices

Different Bluetooth® devices support different Bluetooth® standards and security capabilities. There's a possibility that someone could keep your Xperia™ device unlocked by imitating your Bluetooth® connection, even if your trusted device is no longer nearby. Your device is not always able to determine whether your connection is secure from someone trying to imitate it.

When your device can't determine that you're using a secure connection, you'll get a notification on your Xperia™ device and may need to manually unlock it before the trusted device can keep it unlocked.

Bluetooth® connectivity range can vary depending on factors like the model of your device, the connected Bluetooth® device, and your environment. Depending on these factors, Bluetooth® connections can work over distances up to 100 meters. If someone takes your Xperia™ device while it's near a trusted device, they may be able to access your Xperia™ device if the trusted device has unlocked it.

Connecting to trusted places

When the Trusted places feature is set up, the lock screen security on your Xperia™ device gets disabled when you are in a designated trusted location. For this feature to work, you must have an Internet connection (preferably over Wi-Fi®) and allow your device to use your current location.

To set up trusted places, first make sure that high accuracy location mode or batterysaving location mode is enabled on your device before you add home or custom locations.

The exact dimensions of a trusted location are an estimate and may extend beyond the physical walls of your home or other area that you have added as a trusted location. This

This is an Internet version of this publication. © Print only for private use.

feature can keep your device unlocked within a radius of up to 80 meters. Also be aware that location signals can be replicated or manipulated. Someone with access to specialised equipment could unlock your device.

To add your home location

1Make sure location is turned on and that you are using either the High accuracy or Battery saving Location mode setting.

2 From your Home screen, tap .

3Find and tap Settings > Lock screen & security > Smart Lock > Trusted places > Home.

4Tap Turn on this location.

To edit your home location

1Make sure location mode is turned on and that you are using either the High accuracy or Battery saving setting.

2 From your Home screen, tap .

3Find and tap Settings > Lock screen & security > Smart Lock > Trusted places.

4Select your home location.

5Tap Edit.

6In the search bar, enter the location that you want to use as your home location.

If other residences share your street address, you can add the actual location of your home within the building complex as a custom place.

To remove your home location

1Make sure location mode is turned on and that you are using either the High accuracy or Battery saving setting.

2 From your Home screen, tap .

3Find and tap Settings > Lock screen & security > Smart Lock > Trusted places > Home.

4Tap Turn off this location.

Using custom locations

You can add any location as a trusted, custom place where your device can remain unlocked.

To add a custom place

1Make sure location mode is turned on and that you are using either the High accuracy or Battery saving setting.

2 From your Home screen, tap .

3Find and tap Settings > Lock screen & security > Smart Lock > Trusted places.

4Tap Add trusted place.

5To use your current location as a trusted, custom place, tap Select this location.

6Alternatively, to enter another location, tap the magnification glass icon and type the address. Your device searches for the entered location. To use the suggested address, tap the address.

7To fine-tune the location, tap the back arrow next to the address, drag the location pin to the desired location, then tap Select this location.

This is an Internet version of this publication. © Print only for private use.

To edit a custom place

1Make sure location mode is turned on and that you are using either the High accuracy or Battery saving setting.

2From your Home screen, tap .

3Find and tap Settings > Lock screen & security > Smart Lock > Trusted places.

4Select the place that you want to edit.

5Tap Edit address.

6To enter another location, tap the magnification glass icon and type the address. Your device searches for the entered location. To use the suggested address, tap the address.

7To fine-tune the location, tap the back arrow next to the address, then drag the location pin to the desired location, then tap Select this location.

To remove a custom place

1Make sure location mode is turned on and that you are using either the High accuracy or Battery saving setting.

2 From your Home screen, tap .

3Find and tap Settings > Lock screen & security > Smart Lock > Trusted places.

4Select the place that you want to remove.

5Tap Delete.

Keeping your device unlocked while you’re carrying it

Using the On-body detection feature, you can have your device stay unlocked when you have it on you, for example, if you're carrying it in your hand, pocket or bag. The accelerometer in your device keeps your device unlocked when it senses that it's being carried. The device locks when the accelerometer detects that the device has been put down.

The On-body detection feature can't distinguish whose body is connected. If you give your device to someone else while it's unlocked using On-body detection, your device may stay unlocked for the other user. Keep in mind that On-body detection as a security feature is less secure than a pattern, PIN, or password.

To enable On-body detection

1 From your Home screen, tap .

2Find and tap Settings > Lock screen & security > Smart Lock > On-body detection.

3Drag the slider beside Off to the right, then tap Continue.

Using On-body detection

When you use the On-body detection feature, you need to be aware of the following behaviours:

•When your device senses that it's on your body, it stays unlocked after you unlock it.

•Any time you put your device down and it senses that it's no longer on your body, your device locks automatically.

•After you put your device down, for example, if you place it on a table, your device can take up to one minute to lock.

•After you get into a car, bus, train or other land vehicles, your device can take between 5 and 10 minutes to lock.

•Note that when you get on an airplane or a boat (or other non-land based vehicles), your device may not lock automatically, so make sure to lock it manually if needed.

•When you pick up your device again or get out of the vehicle, just unlock it once and your device then stays unlocked for as long as you have it on you.

To turn off On-body detection

1 From your Home screen, tap .

2Find and tap Settings > Lock screen & security > Smart Lock > On-body detection.

3Drag the slider beside On to the left.

This is an Internet version of this publication. © Print only for private use.

SIM card protection

You can lock and unlock each SIM card that you use in your device with a PIN

(Personal Identification Number). When a SIM card is locked, the subscription linked to the card is protected against misuse, meaning that you have to enter a PIN every time you start your device.

If you enter the PIN incorrectly more times than the maximum number of attempts allowed, your SIM card will become blocked. You then need to enter your PUK

(Personal Unblocking Key) and a new PIN. Your PIN and PUK are supplied by your network operator.

To set up a SIM card lock

1 From the Home screen, tap .

2Find and tap Settings > Lock screen & security > Set up SIM card lock.

3Drag the slider beside Lock SIM card to the right.

4Enter the SIM card PIN and tap OK. The SIM card lock is now active and you will be prompted to enter this lock every time you restart the device.

To remove a SIM card lock

1 From the Home screen, tap .

2Find and tap Settings > Lock screen & security > Set up SIM card lock.

3Drag the slider beside Lock SIM card to the left.

4Enter the SIM card PIN and tap OK.

To change the SIM card PIN 1 From the Home screen, tap .

2Find and tap Settings > Lock screen & security > Set up SIM card lock.

3Tap Change SIM PIN.

4Enter the old SIM card PIN and tap OK.

5Enter the new SIM card PIN and tap OK.

6Re-type the new SIM card PIN and tap OK.

To unlock a blocked SIM card using the PUK code

1Enter the PUK code and tap .

2Enter a new PIN code and tap .

3Re-enter the new PIN code and tap .

If you enter an incorrect PUK code too many times, you need to contact your network operator to get a new SIM card.

Finding the identification number of your device

Your device has a unique ID (identification) number. In your device, this number is referred to as the IMEI (International Mobile Equipment Identity). You should keep a copy of this number. You may require it, for example, when you access the Xperia™

Care support service and need to register your device. Also, if your device is stolen, some network providers can use this number to stop the device from accessing the network in your country.

To view your IMEI number via the device settings

1	From your Home screen, tap .
2	Find and tap Settings > About phone > Status > IMEI information.

This is an Internet version of this publication. © Print only for private use.

Finding a lost device

If you have a Google™ account, the “Protection by my Xperia” web service can help you locate and secure your device if you ever lose it. If you have activated this service on your device, you can:

•Locate your device on a map.

•Sound an alert even if the device is in Do not disturb mode.

•Remotely lock the device and make the device display your contact details to anyone who finds it.

•Remotely clear the internal and external memory of the device as a last resort.

The “Protection by my Xperia” service may not be available in all countries or regions.

If you’ve cleared the internal memory of the device using the “Protection by my Xperia” web service, you must sign in to a Google™ account that was previously synced on this device the next time you turn on the device.

To activate Protection by my Xperia

1Make sure you have an active data connection, and enable location services on your device.

2 From your Home screen, tap .

3Find and tap Settings > Lock screen & security > Protection by my Xperia > Activate.

4Mark the checkbox to agree to the terms and conditions of the service, then tap Accept.

5If prompted, sign in to your Google™ account, or create a new account if you don’t already have one.

To verify that Protection by my Xperia can locate your device, go to myxperia.sonymobile.com and sign in using the Google™ account that you are using on your device.

If you are sharing a device with multiple users, note that the Protection by my Xperia service is only available to the user who is logged in as the owner.

Finding a lost device using Android™ Device Manager

Google™ offers a location and security web service called Android™ Device Manager. You can use it in parallel with, or as an alternative to, the my Xperia service.

If you lose your device, you can use Android™ Device Manager to:

•Find and show where your device is located.

•Ring or lock your device, erase everything on it, or add a phone number to the lock screen.

For additional information about Android™ Device Manager, go to www.support.google.com.

Android™ Device Manager does not work if your device is turned off or if it does not have a connection to the Internet. The Android™ Device Manager service may not be available in all countries or regions.

This is an Internet version of this publication. © Print only for private use.

To activate Android™ Device Manager

1If you are sharing a device with multiple users, make sure that you are logged in as the owner.

2Make sure that you have an active data connection and that location services are enabled.

3 From your Home screen, tap .

4Find and tap Google Settings > Lock screen & security .

5Drag the sliders beside Remotely locate this device and Allow remote lock and erase to the right.

6If prompted, agree to the terms and conditions by tapping Activate.

7To verify that Android™ Device Manager can locate your device after you activate the service, go to www.android.com/devicemanager and sign in using your Google™ account.

This is an Internet version of this publication. © Print only for private use.

Learning the basics

Using the touchscreen

Tapping

•Open or select an item.

•Mark or unmark a checkbox or option.

•Enter text using the on-screen keyboard.

Touching and holding

•Move an item.

•Activate an item-specific menu.

•Activate selection mode, for example, to select several items from a list.

Pinching and spreading

•Zoom in or out on web pages, photos and maps, and when you’re taking photos or shooting videos.

This is an Internet version of this publication. © Print only for private use.

Swiping

•Scroll up or down a list.

•Scroll left or right, for example, between Home screen panes.

Flicking

•Scroll quickly, for example, in a list or on a web page. You can stop the scrolling movement by tapping the screen.

Locking and unlocking the screen

When your device is on and left idle for a set period of time, the screen darkens to save battery power and locks automatically. This lock prevents unwanted actions on the touchscreen when you are not using it. When you buy your device, a basic screen swipe lock is already set. This means that you have to swipe left or upwards on the screen to unlock it. You can change the security settings later and add other kinds of locks. See Screen lock on page 11.

To activate the screen

•Briefly press the power key .

This is an Internet version of this publication. © Print only for private use.

To lock the screen

•When the screen is active, briefly press the power key .

Home screen

The Home screen is the starting point for using your device. It's similar to the desktop on a computer screen. Your Home screen can have up to seven panes, which extend beyond the regular screen display width. The number of Home screen panes is represented by a series of dots at the lower part of the Home screen. The highlighted dot shows the pane that you are currently in.

1Introduction to Xperia™ widget — Tap to open the widget and select a task such as copying content from your old device or setting up Xperia™ services

2Dots — Represents the number of Home screen panes

To go to the Home screen

•Press .

To browse the Home screen

Home screen panes

You can add new panes to your Home screen (up to a maximum of seven panes) and delete panes. You can also set the pane that you want to use as the main Home screen pane.

This is an Internet version of this publication. © Print only for private use.

To set a pane as the main Home screen pane

1Touch and hold any area on your Home screen until the device vibrates.

2Flick left or right to browse to the pane that you want to set as your main Home screen pane, then tap in the top left corner of the screen.

To add a pane to your Home screen

1Touch and hold any area on your Home screen until the device vibrates.

2To browse the panes, flick all the way to the right or left, then tap .

To delete a pane from your Home screen

1Touch and hold any area on your Home screen until the device vibrates.

2Flick left or right to browse to the pane that you want to delete, then tap on the top right corner of the pane.

Home screen settings

To uninstall an application from the Home screen

1Touch and hold any area on your Home screen until the device vibrates.

2Flick left or right to browse the panes. All uninstallable applications are

3	indicated by .
3	Tap the application that you want to uninstall, then tap Delete.
	To adjust the size of icons on your Home screen
1	Touch and hold any area on your Home screen until the device vibrates, then
2	tap .
2	Tap Icon size, then select an option.

Application screen

The Application screen, which you open from the Home screen, contains the applications that come pre-installed on your device as well as applications that you download.

	To view all applications on the Application screen
1	From your Home screen, tap .
2	Flick left or right on the Application screen.
	To open an application from the Application screen
•	When the Application screen is open, flick left or right to find the application,

and then tap the application.

To search for an application from the Application screen

1When the Application screen is open, tap Search applications.

2Enter the name of the application that you want to search for.

This is an Internet version of this publication. © Print only for private use.

To add an application shortcut to the Home screen

1On the Application screen, touch and hold an application icon until it becomes selected, then drag the icon to the top of the screen. The Home screen opens.

2Drag the icon to the desired location on the Home screen, then release your finger.

To uninstall an application from the Application screen

1 Touch and hold any area on the Application screen until the device vibrates. All

applications that can be uninstalled are then indicated by .

2 Select the application that you want to uninstall, then tap Delete.

To arrange applications on the Application screen

1When the Application screen is open, tap .

2Tap Sort apps, then select an option.

To move an application on the Application screen

1When the Application screen is open, tap .

2Make sure that Own order is selected under Sort apps.

3Touch and hold the application until it becomes selected, then drag it to the new location.

Navigating applications

You can navigate between applications using the navigation keys, the favourites bar, and the recently used applications window, which lets you switch easily between all recently used applications. The navigation keys are the Home key, the Recent apps key and the Back key. Some applications get closed when you press the Home key

to exit while others are paused or continue to run in the background. If an application is paused or running in the background, you can continue where you left off the next time you open the application.

1Recently used applications window – Open a recently used application

2 Recent apps key – Open the recently used applications window and the favourites bar

3Home key – Exit an application and go back to the Home screen

4Back key – Go back to the previous screen within an application or close the application

To open the recently used applications window

•Press .

To close all the recently used applications

•Tap and then tap .

To open a menu in an application

•While using the application, press .

A menu is not available in all applications.

Widgets

Widgets are small applications that you can use directly on your Home screen. They also function as shortcuts. For example, the Weather widget allows you to see basic weather information directly on your Home screen. But when you tap the widget, the full Weather application opens. You can download additional widgets from Google

Play™.

To add a widget to the Home screen

1Touch and hold an empty area on your Home screen until the device vibrates, then tap Widgets.

2Find and tap the widget that you want to add.

To resize a widget

1Touch and hold a widget until the device vibrates, then release it. If the widget can be resized, for example, the Calendar widget, then a highlighted frame and resizing dots appear.

2Drag the dots inward or outward to shrink or expand the widget.

3To confirm the new size of the widget, tap anywhere on the Home screen.

To move a widget

•Touch and hold the widget until the device vibrates, then drag it to the new location.

To remove a widget

•Touch and hold the widget until the device vibrates, then drag it to Remove from Home screen.

Shortcuts and folders

Use shortcuts and folders to manage your applications and keep your Home screen tidy.

1 Access an application using a shortcut

2Access a folder containing applications

To add an application shortcut to your Home screen

1Touch and hold an empty area on your Home screen.

2In the customisation menu, tap Widgets > Apps.

3Scroll through the list of applications and select an application. The selected application gets added to the Home screen.

In step 3, alternatively, you can tap Widgets > Shortcuts and then select an application from the list available. If you use this method to add shortcuts, some of the applications available allow you to add specific functionality to the shortcut.

To move an item on the Home screen

•Touch and hold the item until it becomes selected, then drag the item to the new location.

To remove an item from the Home screen

•Touch and hold the item until the device vibrates, then drag the item to

Remove from Home screen on the top of the screen.

To create a folder on the Home screen

•Touch and hold an application icon or a shortcut until the device vibrates, then drag and drop it on top of another application icon or shortcut.

To add items to a folder on the Home screen

•Touch and hold an item until the device vibrates, then drag the item to the folder.

To rename a folder on the Home screen

1Tap the folder to open it.

2Tap the folder's title bar to show the Folder name field.

3Enter the new folder name and tap Done.

Background and themes

You can adapt the Home screen to your own style using wallpapers and different themes.

To change your Home screen wallpaper

1Touch and hold an empty area on your Home screen until the device vibrates.

2Tap Wallpapers and select an option.

To set a theme

1Touch and hold an empty area on your Home screen until the device vibrates.

2Tap Themes.

3Select an option and follow the instructions in your device.

When you change a theme, the background also changes in some applications.

Battery and power management

Your device has an embedded battery. You can keep track of your battery

consumption and see how much power applications are using. You can remove apps and activate Battery saver to get more out of your battery. You can also view an

estimate of how much battery time is left and adjust your settings to improve performance and make your battery last longer.

To view your battery consumption and estimated battery time 1 From your Home screen, tap .

2Find and tap Settings > Battery usage. An overview appears showing battery usage data and an estimated battery time.

3Review the information, then proceed as required, for example, uninstall an application or restrict its usage.

To view how much battery power applications use 1 From your Home screen, tap .

2Find and tap Settings > Apps.

3Select an application and review its battery consumption under Battery usage.

Doze and App Standby

Doze and App Standby are powerful and convenient built-in modes which improve your battery life significantly by reducing battery consumption when you are not using the device or certain apps.

Doze

Doze suspends battery draining network activities, such as location services, syncing and Wi-Fi® scanning in the background when you have not been using your device for a long time.

Phone calls and SMS messaging are not affected.

Doze is activated when all of the following conditions are met:

•Your device’s screen is off,

•Your device is not charging,

•You have not used your device for more than 1 hour.

Doze is cancelled when you resume using the device. The mode is also paused periodically when the device is being updated.

This feature is enabled by default and is recommended for best performance. However, if you wish to make exceptions for certain applications, see To make specific applications exempt from optimisation on page 28.

App Standby

App Standby suspends the network activity of unused applications in the background, thus preserving battery life for the activities that are important to you.

Phone calls and SMS messaging are not affected.

App Standby marks an app as idle if:

•The app has not been used for more than 2 days.

•The app has not shown a notification for more than 12 hours.

To make specific applications exempt from optimisation

You can make applications exempt from being optimised by Doze and App Standby.

1 From your Home screen, tap .

2Find and tap Settings > Battery usage.

3Tap the and select Battery optimisation. You will see a list of applications that are not optimised.

4To add or remove applications from this list, tap Not optimised > All apps and select an application from the list to edit its optimisation settings.

5The list of applications that are not optimised will get updated according to your settings. These settings are valid for both Doze and App Standby.

You can also configure Battery optimisation from the Apps menu by tapping .

Battery saver

Battery saver is a powerful feature to improve battery life by reducing battery draining services, like vibration, location services and most background data. You can turn it

on manually, or set it to turn on automatically when a certain battery level percentage is reached. Battery saver turns off when your device is charging.

To turn on/off Battery saver

1 From your Home screen, tap .

2Find and tap Settings > Battery usage.

3Tap the and select Battery saver.

4Tap the on-off switch to turn it on/off. appears in the status bar when this mode is active.

To set it to turn on automatically just tap Turn on automatically and select the preferred option.

Taking a screenshot

You can capture still images of any screen on your device as a screenshot.

Screenshots you take are automatically saved in Album.

To take a screenshot

1Press and hold down the power key until a prompt window appears.

2Tap .

You can also take a screenshot by pressing and holding the power key and volume down key at the same time. Once the screenshot is captured, you can release the keys.

To view your screenshot

•Drag the status bar fully downwards, then tap the screenshot you want to view.

You can also view your screenshots by opening the Album application.

Notifications

Notifications inform you of events such as new messages and calendar notifications as well as activities in progress such as file downloads. Notifications appear in the following places:

•The status bar

•The Notification panel

•The lock screen

To open or close the Notification panel

1To open the Notification panel, drag the status bar downwards.

2To close the Notification panel, drag the panel upwards.

To take action on a notification in the Notification panel

•Tap the notification.

To dismiss a notification from the Notification panel

•Place your finger on a notification and flick left or right.

To expand a notification on the Notification panel

•Drag the notification downwards.

Not all notifications are expandable.

To clear all notifications from the Notification panel

•Tap .

To take action on a notification from the lock screen

•Double-tap the notification.

To dismiss a notification from the lock screen

•Place your finger on the notification and flick left or right.

To expand a notification on the lock screen

•Drag the notification downwards.

Not all notifications are expandable.

Managing notifications on the lock screen

You can set up your device so that only selected notifications get displayed on your lock screen. You can make all notifications and their content accessible, hide sensitive content for all notifications or specific apps, or choose not to show any notifications at all.

To select the notifications to display on the lock screen 1 From your Home screen, tap .

2Find and tap Settings > Sound & notification > When device is locked.

3Select an option.

Notification display options on the lock screen

Show all notification Get all notifications on the lock screen. When you have this setting turned on, keep content in mind that all content (including the content of incoming emails and chats) will be

visible on your lock screen unless you designate the relevant apps as Hide sensitive content in the App notifications settings menu.

Hide sensitive	You must have a PIN, password, or pattern set up as your screen lock in order for
notification content	this setting to be available. Contents hidden is displayed on the lock screen when
	sensitive notifications arrive. For example, you'll get a notification for an incoming
	email or chat, but the content won't be visible on your lock screen.
Don't show	You won't get any notifications on the lock screen.
notifications at all

Setting the notification level for an app

You can set different notification behaviour for individual applications. For example, you can block all email notifications, prioritise Facebook™ notifications and make the content of messaging notifications invisible on the lock screen.

To set the notification level for an app 1 From your Home screen, tap .

2Find and tap Settings > Sound & notification > App notifications.

3Select the app for which you want to change the notification settings.

4Drag the relevant slider to the right.

Notification levels and options for specific applications

Block all	Never show notifications for the selected app.
Treat as priority	Receive the selected app’s notifications when Do not disturb is set to Priority only.
Allow peeking	Let the selected app emphasise certain notifications by sliding them briefly into view on
	the current screen.

Notification light

The notification light informs you about battery status and some other events. For example, a flashing white light means there is a new message or a missed call. The notification light is enabled by default but can be disabled manually.

When the notification light is disabled, it only lights up when there is a battery status warning, for example, when the battery level goes below 15 percent.

+ 91 hidden pages

Sony PM0960 User Manual

Contents

Getting started

About this User guide

Overview

Assembly

Screen protection

Starting your device for the first time

Charging your device

Device security

Making sure your device is protected

Screen lock

Unlocking your device automatically

SIM card protection

Finding the identification number of your device

Finding a lost device

Learning the basics

Using the touchscreen

Locking and unlocking the screen

Home screen

Application screen

Navigating applications

Widgets

Shortcuts and folders

Background and themes

Battery and power management

Taking a screenshot

Notifications
