Sony PM-0460, PM-0450 User Guide
Startup guide
Xperia™C6902/C6903/C6906
Sony Mobile Communications AB
SE-221 88 Lund, Sweden
www.sonymobile.com
1274-4566.1
Welcome
Important Information
Before you use your device, please read the Important Information provided in your device regarding warranty, safety and handling information.
Assembly
To insert the memory card
Do not insert a micro SIM card into the memory card slot.
The memory card may not be included at purchase in
all markets.
To insert the micro SIM card
Do not insert a memory card into the micro SIM card slot.
3
2
1
4
5
Inserting the micro SIM card into the device without the SIM card holder could damage your micro SIM card or your device, and Sony Mobile does not warrant and will not be responsible for any damage caused by such action.
To view the CE mark and the FCC ID
1
3 |
1Detach the cover of the micro SIM card slot.
2Place a fingernail under the right or left edge of the label tray, then drag the tray outwards to view the CE mark and the FCC ID.
Protecting your device from water and dust
<1.5m
Swimming pool Diving Sand/mud
Salt water |
Other liquid |
|
chemicals |
Your device has IP (Ingress Protection) ratings of IP5X, IPX5 and IPX8. These ratings mean that your device is dust resistant and is protected against low pressure water stream as well as against the effects of submersion for 30 minutes in fresh (non-saline) water up to 1.5 metres deep.
Always firmly attach all covers to ensure the water and dust resistance of the device. If liquid is detected inside the device, for example, underneath one of the covers, your warranty will be void.
If the speaker, microphone or headset jack get wet, dry these areas and wait for three hours before using them again. You can, however, use other features in the device that do not utilise the speaker or microphone.
Before using your device in water and in dusty conditions, refer to the relevant section of the User guide for your device for more detailed information. An online User guide as well as a downloadable version is available at www.sonymobile.com/support.
Basics
Overview
1 |
2 |
3 |
4 |
|
|
|
5 |
|
|
|
6 |
|
|
|
7 |
|
|
|
8 |
|
|
|
9 |
|
|
10 |
|
11 12 |
|
13 |
14 |
|
|
|
15 |
|
|
|
16 |
|
|
|
17 |
1. |
Headset jack |
10. |
Main speaker and |
2. |
Proximity sensor/Light |
microphone |
|
sensor |
11. |
Main camera lens |
|
3. |
Ear receiver/Charging |
12. |
Camera light |
light/Notification light |
13. |
Second microphone |
|
4. |
Front camera lens |
14. |
NFC™ detection area |
5. |
Micro SIM card slot |
15. |
Memory card slot cover |
cover |
16. |
Charger/USB cable port |
|
6. |
Power key |
cover |
|
7. |
Volume/Zoom key |
17. |
Charging dock connector |
8.Camera key
9.Strap hole
Do not insert fingers or other objects into the opening for the ear speaker (illustrated in item 14 above) to avoid damaging your device.
Turning on the device
To turn on the device
Make sure that the battery is charged for at least 30 minutes before you turn on the device for the first time.
1 Press and hold down the power key
until the device vibrates.
2 Wait a while for the device to start.
Waking up the screen
To activate the screen
•Briefly press the power key
.
To unlock the screen
•Swipe up or down on the lower part of the screen.
Setting up your device
What is Android™?
Android is your device's operating system. Since Android is developed by Google™, your device is preloaded with several Google™ services, such as Google Maps™ and Google™ web search. To use some of the services provided by Google™, you need a Google account.
Google™ account
With a Google™ account, you can use Gmail™ to send emails, Google Talk™ to chat with friends, and Google Play™ to download applications and games, music, movies and books.
To set up a Google™ account on your device
1 From your Home screen, tap .
2Find and tap Settings > Add account > Google.
3Follow the registration wizard to create a Google™ account, or sign in if you already have an account.
You can also sign in to or create a Google™ account
from the setup guide the first time you start your device. Or you can go online and create an account at www.google.com/accounts.
Basic settings
The first time you start your device, a setup guide explains basic device functions and helps you enter essential settings. You can also access the setup guide later.
To access the setup guide manually
1 |
From the Home screen, tap . |
2 |
Tap Settings > Setup guide. |
Transferring contacts to your new device
Transferring contacts to your new device can sometimes be complicated, but help is available.
You can transfer contacts from several device brands, including iPhone, Samsung, HTC and Nokia.
You need:
•An Internet-connected PC or Apple® Mac® computer.
•A USB cable for your old device.
•A USB cable for your new Android™ device.
•Your old device and new Android™ device.
Get started transferring your contacts
If you are a PC user, use the PC Companion program to transfer your contacts. It's free, and the installation files are already saved on your new device. PC Companion also offers a range of other features, including help to update your device software. For Apple® Mac® computer users, the Sony™ Bridge for Mac application is available to help you transfer your contacts. It's also free and downloadable from www.sonymobile.com/support.
To install PC Companion
1New device: Turn on your new Android™ device and connect it to a PC using a USB cable.
2New device: Tap Install to install PC Companion on the PC.
3Computer: If a popup window appears to notify you about available PC software, select Run Startme.exe.
4Computer: Click Install to start the installation and then follow the instructions to complete the installation.
To transfer contacts to your new device using PC Companion
1Make sure that PC Companion is installed on your PC.
2Open the PC Companion program on the PC, then click Contacts Setup and follow the instructions to transfer your contacts.
To install Sony™ Bridge for Mac
1Using your Apple Mac computer, go to www.sonymobile.com/support, then search for and download the Sony™ Bridge for Mac application to a folder on the computer.
2After the download is complete, open the folder and double-click the Sony Bridge for Mac.dmg file to start the installation.
3Follow the instructions on your Apple® Mac® computer to complete the installation.
To transfer contacts to your new device using Sony™ Bridge for Mac
1Make sure the Sony™ Bridge for Mac application is installed on your Apple® Mac® computer.
2Open the Sony™ Bridge for Mac application on your Apple® Mac® computer.
3Double-click the Sony™ Bridge for Mac icon in the Applications folder, then follow the instructions to transfer your contacts.
Finding your way
Home screen
The Home screen is your gateway to the main features on your device. You can customise your Home screen with applications, widgets, shortcuts, folders, themes, and wallpaper.
The Home screen extends beyond the regular screen display width, so you need to flick left or right to view content in all of the Home screen's panes.
The items in the bar at the bottom of the screen are
always available for quick access.
To go to the Home screen
• Press
.
Application screen
The Application screen, which you open from your Home screen, contains the applications that come pre-installed on your device as well as the applications you download.
The Application screen extends beyond the regular screen width, so you need to flick left and right to view all content.
To open the Application screen
• From your Home screen, tap
.
To open an application
•From your Home screen or the Application screen, tap the application.
Status and notifications
The status bar at the top of your screen shows what's going on in your device. For example, new message and calendar notifications appear here.
Checking notifications and ongoing activities
You can drag down the status bar to open the Notification panel and get more information. For example, you can use the panel to open a new message or view a calendar event. You can also open some applications that run in the background, such as the music player.
To open the Notification panel
• Drag the status bar downwards.
Using the keys
Back
•Go back to the previous screen
•Close the on-screen keypad, a dialog box, an options menu, the Notification panel, or an application
Home
• Go to the Home screen
Task
•Tap to open a window showing your most recently used applications and a small apps bar
More basics
Calling
To make a call by dialling
1 From your Home screen, tap .
2Find and tap Phone.
3Enter the number of the recipient and tap Call. To delete a number, tap
.
To end a call
• Tap
.
To answer a call
• Drag
to the right across the screen.
Multimedia and text messaging
To create and send a message
1 |
From your Home screen, tap , then find and tap |
. |
2 |
Tap . |
|
3Tap
, then tap Add recipient and select a contact from the Contacts list. If the recipient is not listed as a contact, enter the recipient's number manually and tap
.
4When you are finished adding recipients, tap Done.
5Tap Write message and enter your message text.
6 |
If you want to add a media file, tap |
and select an |
|
option. |
|
7 |
To send the message, tap Send. |
|
Settings menu
View and change settings for your device from the Settings menu.
To access your device settings
1 |
From your Home screen, tap . |
|
2 |
Tap Settings. |
|
|
You can also drag the status bar downwards on the |
|
|
Home screen and tap |
to access your device |
|
settings. |
|
Troubleshooting
My device is not responding
If your device hangs, or if you cannot restart it normally, you can force the device to shut down.
To force the device to shut down
2
1
1Detach the cover of the micro SIM card slot.
2Using the tip of a pen or a similar object, press and hold down the OFF button until the device shuts down.
Do not use overly sharp objects that could damage the OFF button.
The device does not recognise my wired headset
•Make sure the wired headset that you are using complies to the CTIA standard. Your device supports the CTIA standard, and may not be fully compatible with other standards such as OMTP.
•If you have a wireless headset that is compatible with your device, try using that instead.
Legal information
Sony C6902/C6903/C6906
Google Play™ is not available in all countries. Some of the services and features described in this Startup guide are not supported in all countries/regions or by all networks and/or service providers in all areas. Without limitation, this applies to the GSM International Emergency Number 112. Please contact your network operator or service provider to determine availability of any specific service or feature and whether additional access or usage fees apply.
This Startup guide is published by Sony Mobile Communications AB or its local affiliated company, without any warranty. Improvements and changes to this Startup guide necessitated by typographical errors, inaccuracies of current information, or improvements to programs and/or equipment, may be made by Sony Mobile Communications AB at any time and without notice. Such changes will, however, be incorporated into new editions of this Startup guide.
© 2013 Sony Mobile Communications AB. All rights reserved. Publication number: 1274-4566.1
Your device has the capability to download, store and forward additional content, e.g. ringtones. The use of such content may be restricted or prohibited by rights of third parties, including but not limited to restriction under applicable copyright laws. You, and not Sony, are entirely responsible for additional content that you download to or forward from your device. Prior to your use of any additional content, please verify that your intended use is properly licensed or is otherwise authorized. Sony does not guarantee the accuracy, integrity or quality of any additional content or any other third party content. Under no circumstances will Sony be liable in any way for your improper use of additional content or other third party content.
This Startup guide may reference services or applications provided by third parties. Use of such programming or services may require separate registration with the third party provider and may be subject to additional terms of use. For applications accessed on or through a third-party website, please review such websites’ terms of use and applicable privacy policy in advance. Sony does not warrant or guarantee the availability or performance of any third-party websites or offered services.
See regulatory information such as the CE mark in the label tray of the device.
All product and company names mentioned herein are the trademarks or registered trademarks of their respective owners. Any rights not expressly granted herein are reserved. All other trademarks are property of their respective owners.
Visit www.sonymobile.com for more information.
All illustrations are for illustration only and may not accurately depict the actual device.
This product is protected by certain intellectual property rights of Microsoft. Use or distribution of such technology outside of this product is prohibited without a license from Microsoft.
Product compliance: This product has been manufactured by or on behalf of Sony Mobile Communications, Mobilvägen, SE-221 88 Lund, Sweden. Inquiries related to product compliance based on national legislation shall be addressed to Sony Mobile Quality Officer, Sony Mobile Communications AB, Mobilvägen, SE-221 88 Lund, Sweden. For any service or guarantee matters, please refer to the contact details provided in the separate service or guarantee documents.
Our support to you – Xperia™ Care
User guide
A User guide for your device is available at
www.sonymobile.com/support.
Support in your device
Get user support directly in your device using the Support application.
To access the Support application
1From your Application screen, find and tap
.
2Find and tap the required support item.
Support on the web
Visit www.sonymobile.com/support to access a range of support and get the most from your device.
Customer support
Customer support – if all else fails. Access the relevant support number at www.sonymobile.com by clicking the Contact us link at the bottom of the page.
Learn more
Learn more about how we can support you with Xperia™ Care at www.sonymobile.com/support.
